SPECIFICATIONS
Temperature Range: –40 to 482°F
Resolution: 0.1°
Accuracy: ± 0.9°F from –4 to 482°F, otherwise
±1.8°F
Response Time: 2 seconds within 1 degree
Calibrated: 40°F and 140°F
Battery: CR2032 3V button cell
GETTING STARTED
Extend probe and thermometer is ready to use.
DESCRIPTION (FRONT)
1. Probe 18/8 stainless-steel
2. Food Safe Antimicrobial coating
3. 2 inch LCD
4. Opening for lanyard
SWITCHING BETWEEN C°/F°
Using the C°/ F° switch found inside battery compartment, toggle between Celsius and Fahrenheit.
Simply twist open battery cover and remove
battery to access switch.
DESCRIPTION (BACK)
1. Battery compartment
2. Probe compartment
3. Magnetic back
SLEEP MODE
Thermometer will automatically enter sleep mode
after 60 seconds. Simply retract and extend probe
to exit sleep mode and continue use.
MAGNETIC BACKING
Unit has a built-in magnetic backing to allow for
convenient storage. Magnetic backing may not
work on stainless steel surfaces.
SPLASH RESISTANT
Thermometer is rated at IP65 splash resistance. It
is protected against low pressure jets if water, such
as splashes from a tap.
TAPERED SENSOR TIP
The ultra-sensitive thermistor sensor is located at
the tip of the probe, requiring a minimum insertion
distance of 0.25 inches (5 mm).
ANTIMICROBIAL COATING
Silver-based antimicrobial additive is impregnated
into the plastic shell to inhibit the growth of patho-
JHQV(I¿FDF\LVUDWHGDWRUJUHDWHU
TROUBLESHOOTING
WON’T SWITCH ON:
Retract and extend probe or change battery
DISPLAYING “ERROR”:
Battery needs to be replaced soon.
DEVICE ASLEEP:
Retract and extend probe.
USE & MAINTENANCE
• Always measure at center of meat, avoid hitting
bone or hard cartilage.
• Prevent build up of grime; always clean the
body with soft damp cloth.
• Do not clean with solvents or scouring agents.
• Do not put device in dishwasher.
• Do not leave device in oven.
• 'RQRWSODFHSUREHGLUHFWO\RYHU¿UH
• Do not immerse device for any length of time.
• Do not subject device to extreme temperature,
vibration, or shock.
REPLACING BATTERY
When display shows “ERROR”, it’s time to change
the battery. Fully retract probe and twist open the
battery door with a coin. Carefully remove existing
battery and insert a new CR2032 with the positive
(+) pole up.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
FOOD TEMPERATURE GUIDE
Recommended Meat Temperatures
Meat Rare Med. Rare Medium Med. Well Well Done
115°F
125°F
135°F
145°F
Beef, Veal
& Lamb
Pork X
Salmon &
Other Fatty
Fish
Sea Bass
& Other
Lean Fish
6KHOOÀVK
120°F
46°C
49°C
52°C
57°C
125°F
130°F
52°C
54°C
115°F
46°C
125°F
52°C
X
125°F
52°C
130°F
54°C
130°F
54°C
X
X
63°C
135°F
57°C
135°F
57°C
135°F
57°C
X
155°F
68°C
140°F
60°C
145°F
63°C
140°F
60°C
140°F
60°C
NOTE: These are common temperatures used by
professional chefs to achieve a desired taste and
texture. For USDA recommended doneness, add
on another 5 to 10°F (2 to 5°C).
Please also be aware that internal temperature will
continue to rise as your dish is resting.
ADDITIONAL TEMPERATURES
FOR SAFETY
Meat Safe Temperature
Ground Meat 160°F / 71°C
Ham (raw) 160°F / 71°C
Ham (smoked) 140°F / 60°C
Poultry 165°F / 74°C
Brisket, Pork
Ribs, Shoulders
Sausage 160°F / 71°C
Candy Temperatures
Thread 230-234°F / 110-112°C
Softball 234-240°F / 112-116°C
Firmball 244-248°F / 118-120°C
Hardball 250-266°F / 121-130°C
Soft Crack 270-290°F / 132-143°C
Hard Crack 300-310°F / 149-154°C
Caramel 320-350°F / 160-l77°C
190-205°F / 88-96°C
TRACEABLE
2 SECOND-TEMP
NSF FOOD
CERTIFIED
THERMOMETER
INSTRUCTIONS
®
