Toshiba YL768-40 User Manual
WL76* Digital
Series
YL76* Digital
Series
Contents
INSTALLING YOUR TV
English
Safety Precautions ...........................................4
Installation and important information ..............5
The remote control ..........................................8
Inserting batteries and effective range ........ 8
CONNECTING YOUR TV
Connecting external equipment ........................ 9
Bundling the cables ....................................... 10
Connecting an HDMI
input .......................................................... 11
To connect an HDMI device ...................... 11
To connect a DVI device ........................... 11
HDMI’s ARC (Audio Return Channel)
feature ................................................. 11
REGZA-LINK connection .................................12
Connecting a computer .................................. 13
To connect a PC to the RGB/PC terminal ...13
To connect a PC to the HDMI terminal ...... 13
Connecting a home network ........................... 14
To connect the TV to a home network -
Wired ................................................... 14
To connect the TV to a home network with an
internet connection - Wireless ................14
Controls and input connections ......................15
Switching on ...........................................15
Using the remote control ..........................15
Using the controls and connections ........... 15
SETTING UP YOUR TV
Startup Application ........................................16
Quick Setup ............................................16
Ant/Cable/Satellite (if available) ............... 18
Satellite Settings ...................................... 18
Auto Tuning ............................................ 20
ATV Manual Tuning ....................................... 21
Tuning ....................................................21
Skip ........................................................22
Sorting positions ......................................23
DTV Manual Tuning ....................................... 23
Manual Tuning ........................................23
Manual Tuning for DVB-C ........................ 24
Manual Tuning for DVB-S ......................... 24
DTV Settings .................................................. 24
Channels (Antenna/Cable) .......................24
Channels (Satellite) .................................25
Standby Channel Update ......................... 26
DVB Character Set ...................................26
Dynamic Scan .........................................26
Location setting ....................................... 26
Analogue switch-off ...............................26
®
or DVI device to the HDMI
CONTROLS AND FEATURES
General controls ............................................ 27
Quick Menu ............................................ 27
Selecting positions ................................... 27
The Time Display – analogue only ........... 27
Stereo and Bilingual transmissions ............ 27
Using 3D functions ........................................ 28
Viewing 3D images .................................. 28
Switching display mode or selecting 3D
format .................................................. 28
Setting the auto start mode ......................30
Setting the 3D PIN code ........................... 30
Setting 3D Start Message ......................... 30
Setting 3D Lock .......................................31
Setting 3D Timer Lock .............................. 31
Setting Enable 3D Timer .......................... 31
Displaying 3D Important Info ................... 31
Switching left and right images ................ 31
Sound controls ..............................................32
Volume controls and sound mute .............. 32
Dual ....................................................... 32
Balance .................................................. 32
Sound Navi ............................................. 32
Surround Settings .................................... 32
Dolby Volume
Dynamic Range Control ........................... 33
Audio Level Offset ................................... 33
Audio Description .................................... 33
Widescreen viewing .......................................34
Picture controls .............................................. 36
Picture Mode ........................................... 36
Picture preferences .................................. 36
Reset ...................................................... 36
Colour Master ......................................... 36
Base Colour Adjustment ........................... 37
Colour Temperature ................................ 37
Auto Brightness Sensor Settings ................ 37
Active Backlight Control ...........................38
Black/White Level .................................... 38
Static Gamma .........................................38
MPEG NR – Noise Reduction ..................... 38
DNR – Digital Noise Reduction ................. 38
Resolution+ ............................................ 38
Active Vision M200 Pro ............................ 38
Film Stabilization ..................................... 39
Resetting the advanced picture settings ..... 39
Expert Picture Settings .............................. 39
Control Visualization ............................... 40
Automatic Format (Widescreen) ................ 40
4:3 Stretch .............................................. 40
Blue Screen ............................................. 40
Picture Position ........................................41
Picture still ..............................................41
®
....................................... 33
2
HDMI Information Display ........................41
Using your home network .............................. 42
Setting up the Network .................................. 43
Wireless Setup ........................................43
Advanced Network Setup ......................... 45
DNS Setup ..............................................46
Network Connection Test ......................... 47
Using the software keyboard .......................... 47
Setting up the Media Renderer feature ............48
Installation .............................................. 48
Media Renderer ....................................... 48
Device Name Setup .................................48
Web Password Setup ................................ 49
Media Controller Setup ............................49
Maximum Volume Setup ..........................49
Using YouTube™ ........................................... 50
Using the Function Menu ......................... 50
Using the Media Player .................................. 52
Basic operation ....................................... 53
Viewing photo files .................................. 54
Viewing movie files (on a DLNA CERTIFIED™
Server or USB device) ............................56
Playing music files (on a DLNA CERTIFIED™
Server or USB device) ............................58
Using the Photo Frame feature ....................... 59
To open Photo Frame ............................... 59
Setting the features ................................. 60
Other features ...............................................61
Panel Lock ..............................................61
The timers .....................................................62
Programme Timers – digital only ............. 62
On Timer ................................................ 62
Sleep Timer .............................................63
Energy Saving Settings ...................................63
Automatic Power Down ............................ 63
No Signal Power Down ............................63
Digital on-screen information and Programme
Guide .........................................................64
Information .............................................64
Guide ..................................................... 65
Genre selection/searching .......................65
Digital settings – parental control .................. 66
Setting the PIN ........................................66
Parental Setup .........................................66
Network Lock ..........................................66
Digital settings – Channel Options ................. 67
Selecting favourite channels ..................... 67
Favourite Channel Lists ............................67
Skip channels .......................................... 67
Locking channels .....................................67
Digital settings – other settings .......................68
Subtitles .................................................. 68
Audio languages ..................................... 68
Common Interface ................................... 68
Software Upgrade and Licences ......................69
Auto Upgrade ......................................... 69
Searching for New Software .....................69
Network Upgrade .................................... 69
Software Licences .................................... 69
System Information and Reset TV .................... 70
System Information .................................. 70
Reset TV .................................................. 70
PC Settings ................................................... 70
Horizontal and Vertical Position ................ 70
Clock Phase ............................................70
Sampling Clock ....................................... 71
Reset ...................................................... 71
Input selection and AV connections ................. 71
Input selection ........................................ 71
External input skip ...................................72
Labeling video input sources .................... 72
Colour Decoding ..................................... 72
PC Audio ................................................ 73
HDMI 2 Audio .........................................73
Side Shared Audio ................................... 73
HDMI Settings .........................................73
Digital Audio Output ...............................74
Using REGZA-LINK ........................................75
Enable REGZA-LINK ................................. 75
TV Auto Power ......................................... 75
Auto Standby .......................................... 75
Amplifier Control ..................................... 75
Speaker Preference .................................. 75
REGZA-LINK input source selection ........... 75
REGZA-LINK playback device control ........ 76
REGZA-LINK one touch play ..................... 76
REGZA-LINK system standby ..................... 76
REGZA-LINK system audio control ............. 76
Toshiba PC compatible with REGZA-LINK .... 76
TEXT SERVICES
Text services ..................................................77
Selecting modes ...................................... 77
Text information ...................................... 77
Navigating pages using Auto ................... 77
Navigating pages using LIST .................... 77
Control buttons ....................................... 78
PROBLEM SOLVING
Questions and Answers .............................. 79
INFORMATION
License Information ....................................... 82
Information ................................................... 84
Specifications and accessories ........................ 88
English
3
INSTALLING YOUR TV
Safety Precautions
English
This equipment has been designed and manufactured
to meet international safety standards but, like any
electrical equipment, care must be taken to obtain the
best results and for safety to be assured. Please read
the points below for your own safety. They are of a
general nature, intended to help with all electronic
consumer products, and some points may not apply to
the goods you have just purchased.
Air Circulation
Leave more than 10cm clearance around the television
to allow adequate ventilation. This will prevent
overheating and possible damage to the television.
Dusty places should also be avoided.
Heat Damage
Damage may occur if the television is left in direct
sunlight or near a heater. Avoid places subject to
extremely high temperatures or humidity. Place in a
location where the temperature remains between 5°C
(41°F) min. and 35°C (94°F) max.
Mains Supply
The mains supply required for this equipment is 220240v AC 50/60Hz. Never connect to a DC supply or
any other power source. DO ensure that the television
is not standing on the mains lead. Use only the
supplied lead.
DO NOT cut off the mains plug from this equipment,
this incorporates a special Radio Interference Filter, the
removal of which will impair its performance.
IF IN DOUBT, PLEASE CONSULT A COMPETENT
ELECTRICIAN.
Do
DO
read the operating instructions before you attempt
to use the equipment.
DO
ensure that all electrical connections (including the
mains plug, extension leads and inter-connections
between pieces of equipment) are properly made and
in accordance with the manufacturers’ instructions.
Switch off and withdraw the mains plug before making
or changing connections.
DO
consult your dealer if you are ever in doubt about
the installation, operation or safety of your equipment.
DO
be careful with glass panels or doors on
equipment.
DO NOT REMOVE ANY FIXED COVERS AS THIS WILL
EXPOSE DANGEROUS AND ‘LIVE’ PARTS.
THE MAINS PLUG IS USED AS A DISCONNECTING
DEVICE AND THEREFORE SHOULD BE READILY
OPERABLE.
Do not
DO NOT
equipment with items such as newspapers, tablecloths,
curtains, etc. Overheating will cause damage and
shorten the life of the equipment.
DO NOT
dripping or splashing or objects filled with liquids, such
as vases, to be placed on the equipment.
DO NOT
such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and
lead to fires.
DO NOT
wood screws. To ensure complete safety, always fit the
manufacturer’s approved stand, bracket or legs with
the fixings provided according to the instructions.
DO NOT
unattended, unless it is specifically stated that it is
designed for unattended operation or has a standby
mode. Switch off by withdrawing the plug, and make
sure your family knows how to do this. Special
arrangements may need to be made for people with
disabilities.
DO NOT
in any doubt about it working normally, or if it is
damaged in any way – switch off, withdraw the mains
plug and consult your dealer.
ABOVE ALL – NEVER let anyone, especially
children, push or hit the screen and cabinet back,
or push anything into holes, slots or any other
openings in the case. These actions will damage
screen or internal parts.
NEVER connect the supplied COMPONENT
Adaptor cable, SCART-AV Adaptor cable or AV
Adaptor cable to a wall outlet. These cables are
ONLY for insertion into the socket provided for
the purpose on the rear of the TV.
NEVER guess or take chances with electrical
equipment of any kind – it is better to be safe
than sorry.
obstruct the ventilation openings of the
allow electrical equipment to be exposed to
place hot objects or naked flame sources,
WARNING:
fire, keep candles or other open
flames away from this product at all
times.
use makeshift stands and NEVER fix legs with
leave equipment switched on when it is
continue to operate the equipment if you are
To prevent the spread of
4
INSTALLING YOUR TV
Installation and important information
Where to install
Locate the television away from direct sunlight and strong
lights. Soft, indirect lighting is recommended for
comfortable viewing. Use curtains or blinds to prevent
Fixing strap
direct sunlight falling on the screen.
Place the TV on a stable, level surface that can
support the weight of the TV. In order to prevent
Injury and maintain stability of this apparatus,
secure the TV to the level surface using the strap if
fitted, or to a wall using a sturdy tie to the P clips
provided.
The LCD display panels are manufactured using an
extremely high level of precision technology; however,
sometimes some parts of the screen may be missing picture
elements or have luminous spots. This is not a sign of a
malfunction.
Fixing strap
Stand style is dependent on model
Make sure the television is located in a position where it cannot be pushed or hit by objects, as pressure will break
or damage the screen. Also, please be certain that small items cannot be inserted into slots or openings in the case.
Cleaning the screen and cabinet…
Turn off the power, and clean the screen and cabinet with a soft, dry cloth. The enclosed cleaning cloth is for
do not
cabinet cleaning. We recommend that you
use any proprietary polishes or solvents on the screen or cabinet
as this may cause damage.
When using a Wall Bracket
Please use a wall bracket appropriate for the size and weight
of the LCD TV.
• Two people are required for installation.
• Never use the four screws attached to the TV.
• To install a wall-mount from another manufacturer, use the
SPACERS
(supplied).
1
Unplug and remove any cables and/or other component
connectors from the rear of the TV.
2
Carefully lay the front of the unit face down on a flat,
cushioned surface such as a quilt or blanket.
3
Follow the instructions provided with your wall bracket.
Before proceeding, make sure the appropriate bracket(s)
are attached to the wall and the back of the TV as described
in the instructions provided with the wall bracket.
4
Make sure to place the spacers supplied between the
bracket and the back of the TV.
5
Always use the screws supplied or recommended by the
wall mount manufacturer.
Screw
Wall bracket
Spacer
(supplied)
TV back panel
Removing the Pedestal Stand:
1
Carefully lay the front of the unit face down on a flat,
cushioned surface such as a quilt or blanket. Leave the
stand protruding over the edge of the surface.
NOTE:
Extreme care should always be used when
removing the pedestal stand to avoid damage to the LCD
panel.
2
Remove the five screws.
3
Once you have removed all five screws holding the
pedestal stand in place, remove the pedestal stand from
the TV by sliding the pedestal stand away from the TV.
Sturdy tie (as short as possible)
Stand clip
‘P’ Clip
Five screws
English
Remove four screws.
(Do not reuse these screws for
attaching a wall bracket.)
Place four spacers (supplied).
5
INSTALLING YOUR TV
English
When using the 3D glasses
About handling the 3D glasses
• Do not leave the 3D glasses, the battery or the
accessories within the reach of small children.
Inhaling or swallowing them may cause suffocation or
lesions in the stomach wall.
If swallowed, consult a doctor immediately.
• Do not repair, modify, or disassemble the 3D glasses
by yourself.
Doing so may cause a fire or cause you to become
indisposed while watching 3D images.
Contact the Toshiba Call Center for repair of your 3D
glasses.
• Do not expose the battery to excessive heat such as
sunshine, fire, or the like.
About the 3D glasses
• Do not use the 3D glasses if they are not working
properly or broken.
Continuing to use them in such a state may cause injury, eye
strain, or indisposition.
Do not use the 3D glasses if they are broken or have any
cracks.
• Do not stand or walk while wearing 3D glasses.
You may lose your balance which could result in falls or
other accidents.
• Do not wear the 3D glasses for any purpose other than
viewing 3D programming.
3D glasses do not function as sunglasses.
• Do not drop, exert pressure on, or step on the 3D
glasses.
Doing so may damage the glass section, which may result in
injury.
Exposing the 3D glasses to liquid or excessive heat may
damage the liquid crystal shutter function.
• If your nose or temple turns red, or you feel pain or
discomfort, stop using the 3D glasses.
Such symptoms as above may occur if you keep wearing
them for a long time, which may also cause indisposition.
• Observe the following for the battery of the 3D
glasses:
- Do not use any battery other than the one specified.
- Do not use any battery with the polarity reversed.
- Do not charge, heat, disassemble, or short the battery.
Violation of the above may cause explosion or leakage of the
battery, and a burn or injury may result.
Cautions on watching 3D images
• Some viewers may experience a seizure or blackout
when exposed to certain flashing images or lights
contained in certain 3D television pictures or video
games.
Anyone who has had a seizure, loss of awareness, or other
symptoms linked to an epileptic condition, or has a family
history of epilepsy, should contact a health care provider
before using the 3D function.
• Avoid use of the 3D function when under the influence
of alcohol.
• If you are ill or feel ill, you should refrain from viewing
3D images, and consult your health care provider as
may be appropriate.
• If you experience any of the following symptoms when
viewing 3D video images, stop viewing and contact
your health care provider:
Convulsions, eye or muscle twitching, loss of awareness,
altered vision, involuntary movements, disorientation, eye
strain, nausea/vomiting, dizziness, headaches.
• If you feel eye fatigue or other discomfort from viewing
3D video images, remove the 3D glasses and
discontinue use until the condition is eliminated.
• Viewing in 3D may cause dizziness and/or
disorientation for some viewers.
Therefore, to avoid injury do not place your TV near open
stairwells, balconies, or wires.
Also do not sit near objects that could be broken if
accidentally hit.
• When viewing 3D images, always wear 3D glasses.
Watching 3D images without 3D glasses may cause eye
strain.
Use specified 3D glasses.
• When watching 3D images, do not wear 3D glasses at
an angle and do not lie down.
If you watch while lying down or with the glasses tilted, the
3D effect is lost and it may cause eye strain.
• It is recommended that the viewer's eyes and 3D
glasses are level with the screen.
• If you have prescription eye glasses or contact lenses,
wear the 3D glasses over them.
Watching 3D images without appropriate eyewear may
cause eye strain.
• If 3D images often appear in double or if you cannot
see the images in 3D, stop viewing.
Continuous viewing may cause eye strain.
• Due to the possible impact on vision development,
viewers of 3D video images should be age 6 or above.
Children and teenagers may be more susceptible to health
issues associated with viewing in 3D and should be closely
supervised to avoid prolonged viewing without rest.
• Watching TV while sitting too close to the screen for an
extended period of time may cause eye strain.
The ideal viewing distance should be at least three times the
screen height.
If the 3D PIN number has been forgotten:
Use the Master PIN code of 1276, and then change to a
number of your choice. Select
PREFERENCES
/
3D Setup
3D PIN
menu to enter PIN.
from the
6
INSTALLING YOUR TV
English
Notes on handling the 3D glasses’ liquid crystal
shutter lenses
• Do not put excessive force on the lenses.
• Do not scratch the surface of the lenses with sharp
objects.
• Do not drop or bend the 3D glasses.
Notes on IR communication
• Do not block the IR sensor for 3D glasses on the TV by
placing objects in front of it.
• Do not cover the IR sensor on the 3D glasses with
stickers or labels.
• Keep the IR sensor on the 3D glasses clean.
• If the 3D glasses interfere with any other IR
communication device or 3D TV, the 3D glasses may
not work correctly. Also, this TV may interfere with the
operation of other IR communication devices. Use the
TV and 3D glasses in a place where they will not
interfere with other devices or products.
Notes on watching the TV
• If you use any device, such as a mobile phone or
mobile wireless device, near the 3D glasses, the 3D
glasses may not work correctly.
• Use the product in the following temperature range;
otherwise, the quality of the 3D image or the reliability
of the product cannot be guaranteed.
- 3D glasses: 0°C - 40°C (32°F - 104°F)
- TV: 0°C - 35°C (32°F - 95°F)
• If you use a fluorescent light, it may flicker depending
on the frequency of the light. In this case, reduce the
brightness of the fluorescent light, or use another
light. (It is not recommended to watch the TV in a dark
room, especially for children.)
• Wear the 3D glasses properly, otherwise you may not
see the correct 3D image.
• When not viewing 3D images on this unit, take off the
3D glasses; otherwise, it may be difficult to see the
display on other products such as PC, digital clock or
calculator, etc.
About the connecting cable
• Use a high-speed and high-quality HDMI cable when
you connect a device such as 3D compatible BD player
or PC to the TV. When you use a standard HDMI cable,
3D images may not be shown.
About the lithium battery
• There is danger of explosion if the battery is incorrectly
replaced. Replace only with the same or equivalent
type.
Please take note
The digital reception function of this television is only effective in the countries listed in the “Country” section of
the “SETUP” menu. Depending on country/area, some of this television's functions may not be available. Reception
of future additional or modified services can not be guaranteed with this television.
If stationary images generated by 4:3 broadcasts, text services, channel identification logos, computer displays,
video games, on-screen menus, etc. are left on the television screen for any length of time, they could become
conspicuous. It is always advisable to reduce both the brightness and contrast settings.
Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at the 4:3
outlines. This is not a defect of the LCD TV and is not covered under the manufacturer’s warranty. Regular use of
other size modes (eg: Super Live) will prevent permanent retention.
EXCLUSION CLAUSE
Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by:
i) fire;
ii) earthquake;
iii) accidental damage;
iv) intentional misuse of the product;
v) use of the product in improper conditions;
vi) loss and/or damage caused to the product whilst in the possession of a third party;
vii) any damage or loss caused as a result of the owner’s failure and/or neglect to follow the instructions set out in the owner’s
manual;
viii) any loss or damage caused directly as a result of misuse or malfunction of the product when used simultaneously with
associated equipment;
Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not limited
to the following: loss of profit, interruption of business, the loss of recorded data whether caused during normal operation or
misuse of the product.
NOTE:
A Toshiba wall bracket or stand, where available, must be used.
7
INSTALLING YOUR TV
7
The remote control
English
Simple at-a-glance reference of your remote
control.
2
3
6
7
10
12
15
17
19
21
25
24
1
For On/Standby mode
2
To select external input sources
3
Selectable Picture preferences
4
Widescreen viewing
5
s
Stereo/bilingual transmissions
6
To select TV Mode
7
To access the analogue or digital Channel List
8
To switch between 2D and 3D mode
9
Number buttons
10
To switch the Audio Description On/Off
11
To return to previous programme position
12
To alter the TV volume
13
To display on-screen information
To access the index page in Text mode
14
To mute the TV sound
15
To access Quick Menu
16
To change programme positions
To change TEXT pages
1
4
5
8
9
11
13
16
14
18
20
22
23
26
2
28
17
To display the digital on-screen Programme Guide
18
To exit menus
19
20
When using menus, the arrows move the cursor on the screen
up, down, left or right. Press
21
On-screen Menus
22
To return to previous Menu
23
Colour buttons:
24
To call up text services
25
To access Media Player Menu
26
Digital Subtitles or Analogue TEXT Subtitle pages if available
27
When in TV mode:
r
D
When using Programme
Guide:
Z
z
CC
cc
28
When using REGZA-LINK:
1
AUDIO
SET UP
V
ROOT
CONTENTS
TOP
DVD
To page up, down, left or right
Text and interactive service control buttons
Picture still
Analogue time
display
- 24 hours
+ 24 hours
- 1 page
+ 1 page
To turn On/Standby
To access
To access
To EJECT
To access
To access
To access
To access
OK
to confirm your selection
When in Text mode:
A
To reveal concealed
text
B
To hold a wanted
page
C
To enlarge text
display size
D
To select a page
whilst viewing a
normal picture
During Playback:
c
To PLAY
v
To STOP
W/w
To PAUSE/STEP
Z
To SKIP-BACK
CC
To REWIND
cc
To FAST FORWARD
z
To SKIP-FORWARD
AUDIO
Menu
SET UP
Menu
ROOT
Menu
CONTENTS
TOP
DVD
Menu
Menu
Menu
Inserting batteries and effective range
Remove the back cover to
reveal the battery compartment
and make sure the batteries are
inserted the proper way.
Suitable battery types for this
remote are AAA, IEC R03 1.5V.
Do not combine a used, old
battery types. Remove dead batteries immediately to prevent
acid from leaking into the battery compartment. Dispose of
them in accordance with instructions on page 83 of this
manual.
Warning:
heat such as sunshine, fire or the like.
The performance of the remote control will deteriorate beyond
a distance of five metres or outside an angle of 30 degrees
from the centre of the television. If the operating range
becomes reduced, the batteries may need replacing.
batteries must not be exposed to excessive
battery with a new one or mix
8
CONNECTING YOUR TV
Connecting external equipment
Before connecting any external equipment, turn off all main power switches. If there is no switch,
remove the mains plug from the wall socket.
LAN port
COMPONENT VIDEO INPUT*
VIDEO INPUT**
OPTICAL DIGITAL AUDIO OUTPUT
PC/HDMI2 AUDIO (shared)
®
HDMI
INPUT SOCKETS
SCART Adaptor cable
(supplied)
POWER switch
POWER cord
FIXING STRAP
English
Aerial/Cable
media recorder
Aerial cables:
. . . . . . . . . . . . . . . . . . . . . . . . .
Connect the aerial to the socket on the rear of the television.
If you use a decoder and/or a media recorder, it is essential
that the aerial cable is connected through the decoder and/or
through the media recorder to the television.
Satellite cable:
. . . . . . . . . . . . . . . . . . . . . . . .
Connect the LNB from the satellite dish to the
ANTENNA
socket on the TV. You can receive TV, radio,
"F-type"
SATELLITE
interactive TV, and HD TV with clear reception.
SCART leads:
Connect the media recorder
Connect the decoder
. . . . . . . . . . . . . . . . . . . . . . . . . .
IN/OUT
TV
socket to the television.
socket to the television.
Use the SCART Adaptor cable (supplied).
Before running
recorder to
*COMPONENT VIDEO INPUT
Use the COMPONENT Adaptor cable (supplied).
The AUDIO terminals are shared with the
**VIDEO INPUT
Use the A/V Adaptor cable or SCART-AV Adaptor cable
(supplied).
The AUDIO terminals are shared with the
INPUT
.
Auto Tuning
Standby
connection:
, put your decoder and media
.
connection:
VIDEO INPUT
COMPONENT
.
The Digital Audio Output socket enables the connection of a
suitable surround sound system.
NOTE: this output is always
active.
Satellite dish
HDMI® (High-Definition Multimedia Interface) is for use with a
DVD decoder or electrical equipment with digital audio and
video output.
For acceptable video or PC signal formats through the HDMI
terminals, see page 85.
LAN
port is used to connect the TV to your home network.
This TV can play digital content stored on a DLNA CERTIFIED™
product with server function.
A wide variety of external equipment can be connected
to the back of the television; therefore, the relevant
owner
’s
manuals for
all
additional equipment must be
referred to for exact instructions.
If the television automatically switches over to monitor external
equipment, return to normal television by pressing the desired
programme position button. To recall external equipment,
press
o
to select between
HDMI 1, HDMI 2, HDMI 3, HDMI 4, PC
DTV, EXT 1, EXT 2, EXT 3
or
ATV
.
,
When the external input mode is selected while viewing DTV
mode, the SCART socket does not output video/audio signals.
9
CONNECTING YOUR TV
Bundling the cables
English
Install the cable clamps, and put the cables in these.
Stand type
Wall Mount type
Cable Clamps
Cable Clamps
10
CONNECTING YOUR TV
English
Connecting an HDMI® or DVI
device to the HDMI input
The HDMI input on your television receives digital
audio and uncompressed digital video from an
HDMI source device or uncompressed digital video
from a DVI (Digital Visual Interface) source device.
This input is designed to accept HDCP (High-Bandwidth
Digital-Content Protection) programme material in digital
form from EIA/CEA-861-D–compliant
devices (such as a set-top box or DVD pl aye r with H DMI or DVI
output). For acceptable video signal formats, see page 85.
NOTE:
• Some early HDMI equipment may not work properly with
your latest HDMI TV, due to the adoption of a new standard.
Please unplug your HDMI cable first and then try setting the
INSTAPORT™
Your early HDMI source should operate properly with your
television. See page 73.
• Supported Audio format: Linear PCM, Dolby Digital (AC-3),
sampling rate 32/44.1/48kHz.
and
Enable Content Type
To connect an HDMI device
Connect an HDMI cable (type A connector) to the HDMI terminal.
For proper operation, it is recommended that you use an HDMI
cable with the HDMI Logo ( ).
• If your HDMI connection is capable of 1080p and/or your
television is capable of refresh rates greater than 50Hz, you
will need a Category 2 cable. Conventional HDMI/DVI cable
may not work properly with this model.
• HDMI cable transfers both video and audio. Separate
analogue audio cables are not required (see illustration).
• See “HDMI 2 Audio” on page 73.
the back of your television
[1]
consumer electronic
options to “
Off
”.
To connect a DVI device
Connect an HDMI-to-DVI adaptor cable (HDMI type A
connector) to the HDMI 2 terminal and audio cables to the PC/
HDMI 2 (AUDIO) socket (see illustration).
• The recommended HDMI-to-DVI adaptor cable length is
6.6 ft (2m).
• An HDMI-to-DVI adaptor cable transfers video only.
Separate analogue audio cables are required.
• See “HDMI 2 Audio” on page 73.
Audio cable for HDMI to
television connection
(not supplied)
HDMI-to- DVI
DVI device
NOTE:
To ensure that the HDMI or DVI device is reset properly, it is
recommended that you follow these procedures:
• When turning on your electronic components, turn on the
television first, and then the HDMI or DVI device.
• When turning off your electronic components, turn off the
HDMI or DVI device first, and then the television.
adaptor Cable
HDMI cable
HDMI device
To view the HDMI device video, press the
HDMI 1, HDMI 2, HDMI 3 or HDMI 4 mode.
o
button to select
HDMI’s ARC (Audio Return Channel) feature
This feature enables the audio signal of the TV to be sent to the
AV amplifier via the HDMI cable. It will not be necessary to
connect a cable from the audio output of the TV to the audio
input of the AV amplifier to reproduce the audio received from
the tuner of the TV through the AV amplifier.
AV amplifier that supports ARC
HDMI cable
11
CONNECTING YOUR TV
REGZA-LINK connection
English
You can control the basic functions of connected audio/video devices using the television’s remote control
if you connect a REGZA-LINK compatible AV amplifier or playback device. For an explanation of setup and
operations, see pages 75–76.
the back of your television
Playback device
AV amplifier
Playback device
For the setup shown above, you will need three HDMI cables.
NOTE:
• If several devices are connected, the REGZA-LINK feature
may not operate properly.
• For proper operation, it is recommended that you use HDMI
cables with the HDMI Logo ( ).
• This function is available when one PC and one AV amplifier
are connected separately. However, it may not operate
properly if the PC is connected via the AV amplifier.
Before controlling the device(s):
• After completing the above connections, set the REGZA-LINK
Setup menu as you desire (see page 75).
• The connected devices must also be set. For details, see the
operation manual for each device.
• The REGZA-LINK feature uses CEC technology as regulated
by the HDMI standard.
• This feature is limited to models incorporating Toshiba’s
REGZA-LINK. However, Toshiba is not liable for those
operations. Refer to individual instruction manuals for
compatibility information.
12
CONNECTING YOUR TV
English
Connecting a computer
With either an RGB/PC or an HDMI connection, you
can watch your computer’s display on the television
and hear the sound from the television’s speakers.
To connect a PC to the RGB/PC terminal
When connecting a PC to the RGB/PC terminal on the
television, use an analogue RGB (15-pin) computer cable and
a PC audio cable for the PC/HDMI 2 (AUDIO) socket. Select
PC/HDMI 2 Audio
from the
menu located in the
options in the
PREFERENCES
AV Connection
menu.
the back of your television
Mini D-sub 15 pin
connector
Computer
Audio cable for PC t o
television connection
(not supplied)
RGB PC cable
(not supplied)
PC
• A band may appear at the edges of the screen or parts of the
picture may be obscured. This is due to scaling of the picture
by the set, it is not a malfunction.
• When PC input mode is selected, some of the television’s
features will be unavailable e.g.
SETUP
menu.
• Some PC models may output unique signals that the
television may be unable to detect (see page 84).
Colour System
To connect a PC to the HDMI terminal
When connecting a PC to the HDMI terminal on the television,
use an HDMI-to-DVI adaptor cable and an analogue audio
cable.
If connecting a PC with an HDMI terminal, use an HDMI cable
(type A connector). A separate analogue cable is not
necessary.
the back of your television
Computer
Audio cable for PC to
television connection
(not supplied)
in the
HDMI-to-DVI
adaptor cable
Conversion adaptor if
(not supplied)
required
To use a PC, set the monitor output resolution on the PC before
connecting it to the television. For acceptable PC signal
formats, see page 84.
To display the optimum picture, use the PC setting feature (see
page 70).
NOTE:
• The PC audio input terminal on the television is shared with
the HDMI 2 analogue audio input terminal (see page 73).
• Some PC models cannot be connected to this television.
• An adaptor is not needed for computers with a compatible
mini D-sub15-pin terminal.
• Depending on the DVD’s title and the specifications of the PC
on which you are playing the DVD-Video, some scenes may
be skipped or you may not be able to pause during multiangle scenes.
For acceptable PC and video signal formats, see page 85.
NOTE:
• The edges of the images may be hidden.
• If connecting a certain PC model with a unique PC signal, the
PC signal may not be detected correctly.
13
CONNECTING YOUR TV
Connecting a home network
English
The LAN port allows your Toshiba TV to connect to
your home network. You can use this revolutionary
home entertainment networking system to access
photo, video and audio files that are stored on a
DLNA CERTIFIED™ server and play/display them on
your TV.
NOTE:
• If you connect to a shared network outside your home, it is
advisable to use a router. Always use DLNA CERTIFIED™
products in private network environments.
• If you use a hub or switch to connect the TV to your home
network, you may not be able to use the automatic setup
and will have to manually set up the network address. See
page 46.
• If you use a router with built-in DHCP functionality, use the
automatic setup. Manual setup may not work.
• If you connect the TV and PC directly, use a crossover LAN
cable.
To connect the TV to a home network -
Wired
the back of your television
Modem (if available)
Router with hub
To connect the TV to a home network with
an internet connection - Wireless
Please refer to “Wireless Setup” section on page 43.
TV (Built-in WLAN system)
Access point (AP)
Wireless LAN router
Modem
PC
[2][1]
Cable or
Phone jack
Server PC
[1] Coaxial or telephone cable (depending on your modem type)
[2] Standard LAN cable
[3] Do NOT connect a phone jack directly to the TV’s LAN port.
[2]
[2][3]
14
CONNECTING YOUR TV
Controls and input connections
A wide variety of external equipment can be connected to the input sockets on the side of the television.
Whilst all the necessary adjustments and controls for the television are made using the remote control, the
buttons on the television may be used for some functions
POWER switch
(Full Power Down Option)
3D IR sensor (page 7)
.
USB 1 port
Media Player
USB 2 port
Photo Viewer
COMMON INTERFACE
The Common Interface is for a Conditional
Access Module (CAM).
Contact a service provider.
The software updating of CI Plus CAM
may be automatically executed. At this
time, your Recording/Reminder
programming will be canceled.
Control panel (touch sensor)
English
GREEN LED – On Timer set
Ambient Light Sensor
ORANGE LED - Programme timer set
digital
only)
(
RED LED – Programme timer Active
digital
only)
(
Switching on
If the RED LED is not lit, check that the mains plug is connected
to the power supply and press the
left side of the television to switch the television on. If the
picture does not appear, press
take a few moments. The BLUE LED will be lit.
To put the television into Standby, press
control. To view the television, press
take a few seconds to appear.
For energy saving:
We recommend that you use the television with the factory
settings. The factory settings are for energy saving.
Turning the television off at its mains supply, or un-plugging
it, will cut energy use to nearly zero for all televisions. This is
recommended when the television is not being used for a
long time, e.g. when on holiday.
Reducing the brightness of the screen will reduce energy use.
Energy efficiency cuts energy consumption and thus saves
money by reducing electricity bills.
NOTE:
Putting the television into standby mode will reduce
energy consumption, but will still draw some power.
!
(POWER) button on the
1
on the remote control; it may
1
on the remote
1
again. The picture may
RED LED – Standby
BLUE LED – Power on
Using the remote control
Press
MENU
on the remote control to display the menu.
The menu appears as a list of five topics. As each symbol is
selected by pressing
respective options will appear below.
NOTE:
The same menu is displayed in DTV (Digital TV) and
ATV (Analogue TV) modes; however, where some items are not
available in a mode, they will appear greyed out.
To use the option, press
move up and down and press
setting. Follow the on-screen instructions. The functions of
each menu are described in detail throughout the manual.
C
or c on the remote control, its
B
and b on the remote control to
C
or c to select your desired
Using the controls and connections
2
To alter the volume gently touch –
To alter the programme position touch
Touch
MENU
picture options.
Touch
The Media Player feature provides access to photo, movie and
music files stored on a USB storage device that is connected via
USB 1 (USB 2 provides access to photos only).
NOTE:
take no responsibility for damage to other connected equipment.
To select an external input, press o until the appropriate input
source is selected.
Please always refer to the owner’s manual of the equipment to
be connected for full details.
and – 2 + or b p B to control the sound and
MENU
to finish.
The USB socket has limited functionality and Toshiba can
+.
b p B
.
15
SETTING UP YOUR TV
Startup Application
English
Before switching on the television, put your decoder
and media recorder, if applicable, to
To set up the television, use the buttons on the
remote control as detailed on page 8.
Quick Setup
a
Press the 1 button. The
appear. This screen will appear the first time that the
television is switched on and each time
selected.
b
Press B, b, C, or c to select the menu language, and
then press
c
Highlight
is now set to tune the stations for your country.
NOTE:
• The following display menus will differ slightly
• If there is not a country that you want to select in the
d
Press OK, and the
e
Press C or c to select
home use, select
f
Press OK. If
confirmation window will appear. If you select
from that window, the TV will proceed to the
Demo
OK
Country
Quick Setup
Country
Primary Subtitle Language
Secondary Subtitle Language
Primary Audio Language
Secondary Audio Language
according to the country you selected.
Others
list, select
Location
To use the TV for displaying in a store showroom, please
select [Store]. [Home] mode is recommended for normal
use.
Store
setup screen.
Menu Language
.
and
C
or c to select. The television
.
Location
Home
Home
Home
.
is s elected in step 5 , a
Standby
screen will
Reset TV
Germany
English
English
English
English
screen will appear.
or
Store
. For normal
Store mode
Auto
.
Yes
is
g
Press OK, and the
press
C
or c to select
TV Mounting
If you are mounting the TV on a wall please select [Wall].
[Stand] is recommended for other uses.
This setting may be modified later under Sound Navi in the
SOUND menu.
h
Press OK, and the
C
or c to select
AutoView
AutoView mode automatically adjusts picture settings
to suit ambient light conditions.
Do you wish to enable AutoView mode?
i
Press OK. If the
press
B
or b to select
and then press
If DVB-C is not supported in your area,
be displayed.
• When you select
to 13.
• When you select
• When you select
the Satellite Settings startup screen will appear
automatically after completing the
Cable
j
Select
Next
screen will appear with the option to select between
DTV and ATV, DTV
to select the appropriate mode.
k
Press B or b to highlight
The television will start to search for available
and/or
ATV
the scan status.
TV Mounting
AutoView
Yes
or No.
Ant/Cable/Satellite
OK
to check ( ).
Ant / Cable / Satellite
Antenna
Cable
Satellite
Antenna
Satellite
Antenna
) scan and pressing OK.
and press OK. The
or
channels. The progress bar will indicate
screen will appear,
Stand
or
Wall
.
Stand
screen will appear, press
No
Antenna, Cable
Next
ATV
Start Scan
screen appears,
Cable
or
Cable
, follow steps 10
, skip to step 14.
(or
Cable
) and
Antenna
Auto Tuning
if available. Use C or c
, and then press OK.
or
Satellite
will not
Satellite
(or
startup
DTV
,
,
16
SETTING UP YOUR TV
English
You must allow the television to complete the search.
Auto Tuning
Progress Found
DTV Tune 3% 2
ATV Tune Waiting...
Channel: C7
When the search is complete, the television will
automatically select position one.
The
Auto Tuning
screen will display the total number
of services found.
l
Press C or c to view the
DTV
(digital channel) or
(analogue channel) lists.
m
Use B or b to move through the list to select a
channel, and then press
ATV
mode, some areas may receive duplicate
In
OK
to view.
stations. There may not be a clear picture or the signal
may be weak, so the station order can be changed
using
ATV Manual Tuning
REMEMBER:
ATV
Press TV at any time to select between
and
DTV
(DTV Ant TV/RADIO/TEXT, DTV Cable
.
TV/RADIO/TEXT, DTV Sat TV/RADIO/TEXT if available)
modes.
NOTE:
The time will be set automatically by
transmission but can be advanced or decreased by
Local Time Setting
using
Next
Select
and press OK. The
in the
DTV Settings
Satellite Settings
screen will appear. From this window, you can add the
satellites that you wish to tune and configure detailed
settings for each one individually. See “Satellite
Settings” section on page 18.
Satellite Settings
Switch Type
LNB Power
Transponder : 1/83 (10743 MHz)
Dish Type : Fixed
Lower LOF (MHz) : 9600
Upper LOF (MHz) : 10600
Highlight
SatelliteNo. Dish LNB
ASTRA 19.2˚E
1
2
3
4
Done
Done
and press OK.
11
None
On
ATV
screen.
If your satellite dish is movable, the following
Positioning
Positioning
Press
C
or c to find the dish position with the strongest
screen will appear.
Satellite : ASTRA 19.2°E
Transponder
Go to 0
Go to Stored Position
Step Size
Positioning
Signal Level
B
or b to highlight
Store Position
1/83 (10743 MHz H)
1
WE
Positioning
, and then press
signal level.
Press
B
or b to highlight
OK
to store the dish position. Repeat steps 14 and 15
Store Position
and press
for the next satellite as needed.
If your satellite dish is not movable, the
Positioning
screen will not appear.
Adjust the dish position manually for maximum Signal
Level strength.
Done
Highlight
and press OK.
If the reception testing completes successfully, the
Auto Tuning
Auto Tuning - Satellite
Satellite
Scan Option
You can select
Press
OK
The television will start to search for available
startup screen will display.
Scan Option
B
or b to highlight
.
Start Scan
from
Start Scan
ASTRA(19.2°E)
Free to Air
Free to Air
, and then press
and
DVB-S
All
.
channels. The progress bar will indicate the scan
status.
When the search is complete, the
Auto Tuning
results
screen will display the total number of services found.
B
or b to move through the list to select a
Use
channel, and then press
OK
to view.
PLEASE NOTE
The
Quick Setup
time from the
menu can also be accessed at any
SETUP
menu.
17
SETTING UP YOUR TV
English
Ant/Cable/Satellite (if available)
From this menu, you can set the RF input configuration.
a
Press
MENU
, and select
b
Use b to highlight
c
to select
Antenna, Cable
NOTE:
When you attempt to change the
setting, a warning message will appear
Satellite
followed by PIN entry (if PIN has been set) and a
prompt for
c
When
following setting options will be provided in the
Tuning
Press
to select your desired option.
With the exception of
items, all of the following items will have 2 operating modes.
The first is
the system. The second is an
able to enter a single value in place of the pre-set value. If no
channel is currently tuned and the
system default value will be shown. However, if a channel is
currently tuned when the item is accessed, the value of the
current channel will be displayed.
Auto Tuning
Ant/Cable/Satellite
screen.
B
or b to select an item, and then press C or c
Auto Tuning
DTV
DTV Scan Type
Auto
where the values for each item are preset by
SETUP
menu.
Ant/Cable/Satellite
or
Satellite
.
is set to
DTV and ATVTuning Mode
Start Scan
Quick ScanScan Type
AutoStart Frequency
AutoEnd Frequency
AutoModulation
AutoSymbol Rate
AutoNetwork ID
and
Input
mode where you will be
Input
state is chosen, a
and use C or
.
Ant/Cable/
Cable
, the
DTV Modulation
DTV Scan Type:
This item determines whether a
be executed.
Quick Scan
The
designed to complete in less time.
is a simplified version of the
Quick Scan
or a
Full Scan
Full Scan
DTV Start Frequency:
This sets the frequency from which the scan will begin.
Auto
will
that is
DTV End Frequency:
This sets the frequency at which the scan will end.
DTV Modulation:
You can choose from five QAM modulation settings.
DTV Symbol Rate:
This is the baud rate (KS/s) of the scan.
DTV Network ID:
This is the Network ID to be utilized for the scan. This item is
greyed out when DTV Scan Type is set to “Full Scan”.
Satellite Settings
From the SETUP menu, you can add the satellites that you wish
to tune and configure detailed settings for each one
To add a satellite:
a
Press
b
Use b to highlight
c
Press b to highlight a new line to add an another
satellite, and press
d
Press b until the required satellite is displayed and press
OK
MENU
Satellite Settings
Switch Type
LNB Power
1
2
3
4
Transponder : 1/83 (10743 MHz)
Dish Type : Fixed
Lower LOF (MHz) : 9600
Upper LOF (MHz) : 10600
.
individually.
and use C or c to select
Satellite Settings
SatelliteNo. Dish LNB
ASTRA 19.2˚E
Done
OK
.
SETUP
. Press OK.
None
On
11
menu.
18
SETTING UP YOUR TV
English
To delete a satellite:
a
In the
Satellite Settings
menu, press B or b to
highlight the satellite you want to delete.
b
Press the
RED
button. A confirmation window will
appear.
c
Press C or c to select
NOTE:
It is not possible to delete position No.1.
Yes
To edit the satellite settings:
a
In the
Switch Type
b
Press C or c to select
2way
c
Press b to highlight
select
Satellite Settings
.
or
DiSEqC 4way
On
or
Off
menu, press B to highlight
None, ToneBurst, DiSEqC
as your satellite switch type.
LNB Power
.
To add a transponder:
a
In the
Satellite Settings
highlight the line you want to edit and press
ASTRA 19.2˚E
111
b
Press the
GREEN
screen will appear.
Transponder Settings
Frequency Polarisation Symbol Rate S/S2
1 10743 H
2 10773
3 10788
4 10817
5 10832
6 10847
7 10861
8 10876
menu, press B or b to
button. The
H
V
V
H
V
H
V
and press OK.
and press C or c to
Transponder Settings
22000
22000
22000
22000
22000
22000
22000
22000
OK
c
Press B to highlight a new line.
Transponder Settings
Frequency Polarisation Symbol Rate S/S2
76 12640 V
77 12662
78 12669
79 12692
80 12699
81 12721
82 12728
83
d
Press OK.
83 0 H0S
e
Edit each parameter as required and press OK. See
page 19
.
83 12731 H 22000 S2
H
V
H
V
H
V
22000
22000
22000
22000
22000
22000
22000
S
S
S
S
S
S
S
To delete a transponder:
.
a
In the
Transponder Settings
menu, press B or b to
highlight the line you want to delete.
b
Press the
RED
button.
To edit the Transponder Settings:
a
In the
Transponder Settings
S
S
S
S
S
S
S
S
highlight the line you want to edit and press
b
Press C or c to select
Symbol Rate
or
S/S2
number buttons if necessary.
c
Press OK to save your settings.
d
Repeat steps 1 through 3 for other lines.
menu, press B or b to
OK
Frequency, Polarisation
, and set the item using the
.
,
19
e
Press
Settings.
Press
time.
Press
initial default settings.
BLUE
to finish editing and return to Satellite
GREEN
to cancel any edits that were made this
YELLOW
to reset all transponder settings to their
SETTING UP YOUR TV
To select the Dish Type:
English
a
In the
Satellite Settings
highlight the required satellite line, and then press
OK
.
b
Press C or c to highlight
GREEN
button.
Dish Settings
Dish : 1
Dish Type
c
Press C or c to select
Movable
or
Fixed
menu, press B or b to
Dish
, and then press the
Dish Type
as the Dish Type.
. You can select
Fixed
To select the LNB Settings:
a
In the
Satellite Settings
highlight the required satellite line, and then press
OK
.
b
Press C or c to highlight
GREEN
button.
LNB Settings
LNB : 1
Lower LOF
Upper LOF
c
Press B or b to select
input the appropriate frequencies.
menu, press B or b to
LNB
, and then press the
9750
10600
Lower LOF
or
Upper LOF
Auto Tuning
NOTE:
As new services are broadcast, it will be necessary to
re-tune the television in order to view them.
Auto Tuning
used to update the channel list.
Tuning is run periodically to ensure that all new services
will completely re-tune the television and can be
are added
. All current channels and settings, i.e. locked
It is re com mended that Aut o
channels, will be lost.
and
a
Press
MENU
Use
SETUP
b
For DTV/ATV Tuning:
A screen will appear warning that previous
programmes and settings will be deleted.
Auto Tuning
Use
available, then highlight
continue with the
NOTE:
field in the
other than “
broadcasting system (B/G, I, D/K or L).
The television will start to search for all available DTV
and/or ATV services.
You must allow the television to complete the
search.
When the search is complete, the
will display the services found.
and use C or c to select
b
to highlight
Menu Language English
Country
Ant/Cable/Satellite
Satellite Settings
Auto Tuning
ATV Manual Tuning
DTV Manual Tuning
DTV Settings
Previous settings will be lost!
Press EXIT for no change.
C
or c to select
If you have selected “
Auto Tuning
Start Scan
DTV and ATV, DTV
Auto Tuning
SETUP
menu, and selected a tuning mode
DTV
” , choose the optimum ATV
. Press OK.
DTV and ATVTuning Mode
Start Scan
.
Others
Auto Tuning
SETUP
menu.
Germany
or
ATV
and press OK to
” for the
, if
Country
screen
20
SETTING UP YOUR TV
English
For Satellite Tuning:
A screen will appear warning that previous
programmes and settings will be deleted.
Auto Tuning
Previous settings will be lost! Press EXIT for no
change.
Start Scan
Free to AirSearch Option
Press
B
or b to highlight
c
to select the desired satellite (
or
All
).
You can select
Highlight
Start Scan
the
Auto Tuning
When the search is complete, the
will display the services found.
c
Use b or B to move through the list to select a
channel, and then press
Satellite
Free to Air
or
All
and press OK to continue with
.
OK
to view.
AllSatellite
and then press C or
No.1 Sat
~
No.4 Sat
as the Search Option.
Auto Tuning
screen
ATV Manual Tuning
Tuning
The television can be tuned-in manually using
Tuning
. For example, you might use the feature if the television
cannot be connected to a media record er/decoder with a SCART
lead or when you want to tune-in a station on another
Use
C
and
c t
ATV Manual Tuning options
settings
o move across the screen and select any of the
.
ATV Manual Tuning
System
1 A C 2 0 V C R
I
.
Then use B or b to adjust the
123 4 65 7 8 9
1
Position
The number to be pressed on the remote control to tune
the channel.
2
System
Specific to certain areas.
3
Colour System
Factory set to Auto, should only be changed if problems
are experienced, i.e. NTSC input from external source.
4
Skip
Set Skip to On (8) or Off (() for the selected channel.
See page 22
5
Signal Class
The channel classification.
6
Channel
The channel number on which a station is being broadcast.
7
Search
Search up and down for a signal.
8
Manual Fine Tuning
Only used if interference/weak signal is experienced. See
page 79.
9
Station
Station identification. Use the B or b and C or c buttons
to enter up to seven characters.
To allocate a position on the television for a decoder and
media recorder: turn the decoder on, insert a pre-recorded
film in the media recorder, press PLAY, and then manually
tune.
ATV Manual
System
.
21
SETTING UP YOUR TV
a
Press
English
b
MENU
menu. Press
press
OK
SETUP
Menu Language English
Country
Ant/Cable/Satellite
Satellite Settings
Auto Tuning
ATV Manual Tuning
DTV Manual Tuning
DTV Settings
Use B or b to highlight the desired position. We
suggest
ATV Manual Tuning
Pos. Channel Station
1
2
3
4
5
6
7
8
Different
c
Press OK to select. If the channel chosen for the media
recorder is set to skip, Skip should be removed before
storing.
d
Press c to select
required.
ATV Manual Tuning
System
I
1 A C 2 0
e
Then press c to select
f
Press B or b to begin the search. The search symbol
will flash.
ATV Manual Tuning
Search
1 C 2 0 IA
and use C or c to select the
b
to highlight
ATV Manual Tuning
to select.
Pos. 0
for a media recorder.
C2
S10
C7
S40
C22
C25
C28
C30
Channel
numbers may be displayed.
System
and use B or b to change if
Search
.
Germany
SETUP
and
g
Each signal will show on the television. If it is not your
media recorder, press
B
or b again to restart the
search.
h
When your media recorder signal is found, press c to
move along to
the required characters,
ATV Manual Tuning
Station
1 A C 2 0 V C R I
i
Press OK to save.
j
Repeat for each
RETURN
Station
. Use B, b, C and c to put in
e.g. VCR
.
position
you want to tune, or press
to return to the list of channels and select the
next number to tune.
k
Press
EXIT
when you have finished.
PLEASE NOTE
This television has direct channel entry if the channel
numbers are known.
ATV Manual Tuning
Select the
Position number
Enter the
standard (terrestrial) channels or
channels and the
save.
Channel
screen in
System
S
for cable
Step 3
, then C for
, the
number. Press OK to
.
Skip
To prevent certain channels from being viewed, positions can be
a
Select
ATV Manual Tuning
b
Use B or b to highlight the position to be skipped and
press
OK
ATV Manual Tuning
Pos. Channel Station
1
2
3
4
5
6
7
8
skipped.
from the
to select.
C2
S10
C7
S40 ABC1
C25
C28
C30
ABC1C22
SETUP
menu.
22
SETTING UP YOUR TV
English
c
Press c to select
d
Use B or b to turn
Press
OK
8
on the screen indicates a skipped position.
ATV Manual Tuning
Skip: On
1 A C 2 0 I
e
Press
RETURN
Each position has to be
Skip
off, repeat the procedure for each position.
Skipped positions
or by the controls on the television but
accessed by the number buttons on the remote
control.
Skip
.
and repeat from
cannot
.
Skip
on.
individually
be selected by
Step 2
or press
selected. To turn
PU and
can
still be
Sorting positions
Channels may be moved and saved to the position of your
a
Select
ATV Manual Tuning
b
With the list of channels showing, use B or b to
highlight the channel you want to move and press
ATV Manual Tuning
Pos. Channel Station
2
3
4
5
1
6
7
8
c
Use B or b to move through the list to your preferred
position. As you do so, the other channels will move to
make room.
S10
C7
C40
C22
C2
C25
C28
C30
choice.
from the
ABC1
ABC1
SETUP
EXIT
menu.
DTV Manual Tuning
NOTE:
The content of this menu varies depending on the DTV
input (
Antenna, Cable
This feature is available for service engineers or can be
used for direct channel entry if the multiplex channel
a
Select
DTV Manual Tuning
Pu
.
c
.
and press
b
Enter the multiplex number using the number buttons
or use
c
Highlight
television will automatically search for that multiplex.
When the multiplex is found, any channels that are not
currently in the channel list will be added and the
channel information at the top of the screen will be
updated.
d
Repeat as necessary. Press
OK
DTV Manual Tuning
Signal Strength
Quality
Channel
C
or c to adjust the number up or down.
Start Scan
DTV Manual Tuning
Pos.New TypeName
1
2
7
40
51
, or
Satellite
) that is currently selected.
Manual Tuning
is known.
.
WEAK
0 New Channels - Total 6
ABC ONE
ABC TWO
ABC THREE
ABC NEWS 24
ABCi
from the
GOOD
Start Scan
, and then press OK. The
EXIT
SETUP
to finish.
menu
STRONGAVERAGE
13
d
Press C to save your move.
Repeat as necessary, and then press
EXIT
.
23
SETTING UP YOUR TV
English
When
Tuning
Frequency
Modulation
Manual Tuning for DVB-C
Ant/Cable/Satellite
items are as follows:
– input a specific frequency to be scanned
– choose from one of five QAM modulation
is set to
options
Symbol Rate
the manual scan
Highlight
– input a specific baud rate (KS/s) to be used for
Start Scan
, and then press OK.
Manual Tuning for DVB-S
When
Ant/Cable/Satellite
items are as follows:
Tuning
DTV Manual Tuning - Satellite
Signal Strength
Quality
Satellite
Transponder
Frequency
Symbol Rate
Polarisation
Search Option
B
or b to highlight an item (
Use
Frequency, Symbol Rate, Polarisation
and then press
Highlight
C
Start Scan
is set to
WEAK
POOR
Start Scan
or c to select the required option.
, and then press OK.
Cable, DTV Manual
Satellite, DTV Manual
STRONGAVERAGE
ASTRA 28.2°E
1/83
10714 MHz
22000 KS/s
H
Free to Air
Satellite, Transponder
or
Search Option
DTV Settings
The channel order may be changed to suit your personal
a
b
c
,
),
Channels (Antenna/Cable)
preference.
Select
DTV Settings
OK
.
Select
Channels
DTV Settings
Channels
Subtitle and Audio
PIN Setting
Parental Control
Local Time Setting
Standby Channel Update
DVB Character Set
Dynamic Scan
For your convenience, you can jump to specific places
in the list by one of two methods.
Channels
Line No. 1/10
Pos. Name
1 ABC ONE
2 ABC TWO
7 ABC THREE
30 CABC Channel
40 ABC NEWS 24
51 ABCi
822 AA
823 AC
from the
and press OK.
SETUP
menu and press
Standard
Off
On
TV
24
Line Number Jump
—Use the
number buttons
(0-9) to input the line number you want to select, and
then press
Station Letter Jump
OK
.
—Press CC or cc to jump
to the next station name with a different initial letter.
It is also possible to change the Position number of a
particular channel.
Renumber
— Press the
RED
button to renumber the
highlighted channel. Edit the channel number using
the
number buttons
Pos.
----
and press OK.
Name
ABC ONE
Move
—Press the
Move
feature. Use the B or b buttons to select the
channel you wish to move and press
GREEN
button to activate the
OK
to check.
If you wish to move multiple channels at once, select
another channel and check in the same way. Repeat as
necessary.
Once all desired channels have been checked, use the
B
or b buttons to place the focus at the position to
which you wish to move the channels. The channels
will be inserted above the highlighted channel. Press
the
GREEN
button to execute the move.
Channels
Line No. 1/10
Pos. Name
1 ABC ONE
2 ABC TWO
7 ABC THREE
30 CABC Channel
40 ABC NEWS 24
51 ABCi
822 AA
823 AC
Sort
—Press the
window will appear. Press
press
OK
Sort
Your existing channel order will be lost. Do you wish to
continue?
Sorting Type
The
Sort
Sorting Type A - Z
Press
C
A - Z
Channel Number
b
Press
YELLOW
button. A confirmation
C
or c to select
.
Yes
selection window will appear.
Sort
or c to set the sorting type.
Station name order (A to Z)
Position No. order (numerical
sequence)
to highlight
Sort
and press OK.
Yes
TV
and
SETTING UP YOUR TV
Channels (Satellite)
a
Select
DTV Settings
OK
.
b
Select
Channels
The satellite channel list will appear.
Channels
Line No. 4/1200
Pos. Station Satellite
1 DDD 19.2°E
2AB
3E
801 BBC
802 BB
803 BA
822 AA
823 AC
c
For your convenience, you can edit and sort your
channel list.
Line Number Jump
(0-9) to input the line number you want to select, and
then press
Station Letter Jump
to the next station name with a different initial letter.
Satellite Jump
next channel on a different Satellite.
Renumber
See page 24.
Move
— Same as Antenna/Cable channels. See
page 25.
Sort
— Press the
window will appear. Press
press
OK
.
The
Sort
menu will appear.
Sort
Group By Satellite
Sorting Type Channel Number
Preset Order Yes
from the
SETUP
and press OK.
OK
—Use the
.
number buttons
—Press CC or cc to jump
—Press Z or z to jump to the
— Same as Antenna/Cable channels.
YELLOW
button. A confirmation
C
or c to select
Sort
menu and press
Satellite TV
19.2°E
19.2°E
22.5°E
22.5°E
22.5°E
25.6°E
25.6°E
Yes
and
English
25
SETTING UP YOUR TV
Group
English
— Press C or c to select
Sorting Type
A - Z
Channel Number
Preset Order
This item is displayed when Country is set to Germany,
and only applies to the Astra 19.2°E satellite.
Press
— Press C or c to set the sorting type.
—Press C or c to set
b
to highlight
Sort
All
or
By Satellite
Station name order (A to Z)
Position No. order (numerical
sequence)
Yes
or No.
and press OK.
Standby Channel Update
If the
Standby Channel Update
standby mode, Digital Tuning is automatically executed and any
a
Select
OK
b
Press b to select
C
new channels are saved.
DTV Settings
.
or c to select On.
is set to On, when the TV is in
from the
SETUP
menu and press
Standby Channel Update
and use
.
If the broadcast information has changed in your DVB-T
receiving area, the TV screen will display the message
Broadcast information has changed. Would you like to
“
rescan now?
for the TV to detect changes and prompt you to rescan, you
a
Select
OK
b
Press b to select
select
Dynamic Scan
”. Please follow the message. If you do not wish
should set this feature to “
DTV Settings
.
On
.
from the
SETUP
Dynamic Scan
Location setting
You can select either
recommended for normal home use. Select
the television for displaying in a shop, etc.
a
Select
Location
b
Press C or c to select
Home
from the
Home
or
SETUP
Store
or
menu.
Store
Off
”.
menu and press
and use C or c to
mode.
Home
when using
.
is
Store
DVB Character Set
This feature allows you to manually select the character set
(
Standard
a
b
= Table 0,
to be used for DVB-C or DVB-T channels.
Select
OK
.
Press b to select
to select
West
DTV Settings
DVB Character Set
Standard, West
= Table 5 or
from the
SETUP
or
Latin alphabet 9
Latin alphabet 9
menu and press
and use C or c
Analogue
digital
This is a
of both
)
lifetime of this set it is very likely that
be switched off to allow for more new
This ‘switch-off’ will happen in a number of phases, which will
be advertised in your area well in advance. It is recommended
that at each phase the television is re-tuned to ensure that
existing and new
.
disruption.
television which is integrated to allow the use
digital
and
analogue
digital
switch-off
services. However, during the
analogue
services will
digital
services.
services can be viewed without
26
CONTROLS AND FEATURES
English
General controls
Quick Menu
Quick Menu
Picture Mode, Picture Size, More Information, Sleep
Timer
Press
select the option.
Quick Menu
Picture Mode AutoView
Picture Size
3D Settings
More Information
Channel Options
YouTube
Media Player
Photo Frame
Sleep Timer
Speakers
Wireless Information
NOTE: Quick Menu
current mode.
Quick menu item example
When viewing a TV
programme or
pictures from the
external input
Single Window or
3D Single Window
When using EPG Genre Colour See page 65.
Media Player (Multi
View, List View)
Photo Frame PICTURE See page 36.
helps you access some options quickly, such as
etc.
QUICK
to display the
Mode Quick menu item Description
Quick Menu
items are different depending on the
Picture Mode See page 36.
Picture Size See page 34.
3D Settings See page 28.
More Information See page 64.
Channel Options See page 67.
YouTube See page 50.
Media Player See page 52.
Photo Frame See page 59.
Sleep Timer See page 63.
Speakers See page 75.
Wireless Information See page 45.
EPG Update/
Cancel EPG Update
Sort See page 55.
Interval Time See page 55.
Repeat See page 55.
Device Information See page 55.
Wireless Information See page 45.
and use B or b to
Super Live
00:00
TV Speakers
See page 65.
Selecting positions
To select a position, use the numbered buttons on the remote
control.
PU and
Positions can also be selected using
To display on-screen information such as position, input mode
or stereo/mono signal, press . Press again to cancel.
The Time Display –
The time display facility allows the current (text service) time to
Press
see the time display from the broadcaster. It will remain on
screen for about 5 seconds.
NOTE:
be seen on the television screen.
D
whilst watching a normal television broadcast to
This display may not be available in some cases.
analogue
Pu.
only
Stereo and Bilingual transmissions
For ATV programmes
If stereo or dual language broadcasts are transmitted, the word
Stereo or Dual will appear on the screen each time positions are
changed, disappearing after a few seconds. If the broadcast is
not in stereo, the word Mono will appear.
Stereo…
Press s to select
Bilingual…
transmitted, the word
required programme number, and if the word
press
Bilingual transmissions are rare. If they are
s
to select
For DTV programmes
For stereo or dual mono broadcasts, press s and use C or
c
to select settings.
Mode Display Pressing
Stereo Stereo S Left S Right
Dual mono Dual 1
Mono –
Multichannel –
For multi-audio track broadcasts, press
change the audio language (see ‘Audio language’ on
page 68).
Stereo
or
Mono
Dual
will be displayed. Choose the
Dual 1, Dual 2
S
or
Mono
Dual 2
s
.
Dual
appears,
.
c
repeatedly to
27
Loading...
