Dimension: L400 × H10 × H10 mm
Material: PC/ABS (plastic)
Totem Basic Element
• Totem Beams are one size – L400 × H10 × H10 mm.
• Cuttable beams will fit for various different projects.
• Use simple but smart Totem Tools for cutting.
• No need to store lots of different elements in yours workshop.
• Plastic is pleasant to use, lightweight, easy to shape, but still
makes sturdy structures.
• Can be reused many times.
User-friendly one size philosophy:
Totem provides plastic cuttable one size Beams, that reflect our main userfriendly philosophy of providing building elements that you can shape
according to your needs.
Simple but smart tools:
The philosophy of having one size of cuttable basic building elements goes
hand in hand with super easy to use and smart Totem Tools. You will be
surprised how handy they are.
We strongly recommend using only Totem Tools for cutting plastic parts of
Totem mechanics for a smooth experience of building.
3-Dimensional Beams structure:
• Nuts stay in structure: special Totem Nut M3 10×6 stay in the
structure of Beam before Bolts are tightened!
• Add element or expand structure anywhere: special layout of
slots and holes makes it to versatile element to construct any
shapes: easy to expand structure, by adding other beam or board or
any other element at any point on your project.
• Totem Grid: The geometry of Totem is so that Brackets and Nuts
are 2×6 mm profile, and they fit into beams in 2 directions.
• Cut to make the size you need: Special Totem Beam Cutter: with
0,2 mm saw makes it a breeze to cut beams.
• Unique invention: the invention of beams is unique and is
protected by patent.
Page 2
Totem Tips:
• Need bigger structure: join few beams side by side together to
make them thinner – unique layout of beams slots allows to join
them at any point.
• Need to make the beam stronger: if your project requires more
resistant Beam – use aluminum Strip Bracket – it perfectly fits into
the track of the Beam.
• 1 cm Step: Totem Beam Step is 1 cm, however you can cut 0,5 cm
if it is required by your project.
