Page 1
THINK
Commercial High-Quality
Sheetfed Inks
The NEX Wave of Printing Solutions
Sheetfed inks developed to perform with paper substrates formulated with low cost fillers, and are compatible
with hydrophobic and hydrophilic surfaces. The large ink-water window will reduce picture framing and water
emulsification while also providing high gloss and reduced VOC’s.
Product Overviews
HYPLUS 100 NEX* our solvent-free sheetfed offset ink,
delivers excellent results, has very good rub resistance, dries to
a very high gloss and will not chalk or ghost, It can be UV
coated, aqueous coated, laminated, as well as other postpress
options.
HYPLUS EC NEX†is our most popular process ink. It provides
strong contrast and high density while maintaining low dot gain
under a variety of screening applications. It dries to a very high
gloss and is compatible with UV and aqueous coatings.
HYUNITY NEX†achieves excellent contrast and high density
while maintaining low dot gain. It has very good rub r
dries to a very high gloss and has a wide water window
esistance,
.
1-866-969-TOYO (8696) • www.toyoink.com
*
†
Page 2
THINK
Commercial High-Quality
Sheetfed Inks
Features and Benefits
■ HYPLUS 100 NEX
Features
• Soy oil based
• Solvent free
• Quick setting
• High gloss and good rub
• High pigmentation
• Environmentally friendly
Benefits
• No VOC-related problem
• Fast turnaround
• Wide paper range
• Sharp dot, high mileage
• UV coatable
• Laser safe
■ HYPLUS EC NEX
Features
• Soy oil based
• High-gloss pigment load
• Low water pickup
• Quick setting
• Color and dot consistency batch to batch
stay open property
Benefits
• High print contrast with low dot gain
• Faster makeready with less emulsification
• Fast turnaround
• Less color variation with better matched reprints
■ HYUNITY NEX
Features
• Soy oil based
High gloss
•
• Wide water window
• Quick setting
• Color and dot consistency batch to batch
Benefits
• High print contrast with low dot gain
• Easy key control
• Fast turnaround
Less color variation with better matched r
•
For technical assistance, call 1-866-969-8696.
Printed with Toyo Ink
*
eprints
†
Specifications
■ HYPLUS 100 NEX
Packaging
1 kilo (2.2 lbs.) and 5 lb. cans, Accel and Technotrans tubes.
Technical Data
ellow Magenta Cyan Black
Y
M Series (Medium Tack)
Tack: 13.0 14.0 15.5 15.5
Flow: 16.5 17.5 15.0 18.0
L Series (Low Tack)
Tack: 12.0 13.0 14.5 13.0
low: 17.0 16.0 17.0 18.5
F
VOC (lb/gal) 0-0.10 0-0.10 0-0.10 0-0.10
Test Method: EPA 24
Recommended Densities
Narrow band: 1.30-1.40 1.35-1.55 1.35-1.50 1.80-2.00
Wide band: 0.90-1.10
Test conditions: Tack Ink-O-Meter 800 rpm@90˚ F Flow/Spread-O-Meter Radius (mm) / 25° C
ay contain up to 3%VOCs due to manufacturing process
M
Note: Actual tack and flow on the press vary due to ink film thickness, image area, press speed, fountain solution
and also the condition of the press and pressroom. The merchandise herein contained is sold without warranties
e
xpress or implied. These conditions shall not be waived other than by an offer of the seller in writing.
■ HYPLUS EC NEX
Packaging
1 kilo (2.2 lbs.) and 5 lb. cans, Accel and Technotrans tubes.
Technical Data
Yellow Magenta Cyan Black
M Series (Medium Tack)
Tack: 12.0 13.5 16.5 15.5
Flow: 18.5 17.5 16.5 16.5
VOC/LB/GAL 1.49 1.27 0.99 0.95
L Series (Low Tack)
Tack: 10.0 11.5 13.5 12.5
Flow: 19.5 18.0 17.0 17.5
VOC/LB/GAL 1.37 0.88 0.96 0.87
Test conditions: Tack Ink-O-Meter 800 rpm@90˚ F Flow/Spread-O-Meter Radius (mm) / 25° C
Note: Actual tack and flow on the press vary due to ink film thickness, image area, press speed, fountain solution
and also the condition of the press and pressroom. The merchandise herein contained is sold without warranties
express or implied. These conditions shall not be waived other than by an offer of the seller in writing.
■ HYUNITY NEX
Packaging
1 kilo (2.2 lbs.) and 5 lb. cans, Accel and Technotrans tubes.
echnical Data
T
Yellow Magenta Cyan Black
M Series (Medium Tack)
Tack: 12.0 13.5 16.5 15.5
Flow: 18.5 17.5 16.5 16.5
VOC/LB/GAL
L Series (Low T
Tack: 10.0 11.5 13.5 12.5
Flow: 19.5 18.0 17.0 17.5
VOC/LB/GAL
Test conditions: Tack Ink-O-Meter 800 rpm@90˚ F Flow/Spread-O-Meter Radius (mm) / 25° C
Note: Actual tack and flow on the pr
and also the condition of the press and pressroom. The merchandise herein contained is sold without warranties
express or implied. These conditions shall not be waived other than by an offer of the seller in writing.
1.49
ack)
1.37
1.27 0.99 0.95
0.88
y due to ink film thickness, image area, press speed, fountain solution
ess var
0.96 0.87
