Toshiba TECRA GMAD00134010, M8-S8011, M8-S8011X, M8-ST3093, M8-ST3094 User Manual

...
®
Tecra
M8 Series
User’s Guide
If you need assistance:
Toshiba’s Support Web site
pcsupport.toshiba.com
Toshiba Global Support Centre
Calling within the United States (800) 457-7777 Calling from outside the United States (949) 859-4273
page 169 in this guide.
GMAD00134010 06/07
2
Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling.
Model: Tecra® M8 Series
Recordable and/or ReWritable Drive(s) and Associated Software Warranty
The computer system you purchased may include Recordable and/or ReWritable optical media drive(s) and associated software, among the most advanced data storage technologies available. As with any new technology, you must read and follow all set-up and usage instructions in the applicable user guides and/or manuals enclosed or provided electronically. If you fail to do so, this product may not function properly and you may lose data or suffer other damage. TOSHIBA AMERICA INFORMATION SYSTEMS, INC. (“TOSHIBA”), ITS AFFILIATES AND SUPPLIERS DO NOT WARRANT THAT OPERATION OF THE PRODUCT WILL BE UNINTERRUPTED OR ERROR FREE. YOU AGREE THAT TOSHIBA, ITS AFFILIATES AND SUPPLIERS SHALL HAVE NO RESPONSIBILITY FOR DAMAGE TO OR LOSS OF ANY BUSINESS, PROFITS, PROGRAMS, DATA, NETWORK SYSTEMS OR REMOVABLE STORAGE MEDIA ARISING OUT OF OR RESULTING FROM THE USE OF THE PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY THEREOF.
Protection of Stored Data
For your important data, please make periodic back-up copies of all the data stored on the hard disk or other storage devices as a precaution against possible failures, alteration, or loss of the data. IF YOUR DATA IS ALTERED OR
LOST DUE TO ANY TROUBLE, FAILURE OR MALFUNCTION OF THE HARD DISK DRIVE OR OTHER STORAGE DEVICES AND THE DATA CANNOT BE RECOVERED, TOSHIBA SHALL NOT BE LIABLE FOR ANY DAMAGE OR LOSS OF DATA, OR ANY OTHER DAMAGE RESULTING THEREFROM. WHEN COPYING OR TRANSFERRING YOUR DATA, PLEASE BE SURE TO CONFIRM WHETHER THE DATA HAS BEEN SUCCESSFULLY COPIED OR TRANSFERRED. TOSHIBA DISCLAIMS ANY LIABILITY FOR THE FAILURE TO COPY OR TRANSFER THE DATA CORRECTLY.
Critical Applications
NOTE
The computer you have purchased is not designed for any “critical applications.” “Critical applications” means life support systems, medical applications, connections to implanted medical devices, commercial transportation, nuclear facilities or systems or any other applications where product failure could lead to injury to persons or loss of life or catastrophic property damage.
ACCORDINGLY, TOSHIBA, ITS AFFILIATES AND SUPPLIERS DISCLAIM ANY AND ALL LIABILITY ARISING OUT OF THE USE OF THE COMPUTER PRODUCTS IN ANY CRITICAL APPLICATIONS. IF YOU USE THE COMPUTER PRODUCTS IN A CRITICAL APPLICATION, YOU, AND NOT TOSHIBA, ASSUME FULL RESPONSIBILITY FOR SUCH USE.
FCC Notice “Declaration of Conformity Information”
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
3
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Only Peripherals complying with the FCC Class B limits may be attached to this equipment. Operation with noncompliant peripherals or peripherals not recommended by Toshiba is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer's parallel port, monitor port, USB port, PS/2 port microphone jack (Port availability depends on model selected). Changes or modifications made to this equipment not expressly approved by Toshiba or parties authorized by Toshiba could void the user's authority to operate the equipment.
®
, i.LINK® port, HDMI out port and
4
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference. This device must accept any interference received, including interference
that may cause undesired operation.
Contact either:
Toshiba’s Support Web site at pcsupport.toshiba.com. Or call the Toshiba Global Support Centre:
Within the United States at (800) 457-7777 Outside the United States at (949) 859-4273
Industry Canada Requirement
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conformé à la norme NMB-003 du
Canada.
FCC requirements
The following information is pursuant to FCC CFR 47, Part 68 and refers to internal modems.
This equipment complies with Part 68 of the FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, the information must be provided to the telephone company.
The modem connects to the telephone line by means of a standard jack called the USOC RJ11C.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC part 68 rules and requirements adopted by the ACTA. It is designed to be connected to a compatible modular jack that is also compliant.
The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company. For products approved after July 23, 2001, the REN for this product is part of the product identifier that has the format US:AAAEQ##TXXXX. The digits represented by the ## are the REN without a decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately shown on the label.
Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information.
Telephone Company Procedures
The goal of the telephone company is to provide you with the best service it can. In order to do this, it may occasionally be necessary for them to make changes in their equipment, operations or procedures. If these changes might affect your service or the operation of your equipment, the telephone company will give you notice, in writing, to allow you to make any changes necessary to maintain uninterrupted service.
If Problems Arise
If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advanced notice is not practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.
5
If trouble is experienced with this equipment, for repair or limited warranty information, please contact Toshiba Corporation, Toshiba America Information Systems, Inc. or an authorized representative of Toshiba, or the Toshiba Support Centre within the United States at (800) 457-7777 or Outside the United States at (949) 859-4273. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.
Disconnection
If you should ever decide to permanently disconnect your modem from its present line, please call the telephone company and let them know of this change.
Fax Branding
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device, including Fax machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual. (The telephone number provided may not be a 900 number or any other number for which charges exceed local or long-distance transmission charges.)
In order to program this information into your fax transmission, refer to the fax software instructions installed on this computer.
6
Alarm Equipment
If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer.
Instructions for IC CS-03 Certified Equipment
1 NOTICE: The Industry Canada label identifies certified equipment.
This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.
2 The user manual of analog equipment must contain the equipment’s
Ringer Equivalence Number (REN) and an explanation notice similar to the following:
The Ringer Equivalence Number (REN) of this device can be found on the label affixed to your computer.
NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.
3 The standard connecting arrangement (telephone jack type) for this
equipment is jack type(s): USOC RJ11C.
Wireless Interoperability
The TOSHIBA Wireless LAN Mini PCI Card products are designed to be interoperable with any wireless LAN product that is based on Direct Sequence Spread Spectrum (DSSS) radio technology, and is compliant to:
The IEEE 802.11 Standard on Wireless LANs (Revision A/B/G), as defined
and approved by the Institute of Electrical and Electronics Engineers.
The Wireless Fidelity (Wi-Fi
The “Wi-Fi CERTIFIED” logo is a certification mark of the Wi-Fi Alliance.
Bluetooth® and Wireless LAN devices operate within the same radio
frequency range and may interfere with one another. If you use Bluetooth and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection.
If you should experience any such problem, immediately turn off your Bluetooth or Wireless LAN device.
®
) certification as defined by the Wi-Fi Alliance.
7
Please contact Toshiba computer product support on Web site http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or pcsupport.toshiba.com in the United States for more information.
Radio Frequency Interference Requirements This device is restricted to indoor use due to its operation in the 5.15 GHz to
5.25 GHz frequency range. FCC requires this product to be used indoors for frequency range 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.
High power radars are allocated as primary users of the 5.25 GHz to 5.35 GHz and 5.65 GHz to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device.
Wireless LAN and Your Health
Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by Wireless LAN devices however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.
Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.
8
In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include:
Using the Wireless LAN equipment on board airplanes, or In any other environment where the risk of interference to other devices or
services is perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use the Wireless LAN device prior to turning on the equipment.
Exposure to Radio Frequency Radiation The radiated output power of the TOSHIBA Wireless LAN Mini PCI Card is
far below the FCC radio frequency exposure limits. Nevertheless, the TOSHIBA Wireless LAN Mini PCI Card shall be used in such a manner that the potential for human contact during normal operation is minimized. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Regulatory Information
The TOSHIBA Wireless LAN Mini PCI Card must be installed and used in strict accordance with the manufacturer’s instructions as described in the user documentation that comes with the product. This device complies with the following radio frequency and safety standards.
Canada – Industry Canada (IC)
This device complies with RSS 210 of Industry Canada.
The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s Web site www.hc-sc.gc.ca/rpb. The RF device shall not be co-located with any other transmitter that has not been tested with this device.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
L'utilisation de ce dispositif est soumis aux deux conditions suivantes: (1) il ne doit pas produire de brouillage et (2) l'utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même s'il est susceptible de compromettre son fonctionnement.
9
The term “IC” before the equipment certification number only signifies that the Industry Canada technical specifications were met.
To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.
Pour empecher que cet appareil cause du brouillage au service faisant l’objet d’une licence, il doit etre utilize a l’interieur et devrait etre place loin des fenetres afin de Fournier un ecram de blindage maximal. Si le matriel (ou son antenne d’emission) est installe a l’exterieur, il doit faire l’objet d’une licence.
This device is restricted to indoor use due to its operation in the 5.15 GHz to
5.25 GHz frequency range. Industry Canada requires this product to be used indoors for frequency range 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.
High power radars are allocated as primary users of the 5.25 GHz to 5.35 GHz and 5.65 GHz to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device.
EU Declaration of Conformity
TOSHIBA declares that this product conforms to the following Standards:
Supplementary Information:
This product is carrying the CE-Mark in accordance with the related European Directives. The party responsible for CE-Marking is TOSHIBA Europe GmbH, Hammfelddamm 8, 41460 Neuss, Germany.
VCCI Class B Information
*The product complies with the requirements of the Low Voltage Directive 73/23/EEC, the EMC Directive 89/336/EEC and/or the R&TTE Directive 1999/5/EC.
10
NOTE
Modem Warning Notice
Conformity Statement
The equipment has been approved to [Commission Decision “CTR21”] for pan­European single terminal connection to the Public Switched Telephone Network (PSTN).
However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
In the event of problems, you should contact your equipment supplier in the first instance.
The above Caution information applies to products that operate with an
802.11a device.
Taiwan
Article 14 Unless approved, for any model accredited low power radio frequency
electric machinery, any company, trader or user shall not change the frequency, increase the power or change the features and functions of the original design.
Article 17 Any use of low power radio frequency electric machinery shall not affect
aviation safety and interfere with legal communications. In the event interference is caused, the use of such electric machinery shall be immediately discontinued. Operation of such products can be resumed only when they are modified and can no longer cause interference.
The legal communications mentioned in the above item refer to radio communications operated in accordance with telecommunication laws and regulations.
Low power radio frequency electric machinery shall resist against interference from legal communications or from industrial, scientific and medical radio emission electric machinery.
Using this Equipment in Japan
In Japan, the frequency bandwidth of 2,400 MHz to 2,483.5 MHz for second generation low-power data communication systems such as this equipment overlaps that of mobile object identification systems (premises radio station and specified low-power radio station).
1. Sticker Please put the following sticker on devices incorporating this product.
The frequency bandwidth of this equipment may operate within the same range as industrial devices, scientific devices, medical devices, microwave ovens, licensed radio stations and non-licensed specified low-power radio stations for mobile object identification systems (RFID) used in factory product lines (Other Radio Stations).
1. Before using this equipment, ensure that it does not interfere with any of the equipment listed above.
2. If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions.
3. Contact TOSHIBA Direct PC if you have problems with interference caused by this product to Other Radio Stations.
2. Indication The indication shown below appears on this equipment.
(3)
(1) (2)
2.4DSOF4
11
(4)
1 2.4: This equipment uses a frequency of 2.4 GHz. 2 DS: This equipment uses DS-SS modulation.
OF: This equipment uses OFDM modulation.
3 The interference range of this equipment is less than 40m. 4 This equipment uses a frequency bandwidth from
2,400 MHz to 2,483.5 MHz. It is possible to avoid the band of mobile object identification systems.
3. TOSHIBA Direct PC Monday – Friday: 10:00 – 17:00 Toll Free Tel: 0120-15-1048 Direct Dial: 03-3457-4850 Fax: 03-3457-4868
Device Authorization
This device obtains the Technical Regulation Conformity Certification and the Technical Conditions Compliance Approval, and it belongs to the device class of radio equipment of low-power data communication system radio station stipulated in the Radio Law and the Telecommunications Business Law of Japan.
The Name of the radio equipment: refer to the equipment label provided on the computer
12
NOTE
NOTE
JAPAN APPROVALS INSTITUTE FOR TELECOMMUNICATIONS EQUIPMENT
Approval Number: D01-1128JP TELECOM ENGINEERING CENTER Approval Number: 03NY.A0018,
03GZDA0017 The following restrictions apply:
Do not disassemble or modify the device. Do not install the embedded wireless module into other device. 5.17 GHz to 5.23 GHz for indoor use only.
Radio Approvals for Wireless Devices
The following information is dependent on what type of wireless device is in your computer. Not all devices are available on all models.
Approved Countries/Regions for use for the Atheros AR5BMB-43/44 and AR5BMB5 Mini PCI Wireless Network Adapters
This equipment is approved to the radio standard by the countries/regions in the following table.
Do not use this equipment except in the countries/regions in the following table.
This device works on passive scan only. A peer-to-peer mode is not available in 802.11a and Turbo Mode.
802.11b (2.4 GHz) Australia Austria Belgium
Canada Denmark Finland France Germany Greece Ireland Italy Liechtenstein Luxembourg Netherlands New Zealand Norway Portugal Sweden Switzerland UK USA
Europe - Restrictions for use of 2.4 GHz Frequencies in European Community Countries
13
België/ Belgique:
Deutschland: License required for outdoor installations. Check with reseller for
France: Restricted frequency band: only channels 1 to 7 (2400 MHz and 2454
For private usage outside buildings across public grounds over less than 300m no special registration with IBPT/BIPT is required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more than 300m. For registration and license please contact IBPT/BIPT.
Voor privé-gebruik buiten gebouw over publieke groud over afstand kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik over afstand groter dan 300m is wel registratie bij BIPT/IBPT nodig. Voor registratie of licentie kunt u contact opnemen met BIPT.
Dans le cas d’une utilisation privée, à l’extérieur d’un bâtiment, au­dessus d’un espace public, aucun enregistrement n’est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m un enregistrement auprès de l’IBPT est requise. Pour les enregistrements et licences, veuillez contacter l’IBPT.
procedure to follow. Anmeldung im Outdoor-Bereich notwendig, aber nicht
genehmigungspflichtig. Bitte mit Händler die Vorgehensweise abstimmen.
MHz respectively) may be used outdoors in France. Please contact A.R.T. (http://www.art-telecom.fr) for applicable procedures to follow.
Bande de fréquence restreinte: seuls les canaux 1- 7 (2400 et 2454 MHz respectivement) doivent être utilisés endroits extérieur en France. Vous pouvez contacter l’Autorité de Régulation des Télécommunications (http://www.art-telecom.fr) pour la procédure à suivre.
Italia: License required for indoor use. Use with outdoor installations not
allowed. E’necessaria la concessione ministeriale anche per l’uso interno.
Verificare con i rivenditori la procedura da seguire.
Nederland: License required for outdoor installations. Check with reseller for
procedure to follow. Licentie verplicht voor gebruik met buitenantennes. Neem contact op
met verkoper voor juiste procedure.
14
802.11a (5 GHz) Australia Austria Belgium
Canada Denmark Finland France Germany Greece Ireland Italy Liechtenstein Luxembourg Netherlands New Zealand Norway Portugal Sweden Switzerland UK USA
Turbo Mode (5 GHz)
Canada USA
Europe - Restrictions for Use of 5 GHz Frequencies in European Community Countries
European Community Countries
Austria O x x Belgium, France,
Switzerland/Lichtenstein Denmark, Finland,
Germany, Greece, Ireland, Italy, Luxembourg, Netherlands, Norway, Portugal, Sweden, UK
Iceland, Spain O O O
O: allowed x: forbidden
5150-5250 MHz
Channels: 36, 40, 44,
48
Indoor Only
OO x
OO O
5250-5350 MHz
Channels: 52, 56, 60,
64
Indoor Only
5470-5725 MHz
Channels: 100, 104, 108, 112,
116, 120, 124, 128, 132, 136, 140
Indoor/Outdoor
To remain in conformance with European spectrum usage laws for Wireless
LAN operation, the above 2.4 GHz and 5 GHz channel limitations apply. The user should use the wireless LAN utility to check the current channel of operation. If operation is occurring outside of the allowable frequencies as listed above, the user must cease operating the Wireless LAN at that location and consult the local technical support staff responsible for the wireless network.
The 5 GHz Turbo mode feature is not allowed for operation in any
European Community country.
15
NOTE
This device must not be operated in ad-hoc mode using channels in the
5 GHz bands in the European Community. Ad-hoc mode provides a direct communication between two client devices without a Wireless LAN Access Point.
This device must be used with Access Points that have employed and
activated a radar detection feature required for European Community operation in the 5 GHz bands. This device will operate under the control of the Access Point in order to avoid operating on a channel occupied by any radar system in the area. The presence of nearby radar operation may result in temporary interruption of operation of this device. The Access Point’s radar detection feature will automatically restart operation on a channel free of radar. You may consult with the local technical support staff responsible for the wireless network to ensure the Access Point device(s) are properly configured for European Community operation.
Approved Countries/Regions for use for the Atheros AR5001X Mini PCI Wireless Network Adapter
This equipment is approved to the radio standard by the countries/regions in the following table.
Do not use this equipment except in the countries/regions in the following table.
This device works on passive scan only. A peer-to-peer mode is not available in 802.11a and Turbo Mode.
802.11b (2.4 GHz) Australia Austria Belgium
Canada Denmark Finland France Germany Greece Ireland Italy Liechtenstein Luxembourg Netherlands New Zealand Norway Portugal Sweden Switzerland UK USA
16
802.11a (5 GHz) Australia Austria Belgium
Canada Denmark Finland France Germany Greece Ireland Italy Liechtenstein Luxembourg Netherlands New Zealand Norway Portugal Sweden Switzerland UK USA
Turbo Mode (5 GHz)
Canada USA
Approved Countries/Regions for use for the Intel® PRO/ Wireless LAN 2100 3B Mini PCI Adapter
This equipment is approved to the radio standard by the countries/regions in the following table.
Do not use this equipment except in the countries/regions in the following table.
Argentina Australia Austria Belgium Brazil Canada Chile Denmark Finland France Germany Greece Iceland Ireland Italy Japan Liechtenstein Luxembourg Mexico Netherlands New Zealand Norway Peru Portugal Singapore Spain Sweden Switzerland UK Uruguay USA Venezuela
17
NOTE
Approved Countries/Regions for use for the Toshiba Mini PCI Wireless LAN Card
This equipment is approved to the radio standard by the countries/regions in the following table.
Do not use this equipment except in the countries/regions in the following table.
Australia Austria Belgium Canada Denmark Finland France Germany Greece Hong Kong Iceland Ireland Italy Japan Liechtenstein Luxembourg Malaysia Netherlands New Zealand Norway Philippines Portugal Singapore Spain Sweden Switzerland Thailand UK USA
Approved Countries/Regions for use for the Intel® PRO/Wireless 3945ABG Network Connection
This equipment is approved to the radio standard by the countries/regions in the following table.
Do not use this equipment except in the countries/regions in the following table.
An adhoc mode is available in Ch1-Ch11(802.11b/g), An Infrastructure mode is available in Ch1-Ch11 (802.11b/g) Ch36,40,44,48,52,56,60,64,149,153,157,161,165 (802.11a) Wake-up on wireless lan function is not available in battery mode.
802.11b/g (2.4 GHz) Australia Brunei Canada
Chile Hong Kong India Indonesia Malaysia Mexico New Zealand Saudi Arabia Taiwan USA Venezuela Vietnam
18
NOTE
802.11a (5 GHz) Australia Brunei Canada
Chile Hong Kong India Indonesia Malaysia Mexico New Zealand Saudi Arabia Taiwan USA Venezuela Vietnam
Approved Countries/Regions for the Intel® Wireless Wi-Fi® Link 4965AGN
This equipment is approved to the radio standard by the countries/regions in the following table.
Do not use this equipment except in the countries/regions in the following table.
An adhoc mode is available in Ch1-Ch11(802.11b/g), An Infrastructure mode is available in Ch1-Ch11 (802.11b/g) Ch36,40,44,48,52,56,60,64,149,153,157,161,165 (802.11a).
802.11b/g (2.4 GHz) Canada USA
802.11a (5 GHz) Canada USA
11a, 11b, 11g and 11n wireless are based on IEEE 802.11a, 802.11b, 802.11g and 802.11n respectively. The IEEE 802.11n specification has not been finalized and is currently in draft release. The TOSHIBA 11a/b/g/n Wireless LAN Adapters are based on the Draft Release, Version 1.0, of the IEEE 802.11n specification. An adapter with 11a/b, 11a/b/g, or 11a/b/g/n can communicate on any of its supported formats; the actual connection will be based on the access point to which it connects.
Connection compatibility with the wireless equipment in Draft 11n mode is not guaranteed.
The Draft 11n function cannot be used with WEP/TKIP. Draft 11n mode can be used only with WPA-PSK(AES) mode or no security mode.
Bluetooth® Wireless Technology Interoperability
Bluetooth® Cards from TOSHIBA are designed to be interoperable with any
product with Bluetooth wireless technology that is based on Frequency Hopping Spread Spectrum (FHSS) radio technology, and is compliant to:
Bluetooth Specification as defined and approved by The Bluetooth Special
Interest Group.
Logo certification with Bluetooth wireless technology as defined by The
Bluetooth Special Interest Group.
Bluetooth wireless technology is a new innovative technology, and TOSHIBA has not confirmed compatibility of its Bluetooth products with all computers and/or equipment using Bluetooth wireless technology other than TOSHIBA portable computers.
Always use Bluetooth cards from TOSHIBA in order to enable wireless networks over two or more (up to a total of seven) TOSHIBA portable computers using these cards. Please contact TOSHIBA computer product support on Web site http://www.toshiba-europe.com/computers/tnt/ bluetooth.htm in Europe or pcsupport.toshiba.com in the United States for more information.
19
When you use Bluetooth cards from TOSHIBA close to 2.4 GHz Wireless LAN devices, Bluetooth transmissions might slow down or cause errors. If you detect certain interference while you use Bluetooth cards from TOSHIBA, always change the frequency, move your computer to the area outside of the interference range of 2.4 GHz Wireless LAN devices (40 meters/43.74 yards or more) or stop transmitting from your computer. Please contact TOSHIBA computer product support on Web site http://www.toshiba-europe.com/ computers/tnt/bluetooth.htm in Europe or pcsupport.toshiba.com in the United States for more information.
Bluetooth and Wireless LAN devices operate within the same radio frequency range and may interfere with one another. If you use Bluetooth and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection. If you should experience any such problem, immediately turn off either one of your Bluetooth or Wireless LAN. Please contact Toshiba computer product support on Web site http://www.toshiba-europe.com/computers/tnt/ bluetooth.htm in Europe or pcsupport.toshiba.com in the United States for more information.
20
Approved Countries/Regions for use (Bluetooth® wireless technology)
Bluetooth® Card from Toshiba equipment is approved to the radio standard by the
countries/regions in the following table.
Do not use this equipment except in the countries/regions in the following table.
Australia Austria Belgium Bulgaria Canada China Cyprus Czech Republic Denmark Egypt Estonia Finland France Germany Greece Hong Kong Hungary Iceland Ireland Italy Japan Jordan Korea Kuwait Latvia Lebanon Liechtenstein Lithuania Luxembourg Malta Netherlands New Zealand Norway Oman Philippines Poland Portugal Singapore Slovakia Slovenia Spain Sweden Switzerland Thailand UK USA
Bluetooth® Wireless Technology and Your Health
The products with Bluetooth® wireless technology, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by devices with Bluetooth wireless technology however is much less than the electromagnetic energy emitted by wireless devices such as mobile phones.
Because products with Bluetooth wireless technology operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Bluetooth wireless technology is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.
21
In some situations or environments, the use of Bluetooth wireless technology may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include:
Using the equipment with Bluetooth wireless technology on board
airplanes, or
In any other environment where the risk of interference to other devices or
services is perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use the device with Bluetooth wireless technology prior to turning on the equipment.
Exposure to Radio Frequency Radiation The radiated output power of the Bluetooth Card from TOSHIBA is far below
the FCC radio frequency exposure limits. Nevertheless, the Bluetooth Card from TOSHIBA shall be used in such a manner that the potential for human contact during normal operation is minimized.
Regulatory statements
This product complies with any mandatory product specification in any country/ region where the product is sold. In addition, the product complies with the following:
European Union (EU) and EFTA
This equipment complies with the R&TTE directive 1999/5/EC and has been provided with the CE mark accordingly.
Canada — Industry Canada (IC)
This device complies with RSS 210 of Industry Canada.
22
Taiwan
Article 14 Unless approved, for any model accredited low power radio frequency
electric machinery, any company, trader or user shall not change the frequency, increase the power or change the features and functions of the original design.
Article 17 Any use of low power radio frequency electric machinery shall not affect
aviation safety and interfere with legal communications. In the event interference is caused, the use of such electric machinery shall be immediately discontinued. Operation of such products can be resumed only when they are modified and can no longer cause interference.
The legal communications mentioned in the above item refer to radio communications operated in accordance with telecommunication laws and regulations.
Low power radio frequency electric machinery shall resist against interference from legal communications or from industrial, scientific and medical radio emission electric machinery.
Using this Equipment in Japan
In Japan, the frequency bandwidth of 2,400 MHz to 2,483.5 MHz for second generation low-power data communication systems such as this equipment overlaps that of mobile object identification systems (premises radio station and specified low-power radio station).
1. Sticker
Please put the following sticker on devices incorporating this product.
The frequency bandwidth of this equipment may operate within the same range as industrial devices, scientific devices, medical devices, microwave ovens, licensed radio stations and non-licensed specified low-power radio stations for mobile object identification systems (RFID) used in factory product lines (Other Radio Stations).
1. Before using this equipment, ensure that it does not interfere with any of the equipment listed above.
2. If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions.
3. Contact TOSHIBA Direct PC if you have problems with interference caused by this product to Other Radio Stations.
2. Indication The indication shown below appears on this equipment.
23
(1) (2)
(3)
2.4FH1
(4)
1 2.4: This equipment uses a frequency of 2.4 GHz. 2 FH: This equipment uses FH-SS modulation. 3 The interference range of this equipment is less than 10m. 4 This equipment uses a frequency bandwidth from 2,400 MHz to
2,483.5 MHz. It is impossible to avoid the band of mobile object identification systems.
3. TOSHIBA Direct PC Monday – Friday: 10:00 – 17:00 Toll Free Tel: 0120-15-1048 Direct Dial: 03-3457-4850 Fax: 03-3457-4868
Device Authorization
This device obtains the Technical Regulation Conformity Certification, and it belongs to the device class of radio equipment of low-power data communication system radio station stipulated in the Radio Law of Japan.
The Name of the radio equipment: EYXF2CS TELECOM ENGINEERING CENTER Approval Number: 01NYDA1305 The following restrictions apply:
Do not disassemble or modify the device. Do not install the embedded wireless module into other device.
24
Optical Drive Safety Instructions
This appliance contains a laser system and is classified as a CLASS 1 LASER PRODUCT. To use this model properly, read the user’s guide carefully and keep it for your future reference.
Never attempt to disassemble, adjust or repair a HD DVD, CD/DVD drive, CD-RW drive, Multi-drive or any other optical drive. You could damage the drive. You would also be exposed to laser light or other safety hazards, resulting in serious injury. Always contact an authorized Toshiba service provider, if any repair or adjustment is required.
Location of the Required Label
(Sample shown below. Location of the label and manufacturing information may vary.)
Copyright
This guide is copyrighted by Toshiba America Information Systems, Inc. with all rights reserved. Under the copyright laws, this guide cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.
©2007 by Toshiba America Information Systems, Inc. All rights reserved.
Export Administration Regulation
This document contains technical data that may be controlled under the U.S. Export Administration Regulations, and may be subject to the approval of the U.S. Department of Commerce prior to export. Any export, directly or indirectly, in contravention of the U.S. Export Administration Regulations is prohibited.
Notice
The information contained in this manual, including but not limited to any product specifications, is subject to change without notice.
TOSHIBA CORPORATION AND TOSHIBA AMERICA INFORMATION SYSTEMS, INC. (TOSHIBA) PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL OR ANY OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO ANY OF THE FOREGOING. TOSHIBA ASSUMES NO LIABILITY FOR ANY DAMAGES INCURRED DIRECTLY OR INDIRECTLY FROM ANY TECHNICAL OR TYPOGRAPHICAL ERRORS OR OMISSIONS CONTAINED HEREIN OR FOR DISCREPANCIES BETWEEN THE PRODUCT AND THE MANUAL. IN NO EVENT SHALL TOSHIBA BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, OR EXEMPLARY DAMAGES, WHETHER BASED ON TORT, CONTRACT OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL OR ANY OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
25
26
Trademarks
Tecra is a registered trademark of Toshiba America Information Systems, Inc. and/or Toshiba Corporation.
Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and/or other countries.
DirectX, Active Desktop, DirectShow, and Windows Media are registered trademarks of Microsoft Corporation.
ConfigFree is a trademark of Toshiba Corporation. Wi-Fi is a registered trademark of the Wi-Fi Alliance. Intel, Intel Core, Celeron, Centrino and Pentium are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in the United States and other countries.
TouchPad is a trademark of Synaptics, Inc. Adobe and Photoshop are either registered trademarks or trademarks of Adobe
Systems Incorporated in the United States and/or other countries. Memory Stick, Memory Stick PRO, and i.LINK are trademarks or registered
trademarks of Sony Corporation. Secure Digital and SD are trademarks of SD Card Association. MultiMediaCard and MMC are trademarks of MultiMediaCard Association. xD-Picture Card is a trademark of Fuji Photo Film, Co., Ltd. ExpressCard is a trademark of PCMCIA. Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Toshiba is under license. Other trademarks and trade names are those of their respective owners.
All other brand and product names are trademarks or registered trademarks of their respective companies.
Computer Disposal Information
Lamp contains mercury. Disposal of this product may be regulated due to environmental considerations. For disposal, reuse or recycling information, please contact your local government or the Electronic Industries Alliance at
www.eiae.org.
Contents
Introduction................................................................................ 35
This guide ...............................................................36
Safety icons ............................................................37
Other icons used...............................................37
Other documentation ..............................................38
Service options .......................................................38
Chapter 1: Getting Started......................................................... 39
Selecting a place to work ........................................39
Creating a computer-friendly environment........39
Keeping yourself comfortable ...........................40
Precautions.......................................................40
Important information on your computer’s
cooling fan..................................................41
Setting up your computer .......................................42
Setting up your software...................................42
Registering your computer with Toshiba ................43
Adding optional external devices.............................43
Connecting to a power source ................................44
Charging the main battery.......................................46
27
28
Contents
Using the computer for the first time......................47
Opening the display panel.................................47
Your computer’s features and specifications ....48
Turning on the power .......................................48
Adding memory (optional)......................................49
Installing a memory module .............................50
Removing a memory module............................55
Checking total memory.....................................56
Hard Drive Recovery Utilities ..................................57
Creating Recovery CDs/DVDs ...........................57
Hard Disk Drive Recovery using the
recovery partition........................................59
Hard Disk Drive Recovery using the
Recovery media ..........................................63
Installing drivers and applications.....................66
Using the TouchPad™.............................................66
Scrolling with the TouchPad™ ..........................67
Control buttons.................................................67
Disabling or enabling the TouchPad™ ..............67
Using external display devices................................67
Directing the display output when you
turn on the computer..................................68
Adjusting the quality of the external display......69
Using an external keyboard.....................................69
Using a mouse........................................................69
Connecting a printer ...............................................69
Setting up a printer ...........................................70
Connecting an optional external diskette drive........71
Turning off the computer........................................71
Options for turning off the computer ................72
Using the Turn Off Computer or Shut Down
Using and configuring Hibernation mode .........76
Using and configuring Standby mode...............77
Closing the display panel ..................................78
Customizing your computer’s settings....................78
commands..................................................74
Contents
29
Caring for your computer........................................79
Cleaning the computer......................................79
Moving the computer........................................79
Using a computer lock......................................79
Chapter 2: Learning the Basics................................................. 81
Computing tips .......................................................81
Using the keyboard.................................................83
Character keys .................................................83
Making your keyboard emulate a full-size
keyboard.....................................................83
Ctrl, Fn, and Alt keys.........................................84
Function keys....................................................84
Special Windows® keys ...................................84
Overlay keys .....................................................85
Using the overlay to type numeric data.............85
Starting a program..................................................86
Starting a program from the Start menu...........86
Starting a program from Windows® Explorer....87
Starting a program from the Run dialog box ....88
Saving your work....................................................88
Printing your work ..................................................90
Backing up your work .............................................91
Restoring your work .........................................92
Using the optical drive ............................................92
Optical drive components .................................93
Inserting a compact disc ..................................93
Playing an audio CD..........................................95
Playing optical media........................................96
Creating a CD/DVD............................................96
Removing a disc with the computer on.............97
Removing a disc with the computer off ............97
Caring for CD or DVD discs .............................98
Toshiba’s online resources .....................................98
Contents
30
Chapter 3: Mobile Computing...................................................99
Toshiba’s energy-saver design................................99
Running the computer on battery power ..............100
Battery Notice .................................................100
Power management........................................101
Using additional batteries ...............................102
Charging batteries.................................................102
Charging the main battery...............................102
Charging the RTC battery................................103
Monitoring main battery power.............................104
Determining remaining battery power.............106
What to do when the main battery runs low ...106
Setting battery alarms.....................................107
Conserving battery power ..............................107
Power Profiles ................................................108
Using a hot key to set the Power Profile .........109
Changing the main battery....................................109
Removing the battery from the computer .......110
Inserting a charged battery .............................111
Taking care of your battery ...................................113
Safety precautions ..........................................113
Maintaining your battery.................................114
Disposing of used batteries ..................................115
Traveling tips ........................................................116
Chapter 4: Exploring Your Computer’s Features...................117
Exploring the desktop ...........................................117
Finding your way around the desktop .............118
Setting up for communications.............................120
Connecting a modem to a telephone line ........121
Connecting your computer to a network.........122
An overview of using the Internet .........................124
The Internet ....................................................124
The World Wide Web .....................................125
Internet Service Providers ..............................125
Connecting to the Internet .............................125
Contents
31
Surfing the Internet.........................................126
Internet features..............................................126
Uploading to, and downloading files from,
the Internet ..............................................127
Exploring audio features .......................................127
Recording sounds...........................................127
Using external speakers or headphones..........128
Web Cam ..............................................................129
Using PC Cards.....................................................129
Inserting a PC Card.........................................129
Removing a PC Card.......................................130
Setting up a PC Card for your computer .........131
Using an ExpressCard™........................................131
Inserting an ExpressCard™.............................131
Removing an ExpressCard™...........................132
Using the Bridge Media Adapter Slot ....................133
Inserting memory media.................................133
Removing memory media...............................134
Using the i.LINK® port ..........................................134
Chapter 5: Utilities....................................................................135
TOSHIBA Assist ....................................................136
Connect...........................................................137
Secure.............................................................138
Protect & Fix...................................................139
Optimize..........................................................140
TOSHIBA Application Installer...............................141
Setting passwords ................................................142
Using an instant password..............................142
Using a supervisor password..........................142
Using a user password ...................................144
Deleting a user password................................145
TOSHIBA PC Diagnostic Tool Utility......................146
TOSHIBA HDD Protection Utility ...........................147
TOSHIBA SD™ Memory Card Format Utility .........148
TOSHIBA Power Saver..........................................149
32
Contents
Preset Power Profiles .....................................150
Quickly creating a new power profile ..............150
Customizing a power profile ...........................150
Mouse Utility ........................................................151
Toshiba Hardware Setup.......................................152
TOSHIBA Zooming Utility......................................153
Toshiba Button Controls .......................................155
CD/DVD Drive Acoustic Silencer ...........................156
TOSHIBA Accessibility ..........................................157
Fingerprint Authentication Utility...........................158
Fingerprint utility limitations ...........................158
Fingerprint Enrollment ....................................158
Fingerprint Logon ...........................................160
Power-on Security ..........................................160
Control Center.................................................161
Password Bank ...............................................163
Care and maintenance of your fingerprint
reader .......................................................167
Fingerprint reader limitations..........................168
Chapter 6: If Something Goes Wrong....................................169
Problems that are easy to fix ................................169
Problems when you turn on the computer............171
The Windows® operating system is not working ..173
Using Startup options to fix problems ............173
Internet problems ...........................................174
The Windows® operating system can
help you....................................................175
Resolving a hardware conflict...............................175
A plan of action...............................................175
Resolving hardware conflicts on your own .....176
Fixing a problem with Device Manager ...........177
Memory problems ..........................................179
Power and the batteries ..................................179
Keyboard problems.........................................181
Display problems............................................181
Contents
33
Disk drive problems........................................183
Optical drive problems....................................185
Sound system problems.................................186
PC Card problems...........................................186
ExpressCard™ problems.................................189
Printer problems.............................................191
Modem problems............................................192
Wireless networking problems .......................193
DVD operating problems.......................................195
Develop good computing habits ...........................197
Data and system configuration backup in the
Windows® operating system.....................198
If you need further assistance...............................202
Before you contact Toshiba ............................202
Contacting Toshiba .........................................203
Other Toshiba Internet Web sites..........................203
Toshiba’s worldwide offices..................................204
Appendix A: Hot Keys..............................................................206
Volume Mute ........................................................206
Password security ................................................206
Without a password........................................206
With a password.............................................207
Maintaining security when the battery is
not fully charged.......................................207
Power profile .......................................................208
Standby mode.......................................................208
Hibernation mode ................................................209
Display modes ......................................................210
Display brightness ................................................210
Disabling or enabling wireless devices..................211
Disabling or enabling the TouchPad .....................211
Zooming applications in/out .................................211
Keyboard hot keys ...............................................212
Contents
34
Appendix B: Power Cord/Cable Connectors..........................213
Appendix C: Using ConfigFree™ with your
Toshiba Computer ..............................................214
Getting Started......................................................215
Starting ConfigFree .........................................215
ConfigFree Utilities................................................217
Connectivity Doctor ........................................217
Search for Wireless Devices ...........................219
Profile Settings ...............................................224
ConfigFree SUMMIT........................................226
Quick Connect.................................................230
Using the Automatic Switch..................................232
Semi-Automatic Switch Feature............................233
Glossary....................................................................................234
Index..........................................................................................248
Introduction
NOTE
NOTE
Welcome to the world of powerful, portable, multimedia computing. With your Toshiba notebook computer, your work and entertainment can accompany you wherever you go.
This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment (RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements and verifies its suppliers’ commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
35
36
NOTE
This guide
This guide introduces the computer’s features. You can:
Introduction
This guide
The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba’s Web site at pcsupport.toshiba.com.
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at
pcsupport.toshiba.com.
Read the entire guide from beginning to end. Skim through and stop when a topic interests you. Use the table of contents and the index to find specific
information.
Safety icons
NOTE
This manual contains safety instructions that must be observed to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and icons highlight these instructions as follows:
Introduction
Safety icons
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
37
Indicates a potentially hazardous situation which, if not avoided, may result in property damage.
Provides important information.
Other icons used
Additional icons highlight other helpful or educational information:
TECHNICAL NOTE: This icon indicates technical information about the computer.
HINT: This icon indicates helpful hints and tips.
DEFINITION: This icon indicates the definition of a term used in the text.
Introduction
38
Other documentation
Other documentation
Your computer comes with the following documentation:
An electronic version of the user’s guide (this document) It may also contain guides for other programs that may come
with your system.
For accessory information, visit Toshiba’s Web site at
accessories.toshiba.com.
Service options
Toshiba offers a full line of optional service programs to complement its limited warranty. Toshiba’s standard limited warranty, extended warranty, and service upgrade terms and conditions are available at warranty.toshiba.com.
To stay current on the most recent software and hardware options for your computer, and for other product information, be sure to regularly check the Toshiba Web site at pcsupport.toshiba.com.
If you have a problem or need to contact Toshiba, see “If Something
Goes Wrong” on page 169.
Chapter 1
Getting Started
This chapter provides tips for working comfortably, summarizes how to connect components, and explains what to do the first time you use your notebook computer.
Selecting a place to work
Your computer is portable and designed to be used in a variety of circumstances and locations.
Creating a computer-friendly environment
Place the computer on a flat surface that is large enough for the computer and any other items you are using, such as a printer. Leave enough space around the computer and other equipment to provide adequate ventilation. Otherwise, they may overheat.
To keep your computer in prime operating condition, protect your work area from:
Dust, moisture, and direct sunlight. Equipment that generates a strong electromagnetic field, such
as stereo speakers (other than speakers that are connected to the computer) or speakerphones.
Rapid changes in temperature or humidity and sources of
temperature change such as air conditioner vents or heaters.
39
Getting Started
40
Selecting a place to work
Extreme heat, cold, or humidity. Liquids and corrosive chemicals.
Keeping yourself comfortable
The Toshiba Instruction Manual for Safety and Comfort, that shipped with your computer, contains helpful information for setting up your work environment and tips for working comfortably throughout the day.
Precautions
Your computer is designed to provide optimum safety and ease of use, and to withstand the rigors of travel. You should observe certain precautions to further reduce the risk of personal injury or damage to the computer.
Avoid prolonged physical contact with the underside or surface
of the computer.
Never allow any liquids to spill into any part of your computer, and never expose the computer to rain, water, seawater or moisture. Exposure to liquid or moisture can cause electric shock or fire, resulting in damage or serious injury. If any of these eventualities should accidentally occur, immediately:
1. Turn off the computer.
2. Disconnect the AC adaptor from the power plug socket and computer.
3. Remove the battery pack.
Failure to follow these instructions could result in serious injury or permanent damage to the computer.
Do not turn on the power again until you have taken the computer to an authorized service center.
Computer base and palm rest can become hot! Avoid prolonged contact to prevent heat injury to skin.
Read the enclosed Instruction Manual for Safety and Comfort.
Never place a heavy object on the computer and be careful not to drop a heavy object onto the computer. It could damage the computer or cause system failure.
Getting Started
NOTE
Selecting a place to work
Never turn off the computer if a drive light indicates a drive is active.
Turning off the computer while it is reading from or writing to a disk/disc or flash media may damage the disk/disc or flash media, the drive, or both.
Keep the computer and disks away from objects that generate
strong magnetic fields, such as large stereo speakers. Information on some disks is stored magnetically. Placing a
magnet too close to a disk can erase important files.
Handle discs carefully. Avoid touching the surface of the disc. Grasp it by its center hole and edge. If you handle the disc incorrectly, you could damage the disc and possibly lose data.
Scan all new files for viruses.
This precaution is especially important for files you receive via email or download from the Internet. Occasionally, even new programs you buy from a supplier may contain a computer virus. You need a special program to check for viruses. Ask your dealer to help you.
41
Important information on your computer’s cooling fan
Your computer may have a CPU cooling fan that cools the CPU by drawing outside air into the computer.
Always make sure your computer and AC adaptor have adequate ventilation and are protected from overheating when the power is turned on or when an AC adaptor is connected to a power outlet (even if your computer is in Standby mode). In this condition, observe the following:
Never cover your computer or AC adaptor with any object. Never place your computer or AC adaptor near a heat source,
such as an electric blanket or heater.
Never block the air vents. Always operate your computer on a hard surface. Using your
computer on a carpet or other soft material can block the vents.
Overheating your computer or AC adaptor could cause system failure, computer or AC adaptor damage or a fire, possibly resulting in serious injury.
The cooling fan location will vary depending on the computer.
Getting Started
NOTE
42
Setting up your computer
Setting up your computer
TECHNICAL NOTE: You must complete all setup steps up to and including “Setting up your software” on page 42 before adding external or internal components to your computer. These components include, but are not limited to, a mouse, keyboard, printer, memory, and PC Cards.
Your computer contains a rechargeable main battery that needs to be charged before you can use it.
To use external power or to charge the battery you must attach the AC adaptor. See “Connecting to a power source” on page 44.
Setting up your software
When you turn on the computer for the first time, do not turn off the power again until the operating system has loaded completely.
The names of windows displayed, and the order in which windows appear, may vary according to your software setup choices.
The first time you turn on your computer, the Setup Wizard guides you through steps to set up your software.
1 From the Welcome screen click Next to enter the Setup
Wizard.
2 Confirm acceptance of Microsoft’s End User License
Agreement and click Next.
3 Select the appropriate option from the Help Protect Your
Computer screen and click Next.
4 Enter the computer name and description and click Next or Skip. 5 Select how your computer will connect to the Internet and click Next.
The computer will pause for a moment while checking for an
Internet connection.
If an Internet connection could not be found, a window will
display the message: “An Internet connection could not be
chosen.” Click Next to continue.
Registering your computer with Toshiba
NOTE
NOTE
NOTE
If you are connecting your computer to a network, consult your system administrator before you choose your computer name and network settings.
6 Follow the remaining screen prompts to complete the setup
process.
7 Click Start when the Thank You message appears.
The Windows performance, and then may restart your computer.
®
operating system checks the system’s
Registering your computer with Toshiba
Product registration is strongly recommended, and allows Toshiba to send you periodic updates, announcements, and special offers applicable to your product. Product registration can be completed during the initial start up process of your computer. If you decide not to register at that time, you can either double-click the Tos hi ba Registration icon on your desktop or go to the Toshiba Web site at
www.register.toshiba.com at a later time. Failure to complete
Product Registration will not diminish Customer rights under the Toshiba limited Warranty.
Getting Started
43
To register online, you must be connected to the Internet.
Adding optional external devices
Before adding external devices or memory, Toshiba recommends setting up your software. See “Setting up your software” on page 42.
After starting your computer for the first time you may want to:
Add more memory (see “Adding memory (optional)” on
page 49)
Connect a mouse (see “Using a mouse” on page 69) Connect a full-size keyboard (see “Using an external
keyboard” on page 69)
Connect an external monitor (see “Using external display
devices” on page 67)
Connect a local printer (see “Connecting a printer” on page 69)
Getting Started
44
Connecting to a power source
Connect an optional external disk drive (see “Connecting an
optional external diskette drive” on page 71)
Install PC Cards (see “Using PC Cards” on page 129)
Connecting to a power source
Your computer requires power to operate. Use the power cord/cable and AC adaptor to connect the computer to a live electrical outlet, or to charge the computer’s battery.
Never pull on a power cord/cable to remove a plug from a socket. Always grasp the plug directly. Failure to follow this instruction may damage the cord/cable, and/or result in a fire or electric shock, possibly resulting in serious injury.
Always confirm that the power plug (and extension cable plug if used) has been fully inserted into the socket, to ensure a secure electrical connection. Failure to do so may result in a fire or electric shock, possibly resulting in serious injury.
Be careful if you use a multiple connector. An overload on one socket could cause a fire or electric shock, possibly resulting in serious injury.
Always use the TOSHIBA AC adaptor that was provided with your computer and the TOSHIBA Battery Charger (that may have been provided with your computer), or use AC adaptors and battery chargers specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor or Battery Charger could cause fire or damage to the computer possibly resulting in serious injury. TOSHIBA assumes no liability for any damage caused by use of an incompatible adaptor or charger.
Power cord/cable
(Sample Illustration) Power cord/cable and AC adaptor
AC adaptor
AC adaptor cord
Getting Started
_
Connecting to a power source
45
To connect AC power to the computer:
1 Connect the power cord/cable to the AC adaptor.
(Sample Illustration) Connecting the power cord/cable to the AC adaptor
Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling.
+
2 Plug the AC adaptor cord into the DC-IN on the back of the
computer.
(Sample Illustration) Connecting the AC adaptor cord to the computer
3 Connect the power cord/cable to a live electrical outlet.
The AC power light on the indicator panel glows blue.
Never attempt to connect or disconnect a power plug with wet hands. Failure to follow this instruction could result in an electric shock, possibly resulting in serious injury.
46
NOTE
Getting Started
Charging the main battery
The computer’s main battery light gives you an indication of
the main battery’s current charge:
Glows amber while the main battery is being charged (AC
adaptor connected)
Glows blue when the main battery is fully charged
Is unlit when the main battery has discharged, the battery
is not charging, or the AC adaptor is not plugged into the computer or AC outlet
Flashes amber when the main battery charge is low and it
is time to recharge the main battery or plug in the AC adaptor
If the AC power light flashes amber during charging, either the main battery is malfunctioning, or it is not receiving correct input from the AC power supply.
Disconnect the AC power cord/cable and remove the main battery pack. See “Changing the main battery” on page 109 for information on replacing the main battery.
Charging the main battery
Your computer came with its battery already installed. Before using the battery to power the computer, you must charge the battery.
To charge the battery, leave the computer plugged into an AC power source with the computer turned off until the battery light glows blue. After that, the battery will be completely charged and ready to power the computer.
Once the battery is charged for the first time, avoid leaving the computer plugged in and turned off for more than a few hours at a time. Continuing to charge a fully charged battery can damage the battery.
TECHNICAL NOTE: The recharging of the battery cannot occur when your computer is using all of the power provided by the AC adaptor to run applications, features, and devices. Your computer’s Power Options utility can be used to select a power level setting that reduces the power required for system operation and will allow the battery to recharge.
Using the computer for the first time
NOTE
NOTE
Battery life and charge time may vary depending on the applications, power management settings, and features used.
Using the computer for the first time
The computer is now ready for you to turn it on and begin using it.
Opening the display panel
1 Facing the front of the computer, locate the center of the
display panel.
2 Gently raise the panel. 3 Adjust the display to a comfortable viewing angle.
Getting Started
47
(Sample Illustration) Opening the display panel
When opening or closing the display panel, place one hand on the palm rest to hold the computer in place and use the other hand to slowly open or close the display panel.
To avoid damaging the display panel, do not force it beyond the point where it moves easily and never lift the computer by the display panel.
Do not press or push on the display panel and be careful to remove any pens or other objects from the keyboard area before closing the display panel.
Getting Started
48
Using the computer for the first time
Small bright dots may appear on your screen display when you turn on your computer. Your display contains an extremely large number of thin-film transistors (TFT) and is manufactured using high­precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology. When the computer is operated on battery power, the screen will dim and you may not be able to increase the brightness of the screen while on battery power.
Your computer’s features and specifications
Certain notebook chassis are designed to accommodate all possible configurations for an entire product Series. Your select model may not have all the features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have selected all those features.
This information applies to all the features and icons described in this guide.
Below are examples of some of the many possible icons used on your computer:
(Sample Illustration) System icons
Turning on the power
To turn on the computer:
1 Make sure any external devices (such as the AC adaptor, if you
plan to use AC power rather than battery power) are properly
connected and ready.
2 Check to ensure that all optical drives are empty.
Getting Started
NOTE
Adding memory (optional)
3 Press and hold the power button in until the on/off light on the
system indicator panel glows blue—about one second.
(Sample Illustration) Turning on the power
The preinstalled operating system will load automatically.
49
When you turn on the computer for the first time, do not turn off the power again until the operating system has loaded completely.
Adding memory (optional)
HINT: To purchase additional memory modules, see the accessories information packaged with your system or visit
accessories.toshiba.com.
Your computer comes with enough memory to run most of today’s popular applications. You may want to increase the computer’s memory if you use complex software or process large amounts of data.
Before adding external devices or memory, Toshiba recommends setting up your software. See “Setting up your software” on page 42.
Getting Started
NOTE
50
Adding memory (optional)
Installing a memory module
Memory modules can be installed in the memory module slots on the base of the computer. You will need a small Phillips screwdriver for this procedure.
If the computer has been running recently, the memory module may be hot. The surrounding area may also be hot. Allow the module to cool to room temperature before replacing it. Avoid touching the cover, the module, and the surrounding area before they have cooled. Failure to follow these directions could result in minor bodily injury.
To avoid damaging the computer’s screws, use a small Phillips screwdriver that is in good condition.
Installing a memory module with the computer’s power on may damage the computer, the module, or both.
The computer has two memory slots—Slot A and Slot B. You can install one or two memory modules.
Before you install or remove a memory module, turn off the computer using the Start menu. If you install or remove a memory module while the computer is in Standby or Hibernation mode, data will be lost.
For this model, Slot A is the bottom slot. Slot B is the top slot. If only one memory module is to be installed, it must be installed in slot A.
If the computer is on, begin at step 1; otherwise, skip to step 3.
1 Click Start, and then Turn off computer or Shut Down
(depending on the system).
The Turn off computer or Shut Down window appears.
2 Click Turn Off or Shut Down.
The operating system turns off the computer.
3 Unplug and remove any cables connected to the computer,
including the AC adaptor.
Getting Started
Adding memory (optional)
4 Remove the main battery. For information on removing the
main battery, see “Removing the battery from the computer”
on page 110.
5 Close the display panel and turn the computer upside down to
locate the memory module slot cover.
Memory module slot cover
51
Front of computer
(Sample Illustration) Locating the memory module slot cover
6 Using a small Phillips screwdriver, loosen the captive screws
that secure the memory module slot cover.
Front of computer
(Sample Illustration) Removing the memory module slot cover
52
NOTE
NOTE
NOTE
Getting Started
Adding memory (optional)
7 Remove the memory module slot cover. 8 Place the screws and the cover in a safe place so that you can
retrieve them later.
Static electricity can damage the memory module. Before you handle the module, touch a grounded metal surface to discharge any static electricity you may have built up.
Avoid touching the connector on the memory module or on the computer. Grease or dust on the connector may cause memory access problems.
9 Carefully remove the new memory module from its antistatic
packaging, without touching its connector.
10 Locate an empty memory module slot on the underside of the
computer.
If no memory slot is available, you must remove a module by performing steps 2-3 of “Removing a memory module” on page 55.
If your system has the memory modules stacked on top of one another, you must remove the top module first before removing/installing the bottom module.
For this model, Slot A is the bottom slot. Slot B is the top slot. If only one memory module is to be installed, it must be installed in slot A.
11 Pick up the memory module by its sides, avoiding any contact
with its connector. Position the module toward the socket,
Getting Started
Adding memory (optional)
aligning the connector’s notch with the matching key in the socket.
notch
latch
connector
latch
key
(Sample Illustration) Aligning the memory module with the socket
12 Firmly press the memory module into the memory slot’s socket
at approximately a 30-degree angle (to the horizontal surface of the computer).
53
(Sample Illustration) Inserting the memory module into the socket
13 Once the module’s connector is fully inserted into the socket,
press downward on the top edge of the module to seat the module into the latches at the sides of the socket. These latches should “snap” into place securely with the corresponding cutouts in the side of the module. If the latches and cutouts do not line up correctly, repeat steps 12-13.
latch
latch
(Sample Illustration) Pressing down on the memory module
54
NOTE
Getting Started
Adding memory (optional)
Do not force the memory module into position. The memory
module should be completely inserted into the socket and level
when secured in place.
Slot B
Slot A
(Sample Illustration) Inserting the memory module into the slot
For this model, Slot A is the bottom slot. Slot B is the top slot. If only one memory module is to be installed, it must be installed in slot A.
14 Replace the memory module slot cover and secure it using the
screws.
15 Re-insert the main battery. For more information on inserting
the main battery, see “Inserting a charged battery” on page 111.
16 Turn the computer right side up. 17 Reconnect the cables. 18 Restart the computer.
TECHNICAL NOTE: You must have at least one memory module installed for the computer to work.
You can now continue setting up the computer. When the operating system has loaded, you can verify that the computer has recognized the additional memory module.
If you are adding extra memory after setting up the computer, verify that the computer has recognized it correctly as described in
“Checking total memory” on page 56.
Removing a memory module
NOTE
If you need to remove a memory module:
1 Complete steps 18 in “Installing a memory module” on
page 50 to shut down the computer and open the memory
module slot cover.
Do not try to remove a memory module with the computer turned on. You can damage the computer and the memory module.
Do not remove the memory module while the computer is in Standby or Hibernation mode. The computer could hang up the next time you turn it on and data in memory will be lost. In either of the above cases, the Standby configuration will not be saved.
The following message appears when you turn on the power: Warning: Resume Failure
Press Any Key to Continue
Getting Started
Adding memory (optional)
55
If the computer hangs up when you turn it on, perform the following: Press the power button and hold it down for at least ten seconds, then turn the power on again.
If your system has the memory modules stacked on top of one another, you must remove the top module first before removing/installing the bottom module.
2 Pull the latches away from the memory module.
The memory module pops up slightly.
3 Gently lift the memory module to a 30-degree angle and slide it
out of the slot.
Front of computer
(Sample Illustration) Removing the memory module
Memory slots
Getting Started
NOTE
56
Adding memory (optional)
4 Replace the memory module slot cover and secure it using the
screws.
5 Re-insert the main battery. For more information on inserting
the main battery, see “Inserting a charged battery” on page 111.
6 Turn the computer right side up. 7 Reconnect the cables. 8 Restart the computer.
TECHNICAL NOTE: You must have at least one memory module installed for the computer to work.
Checking total memory
When you add or remove a memory module, you can check that the computer has recognized the change. To do this:
1 Click Start, Control Panel, Performance and Maintenance,
and then System.
2 The General tab view automatically appears and shows total
memory. If the computer does not recognize the memory configuration, turn
off the computer and remove the memory module slot cover (complete steps 1-8 in “Installing a memory module” on page 50), and then check that the module is inserted completely into the socket and lined up squarely with the socket latches.
From time to time, Windows® will display a pop-up that says, “Windows feature to prevent programs or people from doing things on your computer without your permission. If you were trying to perform the action, click Continue; otherwise, click Cancel. If unsure, cancel and try again.
®
needs your permission to continue.” This is a security
Hard Drive Recovery Utilities
NOTE
NOTE
Hard Drive Recovery Utilities
(Available on certain models)
Your computer has been configured with a hard disk partition to allow you to recover your hard disk drive or reinstall selected applications and software features or utilities.
It is strongly recommended that you create recovery CDs/DVDs before using your system. For more information on creating Recovery media see “Creating Recovery CDs/DVDs” on page 57.
Using the HDD Recovery, you can:
Create Hard Drive Recovery CDs or DVDs using a writable
drive.
Recover your hard disk drive to the factory-set default.
Getting Started
57
Recover just your C: drive, leaving any other partitions you
may have created intact, for example, a D: drive.
Recover your hard disk drive to the factory-set default without
the HDD Recovery partition.
Delete your hard disk drive recovery partition without the risk
of losing your data.
Reinstall drivers and applications which were bundled with
your computer.
Creating Recovery CDs/DVDs
Depending on your system configuration, you may be able to copy the Hard Drive Recovery Utilities to CD or DVD which gives you the ability to recover your hard disk drive and reclaim additional hard disk space used to store the Hard Drive Recovery Utilities on your computer.
The system will prompt you to insert the appropriate number of blank CDs or DVDs to copy the Hard Drive Recovery Utilities. If your optical disc drive is not writable, contact Toshiba Customer Support to obtain the Recovery media for your system.
The Toshiba Global Support Centre in the United States is (800) 457-7777, outside the United States it is (949) 859-4273.
58
Getting Started
Hard Drive Recovery Utilities
To create recovery CDs/DVDs:
1 Double-click the Recovery Disc Creator icon on the
Windows
clicking Start, All Programs, and then Recovery Disc
Creator.
2 Select CD or DVD (to create Recovery media on CDs or
DVDs).
®
desktop. You can also launch the application by
(Sample Image) Recovery Disc Creator screen
3 Select the items you want to copy by clicking the check box
next to the item’s Name—recovery files, applications (original
bundled drivers and applications), or both the recovery files
and applications.
4 Click Create. 5 Insert the first blank CD or DVD into your writable optical
drive when prompted.
6 Follow the on-screen prompts for completing the copy process.
For more information on using the Recovery media you have created with the preceding steps see “Hard Disk Drive Recovery
using the Recovery media” on page 63.
Getting Started
Hard Drive Recovery Utilities
Hard Disk Drive Recovery using the recovery partition
You have the options of recovering your system using the Hard Drive Recovery partition to the factory-set default, or recovering just your C: drive and leaving other partitions (for example, a D: drive) intact, or changing the size of your C: drive and then recovering it.
To recover your hard disk drive using the utilities stored on your computer’s HDD:
1 Make sure the computer is turned off. 2 Press and hold the 0 (zero) key on your keyboard while
powering on the computer. When the computer powers on, the Toshiba Recovery Wizard screen displays.
59
(Sample Image) Toshiba Recovery Wizard screen
60
Getting Started
Hard Drive Recovery Utilities
Recovering the original factory image (recommended recovery method)
Recovering a hard disk drive to its out of box state deletes all partitions on the hard disk drive and your information will be lost. Be sure to save your work to external media first.
1 On the Toshiba Recovery Wizard screen, select Recovery of
Factory Default Software, and then click Next.
The Recovery of Factory Default Software screen appears.
(Sample Image) Recovery of Factory Default Software screen
2 Select Recover to out-of-box-state, and then click Next.
A confirmation message displays reminding you that all data
will be lost during the recovery process. Be sure to save your
work to external media before proceeding.
3 Click Next to begin the recovery.
Once complete, a message displays that the HDD has been
recovered.
4 Press any key on the keyboard to restart the computer.
Getting Started
Hard Drive Recovery Utilities
61
Erasing the hard disk
The Recovery Wizard allows you to delete all data and partitions from the hard disk.
To delete the data and partitions from your hard disk:
1 On the Toshiba Recovery Wizard screen, select Erase the
hard disk, and then click Next.
2 The next screen lists the two methods you can choose:
Delete all data and partitions from the hard disk—This
option deletes all of the data on the hard disk without overwriting the HDD.
Delete all partitions and overwrite all sectors on the
hard disk—This option deletes all data, then overwrites the entire HDD for security purposes. This may take several hours, depending on the size of your HDD.
(Sample Image) Erase the hard disk screen
3 Select the desired method, and then click Next.
A confirmation message displays reminding you that all data will be lost. Be sure you have saved your work to external media before proceeding.
4 Click Next to begin deleting the HDD.
When the process is completed, a message displays informing you that the HDD has been deleted.
5 Press any key on the keyboard to restart the computer.
62
Getting Started
Hard Drive Recovery Utilities
Recovering the C: partition of the HDD without changing the current partition size
Recovering the C: drive to its factory default setting reformats your drive and your information on the recovered drive will be lost. Be sure to save your work to external media first. If you have created other partitions (for example, a D: drive) those partitions and any information on them will not be affected and will remain intact.
To recover only your C: drive:
1 On the Toshiba Recovery Wizard Screen, select Recovery of
Factory Default Software, and then click
2 Select Recover without changing the hard drive partitions.
A confirmation message appears, reminding you that all
information on the C: drive will be lost during the recovery
process. Be sure you have saved your work to external media
before proceeding.
Next.
3 Click Next to begin the restoration.
Once complete, a message displays that the HDD has been
recovered.
4 Press any key on your keyboard to restart the computer.
Recovering the C: partition with a user specified size
Resizing and recovering your C: drive to its factory default setting reformats all partitions on the HDD (for example, if you created a D: drive, it will be deleted during the recovery process) and your information will be lost. Be sure to save your work to external media first.
To resize and recover your C: drive:
1 On the Toshiba Recovery Wizard screen, select Recovery of
Factory Default Software, and then click Next.
2 Select Recover to a custom size partition. 3 Specify the size of the C: drive.
Press the Left/Right Arrow keys to increase/decrease the
C: drive size by 1 GB.
Press the Up/Down Arrow keys to increase/decrease the C:
drive size by 5 GB.
Getting Started
NOTE
Hard Drive Recovery Utilities
The size of the C: drive will display on the progress bar as you make your selections.
4 Click Next to begin the restoration. Once complete, a message
displays that the HDD has been recovered.
5 Press any key on your keyboard to restart the computer.
Hard Disk Drive Recovery using the Recovery media
If you need to recover your computer to its default factory state, you can rebuild the system using your Hard Drive Recovery Utilities.
To recover your hard disk drive using the utilities burned to CDs or DVDs (refer to “Creating Recovery CDs/DVDs” on page 57):
1 Insert the first recovery CD or DVD into your writable optical
drive and power on the computer.
63
2 When the initial screen displays, press
The boot menu appears.
3 Using the arrow keys, select the CD/DVD option and press
Enter.
F12.
(Sample Image) Toshiba HDD Recovery Utility screen
64
Getting Started
Hard Drive Recovery Utilities
Recovering the original factory image (recommended recovery method)
Recovering a hard disk drive to its factory default setting deletes all partitions on the hard disk drive and your information will be lost. Be sure to save your work to external media first.
1 Select Recovery of Factory Default Software, and then click
Next.
2 Select Recover to out-of-the-box-state, and then click Next.
A confirmation message displays, reminding you that all data
will be lost during the recovery process. Be sure you have
saved your work to external media before proceeding.
3 Click Next to begin the recovery process.
Once complete, a message displays that the HDD has been
recovered.
4 Press any key on the keyboard to restart the computer.
Recovering the C: partition of the HDD only
Recovering the C: drive to its factory default setting reformats your drive and your information on the recovered drive will be lost. Be sure to save your work to external media first. If you have created other partitions (for example, a D: drive) those partitions and any information on them will not be affected and will remain intact.
To recover only your C: drive:
1 Select Recovery of Factory Default Software, and then click
Next.
2 Select Recover without the hard drive partitions, and then
click Next.
A confirmation message appears, reminding you that all
information on the C: drive will be lost during the recovery
process. Be sure you have saved your work to external media
before proceeding.
3 Click Next to begin the restoration.
Once complete, a message displays that the HDD has been
recovered.
4 Press any key on your keyboard to restart the computer.
Getting Started
Hard Drive Recovery Utilities
65
Recovering the entire HDD without the HDD Recovery Area
This option recovers your C: drive without creating the HDD Recovery Utilities partition. This will increase the size of your C: drive
Recovering your C: drive to its factory default state without the recovery partition reformats all partitions on the HDD (for example, if you created a D: drive, it will be deleted during the recovery process) and your information will be lost. Be sure to save your work to external media first.
To recover your C: drive without the recovery partition:
1 Select Recovery of Factory Default Software, and then click
Next.
2 Select Recover using all HDD space (no HDD recovery
partition), and then click Next.
A confirmation message appears, reminding you that all partitions will be reformatted and all data will be lost during the recovery process. Be sure you have saved your work to external media before proceeding.
3 Click Yes to begin the restoration.
Once complete, a message displays that the HDD has been recovered.
4 Press any key on your keyboard to restart the computer.
Checking the HDD operating status
After restoring your hard disk drive, you can check its status as follows:
1 Click Start, and then click Control Panel. 2 Double-click the Administrative Tools icon. 3 Double-click the Computer Management icon. 4 Click Disk Management. 5 Highlight the hard disk drive in the Volume list to display its
status in the lower portion of the screen.
Getting Started
NOTE
66
Using the TouchPad™
Installing drivers and applications
The TOSHIBA Application Installer allows you to reinstall the drivers and applications that were originally bundled with your computer.
To reinstall drivers and applications:
1 Double-click the TOSHIBA Application Installer icon on the
Windows
2 Click Next. 3 Click the item(s) you want to install. 4 Click Install.
Follow the on-screen prompts to complete the installation process.
®
Using the TouchPad
The TouchPad™, the small, smooth, square cutout located in front of the keyboard, is sensitive to touch and enables you to move the cursor with the stroke of a finger. Simply move your finger on the TouchPad in the direction you would like to move the cursor:
To move the cursor to the top of the page, push your finger
forward on the TouchPad.
To move the cursor to the bottom of the page, drag your finger
toward yourself.
To move the cursor to the right side of the page, slide your
finger across the TouchPad from left to right.
desktop.
To move it to the left side, slide your finger from right to left.
Because the TouchPad is much smaller than the display screen, moving your cursor across the screen often means having to move your finger several times across the TouchPad in the preferred direction.
Once you have positioned your cursor, you can click it into place by either double-tapping the TouchPad or clicking the control buttons.
Getting Started
Using external display devices
67
Scrolling with the TouchPad
There are two active regions on the TouchPad™ that allow you to scroll as you would with any wheel device on a mouse or trackball.
To scroll vertically, run your finger up or down along the right edge of the TouchPad. To scroll horizontally, run your finger along the bottom edge of the TouchPad. This feature can be disabled or changed in the Mouse Properties dialog box.
Control buttons
When a step instructs you to click or choose an item, move the cursor to the item, then press and release the primary (left-hand) button. To double-click, press the primary button twice in rapid succession. The primary button usually corresponds to the left mouse button.
The function of the secondary (right-hand) button depends on the program you are using. It usually corresponds to the right mouse button (“right-clicking”). Check your program’s documentation to determine whether it uses the right mouse button.
Disabling or enabling the TouchPad
The TouchPad™ is enabled by default. To change the enable/disable TouchPad setting, press TouchPad. For more information, see “Disabling or enabling the
TouchPad” on page 211.
Fn + F9. This hot key enables/disables the
Using external display devices
Your computer comes with a built-in display, but you can also connect an external monitor or projector via the RGB (monitor) port.
Before connecting an external monitor or video projector, configure your computer for the type of device you are connecting. To do this, refer to the documentation for your operating system and devices.
Connecting an external monitor or projector
You can easily attach an external monitor or projector to your computer if you need a larger screen. To do this:
1 Connect the monitor’s video cable to the RGB (monitor) port
on the side of the computer.
2 Connect the device’s power cable to a live electrical outlet.
68
NOTE
Getting Started
Using external display devices
3 Turn on the external device. 4 Set the display mode by pressing
Display Properties settings.
Fn + F5, or by configuring the
Directing the display output when you turn on the computer
Once you have connected an external display device, you can choose to use the internal display only, the external device only, or both simultaneously. The quickest way to change the display output settings is to use the display hot key (
Some modes are only available with the appropriate device attached and turned on.
1 Press 2 While holding down
you want takes effect. Briefly pause each time you press the
key to allow time for the display to change.
This hot key cycles through the settings in the following order
(only the first option is available when you do not have an
external monitor attached):
Fn and F5 simultaneously.
Fn, press F5 repeatedly until the setting
Fn + F5):
F5
LCD—Internal display only
LCD + CRT—Internal display and external monitor
simultaneously
CRT—External monitor only
(Sample Image) Display options window
3 Release the
Fn key.
Using an external keyboard
NOTE
Adjusting the quality of the external display
To obtain the best picture quality from your television (or other video display device), you may need to adjust the video settings. See the video device documentation for additional configuration steps.
TECHNICAL NOTE: To use one of the simultaneous modes, you must set the resolution of the internal display panel to match the resolution of the external display device. The external display device must support a resolution of 800 x 600 or higher.
Using an external keyboard
If you prefer to use a full-size keyboard, you can attach one to your computer. The computer’s USB ports support any USB-compatible keyboard.
Getting Started
69
Using a mouse
You may want to use a mouse instead of the computer’s built-in TouchPad. You can use a USB-compatible mouse.
Connecting a printer
Your printer documentation may require you to install the printer software before physically connecting the printer to your computer. If you do not install the software as instructed by the printer manufacturer, the printer may not function correctly.
Read the documentation that came with your printer. Follow the manufacturer’s instructions when connecting a printer.
You can connect a USB-compatible printer to your computer through the USB ports. To determine if the printer is USB­compatible, check its documentation.
To make the connection, you need a suitable USB cable which may come with your printer. If a USB cable was not included with your printer, you can purchase one from a computer or electronics store.
If your printer supports Plug and Play, your computer may automatically recognize the printer; the printer is then ready for use. Refer to your printer documentation for further instructions.
Getting Started
NOTE
70
Connecting a printer
TECHNICAL NOTE: To determine if your printer supports Plug and Play, check its documentation.
If your printer does not support Plug and Play, you can set up the printer as described in “Setting up a printer” on page 70.
To connect a printer to your computer:
1 Connect the printer cable to the printer and then connect the
other end to one of the computer’s USB ports.
2 Plug the printer’s power cable into a live AC outlet.
Setting up a printer
Some printers require a specific installation process. Refer to your printer installation guide for instructions before completing the following procedure.
If your printer does not support Plug and Play, follow these steps to set it up for the first time. You only need to set up the printer once.
1 Click Start, and then Printers and Faxes.
The Printers and Faxes window appears.
2 Click Add a printer.
The Add Printer Wizard appears.
(Sample Image) Add Printer Wizard
3 Follow the on-screen instructions to set up your printer.
Getting Started
Connecting an optional external diskette drive
Connecting an optional external diskette drive
Some operations, such as creating a password service diskette, require a diskette drive designed for use with 3.5-inch diskettes.
(Sample Illustration) Optional external USB diskette drive
To connect an optional external USB diskette drive, connect the cable to one of the computer’s USB ports.
71
(Sample Illustration) Connecting an optional external USB diskette drive
Turning off the computer
Pressing the power button before shutting down the Windows® operating system could cause you to lose your work. Make sure the system indicator panel’s disk light and the drive-in-use light are off. If you turn off the power while a disk/disc is being accessed, you may lose data or damage the disk/disc and/or drive.
It is a good idea to turn off your computer when you are not using it for a while.
If you are using the computer for the first time, leave the computer plugged into a power source (even though the computer is off) to fully charge the main battery.
Getting Started
72
Turning off the computer
Options for turning off the computer
Depending on the operating system installed, you have more than one option available for turning off the computer: Turn Off or Shut Down, Hibernate, and Standby. Each option has its advantages.
Turn Off or Shut Down
Factors to consider when choosing either Turn Off or Shut Down:
Use the Turn Off command if you are not connected to a
domain server.
Use the Shut Down command if you are connected to a domain
server.
If you have work in progress and are not connected to a
network, use the Windows
to save your system settings so that, when you turn on the
computer again, you will automatically return to where you left
off.
TECHNICAL NOTE: Before using any of these options to shut down or turn off your computer, save your files and make sure all disk/disc activity lights are off.
If you change your mind and decide to continue working after all, wait a few seconds before turning the computer on again.
®
Standby or Hibernate commands
Hibernation mode
Hibernation mode shuts the computer down completely, but it first saves the current state of the computer to the hard disk. Since Hibernation mode does not require power to maintain the saved information, system settings are retained indefinitely.
Factors to consider when choosing Hibernation:
While in Hibernation mode, the computer uses no main battery
power.
Because the state of the system is stored on the hard disk, no
data is lost if the main battery discharges.
Restarting from Hibernation takes less time and consumes less
main battery power than restarting from turning off the
computer.
Getting Started
Turning off the computer
Since information is being retrieved from the hard disk rather
than from memory, restarting from Hibernation takes a little more time and consumes more main battery power to start up than when restarting from Standby.
When starting up again, the computer returns to the state in
which you left it, including all open programs and files you were using.
For information on how to use and configure Hibernation mode see
“Using and configuring Hibernation mode” on page 76.
73
Standby mode
The Standby command places the computer into a power-saving mode. Standby holds the current state of the computer in system memory (RAM) so that, when you restart the computer, you can continue working from where you left off.
Factors to consider when choosing Standby:
While in Standby mode, the computer uses some main battery
power.
The Standby command does not store unsaved information on
your hard disk. You should save your work before putting your computer on Standby.
Restarting from Standby takes less time and consumes less
main battery power than restarting from turning off the computer or using Hibernation mode.
When starting up again, the computer returns to the mode in
which you left it, including all open programs and files you were using.
If you power down using the Standby command and the main battery discharges fully, your unsaved information will be lost. Be sure to save your work first.
For information on using Standby, see “Using and configuring
Standby mode” on page 77.
Getting Started
74
Turning off the computer
Using the Turn Off Computer or Shut Down commands
Depending on the operating system installed, use the following steps to turn off your computer.
Turn Off
Follow these steps to turn off the computer when you are not connected to a domain server:
1 Click Start, and then Turn off computer.
The Turn off computer dialog box appears.
(Sample Image) Turn off computer Windows
2 Click Turn Off.
The computer shuts down completely.
®
dialog box
Shut Down
Follow these steps to shut down the computer when you are connected to a domain server:
1 Click Start, and then Shut down.
The Shut Down Windows
2 Select Shut down from the drop-down list. 3 Click OK.
The computer shuts down completely.
®
dialog box appears.
Turning off the computer more quickly
You can also turn off the computer by pressing the power button. To use this method, you first need to activate it using Toshiba’s
Power Saver utility.
1 Click Start, Control Panel, and then Performance and
Maintenance.
2 Click the TOSHIBA Power Saver icon.
Getting Started
NOTE
Turning off the computer
3 Click on the Setup Action tab.
(Sample Image) Setup action settings screen
75
4 Select the options you want from the drop-down lists.
These options are set separately for how they operate while the computer is running on battery power or while connected to the AC power.
When I press the power button
Set this option to Shut down if you want the computer to shut down when you press the power button.
When I close the lid
Set this option to Shut down if you want the computer to shut down when you close the display panel.
5 Click Apply. 6 Click OK.
Once the computer is configured, you can turn it off by either pressing the power button or closing the display panel, depending on the options set.
Restarting your computer
To start the computer up again, press the power button until the on/off light glows blue.
If you turn off the computer by closing the display panel, you can start it again by opening the display panel.
Getting Started
NOTE
76
Turning off the computer
Using and configuring Hibernation mode
To turn off the computer using the Hibernation command, click Start, Turn off computer, and then select Hibernate.
(Sample Image) Turn off computer Windows
The computer saves the state of all open programs and files, turns off the display, and then turns off.
®
dialog box
Configuring Hibernation mode options
You can place the computer into Hibernation mode by either pressing the power button or closing the display panel. You can also specify an amount of time after which the computer automatically goes into Hibernation mode.
To use any of these methods, you first need to enable them in Toshiba’s Power Saver utility.
1 Click Start, Control Panel, and then Performance and
Maintenance.
2 Click the TOSHIBA Power Saver icon. 3 Click the Setup Action tab. 4 Select Hibernation for the options you want.
These options are set separately for how they operate while the computer is running on battery power or while connected to the AC power.
When I press the power button
Set this option to Hibernate if you want the computer to go into Hibernation mode when you press the power button.
When I close the lid
Set this option to Hibernate if you want the computer to go into Hibernation mode when you close the display panel.
Turning off the computer
5 Click Apply. 6 Click OK.
Once the computer is configured, you can place it into Hibernation mode by either pressing the power button or closing the display panel, depending on the Hibernation options set.
Starting again from Hibernation mode
To start up the computer from Hibernation mode, press the power button until the on/off light glows blue. The computer returns to the screen(s) you were using.
If you put the computer in Hibernation mode by closing the display panel, you can start it again by opening the display panel.
Using and configuring Standby mode
To turn off the computer using the Standby command, click Start, Turn off computer, and then select Stand By.
Getting Started
77
(Sample Image) Turn off computer Windows
The computer saves the status of all open programs and files, turns off the display, and enters into a low-power mode. The on/off light blinks amber indicating the computer is in Standby mode.
®
dialog box
Configuring Standby mode options
You can place the computer into Standby mode by either pressing the power button or closing the display panel. You can also specify an amount of time after which the computer automatically goes into Standby mode.
To use any of these methods, you first need to enable them in Toshiba’s Power Saver utility.
1 Click Start, Control Panel, and then Performance and
Maintenance.
2 Click the TOSHIBA Power Saver icon. 3 Click the Setup Action tab.
78
NOTE
Getting Started
Customizing your computer’s settings
4 Select Standby for the options you want.
These options are set separately for how they operate while the computer is running on battery power or while connected to the AC power.
When I press the power button
Set this option to Standby if you want the computer to go into Standby mode when you press the power button.
When I close the lid
Set this option to Standby if you want the computer to go into Standby mode when you close the display panel.
5 Click Apply. 6 Click OK.
Once the computer is configured, you can place it into Standby mode by either pressing the power button or closing the display panel, depending on the Standby options set.
Starting again from Standby mode
To start up the computer from Standby mode, press the power button until the on/off light glows blue. The computer returns to the screen(s) you were using.
If you place the computer in Standby mode by closing the display panel, you can start it again by opening the display panel.
Closing the display panel
After you have turned off the computer, close the display panel to keep dust and dirt out of the computer.
Customizing your computer’s settings
There are several ways in which you can customize your computer to suit your particular requirements. Refer to your operating system documentation or Help and Support for details.
You may also wish to customize your power usage settings. For more information, see “Power Profiles” on page 108. There are additional custom settings you can choose. See “Utilities” on
page 135.
Caring for your computer
This section gives tips on cleaning and moving your computer. For information about taking care of your computer’s battery, see
“Taking care of your battery” on page 113.
Cleaning the computer
Keep liquids, including cleaning fluid, out of the computer’s keyboard, speaker, and other openings. Never spray cleaner directly onto the computer and/or display. Never use harsh or caustic chemical products to clean the computer.
To keep your computer clean, gently wipe the display panel and exterior case with a lightly dampened cloth.
Moving the computer
Getting Started
Caring for your computer
79
Before moving your computer, even across the room, make sure all disk activity has ended (the drive indicator light stops glowing) and all external peripheral cables are disconnected.
Do not pick up the computer by its display panel or by the back. Doing so could damage the system.
Using a computer lock
You may want to secure your computer to a heavy object such as your desk. The easiest way to do this is to purchase an optional computer lock cable. For more information on purchasing a cable lock, visit accessories.toshiba.com.
(Sample Illustration) Computer lock cable
To secure the computer:
80
Getting Started
Caring for your computer
1 Wrap the cable through or around some part of a heavy object.
Make sure there is no way for a potential thief to slip the cable off the object.
2 Pass the locking end through the loop. 3 Insert the cable’s locking end into the security lock slot on your
computer, then engage the locking device. The computer is now securely locked.
(Sample Illustration) Attaching security lock cable
Chapter 2
Learning the Basics
This chapter gives some computing tips and provides important information about basic features.
Computing tips
Save your work frequently.
Your work stays in the computer’s temporary memory until
you save it to the disk. If the network you are using goes down
and you must restart your computer to reconnect, or your
battery runs out of charge while you are working, you will lose
all work since you last saved.
See “Saving your work” on page 88 for further information.
HINT: Some programs have an automatic save feature that can be activated. This feature saves your file to the hard disk at preset intervals. See your software documentation for details.
81
82
NOTE
Learning the Basics
Computing tips
Back up your files to disks (or other removable media) on a
regular basis. Label the backup copies clearly and store them in a safe place.
It is easy to put off backing up because it takes time. However, if your hard disk suddenly fails, you will lose all the data on it unless you have a separate backup copy. For more information, see “Data and system configuration backup in the Windows®
operating system” on page 198.
Use Error-checking and Disk Defragmenter regularly to
conserve disk space and improve performance.
Scan all new files for viruses.
This precaution is especially important for files you receive via diskette, email, or download from the Internet.
Take frequent breaks to avoid repetitive-motion injuries and
eyestrain.
Do not turn off the computer if a drive indicator light indicates
a drive is active. Turning off the computer while it is reading from or writing to
a disk may damage the disk, the drive, or both.
Before turning off the computer, use the Shut Down command
or Standby command. See “Using and configuring Standby
mode” on page 77 to learn more about Standby.
The Windows® operating system records information, such as your desktop setup, during its shutdown procedure. If you do not let the Windows new icon positions may be lost.
®
operating system shut down normally, details such as
Using the keyboard
Learning the Basics
Using the keyboard
83
Your computer’s keyboard contains character keys, control keys, function keys, and special Windows functionality of a full-size keyboard.
(Sample Illustration) Keyboard
Character keys
Typing with the character keys is very much like typing on a typewriter, except that:
The space bar creates a space character instead of just passing
over an area of the page.
®
keys, providing all the
The lowercase letter l (el) and the number 1 are not
interchangeable.
The uppercase letter O and the number 0 are not
interchangeable.
Making your keyboard emulate a full-size keyboard
Although your computer’s keyboard layout is compatible with a standard full-size keyboard, it has fewer keys.
A standard full-size keyboard has two editing keys; cursor positioning keys; and a numeric keypad. Pressing the specially marked keys allows you to emulate a full-size keyboard.
Your computer’s keyboard has only one this does not matter. However, some programs assign separate functions to the regular and numeric pad keyboard. Using the Fn key, you can simulate the separate key, as follows: Press on the numeric pad of the enhanced keyboard.
Fn key simultaneously in combination with one of the
Fn and Enter simultaneously to simulate the Enter key
Enter, Ctrl, and Alt keys;
Enter key. Most of the time,
Enter keys on the full-sized
Learning the Basics
84
Using the keyboard
Ctrl, Fn, and Alt keys
(Sample Illustration) Ctrl, Fn, and Alt keys
The
Ctrl, Fn, and Alt keys do different things depending on the
program you are using. For more information, see your program documentation.
Function keys
The function keys (not to be confused with the Fn key) are the 12 keys at the top of the keyboard.
(Sample Illustration) Function keys
F1 through F12 are called function keys because they execute
programmed functions when pressed. Used in combination with the
Fn key, function keys marked with icons execute specific functions
on the computer. For example, more information, see “Hot Keys” on page 206.
Special Windows® keys
(Sample Illustration) Special Windows® keys
Your computer’s keyboard has one key and one button that have special functions in Windows
Windows Application key—Has a similar function as the secondary
mouse button
®
button—Opens the Start menu
Fn+F9 turns off the TouchPad. For
®
Windows
Application key
®
:
button
Overlay keys
The keys with gray numbers and symbols on the front of them form the numeric and cursor overlay. This overlay lets you enter numeric data or control the cursor as you would using the 10-key keypad on a desktop computer’s keyboard.
Learning the Basics
Using the keyboard
85
(Sample Illustration) Numeric and cursor control overlay
Using the overlay to type numeric data
The keys with the numbers on their right front are the numeric overlay keys.
To turn the numeric overlay on, press The numeric mode light on the keyboard indicator panel glows when the numeric overlay is on.
To disable the numeric overlay, hold down the again. The numeric mode light on the keyboard indicator panel goes out.
Using the overlay for cursor control
The keys with the gray arrows and symbols on their left front are the cursor control overlay keys.
To turn the cursor control overlay on, press simultaneously. The cursor control mode light on the keyboard indicator panel glows when the cursor control overlay is on.
Fn and F11 simultaneously.
Fn key and press F11
Fn and F10
To disable the cursor control overlay, hold down the press F10 again. The cursor control mode light on the keyboard indicator panel goes out.
Fn key and
Learning the Basics
86
Starting a program
Starting a program
The easiest way to start a program is to double-click the name of the file that contains the information you want to work on. To find the file, use My Computer or Windows
If you prefer to open the program first, you have four options. You can:
Double-click the icon for the program on your desktop Use the Start menu Use Windows
program file
Use the Run dialog box
The next three sections explain how to start a program from the Start menu, Explorer and the Run dialog box.
Starting a program from the Start menu
®
Explorer or My Computer to locate the
®
Explorer.
When you install a program, the operating system usually puts an icon in the All Programs menu. To start a program that has an icon in the All Programs menu, follow these steps, which use the Windows
®
WordPad program as an example:
1 Click Start, and then All Programs.
The Windows
®
operating system displays the All Programs menu, which lists programs and program groups. If your program is listed, go to step 3, otherwise, continue with step 2.
2 Click the program group, in this example, Accessories.
The Accessories menu is displayed.
3 Click the program, in this example, WordPad.
WordPad opens. To close the program, click the Close button in the upper-right
corner of the program’s window.
Learning the Basics
Starting a program
Starting a program from Windows® Explorer
87
If a program is not listed in the All Programs menu, you can start it from Windows
®
Explorer. Windows® Explorer gives you a view of your computer’s contents as a hierarchy or “tree.” You can easily see the contents of each drive and folder on your computer. To use this method, you should know the file name and location of the program’s executable file (this file ends with .exe).
This example opens WordPad using Windows
®
Explorer.
1 Click Start, and then All Programs. 2 Click Accessories. 3 Click Windows Explorer. 4 Click My Computer to expand the window. 5 In the left part of the window, click the line that ends in “(C:).” 6 In the left part of the window, under the C: icon, double-click
the folder containing the program, in this case Program Files. Windows
®
Explorer shows the contents of the Program Files folder on the right side of the window. The left side of the window shows all the folders contained within the Program Files folder.
7 In the left part of the window, click Windows NT. 8 In the left part of the window, click Accessories.
Windows
®
Explorer shows the contents of the Accessories folder on the right side of the window.
9 In the right part of the window, double-click wordpad.
The operating system opens WordPad. To close the program, click the Close button in the upper-right
corner of the program’s window.
Learning the Basics
88
Saving your work
Starting a program from the Run dialog box
This example uses the Run command to start WordPad:
1 Click Start, and then Run.
The Run dialog box appears.
(Sample Image) Run dialog box
2 In the Run dialog box:
If you know the program’s location, type the command
line. For a program in the Windows program name. Otherwise, type the full file path. For example, to access WordPad, type:
c:\Program Files\Windows NT\Accessories\wordpad.exe, then
click OK.
HINT: To run the same program again, click the arrow to the right of the text box and select the command line from the drop-down list.
If you do not know the location, you can search for it by
clicking Start, then Search, and then following the on­screen instructions.
Saving your work
Before you turn off the computer, save your work on the hard disk drive, diskette, flash media, or CD. This is one of the most important rules of computing.
®
folder, type just the
TECHNICAL NOTE: Save your data even when you are using the Standby command, in case the main battery discharges before you return to work.
Saving documents is quick and easy, so it is a good idea to get in the habit of saving frequently.
Learning the Basics
Saving your work
Many programs offer a feature that saves documents at regular intervals. Check your program’s documentation to see if it has an automatic save feature.
89
Saving files
1 In your Windows®-based application, click File, and then Save.
If you are working with a document that already has a file name, this is all you need to do. If you created a new document, your program displays a Save As dialog box.
Use this dialog box to specify where to store the document and to give it a file name.
(Sample Image) Save As dialog box
2 Choose the drive and folder where you want your file to be
stored.
3 Type a file name, then click Save.
HINT: To make another copy of the file you are currently working with, click File, and then Save As, and give the new file a different name.
90
Learning the Basics
Printing your work
File names
The Windows® operating system supports long file names that can contain up to 255 characters and can include spaces. Some applications do not support long file names and require file names limited to no more than eight characters.
You may use all the letters and numbers on the keyboard plus these characters: _ ^ $ ~ ! # % & { } ( ) @ and '. File names are not case­sensitive.
Using a file extension
Most programs assign an extension to the file name that identifies the file as being created in the program with a particular format. For example, Microsoft file name with an extension of “.doc” is assumed to be a Microsoft Word file. Creating your own extension is usually unwise, since the program is unlikely to recognize a strange extension and may refuse to handle your file correctly.
®
Word saves files with a .doc extension. Any
®
TECHNICAL NOTE: By default, the Windows® operating system does not show file extensions. For information on showing or hiding file extensions, see your Windows® online Help.
Printing your work
Ensure the operating system is set up for your printer as described in “Setting up a printer” on page 70.
HINT: You only need to set up the printer the first time you connect it. If you use more than one printer or are changing printers, you will need to set up the Windows additional printer(s).
To print a file:
1 If your printer is not on, turn it on now.
®
operating system to run with the
Learning the Basics
Backing up your work
2 In your Windows® application, click File, and then Print.
The program displays a Print dialog box.
91
(Sample Image) Print dialog box
3 Specify the print parameters. For example, the range of pages
and number of copies to print.
4 Click Print.
Backing up your work
Back up all the files you create in case something happens to your computer. You can back up your files to different types of media such as CDs, DVDs, diskettes, or to a network, if available.
To back up several files at one time, use the Microsoft backup program preinstalled on the computer’s hard disk. Also see
“Backing up your data to CDs with the Windows® operating system” on page 199.
HINT: Backing up all the files on your hard disk may take a considerable amount of time and multiple CDs/DVDs. You may prefer to use a high-capacity backup system, such as an external hard drive.
®
Windows®
Small files can be backed up on diskettes if an optional external diskette drive is available.
Learning the Basics
NOTE
92
Using the optical drive
Restoring your work
To restore information from your backup media to your hard disk, use the Restore page in the backup program. Look in the online Help or your operating system documentation for information on restoring files.
TECHNICAL NOTE: When restoring files, the backup program prompts you if you try to overwrite a file that already exists on the hard disk. Make sure the backup version is the one you want before overwriting the existing file.
Using the optical drive
Optical storage has become the preferred medium for software, music, and video. Digital versatile discs (DVDs) provide a significant increase in data storage and support features that are not available on any other video platform. These features include wide­screen movies, multiple language tracks, digital surround sound, multiple camera angles, and interactive menus.
For these reasons, your computer may come with an optical drive.
TECHNICAL NOTE: Your optical drive is set to play region 1 (North America) DVD-ROMs. If you play a DVD disc from another region, the drive will automatically change to play in the format of the other region. The drive will allow you to change regions four times. On the fourth change, the region will be “locked in.” That is, the drive will only play DVDs from that last region. Note that changing from region 1 to region 2 and back to region 1 is counted as two changes.
For optimum DVD performance, it is recommended that you play DVDs while running the computer on AC power.
Optical drive components
The optical drive is located on the side of the computer. Your optical drive may look like this:
Drive in-use indicator light Eject button Manual eject hole
(Sample Illustration) Optical drive
Drive in-use indicator light—Indicates when the drive is in use. Eject button—Press to release the disc tray.
Do not press the eject button or turn off the computer while the drive in-use indicator light is glowing. Doing so could damage the disc or the drive.
Learning the Basics
Using the optical drive
93
When the disc tray is open, be careful not to touch the lens or the area around it. Doing so could cause the drive to malfunction.
Manual eject hole—Use if you need to release the disc tray when the power is off. Use a straightened paper clip or other narrow object to press the manual eject button located inside the hole.
Never use a pencil to press the manual eject button. Pencil lead can break off inside the computer and damage it.
Inserting a compact disc
To insert a compact disc into the drive:
1 Make sure the computer is turned on.
The drive will not open if the computer’s power is off.
2 Make sure the drive’s in-use indicator light is off. 3 Press the drive’s eject button.
The disc tray slides partially out of the drive (about 1 inch).
94
Learning the Basics
Using the optical drive
4 Grasp the tray and pull it fully open.
(Sample Illustration) Drive tray fully extended
5 Hold the disc by its edges and check that it is free of dust.
If the disc is dusty, clean it as described in “Caring for CD or
DVD discs” on page 98.
6 Place the disc carefully in the disc tray, label side up.
(Sample Illustration) Positioning the disc in the drive
7 Gently press the disc onto the center spindle until it clicks into
place.
Handle DVDs and CDs carefully, making contact only with the center hole and edge. Do not touch the surface of the disc. Do not stack discs. If you incorrectly handle the discs, you could lose data.
8 Make sure the disc is completely on the spindle and is lying flat
NOTE
on the tray.
If you insert the disc incorrectly, it may jam the drive. If this happens, contact Toshiba support for assistance.
9 Push the disc tray in by pressing gently on the center of the tray
until it clicks into place. You are ready to use the disc.
Playing an audio CD
Insert an audio CD and close the disc tray. If the computer is turned on, Windows Media
CD begins to play. You can use the Windows Media program to control the CD.
To access the Windows Media Start menu.
Learning the Basics
Using the optical drive
®
Player opens and the
®
Player, you can open it through the
®
Player
95
When using Windows Media® Player, your system may not be able to activate Standby or Hibernation modes. To prevent this from occurring, close Windows Media or Hibernation mode.
Stop button
Play/Pause button
(Sample Image) Windows Media
®
Player before you select Standby
®
Player screen
Learning the Basics
96
Using the optical drive
The Windows Media® Player control panel works much like an ordinary compact disc player:
To play the CD or to pause, click the Play/Pause button. To stop the CD, click the Stop button.
Before putting on headphones to listen, turn the volume down. Do not set the volume too high when using headphones. Continuous exposure to loud sound can harm your hearing.
Playing optical media
If you insert a CD/DVD into the optical drive and the Auto-Run feature does not automatically start your disc, try launching the CD/DVD manually. To do this, follow these steps:
1 Click Start, and then Computer. 2 Click the optical drive icon.
The disc drive will run the CD/DVD.
If your disc does not run using this method, try using an application that is associated with the media on the disc. For example, if it is a music CD, open Windows Media then play the CD. For other types of media, use the associated software to open the files on the disc.
Creating a CD/DVD
Depending on the configuration, your computer may come with a multi-function drive that allows you to:
Play pre-recorded DVDs Play pre-recorded CDs Read and write data (depending on your system configuration)
and music files to CD-Recordable (CD-R) and CD-Rewritable (CD-RW) discs; and DVD
®
Player and use it to select and
±R/±RW or DVD RAM discs.
Learning the Basics
NOTE
Using the optical drive
Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical drive may not record on certain optical media that bear the applicable logo, or play back optical media recorded by other computers or optical media recorders. Additionally, certain optical media recorded on your optical drive may not play back or operate properly on other computers or optical media players. These problems are not due to any defect in your Toshiba computer or optical drive. Please refer to your computer's product specification for listing of specific format compatibilities.
Copy protection technology may also prevent or limit recording or viewing of certain optical media.
For details on how to use the software, please refer to the respective Online Help menus.
97
Removing a disc with the computer on
To remove a disc (CD or DVD) with the computer turned on:
1 Press the eject button on the drive.
Do not press the eject button while the in-use indicator light is glowing. Doing so could damage the disc or the drive.
Also, if the disc is still spinning when you open the disc tray, wait for it to stop spinning before you remove it.
2 Pull the tray out until it is fully open, remove the disc, and
place it in its protective cover.
3 Gently press the tray in to close it.
Removing a disc with the computer off
To remove a disc with the computer turned off:
1 Insert a slender object, such as a straightened paper clip, into
the manual eject hole. The disc tray slides partially out of the drive (about 1 inch).
Never use a pencil to press the manual eject button. Pencil lead can break off inside the computer and damage it.
Learning the Basics
98
Toshiba’s online resources
2 Pull the tray out until it is fully open, remove the disc, and
place it in its protective cover.
3 Gently press the tray in to close it.
Caring for CD or DVD discs
Store your discs in their original containers to protect them
from scratches and keep them clean.
Do not bend a disc or place heavy objects on top of it. Do not apply a label to, or otherwise mar the surface of, a disc. Hold a disc by its outside edge. Fingerprints on the surface can
prevent the optical drive from reading the data properly.
Do not expose discs to direct sunlight or extreme heat or cold. To clean a disc that is dirty, wipe it with a clean, dry cloth. The
most efficient method to clean it is to start from the center of the disc and wipe toward the outward edge (not in a circle). If necessary, moisten the cloth with water or a neutral cleaner (not benzine or rubbing alcohol). Let the disc dry completely before inserting it in the drive.
Toshiba’s online resources
Toshiba maintains a number of online sites to which you can connect. These sites provide information about Toshiba products, give help with technical questions and keep you up to date with future upgrades. For more information, see “Contacting Toshiba”
on page 203.
Chapter 3
Mobile Computing
This chapter covers all aspects of using your computer while traveling.
Toshiba’s energy-saver design
Your computer enters a low-power suspension mode when it is not being used, thereby conserving energy and saving money in the process. It has a number of other features that enhance its energy efficiency.
Many of these energy-saving features have been set. We recommend you leave these features active, allowing your computer to operate at its maximum energy efficiency, so that you can use it for longer periods while traveling.
99
100
Mobile Computing
Running the computer on battery power
Your computer contains Toshiba EasyGuard®. The Toshiba EasyGuard* technology is made up of four foundational elements that incorporate hardware and software innovations into various Toshiba notebooks that address the most common security, reliability and connectivity issues faced by computer users:
EasyGuard Protect and Fix—to fortify vital information and
vulnerable components against the stress and hazards mobile computers face every day.
EasyGuard Secure—to defend your data and your notebook
against loss, theft or viral attack.
EasyGuard Connect—to help users establish a reliable wired
or wireless connection effortlessly and quickly.
EasyGuard Optimize—to enable users to customize system
settings to be more productive.
*Toshiba EasyGuard some of which may or may not be available on a particular Toshiba notebook depending on the model selected. See
easyguard.toshiba.com for detailed information.
®
technology comprises a number of features
Running the computer on battery power
The computer contains a removable Lithium-Ion (Li-Ion) battery that provides power when you are away from an AC outlet. You can recharge it many times.
Battery Notice
Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations tested by Toshiba at the time of publication. Recharge time varies depending on usage. Battery may not charge while the computer is consuming full power.
After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba Web site at accessories.toshiba.com. Use only batteries designed to work with your Toshiba notebook computer.
Loading...
