AC1200
Wireless MU-MIMO
Gigabit Router
Upgrade to Fast AC Wi-Fi and
gigabit connections
Archer C6
300Mbps + 867Mbps
Dual Band Wi-Fi
Gigabit
Ports
Access Point
Mode
Highlights
Household Wi-Fi at Streaming Speeds
Press play and forget about buering with the Archer C6. Thanks to high-speed
dual Wi-Fi bands, you can run more of your devices at the same time without
interruption. The strong 2.4GHz (300Mbps) Wi-Fi band is perfect for sending
emails, browsing the web, and listening to music. The crystal 5GHz Wi-Fi band
reaches 867Mbps so you can game online and stream in HD simultaneously.
2.4GHz 300Mbps
5GHz 867Mbps
Beamforming for Better Coverage
Beamforming technology detects the location of your connected devices and
concentrates the Archer C6's Wi-Fi towards them to create stronger overall
connections.
Archer C6
Regular Router
TP-Link AC1200 Wireless MU-MIMO Gigabit Router
Archer C6
Highlights
MU-MIMO for 2x Faster Connections
MU-MIMO technology simultaneously transfers data to multiple devices at once,
reducing wait time, increasing Wi-Fi throughput for every device and making each
stream more ecient.
Optimum Wired Versatility
The Archer C6’s multiple Gigabit LAN ports provide your PCs, game consoles and more
with ultra-fast and stable wired networks.
ResetPower
Internet
Access
Traditional Router
Sends data to one device at a time
MU-MIMO Router
Simultaneously sends data to multiple devices
Power
On/O
TP-Link AC1200 Wireless MU-MIMO Gigabit Router
WPS/Wi-Fi
On/O
Ethernet Ports
Archer C6
Features
Ease of Use
· Intuitive Web UI – Ensure quick and simple installation without
hassle
· Hassle-free Management with Tether App – Let you easily
manage your network settings with your smartphone
· Fast Encryption – Quickly connect devices to Wi-Fi at the push
of a button without entering the password
· Access Point Mode – Switch to access point mode to connect
Wi-Fi devices to any wired network
Reliability
· Ultimate Wireless Speed – 300Mbps Wi-Fi speed on 2.4GHz
and 867Mbps Wi-Fi speed on 5GHz meet your daily internet
needs
· MU-MIMO – Simultaneously transfer data to multiple devices
for 2× faster
· Support 802.11 ac – Provide a data transfer rate 3 times faster
than 802.11n for each stream
· IPTV – Support IGMP Proxy/Snooping, Bridge and Tag VLAN to
optimize IPTV streaming
Security
· Active Defense – Protect your home network with rewalls and
wireless encryption
· Guest Network – Provide separate access for guests while
securing the home network
· Access Control – Establish a whitelist or blacklist to allow or
block certain devices from accessing the internet
· Parental Controls – Manage when and how connected devices
can access the internet
· Encryptions for Secure Network – WPA-PSK and WPA2-PSK
encryptions provide active protection against security threats
TP-Link AC1200 Wireless MU-MIMO Gigabit Router
Archer C6
Specications
Hardware
· Ethernet Ports: 4*10/100/1000Mbps LAN Ports, 1*10/100/1000Mbps
WAN Port
· Buttons: Reset Button, Power On/O Button, WPS/Wi-Fi On/O Button
· Antennas: 4 Fixed External Antennas and 1 Internal Antenna
· External Power Supply: 12V/1A
· Dimensions (W x D x H): 9.1 × 5.7 × 1.4 in (230 × 144 × 35 mm)
Software
· WAN Type: Dynamic IP, Static IP, PPPoE, PPTP (Dual Access), L2TP (Dual
Wireless
· Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
· Frequency: 2.4GHz and 5GHz
· Signal Rate:
5GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps
· Transmit Power:
CE EIRP: <20dBm(2.4GHz); <23dBm(5GHz)
· Reception Sensitivity:
5GHz:
11a 6Mbps:-93dBm；11a 54Mbps:-78dBm
；
Access), BigPond
· DHCP: Server, DHCP Client List, Address Reservation
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, NO-IP
· Access Control: Parental Controls, Local Management Control, Host List,
White List, Black List
· Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
· Protocols: IPv4, IPv6
· Management: Access Control, Local Management, Remote Management
· Guest Network: 2.4GHz guest network, 5GHz guest network
11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-65dBm;
11ac HT80 mcs9:-62dBm;
2.4GHz:
11g 54Mbps:-78dBm;
11n HT20 mcs7:-74dBm;
11n HT40 mcs7:-71dbm
· Wireless Function: Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics
· Wireless Security: 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK
encryption
；
TP-Link AC1200 Wireless MU-MIMO Gigabit Router
Archer C6
Specications
Others
· Package Contents
Wireless Router Archer C6
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
· Certication
CE, RoHS
· Environment
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
· System Requirements
Microsoft Windows 10/8.1/8/7/Vista/XP/2000/NT/98SE, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
· Download TP-Link Tether App
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
For more information, please visit
http://www.tp-link.com/en/products/details/Archer-C6.html
or scan the QR code left
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specications may be reproduced in any form or by any means or used
to make any derivative such as translation, transformation, or adaptation without permission from TP-Link Technologies Co., Ltd. Copyright ©2018 TP-Link Technologies Co., Ltd. All rights reserved.
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles,
volume and density of trac, and client location.
*Use of MU-MIMO requires clients to also support MU-MIMO.
