Toshiba M800, U400, M800D, U400D User Manual

TOSHIBA Satellite U400/U400D Satellite Pro U400/U400D PORTÉGÉ M800/M800D Portable Personal Computer

User's Manual

Copyright

© 2008 by TOSHIBA Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.

TOSHIBA Satellite U400/U400D, Satellite Pro U400/U400D, PORTÉGÉ M800/M800D Series Portable Personal Computer User's Manual

First edition June 2008 Ownership and copyright of music, video, computer programs, databases,

etc. are protected by the copyright laws. These copyrighted materials may be copied for private use at home only. If, beyond the limitation above, you copy (including to transform data formats) or modify these materials, transfer them or distribute them via the Internet without approval of copyright owners, you may be subject to claims for compensation for damage and/or criminal penalties due to infringements of copyrights or personal rights. Please remember to observe the copyright laws when you use this product to copy the copyrighted works or perform other actions.

Please note that you may infringe the owner's rights protected by the copyright laws if you use the screen mode switching functions (e.g. Wide mode, Wide Zoom mode, etc.) of this product to display enlarged images/ video at coffee shops or hotels for the purposes of profits or providing these to the public.

Disclaimer

This manual has been validated and reviewed for accuracy. The instructions and descriptions it contains are accurate for the TOSHIBA Satellite U400/U400D, Satellite Pro U400/U400D, PORTÉGÉ M800/ M800D Series Portable Personal Computer at the time of this manual’s production. However, succeeding computers and manuals are subject to change without notice. TOSHIBA assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manual.

ii User’s Manual

Trademarks

Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

DirectX, AcriveDesktop, DirectShow, and Windows Media are registered trademarks of Microsoft Corporation.

Intel, Intel Core, Celeron, Centrino and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Adobe and Photoshop are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Bluetooth™ is a registered trademark owned by its proprietor and used by TOSHIBA under license.

ConfigFree is a trademark of TOSHIBA Corporation. DVD MovieFactory is a trademarks of Ulead Systems Inc. BizCard is a trademark of NewSoft Technology Corporation. Dolby is a registered trademark of Dolby Laboratories. ExpressCard is a trademarks of PCMCIA. HDMI, the HDMI logo and High-Definition Multimedia Interface are

trademarks or registered trademarks of HDMI Licensing LLC. Labelflash™ is a trademark of YAMAHA CORPORATION. Memory Stick, Memory Stick PRO, and i.LINK are registered trademarks

and i.LINK is a trademark of SonyCorporation. MultiMediaCard and MMC are trademarks of MultiMediaCard Association. Photo CD is a trademark of Eastman Kodak. Secure Digital and SD are trademarks of SD Card Association. xD-Picture Card is a trademark of Fuji Photo Film, Co., Ltd. Wi-Fi is a registered trademark of the Wi-Fi Alliance. Other trademarks and registered trademarks not listed above may be used

in this manual.

Safety Instructions

Use the following safety guidelines to help protect yourself and your computer.

User’s Manual iii

When Using Your Computer

Do not operate your portable computer for an extended period of time with the base resting directly on your body. With extended operation, heat can potentially build up in the base. Allowing sustained contact with the skin could cause discomfort or, eventually, a burn.

■ Do not attempt to service the computer yourself. Always follow

installation instructions closely.

■ Do not carry a battery in your pocket, purse, or other container where

metal objects (such as car keys) could short-circuit the battery terminals. The resulting excessive current follow can cause extremely high temperatures and may result in damage from burns.

■ Be sure that nothing rests on your AC adapter’s power cable and that

the cable is not located where it can be tripped over or stepped on.

■ Place the AC adapter in a ventilated area, such as a desk top or on the

floor, when you use it to run the computer or to charge the battery. Do not cover the AC adapter with papers or other items that will reduce cooling; also, do not use the AC adapter while it is inside a carrying case.

■ Use only the AC adapter and batteries that are approved for use with

this computer. Use of another type of battery or AC adapter may risk fire or explosion.

■ Before you connect the computer to a power source, ensure that the

voltage rating of the AC adapter matches that of the available power source. 115 V/ 60 Hz in most of North and South America and some Far Eastern countries such as Taiwan. 100 V/50 Hz in eastern Japan and 100 V/60 Hz in western Japan. 230 V/50 Hz in most of Europe, the Middle East, and the Far East.

■ If you use an extension cable with your AC adapter, ensure that the total

ampere rating of the products plugged in to the extension cable does not exceed the ampere rating of the extension cable.

■ To remove power from the computer, turn it off, remove the battery, and

disconnect the AC adapter from the electrical outlet.

■ To help avoid the potential hazard of electric shock, do not connect or

disconnect any cables or perform maintenance or reconfiguration of this product during and electrical storm.

■ When setting up the computer for work, place it on a level surface.

iv User’s Manual

FCC information

FCC notice “Declaration of Conformity Information”

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

■ Reorient or relocate the receiving antenna.

■ Increase the separation between the equipment and receiver.

■ Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

■ Consult the dealer or an experienced radio/TV technician for help.

Only peripherals complying with the FCC class B limits may be attached to this equipment. Operation with non-compliant peripherals or peripherals not recommended by TOSHIBA is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer’s external monitor port, USB port, serial port, parallel port, PS/2 mouse/keyboard port and microphone jack. Changes or modifications made to this equipment, not expressly approved by TOSHIBA or parties authorized by TOSHIBA could void the user’s authority to operate the equipment.

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

Contact

Address: TOSHIBA America Information Systems, Inc.

9740 Irvine Boulevard Irvine, California 92618-1697

Telephone: (949) 583-3000

User’s Manual v

BSMI notice (Taiwan only)

EU Declaration of Conformity

TOSHIBA declares that this product conforms to the following Standards: Supplementary

Information:

This product is carrying the CE-Mark in accordance with the related European Directives. Responsible for CE-Marking is TOSHIBA Europe, Hammfelddamm 8, 41460 Neuss, Germany.

“The product complies with the requirements of the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC and/or the R&TTE Directive 1999/5/EC.”

VCCI Class B Information

Canadian Regulatory Information (Canada Only)

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulation of the Canadian Department of Communications.

Note that Canadian Department of Communications (DOC) regulations provide, that changes or modifications not expressly approved by TOSHIBA Corporation could void your authority to operate this equipment.

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique de la class B respecte toutes les exgences du Règlement sur le matériel brouileur du Canada.

vi User’s Manual

Modem warning notice

Conformity Statement

The equipment has been approved to [Council Decision 98/482/EC - "TBR 21"] for pan-European single terminal connection to the Public Switched Telephone Network (PSTN).

However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.

In the event of problems, you should contact your equipment supplier in the first instance.

Network Compatibility Statement

This product is designed to work with, and is compatible with the following networks. It has been tested to and found to conform with the additional requirements conditional in EG 201 121.

Germany ATAAB AN005, AN006, AN007, AN009, AN010 and

Greece ATAAB AN005, AN006 and GR01, 02, 03, 04 Portugal ATAAB AN001, 005, 006, 007, 011 and P03, 04, 08,

Spain ATAAB AN005, 007, 012, and ES01 Switzerland ATAAB AN002 All other countries/

regions Specific switch settings or software setup are required for each network,

please refer to the relevant sections of the user guide for more details. The hookflash (timed break register recall) function is subject to separate

national type approvals. It has not been tested for conformity to national type regulations, and no guarantee of successful operation of that specific function on specific national networks can be given.

DE03, 04, 05, 08, 09,12,14,17

ATAAB AN003, 004

User’s Manual vii

Japan regulations

Region selection

If you are using the computer in Japan, technical regulations described in the Telecommunications Business Law require that you select the Japan region mode. It is illegal to use the modem in Japan with any other selection.

Redial

Up to two redial attempts can be made. If more than two redial attempts are made, the modem will return Black Listed. If you are experiencing problems with the Black Listed code, set the interval between redials at one minute or longer.

Japan’s Telecommunications Business Law permits up to two redials on analogue telephones, but the redials must be made within a total of three minutes.

The internal modem is approved by Japan Approvals Institute for Telecommunications Equipment.

Pursuant to FCC CFR 47, Part 68:

When you are ready to install or use the modem, call your local telephone company and give them the following information:

■ The telephone number of the line to which you will connect the modem.

■ The registration number that is located on the device

US : CXSMM01BRD02D450 The FCC registration number of the modem will be found on either the device which is to be installed, or, if already installed, on the bottom of the computer outside of the main system label.

■ The Ringer Equivalence Number (REN) of the modem, which can vary.

For the REN of your modem, refer to your modem’s label.

The modem connects to the telephone line by means of a standard jack called the USOC RJ11C.

A06-5003201

Type of service

Your modem is designed to be used on standard-device telephone lines. Connection to telephone company-provided coin service (central office implemented systems) is prohibited. Connection to party lines service is subject to state tariffs.

If you have any questions about your telephone line, such as how many pieces of equipment you can connect to it, the telephone company will provide this information upon request.

viii User’s Manual

Telephone company procedures

The goal of the telephone company is to provide you with the best service it can. In order to do this, it may occasionally be necessary for them to make changes in their equipment, operations, or procedures. If these changes might affect your service or the operation of your equipment, the telephone company will give you notice in writing to allow you to make any changes necessary to maintain uninterrupted service.

If problems arise

If any of your telephone equipment is not operating properly, you should immediately remove it from your telephone line, as it may cause harm to the telephone network. If the telephone company notes a problem, they may temporarily discontinue service. When practical, they will notify you in advance of this disconnection. If advance notice is not feasible, you will be notified as soon as possible. When you are notified, you will be given the opportunity to correct the problem and informed of your right to file a complaint with the FCC. In the event repairs are ever needed on your modem, they should be performed by TOSHIBA Corporation or an authorized representative of TOSHIBA Corporation.

Disconnection

If you should ever decide to permanently disconnect your modem from its present line, please call the telephone company and let them know of this change.

Fax branding

The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device to send any message via a telephone fax machine unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business, other entity or individual sending the message and the telephone number of the sending machine or such business, other entity or individual. In order to program this information into your fax modem, you should complete the setup of your fax software before sending messages.

■ Use only No.26AWG or larger telecommunication line cord.

User’s Manual ix

Instructions for IC CS-03 certified equipment

1. The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection.

The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.

Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.

2. The user manual of analog equipment must contain the equipment’s Ringer Equivalence Number (REN) and an explanation notice similar to the following:

The Ringer Equivalence Number (REN) of the modem, which can vary. For the REN of your modem, refer to your modem’s label.

The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.

3. The standard connecting arrangement (telephone jack type) for this equipment is jack type(s): USOC RJ11C.

The IC registration number of the modem is shown below.

Canada : 3652B-RD02D450

x User’s Manual

Notes for Users in Australia and New Zealand

Modem warning notice for Australia

Modems connected to the Australian telecoms network must have a valid Austel permit. This modem has been designed to specifically configure to ensure compliance with Austel standards when the country/region selection is set to Australia. The use of other country/region setting while the modem is attached to the Australian PSTN would result in you modem being operated in a non-compliant manner. To verify that the country/region is correctly set, enter the command ATI9 which displays the currently active setting.

To set the country/region permanently to Australia, enter the following command sequence:

AT+GCI=09

Failure to set the modem to the Australia country/region setting as shown above will result in the modem being operated in a non-compliant manner. Consequently, there would be no permit in force for this equipment and the Telecoms Act 1991 prescribes a penalty of $12,000 for the connection of non-permitted equipment.

User’s Manual xi

Notes for use of this device in New Zealand

■ The grant of a Telepermit for a device in no way indicates Telecom

acceptance of responsibility for the correct operation of that device under all operating conditions. In particular the higher speeds at which this modem is capable of operating depend on a specific network implementation which is only one of many ways of delivering high quality voice telephony to customers. Failure to operate should not be reported as a fault to Telecom.

■ In addition to satisfactory line conditions a modem can only work

properly if: a/ it is compatible with the modem at the other end of the call and b/ the application using the modem is compatible with the application

at the other end of the call - e.g., accessing the Internet requires suitable software in addition to a modem.

■ This equipment shall not be used in any manner which could constitute

a nuisance to other Telecom customers.

■ Some parameters required for compliance with Telecom’s PTC

Specifications are dependent on the equipment (PC) associated with this modem. The associated equipment shall be set to operate within the following limits for compliance with Telecom Specifications:

a/ There shall be no more than 10 call attempts to the same number

within any 30 minute period for any single manual call initiation, and

b/ The equipment shall go on-hook for a period of not less than 30

seconds between the end of one attempt and the beginning of the next.

c/ Automatic calls to different numbers shall be not less than 5

seconds apart.

■ Immediately disconnect this equipment should it become physically

damaged, and arrange for its disposal or repair.

■ The correct settings for use with this modem in New Zealand are as

follows: ATB0 (CCITT operation) AT&G2 (1800 Hz guard tone) AT&P1 (Decadic dialling make-break ratio = 33%/67%) ATS0=0 (not auto answer) ATS10=less than 150 (loss of carrier to hang up delay, factory default of

15 recommended) ATS11=90 (DTMF dialling on/off duration=90 ms) ATX2 (Dial tone detect, but not (U.S.A.) call progress detect)

xii User’s Manual

■ When used in the Auto Answer mode, the S0 register must be set with a

value of 3 or 4. This ensures:

■ a person calling your modem will hear a short burst of ringing before

the modem answers. This confirms that the call has been successfully switched through the network.

■ caller identification information (which occurs between the first and

second ring cadences) is not destroyed.

■ The preferred method of dialling is to use DTMF tones (ATDT...) as this

is faster and more reliable than pulse (decadic) dialling. If for some reason you must use decadic dialling, your communications program must be set up to record numbers using the following translation table as this modem does not implement the New Zealand “Reverse dialling” standard.

Number to be dialled: 0 1 2 3 4 5 6 7 8 9 Number to program into computer: 0 9 8 7 6 5 4 3 2 1 Note that where DTMF dialling is used, the numbers should be entered

normally.

■ The transmit level from this device is set at a fixed level and because of

this there may be circumstances where the performance is less than optimal. Before reporting such occurrences as faults, please check the line with a standard Telepermitted telephone, and only report a fault if the phone performance is impaired.

■ It is recommended that this equipment be disconnected from the

Telecom line during electrical storms.

■ When relocating the equipment, always disconnect the Telecom line

connection before the power connection, and reconnect the power first.

■ This equipment may not be compatible with Telecom Distinctive Alert

cadences and services such as FaxAbility.

NOTE THAT FAULT CALLOUTS CAUSED BY ANY OF THE ABOVE CAUSES MAY INCUR A CHARGE FROM TELECOM

General conditions

As required by PTC 100, please ensure that this office is advised of any changes to the specifications of these products which might affect compliance with the relevant PTC Specifications.

The grant of this Telepermit is specific to the above products with the marketing description as stated on the Telepermit label artwork. The Telepermit may not be assigned to other parties or other products without Telecom approval.

A Telepermit artwork for each device is included from which you may prepare any number of Telepermit labels subject to the general instructions on format, size and color on the attached sheet.

The Telepermit label must be displayed on the product at all times as proof to purchasers and service personnel that the product is able to be legitimately connected to the Telecom network.

The Telepermit label may also be shown on the packaging of the product and in the sales literature, as required in PTC 100.

User’s Manual xiii

The charge for a Telepermit assessment is $337.50. An additional charge of $337.50 is payable where an assessment is based on reports against non-Telecom New Zealand Specifications. $112.50 is charged for each variation when submitted at the same time as the original.

An invoice for $NZ1237.50 will be sent under separate cover.

Following information is only for EU-member states:

The symbol indicates that this product may not be treated as household waste. Please ensure this product is properly disposed as inappropriate waste handling of this product may cause potential hazards to the environment and human health. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

This symbol may not be displayed depending on the country and region where you purchased.

EnergyStar® Program

Your computer model may be Energy Star® Compliant. If the model you purchased is compliant, it is labeled with the ENERGY STAR logo on the computer and the following information applies. TOSHIBA. is a partner in the Environmental Protection Agency’s (EPA) Energy Star Program and has designed this computer to meet the latest Energy Star guidelines for energy efficiency.

Your computer ships with the power management options preset to a configuration that will provide the most stable operating environment and optimum system performance for both AC power and battery modes.

To conserve energy, your computer is set to enter the low-power Sleep Mode which shuts down the system and display within 15 minutes of inactivity in AC power mode. We recommend that you leave this and other energy saving features active, so that your computer will operate at its maximum energy efficiency. You can wake the computer from Sleep Mode by pressing the power button.

According to the EPA, a computer meeting the new ENERGY STAR specifications will use between 20% and 50% less energy depending on how it is used. If all U.S. household and businesses replaced old computers with new ENERGY STAR qualified models, we would save more than $1.8 billion in energy costs over the next five years and avoid greenhouse gas emissions equivalent to more than 2.7 million cars.

If every computer purchased by businesses next year met the new ENERGY STAR requirements, businesses would save more than $210 million over the lifetime of those models. That is equivalent to lighting 120 million square feet of U.S. commercial building space each year.

xiv User’s Manual

Visit http://www.energystar.gov or http://www.energystar.gov/power management for more information regarding the ENERGY STAR Program.

Optical disc drive safety instructions

Be sure to check the international precautions at the end of this section.

Panasonic

DVD Super Multi UJ-862E/UJ-862A

■ The DVD Super Multi drive employs a laser system. To ensure proper

use of this product, please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.

■ Use of controls, adjustments or the performance of procedures other

than those specified may result in hazardous radiation exposure.

■ To prevent direct exposure to the laser beam, do not try to open the

enclosure.

User’s Manual xv

Hitach-LG Data Storage

DVD Super Multi GSA-U20N/GSA-U20F

■ The DVD Super Multi drive employs a laser system. To ensure proper

use of this product, please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.

■ Use of controls, adjustments or the performance of procedures other

than those specified may result in hazardous radiation exposure.

■ To prevent direct exposure to the laser beam, do not try to open the

enclosure.

xvi User’s Manual

International Precautions

CAUTION: This appliance contains a laser system and is classified as a "CLASS 1 LASER PRODUCT." To use this model properly, read the instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please contact your nearest "AUTHORIZED service station." To prevent direct exposure to the laser beam, do not try to open the enclosure.

VORSICHT: Dieses Gerät enthält ein Laser-System und ist als "LASERSCHUTZKLASSE 1 PRODUKT" klassifiziert. Für den richtigen Gebrauch dieses Modells lesen Sie bitte die Bedienungsanleitung sorgfältig durch und bewahren diese bitte als Referenz auf. Falls Probleme mit diesem Modell auftreten, benachrichtigen Sie bitte die nächste "autorisierte Service-Vertretung". Um einen direkten Kontakt mit dem Laserstrahl zu vermeiden darf das Gerät nicht geöffnet werden.

ADVARSEL: Denne mærking er anbragt udvendigt på apparatet og indikerer, at apparatet arbejder med laserstråler af klasse 1, hviket betyder, at der anvendes laserstrlier af svageste klasse, og at man ikke på apparatets yderside kan bilve udsat for utilladellg kraftig stråling.

APPARATET BOR KUN ÅBNES AF FAGFOLK MED SÆRLIGT KENDSKAB TIL APPARATER MED LASERSTRÅLER!

Indvendigt i apparatet er anbragt den her gengivne advarselsmækning, som advarer imod at foretage sådanne indgreb i apparatet, at man kan komme til at udsatte sig for laserstråling.

User’s Manual xvii

OBS! Apparaten innehåller laserkomponent som avger laserstråining överstigande gränsen för laserklass 1.

VAROITUS. Suojakoteloa si saa avata. Laite sisältää laserdiodin, joka lähetää näkymätöntä silmilie vaarallista lasersäteilyä.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED IN THE OWNER’S MANUAL MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

VORSICHT: DIE VERWENDUNG VON ANDEREN STEUERUNGEN ODER EINSTELLUNGEN ODER DAS DURCHFÜHREN VON ANDEREN VORGÄNGEN ALS IN DER BEDIENUNGSANLEITUNG BESCHRIEBEN KÖNNEN GEFÄHRLICHE STRAHLENEXPOSITIONEN ZUR FOLGE HABEN.

xviii User’s Manual

Important Notice

Copyrighted works including, but not limited to music, video, computer program, databases are protected by copyright laws. Unless specifically permitted under applicable copyright laws, you cannot copy, modify, assign, transmit or otherwise dispose of any copyrighted work with the consent of the owner of the copyright. Please take notice that unauthorized copying, modification, assignment, transmission and disposition may be subject to claims for damages and penalties.

■ Avoid using a telephone (other than a cordless type) during an electrical

storm. There may be a remote risk of electric shock from lightning.

■ Do not use the telephone to report a gas leak in the vicinity of the leak.

■ Use only the power cord indicated in this manual.

■ Replace only with the same or equivalent type battery recommended by

the manufacturer.

■ Dispose of used batteries according to the manufacturer’s instructions.

Use only the battery pack that came with the computer or an optional battery pack. Use of wrong battery could damage your computer.

TOSHIBA assumes no liability for any damage in such case.

User’s Manual xix

xx User’s Manual

General Precautions

TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer.

Be certain to read the general precautions below and to note the cautions included in the text of the manual.

Creating a computer-friendly environment

Place the computer on a flat surface that is large enough for the computer and any other items you are using, such as a printer.

Leave enough space around the computer and other equipment to provide adequate ventilation. Otherwise, they may overheat.

To keep your computer in prime operating condition, protect your work area from:

■ Dust, moisture, and direct sunlight.

■ Equipment that generates a strong electromagnetic field, such as

stereo speakers (other than speakers that are connected to the computer) or speakerphones.

■ Rapid changes in temperature or humidity and sources of temperature

change such as air conditioner vents or heaters.

■ Extreme heat, cold, or humidity.

■ Liquids and corrosive chemicals.

Stress injury

Carefully read the Instruction Manual for Safety and Comfort. It contains information on the prevention of stress injuries to your hands and wrists that can be caused by extensive keyboard use. Chapter 3, Getting Started, also includes information on work space design, posture and lighting that can help reduce physical stress.

User’s Manual xxi

Heat injury

■ Avoid prolonged physical contact with the computer. If the computer is

used for long periods, its surface can become very warm. While the temperature will not feel hot to the touch, if you maintain physical contact with the computer for a long time, for example if you rest the computer on your lap or if you keep your hands on the palm rest, your skin might suffer a low-heat injury.

■ If the computer has been used for a long time, avoid direct contact with

the metal plate supporting the various interface ports as this can become hot.

■ The surface of the AC adaptor can become hot when in use but this

condition does not indicate a malfunction. If you need to transport the AC adaptor, you should disconnect it and let it cool before moving it.

■ Do not lay the AC adaptor on a material that is sensitive to heat as the

material could become damaged.

Pressure or impact damage

Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction.

ExpressCard overheating

Some ExpressCards can become hot during prolonged use which may result in errors or instability in the operation of the device in question. In addition, you should also be careful when you remove a PC or ExpressCard that has been used for a long time.

Mobile phones

Please be aware that the use of mobile phones can interfere with the audio system. The operation of the computer will not be impaired in any way, but it is recommended that a minimum distance of 30cm is maintained between the computer and a mobile phone that is in use.

Instruction Manual for Safety and Comfort

All important information on the safe and proper use of this computer is described in the enclosed Instruction Manual for Safety and Comfort. Be sure to read it before using the computer.

xxii User’s Manual

Preface

Manual contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxix

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxx

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxx

Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxx

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxx

Key operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxi

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxi

Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxi

Chapter 1 Introduction

Equipment checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

TOSHIBA Value Added Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

Utilities and Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15

Chapter 2 The Grand Tour

Front with the display closed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Left side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Right side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Backside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Underside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Front with the display open. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Optical Disc Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Region codes for DVD drive and media . . . . . . . . . . . . . . . . . . . . . . 2-9

User’s Manual xxiii

Writable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9

CDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10

DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10

DVD Super Multi drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10

AC adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11

Remote controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12

Using the remote controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14

Installing/Removing batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-16

Placing slim size remote controller. . . . . . . . . . . . . . . . . . . . . . . . . .2-18

Chapter 3 Getting Started

Installing the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Connecting the AC adaptor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3

Opening the display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Turning on the power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Windows Vista setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Turning off the power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

Shut Down mode (Boot mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

Hibernation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

Restarting the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9

System Recovery Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

System Recovery Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

Create Optical Recovery Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

Restoring the preinstalled software from the Recovery HDD . . . . .3-11

Restoring the preinstalled software from Recovery Media . . . . . . .3-12

Chapter 4 Operating Basics

Using the TouchPad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Using the fingerprint sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

How to swipe the finger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Points to note about the fingerprint sensor. . . . . . . . . . . . . . . . . . . . .4-4

How to delete the fingerprint data. . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Fingerprint sensor limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Points to note about the fingerprint utility . . . . . . . . . . . . . . . . . . . . . .4-6

Set up procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

Windows logon via fingerprint authentication . . . . . . . . . . . . . . . . . . .4-7

Fingerprint system boot authentication. . . . . . . . . . . . . . . . . . . . . . . .4-7

Fingerprint Single Sign-On feature. . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

USB Sleep and Charge function. . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

How to enable/disable USB sleep and charge function . . . . . . . . . .4-10

Using the Web Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11

Using the software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11

Using the microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13

xxiv User’s Manual

Using the TOSHIBA Face Recognition . . . . . . . . . . . . . . . . . . . . . . . 4-13

Note on Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

How to register the Face Recognition Data . . . . . . . . . . . . . . . . . . 4-14

How to Delete the Face Recognition Data . . . . . . . . . . . . . . . . . . . 4-15

How to launch the help file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

Windows Logon via TOSHIBA Face Recognition . . . . . . . . . . . . . . 4-16

AUTO Mode Login screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

1:1 Mode Login screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17

Using the optical disc drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17

Loading discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18

Removing discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21

Writing CD/DVD with the DVD Super Multi drive . . . . . . . . . . . . . . . 4-22

Important message (DVD Super Multi drive) . . . . . . . . . . . . . . . . . 4-22

Before writing or rewriting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22

When writing or rewriting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25

Disclaimer (DVD Super Multi drive) . . . . . . . . . . . . . . . . . . . . . . . . 4-25

TOSHIBA Disc Creator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26

When Using Ulead DVD MovieFactory for TOSHIBA . . . . . . . . . . . 4-27

How to make a Labelflash DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

How to make a DVD-Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

How to learn more about Ulead DVD MovieFactory . . . . . . . . . . . . 4-28

Important information for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28

Media care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29

CD/DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29

Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Region selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Properties menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Modem Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Dialing Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32

Using the FM tuner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33

Wireless communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33

Wireless LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34

Bluetooth Stack for Windows by TOSHIBA (depends on the model

purchased) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35

Wireless communication switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35

Wireless activity LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35

LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36

LAN cable types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36

User’s Manual xxv

Connecting LAN cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-36

Disconnecting LAN cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-37

Cleaning the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-37

Moving the computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-38

Using the Hard Disk Drive (HDD) Protection . . . . . . . . . . . . . . . . . . .4-38

TOSHIBA HDD Protection Properties. . . . . . . . . . . . . . . . . . . . . . . .4-39

Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-40

Chapter 5 The Keyboard

Typewriter keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

F1 ... F12 function keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2

Soft keys: Fn key combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2

Emulating keys on enhanced keyboard . . . . . . . . . . . . . . . . . . . . . . .5-2

Hot keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3

Fn Sticky key (Depends on the model you purchased) . . . . . . . . . . .5-5

Windows® special keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5

Keypad overlay. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

Turning on the overlays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

Temporarily using normal keyboard (overlay on) . . . . . . . . . . . . . . . .5-7

Generating ASCII characters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Chapter 6 Power and Power-Up Modes

Power conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1

Power indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2

Battery indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2

Power indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3

Battery types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3

Battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3

Real Time Clock battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4

Care and use of the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6

Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6

Charging the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8

Monitoring battery capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10

Maximizing battery operating time . . . . . . . . . . . . . . . . . . . . . . . . . .6-10

Retaining data with power off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-11

Extending battery life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-11

Replacing the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12

Removing the battery pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12

Installing the battery pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-13

Starting the computer by password . . . . . . . . . . . . . . . . . . . . . . . . . .6-13

Power-up modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14

Hot keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14

Panel power off/on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14

System Auto Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14

xxvi User’s Manual

Chapter 7 HW Setup

Accessing HW Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

HW Setup Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

Chapter 8 Optional Devices

ExpressCard Slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

Inserting an ExpressCard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

Removing an ExpressCard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

SD/SDHC/MMC/MEMORY STICK / MEMORY STICK PRO/xD

Memory cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

Installing a memory card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

Removing a memory card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

Memory card care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6

Memory expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Installing a memory module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Removing a memory module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

Additional battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10

Additional AC adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10

External monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11

HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11

Setting for display video on HDMI. . . . . . . . . . . . . . . . . . . . . . . . . . 8-12

Settings for audio on HDMI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12

i.LINK (IEEE1394) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13

Disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

eSATA (External Serial ATA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

Connecting an eSATA device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

Disconnecting an eSATA device . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15

Security lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15

Chapter 9 Troubleshooting

Problem solving process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

Preliminary checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

Analyzing the problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

Hardware and system checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

System start-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

Self test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4

Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4

Disposing of PC and PC batteries . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6

Real Time Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7

Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7

LCD panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8

Hard disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8

User’s Manual xxvii

Recovery Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-9

DVD Super Multi drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-9

Pointing device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-11

USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-13

Memory expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-15

Sound system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-15

Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-16

Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-16

LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-17

Wireless LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-17

Fingerprint Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-18

ExpressCard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-18

TOSHIBA support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-19

Before you call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-19

Where to write . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-19

Appendix A Specifications Appendix B Display Controller Appendix C Wireless LAN Appendix D AC Power Cord and Connectors Appendix E Legal Footnotes

Glossary Index

xxviii User’s Manual

Preface

Congratulations on your purchase of the TOSHIBA Satellite U400/U400D, Satellite Pro U400/U400D, PORTÉGÉ M800/M800D Series computer. This powerful notebook computer provides excellent expansion capability, including multimedia devices, and it is designed to provide years of reliable, high-performance computing.

This manual tells you how to set up and begin using your TOSHIBA Satellite U400/U400D, Satellite Pro U400/U400D, PORTÉGÉ M800/ M800D Series computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.

If you are a new user of computers or if you’re new to portable computing, first read over the Introduction and The Grand Tour chapters to familiarize yourself with the computer's features, components and accessory devices. Then read Getting Started for step-by-step instructions on setting up your computer.

If you are an experienced computer user, please continue reading the preface to learn how this manual is organized, then become acquainted with this manual by browsing through its pages. Be sure to look over the

Specifications section of the Introduction, to learn about features that are

uncommon or unique to the computer. If you are going to install PC Cards or connect external devices such as a monitor, be sure to read Chapter 8,

Optional Devices.

Manual contents

This manual is composed of the following nine chapters, five appendixes, a glossary and an index.

Chapter 1, Introduction, is an overview of the computer's features, capabilities, and options.

Chapter 2, The Grand Tour, identifies the components of the computer and briefly explains how they function.

Chapter 3, Getting Started, provides a quick overview of how to begin operating your computer and gives tips on safety and designing your work area.

User’s Manual xxix

Preface

Chapter 4, Operating Basics, includes instructions on using the following devices: TouchPad, Sound System, optical media drives, modem, wireless communication and LAN. It also provides tips on care of the computer, and CD/DVDs.

Chapter 5, The Keyboard, describes special keyboard functions including the keypad overlay and hot keys.

Chapter 6, Power and Power-Up Modes, gives details on the computer's power resources and battery save modes.

Chapter 7, HW Setup explains how to configure the computer using the HW Setup program.

Chapter 8, Optional Devices, describes the optional hardware available. Chapter 9, Troubleshooting, provides helpful information on how to perform

some diagnostic tests, and suggests courses of action if the computer doesn’t seem to be working properly.

The Appendices provide technical information about your computer. The Glossary defines general computer terminology and includes a list of

acronyms used in the text. The Index quickly directs you to the information contained in this manual.

Conventions

This manual uses the following formats to describe, identify, and highlight terms and operating procedures.

Abbreviations

On first appearance, and whenever necessary for clarity, abbreviations are enclosed in parenthesis following their definition. For example: Read Only Memory (ROM). Acronyms are also defined in the Glossary.

Icons

Icons identify ports, dials, and other parts of your computer. The indicator panel also uses icons to identify the components it is providing information on.

Keys

The keyboard keys are used in the text to describe many computer operations. A distinctive typeface identifies the key top symbols as they appear on the keyboard. For example, Enter identifies the Enter key.

xxx User’s Manual

Key operation

Some operations require you to simultaneously use two or more keys. We identify such operations by the key top symbols separated by a plus sign (+). For example, Ctrl + C means you must hold down Ctrl and at the same time press C. If three keys are used, hold down the first two and at the same time press the third.

Preface

ABC When procedures require an action such as

clicking an icon or entering text, the icon’s name or the text you are to type in is represented in the type face you see to the left.

Display

ABC

Names of windows or icons or text generated by the computer that appears on its display screen is presented in the type face you see to the left.

Messages

Messages are used in this manual to bring important information to your attention. Each type of message is identified as shown below.

Pay attention! A caution informs you that improper use of equipment or failure to follow instructions may cause data loss or damage your equipment.

Please read. A note is a hint or advice that helps you make best use of your equipment.

Indicates a potentially hazardous situation, which could result in death or serious injury, if you do not follow instructions.

Terminology

This term is defined in this document as follows:

Start

User’s Manual xxxi

The word “Start” refers to the “ ” button in Microsoft

Windows Vista™.

Preface

xxxii User’s Manual

Chapter 1

Introduction

This chapter provides an equipment checklist, and it identifies the computer's features, options and accessories.

Some of the features described in this manual may not function properly if you use an operating system that was not pre-installed by TOSHIBA.

Equipment checklist

Carefully unpack your computer. Save the box and packing materials for future use.

Hardware

Check to make sure you have all the following items:

■ TOSHIBA Satellite U400/U400D, Satellite Pro U400/U400D, PORTÉGÉ

M800/M800D Series Portable Personal Computer

■ Universal AC adaptor and power cord

It is necessary to install the battery to use this computer. Refer to Installing the battery pack section in Chapter 3, Getting Started.

User’s Manual 1-1

Introduction

Software

Microsoft® Windows Vista™

The following software is preinstalled:

■ Microsoft

■ Microsoft Internet Explorer

■ TOSHIBA Value Added Package

■ TOSHIBA Hardware Setup

■ TOSHIBA Supervisor Password

■ TOSHIBA Assist

■ TOSHIBA ConfigFree

■ TOSHIBA DVD PLAYER

■ TOSHIBA FingerPrint Utility (FingerPrint support model only)

■ TOSHIBA SD Memory Utilites

■ TOSHIBA Disc Creator

■ TOSHIBA Face Recognition

■ TOSHIBA Acoustic Silencer

■ Ulead DVD MovieFactory

■ Presto! BizCard 5 (Provided with some models)

■ Online Manual

Other software may be preinstalled dependant on the model purchased.

Windows Vista™

for TOSHIBA

Documentation

■ Satellite U400/U400D, Satellite Pro U400/U400D, PORTÉGÉ M800/

M800D Series Personal Computer User Information Guide

■ Microsoft

models)

■ International Limited Warranty (ILW) Instruction (This instruction is

included only with computers sold in ILW supported areas.)

If any of the items are missing or damaged, contact your dealer immediately.

1-2 User’s Manual

Windows Vista™ manual package (Provided with some

Features

Introduction

Please visit your region’s web site for the configuration details of the model that you have purchased.

Processor

Built-in Depend on the model you purchased.

Please visit your region’s website for the configuration details of the model that you have purchased.

Chipset

Mobile Intel® PM45/GM45 Express Chipset or AMD M780G/M780V Chipset

Memory

Slots PC2-5300 or PC2-6400 512 MB, 1024 MB or

2048 MB memory modules can be installed in the two memory slots. Maximum system memory size and speed are depending on the model you purchased.

Main Memory Disclaimer

Video RAM Depending on the model you purchased:

Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications utilized, system memory size and other factors. For PC’s configured with 4 GB of system memory, the full system memory space for computing activities will be considerably less and will vary by model and system configuration.

Intel

GMA HD4500 model: Video RAM capacity shares with main memory, and the proportion depends on Dynamic Video Memory Technology.

ATI Radeon™ HD 3200 Graphics model: ATI Radeon™ 3100 Graphics model: Video RAM capacity shares with main memory, and the proportion depends on ATI HyperMemory™.

User’s Manual 1-3

Introduction

Power

Battery Pack Your computer is powered by a rechargeable

lithium-ion battery pack.

RTC Battery The internal RTC battery backs up the Real Time

Clock and calendar.

AC Adaptor The universal AC adaptor provides power to the

system and recharges the batteries when they are low. It comes with a detachable power cord.

Because it is universal, it can receive a range of AC voltage from 100 to 240 volts; however, the output current varies among different models. Using the wrong model can damage your computer. Refer to the AC adaptor section in Chapter 2, The Grand Tour.

Disks

Hard disk Disclaimer

Hard disk Drive Available in 1x2.5" HDD (9.5mm/SATA)

1 Gigabyte (GB) means 109 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1

GB = 2

= 1,073,741,824 bytes, and therefore

shows less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft Operating System and/or preinstalled software applications, or media content. Actual formatted capacity may vary.

■ 120GB

■ 160GB

■ 200GB

■ 250GB

■ 320GB

Computers in this series are configured with a fixed optical media drive. The available optical media drives are described below.

1-4 User’s Manual

Introduction

DVD Super Multi drive

Some models are equipped with a full-size DVD Super Multi drive module that lets you record data to rewritable CD/DVDs as well as run either 12cm (4.72") or 8cm (3.15") CD/DVDs without using an adaptor. It reads DVD-ROM's at maximum 8 speed and CD-ROM's at maximum 24 speed. It writes CD-R's at up to 24 speed, CD-RW's at up to 16 speed, DVD-R's at maximum 8 speed, DVD-RW's at maximum 6 speed. DVD+R's at maximum 8 speed, DVD+RW's at maximum 8 speed, DVD+R(DL) discs at maximum 6 speed and DVD-R(DL) discs at maximun 6 speed and DVD-RAM discs at maximum 5 speed. It supports the following formats:

■ DVD-ROM

■ DVD-Video

■ DVD-R

■ DVD-RW

■ DVD+R

■ DVD+RW

■ DVD-RAM

■ DVD+R DL

■ DVD-R DL

■ CD-DA

■ CD-Text

■ Photo CD (single/multi-session)

■ CD-ROM Mode 1, Mode 2

■ CD-ROMXA Mode 2 (Form1, Form2)

■ Enhanced CD (CD-EXTRA)

■ CD-G (Audio CD only)

■ Addressing Method 2

Display

The computer's LCD panel supports high-resolution video graphics. The screen can be set at a wide range of viewing angles for maximum comfort and readability.

User’s Manual 1-5

Introduction

Built-In 13.3" WXGA 16 M colors, with the following

Graphics Controller Graphics controller maximizes display

resolution: 1280 horizontal × 800 vertical pixels.

performance. Refer to Display Controller and

Modes section in Appendix B, Display Controller and Modes for more information.

Keyboard

Built-In TOSHIBA Vista keyboard, 85 keys or 86 keys,

compatible with IBM enhanced keyboard, embedded numeric overlay, dedicated cursor

control, and keys. Refer to Chapter 5,

The Keyboard, for details.

Pointing Device

Built-In TouchPad A TouchPad and control buttons in the palm rest

enable control of the on-screen pointer and scrolling of windows.

Ports

HDMI This HDMI jack allows you to connect external

display/audio devices. (Provided with some models)

External Monitor This 15-pin port lets you connect an external

Universal Serial Bus (USB 2.0)

eSATA/USB combo port

i.LINK (IEEE1394a) This port enables high-speed data transfer

Infrared receiver window

1-6 User’s Manual

video display.

The computer has Universal Serial Bus ports that comply with the USB 2.0 standard, which enables data transfer speeds 40 times faster than the USB 1.1 standard. (The ports also support USB 1.1.)

eSATA/USB combo port supports the USB 2.0 and the eSATA function.

directly from external devices such as digital video cameras.

(depending on the model you purchased.)

This window receives signals from the remote control which is provided with your computer.

Introduction

Slots

ExpressCard Slot The ExpressCard slot that can accommodate two

standard module formats; an ExpressCard/34 module and an ExpressCard/54 module. An ExpressCard module is a small add-in card technology based on the PCI Express and Universal Serial Bus (USB) interfaces.

Multiple Digital Media Card Slot

Supports SD/SDHC memory card, MMC, MEMORY STICK, MEMORY STICK PRO and xD Picture card

Multimedia

Web Camera Record/Send still or video images with this

Sound System

Headphone (S/P DIF) jack

Microphone Jack A 3.5 mm mini microphone jack enables

integrated webcam. (Depends on the model purchased)

A Windows speakers as well as jacks for an external microphone and headphones.

This jack outputs analog audio signals. This jack can be used also as S/P DIF jack and enables connection of optical digital correspondence apparatus.

connection of a three-conductor mini jack for monaural microphone input.

Sound System that provides

Communications

Modem Where present, it provides capability for data and

LAN The computer is equipped with a LAN card that

fax communication. It supports V.90 (V.92). The speed of data transfer and fax communication depends on the analog telephone line conditions. The computer has a modem jack for connection to a telephone line. Both V.90 and V.92 are supported only in the USA, Canada. V.90 is available in other regions. (Provided with some models)

supports Fast Ethernet LAN (100 Mbit/s, 100BASE-TX) or Gigabit Ethernet LAN (1 Gbit/s, 1000BASE-T). It is preinstalled as a standard device in some markets. (depending on model you purchased)

User’s Manual 1-7

Introduction

Wireless LAN The Wireless LAN feature is not available on all

models. Where present, it supports the A,B,G and draft N standards but it is compatible with other LAN systems based on Direct Sequence Spread Spectrum / Orthogonal Frequency Division Multiplexing radio technology that complies with the IEEE 802.11 Standard.

■ Automatic Transmit Rate Select mechanism

in the transmit range of 54, 48, 36, 24, 18, 12, 9 and 6 Mbit/s. (IEEE 802.11a/g)

■ Automatic Transmit Rate Select mechanism in

the transmit range of 11, 5.5, 2 and 1 Mbit/s. (IEEE 802.11b)

■ Roaming over multiple channels

■ Card Power Management

■ Wired Equivalent Privacy (WEP) data

encryption, based on 128 bit encryption algorithm.

■ Advanced Encryption Standard (AES) data

encryption, based on 128 bit encryption algorithm.

Bluetooth Some computers in this series are equipped with

Bluetooth functions. Bluetooth wireless technology eliminates the need for cables between electronic devices such as computers and printers. Bluetooth provides fast, reliable, and secure wireless communication in a small space. (Provided with some models)

Wireless Communication Switch

This switch turns the Wireless LAN and Bluetooth function on and off. (Provided with some models)

Security

Security lock slot Connects an optional security lock to anchor the

computer to a desk or other large object.

Password Power-on password protection

Two level password architecture HDD password protection Fingerprint authentication (not available on all

models)

1-8 User’s Manual

Special features

The following features are either unique to TOSHIBA computers or are advanced features, which make the computer more convenient to use.

Introduction

Hot Keys Key combinations let you quickly modify the

system configuration directly from the keyboard without running a system configuration program.

Keypad Overlay A ten-key pad is integrated into the keyboard.

Refer to the Keypad overlay section in Chapter 5, The Keyboard, for instructions on using the keypad overlay.

Instant Security The hot key function Fn + F1 blanks the screen

and disables the computer, providing data security.

Display Automatic Power Off

This feature automatically cuts off power to the internal display when there is no keyboard input for a specified time. Power is restored when any key is pressed.

This can be specified in the Power Options.

HDD Automatic Power Off

This feature automatically cuts off power to the hard disc drive when it is not accessed for a specified time. Power is restored when the hard disc is accessed.

This can be specified in the Power Options.

System Automatic Sleep Mode/

Hibernation

This feature automatically shuts down the system into Sleep Mode or Hibernation Mode when there is no input or hardware access for a specified time.

This can be specified in the Power Options.

Intelligent Power Supply

A microprocessor in the computer's intelligent power supply detects the battery’s charge and calculates the remaining battery capacity. It also protects electronic components from abnormal conditions, such as voltage overload from an AC adaptor.

This can be specified in the Power Options.

Battery Save Mode

This feature lets you save battery power. This can be specified in the Power Options.

Panel Power On/Off

This feature turns power to the computer off when the display panel is closed and turns it back on when the panel is opened.

This can be specified in the Power Options.

User’s Manual 1-9

Introduction

Low Battery Automatic

Hibernation

TOSHIBA HDD Protection

The TOSHIBA HDD Protection function does not guarantee that the hard disk drive will not be damaged.

Hibernation This feature lets you turn off the power without

Sleep Mode If you have to interrupt your work, you can turn

When battery power is exhausted to the point that computer operation cannot be continued, the system automatically enters Hibernation Mode and shuts down.

This can be specified in the Power Options.

This feature uses the acceleration sensor built in the computer to detect vibration and shocks, and automatically moves the hard disk drive's read/ write head to a safe position in order to reduce the risk of damage that could be caused by headto-disk contact. Refer to the Using the Hard

Disk Drive (HDD) Protection section in Chapter

4, Operating Basics, for more details.

exiting from your software. The contents of main memory are saved to the hard disk so that when you turn on the power again, you can continue working right where you left off. Refer to the

Turning off the power section in Chapter 3, Getting Started, for details.

off the power without exiting from your software. Data is maintained in the computer's main memory so that when you turn on the power again, you can continue working right where you left off.

*1 Click , Control Panel, System and Maintenance, and then click

Power Options.

TOSHIBA Value Added Package

This section describes the TOSHIBA Component features pre-installed on the computer.

1-10 User’s Manual

Introduction

TOSHIBA Power Saver

TOSHIBA Zooming Utility

TOSHIBA PC Diagnostic Tool

TOSHIBA Flash Cards

TOSHIBA Components Common Driver

TOSHIBA Accessibility

TOSHIBA Power Saver provides you with the features of more various power supply managements.

This utility allows you to enlarge or reduce the icon size on the Windows Desktop, or the zoom factor associated with specific supported applications.

The TOSHIBA PC Diagnostic Tool will display basic system configuration information and allow the functionality of some of the computer's builtin hardware devices to be tested.

This utility supports the following functions.

■ Hot key function

■ TOSHIBA utility launcher function

TOSHIBA Components Common Driver contains the module required for the utility which TOSHIBA offers.

The TOSHIBA Accessibility utility provides support to movement impaired users when they need to use the TOSHIBA Hot-key functions. In use, the utility allows you to make the Fn key 'sticky', that is you can press it once, release it, and then press one of the 'F' keys in order to access its specific function. When set, the Fn key will remain active until another key is pressed.

TOSHIBA Button Support

This utility controls the button operation of the computer.

The starting application from the button can be changed.

Utilities and Applications

This section describes pre-installed utilities and tells how to start them. For details on operations, refer to each utility’s online manual, help files or readme.txt files.

User’s Manual 1-11

Introduction

TOSHIBA Assist TOSHIBA Assist is a graphical user interface that

provides easy access to help and services.

HW Setup This program lets you customize your hardware

settings according to the way you work with your computer and the peripherals you use. To start the utility, double click the TOSHIBA Assist on your desktop, select OPTIMIZE tab, and click

TOSHIBA Hardware Settings.

Power On Password Two levels of password security, supervisor and

user, are available to prevent unauthorized access to your computer.

To register a supervisor password, double click the TOSHIBA Assist on your desktop select the

SECURE tab and start the Supervisor password utility.

To set a user password, select the SECURE tab on TOSHIBA Assist, then start the User password utility. On the Password tab you can register a user password.

CD/DVD Drive Acoustic Silencer

This utility allows you to configure the read speed of the CD drive. You can either configure Normal Mode, which operates the drive at its maximum speed for quick data access, or Quiet Mode, which runs at single speed for CD audio and which can lessen operational noise. It is ineffective in DVD mode.

Ulead DVD MovieFactory

for

You can edit digital video and make a DVD-Video and support Labelflash™ function.

TOSHIBA

*1 Click , Control Panel, System and Maintenance, and then click

Power Options.

1-12 User’s Manual

Introduction

FingerPrint utility This product has a fingerprint utility installed for

the purpose of enrolling and recognizing fingerprints. (depending on the model purchased.) By enrolling the ID and password to the fingerprint authentication device, it is no longer necessary to input the password from the keyboard. Just by swiping the finger against the fingerprint sensor, the following functions will be enabled:

■ Log-on to Windows and access a security

enabled homepage through IE (Internet Explorer).

■ Files and folders can be encrypted/decrypted

and third party access to them prevented.

■ Disable the password-protected screensaver

when returning from power-saving (Sleep) mode.

■ System boot authentication and Single Touch

Boot feature.

■ Power on Security and Single Sign On

feature.

TOSHIBA DVD PLAYER

The DVD PLAYER is used to play DVD Video. It has an on-screen interface and functions. Click

, point to All Programs, point to TOSHIBA

DVD Player, then click TOSHIBA DVD Player.

TOSHIBA Disc Creator

You can create CD/DVDs in several formats including audio CDs that can be played on a standard stereo CD player and data CDs or DVDs to store multimedia and/or document files on your hard disk drive. This software can be used on a model with the CD-RW/DVD-ROM drive, DVD-R/-RW drive, DVD+_R/+_RW drive and DVD Super Multi drive.

To run TOSHIBA Disc Creator, click , select

All Programs, TOSHIBA, CD&DVD Applications, and then click Disc Creator.

TOSHIBA DVD-RAM Utility

TOSHIBA DVD-RAM Utility has a Physical Format function and Write-Protect function to DVD-RAM.

This utility is contained in the TOSHIBA Disc Creator setup module.

To run TOSHIBA DVD-RAM Utility, click , select All Programs, TOSHIBA, CD&DVD Applications, and then click DVD-RAM Utility.

User’s Manual 1-13

Introduction

TOSHIBA ConfigFree ConfigFree is a suite of utilities to allow easy

control of communication devices and network connections. ConfigFree also allows you to find communication problems and create profiles for easy switching between location and communication networks.

To run ConfigFree, click , select All Programs, TOSHIBA, Networking and then click ConfigFree.

TOSHIBA Face Recognition

TOSHIBA Face Recognition uses a face verification library to verify the face data of users when they log in to Windows. If the verification is successful, the user will be logged into Windows automatically. The user can thus avoid having to enter a password or the like, which makes the login process easier.

Presto! BizCard 5 Presto! BizCard keeps track of names,

companies, mailing addresses, phone/fax numbers, e-mail addresses, and more. Simply scan your business cards and Presto! BizCard automatically saves the data and image for each card. Different viewing modes are available for easy searching, editing, creating, and sorting. You can share information with desktop organizers, contact managers, personal information managers (PIMs), and personal digital assistants (PDAs). You can also print ID badges, mailing labels, and stickers.

Windows Mobility Center

This section describes the Windows Mobility Center. Mobility Center is a utility for accessing several mobile PC settings quickly in one window. A maximum of eight tiles are prepared as the operating system default. Two additional tiles are also added to your Mobility Center.

Installing the "TOSHIBA Extended Tiles for Windows Mobility Center" package will add the following functions.

■ Lock Computer:

Lock your computer without turning it off. This has the same function as the Lock button at the bottom of the right pane of the start menu.

■ TOSHIBA Assist:

Open the TOSHIBA Assist if it is already installed in your computer.

1-14 User’s Manual

Options

Introduction

You can add a number of options to make your computer even more powerful and convenient to use. Refer to Chapter 8 Optional Devices, for details. The following options are available:

Memory expansion Two memory modules can be installed in this

computer.

Use only PC2-5300 or PC2-6400* compatible DDRII memory modules. See your TOSHIBA dealer for details.

* The availability of DDRII depends on the model you purchased.

Battery pack An additional battery pack can be purchased

AC Adaptor If you use your computer at more than one site

from your TOSHIBA dealer. Use it as a spare to increase your computer operating time.

frequently, it may be convenient to purchase an additional AC adaptor for each site so you will not have to carry the adaptor with you.

User’s Manual 1-15

Introduction

1-16 User’s Manual

Chapter 2

The Grand Tour

This chapter identifies the various components of your computer. Become familiar with each component before you operate the computer.

Front with the display closed

The following figure shows the computer's front with its display panel in the closed position.

Multiple Digital

Media Card Slot

Wireless

Communication

Switch

Wireless

Activity LED

Power

LED

Disk LED

Volume D ial

Multiple Digital Media Card Slot

Infrared

Receiver

Window

Front of the computer with display closed

Supports SD/SDHC memory card, MMC, MEMORY STICK, MEMORY STICK PRO and

DC in

LED

Battery

LED

Multiple

Digital

Media Card

Slot LED

xD Picture card

Wireless Communication

The Wireless Communication Switch turns on the wireless networking transceiver.

Switch

Set the switch to off in airplanes and hospitals. Check the wireless activity indicator. It will stop glowing when the wireless communication function is off.

User’s Manual 2-1

The Grand Tour

Volu m e Dial Use this dial to adjust the volume of the stereo

speakers or headphones.

Infrared Receiver Window

An infrared receiver window is provided with some models. This is a sensor window that receives signals from the remote control which is provided with your computer.

Wireless Activity LED

Indicates whether the wireless LAN or Bluetooth is active or not.

(Provided with some models)

DC IN LED The DC IN LED indicates the computer is

connected to the AC adaptor and it is plugged into an AC power source.

Power LED The Power indicator glows blue when the

computer is on. If you select Sleep Mode from Turn Off Computer, this indicator flashes orange (one second on, two seconds off) while the computer enters Sleep Mode.

Battery LED The Battery indicator shows the condition of the

battery's charge: Blue indicates a full charge, orange indicates that the battery is charging and flashing orange indicates a low battery charge. Refer to Chapter 6, Power and Power-Up Modes.

Disk LED Disk LED indicates that the hard disk drive or

optical disc drive is being accessed.

Multiple Digital Media Card Slot LED

Multiple Digital Media Card Slot LED lights up when the Multiple Digital Media Card Slot is accessed.

(Provided with some models)

2-2 User’s Manual

Left side

The following figure shows the computer's left side.

External Monitor Port

HDMI

eSATA/USB

combo port

The Grand Tour

ExpressCard

USB

Port

Slot

External Monitor Port

Cooling

Vents

The left side of the computer

i.LINK

(IEEE1394a) Port

This 15-pin port lets you connect an external video display.

Microphone

Jack

Headphone

(S/P DIF)

Jack

Cooling Vents Cooling vents help prevent the CPU from

overheating.

HDMI A jack enables connection of the application of

High Definition Multimedia Interface, such as DVD Player, LCD Monitor, LCD TV, HDTV, Settop-Box and projector. (Provided with some models)

i.LINK (IEEE1394a) Port

This port allows you to connect an external device, such as a digital video camera, for highspeed data transfer. (Provided with some models)

ExpressCard Slot This slot allows you to insert an ExpressCard. An

ExpressCard is a small, modular add-in card technology based on PCI Express and the Universal Serial Bus (USB) interface. The max. transmission rate is 2.5Gbps. ExpressCard/34 and ExpressCard/54 types are supported.

Do not block the cooling vents. Also ensure that foreign objects are kept out of the vents as items such as pins or similar objects, which can damage the computer's circuitry.

User’s Manual 2-3

The Grand Tour

Universal Serial Bus (USB 2.0) ports

eSATA/

eSATA/USB combo port

Microphone Jack A 3.5 mm mini microphone jack enables

Headphone (S/P DIF) Jack

Right side

The following figure shows the computer's right side.

Universal Serial Bus ports which comply to the USB 2.0 standard, are provided. The ports with

the icon ( ) have USB Sleep and Charge function.

eSATA/USB combo port supports the USB 2.0 and the eSATA function.

connection of a three-conductor mini jack for monaural microphone input.

This jack outputs analog audio signals. This jack can be used also as S/P DIF jack and enables connection of optical digital correspondence apparatus.

ODD

Indicator

Eject

Button

Modem Jack or

FM Antenna Jack*

Security

Lock

Emergency

Eject Hole

The right side of the computer

USB Port

LAN Jack

* The figure shows FM Antenna Jack.

ODD Indicator The ODD indicator glows amber when the

computer accesses the optical disc drive.

Emergency Eject Hole

In the event that the disc drive becomes inexplicably locked or stops responding press this button to force a manual ejection of the ODD tray.

Eject Button Press this button to open the ODD tray.

Universal Serial Bus (USB 2.0) ports

Universal Serial Bus ports which comply to the USB 2.0 standard, are provided. The ports with

the icon ( ) have USB Sleep and Charge function.

2-4 User’s Manual

The Grand Tour

LAN Jack This jack lets you connect to a LAN. The adaptor

has built-in support for Ethernet LAN (10 megabits per second, 10BASE-T) and Fast Ethernet LAN (100 megabits per second, 100BASE-TX). Refer to Chapter 4, Operating

Basics, for details.

Modem Jack The modem jack allows you to use a modular

cable to connect the modem directly to a telephone line. (Depends on the model you purchased.)

■ In case of a lightning storm, unplug the

modem cable from the telephone jack.

■ Do not connect the modem to a digital

telephone line. A digital line will damage the modem.

Backside

FM Antenna Jack A jack enables the connection of FM antenna.

(Depends on the model purchased)

Security Lock A security cable attaches to this port. The

optional security cable anchors your computer to a desk or other large object to deter theft.

The following figure shows the computer's back panel.

DC in 19V Jack

The backside of the computer

DC IN 19V Jack The AC adaptor connects to this socket. Use

only the model of AC adaptor that comes with the computer. Using the wrong adaptor can damage your computer.

User’s Manual 2-5

The Grand Tour

Underside

The following figure shows the underside of the computer. Make sure the display is closed before turning over your computer.

Battery

Pack

Lock

Hard

Disk

Cover

Battery Pack Battery Release Latch

Memory Module and

The underside of the computer

Wireless LAN Cover

Cooling Vents

Memory Module and Wireless LAN Cover

This cover protects two memory module sockets -one or two modules are pre-installed. Refer to the

Memory expansion section in Chapter 8, Optional Devices.

Battery Pack Lock Slide this lock to prepare the battery pack for

removal.

Battery Pack The battery pack powers the computer when the

AC adaptor is not connected. For detailed information on the battery pack, refer to Chapter 6, Power and Power-Up Modes.

Battery Release Latch

Slide and hold this latch to release the battery pack for removal. For detailed information on removing the battery pack, refer to Chapter 6,

Power and Power-Up Modes.

Cooling Vents Cooling vents help prevent the CPU from

overheating.

Hard Disk Cover This cover protects the hard disk.

2-6 User’s Manual

Front with the display open

This section shows the front of the computer with the display open. Refer to the appropriate illustration for details. To open the display, lift the front of the display. Position the display at a comfortable viewing angle.

Web Camera LED*

Display

Screen

Wireless

LAN

Antenna*

Web Camera*

The Grand Tour

Built-in microphone*

Power Button Mute Button*

CD/ DVD Button* Play/Pause Button* Stop Button* Previous Button* Next Button*

Speaker

TouchPad

Speaker

The front of the computer with the display open

Fingerprint Sensor*

TouchPad Control Buttons

* Provided with some models

Please handle your computer carefully to avoid scratching or damaging the surface.

Speakers The speakers emit sound generated by your

software as well as audio alarms, such as low battery condition, generated by the system.

Display Screen The LCD displays high-contrast text and

graphics. Refer to Appendix B, Display

Controller. When the computer operates on the

AC adaptor the display screen’s image will be somewhat brighter than when it operates on battery power. The lower brightness level is intended to save battery power.

Web Camera LED Web Camera LED indicates web camera is

working or not. (Provided with some models)

Web Camera Take your picture or send your image to web

contacts. (Provided with some models)

User’s Manual 2-7

The Grand Tour

Built-in microphone The microphone is used with the Web Camera to

talk to other Web Camera users and to record messages on windows media.

Power Button Turns the computer on and off and puts it into

Hibernation mode and wakes it up from Sleep mode.

Mute Button Press this button to Mute volume.

(Provided with some models)

CD/ DVD Button Pressing this button will launch an application

program that allows for playing of CDs or DVDs. The application that is launched differs by model: Windows Media Player/TOSHIBA DVD PLAYER. (Provided with some models)

Play/Pause Button Press this button to begin playing an audio CD, a

DVD movie or digital audio file. This button also acts as a Pause button.

(Provided with some models)

Stop Button Stops playing of the CD, DVD or digital audio.

(Provided with some models)

Previous Button Skips backwards to the previous track, chapter or

digital file. Refer to Chapter 4, Operating Basics, for details.

(Provided with some models)

Next Button Skips forward to the next track, chapter or digital

file. Refer to Chapter 4, Operating Basics, for details.

(Provided with some models)

TouchPad A TouchPad located in the centre of the palm rest

is used to control the on-screen pointer.

2-8 User’s Manual

Fingerprint Sensor Just by swiping the finger against the fingerprint

sensor, the following functions will be enabled: Log-on to Windows and access a securityenabled homepage through IE (Internet Explorer) Files and folders can be encrypted/decrypted and third party access to them prevented. Disable the password-protected screensavcr when returning from power-saving (Sleep) mode. System boot authentication and Single Touch Boot feature. Authentication of the User Password and Hard Disk Drive Password when booting up the computer. Refer to the Using the

fingerprint sensor section in Chapter 4, Operating Basics. (Provided with some models)

TouchPad Control Buttons

These let you select menu items or manipulate text and graphics designated by the on-screen pointer. Refer to the Using the TouchPad section in Chapter 4, Operating Basics.

Optical Disc Drive

An ATAPI interface controller is used for optical disc operation. When the computer is accessing an optical disc, an indicator on the drive glows.

Region codes for DVD drive and media

Optical disc drive and their associated media are manufactured according to the specifications of six marketing regions. When you purchase DVDVideo, make sure it matches your drive, otherwise it will not play properly.

The Grand Tour

Code Region

1 Canada, United States

2 Japan, Europe, South Africa, Middle East

3 Southeast Asia, East Asia

4 Australia, New Zealand, Pacific Islands, Central

America, South America, Caribbean

5 Russia, Indian Subcontinent, Africa, North Korea,

Mongolia

6 China

Writable discs

This section describes the types of writable CD/DVD discs. Check the specifications of your drive for the type of discs it can write. Use TOSHIBA Disc Creator to write compact discs. Refer to Chapter 4, Operating Basics.

User’s Manual 2-9

The Grand Tour

CDs

■ CD-R discs can be written only once. The recorded data cannot be

erased or changed.

■ CD-RW discs can be recorded more than once. Use either 1, 2, or 4

multi speed CD-RW discs or high-speed 4- to 10-speed discs. The write speed of the ultra-speed CD-RW discs (Ultra-speed is available on the DVD-ROM & CD-R/RW drive only) is a maximum of 24-speed.

DVDs

■ DVD-R, DVD+R, DVD-R DL and DVD+R DL discs can be written only

once. The recorded data cannot be erased or changed.

■ DVD-RW, DVD+RW and DVD-RAM discs can be recorded more than

once.

DVD Super Multi drive

The full-size DVD Super Multi drive module lets you record data to writable CD/DVDs as well as run either 12 cm (4.72") or 8 cm (3.15") CD/DVDs without using an adaptor.

The read speed is slower at the centre of a disc and faster at the outer edge.

DVD read 8 speed (maximum) DVD-R write 8 speed (maximum) DVD-RW write 6 speed (maximum) DVD+R write 8 speed (maximum) DVD+RW write 8 speed (maximum) DVD-R(DL) write 6 speed (maximum) DVD+R(DL) write 6 speed (maximum) DVD-RAM write 5 speed (maximum) CD read 24 speed (maximum) CD-R write 24 speed (maximum) CD-RW write 16 speed (maximum, Ultra-speed media)

2-10 User’s Manual

AC adaptor

The AC adaptor converts AC power to DC power and reduces the voltage supplied to the computer. It can automatically adjust to any voltage from 100 to 240 volts and to a frequency of either 50 or 60 hertz, enabling you to use the computer in almost any country/region.

To recharge the battery, simply connect the AC adaptor to a power source and the computer. Refer to Chapter 6,

Power and Power-Up Modes

The Grand Tour

, for details.

The AC adaptor

■ Use only the AC adaptor that came with the computer or an equivalent

optional adaptor. Use of the wrong adaptor could damage your computer. TOSHIBA assumes no liability for any damage in such case.

■ Use only the AC Adaptor supplied with your computer or an equivalent

adaptor that is compatible. Use of any incompatible adaptor or other types of AC Adaptors may have a different voltage which could cause damage to your computer, computer failure and/or possible data loss. TOSHIBA assumes no liability for any damage, computer failure and/or data loss caused by use of an incompatible adaptor.

Use only the AC adaptor supplied as an accessory. Other AC adaptors have different voltage and terminal polarities and use of them may produce heat and smoke or even result in fire or rupture.

User’s Manual 2-11

The Grand Tour

Remote controller

A remote controller, which is provided with some models, enables you to perform some functions of your computer from a distant location.

You can use your remote controller with Media Center to play CDs, DVDs and videos, to view pictures.

The remote controller helps you to control the playback of a movie through Media Center.

Using the remote controller, you can:

■ Navigate and control all Media Center windows.

■ Control the video.

■ Place the computer in and out of Sleep mode.

Slim size remote controller

CD/DVD

Button

LCD Brightness

Down

LCD

Brightness Up

DVD Menu

Volume +

Volume -

Mute

Back

Start

Rewind

Replay

Stop

Power

LED On/Off

Arrows

More Information

Fast Forward Play/Pause

Skip

CD/DVD button Press this button to launch an application

program that allows Windows Media Player / DVD Video Player.

Brightness down Decreases the computer’s display panel

brightness in individual steps.

Brightness up Increases the computer’s display panel

brightness in individual steps.

2-12 User’s Manual

The Grand Tour

Power Starts or terminate the operating system. This

button functions like the power button of your computer. By default, the Sleep mode is equivalent to the power off state of your computer. To change the setting, click Start Æ

Control panel ÆSystem and Maintenance Æ Power Options ÆChoose what the Power button does. The following four options are

available: Do nothing, Sleep, Hibernate and Shut down.

Volume + Increases the volume while viewing DVDs or

replaying CDs.

Volume - Decreases the volume while viewing DVDs or

replaying CDs.

DVD menu Opens the main menu on a DVD movie, if

available.

Arrows Moves the cursor to navigate within Media

Center windows.

OK Selects the desired action or window option. It

acts like the ENTER Key.

LED on/off Pressing this button to switch the lighting of

indicators.

Mute Turns your computer sound off.

Back Displays the previous window.

More information The button provides more detail information.

Start Opens Media Center to the main window.

Rewind Moves the media (video, DVD, music, and so

on) backwards.

Play/Pause Plays the selected media. This button also acts

as a pause button.

User’s Manual 2-13

The Grand Tour

Fast forward Moves the media (video, DVD, music, and so

on) forwards.

Replay Moves media backward (seven seconds for

Stop Stops the media currently playing.

Skip Moves media forward (30 seconds for videos,

videos, one music track or one DVD chapter at a time).

one music track or one DVD chapter).

Using the remote controller

Some computers include a remote control unit, which allows you to control some of your computer’s functions from a distant location.

■ The remote controller is designed specifically for this computer.

■ Some application programs may not support remote control functions.

Operational range of the remote controller

Point the remote controller at your computer and press a button. The operational angle and distance are described below.

Distance Within 5 meters from the infrared receiver

window.

Angle Within about 30 degrees horizontally and about

15degrees vertically of perpendicular to the infrared receiver window.

2-14 User’s Manual

The Grand Tour

30 Degrees

15 Degrees

30 Degrees

Infrared Receiver Window

Operational range of the remote controller

Remote

Controller

(Vertically)

Even if within the effective scope as described above, the remote controller may malfunction or not work correctly in the following cases.

■ When an obstacle stands between the infrared receiver window of your

computer and the remote controller.

■ When direct sunlight or strong fluorescent light strikes the infrared

receiver window.

■ When the infrared receiver window or the infrared emission part of the

remote controller is dirty.

■ When other computers which use an infrared remote controller are

used near to your computer.

■ When a low battery condition is present.

User’s Manual 2-15

The Grand Tour

Installing/Removing batteries

Be sure to install the provided CR2016 type batteries before using the remote controller. The procedures for installing and removing the batteries vary depending on the type of the remote controller. Check the type and then install or remove the batteries as instructed.

Store the battery for the remote controller beyond the reach of children. If a child swallows a battery, this might result in choking. If it happens,

contact a doctor immediately.

Observe the following precautions when using the battery of the remote controller.

■ Do not use batteries other than those specified.

■ Ensure that you insert the batteries with their polarities correctly

aligned (+ or -).

■ Do not recharge, heat, disassemble or short the battery, or put it into a

fire or flame.

■ Do not use a battery whose “recommended expiration date” has been

reached, or which is completely discharged.

■ Do not use different types of batteries or old and new batteries at the

same time.

■ Do not carry the battery together with metal necklaces, hairpins or

other metal accessories.

■ When storing or disposing of used batteries, make sure to put some

insulation tape on their terminals (+ and -) to avoid short-circuits.

If these precautions are not followed, heating, fluid leakage or explosion may occur. This may cause burns or personal injury. If battery fluid gets on your skin or clothes, wash immediately with clean water. If battery fluid gets in your eyes, rinse your eyes with clean water immediately and see a doctor. Do not touch the battery fluid on instruments or devices with bare hands. Wipe off with a cloth or paper towel.

Type of battery that can be used for the remote controller

When the provided batteries run down, please replace them with adequate ones. CR2016 type battery is available. Other types or battery should not be used.

2-16 User’s Manual

The Grand Tour

Installing the batteries

1. Open the battery cover on the back side of the remote controller.

Battery Cover

Opening the battery cover

2. Be sure to place the batteries with correct polarities. Press the battery down to the stopper then push it forward to fit into the battery case.

Stopper

Battery

Inserting the batteries

3. Close the battery cover. Close the cover securely until it clicks.

Closing the battery cover

Replacing the batteries

When the batteries in the remote controller reach the end of their life, the remote controller may not operate correctly or work only within a short distance from your computer. In this instance, you should purchase new batteries and replace the discharged ones.

User’s Manual 2-17

The Grand Tour

Slim size remote controller

1. Open the battery cover on the back side of the remote controller.

2. Hold down the stopper and slide the battery out of battery case.

Stopper Battery

3. Insert the battery in place. Be sure to place the batteries with correct polarities. Press the battery down to the stopper then push it forward to fit into the battery case.

4. Close the battery cover. Close the cover securely until it clicks.

Placing slim size remote controller

Inserting a slim size remote controller

To insert the slim size remote controller, follow the steps below.

1. Make sure the ExpressCard slot is empty.

2. Set the front side upward and insert the slim size remote controller.

Removing the batteries

Slim size remote

controller

Inserting the slim size remote controller

3. Press gently to ensure a firm connection.

Remove a slim size remote controller

To remove the slim size remote controller, follow the steps below.

1. Press the slim size remote controller slightly to make it stretch out.

2. Grasp the slim size remote controller and pull it out from the slot.

2-18 User’s Manual

Chapter 3

Getting Started

This chapter provides basic information to get you started using your computer. It covers the following topics:

Be sure also to read the Instruction Manual for Safety and Comfort. This guide, which is included with the computer, explains product liability.

■ Installing the battery pack

■ Connecting the AC adaptor

■ Opening the display

■ Turning on the power

■ Windows Vista™ setup

■ Turning off the power

■ Restarting the computer

■ System Recovery Options

■ Create Optical Recovery Discs

■ Restoring the preinstalled Software from the Recovery HDD

■ Restoring the Preinstalled Software from Recovery Media

All users should be sure to read the section Windows Vista setup.

User’s Manual 3-1

Getting Started

Installing the battery pack

To install a battery, follow the steps below.

■ The battery pack is a lithium ion battery, which can explode if not

properly replaced, used, handled or disposed of. Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements.

■ Do not touch the latch while holding the computer. Or you may get

injured by the dropped battery by unintentional release of the latch.

■ Please do not push the power button before installing the battery pack.

1. Turn the computer's power off.

2. Disconnect all cables connected to the computer.

3. Insert the battery pack. The Battery Release Latch clicks into place.

4. Secure the Battery Pack Lock to ensure the battery is locked into place. Later, when you want to remove the battery you must disengage this lock first.

Battery

Pack Lock

Battery Release Latch

Securing the battery pack

Refer to Removing the battery pack section in Chapter 6, Power and

Power-Up Modes, for removing the battery pack.

3-2 User’s Manual

Connecting the AC adaptor

Attach the AC adaptor when you need to charge the battery or you want to operate from AC power. It is also the fastest way to get started, because the battery pack will need to be charged before you can operate from battery power.

The AC adaptor can be connected to any power source supplying from 100 to 240 volts and 50 or 60 hertz. For details on using the AC adaptor to charge the battery pack, refer to Chapter 6, Power and Power-Up Modes.

Use only the AC adaptor supplied as an accessory. Other AC adaptors have different voltage and terminal polarities and use of them may produce heat and smoke or even result in fire or rupture.

■ Use only the AC adaptor supplied with your computer or an equivalent

adaptor that is compatible. Use of any incompatible adaptor could damage your computer. TOSHIBA assumes no liability for any damage caused by use of an incompatible adaptor.

■ When you connect the AC adaptor to the computer, always follow the

steps in the exact order as described in the User's Manual. Connecting the power cable to a live electrical outlet should be the last step otherwise the adaptor DC output plug could hold an electrical change and cause an electrical shock or minor bodily injury when touched. As a general safety precaution, avoid touching any metal parts.

1. Connect the power cord to the AC adaptor.

Getting Started

Connecting the power cord to the AC adaptor

User’s Manual 3-3

Getting Started

2. Connect the AC adaptor's DC output plug to the DC IN 19V jack on the back of the computer.

Connecting the adaptor to the computer

3. Plug the power cord into a live wall outlet.

Opening the display

The display panel can be rotated in a wide range of angles for optimal viewing.

1. Lift the panel up and adjust it to the best viewing angle for you.

Use reasonable care when opening and closing the display panel. Opening it vigorously or slamming it shut could damage the computer.

Opening the display

3-4 User’s Manual

Turning on the power

This section describes how to turn on the power.

After you turn on the power for the first time, do not turn it off until you have set up the operating system. Refer to the section Windows Vista setup.

Press and hold the computer's power button for two or three seconds.

Getting Started

Turning on the power

Windows Vista setup

When you first turn on the power, the computer's initial screen is the Microsoft® Windows Vista™ Startup Screen Logo. Follow the on-screen directions.

Be sure to read the Windows End User License Agreement display carefully.

User’s Manual 3-5

Getting Started

Turning off the power

The power can be turned off in one of the following modes: Shut down (Boot), Hibernation or Sleep Mode.

Shut Down mode (Boot mode)

When you turn off the power in Shut Down mode no data is saved and the computer will boot to the operating system’s main screen.

1. If you have entered data, save it to the hard disk.

2. Make sure all disk (disc) activity has stopped, then remove the CD/ DVDs.

Make sure the Disk LED and ODD indicators are off. If you turn off the power while a disk (disc) is being accessed, you can lose data or damage the disk (disc).

3. Click then click the arrow icon located in the power management button . From the pull down menu, choose Shut Down.

4. Turn off the power to any peripheral devices.

Do not turn the computer or devices back on immediately. Wait a moment to let all capacitors fully discharge.

Sleep Mode

If you have to interrupt your work, you can turn off the power without exiting from your software. Data is maintained in the computer's main memory. When you turn on the power again, you can continue working right where you left off.

■ When the AC adaptor is connected, the computer will go into Sleep

Mode according to the settings in the Power Options.

■ To restore operation from Sleep Mode, press the power button or press

any key. The latter action works only if Wake-up on Keyboard is enabled in HW Setup.

■ If the computer automatically enters Sleep Mode while a network

application is active, the application might not be restored when the computer wakes up from Sleep Mode.

■ To prevent the computer from automatically entering Sleep Mode,

disable Sleep Mode in the Power Options. That action, however, will nullify the computer's Energy Star compliance.

3-6 User’s Manual

Getting Started

■ Before entering Sleep Mode, be sure to save your data.

■ Do not install or remove a memory module while the computer is in

Sleep Mode. The computer or the module could be damaged.

■ Do not remove the battery pack while the computer is in Sleep Mode

(unless the computer is connected to an AC power source). Data in memory will be lost.

Benefits of Sleep Mode

The Sleep Mode feature provides the following benefits:

■ Restores the previous working environment more rapidly than does

Hibernation Mode.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the duration set by the System Sleep Mode feature.

■ You can use the panel power off feature.

Entering Sleep Mode

You can enter Sleep Mode in one of three ways:

■ Click Start then click the power button ( ) located in the power

management buttons ( ). Please note that this feature must be enabled within the Power Options (to access it, click Æ Control Panel Æ System and Maintenance

Æ Power Options).

■ Click , click power button located in the power management

buttons , or click arrow button and select Sleep from the menu.

■ Close the display panel. This feature must be enabled. Please refer to

the Power Options (to access it, click Æ Control Panel Æ System and Maintenance Æ Power Options).

When you turn the power back on, you can continue where you left when you shut down the computer.

You can also enable Sleep Mode by pressing Fn + F3. Refer to Chapter 5,

The Keyboard, for details.

■ When the computer is shut down in Sleep Mode, the power indicator

flashes orange.

■ If you are operating the computer on battery power, you can lengthen

the operating time by turning it off into Hibernation Mode, as Sleep Mode consumes more power.

User’s Manual 3-7

Getting Started

Sleep Mode limitations

Sleep Mode will not function under the following conditions:

■ Power is turned back on immediately after shutting down.

■ Memory circuits are exposed to static electricity or electrical noise.

Hibernation Mode

The hibernation feature saves the contents of memory to the hard disk when the computer is turned off. The next time the computer is turned on, the previous state is restored. The hibernation feature does not save the status of peripheral devices.

■ Save your data. While entering Hibernation Mode, the computer saves

■ Data will be lost if you remove the battery or disconnect the AC adaptor

■ Do not install or remove a memory module while the computer is in

Benefits of Hibernation Mode

The Hibernation Mode feature provides the following benefits:

■ Saves data to the hard disk when the computer automatically shuts

■ You can return to your previous working environment immediately when

■ Saves power by shutting down the system when the computer receives

■ You can use the panel power off feature.

the contents of memory to the HDD. However, for safety sake, it is best to save your data manually.

before the save is completed. Wait for the disk indicator to go out.

Hibernation Mode. Data will be lost.

down because of a low battery.

you turn on the computer.

no input or hardware access for the duration set by the System hibernate feature.

Starting Hibernation Mode

You can also enable Hibernation Mode by pressing Fn + F4. Refer to Chapter 5, The Keyboard, for details.

To enter Hibernation Mode, follow the steps below.

1. Click .

2. Click the arrow icon located in the power management button

3. From the pull down menu, select Hibernate.

3-8 User’s Manual

Automatic Hibernation Mode

The computer will enter Hibernation mode automatically when you press the power button or close the Display Screen. First, however, make the appropriate settings according to the steps below.

1. Open the Control Panel.

2. Open System and Maintenance and open Power Options.

3. Select the Choose what the power button does.

4. Enable the desired Hibernation settings for When I press the power

button and When I close the lid.

5. Click the Save changes button.

Data saving in Hibernation Mode

When you turn off the power in Hibernation Mode, the computer takes a moment to save current memory data to the hard disk. During this time, the disk indicator will light.

After you turn off the computer and memory is saved to the hard disk, turn off the power to any peripheral devices.

Do not turn the computer or devices back on immediately. Wait a moment to let all capacitors fully discharge.

Restarting the computer

Getting Started

Certain conditions require that you reset the system. For example, if:

■ You change certain computer settings.

■ An error occurs and the computer does not respond to your keyboard

commands.

■ There are three ways to reset the computer system:

1. Click then click the arrow icon located in the power management

button , and select Restart from pull down menu.

2. Press Ctrl + Alt + Del to display the menu window, then select Restart

from the Shut down options.

3. Press the power button and hold it down for five seconds. Once the

computer has turned itself off, wait between ten and fifteen seconds before turning it on again with the power button.

User’s Manual 3-9

Getting Started

System Recovery Options

About 1.5GB hidden partition is allocated on the hard drive for the System Recovery Options.

The System Recovery Options feature will be unusable if this partition is deleted.

System Recovery Options

The System Recovery Options feature is installed on the hard disk when shipped from the factory. The System Recovery Options menu includes some tools to repair startup problems, run diagnostics or restore the system. You can see the more information about “Startup Repair” in “Windows Help and Support” content.

The System Recovery Options can also be run manually to repair problems.

The procedure is as follows. Follow the instructions shown on the onscreen menu.

1. Turn off the computer.

2. While holding the F8 key, turn the computer on.

3. The Advanced Boot Options menu will be displayed. Use the arrow keys to select Repair Your Computer and press Enter.

4. Follow the on-screen instructions.

The Windows Vista CompletePC Backup feature can be used on Windows Vista™ Business Edition and Ultimate Edition.

Create Optical Recovery Discs

A recovery image of your computer is stored on the hard disk. You may use this image to create CD or DVD recovery discs using the following steps:

1. Select either blank CD or DVD media.

2. The application will allow you to choose a type of media to create recovery CD/DVD including: CD-R, CD-RW, DVD-R, DVD-RW, DVD+R

and DVD+RW.

Some media may not be compatible with the Optical Drive of your computer. Please verify your Optical Drive supports the blank media you choose.

3-10 User’s Manual

3. Turn on your computer to open Windows Vista.

4. Insert the (first) blank media into the tray of the Optical Drive.

5. Double Click the Recovery Disc Creator icon on the Windows Vista

desktop, or select the application from Start menu.

6. After TOSHIBA Recovery Disc Creator starts, select the type of media

and the title you wish to copy to the media then click the Create button.

If your Optical Drive can only write to CDs, select "CD" as the "Disc Set" on TOSHIBA Recovery Disc Creator If your Optical Drive of your computer can write to either CD or DVDs, select the one you are using as the "Disc Set" on TOSHIBA Recovery Disc Creator.

Restoring the preinstalled software from the Recovery HDD

Part of the space on the hard disk drive is reserved as recovery partition for restoring the pre-installed software from the hard disk drive.

When re-setting up your hard disk, do not change, delete or add partitions in a manner other than specified in the manual. Otherwise, space for software may be destroyed.

In addition, if you use a third-party partitioning program to reconfigure partitions on your hard disk, it may become impossible to re-setup your computer.

1. Turn off your computer.

2. Hold down the 0 (zero) key on the keyboard and turn on your computer.

When “TOSHIBA Leading Innovation >>>” appears, release the 0 (zero) key on the keyboard.

3. A menu appears. Follow the on-screen instructions.

Getting Started

You can not use System Recovery Options if restoring the pre-installed software without System Recovery Options.

When you reinstall the Windows operating system, the hard disk will be reformatted and all data will be lost.

User’s Manual 3-11

Getting Started

Restoring the preinstalled software from Recovery Media

If the preinstalled files are damaged, use the Recovery Media you created, or HDD recovery to restore them. To restore the operating system and all preinstalled software, follow the steps below.

When you reinstall the Windows operating system, the hard disk will be reformatted and all data will be lost.

1. Load the Recovery Media in the optional optical media drive and turn off the computer's power.

2. Hold down the F12 key and turn on the power. When “TOSHIBA Leading Innovation >>>” appears, release the F12 key.

3. Use the upper or lower cursor key to select the CD/DVD in the display menu. For details, refer to the Boot Priority section in Chapter 7, HW

Setup.

4. A menu appears. Follow the on-screen instructions.

When you removed pre-installed drivers/ utilities or when installing, you can setup the respective drivers/ utilities from the following folder. C:\TOSAPINS\***

3-12 User’s Manual

Chapter 4

Operating Basics

This chapter gives information on basic operations including using the TouchPad, optical media drives, sound system, modem, the wireless LAN and LAN. It also provides tips on caring for your computer.

Using the TouchPad

To use the TouchPad, simply touch and move your finger tip across it in the direction you want the on-screen pointer to go.

TouchPad

TouchPad control buttons

TouchPad and TouchPad control buttons

Two buttons below the keyboard are used like the buttons on a mouse pointer. Press the left button to select a menu item or to manipulate text or graphics designated by the pointer. Press the right button to display a menu or other function depending on the software you are using.

User’s Manual 4-1

Operating Basics

Do not press on the TouchPad too hard or press a sharp object such as a ball point pen against the TouchPad. The TouchPad could be damaged.

For some functions, you can tap the TouchPad instead of pressing a control button.

Click: Tap the TouchPad once Double-click: Tap the TouchPad twice Drag and drop:

1. Hold down the left control button and move the cursor to drag the item you want to move.

2. Lift your finger to drop the item where you want it.

Scroll:

Vertical: Move your finger up or down the right edge of the TouchPad. Horizontal: Move your finger left or right along the bottom edge of the

TouchPad.

Using the fingerprint sensor

This product has a fingerprint utility installed for the purpose of enrolling and recognizing fingerprints. By enrolling the ID and password to the fingerprint authentication device, it is no longer necessary to input the password from the keyboard. Just by swiping the finger against the fingerprint sensor, the following functions will be enabled:

■ Logon to Windows and access a security-enabled homepage through

IE (Internet Explorer).

■ Files and folders can be encrypted/decrypted and third party access to

them prevented.

■ Disable the password-protected screen-saver when returning from

power-saving (Sleep) mode.

■ Pre-OS feature and Single Sign-On feature.

■ Authentication of the User Password and Hard Disk Password when

booting up the computer.

To “swipe” refers to the action of reading a fingerprint using the fingerprint sensor.

4-2 User’s Manual

How to swipe the finger

Using the following steps when swiping fingers for fingerprint registration or authentication will help to minimize authentication failures:

1. Align the first joint of the finger to the center of the sensor. Lightly touch the sensor and swipe finger levelly towards you.

2. While lightly touching the sensor, swipe the finger towards you until the sensor surface becomes visible.

3. Ensure the center of the fingerprint is on the sensor when swiping the finger.

Slide the finger over the recognition sensor

■ Avoid swiping with the finger stiff or pressed-on too hard:

Fingerprint reading may fail if the center of the fingerprint is not touching on the sensor, or when finger is swiped while pressing hard. Make sure that the center of the fingerprint is touching the sensor before swiping.

■ Confirm the center of the fingerprint whirl before swiping:

The thumb’s fingerprint has a bigger whirl, which is prone to misalignment and distortions. This will cause difficulty in registration and a drop in the authentication success rate. Always confirm the center of the fingerprint whirl so that it is swiped along the centerline of the sensor.

■ When fingerprint reading is not successful:

There is a possibility of authentication failures if the finger is swiped too quickly or too slowly. Follow the onscreen instructions to adjust the speed of the swipe.

Operating Basics

User’s Manual 4-3

Operating Basics

Points to note about the fingerprint sensor

Failure to follow these guidelines might result in (1) damage to the sensor or cause sensor failure, (2) finger recognition problems, or lower finger recognition success rate.

■ Do not scratch or poke the sensor with your nails or any hard or sharp

objects.

■ Do not press the sensor strongly.

■ Do not touch the sensor with a wet finger or any wet objects. Keep

sensor surface dry and free of water vapor.

■ Do not touch the sensor with a soiled finger. Minute foreign particles on

a soiled or dirty finger may scratch the sensor.

■ Do not paste stickers or write on the sensor.

■ Do not touch the sensor with a finger or any object with built-up static

electricity.

Observe the following before you place your finger on the sensor whether for fingerprint enrollment/registration or recognition.

■ Wash and dry your hands thoroughly.

■ Remove static electricity from your fingers by touching any metal

surface. Static electricity is a common cause of sensor failures, especially when the weather is dry.

■ Clean the sensor with a lint-free cloth. Do not use detergent to clean the

sensor.

■ Avoid the following finger conditions for enrollment or recognition as

they may result in fingerprint enrollment errors or a drop in the fingerprint recognition success rate

■ Soaked or swollen finger (e.g. after taking bath)

■ Injured finger

■ Wet finger

■ Soiled or oily finger

■ Extremely dry skin condition on finger

Observe the following to improve the fingerprint recognition success rate.

■ Enroll two or more fingers.

■ Enroll additional fingers if recognition failure occurs often using enrolled

fingers.

■ Check your finger condition. Changed conditions, such as injured,

rough, extremely dry, wet, soiled, dirty, oily, soaked, swollen fingers, may lower the recognition success rate. Also if the fingerprint is worn down or the finger becomes thinner or fatter, the recognition success rate may be lowered.

4-4 User’s Manual

■ The fingerprint for each finger is different and unique. Please ensure

that only the registered or enrolled fingerprint or fingerprints are used for identification.

■ Check sliding position and speed.

■ Fingerprint data is enrolled up to 30~34.

■ Fingerprint data is stored into the nonvolatile memory in the fingerprint

sensor. Deleting the fingerprint data with Delete menu on Fingerprint Software Management before you dispose the computer is recommended.

How to delete the fingerprint data

Saved fingerprint data is stored in the Non-volatile memory inside the fingerprint sensor. If you hand over the PC to others, or dispose of it, the following operations are recommended.

1. Click Start, point to All Programs, point to TrueSuite Access Manager and click it.

2. The TrueSuite Access Manager Fingerprint Software screen is displayed.

3. Enter your Windows Password and click Next to enter the Control Center. Or swipe your enrolled finger to enter the Control Center.

4. Click Delete All Fingerprints.

Fingerprint sensor limitations

■ The fingerprint sensor compares and analyzes the unique

characteristics in a fingerprint.

■ A warning message will be displayed when recognition is abnormal or

recognition is not successful within a fixed duration.

■ The recognition success rate may differ from user to user.

■ Toshiba does not guarantee that this fingerprint recognition technology

will be error-free.

■ Toshiba does not guarantee that the fingerprint sensor will recognize

the enrolled user or accurately screen out unauthorized users at all times. Toshiba is not liable for any failure or damage that might arise out of the use of this fingerprint recognition software or utility.

Operating Basics

User’s Manual 4-5

Operating Basics

Points to note about the fingerprint utility

■ If Windows Vista™’s file encryption function EFS (Encryption File

System) is used to encrypt a file, the file cannot be further encrypted using the encryption function of this software.

■ You can back up the fingerprint data or the information registered to

Password Bank.

■ Please use Import/Export menu on Fingerprint Software Management.

■ Please also refer to the fingerprint utility Help file for more information.

You can start it using the following method:

■ Click Start, point to All Programs, point to TrueSuite Access

Manager and click Document.

■ Click Start, point to All Programs, point to TrueSuite Access

Manager and click it. The main screen is displayed. Click Help in

the upper right corner of the screen.

Set up procedure

Please use the following procedure when first using fingerprint authentication.

Fingerprint registration

Enroll the required authentication data using the Fingerprints Enrollment Wizard.

■ The fingerprint authentication uses the same Windows logon ID and

password. If the Windows logon password has not been setup, please do so before registration.

■ Up to 30~34 fingerprint patterns can be registered.

1. Click Start, point to All Programs, point to TrueSuite Access Manager and click it. Or double click the icon in the Task Bar.

2. The Enter Windows Password screen is displayed. Enter a password into the Enter Windows Password field. Click Next.

3. The Control Center screen is displayed. Click the non-enrolled finger icon above the finger.

4. The Fingerprint Enrollment screen is displayed. Confirm the message and click Next.

5. The Scanning Practice screen is displayed. You can practice swiping your finger. When you have finished practicing swiping your finger, click Next.

6. The Fingerprint Image Capture screen is displayed. Follow the onscreen instructions and use the same finger you have selected under the Control Center to swipe your finger with good images three times for the fingerprint template to be created.

4-6 User’s Manual

7. In case of finger injury or authentication failure, it is recommended that

another fingerprint also be enrolled. The following message will be displayed: [We recommended enrolling at least two fingerprint images.] Click OK and repeat steps 3, 4, 5 and 6 with another finger.

Windows logon via fingerprint authentication

In place of the usual Windows logon by ID and password, fingerprint authentication also allows logon to Windows.

This is useful especially when many users are using the PCs, as user selection can be skipped.

Fingerprint authentication procedure

1. Start up the computer.

2. The Logon Authorization screen is displayed. Choose any of the

enrolled fingers and swipe the fingerprint on the sensor. If authentication is successful, the user will be logged on to Windows.

■ If the fingerprint authentication fails, please logon using the Windows

logon password.

■ Please logon using the Windows logon password if the fingerprint

authentication failed for five times. To logon using the Windows logon password, enter the Windows logon password at the [Welcome] screen as normal.

■ A warning message will be displayed when authentication is abnormal

or authentication is not successful within a fixed duration.

Operating Basics

Fingerprint system boot authentication

General

The fingerprint authentication system can be used to replace the keyboard based User Password authentication system when booting up.

If you do not want to use the fingerprint authentication system for password authentication when booting up, but prefer to use the keyboard-based system instead, press the BACK SPACE key when the Fingerprint System Boot Authentication screen is displayed. This will switch the password input screen to the keyboard-based one.

User’s Manual 4-7

Operating Basics

■ It is necessary to register the User Password before using the

fingerprint Pre-OS feature and its extended function, the fingerprint Single Sign-On feature. Please use TOSHIBA HW Setup to register the User Password.

■ If you fail fingerprint authentication more than five times, you must

enter the User Password or Supervisor Password manually to start the computer.

■ When swiping, please do it slowly and at a constant speed. If this does

not improve the authentication rate, please adjust the speed.

■ If there are any changes in the environment or settings related to

authorization, you will be required to provide authorization information such as a User Password and HDD password.

How to enable fingerprint system boot authentication settings

It is necessary to first enroll your fingerprint with the TrueSuite Access Manager application prior to enabling and configuring the fingerprint PreOS feature.

Check that your fingerprint is enrolled before configuring the settings.

1. Swipe your finger across the fingerprint sensor. Or enter Windows password and click Next.

2. Click settings.

3. The Administrator Settings screen is displayed. Place a checkmark in “Enable Pre-OS Fingerprint Authentication” and click OK.

The modified configuration for fingerprint Pre-OS feature becomes effective the next time the system is booted up.

Fingerprint Single Sign-On feature

General

This is a feature that allows the user to complete the authentication for both the User Password (and optionally, the HDD user and Supervisor passwords) and logging on to Windows using only one fingerprint authentication when booting up. It is necessary to register the User Password and Windows Logon password before using the fingerprint PreOS feature and this fingerprint Single Sign-On feature. Please use TOSHIBA HW Setup to register your User Password.

Only one fingerprint authentication is required to replace the User Password (and, if selected, the HDD user and Supervisor passwords) and Windows Logon password.

4-8 User’s Manual

How to enable fingerprint Single Sign-On feature

It is necessary to first enroll your fingerprint with the TrueSuite Access Manager application prior to enabling and configuring the fingerprint Single Sign-On feature. Check that the fingerprint is enrolled before configuring the settings.

1. Swipe your finger across the fingerprint sensor. Or enter Windows

password and click Next.

2. Click settings.

3. The Administrator Settings screen is displayed. Place a checkmark in

“Enable Pre-OS Fingerprint Authentication”.

4. Then, place a checkmark in “Enable Single Sign-On Fingerprint

Authentication” and click OK.

The modified configuration for the fingerprint Single Sign-On feature becomes effective the next time the system is booted up.

Fingerprint utility limitations

TOSHIBA does not guarantee that the fingerprint utility technology will be completely secure or error-free. TOSHIBA does not guarantee that the fingerprint utility will accurately screen out unauthorized users at all times. TOSHIBA is not liable for any failure or damage that might arise out of the use of the fingerprint software or utility.

USB Sleep and Charge function

Your computer can supply USB bus power (DC5V) to the USB port even when the power of the computer is turned OFF. “Power OFF” includes Sleep Mode, Hibernation Mode or shutdown state.

This function can only be used for ports that support the USB Sleep and Charge function (hereinafter called “compatible ports”).

Compatible ports are USB ports that have the ( ) symbol icon. You can use the “USB Sleep and Charge function” to charge certain USB-

compatible external devices such as mobile phones or portable digital music players.

However, the “USB Sleep and Charge function” may not work with certain external devices even if they are compliant with the USB specification. In those cases, turn the power of the computer ON to charge the device.

Operating Basics

User’s Manual 4-9

Operating Basics

■ The “USB Sleep and Charge function” only works for compatible ports.

This function is disabled in the default setting. To enable it, you must change [Disabled] to [Enabled] in the HW setup.

■ When “USB Sleep and Charge function” is set to [Enabled] in HW

Setup, USB bus power (DC5V) will be supplied to compatible ports even when the power of the computer is turned OFF. USB bus power (DC5V) is similarly supplied to the external devices which are connected to the compatible ports. However, some external devices cannot be charged solely by supplying USB bus power (DC5V). As for the specifications of the external devices, please contact the device manufacturer or check the specifications of the external devices thoroughly before use.

■ Using the USB sleep and charge function to charge external devices

will take longer than charging the devices with their own chargers.

■ If external devices are connected to compatible ports when the AC

adaptor is not connected to the computer, the battery of the computer will be depleted even when the power of the computer is turned OFF. As such, we recommend that you connect the AC adaptor to the computer when using the USB sleep and charge function.

■ External devices connected to the USB bus power (DC5V) function that

interfaces with the power ON/OFF of the computer may always be in an operational state.

■ When there is a current overflow of the external devices connected to

the compatible ports, USB bus power (DC5V) supply may be stopped for safety reasons.

■ Metal paper clips or hair pins/clips will generate heat if they come into

contact with USB ports. Do not allow USB ports to come into contact with metal products, for example when carrying the computer in your bag.

How to enable/disable USB sleep and charge function

You can set enable/disable USB sleep and charge function in HW setup Refer to the USB Sleep and Charge function in Chapter 7 HW Setup.

4-10 User’s Manual

Using the Web Camera

This section describes the bundled webcam utility, which can capture still and video images. The web camera will auto-run when Windows starts.

Please unstick the protective plastic-film before using the Web Camera.

Operating Basics

Built-in microphone *

Web Camera Lens *

Web Camera LED *

* Provided with some models

Using the software

The web camera software is pre-configured to start when you turn on Windows Vista; if you need to restart it go to Start  All Programs  Camera Assistant Software  Camera Assistant Software.

User’s Manual 4-11

Operating Basics

Capture Still

Images

Effects Mute

Video

Recording

Audio

Recording

Function

Display Window

Camera resolution

Capture Still Images Click to see a preview of the captured image; you

can also e-mail the image.

Video Recording Click to prepare for recording. Click again to start

recording. One more to stop recording and see preview of the video.

Audio Recording Click to start recording, click again to stop and

listen to a preview of the audio.

Function Access additional functions: About, Player,

Effects, Properties, Settings and Help.

About Displays software manufacturer details.

Player Play video files.

Effects Choose images to be displayed on the capture

screen.

Properties Choose from the Options tab to flip, zoom,

flicker rate, night mode and backlight compensation; in the Image tab change the color settings; in the Profiles tab change the lighting conditions.

4-12 User’s Manual

Settings Choose from the: Options tab to change the tool

Help Displays the help files for the software.

Using the microphone

Your computer has a built-in microphone that can be used to record monaural sounds into your applications. It can also be used to issue voice commands to applications that support such functions. (Built-in microphone is provided with some models)

Since your computer has a built-in microphone and speaker, “feedback” may be heard under certain conditions. Feedback occurs when sound from the speaker is picked up in the microphone and amplified back to the speaker, which amplifies it again to the microphone.

This feedback occurs repeatedly and causes a very loud, high-pitched noise. It is a common phenomenon that occurs in any sound system when the microphone input is output to the speaker (throughput) and the speaker volume is too loud or too close to the microphone. You can control throughput by adjusting the volume of your speaker or through the Mute function in the Master Volume panel. Refer to your Windows documentation for details on using the Master Volume panel.

Operating Basics

bar position; the Picture tab to select picture output options such as size, export file and save path; the Video tab to choose video output settings such as Frame Rate, Size, Compression and the frame rate, size, record compressor, and save path; the Audio tab to change the audio device, audio compressor, audio volume and save path.

Using the TOSHIBA Face Recognition

TOSHIBA Face Recognition uses a face verification library to verify the face data of users when they log in to Windows. The user can thus avoid having to enter a password or the like, which makes the login process easier.

User’s Manual 4-13

Operating Basics

Note on Use

Disclaimer

■ TOSHIBA Face Recognition does not guarantee the correct

identification of a user. Changes to the likeness of a registrant, such as hair style changes, wearing a cap, or wearing glasses may effect the recognition rates when such changes occur after the registrant had registered.

■ TOSHIBA Face Recognition may incorrectly recognize faces that are

similar to a registrant.

■ For high security purposes, TOSHIBA Face Recognition is not a

suitable substitute for Windows passwords. When security is a high priority, use your established Windows passwords to log in.

■ Bright background light and/or shadows may prevent a registrant from

being recognized correctly. In that case, log in using your Windows password. If recognition of a registrant fails repeatedly, refer to your computer documentation to learn ways to improve recognition performance.

Toshiba does not guarantee that the face recognition utility technology will be completely secure or error-free. Toshiba does not guarantee that the face recognition utility will accurately screen out unauthorized users at all times. Toshiba is not liable for any failure or damage that might arise out of the use of the face recognition software or utility.

TOSHIBA, ITS AFFILIATES AND SUPPLIERS SHALL HAVE NO RESPONSIBILITY FOR DAMAGE TO OR LOSS OF ANY BUSINESS, PROFITS, PROGRAMS, DATA, NETWORK SYSTEMS OR REMOVABLE STORAGE MEDIA ARISING OUT OF OR RESULTING FROM THE USE OF THE PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY THEREOF.

How to register the Face Recognition Data

Take a picture for facial verification purposes, and register the data needed when you log in. To register the data needed when you log in, follow the steps as described below:

1. To launch this utility, click Start  All Programs  TOSHIBA  Utilities  TOSHIBA Face Recognition.

■ The Registration screen is displayed for a logged-in user whose

face has not been registered.

■ The Management screen is displayed for a logged-in user whose

face has already been registered.

2. Click the Register face button in the Management screen. The Registration screen is displayed.

■ If you wish to practice, click on the Next button in the Registration

screen.

■ If you do not wish to practice, click on the Skip button in the

Registration screen.

4-14 User’s Manual

Operating Basics

3. Click the Next button to start the guide.

4. First, take a picture while moving your neck slightly to the left and right.

5. Now take a picture while moving your neck down and up.

■ Click the Back button to practice the guide once more.

6. Click the Next button to start image-capturing process.

Adjust the position of your face so that it fits within the face-shaped frame.

7. Once your face has been positioned properly, the recording will

commence. Start moving your neck very slightly to the left and right, and then move

your neck up and down.

8. Registration will end after you have repeatedly moved your neck left,

right, down and up. When the register succeeds, below message will be displayed on the

screen: "Registration successful. Now we’ll do the verification test. Click the Next button.".

Click the Next button to perform the verification test.

9. Perform the verification test. Face the screen as you do when you

■ If verification fails, click the Back button and re-register. Please refer

to step 8 from step 6.

10. If verification is successful, click the Next button and register an

account.

11. Register the account.

Fill in the account registration fields.

■ Fill in the User Name, User Full name, Log on to, Password, and

Confirm password fields;

When you have finished it, click Next button.

12. The Management screen is displayed.

The registered account name will be displayed. Clicking on it will cause the captured image of your face to be displayed on the left.

How to Delete the Face Recognition Data

Delete image data, account information, and personal record data created during registration. To delete the Face Recognition Data, follow the steps as described below:

1. To launch this utility, click Start  All Programs  TOSHIBA 

Utilities  TOSHIBA Face Recognition. The Management screen is displayed.

User’s Manual 4-15

Operating Basics

2. Select a user which is deleted in the Management screen.

3. Click the Delete button. "You are about to delete the user data. Would you like to continue?" will be displayed on the screen.

■ If you do not want the data to be deleted, click the No button and

you will then be returned to the Management screen.

■ Clicking on the Yes button will remove the selected user from the

Management screen.

How to launch the help file

For further information on this utility, please refer to help file.

1. To launch the help file, click Start  All Programs  TOSHIBA  Utilities  TOSHIBA Face Recognition Help.

Windows Logon via TOSHIBA Face Recognition

This section explains how to login to Windows with TOSHIBA Face Recognition. Two authentication modes are provided.

■ AUTO Mode Login screen: If the face authentication file is selected by

default, you can log in without using the keyboard or mouse.

■ 1:1 Mode Login screen: This mode is essentially the same as AUTO

mode, but the Select Account screen will appear before the Display Captured Image screen, and you will need to select the user account to be authenticated in order to start the authentication process.

AUTO Mode Login screen

1. Turn on the computer.

2. The Select Tiles screen will be displayed.

3. Select the tile for facial authentication.

4. "Please turn your face to the camera" will be displayed.

5. Verification will be performed. If the authentication is successful, the image data taken in step 4 will be faded in and placed over one another.

■ If an error occurs during authentication, you will be returned to the

Select Tiles screen.

6. Windows Welcome screen will be displayed, and will be logged in automatically to Windows.

4-16 User’s Manual

1:1 Mode Login screen

1. Turn on the computer.

2. The Select Tiles screen will be displayed.

3. Select the tile for facial authentication.

4. The Select Account screen will be displayed.

5. Select the account, and click the arrow button.

6. "Please turn your face to the camera" will be displayed.

7. Verification will be performed. If the authentication is successful, the

image data taken in step 6 will be faded in and placed over one another.

■ If an error occurs during authentication, you will be returned to the

Select Tiles screen.

8. Windows Welcome screen will be displayed, and will be logged in

automatically to Windows.

■ If authentication was successful, but an authentication error

subsequently occurred during the login to Windows, you will be asked to provide your account information.

Using the optical disc drive

Operation is the same for all optical media drives. The full-size drive provides high-performance execution of CD/DVD-based programs. You can run either 12 cm (4.72") or 8 cm (3.15") CDs without an adaptor. An ATAPI interface controller is used for CD/DVD operation. When the computer is accessing a CD/DVD, an indicator on the drive glows.

Refer also to the Writing CD/DVD with the DVD Super Multi drive section for precautions on writing to CD/DVD.

Operating Basics

User’s Manual 4-17

Operating Basics

Loading discs

To load a disc, follow the steps below and refer to the figures.

1. a. When the power is on, press the eject button to open the drawer

slightly.

Eject Button

Pressing the eject button

b. Pressing the eject button will not open the drawer when the disc

drive's power is off. If the power is off, you can open the drawer by inserting a slender object (about 15 mm) such as a straightened paper clip into the eject hole just to the right of the eject button.

Manual release with the eject hole

4-18 User’s Manual

2. Grasp the drawer gently and pull until it is fully opened.

Pulling the drawer open

3. Place the disc, label side up, in the drawer.

Operating Basics

Inserting a disc

User’s Manual 4-19

Operating Basics

When the drawer is fully opened, the edge of the computer will extend slightly over the disc tray. Therefore, you will need to turn the disc at an angle when you place it in the tray. After seating the disc, however, make sure it lies flat, as shown in the figure above.

■ Do not touch the laser lens. Doing so could cause misalignment.

■ Keep foreign matter from entering the drive. Check the back edge of

the tray to make sure it carries no debris before closing the drive.

4. Press gently at the centre of the disc until you feel it click into place. The disc should lie below the top of the spindle, flush with the spindle base.

5. Push the center of the drawer to close it. Press gently until it locks into place.

If the disc is not seated properly when the drawer is closed, the disc might be damaged. Also, the drawer might not open fully when you press the eject button.

Closing the disc drawer

4-20 User’s Manual

Removing discs

To remove the disc, follow the steps below and refer to the figure.

Do not press the eject button while the computer is accessing the disc drive. Wait for the optical media drive indicator to go out before you open the drawer. Also, if the disc is spinning when you open the drawer, wait for it to stop before you remove it.

1. To pop the drawer partially open, press the eject button. Gently pull the

drawer out until it is fully opened.

■ When the drawer pops open slightly, wait a moment to make sure the

disc has stopped spinning before pulling the drawer fully open.

■ Turn off the power before you use the eject hole. If the disc is spinning

when you open the drawer, the disc could fly off the spindle and cause injury.

2. The disc extends slightly over the sides of the drawer so you can hold it.

Hold the disc gently by its edges and lift it out.

Operating Basics

Removing a disc

3. Push the centre of the drawer to close it. Press gently until it locks into

place.

User’s Manual 4-21

Operating Basics

Writing CD/DVD with the DVD Super Multi drive

Some models in this series are equipped with Writing CD/DVD with the DVD Super Multi drive.

You can use the DVD Super Multi drive to write data to either CD-R/RW or DVD-R/-RW/+R/+RW/-RAM discs. The following applications for writing are preinstalled: TOSHIBA Disc Creator and TOSHIBA Direct Disc Writer. Ulead Movie factory for TOSHIBA.

Important message (DVD Super Multi drive)

Before you write or rewrite to CD-R/RW or DVD-R/-RW/+R/+RW/-RAM discs, read and follow all setup and operating instructions in this section. If you fail to do so, the DVD Super Multi drive may not function properly, and you may fail to write or rewrite, lose data or incur other damage.

Before writing or rewriting

■ Based on TOSHIBA's limited compatibility testing, we suggest the

following manufacturers of CD-R/RW and DVD-R/+R/-RW/+RW/-RAM discs. However, in no event does TOSHIBA guarantee the operation, quality or performance of any disc. Disc quality can affect write or rewrite success rates.

CD-R: TAIYO YUDEN Co., Ltd.

MITSUBISHI KAGAKU MEDIA CO, LTD. Ricoh Co., Ltd.

Hitachi Maxell Ltd.

CD-RW: MITSUBISHI KAGAKU MEDIA CO, LTD.

High Speed CD-RW: MITSUBISHI KAGAKU MEDIA CO, LTD.

Ultra Speed CD-RW: MITSUBISHI KAGAKU MEDIA CO, LTD.

DVD-R: DVD Specifications for Recordable disc for

DVD-R(DL): MITSUBISHI KAGAKU MEDIA CO, LTD.

DVD+R: MITSUBISHI KAGAKU MEDIA CO, LTD.

DVD+R(DL): MITSUBISHI KAGAKU MEDIA CO, LTD.

DVD-RW: DVD Specifications for Recordable Disc for

Ricoh Co., Ltd.

General Version2.0

TAIYO YUDEN Co., Ltd. Matsushita Electric Industrial Co., Ltd.

Ricoh Co., Ltd.

Version 1.1 or 1.2

Victor Company of Japan, Ltd. (JVC) MITSUBISHI KAGAKU MEDIA CO, LTD.

4-22 User’s Manual

Toshiba M800, U400, M800D, U400D User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Copyright

Disclaimer

Trademarks

Safety Instructions

When Using Your Computer

FCC information

FCC notice “Declaration of Conformity Information”

FCC conditions

Contact

BSMI notice (Taiwan only)

EU Declaration of Conformity

VCCI Class B Information

Canadian Regulatory Information (Canada Only)

Modem warning notice

Conformity Statement

Network Compatibility Statement

Japan regulations

Region selection

Redial

Pursuant to FCC CFR 47, Part 68:

Instructions for IC CS-03 certified equipment

Notes for Users in Australia and New Zealand

Following information is only for EU-member states:

EnergyStar® Program

Optical disc drive safety instructions

Panasonic

DVD Super Multi UJ-862E/UJ-862A

Hitach-LG Data Storage

DVD Super Multi GSA-U20N/GSA-U20F

International Precautions

Important Notice

General Precautions

Creating a computer-friendly environment

Stress injury

Heat injury

Pressure or impact damage

ExpressCard overheating

Mobile phones

Instruction Manual for Safety and Comfort

Table of Contents

Preface

Manual contents

Conventions

Abbreviations

Icons

Keys

Key operation

Display

Messages

Terminology

Chapter 1

Introduction

Equipment checklist

Hardware

Software

Features

Special features

TOSHIBA Value Added Package

Utilities and Applications

Options

Chapter 2

The Grand Tour

Front with the display closed

Left side

Right side

Backside

Underside

Front with the display open

Optical Disc Drive

Region codes for DVD drive and media

Writable discs

DVDs

DVD Super Multi drive

AC adaptor

Remote controller

Using the remote controller
