We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2004/108/EC Electromagnetic Compatibility Directive.
2006/95/EC Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food (LFGB section 30 & 31).
RKW Quality Assurance, United Kingdom.
Guaranteeforspareparts
The spares and accessories are guaranteed for
1 year from date of purchase.
The main body and housing are guaranteed
for the extended free warranty subject to
registration.
If any defect arises due to faulty materials of
workmanship, the faulty products must be
returned to the place of purchase.
Refund or replacement is at the discretion of
the retailer.
Should you encounter problems or require
a replacement part, please consult the
list below and then contact The Tower
Customer Service Department on:
+44 (0) 333 220 6066.
Any necessary spare parts may be ordered
from the Tower website.
Your warranty becomes void should you decide
to use non Tower spare parts. Spare parts can be
purchased from www.towerhousewares.co.uk
5
Page 6
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
2IMPORTANTSAFETYINFORMATION
Please read these notes carefully BEFORE using your Tower appliance
• Check that the voltage of the main
circuit corresponds with the rating of the
appliance before operating.
• If the supply cord or appliance is
damaged, stop using the appliance
immediately and seek advice from the
manufacturer, its service agent or a
similarly qualied person.
• Do not let the cord hang over the edge
of a table or counter or let it come into
contact with any hot surfaces.
• Do not carry the appliance by the power
cord.
• Do not use any extension cord with this
appliance.
• Do not pull the plug out by the cord as
this may damage the plug and/or the
cable.
• Switch o at the wall socket then remove
the plug from the socket when not in use
or before cleaning.
• Switch o and unplug before tting or
removing tools/attachments, after use and
before cleaning.
• Close supervision is necessary when any
appliance is used by or near children.
• Children should not play with the
appliance.
• This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
• Cleaning and user maintenance should
not be undertaken by children without
supervision.
• Take care when any appliance is used
near pets.
• Do not use this product for anything other
than its intended use.
• This appliance is for household use only.
CAUTIONS
• Do not operate the microwave with the
door open due to the safety interlocks
built into the door mechanism. It is
important not to tamper with the safety
interlocks (safety interlocks automatically
switch o any cooking activity when
the door is opened). This could result in
harmful exposure to excessive microwave
energy.
• Do not place any object (such as
kitchen towels, napkins, etc.) between
the microwave front face and the door
or allow food or cleaner residue to
accumulate on sealing surfaces.
• Do not operate the microwave if it is
damaged. It is particularly important that
the microwave door closes properly and
that there is no damage to the:
Door Hinges and latches
Door seals and sealing surfaces
• Please ensure cooking times are correctly
set, small amounts of food require shorter
cooking or heating time. Over cooking
may result in the food catching on re and
subsequent damage to the microwave.
• When heating liquids, e.g. soups, sauces
and beverages in your microwave,
avoid using straight sided containers
with narrow necks. Stir the liquid before
placing the container in the microwave
and again halfway through the heating
time. After heating, let it stand, stir or
shake it again carefully and check the
temperature of it before consuming
to avoid burns (especially, contents of
feeding bottles and baby food jars).
• An exhaust outlet is located on the top,
bottom or side of the microwave. Don’t
block the outlet. It could result in damage
to your microwave and poor cooking
6
Page 7
Safety and Instruction Manual
Helpline: +44 (0) 333 220 6066
• Do not operate the microwave when
empty. It is best to leave a glass of water
in the microwave when not in use. The
water will safely absorb all microwave
energy if the microwave is accidentally
started.
• Improper use could result in damage to
the microwave.
• Do not use wooden containers and
ceramic containers that have metallic
(e.g. gold or silver) inlays. Always remove
metal twist ties. Check that the utensils
are suitable for use in the microwave
before use. They may heat up and char.
Metal objects in particular may arc in the
microwave, which can cause serious
damage.
• Do not rinse the turntable by placing it in
water just after cooking. This may cause
breakage or damage.
• Before cooking pierce the skin of
potatoes, apples or any such fruit or
vegetables. They could burst.
• Do not cook eggs in their shell. Eggs in
their shell and whole hard-boiled eggs
should not be heated in microwave since
they may explode, even after microwave
heating has ended. Pressure will build up
inside the egg which will burst.
• Do not attempt deep fat frying in your
microwave. This could result in a sudden
boil over of hot liquid.
• If smoke is observed, switch o or
disconnect the microwave from the power
supply and keep the microwave door
closed in order to stie any ames. It can
cause serious damage such as re or
electric shock.
• When food is heated or cooked in
disposable containers made of plastic,
paper or other combustible materials
keep an eye on the microwave and check
it frequently.
• The microwave should be cleaned
regularly and any food deposits should
be removed. Failure to maintain the
microwave in a clean condition could lead
to deterioration of the surface. This could
adversely aect the life of the appliance
and possibly result in a hazardous
situation.
• Follow exact directions given by each
manufacturer for their popcorn product.
Do not leave the oven unattended while
corn is being popped. If corn fails to pop
after the suggested times, discontinue
cooking. Never use a brown paper bag
for popping corn. Never attempt to pop
leftover kernels. Overcooking could result
in the corn catching re.
• Do not use harsh abrasives cleaners
or sharp metal scrapers to clean the
microwave door glass. They can scratch
the surface, which may result in the glass
shattering.
• After cooking, the container is very hot.
Using gloves to take out the food and
avoid steam burns by directing steam
away from the face and hands.
• This appliance is intended to be used in
household and similar applications such
as:
Sta kitchen areas in shops.
Oces and other working environments.
Farm houses.
By clients in hotels, motels and other
residential environments, bed & breakfast
type environments.
• The microwave oven is intended for
heating food and beverages. Drying of
food or clothing and heating of warming
pads, slippers, sponges, damp cloth and
similar may lead to risk of injury, ignition
or re.
• The door or outer surface may get hot
when the appliance is operating.
• In the unlikely event the appliance
develops a fault, stop using it immediately
and seek advice from the service
department:
+44 (0) 333 220 6066
7
Page 8
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
3USINGYOURAPPLIANCE
Beforerstuse:
Take out all the packing, if there is a safe lm over
the oven, tear it o before use. Check carefully
for damage. If any, immediately notify dealer or
send to the manufacturer’s Service Centre.
Microwave ovens must be placed under dry and
non-corrosiveness environments, kept away from
heat and humidity, such as gas burner or water
tank.
To ensure sucient ventilation, the distance of
the back of microwave to the wall should be
at least 10 cm, the side to the wall should be
at least 5 cm, the free distance above the top
surface at least 20 cm. The distance of the
microwave to the ground should be at least
85cm.
The position of the oven shall be such that it
is far from the TV, Radio or antenna as picture
disturbance or noise may occur.
The appliance must be positioned so that the
plug is accessible, and has a good grounding in
case of leakage. A ground loop can be formed to
avoid electric shock.
The microwave oven must be operated with the
door closed.
The microwave oven must not be placed in a
cabinet.
The microwave oven is intended to be used freestanding.
The back of the oven must be placed against a
wall.
During rst use the microwave oven may omit
an odour and slightly smoke. This is due to
manufacturing residue or oil on the heat element
or oven cavity. This is normal and should not
occur after several uses. Keep doors and
windows open to ensure good ventilation. It
is recommended to place a cup of water on
the turntable on set on high and operate the
microwave oven several times to help clean the
microwave of residue.
TheControlPanel:
The control panel consists of two dials for power
and timer settings.
PowerDial:
You use this operator dial
to choose a cooking power
level. It is the rst step to
starting a cooking session.
Power Setting
100% High
85% M.High
66% Medium
48% M.Low
40% Defrost
17% Low
TimerDial:
The Timer dial oers visual
timing settings at easy turn
of your thumb to select a
desired cooking time up
to 30 minutes per cooking
session.
8
Page 9
Safety and Instruction Manual
Helpline: +44 (0) 333 220 6066
Microwavecooking:
For pure microwave cooking, there are six power
levels from which to choose one as best t to do
the job at hand. Power level increases with the
dial turning clockwise. The power levels can be
classied as the following:
Tostartacookingsession:
1. Place food in oven and close the door.
2. Turn Power Selector to select a power level.
3. Use Timer dial to set a cooking time.
NOTE: As soon as the timer is turned, the
microwave starts cooking.
When selecting time for less than 2 minutes, turn
timer past the 2 minute marker and then return to
the correct required time.
CAUTION: ALWAYS RETURN TIMER BACK TO
ZERO POSITION.
To stop oven during cooking process, push the
door release button or open the door by the
handle.
Utensilsguideline:
It is strongly recommended to only use
containers which are suitable and safe for
microwave cooking. Generally speaking,
containers made of heat-resistant ceramic, glass
or plastic are suitable for microwave cooking.
Never use metal containers for microwave
cooking and combination cooking as sparks are
likely to occur and there is a risk of re or injury.
When cooking microwave meals, always check
the packaging to see which parts are microwave
safe. Use the below table as reference:
Material
Heat
resistant
ceramic
Heat
resistant
plastic
Heat
resistant
glass
Plastic lmYes
Grill rackNo
Metal
container
lacquerNo
Bamboo
wood and
paper
Cling lmYes
Microwave
Safe
Yes
Yes
Yes
No
No
Notes
Never use the
ceramics which are
decorated with a
metal rim or glazed.
Cannot be used for
extended periods
of time when mi
crowave cooking.
Not to be used
when cooking meat
or chops as the
high temperature
may damage the
Never to be used
in the microwave.
Microwaves cannot
penetrate through
metal. Microwav
ing with a metal
container can result
in re.
Poor heat-resistant.
Cannot be used for
High-temperature
cooking
Poor heat-resistant.
Cannot be used for
High-temperature
cooking
Cling lm can be
used as long as
it is pierced to let
steam escape, and
it not touching the
food.
-
lm.
-
9
Page 10
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
Caution!: There are a number of accessories
available on the market. Before you buy, make
sure they are suitable for microwave use.
When you put food into the Microwave, ensure
that the food, food supports and/or covering
do not come in direct contact with any of the
internal walls or the ceiling of the cavity since
discolouration may take place.
Some plastics are heat-proof only to certain
temperatures. Check carefully!
Always remove lids of jars and containers,
including take away food containers, before
you cook using your microwave. If you don’t
remove the lids, then steam and pressure can
build up inside and cause an explosion even after
microwave cooking has stopped.
Do not use straight sided containers with narrow
necks when heating liquid. Use extreme care
when inserting a spoon or other utensils into the
container.
Cookingtips:
The following factors may aect the cooking
result:
Foodarrangement
Place thicker areas towards the outside of the
dish with the thinner parts towards the centre.
Spread it evenly and avoid overlap if possible.
Cookingtimelength
Begin cooking on a shorter time setting and
evaluate the food after it times out.
Extend the time according to the actual need.
Over cooking may result in burnt food and
smoke.
Piercing
Food such as potatoes, sh, chicken and
sausages all need to be pierced in several places
before cooking, so that steam does not build up
and cause the food to explode.
Cookingfoodevenly
Food such as chicken, burgers or steak should
be turned once during cooking.
Depending on the type of food, if applicable, stir
from outside to the centre of the dish once or
twice during cooking.
Allowstandingtime
Once the cooking time has nished, allow food
to stand in the Microwave for a few minutes. This
allows the food to complete its cooking cycle
and to cool down naturally.
Ifthefoodiscookedfully:
The colour and rmness of food help to
determine whether it done.
The following signs show that the food is ready:
• Steam coming out from all parts of food,
not just the edge
• Joints of poultry can be moved easily
• Pork or poultry show no signs of blood
• Fish is opaque and can be sliced easily with
a fork
Browningdish
When using a browning dish or self-heating
container, always place a heat-resistant insulator
such as a porcelain plate under it to prevent
damage to the turntable and rotating ring.
10
Page 11
Safety and Instruction Manual
Helpline: +44 (0) 333 220 6066
Microwavesafeplasticwrap
When cooking food with high fat content, do not
allow the plastic wrap come into contact with
food as it may melt.
4TROUBLESHOOTING&FAQ’S
QuestionsAnswers
Is it normal for the turntable
to turn in either direction?
Can I operate my
microwave whilst it is
empty?
Can I open the door whilst
the microwave is running?
Why is my microwave
sparking?
I am trying to cook eggs
and they are popping.
What do I do?
My microwave is taking
longer to cook food than
the cooking guide says.
Can I operate my
microwave without the
turntable?
What does standing
time mean and why is it
recommended?
Yes. The turntable can rotate clockwise or anti-clockwise, depending on
the rotation of the motor when the cooking cycle starts.
No, never run it empty or with a very small load for a long period of time as
this will damage the microwave.
You can open the door at any point during cooking. The microwave energy
will automatically switch o when the door is opened, and the time setting
will pause until the door is closed.
If you see sparks in your microwave, turn it o immediately. Sparks can be
caused by:
metal or aluminium foil that touches the interior of the microwave, metal
from a closing strip or tableware with metallic edges; recycled paper
that contains small metal particles and aluminium foil that is not correctly
covering the food.
Remove anything from the Microwave that may contain metal. Refer to
the Utensils Guideline in this manual for reference of what containers are
microwave safe.
When you bake or poach eggs, the yolk can pop due to a build-up of
steam inside the yolk membrane. Pierce the yolk with a toothpick before
cooking. Never cook eggs without rst piercing their shells.
Variations in the size, shape and weight of your food can aect cooking
times.
Cooking guide times and heat settings should be used as suggestions to
help prevent over-cooking. If you nd the cooking time or temperature is
not suited to your ingredients, adjust accordingly.
No. If you remove the turntable you will get poor cooking results. Ensure
that all dishes used in the Microwave t correctly on to the turntable.
Standing time means that food should be removed from the Microwave
and allowed to ‘stand’ for an additional time to let it nish cooking.
This is important because with microwave cooking, the heat is held in the
food, not in the oven. Many foods build up enough internal heat to allow
the cooking process to continue, even after the food is removed from the
oven. Standing time for joints of meat, large vegetables and cakes is to
allow the inside to cook completely, without overcooking the outside.
Most directions on microwavable food will note how much standing time is
required.
Microwavesafeplasticcookware
Some microwave safe plastic cookware might
not be suitable for cooking foods with high fat
and sugar content. The preheating time specied
in the dish instruction manual must not be
exceeded.
11
Page 12
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
5CLEANING&CARE
The microwave should be cleaned regularly
and any food deposits removed.
Remove the power cord from the wall outlet
before cleaning. Don’t immerse the appliance
in water or other uids when cleaning.
Failure to maintain the microwave in a clean
condition could lead to deterioration of the
surface. This could adversely aect the life
of the appliance and possibly result in a
hazardous situation.
Never use hard detergent, gasoline, abrasive
powder or metal brush to clean any part of
the appliance.
Do not remove the waveguide cover.
After lengthy use, it is possible for odors to
emit from the Microwave.
The following 3 points are some methods to
remove odors or unpleasant smells:
1. Place several lemon slices in a cup, then
heat with high Micro Power for 2-3 min.
2. Put some orange peel into the
Microwave, and then heat them with high
Micro Power for 1 minute.
Tipsforcleaning
If the seal of the microwave is dirty, it may
stop the door from closing properly. Keep the
seal clean.
Residue of food from spillovers or splatters
will attract microwave energy causing it to
burn on. This could reduce the eciency of
the microwave and may cause bad odours.
Details for cleaning door seals, cavity and
adjacent parts:
• Exterior: Wipe the enclosure with a
dampened soft cloth
• Door: Using a dampened soft cloth, wipe
clean the door and window. Wipe the
door seals and adjacent parts to remove
any spills. Wipe the control panel with a
slightly dampened soft cloth.
• Interior walls: Wipe clean the cavity with
a dampened soft cloth. Wipe clean the
waveguide cover to remove any food
remnants.
• Turntable / Rotation ring / Rotation axis:
Wash with mild soap water. Rinse with
clean water and allow drying thoroughly.
Note: Do not remove the Waveguide cover
during cleaning.
Make sure the Waveguide cover is installed
correctly and has not been damaged during
cooking.
Spicy sauces such as ketchup and mustard,
or salty dishes such as salted meat contain
ingredients that can erode the surface.
After use, you should always clean the oven
interior.
12
Page 13
Safety and Instruction Manual
Helpline: +44 (0) 333 220 6066
FUSE
6RECYCLING
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
7WIRINGSAFETYFORUKUSEONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains
lead are coloured in accordance with the
following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must be
connected to the terminal marked [N] or coloured
black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
The wire coloured green/yellow must be
connected to the terminal marked with the letter
[E] or marked
.
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - and then cut it o the mains
lead and immediately dispose of its safely. Never
attempt to reuse the plug or insert it into a socket
outlet as there is a danger of an electric shock.
.
WARNING:
This Appliance MUST be Earthed
13
Page 14
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
8SERVICINGSAFEGUARDS-MICROWAVERADIATION
It is hazardous for anyone, other than a
qualied service technician, to carry out any
service for repairing operation which involves
removal of any cover which gives protection
against exposure to microwave energy.
The temperature of accessible surfaces may
be high when the appliance is operating.
The high voltage capacitor remains charge
after disconnection; short the negative
terminal of h. V capacitor to the oven chassis
(use a screwdriver) to discharge before
touching.
During servicing below listed parts are liable
to be removed and give access to potentials
above 250V to earth.
Magnetron
High voltage transformer
High voltage capacitor
High voltage diode
High voltage fuse
The following conditions may cause undue
microwave exposure during servicing.
Improper tting of magnetron;
Improper matching of door interlock, door
hinge and door;
Improper tting of switch support;
Door, door seal or enclosure has been
damaged.
14
Page 15
Safety and Instruction Manual
Helpline: +44 (0) 333 220 6066
9WARRANTY
Wehopethatyouwillenjoy
yourTowerMicrowave
Ovenformanyyears.
Asathankyoufor
purchasingoneofour
fantasticproducts,
wearegivingyou3years
peaceofmind.
This product is guaranteed for 12 months from
the date of original purchase.
If any defect arises due to faulty materials of
workmanship, the faulty products must be
returned to the place of purchase.
Refund or replacement is at the discretion of
the retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase.
• The product must be installed and
used in accordance with the instructions
contained in this instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear, damage,
misuse or consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire Only.
To receive your 3 year
guarantee, simply register
your appliance
online by visiting
www.towerhousewares.co.uk
The standard one year guarantee is only
extended to the maximum available for each
particular product upon registration of the
product within 28 days of purchase. If you
do not register the product with us
within the 28 day period, your product is
guaranteed for 1 year only.
To validate your extended warranty, please
visit www.towerhousewares.co.uk and register
with us online. Alternatively, call our customer
registration line on +44 (0) 333 220 6066.
Please note that length of extended warranty
oered is dependent on product type and
that each qualifying product needs to be
registered individually in order to extend its
warranty past the standard 1 year.
Extended warranty is only valid with proof of
purchase.
15
Page 16
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
10 YOUR RECEIPT
Ax your store receipt to this page for safe
keeping.
16
Page 17
Safety and Instruction Manual
Helpline: +44 (0) 333 220 6066
NOTES
17
Page 18
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
NOTES
18
Page 19
Safety and Instruction Manual
Helpline: +44 (0) 333 220 6066
NOTES
19
Page 20
thank you!
We hope you enjoy your appliance for
many years. As a thank you for purchasing
one of our fantastic products, we are giving
you an extra 2 years peace of mind.
*To receive your extra 2 years guarantee,
register your appliance online by visiting:
www.towerhousewares.co.uk
Should you have a problem with your
appliance, or need any spare parts,
please call our Service Department on:
+44 (0) 333 220 6066
Your warranty becomes void should you decide
to use non Tower spare parts. Spare parts can be
purchased from www.towerhousewares.co.uk
great british design, innovation and excellence since 1912
1215.V1
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
