Tote Vision LCD-562, LCD-565 User Manual

The Biggest Thing in
LCD-565
LCD Field Monitors
LCD- 565
Side View
shown with MB-1
desk stand
LCD-562
LCD- 562
Unit with Audio
Active Matrix 5.6" Color LCD Monitor
• BNC IN/OUT jacks located on top for easy access (with self-termination feature)
• LED
NEW
power and provides better color saturation
• Battery pack for fi eld monitor use included
• Ideal for troubleshooting system setup/fault location
• Switch for Auto/Manual color adjustment
• Low power consumption
• Case made of durable ABS plastic
• Manual controls for tint, color, brightness (and audio volume for LCD-562)
• Battery pack provides approximately 5 ~ 6 hrs operation
• Snap-on battery pack holds 8AA or 10 NiCad rechargeable batteries (batteries not included)
• Response Time: 60ns/60ns (Rising/Falling)
LCD-562 Unit with Audio Capability (without BNC IN/OUT)
shown in inset above.
Optional Accessories
AC-2000 AC adaptor BP-563 Rechargeable 2600mh NiCad battery pack Provides approximately 6 hrs. operation. DC-12 Car cord DC-12D Dual car cord HS-1 Hot Shoe mount MB-1 Desk Stand (shown above in side view) MB-72M Metal Mounting Bracket TB-565 Custom Totebag with sun shield WM-1 Wall mount bracket
backlight provides longer life
, uses less
Display:
Black Light:
Input Signal:
Dot Format:
Dot Pitch:
Brightness rating:
Number of Pixels:
Contrast Ratio:
Viewing angle L/R/T/B:
Pixel Confi guration:
Power Requirements:
Power Consumption:
Input Signal Level:
Dimensions w/ pack (WHD):
Dimensions w/o pack (WHD):
Actual visible screen size (WH):
Monitor Mounting:
Operating temperature:
Storage temperature:
LCD-565: Connections:
Net Weight:
Gross Weight:
5.6" a-Si TFT LCD active matrix Built-in LED NTSC/PAL (automatically match) 960(H) x 234(V) dots
0.188mm(H) x 0.362mm(V) 200 cd/m² (Nit) 224,640 Dots 300 : 1 65°/65°/45°/65° RGB Stripe 11VDC ~ 14VDC, 500mA, +pin, - ground
4.0 W (340mA @ DC 12V)
1.0V P-P (positive) 75 Ohm 158 x 130 x 55mm / 6.2" x 5.1" x 2.2" 158 x 130 x 42mm / 6.2" x 5.1" x 1.7"
113.3 x 85mm / 4.5" x 3.3" Mounting pad with ¼ - 20 threaded socket 10 ~104°F or 12~40°C
-13 ~ 140°F or -25 ~ 60°C BNC video IN/OUT (female) jacks
2.1mm DC IN jack LCD-562/565: 400g / 14.0 oz. LCD-562: 0.7 kg./ 1.6 lbs LCD-565: 0.6 kg/ 1.3 lbs.
For Rechargeable Battery Pack
order BP-563
to go in TB-565 tote bag
GS-07F-0069L, SIN: 246-42(1), 246-50
Specifi cations subject to change without notice
P. 2 6
©2008 ToteVision
