Tosot TM24HTDI User Manual
TM09HTDI
TM12HTDI
TM18HTDI
TM24HTDI
User Notice
When installing, the entire capacity of the cooperating indoor unit should be not larger than
◆
150% of outdoor unit, otherwise, it will cause the shortage of cooling (heating) capacity.
The power supply of the entire unit must be the power supply of outdoor unit. And disconnect
◆
the main power of outdoor unit before cleaning.
In order to start up the unit successfully, the main power switch should be opened 8 hours
◆
before the operation.
After receiving the turn off signal, every indoor unit will continue to work for 20-70sec to
◆
make good use of the rest cool air or the rest heat air in the heat exchanger, which will prepare for
the next operation. And this is normal.
When the selected operating mode of the indoor unit is conicted to the operating mode of
◆
the outdoor unit, 5 sec later, the malfunction hint will be shown on the indoor unit or wired controller,
then the indoor unit will stop. At this time, change the operating mode of the indoor unit to the one
that would not conict with the outdoor operating mode to make the operation normal. The HEAT
mode conicts with each of the COOL mode, DRY mode and FAN mode, while the COOL mode,
DRY mode and FAN mode are compatible between each other.
The appliance shall not be installed in the laundry. The appliance shall not be used by
◆
children without supervisor.
Power supply uctuating range (+/-10%, +/-1Hz) .
◆
Humidity range: 30%~95%.
◆
Main switch provided by end user: main switch handle should be black or gray, it can be
◆
locked in “OFF” position with padlock.
The main disconnection device should be installed at a height of 0.6~1.7m. Over current
◆
protection is required(UL 1995,CSA C22.2).
The cooling range of the unit is the outdoor ambient temp -5~48℃ DB, the heating range of
◆
the unit (only for the heat pump type unit) is the outdoor ambient temp. -15~27℃ DB.
This appliance is not intended for use by persons (including children) with reduced physical,
◆
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
This product must not be disposed together with the domestic waste. This product has
to be disposed at an authorized place for recycling of electrical and electronic appliances.
Thank you for selecting Tosot air conditioner. Before use, please read this manual
carefully and keep it properly for furthur reference.
Contents
1 Safety Precautions ..........................................................................................1
2 Installation Precautions and Location Choosing .............................................2
2.1 Installation Precautions .........................................................................................2
2.2 Location Choosing ................................................................................................ 2
2.3 Imappropriate Location ......................................................................................... 2
3 Installation of Floor and Ceiling Type Indoor Unit ............................................ 3
3.1 Space Dimension for Unit Installation ................................................................... 3
3.2 Important Notice ....................................................................................................3
3.3 Installation Description .......................................................................................... 3
3.4 Electrical Wiring .................................................................................................... 6
3.5 Drainpipe Installation ............................................................................................7
3.6 Install the Connection Pipes .................................................................................8
4 Part Names of Floor and Ceiling Type Indoor Unit ........................................ 10
5 Working Temperature Range ......................................................................... 11
6 Maintenance Method ..................................................................................... 12
6.1 Cleaning the Air Filters ........................................................................................ 12
6.2 Cleaning the Unit ................................................................................................12
6.3 At the Start of the Season ................................................................................... 12
6.4 During the off Season ......................................................................................... 12
7 Operating Instructions ...................................................................................13
8 Malfunction Analysis ...................................................................................... 15
8.1 Service Center ..................................................................................................... 15
8.2 After-sales Service ............................................................................................... 16
Free Match for North America
1 Safety Precautions
Please read this manual carefully before using this unit. Operate it correctly according to the
guide in this manual.
Please pay special attention to the indicating meaning of these two marks:
Warning! This mark means that the unit may cause property damage, personal injury or
loss of life if the operation is incorrect.
Caution! This mark means that the unit may cause minor or moderate property damage or
personal injury.
Warning!
The unit should be earthed reliably. Do not connect the earth line to the gas pipe, water pipe,
◆
drainage pipe or other unsafe places in potential.
Air conditioner must use special power supply circuit and switches for creepage protect and
◆
air with enough capacity should be installed in the circuit.
Ensure that the connecting of power cord is reliable, otherwise, electric shock or re may
◆
happen.
Do not cut off the power supply when the unit is running, otherwise the lifetime of the unit will
◆
be shortened.
Do not damage wires or use the wires that are not recommended, otherwise, electric shock
◆
or re may happen.
Please don’t operate the unit with wet hands, or electric shock may happen.
◆
Do not put a nger, a rod or other objects into the air outlet or inlet to avoid of damage or
◆
injury.
Cut down the main power supply immediately if any abnormality happens (such as smell of
◆
re etc.). Contact with the service center and consult the qualied technician.
Do not repair or adjust the air conditioner by yourself. Please contact the service center or
◆
Tosot technicians for help.
Do not use the fuse with unsuitable capacity or iron thread instead of fuse, otherwise, it will
◆
cause malfunction or re.
Switch off the power supply of the unit before cleaning the air conditioner, otherwise, electric
◆
shock or damage may happen.
Please turn off the main power of the whole unit before cleaning the conditioner, otherwise
◆
electric shock or harm may be happened.
Chemical sprayer should be placed 1m or more away from the unit, otherwise fire or
◆
explosion may happen.
Do not block air inlets or outlets. Impaired air ow may result in insufcient performance or
◆
trouble.
1
Free Match for North America
2 Installation Precautions and Location Choosing
2.1 Installation Precautions
The installation of air conditioner must be conform to national and local safety
laws.
Installation quality will directly affect the normal use of air conditioner. Do not
attempt to install the air conditioner by yourself. Please contact your dealer after buying
this machine. Professional installation workers will provide installation and test services
according to installation manual.
Do not connect to power until all installation work is completed.
2.2 Location Choosing
Such a place where cool air can be distributed throughout the room.
＊
Such a place where condensate water could be easily drained out.
＊
Such a place that can handle the weight of indoor unit.
＊
Such a place, which is easy for maintenance.
＊
Such a place where is easy to get connected with the outdoor unit.
＊
Such a place where is 1m or more away from other electric appliances such as television,
＊
audio device, etc.
Avoid a location where there is heat source, high humidity or inammable gas.
＊
Do not use the unit in the moist surroundings, such as a laundry, a bath, a shower or a
＊
swimming pool.
Be sure that the installation conforms to the installation drawings.
＊
2.3 Imappropriate Location
Where there is too much of oil.
＊
Where it is acid base area.
＊
Where there is irregular electrical supply.
＊
2
Free Match for North America
3 Installation of Floor and Ceiling Type Indoor Unit
3.1 Space Dimension for Unit Installation
The space around the unit is adequate for ventilation. (Refer to Fig.1)
>1500
POWER
RUN
TIMER
>600
>300
>600
>1000
>600
>200
>600
>2300
>1500
>300
Fig.1
3.2 Important Notice
(1). The unit must be installed by the professional personnel according to this install instruction
to ensure the well use.
Please contact the local Tosot special nominated repair department before installation. Any
malfunction caused by the unit that is installed by the department that is not special nominated by
Tosot would not deal with on time by the inconvenience of the business contact.
(2). It should be done by professional personnel when the air conditioner unit is moved to other
place.
3.3 Installation Description
Ceiling type
＊
Floor type
＊
These two types of units have similar installing procedure as follows:
(1). Determine the mounting position on ceiling or wall by using paper pattern to indicate indoor
frame. Mark the pattern and pull out the paper pattern.(Refer to Fig.2)
(2). Remove the return grill, the side panel and the hanger bracket from the indoor unit as per
procedure bellow.
Press the xing knob of the air intake grills, the grilles will be opened wider and then pull
＊
them out from the indoor.
Loosen the side panel xing screw and remove the side panel. (Refer to Fig.3)
＊
Loosen two hanger bracket setting bolts (M8) on each side for less than 10mm. Remove two
＊
hanger bracket xing bolts (M6) on the rear side. Detach the hanger bracker by pulling it backward
3
