Tosot TM18HEDI User Manual

TM09HEDI TM12HEDI TM18HEDI

Contents

OPERATION INSTRUCTIONS

1. Part names and their functions ........................................................................................................... 1

2. How to use the remote control to operate the unit .............................................................................. 2

3. Maintenance ...................................................................................................................................... 7

4. Operating guide ................................................................................................................................. 10

5. Precautions ....................................................................................................................................... 12

6. Checking before contact the service man ........................................................................................ 13

INSTALLATION INSTRUCTIONS

7. Installation of indoor unit .................................................................................................................... 14

8. Routine check after installation ......................................................................................................... 22

9. 23

Configuration of connection pipe and additional volume of refrigerant...........................................

Thank you for selecting our products

One of the benefits awaiting you with our room air conditioner is not only comfort of life but also good health. This operation instruction brings you the many omfort and technological features your unit has to offer. In addition, it provides you vital information about maintenance, service and economical operating. Take the next few minutes to discover how to get your comfort and economy of the operation from your new room air conditioner.

The figures in this manual may be different with the material objects, please

refer to the material objects for reference.

This appliance is not intended for use by persons (including children) with reduced physical , sensory or mental capabilities or lack of experience and knowledge,unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

External static pressures at the appliance was tested is 0 Pa Fuse link: T250 V; 3.15 A

Part names and their functions

INDOOR UNIT

11 12

OPERATION INSTRUCTIONS

1 2

7 4

14 15

CAUTION

Before opening the front panel, be sure to stop the operation and turn the breaker OFF.

Do not touch the metal parts on the inside of the indoor unit, as it may result in injury.

1. Titanium Apatite Photocatalytic Air-Purifying Filter:

● These filters are attached to the inside

of the air filters.

2. Air outlet

3. Display

4. Front panel

5. Louvers (vertical blades)

● The louvers are inside of the air outlet.

6. Air inlet

7. Air filter

8. Flap (horizontal blade)

9. Cool mode lamp

10. Heat mode lamp

11. Dry mode lamp

12. Run lamp

13. LED display

14. Indoor Unit ON/OFF switch:

● Push this switch once to start operation.

Push once again to stop it.

● The operation mode refers to the following table.

COOL

AUTO

Temperature

setting

25℃

Model Mode

COOLING

ONLY HEAT

PUMP

● This switch is useful when the remote controller

is missing.

Air flow rate

AUTO

15.Signal receiver:

● It receives signals from the remote controller.

● When the unit receives a signal, you will hear

a short beep.

● Settings changed.....beep

16.Air outlet selection switch

17.Room temperature sensor:

● It senses the air temperature around the unit.

Air outlet selection switch

This setting blows air from

•

upper outlet only.

This setting automatically

•

decides a blow pattern depending on mode and conditions.

This setting is recommended.

•

The unit is shipped from the

•

factory with this setting.

Indoor unit

wiring terminal

N(1) 2 3

BU BK BN

YELLOW/ GREEN

Opening the Front Panel

NOTE:

① If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. ② The appliance shall be installed in accordance with national wiring regulations. ③ An all-pole disconnection switch having a contact separation of at least 3mm in all poles should be connected in fixed wiring.

How to use the remote control to operate the unit

Remote Controller Description

1 ON/OFF button

+/- button

MODE button

FAN button

I FEEL button

SWING button

O P E R AT IO N IN S TR U C T IO N S

button

SLEEP button

QUIET button

TEMP button

CLOCK button

T-ON T-OFF button

TURBO button

LIGHT button

X-FAN button

Introduction for icons on display screen

I feel

Quiet

Operation mode

Auto mode Cool mode

Dry mode

Fan mode

Heat mode

Clock

Sleep mode

Light

Temp. display type

:Set temp.

:Outdoor ambient temp.

:Indoor ambient temp.

Set fan speed Turbo mode

Send signal Healthy mode Scavenging functions 8℃ heating function

Set temperature

This is a general remote controller. Some models have this function while some do not. Please refer to the actual models.

X-FAN function Set time

TIMER ON /TIMER OFF

Child lock Up & down swing Left & right swing

How to use the remote control to operate the unit

Remote Controller Description

ON/OFF :

Press this button to turn on the unit .Press this button again to turn off the unit.

Press this button to decrease set temperature. Holding it down above 2 seconds rapidly

decreases set temperature. In AUTO mode, set temperature is not adjustable.

+ :

Press this button to increase set temperature.Holding it down above 2 seconds rapidly increases set temperature. In AUTO mode, set temperature is not adjustable.

MODE :

Each time you press this button,a mode is selected in a sequence that goes from AUTO, COOL,DRY, FAN,and HEAT

AUTO

COOL

DRY

After energization, AUTO mode is defaulted. In AUTO mode, the set temperature will not be displayed on the LED of the indoor, and the unit will automatically select the suitable operation mode in accordance with the room temperature to make indoor room comfortable.

,as the following:

FAN HEAT

*Note:Only for models with heating function.

OPERATION INSTRUCTIONS

FAN

This button is used for setting Fan Speed in the sequence that goes from AUTO,

, ,

Auto

then back to Auto.

Medium speedLow-Medium speedLow speed

High speedMedium-High speed

SWING:

Press this button to set up &down swing angle, which circularly changes as below

OFF

This remote controller is universal . If any command , or is sent out,

the unit will carry out the command as

indicates the guide louver swings as:

I FEEL:

Press this button to turn on I FEEL function. The unit automatically adjust temperature according to the sensed temperature. Press this button again to cancel I FEEL function.

How to use the remote control to operate the unit

ress this button to achieve the on and off of healthy and scavenging functions in operation status.

OPERATION INSTRUCTIONS

Press this button for the first time to start scavenging function;

displays“ ”. Press the button for the

LCD simultaneously; LCD displays“ ” and “ ” .

second time to start healthy and scavenging functions

Press this button for the third time to quit healthy

and scavenging functions simultaneously. Press the button for the fourth time to start healthy

function; LCD display “ ”

SLEEP:

●

Press this button, can select Sleep 1 ( ), Sleep 2 ( ),Sleep 3 ( ) and cancel the Sleep,

. Press this button again to repeat the operation above.

circulate between these, after electrified, Sleep Cancel is defaulted.

●

Sleep 1 is Sleep mode 1, in Cool, Dehumidify modes: sleep status after run for one hour, the main unit setting temperature will increase 1

℃,setting temperature increased 2℃, the unit will run at this

setting temperature; In Heat mode: sleep status after run for one hour, the setting temperature will decrease 1

℃, 2 hours, setting temperature will decrease 2

℃, then the unit will run at this setting

temperature.

●

Sleep 2 is sleep mode 2, that is air conditioner will run according to the presetting a group of sleep temperature curve.

●

Sleep 3- the sleep curve setting under Sleep mode by DIY: (1) Under Sleep 3 mode, press "Turbo" button for a long time, remote control enters into user individuation sleep setting status, at this time, the time of remote control will display "1 hour ", the setting temperature "88" will

display the corresponding temperature of last setti

ng sleep curve and blink (The first entering will display

according to the initial curve setting value of original factory);

(2) Adjust "+" and "-" button, could change the corresponding setting temperature, after adjusted, press "Trubo "button for confirmation;

(3) At this time, 1 hour will be automatically increased at the timer postion on the remote control, (that are "2 hours " or "3 hours " or "8 hours "), the place of setting temperature "88" will display the corresponding temperature of last setting sleep curve and blink; (4) Repeat the above step (2)

～ (3) operation, until 8 hours temperature setting finished, sleep

curve setting finished, at this time, the remote control will resume the original timer display; temperature display will resume to original setting temperature. Sleep3- the sleep curve setting under SLEEP mode by DIY could be inquired:

●

The user could accord to sleep curve setting method to inquire the presetting sleep curve, enter into user individuation sleep setting status, but do not change the temperature, press "Turbo" button directly for confirmation. Note: In the above presetting or enquiry procedure, if continuously within10s, there is no button pressed, the sleep curve setting within10s, there is no button pressed, the sleep curve setting status will be automatically quit and resume to display the original displaying. In the presetting or enquiry procedure, press "ON/OFF" button, "Mod

e" button, "Timer"button or "Sleep" button, the sleep curve setting or enquiry status will quit similarly.

TEMP:

Press this button, could select displaying the indoor setting temperature or indoor ambient temperature.When the indoor unit firstly power on it will display the setting temperature, if the temperature's displaying status is changed from other status to" ",displays the ambient temperature, 5s later or within 5s, it receives other remote control signal that will

return to display the setting temperature. if the users haven't set up the temperature displaying status,that will display the setting temperature.

How to use the remote control to operate the unit

QUIET:

Press this button, the Quiet status is under the Auto Quiet mode (display and "Auto"" " signal) and Quiet mode (display " " singal) and Quiet OFF (there is no signal of " " displayed), after powered on, the Quiet OFF is defaulted. Note: the Quiet function cannot be set up in Fan

and Dry mode;Under the Quiet mode (Display " "

CLOCK :

Press CLOCK button, blinking . Within 5 seconds,pressing +or - button adjusts the

present time.Holding down either button above 2 seconds increases or decreases the time by 1 minute every 0.5 second and then by 10 minutes every 0.5 second. During blinking after setting, press CLOCK button again to confirm the setting,and then

be constantly displayed.

will

T-ON T-OFF:

Press T-ON button to initiate the auto-ON timer. To cancel the auto-timer program, simply press this button again.

After press of this button, disappears and "ON "blinks .0 setting. Within 5 seconds, press + or - button to adjust the time value. Every press of either

button changes the time setting by 1 minute. Holding down either button rapidly changes the

time setting by 1 minute and then 10 minutes. Within 5 Seconds after setting, press TIMER ON button to confirm.

Press T-OFF button to initiate the auto-off timer. To cancel the auto-timer program, simply

press the button again.TIMER OFF setting is the same as TIMER ON.

signal), the fan speed is not available.

0:00 is displayed for ON time

OPERATION INSTRUCTIONS

TURBO:

Press this button to activate / deactivate the Turbo function which enables the unit to reach the preset temperature in the shortest time. In COOL mode, the unit will blow strong

cooling air at super high fan speed. In HEAT mode, the unit will blow strong heating air

at super high fan speed.

LIGHT:

Press LIGHT button to turn on the display's light and press this button again to turn off

the display 's light. If the light is turned on , is displayed. If the light is turned off,

disappears.

X-FAN:

Pressing X-FAN button in COOL or DRY mode,the icon is displayed and the indoor fan will continue operation for 10 minutes in order to dry the indoor unit even though you have turned off the unit. After energization, X-FAN OFF is defaulted. X-FAN is not available in AUTO,FAN or HEAT mode.

Combination of "+" and "-" buttons: About lock

Press "+ " and "-" buttons simultaneously

controller is locked, is

displayed. In this case,

to lock or unlock the keypad. If the remote

pressing any button, blinks

three times.

How to use the remote control to operate the unit

OPERATION INSTRUCTIONS

Combination of "MODE " and "-" buttons :

At unit OFF, press "MODE"

Combination of " TEMP " and "CLOCK" buttons : About Energy-saving Function

Press “TEMP” and “CLOCK” simultaneously in COOL mode to start energy-saving function. Nixie tube on the remote controller displays “SE”. Repeat the operation to quit the function.

Combination of " TEMP " and "CLOCK" buttons : About 8℃ Heating Function

Press “TEMP” and “CLOCK” simultaneously in HEAT mode to start Nixie tube on the remote controller displays “ ” and a selected temperature of “ (46 if Fahrenheit is adopted). Repeat the operation to quit the function.

℉

About Back-lighting Function

The unit lights for 4s when energizing for the first time, and 3s for later press.

and " -" buttons simultaneously to switch between and .

Aboutswitch between Fahrenheit and centigrade

℃

8℃ Heating Function

Replacement of Batteries

1.Remove the battery cover plate from the rear of the remote controller.

8℃”

℉

(As shown in the figure)

2.Take out the old batteries.

3.Insert two new AAA1.5V dry batteries, and pay attention to the polarity.

4. Reinstall the battery cover plate.

★

Notes:

When replacing the batteries, do not use old or different types of batteries,

●

otherwise, it may cause malfunction. If the remote controller will not be used for a long time, please

●

remove batteries to prevent batt

The operation should be performed in its receiving range.

●

It should be kept 1m away from the TV set or stereo sound sets.

●

If the remote controller does not operate normally, please take the

●

batteries out and reinsert them after 30 seconds.If it still can't operate properly,

replace the batteries.

eries from leaking.

Sketch map for replacing batteries
