Toshiba M800 User Manual

User’s Manual

Portégé M800

computers.toshiba-europe.com

Copyright

© 2008 by TOSHIBA Corporation. All rights reserved. Under the copyright
laws, this manual cannot be reproduced in any form without the prior
written permission of TOSHIBA. No patent liability is assumed, with respect
to the use of the information contained herein.

TOSHIBA Portégé M800 Portable Personal Computer User's Manual

First edition March 2008
Ownership and copyright of music, video, computer programs, databases,

etc. are protected by the copyright laws. These copyrighted materials may
be copied for private use at home only. If, beyond the limitation above, you
copy (including to transform data formats) or modify these materials,
transfer them or distribute them via the Internet without approval of
copyright owners, you may be subject to claims for compensation for
damage and/or criminal penalties due to infringements of copyrights or
personal rights. Please remember to observe the copyright laws when you
use this product to copy the copyrighted works or perform other actions.

Please note that you may infringe the owner's rights protected by the
copyright laws if you use the screen mode switching functions (e.g. Wide
mode, Wide Zoom mode, etc.) of this product to display enlarged images/
video at coffee shops or hotels for the purposes of profits or providing these
to the public.

Disclaimer

This manual has been validated and reviewed for accuracy. The
instructions and descriptions it contains are accurate for the TOSHIBA
Portégé M800 Portable Personal Computer at the time of this manual’s
production. However, succeeding computers and manuals are subject to
change without notice. TOSHIBA assumes no liability for damages incurred
directly or indirectly from errors, omissions or discrepancies between the
computer and the manual.

Portégé M800

Trademarks

Microsoft, Windows and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation.

DirectX, AcriveDesktop, DirectShow, and Windows Media are registered
trademarks of Microsoft Corporation.

Intel, Intel Core, Celeron, Centrino and Pentium are trademarks or
registered trademarks of Intel Corporation.

Adobe and Photoshop are either registered trademarks or trademarks of
Adobe Systems Incorporated.

Bluetooth™ is a registered trademark owned by its proprietor and used by
TOSHIBA under license.

ConfigFree is a trademark of TOSHIBA Corporation.
DVD MovieFactory is a trademark of Ulead Systems. Inc.

User’s Manual ii

BizCard is a trademark of NewSoft Technology Corporation.
Dolby is a registered trademark of Dolby Laboratories.
ExpressCard is a trademark of PCMCIA.
HDMI, the HDMI logo and High-Definition Multimedia Interface are

trademarks or registered trademarks of HDMI Licensing LLC.
Labelflash™ is a trademark of YAMAHA CORPORATION.
Memory Stick, Memory Stick PRO, and i.LINK are registered trademarks

and i.LINK is a trademark of Sony Corporation.
MultiMediaCard and MMC are trademarks of MultiMediaCard Association.
Photo CD is a trademark of Eastman Kodak.
Secure Digital and SD are trademarks of SD Card Association.
xD-Picture Card is a trademark of Fuji Photo Film, Co., Ltd.
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
Other trademarks and registered trademarks not listed above may be used

in this manual.

Safety Instructions

Use the following safety guidelines to help protect yourself and your
computer.

When Using Your Computer

Portégé M800

Do not operate your portable computer for an extended period of time with
the base resting directly on your body. With extended operation, heat can
potentially build up in the base. Allowing sustained contact with the skin
could cause discomfort or, eventually, a burn.

■ Do not attempt to service the computer yourself. Always follow

installation instructions closely.

■ Do not carry a battery in your pocket, purse, or other container where

metal objects (such as car keys) could short-circuit the battery
terminals. The resulting excessive current follow can cause extremely
high temperatures and may result in damage from burns.

■ Be sure that noting rests on your AC adapter’s power cable and that the

cable is not located where it can be tripped over or stepped on.

■ Place the AC adapter in a ventilated area, such as a desk top or on the

floor, when you use it to run the computer or to charge the battery. Do
not cover the AC adapter with papers or other items that will reduce
cooling; also, do not use the AC adapter while it is inside a carrying
case.

■ Use only the AC adapter and batteries that are approved for use with

this computer. Use of another type of battery or AC adapter may risk fire
or explosion.

User’s Manual iii

■ Before you connect the computer to a power source, ensure that the

voltage rating of the AC adapter matches that of the available power
source. 115 V/ 60 Hz in most of North and South America and some Far
Eastern countries such as Taiwan. 100 V/50 Hz in eastern Japan and
100 V/60 Hz in western Japan. 230 V/50 Hz in most of Europe, the
Middle East, and the Far East.

■ If you use an extension cable with your AC adapter, ensure that the total

ampere rating of the products plugged in to the extension cable does
not exceed the ampere rating of the extension cable.

■ To remove power from the computer, turn it off, remove the battery, and

disconnect the AC adapter from the electrical outlet.

■ To help avoid the potential hazard of electric shock, do not connect or

disconnect any cables or perform maintenance or reconfiguration of this
product during and electrical storm.

■ When setting up the computer for work, place it on a level surface.

EU Declaration of Conformity

This product is labelled with the CE Mark in accordance with Radio
Equipment and Telecommunications Terminal Equipment Directive 1999/5/
EC which includes the compliance to the Electromagnetic Compatibility
Directive 2004/108/EC and the Low Voltage Directive 2006/95/EC.

CE Marking is the responsibility of TOSHIBA EUROPE GmbH,
Hammfelddamm 8, 41460 Neuss, Germany, phone [phone].

For a copy of the related CE Declaration of Conformity please refer to
thefollowing website: http://epps.toshiba-teg.com

This product and the supplied accessories are designed to observe the
required EMC (Electromagnetic Compatibility) standards. However,
Toshiba cannot guarantee that this product still observes these EMC
standards if accessories or cables not manufactured/distributed by Toshiba
are connected or implemented. To avoid in general EMC problems, the
following advice should be observed:

■ Only CE marked accessories should be connected/implemented

■ Only the best shielded data cables should be connected

Portégé M800

GOST

User’s Manual iv

Modem warning notice

Conformity Statement

The equipment has been approved to [Council Decision 98/482/EC - "TBR
21"] for pan-European single terminal connection to the Public Switched
Telephone Network (PSTN).

However, due to differences between the individual PSTNs provided in
different countries/regions the approval does not, of itself, give an
unconditional assurance of successful operation on every PSTN network
termination point.

In the event of problems, you should contact your equipment supplier in the
first instance.

Network Compatibility Statement

This product is designed to work with, and is compatible with the following
networks. It has been tested to and found to conform with the additional
requirements conditional in EG 201 121.

Germany ATAAB AN005, AN006, AN007, AN009, AN010 and

Greece ATAAB AN005, AN006 and GR01, 02, 03, 04
Portugal ATAAB AN001, 005, 006, 007, 011 and P03, 04, 08,

Spain ATAAB AN005, 007, 012, and ES01
Switzerland ATAAB AN002
All other countries/

regions

Specific switch settings or software setup are required for each network,
please refer to the relevant sections of the user guide for more details.

The hookflash (timed break register recall) function is subject to separate
national type approvals. It has not been tested for conformity to national
type regulations, and no guarantee of successful operation of that specific
function on specific national networks can be given.

Portégé M800

DE03, 04, 05, 08, 09,12,14,17

10

ATAAB AN003, 004

Following information is only for EU-member states:

The symbol indicates that this product may not be treated as
household waste. Please ensure this product is properly
disposed as inappropriate waste handling of this product may
cause potential hazards to the environment and human health.
For more detailed information about recycling of this product,
please contact your local city office, your household waste
disposal service or the shop where you purchased the product.

User’s Manual v

This symbol may not stick depending on the country and region where you
purchased.

EnergyStar® Program

Your computer model may be Energy Star® Compliant. If the model you
purchased is compliant, it is labeled with the ENERGY STAR logo on the
computer and the following information applies.

TOSHIBA is a partner in the Environmental Protection Agency’s (EPA)
ENERGY STAR® Program and has designed this computer to meet the
latest ENERGY STAR
ships with the power management options preset to a configuration that will
provide the most stable operating environment and optimum system
performance for both AC power and battery modes.

To conserve energy, your computer is set to enter the low-power Sleep
mode which shuts down the system and display within 15 minutes of
inactivity in AC power mode. TOSHIBA recommends that you leave this
and other energy saving features active, so that your computer will operate
at its maximum energy efficiency. You can wake the computer from Sleep
mode by pressing the power button.

Products that earn the ENERGY STAR® prevent greenhouse gas
emissions by meeting strict energy efficiency guidelines set by the US EPA
and the EU Commission. According to the EPA, a computer meeting the
new ENERGY STAR
energy depending on how it is used. Visit http://www.eu-energystar.org or

http://www.energystar.gov for more information regarding the ENERGY

STAR Program.

Portégé M800

®

guidelines for energy efficiency. Your computer

®

specifications will use between 20% and 50% less

Optical disc drive safety instructions

Be sure to check the international precautions at the end of this section.

User’s Manual vi

Panasonic

DVD Super Multi UJ-862B/862F

■ The DVD Super Multi drive employs a laser system. To ensure proper

use of this product, please read this instruction manual carefully and
retain for future reference. Should the unit ever require maintenance,
contact an authorized service location.

■ Use of controls, adjustments or the performance of procedures other

than those specified may result in hazardous radiation exposure.

■ To prevent direct exposure to the laser beam, do not try to open the

enclosure.

Portégé M800

User’s Manual vii

Hitach-LG Data Storage

DVD Super Multi GSA-U10N/10F

■ The DVD Super Multi drive employs a laser system. To ensure proper

use of this product, please read this instruction manual carefully and
retain for future reference. Should the unit ever require maintenance,
contact an authorized service location.

■ Use of controls, adjustments or the performance of procedures other

than those specified may result in hazardous radiation exposure.

■ To prevent direct exposure to the laser beam, do not try to open the

enclosure.

Portégé M800

User’s Manual viii

International Precautions

Portégé M800

CAUTION: This appliance contains a laser
system and is classified as a "CLASS 1
LASER PRODUCT." To use this model
properly, read the instruction manual
carefully and keep this manual for your
future reference. In case of any trouble
with this model, please contact your
nearest "AUTHORIZED service station."
To prevent direct exposure to the laser
beam, do not try to open the enclosure.

VORSICHT: Dieses Gerät enthält ein
Laser-System und ist als
"LASERSCHUTZKLASSE 1 PRODUKT"
klassifiziert. Für den richtigen Gebrauch
dieses Modells lesen Sie bitte die
Bedienungsanleitung sorgfältig durch und
bewahren diese bitte als Referenz auf.
Falls Probleme mit diesem Modell
auftreten, benachrichtigen Sie bitte die
nächste "autorisierte Service-Vertretung".
Um einen direkten Kontakt mit dem
Laserstrahl zu vermeiden darf das Gerät
nicht geöffnet werden.

ADVARSEL: Denne mærking er anbragt
udvendigt på apparatet og indikerer, at
apparatet arbejder med laserstråler af
klasse 1, hviket betyder, at der anvendes
laserstrlier af svageste klasse, og at man
ikke på apparatets yderside kan bilve
udsat for utilladellg kraftig stråling.

APPARATET BOR KUN ÅBNES AF
FAGFOLK MED SÆRLIGT KENDSKAB
TIL APPARATER MED LASERSTRÅLER!

Indvendigt i apparatet er anbragt den her
gengivne advarselsmækning, som advarer
imod at foretage sådanne indgreb i
apparatet, at man kan komme til at udsatte
sig for laserstråling.

User’s Manual ix

Portégé M800

OBS! Apparaten innehåller
laserkomponent som avger laserstråining
överstigande gränsen för laserklass 1.

VAROITUS. Suojakoteloa si saa avata.
Laite sisältää laserdiodin, joka lähetää
näkymätöntä silmilie vaarallista
lasersäteilyä.

CAUTION: USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE
SPECIFIED IN THE OWNER’S MANUAL
MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.

VORSICHT: DIE VERWENDUNG VON
ANDEREN STEURUNGEN ODER
EINSTELLUNGEN ODER DAS
DURCHFÜHREN VON ANDEREN
VORGÄNGEN ALS IN DER
BEDIENUNGSANLEITUNG
BESCHRIEBEN KÖNNEN
GEFÄHRLICHE
STRAHLENEXPOSITIONEN ZUR FOLGE
HABEN.

Important Notice

Copyrighted works including, but not limited to music, video, computer
program, databases are protected by copyright laws. Unless specifically
permitted under applicable copyright laws, you cannot copy, modify, assign,
transmit or otherwise dispose of any copyrighted work with the consent of
the owner of the copyright. Please take notice that unauthorized copying,
modification, assignment, transmission and disposition may be subject to
claims for damages and penalties.

■ Avoid using a telephone (other than a cordless type) during an electrical

storm. There may be a remote risk of electric shock from lightning.

■ Do not use the telephone to report a gas leak in the vicinity of the leak.

■ Use only the power cord indicated in this manual.

■ Replace only with the same or equivalent type battery recommended by

the manufacturer.

■ Dispose of used batteries according to the manufacturer’s instructions.

Use only the battery pack that came with the computer or an optional
battery pack. Use of wrong battery could damage your computer.

TOSHIBA assumes no liability for any damage in such case.

User’s Manual x

General Precautions

TOSHIBA computers are designed to optimize safety, minimize strain and
withstand the rigors of portability. However, certain precautions should be
observed to further reduce the risk of personal injury or damage to the
computer.

Be certain to read the general precautions below and to note the cautions
included in the text of the manual.

Creating a computer-friendly environment

Place the computer on a flat surface that is large enough for the computer
and any other items you are using, such as a printer.

Leave enough space around the computer and other equipment to provide
adequate ventilation. Otherwise, they may overheat.

To keep your computer in prime operating condition, protect your work area
from:

■ Dust, moisture, and direct sunlight.

■ Equipment that generates a strong electromagnetic field, such as

stereo speakers (other than speakers that are connected to the
computer) or speakerphones.

■ Rapid changes in temperature or humidity and sources of temperature

change such as air conditioner vents or heaters.

■ Extreme heat, cold, or humidity.

■ Liquids and corrosive chemicals.

Stress injury

Carefully read the Instruction Manual for Safety and Comfort. It contains
information on the prevention of stress injuries to your hands and wrists
that can be caused by extensive keyboard use. Chapter 3, Getting Started,
also includes information on work space design, posture and lighting that
can help reduce physical stress.

User’s Manual xi

Heat injury

■ Avoid prolonged physical contact with the computer. If the computer is

used for long periods, its surface can become very warm. While the
temperature will not feel hot to the touch, if you maintain physical
contact with the computer for a long time, for example if you rest the
computer on your lap or if you keep your hands on the palm rest, your
skin might suffer a low-heat injury.

■ If the computer has been used for a long time, avoid direct contact with

the metal plate supporting the various interface ports as this can
become hot.

■ The surface of the AC adaptor can become hot when in use but this

condition does not indicate a malfunction. If you need to transport the
AC adaptor, you should disconnect it and let it cool before moving it.

■ Do not lay the AC adaptor on a material that is sensitive to heat as the

material could become damaged.

Pressure or impact damage

Do not apply heavy pressure to the computer or subject it to any form of
strong impact as this can damage the computer's components or otherwise
cause it to malfunction.

ExpressCard overheating

Some ExpressCards can become hot during prolonged use which may
result in errors or instability in the operation of the device in question. In
addition, you should also be careful when you remove a PC or
ExpressCard that has been used for a long time.

Mobile phones

Please be aware that the use of mobile phones can interfere with the audio
system. The operation of the computer will not be impaired in any way, but
it is recommended that a minimum distance of 30cm is maintained between
the computer and a mobile phone that is in use.

Instruction Manual for Safety and Comfort

All important information on the safe and proper use of this computer is
described in the enclosed Instruction Manual for Safety and Comfort. Be
sure to read it before using the computer.

User’s Manual xii

Table of Contents

Chapter 1 Introduction

Equipment checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

TOSHIBA Value Added Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

Utilities and Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15

Chapter 2 The Grand Tour

Front with the display closed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Left side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Right side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Backside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Underside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Front with the display open. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Optical Disc Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

AC adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Remote controller (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

Portégé M800

Chapter 3 Getting Started

Installing the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Connecting the AC adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Opening the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Turning on the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Windows Vista™ setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Turning off the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Restarting the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

System Recovery Options and Restoring the

pre-installed Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

User’s Manual xiii

Portégé M800

Chapter 4

Operating Basics

Using the TouchPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Using the fingerprint sensor (optional) . . . . . . . . . . . . . . . . . . . . . . . 4-2

Using the Web Camera (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Using the microphone (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

Using the optical disc drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

Writing CD/DVD with the DVD Super Multi drive

supporting DVD±R DL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17

TOSHIBA Disc Creator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20

Using Ulead DVD MovieFactory for TOSHIBA . . . . . . . . . . . . . . . . . 4-21

Media care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24

Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24

Using the FM tuner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

Wireless communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Cleaning the computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Moving the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32

Using the Hard Disk Drive (HDD) Protection . . . . . . . . . . . . . . . . . . 4-32

Chapter 5 The Keyboard

Typewriter keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

F1 ... F12 function keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Soft keys: Fn key combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Hot keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Windows® special keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

Keypad overlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

Generating ASCII characters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Chapter 6 Power and Power-Up Modes

Power conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Power indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

Battery types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

Care and use of the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Replacing the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10

Starting the computer by password . . . . . . . . . . . . . . . . . . . . . . . . . 6-12

Power-up modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12

Panel power off/on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13

System Auto Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13

Chapter 7 HW Setup

Accessing HW Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

HW Setup Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

User’s Manual xiv

Portégé M800

Chapter 8

Optional Devices

ExpressCard Slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1

SD/SDHC/MMC/MEMORY STICK/MEMORY

STICK PRO/xD Memory cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

Memory expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6

Additional battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

Additional AC adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

External monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10

HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10

i.LINK (IEEE1394) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11

Security lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13

Chapter 9 Troubleshooting

Problem solving process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

Hardware and system checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

TOSHIBA support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17

Appendix A Specifications

Appendix B Display Controller and Modes

Appendix C Wireless LAN

Appendix D AC Power Cord and Connectors

Appendix E Legal Footnotes

Appendix F If your computer is stolen

Glossary

Index

User’s Manual xv

Preface

Congratulations on your purchase of the TOSHIBA Portégé M800
computer. This powerful notebook computer provides excellent expansion
capability, including multimedia devices, and it is designed to provide years
of reliable, high-performance computing.

This manual tells how to set up and begin using your TOSHIBA Portégé
M800 computer. It also provides detailed information on configuring your
computer, basic operations and care, using optional devices and
troubleshooting.

If you are a new user of computers or if you’re new to portable computing,
first read over the Introduction and The Grand Tour chapters to familiarize
yourself with the computer's features, components and accessory devices.
Then read Getting Started for step-by-step instructions on setting up your
computer.

If you are an experienced computer user, please continue reading the
preface to learn how this manual is organized, then become acquainted
with this manual by browsing through its pages. Be sure to look over the

Specifications section of the Introduction, to learn about features that are

uncommon or unique to the computer. If you are going to install
ExpressCards or connect external devices such as a monitor, be sure to
read Chapter 8, Optional Devices.

Manual contents

This manual is composed of the following nine chapters, six appendixes, a
glossary and an index.

Chapter 1, Introduction, is an overview of the computer's features,
capabilities, and options.

Chapter 2, The Grand Tour, identifies the components of the computer and
briefly explains how they function.

Chapter 3, Getting Started, provides a quick overview of how to begin
operating your computer and gives tips on safety and designing your work
area.

Chapter 4, Operating Basics, includes instructions on using the following
devices: TouchPad, Sound System, optical media drives, modem, wireless
communication and LAN. It also provides tips on care of the computer, and
CD/DVDs.

User’s Manual xvi

Chapter 5, The Keyboard, describes special keyboard functions including
the keypad overlay and hot keys.

Chapter 6, Power and Power-Up Modes, gives details on the computer's
power resources and battery save modes.

Chapter 7, HW Setup explains how to configure the computer using the
HW Setup program.

Chapter 8, Optional Devices, describes the optional hardware available.
Chapter 9, Troubleshooting, provides helpful information on how to perform

some diagnostic tests, and suggests courses of action if the computer
doesn’t seem to be working properly.

The Appendices provide technical information about your computer.
The Glossary defines general computer terminology and includes a list of

acronyms used in the text.
The Index quickly directs you to the information contained in this manual.

Conventions

This manual uses the following formats to describe, identify, and highlight
terms and operating procedures.

Abbreviations

On first appearance, and whenever necessary for clarity, abbreviations are
enclosed in parenthesis following their definition. For example: Read Only
Memory (ROM). Acronyms are also defined in the Glossary.

Icons

Icons identify ports, dials, and other parts of your computer. The indicator
panel also uses icons to identify the components it is providing information
on.

Keys

The keyboard keys are used in the text to describe many computer
operations. A distinctive typeface identifies the key top symbols as they
appear on the keyboard. For example, Enter identifies the Enter key.

User’s Manual xvii

Key operation

Some operations require you to simultaneously use two or more keys. We
identify such operations by the key top symbols separated by a plus sign
(+). For example, Ctrl + C means you must hold down Ctrl and at the same
time press C. If three keys are used, hold down the first two and at the
same time press the third.

ABC When procedures require an action such as

clicking an icon or entering text, the icon’s name
or the text you are to type in is represented in the
type face you see to the left.

Display

ABC

Names of windows or icons or text generated by
the computer that appears on its display screen is
presented in the type face you see to the left.

Messages

Messages are used in this manual to bring important information to your
attention. Each type of message is identified as shown below.

Pay attention! A caution informs you that improper use of equipment or
failure to follow instructions may cause data loss or damage your
equipment.

Please read. A note is a hint or advice that helps you make best use of
your equipment.

Indicates a potentially hazardous situation, which could result in death or
serious injury, if you do not follow instructions.

Terminology

This term is defined in this document as follows:

Start The word "Start" refers to the button in

Microsoft

®

Windows Vista™.

User’s Manual xviii

Introduction

This chapter provides an equipment checklist, and it identifies the
computer's features, options and accessories.

Some of the features described in this manual may not function properly if
you use an operating system that was not pre-installed by TOSHIBA.

Equipment checklist

Carefully unpack your computer. Save the box and packing materials for
future use.

Hardware

Check to make sure you have all the following items:

■ TOSHIBA Portégé M800 Portable Personal Computer

■ Universal AC adaptor and power cord

Introduction

Chapter 1

Software

Microsoft® Windows Vista™

The following software is preinstalled:

■ Microsoft

■ Microsoft Internet Explorer

■ TOSHIBA Value Added Package

■ TOSHIBA Hardware Setup

■ TOSHIBA Supervisor Password

■ TOSHIBA Assist

■ TOSHIBA ConfigFree

■ TOSHIBA DVD PLAYER

■ TOSHIBA FingerPrint Utility*

■ TOSHIBA SD Memory Utilites

■ TOSHIBA Disc Creator

User’s Manual 1-1

®

Windows Vista™

Features

Introduction

■ TOSHIBA Face Recognition*

■ TOSHIBA Acoustic Silencer

■ Ulead DVD MovieFactory

■ Presto! BizCard 5*

■ Online Manual

* is preinstalled dependant on the model purchased.

®

for TOSHIBA*

Documentation

■ Portégé M800 Personal Computer User’s Manual

■ Portégé M800 Quickstart

■ Instruction Manual for Safety and Comfort

■ Warranty information

If any of the items are missing or damaged, contact your dealer
immediately.

Please visit your region’s web site for the configuration details of the model
that you have purchased.

Processor

Built-in Depends on the model you purchased.

Please visit your region’s website for the
configuration details of the model that you have
purchased.

®

Chipset Mobile Intel

GM965/GL960 Express Chipset

Memory

Slots PC2-5300 (GM965)/PC2-4200 (GL960) 512 MB,

User’s Manual 1-2

1024 MB or 2048 MB
Up to 2 GB memory modules can be installed in

the memory slot for a maximum of 4 GB (GM965)/
2 GB (GL960) system memory.

Introduction

Main Memory
Disclaimer

Part of the main system memory may be used by
the graphics system for graphics performance
and therefore reduce the amount of main system
memory available for other computing activities.
The amount of main system memory allocated to
support graphics may vary depending on the
graphics system, applications utilized, system
memory size and other factors. For PC's
configured with 4 GB of system memory, the full
system memory space for computing activities will
be considerably less and will vary by model and
system configuration.

If your computer is configured with two 2 GB memory modules, the
memory might be displayed as approximately 3 GB only (depending on the
computer's hardware specifications).

This is correct because the operating system usually displays the available
memory instead of the physical memory (RAM) built into the computer.

Various system components (like the video adapter's GPU and PCI
devices like Wireless LAN, etc.) require their own memory space. Since a
32-bit operating system cannot address more than 4 GB of memory these
system resources overlap the physical memory. It is a technical limitation
that the overlapped memory is not available to the operating system.

Even though some tools might display the actual physical memory built
into your computer, the memory available to the operating system will still
be approximately 3 GB only.

Video RAM Depending on the model you purchased:

Mobile Intel
Intel

®

®

GM965 Express Chipset/Mobile

GL960 Express Chipset model: Video RAM
capacity shares with main memory, and the
proportion depends on Dynamic Video Memory
Technology.

Power

Battery Pack Your computer is powered by a rechargeable

lithium-ion battery pack.

RTC Battery The internal RTC battery backs up the Real Time

Clock and calendar.

User’s Manual 1-3

Introduction

AC Adaptor The universal AC adaptor provides power to the

system and recharges the batteries when they
are low. It comes with a detachable power cord.

Because it is universal, it can receive a range of
AC voltage from 100 to 240 volts; however, the
output current varies among different models.
Using the wrong model can damage your
computer. Refer to the AC adaptor section in
Chapter 2, The Grand Tour.

Disks

Hard disk Drive Available in 1 x 2.5" HDD (9.5 mm/SATA)

■ 80 GB

■ 120 GB

■ 160 GB

■ 200 GB

■ 250 GB

■ 320 GB

User’s Manual 1-4

Introduction

DVD Super Multi drive
(Supporting DVD±R
DL)

Your computer is equipped with a full-size
DVD Super Multi drive module that lets you
record data to rewritable CD/DVDs as well as run
either 12 cm (4.72") or 8cm (3.15") CD/DVDs
without using an adaptor. It reads DVD-ROMs at
maximum 8 speed and CD-ROMs at maximum
24 speed. It writes CD-Rs at up to 24 speed,
CD-RWs at up to 16 speed, DVD-Rs at maximum
8 speed, DVD-RWs at maximum 6 speed,
DVD+Rs at maximum 8 speed, DVD+RWs at
maximum 8 speed, DVD+R(DL) discs at
maximum 4 speed, DVD-R(DL) discs at maximun
4 speed, and DVD-RAM discs at maximum
5 speed. It supports the following formats:

■ DVD-ROM

■ DVD-Video

■ DVD-R

■ DVD-RW

■ DVD+R

■ DVD+RW

■ DVD-RAM

■ DVD+R DL

■ DVD-R DL

■ CD-DA

■ CD-Text

■ Photo CD (single/multi-session)

■ CD-ROM Mode 1, Mode 2

■ CD-ROMXA Mode 2 (Form1, Form2)

■ Enhanced CD (CD-EXTRA)

■ CD-G (Audio CD only)

■ Addressing Method 2

Display

The computer's LCD panel supports high-resolution video graphics. The
screen can be set at a wide range of viewing angles for maximum comfort
and readability.

Built-In 13.3" WXGA 16 M colors, with the following

resolution: 1280 horizontal × 800 vertical pixels.

Graphics Controller Graphics controller maximizes display

User’s Manual 1-5

performance. Refer to Appendix B, Display

Controller and Modes for more information.

Keyboard

Introduction

Built-In TOSHIBA Vista keyboard, 85 keys or 86 keys,

compatible with IBM enhanced keyboard,
embedded numeric overlay, dedicated cursor
control, and keys. Refer to Chapter 5,

The Keyboard, for details.

Pointing Device

Built-In TouchPad A TouchPad and control buttons in the palm rest

enable control of the on-screen pointer and
scrolling of windows.

Ports

HDMI This HDMI jack allows you to connect external

External Monitor This 15-pin port lets you connect an external

Universal Serial Bus
(USB 2.0)

i.LINK (IEEE1394a) This port enables high-speed data transfer

Infrared receiver
window

display/audio devices. (Provided with some
models)

video display.
The computer has Universal Serial Bus ports that

comply with the USB 2.0 standard, which enables
data transfer speeds 40 times faster than the
USB 1.1 standard. (The ports also support
USB 1.1.)

directly from external devices such as digital
video cameras.

This window receives signals from the remote
control which is provided with your computer.

Slots

ExpressCard Slot The ExpressCard slot can accommodate two

Multiple Digital Media
Card Slot

User’s Manual 1-6

standard module formats; an ExpressCard/34
module and an ExpressCard/54 module. An
ExpressCard module is a small add-in card
technology based on the PCI Express and
Universal Serial Bus (USB) interfaces.

Supports SD/SDHC memory card, MMC,
MEMORY STICK, MEMORY STICK PRO and xD
Picture card

Multimedia

Introduction

Web Camera Record/Send still or video images with this

integrated webcam. (Provided with some models)

®

Sound System A Windows

Sound System that provides
speakers as well as jacks for an external
microphone and headphones.

Headphone (S/P DIF)
jack

This jack outputs analog audio signals. This jack
can be used also as S/P DIF jack and enables
connection of an optical digital correspondence
apparatus.

Microphone Jack A 3.5 mm mini microphone jack enables

connection of a three-conductor mini jack for
monaural microphone input.

Communications

Modem The internal modem provides capability for data

LAN The computer is equipped with a LAN card that

and fax communication. It supports V.90 (V.92).
The speed of data transfer and fax
communication depends on the analog telephone
line conditions. The computer has a modem jack
for connection to a telephone line. Both V.90 and
V.92 are supported only in the USA, Canada, UK,
France and Germany. V.90 is supported in other
regions. (Provided with some models)

supports Fast Ethernet LAN (100 Mbit/s,
100BASE-TX) or Gigabit Ethernet LAN (1 Gbit/s,
1000BASE-T).

User’s Manual 1-7

Introduction

Wireless LAN Some computers in this series are equipped with

Wireless LAN feature that supports the A, B,
G and draft N standards but it is compatible with
other LAN systems based on Direct Sequence
Spread Spectrum/Orthogonal Frequency Division
Multiplexing radio technology that complies with
the IEEE 802.11 Standard.

■ Automatic Transmit Rate Select mechanism in

the transmit range of 54, 48, 36, 24, 18, 12,
9 and 6 Mbit/s. (IEEE 802.11a/g)

■ Automatic Transmit Rate Select mechanism in

the transmit range of 11, 5.5, 2 and 1 Mbit/s.
(IEEE 802.11b)

■ Roaming over multiple channels

■ Card Power Management

■ Wired Equivalent Privacy (WEP) data

encryption, based on 128 bit encryption
algorithm.

■ Advanced Encryption Standard (AES) data

encryption, based on 128 bit encryption
algorithm.

Bluetooth Some computers in this series are equipped with

Bluetooth functions. Bluetooth wireless
technology eliminates the need for cables
between electronic devices such as computers
and printers. Bluetooth provides fast, reliable, and
secure wireless communication in a small space.
(Provided with some models)

Wireless
Communication

This switch turns the Wireless LAN and Bluetooth
functions on and off. (Provided with some models)

Switch

Security

Security lock slot Connects an optional security lock to anchor the

Password Power-on password protection

User’s Manual 1-8

computer to a desk or other large object.

Two level password architecture
HDD password protection
Fingerprint authentication (Provided with some

models)

Special features

The following features are either unique to TOSHIBA computers or are
advanced features, which make the computer more convenient to use.

Hot Keys Key combinations let you quickly modify the

Keypad Overlay A ten-key pad is integrated into the keyboard.

Instant Security The hot key function Fn + F1 blanks the screen

Display Automatic
Power Off

HDD Automatic Power

*1

Off

System Automatic
Sleep Mode/
Hibernation

Intelligent Power
Supply

Battery Save Mode

Panel Power On/Off

*1

Introduction

system configuration directly from the keyboard
without running a system configuration program.

Refer to the Keypad overlay section in Chapter 5,

The Keyboard, for instructions on using the

keypad overlay.

and disables the computer, providing data
security.

*1

This feature automatically cuts off power to the
internal display when there is no keyboard input
for a specified time. Power is restored when any
key is pressed.

This can be specified in the Power Options.
This feature automatically cuts off power to the

hard disc drive when it is not accessed for a
specified time. Power is restored when the hard
disc is accessed.

This can be specified in the Power Options.
This feature automatically shuts down the system

*1

into Sleep Mode or Hibernation Mode when there
is no input or hardware access for a specified
time.

This can be specified in the Power Options.
A microprocessor in the computer's intelligent

power supply detects the battery’s charge and
calculates the remaining battery capacity. It also
protects electronic components from abnormal
conditions, such as voltage overload from an
AC adaptor.

This can be specified in the Power Options.

*1

This feature lets you save battery power.
This can be specified in the Power Options.

*1

This feature turns power to the computer off when
the display panel is closed and turns it back on
when the panel is opened.

This can be specified in the Power Options.

User’s Manual 1-9

Introduction

Low Battery
Automatic
Hibernation

*1

When battery power is exhausted to the point that
computer operation cannot be continued, the
system automatically enters Hibernation Mode
and shuts down.

This can be specified in the Power Options.

TOSHIBA HDD
Protection

This feature uses the acceleration sensor built in
the computer to detect vibration and shocks, and
automatically moves the hard disk drive's read/
write head to a safe position in order to reduce the
risk of damage that could be caused by headto­disk contact. Refer to the Using the Hard Disk

Drive (HDD) Protection section in Chapter 4,
Operating Basics, for more details.

The TOSHIBA HDD Protection function does not guarantee that the hard
disk drive will not be damaged.

Hibernation This feature lets you turn off the power without

exiting from your software. The contents of main
memory are saved to the hard disk so that when
you turn on the power again, you can continue
working right where you left off. Refer to the

Turning off the power section in Chapter 3,
Getting Started, for details.

Sleep Mode If you have to interrupt your work, you can turn off

the power without exiting from your software.
Data is maintained in the computer's main
memory so that when you turn on the power
again, you can continue working right where you
left off.

*1 Click , Control Panel, System and Maintenance, and then click

Power Options.

User’s Manual 1-10

TOSHIBA Value Added Package

This section describes the TOSHIBA Component features pre-installed on
the computer.

TOSHIBA Power
Saver

TOSHIBA Zooming
Utility

TOSHIBA PC
Diagnostic Tool

TOSHIBA Flash Cards This utility supports the following functions.

TOSHIBA
Components
Common Driver

TOSHIBA
Accessibility

TOSHIBA Button
Support

TOSHIBA Power Saver provides you with the
features of more various power supply
managements.

This utility allows you to enlarge or reduce the
icon size on the Windows Desktop, or the zoom
factor associated with specific supported
applications.

The TOSHIBA PC Diagnostic Tool will display
basic system configuration information and allow
the functionality of some of the computer's built-in
hardware devices to be tested.

■ Hot key function

■ TOSHIBA utility launcher function

TOSHIBA Components Common Driver contains
the module required for the utility which TOSHIBA
offers.

The TOSHIBA Accessibility utility provides
support to movement impaired users when they
need to use the TOSHIBA Hot-key functions. In
use, the utility allows you to make the Fn key
"sticky", that is you can press it once, release it,
and then press one of the "F" keys in order to
access its specific function. When set, the Fn key
will remain active until another key is pressed.

This utility controls the button operation of the
computer.

The starting application from the button can be
changed.

Introduction

User’s Manual 1-11

Utilities and Applications

This section describes pre-installed utilities and tells how to start them. For
details on operations, refer to each utility’s online manual, help files or
readme.txt files.

TOSHIBA Assist TOSHIBA Assist is a graphical user interface that

HW Setup This program lets you customize your hardware

Power On Password Two levels of password security, supervisor and

CD/DVD Drive
Acoustic Silencer

Ulead DVD
MovieFactory
TOSHIBA

®

for

Introduction

provides easy access to help and services.

settings according to the way you work with your
computer and the peripherals you use. To start
the utility, double click the TOSHIBA Assist on
your desktop, select OPTIMIZE tab, and click
TOSHIBA Hardware Settings.

user, are available to prevent unauthorized
access to your computer.

To register a supervisor password, double click
the TOSHIBA Assist on your desktop select the
SECURE tab and start the Supervisor password
utility.

To set a user password, select the SECURE tab
on TOSHIBA Assist, then start the User
password utility. On the Password tab you can
register a user password.

This utility allows you to configure the read speed
of the optical disc drive. You can either configure
Normal Mode, which operates the drive at its
maximum speed for quick data access, or Quiet
Mode, which runs at single speed for CD audio
and which can lessen operational noise. It is
ineffective in DVD mode.

You can edit digital video and make a DVD-Video
and support Labelflash™ function. (Provided with
some models)

*1 Click , Control Panel, System and Maintenance, and then click

Power Options.

User’s Manual 1-12

Introduction

FingerPrint utility Depending on the model purchased, your

computer has a fingerprint utility installed for the
purpose of enrolling and recognizing fingerprints.
By enrolling the ID and password to the fingerprint
authentication device, it is no longer necessary to
input the password from the keyboard. Just by
swiping the finger against the fingerprint sensor,
the following functions will be enabled:

■ Log-on to Windows and access a security

enabled homepage through IE (Internet
Explorer).

■ Files and folders can be encrypted/decrypted

and third party access to them prevented.

■ Disable the password-protected screensaver

when returning from power-saving (Sleep)
mode.

■ System boot authentication and Single Touch

Boot feature.

■ Power on Security and Single Sign On

feature.

TOSHIBA DVD
PLAYER

The DVD PLAYER is used to play DVD Video. It
has an on-screen interface and functions. Click

, point to All Programs, point to TOSHIBA

DVD Player, then click TOSHIBA DVD Player.

TOSHIBA Disc
Creator

You can create CD/DVDs in several formats
including audio CDs that can be played on a
standard stereo CD player and data CDs or DVDs
to store multimedia and/or document files on your
hard disk drive. This software can be used on a
model with the CD-RW/DVD-ROM drive, DVD-R/

-RW drive, DVD+R/+RW drive and DVD Super
Multi drive.

To run TOSHIBA Disc Creator, click , select All
Programs, TOSHIBA, CD&DVD Applications,
and then click Disc Creator.

TOSHIBA DVD-RAM
Utility

TOSHIBA DVD-RAM Utility has a Physical Format
function and Write-Protect function to DVD-RAM.

This utility is contained in the TOSHIBA Disc
Creator setup module.

To run TOSHIBA DVD-RAM Utility, click ,
select All Programs, TOSHIBA, CD&DVD
Applications, and then click DVD-RAM Utility.

User’s Manual 1-13

Introduction

TOSHIBA ConfigFree ConfigFree is a suite of utilities to allow easy

control of communication devices and network
connections. ConfigFree also allows you to find
communication problems and create profiles for
easy switching between location and
communication networks.

TOSHIBA Face
Recognition

To run ConfigFree, click , select

TOSHIBA, Networking

and then click

TOSHIBA Face Recognition uses a face
verification library to verify the face data of users

All Programs

ConfigFree

when they log in to Windows. If the verification is
successful, the user will be logged into Windows
automatically. The user can thus avoid having to
enter a password or the like, which makes the login
process easier. (Provided with some models)

Presto! BizCard 5 Presto! BizCard keeps track of names,

companies, mailing addresses, phone/fax
numbers, e-mail addresses, and more. Simply
scan your business cards and Presto! BizCard
automatically saves the data and image for each
card. Different viewing modes are available for
easy searching, editing, creating, and sorting. You
can share information with desktop organizers,
contact managers, personal information
managers (PIMs), and personal digital assistants
(PDAs). You can also print ID badges, mailing
labels, and stickers. (Provided with some models)

Windows Mobility
Center

This section describes the Windows Mobility
Center. Mobility Center is a utility for accessing
several mobile PC settings quickly in one window.
A maximum of eight tiles are prepared as the
operating system default. Two additional tiles are
also added to your Mobility Center.

Installing the "TOSHIBA Extended Tiles for
Windows Mobility Center" package will add the
following functions.

■ Lock Computer:

Lock your computer without turning it off. This
has the same function as the Lock button at
the bottom of the right pane of the start menu.

■ TOSHIBA Assist:

Open the TOSHIBA Assist if it is already
installed in your computer.

,

.

User’s Manual 1-14

Options

Introduction

You can add a number of options to make your computer even more
powerful and convenient to use. Refer to Chapter 8 Optional Devices, for
details. The following options are available:

Memory expansion Two memory modules can be installed in this

computer.

Use only PC5300* compatible DDRII memory modules. See your
TOSHIBA dealer for details.

* The availability of DDRII depends on the model you purchased.

Battery pack An additional battery pack can be purchased from

your TOSHIBA dealer. Use it as a spare to
increase your computer operating time.

AC Adaptor If you use your computer at more than one site

frequently, it may be convenient to purchase an
additional AC adaptor for each site so you will not
have to carry the adaptor with you.

User’s Manual 1-15

The Grand Tour

This chapter identifies the various components of your computer. Become
familiar with each component before you operate the computer.

Front with the display closed

The following figure shows the computer's front with its display panel in the
closed position.

Multiple Digital

Media Card Slot

Wireless

Communication

Switch

Wireless

Activity LED

The Grand Tour

Chapter 2

Power

LED

Disk
LED

Volume D ial

Front of the computer with display closed

Multiple Digital Media
Card Slot

Infrared

Receiver

Window

Supports SD/SDHC memory card, MMC,
MEMORY STICK, MEMORY STICK PRO and xD

DC IN

LED

Battery

LED

Multiple

Digital

Media Card

Slot LED

Picture card

Wireless
Communication

The Wireless Communication Switch turns the
wireless networking transceiver on or off.

Switch

Set the switch to off in airplanes and hospitals. Check the wireless activity
indicator. It will stop glowing when the wireless communication function is
off.

User’s Manual 2-1

The Grand Tour

Volu m e D i a l Use this dial to adjust the volume of the stereo

speakers or headphones.

Infrared Receiver
Window

An infrared receiver window is provided with
some models. This is a sensor window that
receives signals from the remote control which is
provided with some models.

Wireless Activity LED Indicates whether the Wireless LAN or Bluetooth

is active or not. (Provided with some models)

DC IN LED The DC IN LED indicates the computer is

connected to the AC adaptor and it is plugged into
an AC power source.

Power LED The Power indicator glows blue when the

computer is on. If you select Sleep Mode from
Turn Off Computer, this indicator flashes orange
(one second on, two seconds off) while the
computer enters Sleep Mode.

Battery LED The Battery indicator shows the condition of the

battery's charge: Blue indicates a full charge,
orange indicates that the battery is charging and
flashing orange indicates a low battery charge.
Refer to Chapter 6, Power and Power-Up Modes

Disk LED Disk LED indicates that the hard disk drive or

optical disc drive is being accessed.

Multiple Digital Media
Card Slot LED

Multiple Digital Media Card Slot LED lights up
when the Multiple Digital Media Card Slot is
accessed.

Left side

The following figure shows the computer's left side.

External Monitor Port

Cooling

Vents

The left side of the computer

User’s Manual 2-2

i.LINK

(IEEE1394a) Port

HDMI

USB Ports

Microphone

Jack

ExpressCard Slot

Headphone

(S/P DIF)

Jack

The Grand Tour

External Monitor Port This 15-pin port lets you connect an external

video display.

Cooling Vents Cooling vents help prevent the CPU from

overheating.

HDMI A jack enables connection of the application of

High Definition Multimedia Interface, such as
DVD Player, LCD Monitor, LCD TV, HDTV, Set­top-Box and projector. (Provided with some
models)

i.LINK (IEEE1394a)
Port

This port allows you to connect an external
device, such as a digital video camera, for
highspeed data transfer. (Provided with some
models)

ExpressCard Slot This slot allows you to insert an ExpressCard. An

ExpressCard is a small, modular add-in card
technology based on PCI Express and the
Universal Serial Bus (USB) interface. The max.
transmission rate is 2.5 Gbps. ExpressCard/34
and ExpressCard/54 types are supported.

Do not block the cooling vents. Also ensure that foreign objects are kept
out of the vents as items such as pins or similar objects, which can
damage the computer's circuitry.

Universal Serial Bus
(USB 2.0) ports

Universal Serial Bus ports, which comply to the
USB 2.0 standard, are provided. A port with the
icon ( ) has USB Sleep and Charge function.

Microphone Jack A 3.5 mm mini microphone jack enables

connection of a three-conductor mini jack for
monaural microphone input.

Headphone (S/P DIF)
Jack

This jack outputs analog audio signals. This jack
can be used also as S/P DIF jack and enables
connection of optical digital correspondence
apparatus.

User’s Manual 2-3

Right side

The following figure shows the computer's right side.

ODD

Indicator

Eject

Button

Modem Jack or

FM Antenna Jack*

The Grand Tour

Security

Lock

Emergency

Eject Hole

The right side of the computer

USB Port

LAN
Jack

* The figure shows FM Antenna Jack.

ODD Indicator The ODD indicator glows amber when the

computer accesses the optical disc drive.

Emergency Eject Hole In the event that the disc drive becomes

inexplicably locked or stops responding press this
button to force a manual ejection of the ODD tray.

Eject Button Press this button to open the ODD tray.

Universal Serial Bus
(USB 2.0) ports

Universal Serial Bus ports, which comply to the
USB 2.0 standard, are provided. A port with the
icon ( ) has USB Sleep and Charge function.

LAN Jack This jack lets you connect to a LAN. The adaptor

has built-in support for Ethernet LAN
(10 megabits per second, 10BASE-T) and Fast
Ethernet LAN (100 megabits per second,
100BASE-TX). Refer to Chapter 4, Operating

Basics, for details.

Modem Jack The modem jack allows you to use a modular

cable to connect the modem directly to a
telephone line. (Provided with some models.)

■ In case of a lightning storm, unplug the

modem cable from the telephone jack.

■ Do not connect the modem to a digital

telephone line. A digital line will damage the
modem.

FM Antenna Jack A jack enables the connection of FM antenna.

(Provided with some models)

Security Lock A security cable attaches to this port. The optional

security cable anchors your computer to a desk or
other large object to deter theft.

User’s Manual 2-4

Backside

The Grand Tour

The following figure shows the computer's back panel.

DC in 19V Jack

The backside of the computer

Underside

The following figure shows the underside of the computer. Make sure the
display is closed before turning over your computer.

DC IN 19V Jack The AC adaptor connects to this socket. Use only

the model of AC adaptor that comes with the
computer. Using the wrong adaptor can damage
your computer.

Battery Pack Battery Release Latch

Battery

Pack

Lock

Hard

Disk

Cover

Cooling
Vents

Memory Module and

Wireless LAN Cover

The underside of the computer

Memory Module and
Wireless LAN Cover

This cover protects the two memory module
sockets - one or two modules are pre-installed.
Refer to the Memory expansion section in
Chapter 8, Optional Devices.

User’s Manual 2-5

The Grand Tour

Battery Pack Lock Slide this lock to prepare the battery pack for

Battery Pack The battery pack powers the computer when the

Battery Release Latch Slide and hold this latch to release the battery

Cooling Vents Cooling vents help prevent the CPU from

Hard Disk Cover This cover protects the hard disk.

Front with the display open

This section shows the front of the computer with the display open. Refer to
the appropriate illustration for details. To open the display, lift the front of the
display. Position the display at a comfortable viewing angle.

Web Camera LED*

Display
Screen

removal.

AC adaptor is not connected. For detailed
information on the battery pack, refer to
Chapter 6, Power and Power-Up Modes.

pack for removal. For detailed information on
removing the battery pack, refer to Chapter 6,

Power and Power-Up Modes.

overheating.

Web Camera*

Built-in microphone*

Power Button
Mute Button or LED On/Off Button*

CD/DVD Button*

Play/Pause Button*

Stop Button*

Previous Button*

Next Button*

Speaker

TouchPad

Speaker

The front of the computer with the display open

Fingerprint
Sensor*

TouchPad
Control
Buttons

* Provided with some models

User’s Manual 2-6

The Grand Tour

Please handle your computer carefully to avoid scratching or damaging the
surface.

Speakers The speakers emit sound generated by your

software as well as audio alarms, such as low
battery condition, generated by the system.

Display Screen The LCD displays high-contrast text and graphics.

Refer to Appendix B, Display Controller and

Modes. When the computer operates on the

AC adaptor the display screen’s image will be
somewhat brighter than when it operates on
battery power. The lower brightness level is
intended to save battery power.

Web Camera LED Web Camera LED indicates web camera is

working or not. (Provided with some models)

Web Camera Take your picture or send your image to web

contacts. (Provided with some models)

Built-in microphone The Microphone is used with the Web Camera to

talk to other Web Camera users and to record
messages on windows media. (Provided with
some models)

Power Button Turns the computer on and off and puts it into

Hibernation Mode and wakes it up from Sleep
Mode.

Mute Button or LED
On/Off Button

Depending on the model you purchased, press
this button to mute the volume or to switch the
illumination of the TouchPad, brand logo and
buttons on or off. (Provided with some models)

CD/ DVD Button Pressing this button will launch an application

program that allows for playing of CDs or DVDs.
The application that is launched differs by model:
Windows Media Player/TOSHIBA DVD PLAYER.
(Provided with some models)

Play/Pause Button Press this button to begin playing an audio CD, a

DVD movie or digital audio file. This button also
acts as a Pause button. (Provided with some
models)

Stop Button Stops playing of the CD, DVD or digital audio.

(Provided with some models)

Previous Button Skips backwards to the previous track, chapter or

digital file. Refer to Chapter 4, Operating Basics,
for details. (Provided with some models)

Next Button Skips forward to the next track, chapter or digital

file. Refer to Chapter 4, Operating Basics, for
details. (Provided with some models)

User’s Manual 2-7

The Grand Tour

TouchPad A TouchPad located in the centre of the palm rest

Fingerprint Sensor Just by swiping the finger against the fingerprint

TouchPad Control
Buttons

Optical Disc Drive

An ATAPI interface controller is used for CD/DVD-ROM operation. When
the computer is accessing a CD/DVD, an indicator on the drive glows.

Region codes for DVD drive and media

Optical disc drive and their associated media are manufactured according
to the specifications of six marketing regions. When you purchase DVD­Video, make sure it matches your drive, otherwise it will not play properly.

Code Region
1 Canada, United States
2 Japan, Europe, South Africa, Middle East
3 Southeast Asia, East Asia
4 Australia, New Zealand, Pacific Islands, Central

5 Russia, Indian Subcontinent, Africa, North Korea,

6 China

is used to control the on-screen pointer.

sensor, the following functions will be enabled:
Log-on to Windows and access a security­enabled homepage through IE (Internet Explorer).
Files and folders can be encrypted/decrypted and
third party access to them prevented. Disable the
password-protected screensaver when returning
from power-saving (Sleep) mode. System boot
authentication and Single Touch Boot feature.
Authentication of the User Password and Hard
Disk Drive Password when booting up the
computer. Refer to the Using the fingerprint

sensor (optional) section in Chapter 4, Operating
Basics. (Provided with some models)

These let you select menu items or manipulate
text and graphics designated by the on-screen
pointer. Refer to the Using the TouchPad section
in Chapter 4, Operating Basics.

America, South America, Caribbean

Mongolia

User’s Manual 2-8

Writable discs

This section describes the types of writable CD/DVD discs. Check the
specifications of your drive for the type of discs it can write. Use TOSHIBA
Disc Creator to write compact discs. Refer to Chapter 4, Operating Basics.

CDs

■ CD-R discs can be written only once. The recorded data cannot be

erased or changed.

■ CD-RW discs can be recorded more than once. Use either 1, 2, or

4 multi speed CD-RW discs or high-speed 4- to 10-speed discs. The
write speed of the ultra-speed CD-RW discs (Ultra-speed is available
on the DVD-ROM & CD-R/RW drive only) is a maximum of 24-speed.

DVDs

■ DVD-R, DVD+R, DVD-R DL and DVD+R DL discs can be written only

once. The recorded data cannot be erased or changed.

■ DVD-RW, DVD+RW and DVD-RAM discs can be recorded more than

once.

DVD Super Multi drive (Supporting DVD±R DL)

The full-size DVD Super Multi drive module lets you record data to writable
CD/DVDs as well as run either 12 cm (4.72") or 8 cm (3.15") CD/DVDs
without using an adaptor.

The Grand Tour

The read speed is slower at the centre of a disc and faster at the outer
edge.

DVD read 8 speed (maximum)

DVD-R write 8 speed (maximum)

DVD-RW write 6 speed (maximum)

DVD+R write 8 speed (maximum)

DVD+RW write 8 speed (maximum)

DVD-R(DL) write 4 speed (maximum)

DVD+R(DL) write 4 speed (maximum)

DVD-RAM write 5 speed (maximum)

CD read 24 speed (maximum)

CD-R write 24 speed (maximum)

CD-RW write 16 speed (maximum, Ultra-speed media)

User’s Manual 2-9

AC adaptor

The AC adaptor converts AC power to DC power and reduces the voltage
supplied to the computer. It can automatically adjust to any voltage from
100 to 240 volts and to a frequency of either 50 or 60 hertz, enabling you to
use the computer in almost any country/region.

To recharge the battery, simply connect the AC adaptor to a power source
and the computer. Refer to Chapter 6, Power and Power-Up Modes for
details.

The Grand Tour

The AC adaptor

■ Use only the AC adaptor that came with the computer or an equivalent

optional adaptor. Use of the wrong adaptor could damage your
computer. TOSHIBA assumes no liability for any damage in such case.

■ Use only the AC Adaptor supplied with your computer or an equivalent

adaptor that is compatible. Use of any incompatible adaptor or other
types of AC Adaptors may have a different voltage which could cause
damage to your computer, computer failure and/or possible data loss.
TOSHIBA assumes no liability for any damage, computer failure and/or
data loss caused by use of an incompatible adaptor.

Use only the AC adaptor supplied as an accessory. Other AC adaptors
have different voltage and terminal polarities and use of them may produce
heat and smoke or even result in fire or rupture.

User’s Manual 2-10

Remote controller (optional)

A remote controller, which is provided with some models, enables you to
perform some functions of your computer from a distant location.

You can use your remote controller with Media Center to play CDs, DVDs
and videos, to view pictures.

The remote controller helps you to control the playback of a movie through
Media Center.

Using the remote controller, you can:

■ Navigate and control all Media Center windows.

■ Control the video.

■ Place the computer in and out of Sleep Mode.

Slim size remote controller

CD/DVD Button

LCD

Brightness

Down

LCD

Brightness Up

The Grand Tour

DVD Menu

Volume +

Volum e -

OK

Mute

Back

Start

Rewind

Replay

Stop

Power

LED On/Off

Arrows

More Information

Fast Forward
Play/Pause

Skip

CD/DVD button Press this button to launch an application

program that allows Windows Media Player/DVD
Video Player.

Brightness down Decreases the computer’s display panel

brightness in individual steps.

Brightness up Increases the computer’s display panel

brightness in individual steps.

User’s Manual 2-11

The Grand Tour

Power Starts or terminates the operating system. This

button functions like the power button of your
computer. By default, the Sleep Mode is
equivalent to the power off state of your
computer. To change the setting, click Start 

Control panel  System and Maintenance 
Power Options  Choose what the Power
button does. The following four options are

available: Do nothing, Sleep, Hibernate and Shut
down.

Volu m e + Increases the volume while viewing DVDs or

replaying CDs.

Volu m e - Decreases the volume while viewing DVDs or

replaying CDs.

DVD menu Opens the main menu on a DVD movie, if

available.

Arrows Moves the cursor to navigate within Media

Center windows.

OK Selects the desired action or window option. It

acts like the ENTER Key.

LED on/off Pressing this button to switch the lighting of

indicators.

Mute Turns your computer’s sound off.

Back Displays the previous window.

More information The button provides more detailed information.

Start Opens Media Center to the main window.

Rewind Moves the media (video, DVD, music, and so on)

backwards.

Play/Pause Plays the selected media. This button also acts

as a pause button.

Fast forward Moves the media (video, DVD, music, and so on)

forwards.

User’s Manual 2-12

The Grand Tour

Replay

Moves media backward (seven seconds for videos,
one music track or one DVD chapter at a time).

Stop Stops the media currently playing.

Skip Moves media forward (30 seconds for videos,

one music track or one DVD chapter).

Using the remote controller

Some computers include a remote control unit, which allows you to control
some of your computer’s functions from a distant location.

■ The remote controller is designed specifically for this computer.

■ Some application programs may not support remote control functions.

Operational range of the remote controller

Point the remote controller at your computer and press a button. The
operational angle and distance are described below.

Distance
Angle Within about 30 degrees horizontally and about

Within 5 meters from the infrared receiver window.

15 degrees vertically of perpendicular to the
infrared receiver window.

30 Degrees

15 Degrees

30 Degrees

Infrared Receiver
Window

Operational range of the remote controller

User’s Manual 2-13

Remote

Controller

5M

(Vertically)

Even if within the effective scope as described above, the remote controller
may malfunction or not work correctly in the following cases.

■ When an obstacle stands between the infrared receiver window of your

computer and the remote controller.

■ When direct sunlight or strong fluorescent light strikes the infrared

receiver window.

■ When the infrared receiver window or the infrared emission part of the

remote controller is dirty.

■ When other computers which use an infrared remote controller are

used near to your computer.

■ When a low battery condition is present.

Installing/Removing batteries

Be sure to install the provided CR2016 type batteries before using the
remote controller. The procedures for installing and removing the batteries
vary depending on the type of the remote controller. Check the type and
then install or remove the batteries as instructed.

Store the battery for the remote controller beyond the reach of children.
If a child swallows a battery, this might result in choking. If it happens,
contact a doctor immediately.

Observe the following precautions when using the battery of the remote
controller.

■ Do not use batteries other than those specified.

■ Ensure that you insert the batteries with their polarities correctly

aligned (+ or -).

■ Do not recharge, heat, disassemble or short the battery, or put it into a

fire or flame.

■ Do not use a battery whose "recommended expiration date" has been

reached, or which is completely discharged.

■ Do not use different types of batteries or old and new batteries at the

same time.

■ Do not carry the battery together with metal necklaces, hairpins or

other metal accessories.

■ When storing or disposing of used batteries, make sure to put some

insulation tape on their terminals (+ and -) to avoid short-circuits.

If these precautions are not followed, heating, fluid leakage or explosion
may occur. This may cause burns or personal injury. If battery fluid gets on
your skin or clothes, wash immediately with clean water. If battery fluid
gets in your eyes, rinse your eyes with clean water immediately and see a
doctor. Do not touch the battery fluid on instruments or devices with bare
hands. Wipe off with a cloth or paper towel.

The Grand Tour

User’s Manual 2-14

The Grand Tour

Type of battery that can be used for the remote controller

When the provided batteries run down, please replace them with adequate
ones. CR2016 type battery is available. Other types of batteries should not
be used.

Installing the batteries

1. Open the battery cover on the back side of the remote controller.

Battery Cover

Opening the battery cover

2. Be sure to place the batteries with correct polarities. Press the battery
down to the stopper then push it forward to fit into the battery case.

Stopper

Battery

Inserting the batteries

3. Close the battery cover. Close the cover securely until it clicks.

Closing the battery cover

Replacing the batteries

When the batteries in the remote controller reach the end of their life, the
remote controller may not operate correctly or work only within a short
distance from your computer. In this instance, you should purchase new
batteries and replace the discharged ones.

User’s Manual 2-15

Slim size remote controller

1. Open the battery cover on the back side of the remote controller.

2. Hold down the stopper and slide the battery out of battery case.

Stopper Battery

Removing the batteries

3. Insert the battery in place. Be sure to place the batteries with correct
polarities. Press the battery down to the stopper then push it forward to
fit into the battery case.

4. Close the battery cover. Close the cover securely until it clicks.

Placing slim size remote controller

Inserting a slim size remote controller

To insert the slim size remote controller, follow the steps below.

1. Make sure the ExpressCard slot is empty.

2. Set the front side upward and insert the slim size remote controller.

The Grand Tour

Slim size remote

controller

Inserting the slim size remote controller

3. Press gently to ensure a firm connection.

Remove a slim size remote controller

To remove the slim size remote controller, follow the steps below.

1. Press the slim size remote controller slightly to make it stretch out.

2. Grasp the slim size remote controller and pull it out from the slot.

User’s Manual 2-16

Getting Started

This chapter provides basic information to get you started using your
computer. It covers the following topics:

Be sure also to read the Instruction Manual for Safety and Comfort. This
guide, which is included with the computer, explains product liability.

■ Installing the battery pack

■ Connecting the AC adaptor

■ Opening the display

■ Turning on the power

■ Windows Vista™ setup

■ Turning off the power

■ Restarting the computer

■ System Recovery Options and Restoring the preinstalled Software

All users should be sure to read the section Windows Vista™ setup.

Getting Started

Chapter 3

Installing the battery pack

Skip this section, if your computer came with the battery pack installed. To
install a battery, follow the steps below.

■ The battery pack is a lithium ion battery, which can explode if not

properly replaced, used, handled or disposed of. Dispose of the battery
as required by local ordinances or regulations. Use only batteries
recommended by TOSHIBA as replacements.

■ Do not touch the latch while holding the computer. Or you may get

injured by the dropped battery by unintentional release of the latch.

■ Please do not push the power button before installing the battery pack.

1. Turn the computer's power off.

2. Disconnect all cables connected to the computer.

3. Insert the battery pack. The Battery Release Latch clicks into place.

User’s Manual 3-1

Getting Started

4. Secure the Battery Pack Lock to ensure the battery is locked into place.
Later, when you want to remove the battery you must disengage this
lock first.

Battery Release Latch

Battery

Pack Lock

Securing the battery pack

Refer to Removing the battery pack section in Chapter 6, Power and

Power-Up Modes, for removing the battery pack.

Connecting the AC adaptor

Attach the AC adaptor when you need to charge the battery or you want to
operate from AC power. It is also the fastest way to get started, because
the battery pack will need to be charged before you can operate from
battery power.

The AC adaptor can be connected to any power source supplying from
100 to 240 volts and 50 or 60 hertz. For details on using the AC adaptor to
charge the battery pack, refer to Chapter 6, Power and Power-Up Modes.

Use only the AC adaptor supplied as an accessory. Other AC adaptors
have different voltage and terminal polarities and use of them may produce
heat and smoke or even result in fire or rupture.

User’s Manual 3-2

Getting Started

■ Use only the AC adaptor supplied with your computer or an equivalent

adaptor that is compatible. Use of any incompatible adaptor could
damage your computer. TOSHIBA assumes no liability for any damage
caused by use of an incompatible adaptor.

■ When you connect the AC adaptor to the computer, always follow the

steps in the exact order as described in the User's Manual. Connecting
the power cable to a live electrical outlet should be the last step
otherwise the adaptor DC output plug could hold an electrical change
and cause an electrical shock or minor bodily injury when touched. As
a general safety precaution, avoid touching any metal parts.

1. Connect the power cord to the AC adaptor.

Connecting the power cord to the AC adaptor

2. Connect the AC adaptor's DC output plug to the DC IN 19V jack on the
back of the computer.

Connecting the adaptor to the computer

3. Plug the power cord into a live wall outlet.

User’s Manual 3-3

Opening the display

The display panel can be rotated in a wide range of angles for optimal
viewing.

1. Lift the panel up and adjust it to the best viewing angle for you.

Use reasonable care when opening and closing the display panel. Opening
it vigorously or slamming it shut could damage the computer.

Getting Started

Opening the display

User’s Manual 3-4

Turning on the power

This section describes how to turn on the power.

After you turn on the power for the first time, do not turn it off until you have
set up the operating system. Refer to the section Windows Vista™ setup.

Press and hold the computer's power button for two or three seconds.

Windows Vista™ setup

When you first turn on the power, the computer's initial screen is the
Microsoft

Follow the on-screen directions.

®

Windows Vista™ Startup Screen Logo.

Getting Started

Turning on the power

Be sure to read the Windows End User License Agreement
display carefully.

Turning off the power

The power can be turned off in one of the following modes: Shut down
(Boot), Hibernation or Sleep Mode.

Shut Down mode (Boot mode)

When you turn off the power in Shut Down mode no data is saved and the
computer will boot to the operating system’s main screen.

1. If you have entered data, save it to the hard disk.

2. Make sure all disk (disc) activity has stopped, then remove the CD/
DVDs.

Make sure the Disk LED and ODD indicators are off. If you turn off the
power while a disk (disc) is being accessed, you can lose data or damage
the disk (disc).

User’s Manual 3-5

3. Click then click the arrow icon located in the power management
button . From the pull down menu, choose Shut Down.

4. Turn off the power to any peripheral devices.

Do not turn the computer or devices back on immediately. Wait a moment
to let all capacitors fully discharge.

Sleep Mode

If you have to interrupt your work, you can turn off the power without exiting
from your software. Data is maintained in the computer's main memory.
When you turn on the power again, you can continue working right where
you left off.

■ When the AC adaptor is connected, the computer will go into Sleep

Mode according to the settings in the Power Options.

■ To restore operation from Sleep Mode, press the power button or press

any key. The latter action works only if Wake-up on Keyboard is
enabled in HW Setup.

■ If the computer automatically enters Sleep Mode while a network

application is active, the application might not be restored when the
computer wakes up from Sleep Mode.

■ To prevent the computer from automatically entering Sleep Mode,

disable Sleep Mode in the Power Options. That action, however, will
nullify the computer's Energy Star compliance.

Getting Started

■ Before entering Sleep Mode, be sure to save your data.

■ Do not install or remove a memory module while the computer is in

Sleep Mode. The computer or the module could be damaged.

■ Do not remove the battery pack while the computer is in Sleep Mode

(unless the computer is connected to an AC power source). Data in
memory will be lost.

Benefits of Sleep Mode

The Sleep Mode feature provides the following benefits:

■ Restores the previous working environment more rapidly than

Hibernation Mode.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the duration set by the System Sleep
Mode feature.

■ You can use the panel power off feature.

User’s Manual 3-6

Getting Started

Entering Sleep Mode

You can enter Sleep Mode in one of three ways:

■ Click Start then click the power button ( ) located in the power

management buttons ( ).
Please note that this feature must be enabled within the Power Options

(to access it, click  Control Panel  System and
Maintenance  Power Options).

■ Click , click power button located in the power management

buttons , or click arrow button and select Sleep from
the menu.

■ Close the display panel. This feature must be enabled. Please refer to

the Power Options (to access it, click  Control Panel  System
and Maintenance  Power Options).

When you turn the power back on, you can continue where you left when
you shut down the computer.

You can also enable Sleep Mode by pressing Fn + F3. Refer to Chapter 5,

The Keyboard, for details.

■ When the computer is shut down in Sleep Mode, the power indicator

flashes orange.

■ If you are operating the computer on battery power, you can lengthen

the operating time by turning it off into Hibernation Mode, as Sleep
Mode consumes more power.

Sleep Mode limitations

Sleep Mode will not function under the following conditions:

■ Power is turned back on immediately after shutting down.

■ Memory circuits are exposed to static electricity or electrical noise.

Hibernation Mode

The hibernation feature saves the contents of memory to the hard disk
when the computer is turned off. The next time the computer is turned on,
the previous state is restored. The hibernation feature does not save the
status of peripheral devices.

■ Save your data. While entering Hibernation Mode, the computer saves

the contents of memory to the HDD. However, for safety sake, it is best
to save your data manually.

■ Data will be lost if you remove the battery or disconnect the AC adaptor

before the save is completed. Wait for the disk indicator to go out.

■ Do not install or remove a memory module while the computer is in

Hibernation Mode. Data will be lost.

User’s Manual 3-7

Getting Started

Benefits of Hibernation Mode

The Hibernation Mode feature provides the following benefits:

■ Saves data to the hard disk when the computer automatically shuts

down because of a low battery.

■ You can return to your previous working environment immediately when

you turn on the computer.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the duration set by the System
hibernate feature.

■ You can use the panel power off feature.

Starting Hibernation Mode

You can also enable Hibernation Mode by pressing Fn + F4. Refer to
Chapter 5, The Keyboard, for details.

To enter Hibernation Mode, follow the steps below.

1. Click .

2. Click the arrow icon located in the power management button

3. From the pull down menu, select Hibernate.

.

Automatic Hibernation Mode

The computer will enter Hibernation mode automatically when you press
the power button or close the Display Screen. First, however, make the
appropriate settings according to the steps below.

1. Open the Control Panel.

2. Open System and Maintenance and open Power Options.

3. Select the Choose what the power button does.

4. Enable the desired Hibernation settings for When I press the power
button and When I close the lid.

5. Click the Save changes button.

Data saving in Hibernation Mode

When you turn off the power in Hibernation Mode, the computer takes a
moment to save current memory data to the hard disk. During this time, the
disk indicator will light.

After you turn off the computer and memory is saved to the hard disk, turn
off the power to any peripheral devices.

Do not turn the computer or devices back on immediately. Wait a moment
to let all capacitors fully discharge.

User’s Manual 3-8

Getting Started

Restarting the computer

Certain conditions require that you reset the system. For example, if:

■ You change certain computer settings.

■ An error occurs and the computer does not respond to your keyboard

commands.

There are three ways to reset the computer system:

1. Click then click the arrow icon located in the power management
button , and select Restart from pull down menu.

2. Press Ctrl + Alt + Del to display the menu window, then select Restart
from the Shut down options.

3. Press the power button and hold it down for five seconds. Once the
computer has turned itself off, wait between ten and fifteen seconds
before turning it on again with the power button.

System Recovery Options and Restoring the pre-installed Software

System Recovery Options

About 1.5GB hidden partition is allocated on the hard disk drive for the
System Recovery Options.

This partition stores files which can be used to repair the system in the
event of a problem.

The System Recovery Options feature will be unusable if this partition is
deleted.

The System Recovery Options feature is installed on the hard disk when
shipped from the factory. The System Recovery Options menu includes
tools to repair startup problems, run diagnostics or restore the system.

See the Windows Help and Support content for more information about
Startup Repair.

The System Recovery Options can also be run manually to repair
problems.

The procedure is as follows. Follow the instructions shown on the on­screen menu.

1. Turn off the computer.

2. Turn on the computer and when the TOSHIBA screen appears
repeatedly press the F8 key.

3. The Advanced Boot Options menu will be displayed.
Use the arrow keys to select Repair Your Computer and press
ENTER.

4. Follow the on-screen instructions.

The Windows Vista® CompletePC Backup feature can be used on
Windows Vista

User’s Manual 3-9

®

Business Edition and Ultimate Edition.

Restoring the pre-installed Software

Depending on the model you purchased, different ways for restoring the
pre-installed software are offered:

■ Creating optical Recovery Discs

■ Restoring the pre-installed software from your created Recovery Discs.

■ Restoring the pre-installed software from the Recovery hard disk drive.

Creating Optical Recovery Discs

This section describes how to create Recovery Discs.

■ Be sure to connect the AC adaptor when you create Recovery Discs.

■ Be sure to close all other software programs except the Recovery Disc

Creator.

■ Do not run software such as screen savers which can put a heavy load

on the CPU.

■ Operate the computer at full power.

■ Do not use power-saving features.

■ Do not write to the disc when the virus check software is running. Wait

for it to finish, then disable virus detection programs including any
software that checks files automatically in the background.

■ Do not use utilities, including those intended to enhance hard disk drive

access speed. They may cause unstable operation and damage data.

■ Do not shut down/log off or Sleep/Hibernate while writing or rewriting

the disc.

■ Set the computer on a level surface and avoid places subjected to

vibrations such as airplanes, trains or cars.

■ Do not place your computer on unstable tables or any other unstable

surfaces.

A recovery image of the software on your computer is stored on the hard
disk drive, and can be copied to DVD media by using the following steps:

1. Have a blank DVD media ready.

2. The application will allow you to choose from a variety of different media
onto which the recovery image can be copied including DVD-R,
DVD-RW, DVD+R, DVD+RW.

Getting Started

Please note that some of the above media may not be compatible with the
optical disc drive installed into your computer. You should therefore verify
the optical disc drive supports the blank media you have chosen before
proceeding.

3. Turn on your computer and allow it to load the Windows Vista®
operating system from the hard disk drive as normal.

4. Insert the first blank media into the optical disc drive tray.

®

5. Double click the Recovery Disc Creator icon on the Windows Vista
desktop, or select the application from Start Menu.

User’s Manual 3-10

Getting Started

6. After Recovery Disc Creator starts, select the type of media and the title
you wish to copy, and then click the Create button.

7. Follow the on-screen instructions.

Your Recovery Discs will be created.

Restoring the pre-installed software from your created Recovery
Discs

If the pre-installed files are damaged, you are able to use the Recovery
Discs you have created to restore the computer to the state it was in when
you originally received it. To perform this restoration, follow the steps
below:

When the sound mute feature has been activated by pressing the
Fn + ESC key, be sure to disable this to allow sounds to be heard before
starting the restore process. Please refer to Chapter 5, The Keyboard, for
further details.

When you reinstall the Windows operating system, the hard disk will be
reformatted and all data will be lost.

1. Load the Recovery Discs into the optical disc drive and turn off the
computer's power.

2. While holding down F12 key on the keyboard, turn on your computer ­when the TOSHIBA logo screen appears, release the F12 key.

3. Use the cursors key to select the CD-ROM icon from the menu. Please
refer to the Boot Priority section in Chapter 7, HW Setup for further
information.

4. A menu will be displayed from which you should follow the on-screen
instructions.

Restoring the pre-installed software from the Recovery hard disk
drive

On your Data drive you may find a folder "HDDRecovery". This folder
stores files which can be used to recover your system to the originally
installed factory state.

If you subsequently set up your hard disk drive again, do not change,
delete or add partitions in a manner other than specified in the manual,
otherwise you may find that space for the required software is not available.

In addition, if you use a third-party partitioning program to reconfigure the
partitions on your hard disk drive, you may find that it becomes impossible
to setup your computer.

When the sound mute feature has been activated by pressing the
Fn + ESC key, be sure to disable this to allow sounds to be heard before
starting the restore process. Please refer to Chapter 5, The Keyboard, for
further details.

User’s Manual 3-11

Getting Started

Be sure to connect the AC adaptor, otherwise you may run out of battery
during the recovery process.

When you reinstall the Windows operating system, the hard disk will be
reformatted and all data will be lost.

1. Turn off the computer.

2. Turn on the computer and when the TOSHIBA screen appears
repeatedly press the F8 key.

3. The Advanced Boot Options menu will be displayed.
Use the arrow keys to select Repair Your Computer and press
ENTER.

4. Select your preferred keyboard layout and press Next.

5. To access the recovery process please log on as an enabled user with
sufficent rights.

6. Click TOSHIBA HDD Recovery on the System Recovery Options
screen.

7. Follow the on-screen instructions on the TOSHIBA HDD Recovery
dialog.

The computer will be restored to its factory state.

User’s Manual 3-12

Operating Basics

This chapter gives information on basic operations including using the
TouchPad, the optional fingerprint sensor, the optional web camera,
optional internal microphone, optical media drives, sound system, modem,
the Wireless LAN and LAN. It also provides tips on caring for your
computer.

Using the TouchPad

To use the TouchPad, simply touch and move your finger tip across it in the
direction you want the on-screen pointer to go.

Operating Basics

Chapter 4

TouchPad

TouchPad control buttons

TouchPad and TouchPad control buttons

Two buttons below the keyboard are used like the buttons on a mouse
pointer. Press the left button to select a menu item or to manipulate text or
graphics designated by the pointer. Press the right button to display a menu
or other function depending on the software you are using.

User’s Manual 4-1

Do not press on the TouchPad too hard or press a sharp object such as a
ball point pen against the TouchPad. The TouchPad could be damaged.

For some functions, you can tap the TouchPad instead of pressing a control
button.

Click: Tap the TouchPad once
Double-click: Tap the TouchPad twice
Drag and drop: 1. Hold down the left control button and move the

cursor to drag the item you want to move.

2. Lift your finger to drop the item where you want it.

Scroll: Vertical: Move your finger up or down the right edge

of the TouchPad.
Horizontal: Move your finger left or right along the

bottom edge of the TouchPad.

Using the fingerprint sensor (optional)

Your computer has a fingerprint utility installed for the purpose of enrolling
and recognizing fingerprints. By enrolling the ID and password to the
fingerprint authentication device, it is no longer necessary to input the
password from the keyboard. Just by swiping the finger against the
fingerprint sensor, the following functions will be enabled:

■ Logon to Windows and access a security-enabled homepage through

IE (Internet Explorer).

■ Files and folders can be encrypted/decrypted and third party access to

them prevented.

■ Disable the password-protected screensaver when returning from

power-saving (Sleep) mode.

■ Pre-OS feature and Single Sign-On feature.

■ Authentication of the User Password and Hard Disk Password when

booting up the computer.

To "swipe" refers to the action of reading a fingerprint using the fingerprint
sensor.

Operating Basics

User’s Manual 4-2

How to swipe the finger

Using the following steps when swiping fingers for fingerprint registration or
authentication will help to minimize authentication failures:

1. Align the first joint of the finger to the center of the sensor. Lightly touch
the sensor and swipe finger levelly towards you.

2. While lightly touching the sensor, swipe the finger towards you until the
sensor surface becomes visible.

3. Ensure the center of the fingerprint is on the sensor when swiping the
finger.

Slide the finger over the recognition sensor

■ Avoid swiping with the finger stiff or pressing too hard:

Fingerprint reading may fail if the center of the fingerprint is not
touching on the sensor, or when finger is swiped while pressing hard.
Make sure that the center of the fingerprint is touching the sensor
before swiping.

■ Confirm the center of the fingerprint whirl before swiping:

The thumb’s fingerprint has a bigger whirl, which is prone to
misalignment and distortions. This will cause difficulty in registration
and a drop in the authentication success rate. Always confirm the
center of the fingerprint whirl so that it is swiped along the centerline of
the sensor.

■ When fingerprint reading is not successful:

There is a possibility of authentication failures if the finger is swiped too
quickly or too slowly. Follow the onscreen instructions to adjust the
speed of the swipe.

Operating Basics

Points to note about the fingerprint sensor

Failure to follow these guidelines might result in (1) damage to the sensor
or cause sensor failure, (2) finger recognition problems, or lower finger
recognition success rate.

■ Do not scratch or poke the sensor with your nails or any hard or sharp

objects.

■ Do not press the sensor strongly.

User’s Manual 4-3

Operating Basics

■ Do not touch the sensor with a wet finger or any wet objects. Keep

sensor surface dry and free of water vapor.

■ Do not touch the sensor with a soiled finger. Minute foreign particles on

a soiled or dirty finger may scratch the sensor.

■ Do not paste stickers or write on the sensor.

■ Do not touch the sensor with a finger or any object with built-up static

electricity.

Observe the following before you place your finger on the sensor whether
for fingerprint enrollment/registration or recognition.

■ Wash and dry your hands thoroughly.

■ Remove static electricity from your fingers by touching any metal

surface. Static electricity is a common cause of sensor failures,
especially when the weather is dry.

■ Clean the sensor with a lint-free cloth. Do not use detergent to clean the

sensor.

■ Avoid the following finger conditions for enrollment or recognition as

they may result in fingerprint enrollment errors or a drop in the
fingerprint recognition success rate

■ Soaked or swollen finger (e.g. after taking bath)

■ Injured finger

■ Wet finger

■ Soiled or oily finger

■ Extremely dry skin condition on finger

Observe the following to improve the fingerprint recognition success rate.

■ Enroll two or more fingers.

■ Enroll additional fingers if recognition failure occurs often using enrolled

fingers.

■ Check your finger condition. Changed conditions, such as injured,

rough, extremely dry, wet, soiled, dirty, oily, soaked, swollen fingers,
may lower the recognition success rate. Also if the fingerprint is worn
down or the finger becomes thinner or fatter, the recognition success
rate may be lowered.

■ The fingerprint for each finger is different and unique. Please ensure

that only the registered or enrolled fingerprint or fingerprints are used
for identification.

■ Check sliding position and speed.

■ Fingerprint data can be enrolled up to 30~34 times.

■ Fingerprint data is stored into the nonvolatile memory in the fingerprint

sensor. Deleting fingerprint data with Delete menu on Fingerprint
Software Management before you dispose the computer is
recommended.

User’s Manual 4-4

How to delete the fingerprint data

Saved fingerprint data is stored in the Non-volatile memory inside the
fingerprint sensor. If you hand over the PC to others, or dispose of it, the
following operations are recommended.

1. Click Start, point to All Programs, point to TrueSuite Access
Manager and click it.

2. The TrueSuite Access Manager Fingerprint Software screen is
displayed.

3. Enter your Windows Password and click Next to enter the Control
Center. Or swipe your enrolled finger to enter the Control Center.

4. Click Delete All Fingerprints.

Fingerprint sensor limitations

■ The fingerprint sensor compares and analyzes the unique

characteristics in a fingerprint.

■ A warning message will be displayed when recognition is abnormal or

recognition is not successful within a fixed duration.

■ The recognition success rate may differ from user to user.

■ Toshiba does not guarantee that this fingerprint recognition technology

will be error-free.

■ Toshiba does not guarantee that the fingerprint sensor will recognize

the enrolled user or accurately screen out unauthorized users at all
times. Toshiba is not liable for any failure or damage that might arise out
of the use of this fingerprint recognition software or utility.

Operating Basics

Points to note about the fingerprint utility

■ If Windows Vista™’s file encryption function EFS (Encryption File

System) is used to encrypt a file, the file cannot be further encrypted
using the encryption function of this software.

■ You can back up the fingerprint data or the information registered to

Password Bank.

■ Please use Import/Export menu on Fingerprint Software Management.

■ Please also refer to the fingerprint utility Help file for more information.

You can start it using the following method:

■ Click Start, point to All Programs, point to TrueSuite Access

Manager and click Document.

■ Click Start, point to All Programs, point to TrueSuite Access

Manager and click it. The main screen is displayed. Click Help in

the upper right corner of the screen.

User’s Manual 4-5

Set up procedure

Please use the following procedure when first using fingerprint
authentication.

Fingerprint registration

Enroll the required authentication data using the Fingerprints Enrollment
Wizard.

■ The fingerprint authentication uses the same Windows logon ID and

password. If the Windows logon password has not been setup, please
do so before registration.

■ Up to 30~34 fingerprint patterns can be registered.

1. Click Start, point to All Programs, point to TrueSuite Access
Manager and click it. Or double click the icon in the Task Bar.

2. The Enter Windows Password screen is displayed. Enter a password
into the Enter Windows Password field. Click Next.

3. The Control Center screen is displayed. Click the non-enrolled finger
icon above the finger.

4. The Fingerprint Enrollment screen is displayed. Confirm the message
and click Next.

5. The Scanning Practice screen is displayed. You can practice swiping
your finger. When you have finished practicing swiping your finger, click
Next.

6. The Fingerprint Image Capture screen is displayed. Follow the
onscreen instructions and use the same finger you have selected under
the Control Center to swipe your finger with good images three times for
the fingerprint template to be created.

7. In case of finger injury or authentication failure, it is recommended that
another fingerprint also be enrolled. The following message will be
displayed: [We recommended enrolling at least two

fingerprint images.]

6 with another finger.

Click OK and repeat steps 3, 4, 5 and

Operating Basics

User’s Manual 4-6

Windows logon via fingerprint authentication

In place of the usual Windows logon by ID and password, fingerprint
authentication also allows logon to Windows.

This is useful especially when many users are using the PC, as user
selection can be skipped.

Fingerprint authentication procedure

1. Start up the computer.

2. The Logon Authorization screen is displayed. Choose any of the
enrolled fingers and swipe the fingerprint on the sensor.
If authentication is successful, the user will be logged on to Windows.

■ If the fingerprint authentication fails, please logon using the Windows

logon password.

■ Please logon using the Windows logon password if the fingerprint

authentication failed for five times. To logon using the Windows logon
password, enter the Windows logon password at the
screen as normal.

■ A warning message will be displayed when authentication is abnormal

or authentication is not successful within a fixed duration.

[Welcome]

Fingerprint system boot authentication

Operating Basics

General

The fingerprint authentication system can be used to replace the keyboard
based User Password authentication system when booting up.

If you do not want to use the fingerprint authentication system for password
authentication when booting up, but prefer to use the keyboard-based
system instead, press the BACK SPACE key when the Fingerprint System
Boot Authentication screen is displayed. This will switch the password input
screen to the keyboard-based one.

■ It is necessary to register the User Password before using the

fingerprint Pre-OS feature and its extended function, the fingerprint
Single Sign-On feature. Please use TOSHIBA HW Setup to register the
User Password.

■ If you fail fingerprint authentication more than five times, you must

enter the User Password or Supervisor Password manually to start the
computer.

■ When swiping, please do it slowly and at a constant speed. If this does

not improve the authentication rate, please adjust the speed.

■ If there are any changes in the environment or settings related to

authorization, you will be required to provide authorization information
such as a User Password and HDD password.

User’s Manual 4-7

How to enable fingerprint system boot authentication
settings

It is necessary to first enroll your fingerprint with the TrueSuite Access
Manager application prior to enabling and configuring the fingerprint Pre­OS feature.

Check that your fingerprint is enrolled before configuring the settings.

1. Swipe your finger across the fingerprint sensor. Or enter Windows
password and click Next.

2. Click settings.

3. The Administrator Settings screen is displayed. Place a checkmark in
"Enable Pre-OS Fingerprint Authentication" and click OK.

The modified configuration for fingerprint Pre-OS feature becomes effective
the next time the system is booted up.

Fingerprint Single Sign-On feature

General

This is a feature that allows the user to complete the authentication for both
the User Password (and optionally, the HDD user and Supervisor
passwords) and logging on to Windows using only one fingerprint
authentication when booting up. It is necessary to register the User
Password and Windows Logon password before using the fingerprint Pre­OS feature and this fingerprint Single Sign-On feature. Please use
TOSHIBA HW Setup to register your User Password.

Only one fingerprint authentication is required to replace the User
Password (and, if selected, the HDD user and Supervisor passwords) and
Windows Logon password.

Operating Basics

How to enable fingerprint Single Sign-On feature

It is necessary to first enroll your fingerprint with the TrueSuite Access
Manager application prior to enabling and configuring the fingerprint Single
Sign-On feature. Check that the fingerprint is enrolled before configuring
the settings.

1. Swipe your finger across the fingerprint sensor. Or enter Windows
password and click Next.

2. Click settings.

3. The Administrator Settings screen is displayed. Place a checkmark in
"Enable Pre-OS Fingerprint Authentication".

4. Then, place a checkmark in "Enable Single Sign-On Fingerprint
Authentication" and click OK.

The modified configuration for the fingerprint Single Sign-On feature
becomes effective the next time the system is booted up.

User’s Manual 4-8

Fingerprint utility limitations

TOSHIBA does not guarantee that the fingerprint utility technology will be
completely secure or error-free. TOSHIBA does not guarantee that the
fingerprint utility will accurately screen out unauthorized users at all times.
TOSHIBA is not liable for any failure or damage that might arise out of the
use of the fingerprint software or utility.

USB Sleep and Charge function

Your computer can supply USB bus power (DC5V) to the USB port even
when the power of the computer is turned OFF. "Power OFF" includes
Sleep Mode, Hibernation Mode or shutdown state.

This function can only be used for ports that support the USB Sleep and
Charge function (hereinafter called "compatible ports").

Compatible ports are USB ports that have the ( ) symbol icon.
You can use the "USB Sleep and Charge function" to charge certain USB-

compatible external devices such as mobile phones or portable digital
music players.

However, the "USB Sleep and Charge function" may not work with certain
external devices even if they are compliant with the USB specification. In
those cases, turn the power of the computer ON to charge the device.

■ The "USB Sleep and Charge function" only works for compatible ports.

This function is disabled in the default setting. To enable it, you must
change [Disabled] to [Enabled] in the HW setup.

■ When "USB Sleep and Charge function" is set to [Enabled] in HW

Setup, USB bus power (DC5V) will be supplied to compatible ports
even when the power of the computer is turned OFF.
USB bus power (DC5V) is similarly supplied to the external devices
which are connected to the compatible ports. However, some external
devices cannot be charged solely by supplying USB bus power
(DC5V). As for the specifications of the external devices, please
contact the device manufacturer or check the specifications of the
external devices thoroughly before use.

■ Using the USB sleep and charge function to charge external devices

will take longer than charging the devices with their own chargers.

■ If external devices are connected to compatible ports when the AC

adaptor is not connected to the computer, the battery of the computer
will be depleted even when the power of the computer is turned OFF.
As such, we recommend that you connect the AC adaptor to the
computer when using the USB sleep and charge function.

■ External devices connected to the USB bus power (DC5V) function that

interfaces with the power ON/OFF of the computer may always be in
an operational state.

■ When there is a current overflow of the external devices connected to

the compatible ports, USB bus power (DC5V) supply may be stopped
for safety reasons.

Operating Basics

User’s Manual 4-9

■ Metal paper clips or hair pins/clips will generate heat if they come into

contact with USB ports. Do not allow USB ports to come into contact
with metal products, for example when carrying the computer in your
bag.

How to enable/disable USB sleep and charge function

You can set enable/disable USB sleep and charge function in HW setup
Refer to the

USB Sleep and Charge function

Using the Web Camera (optional)

This section describes the webcam utility, which can capture still and video
images. The web camera will auto-run when Windows starts.

Please unstick the protective plastic-film before using the Web Camera.

in Chapter 7

Built-in microphone*

Web Camera Lens*

Web Camera LED*

Operating Basics

Operating Basics

.

* Provided with some models

User’s Manual 4-10

Using the software

The web camera software is pre-configured to start when you turn on
Windows Vista; if you need to restart it go to Start  All Programs 
Camera Assistant Software  Camera Assistant Software.

Capture Still

Images

Effects Mute

Capture Still Images Click to see a preview of the captured image; you

can also e-mail the image.

Video Recording Click to prepare for recording. Click again to start

recording. One more to stop recording and see
preview of the video.

Audio Recording Click to start recording, click again to stop and

listen to a preview of the audio.

Function Access additional functions: About, Player,

Effects, Properties, Settings and Help.

About Displays software manufacturer details.
Player Play video files.
Effects Choose images to be displayed on the capture

screen.

Properties Choose from the Options tab to flip, zoom, flicker

rate, night mode and backlight compensation; in
the Image tab change the color settings; in the
Profiles tab change the lighting conditions.

Video

Recording

Audio

Recording

Operating Basics

Function

Display Window

Camera resolution

User’s Manual 4-11

Operating Basics

Settings Choose from the: Options tab to change the tool

Help Displays the help files for the software.

bar position; the Picture tab to select picture
output options such as size, export file and save
path; the Video tab to choose video output
settings such as Frame Rate, Size, Compression
and the frame rate, size, record compressor, and
save path; the Audio tab to change the audio
device, audio compressor, audio volume and
save path.

Using the microphone (optional)

Some models in this series are equipped with a built-in microphone that
can be used to record monaural sounds into your applications. It can also
be used to issue voice commands to applications that support such
functions.(Built-in microphone is provided with some models)

Since your computer has a built-in microphone and speaker, "feedback"
may be heard under certain conditions. Feedback occurs when sound from
the speaker is picked up in the microphone and amplified back to the
speaker, which amplifies it again to the microphone.

This feedback occurs repeatedly and causes a very loud, high-pitched
noise. It is a common phenomenon that occurs in any sound system when
the microphone input is output to the speaker (throughput) and the speaker
volume is too loud or too close to the microphone. You can control
throughput by adjusting the volume of your speaker or through the Mute
function in the Master Volume panel. Refer to your Windows documentation
for details on using the Master Volume panel.

Using the optical disc drive

The full-size drive provides high-performance execution of CD/DVD-based
programs. You can run either 12 cm (4.72") or 8 cm (3.15") CDs without an
adaptor. An ATAPI interface controller is used for CD/DVD operation. When
the computer is accessing a CD/DVD, an indicator on the drive glows.

Refer also to the Writing CD/DVD with the DVD Super Multi drive

supporting DVD±R DL section for precautions on writing to CD/DVD.

User’s Manual 4-12

Loading discs

To load a disc, follow the steps below and refer to the figures.

1. a. When the power is on, press the eject button to open the drawer

slightly.

Eject Button

Pressing the eject button

b. Pressing the eject button will not open the drawer when the disc

drive's power is off. If the power is off, you can open the drawer by
inserting a slender object (about 15 mm) such as a straightened
paper clip into the eject hole just to the right of the eject button.

Operating Basics

Manual release with the eject hole

User’s Manual 4-13

2. Grasp the drawer gently and pull until it is fully opened.

Pulling the drawer open

3. Place the disc, label side up, in the drawer.

Operating Basics

Inserting a disc

User’s Manual 4-14

Operating Basics

When the drawer is fully opened, the edge of the computer will extend
slightly over the disc tray. Therefore, you will need to turn the disc at an
angle when you place it in the tray. After seating the disc, however, make
sure it lies flat, as shown in the figure above.

■ Do not touch the laser lens. Doing so could cause misalignment.

■ Keep foreign matter from entering the drive. Check the back edge of

the tray to make sure it carries no debris before closing the drive.

4. Press gently at the centre of the disc until you feel it click into place. The
disc should lie below the top of the spindle, flush with the spindle base.

5. Push the center of the drawer to close it. Press gently until it locks into
place.

If the disc is not seated properly when the drawer is closed, the disc might
be damaged. Also, the drawer might not open fully when you press the
eject button.

Closing the disc drawer

User’s Manual 4-15

Removing discs

To remove the disc, follow the steps below.

Do not press the eject button while the computer is accessing the disc
drive. Wait for the optical media drive indicator to go out before you open
the drawer. Also, if the disc is spinning when you open the drawer, wait for
it to stop before you remove it.

1. To pop the drawer partially open, press the eject button. Gently pull the
drawer out until it is fully opened.

■ When the drawer pops open slightly, wait a moment to make sure the

disc has stopped spinning before pulling the drawer fully open.

■ Turn off the power before you use the eject hole. If the disc is spinning

when you open the drawer, the disc could fly off the spindle and cause
injury.

2. The disc extends slightly over the sides of the drawer so you can hold it.
Hold the disc gently by its edges and lift it out.

Operating Basics

Removing a disc

3. Push the centre of the drawer to close it. Press gently until it locks into
place.

User’s Manual 4-16

Operating Basics

Writing CD/DVD with the DVD Super Multi drive supporting DVD±R DL

Some models in this series are equipped with Writing CD/DVD with the
DVD Super Multi drive (Supporting DVD±R DL).

You can use the DVD Super Multi drive to write data to either CD-R/RW or
DVD-R/-RW/+R/+RW/-RAM discs. The following applications for writing are
preinstalled: TOSHIBA Disc Creator and Ulead DVD MovieFactory for
TOSHIBA.

Important message (DVD Super Multi drive supporting DVD±R DL)

Before you write or rewrite to CD-R/RW or DVD-R/-RW/+R/+RW/-RAM
discs, read and follow all setup and operating instructions in this section. If
you fail to do so, the DVD Super Multi drive may not function properly, and
you may fail to write or rewrite, lose data or incur other damage.

Before writing or rewriting

■ Based on TOSHIBA's limited compatibility testing, we suggest the

following manufacturers of CD-R/RW and DVD-R/+R/-RW/+RW/-RAM
discs. However, in no event does TOSHIBA guarantee the operation,
quality or performance of any disc. Disc quality can affect write or
rewrite success rates.

CD-R: TAIYO YUDEN Co., Ltd.

MITSUBISHI KAGAKU MEDIA CO, LTD.
Ricoh Co., Ltd.

Hitachi Maxell Ltd.

CD-RW: MITSUBISHI KAGAKU MEDIA CO, LTD.

Ricoh Co., Ltd.

High Speed CD-RW: MITSUBISHI KAGAKU MEDIA CO, LTD.

Ricoh Co., Ltd.

Ultra Speed CD-RW: MITSUBISHI KAGAKU MEDIA CO, LTD.

DVD-R: DVD Specifications for Recordable disc for

DVD-R (DL): MITSUBISHI KAGAKU MEDIA CO, LTD.
DVD+R: MITSUBISHI KAGAKU MEDIA CO, LTD.

DVD+R (DL): MITSUBISHI KAGAKU MEDIA CO, LTD.

DVD-RW: DVD Specifications for Recordable Disc for

General Version 2.0

TAIYO YUDEN Co., Ltd.
Matsushita Electric Industrial Co., Ltd.

Ricoh Co., Ltd.

Version 1.1 or 1.2

Victor Company of Japan, Ltd. (JVC)
MITSUBISHI KAGAKU MEDIA CO, LTD.

User’s Manual 4-17

Operating Basics

DVD+RW: MITSUBISHI KAGAKU MEDIA CO, LTD.

DVD-RAM: DVD Specifications for DVD-RAM Disc for

Version 2.0, 2.1 or 2.2

Hitachi Maxell Ltd.
Matsushita Electric Industrial Co., Ltd.

This drive cannot use discs that allow writing of 8 speeds or more (DVD-R,
DVD+R, DVD+RW ), or 6 speeds or more (DVD-RW)

■ If the disc is poor in quality, dirty or damaged, writing or rewriting errors

may occur. Be careful to check the disc for dirt or damage before you
use it.

■ The actual number of rewrites to CD-RW, DVD-RW, DVD+RW or

DVD-RAM is affected by the quality of the disc and the way it is used.

■ There are two types of DVD-R discs: authoring and general use discs.

Do not use authoring discs. Only general use discs can be written to by
a computer drive.

■ We can support only Format1 of DVD-R DL. Therefore you cannot do

the additional writing. If your data is under 4.7 GB, we suggest to use
DVD-R (SL) media.

■ You can use DVD-RAM discs that can be removed from a cartridge and

DVD-RAM discs designed without a cartridge. You can not use a disc
with a 2.6 GB single-sided capacity and 5.2 GB double-sided capacity.

■ Other DVD-ROM drives for computers or other DVD players may not be

able to read DVD-R/-RW or DVD+R/+RW discs.

■ Data written to a CD-R/DVD-R/DVD+R disc cannot be deleted either in

whole or in part.

■ Data deleted (erased) from a CD-RW, DVD-RW, DVD+RW and

DVD-RAM disc cannot be recovered. Check the content of the disc
carefully before you delete it. If multiple drives that can write data to
discs are connected, be careful not to delete data from the wrong drive.

■ In writing to a DVD-R/-RW, DVD+R/+RW or DVD-RAM disc, some disc

space is required for file management, so you may not be able to write
the full capacity of the disc.

■ Since the disc is based on the DVD standard, it might be filled with

dummy data if the written data is less than about 1 GB. Even if you write
only a small amount of data, it might take time to fill in the dummy data.

■ DVD-RAM formatted by FAT32 cannot be read in Windows® 2000

without DVD-RAM Driver Software.

■ When multiple drives that can write data to discs are connected, be

careful not to write to the wrong drive.

■ Be sure to connect the AC adaptor before you write or rewrite.

■ Before you enter Sleep Mode/Hibernation Mode, be sure to finish

DVD-RAM writing. Writing is finished if you can eject DVD-RAM media.
Be sure to close all other software programs except the writing software.

■

User’s Manual 4-18

■ Do not run software such as a screen saver, which can put a heavy load

on the CPU.

■ Operate the computer under the power scheme High Performance. Do

not use power-saving features.

■ Do not write while virus check software is running. Wait for it to finish

and then disable virus detection programs including any software that
checks files automatically in the background.

■ Do not use hard disc utilities, including those intended to enhance HDD

access speed. They may cause unstable operation and data damage.

■ Write from the computer's hard disc drive to the CD/DVD. Do not try to

write from shared devices such as a LAN server or any other network
device.

■ Writing with software other than TOSHIBA Disc Creator is not

recommended.

When writing or rewriting

Please observe/consider the following when you write or rewrite to a CD-R/

-RW, DVD-R/-RW/-RAM or DVD+R/+RW disc.

■ Do not perform any of the following actions when writing or rewriting:

■ Change users in the Windows® Vista operating system.

■ Operate the computer for any other function, including using a

mouse or TouchPad or closing/opening the LCD panel.

■ Start a communication application such as a modem.

■ Apply impact or vibration to the computer.

■ Install, remove or connect external devices, including the following:

PC Card, USB devices, external display, optical digital devices.

■ Use the audio/video control buttons to reproduce music or voice.

■ Open the DVD Super Multi drive.

■ Do not use shut down/log off and Sleep Mode/Hibernation Mode while

writing or rewriting.

■ Make sure writing or rewriting is completed before going into Sleep

Mode/Hibernation Mode. Writing is completed if you can open the
DVD Super Multi drive tray.

■ Set the computer on a level surface and avoid places subject to

vibration such as airplanes, trains, or cars. Do not use an unstable
surface such as a stand.

■ Keep mobile phones and other wireless communication devices away

from the computer.

■ Always copy data from the hard disk drive to the CD-R/-RW,DVD-R/

-RW/-RAM or DVD+R/+RW disc. Do not use cut-and-paste. The
original data will be lost if there is a write error.

Operating Basics

User’s Manual 4-19

Disclaimer (DVD Super Multi drive supporting DVD±R DL)

TOSHIBA does not bear responsibility for the following:

■ Damage to any CD-R/RW or DVD-R/-RW/+R/+RW/-RAM disc that may

be caused by writing or rewriting with this product.

■ Any change or loss of the recorded contents of CD-R/RW or DVD-R/

-RW/+R/+RW/-RAM disc that may be caused by writing or rewriting with
this product, or for any business profit loss or business interruption that
may be caused by the change or loss of the recorded contents.

■ Damage that may be caused by using third party equipment or

software. Given the technological limitations of current optical disc
writing drives, you may experience unexpected writing or rewriting
errors due to disc quality or problems with hardware devices. Also, it is
a good idea to make two or more copies of important data, in case of
undesired change or loss of the recorded contents.

TOSHIBA Disc Creator

Note the following limitations when you use TOSHIBA Disc Creator:

■ DVD-Video cannot be created using TOSHIBA Disc Creator.

■ DVD-Audio cannot be created using TOSHIBA Disc Creator.

■ You cannot use the TOSHIBA Disc Creator "Audio CD" function to

record music to the DVD-R/-RW or DVD+R/+RW media.

■ Do not use the "Disc Backup" function of TOSHIBA Disc Creator to

copy

■ DVD-Video and DVD-ROM with copyright protection. DVD-RAM media

cannot be backed up with the "Disc Backup" function of TOSHIBA Disc
Creator.

■ You cannot back up a CD-ROM or CD-R/RW to DVD-R/-RW or DVD+R/

+RW using the "Disc Backup" function of TOSHIBA Disc Creator.

■ You cannot back up DVD-ROM, DVD-Video or DVD-R/-RW or DVD+R/

+RW to CD-R/RW using TOSHIBA Disc Creator.

■ TOSHIBA Disc Creator cannot record in packet format.

■ You might not be able to use the Disc Backup function of TOSHIBA

Disc Creator to backup a DVD-R/-RW or DVD+R/+RW disc that
wasmade with other software on a different DVD-R/-RW or DVD+R/
+RW recorder.

■ If you add data to a DVD-R and DVD+R disc that you have already

recorded to, you might not be able to read the added data under some
circumstances. It cannot be read in 16-bit operating systems, such as
Windows
Service Pack 6 or later to read the data, and in Windows
need Service Pack 2 or later to read it. Some optical media drives
cannot read added data regardless of the operating system.

■ TOSHIBA Disc Creator does not support recording to DVD-RAM discs.

To record to a DVD-RAM, use Explorer or other similar utility.

®

98SE and Windows® ME, in Windows® NT4 you will need

Operating Basics

®

2000 you will

User’s Manual 4-20

■ When you back up a DVD disc, be sure the source drive supports

recording to DVD-R/-RW or DVD+R/+RW discs. If the source drive
does not support recording to DVD-R/-RW or DVD+R/+RW discs, it
might not be backed up correctly.

■ When you back up a DVD-R, DVD-RW, DVD+R or DVD+RW, be sure to

use the same type of disc.

■ You cannot partially delete any data written to a CD-RW, DVD-RW or

DVD+RW disc.

Data Verification

To verify that data is written or rewritten correctly, follow the steps below
before you write or rewrite a Data CD/DVD.

1. Display the setting dialog box by one of the following two steps:

■ Click the setting button ( ) for writing on the main toolbar in the

Data Disc mode.

■ In the Settings menu, select Settings for Each Mode, then Data

Disc.

2. Mark the Verify Written Data check box.

3. Select File Open or Full Compare mode.

4. Click the OK button.

Using Ulead DVD MovieFactory for TOSHIBA

Operating Basics

How to make a Labelflash DVD

Simplified steps for making a Labelflash DVD:

1. Insert a Labelflash disc in DVD drive.

Set PRINTING SIDE surface for underside.

2. Click  All Programs  DVD MovieFactory for TOSHIBA 
Ulead DVD MoiveFactory for TOSHIBA Laucher to launch DVD

Moive Factory.

3. Click Print Dise Label  Label Printing. Ulead Label@Once is
started.

4. Click the General tab.

5. Choose DVD Drive for Printer. e.g. <E:> PIONEER DVD…

6. Add and customize the look of your images and text.

7. Click Labelflash setting and choose Draw Quality.

8. Click Print.

User’s Manual 4-21

How to make a DVD-Video

Simplified steps for making a DVD-Video from video data captured from a
DV-Camcorder:

1. Click  All Programs  DVD MovieFactory for TOSHIBA 
Ulead DVD MovieFactory for TOSHIBA Launcher to launch DVD
MovieFactory.

2. Insert a DVD-RW or DVD+RW disc in Burner.

3. Click Video Disc  Burn Video to Disc to launch Direct Recording
dialog box, choose DVD-Video/+VR to invoke Straight Capture to
Disc Page.

4. Choose DVD-Video format.

5. Confirm the capture source is DV.

6. Press Capture button.

Simplified steps for making a DVD-Video from adding video source:

1. Click  All Programs  DVD MovieFactory for TOSHIBA 
Ulead DVD MovieFactory for TOSHIBA Launcher to launch DVD
MovieFactory.

2. Click Video Disc  New Project to invoke 2
project type, then invoke DVD MovieFactory.

3. Add source from HD Disk by click Add video files button to invoke
browser dialog box.

4. Choose the source video then go to Next page to apply Menu.

5. After choose the menu template, press Next button to go to Burning
Page.

6. Choose the output type then press Burn button.

nd

Launcher, choose your

Operating Basics

How to learn more about Ulead DVD MovieFactory

Please refer to the Help and Manual files for additional Ulead DVD
MovieFactory information.

Important information for use

Note the following limitations when you write Video DVD:

1. Editing digital video

■ Log in with Administrator rights to use DVD MovieFactory.

■ Make sure that your computer is running on AC power when using

DVD MovieFactory.

■ Operate the computer at Full Power. Do not use power-saving

features.

■ While you are editing DVD, you can display preview. However, if

another application is running the preview might not display
properly.

■ DVD MovieFactory cannot edit or play copy protected content.

User’s Manual 4-22

Operating Basics

■ Do not enter sleep or hibernation mode while using DVD

MovieFactory.

■ Do not operate DVD MovieFactory immediately after turning on the

computer. Please wait until all Disc Drive activity has stopped.

■ When recording to a DV-Camcorder, to ensure you capture all of

your data, let the camcorder record for a few seconds before you
begin recording your actual data.

■ CD recorder, JPEG functions, DVD-Audio, mini DVD and Video CD

functions are not supported in this version.

■ While recording video to DVD, please close all other programs.

■ Do not run software like a screen saver because it can put a heavy

load on the CPU.

■ Do not support mp3 decode and encode.

2. Before recording the video to DVD

■ When you record DVD disc, please use only discs recommended by

the Drive manufacturer.

■ Do not set the working drive to a slow device like a USB 1.1 hard

disk drive or it will fail to write DVD.

■ Do not perform any of the following actions:

■ Operate the computer for any other function, including using a

mouse to TouchPad or closing/Opening the LCD panel.

■ Bump or cause vibration to the computer.

■ Use the Mode control button and Audio/Video control button to

reproduce music or voice.

■ Open the DVD drive.

■ Install, remove or connect external devices, including the

following: PC card, SD card, USB device, external display,
i.LINK. devices, optical digital devices.

■ Please verify your disc after recording important data.

■ DVD-R/+R/+RW disc cannot be written in VR format.

■ Not support to output VCD and SVCD format.

3. About Straight to Disc

■ Not support to record on DVD-R/+R disc

■ Not support to record DVD+VR format by HDV

■ HDV support to burn DVD-Video only

■ DVD-VR format not support to add Menu

4. About recorded DVDs

■ Some DVD-ROM drives for personal computers or other DVD

players may not be able to read DVD-R/+R/-RW/-RAM discs.

■ When playing your recorded disc on your computer, please use

WinDVD software application.

■ If you use an over-used rewritable disc, the full formatting might be

locked. Please use a brand new disc.

User’s Manual 4-23

Media care

This section provides tips on protecting data stored on your CD/DVD.
Handle your media with care. The following simple precautions will
increase the lifetime of your media and protect the data stored on them:

CD/DVDs

1. Store your CD/DVD in the container they came in to protect them and

2. Do not bend the CD/DVD.

3. Do not write on, apply a sticker to, or otherwise mar the surface of the

4. Hold the CD/DVD by its outside edge or the edge on the centre hole.

5. Do not expose to direct sunlight, extreme heat or cold. Do not place

6. If your CD/DVD become dusty or dirty, wipe them with a clean dry cloth.

Modem

This section describes how to connect and disconnect the internal modem
to and from a telephone jack.

Operating Basics

keep them clean.

CD/DVD that contains data.

Fingerprints on the surface can prevent the drive from properly reading
data.

heavy objects on your CD/DVD.

Wipe from the centre out, do not wipe in a circular direction around the
CD/DVD. If necessary, use a cloth dampened in water or a neutral
cleaner. Do not use benzine, thinner or similar cleaner.

The internal modem does not support voice functions. All data and fax
functions are supported.

■ In case of a lightning storm, unplug the modem cable from the

telephone jack.

■ Do not connect the modem to a digital telephone line. A digital line will

damage the modem.

Region selection

Telecommunication regulations vary from one region to another, so you will
need to make sure the internal modem's settings are correct for the region
in which it will be used.

To select a region, follow the steps below.

1. Click start, point to All Programs, TOSHIBA, Networking, and click
Modem Region Select.

Do not use the Country/Region Select function in the Modem setup utility
in the Control Panel if the function is available. If you change the Country/
Region in the Control Panel, the change may not take effect.

User’s Manual 4-24

2. The Region Selection icon will appear in the Task Bar. Click the icon
with the primary mouse button to display a list of regions that the
modem supports. A sub menu for telephony location information will
also be displayed. A check will appear next to the currently selected
region and telephony location.

3. Select a region from the region menu or a telephony location from the
sub-menu.

■ When you click a region it becomes the modem's region selection,

and the New Location for telephony will be set automatically.

■ When you select a telephony location, the corresponding region is

automatically selected and it becomes the modem's current region
setting.

Properties menu

Click the icon with the secondary mouse button to display properties menu
on the screen.

Settings

You can enable or disable the following settings:

AutoRun Mode

The Region Select utility starts automatically when you start up the
operating system.

Operating Basics

Open the Dialling Properties dialog box after selecting
region

The dialing properties dialog box will be displayed automatically after you
select the region.

Location list for region selection

A submenu appears displaying location information for telephony.

Open dialog box, if the modem and Telephony Current
Location region code do not match

A warning dialog box is displayed if current settings for region code and
telephony location are incorrect.

Modem Selection

If the computer cannot recognize the internal modem, a dialog box is
displayed. Select the COM port for your modem to use.

User’s Manual 4-25

Dialing Properties

Select this item to display the dialing properties.

If you are using the computer in Japan, the Telecommunications Business
Law requires that you select Japan region mode. It is illegal to use the
modem in Japan with any other selection.

Connecting

To connect the modem cable, follow the steps below.

■ The modular cable that comes with the computer must be used to

connect a modem. Connect the end of the modular cable with the core
to the computer.

■ In case of a lightning storm, unplug the modem cable from the

telephone jack.

■ Do not connect the modem to a digital telephone line. A digital line will

damage the modem.

1. Plug one end of the modular cable into the modem jack.

2. Plug the other end of the modular cable into a telephone jack.

Operating Basics

Connecting the internal modem

Do not pull on the cable or move the computer while the cable is
connected.

If you use a storage device such as an optical drive or hard disk drive
connected to a 16-bit PC Card, you might experience the following modem
problems:

■ Modem speed is slow or communication is interrupted.

■ Skips may occur in sound.

User’s Manual 4-26

Disconnecting

To disconnect the internal modem cable, follow the steps below.

1. Pinch the lever on the connector in the telephone jack and pull out the
connector.

2. In the same way, pull the cable’s other connector out of the computer.

Using the FM tuner

The availability of this feature is depending on the model you purchased.

1. Plug the FM tuner antenna into the FM Antenna jack.

FM Antenna
Jack

Operating Basics

FM tuner antenna

Plug FM tuner antenna into the jack

Select Start  All Programs  FM Tuner Utility to start FM software.

Wireless communications

The computer’s wireless communication function supports both Wireless
LAN and Bluetooth devices.

Only some models are equipped with both Wireless LAN and Bluetooth
functions.

User’s Manual 4-27

■ Do not use the Wireless LAN (Wi-Fi) or Bluetooth functionalities near a

microwave oven or in areas subject to radio interference or magnetic
fields. Interference from a microwave oven or other source can disrupt
Wi-Fi or Bluetooth operation.

■ Turn Wi-Fi and Bluetooth functionalities off when near a person who

may have a cardiac pacemaker implant or other medical electric
device. Radio waves may affect pacemaker or medical device
operation, possibly resulting in serious injury. Follow the instruction of
your medical device when using any Wi-Fi or Bluetooth functionality.

■ Always turn off Wi-Fi or Bluetooth functionality if the computer is near

automatic control equipment or appliances such as automatic doors or
fire detectors. Radio waves can cause malfunction of such equipment,
possibly resulting in serious injury.

■ It may not be possible to make a network connection to a specified

network name using the ad hoc network function.
If this occurs, the new network (*) will have to be configured for all
computers connected to the same network in order to re-enable
network connections.
* Please be sure to use new network name.

Wireless LAN

The Wireless LAN feature is not available on all models. Where present, it
supports the A,B, G and N standards but it is compatible with other LAN
systems based on Direct Sequence Spread Spectrum/Orthogonal
Frequency Division Multiplexing radio technology that complies with
IEEE802.11 Wireless LAN standard.

■ Automatic Transmit Rate Select mechanism in the transmit range of 54,

48, 36, 24, 18, 12, 9 and 6 Mbit/s. (IEEE 802.11g)

■ Automatic Transmit Rate Select mechanism in the transmit range of 11,

5.5, 2 and 1 Mbit/s. (IEEE 802.11b)

■ Roaming over multiple channels

■ Card Power Management

■ Wired Equivalent Privacy (WEP) data encryption, based on the 128 bit

encryption algorithm.

■ Advanced Encryption Standard (AES) data encryption, based on 128 bit

encryption algorithm.

Operating Basics

Security

■ Be sure to enable the encryption function otherwise you may expose

your computer to illegal access by an outsider across the Wireless LAN
which may cause intrusion, eavesdropping, and the loss or destruction
of stored data. TOSHIBA strongly recommend the customer to enable
the encryption function.

■ TOSHIBA is not liable for the eavesdropping of data due to the use of

Wireless LAN and the damage thereof.

User’s Manual 4-28

Operating Basics

Bluetooth Stack for Windows by TOSHIBA (depends on the model
purchased)

Please note that this software is specifically designed for the following
operating systems:

■ Microsoft® Windows Vista™

Detailed information regarding the use with these operating systems is
listed below. Please refer also to the electronic information which is
included with each software.

This Bluetooth Stack is based on Bluetooth Version 1.1/1.2/2.0+EDR
specification. TOSHIBA cannot confirm compatibility between any PC
products and/or other electronic devices that use Bluetooth other than
TOSHIBA notebook computers.

Release Notes related to the Bluetooth Stack for Windows
by TOSHIBA

1. Fax application software:
Regarding FAX application software, there are some software that you

cannot use on this Bluetooth Stack.

2. Multi User:
On Windows Vista™, the use of Bluetooth is not supported in a multi-

user environment. This means that, when you use Bluetooth, other
users logged onto the same computer will not be able to use its
Bluetooth functionality.

Product Support

The latest information regarding Operating System support, Language
Support or available upgrades can be found on our web site

http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or
http://www.pcsupport.toshiba.com in the United States.

Wireless communication switch

You can enable or disable the Wireless LAN function, with the on/off switch.
No transmissions are sent or received when the switch is off. Slid the
Switch to turn it on and turn it off.

Set the switch to off in airplanes and hospitals. Check the indicator. It will
stop glowing when the wireless communication function is off.

User’s Manual 4-29

Wireless activity LED

The wireless activity LED indicates the status of the wireless
communication functions.

Indicator status Indication
LED off Wireless communication switch is set to off.

LED glows Wireless communication switch is on. Wireless

If you used the Task Bar to disable Wireless LAN, you will need to restart
the computer to re-enable it. Alternatively, you can also follow this
procedure:

1. In the Control Panel, click System and Maintenance.

2. Click the Device Manager. The Device Manager window opens. Click

3. Select your preferred Network adaptor, then click the Enable button in

LAN

The computer has built-in support for Fast Ethernet LAN or Giga bit
Ehternet LAN (depends on the model you purchased). This section
describes how to connect/disconnect to a LAN.

Operating Basics

Automatic power down because of overheating.
Power malfunction

LAN is turned on by an application.

Network adaptors.

the tool bar.

LAN cable types

The computer must be configured properly before connecting to a LAN.
Logging onto a LAN using the computer's default settings could cause a
malfunction in LAN operation. Check with your LAN administrator
regarding set-up procedures.

If you are using Fast Ethernet LAN (100 megabits per second,
100BASE-TX), be sure to connect with a CAT5 cable or higher. You cannot
use a CAT3 cable.

If you are using Giga bit Ethernet LAN, be sure to connect with a CAT5-E
cable or higher. You cannot use a CAT5 or a CAT3 cable.

Connecting LAN cable

To connect the LAN cable, follow the steps below.

1. Turn off the power to the computer and to all external devices
connected to the computer.

2. Plug one end of the cable into the LAN jack. Press gently until you hear
the latch click into place.

User’s Manual 4-30

Connecting the LAN cable

3. Plug the other end of the cable into a LAN hub connector. Check with
your LAN administrator before connecting to a hub.

Disconnecting LAN cable

To disconnect the LAN cable, follow the steps below.

1. Pinch the lever on the connector in the computer's LAN jack and pull
out the connector.

2. Disconnect the cable from the LAN hub in the same manner. Check
with your LAN administrator before disconnecting from the hub.

Operating Basics

Cleaning the computer

To help ensure long, trouble-free operation, keep the computer free of dust
and use care with liquids around the computer.

■ Be careful not to spill liquids into the computer. If the computer does get

wet, turn the power off immediately and let the computer dry completely
before you turn it on again.

■ Clean the computer using a slightly damp (with water) cloth. You can

use glass cleaner on the display. Spray a small amount of cleaner on a
soft, clean cloth and wipe the screen gently with the cloth.

Never spray cleaner directly onto the computer or let liquid run into any
part of it. Never use harsh or caustic chemical products to clean the
computer.

■ Remove the dust from the cooling vents on the Left side of the

computer regularly with a vacuum cleaner. Refer to Chapter 2, The

Grand Tour, Left side.

User’s Manual 4-31

Moving the computer

The computer is designed for rugged durability. However, a few simple
precautions taken when moving the computer will help ensure trouble-free
operation.

■ Before moving the computer, it recommends changing the function of

TOSHIBA HDD Protection. Refer to the section, Using the Hard Disk

Drive (HDD) Protection, in this chapter.

■ Make sure all disk activity has ended before moving the computer.

Check the HDD indicator on the computer.

■ If a CD/DVD is in the drives, remove it. Also make sure the disc tray is

securely closed.

■ Turn off (shut down) the computer.

■ Disconnect the AC adaptor and all peripherals before moving the

computer.

■ Close the LCD display panel. Do not pick up the computer by its display

panel.

■ Before carrying your computer, shut down the computer, disconnect the

power cable and wait until the PC cools down. Failure to follow this
instruction could result in minor injury.

■ Always turn off the power when you move the computer. If the power

button has a lock, set it to the lock position. Also be careful not to
subject the computer to impact. Failure to follow this instruction could
result in damage to computer, computer failure or loss of data.

■ Never transport your computer with PC cards installed. This could

cause damage to your computer and/or PC card, resulting in product
failure.

■ Use the carrying case when transporting the computer.

■ When carrying your computer, be sure to hold it securely so that it does

not fall or hit anything.

■ Do not carry your computer by holding protruded portions.

Operating Basics

Using the Hard Disk Drive (HDD) Protection

This computer has a function for reducing the risk of damage on the hard
disk drive.

Using an acceleration sensor built into the computer, TOSHIBA HDD
Protection detects vibration shocks and similar signs of movement of the
computer, and automatically moves the Hard Disk Drive head to a safe
position to reduce the risk of damage that could be caused by head-to-disk
contact.

This function does not guarantee that the hard disk drive will not be
damaged.

User’s Manual 4-32

When vibration is detected, a message will be displayed on the screen, and
the icon in the taskbar notification area will change to the protection state.
This message is displayed until the OK button is pressed or 30 seconds
pass. When vibration subsides, the icon returns to the normal state.

Taskbar Icon

State Icon Description
Normal TOSHIBA HDD Protection is enabled.

Protection TOSHIBA HDD Protection is active. The

hard disk drive head is in a safe position.

OFF TOSHIBA HDD Protection is disabled.

TOSHIBA HDD Protection Properties

You can change the TOSHIBA HDD Protection settings by using the
TOSHIBA HDD Protection Properties window. To open the window, click

Start  All Programs  TOSHIBA  Utilities  HDD Protection
Setting. The window can also be started from the icon on the Taskbar or
from the Control Panel.

HDD Protection

You can choose whether to enable or disable TOSHIBA HDD Protection.

Operating Basics

Detection Level

This function can be set to four levels. The sensitivity levels in which
vibrations, impacts and their similar signs are detected can be set to OFF,
1, 2 and 3 in ascending order. Level 3 is recommended for better protection
of the computer. However, when the computer is used in a mobile
environment or in other unstable conditions, setting the detection level to
3 could result in frequent execution of TOSHIBA HDD Protection, which will
slow Hard Disk Drive reading and writing. Set a lower detection level when
the speed of Hard Disk Drive reading and writing is a priority.

Different detection levels can be set depending on whether the computer is
used as handheld or mobile usages, or whether it is used in a stable
environment such as on a table in the workplace or at home. By setting
different detection levels for the computer depending on whether it runs
with the AC power (desktop) or with batteries (handheld or mobile usage),
the detection level automatically switches according to the power
connection mode.

User’s Manual 4-33

Details

To open the Details window, click the Setup Detail button in the TOSHIBA
HDD Protection Properties window.

Detection Level Amplification

When the AC adaptor is disconnected or the lid is closed, HDD Detection
assumes that the computer will be carried and sets the detection level to
the maximum for 10 seconds.

TOSHIBA HDD Protection Message

Specify whether to display a message when TOSHIBA HDD Protection is
active.

■ This function does not work when the computer is starting, in Sleep

Mode, in Hibernation Mode, in transition to Hibernation Mode,
recovering from Hibernation Mode, or powered off. Be sure to not
subject the computer to vibration or impact while the function is
disabled.

■ This function only operates with Windows Vista™.

Operating Basics

User’s Manual 4-34

The Keyboard

The computer's keyboard layouts are compatible with a 101/102-key
enhanced keyboard. By pressing some keys in combination, all the 101/
102-key keyboard functions can be executed on the computer.

The number of keys on your keyboard depends on which country/region’s
keyboard layout your computer is configured with. Keyboards for numerous
languages are available.

There are six types of keys: typewriter keys, keypad overlay, function keys,
soft keys, Windows

Typewriter keys

The typewriter keys produce the upper- and lower-case letters, numbers,
punctuation marks, and special symbols that appear on the screen.

There are some differences, however, between using a typewriter and
using a computer keyboard:

■ Letters and numbers produced in computer text vary in width. Spaces,

which are created by a "space character," may also vary depending on
line justification and other factors.

■ The lowercase l (el) and the number 1 (one) are not interchangeable on

computers as they are on a typewriter.

■ The uppercase O (oh) and the 0 (zero) are not interchangeable.

■ The Caps Lock function key locks only the alphabetic characters in

uppercase while the shift lock on a typewriter places all keys in the
shifted position.

■ The Shift keys, the Tab key, and the BackSpace key perform the same

function as their typewriter counterparts but also have special computer
functions.

Chapter 5

®

special keys, and cursor control keys.

The Keyboard

User’s Manual 5-1

F1 ... F12 function keys

The function keys (not to be confused with Fn) are the 12 keys at the top of
your keyboard. These keys function differently from other keys.

F1 through F12 are called function keys because they execute
programmed functions when pressed. Used in combination with the Fn key,
keys marked with icons execute specific functions on the computer. Refer
to the section, Soft keys: Fn key combinations, in this chapter. The function
executed by individual keys depends on the software you are using.

Soft keys: Fn key combinations

The Fn (function) is used in combination with other keys to form soft keys.
Soft keys are key combinations that enable, disable or configure specific
features.

Some software may disable or interfere with soft-key operations. Soft-key
settings are not restored by the Sleep Mode feature.

Emulating keys on enhanced keyboard

The Keyboard

A 101-key enhanced keyboard layout

The keyboard is designed to provide all the features of the 101-key
enhanced keyboard, shown in figure above. The 101/102-key enhanced
keyboard has a numeric keypad and scroll lock key. It also has additional
Enter and Ctrl keys to the right of the main keyboard. Since the keyboard
is smaller and has fewer keys, some of the enhanced keyboard functions
must be simulated using two keys instead of one on the larger keyboard.

Your software may require you to use keys that the keyboard does not
have. Pressing the Fn key and one of the following keys simulates the
enhanced keyboard's functions.

User’s Manual 5-2

Hot keys

The Keyboard

Press Fn + F11 to access the integrated keypad. When activated, the keys
with gray markings on the bottom edge become numeric keypad keys.
Refer to the Keypad overlay section in this chapter for more information on
how to operate these keys. The power on default for both settings is off.

Press Fn + F12 to lock the cursor on a specific line. The power on default is
off.

+

Mute:Turns the volume on and off.

+

Lock: Enters "Lock computer" mode. To restore your desktop, you need to
log on again.

+

Power plan: Displays the power save modes and lets you change the
power settings.

+

Sleep: This hot key switches the system to Sleep Mode.

+

Hibernate:This hot key switches the system to Hibernation Mode.

+

Output: Changes the active display device.

Default resolution for simultaneous mode is set to 1024 × 768. If you
connect an RGB (Monitor) that is not set to a 1024 × 768 resolution,
change it in "Display Properties".

+

Brightness (decrease): Turns the monitor brightness down.

User’s Manual 5-3

+

Brightness (increase): Turns the monitor brightness up.

+

Wireless: Switches the active wireless device if the wireless
communication switch is switched on.

+

TouchPad: Enables or disables the Touch Pad function.

+

Enable Keypad: Enables or disables the Key Pad function.

+

Number Lock: Enables or disables the Number Lock function.

The Keyboard

+

Scroll Lock: Enables or disables the Scroll Lock function.

+

Zoom: Changes the display resolution.

+

TOSHIBA Zooming Utility (reduce): Reduces the icon size on the
desktop or the font size within one of the supported application windows.

+

TOSHIBA Zooming Utility (enlarge): Increases the icon size on the
desktop or the font size within one of the supported application windows.

Before using Fn + 1 and Fn + 2, you must install the TOSHIBA Zooming
Utility. The Utility only supports the following application windows:
Microsoft Internet Explorer, Microsoft Office, Windows Media Player,
Adobe Reader and the icons on the desktop.

User’s Manual 5-4

Fn Sticky key (Depends on the model you purchased)

You can use the TOSHIBA Accessibility Utility to make the Fn key sticky,
that is, you can press it once, release it, and then press an "F number" key.
To start the TOSHIBA Accessibility Utility, click start, point to All

Programs, point to TOSHIBA, point to Utilities and click Accessibility.

Windows® special keys

The keyboard provides two keys that have special functions in Windows® :
Windows
key, has the same function as the secondary mouse button.

This key activates the Windows® start menu.

This key has the same function as the secondary mouse button.

®

logo key activates the start menu and the other, the application

Keypad overlay

Your computer's keyboard does not have an independent numeric keypad,
but its numeric keypad overlay functions like one.

The keys in the centre of the keyboard with gray letters make up the
numeric keypad overlay. The overlay provides the same functions as the
numeric keypad on the 101/102-key enhanced keyboard described
previously.

The Keyboard

Turning on the overlays

The numeric keypad overlay can be used for numeric data input.

Numeric mode

To turn on the Numeric mode, press Fn + F11. Now try numeric data entry
using the keys in the following figure. Press Fn + F11 again to turn off the
overlay.

User’s Manual 5-5
