TPI HF684TC Specifications Sheet

30 AMP Plug
NEMA #6-30P

30 AMP Plug
NEMA #6-30P

30 AMP Plug
NEMA #6-30P

474 Series 240 Volt Dual Heat Fan Forced Portable Heater

80

• 2000W & 4000W heat settings

• Temperature control thermostat

• Manual reset type limit control

• 6’ long - 3 conductor cord

• Imported to TPI Corporation

Width: 16”

Height: 16”

Depth: 8-1/2”

20 AMP Plug
NEMA #6-20P

specications

UPC#

686334

446181 H474TM-C 2000 / 4000 13652 240 8.3 / 16.6 1 20

MODEL WAT T S

MAX

VOLTS AMPS PHASE

BTU's

5800 Series Garage/Workshop 240/208 Volt Fan Forced Portable Heater

• Up to 4800 Watts of heating comfort for
garage or utility room applications

• 4000 Watts available for smaller areas.

• Built in bi-metal double pole

thermostat - 50° to 90° range.

• Steel tubular heating element

• Wall/Ceiling bracket included

• Manual reset standard

• Power on and overheat pilot lights

UPC#

686334

503402 HF5840TC 4000/3000 13652

503396 HF5848TC 4800/3600 15086 20 / 17.3 30 Amp

MODEL WATT S

MAX

BTU's

VOLTS AMPS PHASE

240 / 208

• Imported to TPI Corporation

specications

ITEM WIDTH HEIGHT DEPTH

Heater 10.625 11” 9.625”

Bracket 2.5” 10” 14.0”

PLUG
TYPE

16.6 / 14.4

20 Amp

1

WT.

(LBS)

WT.

(LBS)

17

ICH Series 240/208 Volt Construction Site/Utility Fan Forced Portable Heater

• Operates on 240V or 208V

• Steel tubular heating element

• 43°F air heat rise

• Internal overheat thermostat

• Temperature control thermostat

• 6’ long cordset

UPC#

686334

450874 ICH-240C 4000 / 3000 13648 240 / 208 16.7 / 14.4 1 15

MODEL WATTS

• Imported to TPI Corporation

specications

Width: 10 5/8”

Height: 12 3/4”

MAX

BTU's

20 AMP Plug
NEMA #6-20P

VOLTS AMPS PHASE

Depth: 10”

WT.

(LBS)

680 Series “Bulldog” 240/208 Volt Fan Forced Portable Unit Heater

Swivel base allows unit to be wall, oor, or

ceiling mounted.

• Operates on 240V or 208V

• Finned steel tubular heating element

• Internal manual reset thermal cut-out

• 6’ long cord with molded plug

• Temperature control thermostat with 35°F to 85°F range

• 10’ air throw - 262 CFM

• Imported to TPI Corporation specications

UPC#

686334

446280

446297 HF685TC 4800/3600 16384/12288 240/208 1 20.0/17.4 58oF 20

446303 HF686TC 5600/4200 19107/14330 240/208 1 23.4/20.2 75 oF 20

683500 A1560

* HF684TC UL listed only

MODEL WATTS

*HF684TC

4000/3000 13652/10239 240/208 1 16.7/14.5 48 oF 20

OPTIONAL WALL CEILING BRACKET FOR HF680 & ICH 240C SERIES

MAX

BTU's

VOLTS PHASE AMPS

20 AMP Plug
NEMA #6-20P

HF684TC HF685TC,

Width: 13 1/2”

Height: 17 1/2”

Depth: 11 1/2”

HEATERS

30 AMP Plug
NEMA #6-30P

HF686TC

TEMP

RISE

WT.

(LBS)
