FEATURES
• Laminar fl ow
• Brass construction
• 1/2” NPT connection
COLORS/FINISHES
• #CP Polished Chrome
• #BN Brushed Nickel
• #PN Polished Nickel
CODES/STANDARDS
TS230E
Wyeth™ Wall Spout
• Meets or exceeds ASME A112.18.1/CSA B125.1
• Certifi cations: IAPMO(cUPC), State of
Massachusetts and others
• Code Compliance: UPC, IPC, NSPC, NPC Canada,
and others
PRODUCT SPECIFICATION
The tub spout shall have a laminar fl ow. Product shall
feature brass construction. Product shall have
1/2” NPT connection. Product shall be TOTO Model
TS230E#____.
Page 2
TS230E
SPECIFICATIONS
• Warranty Lifetime Limited Warranty
(Residential Use)
One Year (Commercial Use)
• Material Brass
• Shipping Weight 2.7 lbs.
• Shipping Dimensions 9-1/4”L x 4”W x 3-1/2”H
Wyeth™ Wall Spout
2-5/8"
67mm
3-3/16"
Ph: (888) 295-8134 | Fax: (800) 699-4889 | www.totousa.com
80mm
10
8-1/8"
206mm
1/2" NPT
7-5/16"
These dimensions and specifi cations are subject to change without notice
186mm
Tub Rim
Printed in U.S.A. | © TOTO USA 09/12 | Printed on recycled paper ♻
~4-6" [102-152mm]
