TOTO SBSA2029 Specifications

FEATURES

• WaterSense® certified low-flow 1.2 gpm faucet

• Brass construction

• Lever handle

• Metal pop-up drain assembly included

COLORS/FINISHES

• #CP Polished Chrome

OPTIONAL ACCESSORIES

• THP3158#CP – 4" Cover Plate

• THP3159#CP – 8" Cover Plate

PRODUCT SPECIFICATION

TLS01304U

LB Single-Handle Faucet – Semi-Vessel

Product shall have a maximum flow rate of 1.2 gpm (4.5
lpm). Product shall have a brass construction. Product
shall have lever handles. Product shall have a ceramic
disk valve cartridges. Product shall include metal
pop-up drain assembly. Product shall be TOTO Model
TLS01304U#____.

CODES/STANDARDS

• Meets or exceeds ASME A112.18.1/CSA B125.1,
NSF 61-9, NSF 372

• Certifications: IAPMO(cUPC), EPA WaterSense,
State of Massachusetts and others

• Code Compliance: UPC, IPC, NSPC, CEC, DoE,
NPC Canada, and others

• California Green Building Code, City of Los Angeles
Water Efficiency Ordinance

• Complies with federal and state requirements as
lead-free (weighted average of 0.25% lead or less)

• ADA compliant

• Complies with CA Prop 65 warning requirements

Red

Blue

Cold water

Mixed
water

Hot water

45°

45°

Red

Hot water

45°

1-5/16”~

1-7/16”

Mounting hole

(33-37mm)

1-5/16”~1-7/16”

Mounting hole

(33-37mm)

22°

open

close

25°

(324mm)

(106mm)

(233mm)

(363mm)

(241mm)

(Ø31.75mm)

1-1/4”

Deck
thickness
Maximum

(35mm)

(Ø60mm)

2-3/8”

9-1/2”

4-3/16”

14-5/16”

1-7/16”

9-3/16”

12-13/16”

Mixed
water

45°

Mixed
water

7-13/16”

1-5/16”~1-7/16”

Mounting hole

(33-37mm)

Red

Blue

Cold water

Mixed
water

45°

45°

Red

Blue

Cold water

Mixed
water

Hot water

45°

45°

TLS01304U

SPECIFICATIONS

LB Single-Handle Faucet – Semi-Vessel

Material

Maximum Flow Rate

Warranty

DIMENSIONS

Red

Hot water

45°

Mixed
water

Brass

1.2 gpm (4.5 lpm)

Lifetime Limited Warranty (Residential Use)
One Year (Commercial Use)

Blue

Cold water

45°

25°

22°

close

6-13/6”

Pressure (kPa)

Pressure (psi)

10-7/16”

(264mm)

0 100 200 300 400 500

1.4

1.2

1

0.8

0.6

0.4

Flow rate (gpm)

0.2

0

0 10 20 30 40 50 60 70 80

open

4-3/16”

(106mm)

(173mm)

5.3

4.5

3.8

3.0

2.3

1.5

0.8

0.0

Flow rate (lpm)

2-3/8”

(Ø60mm)

(198mm)

1-1/4”

Mounting hole
1-5/16”~

1-7/16”

(33-37mm)

Ph: [phone] | Fax: [phone] | www.totousa.com | © TOTO USA

(Ø31.75mm)

Maximum 11-1/4”

(285mm)

These dimensions and specications are subject to change without notice

(423mm)

16-11/16”

Deck
thickness
Maximum

1-7/16”
(35mm)

Comp

3/8”

# SS-01483 v.01
