SPECIFICATIONS
Display: ¾” digits, 1½” LCD
Range: 32 to 392°F and 0 to 200°C
Resolution: 1°
Accuracy: ±2°C
Sampling Rate: 1 second
Size/Weight: 2¾ x 3 x ½” / 4.2 oz
Alarm: Audible, distinct alarm sound for both
temperature and time
Features: Probe – 0.16” dia. x 8½” length
Cable – 42” length
Adjustable viewing angle
CONTROLS/INDICATORS
START/STOP - Starts and stops timer operation
HR - Sets hours for timer feature
MIN - Sets minutes for timer feature
CLEAR - Clears timer display
UP - Increases degree increment of alarm
DOWN - Decreases degree increment of alarm
TEMP ALERT ON/OFF - Turns temperature alarm on/off.
°F/°C (on back of unit) - Switches Fahrenheit to Celsius
TIMER OPERATION
1. Reset display to 0:00 by simultaneously pressing the
HR & MIN buttons (timer must be stopped to reset).
2. Press HR button to advance hours to desired setting.
Press MIN button to advance minutes to desired set-
ting. An audible beep conrms each entry. Rapidly
advance the hours or minutes by holding down HR
or MIN button.
3. When timer is set, press the START/STOP button to
start countdown alarm operation.
4. If a pause in timing operation is required press the
START/STOP button to “freeze” the display at the
current reading (time-out). To resume time at the
point it was stopped, press the START/STOP button
again. An unlimited number of timeouts may be
taken.
5. When the timer reaches zero a 1-minute alarm
sounds, a “TIME’s-UP” message is displayed and
the timer begins counting up.
6. Press the START/STOP button to silence the alarm
and return the display to it’s previously programmed
setting.
NOTE: The timer and temperature alarm are easily
recognizable by two distinct alarm sounds.
THERMOMETER OPERATION
1. Connect the probe jack to the outlet on the left side
of the unit’s stand. Insert the probe tip in the material to be measured.
NOTE: The probe may be used to monitor temperatures
in air/gas, liquids and semisolids.
NOTE: The probe cable is not waterproof. Do not
immerse the probe cable in liquid. Immersing the probe
cable in liquid can cause permanent damage to the
thermometer.
2. Slide the °F/°C switch to °F to display the temperature in Fahrenheit or to °C to display the temperature
in Celsius.
3. Slide the TEMP ALERT switch to ON. An “ALERT”
message is displayed indicating the temperature
alarm is on.
4. Set the temperature alarm in 1° increments by scrolling UP or DOWN using the TEMP SET buttons.
5. When the temperature reading, as measured at the
probe, matches or is higher than the temperature
alarm setting a 5-minute alarm sounds. The temper-
ature alarm can be temporarily silenced by pressing
the START/STOP button. If the temperature remains
above the alarm setpoint a 5 second reminder alarm
will continue to sound every minute. To turn the
temperature alarm off, slide the TEMP ALERT switch
to the OFF position.
NOTE: The timer and temperature alarm are easily
recognizable by two distinct alarm sounds.
ALL OPERATIONAL DIFFICULTIES
If this unit does not function properly for any reason,
replace the battery with a new high-quality battery (see
“Battery Replacement” section). Low battery power can
occasionally cause any number of “apparent” operational
difculties. Replacing the battery with a new fresh battery
will solve most difculties.
BATTERY REPLACEMENT
Erratic readings, a faint display, no display or ashing display are all indicators that the battery must be
replaced. Remove the battery compartment panel that
is located on the underside of the unit and replace the
exhausted battery with a new alkaline AAA battery. With
the battery securely in place, replace the compartment
cover.
5 Commonwealth Ave
5 Commonwealth Ave
Woburn, MA 01801
Woburn, MA 01801
TestEquipmentDepot.com
TestEquipmentDepot.com
TRACEABLE
ALARM
THERMOMETER/
ALARM TIMER
INSTRUCTIONS
®
