TP-Link AC1350, EC230-G1 Installation Guide

AC1350
Wireless Dual Band
Gigabit Router

Upgrade to Fast AC Wi-Fi and
gigabit connections

EC230-G1

450Mbps + 867Mbps
Dual Band Wi-Fi

Gigabit

Beamforming

Ports

Highlights

Highlights

MU-MIMO for 2 x Faster Connections

MU-MIMO technology serves up to two devices at once, reducing wait time,

increasing Wi-Fi throughput for every device, and making each stream more

ecient.

Beamforming for Better Corverage

Beamforming technology detects the location of your connected devices

and concentrates the EC230-G1's Wi-Fi towards them to create stronger

overall connections.

Traditional Router

Sends data to one device at a time

EC230-G1

Simultaneously sends data to multiple devices

EC230-G1 Regular Router

TP-Link AC1350 Wireless Dual Band Gigabit Router

EC230-G1

Highlights

Faster Wi-Fi for More Device

2.4GHz and 5GHz bands run at fast AC1350 Wi-Fi speeds to deliver more

bandwidth and support more devices in your home.

Gigabit Ethernet

Enjoy fast, reliable wired connections for gaming and streaming in the best quality.

Internet

Power

Reset

Access

450Mbps 2.4GHz

867Mbps 5GHz

Power

On/O

WPS/Wi-Fi

On/O

TP-Link AC1350 Wireless Dual Band Gigabit Router

Ethernet Ports

EC230-G1

Features

Ease of Use Security

· Intuitive Web UI – Ensure quick and simple installation without

hassle

· Fast Encryption – Quickly connect devices to Wi-Fi at the

push of a button without entering the password

Reliability

· Ultimate Wireless Speed – 450Mbps Wi-Fi speed on 2.4GHz

and 867Mbps Wi-Fi speed on 5GHz meet your daily internet
needs

· MU-MIMO – Simultaneously transfer data to multiple devices

for 2× faster

· Support 802.11 ac – Provide a data transfer rate 3 times

· Active Defense – Protect your home network with rewalls and

wireless encryption

· Multi-SSID – Provides dierent wireless access for dierent

applications and services

· Access Control – Establish a whitelist or blacklist to allow or

block certain devices from accessing the internet

faster than 802.11n for each stream

· IPTV – Support IGMP Proxy/Snooping, Bridge and Tag VLAN

to optimize IPTV streaming

! "#$%&'$# ()**#+,%)* - ($%#*, &..)+%&,%)* /)0 '),1 234567

!"# $%&' ()(!* +, -. () $/ #01+20,

· Parental Control – Manage when and how connected devices

can access the internet

Remark : The actual number of client will depend on real situation.

TP-Link AC1350 Wireless Dual Band Gigabit Router

EC230-G1

Specications

Hardware

· Chipset : Qualcomm

· CPU speed : 775MHz

· RAM Type : 128MB DDR2

· ROM : 16MB

· Ethernet Ports: 4*10/100/1000Mbps LAN Ports, 1*10/100/1000Mbps WAN Port

· Buttons: Reset Button, Power On/Off Button, WPS/Wi-Fi On/Off Button

· Antennas: 4 Fixed Omni Directional Antennas 2 * (2.4G：5dBi) 2 * (5G：5dBi)

· External Power Supply: 12V/1A

· Dimensions (W x D x H): 9.1 × 5.7 × 1.4 in (230 × 144 × 35 mm)

Software

· WAN Type: Multi- EWAN, Dynamic IP, Static IP, PPPoE, PPTP, L2TP

· DHCP: Server, DHCP Client List, Address Reservation

· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ

· VPN Passthrough: PPTP, L2TP, IPSec

· VPN Server: PPTP, OpenVPN

· Dynamic DNS: DynDns, NO-IP

· Access Control: Parental Controls, Local Management Control, Host List, White

List, Black List

· Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding

· Protocols: IPv4, IPv6

Wireless

· Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz

· Frequency: 2.4GHz and 5GHz

· Signal Rate:

5GHz: Up to 867Mbps

2.4GHz: Up to 450Mbps

· Wireless Function: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Schedule,

Wireless Statistics, AP mode

· Wireless Security: 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption

· Management: Access Control, Local Management, Remote Management,

TR-069,TR-098,TR181,TR-111,TR143

TP-Link AC1350 Wireless Dual Band Gigabit Router

EC230-G1

Specications

Others

· Package Contents

Wireless Router EC230-G1

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

· Certication

CE, RoHS

· Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉)

Storage Temperature: -40℃~70℃ (-40℉ ~158℉)

· System Requirements

Microsoft Windows 10/8.1/8/7/Vista/XP/2000/NT/98SE, MAC OS,
NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome

20.0, Safari 4.0, or other Java-enabled browser Cable or DSL Modem

Subscription with an internet service provider (for internet access)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
