Satellite Pro M70-235:Intel® Centrino™ mobile technology including
Intel® Pentium® M processor 750/ XP Pro/ 15.4" W-TFT/ 60 GB/ 512 MB/
DVD-Super-Multi(DL)/ LAN/ WiFi/ i.Link/ BT
Part Number : PSM76E-00G005G3
Ideal for the image-conscious home or business user who values superb widescreen performance,
this stylish notebook features a 15.4" WXGA Toshiba TruBrite (on selected models) display for a
crystal-clear picture
Experience the ultimate thrill of high definition viewing. Thanks to "HD to go" from Toshiba, HD
viewing is now going mobile with video images so vivid they almost seem alive
Seamless mobility with Intel® Centrino™ mobile technology plus Microsoft® Office OneNote™ 2003
for intuitive information management and Toshiba ConfigFree™ for easy management of wireless
and wired network connectivity
Thrilling and breathtaking graphics with ATI MOBILITY™ RADEON™ X700 or X600 SE featuring
HyperMemory™ technology or Intel® 915GM with up to 128 MB RAM (UMA)
Enjoy instant-on entertainment (without having to boot the operating system) via the Express Media
Player (on selected models), along with stunning audio quality courtesy of Harman Kardon® stereo
speakers (on selected models)
Offers state-of-the-art connectivity and a broad range of expansion options, including Wireless LAN
802.11b/g, i.LINK, TV-out (S-video), 5-in-1 bridge media slots and Express Card slot (on selected
models) for future-proof PC Card support
Page 2
Property Value
Technology
Operating system
System memory
Hard disk
DVD Super Multi drive
(Double Layer)
● type : Intel® Centrino™ mobile technology including Intel® Pentium® M processor 750, Intel®
PRO/Wireless 2200BG network connection and Intel® 915PM Express chipset
● clock speed : 1.86 GHz
● front side bus : 533 MHz
● 2nd level cache : 2 MB
● Windows® XP Professional
● standard : 512 MB
● maximum expandability : 2,048 MB
● technology : DDR2 RAM
● capacity : 60 GB
● certification : S.M.A.R.T.
● compatibility : CD-ROM, CD-R, CD-RW, DVD-ROM, DVD-R, DVD-RW, DVD+R, DVD+RW,
DVD-RAM
● maximum speed : Read: 24x CD-ROM, 8x DVD-ROM/ Write: 24x CD-R, 4x CD-RW, 10x HS CD-
RW, 10x US CD-RW, 8x DVD-R, 2x DVD-R (Double Layer), 4x DVD-RW, 8x DVD+R, 2.4x DVD
+R (Double Layer), 4x DVD+RW, 5x DVD-RAM
● type : DVD Super Multi (+-R Double Layer) drive
Display
Graphics adapter
● size : 15.4 "
● type : Toshiba TruBrite WXGA TFT display
● manufacturer : ATI
● type : MOBILITY™ RADEON® X700
● memory amount : 256 MB
● connected bus : 16x PCI Express
Page 3
Internal video modes
● resolution : 1,280 x 800
● maximum number of colours : 16.7 million
Max. external video
modes
● max. resolution : 2,048 x 1,536
● max. colours : 16.7 Million
● max. refresh rate : 100 Hz
● non-interlaced resolution with max. refresh rate : 1,600 x 1,200
Battery
● technology : lithium-ion
● maximum life : 2:26 (Mobile Mark™) hours
AC adapter
● input voltage : autosensing AC adapter (100/240 V) for worldwide usage
Interfaces
● 1 x DC-in
● 1 x RJ-11
● 1 x RJ-45
● 1 x TV-out (s-video)
● 1 x i.LINK® (IEEE 1394)
● 1 x headphone (stereo)
● 3 (Rear 2, Left 1) x USB 2.0
● 1 x 5-in-1 Bridge Media slot (supports SD™ Card, Memory Stick®, Memory Stick Pro™,
MultiMedia Card™, xD-Picture Card™)
● 1 x microphone-in
Expansion
● 1 x PC Card slot for 1 Type II card
● 1 x ExpressCard slot
● 2 x memory slots (1 to configure, 1 service upgradeable)
Wireless
communication
● Compliancy : Wi-Fi™
● Network Support : 802.11b/g
● Wireless Technology : Wireless LAN
● Wireless Technology : Bluetooth™
Page 4
Wired communication
● topology : international V.90 modem, V.92 ready
● speed : 56 Kbps data (V.90) and 14.4 Kbps fax
● topology : Ethernet LAN
● speed : 10/100 Base-TX
Sound system
● supported audio format : 16-bit stereo
● speakers : built-in Harman Kardon® stereo speakers
Keyboard
● keys : 86
● Windows keys : 2
● inlaid numeric keypad : yes
● Hot Keys : 2
Physical dimensions
● W x L x H : 360 x 263 x 38,5 mm
● weight : 2,71 kg
Pointing device
● type : Touch Pad
● interface : PS/2
Warranty
● 2-year international warranty
Bundled hardware
● AC adapter
● AC Power Cable
● Quick start guide
● User manual
Bundled software
● Toshiba utilities and drivers
● on-line user's manual
● ConfigFree™
● Sonic¿ Record Now!
● InterVideo® WinDVD
● Norton Internet Security™ 2005 (90-day free trial version)
Page 5
Security features
● system password security
Special features
● Multimedia Bar with 6 Easy Keys (Internet Browser, CD-Contol, Rewind, Play, Stop, Forward)
CPU performance may vary from specifications under certain conditions such as the use of battery instead of AC power, certain
external peripherals, certain multimedia applications or network connections, complex modelling software and in areas with low air
pressure at high altitude (1,000 metres above sea level) and/or certain temperatures. CPU performance may also vary from
specifications due to design configuration. Under some conditions, your computer may automatically shut down as a normal
protective measure. To avoid risk of lost data, please make periodic back-up copies. For optimum performance, use your computer
only under recommended conditions. Please read detailed restrictions in the product resource guide, visit the Toshiba web site:
computers.toshiba-europe.com and/or contact Toshiba Technical Support.
Copyright © 2005 Toshiba Corporation. All rights reserved.
