Toshiba XV636-32, XV636-37, XV636-42, XV636-46, XV635-42 User Manual

...

XV***

Digital

Series

TOSHIBA

Contents

SETTING UP

Safety precautions – Some do’s and don't for you to be aware of 4 Installation and important information 5 The remote control – an at-a-glance guide 6 Connecting external equipment – a guide to connecting external equipment to the back of the television 7 REGZA-LINK connections 8 Connecting an HDMI or DVI device to the HDMI input 9 Connecting a computer – connecting a computer to the HDMI terminal on the back of the television 10 Acceptable signals through HDMI terminals 11 Connecting a computer – connecting a computer to the RGB/PC terminal on the back of the television 12 Acceptable PC signals through the PC terminal 13 Using the controls – switching on the television, standby, using the remote control, using the controls on

the television, headphone socket 14

TUNING THE TELEVISION

Tuning the television for the first time 15 Setting antenna or cable 16

DTV auto tuning, manual tuning, manual tuning for DVB-C 17 DTV location, auto channel update, DVB character set, Analogue switch off 18 DTV sorting channels, skipping channels 19 ATV manual tuning, broadcast system 20 ATV skipping channels, sorting channel positions 21

CONTROLS AND FEATURES

General controls – selecting programme positions 22 Stereo and bilingual transmissions – stereo/mono or dual language broadcasts 22 Time display (ATV only) 22

Sound controls – volume, sound mute 22

Quick menu 22 Sound settings – dual, bass, treble and balance, advanced sound settings (surround, voice enhancement,

dynamic bass boost, external woofer), Dolby Volume

Sound settings – dynamic range control (DTV only), audio level offset, headphone settings,

audio description 24 Widescreen viewing 25 Picture controls – picture position (ATV only), picture mode, picture preferences (contrast, brightness,

colour, tint, sharpness) 27 Picture controls – reset, backlight, 3D colour management, base colour adjustment 28 Picture controls – colour temperature, auto brightness sensor settings, active backlight control,

black/white level 29 Picture controls – static gamma, MPEG noise reduction (MPEG NR), digital noise reduction (DNR),

Resolution + 30 Picture controls – Active Vision M100, film stabilization, expert mode, reset 31 Picture controls – control visualization, panel lock (disabling the buttons on the television),

automatic format (widescreen) 32 Picture controls – 4:3 stretch, blue screen, side panel adjustment, Toshiba illumination, picture still 33

DTV programme timer 34

Timers – on timer (setting the television to turn on) 34 Timers – cancelling the on timer, sleep timer (setting the television to turn off) 35

DTV on-screen information 36 DTV programme guide 37 DTV Settings – setting the PIN code, parental control, locking channels 38 DTV Settings – subtitles, audio languages, common interface 39

Contents (continued)

Software Upgrade – auto upgrade, searching for new software, software licences, system information,

reset TV 40 Media player – auto start, opening media player automatically, opening media player from the menu 41 Media player – multiview, single view, slideshow, interval time and repeat 42 Media player – playing movies, picture size and repeat, DivX® VOD 43 Media player – playing music, repeat mode 44 Media player – setting up the photo frame feature 45 PC settings for RGB/PC connections – picture position, clock phase, sampling clock, reset 46 REGZA-LINK controls – general information, input source selection 47 REGZA-LINK menus – enable REGZA-LINK 48 REGZA-LINK menus – TV auto power, auto standby, amplifier control, speaker preference 49 Input selection and AV connections – input selection, external input skip, input signal selection, PC audio 50 Input selection and AV connections – HDMI1 Audio, HDMI settings (lip sync, INSTAPORT™, RGB range),

digital output 51

TEXT SERVICES

ATV text services – selecting modes, general information, Auto and LIST modes 52 ATV text services – control buttons 53 DTV interactive services – general information 53

PROBLEM SOLVING

Questions and Answers – answers to some common queries including manual fine tuning, colour system 54

INFORMATION

Disposal 58 Specifications and Accessories – technical information about the television, supplied accessories 59

Safety Precautions

This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken to obtain the best results and for safety to be assured. Please read the points below for your own safety. They are of a general nature, intended to help with all electronic consumer products and some points may not apply to the goods you have just purchased.

DO NOT obstruct the ventilation openings of the equipment with items such as newspapers, tablecloths, curtains, etc. Overheating will cause damage and shorten the life of the equipment.

DO NOT allow electrical equipment to be exposed to dripping or splashing or objects filled with liquids, such as vases, to be placed on the equipment.

DO NOT place hot objects or naked flame sources, such as lighted candles or nightlights on, or close to equipment. High temperatures can melt plastic and lead to fires.

DO NOT use makeshift stands and NEVER fix legs with wood screws. To ensure complete safety, always fit the manufacturers’ approved stand, bracket or legs with the fixings provided according to the instructions.

DO NOT leave equipment switched on when it is unattended, unless it is specifically stated that it is designed for unattended operation or has a standby mode. Switch off by withdrawing the plug, make sure your family know how to do this. Special arrangements may need to be made for people with disabilities.

DO NOT continue to operate the equipment if you are in any doubt about it working normally, or it is damaged in any way – switch off, withdraw the mains plug and consult your dealer.

WARNING – excessive sound pressure from earphones or headphones can cause hearing loss.

ABOVE ALL – NEVER let anyone, especially children, push or hit the screen, push anything into holes, slots or any other openings in the case.

NEVER guess or take chances with electrical equipment of any kind – it is better to be safe than sorry.

Leave more than 10cm clearance around the television to allow adequate ventilation. This will prevent overheating and possible damage to the television. Dusty places should also be avoided.

Damage may occur if the television is left in direct sunligh

t or near a heater. Avoid places subject to

extremely high temperat

ures or humidity. Place in a location where the temperature remains between 5°C (41°F) min. and 35°C (94°F) max.

The mains supply required for this equipment is 220-240v AC 50/60Hz. Never connect to a DC supply or any other power source. DO ensure that the television is not standing on the mains lead. DO NOT cut off the mains plug from this equipment, this incorporates a special Radio Interference Filter, the removal of which will impair its performance.

In the UK, the fuse fitted in the plug is approved by ASTA or BSI to BS1362. It should only be replaced by a correctly rated and approved type and the fuse cover must be refitted.

IF IN DOUBT PLEASE CONSULT A COMPETENT ELECTRICIAN.

DO read the operating instructions before you attempt to use the equipment.

DO ensure that all electrical connections (including the mains plug, extension leads and inter-connections between pieces of equipment) are properly made and in accordance with the manufacturers’ instructions. Switch off and withdraw the mains plug before making or changing connections.

DO consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.

DO be careful with glass panels or doors on equipment.

Air Circulation

Do not

Heat Damage

Mains Supply

DO NOT REMOVE ANY FIXED COVERS AS THIS WILL EXPOSE DANGEROUS AND 'LIVE' PARTS.

THE MAINS PLUG IS USED AS A DISCONNECTING DEVICE AND THEREFORE SHOULD BE READILY OPERABLE.

Installation and important information

EXCLUSION CLAUSE

Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by: i) fire; ii) earthquake; iii) accidental damage; iv) intentional misuse of the product; v) use of the product in improper conditions; vi) loss and/or damage caused to the product whilst in the possession of a third party; vii) any damage or loss caused as a result of the owner’s failure and/or neglect to follow the instructions set out in the owner’s

manual;

viii) any loss or damage caused directly as a result of misuse or malfunction of the product when used simultaneously with

associated equipment;

Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not limited to the following, loss of profit, interruption of business, the loss of recorded data whether caused during normal operation or misuse of the product.

NOTE: A Toshiba wall bracket or stand, where available, must be used to maintain the product’s BEAB approval.

Where to install

Locate the television away from direct sunlight and strong lights, soft, indirect lighting is recommended for comfortable viewing. Use curtains or blinds to prevent direct sunlight falling on the screen.

Place the TV on a stable, level surface that can support the weight of the TV. In order to maintain stability and prevent it

falling over, secure the TV to the level surface using the strap located under the table top stand, or to a wall using a sturdy tie to the clip on the back of the table top stand.

The LCD display panels are manufactured using an extremely high level of precision technology, however sometimes some parts of the screen may be missing picture elements or have luminous spots. This is not a sign of a malfunction.

Make sure the television is located in a position where it cannot be pushed or hit by objects, as pressure will break or damage the screen, and that small items cannot be inserted into slots or openings in the case.

Cleaning the screen and cabinet…

Turn off the power, clean the screen and cabinet with a soft, dry cloth. We recommend that you do not use any proprietary polishes or solvents on the screen or cabinet as this may cause damage.

Please take note

The digital reception function of this television is only effective in the countries listed in Country in the SETUP menu. Depending on the country/area some of this television’s functions may not be available. Reception of future additional or modified services can not be guaranteed with this television.

If stationary images generated by 4:3 broadcasts, text services, channel identification logos, computer displays, video games, on screen menus, etc. are left on the television screen for any length of time they could become conspicuous, it is always advisable to reduce both the brightness and contrast settings.

Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at the 4:3 outlines, this is not a defect of the LCD TV and is not covered under the manufacturers warranty. Regular use of other size modes (eg. Superlive) and varying the “side panel” brightness (if available on the model) will prevent permanent retention.

Side View

Stand style is dependant on the model

Top View

Sturdy tie (short as possible)

Stand

clip

Stand

clip

‘P’ Clip

Fixing strap

‘P’ Clip

Sturdy tie (short as possible)

Fixing

strap

The remote control

Remove the back cover to reveal the battery compartment and make sure the batteries are inserted the right way round. Suitable battery types for this remote are AAA, IEC R03 1.5V.

Do not combine a used, old battery with a new one or mix battery types. Remove discharged batteries immediately to prevent acid from leaking into the battery compartment. Dispose of them in accordance with the disposal instructions in this manual. Warning: batteries must not be exposed to excessive heat such as sunshine, fire or the like.

The performance of the remote control will deteriorate beyond a distance of five metres or outside an angle of 30 degrees from the centre of the television. If the operating range becomes reduced the batteries may need replacing.

Inserting batteries and effective range of the remote

Simple at-a-glance reference of your remote control.

To change programme positions and text pages

Widescreen viewing To call up text services in analogue mode

and interactive services in digital mode

To exit Menus

Digital subtitles

To select mode

To select input from external sources,

analogue or

digital

TV.

Quick menu

Stereo/bilingual transmissions

To switch between ATV (analogue

TV) and DTV (digital TV)

To display on-screen menus

To display the digital on-screen

Programme Guide

To alter the volume

To display on-screen information

Text and interactive service control buttons

To return to the previous menu

Number buttons

Audio description

To mute the sound

For On/Standby mode

REGZA-LINK or DVD mode:

press

to PAUSE/STEP

press

to PLAY

press

to REWIND

press

to FAST FORWARD

press

to EJECT

press

to STOP

press

to SKIP-REWIND

press

to SKIP-FORWARD

When using menus the arrows move the cursor on the screen up, down, left or right. OK to confirm your selection

When in TV mode:

MENU To display on-screen menus ATV/DTV

To switch between ATV (analogue TV) and DTV (digital TV)

LIST

To switch between TV and Radio lists in DTV mode

u Still picture

8/9

Analogue time display

When using the Programme Guide:

– 24 hours

+ 24 hours

– 1 page

+ 1 page

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are registered trademarks of

Dolby Laboratories.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.

INSTAPORT™ and INSTAPORT logo are trademarks of Silicon Image, Inc. in the United States and other countries.

Manufactured under licence from Audyssey Laboratories U.S. and foreign patents pending. Audyssey EQ is a registered trademark of Audyssey Laboratories.

Connecting external equipment

Before connecting any external equipment, turn off all main power switches. If there is no switch remove the mains plug from the wall socket.

PLEASE NOTE: Although this television is able to connect to HDMI equipment it is possible that some equipment may not operate correctly.

A wide variety of external equipment can be connected to the back of the television, therefore the relevant owners manuals for all additional equipment must be referred to.

We recommend SCART 1 for a decoder and SCART 2 for a media recorder.

If connecting S-VIDEO equipment, set the INPUT for EXT2. See page 50.

If the television automatically switches over to monitor external equipment, return to normal television by pressing the desired programme position button. To recall external equipment, press

to select between TV, EXT1, EXT2, EXT3C, HDMI1,

HDMI2, HDMI3, HDMI4 (Model dependant) or PC.

When the external input mode is selected whilst viewing DTV mode the SCART socket will not output video/audio signals. The SCART output will also be muted in EPG mode.

Aerial cables:

Connect the aerial to the socket on the rear of the television. If you use a decoder* and/or a media recorder it is essential that the aerial cable is connected through the decoder and/or through the media recorder to the television.

SCART leads:

Connect the video recorder IN/OUT socket to the television. Connect the decoder TV socket to the television. Connect the media recorder SAT socket to the decoder MEDIA REC. socket.

Before running Auto tuning put your decoder and media recorder to Standby.

The phono sockets alongside the COMPONENT VIDEO INPUT sockets will accept L and R audio signals.

The Digital Audio Output socket enables the connection of a suitable surround sound system. NOTE: this output is always

active.

HDMI (High-Definition Multimedia Interface) is for use with a DVD, decoder or electrical equipment with digital audio and video output. It is designed for best performance with 1080i and 1080p high-definition video signals but will also accept and display VGA, 480i, 480p, 576i, 576p and 720p signals.

Media Recorder

Decoder*

CABLE HOLDER

FIXING STRAP

HDMI INPUT SOCKETS

SCART 2 (EXT2)

COMPONENT VIDEO INPUT (EXT3)

SCART 1 (EXT1)

OPTICAL DIGITAL AUDIO OUTPUT

a decoder could

be Digital Satellite or any other

compatible decoder.



The cable holders

can be used for aerial,

media recorder and

audio cables. Do not

use as handles and

remove all cables

before moving the

television.



REGZA-LINK connections

HDMI IN HDMI OUT

HDMI OUT

The back of your television

Playback equipment

AV amplifier

Playback equipment

The basic functions of connected audio/video equipment can be controlled using the televisions remote control if a REGZA-LINK compatible device is connected.

NOTE: It is recommended that for correct operation all audio/video devices are connected using HDMI cables branded with the HDMI logo ( ). If several devices are connected, the REGZA-LINK feature may not operate properly.

After connecting the equipment use the REGZA-LINK menus to setup the desired options. The connected equipment must also be set. For details see the operation manual for each connected device.

NOTE: The REGZA-LINK feature uses CEC Technology as regulated by the HDMI standard. This feature is limited to models incorporating Toshiba’s REGZA-LINK. However, Toshiba is not liable for those operations. Refer to individual instruction manuals for compatability information.

DVI / HDCP

OUT

VIDEO AUDIO

L R

OUT

Connecting an HDMI or DVI device to the

HDMI input

The HDMI input on the television receives digital audio and uncompressed digital video from an HDMI source device, or uncompressed digital video from a DVI (Digital Visual Interface) source device.

This input is designed to accept HDCP (High-Bandwidth Digital-Content Protection) programme material in digital form from EIA/CEA-861-D–compliant [1] consumer electronic devices (such as a set-top box or DVD player with HDMI or DVI output). For acceptable signal formats, see page 11.

NOTE: Some early HDMI equipment may not work properly with the latest HDMI TV, due to the adoption of a new standard. Please unplug the HDMI cable first and then try setting the options in HDMI Settings to Off. See page 51.

Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.

Connect an HDMI cable (type A connector) to the HDMI terminal. For proper operation, it is recommended that an HDMI cable with the HDMI Logo ( ) is used.

If the HDMI connection is capable of 1080p and/or the television is capable of refresh rates greater than 60Hz, a Category 2 cable will be required. Conventional HDMI/DVI cable may not work properly with this mode.

HDMI cable transfers both video and audio. Separate analogue audio cables are not required. See “HDMI1 Audio” on page 51.

Connecting an HDMI device

To view the HDMI device video, press the Bto select HDMI1, HDMI2, HDMI3 or HDMI4 (Model dependant) mode.

Connecting an HDMI Device

Connect an HDMI-to-DVI adaptor cable (HDMI type A connector) to the HDMI1 terminal and audio cables to the HDMI1 (AUDIO) socket. The recommended HDMI-to-DVI adaptor cable length is 6.6 ft (2m).

An HDMI-to-DVI adaptor cable transfers video only. Separate analogue audio cables are required.See “HDMI1 Audio” on page 51.

NOTE: To ensure that the HDMI or DVI device is reset properly, it is recommended that these procedures are followed: When switching on electronic components, switch on the television first and then the HDMI or DVI device. To switch off, first switch off the HDMI or DVI device and then the television.

Connecting a DVI Device

Audio cable for HDMI to

television connection

(not supplied)

HDMI-to-DVI adaptor cable

DVI device

HDMI cable

HDMI device

[1] EIA/CEA-861-D compliance covers the transmission of uncompressed digital video with high-bandwidth digital content protection, which is being standardised for reception of high-definition video signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the television. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC. INSTAPORT™ and INSTAPORT logo are trademarks of Silicon Image, Inc. in the United States and other countries.

VIDEO AUDIO

L R

OUT

HDMI OUT

Connecting a computer via HDMI

the back of your television

Computer

Audio cable for PC to television

connection (not supplied)

HDMI-to-DVI adaptor cable

With the HDMI connection, you can watch your computer’s display on the television and hear the sound from the televisions speakers.

When connecting a PC to the HDMI terminal on the television, use an HDMI-to DVI adaptor cable and an analogue audio cable.

If connecting a PC with an HDMI terminal, use an HDMI cable (type A connector). A separate analogue audio cable is not necessary). See page 9.

PLEASE NOTE:

It is possible that some PCs when connected may not display correctly. Some PC models cannot be connected to this television.

A band may appear at the edges of the screen or parts of the picture may be obscured. This is due to scaling of the picture by the set, it is not a malfunction.

Connecting a PC to the HDMI Terminal

Acceptable signals through

HDMI terminals

Format Resolution V. Frequency H. Frequency Pixel Clock Frequency VESA Standard

480i 720 X 480i 59.940/60.000Hz 15.734/15.750kHz 27.000/27.027MHz

576i 720 X 576i 50.000Hz 15.625kHz 27.000MHz

480p 720 X 480p 59.940/60.000Hz 31.469/31.500kHz 27.000/27.027MHz

576p 720 X 576p 50.000Hz 31.250kHz 27.000MHz

1080i 1920 X 1080i 59.940/60.000Hz 33.716/33.750kHz 74.176/74.250MHz

1080i 1920 X 1080i 50.000Hz 28.125kHz 74.250MHz

720p 1280 X 720p 59.940/60.000Hz 44.955/45.000kHz 74.176/74.250MHz

720p 1280 X 720p 50.000Hz 37.500kHz 74.250MHz

1080p 1920 X 1080p 59.940/60.000Hz 67.433/67.500kHz 148.352/148.500MHz

1080p 1920 X 1080p 50.000Hz 56.250kHz 148.500MHz

1080p 1920 X 1080p 24.000Hz 27.000kHz 74.250MHz

VGA 640 X 480

59.940/60.000Hz 31.469/31.500kHz 25.175/25.200MHz

•

72.809Hz 37.861kHz 31.500MHz

•

75.000Hz 37.500kHz 31.500MHz

•

SVGA 800 X 600

56.250Hz 35.156kHz 36.000MHz

•

60.317Hz 37.879kHz 40.000MHz

•

72.188Hz 48.077kHz 50.000MHz

•

75.000Hz 46.875kHz 49.500MHz

•

XGA 1024 X 768

60.004Hz 48.363kHz 65.000MHz

•

70.069Hz 56.476kHz 75.000MHz

•

75.029Hz 60.023kHz 78.750MHz

•

WXGA

1280 X 768

59.995Hz 47.396kHz 68.250MHz

•

59.870Hz 47.776kHz 79.500MHz

•

74.893Hz 60.289kHz 102.250MHz

•

1360 X 768 60.015Hz 47.712kHz 85.500MHz

•

SXGA 1280 X 1024

60.020Hz 63.981kHz 108.000MHz

•

75.025Hz 79.976kHz 135.000MHz

•

The HDMI inputs on this television only accept VGA, SVGA, XGA, WXGA and SXGA signal formats which are compliant with VESA as shown in the table below.

The input signals for some PCs and HDMI or DVI devices are different from the resolution and frequencies listed and this may cause the following; incorrect display, false format detection, picture position failure, blur or judder. These problems may be resolved by setting the monitor output format on the PC, HDMI or DVI device to conform to any of the signals listed in the table.

Connecting a computer via RGB/PC

The back of your

television

Computer

Audio cable for PC to

television connection

(not supplied)

Conversion adaptor if required (not supplied)

RGB PC cable (not supplied)

Mini D-sub

15 pin connector

Before connecting any external equipment, turn off all main power switches. If there is no switch remove the mains plug from the wall socket.

Connect the PC cable from the computer to the PC terminal on the back of the television, then the audio cable to the PC/HDMI1 Audio socket on the back of the television. Select

PC from the PC/HDMI1 Audio options in the AV connection menu located in the SET UP menu.

Press the

to select PC mode.

IMPORTANT NOTE: Some PCs when connected they may not display correctly.

PLEASE NOTE:

Some PC models cannot be connected to this television.

An adaptor is not needed for computers with a DOS/V compatible mini D-sub 15 pin terminal.

A band may appear at the edges of the screen or parts of the picture may be obscured. This is due to scaling of the picture by the set, it is not a malfunction.

When PC input mode is selected some of the television’s features will be unavailable e.g. Manual setting in the SET UP menu, Colour, Tint, DNR and Black/White Level in the PICTURE menu.

Pin assignment for RGB/PC terminal

Signal information for Mini D-sub 15 pin connector

Pin No. Signal name Pin No. Signal name

1 R 9 NC

2 G 10 Ground

3 B 11 NC

(not connected)

12 NC

5 NC 13 H-sync

6 Ground 14 V-sync

7 Ground 15 NC

8 Ground

Acceptable PC signals through

the PC terminal

Format Resolution V. Frequency H. Frequency Pixel Clock Frequency VESA Standard (DMT)

VGA 640 X 480

59.940Hz 31.469kHz 25.175MHz

•

72.809Hz 37.861kHz 31.500MHz

•

75.000Hz 37.500kHz 31.500MHz

•

SVGA 800 X 600

56.250Hz 35.156kHz 36.000MHz

•

60.317Hz 37.879kHz 40.000MHz

•

72.188Hz 48.077kHz 50.000MHz

•

75.000Hz 46.875kHz 49.500MHz

•

XGA 1024 X 768

60.004Hz 48.363kHz 65.000MHz

•

70.069Hz 56.476kHz 75.000MHz

•

75.029Hz 60.023kHz 78.750MHz

•

WXGA

1280 X 768

59.995Hz 47.396kHz 68.250MHz

•

59.870Hz 47.776kHz 79.500MHz

•

74.893Hz 60.289kHz 102.250MHz

•

1360 X 768 60.015Hz 47.712kHz 85.500MHz

•

SXGA 1280 X 1024

60.020Hz 63.981kHz 108.000MHz

•

75.025Hz 79.976kHz 135.000MHz

•

The PC input on this television only accepts signal formats which are compliant with VESA-DMT as shown in the table below.

Some PCs input signals are different from the resolution and frequencies listed and this may cause the following; incorrect display, false format detection, picture position failure, blur or judder. These problems may be resolved by setting the monitor output format on the PC to conform to any of the signals listed in the table.

Using the Controls

Whilst all the necessary adjustments and controls for the television are made using the remote control, the buttons on the television may be used for some functions.

To alter the volume press — j+.

To alter the programme position press

eeFff

Press MENU and S,R, Q or P to control the sound and picture options. Press MENU to finish.

When connecting sound equipment to EXT3, connect the audio output of the equipment to thephono sockets on the television.

To select the external input, press Band select the required input source. See page 50.

Please always refer to the owner’s manual of the equipment to be connected for full details.

NOTE: Interactive video games that involve shooting a ‘gun’ type of joystick at an on-screen target may not work with this television.

Switching On

Using the Controls

Press the MENU button on the remote control to see the menus.

The menu appears as a list of five topics. As each symbol is selected by pressing

or xon the navigation ring on the

remote control, its respective options will appear below.

IMPORTANT: At the bottom of the screen will be a bar displaying a selection of control functions, i.e. Select, Watch, Back, Watch TV.

NOTE: The same menu is displayed in DTV (Digital TV) and ATV (Analogue TV) modes, however, where some items are not available in a mode they will appear greyed out.

To use the options press the fand ebutton on the remote control to move up and down through them and OK, zord xto select the required choice. Follow the on screen instructions. The functions of each menu are described in detail throughout the manual.

Using the Remote Control

If the RED LED is unlit check that the mains plug is connected to the power supply and press the i/IPOWER button on the left side of the television. If the picture does not appear press ion the remote control, it may take a few moments, the GREEN LED will be lit.

To put the television into Standby press

on the remote control. To view the television press iagain. The picture may take a few seconds to appear.

NOTE: When the television is put into standby it will automatically search for updates if Auto Channel Update has been activated.

When the

/IPOWER switch is turned off, the digital channel position you previously viewed may not be memorised in the television memory.

RETURN

Standby

GREEN LED – On Timer Set (LED 2)

ORANGE LED – Programme Timer Set (digital only)

RED LED – Programme Timer Active (digital only) (LED 3)

RED LED – Standby

GREEN LED – Power on (LED 1)

Headphone jack

COMMON INTERFACE

The Common Interface is for a Conditional Access

Module (CAM). Contact a service provider.

Input 3

(side) will take

priority over

EXT3 (back) if both connections are used at the

same time.



POWER switch

(Full Power

Down Option)

INPUT 3

(EXT3)

USB JPEG VIEWER

This socket has limited

functionality and

Toshiba can take no

responsibility for damage to other

connected equipment.

SD Card slot allows access to photo files

HDMI4 INPUT

(Model dependant)

Tuning the television for the first time

Before switching on the television put your decoder and media recorder to Standby if they are connected and ensure the aerial is connected. To set up the television use the buttons on the remote control as detailed on page 6.

Press zor xto view the DTV (digital channels) or ATV (analogue channels) lists.

Use eorfto move through the list to select a channel then press EXIT to view.

In ATV mode some areas may receive duplicate stations. There may not be a clear picture or the signal may be weak, so the station order can be changed using ATV Manual Tuning.

NOTE: The time will be set automatically by transmission but can be advanced or decreased using Local Time Setting in the DTV Settings screen.

When the search is complete the television will automatically select position one.

The Auto Tuning screen will display the total number of services found.

PLEASE NOTE

The Reset TV menu can also be accessed at any time from the SETUP menu.

Auto Tuning

DTV Services Found: 90 ATV Services Found: 4

DTV ATV

Type Pos. Name CH

1 BBC ONE 34

2 BBC TWO 34 3 ITV1 31 4 Channel 4 31 5FIVE 48 6 ITV2 31 7 BBC THREE 34

Auto Tuning

DTV Services Found: 90 ATV Services Found: 4

DTV ATV

Pos. Name CH

0 VCR C60

1 BBC ONE C22 2 BBC TWO C28 3 ITV C25 4 CH4 C32

Press the ibutton, the Quick Setup screen will appear. This screen will appear the first time that the television is switched on and each time Reset TV is selected.

Using

highlight Menu Language, then

or xto select.

Press eto highlight Country and zor xto select. The television will now tune the stations for your country. Press OK.

The Location screen will appear, press zor xto select between Home or Store (for normal home use select Home) then press OK.

If Home is selected the AutoView option will be activated, automatically adjusting the picture setting to the current viewing conditions. In most cases the television will then operate with lower energy consumption.

If the Ant/Cable In screen appears, press

or xto select between Antenna or Cable

then press OK.

The Auto Tuning start up screen will appear with the option to select between DTV and ATV, DTV or ATV. Using zor xselect DTV and ATV then press eto highlight Start Scan.

Press OK again to start Auto Tuning. The television will start to search for all available DTV and ATV stations. The progress bar will indicate progress.

You must allow the television to complete the search.

Quick Setup

Menu Language English

Country UK Primary Subtitle Language English Secondary Subtitle Language English Primary Audio Language English Secondary Audio Language English

Auto Tuning

Progress Found

DTV Tune 75% 80 ATV Tune Waiting...

Channel: C58

Setting Antenna or Cable

Ant/Cable In (if available)

Press MENU and use zor xto select SETUP. Use eto highlight Ant/Cable In.

Press

or xto select Antenna or Cable.

A screen will appear warning that the televisions features will be changed.

The Auto Tuning screen will appear. When Cable has been selected the Auto Tuning screen will show setting options.

When the options have been set use eorfto highlight Tuning Mode, then press zor xto select between DTV and ATV, DTV or ATV.

Press eto highlight Start Scan, then press OK.

If this feature is available the television can be configured to either Antenna or Cable. If the setting is changed the

Auto Tuning screen will automatically appear (if a Pin Code has been set this will have to be entered in order

to change the setting). All current programmes and

settings will be lost.

With the exception of Scan Type and Modulation, all of the settings have two options:

Auto – values are pre-set by the television’s operating system.

Input – allows a single value to be entered in place of the pre-set value. If no channel is currently tuned and Input is chosen a system default value will be displayed. If a channel is currently tuned and Input is chosen the value of the channel will be displayed.

Scan Type

There are two options, Full Scan and Quick Scan. Quick Scan is a simplified version of Full Scan and takes less time to complete.

Start Frequency

This sets the frequency from which the scan will start.

End Frequency

This sets the frequency at which the scan will stop. The valid entry range for frequency items is 113.000-

858.000 for C-Book/Other and 114.000-858.000 for Nordig-C. If numbers outside of this range are entered the values will automatically set to the minimum or maximum valid values.

Modulation

There are five QAM modulation settings to choose from.

Symbol Rate

This is the Baud rate (KS/s) of the scan. The valid entry range for Symbol Rate is 4000-7200. If a

number outside of this range is entered the value will automatically set to the minimum or maximum valid value.

Network ID

This is the Network ID to be used for the scan. This item is greyed out when the Scan Type is set to Full Scan.

The valid entry range for Network ID is 1-65535. If a number outside of this range is entered the value will automatically set to the minimum or maximum valid value.

SETUP

Menu Language English Country UK

Ant/Cable In Antenna

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning DTV Settings AV Connection

Auto Tuning

Tuning Mode DTV and ATV

Start Scan DTV Scan Type Full Scan

Start Frequency Auto End Frequency Auto Modulation Auto Symbol Rate Auto

Network ID Auto

Auto Tuning

Previous settings will be lost! Press EXIT for no change.

Tuning Mode DTV and ATV

Start Scan

SETUP

Menu Language English Country UK

Ant/Cable In Antenna

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning DTV Settings AV Connection

Select DTV Manual Tuning from the SETUP menu and press OK.

Enter the multiplex number using the number buttons or use zor xto adjust the number and then press eto select Start Scan, press OK. The television will automatically search for that multiplex.

When the multiplex is found any channels not currently on the channel list will be added and the channel information at the top of the screen will be updated.

Repeat as necessary. Press EXIT to finish.

This feature is available for service engineers or can be

used for direct channel entry if the multiplex channel

is known.

NOTE: As new services are broadcast it will be necessary to re-tune the television in order to view them.

DTV auto tuning, manual tuning,

manual tuning for DVB-C

Use zor xto select DTV then press eto select Start Scan, press OK to start Auto tuning.

The television will start to search for all available DTV stations.

You must allow the television to complete the search.

When the search is complete the Auto Tuning screen will display the services found.

Use eorfto move through the list to select a channel then press OK to view.

Auto Tuning

Press MENU and use zor xto select SETUP. If available use eto highlight Ant/Cable In and then zor xto select Antenna or Cable.

Use eto highlight Auto Tuning. Press OK.

A screen will appear warning that previous digital channels and settings will be deleted.

Auto tuning will completely re-tune the television and can

be used to up date the channel list.

It is recommended that DTV Auto tuning is run

periodically to ensure that new services are added.

All current programmes and settings, i.e. locked

programmes, will be lost.

Manual Tuning

Manual Tuning for DVB-C

When Ant/Cable In is set to Cable, DTV Manual

Tuning will display the following information:

Frequency – a specific frequency can be input for

scanning.

Modulation – select from five QAM modulation options.

Symbol Rate – A specific baud rate (KS/s) can be input

for manual scanning.

DTV location, auto channel update,

DVB character set, Analogue switch off

This is a digital television which is integrated to allow the use of both digital and analogue services. However, during the lifetime of this set it is very likely that analogue services will be switched off to allow for more new digital services.

This ‘switch-off’ will happen in a number of phases, which will be advertised in your area well in advance. It is recommended that at each phase the television is re-tuned to ensure that existing and new digital services can be viewed without disruption.

Analogue Switch-off

SETUP

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning DTV Settings AV Connection

Picture Position

Quick Setup

Location Home

Location

Press MENU and use zor xto select SETUP.

Use eto highlight Location.

Use

or xto select Home or Store.

When Home is selected the AutoView option will be activated, automatically adjusting the picture setting to the current viewing conditions. In most cases the television will then operate with lower energy consumption.

There are two options available Home and Store. Store

is for use when a television is being used for display, i.e. in

shops etc. Home is recommended for normal home use.

Auto Channel Update

1 2

Press MENU and use zor xto select SETUP.

Use eto highlight DTV Settings and press OK.

Press eto select Auto Channel Update and use zor xto select On.

If Auto Channel Update is set to On when the television

is in standby mode Digital Tuning will automatically

execute and new channels will be stored.

DVB Character Set

In the SETUP menu press eto highlight DTV Settings and press OK.

Press eto select DVB Character Set and use

or xto select between Standard or West.

The character set to be used for DVB-C or DVT-B

channels can be set manually

(Standard – Table 0 or Western – Table 5).

DTV Settings Channels Channel Options Subtitle and Audio PIN Setting

Parental Control

Local Time Setting 11:51 Auto Channel Update On

DVB Character Set Standard

DTV Settings Channels Channel Options Subtitle and Audio PIN Setting

Parental Control

Local Time Setting 11:51

Auto Channel Update On

DVB Character Set Standard

+ 41 hidden pages
