GPS Tracker
TRKM110
Manufacture: Trackimo INC.
Pack contents / productparts ................................................... 25
General information ................................................................ 26
Keytosymbols ................................................................................. 26
Properus e........................................................................... 28
Safety ................................................................................ 28
Initial set-up ............................................................................. 32
Checking thepackcontents ............................................................. 32
Installing and chargingthebattery.................................................... 32
Turning thetrackeron ...................................................................... 33
Activatingthetracker ........................................................................ 33
Installingtheapp .............................................................................. 33
Functions ........................................................................... 34
Checkingtheconnection .................................................................. 34
Buttonfunctions ............................................................................... 34
Geofencing ..................................................................................... 34
Speedalert ...................................................................................... 35
Movementalert ................................................................................ 35
Lowbatteryalert ............................................................................... 36
Lightsensor ..................................................................................... 36
GPS signalandreception ................................................................. 36
Light andsoundmeanings ............................................................... 38
Cleaning ............................................................................. 39
Storage .............................................................................. 39
Technicaldata ..................................................................... 40
DeclarationofConformity ..................................................... 41
Disposal ............................................................................. 41
Disposing ofthepackaging ...............................................................41
Disposing ofthetracker .....................................................................41
Pack contents / product parts
1
On/offbutton
2
Lightsensor
3
Magnetic chargingport
4
Redlight
5
Bluelight
6
Greenlight
7
Chargingcable
8
Lanyard withclip
General information
These operating
instructions are for the
TrackimoTravel3GGPS
be referred to as „tracker‟ in the
following. They contain important
information regarding set-up and
operation. Before using the tracker,
pleasereadtheoperatinginstructions
carefully. This particularly applies to
thesafetynotes.Failuretoadhereto
these operating instructions may
resultinsevereinjuryordamageto
thetracker.
The operating instructions are
basedonthestandardsandrulesin
forceintheEuropeanUnion.When
abroad, you must also observe
country-specific guidelines and
laws.
Tracker,whichwillsimply
Keep the operating instructions for
futureuse.Ifyoupassthetrackeron to
third parties, please be absolutely
sure to include these operating
instructions.
Key to symbols
Declaration of Conformity
(see “Declaration of
Conformity” chapter):
Products marked with this
symbol conform with all
applicable Community
provisions in effect in the
European Economic Area.
Products marked with
this symbol conform with
Protection Class II.
.
Signal words
Thefollowingsignalwordsareused
intheseoperatinginstructions:
Thissignalwordindicatesahazard
withamoderatedegreeofriskthat
mayleadtodeathorsevereinjuryif it
is notavoided.
Thissignalwordwarnsagainst
potential damage toproperty.
WARNING!
NOTICE!
Proper use
The tracker is suitable for locating
an item or living being.
Only use the tracker as described
intheseoperatinginstructions.Any
otheruseisdeemedimproperand
mayresultindamagetopropertyor
even personal injury. The tracker is
not a children‟stoy.
The manufacturer and vendor do
not accept any liability for damage
caused by improper or incorrect
use.
Trackimo is a GPS tracking device
that allows tracking and finding
valuables and sending smart alerts.
Trackimo system was designed to
be user friendly. At any given
moment you can check where your
things have been and where they are
now. No matter what you are travelling
with, you and your luggage will be safe
on the road!
Safety
WARNING!
Electric shock hazard!
Incorrect electrical
installation or
usingamainsvoltagethatistoo
high
canresultinanelectricshock.
−
Only connect the tracker
and the charging cable if
the mains voltage of the
power socket
matchesthatstatedonthel
abel.
−
Only connect the mains
adaptortoaneasilyacces
sible power socket so
that the charging cable
can be quickly disconnected
from the mains supply if
itmalfunctions.
−
Donotusethetrackerifthere
are visible signs of damage
or if the charging cable is
defective.
−
If the charging cable is
damaged, it must be replaced
by the manufacturer, the
manufacturer‟s service
department or a similarly
qualified person in order to
avoidrisk.
−
Only charge the batterywith
the charging cablesupplied.
−
Donotopenthetrackercasing.
Instead, ensure any repairs
are carried out by specialists.
Contact a specialistworkshop.
Warrantyandguaranteeclaims
cannotbemadeifrepairshave
been carried out independently,
or if the tracker has been
incorrectly connected or
operated.
−
Only parts that correspond
with the original device‟sdata
can be used in repairs. This
tracker containselectronic
and mechanical parts that are
essential for protecting against
potential hazards.
−
Do not submerge the charging
cableorthetrackerinwateror
otherliquids.
−
Keep the tracker and all
accessories away from open
flames and hotsurfaces.
−
Do not kink the charging cable
and do not place it over sharp
edges.
−
−
Only use the charging
cableindoors.Neveruse
the charging cable in places
wherethereisahighlevel of
humidity, or in therain.
Ensure that children do notput
objects into thetracker.
WARNING!
Explosion and fire hazard!
Improperuseofthebatteryincreases
theriskofexplosionandfire.
−
Protectthetrackerfrom
mechanicaldamage.
−
Do not expose the battery to
excessive heat such as direct
sunlight,fire,etc.Theambientair
temperature should not exceed
60°Corfallbelow-20°C.
−
Onlyuseoriginalaccessories
forcharging.
−
Always store the tracker
inadryspaceattheright
temperature.
−
Do not try to remove the
batteryfromthetrackerusing
spikes or sharpobjects.
−
Do not drop the tracker and
do not dismantle or modify the
tracker.
−
Do not transport or store the
tracker with metalobjects.
−
Do not dismantle or modify the
tracker.
−
Donotusethetrackerwhere
therearestrongelectrostatic
fields.
WARNING!
Danger! Acid-burn risk!
Damaged batteries that leak can
causeburnsiftheycomeintocontact
with theskin.
−
−
Never open thebattery.
Alwayswearprotectivegloves
if a battery isleaking.
WARNING!
Dangers to children and
persons with reduced
physical, sensory ormental
abilities (for example
partially disabled people,
older persons with
limitations to physical or
mental abilities) or those
with less experience and
knowledge (for example
older children).
− The tracker is not a children‟s
toy. If you give your child the
tracker to take with them, you
must comprehensivelyexplain
the dangers to them and
explain how to operate the
tracker.
−
Do not allow children to play
with packaging film. Children
may get caught in it when
playing andsuffocate.
−
Do not allow children to play
with small parts. They could
swallow these andchoke.
Initial set-up
Checking the pack contents
NOTE
Risk of damage!
Ifyoucarelesslyopenthepackaging
with a sharp knife or another sharp
object, the tracker can quickly
becomedamaged.
− Be very careful when opening
the packaging.
1.
Takeeachindividualpartoutof
thepackaging.
2.
Checkwhethereverythinghas
beendelivered.
3.
Check whether individual parts
showanysignsofdamage.Ifthis
isthecase,donotusethetracker.
Contact themanufacturer.
Installing and charging the
battery
When you unpack the tracker for
the first time, the battery is empty.
Charge it as follows:
1.
Connectthechargingplugofthe
chargingcabletothetrackerwith
the magnetic chargingport.
2.
Connect the other end of the
chargingcabletotheUSBpower
adaptor and then to the power
socket.Alternatively,youcanalso
connect the charging cable to a
computer.
3.
Chargethetrackerfor12hours.
The red light will blink whilst
charging. When the tracker is fully
charged, the light will turn solid red.
4.
Disconnectthetrackerfromthe
chargingcable.
Turning the tracker on
1.
Takethetrackeroutsidesothatit
isintheopenair.
2.
Pressandholdtheon/offbutton
foratleast3seconds.
Thegreenlightonthefrontwillstart
toflash.
3.
Putthetrackerdownandwaitfor at
least 15minutes.
ThetrackerwillcarryoutinitialGPS
positioning.Thisisrequiredforthe
device to function correctly. The
tracker will then be ready for use
and can beactivated.
Activating the tracker
1.
OpenyourInternetbrowserand
go to the following
website:www.trackimo.eu
2.
Select yourlanguage.
3.
Clickon„Activate‟,createanac-
countandfollowtheon-screen
instructions.
Youcanalsoactivatethetrackerwith
theapp.Todoso,proceedasfollows:
4.
Downloadtheapp(seethechap-
ter “Installing theapp”).
5.
Clickon“Register”andfollowthe
instructionsthereforregistering,
or log into your account if you
already haveone.
6.
Select “Activate device” in the
operationmenuandfollowthe
instructions.
Installing the app
Download the trackimo app free of
charge via the Google Playstore or
the Apple Store and install this on
your smartphone. Then log into the
account you created on the website.
Functions
Checking the connection
Press the on/off button to check
whetherthetrackerisonoroff.Ifat
leastonelightcomeson,thetracker is
on. If no light comes on, the
tracker isoff.
Note:
usingtheOFFsettinginyourapp‟s
menu or on the tracking interval
homepage. The device doesn‟t
have to be turned off. Charge the
batteryfromtimetotime,butatthe
latestwhenyoureceiveamessage
notifyingyouthatthebatterylevelis
at10%.Assoonasthebatterylevel
islow,theredlightwillstarttoblink.
You can save battery life by
Button functions
On/off button:
Press and hold the on/off button
to turn the tracker on or off.
Briefly press the on/off button
once to check whether the
tracker is on.
Geofencing
A geofence is a self-defined
virtualboundary.Youwillreceivea
notificationassoonasthetracker
leaves this area or goes into this area.
1.
Selectthetrackeronthetrackimo
homepageorinyourapp.
2.
Click on“Barriers”.
3.
Clickonthe“Createanewbarrier”
button.
A pink rectangular fence will be
created around your device‟s
current location (or in the centreof
the map).
−
−
−
4.
5.
Youcanalsoenteranaddress
to position afence.
You can choose apre-defined
size.
You can change the size
by making the sides ofthe
rectangle bigger or smaller, or
by moving the rectangle.
Onceyourfencehasbeencreated,
you can give your geofence a
nameandclickon“Save”.
Now you can enter additional
telephone numbers (for SMS
notifications) or e-mail addresses
fornotifications.
Speed alert
You will receive a notification as
soon as the tracker moves faster
than the speed pre-defined by you.
1.
Selectthetrackeronthetrackimo
homepageorinyourapp.
2.
Go to“Settings”.
3.
Enter aspeed.
4.
Addacontactwhererequired.
5.
Click on“Save”.
Movement alert
You will receive a notification as
soonasthetrackerstartstomove.
1.
Selectthetrackeronthetrackimo
homepageorinyourapp.
2.
Go to“Settings”.
3.
Setthemovementalertfunction
to“On”.
4.
Addacontactwhererequired.
5.
Click on“Save”.
Low battery alert
You will receive a notification when
the tracker battery level is low.
1.
Selectthetrackeronthetrackimo
homepageorinyourapp.
2.
Go to“Settings”.
3.
Setthe“Lowbatteryalert”
function to“On”.
4.
Addacontactwhererequired.
5.
Click on“Save”.
Light sensor
The tracker has a light sensor. It
registersstronglightchangessuch
as an abrupt change of light from
dark to bright. If such a change of
light is registered, the tracker will
automaticallysendanotificationto
your registered e-mail address or,
ifyouhavespecifiedatelephone
number, a text message will be sent
to this number.
GPSsignal and reception
ThetrackerusesGPS(GlobalPositioningSystem)technologytocalculateitscurrentlocation.Itreceives
signalsfromGPSsatellitesinspace.
TheseGPSsignalscanbereceived
when the device is used outdoors
or in avehicle.
TheGPSsignalisblocked,however,
whenthetrackerislocatedinside
a building or under a concrete
roof. The signal may be blocked
or diverted even if the tracker is
placed near a window. In such
cases the device will use an
alternative method to calculate
its position. The position is determined through identification of
a nearby 2.4G router or mobile
communications antenna. This is
less precise than GPS data, and
may be hundreds of metres from
the tracker. If the device is using a
cell-based location (also known as
“GSM-based location”), you will be
able to tell by a semi-transparent
blue circle over the location.
Action
Light Sound
Press the on/off
button and hold
Green light lights up, then blinks
twice; the tracker starts up
Short beep
sound
Press the on/off
button and hold
Green light turns on and red
lightflashes;thetrackerturnsoff
No sound
Press the on/off
button quickly
Green light turns on briefly
No sound
Connected to the
mobile network
Blue light turns on for 4 seconds
Long beep
sound
Low battery
Red light blinks
No sound
Battery is charging
Red light blinks slowly
No sound
Connected to a power
source and battery is
fully charged
Red light solidly lit up
No sound
Not connected to
mobile network or GPS
Blue light blinks slowly
Short beep
sound
Light and sound meanings
Cleaning
Improperhandlingofthetrackermay
result indamage.
−
−
−
NOTE
Risk of damage!
Do not use any abrasive cleaning agents, brushes with metal
or nylon bristles or any sharp
or metallic cleaning materials
such as knives, metal scouring
pads, etc. These could damage
surfaces.
Never submerge the tracker in
wateranddonotuseanysteam
cleaners when cleaning. This
can damage thetracker.
Never put the tracker in the
washingmachine.Thiswould
destroyit.
1.
Wipesurfaceswithaslightly
dampcloth.
2.
Thenensureyoufullydryall
parts.
Storage
−
Storethetrackerinitsoriginal
packaging or a similar
cardboardbox.
−
Keepthetrackerinadryand
clean environment out of the
reach ofchildren.
Technical data
Model: TRKM110
Battery: Li-Ion, 10000mAh
Inputvoltage: 5V/2000mA
IPcode: IP68
Protectionclass:
Operating temperature: –20 to +45 °C
Batterylife: 33 to 100 days
formGSM/WCDMA: MTK2503
Position location
platformGPS: MTK2503
Frequencyband: GSMGSM850/GSM900/DCS1800/PCS1900
Wi-Fi: NO,MT5931
Bluetooth: TI CC2541BT4.0
Dimensions: 90×64×34mm
Weight: approx. 300g
Declaration of Conformity
TheNDMNetworkhereby
declaresthattheTRKM015
tracker radio equipment
model conforms with EU Directive
2014/53/EU.ThefulltextfortheEU
DeclarationofConformitycanbe
foundonthefollowingwebpage:
https://trackimo.eu/de/download/
Disposal
Disposing of the packaging
cardboard and carton as waste
paper and dispose of foils via the
recyclable material collection
service.
Dispose of the
packagingensuringthat
materials are correctly
separated.Disposeof
Disposing of the tracker
(Applicable in the EU and other
Europeancountrieswithsystems
ofseparatelycollectingwasteand
recyclables).
consumers are
to separate old devices from
household waste
disposing of them using a municipal/district collection point. This
ensures that old devices are properly recycled and avoids negative
environmental impact. This is why
electronic devices are labelledwith
the symbol shownhere.
Olddevicescannotbe
disposed of as
householdwaste!
Ifthetrackercanno
longerbeused,all
legally obligated
, e.g. by
legally obligated to dispose of all
batteries at a municipal/district
collection point or at a retailer,
regardless of whether or not they
contain harmful substances*, so
that they can be disposed of in an
environmentally friendly way.
*labelled as: Cd = cadmium,
Hg = mercury, Pb = lead
Batteries cannot be
disposed of as household waste!
As a consumer, you are
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device,pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Specific Absorption Rate (SAR) information:
This GPS Tracker meets the government's requirements for exposure to radio
waves. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies.
The standards include a substantial safety margin designed to assure the safety of all
persons regardless of age or health.
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device
types:GPS Tracker (FCC ID: 2AAI6-TRKM110) has also been tested against this
SAR limit. The highest SAR value reported under this standard during product
certification for use when properly worn on the body is 1.13 W/kg. The use of belt clips,
holsters and similar accessories should not contain metallic components in its
assembly. The use of accessories that do not satisfy these requirements may not
comply with FCC RF exposure requirements, and should be avoided
Loading...
