Toshiba Satellite S40, Satellite S50, Satellite S70-B, Satellite L40, Satellite L70 User's Guide

...

GMAD00396010 04/14



If you need assistance: Technical support is available online at Toshiba’s Web site at

support.toshiba.com. At this Web site, you will find answers

for many commonly asked technical questions plus many downloadable software drivers, BIOS updates, and other downloads.

For more information, see “If Something Goes Wrong” on

page 122 in this guide.

Satellite®/Satellite Pro® L40/ L50/L70/S40/S50/S70 - B Series

User’s Guide

5.375 x 8.375 ver 2.3

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling.

For the state of California only.

Model: Satellite®/Satellite Pro® L40/L50/

L70/S40/S50/S70 - B Series

Recordable and/or ReWritable Drive(s) and Associated Software Warranty

The computer system you purchased may include Recordable and/ or ReWritable optical disc drive(s) and associated software, among the most advanced data storage technologies available. As with any new technology, you must read and follow all set-up and usage instructions in the applicable user guides and/or manuals enclosed or provided electronically. If you fail to do so, this product may not function properly and you may lose data or suffer other damage.

TOSHIBA AMERICA INFORMATION SYSTEMS, INC. (“TOSHIBA”), ITS AFFILIATES AND SUPPLIERS DO NOT WARRANT THAT OPERATION OF THE PRODUCT WILL BE UNINTERRUPTED OR ERROR FREE. YOU AGREE THAT TOSHIBA, ITS AFFILIATES AND SUPPLIERS SHALL HAVE NO RESPONSIBILITY FOR DAMAGE TO OR LOSS OF ANY BUSINESS, PROFITS, PROGRAMS, DATA, NETWORK SYSTEMS OR REMOVABLE STORAGE MEDIA ARISING OUT OF OR RESULTING FROM THE USE OF THE PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY THEREOF.

5.375 x 8.375 ver 2.3

Protection of Stored Data

For your important data, please make periodic back-up copies of all the data stored on the hard disk or other storage devices as a precaution against possible failures, alteration, or loss of the data. IF

YOUR DATA IS ALTERED OR LOST DUE TO ANY TROUBLE, FAILURE O R MALFUNCTION OF THE HAR D DISK DRIVE OR OTHER STORAGE DEVICES AND THE DATA CANNOT BE RECOVERED, TOSHIBA SHALL NOT BE LIABLE FOR ANY DAMAGE OR LOSS OF DATA, OR ANY OTHER DAMAGE RESULTING THEREFROM. WHEN COPYING OR TRANSFERRING YOUR DATA, PLEASE BE SURE TO CONFIRM WHETHER THE DATA HAS BEEN SUCCESSFULLY COPIED OR TRANSFERRED. TOSHIBA DISCLAIMS ANY LIABILITY FOR THE FAILURE TO COPY OR TRANSFER THE DATA CORRECTLY.

Critical Applications

The computer you have purchased is not designed for any “critical applications.” “Critical applications” means life support systems, medical applications, connections to implanted medical devices, commercial transportation, nuclear facilities or systems or any other applications where product failure could lead to injury to persons or loss of life or catastrophic property damage.

ACCORDINGLY, TOSHIBA, ITS AFFILIATES AND SUPPLIERS DISCLAIM ANY AND ALL LIABILITY ARISING OUT OF THE USE OF THE COMPUTER PRODUCTS IN ANY CRITICAL APPLICATIONS. IF YOU USE THE COMPUTER PRODUCTS IN A CRITICAL APPLICATION, YOU, AND NOT TOSHIBA, ASSUME FULL RESPONSIBILITY FOR SUCH USE.

5.375 x 8.375 ver 2.3

FCC Notice “Declaration of Conformity Information”

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

❖ Reorient or relocate the receiving antenna. ❖ Increase the separation between the equipment and receiver. ❖ Connect the equipment to an outlet on a circuit different from

that to which the receiver is connected.

❖ Consult the dealer or an experienced radio/TV technician for

help.

Only Peripherals complying with the FCC Class B limits may be attached to this equipment. Operation with noncompliant peripherals or peripherals not recommended by Toshiba is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer's ports. Changes or modifications made to this equipment not expressly approved by Toshiba or parties authorized by Toshiba could void the user's authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

❖ This device may not cause harmful interference. ❖ This device must accept any interference received, including

interference that may cause undesired operation.

Contact Toshiba’s Support Web site at support.toshiba.com.

NOTE

5.375 x 8.375 ver 2.3

Bluetooth® Wireless Technology

Interoperability

This section is only applicable if your system has a

Bluetooth

module.

Bluetooth

modules are designed to be interoperable with any

product with

Bluetooth

wireless technology that is based on Frequency Hopping Spread Spectrum (FHSS) radio technology, and is compliant to:

❖

Bluetooth

Specification as defined and approved by The

Bluetooth

Special Interest Group.

❖ Logo certification with

Bluetooth

wireless technology as

defined by The

Bluetooth

Special Interest Group.

Bluetooth

modules enable wireless networks over two or more (up to a total of seven) TOSHIBA portable devices. Please contact TOSHIBA computer product support on Web site http://www.toshiba-europe.com/computers/tnt/ bluetooth.htm in Europe or support.toshiba.com in the United States for more information.

When you use a

Bluetooth

module close to 2.4 GHz Wireless

LAN devices,

Bluetooth

transmissions might slow down or cause errors. If you detect certain interference while you use a

Bluetooth

device, always change the frequency, move your device to the area outside of the interference range of 2.4 GHz Wireless LAN devices (40 meters/43.74 yards or more) or stop transmitting from your device. Please contact TOSHIBA computer product support on Web site http:// www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or support.toshiba.com in the United States for more information.

Bluetooth

and Wireless LAN devices operate within the same radio frequency range and may interfere with one another. If you use

Bluetooth

and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection. If you should experience any such problem, immediately turn off either one of your

Bluetooth

or Wireless LAN. Please contact Toshiba computer product support on Web site http://www.toshiba-europe.com/computers/tnt/ bluetooth.htm in Europe or support.toshiba.com in the United States for more information.

NOTE

5.375 x 8.375 ver 2.3

Bluetooth® Wireless Technology and Your

Health

The products with

Bluetooth

wireless technology, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by devices with

Bluetooth

wireless technology however is much less than the electromagnetic energy emitted by wireless devices such as mobile phones.

Because products with

Bluetooth

wireless technology operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes

Bluetooth

wireless technology is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

In some situations or environments, the use of

Bluetooth

wireless technology may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include:

❖ Using the equipment with

Bluetooth

wireless technology on

board airplanes, or

❖ In any other environment where the risk of interference to other

devices or services is perceived or identified as harmful.

If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use the device with

Bluetooth

wireless technology prior to turning on the equipment.

Exposure to Radio Frequency Radiation The radiated output power of the Bluetooth module is far

below the FCC radio frequency exposure limits. Nevertheless, the Bluetooth module shall be used in such a manner that the potential for human contact during normal operation is minimized.

5.375 x 8.375 ver 2.3

Wireless Interoperability

Wireless LAN products are designed to be interoperable with any wireless LAN product that is based on Direct Sequence Spread Spectrum (DSSS) radio technology, and is compliant to:

❖ The IEEE 802.11 Standard on Wireless LANs (Revision a/b/g/n/

ac), as defined and approved by the Institute of Electrical and Electronics Engineers.

❖ The Wireless Fidelity (Wi-Fi

) certification as defined by the WiFi Alliance. The “Wi-Fi CERTIFIED” logo is a certification mark of the Wi-Fi Alliance.

Bluetooth

and Wireless LAN devices operate within the same radio frequency range and may interfere with one another. If you use

Bluetooth

and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection.

If you should experience any such problem, immediately turn off your

Bluetooth

or Wireless LAN device.

Please contact Toshiba computer product support on Web site http://www.toshiba-europe.com/computers/tnt/ bluetooth.htm in Europe or support.toshiba.com in the United States for more information.

Radio Frequency Interference Requirements This device is restricted to indoor use due to its operation in

the 5.15 GHz to 5.25 GHz frequency range. FCC requires this product to be used indoors for frequency range 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.

Please note that high-power radars are allocated as primary users of the 5.25 GHz to 5.35 GHz and 5.65 GHz to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device.

The above caution applies to products that operate with an

802.11a radio device.

NOTE

5.375 x 8.375 ver 2.3

Wireless LAN and Your Health

Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by Wireless LAN devices however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.

Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include:

❖ Using the Wireless LAN equipment on board airplanes, or ❖ In any other environment where the risk of interference to other

devices or services is perceived or identified as harmful.

Exposure to Radio Frequency Radiation The radiated output power of the Wireless LAN is far below

the FCC radio frequency exposure limits. Nevertheless, the Wireless LAN shall be used in such a manner that the potential for human contact during normal operation is minimized. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

5.375 x 8.375 ver 2.3

Optical Disc Drive Safety Instructions

This section is only applicable if your system has an Optical Disc Drive.

This appliance contains a laser system and is classified as a CLASS 1 LASER PRODUCT. To use this model properly, read the User’s Guide carefully and keep it for your future reference.

Never attempt to disassemble, adjust or repair an optical disc drive. You could damage the drive. You would also be exposed to laser light or other safety hazards, resulting in serious injury. Always contact an authorized Toshiba service provider, if any repair or adjustment is required.

Location of the Required Label

(Sample shown below. Location of the label and manufacturing information may vary.)

Canada – Industry Canada (IC)

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conformé à la norme

NMB-003 du Canada. This device complies with RSS 210 of Industry Canada.

The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s Web site www.hc-sc.gc.ca/rpb. The RF device shall not be co-located with any other transmitter that has not been tested with this device.

NOTE

5.375 x 8.375 ver 2.3

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

L’ utili sation de ce disp ositi f est soumis aux deux conditions suivantes: (1) il ne doit pas produire de brouillage et (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même s’il est susceptible de compromettre son fonctionnement.

The term “IC” before the equipment certification number only signifies that the Industry Canada technical specifications were met.

To p r ev e nt ra di o in t er f ere nc e t o t he l i c en s ed se r v ic e , t hi s de v ic e i s intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.

Pour empecher que cet appareil cause du brouillage au service faisant l’objet d’une licence, il doit etre utilize a l’interieur et devrait etre place loin des fenetres afin de Fournier un ecram de blindage maximal. Si le matriel (ou son antenne d’emission) est installe a l’exterieur, il doit faire l’objet d’une licence.

This device is restricted to indoor use due to its operation in the 5.15 GHz to 5.25 GHz frequency range. Industry Canada requires this product to be used indoors for frequency range

5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.

Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.

Veuillez noter que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.

The above caution applies to products that operate with an

802.11a radio device.

NOTE

5.375 x 8.375 ver 2.3

Regulatory statements

This product complies with any mandatory product specification in any country/region where the product is sold. In addition, the product complies with the following:

EU Declaration of Conformity

TOSHIBA declares that this product conforms to the following Standards:

This product is carrying the CE-Mark in accordance with the related European Directives. The party responsible for CE-Marking is TOSHIBA Europe GmbH, Hammfelddamm 8, 41460 Neuss, Germany.

The European Union WEEE (Waste from Electrical and Electronic Equipment) Directive Information

The European Union WEEE (Waste from Electrical and Electronic Equipment) Directive is intended to protect the quality of the environment and human health through the responsible use of natural resources and the adoption of waste management strategies that focus on recycling and reuse. This Directive requires producers of electrical and electronic products put on the market in European Union (EU) member countries after August 2005 to mark such products with a crossed-out wheeled bin with a black bar symbol. If the product’s battery or accumulator contains more than the specified values of lead (Pb), mercury (Hg), and/or cadmium (Cd) defined in the Battery Directive (2006/66/EC), then the chemical symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd) will appear below the crossed out wheeled bin symbol on the battery.

Supplementary Information:

*The product complies with the requirements of the Low Voltage Directive 73/23/EEC, the EMC Directive 89/336/EEC and/or the R&TTE Directive 1999/5/EC.

Pb, Hg, Cd

5.375 x 8.375 ver 2.3

In the European Union, these symbols indicate that when the last end user wishes to discard this product, it must be sent to appropriate facilities for recovery and recycling. This Directive applies to EU member countries only and does not apply to end users in other countries such as the United States.

Although the initial emphasis is in Europe, Toshiba is already working with design engineers, suppliers, and other partners to determine appropriate worldwide product life cycle planning and end-of-life strategies for our products. Please contact your local government for applicable laws and regulations governing the disposal of this product. For information on how to trade-in or recycle your product, visit www.reuse.toshiba.com.

Europe - Restrictions for use of 2.4 GHz Frequencies in European Community Countries

België/ Belgique:

For private usage outside buildings across public grounds over less than 300m no special registration with IBPT/BIPT is required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more than 300m. For registration and license please contact IBPT/BIPT.

Voor privé-gebruik buiten gebouw over publieke groud over afstand kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik over afstand groter dan 300m is wel registratie bij BIPT/IBPT nodig. Voor registratie of licentie kunt u contact opnemen met BIPT.

Dans le cas d’une utilisation privée, à l’extérieur d’un bâtiment, au-dessus d’un espace public, aucun enregistrement n’est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m un enregistrement auprès de l’IBPT est requise. Pour les enregistrements et licences, veuillez contacter l’IBPT.

Deutschland: License required for outdoor installations. Check with reseller

for procedure to follow. Anmeldung im Outdoor-Bereich notwendig, aber nicht

genehmigungspflichtig. Bitte mit Händler die Vorgehensweise abstimmen.

France: Restricted frequency band: only channels 1 to 7 (2400 MHz

and 2454 MHz respectively) may be used outdoors in France. Please contact A.R.T. (http://www.art-telecom.fr) for applicable procedures to follow.

5.375 x 8.375 ver 2.3

Europe - Restrictions for Use of 5 GHz Frequencies in European Community Countries

O: allowed x: forbidden

❖ To remain in conformance with European spectrum usage laws

for Wireless LAN operation, the above 2.4 GHz and 5 GHz channel limitations apply. The user should use the wireless LAN utility to check the current channel of operation. If

Bande de fréquence restreinte: seuls les canaux 1- 7 (2400 et 2454 MHz respectivement) doivent être utilisés endroits extérieur en France. Vous pouvez contacter l’Autorité de Régulation des Télécommunications (http://www.arttelecom.fr) pour la procédure à suivre.

Italia: License required for indoor use. Use with outdoor installations

not allowed. È necessaria la concessione ministeriale anche per l’uso

interno. Verificare con i rivenditori la procedura da seguire.

Nederland: License required for outdoor installations. Check with reseller

for procedure to follow. Licentie verplicht voor gebruik met buitenantennes. Neem

contact op met verkoper voor juiste procedure.

European Community Countries

5150-5250 MHz Channels: 36,

40, 44, 48 Indoor Only

5250-5350 MHz Channels: 52,

56, 60, 64 Indoor Only

5470-5725 MHz Channels: 100,

104, 108, 112, 116, 120, 124, 128, 132, 136, 140

Indoor/Outdoor Austria O x x Belgium, France,

Switzerland/ Liechtenstein

OOx

Denmark, Finland, Germany, Greece, Ireland, Italy, Luxembourg, Netherlands, Norway, Portugal, Sweden, UK

OOO

Iceland, Spain O O O

5.375 x 8.375 ver 2.3

operation is occurring outside of the allowable frequencies as listed above, the user must cease operating the Wireless LAN at that location and consult the local technical support staff responsible for the wireless network.

❖ The 5 GHz Turbo mode feature is not allowed for operation in

any European Community country.

❖ This device must not be operated in ad-hoc mode using

channels in the 5 GHz bands in the European Community. Adhoc mode provides a direct communication between two client devices without a Wireless LAN Access Point.

❖ This device must be used with Access Points that have

employed and activated a radar detection feature required for European Community operation in the 5 GHz bands. This device will operate under the control of the Access Point in order to avoid operating on a channel occupied by any radar system in the area. The presence of nearby radar operation may result in temporary interruption of operation of this device. The Access Point’s radar detection feature will automatically restart operation on a channel free of radar. You may consult with the local technical support staff responsible for the wireless network to ensure the Access Point device(s) are properly configured for European Community operation.

Taiwan

The legal communications mentioned in the above item refer to radio communications operated in accordance with telecommunication laws and regulations.

Low power radio frequency electric machinery shall resist against interference from legal communications or from industrial, scientific and medical radio emission electric machinery.

Article 14 Unless approved, for any model accredited low power radio

frequency electric machinery, any company, trader or user shall not change the frequency, increase the power or change the features and functions of the original design.

Article 17 Any use of low power radio frequency electric machinery shall

not affect aviation safety and interfere with legal communications. In the event interference is caused, the use of such electric machinery shall be immediately discontinued. Operation of such products can be resumed only when they are modified and can no longer cause interference.

5.375 x 8.375 ver 2.3

Using this Equipment in Japan

In Japan, the frequency bandwidth of 2,400 MHz to 2,483.5 MHz for second generation low-power data communication systems such as this equipment overlaps that of mobile object identification systems (premises radio station and specified low-power radio station).

1. Sticker Please put the following sticker on devices incorporating this

product.

2. Indication The indication shown below appears on this equipment.

1 2.4: This equipment uses a frequency of 2.4 GHz. 2 DS: This equipment uses DS-SS modulation.

OF: This equipment uses OFDM modulation.

3 The interference range of this equipment is less than 40m. 4 This equipment uses a frequency bandwidth from

2,400 MHz to 2,483.5 MHz.

It is possible to avoid the band of mobile object identification

systems. The indication shown below appears on this equipment.

1 2.4: This equipment uses a frequency of 2.4 GHz. 2 FH: This equipment uses FH-SS modulation.

The frequency bandwidth of this equipment may operate within the same range as industrial devices, scientific devices, medical devices, microwave ovens, licensed radio stations and non-licensed specified low-power radio stations for mobile object identification systems (RFID) used in factory product lines (Other Radio Stations).

1. Before using this equipment, ensure that it does not interfere with any of the equipment listed above.

2. If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions.

3. Contact TOSHIBA Direct PC if you have problems with interference caused by this product to Other Radio Stations.

'62)

!





)+

!





5.375 x 8.375 ver 2.3

3 The interference range of this equipment is less than 10m. 4 This equipment uses a frequency bandwidth from 2,400 MHz to

2,483.5 MHz.

3. TOSHIBA Direct PC Monday – Friday: 10:00 – 17:00 To ll Fr ee Tel : 0 12 0 -1 5 - 10 4 8 Direct Dial: 03-3457-4850 Fax: 03-3457-4868

VCCI Class B Information

Device Authorization

This device obtains the Technical Regulation Conformity Certification and the Technical Conditions Compliance Approval, and it belongs to the device class of radio equipment of low-power data communication system radio station stipulated in the Radio Law and the Telecommunications Business Law of Japan.

This guide is copyrighted by Toshiba America Information Systems, Inc. with all rights reserved. Under the copyright laws, this guide cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.

5.375 x 8.375 ver 2.3

Export Administration Regulation

This document contains technical data that may be controlled under the U.S. Export Administration Regulations, and may be subject to the approval of the U.S. Department of Commerce prior to export. Any export, directly or indirectly, in contravention of the U.S. Export Administration Regulations is prohibited.

Notice

The information contained in this manual, including but not limited to any product specifications, is subject to change without notice.

TOSHIBA CORPORATION AND TOSHIBA AMERICA INFORMATION SYSTEMS, INC. (TOSHIBA) PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL OR ANY OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO ANY OF THE FOREGOING. TOSHIBA ASSUMES NO LIABILITY FOR ANY DAMAGES INCURRED DIRECTLY OR INDIRECTLY FROM ANY TECHNICAL OR TYPOGRAPHICAL ERRORS OR OMISSIONS CONTAINED HEREIN OR FOR DISCREPANCIES BETWEEN THE PRODUCT AND THE MANUAL. IN NO EVENT SHALL TOSHIBA BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, OR EXEMPLARY DAMAGES, WHETHER BASED ON TORT, CONTRACT OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL OR ANY OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.

5.375 x 8.375 ver 2.3

Trademarks

Satellite, Satellite Pro, and eco Utility are either registered trademarks or trademarks of Toshiba America Information Systems, Inc. and/or To sh i ba C o rp o r at i on .

Adobe and Photoshop are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Blu-ray and Blu-ray Disc are trademarks of the BD Association. Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.

and any use of such marks by To sh ib a i s un d er li c e ns e . O th er trademarks and trade names are those of their respective owners.

U.S. patents apply to this product. See http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks and DTS Premium Voice Pro is a trademark of DTS, Inc. ©DTS, Inc. All Rights Reserved.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Intel, Intel Core, Celeron, Centrino and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Microsoft, Outlook, Windows, and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

MultiMediaCard and MMC are registered trademarks of MultiMediaCard Association.

Secure Digital, microSD, and SD are trademarks or registered trademarks of SD-3C, LLC in the United States, other countries or both.

Wi-Fi is a registered trademark of the Wi-Fi Alliance. All other brand and product names are trademarks or registered

trademarks of their respective companies.

Licenses

This Product is licensed under the AVC, the VC-1 and the MPEG-4 Part 2 Visual patent portfolio licenses for the personal and noncommercial use of a consumer to (i) encode video in compliance with the above standards (“Video Standards”) and/or (ii) decode AVC, VC-1 and MPEG-4 Part 2 Visual that was encoded by a consumer engaged in personal and non-commercial activity or was obtained from a video provider licensed to provide such video. None of the licenses extend to any other product regardless of whether such product is included with this product in a single article. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, LLC. See www.mpegla.com.

5.375 x 8.375 ver 2.3

Computer Recycling Information

As part of a commitment to people and the future, Toshiba promotes the efficient use of resources by working to achieve our zero-wasteto-landfill goal at all our production sites. In addition to our existing waste reduction and recycling policies, Toshiba is strongly committed to reducing electronic waste. In order to ensure efficient use of resources and appropriate treatment of hazardous substances, in accordance with recycling regulations in each state, country, and territory, Toshiba wants to make it easy for customers to recycle products at the end of the life cycle. To learn more about To sh i ba ' s s u st a in ab i li ty commitment, visit toshiba.com/recycle.

Reuse, Donation, Recycling

Functional computers can be donated to a local charity or resold easily through a Toshiba-branded program.

Non working Toshiba computers can be mailed-back for free recycling.

For additional details, please visit toshiba.com/recycle.

5.375 x 8.375 ver 2.3

Contents

Introduction.......................................................26

This guide ............................................................ 28

Safety icons ......................................................... 29

Other icons used............................................ 29

Your computer’s features and

specifications ........................................... 30

Documentation .................................................... 30

Service options .................................................... 30

Chapter 1: Getting Started......................................31

Selecting a place to work .................................... 31

Setting up a work environment...................... 31

Keeping yourself comfortable........................ 32

Computer user comfort recommendations.... 32

Good Working Posture .................................. 32

Using the notebook with an external

keyboard, mouse or monitor.................... 33

Typing style.................................................... 34

Taking breaks and varying tasks ................... 35

Mobile computing tips ................................... 35

Transporting the notebook ............................ 35

Contents

5.375 x 8.375 ver 2.3

Seeking additional help.................................. 36

Check list ....................................................... 36

Precautions .................................................... 37

Important information on your computer’s

cooling fan................................................ 39

Setting up your computer .................................... 39

Connecting to a power source ............................ 40

Charging the main battery ................................... 41

Using the computer for the first time................... 42

Initial setup..................................................... 42

Setting up your software................................ 42

Registering your computer with Toshiba............. 43

To Shut down your computer .............................. 43

To Restart your computer.................................... 44

To place your computer in Sleep mode............... 45

Adding optional external devices......................... 45

Adding memory ................................................... 46

Recovering the Internal Storage Drive ................. 46

Creating recovery media................................ 47

Restoring from recovery media...................... 50

Refresh your PC (with user’s data) ................ 51

Reset your PC................................................ 53

Installing drivers and applications.................. 56

Using the touch pad ............................................ 57

Adjusting touch pad settings ......................... 59

Disabling or enabling the touch pad .............. 60

Connecting an external device ...................... 60

Using external display devices ............................ 61

Selecting video cables................................... 61

Connecting an HDMI™-compatible

television or display device ...................... 61

Connecting an external monitor or

projector................................................... 62

Directing the display output when you

turn on the computer ............................... 62

Adjusting the quality of the external

display...................................................... 63

Customizing your computer’s settings ................ 64

Contents

5.375 x 8.375 ver 2.3

Caring for your computer..................................... 64

Cleaning the computer .................................. 64

Moving the computer..................................... 65

Using a computer lock................................... 65

Chapter 2: Learning the Basics.............................. 66

Computing tips .................................................... 66

Using the keyboard.............................................. 67

Function keys................................................. 68

Special Windows

keys ................................ 69

Touch screen ....................................................... 69

Touch screen navigation................................ 69

Mouse properties................................................. 70

Starting an app .................................................... 71

Starting an app from the Start screen ........... 71

Saving your work ................................................. 72

Backing up your work.......................................... 72

Using the optical disc drive ................................. 72

Viewing Blu-ray Disc™ movies...................... 73

Optical disc drive components ...................... 74

Media control buttons.................................... 75

Inserting an optical disc ................................ 76

Playing optical media..................................... 76

Recording optical media................................ 77

Removing a disc with the computer on ......... 78

Removing a disc with the computer off......... 78

Toshiba’s online resources.................................. 78

Chapter 3: Mobile Computing................................ 79

Toshiba’s energy-saver design............................ 79

Running the computer on battery power............. 79

Battery Notice ................................................ 80

Power management....................................... 81

Charging batteries ............................................... 81

Charging the main battery ............................. 81

Charging the RTC battery .............................. 82

Monitoring battery power .................................... 83

Determining remaining battery power............ 84

Contents

5.375 x 8.375 ver 2.3

What to do when the main battery runs

low............................................................ 85

Setting battery notifications ........................... 85

Conserving battery power ............................. 86

Power Plans ................................................... 87

Using the eco power plan.................................... 88

Changing the main battery................................... 89

Removing the battery from the computer...... 90

Inserting a charged battery............................ 91

Taking care of your battery.................................. 92

Safety precautions ......................................... 92

Maintaining your battery ................................ 93

Disposing of used batteries ................................. 93

Traveling tips........................................................ 94

Chapter 4: Exploring Your Computer’s Features ....96

Exploring the Start screen ................................... 96

Charms........................................................... 97

Tiles................................................................ 98

Exploring the desktop.......................................... 98

Finding your way around the desktop ........... 98

Windows

Store................................................. 100

Setting up for communications.......................... 101

Connecting your computer to a network ..... 102

Exploring audio features .................................... 102

Recording sounds........................................ 102

Using external speakers or headphones ..... 103

Using the Web Camera...................................... 104

Using the Memory card reader .......................... 104

Inserting memory media .............................. 105

Removing memory media ............................ 105

Chapter 5: Utilities ................................................107

eco Utility® ........................................................108

Password Utility ................................................. 109

Using a supervisor password ...................... 109

Using a user password ................................ 111

Deleting a user password ............................ 113

System Settings................................................. 114

Contents

5.375 x 8.375 ver 2.3

Sleep Utilities ..................................................... 116

USB Sleep and Charge................................ 116

Enabling/Disabling USB Sleep and

Charge.................................................... 118

Power supply mode settings ....................... 118

Function Key...................................................... 119

Recovery Media Creator.................................... 120

Service Station................................................... 120

TOSHIBA Application Installer ........................... 121

Chapter 6: If Something Goes Wrong .................. 122

Problems that are easy to fix ............................. 122

Problems when you turn on the computer ........ 123

The Windows

operating system is not

working ........................................................ 125

Using Startup options to fix problems......... 126

Internet problems......................................... 128

The Windows

operating system can

help you.................................................. 129

Fixing a problem with Device Manager ............. 129

Checking device properties ......................... 129

Power and the batteries..................................... 130

Keyboard problems ........................................... 132

Display problems ............................................... 132

Disk or storage drive problems.......................... 134

Error-checking ............................................. 134

Optical disc drive problems............................... 136

Sound system problems.................................... 139

Printer problems ................................................ 139

Wireless networking problems........................... 140

DVD Blu-ray Disc™ operating problems ........... 142

Develop good computing habits........................ 143

Data and system configuration backup in

the Windows

operating system............ 144

If you need further assistance............................ 149

Contacting Toshiba...................................... 150

Other Toshiba Internet Web sites ...................... 150

Toshiba’s worldwide offices .............................. 150

Contents

5.375 x 8.375 ver 2.3

Appendix A: TOSHIBA Function Keys ..................152

Functions ........................................................... 152

Help file ........................................................ 153

Display brightness........................................ 153

Output (Display switch) ............................... 154

Disabling or enabling the touch pad ............ 155

Media buttons.............................................. 155

Volume Mute................................................ 155

Disabling or enabling wireless devices ........ 156

Keyboard Function keys .............................. 156

Zoom (Display resolution) ............................ 156

Appendix B: Power Cord/Cable Connectors........157

Glossary..........................................................158

Index ...............................................................173

Introduction

Welcome to the world of powerful, portable, multimedia computing. With your Toshiba computer, your work and entertainment can accompany you wherever you go.

Your computer is ENERGY STAR

qualified.

To sh i ba is a p ar t ne r i n t he Environmental Protection Agency’s (EPA) ENERGY STAR

Program and has designed

this computer to meet the latest ENERGY STAR

guidelines for energy efficiency. Your computer ships with the power management options preset to a configuration that will provide the most stable operating environment and optimum system performance for both AC power and battery modes.

To conserve energy, your computer’s power management features have been pre-configured to activate the display Sleep mode after 15 minutes of inactivity; the system Sleep mode is activated after 30 minutes of user inactivity. We recommend that you leave these and other energy saving features active, so that your computer will operate at its maximum energy efficiency. You can wake the computer from Sleep mode by pressing the power button. See the “Mobile Computing” section of the Toshiba User’s Guide for more information on using power management settings to conserve computer energy.

Introduction

5.375 x 8.375 ver 2.3

When considering additions to your home office, purchase products that have earned the ENERGY STAR

for all your equipment needs, which can save you money, save energy, and help protect the climate.

Visit http://www.energystar.gov or

http://www.energystar.gov/powermanagement for more

information regarding the ENERGY STAR

Program.

This computer is compatible with European Union Directive 2011/65/EU, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment (RoHS), which restricts use of certain chemicals including, but not limited to, lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its computer component suppliers to meet RoHS requirements and verifies its suppliers’ commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.

Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

NOTE

Introduction

This guide

5.375 x 8.375 ver 2.3

The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba’s Web site at support.toshiba.com.

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at

support.toshiba.com.

This guide

This guide introduces the computer's features as well as some basic procedures needed to perform tasks in Windows 8.1.

Yo u c an :

❖ Read the entire guide from beginning to end. ❖ Skim through and stop when a topic interests you. ❖ Use the table of contents and the index to find specific

information.

NOTE

Introduction

Safety icons

5.375 x 8.375 ver 2.3

Safety icons

This manual contains safety instructions that must be observed to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and icons highlight these instructions as follows:

Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

Indicates a potentially hazardous situation which, if not avoided, may result in property damage.

Provides important information.

Other icons used

Additional icons highlight other helpful or educational information:

TECHNICAL NOTE: This icon indicates technical information about the computer.

HINT: This icon indicates helpful hints and tips.

DEFINITION: This icon indicates the definition of a term used in the text.

NOTE

Introduction

Documentation

5.375 x 8.375 ver 2.3

Your c o mpute r’s feat ures a nd sp e cific ation s

Certain computer chassis are designed to accommodate all possible configurations for an entire product Series. Your select model may not have all the features and specifications corresponding to all of the icons or switches shown on the computer chassis, unless you have selected all those features.

This information applies to all the features and icons described in this guide.

Below are examples of some of the many possible icons used on your computer:

(Sample Illustration) System icons

Documentation

Yo ur co mp u te r c om e s wi t h t he f o ll ow i ng do cu m en ta t io n:

❖ An electronic version of the User’s Guide (this document) ❖ A Quick Start document ❖ It may also include other documentation

For accessory information, visit Toshiba’s Web site at

accessories.toshiba.com.

Service options

Toshiba offers a full line of service programs to complement its standard limited warranty. Toshiba’s standard limited warranty, extended warranty, and service upgrade terms and conditions are available at warranty.toshiba.com.

To s t ay cu r re nt o n t he mo st r ec e nt s of tw a re a nd h a rd wa re options for your computer, and for other product information, be sure to regularly check the Toshiba Web site at

support.toshiba.com.

If you have a problem or need to contact Toshiba, see “If

Something Goes Wrong” on page 122.

Chapter 1

Getting Started

This chapter provides tips for using your computer effectively, summarizes how to connect components, and explains what to do the first time you use your computer.

Please read the safety instruction information on the Quick Start document (that shipped with your computer) carefully and make sure you fully understand the instructions before you attempt to use your computer in order to avoid potential hazards that could cause bodily injury, property damage, or damage the computer.

Selecting a place to work

Yo ur co mp u te r i s p or t ab le an d d es ig n ed t o b e u se d i n a variety of circumstances and locations.

Setting up a work environment

Place the computer on a hard flat surface that is large enough for the computer and any other items you are using, such as a printer. Leave enough space around the computer and other equipment to provide adequate ventilation. Otherwise, they may overheat.

To k ee p yo u r co mp ut e r in p ri me o p er at in g c on d it i on , pr o te ct your work area from:

❖ Dust, moisture, and direct sunlight.

Getting Started

Selecting a place to work

❖ Equipment that generates a strong electromagnetic field,

such as stereo speakers (other than speakers that are connected to the computer) or speakerphones.

❖ Rapid changes in temperature or humidity and sources

of temperature change such as air conditioner vents or heaters.

❖ Extreme heat, cold, or humidity. ❖ Liquids and corrosive chemicals.

Keeping yourself comfortable

This section provides information for setting up your work environment and tips for working comfortably throughout the day.

Computer user comfort recommendations

Good Working Posture

❖ Adjust your chair height: your feet should be flat on the

floor and the bottom of your thighs should be evenly supported by the seat. If your feet cannot reach the floor, use a foot rest. Avoid pressure points behind the knee or under the thigh.

❖ The space under your desk should be free of clutter so

that your legs and feet are not restricted, and you can get close enough to your notebook and other items that you use frequently.

❖ Adjust the chair back rest: it should match the curve of

your back and provide comfortable back support.

❖ Adjust the chair arm rests: they should be about the

same height as the keyboard and comfortably support your arms, allowing your shoulders to relax.

❖ When using the keyboard, it should be centered in front

of you.

❖ The keyboard and pointing device should be close to

your elbow level. The keyboard should be flat so that your wrists are straight when typing. However, if the notebook is on a work surface that is above your elbow height you may need to slope the notebook to keep your wrists straight.

❖ Work with relaxed shoulders.

Getting Started

Selecting a place to work

❖ When typing, keep your wrists straight and try not to rest

your wrists on the notebook. Support your arms on your forearm area. The forearms can be supported by the chair arm supports or the desk surface.

❖ The notebook display should be tilted so that the image

on the screen is clear.

❖ Avoid glare: position the notebook so that light sources

(lamps or windows) do not shine or reflect directly into your eyes. Place the notebook display away from bright light sources or reduce the light intensity from windows by using blinds. Glare on the notebook display may cause eye strain, eye fatigue or headaches.

❖ Certain notebook displays have a brightness

approaching that of a TV device. We recommend that you adjust the brightness of your notebook display to a comfortable level to prevent possible eye strain.

❖ Keep your head level, facing forward and balanced over

your torso.

❖ Adjust the font size of text on your screen to make

viewing comfortable.

❖ Rest your eyes periodically by focusing on objects that

are farther away.

Using the notebook with an external keyboard, mouse or monitor

(Sample Illustration) Correct posture

Getting Started

Selecting a place to work

❖ When using a notebook for long hours, it may be more

comfortable to dock the notebook and use an external keyboard, mouse and monitor.

❖ The keyboard and mouse (or trackball) should be close

to your elbow level.

❖ The mouse should be next to the keyboard to avoid a

reach. If you have to reach, the arm should be supported in the forearm area by the desk surface or the chair arm supports.

❖ Alternative keyboards, such as the split curved

keyboard, may improve shoulder and arm comfort.

❖ Select a mouse that is comfortable for you to use. ❖ Don’t rest your wrists on the edge of the keyboard or on

the work surface when typing.

❖ The monitor should be about an arm length away while

sitting back in the chair.

❖ The monitor should be centered in front of your body. ❖ The top of the monitor should be at or slightly below eye

level. A monitor that is too high or too low can cause awkward head and neck postures and may lead to discomfort in the neck muscles.

❖ If you use bifocals you may need to lower the monitor.

Alternatively, you might consider customized prescription computer glasses.

Typing s tyle

❖ Learn to touch type so that you don’t have to look down

at the keyboard.

❖ Type with straight wrists. ❖ Type lightly. ❖ Learn the keyboard shortcuts for your applications. You

will be more productive.

❖ Use the pointing device (e.g., touch pad, Accupoint

, or tablet pen whichever is available with your notebook computer, or other optional pointing devices like mouse or trackball) with a comfortable hand posture. Avoid awkward hand postures or high gripping force.

❖ It is helpful to change the type of pointing device that

you use on a regular basis to avoid working in just one hand posture.

Getting Started

Selecting a place to work

Taking breaks and varying tasks

❖ Change the way you work so that you are not stuck in

the same posture for long periods of time. Some people find it comfortable to occasionally stand while using the notebook. To do this properly, the notebook needs to be on an elevated surface. Make sure you follow the Good Working Posture points mentioned above while working.

❖ Take short, strategically spaced rest breaks to avoid eye

strain and body fatigue. For example, stand up and walk around or stretch for a few minutes every hour.

❖ Ta ki n g re gu la r b re ak s i s e sp e ci a ll y i mp or ta n t i f y ou ar e

working long hours on your computer or working on a deadline.

❖ If stress at work is affecting your health, try to identify

the sources of the stress and evaluate ways to reduce the stress.

Mobile computing tips

❖ When using the notebook at airports, on airplanes or

trains, or at meetings, make sure that you take the time to consider the points just mentioned.

❖ When working on the road it may be difficult to set up

the notebook in an optimal position. In these situations it is important that you take frequent breaks and change your posture frequently to relieve the excess loads on your body.

❖ Be creative, when in a hotel room, use a rolled up

blanket or pillows to provide back support, or to provide arm support. To position the computer at a good height, remember to operate the computer on a hard flat stable surface. Using your computer on a carpet, blanket or other soft materials can block the air vents including those located at the base of the computer and possibly cause overheating of your computer.

Transporting the notebook

Although your notebook is light, carrying it for a long time may lead to shoulder and arm fatigue. If you carry your notebook with other items, consider using an ergonomicallydesigned computer case.

Getting Started

Selecting a place to work

Seeking additional help

Follow the advice from your employer’s company health and safety staff. Contact them if you need assistance making adjustment to your workstation or adjusting the lighting.

Again, if you experience persistent or recurrent pain, ache, numbness, burning, or stiffness you should promptly see a qualified health care provider. These sensations may be caused by serious medical conditions that can be treated.

For more specific recommendations on the safety and comfort of your computer environment, customers in the United States may visit the United States Department of Labor, Occupational Safety & Health Administration Web site at:

http://www.osha.gov/SLTC/etools/computerworkstations/

Check list

❏ Is your chair comfortable - does it support your back and

arms well?

❏ Are your feet flat on the ground? ❏ Is there adequate space under your desk for your legs? ❏ Are the keyboard and mouse at elbow level? ❏ Are your shoulders relaxed when using the keyboard? ❏ Are your shoulders relaxed when using a mouse or other

optional pointing device?

❏ Are your hands and wrists aligned in a comfortable,

straight posture?

❏ Are your arms supported in the forearm area (not at the

wrist)?

❏ Do you hold the mouse or trackball with a loose, relaxed

hand?

❏ Do you use a light touch when typing or using the

mouse?

❏ Do you clean your mouse or trackball regularly? ❏ Is the top of your monitor close to eye level? ❏ Is the monitor about an arm length away? ❏ Have you eliminated the glare on the monitor? ❏ Is the monitor tilted so that it is easy to read? ❏ Do you change postures regularly? ❏ Do you take breaks, at least once an hour?

Getting Started

Selecting a place to work

Precautions

Your computer is designed to provide optimum safety and ease of use, and to withstand the rigors of travel. You should observe certain precautions to further reduce the risk of personal injury or damage to the computer.

❖ Avoid prolonged physical contact with the underside or

surface of the computer.

Never allow any liquids to spill into any part of your computer, and never expose the computer to rain, water, seawater or moisture. Exposure to liquid or moisture can cause electric shock or fire, resulting in damage or serious injury. If any of these eventualities should accidentally occur, immediately:

1. Turn off the computer.

2. Disconnect the AC adaptor from the power plug socket and computer.

3. Remove the battery pack, if applicable. Failure to follow these instructions could result in serious

injury or permanent damage to the computer. Do not turn on the power again until you have taken the

computer to an authorized service center.

❖ Avoid prolonged physical contact with the underside

or surface of the computer.

❖ Computer base and palm rest can become hot! Avoid

prolonged contact to prevent heat injury to skin.

To da y ’s p er fo r ma n ce c o mp u te r s ge n er at e h ea t u nd er n o rm a l operating conditions, as a function of system activity. Avoid extended contact between the computer base or palm rest and your skin. Under certain operating conditions such prolonged contact between the computer base or palm rest and your skin may result in skin irritation and/or heat injury.

Getting Started

Selecting a place to work

Consider using a hard computer insulating pad or similarly suitable hard insulating material when using a computer on your lap.

Never place a heavy object on the computer and be careful not to drop a heavy object onto the computer. It could damage the computer or cause system failure.

❖ Never turn off the computer if a drive light indicates a

drive is active. Tur ni ng o ff th e co mp ut er w hi le i t is r ea di ng f rom o r

writing to a disk/disc or flash media may damage the disk/disc or flash media, the drive, or both.

❖ Keep the computer and disks away from objects that

generate strong magnetic fields, such as large stereo speakers.

Information on some disks is stored magnetically. Placing a magnet too close to a disk can erase important files.

Handle discs carefully. Avoid touching the surface of the disc. Grasp it by its center hole and edge. If you handle the disc incorrectly, you could damage the disc and possibly lose data.

❖ Scan all new files for viruses.

This precaution is especially important for files you receive via email or download from the Internet. Occasionally, even new programs you buy from a supplier may contain a computer virus. You need a special program to check for viruses.

Getting Started

Setting up your computer

Important information on your computer’s cooling fan

Your computer may have a CPU cooling fan that cools the CPU by drawing outside air into the computer.

Always make sure your computer and AC adaptor have adequate ventilation and are protected from overheating when the power is turned on or when an AC adaptor is connected to a power outlet (even if your computer is in Sleep mode). In this condition, observe the following:

❖ Never cover your computer or AC adaptor with

any object.

❖ Never place your computer or AC adaptor near a

heat source, such as an electric blanket or heater.

❖ Never cover or block the air vents including those

located at the underside of the computer.

❖ Always operate your computer on a hard flat

surface. Using your computer on a carpet or other soft material can block the vents located at the underside of the computer.

Overheating your computer or AC adaptor could cause system failure, computer or AC adaptor damage or a fire, possibly resulting in serious injury.

The cooling fan location will vary depending on the computer.

Setting up your computer

TECHNICAL NOTE: You must complete all setup steps up to and including “Setting up your software” on

page 42 before adding external or internal components

to your computer. These components include, but are not limited to, a mouse, keyboard, and printer.

Your computer contains a rechargeable main battery that needs to be charged before you can use it.

To u s e e xt e rn al po w er or t o ch a rg e th e b at t er y y o u m us t attach the AC adaptor. See “Connecting to a power source”

on page 40.

NOTE

Getting Started

Connecting to a power source

Please handle your computer carefully to avoid scratching or damaging the surface.

Connecting to a power source

Your computer requires power to operate. Use the power cord/cable and AC adaptor to connect the computer to a live electrical outlet, or to charge the computer’s battery.

Never pull on a power cord/cable to remove a plug from a socket. Always grasp the plug directly. Failure to follow this instruction may damage the cord/cable, and/or result in a fire or electric shock, possibly resulting in serious injury.

Always confirm that the power plug (and extension cable plug if used) has been fully inserted into the socket, to ensure a secure electrical connection. Failure to do so may result in a fire or electric shock, possibly resulting in serious injury.

Be careful if you use a multiple connector. An overload on one socket could cause a fire or electric shock, possibly resulting in serious injury.

Always use the TOSHIBA AC adaptor that was provided with your computer, or use AC adaptors specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor could cause fire or damage to the computer possibly resulting in serious injury. TOSHIBA assumes no liability for any damage caused by use of an incompatible adaptor.

To c o nn e ct AC po we r to th e c om p ut e r:

1 Connect the power cord/cable to the AC adaptor.

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

NOTE

Getting Started

Charging the main battery

2 Plug the AC adaptor cord into the DC-IN on the side of

the computer.

To lo c a t e y o u r D C - I N p o r t, p l ea s e r e f er t o y o u r Q u i c k Start document.

3 Connect the power cord/cable to a live electrical outlet.

The AC power light on the indicator panel glows white.

Never attempt to connect or disconnect a power plug with wet hands. Failure to follow this instruction could result in an electric shock, possibly resulting in serious injury.

The computer’s main battery light gives you an indication of the main battery’s current charge:

❖ Glows amber while the main battery is being charged

(AC adaptor connected)

❖ Glows white when the main battery is fully charged ❖ Is unlit when the main battery has discharged, the

battery is not charging, or the AC adaptor is not plugged into the computer or AC outlet

❖ Flashes amber when the main battery charge is low

and it is time to recharge the main battery or plug in the AC adaptor

If the AC power light flashes amber during charging, either the main battery is malfunctioning, or it is not receiving correct input from the AC power supply.

Charging the main battery

The computer battery may not be accessible by the user.

Before using the battery to power the computer, you must charge the battery.

To c h ar ge t h e b at t er y, l ea ve th e c o mp u te r p l ug g ed i nt o a n AC power source with the computer turned off until the battery light glows white. After that, the battery will be completely charged and ready to power the computer.

NOTE

Getting Started

Using the computer for the first time

Battery life and charge time may vary depending on the applications power management settings, and features used.

Using the computer for the first time

The computer is now ready for you to turn it on and begin using it, see “Exploring Your Computer’s Features” on

page 96.

When opening or closing the display panel, place one hand on the palm rest to hold the computer in place and use the other hand to slowly open or close the display panel.

To av o i d d a m a g in g t he d i sp l ay p a ne l , d o no t f o rc e it beyond the point where it moves easily and never lift the computer by the display panel.

Do not press or push on the display panel and be careful to remove any pens or other objects from the keyboard area before closing the display panel.

Initial setup

The Startup screen is the first screen displayed when you turn on your computer for the first time. Follow the on-screen instructions on each screen in order to properly install the operating system and begin using your computer.

Setting up your software

When you turn on the computer for the first time, do not turn off the power again until the operating system has loaded completely.

The names of windows displayed, and the order in which windows appear, may vary according to your software setup choices.

NOTE

Getting Started

Registering your computer with Toshiba

The first time you turn on your computer, the setup guides you through steps to set up your software. Follow the onscreen instructions.

Registering your computer with Toshiba

Product registration is strongly recommended, and allows To sh i ba to se n d y ou pe ri od ic up d at es , an n ou n ce m en ts , a n d special offers applicable to your Product. Product registration can be completed by one of three methods:

1 From the Toshiba Web site at register.toshiba.com: Type

in the requested information and complete the registration process.

2 From the Start screen: Type

Registration while in the

Start screen, locate and complete the registration process.

3 From the Desktop: Press the

Windows

( ) key to

display the Start screen. Click or touch the

Search ( )

icon at the upper-right corner of the screen and, in the Search field, type

Registration. In the list that appears,

click or touch

Registration and complete the

registration process.

Failure to complete Product Registration will not diminish your rights under the Toshiba Standard Limited Warranty.

To re g i s te r o nl i n e , a n In t er n e t co n n e ct i o n i s r eq u i re d .

To Shut down your compute r

1 Press the Windows® ( ) key to display the Start

screen.

Pressing the power button before shutting down the Windows



operating system could cause you to lose your work. Make sure the system indicator panel’s storage drive light and the drive in-use light are off. If you turn off the power while a disk/disc is being accessed, you may lose data or damage the disk/disc and/or drive.

NOTE

Getting Started

To R e st ar t y ou r c om p ut e r

2 Click or touch the Power ( ) icon at the upper-right

corner of the screen.



(Sample Image) Shut down

To pe r f o rm a H yb r i d s h u t d o w n , ( i n s te a d of p e r fo r m i ng a Shut down), click or touch the

Shut down option but do

NOT hold the Shift key.

3 Highlight

Shut down while holding the Shift key, and

then click or touch the

Shut down option.

The computer closes all open applications, shuts down the operating system, and then turns off.

To Rest art y our c omput er

1 Press the Windows® ( ) key to display the Start

screen.

2 Click or touch the

Power ( ) icon at the upper-right

corner of the screen.



(Sample Image) Restart

3 Highlight Restart, and then click or touch the Restart

option. The computer closes all open applications, and restarts

the operating system.

Shut down option

NOTE

Restart option

Getting Started

To p l ac e y ou r c om p ut er in S l ee p m od e

To plac e you r computer in Slee p mod e

1 Press the Windows® ( ) key to display the Start

screen.

If you power down using the Sleep command and the battery discharges fully, your unsaved information will be lost. Be sure to save your work first.

2 Click or touch the

Power ( ) icon at the upper-right

corner of the screen.



(Sample Image) Sleep

3 Highlight Sleep, and then click or touch the Sleep

option. Sleep mode saves the current state of the computer to

memory so that, when you restart the computer, you can continue working from where you left off.

Adding optional external devices

Before adding external devices, Toshiba recommends setting up your software. See “Setting up your software”

on page 42.

After starting your computer for the first time you may want to:

❖ Connect external devices (see “Connecting an external

device” on page 60)

❖ Connect an external monitor (see “Using external

display devices” on page 61)

Sleep option

NOTE

Getting Started

Adding memory

Yo ur co mp u te r c om e s wi t h en o ug h m em o ry t o r un mo st of today’s popular applications. Toshiba will not be responsible for any product damage, data loss, service or part replacement made necessary by improper installation of a memory module.

Recovering the Internal Storage Drive

To pu r c h as e a n o p t io n a l ex t e r na l w r i ta b le o p ti c a l d i sc drive, visit the Toshiba Web site at

accessories.toshiba.com.

Yo ur co mp u te r i nc l ud e s re c overy utilities to allow you to recover your internal storage drive if necessary.

The following internal storage drive recovery options are available:

A recovery image of your computer is stored on the internal storage drive, and the image can be restored by running the recovery utilities directly from your internal storage drive as described in the sections below. However, it is strongly recommended that you create recovery media. If the recovery files on your internal storage drive become corrupted or are deleted, you can restore your system from your recovery media. Also, if your original internal storage

Recovery option Description

Creating recovery media

This option allows you to create the recovery media you will use to restore your computer.

See “Creating recovery media” on page 47.

Restoring from recovery media

This option allows you to restore your system from the recovery media you created.

See “Restoring from recovery media” on page 50.

Refresh your PC (with user’s data)

This option allows you to refresh your system without losing your data.

See “Refresh your PC (with user’s data)” on

page 51.

Reset your PC This option allows you to remove all data from your

system and reinstall Windows

See “Reset your PC” on page 53.

NOTE

Getting Started

Recovering the Internal Storage Drive

drive fails, you can restore your system to a new internal storage drive from your recovery media. It is strongly recommended that you create recovery media before using your system for the first time. See “Creating recovery media”

on page 47 and “Restoring from recovery media” on page 50.

❖ During the recovery process your computer must be

connected to an external power source via the AC adaptor.

❖ When you restore your system, only the operating

system files and drivers originally shipped with the computer are restored. Any files that you created are not restored during this process. Be sure to separately save the files you have created to external media using Windows

or another backup program. For more information, see “Backing up your work” on

page 72.

Creating recovery media

It is strongly recommended that you create recovery media. If the recovery files on your internal storage drive become corrupted or are deleted, you can restore your system from your recovery media. Also, if your original internal storage drive fails, you can restore your system to a new internal storage drive from your recovery media.

During the recovery process your computer must be connected to an external power source via the AC adaptor.

When you create recovery media, only the operating system files and drivers originally shipped with the computer are backed up to the external media and can be restored from this media. Any files that you created are not backed up on the recovery media. You will need to separately back up the files you created; for more information, see “Backing up your work” on page 72.

NOTE

Getting Started

Recovering the Internal Storage Drive

When you create recovery media, the system will prompt you to insert several blank DVDs or connect one or more USB flash drives of a certain minimum capacity to your computer. The amount of space required for storing the recovery files varies by computer model. Follow the procedure below to determine how much space you will need for storing your system’s recovery files.

To c re at e re co ve r y m ed i a:

1 From the Start screen begin typing

Recovery Media

Creator

and click or touch your selection. If you are in

the Desktop, press the

Windows

( ) key to display the

Start screen. Click or touch the

Search ( ) icon at the

upper-right corner of the screen and, in the Search field, type

Recovery Media Creator. In the list that appears,

click or touch your selection. The TOSHIBA Recovery Media Creator dialog box

displays.



(Sample Image) TOSHIBA Recovery Media Creator dialog box

An optional external writable optical disc drive must be connected to your computer in order for the DVD option to display in the dialog box.

2 Select

DVD or USB Flash from the drop-down list,

depending on the type of external media you want to use.

NOTE

Getting Started

Recovering the Internal Storage Drive

3 Check the “Information” area of the dialog box to

determine the number of DVDs you will need and/or the minimum amount of storage space required for copying your system’s recovery files to USB flash drive(s).

4 Do one of the following:

❖ If you are copying files to DVD, insert a blank DVD

into the optional external writable optical disc drive.

❖ If you are copying files to a USB flash drive, connect

a USB flash drive of the required minimum capacity (as specified in the TOSHIBA Recovery Media Creator utility) to your computer.

All information stored on your DVDs or USB flash drive(s) will be erased during the process of creating the recovery media. Be sure to save the information stored on your external media to another storage device before executing this procedure, or use blank media.

5 Click or touch the

Create button in the TOSHIBA

Recovery Media Creator utility dialog box.

6 Follow the on-screen prompts to complete the copy

process.

If you are copying the recovery files to DVDs, be sure to label each DVD in the set sequentially (for example, “1 of 3,” “2 of 3,” etc.), so that you will know in which order to insert the discs during recovery.

For information on using the Recovery media you have created with the preceding steps, see “Restoring from

recovery media” on page 50.

NOTE

Getting Started

Recovering the Internal Storage Drive

Restoring from recovery media

The recovery process deletes information stored on the internal storage drive. Be sure to save your work to external media before executing the recovery (see

“Backing up your work” on page 72).

During the recovery process your computer must be connected to an external power source via the AC adaptor.

If you have created recovery media for your system, you can restore your system from such media, if necessary. For example, if your original internal storage drive fails, you can restore your system to a new internal storage drive from your recovery media. For instructions on creating recovery media, see “Creating recovery media” on page 47.

When you restore your system, only the operating system files and drivers originally shipped with the computer are restored. Any files that you created are not restored during this process. Be sure to separately save the files you have created to external media using Windows

or another backup program. For more

information, see “Backing up your work” on page 72.

To r ec ov er yo u r i nt e rn al st o ra g e d ri ve f r om re co ve r y m ed i a:

1 Make sure your computer is turned off. 2 Do one of the following:

❖ If your recovery files are on DVDs, insert the first

recovery DVD into your optional external writable optical disc drive.

❖ If your recovery files are on a USB flash drive,

connect the USB flash drive to your computer.

3 Turn on your computer while pressing the

F12 key on

your keyboard. The Boot menu displays.

4 Using the arrow keys, select the

DVD option or the USB

Flash option, depending on which type of media you are

using, and then press the ENTER key.

NOTE

Getting Started

Recovering the Internal Storage Drive

5 A warning screen appears, stating that when the

recovery is executed all data on your internal storage drive will be deleted and rewritten. Click or touch

Yes to

continue.

6 Follow the on-screen instructions to complete the

recovery process. When the process is complete, a message displays

indicating that the drive has been recovered.

7 Click or touch

Finish to restart the computer.

Refresh your PC (with user’s data)

Using “Refresh your PC” recovers your Windows® installation to an earlier state while attempting to keep your data and apps you installed from the Windows

Store. Your PC settings and any Desktop Applications installed from media or websites will be deleted. Toshiba does not guarantee that your data will not be deleted during the Refresh process. Please make a back up of your data to external media before executing this process. For more information, see “Backing up your

work” on page 72.

During the recovery process your computer must be connected to an external power source via the AC adaptor.

Yo u c an r e co v er th e f ac t or y d ef a ult software (refresh your PC), while the computer will attempt to back up your data using the utilities stored on your computer’s internal storage drive:

TECHNICAL NOTE: Your data will be copied into the backup folder. All of the data will be moved to this folder during the recovery process, however the current directory structure will be retained.

1 From the Start or Desktop screen, move your pointer to

the upper-right corner of the screen or swipe in from the right edge.

2 When the Windows

charms appear click or touch the

Settings ( ) charm.

NOTE

Getting Started

Recovering the Internal Storage Drive

3 Click or touch Change PC Settings.

The PC settings window appears.

(Sample Image) PC settings screen

4 Click or touch Update and recovery. 5 Click or touch

Recovery.

6 Select

Refresh your PC without affecting your files,

and click or touch

Get Started.

The “Refresh your PC” screen appears.

(Sample Image) Refresh your PC screen

To s hi b a d o e s n o t g u a r a nt e e s u c c es s fu l da t a ba c k u p . B e sure to save your work to external media before executing the recovery (see “Backing up your work” on

page 72).

Getting Started

Recovering the Internal Storage Drive

7 Click or touch the Next button to begin.

The “Ready to refresh your PC” screen appears.

(Sample Image) Ready to refresh your PC screen

Yo u w il l b e p ro m pt e d t o re fr es h y ou r s ys t em .

8 Click or touch the

Refresh button.

9 You r s ys t em wi ll re s ta r t.

The “Refreshing your PC” window appears. When the process is complete your system will reboot your Windows

operating system.

Reset your PC

The recovery process deletes information stored on the internal storage drive. Be sure to save your work to external media before executing the recovery (see

“Backing up your work” on page 72).

During the recovery process your computer be must connected to an external power source via the AC adaptor.

1 From the Start or Desktop screen, move your pointer to

the upper-right corner of the screen or swipe in from the right edge.

2 When the Windows

charms appear click or touch the

Settings ( ) charm.

NOTE

Getting Started

Recovering the Internal Storage Drive

3 Click or touch Change PC Settings.

The PC settings window appears.

(Sample Image) PC settings screen

4 Click or touch Update and recovery. 5 Click or touch

Recovery.

6 Select

Remove everything and reinstall Windows,

and click or touch

Get Started.

The “Reset your PC” screen appears.

(Sample Image) Reset your PC screen

Getting Started

Recovering the Internal Storage Drive

7 Click or touch the Next button.

The “Do you want to fully clean your drive?” screen appears.

(Sample Image) Do you want to fully clean your drive screen

8 Select one of the following options:

❖

Just remove my files

❖ Fully clean the drive

The “Ready to reset your PC” screen appears.

(Sample Image) Ready to reset your PC screen

9 Click or touch the Reset button.

The “Resetting your PC” window appears. When the process is complete your system will reboot your Windows

operating system.

Getting Started

Recovering the Internal Storage Drive

Selecting the “Fully clean the drive” option may take several hours.

Installing drivers and applications

The TOSHIBA Application Installer allows you to reinstall the drivers and applications that were originally bundled with your computer.

Yo u mu s t h av e a n I n t e r n et c o n ne c t i on to re i n s ta l l applications.

To r ei ns ta l l d ri ve rs a n d a pp l ic a ti o ns :

1 From the Start screen begin typing

TOSHIBA

Application Installer

and click or touch your selection.

If you are in the Desktop, press the

Windows

( ) key

to display the Start screen. Click or touch the

( ) icon at the upper-right corner of the screen and, in the Search field, type

TOSHIBA Application Installer.

In the list that appears, click or touch your selection.



(Sample Image) Installing drivers and applications

2 Click or touch Next. 3 Click or touch the item you want to install. 4 Click or touch

Install.

5 Follow the on-screen prompts to complete the

installation process, see “TOSHIBA Application Installer”

on page 121.

NOTE

Search field

Getting Started

Using the touch pad

Some of the touch pad operations described in this section are only supported in certain applications, and only on certain models.

You can use the touch pad (the small, touch-sensitive area in front of the keyboard) and the adjacent control buttons to:

❖ Move the pointer on the screen ❖ Select an item on the screen ❖ Open or activate an item on the screen ❖ Scroll through a document or information ❖ Zoom in for a close-up view ❖ Zoom out to see more information at once



(Sample Illustration) The touch pad and associated control buttons

Refer to the table below for specific instructions on performing each operation.

The

pointer

is the icon (usually an arrow) that moves on the screen when you slide your finger across the touch pad or move a mouse connected to your computer.

NOTE

To u c h p a d

Secondary control buttonPrimary control button

NOTE

Getting Started

Using the touch pad

To: Do t he follo w i ng: Exam p l e:

Move the onscreen pointer

Slide your finger across the touch pad in the direction you want to move the pointer.

To mo v e th e p o in t e r a l o ng e r distance, slide your finger several times across the touch pad in the preferred direction.

(Sample Illustration) Pointer moves to the right

Select an item 1 Move the pointer to the item

you want to select.

2 Do one of the following:

❖ Ta p t he to u ch pa d o n ce

❖ Press and release the

primary (left-hand) control button

(Sample Illustration) Ta p o n c e t o s e l e ct

Open or activate an item

1 Move the pointer to the item

you want to open/activate.

2 Do one of the following:

❖ Ta p th e to u ch p ad t w ic e

in rapid succession

❖ Press and release the

primary control button twice in rapid succession

(Sample Illustration) Ta p t w i ce t o o p e n

Right-click an item

1 Move the pointer to the item

you want to right-click.

2 Press and release the

secondary control button.

This feature varies by program. Check your program documentation for specific instructions on right-clicking.

(Sample Illustration) Click the secondary (right-hand) control button

Scroll vertically Slide your finger along the right

edge of the touch pad in the direction you want to scroll. Repeat to scroll a longer distance.

(Sample Illustration) Vertical scrolling active area

Getting Started

Using the touch pad

Adjusting touch pad settings

While you are typing, the on-screen pointer may seem to move or jump around “by itself” to random locations on the screen. The on-screen pointer may also seem to automatically select text, click buttons, and activate other user interface elements. For help with these problems, try one or more of the following:

❖ Try adjusting your typing technique to avoid accidental

contact with the touch pad. You may be inadvertently brushing the touch pad with the heel of your hand as you type. Also, accidental light touches or taps on the touch pad may select an item or text on the screen, and potentially the item or text may be replaced by the next character you type.

Scroll horizontally

Slide your finger along the bottom edge of the touch pad in the direction you want to scroll. Repeat to scroll a longer distance.

(Sample Illustration) Horizontal scrolling active area

Zoom in/out To zoom in:

❖ Place two fingers close

together on the touch pad and then slide them apart.

To zo o m o ut :

❖ Place two fingers slightly

apart on the touch pad and then slide them together.

(Sample Illustration) Zooming in

(Sample Illustration) Zooming out

To: Do t he follo w i ng: Exam p l e:

Getting Started

Using the touch pad

❖ Te mp o ra ri ly d i sa b le th e t o uc h p a d, so th a t i t d oe s n o t

respond to touch or button presses while you type. See

“Disabling or enabling the touch pad” on page 60.

❖ Adjust the sensitivity of the touch pad, so that it is less

responsive to accidental light taps and lighter finger pressure.

To u ch p a d s e t t in g o pt i on s v ar y b y c o m p ut e r mo d e l . T he touch pad settings are accessible through the Mouse Properties option of the Windows Control Panel. For more information, please visit support.toshiba.com.

Disabling or enabling the touch pad

The touch pad is enabled by default. To enable/disable the touch pad, press

F5. For more information, see “Disabling or

enabling the touch pad” on page 155.

Connecting an external device

Depending on your system, some models may include USB 3.0 port(s). To distinguish these ports, please look for the blue inset within the USB 3.0 port (if available).

Yo u c an e a si ly at t ac h a n e xt er n al d ev i ce yo ur co mp u te r. To do this:

1 Read the directions that came with the device to see if

you first need to install new software.

2 Connect the device’s video or USB cable to the port on

the computer and to the device.

3 Connect the device’s power cable to a live electrical

outlet (if applicable).

4 Tur n on t he ext er na l de vi ce ( if a pp li ca bl e) .

Yo ur co mp u te r m ay au t om at i ca ll y d e te ct th e e xt er n al device.

NOTE

Getting Started

Using external display devices

Yo ur co mp u te r c om e s wi t h a b ui l t- in di s pl ay , b ut yo u c an also connect the following types of external display devices to the video ports described below:

To lo c a t e y o u r H D M I ™ o r RG B p or t , p l e as e r ef e r to y o ur Quick Start document.

❖ An HDMI™-compatible television or external display

device via the HDMI™ Out port*

❖ An external monitor or projector via the RGB (monitor)

port*

(Sample Illustration) Video ports on right side of computer

Selecting video cables

To c o nn e ct a d ev i ce to th e H D MI ™ Ou t p or t, yo u m u st purchase an HDMI™ cable.

Connecting an HDMI™-compatible television or display device

To c o nn e ct an HD M I™ - co mp at ib l e t el e vi s io n o r d i sp la y device to the computer:

❖ Connect one end of an HDMI™ cable (not included with

your computer) to the HDMI™ Out port on the side of your computer, and then connect the other end of the cable to your television or display device. Refer to the manual that came with the television or display device for more information.

Yo ur co mp u te r s ho u ld a u to ma t ic a ll y d et ec t t h e ex t er na l display device.

NOTE

HDMI™ Out port* RGB (monitor) port*

*Available on certain models

Getting Started

Using external display devices

Connecting an external monitor or projector

Yo u ca n e a si ly a tt a ch a n e xt e rn al m on it o r o r p ro je c to r t o y ou r computer if you need a larger screen. To do this:

1 Read the directions that came with the monitor to see if

you first need to install new software.

2 Connect the monitor’s video cable to the RGB (monitor)

port on the side of the computer.

3 Connect the device’s power cable to a live electrical

outlet.

4 Tur n on t he e xt er nal d ev ic e.

Yo ur co mp u te r w il l a u to ma t ically detect the external display device.

Yo u ca n c h an g e t he d i s pl a y s et t i n g s b y p re s s i ng t h e () +

P keys, or by configuring the display properties

settings.

Directing the display output when you turn on the computer

Once you have connected an external display device, you can choose to use the internal display only, the external device only, or both simultaneously.

Some modes are only available with the appropriate device attached and turned on.

The quickest way to change the display output settings is to use the ( ) +

P keys:

Press the ( ) +

P keys repeatedly until the setting you want

takes effect. Briefly pause each time you press the ( ) +

keys to allow time for the display to change. This cycles through the settings in the following order (the

last two options are available if an external monitor is connected):

❖ PC screen only ❖ Duplicate

NOTE

Getting Started

Using external display devices

❖ Extend ❖ Second screen only



(Sample Image) Display options window

The ( ) + P keys navigate through the options without activating a selection. Press

ENTER to activate a

selection.

Yo u ma y a l so u s e t h e F4 key, and then press ENTER to activate a selection.

Adjusting the quality of the external display

To o b ta i n t he b es t p ic t ur e qu al i ty fr om y ou r t e le v is i on (o r other video display device), you may need to adjust the video settings. See the video device documentation for additional configuration steps.

NOTE

Getting Started

Customizing your computer’s settings

There are several ways in which you can customize your computer to suit your particular requirements. You can go into your computer settings to make adjustments to your computer to suit your needs.

From the Start or Desktop screen, move your pointer to the upper-right corner of the screen or swipe in from the right edge. When the Windows

charms appear, click or touch the

Settings ( ) charm, and then click or touch Change PC Settings

. Then choose a category you wish to change.

Refer to your operating system documentation or Help and Support for details.

You may also wish to customize your power usage settings. For more information, see “Power Plans” on page 87. There are additional custom settings you can choose. See

“Utilities” on page 107.

Caring for your computer

This section gives tips on cleaning and moving your computer. For information about taking care of your computer’s battery, see “Taking care of your battery” on

page 92.

Please handle your computer carefully to avoid scratching or damaging the surface.

Cleaning the computer

Keep liquids, including cleaning fluid, out of the computer’s keyboard, speaker, and other openings. Never spray cleaner directly onto the computer and/or display. Never use harsh or caustic chemical products to clean the computer.

To k e ep yo u r c om p ut e r cl ea n, ge n tl y w i pe th e d i sp la y pa n el and exterior case with a lightly dampened cloth.

NOTE

Getting Started

Caring for your computer

Moving the computer

Before moving your computer, even across the room, make sure all drive activity has ended (the internal storage drive and optical disc drive indicator lights stop glowing) and all external peripheral cables are disconnected.

Do not pick up the computer by its display panel or by the back. Doing so could damage the system.

Using a computer lock

Yo u m ay w a nt t o s e cu re yo u r c om pu t er to a he av y o bj e ct such as your desk. The easiest way to do this is to purchase an optional computer lock cable. For more information on purchasing a cable lock, visit accessories.toshiba.com.

(Sample Illustration) Computer lock cable

To s e cu re t he co m pu t er :

1 Wrap the cable through or around some part of a heavy

object. Make sure there is no way for a potential thief to slip the

cable off the object.

2 Pass the locking end through the loop. 3 Insert the cable’s locking end into the security lock slot

on your computer, then engage the locking device.

The computer is now securely locked.

(Sample Illustration) Attaching security lock cable

Chapter 2

Learning the Basics

This chapter gives some computing tips and provides important information about basic features.

Computing tips

❖ Save your work frequently.

Yo ur wo rk st ay s i n t he co mp u te r ’s t e mp o ra ry me m or y

until you save it to the internal storage drive. If the

network you are using goes down and you must restart

your computer to reconnect, or your battery runs out of

charge while you are working, you will lose all work since

you last saved.

See “Saving your work” on page 72 for further

information.

HINT: Some programs have an automatic save feature that can be activated. This feature saves your file to the internal storage drive at preset intervals. See your software documentation for details.

Learning the Basics

Using the keyboard

❖ Back up your files to external media on a regular basis.

Label the backup copies clearly and store them in a safe

place.

It is easy to put off backing up because it takes time.

However, if your internal storage drive suddenly fails, you

will lose all the data on it unless you have a separate

backup copy. For more information, see “Data and

system configuration backup in the Windows®

operating system” on page 144.

❖ Use Error-checking and Disk Defragmenter regularly to

check and optimize disk space and improve

performance.

❖ Scan all new files for viruses.

This precaution is especially important for files you

receive via external media, email, or download from the

Internet.

❖ Take frequent breaks to avoid repetitive-motion injuries

and eyestrain.

❖ Do not turn off the computer if a drive indicator light

indicates a drive is active.

Tur ni ng o ff th e co mp ut er w hi le i t is r ea di ng f rom o r

writing to a disk may damage the disk, the drive, or both.

The Windows operating system records information, such as your desktop setup, during its shutdown procedure. If you do not let the Windows



operating system shut down normally, details such as new icon positions may be lost.

Using the keyboard

Yo u r c om p u t e r m a y be e q u ip p e d wi t h a 1 0 - k e y keyboard, depending on your model.

Your computer’s keyboard contains character keys, control keys, function keys, and special Windows

keys.

NOTE

Learning the Basics

Using the keyboard



(Sample Illustration) Keyboard



(Sample Illustration) 10-key keyboard (Available on certain models)

To ca p t u re a pr i n t s c r ee n o f t h e e n t i re s c re e n , p r e ss th e

Fn + PRTSC key. (This only applies to models with a

10-key keypad.) To ca p t u re o n ly t h e a c t iv e w i n d ow d i sp l ay e d , p r e ss

Fn + ALT while simultaneously pressing the PRTSC key.



(Sample Illustration) PRTSC key on the 10-key keyboard

Function keys

The function keys (not to be confused with the Fn key) are the 12 keys at the top of the keyboard.



(Sample Illustration) Function keys

NOTE

Learning the Basics

Touch screen

F1 through F12 are called function keys because they

execute programmed functions when pressed. Used in combination with the

Fn key, function keys marked with

icons execute specific functions on the computer. For example,

F5 turns the touch pad ON/OFF. For more

information, see “TOSHIBA Function Keys” on page 152.

Special Windows® keys



(Sample Illustration) Special Windows® keys

Yo ur co mp u te r ’s k e yb o ard h as o n e k ey a n d o ne b ut t on th a t have special functions in Windows

❖

Windows® key—Toggles between the Desktop screen

and the last app opened on the Start screen. For more information refer to Help & Support, or see “Exploring

the Start screen” on page 96

❖

Application key—Has a similar function as the

secondary mouse button

Touch s creen

Yo ur co mp u te r m ay co me wi t h a t ou ch sc r ee n , e na bl i ng direct interaction with displayed apps and programs through simple or multi-touch gestures.

Touch sc r een n a vigati o n

Use your finger to manipulate the on-screen icons, buttons, menu items, and other items on the touch screen. You can also change the screen’s orientation.

The screen is made of glass so avoid contact with sharp, rough, or abrasive objects or substances as screen may break or scratch if not handled properly. If you see a crack in the glass, discontinue use of the device to avoid injury.

Application key

Windows

key

Learning the Basics

Mouse properties

Touch—Touch to activate items displayed on the screen,

such as app and setting icons or on-screen buttons. Touch to type using the keyboard.

Touch & hol d —Touch and hold an item on the screen by

touching and holding the item in place until an action occurs.

Drag—Touch and hold an item for a moment and then,

without lifting your finger, move the item until you reach the target position. For example, drag items on any app screen to reposition them.

Swipe or slide—To swipe or slide, quickly move your finger

across the surface of the screen without pausing. For example, swipe your finger to the left from the right edge of the screen to display the Windows

charms.

Double-tap—Tap quickly twice to zoom in. For example,

double-tap a section of a Web page to zoom in on that section. Double-tap again to zoom out.

Pinch—In some apps (such as Maps and Games), you can

zoom in and out by placing two fingers on the screen at once and pinching them together (to zoom out) or spreading them apart (to zoom in).

Rotate—Place two or more fingers on an item and rotate

your hand. The item rotates in the direction you turn your hand. (Not functional in all apps).

Mouse properties

Mouse properties allow you to change your pointing device or mouse settings.

To access Mouse properties:

1 If you are in the Desktop, press the

Windows

( ) key

to display the Start screen. Click or touch the

( ) icon at the upper-right corner of the screen and, in the Search field, type

Mouse. In the list that appears,

click or touch your selection. The Mouse screen appears.

2 Adjust the settings as desired, and then click or touch

OK.

Learning the Basics

Starting an app

To Start an app on the Start screen, move your pointer over the appropriate app tile and click or touch to open.

To S t ar t a n a p p f ro m th e D es k to p , m ov e y o ur p oi nt e r t o t he upper-right corner of the screen or swipe in from the right edge. When the Windows

charms slide out from the right,

click or touch the

Start ( ) charm, and then click or touch

the appropriate app tile to open.

Starting an app from the Start screen

To s t ar t a n a p p o n th e St a rt sc re en , m ov e y o ur po in te r o ve r the appropriate tile and click or touch to open. Swipe your finger to the left or right to reveal more available tiles.

1 To se arc h f or a n a pp u si ng t he A pp s pa ge , cl ic k or t ou ch

the

Down arrow ( ) icon in the lower-left corner of the

Start screen. The Apps screen appears with the available system apps to choose from or you can enter your search in the search field.

(Sample Image) Searching for apps

To re t u r n t h e St a r t s c r ee n , c l i ck o r t o u c h t he Up arrow () icon in the lower-left corner of the screen.

NOTE

Learning the Basics

Saving your work

Before you turn off the computer using the Shut down command, save your work on the internal storage drive, external media, flash media, or optical disc. This is one of the most important rules of computing.

Many applications offer a feature that saves documents at regular intervals. Check your program’s documentation to see if it has an automatic save feature.

Backing up your work

Back up all the files you create in case something happens to your computer. You can back up your files to different types of media such as CDs, DVDs, external storage media, or to a network, if available.

To back up several files at one time, use the Microsoft

Windows

file recovery program preinstalled on the computer’s internal storage drive. Also see “Backing up your

data or your entire computer with the Windows® operating system” on page 146.

HINT: Backing up all the files on your internal storage drive may take a considerable amount of time and multiple CDs/DVDs. You may prefer to use a highcapacity file recovery system, such as an external hard drive.

Using the optical disc drive

(Available on certain models.)

Optical storage is a popular medium for software, music, and video. Digital versatile discs or Blu-ray Discs

™ provide a

significant increase in data storage and support features that were not available on previous video platforms. These features include wide-screen movies, multiple language tracks, digital surround sound, multiple camera angles, and interactive menus.

Learning the Basics

Using the optical disc drive

TECHNICAL NOTE: Your optical disc drive is set to play region 1 (North America) for DVD-ROMs or BD-ROMs, depending on the type of drive. A DVD disc or Blu-ray™ Disc of a region other than the above mentioned cannot be played unless you manually change it in the Properties setting of the optical disc drive. The drive will allow you to change regions four times. On the fourth change, the region will be “locked in.” That is, the drive will only play DVDs and Blu-ray Discs

™ from that last region. Note that

changing from region 1 to region 2 and back to region 1 is counted as two changes.

For optimum DVD and Blu-ray Disc™ performance, it is recommended that you play DVDs and Blu-ray Discs

™

while running the computer on AC power.

When viewing DVD and Blu-ray Disc™ movies use the DVD or Blu-ray Disc™ player software that came with your computer.

Viewing Blu-ray Disc™ movies

(Available on certain models.)

Yo ur sy st e m ma y c om e w i th a Bl u -r ay Di s c™ d r iv e . D ue t o differences between High Definition and previous viewing capabilities, consider the following:

❖ Use an HDCP (High-Bandwidth Digital Content

Protection) HDMI™ cable to view High Definition content via your Blu-ray Disc™ drive on an external monitor or television. The external monitor or television must support HDMI™.

❖ Some Blu-ray Disc™ movies have online content that

can be accessed from the disc. To view this content, your computer must be connected to the Internet.

❖ While viewing online content, your system may not view

it in High Definition on an external monitor, even though your display setting is set to simultaneous. This is due to the lower resolution used in the simultaneous setting. For more information on your computer’s display settings, see “Directing the display output when you turn

on the computer” on page 62.

NOTE

Learning the Basics

Using the optical disc drive

❖ When an HDMI™ cable is used to send a High Definition

signal to an external monitor the audio signal is automatically sent with the video signal. If you want to change the destination of the audio signal, use the Sound properties in the Control Panel.

(Sample Image) Sound properties window

❖ If you want to use the internal speakers, click the

Speakers tab and click Set Default.

❖ Use the arrow keys on your keyboard to navigate within

the Blu-ray Disc™ player console.

Use of the touch pad or a mouse is not supported within the Blu-ray Disc™ player.

Optical disc drive components

The optical disc drive is located on the side of the computer. Yo ur op ti c al di s c dr iv e ma y lo o k l ik e t hi s:



(Sample Illustration) Optical disc drive

NOTE

Drive in-use indicator light Eject button Manual eject hole

Learning the Basics

Using the optical disc drive

Drive in-use indicator light—Indicates when the drive is in

use.

Eject button—Press to release the disc tray.

Do not press the eject button or turn off the computer while the drive in-use indicator light is glowing. Doing so could damage the disc or the drive.

When the disc tray is open, be careful not to touch the lens or the area around it. Doing so could cause the drive to malfunction.

Manual eject hole—Use if you need to release the disc

tray when the power is off. Use a straightened paper clip or other narrow object to press the manual eject button located inside the hole.

Never use a pencil to press the manual eject button. Pencil lead can break off inside the computer and damage it.

Media control buttons

The media control buttons located above the keyboard allow you mute the sound and play audio CDs or DVD movies when the computer is on.

(Sample Illustration) Media control buttons

The Previous track button allows you to restart playing the current track or go to the previous track.

The

Play/pause button allows you to start playing or pause

the media currently playing. The

Next track button allows you to go to the next track.

The

Volume decrease button allows you to decrease the

volume.

Mute button

Previous track

Next track

Play/pause button

button

Volume decrease button

Volume increase button

Learning the Basics

Using the optical disc drive

The Volume increase button allows you to increase the volume.

The

Mute button allows you to enable/disable volume mute.

Inserting an optical disc

To i n se r t a n op ti ca l d i sc in t o t he dr iv e:

1 Make sure the computer is turned on. 2 Make sure the drive’s in-use indicator light is off. 3 Press the drive’s eject button. 4 Hold the disc by its edges and check that it is free of

dust. If the disc is dusty, clean it.

5 Place the disc carefully in the disc tray, label side up,

and gently press the disc onto the center spindle until it clicks into place.

Handle DVDs, Blu-rayTM, discs, and CDs carefully, making contact only with the center hole and edge. Do not touch the surface of the disc. Do not stack discs. If you incorrectly handle the discs, you could lose data.

6 Push the disc tray in by pressing gently on the center of

the tray until it clicks into place.

If you insert the disc incorrectly, it may jam the drive. If this happens, contact Toshiba support for assistance.

Playing optical media

If you insert an optical disc into the optical disc drive and the Auto-Run feature does not automatically start your disc, try launching the optical disc manually. To do this, follow these steps:

1 Press the ( ) +

E keys.

2 Double-click the optical disc drive icon.

The drive will run the optical disc.

Learning the Basics

Using the optical disc drive

If your disc does not run using this method, try using an application that is associated with the media on the disc. For example, if it is a music CD, open Windows Media

Player and use it to select and then play the CD. For other types of media, use the associated software to open the files on the disc.

Recording optical media

Depending on the configuration, your computer may come with an optical disc drive that allows you to:

❖ Play pre-recorded and recorded optical media. ❖ Read/write data and multi-media files to recordable

optical media.

For more information regarding supported optical media formats please refer to your computer’s detailed specifications at support.toshiba.com.

Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical disc drive may not record on certain optical media that bear the applicable logo, or play back optical media recorded by other computers or optical media recorders. Additionally, certain optical media recorded on your optical disc drive may not play back or operate properly on other computers or optical media players. These problems are not due to any defect in your Toshiba computer or optical disc drive. Please refer to your computer's product specification for listing of specific format compatibilities.

Copy protection technology may also prevent or limit recording or viewing of certain optical media.

For details on how to use the software, please refer to the respective Online Help menus.

NOTE

Learning the Basics

Toshiba’s online resources

Removing a disc with the computer on

To r em ov e a n o pt i ca l d i sc wi th t he co m pu t er tu r ne d o n:

1 Press the eject button on the drive.

Do not press the eject button while the drive in-use indicator light is glowing. Doing so could damage the disc or the drive.

Also, if the disc is still spinning when you open the disc tray, wait for it to stop spinning before you remove it.

2 Pull the tray out until it is fully open, remove the disc, and

place it in its protective cover.

3 Gently press the tray in to close it.

Removing a disc with the computer off

To r em ov e a d i sc wi t h th e co mp u te r t u rn e d o ff :

1 Insert a slender object, such as a straightened paper

clip, into the manual eject hole. The disc tray slides partially out of the drive.

Never use a pencil to press the manual eject button. Pencil lead can break off inside the computer and damage it.

2 Pull the tray out until it is fully open, remove the disc, and

place it in its protective cover.

3 Gently press the tray in to close it.

Toshiba ’s onli ne re sourc es

To sh i ba m ai nt a in s a n um be r o f online sites to which you can connect. These sites provide information about Toshiba products, give help with technical questions and keep you up to date with future upgrades. For more information, see

“Contacting Toshiba” on page 150.

Chapter 3

Mobile Computing

This chapter covers all aspects of using your computer while traveling.

Toshiba ’s ener gy-sa ver desi gn

Yo ur c om p ut er e nt e rs a l ow -p ow e r s u sp e ns io n m od e w h en i t is not being used, thereby conserving energy and saving money in the process. It has a number of other features that enhance its energy efficiency.

Many of these energy-saving features have been preset by Toshiba. We recommend you leave these features active, allowing your computer to operate at its maximum energy efficiency, so that you can use it for longer periods while traveling.

Running the computer on battery power

The computer contains a Lithium-Ion (Li-Ion) battery that provides power when you are away from an AC outlet. You can recharge it many times.

Mobile Computing

Running the computer on battery power

Battery Notice

Battery life rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any individual user. Actual battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as well as the natural performance variations produced by the design of individual components. The battery life rating is only achieved on the select models and configurations tested by Toshiba under the specific test settings at the time of publication and is not an estimate of a system’s battery life under any conditions other than the specific test settings.

Recharge time varies depending on usage. Battery may not charge while the computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.

To e n su re t ha t t h e b at t er y m a intains its maximum capacity, operate the computer on battery power at least once a month. The Lithium-Ion battery has no memory effect so it is not necessary to let the battery fully discharge each time. However, for better accuracy of the battery meter, it is helpful to fully discharge the battery periodically. Please see

“Maintaining your battery” on page 93 for procedures. If the

computer is continuously operated on AC power, either through an AC adaptor or a port replicator (if applicable to your system), for an extended period (more than a month), the battery may fail to retain a charge. This may shorten the life of the battery, and may cause the battery meter to be inaccurate.

For best performance when playing streaming media (especially streaming video), either power the computer from its AC adaptor, or set up a power plan that keeps the computer running at full performance even when powered from its battery. For more information about Windows® power plans, see “Power Plans” on page 87.

The computer may also have an internal real-time-clock (RTC) battery.

NOTE

Mobile Computing

Charging batteries

The RTC battery powers the RTC memory that stores your system configuration settings and the current time and date information. It maintains this information for up to a month while the computer is turned off.

TECHNICAL NOTE: Depending on your system, the RTC battery may only charge while the computer is turned on.

Power management

Yo ur co mp u te r s hi p s wi t h th e p o we r m an ag e me n t op t io ns preset to a configuration that will provide the most stable operating environment and optimum system performance for both AC power and battery modes.

Changes to these settings may result in system performance or stability issues. Users who are not completely familiar with the power management component of the system should use the preset configuration. For assistance with setup changes, contact Toshiba’s Customer Support Center.

Charging batteries

The battery needs to be charged before you can use it to power the computer.

Always use the AC adaptor specified by Toshiba. You can order a Toshiba AC adaptor from Toshiba’s Web site at accessories.toshiba.com.

Battery charge time may vary depending on the applications, power management settings, and features used.

Charging the main battery

The battery needs to be charged before you can use it to power the computer.

To c h ar ge t h e m ai n b a tt e ry, p lu g t h e c om p ut e r i nt o a li v e electrical outlet. The battery charges whether the computer is on or off.

NOTE

Mobile Computing

Charging batteries

TECHNICAL NOTE: The recharging of the battery may not occur when your computer is using all of the power provided by the AC adaptor to run applications, features, and devices. Your computer's Power Options utility can be used to select a power level setting that reduces the power required for system operation and will allow the battery to recharge.

The battery may not start charging immediately under the following conditions:

❖ The battery is extremely hot or cold.

To e n su re t ha t t h e b at t er y c h ar ge s t o i ts fu l l c ap a ci t y, wait until it reaches room temperature (50 to 80 degrees Fahrenheit, 10 to 26 degrees Celsius).

❖ The battery is almost completely discharged.

Leave the power connected and the battery should begin charging after a few minutes.

HINT: Once the battery is fully charged, we recommend that you periodically operate your computer on battery power until the battery discharges completely.

Please make a complete back up of your data to external media before discharging the battery. For more information, see “Backing up your work” on page 72

Charging the RTC battery

Yo ur co mp u te r m ay ha ve an in te r na l re a l- t im e c lo c k ( RT C ) battery. The RTC battery powers the System Time Clock and BIOS memory used to store your computer’s configuration settings. When fully charged, it maintains this information for up to a month when the computer is powered off.

The RTC battery may have become completely discharged while your computer was shipped, resulting in a CMOS error message during startup. The error message may vary by computer model.

Mobile Computing

Monitoring battery power

Depending on your system, the RTC battery may only charge while the computer is turned on.

To r ec ha rg e th e R T C ba tt er y, p lu g t he co m pu t er in t o a l iv e electrical outlet and leave the computer powered on for 24 hours.

It is seldom necessary to charge the RTC battery because it charges while the computer is on. If the RTC battery is low, the real-time clock and calendar may display the incorrect time and date or stop working.

When Hibernation mode is enabled and the RTC battery is completely discharged, a warning prompts you to reset the real-time clock.

The computer can be used while the RTC battery is being charged, although the charging status of the RTC battery cannot be monitored.

Monitoring battery power

To l o c a te yo u r s y s t em i nd i c a to r li g h t s, p le a s e r e fe r t o yo u r Quick Start document.

The computer’s main battery light gives you an indication of the main battery’s current charge.

❖ Glows amber while the main battery is being charged

(AC adaptor connected)

❖ Glows white when the main battery is fully charged

Battery life and charge time may vary, depending upon power management settings, applications and features used.

❖ Flashes amber when the main battery charge is low and

it is time to recharge the main battery or plug in the AC adaptor

NOTE

Mobile Computing

Monitoring battery power

If the AC power light flashes amber during charging, either a battery pack is malfunctioning, or it is not receiving correct input from the AC power supply.

HINT: Be careful not to confuse the AC power light/ Battery light ( ) and the power button ( ) light.

When the AC power light/Battery light or power button light flashes amber, it indicates that the system is suspended (using the Windows



operating system Sleep

command).



(Sample Illustration) Power and battery light locations

Determining remaining battery power

Wait a few moments after turning on the computer before trying to monitor the remaining battery power. The computer needs this time to check the battery’s remaining capacity and perform its calculations.

Move the pointer over the power icon in the notification area, see “Finding your way around the desktop” on page 98 for more information on the notification area. A pop-up message displays the remaining battery power as a percentage.

With repeated discharges and recharges, the battery’s capacity gradually decreases. A frequently used older battery does not power the computer for as long as a new battery, even when both are fully charged.

NOTE

AC power light/Battery light

System indicator lights

Wireless indicator light

Front edge of system

NOTE

Mobile Computing

Monitoring battery power

TECHNICAL NOTE: The computer drains the battery faster at low temperatures. Check your remaining charge frequently if you are working in temperatures below 50 degrees Fahrenheit.

The computer calculates the remaining battery charge based on your current rate of power use and other factors such as the age of the battery.

What to do when the main battery runs low

When the main battery runs low you can:

❖ Plug the computer into an external power source and

recharge the main battery

❖ Place the computer into Hibernation mode and replace

the battery, if applicable, with a charged spare (not included with your computer)

❖ Save your work and turn off the computer

If you do not manage to do any of these things before the main battery completely runs out of power, the computer automatically enters Hibernation mode and turns itself off. Hibernation mode keeps track of where you were, so that when you turn on the power again, you can continue where you left off.

Setting battery notifications

Yo u c an s et t w o n ot i fi c at i on s. E ac h n ot if ic a ti o n c an b e s e t to alert you when a specified percentage of remaining battery power has been reached. You can also set the computer to enter Sleep mode or Hibernation mode or to completely shut down when the notification goes off.

To c h an g e t he de fa ul t n ot i fi c at i on se t ti n gs :

1 While on the desktop, click or touch the

Battery ( )

icon in the notification area.

2 Click or touch

More power options.

The Power Options window appears.

3 Click or touch

Change plan settings under the power

plan to be customized. The Edit Plan Settings window appears.

Mobile Computing

Monitoring battery power

4 Click or touch Change advanced power settings.

The Advanced settings tab of the Power Options window appears.

5 Double-click or touch

Battery to display the battery

options.



(Sample Image) Advanced settings tab of Power Options screen

6 Configure the alarm settings to suit your needs.

Conserving battery power

How long a fully charged battery pack lasts when you are using the computer depends on a number of factors, such as:

❖ How the computer is configured ❖ How much you use the internal storage drive, optical

disc drive, or other optional devices

❖ Where you are working, since operating time decreases

at low temperatures

There are various ways in which you can conserve power and extend the operating time of your battery:

❖ Enable Sleep or Hibernation, which saves power when

you turn off the computer and turn it back on again

❖ Use the Windows

power-saving option plans

Mobile Computing

Monitoring battery power

These power-saving options control the way in which the computer is configured. By using them, you can increase the length of time you can use the computer before you need to recharge the battery.

Microsoft

has combined these options into preset Power Plans. Using one of these power plans lets you choose between maximum power savings and peak system performance. You may also set individual power-saving options to suit your own needs.

The following sections describe how to choose a Power Plan and discuss each power-saving option.

Power Plans

Yo u c an ch o os e a p re de f in ed Po w er Pl a n o r s el e ct yo u r o wn combination of power options. To do this:

1 While on the desktop, click or touch the

Battery ( )

icon in the notification area.

2 Click or touch

More power options.

The Windows

Power Options window appears.



(Sample Image) Windows® Power Options window

3 Select an appropriate plan for your work environment or

create your own custom plan.

4 Click or touch

Create a power plan in the left pane to

set up a new plan.

Mobile Computing

Using the eco power plan

To ed i t a p l a n o r t o ed i t a d v an c e d s e t t i ng s , co n t i nu e t o the following steps.

5 Click or touch

Change plan settings to choose the

plan you want to edit. This screen allows you to change basic settings.

6 Click or touch

Change advanced power settings to

access settings for battery notification levels, internal storage drive power save time, etc.

You can click or touch the plus signs to expand each item and to see what settings are available for each item.

7 Click or touch

OK to save the plan changes you have

performed.

Depending on your model, the two power plans eco and Balanced are satisfactory for most people and do not need to be edited. The eco plan is the best used for maximum battery time. The Balanced plan is a compromise between battery time and performance.

Using the eco power plan

This computer is equipped with the eco power plan. Operating the computer with this power plan enabled reduces electrical power consumption by slightly lowering system performance. For example, when this power plan is enabled, the brightness of the display is reduced and the interval before Sleep mode takes effect is shortened. To enable or disable the eco power plan, see “Power Plans” on

page 87.

The eco Utility

monitors your power savings from using the eco power plan by tracking real-time power consumption and accumulated savings over time. To learn how to access the utility, see “eco Utility®” on page 108.

For more information on the eco power plan, see the Help file in the eco Utility

window.

NOTE

Mobile Computing

Changing the main battery

When your main battery has run out of power, you have two options: plug in the AC adaptor or install a charged battery.

If you find that a new battery is needed, contact the location where you purchased the computer for more information on replacing the battery. Toshiba will not be responsible for any product damage, data loss, service, or part replacement made necessary by improper installation of a new battery.

If the computer is leaking or its case is cracked, put on protective gloves to handle it.

When your main battery has run out of power, you have two options: plug in the AC adaptor or install a charged battery.

Never short circuit the battery pack by either accidentally or intentionally bringing the battery terminals in contact with another conductive object. This could cause serious injury or fire, and could also damage the battery pack and computer.

Never expose a battery pack to abnormal shock, vibration or pressure. The battery pack's internal protective device could fail, causing it to overheat or ignite, resulting in caustic liquid leakage, or explosion or fire, possibly resulting in death or serious injury.

TECHNICAL NOTE: To avoid losing any data, save your files and then either completely shut down your computer or put it into Hibernation mode before changing the battery.

Mobile Computing

Changing the main battery

Removing the battery from the computer

To r em ov e t he ba t te r y:

1 Save your work. 2 Tur n of f th e co mp ut er, s ee “To Shut down your

computer” on page 43.

3 Unplug and remove any cables connected to the

computer, including the AC adaptor.

4 Close the display panel and turn the computer upside

down.

Depending on your model, the battery will either have latches or screws, allowing for the removal of the battery.

5 Slide the battery release lock to the unlocked position, or

using a small Phillips screwdriver, loosen the screw(s) that secure the battery.



(Sample Illustration) Unlocking the battery

6 Slide and hold the battery release latch to release the

battery, if applicable.

7 Pull the discharged battery out of the computer.



(Sample Illustration) Removing the battery

NOTE

Model with latches Model with screws

Battery screws

Model with latches Model with screws

Mobile Computing

Changing the main battery

If the battery is leaking or its case is cracked, put on protective gloves to handle it, and discard it immediately. Always dispose of used battery packs in compliance with all applicable laws and regulations. Put insulating tape, such as cellophane tape, on the electrode during transportation to avoid a possible short circuit, fire or electric shock. Failure to do so could possibly result in serious injury.

Inserting a charged battery

To i n se r t a b a tt e ry :

1 Wipe the terminals of the charged battery with a clean

cloth to ensure a good connection.

2 Insert the charged battery into the slot until the latch

clicks. The battery pack has been designed so that you cannot

install it with reverse polarity.

If the battery does not slide into the slot easily, move the battery release lock to the unlocked position and try again. Do not force the battery into position.



(Sample Illustration) Inserting the battery

3 Slide the battery release lock to the locked position (if

applicable), or replace the battery and secure it using the screw(s).

Model with latches Model with screws

Mobile Computing

Taking care of your battery



(Sample Illustration) Locking the battery

4 Tur n th e co mp ut er r ig ht s id e up . 5 Reconnect any cables that were removed in step 3 of

“Removing the battery from the computer” on page 90.

6 Restart the computer.

Taki ng care of yo ur ba ttery

The following sections offer tips on how to take care of your battery and prolong its life.

Safety precautions

Always immediately turn the power off and disconnect the power cable/cord plug from the plug socket and stop using the computer if you observe any of the following conditions:

❖ Offensive or unusual odor ❖ Excessive heat ❖ Discoloration ❖ Deformation, cracks, or leaks ❖ Smoke ❖ Other unusual events during use, such as

abnormal sound

Do not expose the computer to fire. The battery could explode

Do not turn on the computer’s power again until an authorized Toshiba service provider has checked it for safety. Continued use could cause a fire or rupture possibly resulting in serious injury or computer failure including but not limited to the loss of data.

Battery screws

Model with latches Model with screws

Mobile Computing

Disposing of used batteries

Maintaining your battery

Fully discharging your battery pack will allow better accuracy of the battery meter.

To f u ll y d i sc h ar ge y o ur ba t te r y pa ck :

❖ Periodically, disconnect the computer from a power

source and operate it on battery power until the battery pack fully discharges.

❖ If you have extra battery packs, rotate their use (for

models with an accessible battery only).

❖ If you will not be using the system for an extended

period, more than one month, remove the battery pack (for models with an accessible battery only).

❖ Store spare battery packs in a cool dry place out of

direct sunlight (for models with an accessible battery only).

Disposing of used batteries

The life of a battery pack depends on usage. When the battery pack needs replacing, the main battery light flashes amber shortly after you have fully recharged the battery.

You must discard a battery if it becomes damaged.

Never attempt to dispose of a battery pack by burning or by throwing it into a fire, and never allow exposure to a heating apparatus (e.g., microwave oven). Heat can cause a battery pack to explode and/or release caustic liquid, both which may possibly cause serious injury.

Always dispose of used battery packs in compliance with all applicable laws and regulations. Put insulating tape, such as cellophane tape, on the electrode during transportation to avoid a possible short circuit, fire or electric shock. Failure to do so could possibly result in serious injury.

Mobile Computing

Traveling tips

Always use the battery pack supplied as an accessory or an equivalent battery pack specified in the User's Manual. Other battery packs have different voltage and terminal polarities. Use of non-conforming battery packs could generate smoke or cause fire or rupture, possibly resulting in serious injury.

After repeated use, the batteries will finally lose their ability to hold a charge and you will need to replace them. Under certain applicable laws and regulations, it may be illegal to dispose of old batteries by placing them in the trash.

Please be kind to our shared environment. Check with your local government authority for details regarding where to recycle old batteries or how to dispose of them properly.

In addition, Toshiba’s recycling initiatives include recycling programs, events and consumer promotions. For details, please visit toshiba.com/recycle.

Toshiba is dedicated to preserving the environment by sponsoring

Call2Recycle™, a program of the

Rechargeable Battery Recycling Corporation, so you can easily recycle accessible rechargeable batteries. For more information and for free drop-off locations, visit

http://www.call2recycle.org/locator/ or call 1-800-822-8837.

Notice regarding CR coin cell batteries, applicable to California, U.S.A. only:

Perchlorate Material - special handling may apply. See

http://www.dtsc.ca.gov/hazardouswaste/perchlorate/

Traveling tips

The environmental precautions listed in “Selecting a place to

work” on page 31, also apply while traveling.

❖ Never leave your computer on a sunny ledge or in a

place where it could get wet or covered in dust.

❖ Always travel with the computer in a carrying case.

To sh i ba of fe rs a c ho i ce of ca r ry i ng ca s es fo r th e computer. They all provide plenty of extra space for manuals, power cords, and compact discs. Contact your authorized Toshiba representative for more information or visit Toshiba’s Web site at accessories.toshiba.com.

Mobile Computing

Travel ing tip s

TECHNICAL NOTE: When traveling by air, you may be required to pass your computer through airport security equipment. The X-ray equipment will not harm your computer.

Before using your computer aboard an aircraft, make sure the Wireless antenna is OFF (Airplane mode is ON) if your computer has wireless LAN capability.

To en a b l e o r di s ab l e wi r e l es s c om m u n ic a t i on , u s e th e

F12 key. For more information see “TOSHIBA Function

Keys” on page 152.

NOTE

Chapter 4

Exploring Your Computer’s Features

In this chapter, you will explore some of the special features of your computer.

Exploring the Start screen

The Start screen is the launching pad for everything you can do in the Windows

operating system, providing new and easy ways to access everything from your favorite apps and Web sites to your contacts and other important information.

When you move your pointer to the upper-right corner of the screen or swipe in from the right edge, a list of Windows

charms will slide out from the right. These Windows

charms perform various commands, including basics tasks like turning off the power and advanced PC settings.

Yo u c an g o t o t he S t ar t s cr ee n by c l ic k in g o r to u ch i ng t h e

Start charm, see “Charms” on page 97. You can also use

the Windows® key ( ) on your keyboard or on the LCD screen to go to the Start screen or to toggle back to the Desktop screen. For detailed information, please refer to the Windows

Help and Support.

By clicking on or touching the

Desktop tile from the Start

screen, you will find the Windows® settings and features you are most familiar with.

Exploring Your Computer’s Features

Exploring the Start screen

For detailed information on the new functionality, refer to the Windows

Help and Support.

(Sample Image) Windows® Start screen

Charms

Use the Windows® charms to start apps, find documents, set up system components, and perform most other computing tasks.

By moving your pointer to the upper-right corner of the screen or swiping in from the right edge of your screen, you will find a list of charms:

Search, Share, Start, Devices,

and

Settings.

Yo u m ay a l so ac ce s s th e

Power and Search icons in the

upper-right corner of the Start screen.

Search—This charm allows you to search for most anything

you need to locate on your computer. It can help you find apps, documents, photos, and your favorite music.

Share—This charm allows you to share music and photos

with your favorite social Web sites.

Start—This charm allows you to view all of the available

apps downloaded to your system.

Devices—This charm allows you to manage your hardware

devices.

Settings—This charm allows you to manage your system

settings.

App tiles

Power icon

Search icon

Apps page icon

Exploring Your Computer’s Features

Exploring the desktop

Tiles

Tiles can be accessed and launched from the Start screen. Typical Start screen tiles are the Desktop tile and Mail tile, as

well as tiles representing all other applications downloaded to your system.

Exploring the desktop

You can use its features to start applications, find documents, set up system components, and perform most other computing tasks.

HINT: The illustrated examples in this guide may appear slightly different from the screens displayed by your system. The differences are not significant and do not indicate any change in the functionality of your system.

Finding your way around the desktop

Your computer’s desktop includes several standard features: icons, taskbar, notification area, notifications, and background pattern.

(Sample Image) Windows® Desktop screen

Ta s k b ar

Icons

Notification area

Notifications

Exploring Your Computer’s Features

Exploring the desktop

Icons

An icon represents a folder, file, or program that can be quickly activated by double-clicking or touching the icon.

Yo u c an c r ea t e a n ew de sk t op ic on fo r a ny fo ld e r, fi le , o r program by dragging the element’s icon from its location in a window to the desktop area.

Yo u m ay s e e va r io u s i co ns di sp l ay e d on yo ur sy s te m desktop, for example:

Recycle Bin—Holds files you have deleted. You may be able to retrieve these files until you empty the Recycle Bin.

❖ TECHNICAL NOTE: If you delete a large number of

files or very large files from the internal storage drive, there may be insufficient space available in the Recycle Bin to hold these files. In this case, Windows

will prompt you to either permanently

delete the file(s) or cancel the deletion.

❖ If you delete a file (of any size) from an external

media or flash media, it does not go into the Recycle Bin. The file is permanently deleted.

❖ Permanently deleted files cannot be recovered

from the Recycle Bin.

For more information on the Recycle Bin, see Windows

online Help.

If you place the pointer over an icon, a popup description of the file contents appears.

Yo ur de sk t op ma y c on ta i n ot h er icons depending on your configuration. See Windows

online Help for more specific information on each icon and how to use it, or see “Help file”

on page 153.

Taskbar

Each time you open a program, a button associated with that program appears on the taskbar. With some programs, a button appears on the taskbar for each document or window you open. You can use these buttons to quickly switch between the programs or windows.

To m ak e a pr og r am o r wi n do w t he c ur re nt ly a ct iv e o n e, c li ck or touch the associated taskbar button.

NOTE

100

Exploring Your Computer’s Features

Windows® Store

Notification area

The notification area displays icons of tasks or programs that run continuously in the background and displays notifications. To learn more about each task, position the pointer over the icon for a few moments and a short description of the task appears.

Typical tasks in the notification area are Current time, Power usage mode, network connectivity status, and speaker volume.

To a c ti v at e a sp e ci f ic t as k, c l ic k o r to uc h t h e a pp ro pr ia t e notification area icon.

Notifications

There are many types of notifications you can employ to help you with the many tasks you perform every day.

User experience notifications can be set for toast, tile, badge, and raw notifications.

Toast notifi c a t i o n s —Designed for time-sensitive delivery

of personalized content, such as an instant message from a friend.

Tile no t i f i c a t i o n s —Used by applications that are not

currently running with an at-a-glance characteristic, giving you a quick preview of the subject line of your latest email or the current weather conditions.

Badge notifications—A specialized type of tile notification

(shown on the Start screen tile) using glyphs to indicate the number of applications that have updates available or the status of a running application.

Raw notifications—These run a background task on behalf

of an application while that application is not running in order to make available the latest content, such as an online newspaper.

Windows® Store

Although many applications will be pre-installed or built-in to your computer, you will also have the ability to download many other applications with a touch or the click of your mouse.

While in the Desktop screen, locate the

Windows® Store

( ) icon in the taskbar.

Toshiba Satellite S40, Satellite S50, Satellite S70-B, Satellite L40, Satellite L70 User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
