TPP Pipettor Turbo-Fix Operating instructions
155923_V13
Declaration of conformity
TPP Techno Plastic Products AG – 8219 Trasadingen,
Switzerland
declares on its own responsibility that the devices
comply with:
EU Regulations
Standards for EU
Standards for Canada and USA
Trasadingen, November 4, 2016
Description Models
TPP Pipettor Turbo-Fix 94700, 94701, 94702
EU Directives (DoW: Date of Withdrawal) Before DoW DoW After DoW
Low Voltage Equipment 2006/95/EC 20.04.2016 2014/35/EU
Electromagnetic Compatibility 2004/108/EC 20.04.2016 2014/30/EU
Restriction of Hazardous Substances 2011/65/EU
Waste Electrical and Electronic Equipment 2012/19/EU
Battery Directive 2006/66/EC
Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH)
1907/2006
Capacity Labelling of Portable Secondary Batteries 1103/2010
Ecodesign - Power supplies 278/2009
Safety requirements for electrical equipment for measurement,
control and laboratory use - General requirements.
EN 61010-1: 2010
Electrical equipment for measurement, control and laboratory use EMC requirements.
EN 61326-1: 2013
Safety requirements for electrical equipment for measurement,
control and laboratory use - General requirements.
CAN/CSA-C22.2
No. 61010-1
Safety requirements for electrical equipment for measurement,
control and laboratory use - General requirements.
UL 61010-1
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Part 15 of the
FCC Rules
Class A
Rolf Tanner
CEO
Markus Stoll
Quality Manager
TPP Pipettor Turbo-Fix - Operating instructions V13
www.tpp.ch 3
Table of Contents
1 Introduction ................................................................................................................ 4
2 Description of the device............................................................................................ 5
3 Installation .................................................................................................................. 6
4 Operation ................................................................................................................... 7
5 Maintenance............................................................................................................. 10
6 Technical data.......................................................................................................... 11
7 Spare parts............................................................................................................... 12
Imprint
© 2018 TPP Techno Plastic Products AG
Supplier
Customer service
Please contact your local TPP Techno Plastic Products AG representative, see
www.tpp.ch
or contact info@tpp.ch.
TPP Techno Plastic Products AG
CH-8219 Trasadingen, Switzerland
T +41 52 687 01 87
F +41 52 687 01 77
info@tpp.ch
www.tpp.ch
TPP Pipettor Turbo-Fix - Operating instructions V13 Introduction
4 TPP Techno Plastic Products AG
1 Introduction
1.1 Intended use
TPP Pipettor Turbo-Fix is a pipette controller designed for aspirating and dispensing
aqueous solutions with plastic or glass pipettes of 1 to 100 ml volumes. It is intended for
measurement, control and laboratory use. Any use of this instrument in a medical or IVD
setting is under the sole responsibility of the user.
1.2 Safety notes
1) Do not use or charge TPP Pipettor Turbo-Fix in an atmosphere with danger of
explosion. Also, do not pipette highly flammable liquids such as acetone or ether.
2) When handling dangerous substances, comply with the material safety data sheet
(MSDS) and with all safety guidelines such as the use of protective clothing and safety
goggles. Never point a pipette in anyone’s direction.
3) Avoid pipetting of liquids whose vapours could attack the materials PA (polyamide),
POM (polyoxymethylene), FPM (fluor-rubber), NBR (nitrile-rubber), CR (chloroprene),
silicone. Corrosive vapours could also damage metallic parts inside the device.
4) Use an original TPP mains adapter only and protect it from moisture, otherwise
TPP Pipettor Turbo-Fix might be damaged.
5) Prolonged exposure of TPP Pipettor Turbo-Fix to UV-light can cause discolouration
and/or yellowing of the plastic housing. However, this will not affect the performance of
the device in any way.
6) Old Li-ion batteries may cause a safety risk. We recommend to replace the battery after
3 years of use. Also replace the battery if the charging intervals are unusually short or
if the charging takes much longer than usual (4 hours or more). These are indicators
that the battery has reached the end of its life-cycle.
7) Li-ion technology bears the risk of thermal runaway and cell rupture if the battery was
damaged. Do not expose the battery to heat (> 60°C) and avoid mechanical stress.
Batteries which were subject to deep discharges may develop internal short circuits,
leading to an increased self-discharge rate and heating during battery charging. This
may also result in thermal runaway and cell rupture.
8) To extend the battery life-cycle, it is recommended to charge the battery every 2
months if the pipette controller is not used regularly. If the pipette controller is not used
for more than 6 months, remove the battery from the instrument.
Regardless of the listed safety notes, additionally applicable regulations and guidelines of
trade associations, health authorities, trade supervisory offices, etc. must be observed.
Please visit our website www.tpp.ch
on a regular basis for up to date information regarding
REACH classified chemicals contained in our products.
TPP Pipettor Turbo-Fix - Operating instructions V13 Description of the device
www.tpp.ch 5
2 Description of the device
2.1 Scope of delivery
• TPP Pipettor Turbo-Fix device
• 1 rechargeable Li-ion battery
• Mains adapter
• Wall mount
• Hydrophobic sterile filter 0,45 µm (spare)
• Quick Start Guide
2.2 Overview of TPP Pipettor Turbo-Fix
1 Aspiration button
2 Dispensing button
3 Thumb wheel to set maximum speed
4 Battery charge indicator
5 Socket for mains adapter cable
6 Handle
7 Nose piece
7 Nose piece “Stabifix”
7a O-ring
7b Nose piece housing, upper part
7c Filter rubber
7d Hydrophobic filter
7e Pipette mount
7f Nose piece housing, lower part
1
2
4
5
7
6
3
c
d
e
f
b
7a
TPP Pipettor Turbo-Fix - Operating instructions V13 Installation
6 TPP Techno Plastic Products AG
3 Installation
3.1 Charging the battery
A full charge takes 3.5 hours. Before the first use, TPP Pipettor Turbo-Fix should be
charged until the battery charge indicator (4) turns green, showing that the battery is full.
When the battery charge indicator (4
) starts flashing red, TPP Pipettor Turbo-Fix can be
used for around 100 pipetting cycles before shutting down. It should thus be recharged
immediately.
TPP Pipettor Turbo-Fix has an integrated protection: it will not overcharge even if it is
connected to power for indefinite time. To avoid unnecessary power consumption, it is
recommended to unplug the power supply when the charge indicator is green.
TPP Pipettor Turbo-Fix can be used while it is being charged.
The battery charge indicator provides various information:
3.2 Replacing the battery
3.3 Mounting of the wall mount
The wall mount serves to park TPP Pipettor Turbo-Fix.
To mount the wall mount, remove the protective foil from the adhesive tape at the back of
the holder. Hold it with the sign <up> facing upwards and press it to the desired place.
Make sure that the surface onto which the wall mount is mounted is smooth, clean and
grease-free. Wait 24 hours before using the wall mount for the first time. Alternatively the
wall mount can be fixed with the included screws.
Battery charge indicator Battery status and information
Flashes red Battery is low. Charging is needed.
Is red and power supply is connected Battery is being charged.
Is green and power supply is connected Battery is fully charged.
Flashes alternately red and green Battery error. Check if the correct type of
battery with correct polarity (+/-) and/or
power supply are used.
1) Move the lid of the battery compartment upwards and
remove it (a).
2) Replace the old battery with an original TPP
rechargeable battery (Li-ion, min. 500 mAh) and make
sure that it is inserted with the correct polarity (+/ –).
3) Close the battery compartment with the lid (a).
a
TPP Pipettor Turbo-Fix - Operating instructions V13 Operation
www.tpp.ch 7
4 Operation
4.1 Inserting the pipette
WARNING
Do not insert pipettes with force into TPP Pipettor T urbo-Fix, because they can
break and cause injury, particularly thin pipettes made of glass.
4.2 Pipetting
Press the aspiration button (1) to fill the pipette and the dispensing button (2) to empty it.
The aspiration and dispensing speed can be controlled in two manners:
• Fine speed adjustment by varying the finger pressure on the buttons (1
, 2).
• Step-less presetting of the maximum pump speed by turning the thumb wheel (3) to
optimally match the pipette volume (turning to the left = slower pump speed, for small
pipettes; to the right = faster, for large pipettes).
To empty the pipette by gravity force, press the dispensing button only slightly in order to
avoid reaching the trigger point where the pump starts running. Gravity dispensing is used
for “to deliver” (TD) pipettes that are not
of the “blow-out” type (blow-out pipettes have two
thin rings or a frosted band around the neck).
TPP Pipettor Turbo-Fix is featured with a “TURBO” mode. Plug the mains adapter cable
into the pipette controller and turn the thumb wheel completely to the right for maximal
speed.
The silicone pipette mount (7e
) has a special conical
channel to guarantee a firm and leak-proof grip of the
pipette independently of its diameter.
Disassemble the nose piece (see “5.1
Cleaning and
servicing” on page 10) and orient the pipette mount:
a) with the large opening facing down for pipettes > 2 ml
(factory setting), or
b) with the small opening facing down for pipettes < 2 ml.
a) b)
TPP Pipettor Turbo-Fix – Operating instructions V13 Operation
8 TPP Techno Plastic Products AG
4.3 Troubleshooting
Problem Probable cause Remedy
Pipette drips
(leak in the system).
Pipette is damaged or not fully
inserted in the nose piece (7
).
Reinsert a new pipette and push it all the way into the
nose piece. Make sure that the pipette mount
orientation is correct (see section 4.1
).
The inside of the pipette mount (7 e)
is damaged resulting in insufficient
sealing of the pipette neck.
Replace the pipette mount.
The filter rubber (7c
) or the filter
(7d) in the nose piece are damaged
or missing causing a leak.
Replace the filter rubber and/or the filter.
Reduced aspiration
efficiency or no liquid
aspiration.
The filter (7d
) is wet or dirty. Replace filter.
The nose piece (7
) is not tight. Tighten the nose piece, or replace defective parts.
The battery is discharged (battery
charge indicator flashes red).
Charge the battery.
The battery is missing. Insert the battery, or connect the instrument to the
mains adapter.
The battery is defective. Replace the battery.
The battery is wrongly inserted. Insert correctly, note polarity (+) and (-).
Reduced operating time
with fully charged battery.
The battery is worn. Replace the battery.
Wrong battery type is inserted. Use only original Li-ion battery (#94756).
Extremely long charging
time of battery.
Wrong mains adapter is used. Use only original mains adapter.
Extremely short charging
and operating time.
Wrong battery type is inserted. Use only original Li-ion battery (#94756).
TPP Pipettor Turbo-Fix – Operating instructions V13 Operation
www.tpp.ch 9
Battery is not charging. The battery is wrongly inserted. Insert correctly, note polarity (+) and (-).
Wrong battery type is inserted. Use only original Li-ion battery (#94 756).
Wrong mains adapter is used. Use only original mains adapter (see chapter 6.1
).
Battery operation not
possible.
The battery is wrongly inserted. Insert correctly, note polarity (+) and (-).
Wrong battery type is inserted. Use only original Li-ion battery (#94 756).
The battery is missing. Insert the battery.
Problem Probable cause Remedy
TPP Pipettor Turbo-Fix - Operating instructions V13 Maintenance
10 TPP Techno Plastic Products AG
5 Maintenance
After maintenance work, perform a leak test to ascertain correct functioning of
TPP Pipettor Turbo-Fix: liquid should not leak out of a filled pipette before the dispensing
button is pressed.
5.1 Cleaning and servicing
TPP Pipettor Turbo-Fix can be cleaned with a cloth moistened with soapy water or with a
70 % ethanol.
Disassembly of the nose piece:
It is recommended to change the hydrophobic filter (7 d
) every three months. Should the
filter get wetted or soiled, it has to be changed immediately. The filter must be oriented
with the blue (0.45 µl) / red (0.2 µl) side facing upwards towards TPP Pipettor Turbo-Fix.
5.2 Dekontamination
The nose piece housing (7b, 7 f), the pipette mount (7e) and the filter rubber (7 c) can be
autoclaved at 121 °C, 1 bar overpressure for 20 minutes. Silicone may become brittle after
extensive autoclaving. Replace the pipette mount and filter rubber if they are damaged.
If the housing of the TPP Pipettor Turbo-Fix have been in contact with biohazardous
material, it must be decontaminated in accordance to good laboratory practice. Do not
spray directly on the instrument but use a lint-free cloth, lightly soaked with a disinfectant
and wipe dry directly after decontamination. Never use acetone or other solvents! Follow
the instructions provided by the disinfectant manufacturer.
5.3 Equipment disposal
TPP Pipettor Turbo-Fix device must not be disposed of with unsorted municipal
waste. Do not dispose of the device in a fire.
TPP Pipettor Turbo-Fix contains a Li-ion battery. Do not modify the battery in
any way. Dispose of the TPP Pipettor Turbo-Fix device and the battery
separately in accordance with the laws and regulations in your area governing
disposal of devices containing Li-ion batteries.
Unscrew the nose piece (7
) from the handle by turning it
counter clockwise. Hold the upper part of nose piece
housing (7b
), press the lower part (7 f) firmly against the
upper part (7b
) and turn it counter clockwise (left). The
lower part of nose piece housing (7f) will disengage after
about 1/8th of a turn.
Remove the pipette mount (7e
), the filter (7d) and the
filter rubber (7c
), if required.
TPP Pipettor Turbo-Fix - Operating instructions V13 Technical data
www.tpp.ch 11
6 Technical data
6.1 Specifications
6.2 Chemical compatibility
The table below lists TPP Pipettor Turbo-Fix parts that come into contact with the
aspirated liquid or its aerosols and vapors, and rates the compatibility of these parts to a
few of the chemicals commonly used in laboratories. To determine the compatibility of a
component to a chemical not listed in the table, please consult one of the several tables
available on the internet. Note that the rating refers to soaking in the concentrated
chemical; however, more relevant here is the attenuated effect resulting from vapors and
the diluted chemical. It is recommended to test the compatibility of relevant components
to a specific chemical prior to extensive use.
TPP Techno Plastic Products AG does not warrant that the information in the table is
accurate or complete and that any material is suitable for any purpose.
Pipetting speed max. 13.5 ml/s (with a 50 ml serological pipette)
Battery Type: rechargeable, Li-ion, min. 500 mAh
Typical charging time: 3.5 hours
Charging cycles: 500– 1000 (when charging as indicated)
Running time: at least 5 500 cycles of aspiration and
dispensing of 25 ml.
Electricity supply Mains adapter input: 100– 240 VAC, 50/60 Hz
Device Input: 16–19 VDC, 3.1 W
Materials Housing: PA
Nose piece housing: POM
Pipette mount: Silicone
Filter rubber: Silicone
Dimensions (H x W x D) 125 x 130 x 35 mm
Weight 195 g
Ambient conditions Operation: 5–40 °C, max. 80% RH
Storage: -10–50 °C, max. 95% RH
TPP Pipettor Turbo-Fix - Operating instructions V13 Spare parts
12 TPP Techno Plastic Products AG
Chemical compatibility chart
Compatibility ratings:
A = Good: no or minor effects.
B = Fair: moderate effects, not recommended for continuous use.
C = Critical: not recommended, suitability to be determined by test.
7Spare parts
Parts Materials
JAVEL (e.g. NaClO)
Acetic acid
Ethanol
Isopropyl alcohol
NaCl saturated
Sodium hydroxide (50%)
Sodium acetate
(3M, pH 5.2)
Hydrochloric acid (20%)
Chloroform
Acetone
Handle PA A C B A A A A C C A
Nose piece housing POM C C A A A A A B A A
Pipette mount,
Filter rubber, tubings
Silicone A B A A A A C A C C
Internal parts
(e. g. pump)
FPM AAAAAC C AAC
NBR ABBAAA A ACC
CR AAAAAA A ABA
Metal CCAABC A CAA
Spare part Part No.
Mains adapter for
Turbo-Fix (100-240 VAC,
50/60 Hz)
EU version: type C plug, 2-pole 94760
US/JP version: type A plug, 2-pole 94761
UK version: type G „Commonwealth“ plug, 3-pole 94762
Nose piece “Stabifix” (7
) complete set with filter 0.45 µm, unsterile 94750
Wall mount for holding Pipettor Turbo-Fix on the wall 94751
Filter 0.45 µm (7d
) sterile 94752
Filter 0.22 µm (7d
) sterile 94753
Pipette mount (7e
) silicone, to fix the pipette in the nose piece “Stabifix” 94754
Filter rubber (7c) silicone, to fix the filter in the nose piece “Stabifix” 94755
Battery Li-ion Lithium polymer, min. 500 mAh 94756
Battery compartment lid transparent, TPP yellow 94757
Housing (6
) transparent, TPP yellow 94758
Loading...
