Toshiba (Australia) Pty. Limited ABN 19 001 320 421. Specifications subject to change without notice.
Trademarks as indicated are the property of the respective owners.
Toshiba Australia Information Systems Division 10/06.
SPECIFICATIONS
x2000
With detachable control panel
High security (password function and panellock)
Easy set-up and "easy to use"
■
■
■
Exceptional talents with a
great appreciation of colours.
MODEL x2000
Display 0.61” LCD Chip
Resolution XGA 1,024 x 768
Brightness 2,00 0 ANSI-lumens
Colour reproduc tion 16.7 mio. colours
Contr ast 400 : 1
Projec tion format 4 : 3 switc hable to 16 : 9
Lamp 210 W (TLPLW11LAMP)
Max. la mp life up to max . 2,000 hours/ up to max.
3,000 hours in ECO mode
Lens F = 1.6 -1.89 / f = 18.6 - 22.3 mm,
manual zoom and focus
Zoom 1,2 x
Frequency (hor./vert.) 15 - 120 kHz / 30 - 150 Hz
Projec tion front, rear and ceiling
Digital keystone correction auto ver tical
Input signals NTSC / PAL / SECAM, 480i, 480p, 576i,
576p, 720p, 1.0 80i, VGA / SVGA, XGA /
SXGA / UXGA (compr.)
Input s RGB (D- sub 15), S-video, composite
video (1 x RC A), RGB audio (stereo mini
jack), video / S-video audio
(1 x RCA L/R)
Outputs RGB (D- sub 15), audio (s tereo mini jack)
Serial interface RS-232C (mini DIN8 pin)
Power supply AC 100 - 240 V, 50 / 60 Hz
Louds peaker 1 W mono
Dimensions (W x H x D) 295 x 81 x 255 mm
Weight 2.5 kg
Operation noise standard 36dB / ECO mode 33dB
Specials security-function, user logo, pas sword,
panellock with detachable control
panel
Acces sories remote control with batteries, owner s
manual (CD ROM), quick reference,
RGB- and power cable, softcase
Options ceiling mounting, trolley, spare lamp,
camera c001, screen, hard case,
AV cables
picture size
(diagonal in m)
projection distance a (m)
min length
(zooming max)
max length
(zooming min)
0.76 1.16
1.50 1.96 2.36
2.50 3 .30 3.97
5.00 6.65 8.00
7.60 7.62 10.00
Toshiba Australia, ISD, ph: 13 30 70
www.isd.toshiba.com.au/projectors <http://www.isd.toshiba.com.au/projectors>
WARRANTY:
3 YEARS WARRANTY,
90 day replacement warranty and 90 day lamp warranty
