Toshiba MMU-AP0182SH, MMU-AP0242SH, MMU-AP0152SH Engineering Data

Oct. 05’
Engineering Data
1-way (2 series)
Air Discharge Cassette Type
Indoor Unit
MMU-AP0152SH MMU-AP0182SH MMU-AP0242SH
Contents
1. Specifications
2. Dimensions
3. Electrical current characteristics
5. Wiring diagrams
6. Air speed characteristics
7. Sound characteristics (NC Curve)
8. Fresh air intake (Design guide)
9. Barycentric position
1. Specifications
1-way (2 series) Air Discharge Cassette Type
50Hz
Model name MMU-
Cooling/Heating capacity (kW)
Electrical
characteristics
Appearance
Dimension
Total weight
Heat exchanger
Soundproof / Heat-insulating material
Fan
Standard air flow
Motor (W)
Air filter
Controller
Connecting pipe
Sound pressure level
Power supply
Running current (A)
Power consumption (kW)
Starting current (A)
Main unit
Ceiling panel
Panel color
Main unit
Ceiling panel
Main unit (kg)
Ceiling panel (kg)
High (m3/h)
(Mid./Low) (m3/h)
Gas pipe (mm)
Liquid pipe (mm)
Drain pipe (Nominal dia.mm)
High/Mid./Low (dB(A))
Height (mm)
Width (mm)
Depth (mm)
Height (mm)
Width (mm)
Depth (mm)
AP0152SH AP0182SH AP0242SH
4.5/5.0 5.6/6.3 7.1/8.0
1 phase 50Hz 230V (220-240V)
0.34 0.37 0.62
0.042 0.046 0.075
0.51 0.54 0.80
Heat-insulating material attached Zinc hot dipping steel plate
RBC-US21PGE
Moon white (Muncel 2.5GY9.0/0.5)
200
1000
710
20
1230
800
21 22
5.5
Finned tube
Polyethylene foam + Expanded polystyrene
Centrifugal fan (Sirocco fan)
750 780 1140
690/630 720/660 960/810
30
Standard filter attached (Long life filter)
Remote controller
12.7 15.9
6.4 9.5
25 (Polyvinyl chloride tube : External dia.32 Internal dia.25)
37/35/32 38/36/34 45/41/37
11
1. Specifications
1-way (2 series) Air Discharge Cassette Type
60Hz
Model name MMU-
Cooling/Heating capacity (kW)
Electrical
characteristics
Appearance
Dimension
Total weight
Heat exchanger
Soundproof / Heat-insulating material
Fan
Standard air flow
Motor (W)
Air filter
Controller
Connecting pipe
Sound pressure level
Power supply
Running current (A)
Power consumption (kW)
Starting current (A)
Main unit
Ceiling panel
Panel color
Main unit
Ceiling panel
Main unit (kg)
Ceiling panel (kg)
High (m3/h)
(Mid./Low) (m3/h)
Gas pipe (mm)
Liquid pipe (mm)
Drain pipe (Nominal dia.mm)
High/Mid./Low (dB(A))
Height (mm)
Width (mm)
Depth (mm)
Height (mm)
Width (mm)
Depth (mm)
AP0152SH AP0182SH AP0242SH
4.5/5.0 5.6/6.3 7.1/8.0
1 phase 60Hz 220V
0.35 0.39 0.62
0.041 0.045 0.073
0.53 0.54 0.80
Heat-insulating material attached Zinc hot dipping steel plate
RBC-US21PGE
Moon white (Muncel 2.5GY9.0/0.5)
200
1000
710
20
1230
800
21 22
5.5
Finned tube
Polyethylene foam + Expanded polystyrene
Centrifugal fan (Sirocco fan)
750 780 1140
690/630 720/660 960/810
30
Standard filter attached (Long life filter)
Remote controller
12.7 15.9
6.4 9.5
25 (Polyvinyl chloride tube : External dia.32 Internal dia.25)
37/35/32 38/36/34 45/41/37
22
2. Dimensions
1-way (2 series) Air Discharge Cassette Type (MMU-AP***SH)
Wire inlet (Knockout hole)
56
112
Fresh air inlet (Ø92 knockout hole)
Ø112 (4-tapping screw under-hole)
233122
C/L
710 Unit external size
20
252
C/L
1060 Hanging bolt pitch
1190 Ceiling opening size 1230 Panel external size
1000 Unit external size
706
248
Drain pipe connecting port (Be sure to connect the attached flexible hose.)
72
20
100
220
475 Hanging bolt pitch
135
20 94
Refrigerant pipe connecting port Gas side B
Hanging bolt M10 or W3/8 (Local supply)
43
6080
800 Panel external size
760 Ceiling opening size
216
20
154
Refrigerant pipe connecting port Liquid side A
Wire inlet
200
93
20
Lower surface of ceiling
Wired remote controller (RBC-AMT31E)
Ceiling panel (Sold separately)
4
2.7
120
120
76
73.4
For front air discharge unit (Sold separately) knockout hole
Model name MMU-
AP015, AP018 type
AP024 type
16
AB
Ø6.4 Ø12.7
Ø9.5 Ø15.9
33
3. Electrical current characteristics
1-way (2 series) Air Discharge Cassette Type
Type
S-MMS (50Hz)
S-MMS (60Hz)
S-HRM
Model
MMU-AP0152SH
MMU-AP0182SH
MMU-AP0242SH
MMU-AP0152SH
MMU-AP0182SH
MMU-AP0242SH
MMU-AP0152SH
MMU-AP0182SH
MMU-AP0242SH
Nominal Voltage
(V-Ph-Hz)
230-1-50
230-1-50
230-1-50
220-1-60
220-1-60
220-1-60
230-1-50
230-1-50
230-1-50
Voltage Range
Min Max
198 264
198 264
198 264
198 264
198 264
198 264
198 264
198 264
198 264
Fan Motor
kW FLA
0.030 0.40
0.030 0.42
0.030 0.71
0.030 0.40
0.030 0.45
0.030 0.75
0.030 0.40
0.030 0.42
0.030 0.71
Power Supply
MCA MOCP
0.49 15
0.53 15
0.88 15
0.50 15
0.57 15
0.94 15
0.49 15
0.53 15
0.88 15
44
4. Sensible capacity table
1-way (2 series) Air Discharge Cassette Type (MMU-AP***SH)
TC : Total capacity [kW] SHC : Sensible capacity [kW]
Indoor air temp. Unit size
015
018
024
Outdoor
air temp.
CDB
10.0
12.0
14.0
16.0
18.0
20.0
21.0
23.0
25.0
27.0
29.0
31.0
33.0
35.0
37.0
39.0
10.0
12.0
14.0
16.0
18.0
20.0
21.0
23.0
25.0
27.0
29.0
31.0
33.0
35.0
37.0
39.0
10.0
12.0
14.0
16.0
18.0
20.0
21.0
23.0
25.0
27.0
29.0
31.0
33.0
35.0
37.0
39.0
14.0CWB 16.0CWB 18.0CWB 19.0CWB 20.0CWB 22.0CWB 24.0CWB 20CDB 23CDB 26CDB 27CDB 28CDB 30CDB 32CDB
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.7 2.8 4.1 3.0 4.4 3.2 4.5 3.2 4.6 3.2 4.9 3.2 5.1 3.1
3.6 2.7 4.0 2.9 4.2 3.1 4.4 3.1 4.5 3.1 4.7 3.1 5.0 3.0
3.5 2.7 3.8 2.8 4.1 3.0 4.2 3.0 4.4 3.0 4.6 3.0 4.8 2.9
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.6 3.5 5.1 3.7 5.4 3.9 5.6 3.9 5.8 3.9 6.1 3.9 6.4 3.8
4.5 3.3 4.9 3.6 5.3 3.8 5.4 3.8 5.6 3.8 5.9 3.7 6.2 3.7
4.3 3.3 4.8 3.5 5.1 3.7 5.3 3.7 5.4 3.7 5.7 3.6 6.0 3.6
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.8 4.4 6.4 4.7 6.9 5.0 7.1 5.0 7.3 5.0 7.7 5.0 8.1 4.8
5.6 4.3 6.2 4.6 6.7 4.9 6.9 4.8 7.1 4.8 7.5 4.8 7.8 4.7
5.5 4.2 6.1 4.4 6.5 4.7 6.7 4.7 6.9 4.7 7.3 4.7 7.6 4.6
55
5. Wiring diagrams
1-way (2 series) Air Discharge Cassette Type (MMU-AP***SH)
66
6. Air speed characteristics
1-way (2 series) Air Discharge Cassette Type
<Heating mode>
MMU-AP0152SH, AP0182SH
3.5m
3m
2m
1m
Main unit
MMU-AP0242SH
3.5m
Main unit
0.3
1m 2m 3m 4m
1.0
0.5
0.3
0.5
3m
2m
1m
1.0
0.3
0.5
1m 2m 3m 4m
0.3
0.5
77
7. Sound Characteristics (NC Curve)
1-way (2 series) Air Discharge Cassette Type
MMU-AP0152SH
Fan tap
Sound pressure
level (dB(A))
90
80
70
60
50
40
30
20
Approximate threshold of
Octave band sound pressure level (dB)
hearing for continuous noise
10
63 125 250 500 1000 2000 4000 8000
Octave band center frequency (Hz)
HML
37 35 32
HM
L
NC-70
NC-60
NC-50
NC-40
NC-30
NC-20
MMU-AP0242SH
Fan tap
Sound pressure
level (dB(A))
90
80
70
60
50
40
30
20
Octave band sound pressure level (dB)
Approximate threshold of hearing for continuous noise
10
63 125 250 500 1000 2000 4000 8000
Octave band center frequency (Hz)
HML
45 41 37
H M
L
NC-70
NC-60
NC-50
NC-40
NC-30
NC-20
MMU-AP0182SH
Fan tap
Sound pressure
level (dB(A))
90
80
70
60
50
40
30
20
Approximate threshold of
Octave band sound pressure level (dB)
hearing for continuous noise
10
63 125 250 500 1000 2000 4000 8000
Octave band center frequency (Hz)
HML
38 36 34
M
H
L
NC-70
NC-60
NC-50
NC-40
NC-30
NC-20
Center
1.5m
Microphon
88
8. Fresh air intake (Design guide)
1-way (2 series) Air Discharge Cassette Type
Caution
The fresh air shall be treated by heat reclaim ventilator or the like. Be sure to decide the fresh air volume so that mixed suction air with fresh air keep operating temperature. *1.Recommended treated air temperature is 12 °C to 30 °C.
However, please make a fresh air volume within 20% of standard.
Model name MMU- AP0152SH AP0182SH AP0242SH Standard air flow (m3/h) 750 780 1140
Provide an air filter in fresh air duct.
(Fresh air doesn't pass through the filter of Indoor unit.) Be sure to insulate the fresh air duct. Please wire for inter - lock with fan of Heat exchanger unit and Indoor unit.
80
70
60
50
40
30
Static Pressure (Pa)
20
10
0
0 50 100 150 200 250
Indoor unit
MMU-AP0152SH,MMU-AP182SH
MMU-AP0242SH
Fresh Air Volume (m3/h)
Duct fan
motor
Flange Option :TCB-FF101URE
Fresh Air Volume
Inter - lock circuit
Connect the driving relay of the duct fan(DC 12V) between 1 and 6 on the indoor P.C. board. (Rated current of the relay for duct fan shall be up to 75mA.) After installation, implement a trial operation to check that the duct fan of the indoor unit start/stop simultaneously. (Implement the trial operation following to the installation manual of the indoor unit.)
99
9. Barycentric position
1-way (2 series) Air Discharge Cassette Type
Model name X (mm) Y (mm) Z (mm)
MMU-AP0152SH
MMU-AP0182SH
MMU-AP0242SH
370 475 80
Weight (kg)
Main unit Ceiling panel
20 5.5
21 5.5
1010
1-way Air Discharge Cassette Type Engineering Data
Oct, 2005 First Edition
Loading...
