TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic

TC7SH32FS

2-INPUT OR GATE

Features

High speed: tpd = 3.8 ns (typ.) at VCC = 5 V

Low power dissipation: I

High noise immunity: V

5.5V tolerant input.

Wide operating voltage range: VCC (opr) = 2~5.5 V

Marking ・Pin Assignment

(top view)

= 2 μA (max) at Ta = 25°C

CC

= V

NIH

= 28% VCC (min)

NIL

Weight : 0.001 g (Typ.)

TC7SH32FS

SON5-P-0.35

(fSV)

H 4

Type Name

IN A

GND

IN B

V

1

2

3

5

4

CC

OUT Y

1

2007-11-01

TC7SH32FS

>

Absolute Maximum Ratings

(Ta = 25°C)

Characteristics Symbol Rating Unit

Supply voltage range V

DC input voltage V

DC output voltage V

Input diode current I

Output diode current I

DC output current I

DC VCC/ground current ICC ±50 mA

Power dissipation PD 50 mW

Storage temperature T

CC

IN

OUT

IK

OK

OUT

stg

−0.5~7.0 V

−0.5~7.0 V

−0.5~VCC + 0.5 V

−20 mA

±20 mA

±25 mA

−65~150 °C

Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the

significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even
if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings and the operating ranges.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).

Logic Diagram Truth Table

IN A

IN B

1

OUT Y

A B Y

L L L

L H H

H L H

H H H

Operating Ranges

Characteristics Symbol Rating Unit

Supply voltage VCC 2.0~5.5 V

Input voltage VIN 0~5.5

Output voltage V

Operating temperature T

Input rise and fall time dt/dv

0~V

OUT

opr

0~100 (VCC = 3.3 ± 0.3 V)

0~20 (V

CC

−40~85 °C

= 5 ± 0.5 V)

CC

V

V

ns/V

2

2007-11-01
