About This Guide
This guide is a complement to Quick Installation Guide. The Quick Installation Guide provides instructions for quick Internet setup, while this guide contains details of each function and demonstrates how to configure them.
When using this guide, please notice that features of the router may vary slightly depending on the model and software version you have, and on your location, language, and Internet service provider. All screenshots, images, parameters and descriptions documented in this guide are used for demonstration only.
Conventions
In this guide the following conventions are used:
Convention |
Description |
|
Underlined |
Underlined words or phrases are hyperlinks. You can click to redirect to a website or a |
|
specific section. |
||
 |
||
Teal |
Contents to be emphasized and texts on the web page are in teal, including the menus, |
|
items, buttons and so on. |
||
 |
The menu structures to show the path to load the corresponding page. For example,
>Advanced > Wireless > MAC Filtering means the MAC Filtering function page is under the Wireless menu that is located in the Advanced tab.
 |
 |
 |
Note: |
Ignoring this type of note might result in a malfunction or damage to the device. |
|
 |
 |
 |
|||
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Tips: |
Indicates important information that helps you make better use of your device. |
 |
 |
 |
 |
||
 |
 |
 |
 |
||
More Info
The latest software, management app and utility are available from the Download Center at www.tp-link.com/support.
The Quick Installation Guide can be found where you find this guide or inside the package of the router.
Specifications can be found on the product page at http://www.tp-link.com.
A Technical Support Forum is provided for you to discuss our products at http://forum.tp-link.com.
Our Technical Support contact information can be found at the Contact Technical Support page at www.tp-link.com/support.
1
Chapter 1
Get to Know About Your Router
This chapter introduces what the router can do and shows its appearance.
It contains the following sections:
•Product Overview
•Panel Layout
Chapter 1 |
 |
1. 1. Product Overview
The TP-LINK router is designed to fully meet the need of Small Office/Home Office (SOHO) networks and users demanding higher networking performance. The powerful antennas ensure continuous Wi-Fi signal to all your devices while boosting widespread coverage throughout your home, and the built-in Ethernet ports supply high-speed connection to your wired devices.
Moreover, it is simple and convenient to set up and use the TP-LINK router due to its intuitive web interface and the powerful Tether app.
1. 2. Panel Layout
1. 2. 1. Top View
The router’s LEDs (view from left to right) are located on the front panel. You can check the router’s working status by following the LED Explanation table.
LED Explanation
 |
Name |
Status |
Indication |
 |
 |
On |
System initialization completes. |
 |
(Power) |
Flashing |
System initialization or firmware upgrade is in progress. Do not |
 |
|||
 |
disconnect or power off the router. |
||
 |
 |
Off |
Power is off. |
3
Chapter 1
LED Explanation
Name |
Status |
Indication |
|
(Wireless) |
On |
The 2.4GHz wireless function is working properly. |
|
Off |
The 2.4GHz wireless function is disabled. |
||
 |
|||
(Wireless) |
On |
The 5.0GHz wireless function is working properly. |
|
Off |
The 5.0GHzwireless function is disabled. |
||
 |
|||
 |
On/Off |
Turns on when WPS connection is established, and goes off about 5 |
|
 |
minutes later. |
||
(WPS) |
 |
||
Flashing |
A wireless device is trying to connect to the network via WPS. This |
||
 |
|||
 |
process may take up to 2 minutes. |
||
 |
 |
||
(Ethernet) |
On |
One of Ethernet ports is connected. |
|
Off |
No Ethernet port is connected. |
||
 |
|||
 |
Green On |
The Internet is available. |
|
(Internet) |
Orange On |
The router’s WAN port is connected, but the Internet is not available. |
|
 |
Off |
The router’s WAN port is not connected. |
1. 2. 2. The Back Panel
Wi-Fi /WPS
The following parts (view from left to right) are located on the rear panel.
4
Chapter 1 |
 |
|
 |
 |
|
Item |
Description |
|
Power Port |
For connecting the router to a power socket via the provided power adapter. |
|
Power On/Off Button |
Press this button to power on or off the router. |
|
Reset Button |
Press and hold this button until all the LEDs turn on momentarily to reset the router to |
|
its factory default settings. |
||
 |
||
 |
Press this button, and immediately press the WPS button on your device. The WPS |
|
 |
LED of the router should change from flashing to solid on, indicating successful WPS |
|
Wi-Fi/WPS |
connection. |
|
 |
Press and hold this button for more than 5 seconds to turn on or off the wireless |
|
 |
function of your router. |
|
WAN Port |
For connecting to a DSL/Cable modem, or an Ethernet port. |
|
Ethernet Ports (1/2/3/4) |
For connecting your PCs or other wired network devices to the router. |
|
Antennas |
Used for wireless operation and data transmitting. Upright them for the best Wi-Fi |
|
performance. |
||
 |
5
Chapter 2
Connect to the Internet
This chapter contains the following sections:
•Position Your Router
•Connect Your Router
Chapter 2 |
 |
2. 1. Position Your Router
•The product should not be located in a place where it will be exposed to moisture or excessive heat.
•Place the router in a location where it can be connected to multiple devices as well as to a power source.
•Make sure the cables and power cord are safely placed out of the way so they do not create a tripping hazard.
•The router can be placed on a shelf or desktop.
•Keep the router away from strong devices with strong electromagnetic interference, such as Bluetooth devices, cordless phones and microwaves.
2. 2. Connect Your Router
This mode enables multiple users to share Internet connection via ADSL/Cable Modem. 1. Follow the steps below to connect your router.
If your Internet connection is through an Ethernet cable directly from the wall instead of through a DSL / Cable / Satellite modem, connect the Ethernet cable to the router’s WAN port, and then follow Step 4 and 5 to complete the hardware connection.
Power adapter
4
Internet
1
2
Power adapter
3
1 ) |
Turn off the modem, and remove the backup battery if it has one. |
2 ) |
Connect the modem to the WAN port on your router with an Ethernet cable. |
3 ) |
Turn on the modem, and then wait about 2 minutes for it to restart. |
7
Chapter 2 |
 |
 |
 |
|
4 ) |
Connect the power adapter to the router and turn on the router. |
|||
5 ) |
Verify that the hardware connection is correct by checking these LEDs. |
|||
 |
Power |
2.4G |
5G |
Internet |
 |
On |
On |
On |
On |
Note:
If the 2.4G and 5.0G Wi-Fi LEDs are off, press and hold the Wi-Fi/WPS button on the rear panel for more than 5 seconds to turn them on.
2. Connect your computer to the router.
• Method 1: Wired
Turn off the Wi-Fi on your computer and connect the devices as shown below.
 |
 |
 |
Ethernet cable |
 |
|
• Method 2: Wirelessly |
 |
 |
 |
 |
|
1 ) |
Find the SSID (Network Name) and Wireless Password printed on the label at the bottom |
||||
 |
of the router. |
 |
 |
 |
 |
2 ) |
Click the network icon of your computer or go to Wi-Fi Settings of your smart device, |
||||
 |
and then select the SSID to join the network. |
 |
 |
||
 |
Computer |
 |
 |
 |
Smart Device |
 |
Connections are available |
 |
< Settings |
Wi-Fi |
|
 |
 |
 |
 |
||
 |
Wireless Network Connection |
 |
 |
Wi-Fi |
 |
 |
TP-Link_XXXX |
 |
OR |
CHOOSE A NETWORK... |
|
 |
TP-Link_XXXX_5G |
 |
 |
TP-Link_XXXX |
|
 |
Connect automatically |
Connect |
 |
||
 |
 |
TP-Link_XXXX_5G |
|||
Other...
• Method 3: Use the WPS button
Wireless devices that support WPS, including Android phones, tablets, most USB network cards, can be connected to your router through this method ( Not supported by iOS devices).
Note:
The WPS function cannot be configured if the wireless function of the router is disabled. Also, the WPS function will be disabled if your wireless encryption is WEP. Please make sure the wireless function is enabled and is configured with the appropriate encryption before configuring the WPS.
8
Chapter 2 |
 |
|
1 ) |
Tab the WPS icon on the device’s screen. Here takes an Android phone as an example. |
|
2 ) |
Immediately press the WPS button on your router. |
 |
Close to
Wi-Fi /WPS
9
Chapter 3
Login
This chapter introduces how to log in to the web management page of router.
Chapter 3 |
 |
With the web-based utility, it is easy to configure and manage the router. The webbased utility can be used on any Windows, Macintosh or UNIX OS with a Web browser, such as Microsoft the Internet Explorer, Mozilla Firefox or Apple Safari.
Follow the steps below to log in to your router.
1.Set up the TCP/IP Protocol in Obtain an IP address automatically mode on your computer.
2.Visit http://tplinkwifi.net, and log in with the username and password you set for the router. The default one is admin (all lowercase) for both username and password.
Note:
If the login window does not appear, please refer to the “FAQ” section.
11
Chapter 4
Configure the Router in
Standard Wireless Mode
This chapter presents how to configure the various features of the router working as a standard wireless router.
It contains the following sections:
•Status
•Network
•Wireless
•Guest Network
•DHCP
•Forwarding
•Security
•Parental Controls
•Access Control
•Advanced Routing
•Bandwidth Control
•IP&MAC Binding
•Dynamic DNS
•IPv6 Support
•System Tools
•Logout
Chapter 4 |
 |
4. 1. Status
1.Visit http://tplinkwifi.net, and log in with the username and password you set for the router.
2.Go to Status. You can view the current status information of the router.
•Firmware Version - The version information of the router’s firmware.
•Hardware Version - The version information of the router’s hardware.
•LAN - This field displays the current settings of the LAN, and you can configure them on the Network > LAN page.
•MAC address - The physical address of the router.
•IP address - The LAN IP address of the router.
•Subnet Mask - The subnet mask associated with the LAN IP address.
•Wireless - This field displays the basic information or status of the wireless function, and you can configure them on the Wireless > Wireless Settings page.
•Wireless Radio - Indicates whether the wireless feature is enabled or not.
13
Chapter 4 |
 |
•Name (SSID) - The SSID of the router.
•Mode - The current wireless working mode in use.
•Channel Width - The current wireless channel width in use.
•Channel - The current wireless channel in use.
•MAC Address - The physical address of the router.
•WDS Status - The status of WDS connection.
•WAN - This field displays the current settings of the WAN, and you can configure them on the Network > WAN page.
•MAC Address - The physical address of the WAN port.
•IP Address - The current WAN (Internet) IP Address. This field will be blank or 0.0.0.0 if the IP Address is assigned dynamically and there is no Internet connection.
•Subnet Mask - The subnet mask associated with the WAN IP Address.
•Default Gateway - The Gateway currently used is shown here. When you use Dynamic IP as the Internet connection type, click Renew or Release here to obtain new IP parameters dynamically from the ISP or release them.
•DNS Server - The IP addresses of DNS (Domain Name System) server.
•Traffic Statistics - The router’s traffic statistics.
•Received (Bytes) - Traffic in bytes received from the WAN port.
•Received (Packets) - Traffic in packets received from the WAN port.
•Sent (Bytes) - Traffic in bytes sent out from the WAN port.
•Sent (Packets) - Traffic in packets sent out from the WAN port.
•System Up Time - The length of the time since the router was last powered on or reset.
Click Refresh to get the latest status and settings of the router.
4. 2. Network
4. 2. 1. WAN
1.Visit http://tplinkwifi.net, and log in with the username and password you set for the router.
2.Go to Network > WAN.
3.Configure the IP parameters of the LAN and click Save.
Dynamic IP
If your ISP provides the DHCP service, please select Dynamic IP, and the router will automatically get IP parameters from your ISP.
14
Chapter 4 |
 |
Click Renew to renew the IP parameters from your ISP.
Click Release to release the IP parameters.
•MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet networks is 1500 Bytes. It is not recommended that you change the default MTU size unless required by your ISP.
•Use These DNS Servers - If your ISP providess you one or two DNS addresses, select Use These DNS Servers and enter the primary and secondary addresses. Otherwise, the DNS servers will be assigned dynamically from your ISP.
•Host Name - This option specifies the name of the router.
•Get IP with Unicast DHCP - A few ISPs’ DHCP servers do not support the broadcast applications. If you cannot get the IP address normally, you can choose this option. (It is rarely required.)
Static IP
If your ISP provides a static or fixed IP address, subnet mask, default gateway and DNS setting, please select Static IP.
• IP Address - Enter the IP address in dotted-decimal notation provided by your ISP.
15
Chapter 4 |
 |
•Subnet Mask - Enter the subnet mask in dotted-decimal notation provided by your ISP. Normally 255.255.255.0 is used as the subnet mask.
•Default Gateway - Enter the gateway IP address in dotted-decimal notation provided by your ISP.
•MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet networks is 1500 Bytes. It is not recommended that you change the default MTU size unless required by your ISP.
•Primary/Secondary DNS - (Optional) Enter one or two DNS addresses in dotteddecimal notation provided by your ISP.
PPPoE/Russia PPPoE
If your ISP provides PPPoE connection, select PPPoE/Russia PPPoE.
•User Name/Password - Enter the user name and password provided by your ISP. These fields are case-sensitive.
•Confirm Password - Enter the Password provided by your ISP again to ensure the password you entered is correct.
•Secondary Connection - It’s available only for PPPoE connection. If your ISP provides an extra connection type, select Dynamic IP or Static IP to activate the secondary connection.
•WAN Connection Mode
•Connect on Demand - In this mode, the Internet connection can be terminated automatically after a specified inactivity period (Max Idle Time) and be reestablished when you attempt to access the Internet again. If you want to keep your Internet connection active all the time, please enter 0 in the Max Idle Time
16
Chapter 4 |
 |
field. Otherwise, enter the number of minutes you want to have elapsed before your Internet access disconnects.
•Connect Automatically - The connection can be re-established automatically when it is down.
•Time-based Connecting - The connection will only be established in the period from the start time to the end time (both are in HH:MM format).
•Connect Manually - You can click Connect/Disconnect to connect/disconnect immediately. This mode also supports the Max Idle Time function as Connect on Demand mode. The Internet connection can be disconnected automatically after a specified inactivity period (Max Idle Time) and not be able to re-establish when you attempt to access the Internet again.
Note:
•Only when you have configured the system time on the System Tools > Time Settings page, will the time-based connecting function take effect.
•Sometimes the connection cannot be terminated although you have specified the Max Idle Time because some applications are visiting the Internet continually in the background.
If you want to do some advanced configurations, please click Advanced.
•MTU Size - The default MTU size is 1480 bytes. It is not recommended that you change the default MTU size unless required by your ISP.
•Service Name/AC Name - The service name and AC (Access Concentrator) name should not be configured unless you are sure it is necessary for your ISP. In most cases, leaving these fields blank will work.
•ISP Specified IP Address - If your ISP does not automatically assign IP addresses to the router, please select Use IP address specified by ISP and enter the IP address provided by your ISP in dotted-decimal notation.
17
Chapter 4 |
 |
•Detect Online Interval - The router will detect Access Concentrator online at every interval. The default value is 0. You can input the value between 0 and 120. The value 0 means no detect.
•Primary DNS/Secondary DNS - If your ISP does not automatically assign DNS addresses to the router, please select Use the following DNS servers and enter the IP address in dotted-decimal notation of your ISP’s primary DNS server. If a secondary DNS server address is available, enter it as well.
BigPond Cable
If your ISP provides BigPond cable connection, please select BigPond Cable.
•User Name/Password - Enter the user name and password provided by your ISP. These fields are case-sensitive.
•Auth Server - Enter the authenticating server IP address or host name.
•Auth Domain - Type in the domain suffix server name based on your location.
•MTU Size - The default MTU size is 1480 bytes. It is not recommended that you change the default MTU size unless required by your ISP.
•Connection Mode
•Connect on Demand - In this mode, the Internet connection can be terminated automatically after a specified inactivity period (Max Idle Time) and be reestablished when you attempt to access the Internet again. If you want to keep your Internet connection active all the time, please enter 0 in the Max Idle Time field. Otherwise, enter the number of minutes you want to have elapsed before your Internet access disconnects.
18
Chapter 4 |
 |
•Connect Automatically - The connection can be re-established automatically when it is down.
•Connect Manually - You can click Connect/Disconnect to connect/disconnect immediately. This mode also supports the Max Idle Time function as Connect on Demand mode. The Internet connection can be disconnected automatically after a specified inactivity period (Max Idle Time) and not be able to re-establish when you attempt to access the Internet again.
Note:
Sometimes the connection cannot be terminated although you have specified the Max Idle Time because some applications are visiting the Internet continually in the background.
L2TP/Russia L2TP
If your ISP provides L2TP connection, please select L2TP/Russia L2TP.
•User Name/Password - Enter the user name and password provided by your ISP. These fields are case-sensitive.
•Confirm Password - Enter the Password provided by your ISP again to ensure the password you entered is correct.
•Connect/Disconnect - Click this button to connect or disconnect immediately.
19
Chapter 4 |
 |
•Dynamic IP/ Static IP - Select either as required by your ISP. If Static IP is selected, please enter the IP address, subnet marsk, gateway and DNS also provided by your ISP.
•Internet IP Address/ Internet DNS - The Internet IP address and DNS server address assigned by L2TP server.
•Connection Mode
•Connect on Demand - In this mode, the Internet connection can be terminated automatically after a specified inactivity period (Max Idle Time) and be reestablished when you attempt to access the Internet again. If you want to keep your Internet connection active all the time, please enter 0 in the Max Idle Time field. Otherwise, enter the number of minutes you want to have elapsed before your Internet access disconnects.
•Connect Automatically - The connection can be re-established automatically when it is down.
•Connect Manually - You can click Connect/Disconnect to connect/disconnect immediately. This mode also supports the Max Idle Time function as Connect on Demand mode. The Internet connection can be disconnected automatically after a specified inactivity period (Max Idle Time) and not be able to re-establish when you attempt to access the Internet again.
Note:
Sometimes the connection cannot be terminated although you have specified the Max Idle Time because some applications are visiting the Internet continually in the background.
PPTP/Russia PPTP
If your ISP provides PPTP connection, please select PPTP/Russia PPTP.
20
Chapter 4 |
 |
|
 |
 |
 |
 |
 |
 |
•User Name/Password - Enter the user name and password provided by your ISP. These fields are case-sensitive.
•Confirm Password - Enter the Password provided by your ISP again to ensure the password you entered is correct.
•Connect/Disconnect - Click this button to connect or disconnect immediately.
•Dynamic IP/ Static IP - Select either as required by your ISP. If Static IP is selected, please enter the IP address, subnet marsk, gateway and DNS also provided by your ISP.
•Internet IP Address/ Internet DNS - The Internet IP address and DNS server address assigned by L2TP server.
•Connection Mode
•Connect on Demand - In this mode, the Internet connection can be terminated automatically after a specified inactivity period (Max Idle Time) and be reestablished when you attempt to access the Internet again. If you want to keep your Internet connection active all the time, please enter 0 in the Max Idle Time field. Otherwise, enter the number of minutes you want to have elapsed before your Internet access disconnects.
21
Chapter 4 |
 |
•Connect Automatically - The connection can be re-established automatically when it is down.
•Connect Manually - You can click Connect/Disconnect to connect/disconnect immediately. This mode also supports the Max Idle Time function as Connect on Demand mode. The Internet connection can be disconnected automatically after a specified inactivity period (Max Idle Time) and not be able to re-establish when you attempt to access the Internet again.
Note:
Sometimes the connection cannot be terminated although you have specified the Max Idle Time because some applications are visiting the Internet continually in the background.
4. 2. 2. MAC Clone
1.Visit http://tplinkwifi.net, and log in with the username and password you set for the router.
2.Go to Network > MAC Clone.
3.Configure the WAN MAC address and click Save.
•WAN MAC Address - This field displays the current MAC address of the WAN port. If your ISP requires you to register the MAC address, please enter the correct MAC address in this field. Click Restore Factory MAC to restore the MAC address of WAN port to the factory default value.
•Your PC’s MAC Address - This field displays the MAC address of the PC that is managing the router. If the MAC address is required, you can click Clone MAC Address and this MAC address will be filled in the WAN MAC Address field.
Note:
•You can only use the MAC Address Clone function for PCs on the LAN.
•If you have changed the WAN MAC address when the WAN connection is PPPoE, it will not take effect until the connection is re-established.
4. 2. 3. LAN
1.Visit http://tplinkwifi.net, and log in with the username and password you set for the router.
2.Go to Network > LAN.
3.Configure the IP parameters of the LAN and click Save.
22
Chapter 4 |
 |
|
 |
 |
 |
 |
 |
 |
•MAC Address - The physical address of the LAN ports. The value can not be changed.
•IP Address - Enter the IP address in dotted-decimal notation of your router (factory default - 192.168.0.254).
•Subnet Mask - An address code that determines the size of the network. Normally 255.255.255.0 is used as the subnet mask.
•IGMP Proxy - The Internet Group Management Protocol (IGMP) feature allow you to watch TV on IPTV-supported devices on the LAN .
Note:
•If you have changed the IP address, you must use the new IP address to log in.
•If the new IP address you set is not in the same subnet as the old one, the IP address pool in the DHCP Server will be configured automatically, but the Virtual Server and DMZ Host will not take effect until they are re-configured.
4. 3. Wireless
4. 3. 1. Basic Settings
1.Visit http://tplinkwifi.net, and log in with the username and password you set for the router.
2.Go to Wireless > Wireless Settings.
3.Configure the basic settings for the wireless network and click Save.
23
Chapter 4 |
 |
•Wireless Network Name - Enter a string of up to 32 characters. The default SSID is TP-LINK_XXXX (XXXX indicates the last unique four numbers of each router’s MAC address). It is strongly recommended that you change your network name (SSID). This value is case-sensitive. For example, TEST is NOT the same as test.
•Mode - Select the desired mode. It is strongly recommended that you keep the default setting 11bgn mixed, so that all 802.11b/g/n wireless devices can connect to
the router.
Note:
If 11bg mixed mode is selected, the Channel Width field will turn grey and the value will become 20M, and cannot be changed.
•Channel Width - Select any channel width from the drop-down list. The default setting is Auto, which can automatically adjust the channel width for your clients.
•Channel - This field determines which operating frequency will be used. The default channel is set to Auto. It is not necessary to change the wireless channel unless you notice interference problems with another nearby access point.
•Enable Wireless Router Radio - The wireless radio of the router can be enabled or disabled to allow or deny wireless access. If enabled, the wireless clients will be able to access the router.
•Enable SSID Broadcast - If enabled, the router will broadcast the wireless network name (SSID).
•Enable WDS Bridging - You can select this to enable WDS Bridging, with this function, the router can bridge two or more WLANs.
Note:
If this checkbox is selected, you had better make sure the following settings are correct.
•SSID (to be bridged) - The SSID of the AP your router is going to connect to as a client. You can also use the survey function to select the SSID to join.
•BSSID (to be bridged) - The BSSID of the AP your router is going to connect to as a client. You can also use the survey function to select the BSSID to join.
•Survey - Click this button, you can search the AP which runs currently.
•WDS Mode - This field determines which WDS Mode will be used. It is not necessary to change the WDS mode unless you notice network communication problems with
24
Loading...
