OWNER’S MANUAL
3LCD DATA PROJECTOR
TLP-S10 (SVGA)
Before Using
Preparations
Operations
Maintenance
Others
Before Using
SAFETY PRECAUTIONS
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES
ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET.
REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
WARNING: Handling the cord on this product or cords associated with accessories sold with
USA only
FCC Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for a Class
USA only
WARNING: Changes or modifications made to this equipment, not expressly approved by
USA only
Notice: This Class A digital apparatus complies with Canadian ICES-003. Cet appareil
CANADA only
WARNING: This is a Class A product. In a domestic environment this product may cause
this product, will expose you to lead, a chemical known to the State of California
to cause birth defects or other reproductive harm.
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiates radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Toshiba, or parties authorized by Toshiba, could void the user’s authority to operate
the equipment.
numérique de la classe A est conforme à la norme NMB-003 du Canada.
radio interference in which case the user may be required to take adequate
measures.
Wash hands after handling
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND
INSTRUCTIONS GIVEN IN THIS OWNER'S MANUAL AND THOSE
MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE
REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can
result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you
if you observe the following procedures for installation, use and servicing. This unit is fully
transistorized and does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO
DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL ONLY.
1. Read Owner's Manual
After unpacking this product, read
the owner's manual carefully, and
follow all the operating and other
instructions.
.
2. Power Sources
This product should be operated
only from the type of power source
indicated on the marking label.
If you are not sure of the type of
power supply to your home,
consult your product dealer or
local power company.
For products intended to operate
from battery power, or other
sources, refer to the operating
instructions.
3. Source of Light
Do not look into the lens while the
lamp is on. The strong light from
the lamp may cause damage to
your eyes or sight.
4. Ventilation
Openings in the cabinet are
provided for ventilation and to
ensure reliable operation of the
product and to protect it from
overheating, and these openings
must not be blocked or covered.
The openings should never be
blocked by placing the product on
a bed, sofa, rug or other similar
surface. This product should not
be placed in a built-in installation
such as a bookcase or rack unless
proper ventilation is provided or
the manufacturer's instructions
have been adhered to.
Before Using
CAUTION: Laser beam is emitted when the laser button of the remote control is pressed.
Do not look at the laser beam directly from the front of the remote control. Do not
turn the laser beam toward a person or to a mirror.
2 3
IMPORTANT SAFETY INSTRUCTIONS (Continued)
5. Heat
The product should be situated
away from heat sources such as
radiators, heat registers, stoves, or
other products (including
amplifiers) that produce heat.
6. Water and Moisture
Do not use this product near water.
- for example, near a bath tub,
wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a
swimming pool and the like.
7. Cleaning
Unplug this product from the wall
outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners.
Use a soft cloth for cleaning.
8. Power-Cord Protection
Power-supply cords should be
routed so that they are not likely to
be walked on or pinched by items
placed upon or against them,
paying particular attention to cords
at plugs, convenience receptacles,
and the point where they exit from
the product.
9. Overloading
Do not overload wall outlets;
extension cords, or integral
convenience receptacles as this
can result in a risk of fire or
electric shock.
10. Lightning storms
For added protection for this
product during storm, or when it is
left unattended and unused for
long periods of time, unplug it from
the wall outlet. This will prevent
damage to the product due to
lightning and power-line surges.
11. Object and Liquid Entry
Never push objects of any kind
into this product through openings
as they may touch dangerous
voltage points or short-out parts
that could result in a fire or electric
shock. Never spill liquid of any
kind on the product.
12. Do not place the product
vertically
Do not use the product in the
upright position to project the
pictures at the ceiling, or any other
vertical positions. It may fall down
and dangerous.
13. Stack Inhibited
Do not stack other equipment on
this product or do not place this
product on the other equipment.
Top and bottom plates of this
product develops heat and may
give some undesirable damage to
other unit.
14. Attachments
Do not use attachments not
recommended by the product
manufacturer as they may cause
hazards.
15. Accessories
Do not place this product on an
unstable cart, stand, tripod,
bracket, or table. The product may
fall, causing serious injury to a
child or adult, and serious damage
to the product. Use only with a
cart, stand, tripod, bracket, or table
recommended by the
manufacturer, or sold with the
product. Any mounting of the
product should follow the
manufacturer's instructions, and
should use a mounting accessory
recommended by the
manufacturer. A product and cart
combination should be moved with
care. Quick stops, excessive
force, and uneven surfaces may
cause the product and cart
combination to overturn.
S3125A
Before Using
4 5
IMPORTANT SAFETY INSTRUCTIONS (Continued)
16. Damage Requiring Service
Unplug this product from the wall
outlet and refer servicing to
qualified service personnel under
the following conditions:
a) When the power-supply cord or
plug is damaged.
b) If liquid has been spilled, or
objects have fallen into the
product.
c) If the product has been exposed to
rain or water.
d) If the product does not operate
normally by following the operating
instructions. Adjust only those
controls that are covered by the
operating instructions as an
improper adjustment of other
controls may result in damage and
will often require extensive work by
a qualified technician to restore
the product to its normal
operation.
e) If the product has been dropped or
damaged in any way.
f) When the product exhibits a
distinct change in performance this indicates a need for service.
17. If glass components,
including lens and lamp,
should break, contact your
dealer for repair service.
This product incorporates glass
components, including a lens and
a lamp. If such parts should
break, please handle with care to
avoid injury and contact your
dealer for repair service. The
broken pieces of glass may cause
to injury. In the unlikely event of
the lamp rupturing, thoroughly
clean the area around the
projector and discard any edible
items placed in that area.
18. Servicing
Do not attempt to service this
product yourself as opening or
removing covers may expose you
to dangerous voltage or other
hazards. Refer all servicing to
qualified service personnel.
19. Replacement Parts
When replacement parts are
required, be sure the service
technician has used replacement
parts specified by the
manufacturer or have the same
characteristics as the original part.
Unauthorized substitutions may
result in fire, electric shock, or
other hazards.
(Replacement of the lamp only
should be made by users.)
20. Safety Check
Upon completion of any service or
repairs to this product, ask the
service technician to perform
safety checks to determine that
the product is in proper operating
condition.
21. Do not leave thermalpaper documents or easily
deformed items on top of
the unit or near the air
exhaust for long periods
of time.
The heat from the unit could erase
the information on the thermal
paper, or cause deformation or
warping.
Before Using
6 7
LABEL LOCATIONS
POWER SUPPLY CORD SELECTION
If your line voltage is 220 to 240V, use one of the following types of cable.
WARNING Label
CAUTION Label
MODEL NO. /
RATING Label
SERIAL NO. Label
MANUFACTURED;
SERIAL NO.
CAUTION Label
WARNING Label
Plug
configuration
Use a 5A fuse which is approved by ASTA
or BSI to BSI362.
Always replace the fuse cover after
changing the fuse.
Plug type
EURO
UK
Line voltage
220 – 240V
220 – 240V
Plug
configuration
Plug type Line voltage
Australian
240V
10A
Switzerland
240V
6A
North American
240V
15A
200 – 240V
200 – 240V
200 – 240V
IMPORTANT PRECAUTIONS
Save Original Packing Materials
The original shipping carton and packing materials will come in handy if you ever have to
ship your LCD projector. For maximum protection, repack the set as it was originally
packed at the factory.
Moisture Condensation
Never operate this unit immediately after moving it from a cold location to a warm location.
When the unit is exposed to such a change in temperature, moisture may condense on
the crucial internal parts. To prevent the unit from possible damage, do not use the unit for
at least 2 hours when there is an extreme or sudden change in temperature
.
Before Using
Place and Manner of Installation
• Do not place in hot locations, such as near heating equipment. Doing so could cause
malfunction, and shorten the life of the LCD panel.
• Avoid locations with oil or cigarette smoke. Doing so will dirty the LCD panel and other
optical parts, shortening their lives, and darkening the screen.
• Do not place slantwise in angle of 20° or more. Doing so could shorten the life of the
lamp.
• Using this instrument near a TV or radio may cause intereference to the images or audio
sound. If this happens, move it away from the TV or radio.
• Moving the projector from a low-temperature room to a high-temperature room may
cause condensation on the lens or internal parts in the instrument. If you continue to use
it in that situation, the malfunction may result. Ensure to wait until the condensation
naturally disappears.
• In a high altitude location where air is thin, cooling efficiency of the scanner is reduced so
use it with the ambient temperature being lowered.
8 9
IMPORTANT PRECAUTIONS (Continued)
EXEMPTION CLAUSES
Avoid Volatile Liquid
Do not use volatile liquids, such as an insect spray, near the unit. Do not leave rubber or
plastic products touching the unit for a long time. They will leave marks on the finish.
If cleaning with a chemically saturated cloth, be sure to follow the product's precautions.
LCD Panel
The life of the LCD panel is limited. Take care over the points below so as to use the
panel for years.
• To prolong the life of this panel, never fail to turn the power off when the panel is not in
use and make sure that the lamp has gone out. The state of the lamp being extinguished
helps enhance the effect of energy saving.
• If the air filter is stained and is clogged up, the main unit inner temperature rises. As a
result, the life of the LCD is shortened and a malfunction may also occur.
Clean the air filter from time to time and replace it regularly. It is recommended that this
replacement be done at the time of replacing a lamp. (Ask a dealer where the unit was
purchased or your nearby service station about an air filter for replacement.)
In the spaces provided below, record the Model and Serial No. located at the bottom of
your LCD projector.
Model No. Serial No.
Retain this information for future reference.
• Toshiba Corporation bears no responsibility in the case of damages arising from natural
disaster such as earthquakes, lightning, etc., fire not liable to Toshiba Corporation,
operating by third parties, other accidents, or use under abnormal conditions including
erroneous or improper operation and other problems.
• Toshiba Corporation bears no responsibility for incidental damages (lost profit, work
interruption, corruption or loss of the memory contents, etc.) arising from the use of or the
inability to use this unit.
• Toshiba Corporation accepts no liability whatsoever for any damages arising from not
having followed the descriptions in this Instruction Manual.
• Toshiba Corporation accepts no liability whatsoever for any damages arising from
malfunctions arising from combination with equipment or software that is not related to
Toshiba Corporation.
OTHER CAUTIONS AND INFORMATIONS
Copyrights
Showing or transmitting commercial imaging software or broadcast or cable-broad
casting programs with the purpose of other than the personal and private viewing,
including modifying images using the freeze or resize functions, or displaying with the
varying aspect ratio of the images, could violate the direct or indirect copyrights of the
imaging software or broadcast program, etc., if done without first consulting with the
copyright holder. For this reason, please take appropriate measures before performing
one of the actions listed above, including obtaining a license from the copyright holder.
Disposal
This product contains substances which are harmful to humans and the environment.
• Solder used in the internal parts contains the lead.
• The lamp contains inorganic mercury.
Please dispose of this product or used lamps in accordance with local regulations.
Before Using
Trademarks
• VGA, SVGA, XGA, SXGA, UXGA are trademarks or registered trademarks of
International Business Machines Corporation.
• Macintosh is a registered trademark of Apple Computer, Inc.
• Windows is a registered trademark of Microsoft Corporation in the U.S. and other
countries.
• Adobe is a registered trademark and Acrobat Reader is a trademark of Adobe Systems
Incorporated.
Notational Conventions Used in This Manual
References to pages with related information are annotated as follows.
For example, if making a reference to page 24:
10 11
p.24
CONTENTS
Before Using
SAFETY PRECAUTIONS ................................................................................ 2
IMPORTANT SAFETY INSTRUCTIONS ......................................................... 3
LABEL LOCATIONS ........................................................................................ 8
POWER SUPPLY CORD SELECTION ............................................................ 9
IMPORTANT PRECAUTIONS ......................................................................... 9
EXEMPTION CLAUSES ................................................................................ 11
OTHER CAUTIONS AND INFORMATIONS .................................................. 11
CONTENTS ................................................................................................... 12
Preparations
Checking the package contents ..................................................................... 14
Names of each part on the main unit ............................................................. 15
Names of each part on the control panel and remote control ........................ 16
Preparing and using the remote control ......................................................... 17
Placement ...................................................................................................... 18
Connection ..................................................................................................... 19
Operations
Turning the power on and off ......................................................................... 20
Basic operations ............................................................................................ 22
Using handy features ..................................................................................... 24
Using auto setting (Auto setting) ................................................................ 24
Correcting the keystone distortion (Keystone)............................................ 25
Zooming out the images ............................................................................. 25
Cutting off the picture and sound temporarily (Mute) ................................. 26
Freezing the image (Freeze) ...................................................................... 26
Enlarging the picture size (Resize) ............................................................. 27
Displaying Information [Status display]....................................................... 28
Using the menus ............................................................................................ 29
How to use the menus ................................................................................ 29
The image adjustment menu ...................................................................... 30
The default setting menu ............................................................................ 30
The display setting menu............................................................................ 31
Reset menu (Special menu) ....................................................................... 31
Others
Trouble indications ......................................................................................... 35
Before calling service personnel .................................................................... 36
Specifications ................................................................................................. 37
List of general specifications ...................................................................... 37
List of supported signals (RGB signals) ..................................................... 38
List of supported signals (Y/P
List of supported signals (Video, S-Video signals) ..................................... 39
Pin assignment of COMPUTER & MONITOR terminals ............................ 39
CONTROL terminal .................................................................................... 40
Separately Sold Product ............................................................................. 40
B/PR signals) ................................................ 39
Before Using
Maintenance
Air filter cleaning ............................................................................................ 32
Lens and main unit cleaning .......................................................................... 33
Lamp replacement ......................................................................................... 33
12 13
Preparations
Checking the package contents
Please make sure that the following items are included in the box, along with the main unit. If
any item is missing, please contact the store immediately where you purchased the product.
(1) (4) (7)
(2) (5) (8)
(3) (6) (9)
(10)
■■ (1) Remote control
■■ (2) R03 (SIZE AAA) batteries for remote
control (2)
■■ (3) Quick Reference
■■ (4) CD-ROM
■■ (6) Power cord
■■ (7) RGB cable
■■ (8) Video cable
■■ (9) Audio cable (for computer)
10
) Audio cable (for a VCR)
■■ (
■■ (5) Owner’s Manual
Note
The shape and number of supplied power cords vary depending on the product destination.
◆The Supplied CD-ROM
The supplied CD-ROM contains an owner’s manual, including information omitted in this
Owner’s manual (Getting started) and Acrobat
■ Installing Acrobat® Reader™
Windows®: Run the CD-ROM, select the Reader/English folder, and run ar500enu.exe.
Follow the on-screen instructions.
Macintosh: Run the CD-ROM, select the Reader/English folder, and run Reader
Installer. Follow the on-screen instructions to install the software.
■ Viewing the manual
Run the CD-ROM and double-click on Start.pdf. Acrobat® Reader™ launches, and the
menu screen of the Owner’s manual appears. Click on your language. The Owner’s
Manual cover and list of bookmarks appear. Click on a bookmark title to view that
section of the manual. Click on
See the Help menu for more information about Acrobat
p.
®
Reader™ to view the manual.
to view a reference page with related information.
®
(See note)
Reader™.
Names of each part on the main unit
(4) (2)(3) (1)
(4)
(9)
(8)
(5) (7)(6)
(14)
AUDIO
(1)
(16)(15) (17)
COMPUTER-
(
MONITOR
Y/P
VIDEO
)
S-VIDEOVIDEO
B/PR
Name : Function
(1) Infrared remote sensor : Senses commands from the remote control.
(2) Lens : Projects expanded image.
(3) Focusing ring : Adjusts screen focus.
p.23
(4) Air intake : Draws in air from outside unit.
(5) Tilt adjuster : Adjusts the projector’s horizontal tilt.
(6) Lamp cover : Remove to replace lamp.
p.34
(7) AC IN socket : Connect the supplied power cord here.
(8) Foot adjuster : Adjusts the vertical projection angle.
(9) Foot adjuster release button : Press to stow the foot adjuster.
(10) Control panel : Operates the projector.
p.16
p.23
(11) Air exhaust : Expels air that has grown hot inside the projector.
12
) Speaker : Plays audio.
(
(
13
) Anti-theft lock hole : Attach a security chain, etc. here.
14
) AUDIO terminal : Feeds the audio signal from a computer or video
(
equipment.
15
) MONITOR terminal : Connected to the monitor display.
(
16
) COMPUTER terminal : Feeds the RBG signal from a computer or the compo-
(
nent video signal (Y/P
17
) VIDEO terminal : Feeds the video signal from a video equipment.
(
18
) S-VIDEO terminal : Feeds the S-video signal from a video equipment.
(
(
19
) CONTROL terminal : Connected to the RS-232C por t on a controlling
B/PR) from a video equipment.
computer for operating the projector.
(10)
(12) (11)(13)(11)
(18)(19)
CONTROL
p.17
p.23
p.20
p.23
p.40
(5)
Preparations
1514
Names of each part on the control panel and remote control
Preparing and using the remote control
Control panel
Remote Control
CLASS 1 LED PRODUCT
Remote control transmitter
ON/
KEYSTONE
-
AUTOSET
RESIZE
ZOOM
+
MENU VOL.
ZOOM
-
STANDBY
INPUT
FREEZE
+
(1)
(4)
(12)
(2)
(5)
(6)
(7 ) (8 ) (9 ) (10)
FAN
TEMP
LAMP
ON
ON / STANDBYINPUT
VOL.
(1)(2)
(6)
+
(5)
ZOOM
+
MENU
VOL.
-
ZOOM.
AUTO SET
-
KEYSTONE
(3) (4)
(15)
(3)
(11)
(13)
(14)
CALL
MUTE
CANCEL
VOL.
Name : Main Function
(1) ON/STANDBY button : Turns the power on/off (standby).
(2) INPUT button : Selects input.
p.22
p.20
(3) KEYSTONE button : Adjusts keystone (trapezoidal distortion).
(4) AUTO SET button : Sets up image and mode.
(5) MENU button : Displays menus and makes selections.
(6) Selection buttons : Menu selections and adjustments, etc.
(7) FAN indicator : Displays cooling fan mode.
p.24
p.23
p.29
p.29
p.35
(8) TEMP indicator : Lights when internal temperature too high.
(9) LAMP indicator : Displays lamp mode.
(10) ON indicator : Displays whether power is on or off.
p.21
p.20
(11) MUTE button : Cuts off the picture and sound temporarily.
(12) FREEZE button : Pauses image.
(13) RESIZE buttons : Enlarges picture size.
(14) CANCEL button : Exiting the operation.
(15) CALL button : Displays the information on the screen.
p.26
p.27
p.28
p.28
Note
• For the remainder of this manual, buttons are referred to as follows:
Selection buttons ⇒
; MENU button ⇒
p.25
p.35
p.26
■ Loading dry-cell batteries
into the remote control
q Remove the battery cover.
■ Operating the remote
control
Point the remote control toward the
projector’s infrared remote sensor,
and press a button on the remote
control.
• Operating the projector from the front
w Insert the dry-cell batteries.
Be sure to align the plus and minus
ends of the batteries properly.
• Operating the projector from the rear
Two batteries (R03, SIZE AAA) are
used.
Approx. 15°
Approx. 5m
e Replace the battery cover.
Approx. 15°
Approx. 5m
Dry-cell batteries
• Before using the batteries, be sure to observe the Safety Precautions described in
previous pages.
• Remove batteries from remote control when not using for extended periods.
• If the remote control stops working, or if its range decreases, replace all the batteries with
new ones.
The remote control
• The remote control may fail to operate if the infrared remote sensor is exposed to bright
sunlight or fluorescent lighting.
• Do not drop or bang.
• Do not leave in hot or humid locations.
• Do not get wet or place on top of wet objects.
• Do not take apart.
• In rare cases, ambient conditions could impede the operation of the remote control. If this
happens, point the remote control at the main unit again, and repeat the operation.
Preparations
1716
Placement
Connection
Placement Styles
As shown in the figures below, this device can be placed in 4 different styles.
The factory setting is “floor-mounted front projection.” Set the placement style in the
default setting menu
Floor-mounted front
projection
AC IN
p.30
, in accordance with your needs.
Floor-mounted rear
projection
Ceiling-mounted front
projection
Ceiling-mounted rear
projection
CAUTION
• Always obey the instructions listed in IMPORTANT SAFETY INSTRUCTIONS when placing
the unit.
• If you wish to mount the projector on the ceiling, be sure to ask your dealer to do so.
Mounting the projector on a ceiling requires special ceiling brackets (sold separately) and
specialized knowledge. Improper mounting could cause the projector to fall, resulting in an accident.
• If the projector is ceiling-mounted, install the breaker for turning off the power in case of
anomaly. Let everyone involved with the use of the projector know that.fact.
Projection Distance and Screen Size
Use the figures, tables, and formulas below to determine the screen size and projection
distance. (Screen sizes are approximate values for full-size picture with no keystone adjustment)
As seen from above
Screen
90°
As seen from the side
Lens center
90°
a
a is the distance (m) between the lens and
the screen, and corresponds to a range of
1.52 m to 11.59 m.
projection size (inches) – 0.8668
a =
screen size
(cm)
25.81
projection distance a (m)
40 (102) 1.52
60 (152) 2.29
80 (203) 3.07
100 (254) 3.84
150 (381) 5.78
200 (508) 7.72
250 (635) 9.65
300 (762) 11.59
Before connection
• Read the owner’s manual of the device to connect to the projector.
• Some types of computer cannot be used or connected to this projector.
Check for an RGB output terminal, supported signal
• Turn off the power of both devices before connecting.
• The figure below is a sample connection. This does not mean that all of these devices
can or must be connected simultaneously. (Dotted lines mean items can be exchanged.)
AC IN
CRT monitor, etc.
To audio output
Audio cable
(for computer)
(supplied)
)
To audio
output
White (L)
Red (R)
VIDEO
S-VIDEOVIDEO
CONTROL
VCR
To audio
output
White (L)
Red (R)
MONITOR
AUDIO
Monitor cable
Mini D-sub 15P-BNC
(not supplied)
To Y/CB/CR output
Green (Y)
Blue (C
Red (C
DVD player
COMPUTER-
(
Y/P
B/PR
Audio cable
(supplied)
B),
R)
Yellow
(to video output)
Conversion
adapter
BNC-pin
(not supplied)
Note
• The AUDIO terminal can be used with all the devices for input terminal.
p.38
S-Video cable
(not supplied)
Video cable
(supplied)
To S-Video
output
, etc.
Computer
To RGB
output
RGB cable
(supplied)
Control cable
p.40
To RS-232C terminal
Computer (for control)
Preparations
1918
Operations
Turning the power on and off
Connecting the power cord
Insert the power cord connector into the AC IN socket of the projector.
1
Insert the power cord plug into a wall or other power outlet.
2
When the power cord is plugged in, the following
three green indicators will come on for several
seconds: ON, TEMP, and LAMP. Next, the ON
indicator will change to orange, indicating standby
mode.
(Do not perform any operations while the 3 green
(Supplied) Power cord connector
indicators are on.)
Removing the lens cover
Be sure to remove the lens cover when the power is
turned on. If it is left on, it could become deformed due
to heat.
■ Turning the power on
Press the ON/STANDBY
button.
The power turns on, and the following
3 green indicators light: ON, LAMP,
and FAN. After a moment, the startup screen appears.
Control panel
FAN
TEMP
LAMP
ON
ON / STANDBYINPUT
ZOOM
+
VOL.
MENU
-
AUTO SETKEYSTONE
ZOOM
-
Remote
Control
ON/
STANDBY
CALL
KEYSTONE
AUTOSET
MUTE
VOL.
+
RESIZE
CANCEL
INPUT
Start-up screen
FREEZE
WARNING
• Do not look into the lens during operation. Doing so could damage your vision.
CAUTION
•
Do not block the air intake or exhaust. Doing so could cause a fire due to internal overheating.
• Do not place your hands, face, or other objects near the air exhaust. Doing so could
cause burns, deform/break the object.
Notes
• The start-up screen will disappear after a moment. You can dismiss the star t-up screen before this
by performing any operation. You can also configure the start-up screen not to appear via the
Display setting menu
• The first time you use the projector after purchase, after the start-up screen disappears, the
Language menu is displayed
p.31
.
p.22
.
Turning the power off
Press the ON/STANDBY button.
1
A message appears on the screen, confirming that you wish to shut off the power. This
message will disappear after a moment. (This operation is no longer valid after the
message disappears.)
Press the ON/STANDBY button again.
2
The screen turns off, but the internal cooling fan continues to operate for a short while.
Then, the projector goes into standby mode.
When cooling lamp During internal cooling After cooling is completed
FAN TEMP LAMP ON
(Green) (Green) (Orange)
A
During cooling, the LAMP indicator flashes. In this state, the power cannot be
A
turned back on. In addition, unplugging the power cord in this state will shorten
Flashing
(Green) (Off) (Orange)
B C
the life of the lamp.
After the LAMP indicator goes off, the cooling fan continues to operate for a
B
short while in order to expel excess internal heat. If you are in a hurry, there is
no problem with unplugging the power cord in this state.
In standby mode.
C
Note
• The projector consumes about 6W of power in standby. We recommend you to unplug the
power cord if you will not use the projector for an extended period.
PRECAUTIONS
• Before unplugging the power cord, make sure that the LAMP indicator is off. Unplugging
the power cord and cutting off the power while the projector is running or being cooled
will shorten the life of the lamp. However, please unplug the power cord if the
projector locks up or acts abnormally.
• If the power cord was unplugged before cooling was complete, give the lamp sufficient
time to cool before plugging it back in. If the lamp overheats, it may fail to light, and its
lifetime will be shortened.
LCD Panels
LCD panels wear out. In order to prolong the lifetime of your LCD panel, take the
following precautions.
• In order to extend the lifetime of the LCD panel, always turn off the power when not in
use, and make sure that the lamp is off. Keeping the lamp off is also very effective at
saving electricity.
• If the air filter becomes dirty and clogged, the projector’s internal temperature will rise,
shortening the lifetime of the LCD panel and causing malfunctions. Clean the air filter
from time to time
purchased your projector, or your local Service Station for replacement air filters.
p.32
, and replace it periodically. Contact the store where you
FAN TEMP LAMP ONFAN TEMP LAMP ON
(Off) (Off) (Orange)
Operations
20
21
Basic operations
Turn on the power.
1
Turn on the power by following the instructions in “Turning on the power”
2
Select the language and the lamp power (When using the
first time).
When the projector is used for the first time after purchase, menu for language and
lamp power selection and configuration is displayed in English. (If the screen is out of
focus, adjust it according to the step
q Use the or buttons to select the
desired language and press the
Message for setup confirmation is displayed in a
selected language.
w Using the or button, select Standard
or Low and press the
The lamp power, if selected, will be toggled without
pressing the
disappears in a few seconds.
button. The display automatically
Notes
• When the projector is turned on the next time, the Language and Lamp power
menus do not appear upon startup. However, if “Reset all” is executed from the
p.31
Reset menu
time when the power is turned on
• The language can also be set via the Display setting menu
via the Default setting menu
• This owner’s manual assumes that English has been selected.
Place connected device(s) in operating status.
3
Turn on and boot up connected computers and other devices.
4
Select input.
, the Language and Lamp power menus will be displayed the next
q Press the INPUT button.
A list of inputs appears on the screen.
w Use the buttons to select the desired
input, and press the
The picture for the selected input is projected.
button.
.)
6
button.
p.30
.
button.
................
English
Fran çais
Deutsch
................
Italiano
Español
Português
...................
...................
p.30
Computer
Y/P
B/PR
Video
S-video
English
..............
French
..............
German
...............
Italian
Spanish
..........
Portuguese
Japanese
.......
Chinese (simplified)
.......
Chinese (traditional)
Korean
and Lamp power
p.20
5
Projector placement angle adjustments
.
The placement angle and the height of the projected image can be adjusted by the foot
adjuster.
q Lift up the front of the projector to
1
the desired angle, then press the
foot adjuster release button.
The foot adjuster extends. Release the
button to lock the position.
w Turn the foot adjuster to fine-tune
the angle.
3
2
e To adjust the horizontal angle, use
the tilt adjuster.
To stow the foot adjuster, hold up the projector while pressing the foot adjuster
release button, then slowly lower the projector.
Adjust the picture size and focus.
6
q Move the projector back and forth to adjust
the screen size.
w Use the focusing ring to adjust the focus.
Adjusting the volume with the buttons
7
The speaker volume can be adjusted when an audio signal is being input.
Notes
•
Note that because of the lamp characteristics, the brightness of the lamp may fluctuate slightly
• A lamp is a consumable supply.
If used for extended periods, images will appear dark, and the lamp could burn out. This
is characteristic of a lamp, and is not malfunction. (The lifetime of the lamp depends on
conditions of use.)
• The LCD panel is made using extremely advanced technology, but there may be black
spots (pixels that do not light) or bright spots (pixels that are constantly lit) on the panel.
Please note that these are not malfunctions.
•
Although this projector supports a wide range of RGB signals
supported by the model (XGA or SVGA, depending on the model) will expand or shrink the
pictures, and will affect image quality slightly. To view high-quality images, it is
recommended that the computer’s external output should be set to the projector’s resolution.
• With some models of computer having LCD displays or the like, displaying images
simultaneously on the projector and the monitor’s display may cause the images to be
shown improperly. If this happens, turn off the computer’s LCD display. For information on
how to turn off the LCD display, see the owner’s manual of your computer.
• If a signal not supported by the projector is input, the
• If a no signal is being input from the connected device, the
• If an unavailable operation button is pressed, the
p.38
, any resolutions not
icon will appear.
icon will appear.
icon will appear.
Operations
.
22
23
Using handy features
■ Using auto setting (Auto setting)
This function sets up the projector to the optimum state for
each type of the input signal by using simple operations.
1
Press the AUTO SET button.
The Auto setting menu appears.
2
Press the AUTO SET button again.
The menu item is automatically adjusted/set.
For computer input, the
icon will appear during
processing.
Note
• Auto adjustment/setting may not be performed correctly for input signals other than
those supported by the projector
p.38, p.39
.
● Manual adjustment and setting
The menu items vary depending on the input type, as shown in the table below.
Use the
the
buttons to adjust the items in the table below, then press
button when you are finished. The menu disappears. (The CANCEL button
on the remote control also allows you to exit the menu mode.)
Input Item
Computer
Phase Adjust with to eliminate flicker.
Frequency
Adjust with to eliminate periodic patterns and
flickering when many vertical lines appear on the screen.
H-position Move left Move right
V-position Move up Move down
Select ItemSelect Item
Clamp 1 Adjusts the clamp pulse position with or .
Clamp 2 Adjusts the clamp pulse width with or .
Y/PB/PR
Phase Adjust with to eliminate flicker.
Signal format
[ : Enter to setting mode] [ : Select one
of the following] [Apply: ]
480i(525i)@60Hz/480p(525p)@60Hz/
576i(625i)@50Hz/576p(625p)@50Hz/
720p(750p)@60Hz/720p(750p)@50Hz/
1080i(1125i)@60Hz/1080i(1125i)@50Hz/
1035i(1125i)@60Hz/1152i(1250i)@50Hz
Video
S-video
Video mode [ : Enter to setting mode] [ : Select one
of the followings] [Apply: ]
NTSC/PAL/SECAM/PAL-N/PAL-M/PAL60/NTSC4.43
Note
• Moving pictures generated with the DVD software for computers may appear
unnatural if it is projected with this projector, but it is not a malfunction.
Control panel
FAN
TEMP
VOL.
-
Description
LAMP
ON
ON / STANDBYINPUT
ZOOM
+
MENU
VOL.
+
AUTO SETKEYSTONE
ZOOM
-
Remote
Control
CALL
KEYSTONE
AUTOSET
MUTE
RESIZE
CANCEL
■ Correcting the keystone distortion (Keystone)
When the foot adjuster
ON/
STANDBY
FREEZE
INPUT
projection angle, the picture will undergo keystone (trapezoidal) distortion.
This projector is capable of correcting this keystone distortion
1
Press the KEYSTONE button.
The Keystone menu appears.
2
Use the buttons for keystone adjustment.
On completing the adjustment, press the button to dismiss the menu (you can also use the
CANCEL button on the remote control for menu dismissal). The trapezoidal distortion will be
automatically corrected. During the processing, the icon
Item Description
Keystone Shrink button of the screen Shrink top of the screen
Notes
• Depending on the amount of keystone adjustment and the content of images, some
information may be lost, or the picture quality may suffer.
• Keystone adjustment will not change the shape of the menus.
■ Zooming out the images
This equipment is provided with the digital zoom (electric zoom: 100-80%). (Note that
the display, if digitally zoomed out, may suffer from some degradation.)
1
Press the ZOOM – button.
Each time the ZOOM – button is pressed, the
image is reduced in size.
2
Press the ZOOM + button to bring it back
to the original size.
Each time the ZOOM + button is pressed, the
image size increases.
(You cannot make it larger than the original size.)
p.23
is used to change the
Before correction
After correction
Control panel
FAN
.
TEMP
VOL.
-
LAMP
ON
ON / STANDBYINPUT
ZOOM
+
MENU
AUTO SETKEYSTONE
ZOOM
-
Control
CALL
AUTOSET
KEYSTONE
MUTE
VOL.
+
RESIZE
CANCEL
is displayed.
Remote
Control panel
FAN
TEMP
LAMP
ON
ON / STANDBYINPUT
ZOOM
+
VOL.
MENU
-
AUTO SETKEYSTONE
ZOOM
-
Remote
Control
RESIZE
CANCEL
ZOOM
VOL.
+
+
MENU VOL.
VOL.
-
ZOOM
-
Notes
• Pressing either the ZOOMor ZOOM+ button would
display the
• The adjustment value will
automatically be saved.
icon.
ON/
STANDBY
FREEZE
INPUT
Operations
INPUT
+
24
25
Using handy features (Continued)
■ Cutting off the picture and sound temporarily (Mute)
When you want to project the images of another projector, overhead
projector, etc. temporarily, this projector’s images and sound can be
turned off.
Press the remote control’s MUTE button.
The picture and sound are cut off. The Mute function is released
when pressing the MUTE button again. To cancel the command,
press the CANCEL button.
Notes
• The icon will appear while mute is in effect.
• Operating any other functions cancel the muting.
■ Freezing the image (Freeze)
The image being projected can be made to be frozen. This function is to
be used to pause a video during a presentation, etc.
Press the remote control’s FREEZE button.
The picture pauses. The Freeze function is released when pressing
the FREEZE button again. To cancel the command, press the
CANCEL button.
Notes
• The icon will appear while freeze is in effect.
• The freeze function can be used on the resize function. Other operations will
release the freeze.
• Even if an image is frozen on the projector, the pictures are running on the video or
other equipment.
• If you use this function on video soft sold on the market, broadcast or broadcast on
cable except for the purpose of your private viewing and listening, it may infringe
the copyright protected by the copyright laws.
Remote
Control
CALL
KEYSTONE
AUTOSET
MUTE
RESIZE
CANCEL
Remote
Control
CALL
KEYSTONE
AUTOSET
MUTE
RESIZE
CANCEL
■ Enlarging the picture size (Resize)
The image being projected can be enlarged.
1
Press the remote control’s RESIZE button.
The enlargement ratio is increased each time the RESIZE button is pressed.
ON/
STANDBY
FREEZE
INPUT
ON/
STANDBY
FREEZE
INPUT
To decrease the enlargement ratio, press the remote control’s
2
RESIZE
button.
The enlargement ratio is decreased each time the RESIZE button is pressed.
(The image cannot be shrunk to less than its original size.)
Remote
Control
3
Press and hold down the buttons to
move the enlarged area.
4
Press the CANCEL button to undo the resize.
RESIZE
2
CANCEL
4
INPUT
ZOOM
+
MENU VOL.
+
VOL.
-
ZOOM
-
The resize is released, and the image returns to its original size.
Notes
• The icon will appear while resize is in effect.
• An enlarged image can be frozen using the FREEZE button. The resize function on
a frozen image can also be used.
• Operations other than freeze will cancel the resize.
• Since the enlargement is performed using digital processing, enlarging will cause
the image to appear jagged.
• Rarely, the picture could become garbled while the enlarged area is being moved.
• If you use this function on video soft sold on the market, broadcast or broadcast on
cable except for the purpose of your private viewing and listening, it may infringe
the copyright protected by the copyright laws.
1
3
Operations
26
27
Using handy features (Continued)
Using the menus
■ Displaying Information [Status display]
This displays information about the input signal, lamp use time, etc.
Press the button twice (or press the CALL button on the remote
control once).
When the button is pressed once, the Setting
display menu appears. Pressing it again displays
information
of information is displayed. Press the
p.29
. The table below shows what kind
button (or
press the CALL or CANCEL button on the remote
control to serve the same purpose) again to
dismiss the display.
Item Description
Input Input source name Yes Yes Yes Yes
RGB signal mode RGB input mode
[Note 1]
H-resolution Horizontal resolution (in bits) Yes No No No
V-resolution Vertical resolution (in bits) Yes No No No
H-frequency Horizontal sync frequency Yes No No No
V-frequency Vertical sync frequency
Sync Sync signal polarity
[Note 2]
[Note 3]
Signal format Y/PB/PR signal format No Yes No No
Video mode Color method of video signal No No Yes Yes
p.38
[Note 4]
[Note 5]
is shown.
Lamp time Time of lamp use
Version Firmware version
Notes
1: The mode of supported RGB signals
2: Same as the refresh rate of the computer signal.
3: Sync signal polarity shown as P (positive) or N (negative) for [H/V].
4: Displays [Lamp time] as a measure of when the lamp should be replaced. (Cannot be
used as a counter of guaranteed lamp time.) When the displayed time approaches 2,000
hours, consult with a store about getting a TLPLV3 replacement lamp (sold separately)
prepared.
5: [Version] shows the version of the projector’s internal control program. This version is
referred to for customer service, etc.
Notes
• The displayed information will not be refreshed if the status changes. To refresh the
information, dismiss the display, then display it again.
• Conducting another operation while information is being displayed dismisses the
display.
Control panel
FAN
TEMP
LAMP
ON
ON / STANDBYINPUT
ZOOM
+
MENU
VOL.
VOL.
-
+
AUTO SETKEYSTONE
ZOOM
-
“Ye s ”: displayed, “No”: not displayed
Computer Y/PB/PR Video S-video
YesNoNoNo
YesNoNoNo
YesNoNoNo
Ye s Ye s Ye s Ye s
Ye s Ye s Ye s Ye s
Remote
Control
CALL
KEYSTONE
AUTOSET
MUTE
RESIZE
CANCEL
You can call up on-screen menus, and conduct a number of adjustments and settings using
the operation buttons
p.16
on the control panel (main unit side) and remote control.
■ How to use the menus
The menu shown below is only for operation instructions and might be different from the
actual display.
ON/
STANDBY
FREEZE
2. Select a Category
Select a category by using
1. Start
.
There are following three
INPUT
categorys.
Image adjustment menu
Default setting menu
Display setting menu
p.30
p.30
p.31
Press to open the menu
3. Adjustments & Settings
of the selected category.
Item
Adjustment/Setting Value
These marks signify the
items can be adjusted/set
by using .
These marks signify an
item can be switched by
using .
The figure shows a typical example.
As the display may differ depending
on the item, use the following pages
as a reference.
These marks signify the items can be selected from
the list by using .
After an item is selected, apply it by pressing .
4. Back
Note
• Menu adjustments and settings are saved when the power is turned off via the ON/
STANDBY button. If the power cable is disconnected before this, or the power goes out,
then the data will not be saved.
• You can also use the CANCEL button on the remote control to dismiss the menu display.
Display the Setting display menu
Displays the current
adjustments of selected
category.
Item shown with gray
cannot be adjusted with
the current input source.
Finish via the Status
display menu.
This mark signfy that
there are options.
Press to display a
list of options.
The menu disappears.
5. To Finish
Operations
To Status display
p.28
6. End
28
29
Using the menu (Continued)
■ The image adjustment menu
Use this menu to adjust image-related items.
Items that can be adjusted are marked with “Ye s ”, and those that cannot are marked with “No”.
Item Description
Contrast
Brightness
Color
[Note 1]
Tint
Sharpness
R-level
G-level
B-level
Up/down shift
Notes
1: Tint can only be adjusted when Video mode
2: Up/down shift can only be adjusted when Screen size
[Note 2]
Lower Higher
Darker Brighter
Lighter Deeper
Reddish Greenish
Softer Sharper
Less red More red
Less green More green
Less blue More blue
Shift down Shift up
Computer
Y/PB/PR Video S-video
Ye s Ye s Ye s Ye s
Ye s Ye s Ye s Ye s
No Yes Yes Yes
No No Yes Yes
No Yes Yes Yes
Ye s Ye s Ye s Ye s
Ye s Ye s Ye s Ye s
Ye s Ye s Ye s Ye s
No Yes Yes Yes
p.24
is set to NTSC or NTSC4.43.
p.31
is set Wide.
■ The default setting menu
This menu shows placement status and other settings.
Item
Projection
mode
No signal
power off
Power on
Sets projection mode in accordance with Placement Style
(Placed
on floor)
Sets the period of time to wait until turning off the power after signal input stops:
Off (not turned off) 1 min 2 min ... 60 min
Sets whether to turn on the power when the ON/STANDBY button is pressed
(Manual), or when the power cord is plugged in (Auto). Manual Auto
[Note 1]
Lamp power
Note
1: When lamp power is set to low, the screen becomes a little darker, but the cooling fan noise gets
quieter.
Sets the lamp power Standard Low
Description
(Rear)
(Hung from
ceiling)
p.18
(Back hung
from ceiling)
■ The display setting menu
Use this menu to set screen display-related items.
Item
Description
Screen size
(Full): Display with LCD panel’s resolution
(Thru): Display with sampling resolution (for computer input)
Language
(Wide): Wide-screen display (for Video, S-video, and Y/P
Select one of the languages below to use for displaying menus and messages
B/PR
)
[ : Enter setting mode] [ :Selection] [Apply: ]
English/Français/Deutsch/Italiano/Español/
Português/ / / /
Background
Icon
Start-up screen
Screen to display when there is no input signal
Display icons as function guides On Off
Display start-up screen when power turned on On Off
(Logo) (Blue) (None)
Notes
• If “Thru” is selected for screen size, portions exceeding the pixel count of the LCD panel
p.37
will not appear on the screen. Note that for RGB signals with clock speeds
p.38
SXGA3_60
is higher than this, the RGB pixel signal is reduced before sampling.
• Displaying the images with the aspect ratio different from the original with the purpose of
other than the personal and private viewing, using the screen size menu may violate the
copyright protected by the law.
or lower, all input pixel signals are sampled. However, if the clock speed
■ Reset menu (Special menu)
When other menus are not displayed and the button is held down, the menu appears.
• Select Reset All and press the
Reset all
Reset all menu items to their factory settings
[ : Enter execution mode] [Yes No] [Apply: ]
button to return all menu items to the factory settings.
DescriptionItem
Operations
Notes
• Note that if Power on is set to Auto, then if the power cord is plugged in when power is
restored after a power outage, the projector power will come on.
• Even if Power on is set to Auto, press the ON/STANDBY button to turn off the power.
Unplugging the power cord to cut off the power will shorten the life of the lamp.
30
31
Maintenance
Air filter cleaning
The air filter prevents dust and debris from getting inside the projector. Never run the
projector with the filter removed. It is recommended that the air filter is cleaned regularly.
The icon message “Check the air filter for dirt.” is displayed every 100 hours. (If the
•
usage time exceeds 100 hours, this message is displayed for 30 seconds when the image is
displayed for the first time after power is turned on. This display will be dismissed with any
operation.)
• Check out the filter and any debris is found, use the following procedure for cleaning.
WARNING
• Request cleaning and maintenance of a ceiling-mounted unit from your projector
dealership.
Unplug power cord.
1
Remove the air filter.
2
Pull out the air filter by taking the catch shown in the figure.
Clean the filter.
3
Carefully remove the dust and dirt from the air filter with a
vacuum cleaner or the like.
Replace the air filter.
4
Lens and main unit cleaning
WARNING
• Request cleaning and maintenance of a ceiling-mounted unit from your projector
dealership.
■ Lens cleaning
• Clean the lens with a commercially available blower and/or
lens cleaner.
• The lens is easily scratched, so do not rub it with hard objects,
or strike it.
■ Main unit cleaning
• Clean the main unit after unplugging the power cord.
• Wipe dirt off the main unit gently with a soft cloth.
• If the soiling is severe, dip the cloth in a neutral
detergent diluted in water, wring well, and gently wipe
off the dirt, then finish up by wiping with a dry cloth.
● Replacing air intake and exhaust fans, and air filter
To maintain the performance, it is recommended that these should be replaced about
every 2 to 3 years. Consult with your dealer for details.
Lamp replacement
A lamp is consumable supplies. If used for extended periods, images will appear dark, and
the lamp could burn out. This is characteristic of a lamp, and is not malfunction. (The lifetime
of the lamp depends on condition of use. If this happens, replace it with a new one
WARNING
•
If the projector is mounted on a ceiling, request a lamp replacement from your projector dealership.
• When replacing, always use lamp “TLPLV3” (sold separately).
.
Notes
• Allowing dirt and dust to build up in the air filter will worsen the air circulation inside the
projector, causing the internal temperature to rise, causing the projector to stop working
or malfunction.
• Insert the air filter all the way in. Leaving gaps will allow dust and dirt to get inside the
projector again.
• If you wash the air filer with water, make sure to dry it completely before replacing it.
• If the air filter is torn, consult with your dealer about replacing it with a new one.
Continuing to use a ripped filter will allow dust and dirt to get inside the projector.
32
CAUTION
•
If you have been using the projector, the lamp will be very hot, and may cause burn injuries
Wait for the lamp to cool (for longer than 1 hour) before replacing it.
• If the lamp should break, please handle with care to avoid injury due to broken pieces
and contact your dealer for repair service.
Unplug power cord.
1
Wait until lamp is sufficiently cooled.
2
Wait for at least 1 hour.
33
.
Maintenance
Others
Lamp replacement (Continued)
Remove the lamp cover.
3
Loosen the 2 screws, then pull up to the
direction of the arrow with your fingers on the
area shown in the figure to remove the lamp
cover.
Pull out the lamp.
4
Loosen the 2 screws holding the lamp in place,
and pull up the handle to remove the lamp.
Mount the new lamp.
5
Align the orientation, press down until the bottom is
reached, and lock in place using the two lamp
locking screws.
Replace the lamp cover.
6
Align the cover, and press it in, then tighten the
screws loosened in step
3
until the lamp cover is
no longer loose.
Reset the lamp timer.
7
See the lamp’s manual for instructions on resetting
the lamp timer.
Notes and Precautions
• Press the button twice to display (a rough guide) the time of lamp use, the Lamp time
item, in the Status display menu.
p.28
• It is recommended that the lamp should be replaced after 2,000 hours of use. When
Lamp time reaches 2,000 hours, the
disappears when you press
button.
icon and a message will appear. This display
• Attach the lamp cover correctly so that it is not loose. If it is not attached correctly, the
lamp may fail to come on
p.35
, and the lamp’s lifetime may be shortened.
• Always replace the lamp with a new one.
• The lamp is made out of glass. Do not touch the glass surface with your bare hands,
bang it, or scratch it. (Dirt, jolts, scratches and the like could break the lamp.)
Used Lamps
This projector’s lamps contain trace amounts of environmentally harmful inorganic
mercury. Be careful not to break used lamps, and dispose it in accordance with local
regulations.
3
4
5
1
2
1
2
2
1
Trouble indications
The indicator lights inform you of internal abnormalities.
LAMPTEMP
LAMPTEMP
(Red lit) (Red lit)
Or
(Orange lit)
Or
(Green lit)
LAMPTEMP
(Red lit)
LAMPTEMP
(Orange
flashing)
ON
No power
⇒ Problem with projector
(Off)
ON
ONLAMPTEMPFAN
ON
ON
(Red lit)
• Unplug the power cord, and contact your dealer.
Lamp went out during use, or won’t come on
⇒ Lamp temperature is high so that it is difficult to turn on, the lifetime of
the lamp has ended or the projector is malfunctioning.
• Unplug the power cord and wait for a short while, then turn the power
back on.
• If a lamp burns out, replace it with a new one.
❈ After approx. one minute of abnormal display, the projector returns to
the standby state waiting for internal cool down.
Power went out during use
⇒ Internal overheating, or the outside temperature is too high.
• Place the projector so that the air intake and exhaust are not blocked.
• Unplug the power cord and wait for a short while, then turn the power
back on.
• Clean the air filter.
❈ The icon will appear before the power goes out.
❈ After approx. one minute of abnormal display, the projector returns to
the standby state waiting for internal cool down.
p.32
Power went out during use
⇒ Problem with internal cooling fan.
• Unplug the power cord, and contact your dealer.
❈ The
❈ After approx. one minute of abnormal display, the projector returns to
icon will appear before the power goes out.
the standby state waiting for internal cool down.
Power went out during use, or power won’t come on
⇒ The lamp cover is not properly attached.
• Unplug the power cord, and reattach the lamp cover.
❈ After approx. one minute of abnormal display, the projector returns to
the standby state waiting for internal cool down.
p.34
FAN
FAN
(Red lit) (Red lit)
(Green lit)
Or
(Off)
FAN
(Red lit or flashing)
Or
(Orange lit or flashing)
FAN
PRECAUTIONS
• Make sure to unplug the power cord if something goes wrong.
• If the power cord is unplugged before cooling is complete, give the lamp enough time to
cool before plugging it back in. If the lamp overheats, it may fail to light. Unplugging the
power cord repeatedly when the temperature is high will shorten the life of the lamp.
(Even if you are not concerned about lamp lifetime, the light may not come on if you do
not wait at least 3 minutes.)
Others
34
35
Before calling service personnel
Specifications
If you think something is wrong, check the followings before contacting customer service.
Please see “Trouble indications”
p.35
as well.
If This Happens Check
No power
Power goes out
during use
No picture
• Is the power cord plugged in? Is it connected to the projector?
• Is the lamp cover loose?
• Is the ambient temperature high?
• Is the air filter clogged?
• Is the air intake or air exhaust blocked?
• Is the projector turned on?
• Is the mute function on?
• Is the brightness setting minimized?
• Are the connections set up correctly?
p.35
p.35
p.35
p.35
p.22
p.26
p.30
p.19
• Are all the connected devices functioning properly?
No audio
• Is the projector turned on?
• Is the mute function on?
• Is the volume setting minimized?
• Are the connections set up correctly?
p.22
p.26
p.23
p.19
• Are all the connected devices functioning properly?
p.38
Picture not
displayed
correctly
• Is the input signal supported by the projector?
• Is the correct video mode selected?
• Is the correct signal format selected?
p.24
p.24
• Is the selecting of computer or Y/PB/PR input correct?
,
p.39
p.22
• Is there something generating an abnormal video signal, for
instance the video tape?
Picture blurred
Part of picture
out of focus
Image is dark
Colors too light
Bad shading
Remote control
doesn’t work
• Is the lens dirty?
• Is the lens focus adjusted optimally?
• Is the projection distance within the projector’s supported range?
p.18
• Is the projector’s screen placement angle tilted too far?
• Are the sharpness or sampling phase adjustments off?
• Are the brightness or contrast adjustments off?
• Is the lamp nearing the end of its service life?
• Are the color, tint, R-level, G-level, or B-level adjustments off?
• Is the screen dirty?
• Is the lamp nearing the end of its service life?
• Are the remote control’s batteries drained?
• Are the batteries inserted into the remote control correctly?
• Is the remote control being used within the effective range?
p.33
p.23
p.30
p.28
p.30
p.18
p.24
p.30
p.17
p.17
p.30
• Are there any obstructions between the remote control and
projector?
• Are there any fluorescent or other bright lights shining at the
projector’s infrared remote sensor?
■ List of general specifications
Item Specification
Consumption Power 220 W
Weight 2.2 kg
External Dimensions 303 × 84 × 206 mm (W × H × D)
(including protruding parts)
Cabinet material* PC+ABS resin and ABS resin
Conditions for usage environment
Display method
Panel size
LCD Panel
Drive system
elements
Lens F=1.8
Lamp High-pressure mercury lamp
Projection screen size 40-300 type
Projection distance 1.52-11.59 m
Speaker 1 W (Monaural)
COMPUTER terminal Mini D sub 15 pin RGB / Y/PB/PR (dual use)
MONITOR terminal Mini D sub 15 pin RGB / Y/PB/PR (dual use)
S-VIDEO terminal Mini DIN 4 pin
VIDEO terminal RCA Pin Jack, 1 V (p-p), 75 Ω
AUDIO terminal 3.5mm dia. stereo mini-jack, 1.5V (rms); 22 kΩ or more
CONTROL terminal Mini DIN 8 pin (RS-232C)
Connection terminal
* Each plastic part displays the materials it is made from, in order to facilitate recycling after this
product becomes no longer usable.
Temp: 0°C to 35°C; relative humidity: 30% to 70%
3-panel transmission
0.5 type
TFT active matrix
480,000 pixels (800H × 600V)
Others
36
37
Specifications (Continued)
51
10
1511
6
■ List of supported signals (RGB signals)
This projector supports the following RGB signals. Note, however, that depending on the
computer model, the screen may show flicker or streaking. Please adjust the projector if
this happens.
(Press the AUTO SET button, and adjust automatically or manually.
Resolution
720 x 400
640 x 480
800 x 600
832 x 624
1024 x 768
1152 x 864
1280 x 960
1280 x 1024
1400 x 1050
1600 x 1200
1792 x 1344
1856 x 1392
1920 x 1440
Mode
720x400_85
VGA_60
VGA_72
VGA_75
VGA_85
SVGA_56
SVGA_60
SVGA_72
SVGA_75
SVGA_85
MAC16"
XGA_43i
XGA_60
XGA_70
XGA_75
XGA_85
MAC19"
SXGA1_75
QuadVGA_60
QuadVGA_85
SXGA3_60
SXGA3_75
SXGA3_85
SXGA+
UXGA_60
UXGA_65
UXGA_70
UXGA_75
UXGA_85
1792x1344_60
1856x1392_60
1920x1440_60
Refresh rate
(Hz)
85.039
59.940
72.809
75.000
85.008
56.250
60.317
72.188
75.000
85.061
74.550
86.957
60.004
70.069
75.029
84.997
74.700
75.000
60.000
85.002
60.020
75.025
85.024
60.012
60.000
65.000
70.000
75.000
85.000
60.000
60.000
60.000
H-frequency
106.250
Note
• Signals whose resolution exceeds the LCD panel’s number of pixels
compressed. For this reason, some information may be lost, or image quality may be
affected.
(kHz)
37.927
31.469
37.861
37.500
43.269
35.156
37.879
48.077
46.875
53.674
49.725
35.522
48.363
56.476
60.023
68.667
60.134
67.500
60.000
85.938
63.981
79.976
91.146
63.973
75.000
81.250
87.500
93.750
83.640
86.333
90.000
p.24
p.37
)
Clock
(MHz)
35.500
25.175
31.500
31.500
36.000
36.000
40.000
50.000
49.500
56.250
57.283
44.900
65.000
75.000
78.750
94.500
79.857
108.000
108.000
148.500
108.000
135.000
157.500
118.094
162.000
175.500
189.000
202.500
229.500
204.750
218.250
234.000
will be
■ List of supported signals (Y/PB/PR signals)
Signal format fh(kHz) fv(Hz)
480i(525i)@60Hz 15.73 59.94
480p(525p)@60Hz 31.47 59.94
576i(625i)@50Hz 15.63 50.00
576p(625p)@50Hz 31.25 50.00
720p(750p)@60Hz 45.00 60.00
720p(750p)@50Hz 37.50 50.00
1080i(1125i)@60Hz 33.75 60.00
1080i(1125i)@50Hz 28.13 50.00
1035i(1125i)@60Hz 33.75 60.00
1152i(1250i)@50Hz 31.25 50.00
■ List of supported signals (Video, S-Video signals)
Video mode fh(kHz) fv(Hz) fsc(MHz)
NTSC 15.73 60 3.58
PAL 15.63 50 4.43
SECAM 15.63 50 4.25 or 4.41
PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58
PAL-60 15.73 60 4.43
NTSC4.43 15.73 60 4.43
■ Pin assignment of COMPUTER & MONITOR terminals
Pin Pin description
Mini D sub 15 Pin connector
Input Signal
• RGB input
R/G/B signals: 0.7V (p-p) 75 Ω
Horizontal sync signal: TTL level (Pos/neg polarity)
Vertical sync signal: TTL level (Pos/neg polarity)
• Y/PB/PR input
Y signal: 1.0V (p-p) 75 Ω
B/PR signals: 0.7V (p-p) 75 Ω
P
No. During RGB input
1
Video signal (R)
2 Video signal (G) Luminance signal (Y)
3 Video signal (B)
4 GND ∗
5 GND ∗
6 GND (R) GND (PR)
7 GND (G) GND (Y)
8 GND (B) GND (PB)
9 N.C ∗
10 GND ∗
11 GND ∗
12 N.C ∗
13 Horizontal sync signal ∗
14 Ver tical sync signal ∗
15 N.C ∗
∗ Do not connect anything.
During Y/PB/PR input
Color difference signal (PR)
Color difference signal (PB)
Others
38
39
Specifications (Continued)
■ CONTROL terminal
● Pin assignment
Pin No.
7
8
6
5
4
1
2
Mini DIN 8 pin connector
3
1
2
3
4
5
6
7
8
● Interface format
1 Communication method RS-232C, 9600bps, No Parity, Data Length: 8 bits;
Stop Bit Length: 1 bit
2 Communication format STX (02h) Command (3Byte) ETX (03h)
Only 1 command valid per communication.
3 Data format For input commands, only ASCII-compliant all-uppercase
alphanumeric characters supported.
4 Replies Acknowledge ACK (06h) CR (0Dh) Data ... Normally ended
No acknowledge NAK (15h)
If commands are to be sent consecutively, wait for the response from the projector
before sending the next command.
● Main Commands
Item Command
Power on PON
Power off POF
Icon display on MO0
Icon display off MO1
Auto setting (RGB input) PAT
Status display on DON
Status display off DOF
Note
• Contact your dealer for control cable and other commands.
Signal Name
RXD
CTS
DSR
GND
RTS
N.C
TXD
N.C
ACK (06h) ESC (1Bh) ... Aborted
Computer input select IN1
Y/PB/PR input select IN2
Video input select IN3
S-video input select IN4
Description
Receiving data
Consent to send
Data set ready
Signal ground
Request to send
No connection
Sending data
No connection
Item Command
■ Separately Sold Product
Replacement Lamp Model TLPLV3
Note
• Design, specifications, etc. subject to change without notice for improvements, etc.
40
Loading...
