Vector 180 Series Product Brief
RD400/400A Series
PCIe® NVMe® M.2
The SSD for enthusiasts
and hardcore gamers
June 2016
Product Brief | RD400 Series | V 1.0 | © 2016 TOSHIBA CORPORATION, All Rights Reserved. OCZ is a trademark or a registered
trademark of Toshiba Corporation and/or its afliates. All other marks are property of their respective owners.
1
Page 2
Overview
Introducing a new breed of enthusiast storage, the OCZ RD400 NVM Express® M.2 solid state drive series, designed to
propel high-end computing into a new realm of possibilities. The OCZ RD400 PCIe Gen3 x4 outperforms SATA SSDs
by over 4.5 times in sequential read (up to 2,600 MB/s) , and over 3 times in sequential write performance (up to 1,600
MB/s) so your system won’t be deprived of the storage bandwidth your data-intensive workload requires.* The OCZ
RD400’s next generation NVMe® interface provides a more responsive PC experience and shorter storage latency than
that of today’s traditional hard disk drives and SATA SSDs. Along with high performance, the OCZ RD400 is designed
for mobile, desktop, or workstation applications.
* This reects maximum performance of RD400 512 GB compared to VT180 480 GB.
Game-changing Storage
TOSHIBA’s new OCZ RD400 SSD redenes high performance storage for enthusiasts and hardcore gamers that feel
held back by commodity storage hardware. With over 200,000 IOPS @4 KiB of random read performance at your beck
and call, the OCZ RD400 will be your next high-end system.
Get in the PCI Express Lane
Why keep using an interface that was designed for hard disk drives? PCI Express revolutionizes ash storage for
tomorrow’s high-speed computing age. The OCZ RD400 boosts bandwidth and puts your data in the fast lane leaving
SATA SSDs in the dust.
NVM Express
Utilizing NVMe technology, the OCZ RD400 reduces latency in your system’s I/O path between the drive and your CPU,
resulting in smooth and responsive performance.
Good Things Come in Small Packages
The OCZ RD400’s compact M.2 2280 form factor packs in high performance and up to 1024 GB of storage capacity
enabling high-end desktop speeds to exist not only in your notebook, but directly on your motherboard without taking
up a PCIe slot.
Flexibility for the Future
If you want to harness the power of NVMe now but don’t want to upgrade your motherboard yet, the OCZ RD400 is
available with an M.2 PCIe adaptor add-in-card. This option allows your investment to go the distance when you opt for
an M.2 platform in the future.
RD400 Series Product Brief | V 1.0 | June 2016
© 2016 TOSHIBA CORPORATION, All Rights Reserved. OCZ is a trademark or a registered trademark of Toshiba Corporation and/or its
afliates. All other marks are property of their respective owners.
2
Page 3
Features
NVMe Compliant
Say good bye to legacy storage buses.
M.2 2280 Compliant
Latest SSD form factor for your next gen system build.
Custom Drivers
RD400/400A utilizes custom high performance drivers.
Advanced Warranty Program
PCIe Performance
Surpass the SATA bottleneck once and for all.
Low Power Mode
Requires less power when drive is in standby mode.
1024GB Storage
Store loads of data on up to 1024GB of SSD capacity.
A new approach to service that mitigates the hassle surrounding support and warranty
claims consumers often have to deal with. This program provides advanced replacement
with no return shipping costs. Advanced Warranty Program is limited by selected regions.
Detailed warranty terms available at www.ocz.com
ADVANCED WARRANTY
PROGRAM
SSD Utility SSD Management Software
The SSD Utility was designed to help your OCZ drive thrive and lets you be in control of maintenance, monitoring,
SSD tuning, OS tuning and more!
RD400 Series Product Brief | V 1.0 | June 2016
© 2016 TOSHIBA CORPORATION, All Rights Reserved. OCZ is a trademark or a registered trademark of Toshiba Corporation and/or its
afliates. All other marks are property of their respective owners.
3
Page 4
Specications
Performance
Sequential Read Speed
Sequential Write Speed
Random Read (4 KiB)
Random Write (4 KiB)
2
2
1
1
128 GB 256 GB 512 GB 1024 GB
Up to 2,200 MB/s Up to 2,600 MB/s Up to 2,600 MB/s Up to 2,600 MB/s
Up to 620 MB/s Up to 1,150 MB/s Up to 1,600 MB/s Up to 1,550 MB/s
Up to 170,000 IOPS Up to 210,000 IOPS Up to 190,000 IOPS Up to 210,000 IOPS
Up to 110,000 IOPS Up to 140,000 IOPS Up to 120,000 IOPS Up to 130,000 IOPS
Endurance
TBW (Total Bytes Written)
Daily Usage Guidelines
1
Sequential speeds are measured with ATTO v2.47.
2
4 KiB random performance is measured with IOMETER 2010, 4KiB le size, QD32 (100% Incompressible Data).
3
Denition and conditions of TBW (Terabytes Written) are based on JEDEC standard; JESD218A, February 2011, and dened for the service life.
4
Daily usage guidelines value is calculated by dividing TBW by 365 x 5.
3
4
74 TB 148 TB 296 TB 592 TB
40 GB/day 81 GB/day 162 GB/day 324 GB/day
Physical
Usable Capacities 128 GB, 256 GB, 512 GB, 1024 GB
Form Factor M.2 2280, M.2 2280+AIC
PCI Express Base Specication Revision 3.1 (PCIe)
Interface
Maximum Speed: 32 GT/s (PCIe Gen3x4L )
Command: NVM Express Revision 1.1b (NVMe)
NAND Flash Memory Type MLC
Dimension (L x W x H)
128 GB, 256 GB, 512 GB: 80 x 22 x 2.23 mm
1024 GB: 80 x 22 x 3.58 mm
AIC: 157.64 x 105.51 x 17.2 mm
128 GB: 6.8 g (typ.)
Drive Weight
256 GB, 512 GB: 7.2 g (typ.)
1024 GB: 8.6 g (typ.)
AIC: 63 g (typ.)
Power Requirements
Supply Voltage 128 GB, 256 GB, 512 GB, 1024 GB: 3.3 V +/- 5%
AIC: 12 V +/- 5%
Power Consumption (Active)
Power Consumption (Power State 5) 128 GB, 256 GB, 512 GB, 1024 GB and AIC: 6.0 mW (typ.)
128 GB, 256 GB, 512 GB: 6.0 W (typ.)
1024 GB and AIC: 6.4 W (typ.)
RD400 Series Product Brief | V 1.0 | June 2016
© 2016 TOSHIBA CORPORATION, All Rights Reserved. OCZ is a trademark or a registered trademark of Toshiba Corporation and/or its
afliates. All other marks are property of their respective owners.
4
Page 5
Environmental
Operating Temperature 0 °C to 70 °C
Storage Temperature -40 °C to 85 °C
Shock Resistance 9.8 km/s2 {1000 G} (0.5 ms)
Vibration
Operational 21 m/s2 {2.17 Grms} (Peak, 7 to 800 Hz)
Non-operational 30 m/s2 {3.13 Grms} (Peak, 5 to 800 Hz)
Certications UL/cUL, FCC, CE, RCM, KC, BSMI, VCCI, and ISED
Reliability / Security
MTBF 1.5 Mhours
Product Health Monitoring Self-Monitoring, Analysis and Reporting Technology (SMART) Support
Compatibility
PCI Express Compatible with PCI Express® Base Specication Revision 3.1
Operating System
5
Connector Type
Targeted Applications Client desktops and laptops
5
Compatible operating system for SSD is not the same as compatible operating system for SSD Utility or CLOUT
Windows® 10, Windows® 8.1, Windows® 7; Linux® Fedora 21, Mint 17.1, ElementaryOS
Freya, OpenSUSE 13.2, Ubuntu 14.04, Ubuntu 14.10; Mac® OS X® 10.9, 10.10, 10.11
M.2: M.2 M key socket
AIC: PCIe slot
Additional
Performance Optimization TRIM, Idle Time Garbage Collection
Service & Support 5-Year6 Advanced Warranty Program7, Toll-Free Tech Support
Software SSD management software: SSD Utility and Command Line Online Update Tool (CLOUT)
6
Warranty is 5 years or the max TBW (total bytes written) per model capacity, whichever occurs rst.
7
Available to limited regions and countries. Check availability.
RD400 Series Product Brief | V 1.0 | June 2016
© 2016 TOSHIBA CORPORATION, All Rights Reserved. OCZ is a trademark or a registered trademark of Toshiba Corporation and/or its
afliates. All other marks are property of their respective owners.
5
Page 6
Ordering Information Model Part Number UPC
128 GB RVD400-M22280-128G 842024037347
RD400
RD400A (with AIC)
256 GB RVD400-M22280-256G 842024037354
512 GB RVD400-M22280-512G 842024037361
1024 GB RVD400-M22280-1T 842024037378
128 GB RVD400-M22280-128G-A 842024037538
256 GB RVD400-M22280-256G-A 842024037552
512 GB RVD400-M22280-512G-A 842024037569
1024 GB RVD400-M22280-1T-A 842024037545
Denition of capacity: Toshiba denes a megabyte (MB) as 1,000,000 bytes, a gigabyte (GB) as 1,000,000,000 bytes and a terabyte (TB) as
1,000,000,000,000 bytes. A computer operating system, however, reports storage capacity using powers of 2 for the denition of
1GB = 230 = 1,073,741,824 bytes and therefore shows less storage capacity. Available storage capacity (including examples of various media les)
will vary based on le size, formatting, settings, software and operating system, such as Microsoft Operating System and/or pre-installed software
applications, or media content. Actual formatted capacity may vary.
A kibibyte (KiB) means 210, or 1,024 bytes, a mebibyte (MiB) means 220, or 1,048,576 bytes, and a gibibyte (GiB) means 230, or 1,073,471,824 bytes.
IOPS: Input Output Per Second (or the number of I/O operations per second)
MTTF (Mean Time to Failure) is not a guarantee or estimate of product life; it is a statistical value related to mean failure rates for a large number of
products which may not accurately reect actual operation. Actual operating life of the product may be different from the MTTF.
Read and write speed may vary depending on the host device, read and write conditions, and le size.
Subject to Change: While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein,
product specications, congurations, prices, system/component/options availability are all subject to change without notice.
Microsoft and Windows, Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries. Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries. Mac and OS X are trademarks of Apple Inc.,
registered in the U.S. and other countries.
NVM Express® and NVMe® are trademarks of NVM Express, Inc.
Product image may represent design model.
OCZ RD400 comes with a 5-Year Advanced Warranty Program. Advanced Warranty Program is limited by selected regions. Detailed warranty
terms available at www.ocz.com
