USB 3.0 7-Port Hub
with 2 Charing Ports
UH720

Features
Extra 2 Charging Ports for
All Your Devices
· Extra 2 USB ports supporting 2.4A outputs
are specically designed for ultra fast
charging. It charges most USB-charged
devices, no matter devices with large battery
like tablet and smartphone, or gadgets with
tiny battery like smart wearable devices, at full
speed.
*Exact charging time may vary and is subject
to actual charging situations.
10x Data Transfer Speed
· Equipped with USB 3.0 ports, the UH720 can
transfer a 1080p movie under 2 minutes 18
seconds, whereas it takes 7 minutes 36
seconds with a USB Hub equipped with USB
2.0 ports.
*The actual transmission speed depends on
the setting of the device connected.
Increase the Number of
Aavailable Ports
· �The UH720 is perfect for anyone who has a
computer with only one or two USB ports, and
wants easier access to additional ports
without having to switch between devices.
* Many laptops have only one or two USB ports
* Many computers have USB ports in
dicult-to-reach locations
Exclusive TP-Link Smart
Charging Technology
· TP-Link Smart Charging technology intelligently
identies the connected devices and
automatically delivers the fastest possible
charge to your smartphones, tablets or other
USB-charged devices to minimize the charging
time.
Protect Both Your Devices
and Precious Data
· UH720 has a sophisticated circuit design
with multiple protections for your devices
against over-heating, over-current,
over-voltage and short circuit. A built-in
surge protector keeps both your devices and
data safe in the process of transferring data.
· UH720 support USB ports hot swapping that
can be safely connected and disconnected
while the computer is powered on and
running.
Considerate Design
· A dim white LED indicator on the power
button helps visulaize the connection status
and similarly, 7 dim white LED indicators
beyond each USB port also indicate whether
the devices are properly connected.
TP-Link
USB 3.0 7-Port Hub with 2 Charing Ports
UH720

Specications
Hardware
· Product Dimension: 6.5 x 2.6 x 0.7 in. (165 x 65.5 x 17.5 mm)
· Input Interface: 1 USB 3.0 Micro B
· Output Interface: 7 USB 3.0 Standard A, 2 2.4A Charging Ports
· Supported Systems: Windows, Mac OS X and Linux systems
Others
· Certication: CE, FCC, RoHS
· Package Contents
USB 3.0 7-Port Hub with 2 Charging Ports UH720
Typical Applications
FUSED
Power Adapter
USB 3.0 Ports
Provides transfer rates of up to 5Gbps,
10 times faster than USB 2.0.
Connect your PC to the USB Hub using
the included USB cable.
:
PC
12V/3.3A Power Adapter
1-Meter USB 3.0 Cable
Quick Installation Guide
USB Drive
Printer Mouse
Intelligent
Chip
Smart Charging
Recognizes the connected devices and adjusts the power to
match output.
SmartphonePad
2.4A Charging Ports
Supplies enough current for all
kinds of mobile devices.
For more information, please visit
https://www.tp-link.com/en/products/details/cat-5690_UH720.html
or scan the QR code on the left
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies CO., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specications may be reproduced in any form or by any means or used to make any derivative such as translation,
transformation, or adaptation without permission from TP-Link Technologies CO., Ltd.
