Satellite M60
TOSHIBA Satellite M60 Series User’s Manual
Page 2
Copyright
© 2005 by TOSHIBA Corporation. All rights reserved. Under copyright law, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.
TOSHIBA Satellite M60 Series Portable Personal Computer User’s Manual First edition May 2005 Ownership and copyright of music, videos, computer programs, databases,
etc. are protected by the copyright laws. These copyrighted materials may be copied for private use at home only. If, beyond the limitation above, you copy (including to transform data formats) or modify these materials, transfer them or distribute them via the Internet without approval of copyright owners, you may be subject to claims for compensation for damage and/or criminal penalities due to infringements of copyrights or personal rights. Please remember to observe the copyright laws when you use this product to copy the copyrighted works or perform other actions. Please note that you may infringe the owner’s rights protected by the copyright laws if you use the screen mode switching functions (e.g.Wide mode, Wide Zoom mode, etc.) of this product to display enlarged images/ video at coffee shops or hotels for the purposes of profits or providing these to the public.
Disclaimer
This manual has been validated and reviewed for accuracy. The instructions and descriptions it contains are accurate for the Satellite M60 series Portable Personal Computers at the time of this manual’s production. However, succeeding computers and manuals are subject to change without notice. TOSHIBA assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manual.
Trademarks
IBM is a registered trademark and IBM PC, OS/2, and PS/2 are trademarks of International Business Machines Corporation.
Celeron, Intel, Intel SpeedStep, and Pentium are trademarks or registered trademarks of Intel Corporation.
MS-DOS, Microsoft, Windows and DirectX are registered trademarks of Microsoft Corporation.
Centronics is a registered trademark of Centronics Data Computer Corporation.
Photo CD is a trademark of Eastman Kodak. Bluetooth is a trademark owned by its proprietor and used by TOSHIBA
under license. iLINK is a trademark of Sony Corporation.
ii User’s Manual
Page 3
TruSurround XT, WOW XT, SRS and symbol are trademarks of SRS Labs, Inc.
TruSurround XT, WOW XT, TruBass, SRS 3D and FOCUS technologies are incorporated under license from SRS Labs, Inc.
Other trademarks and registered trademarks not listed above may be used in this manual.
Macrovision License of Notice
This product incorporates copyright protection technology that is protected by methods and claims of certain U.S. patents and other intellectual rights owned by Macrovision Corporation, and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation and is intended for home and other limited viewing uses only unless authorized by Macrovision Corporation. Reverse engineering of disassembly is prohibited.
Safety Instructions
Use the following safety guidelines to help protect yourself and your computer.
When Using Your Computer
Do not operate your portable computer for an extended period of time with the base resting directly on your body. With extended operation, heat can potentially build up in the base. Allowing sustained contact with the skin could cause discomfort or, eventually, a burn.
Do not attempt to service the computer yourself. Always follow
installation instructions closely.
Do not carry a battery in your pocket, purse, or other container where
metal objects (such as car keys) could short-circuit the battery terminals. The resulting excessive current flow can cause extremely high temperatures and may result in damage from burns.
Be sure that nothing rests on your AC adapter’s power cable and that
the cable is not located where it can be tripped over or stepped on.
Place the AC adapter in a ventilated area, such as a desk top or on the
floor, when you use it to run the computer or to charge the battery. Do not cover the AC adapter with papers or other items that will reduce cooling; also, do not use the AC adapter while it is inside a carrying case.
Use only the AC adapter and batteries that are approved for use with
this computer. Use of another type of battery or AC adapter may risk fire or explosion.
User’s Manual iii
Page 4
Before you connect the computer to a power source, ensure that the
voltage rating of the AC adapter matches that of the available power source.
115 V/60Hz in most of North and South America and some Far Eastern countries such as Taiwan.
100 V/50Hz in eastern Japan and 100 V/60Hz in western Japan. 230 V/50 Hz in most of Europe, the Middle East, and the Far East.
If you use an extension cable with your AC adapter, ensure that the total
ampere rating of the products plugged in to the extension cable does not exceed the ampere rating of the extension cable.
To help avoid the potential hazard of electric shock, do not connect or
disconnect any cables or perform maintenance or reconfiguration of this product during an electrical storm.
When setting up the computer for work, place it on a level surface.
Do not dispose of batteries in a fire. They may explode. Check with
local authorities for disposal instructions.
When traveling with the hard drive removed from the computer, wrap
the drive in a non-conducting material, such as cloth or paper. If you have the drive checked by hand, be ready to install the drive in the computer. Your can put the hard drive through an X-ray security machine, but never, put the drive through a metal detector.
When traveling with the hard drive removed from the computer, wrap
the drive in a non-conducting material, such as cloth or paper. If you have the drive checked by hand, be ready to install the drive in the computer. Your can put the hard drive through an X-ray security machine, but never, but the drive through a metal detector.
When traveling, do not place the computer in overhead storage
compartments where it could slide around. Do not drop your computer or subject it to other mechanical shocks.
Protect your computer, battery, and hard drive from environmental
hazards such as dirt, dust, food, liquids, temperature extremes, and overexposure to sunlight.
When you move your computer between environments with very
different temperature and/or humidity ranges, condensation may form on or within the computer. To avoid damaging the computer, allow sufficient time for the moisture to evaporate before using the computer.
When taking the computer from low-temperature conditions into a warmer environment or from high-temperature conditions into a cooler environments, allow the computer to acclimatize to room temperature before turning on power.
When you disconnect a cable, pull on its connector or on its strain relief
loop, not on the cable itself. As you pull out the connector, keep it evenly aligned to avoid bending any connector pins. Also, before you connect a cable make sure both connectors are correctly oriented and aligned.
iv User’s Manual
Page 5
Before you clean your computer, turn if off, unplug it from its power
source, and remove the battery.
Handle components with care. Hold a component such as a memory
module by its edges, not its pins.
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:
Do not use this product near water, for example, near a bathtub,
washing bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak.
Use only the power cord indicated in this manual.
Replace only with the same or equivalent type battery recommended by
the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
To reduce the risk of fire, use only No. 26 AWG or larger
telecommunication line cord.
Use only the battery pack that came with the computer or an equivalent optional battery pack. Use of the wrong battery could damage your computer.
TOSHIBA assumes no liability for any damage in such case.
EU Declaration of Conformity
This product is carrying the CE-Mark in accordance with the related European Directives. Responsible for CE-Marking is TOSHIBA Europe GmbH, Hammfelddamm 8, 41460 Neuss, Germany.
The complete and official EU Declaration of Conformity can be found on TOSHIBA’s web site http://epps.toshiba-te
User’s Manual v
g.com on the Internet.
Page 6
Optical Disc Drive Safety Instruction
Be sure to check the international precautions at the end of this section.
The optical drive that is used in this computer is equipped with a laser device. The classification label with the following sentence is affixed to the surface of the drive.
CLASS 1 LASER PRODUCT LASER KLASSE 1 LUOKAN 1 LASERLAITE APPAREIL A LASER DE CLASSE 1 KLASS 1 LASER APPARAT
The drive with the above label is certified by the manufacturer that the drive complies with the requirement for laser product on the date of manufacturing pursuant to article 21 of Code of Federal Regulations by the United States of America, Department of Health & Human Services, Food and Drug Administration.
In other countries, the drive is certified to comply with the requirement pursant to IEC 825 and EN60825 on class 1 laser product.
Depending on the model purchased, this computer is equipped with one of the optical drives from the following list:
Manufacturer Type
Panasonic Communications Co., LTD. CD-RW/DVD-ROM UJDA760
TOSHIBA Samsung Storage Technology
Hitachi LG Data Storage CD-RW/DVD-ROM GCC-4244
Panasonic Communications Co., LTD. DVD Super Multi UJ-840B
TOSHIBA Samsung Storage Technology.
TEAC DVD Super Multi DV-W28EA
vi User’s Manual
CD-RW/DVD-ROM TS-L462A
DVD Super Multi TS-L632B
Page 7
International precautions
This drive employs a laser system. To ensure proper use of this product,
please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.
Use of controls, adjustments or the performance of procedures other
than those specified may result in hazardous radiation exposure.
To prevent direct exposure to the laser beam, do not try to open the
enclosure.
Location of the required label
Sample shown below. Location of the label on the drive and manufacturing information may vary.
CAUTION: This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT.” To use this model properly, read the instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please contact your nearest “AUTHORIZED service station.” To prevent direct exposure to the laser beam, do not try to open the enclosure.
User’s Manual vii
Page 8
VORSICHT: Dieses Gerät enthält ein Laser­System und ist als “LASERSCHUTZKLASSE 1 PRODUKT” klassifiziert. Für den richtigen Gebrauch dieses Modells lesen Sie bitte die Bedienungsanleitung sorgfältig durch und bewahren diese bitte als Referenz auf. Falls Probleme mit diesem Modell auftreten, benachrichtigen Sie bitte die nächste “autorisierte Service-Vertretung”. Um einen direkten Kontakt mit dem Laserstrahl zu vermeiden darf das Gerät nicht geöffnet werden.
ADVARSEL: Denne mærking er anbragt udvendigt på apparatet og indikerer, at apparatet arbejder med laserstråler af klasse 1, hviket betyder, at der anvendes laserstrlier af svageste klasse, og at man ikke på apparatets yderside kan bilve udsat for utilladellg kraftig stråling.
APPARATET BOR KUN ÅBNES AF FAGFOLK MED SÆRLIGT KENDSKAB TIL APPARATER MED LASERSTRÅLER!
Indvendigt i apparatet er anbragt den her gengivne advarselsmækning, som advarer imod at foretage sådanne indgreb i apparatet, at man kan komme til at udsætte sig for laserstråling.
OBS! Apparaten innehåller laserkomponent som avger laserstråining överstigande gränsen för laserklass 1.
VAR OITU S. Suojakoteloa si saa avata. Laite sisältää laserdiodin, joka lähetää näkymätöntä silmilie vaarallista lasersäteilyä.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED IN THE OWNER’S MANUAL MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
VORSICHT: DIE VERWENDUNG VON ANDEREN STEURUNGEN ODER EINSTELLUNGEN ODER DAS DURCHFÜHREN VON ANDEREN VORGÄNGEN ALS IN DER BEDIENUNGSANLEITUNG BESCHRIEBEN KÖNNEN GEFÄHRLICHE STRAHLENEXPOSITIONEN ZUR FOLGE HABEN.
viii User’s Manual
Page 9
Modem warning notice
Conformity Statement
The equipment has been approved to [Commission Decision “CTR21”] for pan- European single terminal connection to the Public Switched Telephone Network (PSTN).
However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.
In the event of problems, you should contact your equipment supplier in the first instance.
Network Compatibility Statement
This product is designed to work with, and is compatible with the following networks. It has been tested to and found to confirm with the additional requirements conditional in EG 201 121.
Germany ATAAB AN005,AN006,AN007,AN009,AN010
Greece ATAAB AN005,AN006 and GR01,02,03,04
and DE03,04,05,08,09,12,14,17
Portugal ATAAB AN001,005,006,007,011 and
Spain ATAAB AN005,007,012, and ES01
Switzerland ATAAB AN002
Norway ATAAB AN002,005,007 and NO 01, 02
All other countries/ regions
Specific switch settings or software setup are required for each network, please refer to the relevant sections of the user guide for more details.
The hookflash (timed break register recall) function is subject to separate national type approvals. It has not been tested for conformity to national type regulations, and no guarantee of successful operation of that specific function on specific national networks can be given.
User’s Manual ix
P03,04,08,10
ATAAB AN003,004
Page 10

General Precautions

TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer.
Be certain to read the general precautions below and to note the cautions included in the text of the manual.
Stress injury
Carefully read the Instruction Manual for Safety and Comfort. It contains information on prevention of stress injuries to your hands and wrists that can be caused by extensive keyboard use. Chapter 3, Getting Started, also includes information on work space design, posture and lighting that can help reduce physical stress.
Heat injury
Avoid prolonged physical contact with the bottom of the computer. If the
computer is used for long periods, its surface can become very warm. While the temperature will not feel hot to the touch, if you maintain physical contact with the computer for a long time (if you rest the computer on your lap, for example) your skin might suffer low-heat injury.
If the computer has been used for a long time, avoid direct contact with
the metal plate supporting the I/O ports. It can become hot.
The surface of the AC adapter can become hot when in use. This
condition does not indicate a malfunction. If you need to transport the AC adapter, disconnect it and let it cool before moving it.
Do not lay the AC adapter on a material that is sensitive to heat. The
material could be damaged.
Pressure or impact damage
Do not apply heavy pressure to the computer or subject it to strong impact. Excessive pressure or impact can damage computer components or
otherwise cause malfunctions.
PC Card overheating
Some PC Cards can become hot with prolonged use. Overheating of a PC Card can result in errors or instability in the PC Card operation. Also be careful when you remove a PC Card that has been used for a long time.
Mobile phones
Use of mobile phones can interfere with the audio system. Computer operation is not impaired but it is recommended that a distance of 30cm be maintained between the computer and a mobile phone in use.
x User’s Manual
Page 11
LCD
Over a period of time, and depending on the usage of the computer, the brightness of the LCD screen will deteriorate. This is an intrinsic characteristic of LCD technology. Maximum brightness is only available when operating in AC power mode. Screen will dim when the computer is operated on battery power and you may not be able to increase the brightness of the screen.
Central Processing Unit (“CPU”) Performance Disclaimer:
CPU performance in your computer product may vary from specifications under the following conditions:
use of certain external peripheral products
use of battery power instead of AC power
use of certain multimedia, computer generated graphics or video
applications
use of standard telephone lines or low speed network connections
use of complex modeling software, such as high end computer aided
design applications
use of several applications or functionalities simultaneously
use of computer in areas with low air pressure
(high altitude > 1,000 meters or > 3,280 feet above sea level)
use of computer at temperatures outside the range of 5 ºC to 30 ºC
(41ºF to 86 ºF) or > 25 ºC (77 ºF) at high altitude (all temperature references are approximate and may vary depending on the specific computer model)
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down.
This is a normal protective feature designed to reduce the risk of lost data or damage to the product when used outside recommended conditions.
To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your appendix A. Contact Toshiba Technical Service and Support for more information.
Graphics Processing Unit (“GPU”) Performance Disclaimer:
The graphics processing unit (“GPU”) performance may vary depending on product model, design configuration, applications, power management settings and features utilized.
GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
User’s Manual xi
Page 12
Main Memory Disclaimer
The graphics system in your computer may use part of the main system memory for graphics performance and therefore reduce the amount of system memory available for other computing activities. The amount of system memory allocated to support graphics may vary depending on the graphics system, applications utilized, system memory size and other factors.
Copy Protection
Copy protection technology included in certain media may prevent or limit recording or viewing of the media.
Hard Disk Drive Capacity
1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft Windows software applications, or media content. Actual formatted capacity may vary.
®
Operating System and/or pre-installed
Non-applicable Icons
Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your selected model may not have all the features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have selected all those features.
Wireless LAN/Atheros
The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the theoretical maximum speed.
To use the Atheros SuperAG™ or SuperG™ function, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format of data transmitted.
SRS
SRS TruSurround XT is available in the Microsoft Windows® operating system only.
Images
All images are simulated for purposes of illustration.
xii User’s Manual
Page 13
Express Media Player
The Express Media Player is not a Windows® operating system-based application. Battery life will be less than when using similar applications in the Windows
®
Operating System.
LCD Brightness and Eye Strain
Your LCD display has a brightness approaching that of a TV device. We recommend that you adjust the brightness of your LCD to a comfortable level to prevent possible strain on your eyes.
CE compliance
This product and the original options are designed to observe the related EMC (Electromagnetic Compatibility) and safety standards. However, TOSHIBA cannot guarantee that this product still observes these EMC standards if options or cables not produced by TOSHIBA are connected or implemented. In this case the persons who have connected / implemented those options / cables have to provide assurance that the system (PC plus options / cables) still fulfils the required standards. To avoid general EMC problems, the following guidance should be noted:
Only CE marked options should be connected / implemented
Only best shielded cables should be connected
Working environment
This product was designed to fulfill the EMC (Electromagnetic Compatibility) requirements to be observed for so-called “Residential, commercial and light industry environments”.
TOSHIBA do not approve the use of this product in working environments other than the above mentioned “Residential, commercial and light industry environments”.
For example, the following environments are not approved:
Industrial Environments (environments with a mains voltage >230V~)
Medical Environments
Automotive Environments
Aircraft Environments
If this product is supplied with a network port, please refer to the paragraph “Network connection”.
Any consequences resulting from the use of this product in working environments that are not approved are not the responsibility of TOSHIBA Europe GmbH.
User’s Manual xiii
Page 14
The consequences of the use of this product in non-approved working environments may be:
Interference with other devices or machines in the near surrounding
area
Malfunction of, or data loss from, this product caused by disturbances
generated by other devices or machines in the near surrounding area
Therefore TOSHIBA strongly recommend that the electromagnetic compatibility of this product should be suitably tested in all non-approved working environments before use. In the case of automobiles or aircraft, the manufacturer or airline respectively should be asked for permission before use of this product.
Furthermore, for general safety reasons, the use of this product in environments with explosive atmospheres is not permitted.
Information on the secure writing of optical disc
Even if your software gives no indication that any problems have occurred, you should always check to ensure that information has been successfully stored on recordable optical disc (CD-R, CD-RW and so forth).

Wireless LAN and your Health

Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by Wireless LAN devices however is far less than the electromagnetic energy emitted by other wireless devices such as mobile phones.
Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.
In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building or responsible representatives of the organisation. These situations may for example include:
Using the Wireless LAN equipment on board of aeroplanes.
In any other environment where the risk of interference to other devices
or services is perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a specific organisation or environment (e.g. airports), you are encouraged to ask for authorisation to use the Wireless LAN device prior to turning on the equipment.
xiv User’s Manual
Page 15
Safety Instruction for Wireless Products
If your computer has a wireless function, all safety instructions must be read carefully and must be fully understood, before you attempt to use it. This manual contains the safety instructions that must be observed in order to avoid potential hazards that could result in personal injuries or could damage your Wireless Products.
Limitation of Liability
For damage occurring due to an earthquake or thunder, fire beyond our responsibility, action by third party, other accident, intentional or accidental mistakes by a user, misuse, use under abnormal conditions, we do not take any responsibility.
For incidental damage (loss of business profit, business interruption, etc.) occurring due to use or disability of the product, we do not take any responsibility.
For damage occurring due to non observance of the contents described in the instruction manual, we do not take any responsibility.
For damage occurring due to erroneous operation or hang up caused by use in combination with products not related to our company, we do not take any responsibility.
Usage Restrictions
Do not use the Wireless Products for controlling the following equipment:
Equipment directly linked with human life corresponding to the
following.
Medical equipment such as life support systems, equipment used in
operations, etc.
Exhaust systems for gases such as poisonous gas etc. and exhaust
systems for smoke.
Equipment that must be set up in compliance with various laws such
as the Fire Services Act, the Construction Standard Act, etc.
Equipment corresponding to that mentioned above.
Equipment linked with human safety or having a serious influence on
the safe maintenance of public function, etc., because it is not designed or manufactured for this type of use.
Traffic control equipment for air, railroad, road, marine transport, etc.
Equipment used in atomic power plants etc.
Equipment corresponding to that mentioned above.
User’s Manual xv
Page 16
Warning
Turn OFF the Wireless Communication switch of Wireless Products in a congested place, such as a crowded commuter train.
Keep this product at least 22cm away from a cardiac pacemaker. Radio waves can potentially affect cardiac pacemaker operation, thereby
causing respiratory troubles. Turn OFF the Wireless communication switch inside a medical facility or
near medical electric equipment. Do not bring medical electric equipment close to the product.
Radio waves can potentially affect medical electric equipment, thereby causing an accident due to malfunction.
Turn OFF the Wireless communication switch near an automatic door, fire alarm or other automatic control equipment.
Radio waves can potentially affect automatic control equipment, thereby causing an accident due to malfunction.
Do not turn ON the Wireless Communication switch in aircraft or in places that generate or can generate radio interference.
Radio waves can potentially affect them, causing an accident due to malfunction.
Monitor possible radio interference or other issues with other equipment while the product is used. If any effect is caused, turn OFF the Wireless Communication switch.
Radio waves can potentially affect other equipment, thereby causing an accident due to malfunction.
When using the product in a car, check with the automobile dealer if the car has an adequate electromagnetic compatibility (EMC).
Radio waves of the product can potentially hamper safe driving. Depending on the model, the product may rarely affect the car's electronic
equipment if it is used in a car.
Note
Do not use this product in the following places: Near a microwave oven or other environment which generates a magnetic
field. Near any place or equipment that generates static electricity or radio
interference. Depending on the environment, in a place where radio waves cannot reach
the product.
xvi User’s Manual
Page 17
Satellite M60

Table of Contents

General Precautions
Wireless LAN and your Health. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
Preface
Manual contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi
Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii
Chapter 1 : Introduction
Equipment checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Special features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Chapter 2 : The Grand Tour
Front with the display closed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Left side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Right side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Back side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Underside. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Front with the display open . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Keyboard Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Optical Disc drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Chapter 3 : Getting Started
Setting up your work space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Connecting the AC adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Opening the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Turning on the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Starting up for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Turning off the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Restarting the computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Restoring the preinstalled software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
User’s Manual xvii
Page 18
Chapter 4 : Operating Basics
Using the TouchPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Using the internal modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7
Using optical disc drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Express Media Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13
Writing CDs on a CD-RW/DVD-ROM drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-17
Writing CDs/DVDs on a DVD Super Multi drive supporting
double layer disc recording. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-19
Media Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-23
Diskettes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-23
TV-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-24
Setting up more than one display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-24
Cleaning the computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-25
Moving the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-25
Chapter 5 : The Keyboard
Typewriter keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
F1 ... F12 function keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Soft keys: Fn key combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Hotkeys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Windows special keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Desktop-style Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
Chapter 6 : Power and Power-Up Modes
Power conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Power indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Battery types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Care and use of the battery pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Replacing the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
TOSHIBA Password Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
Power-up modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-13
Panel power off/on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-13
System automatic Standby/Hibernation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-13
Chapter 7 : HW Setup
Accessing HW Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
HW Setup Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
xviii User’s Manual
Page 19
Chapter 8 : Optional Devices
PC Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
ExpressCard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
SD/MMC/MS/MS Pro/xD Memory cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Memory expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Additional battery pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
Additional AC adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
External monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
Television . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
i.LINK (IEEE1394) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19
Security lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-20
Chapter 9 : Troubleshooting
Problem solving process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Hardware and system checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
TOSHIBA support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
Appendix A : Specifications
Appendix B : Display Modes
Appendix C : AC Power Cord and Connectors
Appendix D : If your computer is stolen
Glossary
User’s Manual xix
Page 20
xx User’s Manual
Page 21
Satellite M60

Preface

Congratulations on your purchase of the Satellite M60 computer. This powerful notebook computer provides excellent expansion capability, including multimedia devices, and it is designed to provide years of reliable, high-performance computing.
This manual tells how to set up and begin using your Satellite M60 computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.
If you are a new user of computers or if you’re new to portable computing, first read over the Satellite M60 Features and The Grand Tour chapters to familiarize yourself with the computer’s features, components and accessory devices. Then read Getting Started for step-by-step instructions on setting up your computer.
If you are an experienced computer user, please continue reading the preface to learn how this manual is organized, then become acquainted with this manual by browsing through its pages. Be sure to look over the Special features section of the Satellite M60 Features, to learn about features that are uncommon or unique to the computer.

Manual contents

This manual has nine chapters, four appendixes, a glossary and an index. Chapter 1, Introduction, is an overview of the computer’s special features,
utilities, and options. Chapter 2, The Grand Tour, identifies the components of the computer and
briefly explains how they function. Chapter 3, Getting Started, provides a quick overview of how to begin
operating your computer and gives tips on safety and designing your work area. Be sure to read the sections on setting up the operating system and on restoring the preinstalled software.
Chapter 4, Operating Basics, includes instructions on using the following devices: TouchPad, the optical disc drives, the internal modem, LAN and wireless LAN. It also provides tips on care of the computer, diskettes and DVD/CD-ROMs.
User’s Manual xxi
Page 22
Preface
Chapter 5, The Keyboard, describes special keyboard functions including the keypad overlay and hotkeys.
Chapter 6, Power and Power-Up Modes, gives details on the computer’s power resources.
Chapter 7, HW Setup, introduces you to the TOSHIBA Hardware Setup program.
Chapter 8, Optional Devices, describes the optional hardware available. Chapter 9, Troubleshooting, provides helpful information on how to perform
some diagnostic tests, and suggests courses of action if the computer doesn’t seem to be working properly.
The Appendices provide technical information about your computer. The Glossary defines general computer terminology and includes a list of
acronyms used in the text.

Conventions

This manual uses the following formats to describe, identify, and highlight terms and operating procedures.
Abbreviations
On first appearance, and whenever necessary for clarity, abbreviations are enclosed in parentheses following their definition. For example: Read Only Memory (ROM). Acronyms are also defined in the Glossary.
Icons
Icons identify ports, dials, and other parts of your computer. The indicator panel also uses icons to identify the components it is providing information on.
Keys
The keyboard keys are used in the text to describe many computer operations. A distinctive typeface identifies the key top symbols as they appear on the keyboard. For example, Enter identifies the Enter key.
Key operation
Some operations require you to simultaneously use two or more keys. We identify such operations by the key top symbols separated by a plus sign (+). For example, Ctrl + C means you must hold down Ctrl and at the same time press C. If three keys are used, hold down the first two and at the same time press the third.
DISKCOPY A: B: When procedures require an action such as
xxii User’s Manual
clicking an icon or entering text, the icon’s name or the text you are to type in is represented in the type face you see to the left.
Page 23
Display
Names of windows or icons or text generated by the computer that appears on its display screen is presented in the type face you see to the left.
ABC
Messages
Messages are used in this manual to bring important information to your attention. Each type of message is identified as shown below.
Pay attention! A caution informs you that improper use of equipment or failure to follow instructions may cause data loss or damage your equipment.
Please read. A note is a hint or advice that helps you make best use of your equipment.
Preface
User’s Manual xxiii
Page 24
Preface
xxiv User’s Manual
Page 25
Satellite M60
Introduction
This chapter provides an equipment checklist, and it identifies the computer’s features, options and accessories.
Some of the features described in this manual may not function properly if you use an operating system that was not preinstalled by TOSHIBA.

Equipment checklist

Carefully unpack your computer. Save the box and packing materials for future use. Check to make sure you have all the following items:
Hardware
Satellite M60 Series Portable Personal Computer
Universal AC Adapter and Power Cord
Modular cable for modem (optional)
Chapter 1
User’s Manual 1-1
Page 26
Introduction
Software
Microsoft® Windows® XP Home Edition Service Pack2
The following software preinstalled on your hard disk:
®
Microsoft
Windows® XP Home Edition
DVD Video Player
TOSHIBA Power Saver Utility
TOSHIBA Assist
TOSHIBA TouchPad On/Off Utility
TOSHIBA Accessibility Utility
TOSHIBA Controls
TOSHIBA HW Setup Utility
TOSHIBA PC Diagnostic Tool
TOSHIBA Touch and Launch
TOSHIBA Zooming Utility
TOSHIBA SD Memory Card Format
TOSHIBA Acoustic Silencer
TOSHIBA Virtual Sound
TOSHIBA Hotkey Utility
WinDVD Creator
Online Manual
Display Driver
TouchPad driver
Sound driver
Modem driver
LAN driver
Wireless LAN driver
The system may not function properly if you use drivers that are not preinstalled or distributed by TOSHIBA.
Documentation and Backup Media
Your computer’s documentation:
Satellite M60 Series Personal Computer User’s Manual
Satellite M60 Quickstart
Instruction Manual for Safety and Comfort
Warranty information
Product Recovery DVD-ROM
If any of the items are missing or damaged, contact your dealer immediately.
1-2 User’s Manual
Page 27

Features

Introduction
The Satellite M60 Series computer uses TOSHIBA’s advanced Large Scale Integration (LSI), Complementary Metal-Oxide Semiconductor (CMOS) technology extensively to provide compact size, minimum weight, low power usage, and high reliability. This computer incorporates the following features and benefits:
Processor
Depending on the model you purchased:
®
Celeron® M Processor 350 or higher
Intel Intel® Pentium® M Processor 730 or higher Other processors may be introduced in the
future.
Chip Set
Mobile Intel® 915PM Express Chipset (400/533 MHz FSB supported) for external graphics controller
®
Mobile Intel (400/533 MHz FSB supported) for integrated graphics controller
(Chipset depends on the model you purchased) ATI MOB ILI TY™ RADEON ATI MOB ILI TY™ RADEON® X700 NVIDIA (GPU depends on the models you purchased.) ENE KB910 for Keyboard Controller, Battery
management Unit, and RTC. ENE CB714 controller with Multiple Digital Media
Card Slot support IEEE 1394 controller ALC250 for AC97 CODEC. Realtek RTL8100CL for 10M/100M LAN or
RTL8110SBL for Gigabit LAN
910GML/915GM Express Chipset
®
X600SE
®
GeForce™ GO 6600
User’s Manual 1-3
Page 28
Introduction
Memory
Main Memory Disclaimer
The graphics system in your computer may use part of the main system memory for graphics performance and therefore reduce the amount of system memory available for other computing activities. The amount of system memory allocated to support graphics may vary depending on the graphics system, applications utilized, system memory size and other factors.
Slot 256, 512 or 1,024 MB memory modules can be
installed in the two main memory slots for a maximum of 2,048 MB of system memory.
L2 Cache
1 MB L2 Cache (Intel 2 MB L2 Cache (Intel
®
Celeron® M Processor)
®
Pentium® M Processor)
Video RAM Depending on the model you purchased:
Up to 128MB integrated solution and shared with main memory for Mobile Intel
®
915GM/910GML
Express Chipset ATI MOBILITY™ RADEON
®
X600SE+64/128MB
VRAM with 128 bit bus ATI MOBILITY™ RADEON® X700+64/128/
256MB VRAM with 128 bit bus
®
NVIDIA
GeForce™ GO 6600+128/256MB
VRAM with 128 bit bus
BIOS
1 MB Flash ROM for system BIOS Suspend to RAM/Hard Disk Drive Password protection (System) Various hot key for system control Refreshable Complete ACPI 1.0b Function
1-4 User’s Manual
Page 29
Power
Introduction
Battery Pack 8-cell Lithium Ion smart battery pack with
RTC Battery The internal RTC battery backs up the Real Time
AC adapter The universal AC adapter provides power to the
14.8V / 4300mAh capacity Approximately 4-12 hours or longer charge time
to 100% battery capacity with the system on Approximately 4 hours charge time to 100%
battery capacity with the system off Discharge time in shutdown mode is
approximately 1 month
Clock (RTC) and calendar.
system and recharges the batteries when they are low. It comes with a detachable power cord.
TouchPad
A TouchPad and control buttons in the palm rest enable control of the on-screen pointer.
Display
17" TFT screen with a resolution of 1440 horizontal x 900 vertical pixels WXGA
17" High Brightness TFT screen with a resolution of 1440 horizontal x 900 vertical pixels WXGA
17" TFT screen with a resolution of 1680 horizontal x 1050 vertical pixels WSXGA+
Disks
Fixed hard disk Available in five sizes.
40.0 billion bytes (37.26GB)
60.0 billion bytes (55.88GB)
80.0 billion bytes (74.52GB)
100.0 billion bytes (93.16GB)
120.0 billion bytes (111.78GB) Bus Master IDE
9.5m/m 2.5" hard disk drive support Ultra DMA 100
User’s Manual 1-5
Page 30
Introduction
CD-RW/DVD-ROM drive
DVD Super Multi drive (Supporting Double Layer)
Some models are equipped with a full- size CD-RW/DVD-ROM module that lets you record data to rewritable CD/CD-RWs as well as run either 12cm (4.72”) or 8cm (3.15”) CD/DVDs without using an adapter. It reads DVD-ROMs at maximum 8 speed and CD-ROMs at maximum 24 speed. It writes CD-R at up to 24 speed, CD-RW at up to 24 speed. This drive supports the following formats:
DVD-ROM DVD-Video
DVD-R DVD-RW
CD-R CD-RW
CD-DA CD-Text
DVD-RAM
Photo CD (single/multi-session)
CD-ROM Mode1, Mode2
CD-ROMXA Mode2 (Form1, Form2)
Enhanced CD(CD-EXTRA)
Some models are equipped with a full- size DVD Super Multi Drive module that lets you record data to rewritable CD/DVDs as well as run either 12cm (4.72") or 8cm (3.15") CD/DVDs without using an adaptor. It reads DVD-ROMs at maximum 8 speed and CD-ROMs at maximum 24 speed. It writes CD-R at up to 24 speed, CD-RW at up to 10 speed, DVD-R at maximum 8 speed, DVD-RW at maximum 4 speed, DVD+R at maximum 8 speed, DVD+RW at maximum 4 speed DVD+R DL at maximum
2.4 speed, and DVD-RAM at maximum 5 speed. This drive supports the following formats:
DVD-ROM DVD-Video
DVD-R DVD-RW
DVD+R DVD+RW
DVD+R DL CD-Text
CD-DA CD-RW
CD-R DVD-RAM
Photo CD (single/multi-session)
CD-ROM Mode1, Mode2
CD-ROMXA Mode2 (Form1, Form2)
Enhanced CD (CD-EXTRA)
1-6 User’s Manual
Page 31
Introduction
Slots
PC Card Accommodates one type II device.
ExpressCard This slot allows you to insert an Express Card
device which is a small, modular add-in card technology based on the PCI Express and Universal Serial Bus (USB) interfaces. The maximum transmission rate is 2.5Gbps and both 34mm and 54mm types are supported.
Multiple Digital Media Card (SD/ MMC/MS/MS Pro/xD)
This slot lets you easily transfer data from devices, such as digital cameras and Personal Digital Assistants, that use flash-memory.
Ports
External monitor 15-pin analog VGA port supports VESA DDC2B
compatible functions.
Universal Serial Bus The computer has three Universal Serial Bus
(USB) ports that comply with the USB 2.0 standard, which enables data transfer speeds more than 40 times faster than USB 1.1 (which this computer also supports.) The USB ports may be used to transfer data at Low, Full, and High speeds.
i.LINK (IEEE1394) This port enables high-speed data transfer
directly from external devices such as digital video cameras.
TV Out The 4-pin S-Video port is compatible with PAL or
NTSC TV standards, supporting Macrovision
7.02 copy protection.
Multimedia
Sound system
Windows system provides internal speakers as well as jacks for an external microphone and headphones.
Express Media Player
Let you use the computer’s fixed optical disc drive as a stand-alone audio CD-player/DVD player.
Headphone jack A standard 3.5mm headphone jack
®
Operating System compatible sound
User’s Manual 1-7
Page 32
Introduction
Microphone jack A standard 3.5 mm mini microphone jack enables
connection of monaural microphone input.
Control Buttons Two programmable buttons (one set by default to
Internet and which opens your web browser, and one set by default to open Windows Media Player), and four multimedia keys for controlling CD/DVD and/or digital media file playback.
Communications
Modem An internal modem provides capability for data
and fax communication. It supports V.90 or V.92 depending on the region. The speed of data and fax transfer depends on analog telephone line conditions. It has a modem jack for connecting to a telephone line.
LAN The computer has built-in support for Ethernet
Wireless LAN (depends on the model you purchased)
Bluetooth (depends on the model you purchased)
LAN (10 megabits per second, 10BASE-T), Fast Ethernet LAN (100 megabits per second 100BASE-TX), or Gigabit Ethernet LAN (1000megabits per second, 1000BASE-T).
Some computers in this series are equipped with a wireless LAN mini-PCI card that is compatible with other LAN systems that support either the
802.11a/b/g or 802.11b/g wireless standards. It has a Frequency Channel Selection (2.4 or 5 GHz) and allows roaming over multiple channels.
Bluetooth is a short-range wireless technology used to create PANs (Personal Area Networks) among your devices, and with other nearby devices like mobile computers, mobile phones, and digital cameras.
Security
Boot-up password protection Two level password architecture
Security Lock Slot
Receives an optional security lock in order to anchor the computer to a desk or other large, heavy object.
1-8 User’s Manual
Page 33

Special features

The following features are either unique to TOSHIBA computers or are advanced features, which make the computer more convenient to use.
Hotkeys Key combinations let you quickly modify the
Introduction
system configuration directly from the keyboard without running a system configuration program.
Display Automatic Power off
Hard Disk Drive Automatic Power Off
System Automatic Standby/Hibernation
Power-on Password Two levels of password security are available:
Battery Save Mode This feature lets you save battery power. You can
Instant Security A hotkey function blanks the screen providing
Panel Power Off/On This feature turns power to the computer off
This feature automatically cuts off power to the internal display when there is no input from the keyboard or pointing device for a specified time period. Power is restored when any key is pressed or when there is input from a pointing device. You can specify the time in the TOSHIBA Power Saver utility.
This feature automatically cuts off power to the hard disk drive when it is not accessed for a specified time period. Power is restored when the hard disk is accessed. You can specify the time in the TOSHIBA Power Saver utility.
This feature automatically places the system into Standby Mode or Hibernation Mode when there is no input or hardware access for a specified time period. You can specify the time and select either System Standby or System Hibernate in the TOSHIBA Power Saver utility.
supervisor and user. This feature prevents unauthorized access to your computer.
specify the settings for Battery Save Mode in the TOSHIBA Power Saver utility.
quick and easy data security.
when the display panel is closed and turns it back on when the panel is opened. You can specify the setting in the TOSHIBA Power Saver utility.
Low Battery Automatic Hibernation
User’s Manual 1-9
When battery power is exhausted to the point that computer operation cannot be continued, the system automatically enters Hibernation Mode and shuts down. You can specify the setting in the TOSHIBA Power Saver utility.
Page 34
Introduction
Hibernation This feature lets you turn off the power without
exiting from your software. The contents of main memory are saved to the hard disk. When you turn on the power again, you can continue working right where you left off. Refer to the Turning off the power section in Chapter 3, Getting Started, for details.

Utilities

Standby In Standby mode, power to the system remains
on, but the CPU and all other devices are in sleep mode. When the computer is in standby mode, the Power LED flashes in amber. The computer enters Standby mode regardless of the Hibernate setting. Refer to the Turning off the power section in Chapter 3, Getting Started, for details.
Before entering Standby mode, be sure to save your data.
Do not install or remove a memory module while the computer is in
Standby mode. The computer or the module could be damaged.
Do not remove the battery pack while the computer is in Standby mode.
Data in memory will be lost.
This section describes preinstalled utilities and tells how to start them. For details on operations, refer to each utility’s online manual, help files or readme files.
TOSHIBA Power Saver
There are two ways to display the Windows Control Panel. The default is Category View.
®
XP
TOSHIBA Power Saver is under the Performance and Maintenance item.
TOSHIBA Controls This utility allows you to perform the following two
functions:
Buttons
Assign applications or functions to the Internet button and the CD/DVD button.
The default settings are to launch the default Internet browser and the Windows Media Player respectively.
Media Apps
Select the application for audio and video playback.
1-10 User’s Manual
Page 35
Introduction
DVD Player The DVD Video Player is used to play
DVD-Video. It has an on-screen interface and functions. Click Start, point to All Programs, point to InterVideo WinDVD then click InterVideo WinDVD.
ConfigFree ConfigFree is a suite of utilities to allow easy
control of communication device and network connections. ConfigFree also allows you to find communication problems and create profiles for easy switching between location and communication networks.
To start ConfigFree, click the Windows Start Button, point to All Programs, point to TOSHIBA, point to Networking and click ConfigFree.
TOSHIBA TouchPad On/Off Utility
Pressing Fn+F9 in a Windows System environment enables or disables the
®
Operating
TouchPad function. When you press these hot keys, the current setting will change and be displayed as an icon.
RecordNow! Basic for TOSHIBA
You can create CD/DVDs in several formats including audio CDs that can be played on a standard stereo CD player and data CD/DVDs to store the files and folders on your hard disk drive. This software can be used on models with either a DVD-ROM/CD-R/RW drive or a DVD Super Multi drive.
DLA for TOSHIBA DLA (Drive Letter Access) is the packet writing
software which provides the function to write files and/or folders to DVD+RW, DVD-RW or CD-RW discs via a drive letter like a floppy disk or other removable disks.
TOSHIBA Touch and Launch
TOSHIBA Touch and Launch is a tool that allows you to perform various tasks easily using the Touch Pad. It is useful in the following conditions.
To open a file located on the desktop whose
icon is obscured by a window.
To open a page contained in the Internet
Explorer Favorites menu.
To display the list of currently open windows
and change the active window.It also provides the following functions by customizing the settings.
To open a file stored in a predefined folder.
To quickly launch your frequently used
applications which have been registered.
User’s Manual 1-11
Page 36
Introduction

Options

TOSHIBA Zooming Utility
TOSHIBA Assist TOSHIBA Assist is a graphical user interface that
TOSHIBA HW Setup This program lets you customize your hardware
TOSHIBA Accessibility
CD/DVD Drive Acoustic Silencer
You can add a number of options to make your computer even more powerful and convenient to use. The following options are available:
This utility allows you to enlarge or reduce the icon size on the desktop or the application window.
provides easy access to help and services.
settings according to the way you work with your computer and the peripherals you use. To start the utility, click Start, click Control Panel, click
Printers and Other Hardware and select the TOSHIBA HW Setup icon.
This utility lets you make the Fn key sticky, that is, you can press it once, release it, and then press an “F number” key. The Fn key remains active until another key is pressed.
This utility allow you to set the read speed of the CD/DVD drive.
You can either set Normal Mode to run the drive at its fastest speed to read data early, or Quiet Mode to lessen operating noise.
Memory Modules Two memory modules can be installed in this
Use only DDRII-533MHz compatible memory modules. See your TOSHIBA dealer for details.
Battery Pack An additional battery pack can be purchased
AC adapter If you use your computer at more than one site
USB Floppy Disk Drive Kit
1-12 User’s Manual
computer.
from your TOSHIBA dealer. Use it as a spare to increase your computer operating time.
frequently, it may be convenient to purchase an additional AC adapter for each site so you will not have to carry the adapter with you.
Lets you attach a floppy disk drive to your computer by means of a USB cable.
Page 37
Satellite M60
The Grand Tour
This chapter identifies the various components of your computer. Become familiar with each component before you operate the computer.
Certain types of notebook chassis are designed to accommodate all possible configurations for an entire product series. Your selected model may not have all the features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have selected all those features.

Front with the display closed

The following figure shows the computer front with its display panel in the closed position.
Chapter 2
p
r
1.Microphone Jack
2.Headphone Jack
3.Volume Control
Front of the computer with display closed
Microphone Jack The standard 3.5 mm mini microphone jack
Headphone Jack The headphone jack lets you connect stereo
User’s Manual 2-1
o
n
4.Multiple Digital Media Card Slot
5.Left and Right Speakers
enables connection of a three conductive type mini-jack for a monaural microphone.
headphones or other audio output devices such as external speakers with a power amplifier. Connecting headphones or other devices to this jack automatically disables the internal speakers.
q
r
Page 38
The Grand Tour
Volume Control Use this dial to adjust the volume of the stereo
speakers or headphones.

Left side

Multiple Digital Media Card Slot
Left and Right Speakers
The following figure shows the computer’s left side.
Optical Disc Drive The computer is configured with a full-size optical
Optical Disc Drive LED
The Multiple Digital Media Card Slot allows you to use media cards from digital still cameras and various forms of portable information equipment.
The audio speakers.
n
1. Optical Disc Drive 2. Optical Disc Drive LED
The left side of the computer
disc drive module that lets you run either 12 cm (4.72") or 8 cm (3.15") discs without using an adapter. See the Drives section in this chapter for technical specifications on each drive and Chapter 4, Operating Basics, for information on using the drive and caring for discs.
This indicator lights when the Optical Disc Drive is being accessed.
o
2-2 User’s Manual
Page 39

Right side

The following figure shows the computer's right side.
* This feature is available depending the model you purchased.
PC Card Slot The PC Card slot can accommodate one 5 mm PC
ExpressCard Slot
i .LINK (IEEE1394) Port
Wireless Communication Switch
Wireless Communication LED
Universal Serial Bus (USB) Port
Modem Jack The modem jack lets you use a modular cable to
n
o
1.PC card slot
2.ExpressCard Slot
3.i.Link (IEEE1394) Port
4.Wireless Communication Switch*
The right side of the computer
Card (Type II). You can install any industry standard PC Card such as a SCSI adapter, Ethernet adapter or flash memory card.
This slot allows you to insert an Express Card device which is a small, modular add-in card technology based on the PCI Express and Universal Serial Bus (USB) interfaces. The maximum transmission rate is
2.5 Gbps and both 34 mm and 54 mm types are supported.
This feature may not be present, depending on your configuration.
This feature may not be present, depending on your configuration. This feature may not be present, depending on your configuration.
The wireless communication switch turns on the wireless networking transceiver. The Wireless
Communication LED beside it indicates that wireless networking is turned on.
This feature may not be present, depending on your configuration.
Indicates whether wireless LAN or Bluetooth is active or not.
This feature may not be present, depending on your configuration.
The Universal Serial Bus (USB 2.0 and 1.1) port enables USB-equipped devices (such as keyboards, mice, hard drives, scanners, and printers) to be connected to the computer.
connect the modem directly to a telephone line.
The Grand Tour
q
5.Wireless Communication LED*
p
6.Universal Serial Bus (USB) Port
7.Modem Jack
r
s
t
User’s Manual 2-3
Page 40
The Grand Tour

Back side

The following figure shows the computer's back panel.
t
1.Security Lock
2.Universal Serial Bus (USB) Port
3.RGB (Monitor) Port
4.TV Out Port
Security Lock A security cable attaches to this port in order to
Universal Serial Bus (USB) Ports
RGB (Monitor) Port This 15-pin port lets you connect an external
TV Out Port Plug a 4-pin S- video cable into this connector for
DC IN 19V Jack The DC IN jack is where you plug in the AC
Fan Vents The fan vents help to keep the CPU from
LAN Jack This jack lets you connect to a LAN.
s
The back side of the computer
q
r
anchor your computer to a desk or other large object to deter theft.
The Universal Serial Bus (USB 2.0 and 1.1) ports enable USB-equipped devices (such as keyboards, mice, hard drives, scanners, and printers) to be connected to the computer.
video display to the computer.
the output of an NTSC or PAL signal.
adapter.
overheating.
The adapter has built-in support for Ethernet LAN (10 megabits per second, 10BASE-T), Fast Ethernet LAN (100 megabits per second, 100BASE-TX) or Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T). Two indicators built into the jack let you see the LAN status.
p
o
5.DC IN 19V Jack
6.Fan Vent
7.LAN Jack
n
To prevent possible over heating of the CPU, never block the fan vents.
2-4 User’s Manual
Page 41

Underside

The following figure shows the underside of the computer. Make sure the display is closed before turning over your computer.
The Grand Tour
p
n
o
1.Battery Pack Latch
2.Battery Pack
3.Expansion Memory Socket
The underside of the computer
Battery Pack Latch Slide this latch to remove the battery pack.
Battery Pack The battery pack powers the computer when
Expansion Memory Socket
User’s Manual 2-5
the AC adapter is not connected. For detailed information on the battery pack, refer to Chapter 6, Power and Power-Up Modes.
Use this socket to install a memory module to increase your computer’s memory. Refer to the Memory Expansion section in Chapter 8, Optional Devices.
Page 42
The Grand Tour

Front with the display open

The following figure shows the front of the computer with the display open. To open the display, slide the display latch on the front of the display and lift up. Position the display at a comfortable viewing angle.
s
t
u v
w
z z
z
11 12
13
14
z
15
z
r
p
q
o
n
1.DC-IN LED
2.Power LED
3.Battery LED
4.Hard Disk LED
5.Multiple Digital Media Card Access LED
6.Display Screen
7.Power Button
The front with the display open
8.Internet Button
9.CD/DVD Button
10.Play/Pause
11.Stop
12.Previous
13.Next
14.TouchPad
15.TouchPad Controls
DC IN LED The DC IN LED indicates the computer is
connected to the AC adapter and it is plugged into an AC power source.
Power LED The Power LED flashes amber while the system
is in Standby mode. The LED turns off when the computer is turned off or in hibernation mode. In normal operating mode, the LED is green.
2-6 User’s Manual
Page 43
The Grand Tour
Battery LED The Battery LED indicates the battery’s current
charge/discharge status. It lights green when the battery is fully charged. It lights amber while the battery is being charged from the AC adapter. It flashes amber when the battery capacity is low.
Hard Disk Drive LED The Hard Disk Drive LED indicates that the
Hard Disk Drive is being accessed. Every time your computer runs a program, opens a file, or performs some other function in which it must access the Hard Disk Drive, this light goes on.
Multiple Digital Media Card Slot Access LED
The Multiple Digital Media Card Slot Access LED lights up when the Multiple Digital Media Card slot is accessed.
Display Screen The LCD displays high-contrast text and
graphics. Refer to Appendix B. When the computer operates on the AC adapter the display screen’s image will be somewhat brighter than when it operates on battery power. The brightness level is intended to save battery power.
To prolong the life of your display screen, use a screen saver when youíre not working with the computer and it is idle.
Power Button Press the power button to turn the computer’s
power on and off. There is an LED inside the power button which shines blue when the system is on.
Internet Button Press the Internet button to open your default
web browser. The button setting can be changed in TOSHIBA
Controls. To access the TOSHIBA Controls utility, click start, click Control Panel, click Printers
and Other Hardware and select the TOSHIBA Controls icon.
User’s Manual 2-7
Page 44
The Grand Tour
CD/DVD Button
Pressing this button in the power-off condition will run Express Media Player. Once Express Media Player is launched, the Power indicator turns on and the audio button is enabled. Meanwhile, when Express Media Player is running, pressing this button will do nothing. Pressing this button in the power-on or standby conditions will launch Windows Media
®
Player (default setting).
The button setting can be changed in TOSHIBA Controls. To access the TOSHIBA Controls utility, click start, click Control Panel, click Printers
and Other Hardware and select the TOSHIBA Controls icon.
When you use Express Media Player, please assign the CD/DVD button to “CD/DVD” in TOSHIBA Controls.
Play/Pause Press this button to begin playing an audio CD,
a DVD movie or digital audio files. This button also acts as a Pause button.
Stop Stops playing the CD, DVD or digital audio.
Next Skips forward to the next track, chapter or data.
Refer to Chapter 4, Operating Basics, for details.
Previous Skips back to the previous track, chapter or data.
Refer to Chapter 4, Operating Basics, for details.
If Random or Shuffle is selected in Windows® Media Player, selecting Next or Previous advances to a random selection.
TouchPad A pointing device located in the center of the
palm rest is used to control the on-screen pointer. Refer to the Using the TouchPad section in Chapter 4, Operating Basics.
TouchPad Control Buttons
Control buttons below the TouchPad let you select menu items or manipulate text and graphics designated by the on-screen pointer.
2-8 User’s Manual
Page 45

Keyboard Indicators

The Grand Tour
Scroll Lock
Scroll Lock When the Scroll Lock icon lights green, the cursor is
locked on a specific line.
Num Lock You can use the number keys on the numeric keypad for
numeric input when the the Num Lock icon lights green. When it does not light, you can use the cursor keys.
Caps Lock The Caps Lock LED lights when you press the Caps Lock
key. When this light is on, pressing a letter key on the keyboard produces an uppercase (capital) letter.

Optical Disc drive

One of the following optical disc drives is installed in the computer: CD-RW/ DVD-ROM drive or the DVD Super Multi drive (either single layer or double layer support, depending on the configuration of your computer). An ATAPI interface controller is used for CD/DVD-ROM operation. When the computer is accessing a disc, an indicator on the drive glows.
Region codes for DVD drives and media
The disc drive and its media are manufactured according to the specifications of six marketing regions. When you purchase DVD-Video, make sure it matches your drive, otherwise it will not play properly.
Code Region
1 Canada, United States
Num Lock
CapS Lock
2 Japan, Europe, South Africa, Middle East
3 Southeast Asia, East Asia
4 Australia, New Zealand, Pacific Islands, Central America,
South America, Caribbean
5 Russia, Indian Subcontinent, Africa, North Korea, Mongolia
6 China
User’s Manual 2-9
Page 46
The Grand Tour
Writable discs
This section describes the types of writable discs. Check the specifications for your drive to for the type of discs it can write. Use Record Now! to write
compact discs. Refer to Chapter 4, Operating Basics.
CDs
CD-R discs can be written only once. The recorded data cannot be
erased or changed.
CD-RW discs can be recorded more than once. Use either 1x, 2x, or 4x
multi speed CD-RW discs or high-speed 4x to 10x discs. The write speed of the ultra-speed CD-RW discs is a maximum of 24x.
DVDs
DVD-R and DVD+R discs can be written only once. The recorded data
cannot be erased or changed.
DVD-RW, DVD+RW and DVD-RAM discs can be recorded more than
once.
CD-RW/DVD-ROM drive
The full-size CD-RW/DVD-ROM drive module lets you record data to rewritable CDs as well as run either 12 cm (4.72") or 8 cm (3.15") discs without using an adapter.
The read speed is slower at the center of a disc and faster at the other edge.
DVD read 8 speed (maximum) CD read 24 speed (maximum) CD-R write 24 speed (maximum) CD-RW write 24 speed (maximum, ultra-speed media)
2-10 User’s Manual
Page 47
The Grand Tour
DVD Super Multi drive with double layer disc recording support
The full-size DVD super multi drive module lets you record data to rewritable discs as well as run either 12cm (4.72") or 8cm (3.15") discs without using an adapter.
The read speed is slower at the center of a disc and faster at the other edge.
DVD read 8 speed (maximum) DVD-R write 8 speed (maximum) DVD-RW write 4 speed (maximum) DVD+R write 8 speed (maximum) DVD+RW write 4 speed (maximum) DVD-RAM write 5 speed (maximum) CD read 24 speed (maximum) CD-R write 24 speed (maximum) CD-RW write 10 speed (maximum, ultra-speed media) DVD+R (DL) write 2.4 speed (maximum)
This drive can not use discs that allow writing faster than 8 or more speed (DVD-R, DVD+R with Single Layer), 4 or more speed (DVD-RW, DVD+RW), 5 speed (DVD-RAM) or ultra-speed+(CD-RW).
AC adapter
The AC adapter converts AC power to DC power and reduces the voltage supplied to the computer. It can automatically adjust to any voltage from 100 to 240 volts and to a frequency of either 50 or 60 hertz, enabling you to use the computer in almost any country/region.
To recharge the battery, simply connect the AC adapter to a power source and the computer. See Chapter 6, Power and Power-Up Modes, for details.
The AC adapter
User’s Manual 2-11
Page 48
The Grand Tour
Use of the wrong adapter could damage your computer. TOSHIBA assumes no liability for any damage in such case. The output rating is 19 volts DC.
Please use only the AC Adapter supplied with the computer or an AC adapter certified by TOSHIBA.
2-12 User’s Manual
Page 49
Satellite M60
Getting Started
This chapter provides basic information to get you started using your computer. It covers the following topics:
Setting up your work space - for your health and safety
Be sure also to read Instruction Manual for Safety & Comfort. This guide, which is included with the computer, explains product liability.
Connecting the AC adapter
Opening the display
Turning on the power
Starting up for the first time
Turning off the power
Restarting the computer
Restoring the preinstalled software
Chapter 3
All users should be sure to carefully read the section Starting up for the first time, which describe actions to take when you turn on the power for the first time.

Setting up your work space

Establishing a comfortable work site is important for you and your computer. A poor work environment or stressful work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. Proper ambient conditions should also be maintained for the computer’s operation. This section discusses the following topics:
General conditions
Placement of the computer and peripheral devices
Seating and posture
Lighting
Work habits
User’s Manual 3-1
Page 50
Getting Started
General conditions
In general, if you are comfortable, so is your computer, but read the following to make sure your work site provides a proper environment.
Make sure there is adequate space around the computer for proper
ventilation.
Make sure the AC power cord connects to an outlet that is close to the
computer and easily accessible.
The temperature should be 5 to 35 degrees Centigrade
(41 to 95 degrees Fahrenheit) and the relative humidity should be 20 to 80 percent.
Avoid areas where rapid or extreme changes in temperature or humidity
may occur.
Keep the computer free of dust, moisture, and exposure to direct
sunlight.
Keep the computer away from heat sources, such as electric heaters.
Do not use the computer near liquids or corrosive chemicals.
Some components in the computer, including data storage media, can
be damaged by magnets. Do not place the computer near magnetic objects or bring magnetic objects close to the computer. Be careful of objects, such as stereo speakers, that produce strong magnetic fields during operation. Also, be careful with metal objects, such as bracelets, which can be inadvertently magnetized.
Do not operate the computer in close proximity to a mobile phone.
Leave ample ventilation room for the fan. Ensure that there are no
obstructions around any of the system inlets or exhaust vents.
Placement of computer
Position the computer and peripheral devices to provide comfort and safety.
Set the computer on a flat surface at a comfortable height and distance.
The display should be no higher than eye level to avoid eye strain.
Place the computer so that it is directly in front of you when you work
and make sure you have adequate space to easily operate other devices.
Allow adequate space behind the computer to let you freely adjust the
display. The display should be angled to reduce glare and maximize visibility.
If you use a paper holder, set it at about the same height and distance
as the computer.
3-2 User’s Manual
Page 51
Seating and posture
The height of your chair in relation to the computer and keyboard as well as the support it gives your body are primary factors in reducing work strain.
Below eye level
Foot rest
Posture and positioning of the computer
Place your chair so that the keyboard is at or slightly below the level of
your elbow. You should be able to type comfortably with your shoulders relaxed.
Your knees should be slightly higher than your hips. If necessary, use a
foot rest to raise the level of your knees to ease pressure on the back of your thighs.
Adjust the back of your chair so it supports the lower curve of your
spine.
Sit straight so that your knees, hips and elbows form approximately
90 degree angles when you work. Do not slump forward or lean back too far.
Getting Started
90°angles
Lighting
Proper lighting can improve legibility of the display and reduce eye strain.
Position the computer so that sunlight or bright indoor lighting does not
reflect off the screen. Use tinted windows, shades or other screen to eliminate sun glare.
Avoid placing the computer in front of bright light that could shine
directly in your eyes.
If possible, use soft, indirect lighting in your computer work area.
Use a lamp to illuminate your documents or desk, but be sure to position the lamp so that it does not reflect off the display or shine in your eyes.
User’s Manual 3-3
Page 52
Getting Started
Work habits
A key to avoiding discomfort or injury from repetitive strain is to vary your activities.
If possible, schedule a variety of tasks into your work day. If you must spend long periods at the computer, finding ways to break up the routine can reduce stress and improve your efficiency.
Sit in a relaxed posture. Good positioning of your chair and equipment
as described earlier can reduce tension in your shoulders or neck and ease back strain.
Vary your posture frequently.
Occasionally stand up and stretch or exercise briefly.
Exercise and stretch your wrists and hands a number of times during
the day.
Frequently, look away from the computer and focus your eyes on a
distant object for several seconds, for example 30 seconds every 15 minutes.
Take frequent short breaks instead of one or two long breaks,
for example, two or three minutes every half hour.
Have your eyes examined regularly and visit a doctor promptly,
if you suspect you might be suffering from a repetitive strain injury.
Please check every couple of months to ensure the fan inlets or
exhaust vents (see sections 2-5 and 2-7) are unobstructed. Clean them if necessary.
A number of books are available on ergonomics and repetitive strain injury or repetitive stress syndrome. For more information on these topics or for pointers on exercises for such stress points as hands and wrists, please check with your library or book vendor. Also refer to the computer’s Instruction Manual for Safety and Comfort.

Connecting the AC adapter

Attach the AC adapter when you need to charge the battery or you want to operate from AC power. It is also the fastest way to get started, because the battery pack will need to be charged before you can operate from battery power. The AC adapter can be connected to any power source supplying from 100 to 240 volts and 50 or 60 hertz. For details on using the AC adapter to charge the battery pack, refer to Chapter 6, Power and
Power-Up Modes.
Use of the wrong adapter could damage your computer. TOSHIBA assumes no liability for any damage in such case. The output rating is 19 volts DC.
3-4 User’s Manual
Page 53
Getting Started
1. Connect the power cord to the AC adapter.
Connecting the power cord to the AC adapter
2. Connect the AC adapter's DC output plug to the DC IN input port on the back of the computer.
Connecting the adapter to the computer
3. Plug the power cord into a live wall outlet. The Battery and DC IN indicators on the front of the computer should glow.

Opening the display

The display panel can be rotated in a wide range of angles for optimal viewing.
1. Slide the display latch on the front of the computer to the right to unlatch the display panel.
Opening the display
User’s Manual 3-5
Page 54
Getting Started
2. Lift the panel up and adjust it to the best viewing angle for you.
Use reasonable care when opening and closing the display panel. Opening it vigorously or slamming it shut could damage the computer.

Turning on the power

This section describes how to turn on the power.
After you turn on the power for the first time, do not turn it off until you have set up the operating system. Refer to the section Starting up for the first time in this chapter.
1. If a USB Floppy Disk drive is connected, make sure the drive is empty. If a diskette is in the drive, press the eject button to remove it.
2. Open the display panel.
3. Press the Power button.
Turning on the power
3-6 User’s Manual
Page 55

Starting up for the first time

Getting Started
When you first turn on the power, the computer’s initial screen is the Windows each screen. During setup, you can click the Back button to return to the previous screen.
Be sure to read the Windows Agreement carefully.
®
XP Startup Screen Logo. Follow the on-screen directions for

Turning off the power

The power can be turned off in one of the following modes: Shut down (Boot), Hibernation or Standby mode.
Shut Down mode (Boot mode)
When you turn off the power in Shut Down mode, no data is saved and the computer will boot to the operating system’s main screen.
1. If you have entered data, save it to the hard disk or to a diskette.
2. Make sure all disk activity has stopped, then remove the optical disc
media or floppy diskette.
Make sure the Built-in Hard Disk Drive and optical disc drive are off. If you turn off the power while a disk is being accessed, you can lose data or damage the disk.
3. Click Start and click Shut Down. From the Shut Down dialogue box,
choose Turn Off .
4. Turn off the power to any peripheral devices.
®
Operating System End User License
Do not turn the computer or devices back on immediately. Wait a moment to let all capacitors fully discharge.
Hibernation mode
The hibernation feature saves the contents of memory to the hard disk when the computer is turned off. The next time the computer is turned on, the previous state is restored. The hibernation feature does not save the status of peripheral devices.
1. While entering hibernation mode, the computer saves the contents of memory to the Hard Disk Drive. Data will be lost if you remove the battery or disconnect the AC adapter before the save is completed. Wait for the Built-in Hard Disk Drive indicator to go out.
2. Do not install or remove a memory module while the computer is in hibernation mode. Data will be lost.
User’s Manual 3-7
Page 56
Getting Started
Benefits of Hibernation
The hibernation feature provides the following benefits:
Saves data to the hard disk when the computer automatically shuts
down because of a low battery.
For the computer to shut down in Hibernation Mode, the hibernation feature must be enabled within the Hibernate tab of the Windows Power Options utility and the Basic Setup tab of the TOSHIBA Power Saver utility. If these changes are not made, the computer will shut down in Standby Mode - if battery power becomes depleted, data saved in Standby Mode will be lost.
You can return to your previous working environment immediately when
you turn on the computer.
Saves power by shutting down the system when the computer receives
no input or hardware access for the duration set by the System hibernate feature.
You can use the panel power off feature.
Starting Hibernation
You can also enable Hibernation by pressing Fn + F4. See Chapter 5,
The Keyboard, for details.
To enter Hibernation mode, follow the steps below.
1. Click Start.
2. Select Shut Down.
3. Open the Shut Down dialog box. Hibernate is not displayed.
4. Press the Shift key. The Standby item will change to Hibernate.
5. Select Hibernate.
Automatic Hibernation
The computer will enter Hibernate mode automatically when you press the power button or close the lid. First, however, make the appropriate settings according to the steps below.
1. Open the Control Panel.
2. Open Performance and Maintenance and open Power Options.
3. Select the Hibernation tab.
4. Select Enable Hibernate, then click OK button.
5. Open Toshiba Power Saver.
6. Select Setup Action tab.
7. Enable the desired Hibernation settings for When I press the power button and When I close the lid of my portable computer.
8. Click the OK button.
3-8 User’s Manual
Page 57
Data save in hibernation mode
When you turn off the power in hibernation mode, the computer takes a moment to save current memory data to the hard disk. During this time, the Built-in Hard Disk Drive indicator will light.
After you turn off the computer and memory is saved to the hard disk, turn off the power to any peripheral devices.
Do not turn the computer or devices back on immediately. Wait a moment to let all capacitors fully discharge.
Standby mode
In standby mode the power remains on, but the CPU and all other devices are in sleep mode.
If the computer is not used or accessed in any way, including receipt of
e-mail, for approximately 15 or 30 minutes when the AC adapter is connected, the computer will automatically enter Standby mode (TOSHIBA Power Saver default).
To restore operation, press the power button.
If the computer automatically enters Standby mode while a network
application is active, the application might not be restored when the computer wakes up from Standby.
To prevent the computer from automatically entering Standby Mode
disable Standby in the TOSHIBA Power Saver utility. However, please note that making this change will nullify the computer’s Energy Star compliance.
Getting Started
Standby precautions
Before entering Standby mode, be sure to save your data.
Do not remove/install memory or remove power components:
Do not remove/install memory modules - the computer or module
could be damaged.
Do not remove the Battery Pack.
In any of the above cases, the standby configuration will not be saved.
If you carry the computer on board an aircraft or into a hospital, be sure
to shut down the computer in hibernation mode or in shutdown mode to avoid radio signal interference.
Benefits of standby
The standby feature provides the following benefits:
Restores the previous working environment more rapidly than does
hibernation.
Saves power by shutting down the system when the computer receives
no input or hardware access for the duration set by the System Standby feature.
You can use the panel power off feature.
User’s Manual 3-9
Page 58
Getting Started
Enabling Standby
You can also enable Standby by pressing Fn + F3. See Chapter 5,
The Keyboard, for details.
You can enter standby mode in one of three ways:
1. Click Start, click Shut Down and click Stand by.
2. Close the display panel. This feature must be enabled. Refer to the Setup Action tab in TOSHIBA Power Saver Utility described in the Control Panel.
3. Press the power button. This feature must be enabled. Refer to the Setup Action tab in TOSHIBA Power Saver Utility described in the Control Panel.
When you turn the power back on, you can continue where you left when you shut down the computer.
When the computer is shut down in standby mode, the power indicator
glows amber.
If you are operating the computer on battery power, you can lengthen
the operating time by shutting down in hibernation mode. Standby mode consumes more power.
Standby limitations
Standby will not function under the following conditions:
Power is turned back on immediately after shutting down.
Memory circuits are exposed to static electricity or electrical noise.

Restarting the computer

Certain conditions require that you reset the system. For example, if:
You change certain computer settings.
An error occurs and the computer does not respond to your keyboard
commands.
There are three ways to reset the computer system:
1. Select Restart from the Shut Down dialogue.
2. If the computer is already on, press Ctrl + Alt + Del.
3. Press the power button to turn the computer off, then press it a second to time in order to restart.
Only use step 3 if the operating system freezes or locks up due to a crash. Performing step 3 should only ever be a last resort as you will lose all unsaved data and could potentially damage critical files.
3-10 User’s Manual
Page 59

Restoring the preinstalled software

If preinstalled files are damaged, use the Product Recovery media to restore them. To restore the operating system and all preinstalled software, follow the steps below.
Restoring the Windows operating system
When you reinstall the Windows® operating system, the hard disk will be reformatted and all data will be lost.
1. Load the Product Recovery disc in the drive and turn off the computer’s
power.
2. Power on your computer, when In Touch with Tomorrow TOSHIBA
appears, press the F12 key - the Boot Menu will appear.
3. Use the up or down cursor keys to select the CD-ROM/DVD drive from
the displayed menu.
4. Follow the on-screen instructions.
5. If your computer came with additonal software installed, this software
can not be recovered from the Product Recovery DVD-ROM. Re-install these applications (e.g. Works Suite, DVD Player, Games, etc.) separately from other media.
Restoring Express Media Player
Getting Started
Please use the Express Media Player Recovery CD to reinstall the “Express Media Player” before you reinstall a Windows (Depends on configuration)
To restore Express Media Player, follow the steps below.
1. Load the Express Media Player Recovery CD in the optical media drive
and turn off the computer’s power.
2. Power on your computer, when In Touch with Tomorrow TOSHIBA
appears, press the F12 key - the Boot Menu will appear.
3. Use the up or down cursor keys to select the CD-ROM/DVD drive from
the displayed menu.
4. Follow the on-screen instructions.
®
operating system.
Restoring TOSHIBA utilities and drivers
If Windows is working properly, individual drivers or applications can be separately restored. The TOSHIBA Tools & Utilities folder (C:\TOOLSCD) contains drivers and applications, which are included with your computer system. If your system drivers or applications have become damaged in some way, you can reinstall most of the components from this folder.
Create a copy of this folder on external media for more convenience.
User’s Manual 3-11
Page 60
Getting Started
3-12 User’s Manual
Page 61
Satellite M60
Operating Basics
This chapter gives information on basic operations including using the TouchPad, optical disc drives, the internal modem, LAN and wireless LAN. It also provides tips on caring for your computer and on heat dispersal.

Using the TouchPad

To use the TouchPad, simply move your finger tip across it in the direction you want the on-screen pointer to go.
Chapter 4
1. TouchPad control buttons 2. TouchPad
TouchPad and control buttons
User’s Manual 4-1
Page 62
Operating Basics
Two buttons below the keyboard are used like the buttons on a mouse pointer.
Press the left button to select a menu item or to manipulate text or graphics designated by the pointer. Press the right button to display a menu or other function depending on the software you are using.
Do not press on the TouchPad too hard or press a sharp object such as a ball point pen against it. The TouchPad could be damaged.
The TouchPad has similar functions to a two-button mouse with a scroll wheel. For some functions, you can tap it instead of pressing a button.
You can customize pointing device actions in Mouse Properties. Open the Control Panel, select the Mouse icon and press Enter to open the Mouse Properties window.
Click: Click the left control button or tap the TouchPad one time. Double-click: Click the left control button twice or tap the TouchPad twice. Scroll Vertical: Move your finger up or down the right edge of the
TouchPad. Scroll Horizontal: Move your finger left or right along the bottom edge of
the TouchPad.

Using the internal modem

This section describes how to make settings and connect the modem. Refer to the computer’s online help files for more information. Refer also to the online help files for your modem software.
The internal modem does not support the voice functions described in the help files. All data and fax functions are supported.
In case of a lightning storm, unplug the modem cable from the telephone
jack.
Do not connect the modem to a digital telephone line. A digital line will
damage the modem.
4-2 User’s Manual
Page 63
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:
1. Do not use this product near water, for example, near a bathtub, wash
bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord indicated in this manual.
Region selection
Telecommunication regulations vary from one country/region to another, so you will need to make sure the internal modem’s settings are correct for the country/region in which it will be used.
1. Open the Modem Region Select application. It is located on the
Programs menu at TOSHIBA > Networking.
Do not use the Country/Region Select function in the Modem setup utility in the Control Panel if the function is available. If you change the Country/Region in the Control Panel, the change may not take effect.
2. The Region Selection icon appears on the Windows Task Bar.
Operating Basics
The Region Selection icon
3. Click the icon with the primary mouse button to display a list of regions
that the modem supports. A sub menu for telephony location information will also be displayed. A check will appear next to the currently selected region and telephony location.
4. Select a region from the region menu or a telephony location from the
submenu.
When you click a region it becomes the modem’s region selection,
and the New Location for telephony will be set automatically.
When you select a telephony location, the corresponding region is
automatically selected and it becomes the modem’s current region setting.
User’s Manual 4-3
Page 64
Operating Basics
Properties menu
Click the icon with the secondary mouse button to display the following menu.
Setting
You can enable or disable the following settings:
AutoRun Mode
Region Select Utility starts automatically when you start up the operating system.
Open the Dialing Properties dialog box after selecting region
The dialing properties dialog box will be displayed automatically after you select the region.
The properties menu
Location list for region selection
A submenu appears displaying location information for telephony.
Open dialog box, if the modem and Telephony Current Location region code do not match
A warning dialog box is displayed if current settings for region code and telephony location are incorrect.
Modem Selection
If the computer cannot recognize the internal modem, a dialog box is displayed. Select the COM port for your modem to use.
Dialing Properties
Select this item to display the dialing properties.
If you are using the computer in Japan, technical regulations described in the Telecommunications Business Law require that you select Japan region mode. It is illegal to use the modem in Japan with any other selection.
4-4 User’s Manual
Page 65
Connecting
To connect the internal modem cable, follow the steps below.
In case of a lightning storm, unplug the modem cable from the telephone
jack.
Do not connect the modem to a digital telephone line. A digital line will
damage the modem.
1. Plug one end of the modular cable into the modem jack.
2. Plug the other end of the modular cable into a telephone jack
Connecting the internal modem
Do not pull on the cable or move the computer while the cable is connected.
Operating Basics
If you use a storage device such as a DVD-ROM drive or Hard Disk Drive connected to a 16-bit PC card, modem speed might be slow or communication might be interrupted.
If modem speed is low or communication is interrupted when you are using the modem, please set the CPU speed to Maximum within the TOSHIBA Power Saver utility.
Disconnecting
To disconnect the internal modem cable, follow the steps below.
1. Pinch the lever on the connector in the telephone jack and pull out the
connector.
2. Disconnect the cable from the computer in the same manner.
User’s Manual 4-5
Page 66
Operating Basics
LAN
The computer is equipped with LAN circuits that support Ethernet LAN (10 megabits per second, 10BASE-T), Fast Ethernet LAN (100 megabits per second, 100BASE-TX), or Gigabit Ethernet LAN (1000megabits per second, 1000BASE-T). This section describes how to connect/disconnect to a LAN.
If you use Gigabit Ethernet LAN(1000megabits per second, 1000BASE-T), be sure to connect with CAT5e or CAT6 cable.
Do not install or remove an optional memory module while Wake-up on LAN is enabled.
Wake-up on LAN does not work without the AC adapter. Leave it connected, if you are using this feature.
Connecting the LAN cable
The computer must be configured properly before connecting to a LAN. Logging onto a LAN using the computer’s default settings could cause a malfunction in LAN operation. Check with your LAN administrator regarding set-up procedures.
If you are using Fast Ethernet LAN (100 megabits per second, 100BASE-TX), be sure to connect with a CAT5 cable. You cannot use a CAT3 cable.
If you are using Ethernet LAN (10 megabits per second, 10BASE-T), you can connect with either a CAT5 or a CAT3 cable.
If you use Gigabit Ethernet LAN(1000megabits per second, 1000BASE-T), be sure to connect with CAT5e or CAT6 cable.
To connect the LAN cable, follow the steps below.
1. Turn off the power to the computer and to all external devices connected to the computer.
2. Plug one end of the cable into the LAN jack. Press gently until you hear the latch click into place.
Connecting the LAN cable
3. Plug the other end of the cable into a LAN hub connector. Check with your LAN administrator before connecting to a hub.
4-6 User’s Manual
Page 67
Disconnecting the LAN cable
To disconnect the LAN cable, follow the steps below.
1. Pinch the lever on the connector in the computer’s LAN jack and pull
out the connector.
2. Disconnect the cable from the LAN hub in the same manner.
Check with your LAN administrator before disconnecting from the hub.

Wireless LAN

The wireless LAN is compatible with other LAN systems that comply with the 802.11b/g or 802.11a/b/g wireless LAN standard.
It supports the following:
Automatic Transmit Rate Select mechanism in the transmit range of
54, 11, 5.5, 2 and 1 Mbit/s.
Advanced Encryption Standard (AES) data encryption, based on 128bit
encryption algorithm.
Wake-up on LAN does not function on a Wireless LAN.
Frequency Channel Selection (5GHz and 2.4 GHz)
Roaming over multiple channels
Card Power Management
Wired Equivalent Privacy (WEP) data encryption.
Operating Basics
Wireless LAN Disclaimer:
The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the theoretical maximum speed.
To use the Atheros SuperAG™ or SuperG™ function, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format of data transmitted.
Security
1. TOSHIBA strongly recommends that you enable the WEP (encryption)
function otherwise your computer could be left wide open to illicit access via the Wireless LAN - this may result in an intrusion leading to the theft or even loss of stored data among other things. Moreover, the owner of an Internet connection is responsible for all browsing, downloading, and uploading activities on that connection, therefore an unsecured wireless network connected directly to the Internet is an open invitation for outsiders to abuse your ISP account privileges.
2. TOSHIBA is not liable for data packet theft due to the use of the
Wireless LAN, and any damage thereof.
User’s Manual 4-7
Page 68
Operating Basics
Wireless communication switch
You can enable or disable the wireless LAN function with the wireless communication switch, no transmissions will be sent or received when the switch is off. Slide the switch forward (to the front side of the computer) to turn it off and backward (to the rear of the computer) to turn it on.
Turn the switch off in airplanes and hospitals. Check the LED. It stops glowing when the wireless communication function is off.
Wireless communication LED
The LED indicates the status of the wireless communication functions.
LED status Indication
LED off Wireless communication switch is set to off
LED glows Wireless communication switch is on

Using optical disc drives

The illustrations in this section might differ slightly from your drive, but operation is the same for all optical disc drives. The full-size drive provides high-performance execution of disc-based programs. You can run either 12 cm (4.72") or 8 cm (3.15") discs without an adapter. An ATAPI interface controller is used for disc drive operation. When the computer is accessing a disc, an indicator on the drive illuminates.
Use the WinDVD application to view DVD-Video discs.
If you have a CD-RW/DVD-ROM drive, refer also to the Writing CDs on CD-RW/DVD-ROM drive section for precautions on writing to CDs.
If you have a DVD Super Multi drive, refer also to the Writing CD/DVDs on DVD Super Multi drive section for precautions on writing to CDs.
Loading optical media discs
To load a disc, follow the steps below.
1. Turn on the power.
2. a. Press the eject button to open the drawer slightly.
4-8 User’s Manual
Page 69
Operating Basics
Eject button
Pressing the eject button
b. Pressing the eject button will not open the drawer when the
computer’s power is off. If the power is off, you can open the drawer by inserting a slender object (about 15 mm) such as a straightened paper clip into the eject hole just to the right of the eject button.
Manual release with the eject hole
3. Grasp the drawer gently and pull until it is fully open.
Pulling the drawer open
User’s Manual 4-9
Page 70
Operating Basics
4. Lay the disc, label side up, in the drawer.
Inserting a disc
Be careful not to touch the lens or the area around it. Doing so could cause the drive to malfunction.
5. Press gently at the center of the disc until you feel it click into place. The disc should lie below the top of the spindle, flush with its base.
6. Push the center of the drawer to close it. Press gently until it locks in place.
If the disc is not seated properly when the drawer is closed, it might be damaged. Also, the drawer might not open fully when you press the eject button.
Closing the drive drawer
4-10 User’s Manual
Page 71
Removing optical media discs
To remove the disc, follow the steps below.
Do not press the eject button while the computer is accessing the disc drive. Wait for the optical disc indicator to go out before you open the drawer. Also, if the disc is spinning when you open it, wait for it to stop before you remove it.
1. To pop the drawer partially open, press the eject button. Gently pull the
drawer out until it is fully opened.
When the drawer pops open slightly, wait a moment to make sure the
disc has stopped spinning before pulling the drawer fully open.
Turn off the power before you use the eject hole. If the disc is spinning
when you open the drawer, it could fly off the spindle and cause injury.
2. The disc extends slightly over the sides of the drawer so you can grasp
it. Hold it gently and lift it out.
Operating Basics
Removing a disc
3. Push the center of the drawer to close it. Press gently until it locks into
place.
User’s Manual 4-11
Page 72
Operating Basics
Buttons
The Internet button and the CD/DVD button can be assigned functions and applications in the TOSHIBA Controls Properties.
CD/DVD play control buttons
In addition to the power button, the following four buttons control functions of the optical disc drive and Digital Audio Data:
Play/Pause Starts or pauses play
Stop Stops play
Next Advances to the next track, chapter or data
Previous Returns to the previous track, chapter or data
If Random or Shuffle is selected in Windows® Media Player, selecting Next or Previous advances to a random selection.
4-12 User’s Manual
Page 73

Express Media Player

Express Media Player is a quick play feature that enables users to perform, DVD and CD playback.
Notes for Express Media Player
Express Media Player (CD) and Express Media Player (DVD) Usage
Dirty or scratched CD/DVDs might not be playable. In addition,
the CD/DVD might not be removable if the dirt or scratches are serious.
Press the personal computer’s power switch for five seconds or more to
force it to shut down, you can open the drawer by inserting slender object (about 15mm) into the eject hole. Refer to the Loading compact discs section in Chapter 4, Operating Basics.
Express Media Player (DVD) Usage
Express Media Player (DVD) plays the disc according to the way the
DVD-Video is programmed by the producer, and hence, sometimes it might not work as expected.
( ) might appear on screen during operation. When ( ) is displayed,
it means that Express Media Player (DVD) or DVD-Video prohibits that particular operation from being carried out.
Please also read the instructions that come with the DVD that you want
to play.
Depending on the DVD being played, there might be dropping of frames
or skipping of audio.
The DVD can only be played on the LCD display of the computer.
External video output is not supported.
For DVD titles with parental control, scenes set in advance as
DVD-Video can be played. The level setting for the parental control is not supported.
Data stored in the Video CD, DVD-Audio, -VR or +VR formats are
not playable. In addition, media that is not finalized, MPEG, DivX, mini DVD and other types of file formats are also not playable.
Closed captions are not displayed.
Audio is only output in 2-channel, stereo format.
Titles with DTS or SDDS audio will not produce any audio output if
these formats are selected.
Audio output from SPDIF is not supported.
This system is not karaoke mode compatible.
When continuous actions are to be carried out, ensure that the current
action is completed before carrying out the next one. Failure to do so might result in unexpected results.
Operating Basics
User’s Manual 4-13
Page 74
Operating Basics
Express Media Player Settings
Initial settings
There are a few settings that need to be made in order to use Express Media Player functions. The method for configuring the settings for the functions is explained here.
When Express Media Player is first started or the recovery CD is used, the screen for carrying out the initial settings of the Express Media Player is displayed.
Please implement the settings as follows:
1. Language for displaying the Express Media Player set up and guide. (Please refer to Table 1 for the language code.)
2. Keyboard. (Please refer to Table 2 for the keyboard code.)
Display Language setting and keyboard setting can be changed using the set up for the DVD Player.
Display Language Code Language
English English
Español Spanish
Français French
Italiano Italian
Nederlands Dutch
Português Portuguese
简体中文
繁體中文
Deutsch German
Table 1 Display Language
4-14 User’s Manual
Simplified Chinese
Traditional Chinese
Page 75
Operating Basics
Keyboard Code Keyboard Code
EN1 US English PT1 Portuguese
EN2 UK English RU1 Russian
ES1 Spanish SV1 Swedish
FR1 French TR1 Turkish
FR2 Canadian-
AR1 Arabic
French
IT1 Italian BE1 Belgian
IW1 Hebrew DA1 Danish
JA1 Japanese DE1 German
KO1 Korean DE2 Swiss-German
NO1 Norwegian EL1 Greek
PL1 Polish
Table 2 Keyboard Code
Functions via the Front operation panel and the keyboard in the Express Media Player mode
This list shows how the functions available from the keyboard correspond to those available from the Front operation panel.
Front panel Computer CD DVD
- Power switch Terminates CD Terminates DVD
CD/DVD - Launch the CD Launch the DVD
- Fn + F7 Increases the brightness
- Fn + F6 Decreases the brightness
Increases the brightness
Decreases the brightness
- 1 Select track 1 Select chapter 1
- 2 Select track 2 Select chapter 2
- 3 Select track 3 Select chapter 3
- 4 Select track 4 Select chapter 4
- 5 Select track 5 Select chapter 5
- 6 Select track 6 Select chapter 6
- 7 Select track 7 Select chapter 7
User’s Manual 4-15
Page 76
Operating Basics
- 8 Select track 8 Select chapter 8
- 9 Select track 9 Select chapter 9
- 0 Normally functions
- F8 or F9 - Displays the top
-
-
-
-
- Enter Executes the
- F2 - Displays or hides
- Esc - Menu cancel or
-PgUp - -
-PgDn - -
-
-
- M Mute the volume Mute the volume
- O Rewinds by about
- P Skip by about 10
Ctrl +
Ctrl +
K Previous track Previous chapter
as “0”
- Move the cursor
- Move the cursor
- Move the cursor
- Move the cursor
selected option
Increases the volume
Decreases the volume
10 seconds
seconds
Normally functions as “0”
menu
Executes the selected option
the Settings Menu
back or return
Increases the volume
Decreases the volume
Rewinds the video
Forwards the video
L Next track Next chapter
Space Play or pauses Play or pauses
Ctrl + Space Stop Stop
- Ctrl + R Repeat -
- Ctrl + S Shuffle -
4-16 User’s Manual
Page 77
Operating Basics
- D Changes the screen
- G - Changes the angle
- S - Changes the
- A - Changes the audio
- T - Select title
- Y - Slow play
- F1 Display the keyguide
-E Eject Eject
- W Changes the SRS WOW XT Mode *
* Changes the SRS mode of the built-in speaker from External Speaker to
Open Type Headphone to Closed Type Headphone to SRS Off.

Writing CDs on a CD-RW/DVD-ROM drive

You can use the CD-RW/DVD-ROM drive to write data to CD-R/RW discs.
Important message
Before you write or rewrite to CD-R/RW disc, read and follow all setup and operating instructions in this section. If you fail to do so, the CD-RW/DVD-ROM drive may not function properly, and you may fail to write or rewrite, lose data or incur other damage.
Changes the screen
subtitle
channel
Display the keyguide
-
Disclaimer
TOSHIBA does not bear responsibility for the following:
Damage to any CD-R/RW disc that may be caused by writing or
rewriting with this product.
Any change or loss of the recorded contents of CD-R/RW disc that may
be caused by writing or rewriting with this product, or for any business profit loss or business interruption that may be caused by the change or loss of the recorded contents.
Damage that may be caused by using third party equipment or
software.
Given the technological limitations of current optical disc writing drives, you may experience unexpected writing or rewriting errors due to disc quality or problems with hardware devices. Also, it is a good idea to make two or more copies of important data, in case of undesired change or loss of the recorded contents.
User’s Manual 4-17
Page 78
Operating Basics
CD-R discs can be written only once. CD-RW discs can be rewritten many times.
Before writing or rewriting
Please observe the following points when you write or rewrite the data.
We recommend the following manufacturers of CD-R and CD-RW
media. Media quality can affect write or rewrite success rates.
CD-R: TAIYOYUDEN CO., LTD.
CD-RW: MITSUBISHI CHEMICAL CORPORATION
TOSHIBA has confirmed the operation of CD-R and CD-RW media of the manufacturers above. Operation of other media cannot be guaranteed.
CD-RW can generally be rewritten about 1,000 times. However,
the actual number of rewrites is affected by the quality of the media and the way it is used.
Be sure to connect the universal AC adapter when you write or rewrite.
Be sure to close all other software programs except the writing
software.
Do not run software such as a screen saver which can put a heavy load
on the CPU.
Operate the computer at full power. Do not use power-saving features.
Do not write while virus check software is running. Wait for it to finish,
then disable virus detection programs including any software that checks files automatically in the background.
Do not use hard disk utilities, including those intended to enhance hard
disk drive access speed. They may cause unstable operation and damage data.
Write from the computer’s hard disk drive to the CD. Do not try to write
from shared devices such as a LAN server or any other network device.
Writing with software other than Sonic RecordNow! has not been
confirmed. Therefore, operation with other software cannot be guaranteed.
MITSUBISHI CHEMICAL CORPORATION RICOH Co., Ltd. MITSUI CHEMICAL, Inc.
RICOH Co., Ltd.
4-18 User’s Manual
Page 79
When writing or rewriting
Note the following when you write or rewrite a CD-R or CD-RW.
Always copy data from the Hard disk drive to the CD. Do not use
cut-and-paste. The original data will be lost if there is a write error.
Do not perform any of the following actions:
Change users in the Windows XP operating system.
Operate the computer for any other function, including the use of a
mouse or TouchPad, or closing/opening the LCD panel.
Start a communication application, such as a modem.
Apply impact or vibration to the PC.
Install, remove or connect external drives, including the PC Cards,
USB devices, an external display, i.LINK devices or optical digital devices.
Open the optical disc drive.
If the media is poor in quality, dirty or damaged, writing or rewriting
errors may occur.
Set the computer on a level surface and avoid places subject to
vibration, such as airplanes, trains, or cars. Do not use an unstable surface, such as a stand.
Keep mobile phones and other wireless communication devices away
from the computer.
Operating Basics

Writing CDs/DVDs on a DVD Super Multi drive supporting double layer disc recording

You can use the DVD Super Multi drive to write data to either CD-R/RW or DVD-R/-RW/+R/+RW/-RAM discs.
Important message
Before you write or rewrite to CD-R/RW or DVD-R/-RW/+R/+RW/-RAM disc, read and follow all set-up and operating instructions in this section. If you fail to do so, the DVD Super Multi drive may not function properly, and you may fail to write or rewrite, lose data or incur other damage.
Disclaimer
TOSHIBA does not bear responsibility for the following:
Damage to any CD-R/RW or DVD-R/-RW/+R/+RW/-RAM disc that may
be caused by writing or rewriting with this product.
Any change or loss of the recorded contents of CD-R/RW or
DVD-R/-RW/ +R/+RW /-RAM disc that may be caused by writing or rewriting with this product, or for any business profit loss or business interruption that may be caused by the change or loss of the recorded contents.
Damage that may be caused by using third party equipment or
software.
User’s Manual 4-19
Page 80
Operating Basics
Given the technological limitations of current optical disc writing drives, you may experience unexpected writing or rewriting errors due to disc quality or problems with hardware devices. Also, it is a good idea to make two or more copies of important data, in case of undesired change or loss of the recorded contents.
Before writing or rewriting
Please observe the following points when you write or rewrite data.
Based on TOSHIBA’s limited compatibility testing, we suggest the
following manufacturers of CD-R/RW and DVD-R/+R/-RW/+RW/-RAM disc. However, in no event does TOSHIBA guarantee the operation, quality or performance of any disc. Disc quality can affect write or rewrite success rates.
CD-R: TAIYOYUDEN CO., LTD.
CD-RW: MITSUBISHI CHEMICAL CORPORATION
DVD-R: DVD Specifications for Recordable Disc for
MITSUBISHI CHEMICAL CORPORATION RICOH Co., Ltd. MITSUI CHEMICAL, Inc.
RICOH Co., Ltd.
General Version 2.0
TAIYOYUDEN CO., LTD. Matsushita Electric Industrial Co., Ltd.
DVD-RW: DVD Specifications for Re-recordable Disc for
Version 1.1 or Version 1.2 VICTOR COMPANY OF JAPAN, LIMITED MITSUBISHI CHEMICAL CORPORATION
DVD+R: MITSUBISHI CHEMICAL CORPORATION
RICOH Co., Ltd.
DVD+RW: MITSUBISHI CHEMICAL CORPORATION
RICOH Co., Ltd.
*DVD-RAM: DVD Specifications for DVD-RAM Disc for
Version 2.0, Version 2.1 or Version 2.2
Matsushita Electric Industrial Co., Ltd. Hitachi Maxell Ltd. *DVD Multi drive and DVD Super Multi can use
DVD-RAM.
DVD+R (Double
MITSUBISHI CHEMICAL CORPORATION
Layer):
4-20 User’s Manual
Page 81
Operating Basics
If the disc is poor in quality, dirty or damaged, writing or rewriting errors
may occur. Be careful to check the disc for dirt or damage before you use it.
The actual number of rewrites to CD-RW or DVD-RW/+RW/-RAM is
affected by the quality of the disc and the way it is used.
There are two types of DVD-R: authoring and general use discs.
Do not use authoring discs. Only general use discs can be written to by a computer drive.
You can use DVD-RAM discs that can be removed from a cartridge and
DVD-RAM discs designed without a cartridge. You cannot use a disc with a 2.6 GB single-sided capacity or 5.2 GB double-sided capacity.
Other DVD-ROM drives for computers or other DVD players may not be
able to read DVD-R/+R/-RW/+RW/-RAM discs.
Data written to a CD-R/DVD-R/+R disc cannot be deleted either in
whole or in part.
Data deleted (erased) from a CD-RW and DVD-RW/+RW/-RAM disc
cannot be recovered. Check the content of the disc carefully before you delete it. If multiple drives that can write data to discs are connected, be careful not to delete data from the wrong drive.
In writing to a DVD-R/+R/-RW/+RW disc, some disc space is required
for file management, so you may not be able to write the full capacity of the disc.
Since the disc is based on the DVD-R/-RW standard, it will be filled with
dummy data if the written data is less than about 1 GB. Even if you write only a small amount of data, it might take time to fill in the dummy data.
Two types of DVD-R/+R/-RW/+RW/-RAM discs are on the market:
data and video. Use a video disc to store video data. You can use video discs on a DVD recorder as well as on your computer’s DVD-ROM drive. You cannot use data discs on a DVD recorder.
DVD-RAM formatted by FAT32 cannot be read in Windows 2000
without DVD-RAM Driver Software.
When multiple drives that can write data to discs are connected, be
careful not to write to the wrong drive.
Be sure to connect the universal AC adapter before you write or rewrite.
Before you enter standby/hibernation mode, be sure to finish DVD-RAM
writing. Writing is finished if you can eject DVD-RAM media.
Be sure to close all other software programs except the writing
software.
Do not run software such as a screen saver, which can put a heavy load
on the CPU.
Operate the computer in the full-power mode. Do not use power-saving
features.
Do not write while virus check software is running. Wait for it to finish,
then disable virus detection programs including any software that checks files automatically in the background.
User’s Manual 4-21
Page 82
Operating Basics
Do not use hard disk utilities, including those intended to enhance Hard
Disk Drive access speed. They may cause unstable operation and data damage.
Write from the computer’s Hard Disk Drive to the disc. Do not try to
write from shared devices such as a LAN server or any other network device.
Writing with software other than Sonic RecordNow! has not been
confirmed. Therefore, operation with other software cannot be guaranteed.
When writing or rewriting
Please observe/consider the following when you write or rewrite to a CD-R/RW, DVD-R/-RW/-RAM or DVD+R/+RW disc.
Do not perform any of the following actions when writing or rewriting:
Change users in the Windows XP operating system.
Operate the computer for any other function, including using a
mouse or Touch Pad or closing/opening the LCD panel.
Start a communication application such as a modem.
Apply impact or vibration to the computer.
Install, remove or connect external drives, including the PC Cards,
USB devices, an external display, i.LINK devices or optical digital devices.
Use of the Audio/Video control button to reproduce music or voice.
Open the drive.
Do not use shut down/log off and standby/hibernation while writing or
rewriting.
Make sure writing or rewriting is completed before going into
standby/hibernation. Writing is completed if you can open the drive tray.
Set the computer on a level surface and avoid places subject to
vibration such as airplanes, trains or cars. Do not use an unstable surface such as a stand.
Keep mobile phones and other wireless communication devices away
from the computer.
Always copy data from the hard disk drive to the DVD media. Do not
use cut-and-paste as the original data will be lost if there is a write error.
4-22 User’s Manual
Page 83

Media Care

This section provides tips on protecting data stored on your discs and diskettes.
Handles your media with care. The following simple precautions will increase the lifetime of your media and protect the data stored on them:
1. Store your discs in the container they came in to protect them and keep
2. Do not bend the disc.
3. Do not write on, apply a sticker to, or otherwise mar the surface of the
4. Hold the disc by its outside edge or the edge on the center hole.
5. Do not expose to direct sunlight, extreme heat or cold. Do not place
6. If your discs become dusty or dirty, wipe them with a clean dry cloth.

Diskettes

1. Store your diskettes in the container they came in to protect them and
2. Do not slide back the diskette’s protective metal covering or touch the
3. Data may be lost if the diskette is twisted; bent; or exposed to direct
4. Do not place heavy objects on your diskettes.
5. Do not eat, smoke, or use erasers near your diskettes. Foreign particles
6. Magnetic energy can destroy data on diskettes. Keep your diskettes
Operating Basics
them clean.
disc that contains data.
Fingerprints on the surface can prevent the drive from properly reading data.
heavy objects on your discs.
Wipe from the center out, do not wipe in a circular direction around the disc. If necessary, use a cloth dampened in water or a neutral cleaner. Do not use benzine, thinner or similar cleaner.
keep them clean. If a diskette is dirty, do not use cleaning fluid. Clean it with a soft damp cloth.
diskette’s magnetic surface. Fingerprints may prevent the diskette drive from reading data from the diskette.
sunlight, extreme heat or cold.
inside the diskette’s jacket can damage the magnetic surface.
away from speakers, radios, television sets and other sources of magnetic fields.
User’s Manual 4-23
Page 84
Operating Basics

TV-Out

Use the TV-Out port to connect to a television. Be sure to use a 4 pin type S-video cable. For more details, see Appendix B.
TV Out Port

Setting up more than one display

You can set up your computer to utilize more than one display, effectively spreading a single desktop screen across two monitors.
The Display Properties window allows you to adjust more precisely the relative positioning of the two displays when they are configured as an extended desktop. On the Display Properties window, the two displays can be positioned horizontally, vertically or in any diagonal configuration you wish, as shown below.
If an external display will not be connected next time you use your computer, you should cancel any extended desktop or clone display settings before shutting down your computer.
Clone display settings are those where more than one device has been selected and is simultaneously applicable.
4-24 User’s Manual
Page 85

Cleaning the computer

To help ensure long, trouble-free operation, keep the computer free of dust and use care with liquids around the computer.
Be careful not to spill liquids into the computer. If the computer does get
wet, turn the power off immediately and let the computer dry completely before you turn it on again.
Clean the computer using a slightly damp (with water) cloth. You can
use glass cleaner on the display. Spray a small amount of cleaner on a soft, clean cloth and wipe the screen gently with the cloth.
Never spray cleaner directly onto the computer or let liquid run into any part of it. Never use harsh or caustic chemical products to clean the computer.

Moving the computer

The computer is designed for rugged durability. However, a few simple precautions taken when moving the computer will help ensure trouble-free operation.
Make sure all disk activity has ended before moving the computer.
Check the Built-in Hard Disk Drive and optical disc drive indicators on the computer.
If a diskette is in the diskette drive, remove it.
If a disc is in the optical disc drive, remove it. Also make sure the optical
disc drive drawer is securely closed.
Turn off the power to the computer.
Disconnect all peripherals before moving the computer.
Close the display. Do not pick up the computer by its display panel or
back (where the interface ports are located).
Close all port covers.
Disconnect the AC adapter if it is connected.
Use the carrying case when transporting the computer.
Operating Basics
User’s Manual 4-25
Page 86
Operating Basics
4-26 User’s Manual
Page 87
Satellite M60
The Keyboard
The computer’s keyboard layout is that of a 101/102-key enhanced keyboard.
The number of keys on your keyboard depends on which country/region’s keyboard layout your computer is configured with. Keyboards for numerous languages are available.
There are four types of keys: typewriter keys, function keys, soft keys and cursor control keys. The typewriter keys are gray. The other keys are dark gray.

Typewriter keys

The typewriter keys, produce the upper- and lower-case letters, numbers, punctuation marks, and special symbols that appear on the screen.
There are some differences, however, between using a typewriter and using a computer keyboard:
Letters and numbers produced in computer text vary in width.
Spaces, which are created by a space character may also vary depending on line justification and other factors.
The lowercase l (el) and the number 1 (one) are not interchangeable on
computers as they are on a typewriter.
The uppercase O (oh) and the 0 (zero) are not interchangeable.
The Caps Lock function key locks only the alphabetic characters in
uppercase while the shift lock on a typewriter places all keys in the shifted position.
The Shift keys, the Tab key, and the BkSp (backspace) key perform the
same function as their typewriter counterparts but also have special computer functions.
Chapter 5
User’s Manual 5-1
Page 88
The Keyboard

F1 ... F12 function keys

The function keys, not to be confused with Fn, are the 12 keys at the top of your keyboard.
F1 through F12 are called function keys because they execute programmed functions when pressed. Used in combination with the Fn key, keys marked with icons execute specific functions on the computer. See the section, Soft keys: Fn key combinations, in this chapter. The function executed by individual keys depends on the software you are using.

Soft keys: Fn key combinations

The Fn (function) is unique to TOSHIBA computers and is used in combination with other keys to form soft keys. Soft keys are key combinations that enable, disable or configure specific features.
Some software may disable or interfere with soft-key operations. Soft-key settings are not restored by the Standby feature.

Hotkeys

Fn + ESC Volume Mute Turns the volume on and off. Fn + F1 Instant Security Enters screen saver mode and
blanks the screen. To restore your desktop, press any key or use the TouchPad.
Fn + F2 Power Save Modes Displays the power save
modes and lets you change the power settings
Fn + F3 Standby This hot key switches the system to
Standby mode.
Fn + F4 Hibernate This hot key switches the system to
Hibernate mode.
Fn + F5 Display Selection Changes displays.
Default resolution for simultaneous mode is set to XGA (1024x768). If you connect an RGB (Monitor) that is not XGA resolution, change it in “Display Properties”.
5-2 User’s Manual
Page 89
The Keyboard
Fn + F6 Brightness Down
Fn + F7 Brightness Up Fn + F8 Wireless Device Controls Pressing this hot key
allows you to switch between active wireless devices. Only works if the wireless switch has already been turned on.
Fn + F9 TouchPad On/Off Fn + Space Change Resolution Cycles sequentially from
Fn + 1 Zoom Out To reduce the icon size on the
Fn + 2 Zoom In To enlarge the icon size on the desktop
Before using Fn+1 and Fn+2, you must install the TOSHIBA Zooming Utility. This utility only supports Microsoft Internet Explorer, Microsoft Office, Windows Media Player, Adobe Reader and the icons on the desktop.
the current resolution to 800x600 to 1024x768 and back again to the original resolution.
desktop or the application window, press the 1 key while holding down the Fn key.
or the application window, press the 2 key while holding down the Fn key.

Windows special keys

The keyboard provides two keys that have special functions in Windows XP. One activates the Start menu and the other has the same function as the secondary mouse button.
This key activates the Windows XP Start menu
This key has the same function as the secondary mouse button.
User’s Manual 5-3
Page 90
The Keyboard

Desktop-style Keyboard

The Satellite M60 comes with a “desktop-style” keyboard built into it. This means it is full-sized and features a full set of numeric function keys (also known as calculator keys) on the right-hand side. Unlike other notebooks computers with smaller keyboards, there is no ’Numeric Mode’ or any numeric keyboard overlay.
Desktop-style Keyboard
5-4 User’s Manual
Page 91
Satellite M60
Chapter 6
Power and Power-Up Modes
The computer’s power resources include the AC adapter and internal batteries. This chapter gives details on making the most effective use of these resources including charging and changing batteries, tips for saving battery power, and power up modes.

Power conditions

The computer’s operating capability and battery charge status are affected by the power conditions: whether an AC adapter is connected, whether a battery is installed and what the charge level is for the battery.
Power on Power off (no operation)
AC adapter connected
Battery fully charged
• Operates
• No charge
• LED: Battery green DC IN green
• No charge
• LED: Battery green DC IN green
Battery partially charged
No battery installed or no charge
User’s Manual 6-1
• Operates
• Charge
• LED: Battery Amber DC IN green
• Operates
• No charge
• LED: Battery off DC IN green
• Charge
• LED: Battery Amber DC IN green
• No charge
• LED: Battery off DC IN green
Page 92
Power and Power-Up Modes
AC adapter not connected
Battery capacity is above low battery trigger point
Power on Power off (no operation)
• Operates
• LED: Battery off DC IN off
Battery capacity is below low battery trigger point
Battery capacity exhausted
No battery installed

Power indicators

As shown in the above table, the Battery, DC IN and Power indicators on the system indicator panel alert you to the computer’s operating capability and battery charge status.
Battery indicator
Check the Battery indicator to determine the status of the battery. The following indicator lights indicate the battery status.
• Operates
• Alarm sounds (depending
on the Low Battery Alarm item of CMOS SETUP menu & TOSHIBA Power Saver setting)
• LED: Battery flashes amber
DC IN off
Computer goes into Hibernation or shuts down (depending on the TOSHIBA Power Saver setting)
• No operation
• LED: Battery off
DC IN off
Flashing amber The battery charge is low. The AC adapter must
be connected to recharge the battery
Amber Indicates the AC adapter is connected and
charging the battery.
Green Indicates the AC adapter is connected and the
battery is fully charged.
No light Under any other conditions, the indicator does
not light.
6-2 User’s Manual
Page 93
Power and Power-Up Modes
DC IN indicator
Check the DC IN indicator to determine the power status with the AC adapter connected:
Green Indicates the AC adapter is connected and
No light Indicates the AC adapter is not connected.
Power indicator
Check the Power indicator to determine the power status with the AC adapter connected:
Green The power button will light blue while power is
Blinking amber Indicates power is being supplied to the
No light Under any other conditions, the indicator does

Battery types

The computer has two types of batteries:
Battery pack
Real Time Clock (RTC) battery
supplying proper power to the computer.
being supplied to the computer and the computer is turned on. The power indicator on the front of the computer will light green while the system is on.
computer while the computer is in Standby mode.
not light.
Battery pack
When the AC adapter is not connected, the computer’s main power source is a removable lithium ion battery pack, also referred to in this manual as the battery.
You can purchase additional battery packs for extended use of the computer away from an AC power source.
The battery is a disposable item. When its operation becomes short even when fully charged, replace it with a new one.
The battery pack is a lithium ion battery, which can explode if not properly
replaced, used, handled or disposed of. Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements.
Do not remove the Battery Pack while the computer is in Standby mode.
Data is stored in RAM, so if the computer loses power, it will be lost.
User’s Manual 6-3
Page 94
Power and Power-Up Modes
Real Time Clock battery
The Real Time Clock (RTC) battery provides power for the internal real time clock and calendar. It also maintains the system configuration.
If the RTC battery becomes completely discharged, the system loses this data and the real time clock and calendar stop working. The following message appears when you turn on the power:
ERROR 0271: Check date and time settings. WARNING 0251: System CMOS checksum bad - Default configuration used. Press <F1> to resume, <F2> to Setup.
The computer’s RTC battery is a lithium battery and should be replaced only by your dealer or by a TOSHIBA service representative. The battery can explode if not properly replaced, used, handled or disposed of. Dispose of the battery as required by local ordinances or regulations.
When this error appears, the following action is recommended.
1. Plug in AC over 24 hours.
2. Press F2 to enter BIOS setup menu.
3. Set correct time and date.
If you still see an error message after taking above action, please contact your TOSHIBA service representative.

Care and use of the battery pack

The battery pack is a vital component of portable computing. Taking proper care of it will help ensure longer operating time on battery power as well as a longer life for your battery pack. Follow the instructions in this section carefully to ensure safe operation and maximum performance.
Safety precautions
Mishandling of batteries can cause death, serious injury or property damage.
Carefully observe the following advisories: Danger: Indicates an imminently hazardous situation, which could result in
death or serious injury, if you do not follow instructions. Warning: Indicates a potentially hazardous situation, which could result in
death or serious injury, if you do not follow instructions. Caution: Indicates a potentially hazardous situation, which if not avoided,
may result in moderate or minor injury or property damage. Note: Provides important information.
6-4 User’s Manual
Page 95
Power and Power-Up Modes
Danger
1. Never try to dispose of the battery pack by burning or expose it to a heating device such as a microwave oven. The battery pack could explode and cause bodily injury.
2. Never try to disassemble, repair or otherwise tamper with a battery pack. The battery pack will overheat and ignite. Leakage of caustic alkaline solution or other electrolytic substances will cause fire or injury, possibly resulting in death or serious injury.
3. Never short-circuit the battery pack by contacting the terminals with a metal object. A short-circuit can cause fire or otherwise damage the battery pack and possibly cause injury. To avoid accidental short-circuit, always wrap the battery pack in plastic and cover the terminals with electrical tape when storing or disposing of the battery pack.
4. Never puncture the battery pack with a nail or other sharp object. Never strike it with a hammer or other object. Never step on it.
5. Never try to charge the battery pack in any manner other than that described in the user’s manual. Never connect the battery pack to a plug socket or to an automobile’s cigarette lighter socket. It may rupture or ignite.
6. Use only the battery pack supplied with the computer or other device or a battery pack approved by the computer or device’s manufacturer. Battery packs have different voltages and terminal polarities. Use of an improper battery could cause smoke, fire or rupture of the battery pack.
7. Never subject a battery pack to heat, such as storage near a heat source. Exposure to heat can cause the battery pack to ignite, explode or leak caustic liquid and cause death or serious injury. It could also fail or malfunction causing data loss.
8. Never expose the battery pack to abnormal shock, vibration or pressure. The battery pack’s internal protective device will fail, causing it to overheat, explode, ignite or leak caustic liquids possibly resulting in death or serious injury.
9. Never let a battery pack become wet. A wet battery pack will overheat, ignite or rupture possibly resulting in death or serious injury.
Warning
1. Never allow caustic electrolyte fluid leaked from a battery pack to contact your eyes, skin or clothing. If caustic electrolyte fluid should contact your eyes, immediately wash your eyes with large amounts of running water and seek medical attention, to help prevent eye damage. It electrolyte fluid should contact your skin, immediately wash it under running water to prevent rash. If it contacts your clothes, promptly remove them to prevent the fluid from contacting your skin or eyes.
2. Immediately turn off the power, disconnect the AC adapter and remove the battery if any of the following events are observed in the battery pack: offensive or unusual odor, excessive heat, discoloration or deformation. Never use the computer again until it has been checked by a TOSHIBA service provider. It might generate smoke or fire, or the battery pack might rupture.
User’s Manual 6-5
Page 96
Power and Power-Up Modes
3. Make sure the battery is securely installed in the computer before attempting to charge the battery pack. Improper installation could generate smoke or fire, or cause the battery pack to rupture.
4. Keep the battery pack out or reach of infants and children. It can cause injury.
Caution
1. Never continue to use a battery pack after its recharging capacity has become impaired, or after the display of a warning message indicating that the battery pack’s power is exhausted. Continued use of an exhausted or impaired battery pack could cause the loss of data.
2. Never dispose of battery packs with normal trash. Bring them to your TOSHIBA dealer or to another recycling center to save resources and prevent environmental damage. Cover the terminals with electrical tape to prevent short-circuits, which could cause the battery pack to ignite or rupture.
3. Use only battery packs recommended by TOSHIBA as replacements.
4. Always make sure the battery pack is installed correctly and securely. Otherwise, a battery pack could fall out and possibly cause injury.
5. Charge the battery pack only in an ambient temperature between 5 and 30 degrees Celsius. Otherwise, the electrolyte solution might leak, battery pack performance might deteriorate and the battery life might be shortened.
6. Be sure to monitor the remaining battery power. If the battery pack and real time clock battery discharge completely, Standby Mode will not function and data in memory will be lost. Also, the computer might register an incorrect time and date. In this case, connect the AC adapter to recharge the batteries.
7. Never install or remove the battery pack without first turning off the power and disconnecting the AC adapter. Never remove the battery pack while the computer is in Standby Mode as data will be lost.
Note
1. Never remove the battery pack while the Wake-up on LAN function is enabled. Data will be lost. Before you remove a battery pack, disable the Wake-up on LAN function.
2. To ensure the battery pack maintains maximum capacity, operate the computer on battery power once a week until the battery pack is fully discharged. Refer to the section Extending battery life in this chapter for procedures. If the computer is continuously operated on AC power for an extended period, more than a week, the battery might fail to retain a charge. It might not function efficiently over the expected life of the battery pack and the Battery indicator might not indicate a low-battery condition.
3. After the battery pack is charged, avoid leaving the AC adapter connected and the computer turned off for more than a few hours at a time. Continuing to charge a fully charged battery pack can damage the battery.
6-6 User’s Manual
Page 97
Power and Power-Up Modes
Charging the batteries
When the power in the battery pack becomes low, the Battery indicator flashes amber indicating that only a few minutes of battery power remain. If you continue to use the computer while the Battery indicator flashes, the computer enables Hibernation mode (so you don’t lose data) and automatically turns off.
You must recharge a battery pack when it becomes discharged.
Procedures
To recharge a battery pack while it is installed in the computer, connect the AC adapter to the DC IN socket and plug the other end into a working outlet.
The Battery indicator glows amber when the battery is being charged.
Use only the computer connected to an AC power source to charge the battery pack. Do not attempt to charge the battery pack with any other charger.
Time
The following table shows the time required to fully charge a discharged battery.
Charging time (hours)
Battery type Power on Power off
Battery pack about 12 or longer about 4 or longer
RTC battery about 24 about 24 with AC or Battery pack
The charging time when the computer is on is affected by ambient temperature, the temperature of the computer and how you use the computer.
If you make heavy use of external devices, for example, the battery might scarcely charge at all during operation. Refer also to the section Maximizing battery operating time. The same factors affect charge time.
User’s Manual 6-7
Page 98
Power and Power-Up Modes
Battery charging notice
The battery may not charge right away under the following conditions:
The battery is extremely hot or cold. To make sure the battery charges
to its full capacity, charge the battery at room temperature of 10° to 30°C (50° to 86°F).
The battery is nearly completely discharged. Leave the AC adapter
connected for a few minutes and the battery should begin charging.
Once a battery pack is fully charged, it is recommended that you operate the computer only on battery power until the battery pack completely discharges. Doing so extends battery life and helps ensure accurate monitoring of battery capacity.
The Battery indicator may show a rapid decrease in battery operating time when you try to charge a battery under the following conditions:
The battery has not been used for a long time.
The battery has completely discharged and been left in the computer for
a long time.
A cool battery is installed in a warm computer.
In such cases, follow the steps below.
1. Fully discharge the battery by leaving it in the computer with the power on until the power automatically shuts off.
2. Plug in the AC adapter.
3. Charge the battery until the Battery indicator glows green.
Repeat these steps two or three times until the battery recovers normal capacity.
Leaving the AC adapter connected will shorten battery life. At least once a week, run the computer on battery power until the battery is fully discharged, then recharge the battery.
Monitoring battery capacity
Remaining battery power can be monitored by the TOSHIBA Power Saver. Refer to the Utilities section in Chapter 1, Introduction.
Wait for a moment after turning on the computer before trying to monitor
the remaining operating time. The computer needs this time to check the battery’s remaining capacity.
With repeated discharges and recharges, the battery’s capacity will
gradually decrease. Therefore, an often used, older battery will not operate for as long as a new battery even when both are fully charged.
6-8 User’s Manual
Page 99
Power and Power-Up Modes
Maximizing battery operating time
A battery’s usefulness depends on how long it can supply power on a single charge.
How long the charge lasts in a battery depends on:
How you configure the computer (for example, whether you enable
battery power saving options). The computer provides a battery save mode to conserve battery power. This mode has the following options:
Display auto off
Hard Disk Drive auto off
System auto off
LCD brightness
How often and how long you use the hard disk,
CD-ROM and the diskette drive (if one is connected).
How much charge the battery contained to begin with.
How you use optional devices, such as a PC Card,
to which the battery supplies power.
Enabling Standby Mode conserves battery power if you are frequently
turning the computer off and on.
Where you store your programs and data.
Closing the display when you are not using the keyboard saves power.
Operating time decreases at low temperatures.
The condition of the battery terminals. Make sure the battery terminals
stay clean by wiping them with a clean dry cloth before installing the battery pack.
Retaining data with power off (standby mode)
When you turn off your computer with fully charged batteries, the batteries retain data for the following approximate time periods:
Battery Approximately 1.5 days (Standby mode)
RTC battery Approximately 1 month
Approximately 1 month (Shut down mode)
Extending battery life
To maximize the life of your battery pack:
If you have extra battery packs, rotate their use.
If you will not be using the system for an extended period, remove the
battery pack.
Store spare battery packs in a cool dry place out of direct sunlight.
User’s Manual 6-9
Page 100
Power and Power-Up Modes

Replacing the battery pack

When the battery pack reaches the end of its operating life you will need to install a new one. If the Battery indicator flashes amber shortly after the battery has been fully recharged, the battery pack needs to be replaced.
You might also replace a discharged battery pack with a charged spare when you are operating your computer away from an AC power source. This section explains how to remove and install the battery pack.
Removing the battery pack
To replace a discharged battery pack, follow the steps below.
When handling battery packs, be careful not to short circuit the terminals.
Also do not drop, hit or otherwise apply impact; do not scratch or break the casing and do not twist or bend the battery pack.
Do not remove the battery pack while the computer is in Standby mode.
Data in memory will be lost.
1. Save your work.
2. Turn the computer’s power off. Make sure the Power indicator is off.
3. Remove all cables connected to the computer.
4. Turn the computer upside down.
5. Slide the battery pack latch, then pull the battery out of the bay.
Removing the battery pack
6-10 User’s Manual
Loading...
