SATELLITE PRO 470CDT Product Specifications
470CDT: 2.1 Billion Bytes: PA1255U-T2C
PROCESSOR
Intel Pentium 200MHz (1.8v/2.5v) w/MMX
External data bus width 64 bit
External data/address bus speed 66 MHz
Integrated Coprocessor Yes
Processor Cache 32KB: (16KB code; 16KB data)
LEVEL 2 (L2) CACHE
Data Bus Width 64 bit
Data Bus Speed 66 MHz
DATA RAM: Yes
Type of cache memory 1 Mbit Pipelined Burst Synchronous SRAM, 2.5v
Access Time 8 ns
SYSTEM ARCHITECTURE
PCI BUS (v.2 .1): (32-bit , 33 MHz) Connecting Devices: PC Card Slots, E xpansion Bus, Graphics Controller, Modem DSP
ISA BUS: 16-bit, 8.3 MHz Connecting Devices: BIOS, FDD, HDD, CD-ROM, Sound chip, KBC
MEMORY: 64Mbit EDO DRAM, 3.3V
Standard 32 MB
Maximum 160 MB
Speed 60ns
Hyper Page mode memory access Yes
Data Bus width 64 bit
Local Bus Clock Speed 66 MHz
BIOS (256KB: 2 Mbit FLASH EPROM) Yes: supports APM (v.1.2); VESA (v2.0); DPMS, DCC2, DMI (through Win95); PC I
PnP 1.0a SUPPORT Yes
DISPLAY
Type TFT Active Matrix Color (800 X 600 resolution)
Size 12.1” Diagonal
Dot Pitch .30mm x .30mm
Contrast Ratio 100:1 (min)
VIDEO
Memory: 4Mbit EDO DRAM, 3.3V 2 MB
Speed 50ns
Hyper Page mode support Yes
Controller Chip C&T F65555
Data Bus Width 64-bit
PCI Bus Architecture w/burst mode Yes: 32-bit, 30 MHz
Graphics Accelerator: Yes with 64-bit BitBLT support
DirectDraw, Direct3D, H/W Cursor Yes
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling/Interpolation Yes
Zoomed Video Port Support Yes
DirectMPEG Yes
DirectVideo support Yes:w/Game SDK driver fr/Microsoft
Color Palette 16.7M colors
Internal Support Resolution Colors Support
Full Screen 800 x 600 16.7M colors
Smaller Image 640 x 480 16.7M colors
Virtual Display Mode 1024 x 768 64K colors
Virtual Display Mode 1280 x 1024 256 colors
External Support Resolution
640 x 480 16.7M colors colors 85Hz @ 64K color
800 x 600 16.7M colors colors 85Hz @ 64K color
1024 x 768 64K colors 60 Hz @ 64K color
1280 x 1024 256 colors 60 Hz @ 64K color
Yes
Yes: 256KB
Colors Support Vertical Refresh Rate (Non-Interlaced)
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1998 TAIS sp470.doc Rev. 1 02/07/00 st. Page 1 of 3
SATELLITE PRO 470CDT Product Specifications
470CDT: 2.1 Billion Bytes: PA1255U-T2C
STORAGE
Removable HDD (2.5” Enhanced IDE) 2.168 Billion bytes = 2.02 GB (12msec read/14msec write)
SELECT BAY DEVICES
Second Battery Optional: Part# PA2451UR (Includes battery adapter)
Battery Type Li-Ion (10.8V, 3400mAH)
Modular FDD (3.5” 1 . 44MB) Included/Swappable with CD-ROM
FDD Dimensions 4.57”L x 3.8”W x .59”H
FDD Weight Weight: .29 lbs
Simultaneous FDD & CD-ROM Support Yes: External FDD adapter included
FDD Adapter Dimensions 7.0”L x 5.5”W
FDD Adapter Weight .25 lbs
Modular HDD (2.5” Enhanced IDE) Optional/Swappable with FDD: Part# PA2609U
Capacity 2.1 billion bytes=2.02 GB (13msec)
Modular CD-ROM: Toshiba XM-1502B
5.25” 10 x-Average speed
Weight .4 lbs
Interface .ATAPI (Enhanced IDE)
Random Access Time 150 ms
Average Sustained Transfer Rate 1,500 KB/sec
Supported Disc formats CD-DA, CD-ROM, CD-ROM XA, CD-Bridge (Photo-CD, Video-CD),
KEYBOARD
84/86 keys, 3mm Travel Yes with Windows 95 key support
12 dedicated function keys Yes
Cursor control (8 Keys, Inverted “T”) Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device
EXPANSION SLOTS
Two Stacked PC Card Slots Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.
Support Standards
Internal Memory Slot (One only) Yes
EXPANSION PORTS
One RJ-11 port for internal modem (supplied) Yes
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
Fast Infrared port (Back only) Yes: IrDA 1.1:4Mbps compatible
One (PS/2) 101 Keyboard/Mouse port Yes: “Y”connector supported
One External Floppy Drive port Yes
Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
Microphone (3.5mm mini jack, stereo) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
Noteworthy security lock port Yes
INTERNAL MODEM (Cellular Ready ) 33.6 /14.4 Kbps Data/Fax/Voice modem w/V.80 support for Video Conferencing
DAA support US/Canada and Euro/Australia
Data support Protocols supported
Error correction MNP 1-4
Data compression MNP 5, CCITT V.42 bis
Fax support Fax class 1
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Supported Functions Speaker phone, Telephony Answering Machine, Ring Wake-up Resume
Installed/Swappable with FDD
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Plus)
AccuPoint
Yes: Supports 32-bit, 3.3V PC CardBus cards and 16-bit, 5.0V PC card standards
Bell-103/212A, CCITT-V.21/V.22, V.32, V.32bis, V.34, V.80
Incoming Call Discrimination, Caller ID; Video conferencing
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1998 TAIS sp470.doc Rev. 1 02/07/00 st. Page 2 of 3
SATELLITE PRO 470CDT Product Specifications
470CDT: 2.1 Billion Bytes: PA1255U-T2C
NoteDock III Port Replicator (Optional)
(2) Type III PCI/CardBus ready PC Card slots Yes: each slot supports one card
Supported Interfaces Serial, USB, parallel, PS/2 keyboard, PS/2 mouse, DC in, SVGA port,
POWER
Autosensing External AC Adapter
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 3A (max)
Power Output (Watts) 45W
Battery Type: Li-Ion (10.8V, 3600mAH) Yes (one standard): Part# PA2487UR
Battery Life: (One battery/Two batteries) Full power: 2+ hrs./4 hrs. Low power: 2.5/5 hrs.
Recharge Time (Computer Off/On) 2-3 hrs.(Off) /4-10 hrs.(On) --- (per one battery pack)
MaxTime Power Management
SOUND SYSTEM
Chipsets: Yamaha OPL3-SA3
16-bit stereo audio playback/record Yes
Maximum Sampling Rate 48kHz
FM Synthesis support Yes
Full duplex function Yes
Sound formats supported:
3D Sound Support Yes
DirectSound/Direct3DSound support Yes: with Windows 95 Game SDK driver from Microsoft
Built-in microphone (monoaural) Yes
Speaker system
DIMENSIONS Dimensions
Notebook 11.95”W x 9.4”D x 2”H 6.97 lbs.
AC Adapter 4.92”L x 2.48”W x 1.0”H .66 lbs.
Primary Battery (Standard) 6.87”L x 2.76”W x .73”H .88 lbs.
Select Bay Battery (Optional) 4.55”L x 4.06W x .66”H .78 lbs.
BUNDLED SOFTWARE
Windows®95; Fn-esse, Microsoft Internet Explorer; Yamaha Audio Rack; SystemSoft 32-bit (On Backup CD only),
Puma Intellisync97 (infrared software), SyncroConnect v.1.89 (modem software), Intel Indeo Video, Mediamatics Arcade Pak,
470CDT User’s Guide and Discovery Center
CD’s Included: Windows 95 Companion; Backup CD; Recovery CD
SECURITY Hardware
Password Power-on, & Supervisor
WARRANTY
ENVIRONMENTAL SPECIFICATIONS
Temperature:
Thermal Gradient: 20º C per hour (max.) -- -Relative Humidity
Altitude: -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: 10G; 1.5G w/CD-ROM installed 60G; 50G w/CD-ROM installed
Vibration: 0.5G; 0.25G w/CD-ROM installed 1G; 1G w/CD-ROM installed
Part# PA2717U
lock slot , joystick/MIDI, audio line-in, line-out, headphone, microphone
Part#
PA2450U
Yes
SoundBlaster Pro v.3.01, .WAV, MIDI, Windows Sound System 2.0
Two top-mounted stereo speakers (28mm, 8 Ω)
Weight
Lock slot, screen blank, keyboard lock
3 YR Parts / 1 YR. Labor
Operating
Non-operating
41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
20% to 80% non-condensing 10% to 90% non-conde nsi ng
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1998 TAIS sp470.doc Rev. 1 02/07/00 st. Page 3 of 3
