TP Link WR841NV13 Users Manual

TL-WR841N

User Guide

300Mbps Wireless N Router

REV12.0.0 1910011881

Contents

About This Guide ............................................................................................... 1

Chapter 1. Get to Know About Your Router . . . . . . . . . . . . . . . . . . . . . . . . . 2

1. 1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1. 2. Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1. 2. 1. Top View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1. 2. 2. The Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Chapter 2. Connect the Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2. 1. Position Your Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2. 2. Connect Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Chapter 3. Set Up Internet Connection Via Quick Setup Wizard . . . . . 10

3. 1. Log into the Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3. 2. Configure the Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Chapter 4. Configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4. 1. Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4. 2. WPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4. 3. Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4. 3. 1. WAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4. 3. 2. MAC Clone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4. 3. 3. LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4. 4. Wireless. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4. 4. 1. Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4. 4. 2. Wireless Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4. 4. 3. Wireless MAC Filtering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4. 4. 4. Wireless Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

4. 4. 5. Wireless Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4. 5. Guest Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4. 6. DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4. 6. 1. DHCP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4. 6. 2. DHCP Client List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4. 6. 3. Address Reservation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4. 7. Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

4. 7. 1. Virtual Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

4. 7. 2. Port Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4. 7. 3. DMZ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4. 7. 4. UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4. 8. Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4. 8. 1. Basic Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4. 8. 2. Advanced Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

4. 8. 3. Local Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

4. 8. 4. Remote Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

4. 9. Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

4. 10. Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

4. 11. Advanced Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

4. 11. 1. Static Routing List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

4. 11. 2. System Routing Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

4. 12. Bandwidth Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

4. 12. 1. Control Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

4. 12. 2. Rules List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

4. 13. IP&MAC Binding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

4. 13. 1. Binding Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

4. 13. 2. ARP List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

4. 14. Dynamic DNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

4. 15. IPv6 Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

4. 15. 1. IPv6 Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

4. 15. 2. IPv6 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

4. 16. System Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

4. 16. 1. Time Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

4. 16. 2. Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

4. 16. 3. Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

4. 16. 4. Factory Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

4. 16. 5. Backup & Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

4. 16. 6. Reboot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

4. 16. 7. Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

4. 16. 8. System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

4. 16. 9. Statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

4. 17. Logout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

FAQ .....................................................................................................................73

About This Guide

This guide is a complementation of Quick Installation Guide. The Quick Installation Guide instructs you on quick Internet setup, and this guide provides details of each function and shows you the way to configure these functions appropriate to your needs.

When using this guide, please notice that features of the router may vary slightly depending on the model and software version you have, and on your location, language, and Internet service provider. All screenshots, images, parameters and descriptions documented in this guide are used for demonstration only.

Conventions

In this guide the following conventions are used:

Convention Description

Blue Italic Hyperlinks are in blue italic. You can click to redirect to a website or a specific section.

Blue

Note:

Tips:

Contents to be emphasized and texts on the web page are in blue, including the menus, items, buttons, etc.

The menu structures to show the path to load the corresponding page. For example,

Advanced > Wireless > MAC Filtering means the MAC Filtering function page is under

the Wireless menu that is located in the Advanced tab.

Ignoring this type of note might result in a malfunction or damage to the device.

Indicates important information that helps you make better use of your device.

More Info

The latest software, management app and utility can be found at Download Center at

www.tp-link.com/support.

The Quick Installation Guide can be found where you find this guide or inside the package of the router.

Specifications can be found on the product page at http://www.tp-link.com.

A Technical Support Forum is provided for you to discuss our products at

http://forum.tp-link.com.

Our Technical Support contact information can be found at the Contact Technical

Support page at www.tp-link.com/support.

Chapter 1

Get to Know About Your Router

This chapter introduces what the router can do and shows its appearance.

This chapter contains the following sections:

• Product Overview

• Panel Layout

Chapter 1

Get to Know About Your Router

1. 1. Product Overview

The TP-LINK router is designed to fully meet the need of Small Office/Home Office (SOHO) networks and users demanding higher networking performance. The powerful antennas ensure continuous Wi-Fi signal to all your devices while boosting widespread coverage throughout your home, and the built-in Ethernet ports supply high-speed connection to your wired devices.

Moreover, it is simple and convenient to set up and use the TP-LINK router due to its intuitive web interface and the powerful Tether app.

1. 2. Panel Layout

1. 2. 1. Top View

The router’s LEDs (view from left to right) are located on the front panel. You can check the router’s working status by following the LED Explanation table.

Chapter 1

LED Explanation

Name Status Indication

Get to Know About Your Router

On System initialization completes.

(Power)

Flashing

Off Power is off.

On The wireless function is working properly.

(Wireless)

Off The wireless function is disabled.

On The corresponding Ethernet port is connected.

(Ethernet)

Off No Ethernet port is connected.

Blue On

(Internet)

Orange On

Off

On/Off

(WPS)

Flashing

1. 2. 2. The Back Panel

System initialization or firmware upgrade is in process. Do not disconnect or power off the router.

The Internet is available.

The router’s WAN port is connected, but the Internet is not available.

The router’s WAN port is not connected.

Turns on when WPS connection is established, and goes off about 5 minutes later.

A wireless device is trying to connect to the network via WPS. This process may take up to 2 minutes.

POWERON/OFF WAN 1 2 3 4

WPS/

RESET

WIFI

ON/OFF

Chapter 1

Get to Know About Your Router

The following parts (view from left to right) are located on the rear panel.

Item Description

ON/OFF Button Press this button to power on or off the router.

Power Port For connecting the router to a power socket via the provided power adapter.

WAN Port For connecting to a DSL/Cable modem, or an Ethernet port.

Ethernet Ports (1/2/3/4) For connecting your PCs or other wired network devices to the router.

Use a pin to press and hold this button until all the LED turn on momentarily to reset the router to its factory default settings.

WPS/RESET Button

Wi-Fi ON/OFF Button

Antennas

To enable the WPS function, press this button about 2 seconds. If you have a WPS-supported device, you can press this button to quickly establish connection between the router and the client device and automatically configure wireless security for your wireless network.

Press and hold this button until the function.

Used for wireless operation and data transmitting. Upright them for the best Wi-Fi performance.

LED is on/off to turn on/off the Wi-Fi

Chapter 2

Connect the Hardware

This chapter contains the following sections:

• Position Your Router

• Connect Your Router

Chapter 2

POWERON/OFF

Connect the Hardware

2. 1. Position Your Router

• The product should not be located in a place where it will be exposed to moisture or excessive heat.

• Place the router in a location where it can be connected to multiple devices as well as to a power source.

• Make sure the cables and power cord are safely placed out of the way so they do not create a tripping hazard.

• The router can be placed on a shelf or desktop.

• Keep the router away from strong electromagnetic radiation and devices of electromagnetic sensitive.

2. 2. Connect Your Router

1. Follow the steps below to connect your router.

If your Internet connection is through an Ethernet cable from the wall instead of through a DSL / Cable / Satellite modem, connect the Ethernet cable directly to the router’s WAN port, and then follow Step 4 and 5 to complete the hardware connection.

WIFI

ON/OFF

WPS/

RESET

Power adapter

Internet

Modem

Power adapter

POWERON/OFF WAN 1 2 3 4

Router

POWERON/OFF WAN 1 2 3 4

1 ) Turn off the modem, and remove the backup battery if it has one.

2 ) Connect the modem to the WAN port on your router with an Ethernet cable.

3 ) Turn on the modem, and then wait about 2 minutes for it to restart. 4 ) Connect the power adapter to the router and turn on the router.

Chapter 2

Power

Internet

Wi-Fi

Connections are available

Wireless Network Connection

Connect the Hardware

5 ) Verify that the hardware connection is correct by checking these LEDs.

Tips: If Wi-Fi LED is off, press and hold the WPS/Wi-Fi button until it is on.

2. Connect your computer to the router.

• Method 1: Wired

Turn off the Wi-Fi on your computer and connect the devices as shown below.

Ethernet cable

1 2 3 4

WPS/

RESET

ON/OFF

WIFI

• Method 2: Wirelessly

1. Find the SSID (Network Name) and Wireless Password printed on the label at the bottom of the router.

2. Click the network icon of your computer or go to Wi-Fi Settings of your smart device, and then select the SSID to join the network.

Smart DeviceComputer

Wi-Fi

TP-LINK_XXXX

Connect automatically Connect

TP-LINK_123

< Settings

Wi-Fi

CHOOSE A NETWORK...

TP-LINK_XXXX

TP-LINK_123

Other...

• Method 3: Use the WPS button

Wireless devices that support WPS, including Android phones, tablets, most USB network cards, can be connected to your router through this method. (WPS is not supported by iOS devices).

Note: The WPS function cannot be configured if the wireless function of the router is disabled. Also, the WPS function will be disabled if your wireless encryption is WEP. Please make sure the wireless function is enabled and is configured with the appropriate encryption before configuring the WPS.

1. Tab the WPS icon on the device’s screen.

2. Immediately press the WPS button on your router.

Chapter 2

Connect the Hardware

POWER

WAN 1 2 3 4

POWER

WAN 1 2 3 4

WPS/

RESET

WIFI

ON/OFF

Close to

Chapter 3

Set Up Internet Connection Via Quick Setup Wizard

This chapter introduces how to connect your router to the Internet via the web-based Quick Setup Wizard.

This chapter contains the following sections:

• Log into the Router

• Configure the Router

Chapter 3

Set Up Internet Connection Via Quick Setup Wizard

3. 1. Log into the Router

With the web-based utility, it is easy to configure and manage the router. The webbased utility can be used on any Windows, Macintosh or UNIX OS with a Web browser, such as Microsoft the Internet Explorer, Mozilla Firefox or Apple Safari.

Follow the steps below to log in to your router.

1. Set up the TCP/IP Protocol in Obtain an IP address automatically mode on your

computer.

2. Visit http://tplinkwifi.net, and log in with the username and password you set for the

router. The default one is admin (all lowercase) for both username and password.

Note:

If the login window does not appear, please refer to the FAQ section.

3. 2. Configure the Router

The Quick Setup Wizard will guide you through the process to set up your router.

1. Go to Quick Setup and click Next to start.

1. Select Auto Detect and click Next, and then the router will detect your connection

type automatically.

Note:

• You can also choose the connection type manually. Contact your ISP if you are not sure about the Internet

connection information.

• If you use DSL line and you are only provided with an account name and a password by your ISP, choose PPPoE.

• If you use cable TV or fiber cable, choose Dynamic IP.

• If you are provided with more information such as IP address, Subnet Mask and Default Gateway, choose Static IP.

Chapter 3

Set Up Internet Connection Via Quick Setup Wizard

2. In this case, we take dynamic IP for instance. Please select to clone the mac address

or not and click Next. For other connection types, please enter the parameters provided by your ISP, and then click Next.

3. Either customize your Wireless Network Name and Wireless Password or keep the

default ones, and then click Next.

4. Click Finish to complete the configuration. Now your computers and Wi-Fi devices

can connect to the Internet!

Chapter 3

Set Up Internet Connection Via Quick Setup Wizard

Chapter 4

Configure

This chapter presents how to configure the various features of the router.

This chapter contains the following sections:

• Status

• WPS

• Network

• Wireless

• Guest Network

• DHCP

• Forwarding

• Security

• Parental Controls

• Access Control

• Advanced Routing

• Bandwidth Control

• IP&MAC Binding

• Dynamic DNS

• IPv6 Support

• System Tools

• Logout

Chapter 4

Congure

4. 1. Status

1. Visit http://tplinkwifi.net, and log in with the username and password you set for

the router.

2. Go to Status. You can view the current status information of the router.

• Firmware Version - The version information of the router’s firmware.

• Hardware Version - The version information of the router’s hardware.

• LAN - This field displays the current settings of the LAN, and you can configure them

on the Network > LAN page.

• MAC address - The physical address of the router.

• IP address - The LAN IP address of the router.

• Subnet Mask - The subnet mask associated with the LAN IP address.

Chapter 4

Congure

• Wireless - This field displays the basic information or status of the wireless function,

and you can configure them on the Wireless > Wireless Settings page.

• Wireless Radio - Indicates whether the wireless feature is enabled or not.

• Name (SSID) - The SSID of the router.

• Mode - The current wireless working mode in use.

• Channel Width - The current wireless channel width in use.

• Channel - The current wireless channel in use.

• MAC Address - The physical address of the router.

• WDS Status - The status of WDS connection.

• WAN - This field displays the current settings of the WAN, and you can configure them

on the Network > WAN page.

• MAC Address - The physical address of the WAN port.

• IP Address - The current WAN (Internet) IP Address. This field will be blank or 0.0.0.0 if the IP Address is assigned dynamically and there is no Internet connection.

• Subnet Mask - The subnet mask associated with the WAN IP Address.

• Default Gateway - The Gateway currently used is shown here. When you use Dynamic IP as the Internet connection type, click Renew or Release here to obtain new IP parameters dynamically from the ISP or release them.

• DNS Server - The IP addresses of DNS (Domain Name System) server.

• Traffic Statistics - The router’s traffic statistics.

• Received (Bytes) - Traffic in bytes received from the WAN port.

• Received (Packets) - Traffic in packets received from the WAN port.

• Sent (Bytes) - Traffic in bytes sent out from the WAN port.

• Sent (Packets) - Traffic in packets sent out from the WAN port.

• System Up Time - The length of the time since the router was last powered on or reset.

Click Refresh to get the latest status and settings of the router.

4. 2. WPS

WPS (Wi-Fi Protected Setup) can help you to quickly and securely connect to a network. This section will guide you to add a new wireless device to your router’s network quickly via WPS.

Note:

The WPS function cannot be configured if the wireless function of the router is disabled. Please make sure the wireless function is enabled before configuration.

1. Visit http://tplinkwifi.net, and log in with the username and password you set for the router.

Chapter 4

Congure

2. Go to WPS.

3. Follow one of the following three methods to connect your client device to the router’s Wi-Fi network.

Method ONE: Press the WPS Button on Your Client Device

1. Keep the WPS Status as Enabled and click Add Device.

2. Select Press the button of the new device in two minutes and click Connect.

3. Within two minutes, press the WPS button on your client device.

4. A success message will appear on the WPS page if the client device has been successfully added to the router’s network.

Method TWO: Enter the Client’s PIN

1. Keep the WPS Status as Enabled and click Add Device.

2. Select Enter the new device’s PIN, enter your client device’s current PIN in the PIN filed and click Connect.

Chapter 4

3. A success message will appear on the WPS page if the client device has been successfully added to the router’s network.

Congure

Method Three: Enter the Router’s PIN

1. Keep the WPS Status as Enabled and get the Current PIN of the router.

2. Enter the router’s current PIN on your client device to join the router’s Wi-Fi network.

4. 3. Network

4. 3. 1. WAN

1. Visit http://tplinkwifi.net, and log in with the username and password you set for the router.

2. Go to Network > WAN.

3. Configure the IP parameters of the LAN and click Save.

Dynamic IP

If your ISP provides the DHCP service, please select Dynamic IP, and the router will automatically get IP parameters from your ISP.

Click Renew to renew the IP parameters from your ISP.

Click Release to release the IP parameters.

Chapter 4

Congure

• MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet

networks is 1500 Bytes. It is not recommended that you change the default MTU size unless required by your ISP.

• Use These DNS Servers - If your ISP providess you one or two DNS addresses, select

Use These DNS Servers and enter the primary and secondary addresses. Otherwise,

the DNS servers will be assigned dynamically from your ISP.

• Host Name - This option specifies the name of the router.

• Get IP with Unicast DHCP - A few ISPs’ DHCP servers do not support the broadcast

applications. If you cannot get the IP address normally, you can choose this option. (It is rarely required.)

Static IP

If your ISP provides a static or fixed IP address, subnet mask, default gateway and DNS setting, please select Static IP.

• IP Address - Enter the IP address in dotted-decimal notation provided by your ISP.

Chapter 4

Congure

• Subnet Mask - Enter the subnet mask in dotted-decimal notation provided by your

ISP. Normally 255.255.255.0 is used as the subnet mask.

• Default Gateway - Enter the gateway IP address in dotted-decimal notation provided

by your ISP.

• MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet

networks is 1500 Bytes. It is not recommended that you change the default MTU size unless required by your ISP.

• Primary/Secondary DNS - (Optional) Enter one or two DNS addresses in dotted-

decimal notation provided by your ISP.

PPPoE/Russia PPPoE

If your ISP provides PPPoE connection, select PPPoE/Russia PPPoE.

• User Name/Password - Enter the user name and password provided by your ISP. These

fields are case-sensitive.

• Confirm Password - Enter the Password provided by your ISP again to ensure the

password you entered is correct.

• Secondary Connection - It’s available only for PPPoE connection. If your ISP provides

an extra connection type, select Dynamic IP or Static IP to activate the secondary connection.

• WAN Connection Mode

• Connect on Demand - In this mode, the Internet connection can be terminated automatically after a specified inactivity period (Max Idle Time) and be reestablished when you attempt to access the Internet again. If you want to keep your Internet connection active all the time, please enter 0 in the Max Idle Time

Chapter 4

Congure

field. Otherwise, enter the number of minutes you want to have elapsed before your Internet access disconnects.

• Connect Automatically - The connection can be re-established automatically when it is down.

• Time-based Connecting - The connection will only be established in the period from the start time to the end time (both are in HH:MM format).

• Connect Manually - You can click Connect/Disconnect to connect/disconnect immediately. This mode also supports the Max Idle Time function as Connect

on Demand mode. The Internet connection can be disconnected automatically

after a specified inactivity period (Max Idle Time) and not be able to re-establish when you attempt to access the Internet again.

Note:

• Only when you have configured the system time on the System Tools > Time Settings page, will the time-based connecting function take effect.

• Sometimes the connection cannot be terminated although you have specified the Max Idle Time because some applications are visiting the Internet continually in the background.

If you want to do some advanced configurations, please click Advanced.

• MTU Size - The default MTU size is 1480 bytes. It is not recommended that you change the default MTU size unless required by your ISP.

• Service Name/AC Name - The service name and AC (Access Concentrator) name should not be configured unless you are sure it is necessary for your ISP. In most cases, leaving these fields blank will work.

• ISP Specified IP Address - If your ISP does not automatically assign IP addresses to the router, please select Use IP address specified by ISP and enter the IP address provided by your ISP in dotted-decimal notation.

Chapter 4

Congure

• Detect Online Interval - The router will detect Access Concentrator online at every interval. The default value is 0. You can input the value between 0 and 120. The value 0 means no detect.

• Primary DNS/Secondary DNS - If your ISP does not automatically assign DNS addresses to the router, please select Use the following DNS servers and enter the IP address in dotted-decimal notation of your ISP’s primary DNS server. If a secondary DNS server address is available, enter it as well.

BigPond Cable

If your ISP provides BigPond cable connection, please select BigPond Cable.

• User Name/Password - Enter the user name and password provided by your ISP. These fields are case-sensitive.

• Auth Server - Enter the authenticating server IP address or host name.

• Auth Domain - Type in the domain suffix server name based on your location.

• MTU Size - The default MTU size is 1480 bytes. It is not recommended that you change the default MTU size unless required by your ISP.

• Connection Mode

Chapter 4

Congure

• Connect Automatically - The connection can be re-established automatically when it is down.

• Connect Manually - You can click Connect/Disconnect to connect/disconnect immediately. This mode also supports the Max Idle Time function as Connect

on Demand mode. The Internet connection can be disconnected automatically

after a specified inactivity period (Max Idle Time) and not be able to re-establish when you attempt to access the Internet again.

Note:

Sometimes the connection cannot be terminated although you have specified the Max Idle Time because some applications are visiting the Internet continually in the background.

L2TP/Russia L2TP

If your ISP provides L2TP connection, please select L2TP/Russia L2TP.

• User Name/Password - Enter the user name and password provided by your ISP. These fields are case-sensitive.

• Confirm Password - Enter the Password provided by your ISP again to ensure the password you entered is correct.

• Connect/Disconnect - Click this button to connect or disconnect immediately.

+ 63 hidden pages
