TECRA 750CDM Product Specifications

750CDM: PA1259U-T2C

5.1 Billion Bytes = 4.7 7 GB

PROCESSOR

Intel Pentium 233Mhz (1.8v/2.5v)

External data bus width 64 bit

External data/address bus speed 66 MHz Integrated Coprocessor Yes Processor Cache (L1) 32KB: (16KB code; 16KB data) Standards ACPI v. 1.0 ready

LEVEL 2 (L2) CACHE

Data Bus Width/ Data Bus Speed 64 bit/66 MHz DATA RAM:

2 Mbit Pipelined Burst Synchronous SRAM (64K x 32bit, 2.5V/3.3V) x 2 -- Access Time: 8ns

MEMORY: 64 Mbit EDO DRAM, 3.3V Standard/ Maximum 32MB Maximum 160MB Speed 60ns Hyper Page mode memory access Yes Data width/ Data Bus speed 64 bit/66 MHz

BIOS

Standards supported APM v.1.2, PnP v.1.0A, VESA 2.0, DDC2B, DPMS, ACPI v.1.0

SYSTEM ARCHITECTURE Connecting Devices

PCI BUS (v.2.1): (32-bit, 33 MHz) PC Card Slots, Expansion Bus, Graphics Controller, Modem DSP,

ISA BUS: 16-bit, 8 MHz BIOS ROM, KBC, FDD, Sound chip

STORAGE

Removable HDD (2.5” Enhanced IDE) 5.1 Billion Bytes = 4.77 GB (Read/Write: 12msec/13msec) , Buffer: 512KB

SELECT BAY DEVICES DESCRIPTION

Second Battery Optional: Part# PA2446U

Battery Type Li-Ion (10.8V, 3600mAH) 1.15 lbs.

Modular FDD (3.5” 1.44MB) Included/Swappable with CD-ROM

FDD Dimensions 4.57”L x 3.78”W x .5”H .60 lbs. Simultaneous FDD & CD-ROM Support Yes: External FDD adapter included

FDD Adapter Dimensions 7.0”L x 5.5”W .25 lbs.

Modular HDD (2.5” Enhanced IDE) Optional/For use in SelectBay only: Part # PA2607U

Capacity 4.1 billion bytes = 3.82GB (Read/Write: 13msec/14msec), Buffer: 512KB

Weight .55 lbs.

Modular CD-ROM: Toshiba XM-1602B

5.25” 20X Max. speed Weight .70 lbs Interface .ATAPI (Enhanced IDE) Random Access Time 135 ms @ 20X Max speed Average Sustained Transfer Rate 3420KB/sec @ 20X Max speed; 2394KB/sec @ 14X Average speed CD-ROM Compatibility Red Book, Yellow Book, CD-ROM XA, CD-I Bridge (Photo-CD)

Modular DVD-ROM: Toshiba SD-C2002 Optional: Part# PA2613U

MPEGII video support

DolbyDigital Surround Sound AC-3

DVD Compatibility DVD-ROM only (no DVD-RAM)

Operation modes DVD-ROM

Access Speed 2X 16X Random Access Time 180ms 120ms Sustained Data Transfer rate 2,700 KB/sec 2,400 KB/sec

Storage space/disk 4.7 GB 4.7 GB

Yes: with MMX support

Yes: 512KB

Yes: (512KB 4Mbit FLASH EEPROM, 3.3V)

Video Capture controller, CD-ROM, DVD-ROM decoder, HDD

WEIGHT

Installed/ For use in SelectBay only

CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Extra), CD-RW

Yes: Built into 750CDM. Not supported by Windows NT. Yes: Built into 750CDM. Not supported by Windows NT.

CD-ROM

Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice. Copyright 1998 TAIS 750cdm.doc Rev. 10 02/07/00 nmm. Page 1 of 3

TECRA 750CDM Product Specifications

750CDM: PA1259U-T2C

5.1 Billion Bytes = 4.7 7 GB

DISPLAY

Type 13.3”Diagonal TFT Active Matrix Dot Pitch .26mm x .26mm Contrast Ratio 100:1 (min)

VIDEO

Memory: 16Mbit SGRAM, 3.3V 4 MB

Access Speed 83 MHz with Hyper-page mode support Data Bus Width/Clock Speed 64-bit/33 Mhz

Graphic Controller

PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz Standards supported DPMS, PnP v.1.0A, VESA 2.0 DuoView™ Device support

Controller Chip S3 Virge MX 3D (= 86C260)

64-bit BitBLT Engine Yes 2D Supported Features BitBLT, H/W Cursor, DirectDraw 3D Supported Features

Modeling Fogging Shading Flat shading, Gouraud shading Rendering Bilinear/Trilinear texture mapping , Anti-aliasing, MIP mapping, Z-buffering Direct3D support Yes OpenGL Yes

Digital Video Accelerator

YUV Color Space Conversion Off-loads conversion from CPU for higher performance full motion video

Scaling/ Interpolation Yes: vertical & horizontal

Zoomed Video Port Support Yes: vertical & horizontal

DirectVideo support Yes:w/Game SDK driver fr/Microsoft

DirectMPEG Yes TV Encoder support Yes: NTSC/PAL video out, and S-Video out with flicker reducing filter

INTERNAL VIDEO SUPPORT Colors

Smaller Image 640 x 480 24-bit (16.7M) N/A Smaller Image 800 x 600 24-bit (16.7M) N/A Full Screen 1024 x 768 24-bit (16.7M) N/A Virtual Display Mode 1280 x 1024 16-bit (64K) N/A Virtual Display Mode 1600 x 1200 8-bit (256) N/A

EXTERNAL VIDEO SUPPORT (CRT) Colors

VIDEO CAPTURE SUPPORT Colors

Input sources ZV Port-enabled PC Card or ZV Port-enabled External Camera unit Connected Bus type PCI bus (for ProShare/Video conferencing) and ZV port (normal capture) Supported file formats .BMP, .JPEG, .GIF (for still images), .AVI (for video) Maximum # of Still images to be stored 12 Maximum time of video recording Varies by free space of main memory and HDD

1. Future operating systems may support simultaneous display of different resolutions on mutiple devices.

Allows display of different images (or the same image) on following screen combinations: notebook/external monitor; notebook/TV; external monitor/TV

without compromising picture quality or frame rate.

Refresh Rate (Non-Interlaced)

640 x 480 24-bit (16.7M) 85 Hz 800 x 600 24-bit (16.7M) 85 Hz 1024 x 768 24-bit (16.7M) 85 Hz 1280 x 1024 16-bit (64K) 75 Hz 1600 x 1200 8-bit (256) 42 Hz (Interlaced)

Fps (w/ZV Port/.AVI file)

160 x 120 Up to 16.7M 30 320 x 240 Up to 16.7M 15 640 x 480 Up to 16.7M 3

TECRA 750CDM Product Specifications

750CDM: PA1259U-T2C

5.1 Billion Bytes = 4.7 7 GB

CAMERA

Mount External (hook on right edge of display panel) Type 1/4-inch CCD Effective pixels 640 x 480 (= 307.2K) Lens (Manual Focus) F2.8, f = 4.6 mm Focusing range > 10 cm, by manual focus Viewing angle of Center Minimum illumination 40 luxes Tilting angle -50 to +50 degrees Panning angle -45 to +225 degrees (horizontal) Interface connector Digital/26 pin proprietary connectory Interface cable length 50cm Automatic Light Control (ALC) Yes: AGC (0 db~ +12db); ELC (1/60 ~ 1/10,000 sec) White Balance ATW Yes Dimensions 5.63”L x 1.14”W x .79”D Weight .25 lbs.

SOUND SYSTEM

Chipsets: Yamaha 3D sound effect-enabled OPL3-SA3 and Wavetable-enabled OPL4-ML2 Functions supported

DolbyDigital Surround Sound AC-3 Sound formats supported: 16 bit stereo audio playback/record Yes: w/48kHz maximum sampling rate Full duplex function Yes: including simultaneous playback and record Mixing CD-ROM audio, Zoomed Video audio (stereo), CardBus audio (monaural) DirectSound support Yes: with Windows 95 Game SDK driver from Microsoft Volume control Yes Speaker system:

INTERNAL MODEM (All models)

DAA support US/Canada and Euro/Australia Data support

Protocols supported Bell-103/212A, CCITT-V.21/V.22, V.23, V.22bis, V.32, V.32bis, V.34 Error correction MNP 1-4 Data compression MNP 5 for upto 2X data compression, CCITT V.42 bis for upto 4X data compression

Fax support Fax class 1, Class 1 ECM

Protocols supported V.21 ch2, V.27 ter, V.29, V.17

Cellular support US Cellular support under Windows 95 only

Protocols supported (Phone) Bell-103/212A, CCITT-V.21/V.22, V.23, V.22bis, V.32, V.32bis, V.34 Protocols supported (Fax) V.21 ch2, V.27 ter, V.29, V.17

Fax class Fax class 1, Class 1 ECM

Phones supported

Telephony Functions

(Windows 95 only)

Standard software Ring Zero RingCentral telephony software

DSVD protocols supported

Video Conferencing (Windows 95 only)

Standard software Intel Video Phone with Proshare Technology 2.0 and Microsoft Netmeeting 2.0 Protocols supported

Data sharing support T.120; T.121; T.122; T.123; T.124; T.125; T.126; T .127

Horizontal: ±22.5 degrees (45° total); Vertical: ±16.9 degrees (33.8° total)

Yes: (w/Windows 95 only)

SoundBlaster Pro v.3.01, MIDI, Windows Sound System v.2.0

Two top-mounted stereo speakers (28mm, 16 Ω)

K56 Flex Upgradeable with DSVD, V.34 and V.80 support for Video Conferencing

Motorola Micro TAC (DPC550, Alpha, Lite, and Ultralite) and Motorola Elite only

Speaker phone, Telephony Answering Machine, Ring Wake-up Resume Incoming Call Discrimination, Caller ID ITU-T V.70, V.75, V.76, G.729, V.80, V.25terA, V.34, V.8bis

ITU-T H.323 (Internet video conferencing); H.324 (POTS video conferencing);

H.245; H.223; G.723; H.263; V.80; V.25terA; V.34; V.8bis

TECRA 750CDM Product Specifications

750CDM: PA1259U-T2C

5.1 Billion Bytes = 4.7 7 GB

EXPANSION SLOTS LOCATION

Two Stacked PC Card Slot

32-bit, 3.3V PC CardBus Support Yes 16-bit, 5.0V PC Card Support Yes

Two Internal Memory Slots

EXPANSION PORTS LOCATION

One 9-Pin Serial (16550 UART compliant) Yes: Rear of unit One 15-Pin RGB (SVGA video) Yes: Rear of unit One Expansion B us One 25-Pin Parallel (8 bit ECP) Yes: Rear of unit One DC IN port Yes: Rear of unit Noteworthy security lock port Yes: Rear of unit Microphone (3.5mm mini jack, monoaural) Yes: Rear of unit Headphone (3.5mm mini jack, stereo,16Ω min) Line-in (3.5mm mini jack, stereo, 2V rms) Yes: Rear of unit Line-out (3.5mm mini jack, stereo, 0.7V rms) Yes: Rear of unit Dolby AC3 Digital Yes: Rear of unit (5.1 channel, common with Headphone/AC3 digital) One (PS/2) 101 Keyboard/Mouse port One S-Video out port Yes: Rear of unit One NTSC/PAL out port Yes: Rear of unit Two Fast Infrared ports (front and back) One External Floppy Drive port Yes: Left side Two Universal Serial Bus (USB) ports One Power switch Yes: Left side One Reset Button Yes: Left side Noteworthy security lock port One RJ-11 port for internal modem (supplied) Yes: Right side One Cellular Modem port One External Camera port Yes: Right side (Proprietary 26-pin connector)

KEYBOARD

84keys, 3mm Travel Yes: 12 dedicated function keys; Cursor control (8 Keys, Inverted "T") Windows 95 support Yes Keyboard tilt Yes Numeric keypad (Integrated Overlay) Yes

Integrated Pointing Device Enhanced Port Replicator II (Optional)

Two Type III CardBus ready PC Card slots Yes: each slot supports one card Supported Interfaces Serial, parallel, PS/2 keyboard, PS/2 mouse, DC in, SVGA monitor, FDD port,

Desk Station V Plus (Optional)

Supported Interfaces (2) Full length 32-bit PCI/16-bit ISA slots; (1) Half Length 32-bit PCI slot;

Ports Serial, parallel, PS/2 keyboard, PS/2 mouse, DC in, SVGA monitor, FDD port,

Other features Designed for Windows 95 and PNP; Hot Docking Support

2. Slot supports two Type II PC Cards or one Type III PC Card. 3.Requires the purcha se of appropriate cellular cable: 991-40042.

Yes: Left side (CardBus & ZV Card Ready)

Yes: Below left-half of the palm rest (above main HDD)

Yes: Rear of unit (for use with Docking Station or Port Replicator)

Yes: Rear of unit (stereo, common with Headphone/AC3 digital)

Yes: Rear of unit (supports ”Y”Connector)

Yes: Rear of unit (IrDA 1.1:4 Mbps compatible)

Yes: Left side (Supports 127devices. Throughput Rate: 12Mbits/sec.)

Yes: Left side (Use when docked)

Yes: Right side

AccuPoint Part# PA2716U

lock slot , joystick/MIDI, audio line-in, line-out, headphone, microphone Part# PA2710U

(2) Type III PC Card slots; (1) SCSI II; (1) 5.25” half height drive bay; (1) Select Bay for Modular FDD or CD-ROM

lock slot , joystick/MIDI, audio line-in, line-out, headphone, microphone

TECRA 750CDM Product Specifications

750CDM: PA1259U-T2C

5.1 Billion Bytes = 4.7 7 GB

POWER

60W Autosensing External AC Adapter

Input (Voltage/Frequency) 100-240V; 50-60Hz Output (Voltage/Amps) 15 VDC; 4.0A (max) Battery Type: Li-Ion (3.6V 1200mAh, 12 cells) Yes: Part# PA2445UR (2.83”W x 1.14”H x 6.61”L) -- 1.1 lbs. Battery Life One battery

Full Power mode 3.5 hrs. 7 hrs.

Low Power mode 7 hrs. 8.5 hrs.

Recharge Time: Main Battery

(Computer Off/On) 3.8- 4.0 hrs./5-9 hrs. 3.8 - 4.0 hrs./5-12 hrs. 4-5 hrs./ 6-12 hrs.

Power Savings

DIMENSIONS WEIGHT (includes 1.1 lbs. battery)

BUNDLED SOFTWARE: Windows 95; RingZero RingCentral v.4.xx Telephony application; Toshiba VidCap software; Puma Intellisync 97; Sarnoff Video Brush scanning software; Microsoft Netmeeting 2.0; Intel Video Phone w/Proshare Technology 2.0

Included on CD: Internet Explorer 4.0; LANDesk Client Manager 3.0, SystemSoft CardWorks; Intel Video Interactive (32-bit,v.4.0) Toshiba Fn-esse utility; Online manual. Units ship with Recovery CD, Windows95 Companion disk, and Application CD.

SECURITY Lock slot, Password:power-on, supervisor, HDD access, Docking station eject WARRANTY 3 YR Parts & Labor (battery 1 year) ENVIRONMENTAL SPECIFICATIONS Operating Non-operating

Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C) Thermal Gradient 20º C per hour (max.) -- -Relative Humidity: Operating 20% to 8 0 % non-condensing 10% to 90% non-condensing Altitude: Operating -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m) Shock: Operating 10G (11ms); 1.5G w/CD-ROM installed 60G (11ms); 50G w/CD-ROM installed Vibration: Operating 0.5G; 0.25G (5~500Hz) w/CD-ROM

4. Recharge time may vary depending on condition of battery, and consumption of power for function performed during recharge: eg. use of LCD, HDD/CD-ROM, sound and modem, CardBus card in Port Replicator or PCI card in Desk Station V Plus. 5.

1.15 lbs.

5.51”L x 2 .95”W x .98” --- .90 lbs. (Part#:NW2444U)

Two batteries

Notebook alone Docked In Port Replicator Docked In Desk Station

MaxTime; APM v.1.2 BIOS support

11.95”W x 9.45"D x 2.13”H

8.0 lbs. (with FDD installed); 8.3 lbs. (with DVD-ROM installed)

1G; 1G (5~500Hz) w/CD-ROM

Optional 2nd battery PA2446UR weights
