TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic
TC7WG00FC
Dual 2-Input NAND Gate
Features
• High-level output current: IOH/IOL = ±8 mA (min)
at V
• High-speed operation: t
at V
• Operating voltage range: V
• 5.5-V tolerant inputs
• 3.6-V power down protection outputs
= 2.5 ns (typ.)
pd
= 0.9~3.6 V
CC
Absolute Maximum Ratings
Characteristics Symbol Value Unit
= 3 V
CC
= 3.3 V,15pF
CC
( Ta = 25°C )
TC7WG00FC
Weight: 0.002g (typ.)
Marking
TC7WG00FC
CSON8-P-0.4
Product name
Power supply voltage V
DC input voltage V
DC output voltage V
Input diode current I
Output diode current I
DC output current I
DC VCC/GND current I
Power dissipation PD 150 (Note 4) mW
Storage temperature T
Note: Using continuously under heavy loads (e.g. the application of
high temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the
reliability significantly even if the operating conditions (i.e.
operating temperature/current/voltage, etc.) are within the
absolute maximum ratings and the operating ranges.
Please design the appropriate reliability upon reviewing the
Toshiba Semiconductor Reliability Handbook (“Handling
Precautions”/Derating Concept and Methods) and individual
reliability data (i.e. reliability test report and estimated failure
rate, etc).
Note 1: V
Note 2: High or Low State.
Note 3: V
Note 4: Mounted on an FR4 board.
= 0V
CC
I
absolute maximum rating must be observed.
OUT
< GND
OUT
(25.4 mm × 25.4 mm × 1.6 t, Cu Pad: 11.56 mm
CC
IN
−0.5~4.6 (Note 1)
OUT
−0.5~VCC + 0.5 (Note 2)
IK
OK
OUT
CC
−20 (Note 3) mA
−65~150 °C
stg
−0.5~4.6 V
−0.5~7.0 V
−20 mA
±25 mA
±50 mA
2
)
V
G00
Pin Assignment (top view)
1Y 2B 2AVcc
8 7 6 5
1 2 3 4
1A 1B 2Y GND
1
2007-11-01

Truth Table
TC7WG00FC
IEC Logic Symbol
Inputs Outputs
A B Y
L L H
L H H
H L H
H H L
1A
1B
2A
2B
Operating Ranges
Characteristics Symbol Value Unit
Power supply voltage V
Input voltage VIN 0~5.5 V
Output voltage V
Output Current IOH/IOL
Operating temperature T
Input rise and fall time dt/dV 0~10 (Note 13) ns/V
CC
OUT
opr
0.9~3.6 V
0~3.6 (Note 5)
0~V
±8.0 (Note 7)
±4.0 (Note 8)
±3.0 (Note 9)
±1.7 (Note 10)
±0.3 (Note 11)
±0.02 (Note 12)
−40~85 °C
(Note 6)
CC
V
mA
&
1Y
2Y
Note 5: VCC = 0V
Note 6: High or Low state.
Note 7: VCC = 3.0~3.6 V
Note 8: VCC = 2.3~2.7 V
Note 9: VCC = 1.65~1.95 V
Note 10: VCC = 1.4~1.6 V
Note 11: V
Note 12: V
= 1.1~1.3 V
CC
= 0.9 V
CC
Note 13: VIN = 0.8~2.0 V, VCC = 3.0 V
2
2007-11-01
