TOSHIBA Satellite A75 Series

Model Name Description

Satellite A75S211

Satellite A75S2111

Satellite A75S231

Satellite A75S2311

Intel® Pentium® 4 Processor 538, 15.4” TruBrite™, 512MB, 80GB (4200 RPM), DVDSuperMulti, 802.11bg Wireless LAN, TV-Out, CD play/Instant play button, Parallel port, Microsoft® Windows® XP Home (SP2),1-year Limited Warranty Intel® Pentium® 4 Processor 538, 15.4” TruBrite™, 512MB, 80GB (4200 RPM), DVDSuperMulti, 802.11bg Wireless LAN, TV-Out, CD play/Instant play button, Parallel port, Microsoft® Windows® XP Pro (SP2), 1-year Limited Warranty Intel® Pentium® 4 Processor 548, 15.4” TruBrite™, 512MB, 100GB (4200 RPM), DVDSuperMulti, 802.11bg Wireless LAN, TV-Out, i.LINK™ IEEE®1394, Bridge Media Adaptor, Parallel port, Infrared port, CD play/Instant play button, Microsoft® Windows® XP Home (SP2), 1-year Limited Warranty Intel® Pentium® 4 Processor 548, 15.4” TruBrite™, 512MB, 100GB (4200 RPM), DVDSuperMulti, 802.11bg Wireless LAN, TV-Out, i.LINK™ IEEE®1394, Bridge Media Adaptor, Parallel port, Infrared port, CD play/Instant play button, Microsoft® Windows® XP Pro (SP2), 1year Limited Warranty

Part Number UPC Code

PSA70U-0WK00G

PSA70U-0WK00P

PSA70U-0WL00G

PSA70U-0WL00P

System Characteristics1

Operating System

• Microsoft® Windows® XP Home (SP2)

• Microsoft® Windows® XP Professional (SP2)

Processor2 and Chipset

• Choice of processors:

o Mobile Intel® Pentium® 4 Processor 538 supporting HT

Technology [3.20GHz, 1MB L2 cache, 533MHz Front Side Bus]

o Mobile Intel® Pentium® 4 Processor 548 supporting HT

Technology [3.33GHz, 1MB L2 cache, 533MHz Front Side

• ATI MOBILITY® RADEON® 9000 IGP

Memory

• A75-S211/S2111 configured with 512MB

• 256MB (Min)/1280MB (Max) (256MB on-board model). PC2700

• A75-S231/S2311 configured with 512MB

• 512MB (Min)/1536MB (Max) (512MB on-board model). PC2700

Mass Storage3

Choice of Hard Disk Drives:

• 80GB (4200RPM) or 100GB (4200 RPM), Enhanced IDE (ATA-6)

Optical Disk Drive:

• Fixed Bay DVD Super Multi Drive, 5.25” EIDE, 12.7mm height.

Optional Floppy Disk Drive:

External USB Floppy Drive, 3.5”, 1.44MB

Display4

• 15.4” diagonal widescreen TruBrite™ TFT active-matrix LCD

• Maximum brightness 232 Cd/m

• Brightness Control

Graphics

• ATI MOBILITY™ RADEON® 9000 IGP with 64MB of shared

Input Devices

• Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key

• Mouse: Touch Pad

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 1 of 10

Bus]

DDR333 SDRAM 2.5V SODIMM Memory modules (One slot may be occupied)

hard disk drive; 9.5mm height; user removable

Maximum Speed CD-ROM(24x:read), CD-R(16x:write), CD-RW(4x:write), DVDROM(8x:read), DVD-R(4x:write), DVD-RW(2x:write), DVD+R(2.4x:write), DVD+RW(2.4x:write), DVD-RAM(2x:write) Compatibility CD-ROM(read), CD-R(read/write), CD-RW(read/write), DVDROM(read), DVD-R(read/write), DVD-RW(read/write), DVD+R(read/write), DVD+RW(read/write), DVD-RAM(read/write)

display at 1280 x 800 native resolution

memory, user adjustable to 128MB

stroke, 6mm height; Dedicated Windows® & Application keys support; HotKey function

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Expandability

• 1 main memory slot (may be occupied).

• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,

CardBus

• CD play/Instant play button

• Bridge Media Adaptor (Secure Digital®, Memory Stick™, Memory

Stick Pro™, SmartMedia™, Multi Media Card, xD-Picture [shared slots])

Communications5

• Integrated V.92 modem

• Realtek - 10/100 Base-TX Ethernet

• Integrated Atheros 802.11 bg Wireless LAN supporting Atheros

SuperG™ technology

Ports

Standard

• RGB (monitor) port

• TV-Out port (S-video)

• 3 Universal Serial Bus (USB) port (v2.0)

• External Microphone jack

• Headphone jack

• RJ-45 LAN port

• RJ-11 modem port

• Parallel port

Configured

• IEEE® 1394

• Infrared port

• Bridge Media Adaptor

(Only available on certain models)

Physical Description

• Dimensions (WxDxH Front/H Rear): 14.4” x 10.8” x 1.54”/1.81”

• Weight

• LED Indicators: DC-In, Power, Primary Battery, Hard Drive, CD-

: Starting at 7.97lbs depending upon configuration

DVD ROM Access, Wireless indicator, Caps Lock, Arrow Lock, Numeric Lock, Main Battery Charging Status, Sleep Suspend Mode, Secure Digital Card, Multiple Digital Media Card

Sound

• Realtek ALC250

• 16-bit stereo; Built-in stereo speakers

• 3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,

MIDI (playback) Support

• Sound Volume Control Dial

Power Supply

• 120W (19V 6.3A) Auto-sensing external AC Adapter, 100-240V / 50-60Hz input.

Battery7

• 12-cell (6450mAh), rechargeable, removable Lithium Ion (Li-Ion) battery pack

• Battery Life (Normal Mode): Up to 2 hours (12-cell battery) (measured by Winstone™)

Security

• Slot for cable lock; HDD, memory (by screw only); User Power-on password, Supervisor Password (Set-up Security), Screen Blank (by HotKey), Screen Saver (by software).

032017291898

032017304154

032017304178

032017304185

TOSHIBA

BIOS

• ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS v2.31, PCI BIOS v2.2 support

Software8

Toshiba Software and Utilities

• Toshiba Notebook Maximizer

• Toshiba Speech System

• Toshiba ConfigFree™

• Toshiba Custom Utilities

• Toshiba Touch and Launch

• TOSHIBA MyConnect™ - 45 day free trial offer

MYCONNECT OFFER DETAILS: 1 Valid in the US only! You must cancel your Access Plan before the end of the trial period to avoid being charged the $39.95 monthly Access Service fee for the six month plan commitment period. Monthly automatic renewal feature after end of commitment period. Available to new members in the U.S., age 18 or older, and a major credit card for billing is required. Offer is for unlimited dialup, wired broadband, or Wi-Fi remote access connection time in the 50 United States and the District of Columbia within the MyConnect service area for 30 day continuous service periods. Use of optional 800 telephone number dial-up usage will incur additional fees even during the trial period. Other terms and conditions apply. Offer expires June30, 2005. Information, prices, and availability subject to change without

Third-party Software

Environmental Specifications

Limited Warranty Extended Warranty

Models with 1 Year Standard Limited Warranty

notice.

• Microsoft® Works

• Microsoft® Office OneNote™ 2003

• Software Decoder: InterVideo® (Win-DVD™ 5) -w/SRS

TruSurround XT® Technology (SRS TruSurround XT® Technology features: TruSurround, SRS Dialog Clarity Enhancement, & TruBass)

• Sonic® Solutions Drive Letter Access (DLA)

• Sonic® Solutions RecordNow!™ Basic

• ArcSoft ShowBiz® DVD Version 1.3

• Intuit® Quicken® New User Edition 2004

• Norton AntiVirus™ 2004 – w/3-Month Subscription

• AOL® (3 –Month offer)

AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE, SIMPLY CANCEL BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges may apply, including AK, even during promotional period. Members may incur telephone charges on their phone bill, depending on their location and calling plan, even during promotional period. Available to new AOL members in the United States, age 18 or older; a major credit card or checking account is required.

• Adobe® Acrobat Reader

• AT&T® Worldnet® Service – 1 Month FREE

Telephone access and other charges and other terms and conditions may apply. Offer available to new customers only.

• QuickTime™ Player

• RealOne™ Player 8 Basic

• Microsoft® Internet Explorer

• Napster™ online digital music service (30-day trial)

Operating Non-Operating

Temperature

Thermal Gradient

5° to 35°C

(41° to 95°F)

15°C per hour

maximum

-20° to 65°C

(-4° to 149°F)

20°C per hour

maximum

Relative Humidity 20% to 80% 10% to 95%

Altitude (relative to sea

-60 to 3000 meters -60 to 10,000

level)

Shock 7G 60G

Vibration 0.2G 1.0G

• 1 year parts, labor, and battery Toshiba offers many different warranty extensions and enhanced

service plans such as SystemGuard®, At-Home Repair, and Service Express to provide additional support to your notebook PC. For a full description and complete list of programs, please visit www.accessories.toshiba.com

• 2nd/3rd Year Warranty Extension SWP-PEQQ3V

meters

 3 Year SystemGuard + 2nd/3rd Year Warranty Extension SWP-PEGQ3V

• 3 Year ServiceExpress + 2

nd/3rd

Year Warranty Extension

SWP-PEQP3V

• 3 Year At-Home Repair + 2

nd/3rd

Year Warranty Extension

SWP-PEQH3V

• 3 Year SystemGuard + Service Express + 2 Extension

SWP-PEGP3V

• 3 Year SystemGuard + At-Home Repair + 2 Extension

SWP-PEGH3V

nd/3rd

Year Warranty

nd/3rd

Year Warranty

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 2 of 10

TOSHIBA Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

Memory

KTT3311/512 Kingston PC2100/PC2700, 512MB DDR KTT3311/1G Kingston PC2100/PC2700, 1GB DDR

SD Memory Cards (Only on selected models with 5-in-1 slot)

SD-M2564B3 Toshiba 256MB SD (Secure Digital) SD-M5124B3 Toshiba 512MB SD (Secure Digital)

Power

PA3290U-2ACA Toshiba 120W Global AC Adapter PA3383U-1BRS Toshiba Primary Li Ion Battery (12 cell)

Cases-Security

PA1360U-1NCS Toshiba Nylon Case (15.4") PA1361U-1NCS Toshiba Executive Leather Case (15.4") PA1362U-1NCS Toshiba BackPack (15.4") NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock

Input Devices

PA1336U-1NKB Toshiba USB Keyboard

See Toshiba Service Plan Agreement for program terms and conditions at www.pcsupport.toshiba.com

PA1337U-1NMS Toshiba USB Optical Scroller Mouse

Toshiba USB Ultra-Mini Retractable Scroller

PA1367U-1NMS

Mouse Toshiba USB 2.0 Mini 4-Port Hub (w/AC

PA1368U-1NHB

adapter)

Storage & Back-up

Toshiba 5GB Type II PC Card HDD w/Back-up

HDD1232CZP41002

software

PA3109U-1FDD Toshiba USB Floppy Disk Drive Kit

CMS ABSplus 80GB USB 2.0 Auto Backup

UABS2-80

Syst CMS ABSplus 100GB USB 2.0 Auto Backup

UABS2-100

Syst

PA3404U-1H40 Toshiba 40GB 1.8” USB Mobile Hard Drive

Other

PA1370U-1ETC

PA3390U-1MPM Toshiba Multi Media Center USB/Audio Hub

PA3405U-1BTM Toshiba Bluetooth USB Adapter

Toshiba Keyboard Protector (Tecra/Satellite/Qosmio)

Business Winstone® 2002 BatteryMark™ Version 1.0

These models achieved the battery life times shown using Ziff Davis Media Inc.’s Business Winstone® 2002 BatteryMark™ Version 1.0. These tests were performed without independent verification by the VeriTest testing division of Lionbridge Technologies, Inc. (“VeriTest”). Neither Ziff Davis Media Inc. nor VeriTest makes any representations or warranties as to the results of the tests. Winstone® is a registered trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. Copyright 2002 Ziff Davis Media Inc. All Rights Reserved. All products used in the tests were shipping versions available to the general public. The battery life results were achieved running the Business Winstone® 2002 BatteryMark™ Version 1.0 on the following system parameters. System parameters were set according to Ziff Davis Media Inc.’s recommendations.

Battery Life

CPU Name Mobile Intel® Pentium® 4 processor 518 with HT Technology Mobile Intel® Pentium® 4 processor 538 with HT Technology

Processor info

amount of RAM 512MB 512MB

Amount of secondary RAM cache 1MB 1MB

B Battery

Graphics ATI RC300ML (internal GFX) ATI RC300ML (internal GFX)

amount and type of RAM

graphics driver name and version V8.01 V8.01

Catalog Spec (1st) 2H 2H

(1st+2nd)

Number of Conditioning Phase 1 1

Life Test Run 3 3

speed

number of processors

type(1st)

model number(1st) type(2nd)

model number(2nd)

number of batteries

2.8GHz 3.2GHz

1 1

Li-Ion Li-Ion

PA3383U-1BRS/BAS PA3383U-1BRS/BAS

- -

1 1

UMA UMA

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 3 of 10

TOSHIBA

graphics resolution and color depth, refresh rate 1280x800, 32bit, 60Hz 1280x800, 32bit, 60Hz

hard disk capacity 60G (4200rpm) 80G (4200rpm)

hard disk file system & transfer mode Enhanced IDE(ATA-6) Enhanced IDE(ATA-6)

hard disk controller model ATI IXP150 ATI IXP150

size of hardware cache if any - -

operating system version, service pack Windows XP Professional Savice Pack 1 Windows XP Professional Savice Pack 1

other special conditions N/A N/A

BIOS version 1.00 1.00

Power management setting see another sheet see another sheet

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 4 of 10

TOSHIBA

Business Winstone 2002 BatteryMark Version 1.0 Model#1-2 Power Save Mode Cooling Method MaximumPerformance Intel SpeedStep(R) Technology Processor speed 100%-75% Low 74%-50% Low 49%-25% Low 24%-0% Low Monitor brightness 100%-75% Mid2 (* See Notes) 74%-50% Mid2 49%-25% Mid2 24%-0% Mid2 Turn off monitor 100%-75% NEVER 74%-50% NEVER 49%-25% NEVER 24%-0% NEVER Turn off hard disks 100%-75% 3min 74%-50% 3min 49%-25% 3min 24%-0% 3min System standby 100%-75% NEVER 74%-50% NEVER 49%-25% NEVER 24%-0% NEVER System Hibernate 100%-75% NEVER 74%-50% NEVER 49%-25% NEVER 24%-0% NEVER System Power Mode When I press the power button Power off When I close the lid Hibernate Prompt for password when computer goes off Standby or Hibernation Off Alarm Activate low battery alarm when power level reaches Off Low Battrey Alarm Action Sound alarm Off Display message Off When the alarm goes off,the computer will: Off When the alarm occurs, run this program: Off Activate critical battery alarm when power level reaches Off Critical Battrey Alarm Action Sound alarm Off Display message Off When the alarm goes off,the computer will: Off When the alarm occurs, run this program: Off Hibernate Enable Hibernate Support On SoundMAX Audio Power Management Timer Setting Instant Power Save Power Save Delay Internal Speakers Power Down -

Power Mode

Return Policy

TAIS does not accept the return of component parts, or bundled software, which have been removed from the PC s ystem. Pro- rata refunds on individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are registered trademarks and OneNote is a trademark of Microsoft Corporation in the United States and/or other countries. BAPCO, SYSmark, and MobileMark are U.S. Registered Trademarks of Business Applications Performance Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.

Subject to Change; Product Series Disclaimer.

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at pcsupport.toshiba.com. The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at pcsupport.toshiba.com.

Central Processing Unit (“CPU”) Performance Disclaimer.

CPU performance in your computer product may vary from specifications under the following conditions:

• use of certain external peripheral products

• use of battery power instead of AC power

• use of certain multimedia games or videos with special effects

• use of standard telephone lines or low speed network connections

• use of complex modeling software, such as high end computer aided design applications

• use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

• use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references

are approximate and may vary depending on the specific computer model – please refer to your Resource Guide or visit the Toshiba website at www.pcsupport.toshiba.com

CPU performance may also vary from specifications due to design configuration. Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions under “Env ironmental Conditions” in your product Resource Guide. Contact Toshiba Technical Service and Support for more information.

for details).

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 5 of 10

TOSHIBA

Hard Drive Capacity Disclaimer.

1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available storage capacity will also be less if the product includes pre-installed operating system and/or application software. Actual formatted capacity may vary.

TFT Disclaimer.

Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the LCD Screen will deteriorate. This is an intrinsic characteristic of LCD technology. Screen will dim when the computer is operated on battery power and you may not be able to increase the brightness of the screen.

FCC Modem Speed Disclaimer.

Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary depending on line conditions.

Wireless or Connectivity Claims.

Wireless connectivity is subject to availability of access points. You might have to purchase additional software, hardware and/or services or pay for phone charges and air time, etc. to achieve the functionality as advertised.

Weight Disclaimer

Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

General Battery Life Disclaimer or Business Winstone® 2002 BatteryMark™ Version 1.0 Battery Life Data Disclaimer

Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations tested by Toshiba at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 6 of 10

TOSHIBA

Drawings

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 7 of 10

TOSHIBA

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 8 of 10

TOSHIBA

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 9 of 10

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

TOSHIBA

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A75-Series Revision 1.2 12-21-2004 CBB CB v_1.2 Page 10 of 10

Toshiba Satellite A75-S211, Satellite A75-S2111, Satellite A75-S231, Satellite A75-S2311 Specifications

Specifications and Main Features

Frequently Asked Questions

User Manual
