SATELLITE 320 SERIES Product Specifications
MODEL 320CDS/4.1 billion bytes 320CDT/4.1 billion bytes
PART NUMBER PA1271U-S2C PA1271U-T2C
PROCESSOR (All Models)
Intel Pentium 233Mhz (1.8v/2.5v) w/MMX
Integrated Coprocessor Yes
Processor Cache 32KB: (16KB code; 16KB data)
LEVEL 2 (L2) CACHE (All Models) Yes: 512KB
Data Bus Width/Data Bus Speed 64 bit/66 MHz
DATA RAM: Yes
Type of cache memory 1 Mbit Pipelined Burst Synchronous SRAM, 2.5v
Access Time 8 ns
SYSTEM ARCHITECTURE (All Models)
PCI BUS (v.2.1): (32-bit, 33 MHz) PC Card Slots, Graphics Controller, HDD, CD-ROM, FDD
ISA BUS: 16-bit, 8.25 MHz BIOS, Sound chip, KBC
MEMORY: 64Mbit EDO DRAM, 3.3V (All Models)
Standard 32 MB
Maximum 160 MB
Speed 60ns
Hyper Page mode memory access Yes
Data Bus width 64 bit
Local Bus Clock Speed 66 MHz
BIOS (512KB: 4Mbit FLASH EPROM, 5V) Yes: supports APM (v.1.2); VESA (v2.0); DPMS, DCC2, DMI (through Win95); PCI
PnP 1.0a SUPPORT Yes
DISPLAY 320CDS
Type Color Bright Dual Scan (800 x 600) TFT Active Matrix Color (800 x 600)
Size 12.1” Diagonal 12.1” Diagonal
Dot Pitch .30mm x .30mm .30mm x .30mm
Contrast Ratio 40:1 100:1
VIDEO (All Models)
Memory: 4Mbit EDO DRAM, 3.3V 2 MB
Speed 50ns
Hyper Page mode support Yes
Controller Chip C&T 65555
Data Bus Width 64-bit
PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes with 64-bit BitBLT support
2D graphics support DirectDraw, H/W Cursor
3D graphics support Direct3D
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling/Interpolation Yes
DirectMPEG Yes
DirectVideo support Yes:w/Game SDK driver fr/Microsoft
Color Palette 16.7M colors
Internal Support Resolution
Full Screen 800 x 600 16.7M colors
Smaller Image 640 x 480 16.7M colors
Virtual Display Mode 1024 x 768 64K colors
Virtual Display Mode 1280 x 1024 256 colors
External Support Resolution
640 x 480 16.7M colors colors 85Hz @ 64K color
800 x 600 16.7M colors colors 85Hz @ 64K color
1024 x 768 64K colors 60 Hz @ 64K color
1280 x 1024 256 colors 60 Hz @ 64K color
Yes
Connecting Devices
320CDT
Colors Support
Colors Support Vertical Refresh Rate (Non-Interlaced)
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S320.doc Rev. 11 02/07/00 st. Page 1 of 3
SATELLITE 320 SERIES Product Specifications
MODEL 320CDS/4.1 billion bytes 320CDT/4.1 billion bytes
PART NUMBER PA1271U-S2C PA1271U-T2C
STORAGE (All Models)
Removable1 HDD (2.5” Enhanced IDE) 4.1 billion bytes (13msec read/14msec write)
DRIVE BAY DEVICES (All Models)
FDD (3.5” 1.44MB; 12.7mm high)
Simultaneous FDD & CD-ROM Support Yes: two independent units
CD-ROM: (5.25” ; 12.7mm high)
Weight .62 lbs.
Interface .ATAPI (Enhanced IDE)
Random Access Time 135 ms
Average Sustained Transfer Rate 2,400 KB/sec
Burst Data Transfer Rate PIO Mode 4 (16.7MB/sec)
Supported Disc formats CD-DA, CD-ROM, CD-ROM XA, CD-Bridge (Photo-CD, Video-CD),
KEYBOARD (All Models)
84/86 keys, 3mm Travel Yes with Windows 95 key support & 12 dedicated function keys
Cursor control (8 Keys, Inverted “T”) Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device (All Models)
EXPANSION SLOTS (All Models)
Two Stacked PC Card Slots Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.
Support Standards
Internal Memory Slot (One only) Yes
EXPANSION PORTS (All Models)
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
Fast Infrared port (Back only) Yes: IrDA 1.1:4Mbps compatible
One (PS/2) 101 Keyboard/Mouse port Yes: “Y”connector supported
Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
Microphone (3.5mm mini jack, stereo) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
Noteworthy security lock port Yes
PC Card MODEM (Bundled) --- (All models)
Data support
Protocols supported
Error correction V.42/MNP 2-4
Data compression MNP 5, CCITT V.42 bis
Fax support Group 3, EIA/TIA, Fax class 1
Protocols supported V.17, V.27 ter, V.29
Command Set Hayes, Microcom compatible AT commands
1. One Screw Service removable.
Yes
20X Maximum Speed (14X-Average speed)
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Plus)
AccuPoint
Yes: Supports 32-bit, 3.3V PC CardBus cards and 16-bit, 5.0V PC card standards
Xircom Credit Card Modem 56
Bell-212A, V.23, V.22, V.22bis, V.32, V.32bis, V.34, K56flex
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S320.doc Rev. 11 02/07/00 st. Page 2 of 3
SATELLITE 320 SERIES Product Specifications
MODEL 320CDS/4.1 billion bytes 320CDT/4.1 billion bytes
PART NUMBER PA1271U-S2C PA1271U-T2C
POWER (All models)
Autosensing External AC Adapter
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 2A (max)
Power Output (Watts) 30W
Battery Type: Li-Ion (10.8V, 3600mAH) Yes (one standard): Part# PA2487URN
Battery Life: (Full Power)
Recharge Time (Computer Off/On) 3 - 5 hrs.
MaxTime Power Management
SOUND SYSTEM (All Models)
Chipset: Yamaha OPL3-SA3
16-bit stereo audio playback/record Yes
Maximum sampling ratge 48 kHz
FM Synthesis support Yes (Soft Wave Table included)
Full duplex function Yes
Sound formats supported:
3D Sound Support Yes
Direct3DSound, DirectSound support Yes: with Windows 95 Game SDK driver from Microsoft
Speaker system
DIMENSIONS (All Models) Dimensions
Notebook 11.96”W x 9.4”D x 2.1”H 6.7 lbs.
AC Adapter 3.94”L x 1.96”W x 0.98”H .46 lbs.
Battery (Standard) 6.87”L x 2.76”W x .73”H .88 lbs.
BUNDLED SOFTWARE (All Models)
Windows®95; Microsoft Internet Explorer 4.01 (export version); Yamaha Audio Rack; Puma Intellisync97 (infrared software),
Ring Zero Ring Central Dialer application, Mediamatics Arcade Pak; Symantec Norton Antivirus Scanner 4.0; Prodigy Internet;
Intel Indeo Video, Maxtime, Fn-esse, Online documentation
CD’s Included: Windows 95 Companion CD; Backup CD; Rec overy CD
SECURITY (All Models) Hardware
Password Power-on, Supervisor, & HDD password (both drives)
WARRANTY (All Models)
ENVIRONMENTAL SPECIFICATIONS (All models)
Temperature:
Thermal Gradient: 20º C per hour (max.) N/A N/A
Relative Humidity: Operating
Altitude: Operating -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: Operating 10G; 1.5G w/CD-ROM installed 60G; 50G w/CD-ROM installed
Vibration: Operating 0.5G; 0.25G w/CD-ROM installed 1G; 1G w/CD-ROM installed
3.94”L x 1 .96”W x 0.98”H --- .4 6 lbs.
320CDS: 2.5+ hrs. 320CDT: 3.0 hrs.
depending on the computer function performed
Yes
SoundBlaster Pro V3.01, Windows Sound System V2.0
Two top-mounted stereo speakers (28mm, 8 Ω)
Weight
Cable Lock slot, PC Card lock slot, screen blank, keyboard lock
1 YR Parts / 1 YR. Labor / 1 YR. Battery
Operating Non-operating
41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
20% to 80% non-condensing 10% to 90% non-c ondensing
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S320.doc Rev. 11 02/07/00 st. Page 3 of 3
