GPS Tracker
TRKM015-LC
Manufacture: Trackimo INC.
General information
These operating
instructions are for the
Trackimo™015-LCGPS
Tracker,which willsimply
be referred to as ‘tracker’ in the
following. They contain important
information regarding set-up and
operation. Before using the tracker,
please readthe operating instructions
carefully. This particularly applies to
thesafetynotes.Failure to adhere to
these operating instructions may
result in severeinjury or damage to
the tracker.
The operating instructions are
based on the standards and rules in
force in theEuropean Union.When
abroad, you must also observe
country-specific guidelines and
laws.
Keep the operating instructions for
futureuse. If you passthe trackeron
to third parties, please be absolutely
sure to include these operating
instructions.
Key to symbols
Declaration of Conformity
(see “Declaration of
Conformity” chapter):
Products marked with this
symbol conform with all
applicable Community
provisions in effect in the
European Economic Area.
Products marked with
this symbol conform with
Protection Class II.
The FCC logo indicates
electronic devices that
conform with FCC
provisions from the
American authority, the
FederalCommunications
Commission. The
symbol also guarantees
compatibility with
standards, suchas
those set out by the
International Organization
for Standardization
(abbreviated as ISO).
Signal words
The following signal words are used
in these operating instructions:
WARNING!
This signal word indicates a hazard
with a moderate degree of risk that
may lead to death or severe injury if
it is not avoided.
NOTICE!
Thissignal word warns against
potential damage to property.
Proper use
The tracker is suitable for locating
an item.
Only use the tracker as described
in these operating instructions. Any
other use is deemed improper and
may result in damage to propertyor
even personal injury. The tracker is
not a children’stoy.
The manufacturer and vendor do
not accept any liability for damage
caused by improper or incorrect
use.
Safety
WARNING!
Electric shock hazard!
Incorrect electrical install ation or
using a mains voltage that is too high
can result in an electric shock.
−
Only connect the tracker and
the charging cable if the mains
voltage of the power socket
matches thatstatedon thelabel.
−
Only connect the mains
adaptor to an easily accessible
power socket so that the
charging cable can be quickly
disconnected from the mains
supply if it malfunctions.
−
Do not use the tracker if there
are visible signs of damage
or if the charging cable is
defective.
−
Do not open the tracker casing.
Instead, ensure any repairs
are carried out by specialists.
Contact a specialist workshop.
Warranty and guarantee claims
cannot be made if repairs have
been carried out independently,
or if the tracker has been
incorrectly connected or
operated.
−
Only parts that correspond
with the original device’s
data can be used in repairs.
This tracker contains
electronic and mechanical
parts that are essential for
protecting against potential
hazards.
Do not submerge the tracker in
water or other liquids.
−
Keep the tracker and all
accessories away from open
flames and hot surfaces.
−
Ensure that children do not put
objects into the tracker.
WARNING!
Explosion and firehazard!
Improperuse ofthe batteryincreases
the risk of explosion and fire.
−
Protect the tracker from
mechanical damage.
−
Do not expose the battery to
excessiveheat such as direct
sunlight,fire,etc.The ambientair
temperatureshould not exceed
60 °C or fall below -20 °C.
−
Onlyuse original accessories
for charging.
−
Always store the tracker
in a dry space at the right
temperature.
−
Do not try to remove the
battery from the tracker using
spikes or sharp objects.
−
Do not drop the tracker and
do not dismantle or modify the
tracker.
−
Do not transport or store the
tracker with metal objects.
−
Do not dismantle or modify the
tracker.
−
Do not use the tracker where
there are strong electrostatic
fields.
WARNING!
Danger! Acid-burn risk!
Damaged batteries that leak can
cause burns if theycome intocontact
with the skin.
−
Never open the battery.
−
Always wear protective gloves
if a battery is leaking.
WARNING!
Dangers to childrenand
persons with reduced
physical, sensory ormental
abilities (for example
partially disabled people,
older persons with
limitations to physical or
mental abilities) or those
with less experience and
knowledge (for example
older children).
−
The tracker is not a children’s
toy. If you give your child the
tracker to take with them, you
must comprehensivelyexplain
the dangers to them and
explain how to operate the
tracker.
−
Do not allow children to play
with packaging film. Children
may get caught in it when
playing and suffocate.
−
Do not allow children to play
with small parts. They could
swallow these andchoke.
Initial set-up
Checking the pack contents
NOTE
Risk of damage!
If you carelessly open the packaging
with a sharp knife or another sharp
object, the tracke r can quickly
become damaged.
−
Be very careful when opening
the packaging.
1.
Take each individualpart out of
the packaging.
2.
Checkwhether everything has
been delivered.
3.
Check whether individual parts
show any signs of damage.If this
is the case,do notuse the tracker.
Contact the manufacturer.
Activating the tracker
1.
Open your Internet browser and
go to the following website:
www.trackimo.eu
2.
Select your language.
3.
Click on ‘Activate’, create an account and follow the on-screen
instructions.
Youcanalso activate thetrackerwith
theapp.Todo so,proceedas follows:
4.
Download the app (see the chapter “Installing theapp”).
5.
Click on “Register” and followthe
instructions there forregistering,
or log into your account if you
already have one.
6.
Select “Activate device” in the
operation menu and follow the
instructions.
Installing the app
Download the trackimo app free of
charge via the Google Playstore or
the Apple Store and install this on
your smartphone. Then log into the
account you created on the website.
Geofencing
A geofence is a selfdefined virtual boundary.
Youwill receive a
notification as soonas the
tracker
leaves this area or goes into this
area.
1.
Select the trackeron the
trackimo homepage or in
your app.
2.
Click on “Barriers”.
3.
Clickon the“Createa new
barrier” button.
A pink rectangular fence will be
created around your device’s
current location (or in the centre of
the map).
−
Youcan also enter an address
to position a fence.
−
You can choose a pre-defined
size.
−
You can change the size
by making the sides of the
rectangle bigger or smaller, or
by moving the rectangle.
4.
Onceyourfencehas beencreated,
you can give your geofence a
nameandclickon “Save”.
5.
Now you can enter additional
telephone numbers (for SMS
notifications) or e-mail addresses
for notifications.
Speed alert
You will receive a notification as
soon as the tracker moves faster
than the speed pre-defined by you.
1.
Select the trackeron the trackimo
homepage or in your app.
2.
Go to “Settings”.
3.
Enter a speed.
4.
Add a contact where required.
5.
Click on “Save”.
Movement alert
Youwill receive a notification as
soonas the tracker startsto move.
1.
Select the trackeron the trackimo
homepage or in your app.
2.
Go to “Settings”.
3.
Set the movement alertfunction
to “On”.
4.
Add a contact where required.
5.
Click on “Save”.
Low battery alert
Youwill receive a notification when
the trackerbattery level is low.
1.
Select the trackeron the trackimo
homepage or in your app.
2.
Go to “Settings”.
3.
Set the “Low battery alert”
function to “On”.
4.
Add a contact where required.
5.
Click on “Save”.
Light sensor
The tracker has a light sensor. It
registersstronglight changes such
as an abrupt change of light from
dark to bright. If such a change of
light is registered, the tracker will
automatically send a notificationto
your registered e-mail address or,
if you have specifieda telephone
number, a text message will be sent
to this number.
GPS signal and reception
The tracker uses GPS (Global Positioning System) technology to calculateitscurrent location. It receives
signalsfrom GPS satellites inspace.
TheseGPSsignals can be received
when the device is used outdoors
or in a vehicle.
TheGPS signal is blocked, however,
when the tracker is located inside
a building or under a concrete
roof. The signal may be blocked
or diverted even if the tracker is
placed near a window. In such
cases the device will use an
alternative method to calculate
its position. The position is determined through identification of
a nearby WiFi router or mobile
communications antenna. This is
less precise than GPS data, and
may be hundreds of metres from
the tracker. If the device is using a
cell-based location (also known as
“GSM-based location”), you will be
able to tell by a semi-transparent
blue circle over the location.
Cleaning
NOTE
Risk of damage!
Improper handling of the trackermay
result in damage.
−
Do not use any abrasive cleaning agents, brushes with metal
or nylon bristles or any sharp
or metallic cleaning materials
such as knives, metal scouring
pads, etc. These could damage
surfaces.
−
Never submerge the tracker in
water and do not use any steam
cleaners when cleaning. This
can damage the tracker.
−
Never put the tracker in the
washing machine. Thiswould
destroy it.
1.
Wipe surfaces with a slightly
damp cloth.
2.
Then ensure you fully dry all
parts.
Storage
−
Store the tracker in its original
packaging or a similar
cardboard box.
−
Keep the tracker in a dry and
clean environment out of the
reach of children.
Technical data
Model: TRKM015
Battery: Li-Ion, 800 mAh
Input voltage: 5 V / 500 mA
Protection class:
Operating temperature: –20 to +45°C
Battery life: 48–72hours, 144 hours (standby time)
Position location platform GSM/WCDMA: MTK6276
Position location
platform GPS: MTK3337
Frequency band: GSM GSM 850/ GSM 900/ DCS 1800/ PCS 1900
WCDMA 850/900/1900/2100
Wi-Fi: Yes,MT5931
Dimensions: 99mm x 63mm x 16mm
Weight: approx. 91 g
-LC
Declaration of Conformity
TheNDM Network hereby
declares that the
tracker radio equipment
model conforms with EU Directive
2014/53/EU.Thefull textfortheEU
Declaration of Conformity canbe
found on thefollowing webpage:
https://trackimo.eu/de/download/
Disposal
Disposing of the packaging
Dispose of the
packagingensuring that
materials are correctly
separated. Dispose of
cardboard and carton as waste
paper and dispose of foils via the
recyclable material collection
service.
Disposing of the tracker
(Applicable in the EU and other
Europeancountrieswithsystems
of separately collecting waste and
recyclables).
Old devices cannot be
disposed of as
household waste!
If thetrackercan no
longer be used, all
consumers are
legally obligated
to separate old devices from
household waste
, e.g. by
disposing of them using a municipal/district collection point. This
ensures that old devices are properly recycled and avoids negative
environmental impact. This is why
electronic devices are labelledwith
the symbol shownhere.
Batteries cannot be
disposed of as household wast e!
As a consumer, you are
legally obligated to dispose of all
batteries at a municipal/district
collection point or at a retailer,
regardless of whether or not they
contain harmful substances*, so
that they can be disposed of in an
environmentally friendly way.
*labelled as: Cd = cadmium,
Hg = mercury, Pb = lead
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device,pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Specific Absorption Rate (SAR) information:
This GPS Tracker meets the government's requirements for exposure to radio waves.
The guidelines are based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the safety of all persons
regardless of age or health.
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 2.0 W/kg averaged over one gram of tissue. Device
types:GPS Tracker (FCC ID: 2AAI6-TRKM015-LC) has also been tested against this
SAR limit. The highest SAR value reported under this standard during product
certification for use when properly worn on the body is 0.544W/kg. This device was tested
for typical body-worn operations with the back of the handset kept 10mm from the body.
To maintain compliance with FCC RF exposure requirements, use accessories that
maintain a 10mm separation distance between the user's body and the back of the
handset. The use of belt clips, holsters and similar accessories should not contain
metallic components in its assembly. The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure requirements, and should be
avoided.
Loading...
