TOTO SBSA1792 Specifications

FEATURES

• Lever handle

• For use with the volume control valve (TSMA)

• Ceramic disk cartridge

• To be used in conjunction with a thermostatic
valve system

COLORS/FINISHES

• #CP Polished Chrome

• #BN Brushed Nickel

• #PN Polished Nickel

TS211C

Keane™ Volume Control Trim

CODES/STANDARDS

• Meets or exceeds ASME A112.18.1/CSA B125.1

• Certifi cations: IAPMO(cUPC), State of
Massachusetts and others

• Code Compliance: UPC, IPC, NSPC, NPC Canada,
and others

• ADA compliant

PRODUCT SPECIFICATION

Volume control trim shall have lever handle. Product
shall have ceramic disk cartridge. Product shall be
TOTO Model TS211C#____ and required valve shall
be TOTO Model TSMA, sold separately.

TS211C

Keane™ Volume Control Trim

SPECIFICATIONS

• Warranty Lifetime Limited Warranty
(Residential Use)
One Year (Commercial Use)

• Material Brass

• Shipping Weight 1.6 lbs.

• Shipping Dimensions 7"L x 3-3/4"W x 4"H

INSTALLATION NOTES

VALVE REQUIRED:
Volume control valve, model TSMA, sold separately.

4-5/16"

5-7/16"

Ph: [phone] | Fax: [phone] | www.totousa.com | © TOTO USA

138mm

110mm

2-11/16"

These dimensions and specifi cations are subject to change without notice

Min: 2-1/2" [65mm]

Max: 3-3/4" [95mm]

69mm

9DOYH

&

)LQLVKHG

:DOO6XUIDFH

/

#SS-01057 v.02
