TOTO TOT3501 Specifications

FEATURES

■ 1-1/2” Tubular white schedule

40 heavy duty polypropylene
construction.

■ Trimmable tubes and adjustable

joints provides a precise fit
on the job site.

■ 27” cable length fits most tubs.

■Solid brass overflow head,

stopper and bath drain for a top
quality lasting finish.

■ Low profile cable heads for

tight installations.

■ Easily rotated overflow head

operates drain plunger.

■ Sleek, adjustable large European

mushroom stopper for a smooth
finish and a positive seal.

■ Removable stopper allows easy

cleaning.

■ For acrylic tubs.

■ ABD100#CP

Chrome plated trim.

■ ABD100#BN

Brushed nickel trim.

■ ABD100#PN

Polished nickel trim.

ABD100

Tubular Cable Driven Bath Waste

2-7/8”

• 1-1/2” Tubular white schedule 40 heavy duty
polypropylene construction

• Trimmable tubes and adjustable joints provides a
precise fit on the job site

• 27” cable length fits most tubs

• Solid brass overflow head, stopper and bath drain
for a top quality lasting finish

• Low profile cable heads for tight installations

• Easily rotated overflow head operates drain plunger

• Sleek, adjustable large European mushroom
stopper for a smooth finish and a positive seal

• Removable stopper allows easy cleaning

• For acrylic tubs

MODELS

• ABD100#CP
Chrome plated trim

• ABD100#BN
Brushed nickel trim

• ABD100#PN
Polished nickel trim

ABD100

Tubular Cable Driven Bath Waste

COLOR

• Chrome Plated

CODES/STANDARDS

• Meets and exceeds ASME A112.18.2 / CSA B125.2.

• Certifications: IAPMO(cUPC®) and others

INSTALLATION NOTES

Waste and overflow utilize compression joints which will

require an access panel per model codes. Check local
codes for requirements.

DIMENSIONS

1-1/2” OD
Tubular

Max. 21”
Min. 8-1/2”

9-3/8”

3-1/4”

Max. 14"

Min. 6”

These dimensions and specications are subject to change without notice

2-3/4”
