HDMI 1.3 Extender over Signal

CAT5/CAT6 Cable

Model #: HDMI-C5-3-SET

© 2010 Avenview Inc. All rights reserved.

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or warranties with

respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any

time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in

Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products

including, but not limited to, the implied warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.
Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly prohibited.

2

Table of Contents

Section 1: Getting Started ...................................................................................................................... 3

1.1 Important Safeguards ............................................................................................................ 3

1.2 Safety Instructions ................................................................................................................. 3

1.3 Regulatory Notices Federal Communications Commission (FCC) ......................................... 4

1.4 Introduction ........................................................................................................................... 4

1.5 Package Contents ................................................................................................................... 5

1.6 Before Installation.................................................................................................................. 5

1.7 Panel Description ................................................................................................................... 6

1.8 Installation ............................................................................................................................. 9

1.9 EDID Learning ......................................................................................................................... 9

1.10 General Troubleshooting ..................................................................................................... 10

Section 2: Specifications ....................................................................................................................... 10

3

Section 1: Getting Started

1.1 Important Safeguards

Please read all of these instructions carefully before you use the device. Save this manual for future

reference.

What the warranty does not cover

Any product, on which the serial number has been defaced, modified or removed.



Damage, deterioration or malfunction resulting from:



Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized



product modification, or failure to follow instructions supplied with the product.

Repair or attempted repair by anyone not authorized by us.



Any damage of the product due to shipment.



Removal or installation of the product.



Causes external to the product, such as electric power fluctuation or failure.



Use of supplies or parts not meeting our specifications.



Normal wear and tear.



Any other causes which does not relate to a product defect.



 Removal, installation, and set-up service charges.

1.2 Safety Instructions

The HDMI-C5-3-SET, HDMI 1.3 Extender over Signal CAT5 has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However, like all electronic
equipments, the HDMI-C5-3-SET should be used with care. Read the following safety instructions to protect
yourself from possible injury and to minimize the risk of damage to the unit.

Do not dismantle the housing or modify the module.



Dismantling the housing or modifying the module may result in electrical shock or burn.



Refer all servicing to qualified service personnel.



Do not attempt to service this product yourself as opening or removing housing may expose you to



dangerous voltage or other hazards

 Keep the module away from liquids.
 Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid

falls or spills on to the housing, unplug the module immediately.

 Have the module checked by a qualified service engineer before using it again.
 Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

4

1.3 Regulatory Notices Federal Communications Commission (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this

equipment.

1.4 Introduction

The Avenview HDMI-C5-3-SET HDMI 1.3 over Single CAT5 Extender boosts up your video/audio transmission
distance up to 60m (200ft) in HDTV 1080i format, 40m (130ft) in HDTV 1080p format, and 20m (65ft) in HDTV
1080p with 36 bit color depth. With only one cost effective LAN cable, users can easily extend HDTV sources
from DVD players, Blu-ray Disc player, PS3, PC, and any other HDMI sources compliant with TMDS to distant
display monitors including HDMI/DVI enabled TV sets or LCD PC monitors. With the state-of-the-art Silicon
Image chipsets equipped, deep color video, DTS-HD or Dolby TrueHD audio, and HDCP supports and
compatibility are all further insured. This flexibility makes HDCP compliant DVD players or PS3 transmit utmost
high quality video and audio with a greater distance at the minimal cost, when integrating several components
apart.

The HDMI-C5-3-SET consists of Transmitter (HDMI-C5-3-S) and Receiver (HDMI-C5-3-R). The Transmitter
(HDMI-C5-3-S) captures the input HDMI/DVI signals and carry the signals through one RJ-45 connector into
one cost effective CAT-5/5e/6 LAN cable. The Receiver (HDMI-C5-3-R) equalizes the sent TMDS multimedia
data. The transmission distance between the sending and receiving units can be up to 60m (200ft) under HD
(720p/1080i) or 40m (130ft) under Full HD (1080p). With an 8-level equalization control knob on the receiving
unit, users can adjust the equalization strength to the received TMDS signals accordingly, and therefore
optimize the transmission distance between source and destination.

- Silicon Image chipset embedded for best compatibility and reliability HDMI video input supports up to

1080p resolution

- HDMI 1.3c Compliant

- HDCP 1.1 compliant

- Extend the transmission length up to 60m (200ft) from the HDMI sources under HD resolution (1080i

or 720p at 8 bit color depth)

- Extend the transmission length up to 40m (130ft) from the HDMI sources under Full HD resolution

(1080p at 8 bit color depth)

- Extend the transmission length up to 20m (65ft) from the HDMI sources under Full HD resolution

(1080p at 12 bit color depth)

- Minimize the cable skew by adjustable 8-level equalization control

- Pure unaltered uncompressed 7.1ch digital HDMI over LAN cable transmission

- DTS-HD and Dolby True HD high bit rate audio support

- Allows cascading

- Perfectly integrated with other HDMI-C5-3 Series products
