Toshiba L7361-58 User Manual

Download

USER MANUAL

L73** Digital Series

M83** Digital Series

English

INSTALLING YOUR TV

Safety Precautions .......................................................4

Installation and important information ..........................5

The remote control ............................... ... .....................7

Inserting batteries and effective range..................7

CONNECTING YOUR TV

Connecting external equipment....................................8

Connecting an HDMI

To connect an HDMI device..................................9

HDMI’s ARC (Audio Return Channel) feature.......9

Connecting an HDMI CEC Control compatible

device......................................................................10

Connecting a computer..............................................11

To connect a PC to the HDMI terminal...............11

To connect a PC to the RGB/PC terminal...........11

Connecting a home network.......................................12

To connect the TV to a home network - Wired....12

To connect the TV to a home network with an

internet connection - Wireless..........................12

To connect the TV to the PC with

Intel

Controls and input connections..................................13

Switching on........................................................13

Using the TV controls and connections...............13

Using the menu system.......................................14

SETTING UP YOUR TV

Startup Application .....................................................15

Quick Setup................. ... ............................... ... .. .1 5

Ant/Cable/Satellite (if available)....................... ...20

Satellite Settings .................................................21

Auto Tuning . ................................ .. ... ... ................22

ATV Manual Tuning....................................................23

Tuning.................................................................23

Skip.....................................................................24

Sorting positions..................................................25

DTV Manual Tuning .............. .. ... ................................2 5

Manual Tuning ....................................................25

Manual Tuning for DVB-C...................................26

Manual Tuning for DVB-S...................................26

DTV Settings ...................................... ........................26

Channels (Antenna/Cable)..................................26

Channels (Satellite).............................................27

Standby Channel Update....................................27

Location setting...................................................27

Analogue switch-off.............................................27

CONTROLS AND FEATURES

General controls.........................................................28

Quick Menu........................................... ... ... ........28

Selecting channels..............................................28

The Time Display – analogue only.....................28

Stereo and Bilingual transmissions.....................29

Using 3D functions .....................................................29

Viewing 3D images .............................................29

device.......................................9

Wireless Display.....................................12

Switching display mode or selecting 3D format..30

Setting the auto start mode............... .. ... .............31

Adjusting 2D to 3D Depth ...................................32

Setting the 3D PIN code ..................................... 32

Setting 3D Start Message...................................32

Setting 3D Lock...................................................33

Setting 3D Timer Lock ........................ ................33

Setting Enable 3D Timer.....................................33

Displaying 3D Important Info...............................33

Switching left and right images...........................33

Sound controls ........................................................... 34

Volume controls and sound mute ....................... 34

Dual..................................................................... 34

Balance............................................................... 34

Bass, Treble........................................................ 34

TV Mounting (Wall/Table) ................................... 34

Dynamic Volume

Audyssey ABX™................................................. 34

Dynamic Range Control......................................3 4

Audio Level Offset............. ... .. ............................. 35

TV Speakers On/Off............................................35

Headphone Settings...........................................35

Audio Description................... ... .......................... 35

Widescreen viewing ...................................................36

Picture controls ..........................................................38

Picture Mode.......................................................38

Picture preferences.............................................38

Reset...................................................................38

ColourMaster ...................................................... 38

Base Colour Adjustment ..................................... 39

Colour Temperature....................... ... ..................39

Auto Brightness Sensor ......................................39

Active Backlight Control......................................39

Black/White Level ............................. .. ................3 9

MPEG NR – Noise Reduction.......................... ... 40

DNR – Digital Noise Reduction...........................40

Resolution +........................................................40

ClearScan ...........................................................40

Resetting the advanced picture settings.............40

Expert Picture Settings ....................................... 40

Automatic Format (Widescreen).........................42

4:3 Stretch............... .. ..........................................42

Picture Position...................................................42

Picture still...........................................................42

HDMI Information Display ...................................42

Wireless LAN Information ..........................................43

Setting up the Network...............................................44

Wireless Setup.................................................... 44

Advanced Network Setup ...................................47

DNS Setup..........................................................48

Network Connection Test....................................48

Using the software keyboard ...................... ........49

Network Device Setup. .................................. ... .. ........49

Apps Control Profile............................................49

TV Power On Control (Active Standby) ..............50

Media Renderer Setup........................................ 50

Device Name Setup.......... ............................... ... 50

USB HDD Record Function........................................51

...............................................34

Setting up the USB HDD for recording................51

To record DTV programmes (One Touch

Recording)........................................................51

How to set recordings via the Programme

Guide................................................................52

To check, edit or delete scheduling information..54

To view a recorded programme ..........................54

Operations from the Library screen.....................55

Recording Setup .............................. ...................56

Scheduling priority...............................................57

Using the Cloud TV Service .................................... .. .57

Using Web Browser ............................ .. ..............57

Using Skype.............. .. ... .. .................................. .5 9

Using Hybrid TV Standard (if available) .....................64

Using Intel

Using the Media Player .............................. .. ..............65

Other features ............................................................73

The timers ........................ .. ... .....................................74

Energy Saving Settings ........................................... ...7 5

Digital on-screen information......................................75

Using EPG (Electronic Programme Guide)................76

Digital settings – parental control ...............................77

Digital settings – Channel Options.............................78

Digital settings – other settings ..................................79

Wireless Display....................... ... ...........64

Intel

WiDi Device Name....................................65

Device List...........................................................65

Basic operation ...................................................66

Viewing photo files (on a media server or USB

device)..............................................................67

Viewing movie files (on a media server or USB

device)..............................................................69

Playing music files (on a media server or USB

device)..............................................................72

Panel Lock ......... .................................................73

Blue Screen.........................................................73

Netflix

................................................................73

Programme Timers – digital only.......................74

On Timer .............................................................74

Sleep Timer.........................................................74

Automatic Power Down.......................................75

No Signal Power Down.......................................75

Information ..........................................................75

Using Broadcast Guide.......................................76

Genre selection/searching .................... ... ... ........77

Parental PIN Setup .......................... ...................77

Parental Setup ......................... ... .. ......................78

Selecting favourite channels...............................78

Favourite Channel List........................................78

Skip channels......................................................79

Locking channels................................................79

Subtitles..............................................................79

Audio languages.................................................79

Common Interface .............................................. 80

Software Upgrade and Licences................................80

Searching for New Software ............................... 80

Network Upgrade................................................80

Software Licences...............................................81

System Information and Reset TV .............................81

System Information.............................................81

Reset TV.............................................................81

PC Settings ................................................................ 82

Horizontal and Vertical Position..........................82

Clock Phase........................................................82

Sampling Clock...................................................82

Reset...................................................................82

Input selection and AV connections...........................83

Input selection..................................................... 83

Labelling video input sources..............................83

Digital Audio Output............................................84

Using HDMI CEC Control...........................................85

Enable HDMI CEC Control .................................85

TV Auto Power ............................... ... .. ................8 5

Auto Standby.................................. ....................85

Amplifier Control ................................. ... .............85

Initial Speaker Setting.........................................85

HDMI CEC Control input source selection..........85

HDMI CEC Control one touch play.....................86

HDMI CEC Control system standby....................86

Using MHL TV function ..............................................86

Connecting an MHL-compatible device..............86

Operating an MHL-compatible device.................86

MHL Setup..........................................................86

TEXT SERVICES

Text services.............................................................. 87

Selecting modes ............................ ..................... 87

Text information .................................................. 87

Navigating pages using Auto.............................. 87

Navigating pages using LIST..............................87

Control buttons....................................................88

PROBLEM SOLVING

Questions and Answers .......................................... 89

INFORMATION

Information ................................................................. 92

Licence information ....................................................98

Cautions and other information for 3D ..................... 100

Specifications and accessories................................ 102

English

During the life of your TV f irmware updates will be made available to ensure that your TV maintains optimum performance:

If your TV is connected to the internet, firmware will be automatically made available.

If your TV is not connected to the internet, you can download the latest version of firmware from

*Some features are limited due to local legislation and may not be available in all countries.

www.toshiba-om.net/firmware.php

INSTALLING YOUR TV

Safety Precautions

English

This equipment has been designed and manufactured to meet international safety standards but, like any e lectrical equipment, care must be taken to obtain the best results and for safety to be assured. Please read the poin ts below for your own safety. They are of a general nature, intended to help with all electronic consumer products, and some points may not apply to the goods you have just purchased.

Air Circulation

Leave more than 10 cm clearance around the television t o allow adequate ventilation. This will prevent overheating and possible damage to the television. Dusty places should also be avoided. For wall mounted positions at least 2.5 cm gap was retained from the wall and the 10cm was kept clear around all edges of the TV.

Heat Damage

Damage may occur if the television is left in direct sunlight or near a heater. Avoid places subject to extremely high temperatures or humidity. Place in a location where the temperature remains between 5 °C min. and 35°C max.

Mains Supply

The mains supply required for this equipment is 220-240V AC 50 Hz. Never connect to a DC supply or any other power source. DO ensure that the television is not standing on the mains lead. DO NOT cut off the mains plug from this equipment, this incorporates a special Radio Interference Filter, the removal of which will impair its performance. IF IN DOUBT, PLEASE CONSULT A COMPETENT ELECTRICIAN.

DO read the operating instructions before you attempt t o

use the equipment.

DO ensure that all electrical connections (including the

mains plug, extension leads and inter-connections between pieces of equipment) are properly made and in accordance with the manufacturers’ instructions. Switch off and withdraw the mains plug before making or changing connections.

DO consult your dealer if you are ever in doubt about the

installation, operation or safety of your equipment.

WARNING: To prevent injury, this apparatus must be

securely attached to the floor/wall in accordance with the installation instructions. See page 5.

DO be careful with glass panels or stands on equipment. DO use a soft, dry cloth to clean the unit.

DO NOT REMOVE ANY FIXED COVERS AS THIS WILL EXPOSE DANGEROUS AND ‘LIVE’ PARTS.

THE MAINS PLUG IS USED AS THE DISCONNECTING DEVICE AND THEREFORE SHOULD BE READILY OPERABLE.

Do not

DO NOT obstruct the ventilation openings of the

equipment with items such as newspapers, tablecloths, curtains, etc. Overheating will cause damage and shorten the life of the equipment.

DO NOT allow electrical equipment to be exposed to

dripping or splashing or objects filled with liquids, such as vases, to be placed on the equipment.

DO NOT place hot objects or naked flame sources, such

as lighted candles or nightlights on, or close to equipment. High temperatures can melt plastic and lead to fires.

WARNING: To prevent the spread of

fire, keep candles or other open flames away from this product at all times.

DO NOT use makeshift stands and NEVER fix legs with

wood screws.

DO NOT leave equipment switched on when it is

unattended, unless it is specifically stated that it is designed for unattended operation or has a standby mode. Switch off by withdrawing the plug, and make sure your family knows how to do this. Special arrangements may need to be made for people with disabilities.

DO NOT continue to operate the equipment if you are in

any doubt about it working normally, or it is damaged in any way – switch off, withdraw the mains plug and consult your dealer.

DO NOT push/pull CI CAM at a tilt to prevent breakdown

of COMMON INTERFACE.

WARNING: Excessive sound pressure from earphones

or headphones can cause hearing loss.

ABOVE ALL - NEVER let anyone, especially children, push or hit the screen and cabinet back, or push anything into holes, slots or any other openings in the case. These actions will damage screen or internal parts.

NEVER guess or take chances with electrical equipment of any kind - it is better to be safe than sorry.

INSTALLING YOUR TV

Stand style is dependent on model

Screw (supplied)

9 mm

4 mm

20 mm

Screws

Installation and important information

Where to install

Locate the television away from direct sunlight and strong lights. Soft, indirect lighting is recommended for comfortable viewing. Use curtains or blinds to prevent direct sunlight falling on the screen.

Place the TV on a stable, level surface that can support the weight of the TV. In order to prevent injury and maintain stability of this apparatus, secure the TV using the fixing in the stand.

The LCD display panels are manufactured using an extremely high level of precision technology; however, sometimes some parts of the screen may be missing picture elements or have luminous spots. This is not a sign of a malfunction.

Make sure the television is located in a position where it cannot be pushed or hit by objects, as pressure will break or damage the screen. Also, please be certain that small items cannot be inserted into slots or openings in the case.

Avoid using chemicals (such as air refreshers, cleaning agents, etc.) on or near the TV pedestal.

chemical agents and mechanical stress (such as weight of TV). Failure to follow these instructions could result in serious injury and/or permanent damage to TV and TV pedestal.

Use a wall bracket appropriate for the size and weight of the LCD TV.

• Two people are required for installation.

• Install a wall-mount from another manufacturer.

1 Unplug and remove any cables and/or other

2 Carefully lay the front of the unit face down on a flat,

3 Follow the instructions provided with your wall bracket.

4 Always use the screws supplied or recommended by

Studies indicate that plastics may weaken and crack over time from the combination effects of

When using a Wall Bracket

Removing the Pedestal Stand:

1 Carefully lay the front of the unit face down on a flat,

cushioned surface such as a quilt or blanket. Leave the stand protruding over the edge of the surface.

component connectors from the rear of the TV.

cushioned surface such as a quilt or blanket.

Before proceeding, make sure the appropriate bracket(s) are attached to the wall and the back of the TV as described in the instructions provided with the wall bracket.

the wall mount manufacturer.

NOTE: Extreme care should always be used when removing the pedestal stand to avoid damage to the LCD panel.

2 Remove the cover and screws.

3 Once you have removed all screws holding the

pedestal stand in place, remove the pedestal stand from the TV by sliding the pedestal stand away from the TV.

English

When using MHL (Mobile High-definition Link)

• Interoperability with MHL devices of other manufacturers is not guaranteed.

• Toshiba does not provide any guarantee, therefore, against operational failure such as that described below when an MHL source is connected to the TV.

- No picture or sound

- Some of the functions do not work by remote

operation from the TV

• If the MHL does not work properly, also contact the manufacturer of the source device for advice on its use.

INSTALLING YOUR TV

English

The digital reception function of this television is only effective in the countries listed in the “Country” section of the “Installation” menu. Depending on country/area, some of this television's functions may not be available. Reception of future additional or modified services can not be guaranteed with this television.

If stationary images generated by 4:3 broadcasts, text services, channel identification logos, computer displays, video games, on-screen menus, etc. are left on the television screen for any length of time, they could become conspicuous. It is always advisable to reduce both the brightness and contrast settings.

Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at the 4:3 outlines. This is not a defect of the LCD TV and is not covered under the manufacturer’s warranty. Regular use of other size modes (e.g. Super Live) will prevent permanent retention.

Please take note

EXCLUSION CLAUSE

Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by: i) Fire;

ii) Earthquake; iii) Accidental damage; iv) Intentional misuse of the product; v) Use of the product in improper conditions; vi) Loss and/or damage caused to the product whilst in the possession of a third party; vii) Any damage or loss caused as a result of the owner’s failure and/or neglect to follow the instructions set out in the

owner’s manual;

viii)Any loss or damage caused directly as a result of misuse or malfunction of the product when used simultaneously

with associated equipment;

Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not limited to the following: loss of profit, interruption of business, th e loss of recorded data whether caused during normal operation or misuse of the product.

When Using a USB Hard Drive (HDD)

• The recording function has been designed for private use and entertainment in your home environment. Please note that any commercial use of the recording function could lead to copyright infringement of authors’ rights. Toshiba asks you to respect the intellectual property rights of third parties.

• Before recording to a device connected to the TV, make a test recording and check the recording performance.

• Programmes that are prohibited from copying due to copyright protection cannot be recorded.

• Toshiba shall not be liable for compensation or incidental damages of any kind whatsoever resulting from content that was not properly recorded on the recording device or that was modified or lost.

• Toshiba shall not be liable for damages of any kind whatsoever (breakdown of the recording device, modification or loss of the recorded content, etc.) resulting from malfunction, operating failure or incorrect operation due to combining with another connected device.

• If you connect a USB HDD that has been used with a PC or another TV, only programmes which are recorded using this TV can be playback.

• Switch the TV to standby before you disconnect the USB HDD.

Not doing so may result in loss of the recorded data or malfunction of the USB HDD.

• Please note that recording on the USB HDD is no longer playable after the TV’s main-board is exchanged during service.

INSTALLING YOUR TV

English

The remote control

Simple at-a-glance reference of your remote control.

1 2 4 5 7

11 13

14 16

18 19 21

23 25

27 28

29 31

3 6

8 9

12 15

17 20

22 24

19 - Accesses the CLOUD HOME 20 - Accesses to premium content available

online

21 To access the on-screen Menu 22 To display the digital on-screen Programme Guide 23 To page up, down, left or right 24 When using menus, the arrows move the cursor on the

screen up, down, left or right. Pr ess OK to confirm your selection

25 To return to previous Menu 26 To exit menus and applications 27 When in TV mode:

Analogue time display

When in Text mode:

To reveal concealed text

To hold a wanted page

To enlarge text display size

To erase Text pages temporarily when you are viewing in teletext mode.

During Playback:

c To PLAY v To STOP W To PAUSE Z To SKIP-BACK CC To REWIND cc To FAST FORWARD z To SKIP FORWARD

28 To access the analogue or digital Channel List 29 To call up text services 30 To record DTV programmes 31 Colour buttons: Text and interactive service control

tons

1 For On/Standby mode 2 To select external input sources 3 To select TV Mode 4 Selectable Picture 5 Widescreen viewing 6 Picture still 7 Digital Subtitles or Analogue TEXT Subtitle pages if

available

Stereo/bilingual transmissions

9 To switch between 2D / 3D modes 10 Number butt o ns 11 Switch the Audio Description On/Off 12 To return to previous channel 13 To display on-screen information

To access the index page in Text mode

14 To alter the TV volume 15 To change programme positions

To change TEXT pages

16 To mute the TV sound 17 To access Quick Menu 18 - Accesses the Search Portal

Inserting batteries and effective range

Remove the back cover to reveal the battery compartment and make sure the batteries are inserted the proper way. Suitable battery types for this remote control are AAA, IEC R03 1.5 V.

Do not combine a used, old battery with a new one or mix

exhausted batteries immediately to prevent acid from leaking into the battery compartment. Dispose of them in accordance with instructions on page 99 of this manual.

Warning: Batteries must not be exposed to excessive heat such as sunshine, fire or the like.

The performance of the remote control will deteriorate beyond a distance of five metres or outside an a ngle of 30 degrees from the centre of the television. If the operating range becomes reduced, the batteries may need replacing.

battery types. Remove

CONNECTING YOUR TV

ILLUSTRATION SHOWS 40L.

Satellite dish

* A Decoder can be digital Satellite, free to air or any

other compatible decoder / recorder.

Decoder*

LAN port

COMPONENT VIDEO/AUDIO INPUT

VIDEO/AUDIO INPUT (Y/L/R) (EXT 2)

SCART (EXT 1)

DVB Common Interface (for Conditional Access Module (CAM))

Headphones

HDMI (1~3)

USB (1~2)

HDMI 4 INPUT DIGITAL AUDIO OUTPUT

(OPTICAL) RGB/PC INPUT

LNB IN SATELLITE ANTENNA (L736*/M836* series only)

Aerial

Aerial Cable

Power cord

Connecting external equipment

English

Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the mains plug from the wall socket.

40L/40M 50L/50M/58L/58M

Aerial cables: . . . . . . . . . . . . . . . . . . . . . . . .

Connect the aerial to the socket on the rear of the TV. If you use a decoder and/or a media recorder, it is essential that the aerial cable is connected through the decoder and/or through the media recorder to the TV.

Satellite cable: . . . . . . . . . . . . . . . . . . . . . . .

Connect the LNB from the satellite dish to the SATELLITE ANTENNA socket on the TV. You can receive TV, radio, interactive TV, and HD TV with clear reception.

SCART leads: . . . . . . . . . . . . . . . . . . . . . . . .

Connect the media recorder IN/OUT socket to the television. Connect the decoder TV socket to the television.

Before running Auto Tuning, put your decoder and media recorder to Standby.

The RCA sockets alongside the COMPONENT VIDEO INPUT sockets will accept L and R audio signals.

When connecting the VIDEO/AUDIO devices, connect those cables to Y/L/R sockets.

The Digital Audio Output socket enables the connection of a suitable surround sound system.

NOTE: This output is always active.

(High-Definition Multimedia Interface) is for use

HDMI with electrical equipment with digital audio and video output. It is designed for best performance wit h 1080i and 1080p high-definition video signals but will also accept and display VGA, 480i, 480p, 576i, 576p and 720p signals.

PC format signals will also be displayed. NOTE: Although this television is able to conn ect to HDMI

equipment, it is possible that some equipment may not operate correctly.

LAN port is used to connect the TV to your home network. A wide variety of external equipment can be

connected to the back of the television; therefore, the relevant owner’s manuals for all additional equipment must be referred to for exact instructions.

If the television automatically switches over to monitor external equipment, return to normal televisi on by pressing the desired programme position button. To recall external equipment, press EXT 1, EXT 2, HDMI 1, HDMI 2, HDMI 3, HDMI 4 or PC.

When the external input mode is selected while viewing DTV mode, the SCART socket does not output video/ audio signals.

o to select between TV,

CONNECTING YOUR TV

HDMI cable

the back and side of your television

HDMI device

HDMI cable

AV amplifier that supports ARC

the side of your television

English

Connecting an HDMI® device

The HDMI input on your television receives digital audio and uncompressed digital video from an HDMI source device.

This input is designed to accept HDCP (High-Bandwidth Digital Content Protection) programme material in digital form from EIA/CEA-861-D–compliant consumer electronic devices (such as a set-top box or DVD player with HDMI output). For acceptable video signal formats, see page 93.

NOTE: Supported Audio format: Linear PCM, Dolby Digital (AC-3), sampling rate 32/44.1/48 kHz.

To connect an HDMI device

Connect an HDMI cable (type A connector) to the HDMI terminal.

For proper operation, it is recommended that you use an HDMI cable with the HDMI Logo ( ).

• If your HDMI connection is capable of 1080p and/or you r television is capable of refresh rates greater than 50 Hz, you will need a Category 2 cable. Conventional HDMI/ DVI cable may not work properly with this model.

• HDMI cable transfers both video and audio. Separate analogue audio cables are not required (see illustration).

HDMI’s ARC (Audio Return Channel)

feature

This feature enables the audio signal of the TV t o be sen t to the AV amplifier via the HDMI cable. It will not be necessary to connect a cable from the audio output of the TV to the audio input of the AV amplifier to r eprod uce the audio received from the tuner of the TV through the AV amplifier.

To view the HDMI device video, press HDMI 1, HDMI 2, HDMI 3 or HDMI 4 mode.

o to select

CONNECTING YOUR TV

the side of your television

AV amplifier

Playback device

Connecting an HDMI CEC Control compatible device

English

You can control the basic functions of connected audio /video devi ces using the televi sion’s remote control if you connect an HDMI CEC compatible AV ampli fier or playback device. For an e xplanation of setup and operations, see pages 85–86.

For the setup shown above, you will need three HDMI cables.

NOTE:

• If several devices are connected, the HDMI CEC Control feature may not operate properly.

• For proper operation, it is recommended that you use HDMI cables with the HDMI Logo ( ).

• This function is available when one PC and one AV amplifier are connected separately. However, it may not operate properly if the PC is connected via the AV amplifier.

Before controlling the device(s):

• After completing the above connections, set the HDMI CEC Control Setup menu as you desire (see page 85).

• The connected devices must also be set. For details, see the operation manual for each device.

• The HDMI CEC Control feature uses CEC technology as regulated by the HDMI standard.

• This feature is limited to models incorporating Toshiba’s HDMI CEC Control. However, Toshiba is not liable for those operations. Refer to individual instruction manuals for compatibility information.

CONNECTING YOUR TV

HDMI cable

Computer

the side of your television

HDMI-to-DVI

adaptor cable

Computer

the side of your televi sion

Mini D-sub 15 pin connector

RGB PC cable

(not supplied)

Conversion adaptor if required (not supplied)

Computer

the back of your television

English

Connecting a computer

With either an HDMI or an RGB/PC connection, you can watch your computer’s display on the television.

To connect a PC to the HDMI

terminal

When connecting a PC to the HDMI terminal on the television, use an HDMI cable (type A connector).

If connecting a PC with DVI terminal, use an HDMI- to-DVI adaptor cable.

For acceptable PC and video signal formats, see page 93.

NOTE:

• The edges of the images may be hidden.

• If connecting a certain PC model with a unique PC signal, the PC signal may not be detected correctly.

To connect a PC to the RGB/PC

terminal

When connecting a PC to the RGB/PC terminal on the television, use an analogue RGB (15-pin) computer cabl e.

To use a PC, set the monitor output resolution on the PC before connecting it to the television. For acceptable PC signal formats, see page 92.

To display the optimum picture, use the PC setting feature (see page 82).

NOTE:

• Some PC models cannot be connected to this televisio n.

• An adaptor is not needed for computers with a compatible mini D-sub15-pin terminal.

• Depending on the DVD’s title and the specifications of the PC on which you are playing the DVD-Video, some scenes may be skipped or you may not be able to pause during multi-angle scenes.

• A band may appear at the edges of the screen or parts of the picture may be obscured. This is due to scaling of the picture by the set, it is not a malfunction.

• When PC input mode is selected, some of the television’s features will be unavailable e.g. Colour System in the Options menu.

• Some PC models may output unique signals that the television may be unable to detect (see page 92).

• If connecting a certain PC model with a unique PC signal, the PC signal may not be detected correctly.

CONNECTING YOUR TV

Cable or Phone jack

the back of your television

Modem (if available) Router with Hub

Server PC

Access point (AP)

Wireless LAN router

Modem

Computer

PC with Intel®

Wireless Display

Connecting a home network

English

The LAN port allows your Toshiba TV to connect to your home network. You can use this revolutionary home entertainment networking system to access photo, video and audio files that are stored on a media server and play/ display them on your TV.

NOTE:

• If you connect to a shared network outside your home, it is advisable to use a router. Always use network media products in private network environments. Connect this TV to the same router as other network media products (server).

• If you use a hub or switch to connect the TV to your home network, you may not be able to use the automatic setup and will have to manually set up the network address. See page 47.

• If you use a router with built-in DHCP functionality, use the automatic setup. Manual setup may not work.

• If you connect the TV and PC directly, use a crossover LAN cable.

• Please consult your PC manufacturer about details of PC settings.

• Wireless appliances may interfere with Intel Display.

Wireless

To connect the TV to a home network

- Wired

[1] [2]

[2]

To connect the TV to a home network

with an internet connection - Wireless

Please refer to “Wireless Setup” section on page 44.

NOTE:

• If this device is going to be operated in the frequency range of 5.15 GHz to 5.35 GHz, it is restr icted to ind oor use.

• If this device is going to be operated for 802.11b/g/n function in the frequency range of 2.454 GHz to

2.4835 GHz in France, it is restricted to indoor use.

• A general authorization is required for using this device outdoors or in public places in Italy.

• This device is NOT ALLOWED to be used in the geographical area within a radius of 20 km from the centre of Ny-Alesund in Norway.

• Make the wireless LAN appropriate security setting at the time of wireless LAN use to prevent the illegal use, spoofing and interception of communications.

• Don't connect wireless LAN to an outside network directly. Apply the wireless LAN access point with router function or broadband router. Make the router appropriate security setting to prevent the illegal use. Refer to the manual of router for a security setting.

[3][2]

To connect the TV to the PC with

Intel

Wireless Display

[1] Coaxial or telephone cable (depending on your modem type) [2] Standard LAN cable [3] Do not connect a phone jack directly to the TV’s LAN port.

Warning: This TV complies with the EMC directive only when you use a shielded Cat5 ethernet cable.

Intel® WiDi

CONNECTING YOUR TV

The Common Interface is for a Conditional Access Module (CAM). Contact a service provider. The software updating of CI Plus CAM may be automatically executed. At this time, your Recording/Reminder programming will be cancelled.

Control panel

USB ports

Power LED On = Green Standby = Red

ILLUSTRATION SHOWS 40L.

Remote sensor

DVB COMMON INTERFACE

Media Player/USB HDD connection port

Light sensor

Controls and input connections

A wide variety of external equipment can be connected to the input sockets on the side of the television.

While all the necessary adjustments and controls for the television are made using the remote control, the buttons on the television may be used for some functions.

English

Switching on

If the RED LED is not lit, check that the mains plug is connected to the power supply and press control; it may take a few moments. The GREEN LED will be lit.

To put the television into Standby, press control. To view the television, press may take a few seconds to appear.

For energy saving:

We recommend that you use the television with the factory settings. The factory settings are for energy saving. Unplugging the mains plug will cut energy use to zero for all televisions. This is recommended when the television is not being used for a long time, e.g. when on holiday. Reducing the brightness of the screen will reduce energy use. Energy efficiency cuts energy consumption and can save money.

NOTE: Putting the television into Standby will reduce energy consumption, but will still draw some power.

1 on the remote

1 again. The picture

Using the TV controls and

connections

• To turn on or off the TV, press

• To alter the volume, press + or –. + and – buttons operate as volume up/down as default.

p / o repeatedly to switch the function of 2 +/

•Press

– button as below. Channel→Input→Volume

The Media Player feature provides access to photo, movie and music files stored on a USB storage device that is connected via the USB 1 or USB 2 port or on a network device.

Please always refer to the owner’s manual of the equipment to be connected for full details.

NOTE:

• The USB socket has limited functionality and Toshiba can take no responsibility for damage to other connected equipment.

• Interactive video games that involve shooting a “gun” at an on-screen target may not work with this TV.

CONNECTING YOUR TV

English

Press on the remote control to display the menu. The menu appears as a list of eight topics. As each icon is

selected by pressing respective options will appear on the right.

NOTE: The same menu is displayed in DTV (Digital TV) and ATV (Analogue TV) modes; however, where some items are not available in a mode, they will appear gre yed out.

Using the menu system

B / b on the remote control, its

Press B / b and OK or c

Picture Mode


Press B / b Press B / b and OK or c

Sound

Reset Backlight Contrast Brightness Colour Tint Sharpness Advanced Picture Settings Expert Picture Settings Display Settings

Balance Bass Treble Audyssey Premium Television Dynamic Range Control Dual Audio Level Offset TV Speakers Headphone Level Audio Description Digital Audio Output

Press B / b Press B / b and OK or c

Recording Setup

Options

Press B / b Press B / b and OK or c

Installation

Press B / b Press B / b and OK or c

Network

Press B / b Press B / b and OK or c

Timers

Press B / b Press B / b and OK or c

Get Help

Media Player Setup MHL Setup HDMI CEC Control Setup Hybrid TV Standard Teletext Panel Lock AV Connection Power Management Blue Screen HDMI Information Display

Menu Language Country Location Channel Tuning DTV Settings Quick Setup Reset TV

Network Setup Network Device Setup Smart Apps Setup

3D Auto Start 2D to 3D Depth 3D PIN 3D Safety Settings 3D Important Info

On Timer Sleep Timer

Software Licences Software Upgrade System Information Store Demo

SETTING UP YOUR TV

Quick Setup

Country

Location

Network

Smart TV

Channel Tuning

Country/Language 1/3

Welcome

Thank you for choosing Toshiba TV

Country Germany Primary Subtitle Language German Secondary Subtitle Language Turkish Primary Audio Language German Secondary Audio Language English

German

Greek Greenlandic Hungarian Icelandic Irish Italian Kurdish

Previous Next

Quick Setup

Country

Location

Network

Smart TV

Channel Tuning

Location 1/2

To set up the TV for use within a showroom, please select [Store] from the menu below.

[Home] is recommended for normal use. * Power requirement for Store mode will be

higher due to automatic store demos.

Previous Next

Home Store

Quick Setup

Country

Location

Network

Smart TV

Channel Tuning

Network Type 1/5

Network setup allows you to access content on your home network and the Internet. Enjoy online video, music, games, news and more provided by Smart TV portal* and keep your TV up to date with new software.

* Availability is dependant on country

selection

Please select from Wired or Wireless

Previous Next

Network Type Wired

Skip

Wired

Wireless

Quick Setup

Country

Location

Network

Smart TV

Channel Tuning

Wireless Setup 2/5

Please select a wireless network setup option. Assisted Setup is recommended.

Previous Next

Easy Setup

Assisted Setup

Wireless Setup Easy Setup

Manual Setup

English

Startup Application

Before switching on the TV make sure that your aerial is connected and any decoder / media recorder, if applicable is connected and in

Standby.

Quick Setup

a Press the 1 button, Toshiba logo will appear. After

that, The Menu Language screen will appear. This screen will appear the first time that the television is switched on and each time Reset TV is executed.

b Press BbC c to select the menu language and

press OK. The Country/Language screen will appear.

Menu Language

Please press [OK] to proceed.

English Français Deutsch Español

Italiano

Densk

Türkçe

Pусский

Ελληνικα Hrvatski Укpaϊнcькa Slovenščina

c Press B /b to h ighlight Country and press c and

B / b to select your country.

Português Nederlands Svenska

Norska Suomi Polski

Magyar Slovensky

Română Български Srpski

Český

d Press BbC c to highlight Next and press OK.

The Location screen will appear.

e Press B / b to select Home or Store and press

OK. For normal home use, select Home.

f Press BbC c to highlight Next and press OK.

The Network Type screen will appear.

g Press B to highlight Network Type and then press

c and B / b to select Wireless. Press OK.

• When you select Wired (LAN cable connection) , skip to step 14.

h Press BbC c to highlight Next and press OK.

The Wireless Setup screen will appear.

i Press B to highlight Wireless Setup and then

press

c and B / b to select the Wireless Setup

type. Press OK.

NOTE:

• The following display menus will differ slightly according to the country you selected.

• If there is not a country that you want to select in the list, select Others.

SETTING UP YOUR TV

There are 3 methods for Wireless Setup:

English

• Easy Setup (WPS) - If the AP supports WPS, this method can be used. WPS is an industry standard designed to make connection of wireless LAN equipment and security setup easy. WPS will automatically configure all wireless settings.

NOTE: WEP encryption may not be able to configured by easy setup.

• Assisted Setup - follow step 11. Input the Security Key only.

• Manual Setup, skip to step 12. Input the all settings.

NOTE: EXIT is available during settings.

j In step 9, when you select Easy Setup;

Press

BbC c to highlight Next and press OK.

The Easy Setup screen will appear. Press

c and B / b to select PBC (Push Button

Configuration) or PIN (Personal Identification Number) and press OK.

Press

b to highlight Start Scan and press OK.

PBC - Following the on-screen instructions, push

the appropriate button on your AP. When a window reporting that the setup is complete appears, press

OK. PIN - When the PIN code window appears, enter

the displayed PIN into your AP, and then press OK to continue the PIN Setup. When a message displays to report that the setup is complete, press

OK.

To cancel searching for the AP:

Press BACK while searching for the AP. A message will appear, and then press

C / c to select Yes and press OK.

k In step 9, when you select Assisted Setup;

Press

BbC c to highlight Next and press OK.

The Assisted Setup screen will appear. Press

B / b to select the desired AP and press

OK. NOTE: Check the MAC addre ss on the label of the

AP or in the manual, and select your AP.

B / b to select Security Key and press OK.

Press The Software Keyboard window will appear (page

49).

Input the Security Key by using the Software Keyboard. To save your setting, press the GREEN button.

NOTE:

• The Security Key must adhere to these conditions:

- TKIP/AES: 8-63 ASCII or 64 Hex characters

- WEP: 5 or 13 ASCII or 10 or 26 Hex characters

• There is only one key ID to set for WEP encryption.

B / b to highlight Done and press OK.

Press

NOTE:

• If Network Name is not displayed, see Manual Setup below to set Network Name before Done is selected.

•If BACK is pressed before Done is selected, settings are not saved.

When the message “Wireless configuration is complete.” appears on screen, press OK. The screen will skip to step 13.

l In step 9, when you select Manual Setup;

Press

BbC c to highlight Next and press OK.

The Manual Setup screen will appear. Press

b to select Network Name and press OK.

The Software Keyboard window will appear (page

49).

Input the Network Name by using the Software Keyboard. To save your setting, press the GREEN button.

Press

B / b to select Authentication and then

press

c and B / b to select Open System,

Shared Key, WPA-PSK or WPA2-PSK. Press OK.

Press

B / b to select Encryption, and then press

c and B / b to select None, WEP, TKIP or AES.

Press OK. NOTE:

• Certain encryption types are only compatible with specific authentication types.

- When Authentication is Open System, only

WEP or None is compatible.

- When Authentication is Shared Key, only WEP

or None is compatible.

- When Authentication is WPA-PSK or WPA2-

PSK, only TKIP or AES is compatible.

• When incompatible Authentication/Encryption pairings are detected, a warning message will be displayed, and no connection attempt will be made until the incompatibility is resolved.

• There is only one key ID to set for WEP encryption.

B / b to select Security Key and press OK.

Press Input the Security Key by using the Software Keyboard (page 49). To save your setting, press the GREEN button. This item is greyed out when Encryption is None.

B /

SETTING UP YOUR TV

Quick Setup

Country

Location

Network

Smart TV

Channel Tuning

Advanced Network Setup 3/5

Previous Next

Auto Setup

IP Address Subnet Mask Default Gateway

Auto Setup

Primary DNS Address Secondary DNS Address

5/5Network Connection Test

Network connection was completed successfully.

Quick Setup

Country

Location

Network

Smart TV

Channel Tuning

TV Power On Control

1/2

We recommend you Enable TV Power On Control for quick access to Toshiba services. Once enabled you will be able to view Internet and Menu systems faster. This mode will result in your TV using higher power consumption than when Disabled.

Previous Next

Disabled

Enabled

TV Power On Control Disabled

Antenna Cable Satellite

Previous Next

English

When Encryption is WEP, Key ID setting is available. Press

B / b to select Key ID and press

c and B / b to select 1 (default), 2, 3 or 4.

Press

B / b to highlight Done and press OK.

When the message “Wireless configuration is complete.” appears on screen, press OK.

NOTE: Settings are not saved if BACK is pressed before Done is selected.

m The Advanced Network Setup screen will

appear. When the DHCP function of the router connected

with this TV is On, you can set Auto Setup to On or Off. (This should usually be set to On.) When the DHCP function of the router is Off, set Auto Setup to Off, and set the IP Address DNS address(es) manually.

...

xxx xxx xx x

...

xxx xxx xx x

...

xxx xxx xx x

...

xxx xxx xx x

...

xxx xxx xx x

You can view the fixed MAC address for the TV, if one is installed.

Press

B / b to highlight Next.

n Press OK, and Network Connection Test will start.

A message will appear to indicate if t he connection was successful or if could not be completed.

NOTE: The result of Network Connection Test does not always guarantee the connection.

To cancel the Network Connection Test:

Press EXIT while testing. When the network can be accessed, Software

Upgrade starts automatically. When Software Upgrade is completed, proceed to the next step.

o Press OK, and TV Power On Control screen will

appear. Select Disabled or Enabled and highlight Next.

p Press OK, and Companion Device screen will

appear. Select On or Off from Enable Control and Media Renderer and highlight Next.

q Press OK. If the Ant/Cable/Satellite screen

appears, press Satellite, and then press OK to check ( ).

If DVB-C is not supported in your area, Cable will not be displayed.

• When you select Antenna or Cable, follow step 18 to 21.

• When you select Satellite, skip to step 22.

• When you select Antenna (or Cable) and Satellite, the Satellite Settings startup screen will appear automatically after completing the Antenna (or Cable) scan and pressing OK.

B / b to select Antenna, Cable or

r Press BbC c to highlight Next and press OK.

The Auto Tuning start up screen will appear with the option to select between DTV and ATV, DTV or ATV if available. Press

c and B / b to select

the appropriate mode and press OK.

SETTING UP YOUR TV

Auto Tuning - Antenna

Channel: 23

Progress

0 0

DTV Tune ATV Tune

4 %

Waiting...

Found

1 Astra 19.2E 1 1 2 3 4

None

ToneBurst DiSEqC 2way DiSEqC 4way Single Cable

Satellite Settings

Switch Type

LNB Power

None

No. Satellite

Dish

LNB

Done

1 Astra 19.2E 1 1 2 3 4

Off

Satellite Settings

Switch Type

LNB Power

None

No. Satellite

Dish

LNB

Done

s Press b to highlight Start Scan, and press OK.

English

The television will start to search for available DTV and/or ATV channels. The progress bar will indicate the scan status.

You must allow the television to complete the search.

When the search is complete, the television will automatically select channel one.

The Auto Tuning screen will display the total number of services found.

T Press C / c to view the DTV (digital channel) or

ATV (analogue channel) lists.

u Press B / b to move through the list to select a

channel, and then press OK to view. In ATV mode, some areas may receive duplicate

stations. There may not be a clear picture or the signal may be weak, so the station order can be changed using ATV Manual Tuning.

REMEMBER: Press TV at any time to select between ATV and DTV modes.

NOTE: The time will be set automatically by transmission but can be advanced or decreased by using Local Time Setting in the DTV Settings screen.

v Select Next and press OK. The Satellite Settings

screen will appear. From this window, you can add the satellites that you wish to tune and configure detailed settings for each one individually.

Select Switch Type and choose the correct switch configuration for your satellite dish from the settings None, ToneBurst, DiSEqC 2way,

DiSEqC 4way or Single cable.

NOTE:

• None is being used when the satellite dish will control only one universal Low Noise Block (LNB) with a single satellite (e.g. Astra 19.2°). As a rule, most households use just one satellite.

• ToneBurst sends a 22 kHz signal. ToneBurst is only necessary for simple LNBs (not universal LNBs). The 22 kHz signal is needed for switching LNBs with multifeed signals as well as for changing between low- and high-band.

• DiSEqC 2way automatically switches between two LNBs, which receive different satellites at the same time (e.g. Astra 19.2° and Hotbird 13°).

• DiSEqC 4way automatically switches between up to four LNBs / satellites.

• Single cable is selection and control of plural Satellite antennas through the combined single antenna cable.

The setting LNB Power enables you to switch on or off the LNB's power supply by means of the TV. When your satellite dish consists of only one LNB, LNB Power should generally be activated (On). When using more than two LNBs, it is recommendable to use external power supply for these.

It is possible to select up to four satellites. Please note that the number of available LNBs and the adjustment of your satellite dish determines the number of satellites found. For example, it is not possible to receive more than one satellite if your dish is directed to a single satellite. For further information on satellite signal technology, please contact your local dealer.

SETTING UP YOUR TV

1 Astra 19.2E 1 1 2 3 4

Satellite Settings

Switch Type LNB Power

None

No. Satellite

Dish

LNB

Done

Transponder : 1/120 (10729) MHz Dish Type : Fixed Lower LOF : 9750 Upper LOF : 10600

1 Astra 19.2E 1 1

2 3 4

Satellite Settings

Switch Type LNB Power

None

No. Satellite

Dish

LNB

Done

Transponder : 1/120 (10729) MHz Dish Type : Fixed Lower LOF : 9750 Upper LOF : 10600

Transponder

Go to 0

Go to Stored Position

Step Size Positioning

Positioning

Satellite : Astra 19.2E Signal Level

30%

Store Position

1/120 (10729 MHz V (R))

Signal Level

30%

User Slot Number 0

User Slot Frequency 1284 Password PIN None

Single Cable Settings

Done

Verify Slot Frequency

w If your satellite dish is moveable, the following

Positioning screen will appear.

English

Once you have selected a satellite, you can change further settings under Dish and LNB. Press OK and

C / c to select Dish or LNB and

press GREEN button. Under Dish you choose the dish type that will be

used (fixed or moveable dish). The majority of households have a fixed satellite dish.

LNB allows you to determine the lower and higher Local Oscillator Frequency (LOF). Usually, the factory settings do not need to be changed. You can find the parameters of the lower and higher LOF on the specification sheet of your LNB.

Press

B / b to highlight Done and press OK.

Press

B / b to highlight Positioning, and then

press

C / c to find the dish position with the

strongest signal level. Press

B / b to highlight Store Position and press

OK to store the dish position. Repeat steps 22 and

23 for the next satellite as necessary. Adjust the dish position manually for the maximum

Signal Level strength. The signal level strength is displayed from 0 % to 100 %. A high signal level can be achieved by adjusting the satellite dish the best way possible.

Press

B / b to highlight Done and press OK.

If you select Single Cable in step 22, the Single Cable Settings screen will appear. You can set the appropriate value for each item and highlight Done.

SETTING UP YOUR TV

PLEASE NOTE

Scan Type Quick Scan

Search Option Free to Air

Auto Tuning - Satellite

Start Scan

Tuning Mode DTV and ATV

Auto Tuning - Cable

Start Scan

DTV

Operator Selection Others

Scan Type Quick Scan Start Frequency Auto End Frequency Auto Modulation Auto Symbol Rate Auto Network ID Auto

x If the reception testing completes successfully, the

English

Auto Tuning startup screen will display.

You can select Search Option from Free to Ai r or All.

When choosing the search option All, all channels (including encrypted ones) of the satellite will be searched for. If you wish to only search for unencrypted (free) channels, please select Free to Air. In this case, the channel scan will be completed faster.

y Press b to highlight Start Scan, and press OK.

The television will start to search for available DVB-S channels. The progress bar will indicate the scan status.

When the search is complete, the Auto Tuning results screen will display the total number of services found.

z Use B / b to move through the list to select a

channel, and then press OK to view.

The Quick Setup menu can also be accessed at any time from the Installation menu.

Ant/Cable/Satellite (if available)

From this menu, you can set the RF input configuration.

a Press and B /b to hi gh l ight Installation

icon.

b Press c an d B / b to select Channel Tuning and

press OK.

c Press B / b to select Ant/Cable/Satellite and

press OK.

d Press B / b to select Antenna, Cable or

Satellite.

e Press B / b to highlight Next and press OK.

NOTE: When you attempt to change the Ant/ Cable/Satellite setting, a warning message will

appear followed by PIN entry (if PIN has been set) and a prompt for Auto Tuning.

f When Ant/Cable/Satellite is set to Cable, the

following setting options will be provided in the Auto Tuning screen.

Press

B / b to select an item and press c and B /

b to select your desired option.

With the exception of DTV Scan Type and DTV Modulation items, all of the following items will have 2

operating modes. The first is Auto where the values for each item are preset by the system. The second is an Input mode where you will be able to enter a single value in place of the pre-set value. If no channel is currently tuned and the Input state is chosen, a system default value will be shown. However, if a channel is currently tuned when the item is accessed, the value of the current channel will be displayed.

Operator Selection:

You can choose the Cable operator depending on the

Country you set.

DTV Scan Type:

This item determines whether a Quick Scan or a Full Scan will be executed.

The Quick Scan is a simplified version of the Full Scan that is designed to complete in less time.

DTV Start Frequency:

This sets the frequency from which the scan will begin.

DTV End Frequency:

This sets the frequency at which the scan will end.

DTV Modulation:

You can choose from five QAM modulation settings.

DTV Symbol Rate:

This is the baud rate (KS/s) of the scan.

DTV Network ID:

This is the Network ID to be utilized for the scan. This item is greyed out when DTV Scan Type is set to “Full Scan”.

SETTING UP YOUR TV

1 Astra 19.2E 1 1

2 3 4

Satellite Settings

Switch Type LNB Power

None

No. Satellite

Dish

LNB

Done

Transponder : 1/120 (10729) MHz Dish Type : Fixed Lower LOF : 9750 Upper LOF : 10600

1 Astra 19.2E 11

Transponder Settings

Frequency

1 10743 H 22000 S

2 10773 H 22000 S 3 10788 V 22000 S 4 10817 V 22000 S 5 10832 H 22000 S 6 10847 V 22000 S 7 10861 H 22000 S 8 10876 V 22000 S

Polarisation Symbol Rate S/S2

Transponder Settings

Frequency 76 12640 H 22000 S 77 12662 H 22000 S 78 12669 V 22000 S 79 12692 H 22000 S 80 12699 V 22000 S 81 12721 H 22000 S 82 12728 V 22000 S

Polarisation Symbol Rate S/S2

83 0 H 0 S

83 1231 H 0 S2

English

Satellite Settings

From the System Setup menu, you can add the satellites

that you wish to tune and configure detailed settings for

each one individually.

To add a satellite:

a Press and B /b to hi gh l ight Installation

icon.

b Press c an d B / b to select Channel Tuning and

press OK.

c Press b to select Satellite Settings and press

OK.

d Press b to highlight a new line to add an another

satellite and press OK.

e Press b until the required satellite is displayed and

press OK.

To edit the satellite settings:

a In the Satellite Settings menu, press B to

highlight Switch Type.

b Press C /c to select None, ToneBurst, DiSEqC

2way, DiSEqC 4way or Single Cable as your

satellite switch type.

c Press b to highlight LNB Power and press C / c

to select On or Off.

To add a transponder:

a In the Satellite Settings menu, press B / b to

highlight the line you want to edit and press OK.

b Press the GREEN button. The Transponder

Settings screen will appear.

c Press B to highlight a new line.

To delete a satellite:

a In the Satellite Settings menu, press B / b to

select the satellite you want to delete.

b Press the RED button. A confirmation window will

appear.

c Press C / c to select Yes and press OK.

NOTE: It is not possible to delete position No.1.

Press OK.

Edit each parameter as required and press OK.

SETTING UP YOUR TV

Dish Settings

Dish : 1

Dish Type Fixed

LNB Settings

LNB : 1

Lower LOF 9750

Upper LOF 10600

Ant/Cable/Satellite Satellite Settings

Auto Tuning

ATV Manual Tuning DTV Manual Tuning

< Channel Tuning

DTV

DTV and ATV ATV

Auto Tuning - Antenna

Tuning Mode DTV

Start Scan

To delete a transponder:

English

a In the Transponder Settings menu, press B /b

to highlight the line you want to delete.

b Press the RED button.

To edit the Transponder Settings:

a In the Transponder Settings menu, press B /b

to highlight the line you want to edi t and press OK.

b Press C / c to select Frequency, Polarisation,

Symbol Rate or S/S2, and set the item using the number buttons and

B / b if necessary.

c Press OK to save your settings.

d Repeat steps 1 through 3 for other lines.

e Press the BLUE button to finish editing and return

to Satellite Settings. Press the GREEN button to cancel any edits that

were made. Press the YELLOW button to reset all transponder

settings to their initial default settings.

To select the Dish Type:

a In the Satellite Settings menu, press B / b to

select the required satellite line and press OK.

b Press C / c to highlight Dish and press the

GREEN button.

c Press B /b to select Lower LOF or Upper LOF

and use the number buttons (0-9) to input the appropriate frequencies.

Auto Tuning

NOTE: As new services are br oadcast, it will be necessary

to re-tune the television in order to view them.

Auto Tuning will completely re-tune the television and

can be used to update the channel list. It is

recommended that Auto Tuning is run periodically to

ensure that all new services are added. All current

channels and settings, i.e. locked channels, will be lost.

a Press and B /b to highlight Installation

icon.

b Press c and B / b to select Channel Tuning and

press OK.

c Press B / b to select Auto Tuning and press OK.

A message will appear, and then press select Yes and press OK.

C / c to

d Press c and B /b to select DTV, DTV and ATV,

or ATV, if available, then highlight St art Scan and press OK to continue with the Auto Tuning.

c Press c and B / b to select Dish Type. You can

select Movable or Fixed as the Dish Type.

To select the LNB Settings:

a In the Satellite Settings menu, press B / b to

select the required satellite line and press OK.

b Press C / c to highlight LNB and press the

GREEN button.

NOTE: If you have selected Others for the Country field in the Installation menu, and

selected a tuning mode other than DTV, choose the optimum ATV broadcasting system (B/G, I, D/ K or L).

The television will start to search for all available DTV and/or ATV services.

You must allow the television to complete the search.

When the search is complete, the Auto Tuning screen will display the services found.

e Press B /b to move thro u gh th e list to select a

channel and press OK to view.

SETTING UP YOUR TV

ATV Manual Tuning System

Ant/Cable/Satellite Satellite Settings Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

< Channel Tuning

0C2

1S10 2C7 3S40 4C22 5C25 6C28 7C30

ATV Manual Tuning Pos. Channel Station

ATV Manual Tuning System

ATV Manual Tuning Search

English

ATV Manual Tuning

Tuning

The television can be tuned-in manually using ATV

Manual Tuning. For example, you might use the feature

if the television cannot be connected to a media recorder/ decoder with a SCART lead or when you want to tune-in a

C / c to move across the screen and select any of the

Use ATV Manual Tuning options. Then use settings.

1 Position

The number to be pressed on the remote control to tune the channel.

2 System

Specific to certain areas.

3 Colour System

Factory set to Auto, should only be changed if problems are experienced, i.e. NTSC input from external source.

4 Skip

Set Skip to On ( channel. See page 24.

5 Signal Class

The channel classification.

6 Channel

The channel number on which a station is being broadcast.

7 Search

Search up and down for a signal.

8 Manual Fine Tuning

Only used if interference/weak signal is experienced. See page 89.

9 Station

Station identification. Use the enter up to seven characters.

To allocate a position on the television for a decoder and media recorder: turn the decoder on, insert a pre-recorded film in the media recorder, press PLAY and manually tune .

station on another System.

B / b to adjust the

V R

123 4 65 7 8 9

8) or Off (() for the selected

Bb and Cc buttons to

a In the Channel Tuning menu, press b to select

ATV Manual Tuning and press OK.

b Press B /b to select the desired position. We

suggest Pos. 0 for a media recorder.

Different Channel numbers may be displayed.

c Press OK to select. If the channel chosen for the

media recorder is set to skip, Skip should be removed before storing.

d Press c to select System and press B /b to

change if required.

e Then press c to select Search.

f Press B /b to begin the search. The search

symbol will flash.

SETTING UP YOUR TV

ATV Manual Tuning Station

PLEASE NOTE

0C2

1S10 2C7 3S40 4C22 5C25 6C28 7C30

ATV Manual Tuning Pos. Channel Station

ATV Manual Tuning Skip: On

g Each signal will show on the television. If it is not

English

your media recorder, press

B / b again to restart

the search.

h When your media recorder signal is found, press c

to move along to Station. Use the required characters, e.g. VCR.

BbC c to put in

V R

i Press OK to save.

j Repeat for each position you want to tune.

k Press EXIT when you have finished.

This television has direct channel entry if the channel numbers are known. Select the ATV Manual Tuning screen in Step

3. Enter the Position number, the System, then C for standard (terrestrial) channels or S for cable channels and the Channel number. Press OK to save.

Skip

To prevent certain channels from being viewed, positions

can be skipped.

a Select ATV Manual Tuning from the Channel

Tuning menu.

b Press B / b to highlight the position to be skipped

and press OK.

c Press c to select Skip.

d Press B /b to turn Skip on and press OK.

8 on the screen indicates a skipped position.

e Press BACK and repeat from Step 2 or press

EXIT.

Each position has to be individually selected. To turn Skip off, repeat the procedure for each position.

Skipped positions cannot be selected by P

u or by the controls on the television but can still

be accessed by the number buttons on the remote control.

U and

SETTING UP YOUR TV

Pos. Name 1 ABC ONE 2 ABC TWO 7 ABC THREE 30 CABC Channel

40 ABC NEWS 24

51 ABCi 822 AA 823 AC

Channels Line No.

Antenna TV

1/10

Channel 67

Frequency 842.0 MHz Bandwidth 8 MHz

DTV Manual Tuning - Antenna

Signal Strength

WEAK AVERAGE STRONG

Quality GOOD

Start Scan

1 ABC ONE 2 ABC TWO

7 ABC THREE 40 ABC NEWS 24 51 ABCi

DTV Manual Tuning - Antenna

New Pos. Name Type

0 New Channels - Total 6

English

Sorting positions

Channels may be moved and saved to the position of you r

choice.

a Select ATV Manual Tuning from the Channel

Tuning menu.

b With the list of channels showing, press B / b to

highlight the position to be moved and press

c Press B / b to move through the list to your

preferred position. As you do so, the other channels will move to make room.

d Press C to save your move.

Repeat as necessary and press EXIT.

DTV Manual Tuning

NOTE: This feature varies depending on the Ant/Cable/ Satellite setting.

Manual Tuning

This feature is available for service engineers or can be

used for direct channel entry if the multiplex channel is

a Select DTV Manual Tuning from the Channel

Tuning menu and press OK.

b Enter the multiplex number using the number

buttons or use down.

c Highlight Start Scan and p ress OK. The television

will automatically search for that multiplex.

known.

C / c to adjust the number up or

When the multiplex is found, any channels that are not currently in the channel list will be added and the channel information at the top of the screen will be updated.

d Repeat as necessary. Press EXIT to finish.

SETTING UP YOUR TV

Satellite ASTRA 28.2°E

Transponder 1/83 Frequency 10714 MHz Symbol Rate 22000 KS/s Polarisation H Search Option Free to Air

DTV Manual Tuning - Satellite

Signal Strength

WEAK AVERAGE STRONG

Signal Quality POOR

Start Scan

Channels

Subtitle and Audio Parental PIN Setup Parental Control Local Time Setting Standby Channel Update Common Interface

< DTV Settings

1 ABC ONE

2 ABC TWO 7 ABC THREE 30 CABC Channel 40 ABC NEWS 24 51 ABCi 822 AA 823 AC

Channels

Line No. 1/10

Pos. Name

Antenna TV

Pos. Name

ABC ONE

English

Manual Tuning for DVB-C

When Ant/Cable/Satellite is set to Cable, DTV Manual Tuning items are as follows:

Frequency: Input a specific frequency to be scanned Modulation: Choose from one of five QAM modulation

options Symbol Rate: Input a specific baud rate (KS/s) to be used

for the manual scan Highlight Start Scan and press OK.

Manual Tuning for DVB-S

When Ant/Cable/Satellite is set to Satellite, DTV Manual Tuning items are as follows:

Press

B / b to highlight an item (Satellite, Transponder,

Frequency, Symbol Rate, Polarisation or Search Option) and press

Highlight Start Scan and press OK.

C / c to select the required option.

DTV Settings

Channels (Antenna/Cable)

The channel order may be changed to suit your personal

a Select DTV Settings from the Installation menu

and press OK.

b Press b to select Channels and press OK.

c For your convenience, you can jump to specific

places in the list by one of two methods.

preference.

Line Number Jump —Use the number

buttons (0-9) to input the line number you wan t to

select and press OK. It is also possible to change the Position numb er of

a particular channel.

Renumber — Press the RED button to

renumber the highlighted channel. Edit the channel number using the number buttons and press OK. If the position number you input already exists, a confirmation window will appear.

SETTING UP YOUR TV

1 ABC ONE

2 ABC TWO 7 ABC THREE 30 CABC Channel 40 ABC NEWS 24 51 ABCi 822 AA 823 AC

Channels

Line No. 1/10

Pos. Name

Antenna TV

Your existing channel order will be lost. Do you wish to

continue?

Yes

Pos. Name Satellite 1 DDD 19.2°E 2AB 19.2°E

3E 19.2°E

801 BBC 22.5°E 802 BB 22.5°E 803 BA 22.5°E 822 AA 25.6°E 823 AC 25.6°E

Channels Line No.

Satellite TV

1/10

English

Move —Press the GREEN button to activate the

Move feature. Press

you wish to move and press OK to check. If you wish to move multiple channels at once, select another channel and check in the same way. Repeat as necessary. Once all desired channels have been checked, press

B / b to place the focus at the position to

which you wish to move the channels. The channels will be inserted above the highlighted channel. Press the GREEN button to execute the move.

B / b to select the channel

Position No. Sort —Press the YELLOW

button. A confirmation window will appear. Press

C / c to select Yes and press OK.

Channels (Satellite)

a Select DTV Settings from the Installation menu

and press OK.

b Select Channels and press OK.

The satellite channel list will appear.

c For your convenience, you can edit and sort your

channel list.

Line Number Jump — Press the number

buttons (0-9) to input the line number you wan t to select and press OK.

Satellite Jump — Press Z / z to jump to the

next channel on a different Satellite.

Renumber — Same as Antenna/Cable

channels. See page 26.

Move — Same as Antenna/Cable channels. See

page 27.

Position No. Sort — Press the YELLOW

button. A confirmation window will appear. Press

C / c to select Yes and press OK.

Standby Channel Update

If the Standby Channel Update is set to On, when the TV

is in Standby, Digital Tuning is automatically executed.

a Select DTV Settings from the Installation menu

and press OK.

b Press b to select Standby Channel Update and

press

c and B / b to select On.

Location setting

You can select either Home or Store mode. Home is

recommended for normal home use. Select Store when

using the television for displaying in a shop, etc.

a Select Location from the Installation menu.

b Press C /c to select Home or Store.

Analogue switch-off

This is a digital television which is integrated to allow the use of both digital and analogue services. However, during the lifetime of this set it is very likely that analogue services will be switched off to allow for more new digital services.

This ‘switch-off’ will happen in a number of phases, which will be advertised in your area well in advance. It is recommended that at each phase the television is retuned to ensure that existing and new digital services can be viewed without disruptio n .

CONTROLS AND FEATURES

Intel® WiDi

Picture Mode Standard Picture Size Wide 3D Settings More Information Channel Options Sleep Timer HDMI CEC Device Control Speakers TV Speakers Headphone Level 30 Wireless Information Recording Information

Quick Menu

General controls

English

Quick Menu

Quick Menu helps you access some options quickl y, such as Pi cture Mode, Picture Size, More Information, Sleep Timer etc.

Press QUICK to open the Quick Menu and use select the option.

NOTE: Quick Menu items are different depending on the current mode.

B / b to

Quick menu item example

Mode Quick menu item Description

When viewing a TV programme or pictures from the external input

Single Window

When using EPG Genre Colour See page 77.

Media Player Picture See page 38.

Intel

WiDi See page 64. Picture Mode See page 38. Picture Size See page 36. 3D Settings See page 30. More Information See page 76. Channel Options See page 78. Sleep Timer See page 74. HDMI CEC Device

Control Speakers See page 85. Headphone Level See page 35. Wireless Information See page 46. Recording

Information

EPG Update / Cancel EPG Update

3D Settings See page 30. Sound See page 34. Interval Time See page 68. Repeat See page 68. Background Music See page 68. Play List See page 69. Sleep Timer See page 74. Speakers See page 85. Headphone Level See page 35.

See page 85.

See page 76.

Selecting channels

To select a channel, use the numbered buttons on the remote control.

Channels can also be selected using P To display on-screen information such as channel, input

mode or stereo/mono signal, press . Press again to

U and Pu.

cancel.

The Time Display – analogue only

The time display facility allows the current (text service)

time to be seen on the television screen.

Press

D whilst watching a normal television

broadcast to see the time display from the broa dcaster . It will remain on screen for about 5 seconds.

NOTE: This display may not be available in some cases.

CONTROLS AND FEATURES

English

Stereo and Bilingual transmissions

For DTV programmes

For stereo or dual mono broadcasts, press s and use

C / c to select settings.

Mode Display Pressing c

Stereo Stereo S Left S Right

Dual mono Dual 1 Mono – Multichannel –

For multi-audio track broadcasts, press change the audio language (see “Audio languages” on page

79).

For ATV programmes

If stereo or dual language broadcasts are transmitted, the word Stereo or Dual will appear on the screen each time channels are changed, disappearing afte r a few se conds. If the broadcast is not in stereo, the word Mono will appear.

Stereo… Press Bilingual… Bilingual transmissions are rare. If they are

transmitted, the word Dual will be displayed. Choose the required programme number, and if the word Dual appears, press

s to select Stereo or Mono.

s to select Dual 1, Dual 2 or Mono.

S Dual 2 S Dual

s repeatedly to

Using 3D functions

Before using 3D programming, see and follow “Important information for 3D viewing” section on page 100.

Viewing 3D programming requires the following:

• Toshiba FPT-AG03 (L73*5D/M83*5D : 2pcs supplied, L73**RK/L73**RB : 1pcs supplied, L73*3D/L 73*1D : Not supplied)

• Compatible 3D playback device or 3D source

• 3D capable high quality HDMI cable

Viewing 3D images

Incoming video signals can either be in 2D or 3D format. A 2D signal can be viewed in either 2D or 3D, and 3D can be viewed in either 2D or 3D. If the TV can d etect t he fa ct that a signal is 3D, it can change to 3D mode automatically

– see “Setting the auto start mode” (on page 31).

Otherwise you can change the viewing mode using the 3D

button. Finally, the format of the 3D signal can be either

Side by Side (SBS) or Top and Bottom (TB). You may have to choose the correct format if the TV can not detect it automatically – see “Switching display mode or selecting

Moreover, you can change 2D images to 3D images by

pressing the 3D button when viewing in 2D.

NOTE:

• When 3D format signal is not received, display mode is

not switched to 3D.

• If appropriate mode and format are not selected, 3D

image is not correctly displayed.

• There will be restrictions on the Picture Size settings for

3D Mode and 2D Mode.

• There are individual differences in perception of 3D

images.

• When viewing 3D images, wear the 3D Glasses.

• The 2D to 3D conversion function is activated and

controlled by you according to your personal

preferences.

• The 2D to 3D conversion function is meant for

enjoyment of 2D home video, and other 2 D conten t you

create, in 3D according to your personal preferences.

• The 2D to 3D conversion function is not intended for use

with pre-recorded 2D copyrighted content owned by a

third-party unless the copyright owner has given direct

or indirect permission, or unless applicable law permits

such use.

3D format”.

CONTROLS AND FEATURES

Trigger of Switching

Display Mode

Press 3D button

Input Signal Type Additional

Information

Format Source

Signal

Select 3DSelect

2D to 3D

3D Format Signal

With 3D Auto Detect Information

SBS

Without 3D Auto Detect Information

SBS

2D Format Signal

DD3

Trigger of Switching

Display Mode

Quick menu

Input Signal 3D Format Select Type Additional

Info

Format Source

Signal

SBS TB

3D Format Signal

With 3D Auto Detect Information

SBS TB

Without 3D Auto Detect Information

SBS

2D Format Signal

DD3

Switching display mode or selecting

English

3D format

There are four modes for watching TV.

Mode Description

3D* 2D Changes 3D images to 2D.

2D to 3D* Native Displays a received signal format as it is.

* This mode does not support a ll content depending on its

input source format.

Displays 3D images.

Changes 2D images to 3D.

3D format select

If a right and left images are same in Native mode, sele ct SBS. If a top and bottom images are same in Native mode, select TB. 3D formats are the following.

3D format Description

Side by Side (SBS)

Top and Bottom (TB)

Frame Packing (FP) *

Images for the left and right eyes are positioned side-by-side.

Images for the left and right eyes are positioned at the top and bott om o f t he screen.

Image for the left and right eyes for two frames are positioned at the top and bottom of the screen.

* This format cannot be selected manually.

The 3D button's operation

The behaviour of 3D when viewing in Native mode is different depending on the input mode.

Depending on the input mode, the screen for selecting 2D or 3D is displayed or the display mode switches between 2D and 3D.

To switch to 3D mode:

•Set 3D Auto Start in the 3D menu to 3D.

•Press 3D while viewing 2D mode or Native mode.

3D 3D

3D 3D 3D 3D

* Correct 3D image

To select 3D format from the Quick menu in 3D mode:

a Press QUICK to open the Quick Menu.

b Press B /b to select 3D Settings and press OK.

c Press B /b to select 3D Format Select and press

OK.

d Press C /c to select 3D (SBS) or 3D (TB).

3D 3D

* Correct 3D image

CONTROLS AND FEATURES

Trigger of Switching

Display Mode

Press 3D button

Input Signal Type Additional Info Format Source

Signal

3D Format Signal

With 3D Auto Detect Information

SBS

Without 3D Auto Detect Information

SBS TB

2D Format Signal

Trigger of Switching

Display Mode

Quick menu

Input Signal 2D Format Select Type Additional

Info

Format

Source Signal

SBS TB Native

3D Format Signal

With 3D Auto Detect Information

SBS

Without 3D Auto Detect Information

SBS

2D Format Signal

3 3

< 3D

3D Auto Start 3D 2D to 3D Depth 3 3D PIN 3D Safety Settings 3D Important Info

2D Off

English

To switch to 2D mode:

•Set 3D Auto Start in the 3D menu to 2D.

• Press 3D while viewing 3D mode.

3D 3D

3D 3D 3D 3D

3D 3D

* Correct 2D image

To select 2D format from the Quick menu in 2D mode:

a Press QUICK to open the Quick Menu.

b Press B / b to select 3D Settings and press OK.

c Press B / b to select 2D Format Select and press

OK.

d Press C /c to select Native, 2D (SBS) or 2D (TB).

To switch to Native mode:

•Press 3D while viewing 3D mode.

•Press 3D while viewing 2D to 3D mode.

NOTE: When 3D format signal with 3D Auto Detect

Information is received, it is not possible to switch to

Native.

• From the Quick Menu in 2D mode.

a In the Quick Menu, press B / b to select 3D

Settings and press OK.

b Press B /b to select 2D Format Select and press

OK.

c Press C /c to select Native.

NOTE: When Frame Packing is input, 2D Format

Select will be greyed out.

To switch to 2D to 3D mode:

Press 3D while viewing 2D or Native mode. NOTE: Depending on the input mode, the display mode

switches between 2D and 3D.

Setting the auto start mode

Controls what the TV does when it detects a 3D signal.

a Press and B /b to highlight 3D icon.

b Press c and B / b to select 3D Auto Start.

c Press C / c to select 3D, 2D, or Off and press OK.

3D 3D

* Correct 2D image NOTE: Take off the 3D Glasses in 2D mode.

3D 3D

Option Description

3D Displays as 3D mode automatically when

2D Displays as 2D mode automatically when

Off Displays a screen that allows you to select

3D format signal is received.

3D or 2D when 3D format signal is received.

CONTROLS AND FEATURES

English

Adjusting 2D to 3D Depth

You can adjust the level of 3D.

From the Menu:

a In the 3D menu, press B /b to select 2D to 3D

Depth and press OK.

b Press C / c to select 1, 2, 3, 4, or 5 and press OK.

The higher the number, the stronger the 3D e ffect .

From the Quick Menu:

a Press QUICK to open the Quick Menu.

b Press B / b to select 3D Settings and press OK.

c Press B / b to select 2D to 3D Depth and press

OK.

d Press C / c to select 1, 2, 3, 4, or 5 and press OK.

The higher the number, the stronger the 3D e ffect .

NOTE: Depending on the content, setting t he 3D effect to a high level may result in blurring of the image contours and background.

If you experience any abnormal sensation or feel f atigue or nausea when viewing 3D images, stop watching and rest until the symptoms subside. Before viewing again, adjust the 3D effect to a lower number and view at a level at which the symptoms do not occur.

Setting the 3D PIN code

A 3D PIN code is necessary for using 3D Safety Settings.

To enter a new PIN code:

a In the 3D menu, press B / b to select 3D PIN and

press OK.

b Press the number buttons to enter a 4-digit

number. Confirm the code.

NOTE: PIN code cannot be set to “0000”.

To change or delete your PIN code:

a In the 3D menu, press B / b to select 3D PIN and

press OK.

b Press the number buttons to enter your 4-digit PIN

code.

c Select Change PIN or Delete PIN and press OK.

NOTE:

• PIN code cannot be set to “0000”.

• If PIN is deleted, 3D Safety Settings is greyed out, and the settings are reset to the factory default.

Setting 3D Start Message

When this feature is set to On, a message is displayed

onscreen when a 3D signal is received.

a In the 3D menu, press B / b to select 3D Safety

Settings and press OK.

b Enter your 4-digit 3D PIN code.

c Press B /b to select 3D Start Message.

d Press c and B / b to select On or Off.

CONTROLS AND FEATURES

English

Setting 3D Lock

When this feature is set to On, you must enter 3D PIN

code for changing display mode.

a In the 3D menu, press B /b to select 3D Safety

Settings and press OK.

b Enter your 4-digit 3D PIN code.

c Press B / b to select 3D Lock.

d Press C / c to select On.

Setting 3D Timer Lock

When the 3D Timer Lock feature is set to On, neither the PIN input window nor the 3D start message will be shown while the 3D Enable timer is active, even if a switch to 3D

Mode occurs. This helps to avoid asking for the 3D Lock

PIN and displaying 3D start message every time when

NOTE: This feature cannot be selected until the 3D PIN is set.

switching to 3D.

a In the 3D menu, press B /b to select 3D Safety

Settings and press OK.

b Enter your 4-digit 3D PIN code.

c Press B / b to select 3D Timer Lock.

d Press c and B / b to select On.

Displaying 3D Important Info

a In the 3D menu, press B / b to select 3D

Important Info and press OK.

A message will appear.

Switching left and right images

The left and right eye shutter timing of the glasse s can be

swapped. If 3D images look blurred, switch the left and

right sides of the 3D image.

a Press QUICK to open the Quick Menu.

b Press B /b to select 3D Settings and press OK.

c Press B /b to select Left and Right Image.

d Press c and B / b to select Swapped and press

OK.

Setting Enable 3D Timer

This feature helps to remind you not to watch 3D video for

extended periods of time. Once a set period of time has

passed, a dialogue will be shown asking you if you wish to

continue viewing or not.

a In the 3D menu, press B /b to select 3D Safety

Settings and press OK.

b Enter your 4-digit 3D PIN code.

c Press B / b to select Enable 3D Timer.

d Press c and B / b to select 30, 60, 90, or 120

minutes.

e To cancel the timer, select Off.

CONTROLS AND FEATURES

< Sound

Balance 0 Bass 0 Treble 0 Audyssey Premium Tele vision Dynamic Range Control On

Dual Dual 1

Audio Level Offset TV Speakers On Headphone Level Audio Description Digital Audio Output

Sound controls

English

Volume controls and sound mute

Volume

2+ or 2– to adjust the volume.

Press

Sound Mute

Press once to turn the sound off and again to cancel.

Dual

If a programme or film is being broadcast with a

soundtrack in more than one language, the Dual feat ure

allows selection between them.

a Press and B /b to hi gh l ight Sound icon.

b Press c and B / b to select Dual and press c and

B / b to choose between Dual 1 or Dual 2.

Balance

a In the Sound menu, press B / b to select

Balance and press

right speaker balance.

C / c to emphasize left and

Bass, Treble

TV Mounting (Wall/Table)

Audyssey TV Mounting feature can provide an

appropriate sound depending on the TV installat ion ty pe,

that TV is installed on a wall or a TV table.

a In the Sound menu, press B /b to select

Audyssey Premium Television and press OK.

b Press B /b to select TV Mounting.

c Press c and B / b to select Wall or Table.

Dynamic Volume

Audyssey Dynamic Volume

eliminate loud spikes and raise soft dialog for more

enjoyable television and movie viewing.

controls volume levels to

a In the Sound menu, press B /b to select

Audyssey Premium Television and press OK.

b Press B /b to select Dynamic Volume.

c Press c and B / b to select Day, Night or Off.

Audyssey ABX™

Audyssey ABX™ technology uses sophisticated driver

analysis and low frequency monitoring to extend the range

and bass of small speakers. This enables the system to

produce lower frequencies that would be possible with a

traditional system of the same size.

a In the Sound menu, press B /b to select

Audyssey Premium Television and press OK.

b Press B /b to select Audyssey ABX.

c Press c and B / b to select the desired

Audyssey ABX level (Low, High or Off).

a In the Sound menu, press B / b to select Bass or

Treble.

b Press C / c to change the setting.

Dynamic Range Control

This feature allows control of audio compression for some

digital TV programmes (MPEG-1 and MPEG-2 audio

programmes are not supported).

a In the Sound menu, press B /b to select

Dynamic Range Control.

b Press c and B / b to select On or Off.

CONTROLS AND FEATURES

DTV 2ch 0

ATV 0 External Input 0

< Audio Level Offset

< Headphone Level

Speaker Link On

Headphone Level 30OnOff

Audio Description On

Mixing Level 80

< Audio Description

English

Audio Level Offset

Sometimes there can be large changes in volume when

switching from a DTV 5.1ch to a DTV 2ch, an ATV

channel, or an external input. Using the Audio Level

Offset feature reduces these volume differences.

a Set the volume level usually used when watching

a DTV 5.1ch programme.

b Tune to a channel which is DTV 2ch, ATV or an

external input.

c In the Sound menu, press B / b to select Audio

Level Offset and press OK.

d Press B /b to select an option, and then press C /

c to adjust the volume level.

NOTE:

• The available item changes depending on the current

input source. For example, while watching a DTV 2ch programme, only DTV 2ch is available and the other two items are greyed out in the menu. This allows you to easily adjust according to each condition.

• When watching a DTV 5.1ch programme, this feature is

not available.

TV Speakers On/Off

This feature allows you to turn the TV speakers off when

connecting the audio system.

a In the Sound menu, press B / b to select TV

Speakers.

b Press c and B / b to select Off.

To turn on the built-in speakers:

Select On in step 2.

Headphone Settings

This setting is used to set the sound output when

Speaker

Link

On Sound is output

Off Sound is output

headphones are connected.

Headphone Speakers

2 ± is available.)

(

(Headphone level menu is available.)

No sound

Sound is output

2 ± is available.)

(

a In the Sound menu, press B /b to select

Headphone Level and press OK.

b Press B /b to select Speaker Link and press c

and

B / b to select On or Off.

c If you select Off, then highlight Headphone Level

and use

C / c to adjust the headphone sound.

Audio Description

Audio Description is an additional narrative sound track for

visually impaired individuals to understand and enjoy the

story line more fully. The letters AD will be displayed in the

channel banner when programmes contain AD content.

a In the Sound menu, press B /b to select Audio

Description and press OK.

b Press B /b to select Audio Description and

press

c and B / b to select On.

The AD button on the remote control can al so be used to toggle the Audio Description feature between On and Off.

c To adjust the level of the audio description sound

to the main sound, highlight Mixing Level and press

C / c.

CONTROLS AND FEATURES

This setting will enlarge a 4:3 image

to fit the screen by stretching the image horizontally and vertically,

holding better proportions at the

centre of the image. Some distortion

may occur.

When subtitles are included on a

letterbox format broadcast, this

setting will raise the picture to ensure

that all the text is displayed.

When watching ‘all sides panel

format’ films/video tapes, this setting

will eliminate or reduce the black bars at all sides of the screen by

zooming in and selecting the image

without distortion.

Use this setting when watching a

widescreen DVD, widescreen video tape or

a 16:9 broadcast (when available). Due to

the range of widescreen formats (16:9, 14:9,

20:9 etc.) black bars may be visible on the

top and bottom of the screen.

Use this setting to view a true 4:3 broadcast.

Use this setting when watching a 14:9

broadcast.

WIDE

4:3

SUBTITLE

14:9

SUPER LIVE

CINEMA

Widescreen viewing

English

Depending on the type of broadcast being transmit ted, programmes can be viewed in a number of formats.

CONTROLS AND FEATURES

This setting will show the picture without overscan, i.e. WYSIWYG. This option is only available when

watching a PC signal source via

HDMI or PC terminal.

This setting will show the picture

without overscan or side panels. This option is only available when

watching a PC signal source via

HDMI or PC terminal.

“Dot by Dot” is a non-scaling display. Depending on the input signal format,

the picture is displayed with side

panels and/or bars at the top and

bottom (e.g. VGA input source).

This setting will show the picture without overscan, i.e. WYSIWYG.

NATIVE

PC NORMAL

PC WIDE

Dot by Dot

AV format PC format

Picture Size

PC Normal

PC Wide Dot by Dot

Picture Size

Wide

4:3 Super Live Cinema Subtitle 14:9 Native

English

Press the button on the remote control to display the list of available widescreen formats. Press the button repeatedly to highlight the required format. The Quick Menu feature can also be used to select Picture Size.

Using the special functions to change the size of the displayed image (i .e. changing the height/width ratio) for the purposes of public display or commercial gain may infringe on copyright laws.

CONTROLS AND FEATURES

Picture Mode Standard

Reset

Backlight 0 Contrast 100 Brightness 0 Colour 0 Tint 0 Sharpness 0 Advanced Picture Setting Expert Picture Setting Display Setting

< Picture

ColourMaster Off

Base Colour Adjustment

Colour Temperature Auto Brightness Sensor On Active Backlight Control High Black/White Level Middle Noise Reduction Resolution+ On ClearScan High

Reset

< Advanced Picture Settings

Off

Picture controls

English

Most of the picture controls and functions are available in both digital and analogue modes.

PLEASE NOTE: Features not available will be greyed out.

Picture Mode

This television offers the choice of personalising the

AutoView, Dynamic, Standard, Hollywood Night,

Hollywood Day, Hollywood Pro, Store, Game and PC

are preset options and affect many features/settings

NOTE:

• Because the AutoView mode automatically adjusts picture settings based on ambient light conditions and input signal content, the Auto Brightness Sensor and Expert Picture Setting is greyed out when it is selected.

• Store mode is only available when Location is set to Store.

• Game mode is available in external input mode (other than aerial input). When you select Game mode, suitable widescreen formats will be selected.

• PC mode is available in RGB/PC input mode or HDMI input mode.

picture style.

within the television.

a Press and B /b to hi gh l ight Picture icon

and press OK.

b Press c and B / b to select Picture Mode and

press OK.

Picture preferences

You can customize current picture mode settings as

desired. For example, while selecting “Dynamic”, if you

change the following items, such as Backlight, Contrast,

Brightness, Colour, Tint, Sharpness and the Advanced

Picture Settings items, your new settings are saved for

“Dynamic” picture mode.

a In the Picture menu, press B / b to select either

Backlight, Contrast, Brightness, Colour, Tint or Sharpness and press OK.

b Press C /c to adjust the settings and press OK.

Reset

This feature resets all picture settings to the factory

settings except Picture Mode.

a In the Picture menu, press B / b to select Reset

and press OK.

b A confirmation message will appear. Press C / c

to select Yes and press OK.

ColourMaster

When ColourMaster is set to On, it allows the ‘Base

Colour Adjustment’ feature to become available.

a In the Picture menu, press B / b to select

Advanced Picture Settings and press OK.

b Press b to select ColourMaster and press c and

B / b to select On or Off.

c Press B / b to select the picture mode you prefer

and press OK.

NOTE: The picture mode you select affects the current

input only. You can select a different picture mode for each input.

CONTROLS AND FEATURES

Hue Saturation Brightness

Red

00 0

Green 0 0 0 Blue 0 0 0 Yellow 0 0 0 Magenta 0 0 0 Cyan 0 0 0

Base Colour Adjustment

Reset

Edit

Red

0 00

Hue Saturation Brightness

English

Base Colour Adjustment

The Base Colour Adjustment feature allows the

adjustment of individual colours to suit personal

preference. This can be useful when using an external

source.

a In the Advanced Picture Settings menu, press

B / b to select Base Colour Adjustment and

press OK.

b Press B / b to select an option and press c to

move to the adjustment window.

c Press C / c to select Hue, Saturation or

Brightness and press

as required.

B / b to adjust the settings

d Press BACK to return to the previous menu.

To return to the factory settings, select Reset and

press OK.

Colour Temperature

Colour Temperature increases the “warmth” or

“coolness” of the picture by increasing the red or blue tint.

a In the Advanced Picture Settings menu, press

B / b to select Colour Temperature and press

OK.

Auto Brightness Sensor

When the Auto Brightness Sensor is activated, it will

automatically optimise the backlighting levels to suit

ambient light conditions.

a In the Advanced Pict u r e Se t tings menu, press

B / b to select Auto Brightness Sensor and

press OK.

b Press B /b to select On or Off and press OK.

Active Backlight Control

When the Active Backlight Control feature is activated,

it will control the backlighting levels depending on various

scenes such as picture motion, bright scene or dark

scene.

a In the Advanced Pict u r e Se t tings menu, press

B / b to select Active Backlight Control and

press OK.

b Press B / b to select High, Low or Off and press

OK. High: To control the backl ighting levels depending

on various scenes such as picture motion, bright scene or dark scene

Low: To control the backlighting levels for dark

scene

Black/White Level

Black/White Level increases the strength of dark areas of

the picture to improve the definition.

a In the Advanced Pict u r e Se t tings menu, press

B / b to select Black/White Level and press OK.

b Press B /b to select High, Middle, Low or Off

and press OK.

b Press B / b to select Colour Temperature and

press OK.

c Press B / b to select Cool, Natural or Warm to

suit your preference and press OK.

d Press B / b to select Red Level, Green Level or

Blue Level and press

NOTE: To return the adjustments to the factory defaults, select Reset and press OK.

C / c to adjust the level.

CONTROLS AND FEATURES

< Noise Reduction

MPEG NR Low

DNR Auto

MPEG NR – Noise Reduction

English

When watching a DVD, the compression may cause some

words or picture elements to become distorted or

Using the MPEG NR feature reduces this effect by

pixelated.

smoothing out the edges.

a In the Advanced Picture Settings menu, press

B / b to select Noise Reduction and press OK.

b Press b to select MPEG NR and press OK.

c Press B / b to select Off, Low, Middle or High to

suit your preference and press OK.

NOTE: If the picture mode is set to Game or PC, this

feature is not available.

DNR – Digital Noise Reduction

DNR allows you to “soften” the screen representatio n of a

weak signal to reduce the noise effect.

a Select DNR from the Noise Reduction menu.

b Press B / b to select Off, Low, Middle, High or

Auto and press OK. The differences may not

always be noticeable (for the best result use lower

settings as picture quality can be lost if the setting

is too high).

NOTE: If the picture mode is set to Game or PC, this feature is not available.

Resolution +

The Resolution+ feature allows you to adjust the clarity

levels for your desired picture settings.

a In the Advanced Picture Settings menu, press

B / b to select Resolution+ and press OK.

b Press B / b to select On.

NOTE:

• This feature may not work properly depending on the content.

• Noise may appear in the picture depending on the device connected to the TV (e.g. a device with a specific enhancer function).

ClearScan

This feature helps to eliminate video shaking.

a In the Advanced Pict u r e Se t tings menu, press

B / b to select ClearScan and press OK.

Press

B / b

to select

Off

High, Middle, Standard

Resetting the advanced pi ct ure

settings

This feature allows you to reset the current Advanced

Picture Settings to the default values.

a In the Advanced Pict u r e Se t tings menu, press

B / b to select Reset.

b Press OK.

Expert Picture Settings

This feature is available when the Picture Mode option is

Standard, Hollywood Day, Hollywood Night, and

Test Pattern

When the test pattern is on screen, you can navigate in the Picture submenus and adjust picture settings without removing the image. When you move to a non-Picture menu, or close the menus, regular video will be restored.

Hollywood Pro.

a In the Picture menu, press B / b to select Expert

Picture Settings and press OK.

b Press B / b to select Test Pattern and press OK. c Press B /b to select On and press OK.

RGB Filter

This feature individually enables or disables the red, green, and blue components of the picture to allow for more accurate adjustment of each colour.

a In the Expert Picture Settings menu, press B /b

to select RGB Filter and press OK.

b Press B /b to select Red, Green or Blue to

adjust and press OK.

c Press B /b to select On and press OK. d Press B / b to select Colour or Tint and press C /

c to adjust.

e Press OK.

NOTE: It is not possible to turn off all three colours

simultaneously.

CONTROLS AND FEATURES

Auto Gamma Calibration Please input the target value and place the USB colour analys er over

the square.

Target Colour Temperature Target Gamma

0.313

2.4

0.329 (D65)

ResetStart

English

Colour Decoding

If you view DVDs with this TV, the Colour Decoding option may be set to ensure the colourimetry reproduction.

NOTE: The modes excluding Auto (BT.709 and BT.601) are to convert an irregular signal output from the DVD etc. with incorrect colour to the optimum state. If BT.709 or BT.601 is selected with a normal signal received, the colour may not be correctly displayed. This feature should normally be set to Auto.

a In the Expert Picture Settings menu, press B / b

to select Colour Decoding and press OK.

b Press B / b to select Auto, BT.709 or BT.601 and

press OK.

White Balance-Window Display

This feature displays a special Window Pattern to be used when adjusting white balance with a measuring device.

a In the Expert Picture Settings menu, press B / b

to select White Balance and press OK.

b Press B / b to select Window Display and press

c and B / b to select On and press OK.

White Balance-Setting Type

You can choose from two types of White Balance adjustment.

a In the Expert Picture Settings menu, press B / b

to select White Balance and press OK.

b Press B /b to select Setting Type and press OK.

White Balance-10P White Balance

a Press b to select 10P White Balance.

b Press B /b to select IRE, Red, Green, or Blue.

c Press C /c to adjust and press OK.

NOTE: The adjustments made for Red / Green / Blue are stored separately for each IRE setting. (There are ten IRE settings from 10 to 100.)

Gamma Calibration

Toshiba has integrated picture calibration systems into its LCD televisions. Now you can enjoy the benefits of automatically calibrated gamma and white levels.

In order to take advantage of these features the Toshiba colour analyzer TPA-1 is required.

a In the Expert Picture Settings menu, press B /b

to select Gamma Calibration and press OK.

b Press B /b to select Apply Calibration and

press

c and B / b to select Enabled and press

OK.

c Press B /b to select Auto Gamma Calibration

and press OK.

d Connect the USB colour analyzer to the USB 1 or

USB 2 port.

e Input the target value and place the USB colour

analyzer over the square on screen.

c Press B / b to select 2P or 10P and press OK.

White Balance-2P White Balance

a Press b to select 2P White Balance and press

OK.

b Press B / b to select Red-Offset, Green-Offset,

Blue-Offset, Red-Gain, Green-Gain, or BlueGain.

A white square will appear on the screen.

c Press C / c to adjust and press OK.

f Highlight Start and press OK.

Auto Gamma Calibration will start. Please wait until you see “Auto Gamma Calibration

has been completed.” on screen.

To return to factory setting

a Highlight Reset and press OK.

CONTROLS AND FEATURES

Auto Format On

4:3 Stretch Off

Picture Position PC Settings

< Display Settings

Horizontal Position 0

Vertical Position 0

Reset

< Picture Position

Automatic Format (Widescreen)

English

When this television receives a true Widescreen picture

and Auto Format is On, it will automatically be displayed

in Widescreen format irrespective of the television’s

previous setting.

a Press and B /b to hi gh l ight Picture icon.

b Press c and B / b to select Display Settings and

press OK.

c Press B / b to select Auto Format and press OK.

d Press B / b to select On or Off and press OK.

4:3 Stretch

When 4:3 Stretch is activated, the size switching system

changes 4:3 programmes into full screen picture.

a In the Display Settings menu, press B /b to

select 4:3 Stretch and press OK.

b Press B / b to select On or Off and press OK.

Picture Position

The picture position may be adjusted to suit personal preference and can be particularly useful for external

NOTE: The Picture Position feature cannot be selected on DTV or PC Inputs.

inputs.

a In the Display Settings menu, press B /b to

select Picture Position and press OK.

b Press B / b to select an option and press C / c to

adjust the settings and press OK. The options differ depending on the currently

selected widescreen format and the input signal.

To return to the original factory settings, select

Reset in the Picture Position menu and press OK.

Picture still

This feature is used to hold a still image on the screen.

a Press r to hold an image on the screen, and

press

r again to cancel.

HDMI Information Display

When the HDMI Information Display feature is On and

you are watching an HDMI input source, pressing

displays the HDMI signal information banner.

a In the Options menu, press B / b to select HDMI

Information Display and press OK.

b Press B / b to select On.

HDMI signal information is as follows: Resolution, Scan Type, Frame Rate, Aspect, Bit Depth, Colour Space, RGB/YUV, Chroma Format, and Content Type (if available).

CONTROLS AND FEATURES

English

Wireless LAN Information

Bluetooth™ and Wireless LAN devices operate within the same radio frequency range and may interfere with one another. If you use Bluetooth™ and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection.

If you should experience any such problem, immediately turn off either your Bluetooth™ or Wireless LAN device.

Actual performance can vary, including lower wireless network capacity, data throughput rate, range and coverage. Performance depends on many factors, conditions and variables, including distance from the access point, volume of network traffic, building materials and construction, operating system used, mix of wireless products used, interference and other adverse conditions.

Wireless LAN and your Health

Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by Wireless LAN devices, however, is far less than the electromagnetic energy emitted by wireless devices such as mobile phones.

Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes Wireless LAN is safely used by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building or responsible representatives of the organisation. Such restrictions may apply in environments where the risk of interference to other devices or services is perceived or identified as harmful.

If you are uncertain of the policy that applies to the use of wireless devices in a specific organisation or environment, you are encouraged to ask for authorization to use the Wireless LAN device prior to turning on the equipment.

When using the TV under wireless LAN environment:

NOTE:

• When Encryption is set to “None”, data transmitted over a wireless LAN is not securely protected. Unauthorized users may access your data and network without appropriate security measures. Selecting an en cryp tion setting from your Toshiba TV and using a secure network for wireless LAN transmissions may help avoid unauthorized access to your important data and/or TV. Toshiba disclaims any and all responsibility or liability resulting from any wireless transmissions over the Internet through your Toshiba TV.

• The function of all IEEE802.11 is not supported.

• The ad-hoc mode is not supported.

• It is recommended to use IEEE 802.11a or IEEE

802.11n on 5 GHz for audio and SD video streaming.

• It is recommended to use IEEE 802.11n on 5 GHz for HD video streaming.

• It is recommended that the encoding rate for streaming video content is 20 Mbps or less.

• It is not recommended to use 2.4 GHz for audio and video streaming.

• Content playback may be interrupted by various surrounding interference.

Europe Statement

This Built-in WLAN Module may be operated in below country:

AT Austria IS Iceland BE Belgium LI Liechtenstein CH Switzerland LT Lithuania CY Cyprus LU Luxembourg CZ Czech Republic LV Latvia DE Germany MT Malta DK Denmark NL Netherlands ES Spain NO Norway FI Finland PL Poland FR France PT Portugal GB United Kingdom SE Sweden GR Greece SI Slovenia EE Estonia SK Slovakia HU Hungary BG Bulgaria IT Italy RO Romania IE Ireland TR Turkey

• If this device is going to be operated in the frequency range of 5.15 GHz to 5.35 GHz, it is restricted to indoor use.

• If this device is going to be operated for 802.11 b/g/n function in the frequency range of 2.454 GHz to 2.4835 GHz in France, it is restricted to indoor use.

• A general authorization is required for using this device outdoors or in public places in Italy.

• This device is NOT ALLOWED to be used in the geographical area within a radius of 20 km from the centre of Ny-Alesund in Norway.

• Make the wireless LAN appropriate security setting at the time of wireless LAN use to prevent the illegal use, spoofing and interception of communications.

CONTROLS AND FEATURES

Network Setup

Network Device Setup Smart Apps Setup

< Network

Connection Type Wireless Wireless Setup Advanced Network Setup Network Connection Test

< Network Setup

Wired

Wireless

Easy Setup

Assisted Setup Manual Setup

< Wireless Setup

Setting up the Network

English

You can select the Network Type.

a Press and B /b to highlight Network icon. b Press c and B / b to select Network Setup and

press OK.

c Press B / b to select Connection Type and press

c and B / b to select Wired or Wireless.

d If you selected Wired, see “Advanced Network

Setup” on page 47.

NOTE: After you change between Wireless and Wired, switch off and on AC power supply to reset your TV. Communication may be impossible after the change of

Wireless / Wired.

Wireless Setup

NOTE: Continued connection of AP (Access Point) is not

guaranteed. The connection may be disconnected while watching TV.

There are 3 methods for Wireless Setup

Easy Setup (WPS)

If the AP supports WPS, this method can be used.

• WPS is an industry standard designed to make connection of wireless LAN equipment and security setup easy. WPS will automatically configur e all wireless settings.

NOTE: WEP encryption may not be able to configured by easy setup.

Assisted Setup (setup by using the AP’s notification information)

Network Name, Authentication, and Encryption are decided based on information from the AP. You will manually set the Security Key.

Manual Setup (manual input of all settings)

Easy Setup using PBC (Push Button Configuration)

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B /b to select Wireless Setup and press

OK.

c Press B /b to select Easy Setup and press OK.

d Press c and B / b to select PBC.

e Press b to highlight Start Scan and press OK.

f Following the on-screen instructions, push the

appropriate button on your AP.

g When a window reporting that the setup is

complete appears, press OK.

Easy Setup using PIN (Personal Identification Number)

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B /b to select Wireless Setup and press

OK.

c Press B /b to select Easy Setup and press OK.

d Press c and B / b to select PIN.

e Press b to select Start Scan and press OK.

f Press B /b to select the desired AP and press

OK. NOTE: Check the Network Name and/or MAC

address on the label of the AP or in the manual, and select your AP.

g When the PIN code window appears, enter the

displayed PIN into your AP, and then press Next to continue the PIN Setup. When a message displays to report that the setup is complete, press OK.

CONTROLS AND FEATURES

Easy Setup

Assisted Setup

Manual Setup

< Wireless Setup

English

To cancel searching for the AP:

Press BACK while searching for the AP. A message will appear, and then press C

Yes and press

OK.

/ c to select

Assisted Setup

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B / b to select Wireless Setup and press

OK.

c Press B / b to select Assisted Setup and press

OK.

d Press B / b to select the desired AP and press

OK. NOTE: Check the MAC addre ss on the label of the

AP or in the manual, and select your AP.

e Highlight Security Key and press OK. The

Software Keyboard window will appear.

f Input the Security Key by using the Software

Keyboard (see page 49). To save your setting, press the GREEN button.

NOTE:

• The Security Key must adhere to these conditions:

- TKIP/AES: 8-63 ASCII or 64 Hex characters

- WEP: 5 or 13 ASCII or 10 or 26 Hex characters

• There is only one key ID to set for WEP encryption.

g Highlight Done and press OK.

NOTE: If Network Name is not displayed, see step 3 and 4 in Manual Setup to set Network Name before pressing Done.

NOTE: Settings are not saved if BACK is pressed before Done is selected.

Manual Setup

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B /b to select Wireless Setup and press

OK.

c Press B /b to select Manual Setup and press

OK.

d Press B /b to select Network Name and press

OK. The Software Keyboard window will appear.

e Input the Network Name by using the Software

Keyboard (see page 49). To save your setting, press the GREEN button.

f Press B /b to select Authentication and press c

and

B / b to select Open System, Shared Key,

WPA-PSK or WPA2-PSK.

g Press B /b to select Encryption and press c

and

B / b to select None, WEP, TKIP or AES.

NOTE:

• Certain encryption types are only compatible with specific authentication types.

- When Authentication is Open System, only

WEP or None is compatible.

- When Authentication is Shared Key, only WEP

is compatible.

- When Authentication is WPA-PSK or WPA2-

PSK, only TKIP or AES is compatible.

• When incompatible Authentication/Encryption pairings are detected, a warning message will be displayed, and no connection attempt will be made until the incompatibility is resolved.

• There is only one key ID to set for WEP encryption.

h Press B / b to select Security Key and press OK.

i Input the Security Key by using the Software

Keyboard (see page 49). To save your setting, press the GREEN button.

NOTE: This ite m is greyed out when Encryption is None.

j Highlight Done and press OK.

NOTE: When Encryption is None, a message will

appear. Press

NOTE: Settings are not saved if BACK is pr esse d be fo re Done is selected.

C / c to select Yes and press OK.

CONTROLS AND FEATURES

Intel® WiDi Picture Mode Standard Picture Size Wide 3D Settings More Information Channel Options Sleep Timer HDMI CEC Device Control Speakers TV Speakers Headphone Level 30

Wireless Information

Recording Information

Quick Menu

Wireless Information

English

The settings configured in Wireless Setup can be confirmed.

a Press QUICK to open the Quick Menu.

b Press B / b to select Wireless Information and

press OK.

c When the Network Type is Wireless, a Wireless

Information window will appear.

NOTE: Press the RED button to scan for all APs.

Item Description

Status Connected is displayed when the TV is

Signal Connection signal strength with AP

connected with the AP. Disconnected is displayed when the TV is not connected with the AP.

(STRONG/MEDIUM/WEAK) Speed Link with AP Mode Working mode (11a, 11b, 11g, 11n) Network

SSID set Name

Authentication A uthentication set Encryption E ncryption set Security Key Security Key set AP MAC

Address TV MAC

Address DHCP Enabled is displayed when using

The AP’s MAC address is displayed

when the TV is connected with the AP.

The MAC address of the TV(Wireless)

is displayed.

DHCP.

Disabled is displayed when not using

DHCP. IP Address The TV’s IP address Subnet Mask Value of the Subnet Mask Default

Gateway

Address of the Default GATEWAY

DNS Address of the DNS

NOTE: Even if an AP for IEEE 802.11n is used when Encryption is set to WEP or TKIP, the Speed value might be low. It is recommended that Encryption be changed to AES (see “Manual Setup” on page 45).

Notes on wireless LAN environment

• The function of all IEEE802.11 is not supported.

• The ad-hoc mode is not supported.

• It is recommended to use IEEE 802.11a or IEEE

802.11n on 5 GHz for audio and SD video streaming.

• It is recommended to use IEEE 802.11n on 5 GHz for HD video streaming.

• It is recommended that the encoding rate for streaming video content is 20 Mbps or less.

• It is not recommended to use 2.4 GHz for audio and video streaming.

• Content playback may be interrupted by various surrounding interference.

CONTROLS AND FEATURES

Connection Type Wireless Wireless Setup

Advanced Network Setup

Network Connection Test

< Network Setup

IP Address Setup

DNS Setup MAC Address

< Advanced Network Setup

Auto Setup On

IP Address Subnet Mask Default Gateway

IP Address Setup

Off

Auto Setup IP Address Subnet Mask Default Gateway

IP Address Setup

Off

xxx xxx xxx xxx

Auto Setup IP Address

Subnet Mask

Default Gateway

IP Address Setup

Off

xxx xxx xxx xxx

English

Advanced Network Setup

NOTE:

• When the DHCP function of the router connected with this TV is On, you can set Auto Setup to On or Off. (This should usually be set to On.)

• When the DHCP function of the router is Off, set Auto

Setup to Off, and set the IP Address manually.

IP Address Setup Auto Setup

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B / b to select Advanced Network Setup

and press OK.

c Press B / b to select IP Address Setup and

press OK.

d Highlight Auto Setup and press c and B / b to

select On.

d Highlight Auto Setup and press c and B / b to

select Off.

... ... ...

e Press B /b to select IP Address.

f Press C /c to highlight the field you want to

change, and then use the number buttons to input the IP address. To save the setting, press OK.

NOTE: IP address field number s must be between 0 and 255. After each field number has been set, press OK to store the entire address. If the entire IP Address is invalid, a warning message will appear after OK is pressed.

g Press B /b to select Subnet Mask, and edit in

the same way as IP Address.

...

h Press B /b to select Defa u lt Gateway, and edit

in the same way as IP Address.

NOTE: If you manually set the IP address, you must not use the same IP address for any other device. The IP address you use should be a private address.

. . . . . . . . .

NOTE: Other items will be greyed out when Auto Setup is set to On.

Manual Setup

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B / b to select Advanced Network Setup

and press OK.

c Press B / b to select IP Address Setup and

press OK.

CONTROLS AND FEATURES

Auto Setup Primary DNS Address Secondary DNS Address

DNS Setup

Off

xxx xxx xxx xxx

English

NOTE: When the DHCP function of the router connected to this TV is Off, set Auto Setup to Off, and manually set the DNS address(es). Your internet service provider should have provided these to you.

DNS Setup

Auto setup

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B / b to select Advanced Network Setup

and press OK.

c Press B / b to select DNS Setup and press OK.

d Press B / b to highlight Auto Setup and press c

and

B / b to select On.

NOTE: Other items will be greyed out when Auto Setup is set to On.

Manual setup

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B / b to select Advanced Network Setup

and press OK.

c Press B / b to select DNS Setup and press OK.

MAC Address

You can view the fixed MAC address for the TV (Wired and Wireless).

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B / b to select Advanced Network Setup

and press OK.

c Press B / b to select MAC Address and press

OK.

Network Connection Test

This function checks the Internet connectivity.

a In the Network menu, press B / b to select

Network Setup and press OK.

b Press B /b to select Network Connection Test

and press OK. A message will appear to indicate if the connection

was successful or if it could not be completed. NOTE: The result of Network Connection Test

does not always guarantee the connection.

To cancel the Network Connection Test:

a Press EXIT while testing.

d Press B / b to select Auto Setup and press c

and

B / b to select Off.

... ...

e Press B / b to select Primary DNS Address.

f Press C / c to highlight the field you want to

change, and then use the number buttons to input the Primary DNS Address. To save the setting, press OK.

NOTE: DNS address field numbers must be between 0 and 255. If you input an incompatible number and press OK, the field number will reset to the maximum value(255).

g Press B / b to select Secondary DNS Address,

and edit in the same way as Primary DNS Address.

CONTROLS AND FEATURES

q a z

?&#

xcvbnm,.

;

sdf gh j k l ’_

we r ty u i op -

@./

ghi

pqrs

abc

jkl

tuv

def

mno

wxyz

Open Done

External Control Setup

Media Renderer Off Device Name Setup Intel® WiDi Setup

< Network Device Setup

Device Registration Setup New Device Detection Disabled

< Apps Control Profile

Enabled

Disabled

English

Using the software keyboard

You can enter text by using the Software Keyboard. The

Software Keyboard window will appear when you press

OK on a field that accepts character input.

To enter text using the software keyboard:

a Highlight the desired character on the on-screen

software keyboard.

b Press OK.

c Repeat steps 1 and 2 until you have entered all

desired text.

d Press the GREEN button to save your settings and

return to the previous screen. NOTE: If BACK is pressed, changes are not saved

and the software keyboard window is closed. The text will remain as it was before starting the keyboard.

Network Device Setup

Apps Control Profile

Toshiba Apps allow you to control the TV from a network

connected tablet or smartphone (availability is dependent

In order to use this function, the Setting up the Network (see page 44) and Device Name Setup (see page 50) are

required. The Device Name will display on the screen of

Apps (tablet or smartphone) application.

New Device Detection

a In the Network menu, press B / b to select

Network Device Setup and press OK.

b Press B / b to select External Control Setup and

press OK.

c Press B /b to select Apps Control Profile and

press OK.

d Press B / b to select New Device Detection and

press

on country).

c and B / b to select Enabled.

Input operation on the remote control:

Button Description

OK Inputs the selected character. 0-9 Selects a character for entry.

BbC c Moves the character highlight.

RED Deletes 1 character to the left

GREEN Functions as “Done”. YELLOW Functions as “Shift” key. BLUE Displays the help window. BACK Closes the Software Keyboard

of the cursor.

window without saving changes.

Pairing

To use Apps, it is necessary to connect a compatible tablet or smartphone and this TV to your home network, and carry out pairing (using a 4 or 8 digit password to authenticate the device). Refer to the Apps manual for more details about pairing.

NOTE:

• Pairing with external devices cannot be carried out when the TV is connected to an unencrypted wireless LAN access point. Activate the encryption settings for the wireless LAN access point before carrying out Pairing.

• When the Enable Control is not set to ON in External Control Setup, Apps functions including Pairing cannot be used.

CONTROLS AND FEATURES

Device Registration Setup

English

Once a User Name has completed authentication, it is stored in the TV along with the password. The u pper limit for the number of Use Names that can be remembered is

20. You can delete User Names that are stored in the TV.

a In the Network menu, press B / b to select

Network Device Setup and press OK.

b Press B / b to select External Control Setup and

press OK.

c Press B / b to select Apps Control Profile and

press OK.

d Press B /b to select Device Registration Setup

and press OK. The Device Registration Setup screen will appear and the list of Companion Device ID managed by the TV will be displayed.

e Press B / b to highlight the Companion Device

ID.

f Press B / b to select the Cancel, All, or Delete

buttons and press OK.

NOTE: When re-registering a device which has been

deleted from the list, registration must be carried out again.

TV Power On Control (Active

Standby)

When the TV is connected to the home network via

Wireless LAN, with the TV Power On Control in Enabled,

your TV can be turned on by control from Apps.

a In the Options menu, press B /b to select Power

Management and press OK.

b Press B / b to select TV Power On Control and

press

c and B / b to select Enabled (Active

Standby).

NOTE:

• Depending on the device connected to the home network, it may take a while for the TV to turn on.

• Depending on the device connected to the home network, this feature may not work.

• If the unencrypted Wireless Setup is done, this feature can not be used.

• The power consumption during Active Standby is more than it during Normal Standby.

• After the change from Power On state to Active Standby, there may be a period of several ten seconds which does not receive the operation from a remote control o r external apparatus.

Media Renderer Setup

The TV can be configured as a media renderer.

When operating as a media renderer, the TV displays

content provided by a media server.

The selection of the media is done by media controller.

The TV can play photo, movie, or audio files when

operating as a media renderer.

a In the Network menu, press B / b to select

Network Device Setup and press OK.

b Press B / b to select Media Renderer and press

c and B / b to select On.

If request comes from media controller, prompt will appear and the Media Renderer function will start.

To exit the Media Renderer:

Press EXIT.

Terminology

DMS: Digital Media Server DMR: Digital Media Renderer DMC: Digital Media Controller NOTE: You cannot use 3D function in operating as a

media renderer.

Device Name Setup

The TV’s device name can be changed.

a In the Network menu, press B / b to select

Network Device Setup and press OK.

b Press B /b to select Device Name Setup and

press OK. The Device Name Setup screen will appear.

c Press B /b to select Device Name and press

OK. The Software Keyboard window will appear.

d Input the Device Name by using the software

keyboard (see page 49). To save your setting, press the GREEN button.

NOTE:

• The Device Name can be up to 15 characters long.

• Only the 0-9, - and A-Z (uppercase only) characters may be used for the device name.

e Press b to highlight Done and press OK to save

your setting.

CONTROLS AND FEATURES

USB1 or USB2 on the TV

USB cable (not supplied)

USB HDD

English

USB HDD Record Function

This function can be used to record and play digital broadcast programmes (function is dependant on country selection). Read the precautions below before recording or viewing programmes using the USB HDD record function.

NOTE:

• In order to use this function, a USB HDD needs to be connected to the TV. Do not use USB Hub.

• After recording operation, time may take to a recording start.

• Recorded programmes saved on the USB HDD can only be viewed on this TV. They cannot be viewed when connected to another TV (including the same model of TV), a PC, or other device.

• You cannot watch other channel while recording one channel.

• If the recording time to the USB HDD is too short, no data may be saved.

• You cannot record video input signals on the USB HDD.

• Not all types of broadcast may be recordable.

• After programming the TV to record digital broadca sting, do not disconnect the power plug before recording starts.

• Should video or audio recording fail due to malfunction of the TV or poor reception, no compensation would be paid.

• If there is a power failure or the power plug is disconnected during programmed recording, recording will stop and will not resume when the power returns or the plug is reconnected.

• Do not disconnect the power plug when the indicator LED is lit.

• Any changes implemented by the broadcasting station may affect programme scheduling.

• Scheduling of multiple consecutive programmes may result in the beginning of each programme not being recorded.

• Accurate start / finish time for recording is reliant on broadcasters maintaining correct time stamp if this not the case the recording will fail.

• Some broadcasters can control whether a program can be recorded or how long you may be able to view it for after recording. The on screen message “Retention limit expired” means that the time limit for viewing the program has lapsed.

• Programmed recording cannot take place if the power plug is not connected.

• Disconnecting the power plug during recording may result in failure to save the recorded programme.

• USB HDD recording feature is not available in all countries.

• When the USB HDD is formatted, all the data stored on the HDD will be erased.

Setting up the USB HDD for

recording

To connect a USB HDD (not supplied):

When you connect a USB HDD to the USB port on the TV, a prompt will appear.

a Press C / c to select No and press OK.

NOTE: Not guaranteed to work with all USB HDD.

To record DTV programmes

(One Touch Recording)

To record the programme currently being viewed.

a Press the REC button on the remote control.

The currently viewed programme will start to be recorded.

To stop recording:

a Press the v (stop) button.

A confirmation window “Do you want to stop Recording?” will appear.

b Press C / c to select Yes and press OK.

Recording will stop.

CONTROLS AND FEATURES

Edit Timer 10:50 Tue, 26 Apr The Daily Politics

2 CABC Channel

11:30 - 12:30 Tue, 26 Apr Timer Type Recording

Set Timer Delete Timer

34 AB1 Hard Rain Wed,27 Apr 0:15-1:45

31 PARIS PREMIERE Red Corner Wed,27 Apr 22:15-23:55 11 NT1 The Lawnmower Man Thu,28 Apr 1:20-3:00

9 W9 A Vow to Kill Fri,29 Apr 1:30-3:00 34 AB1 Parenthood Sat,30 Apr 0:45-2:40 11 NT1 Body and Soul Sat,30 Apr 1:15-3:00 31 PARIS PREMIERE The Nun’s Story Sat,30 Apr 15:00-17:30

9 W9 Red Corner Sat,30 Apr 23:20-1:15 11 NT1 The Real Blonde Sun,1 May 0:40-2:00 31 PARIS PREMIERE Critters Sun,1 May 0:40-2:20 11 NT1 Indiana Jones and the Temple of Doom Sun,1 May 21:10-23:20 11 NT1 The jackal Sun,1 May 23:20-1:15 34 AB1 Coup De Ville Mon,2 May 1:10-3:00

Genre Search 5:48 Tue, 22 Apr

Movie

Edit Timer 10:50 Tue, 26 Apr The Daily Politics

2 CABC Channel

11:30 - 12:30 Tue, 26 Apr Timer Type Recording

Set Timer Delete Timer

How to set recordings via the

English

Programme Guide

Programmed recording can be scheduled easily using the

Programme Guide or by specifying the date and time.

PLEASE NOTE

When a timed programme is about to start, an information screen will appear offering the option of watching or cancelling the programme. Other channels will not be available during the timed programme unless the programme timer is cancelled.

It will only be possible to create or edit programme timers for the currently tuned DTV input.

Using the Programme Guide to set future recordings

a Press GUIDE on the remote control to display the

Electronic Programme Guide (EPG).

b Press BbC c to highlight the programme you want

to record and press OK.

c The Edit Timer screen will appear.

Press

B / b to select Timer Type.

To search for and record a programme using Genre Search:

a Press the YELLOW button on the remote control

to access the Genre Search screen.

b Press C /c to select the genre. Programmes listed

will change for the new genre. Press B /b to select the programme for which you want to schedule recording.

c Press OK. The Edit Timer screen will appear.

Press

B / b to select Timer Type.

d Press c and B / b to select Recording and press

OK.

e Press B /b to highlight Set Timer and press OK.

d Press c and B /b to select Recording and press

OK.

e Press B / b to highlight Set Timer and press OK.

CONTROLS AND FEATURES

Edit Timer 5:51 Tue, 22 Apr

Channel 30 CABC Channel

Timer Type Reminder

Set Timer Delete Timer

Date Tue, 22 Apr 2013 Start Time 10:51 End Time 11:51 Repeat Once

4 CHANNEL Z

6:00 Thu, 11 Oct

English

Now

MLB Young’s two-run triple leads AL over NL 6:00 - 8: 00

15 min left

Also

World News and Sports

MLB Young’s two-run triple leads AL over NL

Change

8:00- 9:00

News

Side by Side

Edit Timer 10:50 Tue, 26 Apr The Daily Politics

2 CABC Channel

11:30 - 12:30 Tue, 26 Apr Timer Type Recording

Set Timer Delete Timer

English

To programme the timer:

a Press the BLUE button on the remote control.

b Select the unprogrammed column (blank column)

and press OK. The Edit Timer screen will appear. Press

B / b to select Timer Type.

c Press c and B / b to select Recording and press

OK.

d Press B / b to go through the list adding the details

of the programme by using the number buttons and C / c to make selections.

•Channel

Select the channel you wish to record.

•Date

Select the date that you wish recording to start.

• Start Time

Select the time to start recording.

• End Time

Select the time to end recording.

• Repeat

Select “Once”, “Daily” or “Weekly”.

Once The selected content is recorded once. Daily The same time slot on the same channel is

Weekly The same time slot on the same channel on

recorded every day on and after the selected day.

the same day of the week is recorded on and after the selected day.

To schedule a programme using the information screen:

a Press , the information screen will appear

giving details of the channel and programme currently being viewed.

D+

3D 2D

16:9

AD 18

b Press B /b to select Next and press OK. The Edit

Timer menu will appear.

Press

B / b to select Timer Type.

c Press c and B /b to select Recording and press

OK.

d Press B / b to highlight Set Timer and press OK.

e Press B /b to highlight Set Timer and press OK.

CONTROLS AND FEATURES

Sort : New

3 / 5 WWWWWW Wed, 16 Feb 10:00 WWWWWWWWWWWW Wed, 16 Feb 10:00

WWWWWWW Thu, 17 Feb 10:00

WWWWWWW Fri, 18 Feb 10:00

WWWWWWW Fri, 18 Feb 10:00 WWWWWWW Sat, 19 Feb 10:00

WWWWWWW Sun, 20 Feb 10:00 WWWWWWW Sun, 20 Feb 10:00 WWWWWWW Sun, 20 Feb 10:00 WWWWWWW Mon, 21 Feb 10:00

Library / All

14:15 Wed, 16 Feb

All

1235 ITV London

ASTRA 19.2°E

10 July 2011 14:30(01:30) USB HDD3 Remaining Capacity: 86% (912.0GB)

To check, edit or delete scheduling

English

information

You can check, edit or delete scheduling information.

a Press GUIDE and then press the BLUE button.

Programme Timers screen will appear.

Recording List

• Depending on the transmitter information, the programme broadcast time or other information may not be correctly displayed in the recording list.

• The programme does not appear in the recording list immediately at the start of recording, but appears a few minutes after recording starts.

• Up to 64 programmes can be displayed in the recording list.

• If the channel settings are changed, the digital channel number, or other information may not appear correctly in the recording list.

• As the displayed programme time is calculated from the actual recording information, it may not match the recording time on the USB HDD.

To check a schedule:

a Press B / b on the Programme Timers screen to

check the schedule.

To edit a schedule:

a Press B / b on the Programme Timers screen to

select the title whose schedule you want to edit and press OK.

The Edit Timer screen will appear. Change the settings as required, following the same procedure as for setting the schedule.

b Press B /b to highlight Set Timer and press OK.

To delete a schedule:

a Press B / b on the Programme Timers screen to

select the title whose schedule you want to delete .

b Press the RED button.

Press C /c in the displayed confirmation wi ndow to select Yes and press OK. The selected schedule will be deleted.

NOTE: You can also delete a schedule by selecting Delete Timer from the Edit Timer menu for each

programming method.

To view a recorded programme

To view the recorded Library screen and select a title

from the recorded programme list.

a Press and highlight My Recordings icon and

press OK. The Library screen will appear.

b Press B / b to select the title you want to view.

A preview of the content selected can be seen on the preview screen.

To change the order in which the titles are listed, press the BLUE button.

c Press OK.

Viewing starts.

● icon appears next to the title currently being recorded. When the title currently being recorded is selected and OK is pressed, playback will start from the beginning of the programme currently being recorded.

Operations during viewing

The following operations can be performed using the remote control butto ns.

c To PLAY cc To FAST

v To STOP z To SKIP-

W To PAUSE/STEP C c To shift playback

Z To SKIP-B ACK CC To REWIND

FORWARD

position

CONTROLS AND FEATURES

Sort : New

3 / 5 WWWWWW Wed, 16 Feb 10:00 WWWWWWWWWWWW Wed, 16 Feb 10:00

WWWWWWW Thu, 17 Feb 10:00

WWWWWWW Fri, 18 Feb 10:00

WWWWWWW Fri, 18 Feb 10:00 WWWWWWW Sat, 19 Feb 10:00

WWWWWWW Sun, 20 Feb 10:00 WWWWWWW Sun, 20 Feb 10:00 WWWWWWW Sun, 20 Feb 10:00 WWWWWWW Mon, 21 Feb 10:00

Library / All

14:15 Wed, 16 Feb

All

1235 ITV London

ASTRA 19.2°E

10 July 2011 14:30(01:30) USB HDD3 Remaining Capacity: 86% (912.0GB)

Sort : New

WWWWWW Wed, 16 Feb 10:00 WWWWWWWWWWWW Wed, 16 Feb 10:00 WWWWWWW Thu, 17 Feb 10:00

WWWWWWW Thu, 17 Feb 10:00

WWWWWWW Fri, 18 Feb 10:00 WWWWWWW Fri, 18 Feb 10:00 WWWWWWW Fri, 18 Feb 10:00 WWWWWWW Sat, 19 Feb 10:00

Library / All

All

Thu, 17 Feb 10:00

Fri, 18 Feb 10:00 Fri, 18 Feb 10:00 Fri, 18 Feb 10:00

Sat, 19 Feb 10:00 Sun, 20 Feb 10:00 Sun, 20 Feb 10:00 Sun, 20 Feb 10:00 Mon, 21 Feb 10:00

10 July 2011 14:30(01:30) USB HDD3 Remaining Capacity: 86% (912.0GB)

1235 ITV London

ASTRA 19.2°E

English

Operations from the Library screen

As well as viewing the list of recorded titl es on the Library screen, you can protect or delete titles and re gister titles to

Personal Mode.

To display the Library screen:

a Press and highlight My Recordings icon and

press OK. The Library screen will appear.

To protect or unprotect a recorded programme:

Protecting a programme prevents it from being accidentally deleted.

Select the title of the programme you want to protect and press the GREEN button. icon appears next to the title and the programme is protected.

If Protect is set to On when the programme is recorded,

icon appears next to the title of the recorded

programme. When a title with icon is selected and the GREEN

button is pressed, icon disappears and the programme is unprotected.

To group the recorded programmes

a Press the YELLOW button. A grouping mode

window will appear. Week: Grouping the recorded programme by the

day (Sunday - Saturday) Genre: Grouping the recorded programme by the genre.

To delete a recorded programme:

a Press the RED button. Check boxes will appear

next to the titles.

b Press B / b to select the title you want to delete

and press OK. A check mark will be inserted in the check box.

To insert a check mark against all the titles, press the YELLOW button.

To uncheck all the check boxes, press the BLUE button.

NOTE:

• A check mark will not be inserted against protected titles.

• Note that once deleted, a title cannot be restored.

c Press the RED button.

Select Yes in the confirmation window and press OK.

All the titles with check marks will be deleted.

USB HDD capacity

You can check the remaining capacity of the USB HDD using Remaining Capacity.

To change the title of recorded programme

a Press QUICK when the Library screen is

displayed.

b Press b to select Title Edit and press OK.

The Software Keyboard window will appear.

c Input your desired title by using the software

keyboard (see page 49). Press the GREEN button to save your settings.

NOTE: The remaining capacity displayed is only a guide; it is not guaranteed.

CONTROLS AND FEATURES

Select Device

One Touch Recording Time 120 Minutes TimeShift Size 4GB Start Padding Time None End Padding Time None Device Test Format Device

< Recording Setup

Select Device One Touch Recording Time 120 Minutes TimeShift Size 4GB Start Padding Time None End Padding Time None Device Test Format Device

< Recording Setup

Programme End Time

30 Minutes 60 Minutes 90 Minutes 120 Minutes 150 Minutes 180 Minutes 210 Minutes 240 Minutes 270 Minutes 300 Minutes 330 Minutes

English

Recording Setup

You can set your preferences for recording.

To select USB HDD and Partition for Recording:

a Press and B /b to highlight Options icon. b Press c and B / b to select Recording Setup

and press OK.

c Press B /b to select Select Device and press

OK. USB HDD and Partition list will be appear.

If USB HDD is partitioned by PC, several partitions will be displayed.

d Select USB HDD and Partition you want to

recording.

To set the recording time for One Touch Recording:

a Press and B /b to highlight Options icon. b Press c and B / b to select Recording Setup

and press OK.

c Press B /b to select One Touch Recording

Time and press

recording time.

You can set the Programme End Time in 30minute increments in the range of 30 minutes to 330 minutes.

c and B / b to select the

To select the TimeShift Size:

a In the Recording Setup screen, press B / b to

select TimeShift Size.

b Press c and B / b to select 512 MB, 1GB, 2GB

or 4GB and press OK.

To use TimeShift recording:

Time Shift recording allows you to pause live TV for a

fixed period of time. For Example: If you move away from the TV for a short

period, such as when the phone rings while you are watching TV, you can easily pause live TV and then continue to view from the same point in the programme when you return.

a Press W on the remote control while viewing the

DTV programme. The screen will switch to a still image and recording will start automatically. The recording time is decided by TimeShift Size. If the TimeShift file size reaches the limit set, then the TV will continue to be paused, but the recording buffer will be reset to the beginning.

b Press c (play).

Catch-up viewing will start from where the programme was paused.

c Press v (stop) to stop the recording.

To set the padding time for programmed recording start time and end time:

a In the Recording Setup screen, press B / b to

select Start Padding Time.

b Press C / c to select a time.

You can select from None, 3 Minutes, 5 Minutes,

10 Minutes, 15 Minutes, 30 Minutes, and 45 Minutes.

Recording will start at the selected number of minutes prior to the recording start time.

c Press B / b to select End Padding Time. d Press C / c to select a time.

You can select from None, 3 minutes, 5 minutes, 10 minutes, 15 minutes, 30 minutes, and 45 minutes.

Recording will end at the recording end time plus the selected number of minutes.

CONTROLS AND FEATURES

English

To perform a USB HDD operation test:

a In the Recording Setup screen, press B / b to

select Device Test and press OK. USB HDD operation test will start.

Wait until the test ends.

NOTE: The results o f the device test are only a guide. The device may not function as shown in the results.

To format a USB HDD:

a In the Recording Setup screen, press B / b to

select Format Device and press OK.

b Press C / c to select Yes in the confirmation

window that will appear and press OK. Formatting will start. Wait until formatting ends.

NOTE:

• If the USB HDD is separated several partitions by PC and multiple Partition appear on the Device List screen, press B / b to select the Partition you want to format.

• When the USB HDD (or Partition) is formatted, all the data stored on the USB HDD (or Partition) will be deleted.

Scheduling priority

If scheduled time slots are next to each other and there is more than one minute between the end time of the first schedule and the start time of the next schedule, programmed recording will be performed correctly.

• When Start Padding Time and End Padding Time are set (see page 56), the start time and end time will be th e time plus the additional minutes.

If scheduling times overlap, priority will be given to the programmed recording which starts first. When the programmed recording that started first ends, recording will switch to the next scheduled programme. At this time, depending on how far the scheduling times overlap, the beginning section of the next scheduled programme may not be recorded.

Using the Cloud TV Service

Toshiba's universal portal for internet content and services (services are dependent on country).

NOTE: You need to configure a home network before using this feature (see page 12).

a Press .

The menu screen of the Cloud TV service will appear.

b Press BbC c to select a Cloud TV service, and

press OK. For the operations of the Cloud TV service, refer to Cloud Guide.

Using Web Browser

The web browser on this TV lets you explore everything the web has to offer. Along with access to popular pl aces, you'll be able to search for and browse you r favourite sites.

NOTE:

• Certain services may not be currently available in your

area.

• Your registration or login may be required to use some

services.

• Third party internet services are not provided by

Toshiba, may change or be discontinued at any time and may be subject to Internet service provider restrictions. Toshiba makes no warranties, representations, or assurances about the content, availability or functionality of third-party content or services. Use of third party Internet services may require the creation of a separate account through a computer with Internet access and/or payment of one-time and/or recurring charges and membership. Not all third party services may be available on or compatible with this product. In order to experience the full suggested capabilities of this product, fullycompatible devices may be required.

- does not support platform-dependent technologies such as Active X.

- only supports preinstalled plug-ins.

- may not support media formats other than the following: JPEG/PNG/GIF.

- uses a single built-in font. Some text may not be displayed as intended.

- does not support downloading of files or fonts.

- is a TV browser. It may work differently than PC browsers.

- does not support parental control or locks in the content, and it is the responsibility of the you to monitor browser usage by minors.

• Some pages may not be displayed correctly or may display differently on different devices.

• Certain services may not be available in your area.

CONTROLS AND FEATURES

To use the web browser

English

NOTE: You can change the mouse mode (Mouse Emulation or Navigation) by pressing the GREEN button on the remote control when the web contents screen is open.

a Press on the remote control and select

Internet icon to open the web browser.

b Press BbC c to select the URL address bar and

press OK.

c Enter the desired URL address by using the

Software Keyboard (page 49). Press the GREEN button on the remote control.

d You can now browse websites on your TV using

BbC c buttons on the remote control.

To Add Favourites Websites

By adding frequently visited websites to Favourites, you can browse them easily. You can view the addresses of the websites you visited previously.

a Press on the remote control and select

Internet icon to open the web browser.

b Enter the desired URL address by using the

Software Keyboard (page 49).

c Press BbC c to scroll Favourites STAR on the

Toolbar and press OK.

d Press OK to save the desired website to your

Favourites.

To browse favourite websites

a Press on the remote control and select

Internet icon to open the web browser.

b Use BbC c to select Favourites STAR and press

OK.

c Select the item or folders to move to the desired

URL address and press OK.

d You can now browse websites on your TV using

BbC c on the remote control.

PIP (Picture-in-picture) function

When viewing the web browser page, currently airing programmes or images from external inputs can be displayed in a PIP window (sub-screen).

a Press the RED button while viewing the web

browser page. The currently airing program or images from external inputs are displayed in a PIP window.

NOTE:

• The position of the PIP window, and whether it is displayed or not can be set in the web browser settings.

U and Pu buttons cannot be used when the PIP

• P window is displayed.

• Images in the PIP window cannot be displayed in 3D.

• Images from 3D signals will not be displaye d in the PIP window.

To stop displaying the PIP window:

Press the RED button when the PIP window is displayed.

e Press BACK on the remote to return to browsing

your website. You can press the GREEN button on the remote for thumbnail view of all your Favourites.

NOTE: The desired website is highlighted and displayed on the top row with the + icon. The + icon will change to a page icon after the website has been saved to Favourites.

CONTROLS AND FEATURES

Welcome to Skype

Skype Name

Password

Press [OK] Press [OK]

Create new Skype account

Full Name

Skype Name

1~70 characters

Yes, send me Skype news and special offers.

Password

Repeat Password

6 and 32 characters 6~20 characters

6~20 characters

Press [OK]

I have read and accept.

the Skype Terms of Use the Skype Privacy Statement

I agree - create account

Cancel

Create new Skype account

Full Name

Skype Name

1~70 characters 6 and 32 characters

English

Using Skype

Skype-ready Toshiba TVs bring your family and friends

closer to your home. Skype on your Toshiba TV allows

you to share special moments no matter the distance.

Before using Skype - Preparation

• Connect the FREETALK HD Camera: TALK-7291 to the TV’s USB terminal. Do not use a USB hub. For a Skype-ready Toshiba TV compatible camera, please visit the following website:

http://shop.skype.com

• Arrange the HD camera on top of the TV, ensuring it's in the centre.

• Connect to the network.

NOTE:

• The HD camera is sold separately.

• Do not connect a camera other than the recommended HD camera.

• Using a wireless network may result in degraded call quality.

• Some of the features available on other versions of Skype are not available on the television.

• When using Skype, some functions of the TV will not be available.

• The sound settings are switched to Skype mode.

• If you cannot hear the person you're speaking with, check your TV volume.

• When Optical Digital output or Analogue output is used and you are signed in, the ring tone may not sound.

• The volume level on Skype may differ from other features on your TV.

• When the Reset TV feature is used from the TV Menu, Skype information is reset to factory default settings.

• Screenshots used in this manual may differ from the TV Menu, Skype will be reset to its factory default settings.

Getting started

a Press on the remote control.

b Press BbC c to select Skype icon and press OK.

“Welcome to Skype” screen appears.

You can select a Skype name from the Skype Name drop down menu.

c Select Sign in or Create Account.

To create a new account:

If you do not already have a Skype account, you can create a new one from your TV.

a Select Create Account in the Welcome to Skype

screen and press OK.

No emergency calls with Skype

Skype cannot be used for emergency calls.

!“£$%^&*()_+

QWE R T Y U I O P { }

Alt

ASDFGHJKL : @~

|XCVBNM<>?

Enter

CONTROLS AND FEATURES

Tab

Status: Change your availability status Add Contact: Add a Skype account or phone number

EXIT:Return to previous screen. When at contact list, the EXIT

button will close Skype application without sign out.

The current status for each of your contacts are explained below:

: Online : Away : Offline : Phone number : Do not disturb : Offline with voice messaging or

call forwarding enabled

Your profile picture, status, Skype Name, mood message and available Skype Credit.

- TextTextTextTextTextText Te xtTextTextTextTextText

Name

Skype Credit

Contacts/People

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

+8888888888888

Status Add Contact Exit

No blocked contactor

Initiate Video Call Initiate Voice Call

View Profile -View contact profile (including Skype name, full

name, birth date, gender, location, mobile number and email).

Send Voice Message

-Send Voice Message to contact

Block -Block / unblock contact Remove -Remove contact from list

- TextTextTextTextTextTextTextTextTextTextTextText

Name

Skype Credit

Contacts/People

TextTextTextTextTextText

Name Name

TextTextTextTextTextText

Name Name

TextTextTextTextTextText

Name Name

TextTextTextTextTextText

Name Name

+8888888888888

Name Name

Video call Voice call

View Profile Send a Voice Message Block Remove

Status Add Conta ct Exit

b Enter your Full Name, Skype Name, Password,

English

Repeat password, and Email.

• If you want to receive Skype news and special offers, check the selection box. Skype will inform users about new products, features and special offers by email.

c Select “I agree - create an account” and press

OK.

d You'll now be signed into your new account.

NOTE:

• Please ensure that you have entered your email address correctly. It is required in case you lose or forget your password.

• If you forget your password, visit skype.com to retrieve it.

• If a message appears informing you that the entered Skype name is already registered, please choose a different name.

To Sign into Skype:

If you have a Skype account, sign into Skype in the Welcome to Skype screen.

a Enter your Skype Name and Password.

b Select Sign in and press OK.

•If “Sign in when Skype starts” is checked, your account will sign in automatically when you launch Skype from the menu.

•If “Start Skype when TV starts” is checked, your account will sign in automatically when you turn on the TV. Both these options can be selected together.

Basic Operation

Press B / b to select a tab (Contacts/People, Recent, Settings). Press list. Your contact list will contain the following information: Contact name / Current online status / Profile picture / Mood message

c and B / b to select a contact from the

Contacts/People

Press B / b to select Contacts/People tab. Press c and

B / b to select a contact.

When pressing OK at each contact, the following functions will appear:

CONTROLS AND FEATURES

Other side

Own side

Video call

Voice call

06:34:45

xxxx

ABC

JKL

TUV

DEF

MNO

WXYZ

GHI

PQRS

Incoming Call...

Name

Video Voice Dec line

- TextTextTextTextTextTextTextTextTextTextTextTe xt

Name

Skype Credit

Contacts/People

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

+8888888888888

Status Add Contact Ex it

Online Away Do not disturb Invisible

Sign Out

English

Video or Voice call

Press BbC c to select Video call or Voice call, your screen will now display your call as shown below.

Below is all icon pictures in conversation window.

Start video Stop video Resume the call Unmute the webcam mic Mute the webcam mic Normal size video Full screen video Open dial pad End call (Hang up the call)

Group calls

Using your Toshiba TV, you can join Skype group voice and video calls. However, you can only send and receive audio whilst on these calls.

NOTE: You must be invit ed on to a gro up call, you can not initiate it from the TV.

Incoming call

Incoming calls on Skype will be displayed on the bottom right hand corner of your TV screen. You'll also hear a ring tone which can be adjusted using the VOLUME buttons on your remote control.

You are given three options when an incoming call arrives:

• Video : Answer by video call.

• Voice : Answer by voice call.

• Decline: Decline the incoming call. NOTE: If other applications are active or recording, you'll

only get an “Incoming call notification“ until the application or recording has stopped.

Status

When you press the GREEN button, the change status window will appear as below. You can change your status by pressing B / b and OK. Press BACK to exit.

CONTROLS AND FEATURES

- TextTextTextTextTextTextTextTextTextTextTextText

Name

Skype Credit

Contacts/People

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

+8888888888888

Status Add Contact Exit

Add Contact Type

Skype Contact

Phone Number

Exit

Contact Search Results

Search Result: (jackyding)

Add a Skype contact

Full Name Skype Name Country

Aaaaaa_0101 Aaaaaa_0101 USA Bbbbbb007 Bbbbbb007 UK Cccccc0709 Cccccc A01 HK Ddddddd Ddddddd Ddd Taiwan Eeeeee_Eeee EE_Eeeee Japan Ffffffffff_Fu Ffffffffff_Ff Taiwan Gggggg_Ggg Gggggg _Ggg Taiwan

Back

Notification of authorization request

- TextTextTextTextTextTextTextTextTextTextTextText

Name

Skype Credit

Contact List

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

TextTextTextTextTextTextTextTextText

Name Name

+8888888888888

Status

Notification

You have received a contact request.

Request Form

ms_audi

Exit

john5678236

ms_audi

Hello! Please add me to your Contacts.

Accept Block Decline

- TextTextTextTextTextTextTextTextTextTextTextText

Name

Skype Credit

Recent

Tue Jul 3 04:07:47 2012 Duration 00:10:00

Name Name

Tue Jul 3 03:44:58 2012 Duration 00:00:00

Name Name

Mon Jul 2 10:01:11 2012 Durat ion 00:01:06

Name Name

Mon Jul 2 06:36:49 2012 Durati on 00:03:04

Name Name

Tue Jun 28 03:30:17 2012 Durati on 00:00:08

Name Name

Video call Voice call

View Profile Send Voice Message Listen to Voice Message Add to Contacts Delete This It em

Status Add Conta ct Exit

Add Contact

English

You can add contacts to your list of contacts. When you press the YELLOW button, the Add Contact

Type menu window will appear.

Two sub-functions are supported. Press B /b to select Skype Contact or Phone Number

and press OK.

• Skype Contact

Enter the Skype Name of the person you're looking for. The search result will show up after get response from Skype server.

• Phone Number

You can also enter a phone number in the search window.

When you receive a contact request, a pop-up menu will appear where you can choose to Accept, Block or Decline the request.

Press B / b to select and press OK.

Press C / c button to select and press OK.

Recent

You can see a list of past events in “Recent”. Press B /b to select the Recent tab. Press to select an item and press OK.

c and B / b

You can send a contact request to a person displayed in the search results. Press B /b to select a person and press OK.

Press C / c to select Video call or Voice call. Each call has an icon with it. The meaning of each icon is

as follows:

Icons Description

Incoming call Outgoing call Missed call Unread Voice Message Voice message

CONTROLS AND FEATURES

- TextTextTextTextTextTextTextTextTextTextTextText

Name

Skype Credit

Status Add Contact Exit

Dialer

Taiwan +886 Tajikistan +992 Tanzania +255 Thailand +66 Timor-Leste +670 Togo +228

Please input the country code

-Select One-

User Profile

Change Password

General Settings

Audio Settings

Privacy Settings

Blocked Contacts

Call Settings

About Skype

-Select One-

Name Name

-Select OnePress [OK] Press [OK]

Press [OK] Press [OK] Press [OK]

(1/2)

Gender

Birth Date

Country/Region

State/Province

City Home Phone Office Phone

Mobile Phone

(D) (M) (Y)

Exit

English

Dialer

You can call mobiles and landlines from this screen. Press B /b to select the Dialer tab. Press

to navigate this screen.

Select the country or region first, and then enter the phone number with area code. You'll need a little Skype Credit in your account to call mobiles or landlines using Skype. Emergency calls over Skype are not supported.

c and B / b

Settings

Press B / b to select the Settings tab and press OK. The Settings window will appear.

You can change the following settings:

• User Profile

Add or change your personal information e.g. birth date, country/region or phone number.

• Change Password

You can change your password by entering your existing password and new password twice.

• General Settings

Select whether Skype should automatically start when turning on the TV.

• Audio Settings

Adjust the speaker / ringtone volume manually. The volume of your speakers will be different on Skype

compared to your normal TV volume level. The speaker volume range is 0 - 100 % by 1 steps, and ringtone volume is 0 - 100 % by 25 steps.

• Privacy Settings

Set who you allow calls from, whether it's Anyone or People in my Contact list only.

• Blocked Contacts

If you do not want someone to reach you, simply block them by entering their Skype Name or phone number from this menu. Successfully blocked contacts are displayed in this window.

• Call Settings

If you're not signed into Skype, you can forward incoming calls to another phone number or Skype name, or choose to accept voice messages. However you'll need to have Skype Credit to turn this feature on.

• About Skype

Displays information about Skype.

CONTROLS AND FEATURES

Using Hybrid TV Standard

English

(if available)

Hybrid TV Standard enables the TV to receive HbbTV services. TV services which support this feature often show “press RED” on the screen.

NOTE: You need to configure a home network before using this feature (see page 12).

a Press and B /b to highlight Options icon.

b Press c and B /b to select Hybrid TV Standard.

c Press c and B / b to change from Disabled to

Enabled and press OK. When “press RED” is indicated on the screen,

press the RED button to access HbbTV service site, and then press contents.

NOTE:

• The HbbTV service indication or required key operations may not be possible depending on the service contents. In this case set the Hybrid TV Standard setting to Disabled.

• Toshiba makes no warranties, representations, or assurances about the content.

BbC c to se lect t he de si red

Using Intel® Wireless Display

Intel® Wireless Display (Intel® WiDi) is supported on this TV. You can use your TV as second display for PC with Intel Display.

a Press QUICK to open the Quick Menu.

b Press B / b to select Intel

A prompt will appear on the screen. Select Yes.

c Launch the Intel

select “scan for available adaptors”.

WiDi device name and ID list will then be

Intel displayed on the PC screen.

Select the TV which you wish to connect to. “Connecting” will be shown on the TV.

WiDi software on your PC and

d Connecting your PC to your TV the first time

When selecting the Toshiba TV for the first time, a 4-digit or 8-digit code will appear on your TV screen. This code needs to be inputted into your computer to authenticate the connection.

If authentication has already taken place

“Connected to Intel appear on screen.

e After the Intel

TV screen will mirror the content shown on the PC screen.

NOTE:

• When connecting Intel® WiDi, PC must have power turned on.

• When the Intel Connection Type is set to Wireless, other applications may not be usable.

• Intel the Intel

To exit Intel

Exit Intel WiDi software or by pressing EXIT on the TV remote control.

NOTE: If the PC has been inactive for some time, the

WiDi connection will be disconnected automatically.

Intel

WiDi device name of the TV can be changed fr om

WiDi software.

WiDi:

WiDi by pushing the disconnect button on Intel®

WiDi. Please Wait” will

WiDi connection is complete, the

WiDi software is active, and the

Wireless

WiDi and press OK.

CONTROLS AND FEATURES

English

Intel® WiDi Device Name

The TV's Intel

WiDi device name can be changed.

a In the Network menu, press B / b to select

Network Device Setup and press OK.

b Press B / b to select Intel

OK.

c Press B /b to select Intel

and press OK.

d Select Intel

The Software Keyboard window will appear.

e Input the Intel

software keyboard (see page 49). Press the

GREEN button.

WiDi Device Name and press OK.

WiDi device name by using the

WiDi Setup and press

WiDi Device Name

f Highlight Done and press OK to save your setting.

Device List

Device List displays a list of MAC addresses for previously

connected device that have been connected before. The

maximum number that can be stored is 20.

If the list run out of space, the least-recently-used MAC address will be deleted and the new MAC address added automatically.

a In the Intel

Device List and press OK.

Device List will appear.

The registered MAC Address can be deleted one by one by pressing RED key in the List.

When doing so the following text can be seen “Do you want to unregister this device? Yes/No” (default cursor is “No”).

WiDi Setup screen, highlight the

Using the Media Player

This TV allows you to enjoy movie, music and photo files stored on a USB device connected to the USB port. Moreover, you can also play photos, movi es or music files from your PC by connecting the TV to your home network.

Terminology:

DMP: Digital Media Player DMS: Digital Media Server DMR: Digital Media Renderer DMC: Digital Media Controller

• DMP: The TV can control and play content from a DMS.

- A DMS is a device that can function as a server for

DMP or DMR.

• DMR: The TV can play content from a DMS. Playback is controlled by a DMC.

- A DMC is a device that can instruct the TV to play

content.

NOTE:

• Do not insert/remove USB device while in use.

• MENU is not available during playback.

• When you want to use your TV as a media renderer, set Media Renderer to On (see “Media Renderer Setup” on page 50).

Media Player Specifications

Device

USB device Interface version: USB2.0 HS USB Mass Storage Class devices (MSC)

NOTE:

•Connectivity is not guaranteed for all devices.

•Incorrect behaviour may occur with a USB hub connection.

File system: FAT16 and FAT32 Maximum memory size: Depend on file system

You must obtain any required permission from copyright owners to download or use copyrighted content. TOSHIBA cannot and does not grant such permission.

CONTROLS AND FEATURES

Date Video 23:59, Wed, 31 Dec 1969 Music 23:59, Wed, 31 Dec 1969 Photos 23:59, Wed, 31 Dec 1969 User Files 23:59, Wed, 31 Dec 1969

Videos

Music Photos Search

Devices: CTV-5 Sort: Title

List of Contents

English

Using Media Player with USB

When Auto Start is enabled, you will be asked if you want to start the Media Player whenever a USB device is inserted. If Auto Start is disabled (or if you want to connect to a media server on the network), you must manually start the Media Player from the menu.

To change the Auto Start setting:

Basic operation

a Press and B /b to highlight Options icon. b Press c and B / b to select Media Player Setup

and press OK.

c Press B / b to select USB Auto Start and press

OK.

d Press B / b to select On or Off.

Auto Start

a Insert a USB device into the USB port on the left

side of the TV. A prompt will appear.

b Press C / c to select Yes and press OK.

c Press B / b to select Videos, Music or Photos

and press OK.

d Press BbC c to select Devices and press OK.

To select a file in the list of contents:

a Press BbC c to select a file or folder.

b Press OK to move to the next layer, or press

BACK to return to the previous layer. When you select a file, press OK to play or view.

To move to the tab selection:

a Press the BLUE button.

To close the Media Player:

a Press EXIT.

Using the Media Player with a media server

You need to configure a home network before using this feature (see page 12).

a Press and select My Music, My Videos, My

Photos or My Contents icon and press OK.

b Press BbC c to select Device Name icon and

press OK.

c Press B /b to select a device and press OK.

e Press B / b to select a device and press OK.

NOTE: If Auto Start is set to Off, you can start the Me dia Player manually.

Manual Start

a Insert a USB device into the USB port on the left

side of the TV.

b Press and select My Music, My Videos, My

Photos or My Contents icon and press OK.

c Press BbC c to select Devices and press OK. d Press B / b to select a device and press OK.

Files are displayed in the List View according to the category (Videos, Music or Photos) and device you last selected.

Videos, Music and Photos files and folders are displayed in the list of contents.

To select a file in the list of contents:

a Press BbC c to select a file or folder.

b Press OK to move to the next layer, or press

BACK to return to the previous layer. When you select a file, press OK to play or view.

CONTROLS AND FEATURES

Videos

Music Photos Search

Devices: /usb/sda1 Sort: File Name

/DCIM


01:00, Fri, 28 Dec 1984

English

To sort files (if available):

You can sort files by file name (title) or date accordingly.

a Press BbC c to highlight Sort and press OK.

b Press B / b to select File Name (Title), New or

Old and press OK.

To Search for content (if available):

a Press BbC c to highlight Search and press OK.

b Select the text box and press OK, the Software

Keyboard window will appear (page 49). Input keyword by using the Software Keyboard and the search will search for:

Network Videos: Title name Music: Title name/Artist name/ Album name Photos: Title name USB Videos/Music/Photos: File name.

c Select Devices and Category and press OK.

The list of search result will appear.

To display the Device Information or Wireless Information:

a Press QUICK to open the QUICK Menu.

b Press B / b to select any of the following item.

Using with DLNA: Device Information Using with Wireless: Wireless Information

To close the Media Player:

a Press EXIT.

Viewing photo files (on a media

server or USB device)

There are two types of viewing modes.

Photos List (USB and Network Player Photo)

This view allows you to search for photos in a grid format. The pictures are displayed using thumbnail data in each image file.

The initial highlighted position will be on the top left thumbnail in the Photos List.

a Press BbC c to move the highlight in one

window.

or buttons can be used to page up/down the Photos List when there are more photos than will fit onto one screen. When the or buttons are pressed, the highlight shall be on the photo at the top left of Previous/Next Photos List.

NOTE: The page down function on the last page and page up function on the first page are not available.

b When you select a folder, press OK to move to the

next layer. Press BACK to move back to the previous layer.

c Press OK to view the selected photo in Single

View mode.

CONTROLS AND FEATURES

Single View (USB and Network Player Photo)

English

In this mode, only files located in the selected directory will be displayed. This view allows you to change the photo content manually. When moving from Photos List to Single View, the currently selected photo will be displayed.

a Press c to view the next photo. Press C to view

the previous photo.

b Press to display file status information (file

number, photo title, resolution etc.).

NOTE: The information may not be correctly displayed depending on the contents or the devices.

Slide Show (USB and Network Player Photo)

This view allows you to watch a slide show of your photos. In this mode, only files located in the selected directory will be played.

a To start Slide Show, press OK in the Single View

mode.

b Press C / c to view the previous/next photo.

c Press to display file status information.

Press OK to return to Single View.

To set Interval Time and Repeat settings:

a Press QUICK to open the Quick Menu.

b Press B / b to select either Interval Time or

Repeat.

c Press c and B / b to adjust the setting a nd press

OK.

To rotate the image:

While viewing the image in Single View or Slide Show mode, the image can be rotated 90°.

B button: Clockwise rotation b button: Counterclockwise rotation

NOTE: You can not rotate in 3D (2D to 3D) mode.

Selecting the Playback Mode:

You can view 3D photos in 3D and you can also view 2D photos in 3D.

a Press 3D on the remote control while in Single

View mode or Slide Show mode.

The mode switches between 2D Mode and 3D Mode each time 3D button is pressed.

2D Mode: All photos are displayed in 2D. 3D Mode: The photos are displayed in the 3D mode

selected in the Playback Mode. For the Playback Mode, refer to the following:

Setting the Playback Mode in Quick Menu:

a Press QUICK to open the Quick Menu.

b Press B / b to select Playback Mode.

c Press c and B / b to select 3D Mode 1 or 3D

Mode 2.

3D Mode 1: 3D photos in the USB memory are displayed

in 3D. 2D photos are displayed in 2D. Some 3D photos cannot be displayed in 3D.

3D Mode 2: All photos are displayed in 3D. 2D photos are converted and displayed in 2D to 3D, and 3D photos are displayed in 3D.

To set Background Music (USB only):

a Press QUICK to open the Quick Menu.

b Press B /b to select Background Music and

press

c and B / b to select On.

The music file in the same folder as the displayed photo will start playing.

NOTE:

• All the music files in the same folder as the photo will be played repeatedly.

• To stop music file playback, select Off in Background

Music.

To zoom in/out photos (USB and Network Player Photo):

During the Single View mode or Slide Show mode, the zoom function can be used.

RED button (Zoom in)

S x2 S x4 S x8 zoom in

GREEN button (Zoom out)

S x4 S x2 S x1 zoom out

BbC c buttons: Vertical or Horizontal scrolling

NOTE: Using the zoom function while in the Slide Show mode will stop the slideshow and zoom in/out the photo.

CONTROLS AND FEATURES

Videos

Music Photos

Devices: /usb/sdb Sort: File Name

/12334567891123456789212345678931...

Date

VTS_01_1.mpg /usb/sdb

16:40, Wed, 09 Jan 2013

00:00:33 00:01:59

VTS_01_1.mpg

16:40, Wed, 09 Jan 2013

English

To select a photo from Play List (USB and Network Player Photo):

While in the Single View mode or Slide Show mode, you can select a different photo from the Play List.

a Press QUICK to open the Quick Menu from

Single View mode or Slide Show mode.

b Press B / b to select Play List and press OK.

The Photos List will appear.

c Press B / b to select a file name.

To close the Photo Viewer:

a Press EXIT. The television will return to the last

viewed channel or external input.

File Compatibility

See page 94.

Viewing movie files (on a media

server or USB device)

You can select movies from a Videos List of available

Videos List (USB and Network Player Movie)

files.

a Press BbC c to select a file or folder. or

buttons can be used to page up/down the Videos List when there are more files than will fit onto one

screen. NOTE: The page down function on the last page

and page up function on the first page are not available.

b When you select a folder, press OK to move to the

next layer. Press BACK to move back to the previous layer.

c With the desired file selected, press OK or

(play) to start playback.

NOTE:

• On preview screen, if you highlight the file without pressing OK, the content is played on a preview screen. When OK is pressed, it is played in full screen mode.

• Depending on the file size, it may take some time to start playback.

d Press v to stop playback.

NOTE:

• If playback finishes before return to the Videos List.

• Depending on the file size, it may take some time for playback to begin.

v is pressed, the screen will

CONTROLS AND FEATURES

During playback:

English

• Press W to pause. PAUSE may not be available depending on the contents

or media server.

• To resume normal playback, press

• To play in fast reverse or fast forward directions, press

CC / cc during playback. Each time you press the CC /

cc, the playback speed will change.

Z to playback from the beginning of currently

• Press selected file. Press

• Press to display the file status information (content number, movie title, progress time etc.).

NOTE:

• The information may not be correctly displayed

depending on the contents or the devices.

• During playback, you can adjust the Picture and

Sound menu functions from the Quick Menu.

• The playback speed (

depending on the stream.

z to locate subsequent files.

CC / cc) may not change

(play).

To select subtitle and audio languages (USB only):

• Press SUBTITLE repeatedly to select your preferred subtitle language.

s repeatedly to select your preferred audio

• Press language.

NOTE: This feature is not available depending on the contents.

To set the repeat mode:

a Press QUICK to open the Quick Menu.

Resume Play (USB only)

You can resume playback from where it was last stopped. Press

v while playing the movie to memorize the stopped

position.

NOTE:

• The memorized stopped position will be deleted in any of the following cases.

- Play different content

- Exit Media Player

v in the Videos List

- Press

• This function may not be available depending on the content.

To select a movie from Play List (USB and Network Player Movie):

While playing a movie, you can select a different movie from the Play List.

a Press QUICK to open the Quick Menu.

b Press B /b to select Play List and press OK.

The Movie List will appear.

c Press B /b to select a file name.

To close the Movie Viewer:

a Press EXIT.

File Compatibility

See page 94.

b Press B / b to select Repeat and press c and

B / b to select Off, All or 1.

Mode Description

Off The file is played back only once. All Files in the same folder are repeatedly

1 The same file is repeatedly played back.

played back.

c Press BACK.

NOTE:

• The setting is effective until the TV is turned off.

• This setting is ignored in the network media renderer.

CONTROLS AND FEATURES

< DivX® VOD

DivX® VOD Registration

DivX® VOD Deregistration

English

To register your TV to a DivX® account:

This TV allows you to play back files purchased or rented from DivX purchase or rent DivX be asked to enter a registration code.

a In the Media Player Setup menu, press B /b to

b Press B / b to select DivX

c The DivX

Video-On Demand (VOD) services. When you

select DivX

and press OK.

see the registration code. For details on registration, please visit the DivX

VOD files on the internet, you will

VOD and press OK.

VOD Registration

VOD window will appear and you will

website at

http://vod.divx.com

d Copy the activation file to a memory device and

play it on the TV.

To deregistration your device:

a In step 2 above, select DivX

Deregistration, and then press OK.

VOD

b A confirmation message will appear. Select Yes

and press OK.

c The DivX

ABOUT DIVX VIDEO: DivX created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified video. Visit divx.com tools to convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified device must be registered in order to play purcha sed DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com information on how to complete your registration.

DivX Certified MKV) video up to HD 1080p, including premium content.

see the deregistration code. For details on registration, please visit the DivX

VOD window will appear and you will

website at

http://vod.divx.com

for more information and software

to play DivX® and DivX Plus® HD (H.264/

is a digital video format

device that plays DivX

for more

To playback DivX Plus HD content:

• To play in fast reverse or fast forward directions, press

CC / cc during playback. Each time you press th e CC /

cc, the playback speed will change.

• This TV generates original chapter point in 10% increments for 10 chapters in total, that are accessible by using the number buttons on the remote control.

During playback, press next chapter. When will repeat two times of above. If chapter, the confirmation message will appear. If you select Yes, playback will skip to the beginning of the next content.

Z to skip to the beginning of the current chapter.

Press

Z is pressed twice in succession, it will skip to the

When beginning of the previous chapter. If in succession at the first chapter, stop playing th e cur rent content and the confirmation message will appear. If you select Yes, playback will skip to the beginning of the previous content.

B to skip to the beginning of the previous file.

Press

b to skip to the beginning of the next file.

Press The Number button is used for direct jump. If the 3 button

and OK button is pressed, playback will jump to the beginning of 3rd chapter.

NOTE:

• Depending on the content data will not be operated.

• The playback speed ( depending on the stream.

z to skip to the beginning of the

z is pressed twice in succession, it

z is pressed at the last

Z is pressed twice

CC / cc) may not change

Using Multi Title and Alternative Timelines Multi Title

DivX Plus HD files may contain up to 100 titles. You can change the title (It contains same video file) by

pressing the RED button. When the RED button is pressed, it will display the title

change window at the bottom on the screen (same as Subtitle or Audio change window).

The title is changed cyclically each time the RED button is pressed. Playback will start from start time of sele cted title

B / b.

every

C / c also changes the multi title.

Pressing

NOTE: Depending on the content data will not be operated.

CONTROLS AND FEATURES

Date xxxxxxxxxxx 08:22, Web, 31 Oct 2012 xxxxxxxxxxx 13:00, Mon, 23 Jan 2012 xxxxxxxxxxx 14:24, Tue, 01 Mar 2011

Videos

Music Photos Search

Devices

: /usb/sda1 Sort: File Name

Playing music files (on a media

English

You can listen to music from a Music List of available

server or USB device)

files.

Music List (USB and Network Player Music)

a Press BbC c to select a file or folder. or

buttons can be used to page up/down the Music List when there are more files than will fit onto on e

screen. NOTE: The page down function on the last page

and page up function on the first page are not available.

b When you select a folder, press OK to move to the

next layer. Press BACK to move back to the previous layer.

c With the desired file selected, press OK or

(play) to start playback. NOTE: If you highlight the file without pressing OK,

the content is played on a Music List. When OK is pressed, it is played in full screen mode.

d Press v to stop playback.

NOTE:

• Depending on the file size, it may take some time for playback to begin.

• During playback, you can adjust the Sound menu functions from the Quick Menu.

During playback

• Press W to pause. PAUSE may not be available depending on the contents

or media server.

• To resume normal playback, press

• To play in fast reverse or fast forward directions, press

CC / cc. Each time you press CC / cc, the playback

speed will change.

• Press selected file. Press

Z to playback from the beginning of currently

z to locate subsequent files.

(play).

To set the repeat mode:

a Press QUICK to open the Quick Menu.

b Press B /b to select Repeat.

c Press c and B / b to select Off, All or 1.

Mode Description

Off Files in the same folder are played back

All Files in the same folder are repeatedly

1 The same file is repeatedly played back.

once.

played back.

d Press BACK.

NOTE:

• The setting is effective until the TV is turned off.

• When the TV is used as a media renderer, this feature cannot be used.

To select a music file from Play List (USB and Network Player Music):

While playing a music file, you can select a different music file from the Play List.

a Press QUICK to open the Quick Menu.

b Press B /b to select Play List and press OK.

The Music List will appear.

c Press B /b to select a file name.

To display the file status information:

a Press during playback. The information will

be displayed on the bottom of the screen.

b Press again to remove the information.

NOTE: The information may not be correctly displayed depending on the contents or the devices.

To close the Music Player:

a Press EXIT.

File Compatibility

See page 94.

CONTROLS AND FEATURES

Recording Setup Media Player Setup MHL Setup HDMI CEC Control Setup Hybrid TV Standard Disabled Teletext Auto

Panel Lock Off

AV Connection Power Management Blue Screen Off HDMI Information Display On

< Options

Off

English

Other features

Panel Lock

Panel Lock disables the buttons on the television. All

buttons on the remote control can still be used.

a Press and B /b to highlight Options icon.

b Press c and B / b to select Panel Lock and

press OK.

c Press B / b to select On.

When Panel Lock is On, a reminder will appear when the buttons on the television are pressed. If the standby

button is pressed, the television will switch off and can only be brought out of standby by using the remote control.

Blue Screen

When Blue Screen is selected, the screen will turn blue

and the sound will be muted on analogue channels and

external input modes when no signal is received.

NOTE: Some external input sounds may not be muted.

a In the Options menu, press B / b to select Blue

Screen.

Netflix

To confirm the Netflix ESN (Electronic Serial Number)

a In the Network menu, press B / b to select Smart

Apps Setup and press OK.

b In Smart Apps Setup menu, select Netflix Setup

and press OK.

c Press B /b to select ESN and press OK. Netflix

ESN screen will appear.

To deactivate your TV

a In the Network menu, press B / b to select Smart

Apps Setup and press OK.

b In Smart Apps Setup menu, select Netflix Setup

and press OK.

c Press B / b to select Deactivation and press OK.

d Press C /c to select Yes and press OK.

b Press c and B / b to select On or Off.

CONTROLS AND FEATURES

Edit Timer 5:51 Tue, 22 Apr The Daily Politics

2 CABC Channel

11:48 - 11:54 Tue, 22 Apr

Timer Type Reminder

Set Timer Delete Timer

Recording

Reminder

Enable On Timer On

Enable DTV Clock Off Power On Time 00:00 Repeat Once Input DTV Channel 2 CABC Channel Volume 30 Time until Power On 00:10

On Timer

Done

The timers

English

Programme Timers – digital only

This feature will set the television to go to a specific

channel at a certain time. It can be used to view a

particular programme, or by setting the mode to daily or

weekly, can be used to view a series of programmes.

a Press GUIDE and then press the BLUE button on

the remote control

b Press b if necessary to select an open timer

position, then press OK. The Edit Timer menu will now appear on screen.

c Press B / b to go through the list adding the

details of the programme by using the number buttons and

C / c to make selections.

d When all of the details have been entered,

highlight Set Timer and press OK to save the timer.

On Timer

The feature allows you to set the television to turn on

automatically to a preset channel at a certain ti me of da y

or after a certain length of time.

a Press and B /b to hi gh l ight Timers icon. b Press c and B / b to select On Timer and press

OK.

c Press B /b to select Enable On Timer and press

C / c to select On.

d Press b to select Enable DTV Clock, and then

press

C / c to select On or Off.

e Press B /b to go through the list adding the

details of the On Timer by using the number buttons and

Power On Time (only for DTV Clock On mode): Set the time you prefer with the number buttons. Repeat (only for DTV Clock On mode): Select the desired On Timer operation (Once, Every Day,

Mon-Fri, Mon-Sat, Sat-Sun). Input: Select a video input source (ATV, DTV Ant,

EXT 1, EXT 2, HDMI 1, HDMI 2, HDMI 3, HDMI 4 or PC). Channel: Set the channel that will be tuned when the television turns on.

NOTE: When an external input is selected in the Input field, a channel cannot be selected.

Volume: Set the volume that will be applied when

the television turns on. Time until Power On (only for DTV Clock Off mode): Set the amount of time from now until the TV turns on using the number buttons (maximum of 12 hours).

C / c to make selections.

f Press B /b to hi gh l ight Done and press OK.

To cancel the On Timer:

a In the On Timer menu, select Enable On Timer. b Press C /c to select Off. c Press B /b to hi gh l ight Done and press OK.

Sleep Timer

The television can be set to turn itself Off after a certain

length of time.

a Press and B /b to highlight Timers icon. b Press c and B / b to highlight Sleep Timer and

press OK.

c Use the number buttons to set the desired time.

For example, to switch the television off in one and a half hours enter 01:30, or press increase/decrease in steps of 10 minutes. (Maximum time setting is 12 hours)

c / C to

d Press EXIT to finish. e To cancel the Sleep Timer, enter all zeros for the

above setting.

CONTROLS AND FEATURES

4 CHANNEL Z

6:00 Thu, 11 Oct

English

REC

Now

MLB Young’s two-run triple leads AL over NL 6:00- 8:00

15 min left

Also

World News and Sports

MLB Young’s two-run triple leads AL over NL

Change

8:00- 9:00

News

Side by Side

Edit Timer 10:50 Tue, 26 Apr The Daily Politics

2 CABC Channel

11:30 - 12:30 Tue, 26 Apr Timer Type Recording

Set Timer Delete Timer

English

Energy Saving Settings

Automatic Power Down

The TV will automatically turn itself off (Standby) after 4

hours, if you do not operate the TV either from the remote

a Press and B /b to highlight Options icon.

b Press c and B /b to select Power Management

c Press B / b to select Automatic Power Down.

d Press c and B / b to select On or Off and press

NOTE:

• This feature is set to On when Location is set to Home.

• 1 minute before switching to Standby, a Warning message will appear.

• When the following features are set, the feature that is set for the nearest time will function.

- Automatic Power Down

- Sleep Timer

- Auto shutdown after 1 hour of inactivity (after power on

- No signal auto power off (after 15 minute of no signal)

The TV will automatically turn itself off after 15 minutes

when no signal is detected. You can change the se tting to

• Low signal strength of analogue channel (no signal detection)

• Only Audio L/R is connected to external input to listen to music through the TV speakers.

a In the Power Management menu, press B /b to

control or the TV control panel.

and press OK.

OK.

by On Timer)

No Signal Power Down

Off for the following purposes:

select No Signal Power Down.

Digital on-screen information

When viewing in digital mode, the on-screen information and programme guide provide access to programme details for all available channels.

Information

a Press , the information screen will appear

giving details of the channel and programme currently being viewed.

3D 2D

b Press B / b to select the “Now”, “Next” or “Also”

information guide. The selected information content will appear.

c To record the next scheduled programme, select

Next and press OK. The Edit Timer screen will appear.

D+

Display Example

16:9

AD 18

b Press c and B / b to select the item you want to

change and press

Off.

NOTE:

• Default setting is all On.

• A warning message will appear 1 minute before turning off.

c and B / b to select On or

d The details of the programme will already have

been added to the timer. Highlight Set Timer and press OK to save.

To indicate that a Recording Timer has been set, a clock icon will be displayed in the Next fields of the information screen. A check mark will appear if the timer is a Reminder Timer.

CONTROLS AND FEATURES

1 ABC HDTV World Business Today Big Brotherʼs Little Brother

World Business...

2 ABC1 Seven Wonders of Anclent Rome Battlefield Detectives

Hope & Faith

3 ABC2 ITV Morning News ITV Morning News 4 ABC1 Balairiory ITV Morning... Seven Wonders of Anclent Rome 5 ABC3 Seven Wonders of Anclent Rome Hope & Faith

Hope & Faith

6 BBC ONE BBC News 24 BBC News 24

BBC News 24

7 BBC TWO Kickstart Natural Born Dealers Zoo Story

Animal Cops...

8 BBC THREE World News Today

Go, Diego, Go!

World News Today

9 BBC NEWS 24 Big Brother Live

Go, Diego, Go!

vets in Hong Kong

Hope & Faith

vets in Hong Kong

10 BBCi vets in Hong Kong vets in Hong Kong epsode 12 11 CBBC Channel Worldʼs Toughest Worldʼs Toughest

Worldʼs Toughest

12 TF1 HD Zoo Story Firnbles Zoo Story

Zoo Story

13 FRANCE 2 HD Good Morning Sports Fan Animal Cops Houston

Tue 22

5:48 Tue, 22 Apr

More Info Page Up/Down Now View Genre Timers Watch TV

To display More Information:

English

a Press QUICK to open the Quick Menu.

b Press b to highlight More Information and press

OK.

On-screen Information icons

Icon Description

Service info Service type

Audio info Mono

AD Audio Description

Audio/Subtitle

info

Recording info ●REC Recording + Service

3D info 3D

3D → 2D

Event info HD, SD Video format (HD,

16:9, 4:3 Video Aspect

Subtitle (Single,

Audio track

0, 4 – 18 Parental rating

Timer info Recording

(TV, Radio, Text)

When HE-AAC is

For Hard of Hearing

Skip

Stereo

Dual mono Multichannel Dolby Digital

Dolby Digital+

decoded

info

SD)

Teletext

Multi)

(Mono, Multi)

Encrypted

Reminder

Using EPG (Electronic Programme Guide)

Using Broadcast Guide

a Select the on-screen Guide by pressing GUIDE,

and the Guide screen will appear highlighting details of the channel and programme currently being viewed. This may take a few moments to appear.

6:00 6:30 7:00 7:30 8:00

You can switch the time scale to 1.5 or 3 hours by pressing the GREEN button.

b Press C /c for information on other programmes

scheduled for the channel selected. To highlight the first programme in the genre grid, press the RED button.

c For details of other programmes currently

available, press channel list. As channels are selected, details of the programme currently being broadcast will appear. Press programmes.

d For information on a highlighted programme, press

B / b to scroll up and down the

C / c to view information for future

e To set the timer for that programme, press the

BLUE button to bring up the Programme Timers menu.

f Press to view another page.

Updating EPG:

a In the Guide screen press QUICK.

b Press B /b to select EPG Update.

CONTROLS AND FEATURES

Genre Colour

Movie

Colour Setup

Channels Subtitle and Audio

Parental PIN Setup

Parental Control

Local Time Setting Standby Channel Update Off Dynamic Scan Off

Favourite Region Common Interface

< DTV Settings

New PIN: Confirm PIN:

Parental PIN Setup

English

Genre selection/searching

From the Guide screen, you can use the genre selection

and search features.

a In the Guide screen, press QUICK. b Press B / b to highlight Genre Colour in the

Quick Menu and press OK.

c With the focus on a particular genre, press the

desired coloured button to assign. Four colours will be available to set. Press BACK to go back to the Guide screen.

Digital settings – parental control

In order to prevent viewing of unsuitable films and programmes, channels and menus can be locked in digital mode. These can then only be accessed with a security code PIN.

Parental PIN Setup

a Press and B /b to highlight Installation

icon.

b Press c and B / b to select DTV Settings and

press OK.

c Press B /b to select Parent a l PIN Setup and

press OK.

d Using the number buttons enter a four digit

number. Once entered you will be prompted to confirm by entering again.

The PIN number is now set. If the PIN code has been set, when Auto Tuning

and Reset TV are executed, entering the PIN will be necessary. “0000” is not acceptable.

CONTROLS AND FEATURES

Parental Setup None Playback Setup Enabled

< Parental Control

None

4 5 6 7 8 9 10 11 12 13 14

6M6

9W9 11 NT1 31 PARIS PREMIERE 34 AB1 51 ITV1

Channel List

Favourite

English

The Parental Control featu r e all o w s yo u to block

programmes according to their rating levels. If a PIN has

been set, you will need to enter it before adjusting the

Parental Setup

level.

a In the DTV Settings menu, press B /b to select

Parental Control and press OK.

b Press B / b to select Parental Setup or Playback

Setup and press OK. Parental Setup: Select when you want to set

viewing restrictions on broadcast programmes. Playback Setup: Select when you want to set

viewing restrictions on playback of programmes recorded to the USB HDD.

c Press B / b to select an option.

To view blocked programmes, enter the PIN. To reactivate the Parental Control, turn the TV off and then on again.

Digital settings – Channel Options

Selecting favourite channels

From the Quick Menu / Channel Options menu, it is possible to create a list of the digital channels that are

watched most. Press LIST /

a Select the channel you want to add to your

favourite list.

b Press QUICK to open the Quick Menu.

c Press b to select Channel Options and press

OK.

d Press c to highlight the favourite (✩) box.

e Press OK to select the ones required. A tick will

appear in the box as they are selected.

f Repeat steps 1 through 5 for other channels.

g When all favourites have been selected, press

EXIT.

Favourite Channel List

a Press LIST to display Channel List.

Each time you press

Channels, Radio Channels, Text Channels or Favourites is selected in order.

Cc to select the Favourite

Channel list.

C / c, All Channels, TV

b Press C /c to select Favourites. The number of

favourites available depends on how many lists have been created.

c Press B /b to highlight a channel and press OK

to watch.

CONTROLS AND FEATURES

Subtitle Display Off

Subtitle Type Normal Primary Subtitle Language English Secondary Subtitle Language English Audio Type Normal Primary Audio Language English Secondary Audio Language English

< Subtitle and Audio

English

Skip channels

This feature allows you to set channels that will be skipped

u or PU are used to tune.

when P

a Select the channel you want to skip in your

channel list.

b In the Quick Menu, press b to select Channel

Options and press OK.

c Press c repeatedly to highlight the skip (8) box.

d Press OK to select. A tick will appear in the box.

e Repeat steps 1 through 4 for other channels.

f Press EXIT.

NOTE: Skipped channels cannot be selected by

u or PU but still be accessed by direct number

entry (when tuned a the banner to indicate as a skipped channel).

8 icon will be displayed in

Locking channels

Locking Channels stops the viewing of digital channels,

and they can only be accessed by entering the PIN.

a Select the channel you want to lock in your

channel list.

b In the Quick Menu, press b to select Channel

Options and press OK.

c Press c repeatedly to highlight the lock ( ) box.

d Press OK and PIN entry will be required to set the

locked channels. Enter PIN Code and a tick will appear in the box.

NOTE: A Parental PIN should be set in advance. If not, a warning message will display to reminder you to set a PIN first.

e Repeat steps 1 through 4 for other channels.

f Press EXIT.

Digital settings – other settings

Subtitles

In DTV mode, this feature will show subtitles on the screen

in the selected language provided they are being

a In the DTV Settings menu, press B / b to select

Subtitle and Audio and press OK.

b Press b to select Subtitle Display and press c

and

B / b to select On or Off.

c Press B /b to select Primary Subtitle Language

or Secondary Subtitle Language and press and

B / b to select an option.

The SUBTITLE button can be used to select subtitle on or off for the current channel only and to select the subtitle language if more than one subtitle is available.

This feature allows a programme or film to be vie wed with

a choice of soundtrack language, provided multiple

language tracks are being broadcast.

a In the Subtitle and Audio menu, press B / b to

select Audio Type and press select Normal, For Hard of Hearing or Audio Description and press OK.

b Press B /b to select Primary Audi o Language

or Secondary Audio Language and press

B / b to select an option.

If more than one soundtrack is available, use th e s button to select between them.

broadcast.

Audio languages

c and B / b to

c and

g From this point on, when any of the Locked

Channel list is selected, the PIN must be entered

before they can be accessed.

CONTROLS AND FEATURES

SEARCH FOR NEW SOFTWARE Searching for a new software upgrade for this TV.

48 %...

CH 31

English

The Common Interface Slot, situated on the side of the

television, enables the insertion of a CAM (Conditional

Access Module) and card. These are purchased from a

service provider and allow additional subscription

broadcasts to be viewed. For information, see a service

Common Interface

provider.

a Insert the CAM and card into the Common

Interface Slot, following the instructions provided with the CAM. A box will appear on screen to confirm that the CAM has been inserted.

b Press and B /b to hi gh l ight Installation

icon.

c Press c and B / b to select DTV Settings and

press OK.

d Press B / b to select Common Interface and

press OK.

e Details of the CAM should now be available.

NOTE:

• Software update of a CI Plus CAM may execute automatically if it is instigated by the broadcaster. This could cause the cancellation of any Reminders/ Recordings during this process.

• Some CI or CI+ CAM may not be supported.

• CI+ operation is not guaranteed except for Canal Ready DTT services on suffix FC models.

Software Upgrade and Licences

Searching for New Software

If preferred, software upgrades can be searched for

manually using Search for New Software.

a In the Get Help menu, press B / b to select

Software Upgrade and press OK.

b Press B / b to select Over-the-air Upgrade and

press OK.

c Press c and B / b to select Search for New

Software and press OK. The television will

automatically start searching for a software upgrade, the progress bar will move along the line.

If an upgrade is found, the television will automatically start downloading. If not, a screen will appear stating that an upgrade is unavailable.

NOTE: When Auto Upgrade is set to Off, this feature is not available.

Network Upgrade

TOSHIBA may offer upgrades for the TV’s software in the

future. The TV’s software is upgraded via the Network.

Before downloading software:

Configure your TV to connect to the Internet. NOTE: While the upgrade is being performed, you will not

be able to watch the TV.

a In the Get Help menu, press B /b to select

Software Upgrade and press OK.

b Press B /b to select Network Upgrade and press

OK. NOTE: If the network is not available, a warning

message will appear.

c The TV software upgrade will start when download

succeeds.

CONTROLS AND FEATURES

System Information

TOSHIBA

2013

Jan 19 2013

Software Version : xxxxxxxx

MBOOT Version : xxxxxxxx

CH 25

WEAK

AVERAGE

STRONG

GOOD

CH 33

WEAK

AVERAGE

STRONG

GOOD

CH 67

WEAK

AVERAGE

STRONG

GOOD

English

Software Licences

The licences for the software used in this television are

available for viewing.

a In the Get Help menu, press B / b to select

Software Licences and press OK.

A screen will appear displaying all the licensing information required for the televisions software.

System Information and Reset TV

System Information

This feature can be used to check the version of software

currently installed. When in DTV mode, it includes

additional diagnostic information such as signal strength,

signal quality, centre frequency, modulation, etc.

a In the Get Help menu, press B / b to select

System Information.

b Press OK to display the System Information.

c For information about the signal quality of a

particular multiplex, press multiplex.

d Press OK for a screen showing detailed technical

information about the selected multiplex.

B / b to select that

Reset TV

Selecting Reset TV will reset all TV settings, including

saved channels, to their original factory values.

a In the Installation menu, press B / b to select

Reset TV.

b Press OK to select. A screen will appear warning

that all settings will be lost. Press OK to continue. When the set powers back on, the Quick Setup

screen will appear. Press OK to advance the setup and perform an auto tune. (See “Quick Setup” section on page 15.)

CONTROLS AND FEATURES

Auto Format On 4:3 Stretch Off Picture Position

PC Settings

< Display Settings

< PC Settings

Horizontal Position 0

Vertical Position 0 Clock Phase 0 Sampling Clock 0

Reset

PC Settings

English

Horizontal and Vertical Position

Connect the PC (as shown in the ‘Connecting a computer’

section) and ensure that a picture is showing on the

television screen. The picture position may now be

adjusted to suit personal preference.

a Press and B /b to hi gh l ight Picture icon.

b Press c and B / b to select Display Settings and

press OK.

c Press B / b to select PC Setting and press OK.

d Press B /b to select a n option and press C /c to

adjust the settings.

Sampling Clock

Adjusting the Sampling Clock alters the number of pulses

per scan, this will clear vertical l in e s on th e scr e e n.

a In the Display Settings menu, press B /b to

select PC Settings and press OK.

b Press B /b to select Sampling Clock.

c Press C /c to adjust until the picture clears.

Reset

Use Reset to return all items to the original factory

settings.

a In the Display Settings menu, press B /b to

select PC Settings and press OK.

b Press B /b to select Reset and press OK.

NOTE: When a PC is connected using HDMI, none of these functions will be available.

The screen is disrupted momentarily when adjusting PC Settings. This is not a sign of malfunction.

The default settings and adjustment ranges may vary depending on the input signal format.

Clock Phase

The Clock Phase matches the PC signal with the LCD

display. Adjusting this can clear horizontal stripes and

picture blur.

a In the Display Settings menu, press B /b to

select PC Settings and press OK.

b Press B / b to select Clock Phase.

c Press C / c to adjust until the picture clears and

press OK.

CONTROLS AND FEATURES

Press o on the remote control

2 HDMI 1 HDMI 2 HDMI 3 HDMI 4 PC

Inputs

Press and hold p / o on the TV

DTV Ant TV

2 HDMI 1 HDMI 2 HDMI 3 HDMI 4 PC ATV

Inputs

Recording Setup Media Player Setup MHL Setup HDMI CEC Control Setup Hybrid TV Standard Disabled Teletext Auto Panel Lock Off

AV Connection

Power Management Blue Screen Off HDMI Information Display On

< Options < AV Connection

Input Labelling

Colour System

Input Label

EXT 1 --

EXT 2 -HDMI 1 -HDMI 2 DVD HDMI 3 -HDMI 4 -PC --

Input Labelling

English

Input selection and AV connections

See page 8 for a detailed image showing recommended connections.

Most media recorders and decoders send a signal thr ough the SCART lead to switch the television to the correct Input socket.

Alternatively, press the external source selection button

o until the picture from connected equipment is shown.

Input selection

Use the Input Selection window if the television does not

a By pressing o on the remote control or TV, a list

switch over automatically.

will appear on screen showing all inputs and external equipment.

Labelling video input sources

These input labels are shown in the input selector. You

can label video inputs according to the devices you have

connected to the TV.

a Press and B / b to highlight Options icon.

b Press B /b to select AV Connection and press

OK.

c Press b to highlight Input Labelling and press

OK.

HDMI

displays equipment connected to Input

HDMI on the back or side of the television. PC displays a computer connected to Input RGB/

PC on the back of the television.

d Press B /b to select the item you want to label,

and then press Cable, DVD, Game, PC, Recorder Satellite, VCR or Bluray.

C / c to select --, Amplifier,

e Repeat step 4 for other video inputs.

CONTROLS AND FEATURES

< Sound

Balance 0 Bass 0 Treble 0 Audyssey Premium Television Dynamic Range Control On Dual Dual 1 Audio Level Offset TV Speakers On Headphone Level Audio Description

Digital Audio Output

English

When connecting a surround sound amplifier to th e digital

audio output (Sony/Philips Digital Interface Format [S/

PDIF]), the following options can be selected or adjusted.

Digital Audio Output

a In the Sound menu, press B /b to select Digital

Audio Output and press OK.

b Press B / b to select an option.

Audio Format

Press

C / c to select PCM or Auto.

PCM: This mode outputs PCM format to the digital

audio output socket.

Auto: This mode outputs Dolby Digital (if

available) or PCM to the digital audio output socket. Dolby Digital Dolby Digital Plus MPEG HE-AAC

Audio Delay

Press

C / c to select Auto or Manual.

Auto: This mode automatically adjusts the audio

timing to meet the video timing. NOTE: The time lag might be large between the image and sound depending

on the connected equipment (amplifier etc.). In that case, select Manual.

Manual:You can manually adjust the audio signal

timing to meet the video signal timing.

Delay Adjustment

C / c to adjust the audio signal timing

Press (0 – 250 ms) to meet the video signal timing.

S Dolby Digital

S PCM

S Dolby Digital

NOTE:

• This feature is greyed out when Audio Delay is in Auto.

• A time lag will occur when the video signal or audio signal is changed. Adjust the timing accordingly.

• When adjusting the timing, turn down t he volume of the AV equipment used as far as possible. Depending on the equipment, noise etc. may occur when the signal is changed.

• Depending on the connected equipment (amplifier, etc.), adjustment may not be po ssible.

• When the optical digital output setting

tPCM) is changed, it may be necessary

(Auto to adjust the timing again.

• Do not use other than for audio output from the AV amplifier, etc. (Malfunction may occur)

CONTROLS AND FEATURES

Enable HDMI CEC Control On

TV Auto Power On Auto Standby On Amplifier Control On Initial Speaker Setting TV Speakers

< HDMI CEC Control Setup

Off

2 HDMI 1 HDMI 2

HDMI 3

HDMI 4 PC

Inputs

1DVD

2 VCR/DVR 3 CBL/SAT 4GAME/TV 5 AUX

English

Using HDMI CEC Control

This is a new feature that uses CEC techno logy and allows you to control Toshiba HDMI CEC Control compatible devices from the television remote control via HDMI connection (page 10).

When the Enable HDMI CEC Control item in the HDMI CEC Control Setup menu is set to On, individual functions also set to On will be activated.

Enable HDMI CEC Control

a Press and B /b to highlight Options icon.

b Press c and B / b to select HDMI CEC Control

Setup and pres OK.

c Press b to select Enable HDMI CEC Control and

press

C / c to select On.

Amplifier Control

When Amplifier Control is set to on/off the connected

HDMI CEC Control amplifier.

a In the HDMI CEC Control Setup menu, press b

to select Amplifier Control.

b Press c and B / b to select On or Off.

Initial Speaker Setting

The Initial Speaker Setting allows to select TV speakers or

Amplifier speakers.

a In the HDMI CEC Control Setup menu, press b

to select Initial Speaker Setting.

b Press c and B / b to select TV Speakers or

Amplifier.

HDMI CEC Control input source

selection

If an HDMI CEC Control device with HDMI switching

capability (e.g. AV amplifier) is connected to the HDMI

input, you can select another HDMI CEC Control device

that is connected to the master HDMI device on the in put

source list.

a Press o and a list will appear on screen showing

available input sources.

NOTE: If you set Enable HDMI CEC Control to Off, all other items will be greyed out.

TV Auto Power

The TV Auto Power setting allows the television to be

automatically switched on if an HDMI CEC Control device

is turned on.

a In the HDMI CEC Control Setup menu, press b

to highlight TV Auto Power.

b Press c and B / b to select On or Off.

Auto Standby

When Auto Standby is enabled, the television, when switched off, will automatically switch off (Standby) all

connected HDMI CEC Control equipment.

a In the HDMI CEC Control Setup menu, press b

to highlight Auto Standby.

b Press c and B / b to select On or Off.

b Press b to select the input source that the HDMI

CEC Control devices are connected.

c Press c and a second selection screen will ap pear

showing all connected HDMI CEC Control equipment.

d Press B /b to select the desired input source,

and then press OK.

CONTROLS AND FEATURES

HDMI 3

MHL cable (not supplied)

NOTE:

• These functions depend on the device connected.

English

If you select the HDMI CEC Control input source from the popup window, some HDMI CEC Control devices may automatically turn on.

• If the HDMI cable from connected equipment is changed, Enable in the HDMI CEC Control Setup menu may need to be reset to On.

• If you change the HDMI lead to a connected device or change an HDMI device setting, reset the Enable HDMI CEC Control item on the HDMI CEC Control Setup menu from Off to On.

HDMI CEC Control one touch play

When connected equipment is switched on, HDMI CEC

Control will automatically detect the television through t he

input selection. If the television is in Standby, it will be

These functions can be enabled or disabled from the

HDMI CEC Control Setup (see page 85). NOTE:

• Even if the equipment is showing a menu, the television may automatically show the input source.

• This feature depends on the connected equipment and television state.

switched on automatically.

HDMI CEC Control system standby

If the television is turned off (Standby), the television will

send a message to turn off (Standby) all of the HDMI CEC

Control devices connected to the television.

These functions can be enabled or disabled from the

HDMI CEC Control Setup (see page 85). NOTE: This fea ture depends on the connected equipment

and television state.

Using MHL TV function

You can use the following functions by connecting

between the TV HDMI 3 port and a USB port of mobile

• Charge with mobile phone from TV

• Two-way remote operation between TV and mobile phone

• Video/Audio output from mobile phone

NOTE: These functions may not be available depending on the connected device.

Connect the device to the HDMI 3 port on the TV with an MHL cable (not supplied).

• When you connect an MHL-compatible device to the HDMI 3 port on the TV with the MHL cable, charging starts automatically.

NOTE: Do not connect an MHL-compatible device to any port other than the HDMI 3 port.

When an MHL-compatible device is connected to the HDMI 3 port on the TV, input auto matically switches to th e HDMI 3 port. Operate the device using the remote control for the TV. To display photos, select the photos using press OK. To play a video, press Depending on the connected MHL-compatible device, it may be possible to perform operations from the device.

phones etc. with an MHL cable.

Connecting an MHL-compatible

device

Operating an MHL-compatible

device

BbC c and

c (play).

MHL Setup

Select whether or not input automatically switches to the

HDMI 3 port when an MHL-compatible device is

connected.

a In the Options menu, press B / b to select MHL

Setup.

b Press c to select TV Auto Input Switch.

c Press C /c to select On or Off and press OK.

TEXT SERVICES

Recording Setup Media Player Setup MHL Setup HDMI CEC Control Setup Hybrid TV Standard Disabled Teletext Auto Panel Lock Off AV Connection Power Management Blue Screen Off HDMI Information Display On

< Options

Auto

List

English

Text services

This television has a multi-page text memory, which takes a few moments to load. It offers two

Modes of viewing text – Auto will display Fastext, if available. List will save your four

favourite pages.

Selecting modes

The text character set will be automatically chosen by the

language setting in the Options menu.

a Press and B /b to highlight Options icon.

b Press c and B / b to select Teletext, and then

press

C / c to select Auto or List.

Text information

The TEXT button

To view text services press TEXT. Press again to superimpose the text over a normal broadcast picture and again to return to normal viewing. Channels cannot be changed until text is cancelled.

The first text page shown will be the initial page. Any text page can be accessed by entering the 3-digit

page number using the numbered buttons, pressing the coloured buttons or pressing P page and P

Sub-pages

The pages on the screen will dynamically update as subpages are received.

If you open a page containing sub-pages, the sub-pages are automatically displayed in sequence. To quit automatic sub-page change, press

Once selected, the sub-page you are viewing will be highlighted and, as the television loads any addition al subpages, the colour of the numbers will change, indicating that these pages have been loaded.

These sub-pages will remain available to view until another page is chosen or, in normal TV mode, the channel is changed.

u to go back to the previous page.

U to advance to the next

C / c.

Navigating pages using Auto

If Fastext is available, four coloured titles will appear at the base of the screen.

To access one of the four given subjects, press the relevant coloured button on th e r em o t e co nt r ol .

For further information on your particular text system(s), see the broadcast text index page or consult your local Toshiba dealer.

Navigating pages using LIST

The four coloured choices at the bottom of the screen are numbers – 100, 101, 102 and 103, which have been programmed into the television’s memory. To view these pages, press the relevant coloured buttons.

To change these saved pages, press the relevant coloured button and enter the 3-digit number. This number will change in the top left of the screen and in the coloured highlight.

Press OK to save. Whenever OK is pressed, all four

page numbers showing at the bottom will be saved and the previous ones will be lost.

NOTE: The video signal from the external inputs (EXT-1

and EXT-2) is not saved. If OK is not pressed, the selection will be forgotten when

the channel is changed. Other pages may be viewed by entering the 3-digit page

number – but DO NOT press OK or these pages will be saved.

TEXT SERVICES

English

Below is a guide to the functions of the r emote control text buttons.

Control buttons

k To display the index/initial page:

Press k to access the index/initial page. The one displayed is dependant on the broadcaster.

TEXT To display a page of text:

Press TEXT to display text. Press again to superimpose text over a normal picture. Press again to return to normal television viewing. Channels cannot be changed until this has been done.

A To reveal concealed text:

To discover the solutions on quiz and joke pages press the

A button. B To hold a wanted page:

At times it is convenient to hold a page of text. Press B

B will appear in the top left of the screen. The page

and will be held on screen until the button is pressed again.

C To enlarge the text display size:

Press C once to enlarge the top half of the page, press again to enlarge the bottom half of the page. Press again to revert to normal size.

D To temporarily erase the text screen:

Press D once to erase the text screen temporarily. To recall the text screen, press the button again.

To display news flashes:

Select the news flash page for the chosen text service (see the index page of text service). The news flashes will be displayed as and when they are broadcast.

Remember to cancel text before

changing channels - press the TEXT button twice.

Questions and Answers

< AV Connection

Input Labelling

Colour System

Auto

PAL SECAM NTSC 4.43 NTSC 3.58

ATV Manual Tuning Manual Fine Tuning

Below are the answers to some of the most common queries.

Question Answer

Why is there no sound or picture?

Why is there a picture but no sound?

Sound

Why is the soundtrack in English when a different audio language has been selected?

Why is there incorrect or no sound when in DTV mode?

There is a picture, but why is there little or no colour?

Check the television is not in Standby mode. Check the mains plu g and all mains connections.

Check all lead connections. No sound or unacceptable format sound may be received. Check the volume has not been turned down or that sound mute has not been selected. Check shared audio settings.

The programme is currently being broadcast with an English soundtrack only.

Press s to ensure the hard of hearing option has not been selected.

When using an external source, for instance, a poor quality video tape, if there is little or no colour, improvements may sometimes be achieved. The colour is factory set to Auto to automatically display the best colour system.

To check that you have the best colour:

a With the external source playing, select Colour System from

the Options menu.

PROBLEM SOLVING

English

What else can cause a poor picture?


Why doesn’t the video/DVD being played show on screen?

Why are there vertical stripes on the screen when in PC mode?

b With C /c choose between Auto, PAL, SECAM, NTSC 4.43 or

NTSC 3.58.

Interference or a weak signal. Try a different television station. Manual Fine Tuning may help.

a Select the ATV Manual Tuning menu. Highlight the station and

press OK. Then press

c to select Manual Fine Tuning.

b Using B / b adjust to get the best pict ure and sound. Press OK

and then press EXIT.

Make sure the media recorder or DVD player is connected to the television as shown on page 8, and then select the correct input by pressing o.

The Sampling Clock may need adjustment. Select PC Settings from the Display Settings menu, highlight Sampling Clock and adjust until the lines clear.

PROBLEM SOLVING

English

Why are there horizontal stripes and/ or blurred images on the screen when in PC mode?

Why are the colours wrong when an NTSC source is played?


Question Answer

The Clock Phase may need adjustment. Select PC Settings from the Display Settings menu, highlight Clock Phase and adjust until the

picture clears. Connect the source via a SCART lead and play.

Select Colour System from the Options menu.

a Set the Colour to Auto and exit.

b Go to the Picture menu and adjust the tint.

Why don’t the controls of the television work?

Why doesn’t the remote control work?

Why is the digital channel locked?

Why are some of the digital subscription channels unavailable?

What is DVB-T? What is DVB-C? How are DTV radio channels

selected? What can be done if the PIN number

has been forgotten?

Why when digital subtitles have been selected are they not showing on screen?

Why are there problems with analogue text?

General

Why is a page number visible at the top of the screen but no text?

Why don’t the devices connected via HDMI operate properly?

Why don’t the devices connected via MHL operate properly?

Why don’t the HDMI CEC Control devices work?

Why is the HDMI CEC logo still showing when the equipment has been disconnected?

Check that Panel Lock is not On.

Check that batteries aren't exhausted or inserte d incorrectly.

The channel has been locked in Channel Options (see ’Digital settings – Channel Options’ section).

Your subscription needs upgrading. Contact your service provider.

Digital Video Broadcast via an aerial/antenna. Digital Video Broadcast via a cable connection. Select from All Channel List (LIST button).

Use the Master PIN code of 1276, then change to a number of your choice. Select Parental PIN Setup from the DTV Settings menu to enter PIN. Ensure that no-one else can use the Master PIN by removing the Owner’s Manual.

Subtitles are not currently being transmitted by the broadcaster.

Good performance of text depends on a good strong broadcast signal. This normally requires a roof or loft aerial. If the text is unreadable or garbled, check the aerial. Go to the main index page of the text service and look for the User Guide. This will explain the basic operation of text in some detail. If further information is needed on how to use text see the text section.

Text has been selected but Teletext information is current ly unavailable on the current source.

Make sure to use cables with the HDMI logo (see page 9). Some early HDMI equipment may not work properly with the latest

HDMI TV products, due to new standard adoption. Turn off your TV and unplug the power cord, and then plug and turn on

again. Turn the MHL Source Power Off and On again. Try to reconnect a MHL cable.

When the connected HDMI CEC Control device does not work correctly after you have changed the settings of the device, turn off your television and unplug the power cord, and then plug and turn on again. Unplug the HDMI cable of the HDMI CEC Control device and lead again.

If the HDMI CEC Control device is disconnected, the logo will disappear after approximately one minute.

Question Answer

Remote sensor

Power LED

On = Green

Standby = Red

Light sensor

LED indication Condition

Green Power ON

Red Power OFF

(Standby or Active Standby)

Why don’t the networked devices work?

Why doesn’t the wireless network work?

Why doesn’t the Media Player feature operate?

Why are not 3D images displayed?

Why doesn’t the USB HDD work? Why isn't Skype launched?

Why can't the Skype account be signed in?

General

What do the LEDs on the front of the television indicate?

PROBLEM SOLVING

The LAN cables are not connected properly or at all. Connect all cables (see page 12). Make sure your network address is set up correctly (see page 47).

Check that the AP is powered on.

Make sure that devices are connected correctly. Incorrect behaviour may occur with a USB Hub connection. Check your network setup if using a network media server.

Ensure that there is no object blocking the infrared signals in the infrared reception part of television and 3D glasses. If the i nfrared dat a communication between the television and 3D glasses is lost for 5 minutes, the power of 3D glasses is turned off.

Your country/area may not support the USB HDD function. Check that the recommended video camera (page 59) is con nected t o

the TV. Ensure the network cable connection (page 12). Check the Network setting of TV. Turn off the TV and unplug the power cord. After 1 minute, plug the power cord in and turn on the TV.

If you have no Skype Name, create a Skype Name in Create an account. If you forgot password, visit www.skype.com

Check the table below.

and confirm the password.

English

INFORMATION

Information

English

Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the mains plug from the wall socket.

Signal information for Mini D-sub 15 pin connector

Pin No. Signal name Pin No. Signal name Pin No. Signal name

1R6Ground11NC 2 G 7 Ground 12 DDC Data 3 B 8 Ground 13 H-sync 4 NC* 9 +5V 14 V-sync 5 Ground 10 Ground 15 DDC Clock

* NC = not connected

Acceptable PC signals through the PC terminal

The PC input on this TV only accepts signal formats which are compliant with VESA-DMT as shown in the table below. Since some PCs input signals which are different fr om the resolution and frequency described in the table below, the following phenomenon may occur; incorrect display, false format detection, picture position failure, blur, or judder. In this case, set the monitor output format on your PC to conform to a signal in the table below.

Format Resolution V. Frequency H. Frequency Pixel Clock Frequency

VGA 640 × 480 59.940 Hz 31.469 kHz 25.175 MHz

72.809 Hz 37.861 kHz 31.500 MHz

75.000 Hz 37.500 kHz 31.500 MHz

SVGA 800 × 600 56.250 Hz 35.156 kHz 36.000 MHz

60.317 Hz 37.879 kHz 40.000 MHz

72.188 Hz 48.077 kHz 50.000 MHz

75.000 Hz 46.875 kHz 49.500 MHz

XGA 1024 × 768 60.004 Hz 48.363kHz 65.000 MHz

70.069 Hz 56.476 kHz 75.000 MHz

75.029 Hz 60.023 kHz 78.750 MHz

WXGA 1280 × 768 59.995 Hz 47.396 kHz 68.250 MHz

59.870 Hz 47.776 kHz 79.500 MHz

74.893 Hz 60.289 kHz 102.250 MHz 1280 × 800 59.810 Hz 49.702 kHz 83.500 MHz 1360 × 768 60.015 Hz 47.712 kHz 85.500 MHz

WXGA+ 1440 × 900 59.887 Hz 55.935 kHz 106.500 MHz

SXGA 1280 × 1024 60.020 Hz 63.981 kHz 108.000 MHz

75.025 Hz 79.976 kHz 135.000 MHz

1080p 1920 × 1080p 60.000 Hz 67.500 kHz 148.500 MHz

VESA Standard

(DMT)

INFORMATION

Acceptable video or PC signals through the HDMI te rmina l s

The HDMI inputs on this TV only accept VGA, SVGA, XGA, WXGA, and SXGA signal formats which are compliant with VESA as shown in the table below. Since some PCs and HDMI or DVI devices input signals which are different from t he resolution a nd frequency des cribed in th e table below, the following phenomenon may occur: incorrect display, false format detect io n, p icture pos it ion fa il ure, blur, or judder. In this case, set the monitor output f ormat on your PC, HDMI or DVI device to conform to a signal in the table below.

English

Format Resolution V. Frequency H. Frequency

480i 720 × 480i 59.940/60.000 Hz 15.734/15.750 kHz 27.000/27.027 MHz

576i 720 × 576i 50.000 Hz 15.625 kHz 27.000 MHz 480p 720 × 480p 59.940/60.000 Hz 31.469/31.500 kHz 27.000/27.027 MHz 576p 720 × 576p 50.000 Hz 31.250kHz 27.000 MHz 1080i 1920 × 1080i 59.940/60.000 Hz 33.716/33.750kHz 74.176/74.250 MHz 1080i 1920 × 1080i 50.000 Hz 28.125 kHz 74.250 MHz 720p 1280 × 720p 59.940/60.000 Hz 44.955/45.000kHz 74.176/74.250 MHz 720p 1280 × 720p 50.000 Hz 37.500 kHz 74.250 MHz

1080p 1920 × 1080p 59.940/60.000 Hz 67.433/67.500 kHz 148.352/148.500 MHz 1080p 1920 × 1080p 50.000 Hz 56.250kHz 148.500 MHz 1080p 1920 × 1080p 24.000 Hz 27.000kHz 74.250 MHz 1080p 1920 × 1080p 29.970/30.000 Hz 33.720/33.750 kHz 74.176/74.250 MHz 1080p 1920 × 1080p 25.000 Hz 28.130kHz 74.250 MHz

VGA 640 × 480 59.940/60.000 Hz 31.469/31.500 kHz 25.175/25.200 MHz

72.809 Hz 37.861kHz 31.500 MHz

75.000 Hz 37.500kHz 31.500 MHz

SVGA 800 × 600 56.250 Hz 35.156 kHz 36.000 MHz

60.317 Hz 37.879kHz 40.000 MHz

72.188 Hz 48.077kHz 50.000 MHz

75.000 Hz 46.875kHz 49.500 MHz

XGA 1024 × 768 60.004 Hz 48.363 kHz 65.000 MHz

70.069 Hz 56.476kHz 75.000 MHz

75.029 Hz 60.023kHz 78.750 MHz

WXGA 1280 × 768 59.995 Hz 47.396 kHz 68.250 MHz

59.870 Hz 47.776kHz 79.500 MHz

74.893 Hz 60.289kHz 102.250 MHz

1360 × 768 60.015 Hz 47.712kHz 85.500 MHz

SXGA 1280 × 1024 60.020 Hz 63.981 kHz 108.000MHz

75.025 Hz 79.976kHz 135.000 MHz

Pixel Clock

Frequency

VESA

Standard

INFORMATION

Media Player Supported Format

English

Media

Player

Photo JPEG .jpg

Movie AVI .avi MPEG-2

Media

Format

MPO .mpo MPO

BMP .bmp BMP

MPEG-2 PS.mpg

MPEG-2 TS.ts

MPEG-2 VOB

File

Extension

.jpeg

.mpeg

.trp .tp

.vob MPEG-1 Video

JPEG

MPEG-4 part2 H.264 (MPEG-4 AVC)

DivX Xvid

MPEG-1 Video MPEG-1/2 Layer3 yes MPEG-2 Video MPEG-1/2 Layer2

MPEG-2 Video MPEG-1/2 Layer2 yes

H.264(MPEG-4 AVC) VC-1(WMV9)

MPEG-2 Video

Video codec Audio codec USB

yes yes USB

–

yes

–

yes

–

MPEG-1/2 Layer2 MPEG-1/2 Layer3 Dolby Digital (AC-3) L-PCM ADPCM MPEG-2/4 LC-AAC MPEG-4 HE-AAC

Dolby Digital (AC-3) L-PCM

MPEG-1/2 Layer3 Dolby Digital (AC-3) L-PCM MPEG-4 LC-AAC MPEG-4 HE-AAC

MPEG-1/2 Layer2 MPEG-1/2 Layer3 Dolby Digital (AC-3) L-PCM

yes

yes yes

yes

Network

Data compatibility: JPEG Exif ver 2.2 Maximum viewable resolution:

•JPEG 15360 × 8640 (Baseline)

1024 × 768 (Progressive)

•BMP 9600 × 6400

Maximum number of files: 1000 / folder

Network

Data compatibility: JPEG Exif ver 2.2 Maximum viewable resolution: 4096 × 4096 Maximum number of files: 1000/folder

NOTE: Some files may not be played.

no USB

Maximum number of files: 1000 / folder Maximum viewable resolution:

•Motion-JPEG:640 ×

480

•Other:1920 × 1080

Maximum video size: Unlimited

Network

Maximum video

yes

resolution: 1920 × 1080

Maximum number of file:1000 / folder Maximum video size: Unlimited

NOTE: Some files

may not be played.

Note

INFORMATION

English

Media

Player

Movie MOV .mov H.264 (MPEG-4 AVC)

Music MP3 .mp3 – MPEG-1/2 Layer-3 yes

Media

Format

MP4 .mp4

ASF .asf

DivX .divx

Xvid .xvid Xvid

MKV .mkv MPEG-1 Video

Flash Video (FLV1)

3GPP .3gp MPEG-4 part2

Motion JPEG

MP4 .m4a – MPEG-2/4 LC-AAC yes yes WMA .wma – WMA7/8/ Std yes

WAV .wav – LPCM

LPCM –

File

Extension

.m4v

.wmv

.div

.flv .swf

.avi .mp4 .mkv

Video codec Audio codec USB

MPEG-4 part2

H.264 (MPEG-4 AVC) MPEG-4 part12,14

H.264 (MPEG-4 AVC) MPEG-2/4 LC-AAC yes y es VC-1 (WMV9) WMA7/8/9 Std

DivX 3,4,5,6 MPEG-1/2 Layer2

MPEG-2 Video MPEG-4 part2 H.264 (MPEG-4 AVC)

Sorenson H.263 (FLV1) H.264 (MPEG-4 AVC)

H.264 (MPEG-4 AVC) JPEG L-PCM

MPEG-1/2 Layer3 MPEG-2/4 LC-AAC MPEG-4 HE-AAC

MPEG-1/2 Layer3 MPEG-4 HE-AAC

WMA9 Pro

MPEG-1/2 Layer3 Dolby Digital (AC-3) PCM ADPCM

MPEG-1/2 Layer2 MPEG-1/2 Layer3 Dolby Digital (AC-3) L-PCM MPEG-2/4 LC-AAC MPEG-4 HE-AAC

MPEG-1/2 Layer3 MPEG-2/4 LC-AAC L-PCM ADPCM

MPEG-2/4 LC-AAC yes

ADPCM

WMA9 Std yes WMA9 Pro yes

ADPCM MPEG-1/2 Layer-3 WMA7/8/9/ Std WMA9 Pro

yes no

yes

no yes

Network

yes USB

Maximum number of files: 1000 / folder

Maximum music size: Unlimited

yes

Network

Sampling rate: 32,

44.1 and 48 KHz

Bit rate: 32 to 320 kbps Maximum number of files: 1000 / folder Maximum music size: Unlimited

NOTE: Some files may not be played.

Note

INFORMATION

3D Support Format (HDMI)

English

Resolution

720 × 480p 16:9 59.940/60.000 Hz 31.469/31.500 kHz 54.000/54.054 MHz Side by Side (Full)

720 × 576p 16:9 50.000 Hz 31.250 kHz 27.000 MHz Side by Side (Full)

1280 × 720p 16:9 59.940/60.000 Hz 90.0/89.91 kHz 148.352/148 .500 MHz Frame Packing

1920 × 1080i 16:9 59.940/60.000 Hz 33.716/33.750 kHz 74.176/74.250 MHz Side by Side (Half)

1920 × 1080p 16:9 23.976/24.000 Hz 53.940/54.000 kHz 148.352/148.500MHz Frame Packing

Aspect

ratio

V.Frequency H.Frequency

44.955/45.000 kHz 74.176/74.250 MHz Side by Side (Half)

50.000 Hz 75.000 kHz 148.500 MHz Frame Packing

37.500 kHz 74.250 MHz Side by Side (Half)

50.000 Hz 28.130 kHz 74.250 MHz Side by Side (Half)

26.973 kHz 74.176/74.250 MHz Side by Side (Half)

29.970/30.000 Hz 67.433/67.500 kHz 148.352/148.500 MHz Frame Packing

33.716/33.750 kHz 74.176/74.250 MHz Side by Side (Half)

50.000 Hz 56.250 kHz 148.500 MHz Side by Side (Half)

59.940/60.000 Hz 67.433/67.500 kHz 148.352/148.500 MHz Side by Side (Half)

Pixel Clock

Frequency

27.000/27.027 MHz Side by Side (Half)

3D Structure

Top and Bottom

Side by Side (Half)

Top and Bottom

3D Support Format (DTV)

2D Video

Side by Side (Full)

3D Video

Side by Side (Half)

2D Video 3D Video

INFORMATION

English

Video Format

480i, 480p 16:9 59.940/60.000 Hz Side by Side (Half)

576i, 576p 16:9 50.000 Hz Side by Side (Half)

720p 16:9 59.940/60.000 Hz Side by Side (Half)

1080i 16:9 59.940/60.000 Hz Side by Side (Half)

1080p 16:9 24.000 Hz Side by Side (Half)

* Side by Side (Full) is composed of left and right stereoscopic pictures that each size is equal to 2D. * The 3D function and 2D to 3D conversion function does not support all content depending on its input source format.

Aspect

ratio

V.Fraquency 3D Structure

Top and Bottom

50.000 Hz Side by Side (Half) Top and Bottom

Top and Bottom

50.000 Hz Side by Side (Half) Top and Bottom

Top and Bottom

30.000 Hz Side by Side (Half) Top and Bottom

50.000 Hz Side by Side (Half) Top and Bottom

59.940/60.000 Hz Side by Side (Half) Top and Bottom

INFORMATION

Licence information

English

• DLNA™, DLNA CERTIFIED™, DLNA CERTIFIED Logo are trademarks, service marks, or certification marks of the Digital Living Network Alliance.

• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

• HDMI, the HDMI logo, and HighDefinition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

• This product contains Adobe Player software under license from Adobe Systems Incorporated. Copyright© 1995-2009 Adobe Systems Incorporated. All rights reserved. Adobe and Flash are trademarks of Adobe Systems Incorporated.

• DivX®, DivX Certified®, DivX Plus® HD and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license. Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274

• DVB is a registered trademark of the DVB Project.

• Hybrid TV Standard is implemented according to ETSI TS 102 796 v1.1.1.

• Intel and the Intel logo are trademarks of Intel Corporation in the U.S. and/or other countries.

• MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC.

• Manufactured under license from Audyssey Laboratories. U.S. and foreign patents pending. Audyssey Premium Television™ is a trademark of Audyssey Laboratories. Audyssey Premium Television™ is a suite of technologies that remove the acoustical problems caused by small speakers and drivers. Working together these technologies deliver a better translation of the audio content and make the television experience sound closer to the original.

Flash®

• THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (AVC VIDEO) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM

• THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD ("MPEG-4 VIDEO") AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA,L.L.C. SEE HTTP://WWW.MPEGLA.COM

• MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

• RealD and the RealD logo are trademarks of RealD Inc.

• You can check the software components and obtain a copy of the source codes including GPL and LGPL subject to such EULA requirements on the following Home Page: http://tesc.toshiba.co.uk/Web/Website.nsf/ ContentFrameSet?OpenFrameset There will be a charge to cover the costs of providing the source code.

INFORMATION

Disposal…

The following information is only for EU-member states:

Disposal of products

The crossed out wheeled dust bin symbol indicates that products must be collected and disposed of separately from household waste. Integrated batteries and accumulators can be dispose d of with the product. They will be separated at the recycling centres. The black bar indicates that the product was placed on the market after August 13, 2005. By participating in separate collection of products and batteries, you will help to assure the prope r disposal of products and batteries and thus help to prevent potential negative consequences for the environment and human health. For more detailed information about the collection and recycling programmes availab le in your country, please contact your local city office or the shop where you purchased the product.

Disposal of batteries and/or accumulators

The crossed out wheeled dust bin symbol indicates that batteries and/or accumulators must be collected and disposed of separately from household waste. If the battery or accumulator contains more than the specified values of lead (Pb), mercury (Hg), and/ or cadmium (Cd) defined in the Battery Directive (2006/66/EC), then the chemical symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd) will appear below the crossed out wheeled dust bin symbol. By participating in separate collection of batteries, you will help to assure the proper disposal of products and batteries and thus help to prevent potential negative consequences for the environment and human health. For more detailed information about the collection and recycling programmes availab le in your country, please contact your local city office or the shop where you purchased the product.

EU Conformity Statement

This product is carrying the CE-Mark in accordance with the related European Directives. Responsible for CE-Marking is TOSHIBA TELEVISION CENTRAL EUROPE Sp. z o.o., ul. Pokoju 1 Biskupice Podgórne 55-040 Kobierzyce, Poland This product is labeled with the CE Mark in accordance with the related European Directives, notably Low Voltage

Directive 2006/95/EC, Electromagnetic Compatibility Directive 2004/108/EC and RoHS Directive 2011/65/EU. Furthermore the product complies with the Ecodesign Directive 2005/32/EC (EuP) and 2009/125/EC (ErP) and its

related implementing measures. If this product has an integrated Wireless LAN feature, the Radio Equipment and Telecommunications Terminal

Equipment Directive 1999/5/EC is also applicable.

Cleaning the screen and cabinet…

Turn off the power, and clean the screen and cabinet with a soft, dry cloth. We recommend that you do not use any proprietary polishes or solvents on the screen or cabinet as this may cause damage.

English

INFORMATION

Cautions and other information for 3D

English

Important information for 3D viewing

Available 3D glasses :

Toshiba FPT-AG03 (L73*5D/M83*5D: 2pcs supplied, L73**RK/L73**RB: 1pcs supplied, L73*3D/L73*1D: Not supplied)

CAUTION

• This product contains a coin/button cell battery. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

• The 3D function has been designed for private use and entertainment in your home environment. Please note that any commercial use of the 3D function could lead to copyright infringement of authors’ rights. Toshiba asks you to respect the intellectual property rights of third parties.

About handling the 3D glasses

• Do not leave the 3D glasses or the accessories within the reach of small children.

Inhaling or swallowing them may cause suffocation or lesions in the stomach wall. If swallowed, consult a doctor immediately.

• Do not repair, modify, or disassemble the 3D glasses

by yourself.

Doing so may cause a fire or cause you to become indisposed while viewing 3D images. Contact the Toshiba Call Center for repair of your 3D glasses.

• Do not expose the glasses to excessive heat such as

sunshine, fire, or the like.

About the 3D glasses

• Do not use the 3D glasses if they are not working properly or broken.

Continuing to use them in such a state may cause injury, eye strain, or indisposition. Do not use the 3D glasses if they are broken or have any cracks.

• Do not stand or walk while wearing 3D glasses. You may lose your balance which could result in falls or other accidents.

• Do not wear the 3D glasses for any purpose other than

viewing 3D programming.

3D glasses do not function as sunglasses.

• Do not drop, exert pressure on, or step on the 3D

glasses.

Doing so may damage the glass section, which may result in injury. Exposing the 3D glasses to liquid or excessive heat may damage the liquid crystal shutter function.

• If your nose or temple turns red, or you feel pain or

discomfort, stop using the 3D glasses.

Such symptoms as above may occur if you keep wearing them for a long time, which may also cause indisposition.

• Be careful not to pinch your fingers in the hinge of the

3D glasses.

Cautions on watching 3D images

• Some viewers may experience a seizure or blackout

when exposed to certain flashing images or lights contained in certain 3D television pictures or video games.

Anyone who has had a seizure, loss of awareness, or other symptoms linked to an epileptic condition, or has a family history of epilepsy, should contact a health care provider before using the 3D function.

• Avoid use of the 3D function when under the influence

of alcohol.

• If you are ill or feel ill, you should refrain from viewing

3D images, and consult your health care provider as may be appropriate.

• If you experience any of the following symptoms when

viewing 3D video images, stop viewing and contact your health care provider:

Convulsions, eye or muscle twitching, loss of awareness, altered vision, involuntary movements, disorientation, eye strain, nausea/vomiting, dizziness, headaches.

• If you feel eye fatigue or other discomfort from viewing

3D video images, remove the 3D glasses and discontinue use until the condition is eliminated.

• Viewing in 3D may cause dizziness and/or

disorientation for some viewers.

Therefore, to avoid injury do not place your TV near open stairwells, balconies, or wires. Also do not sit near objects that could be broken if accidentally hit.

• When viewing 3D images, always wear 3D glasses. Watching 3D images without 3D glasses may cause eye strain. Use specified 3D glasses.

• When watching 3D images, do not wear 3D glasses at

an angle and do not lie down.

If you watch while lying down or with the glasses tilted, the 3D effect is lost and it may cause eye strain.

• If 3D images often appear in double or if you cannot

see the images in 3D, stop viewing.

Continuous viewing may cause eye strain.

• Due to the possible impact on vision development,

viewers of 3D video images should be age 6 or above.

Children and teenagers may be more susceptible to health issues

associated with viewing in 3D and should be c

supervised to avoid prolonged viewing without rest.

• Watching TV while sitting too close to the screen for

an extended period of time may cause eye strain.

The ideal viewing distance should be at least three times the screen height.

• Switching left and right images The left and right eye shutter timing of the glasses can be swapped. If 3D images look blurred, switch the left and right sides of the 3D image.

If the 3D PIN number has been forgotten:

Use the Master PIN code of 1276, and then change to a number of your choice. Select 3D PIN from the 3D Setup menu to enter PIN.
