SPECIFICATIONS
Range: 10 to 99,999 RPM Resolution: 0.1 below 1,000 RPM
1 above 1,000 RPM Accuracy: ±1 RPM or 0.05% Sampling Time: 1 second (over 60 RPM) Time Base: Quartz crystal Measuring Distance*: 2 to 78 inches (50-2000 mm)
(*Measurement distance will vary depending on ambient light, environmental conditions and the size of the
reecting surface.)
Laser Output: 1mW Laser Wavelength: 600-700 nm
LASER TARGETING
Laser targeting is always active when the Measurement button is being pressed. Each time the Measurement button is pressed and held, the laser beam will be emitted.
CAUTION: Class II Laser Product. Do not stare into the laser beam.
OPERATION
1. Cut a strip of the reective tape.
2. Stop the rotation of the object to be tested.
3. Make certain that the surface of the rotating object is smooth and clean so that
the reective tape will adhere properly and place the reective tape on the object. The reective tape may be placed on either the
end of the rotating object or circumference (surface) of the rotating object.
Measurement Notes–
The non-reective area of the object must be greater than the reective tape surface. If the object to be tested is normally reective,
it must be covered with black tape or black
paint before attaching the reective tape.
Use particular care when measuring the
rotation of the at end of a shaft with a
relatively small diameter. Completely cover
the at end with non-reective black tape.
Place the reective strip on top of the black
tape as close to the edge as possible.
If the rotation being measured is less than 50 RPM, increase the accuracy of the
measurement by applying additional reective
tape on the rotating object. Place the
additional reective tape approximately 180
degrees from each other (on opposite sides of each other). To determine the actual RPM of the rotating object, divide the displayed
RPM reading by the number of reective tape
pieces.
4. Allow the object to rotate. Press and hold the Measurement button (located on the right side of the unit) and point the laser
beam at the reective tape.
5. Verify proper alignment by observing the location of the laser and by checking the display. When properly aligned, each time
the reective tape passes through the laser
(•)
(
beam (
)
) will ash in the top right corner
of the display.
6. Wait 2 to 10 seconds for the reading to stabilize before recording the results.
7. Release the Measurement button.
MEMORY RECALL
The memory feature allows the last, highest, and lowest readings to be recalled. Readings are normally retained in memory for several minutes.
Upon completion of measurement–
1. Press and hold the MEMORY button to display the last reading recorded prior to releasing the Measurement button. The display will alternate displaying the RPM value and LA (last).
2. Release the MEMORY button.
3. Press the MEMORY button a second time to
display the highest reading recorded. The display will alternate displaying the RPM value and UP (highest).
4. Release the MEMORY button.
5. Press the MEMORY button a third time to display the lowest reading recorded. The display will alternate displaying the RPM value and dn (lowest).
ALL OPERATIONAL DIFFICULTIES
If this tachometer does not function properly for any reason, replace the batteries with new high quality batteries (see Battery Replacement section). Low battery power can occasionally cause any number of
“apparent” operational difculties. Replacing
the batteries with new fresh batteries will
solve most difculties.
BATTERY REPLACEMENT
Erratic readings, faint readings, no display, or LO appearing on the display are all indications that the batteries must be replaced. Open the battery compartment by sliding the battery cover in the direction indicated by the arrow.
Remove the exhausted batteries and replace
them with four (4) new AA alkaline batteries. Make certain to install the new batteries in the directions indicated in the battery compartment (improper battery placement may cause damage to the electronics). Replace the battery cover.
5 Commonwealth Ave Woburn, MA 01801
TestEquipmentDepot.com
TRACEABLE
LASER/PHOTO
TACHOMETER
INSTRUCTIONS
®
