TOTO SBSA1845 Specifications

Vivian® Two-Way Diverter Trim with Off, Lever Handle

FEATURES

• Lever handle

• Integrated off position

• For use with the Two-Way Diverter Valve with Off
(TSMV)

COLORS/FINISHES

• #CP Polished Chrome

• #BN Brushed Nickel

• #PN Polished Nickel

CODES/STANDARDS

TS220D1

• Meets or exceeds ASME A112.18.1/CSA B125.1

• Certications: IAPMO(cUPC), State of

Massachusetts and others

• Code Compliance: UPC, IPC, NSPC, NPC Canada,

and others

• ADA compliant

PRODUCT SPECIFICATION

Two-way diverter trim with off shall have a lever
handle. Product shall be TOTO Model TS220D1#____
and required valve shall be TSMV sold separately.

TS220D1

Vivian® Two-Way Diverter Trim with Off, Lever Handle

SPECIFICATIONS

• Warranty Lifetime Limited Warranty

(Residential Use)
One Year (Commercial Use)

• Material Brass

• Shipping Weight 1.6 lbs.

• Shipping Dimensions 7"L x 3-1/2"W x 4"H

INSTALLATION NOTES

VALVE REQUIRED:

Two-way diverter valve with off model TSMV sold
separately.

5-3/16"

Outlet 2
Position

131mm

3-15/16"

Position

O

100mm

Valve

C

Min: 2-1/2" [65mm]

Max: 3-3/4" [95mm]

Outlet 1
Position

Finished

Wall Surface

2-9/16"

These dimensions and specications are subject to change without notice

65mm

L

Ph: [phone] | Fax: [phone] | www.totousa.com | © TOTO USA

#SS-00850, v.06
