Toshiba HD-E1KE User Manual

HD DVD player

Introduction Connections

Playback

(Basic)

(Advanced)

Playback

OWNER’S MANUAL

connection

Internet

Others

Chapter

SAFETY PRECAUTIONS

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THISAPPLIANCE

TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

CAUTION: This HD DVD player employs a Laser System.

To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference. Should the unit require maintenance, contact an authorized service location.

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

To prevent direct exposure to laser beam, do not try to open the enclosure. Visible and invisible laser radiation when open and interlocks defeated. DO NOT STARE INTO BEAM.

CLASS 1

LASER PRODUCT

Introduction

Introduction Connections

Playback

(Basic)

Playback

(Advanced)

Others

Internet

connection

CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the

risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.

In the spaces provided below, record the Model and Serial No. located on the rear panel of your player.

Model No. Serial No.

Retain this information for future reference.

Location of the required label

Following information is only for EU-member states:

The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, pleasecontact your local city office, your household waste disposal service or the shop where you purchased the product.

The rating plate and the safety caution are on the rear of the unit.

Chapter

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

10.Only use attachments/accessories specified by the manufacturer.

12.Unplug this apparatus during lightning storms or when unused for long periods of time.

13.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS

OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user.

DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.

11.Do not place a flaming object such as a burning candle on the apparatus.

Introduction

Introduction Connections

Playback

(Basic)

Playback

(Advanced)

Others

Internet

connection

ADDITIONAL SAFETY INSTRUCTIONS

14.Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

15.Apparatus should not be exposed to dripping or splashing and no objects filled with liquids, such as vases, should not be placed on the apparatus.

16.Keep your fingers well clear of the disc tray as it is closing. Neglecting to do so may cause serious personal injury.

17.Do not place anything on top of this unit.

18.Do not place the apparatus on amplifiers or equipment that may produce heat.

19.Do not cover the ventilating holes for the inside cooling fan.

20.Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and apparatus malfunction.

21.If the apparatus should smoke or smell, immediately disconnect the power cord from the wall outlet. Wait until the smoke or smell stops, then ask your dealer for a check and repair. Neglecting to do so may cause fire.

22.During thunderstorms, do not touch the connecting cables or the apparatus.

Chapter

Introduction

Precautions

Notes on handling

Never disconnect the power cord from a wall outlet

while the player is turned on, unless it is in an emergency. Doing so may cause malfunction. When shipping the player, the original shipping

carton and packing materials come in handy. For maximum protection, repack the unit as it was originally packed at the factory. Do not use volatile liquids, such as insect spray,

near the player. Do not leave rubber or plastic products in contact with the player for a long time. They will leave marks on the ﬁ nish. The top and rear panels of the player may become

warm after a long period of use. This is not a malfunction.

When not in use

For usual absence

Be sure to remove the disc from the player and

turn off the power. Prolonged absence

Unplug the player from a wall outlet. (This will stop

the clock. Display “SETUP MENU” by pressing SETUP, and reset the clock (

page 50, 57).)

About the volume level

The volume level of some commercial HD DVD and DVD discs may seem lower than that of audio CDs, other software, etc. If you turn up the volume of the TV or ampliﬁ er to play such discs, be sure to turn it back down after playback ﬁ nishes.

Playback restrictions

This owner’s manual explains the basic instructions for this player. Some HD DVD discs or DVD video discs are produced in a manner that allows speciﬁ c or limited operation during playback. As such, the player may not respond to all operating commands. This is not a defect in the player. Please refer to the notes on compatible discs later in this Introduction and to the discussion of DVD playback and features later in this manual.

“

” may appear on the TV screen during operation. “ ” means that the operation is not permitted by the player or the disc.

About software

Notes on locating

Place the player on a level surface. Do not use

it on a shaky or unstable surface such as a wobbly table or inclined stand. The loaded disc may dislodge from its proper position and cause damage to the player.

Before placing the player, make sure that the

surface can stand the weight of the player. Never place the player in a high location to avoid damage to the product or person by an accidental fall of the player. When you place this player near a TV, radio, or

VTR, the playback picture may become poor and the sound may be distorted depending on the condition and location of said equipment. In such an event, place the player as far away much as possible from the TV, radio, or VTR. To avoid damage to this product, never place or

store the unit in direct sunlight; hot, humid areas; or areas subject to excessive dust, oily smoke, cigarette smoke or vibration.

Notes on cleaning

Use a soft, dry cloth for cleaning.

Do not use any type of solvent, such as thinner or

benzine, as they may damage the surface of the player.

Because of problems and errors that can occur during the creation of HD DVD, DVD and CD software and/or the manufacture of HD DVD, DVD and CD discs, Toshiba cannot assure that this player will successfully play every disc bearing the HD DVD, DVD or CD logos. If you happen to experience any difﬁ culty playing an HD DVD, DVD or CD disc on this player, please contact Toshiba customer service.

Some differences

The HD DVD player operates more like a computer and differently than a standard DVD player, In addition to containing a microprocessor, it contains an operating system, random access memory (RAM), and an HD DVD drive. The operating system includes software that is transferred to the RAM when the machine is turned on and at other times during operation. This transfer can take time. Therefore, when you turn the HD DVD player on, it may take a little while before it is ready to use. Likewise, other functions may not be performed as quickly as they would on other AV equipment. Please take these factors into consideration as you use the HD DVD player.

Introduction Connections

Playback

(Basic)

Playback

(Advanced)

Others

Internet

connection

OTST)



Notes on moisture condensation

Moisture condensation damages the unit. Please read the following carefully.

Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass. In the same way, moisture may condense on the optical pick-up lens inside this unit, one of the most crucial internal parts of the unit.

Moisture condensation occurs during the following cases.

When you bring the unit directly from a cold place

to a warm place. When you use the unit in a room where you just

turned on the heater, or a place where the cold wind from the air conditioner directly hits the unit. In summer, when you use the unit in a hot and

humid place just after you move the unit from an air conditioned room. When you use the unit in a humid place.



/PTICALPICKUP

LENS

Notes on copyright

The unauthorized recording, use, display,

distribution, or revision of television programs, videotapes, HD DVDs, DVDs, CDs and other materials, is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and/or criminal liability. This product incorporates copyright protection

technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license from Digital Theater Systems, Inc. U.S. Pat. No's. 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535 and other U.S. and world-wide patents issued and pending. "DTS" and "DTS Digital Surround" are registered trademarks of Digital Theater Systems, Inc. Copyright 1996, 2003 Digital Theater Systems, Inc. All Rights Reserved.

Do not use the unit when moisture condensation may occur.

If you use the unit in such a situation, it may damage discs and internal parts. Connect the power cord of the unit to the wall outlet, turn on the unit, remove the disc, and leave it for two or three hours. After two or three hours, the unit will have warmed up and evaporated any moisture. Keep the unit connected to the wall outlet and moisture condensation will seldom occur.

IA7

T

7ALLOUTLET

HDMI, the HDMI logo and High-Deﬁ nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

SHARC is a registered trademark and Melody is a trademark of Analog Devices, Inc.

and are trademarks of DVD Format/

Logo Licensing Corporation.

All other brand and product names mentioned in this manual are trademarks and/or registered trademarks of their respective holders.

Chapter

Introduction

Features

Playback of HD DVD video discs

HD DVD video discs are high-density, high-capacity discs. 7 The HD DVD disc standard has been approved

by the DVD forum.

7 HD DVD (single layer): 15 GB HD DVD (dual layer): Maximum capacity of 30 GB

A single layer single sided disc (15 GB) has capacity of about 8 hours in 1125 line high deﬁ nition picture; about 48 hours in 525 line

standard deﬁ nition picture (depending on bitrate

of pre-recorded contents). *1GB means 1,000,000,000 bytes. 7 HD DVD Twin Format Discs have both HD DVD

and DVD layers on one side. HD DVD Combination

DVD Discs have HD DVD material on one side and

standard DVD material on the other side. Because

both disc types are new, such discs may not operate properly in this player. 7To view high-deﬁ nition picture in HD DVD discs, an HDTV display (720p, 1080i) is required. 7Connect an HDTV set to the COMPONENT OUTPUT jacks or the HDMI OUTPUT jack on this

player. 7Some discs may require use of HDMI OUTPUT for

viewing of high resolution material.

Compatible with multiple disc types

7 Playback of commercial HD DVD video disc, DVD

video, and Audio CD 7 Playback of DVD-RW (disc recorded in DVD VR

mode or DVD video mode), and DVD-R 7 Playback of CD-RW and CD-R (Audio CD of CD-DA format only; playback of MP3, WMA

and other non-CD-DA audio formats are not

supported.) Because HD DVD is a new format, disc compatibility issues with new and existing format discs are possible. Not all discs are compatible. If you experience compatibility problems, please contact Toshiba customer service. HD DVD discs containing high deﬁ nition content at a ﬁ eld rate of 50Hz or a frame rate of 25Hz can not be played on this player without a ﬁ rmware update. Firmware update is expected in the future. Blu-ray Discs cannot be played on this player.

Internet connection feature (LAN port)

7 Some HD DVD discs enable you to access special HD DVD sites. If an HD DVD site includes

content such as movie trailers, you can watch the content on the player via the Internet if your

internet connection provides sufﬁ cient bandwidth.

HD output jacks

7 An HDMI jack for connecting a single cable to

output video and audio signals

7 Component jacks

Compatibility notes

7 For compatibility, see page 28.

Certain system requirements and Iimitations

For high deﬁ nition video playback: 7HD display (some discs may require HDCP

capable input)

7HD DVD disc with HD content

For Dolby® Digital Plus and Dolby TrueHD multi-channel audio playback: 7A/V Receiver with HDMI™ multi-channel LPCM

capable audio input and 5.1 channel speaker setup.

Certain limitations: Viewing high-deﬁ nition content and up-converting DVD content may require an HDCP capable input on your display device. Because HD DVD is a new format, certain disc, digital connection and other compatibility issues are possible. Some recordable media may not be supported. Dolby Digital Plus, Dolby TrueHD and DTS support for up to 5.1 channels. DTS-HD support for DTS core only. MP3/WMA audio ﬁ les not supported. Please see www.toshibahddvd.eu for more information. Features subject to change and delayed availability. The ﬁ rmware in this player can be updated.

Introduction Connections

Playback

(Basic)

Playback

(Advanced)

Others

Internet

connection

Composite audio/video cable

Customer support

Please contact Toshiba customer service for your country or www.toshibahddvd.eu.

This HD DVD player is manufactured under the HD DVD Format adopted by the DVD Forum. The DVD Forum approved AACS (Advance Access Content System) as content protection system for HD DVD format like it approved CSS (Content Scramble System) for DVD format. Therefore, certain restrictions are imposed on play, analog signal output, etc. of AACS protected contents. When you use pre-recorded contents, the contents may designate whether or not to apply such restrictions. As those restrictions may be adopted and/or changed and announced by AACS after the production of this product, the operation of this product and restrictions thereon may vary depending on the time you purchase this product as well as during the life of this product. To obtain updated information about AACS and this product, please contact Toshiba customer service for your country or www.toshibahddvd.eu.

Accessories

Check that the following accessories are supplied.

Remote control Batteries (AAA)x2

Power cord

Use either to match your wall outlet.

Caution

• Do not use this power cord with any device other than this player.

Chapter

Introduction

Table of Contents

SAFETY PRECAUTIONS ..................................................................................... 2

Introduction

IMPORTANT SAFETY INSTRUCTIONS ............................................................... 4

Precautions .......................................................................................................... 6

Features ................................................................................................................ 8

Accessories .......................................................................................................... 9

Index to parts and controls ............................................................................... 12

Front panel .................................................................................................................................................................. 12

Rear panel .................................................................................................................................................................. 13

Display ........................................................................................................................................................................ 14

Remote control............................................................................................................................................................15

Preparation of the remote control .................................................................... 16

Loading batteries ........................................................................................................................................................ 16

Operating with the remote control .............................................................................................................................. 16

Programming for TV control ........................................................................................................................................ 17

Operating your TV with the remote control ................................................................................................................. 17

Hint on reading this manual ............................................................................. 18

Icons for function applicability .................................................................................................................................... 18

Instructions and actual buttons .................................................................................................................................. 18

Connecting to a TV .............................................................................................20

Connections

Connecting to an audio system ........................................................................24

7Via HDMI output..........................................................................................................................................................24

Via optical digital audio output ................................................................................................................................... 24

Disc compatibility ...............................................................................................28

Playback (Basic)

Powering on/Loading a disc ..............................................................................30

Playing a disc ......................................................................................................31

Stopping playback / Pausing playback ................................................................................................... 31

Playing from the top menu ....................................................................................................................... 32

Using A/B/C/D buttons ............................................................................................................................. 32

Playing from a menu in a recorded disc .................................................................................................. 32

Selecting the sound .................................................................................................................................33

Selecting the sound of a disc recorded in DVD VR mode ....................................................................... 33

Selecting subtitles .................................................................................................................................... 34

Selecting the camera angle ..................................................................................................................... 34

Playing at various speeds ..................................................................................35

Locating by entering a section number ................................................................................................... 36

Locating by entering elapsed time ..........................................................................................................36

Resuming playback from the location last stopped (Title resume) .......................................................... 36

Introduction Connections

Playback

(Basic)

Playback

(Advanced)

Others

Internet

connection

Repeat playback ................................................................................................ 38

Playback (Advanced)

EXTENSION ports .............................................................................................. 39

Using the cursor function ................................................................................. 39

Checking the current status and settings ....................................................... 40

Internet connection feature (Outline) ............................................................... 42

Internet connection

Internet connection feature (Preparation) ....................................................... 44

Internet connection feature (Operation) .......................................................... 47

Customizing the function settings ................................................................... 50

Picture ......................................................................................................................................................52

Others

Audio ........................................................................................................................................................53

Language .................................................................................................................................................54

Ethernet ....................................................................................................................................................55

General .....................................................................................................................................................56

Firmware update ......................................................................................................................................58

Language code list ............................................................................................ 59

Output sound conversion table ........................................................................ 60

License information on the software used in the TOSHIBA HD DVD player

.. 61

Before calling service personnel ..................................................................... 68

Speciﬁ cation ...................................................................................................... 69

INFORMATION ON CUSTOMER SUPPORT ...................................... Back cover

Chapter

Introduction

Index to parts and controls

See pages with arrows for details.

Front panel

1011

* The above illustration displays the front panel with the cover open.

Note

Do not place a heavy object on the cover while it is open. Doing so may damage the player.

ON/STANDBY button / ON/STANDBY

indicator

Turns the power on/restores the unit to the

standby mode.

Remote sensor page 16

page 30

(SKIP) button page 35

Skips to the next chapter or track.

(SKIP) button page 35

Skips to the previous chapter or track.

56789

Front panel display page 14

EXTENSION ports page 39

(PLAY) button

Starts playback.

(STOP) button page 31

Stops playback.

(PAUSE) button

Stops playback momentarily.

page 31

OPEN/CLOSE button page 30

Opens and closes the disc tray.

Disc tray page 30

Loads a disc into the disc drive.

Introduction Connections

Playback

(Basic)

Playback

(Advanced)

Others

Internet

connection

Rear panel

541 2 3 6

LAN port page 44

Use this to connect to a network with an

always-on broadband connection.

DIGITAL AUDIO OUTPUT BITSTREAM/PCM

OPTICAL jack

Outputs digital audio signals. Connect to a digital audio input on an ampliﬁ er

equipped with digital audio decoder.

When connecting the optional digital cable, ﬁ t

the connector into the jack ﬁ rmly.

COMPONENT OUTPUT jacks page 22

Outputs video signals to a connected TV or

monitor.

Connect to a TV or monitor equipped with

component video jacks.

page 24

Ventilation fan

Do not cover the ventilation holes.

AC IN socket page 21, 22

Connect the supplied power cord.

VIDEO OUTPUT (VIDEO, S-VIDEO)

page 22

Outputs video signals to a connected TV or

ampliﬁ er.

ANALOG AUDIO OUTPUT jacks page 22

Outputs audio signals to a connected TV or AV

ampliﬁ er.

HDMI OUTPUT jack page 21

Outputs video/audio signals to a connected

TV, monitor or AV ampliﬁ er.

Connect to a TV, monitor or AV ampliﬁ er

equipped with HDMI input.

Chapter

Introduction

Index to parts and controls (Continued)

Display

3 5

6 7 92 41

Status indicator

HD DVD : Illuminates when an HD DVD disc is

DVD : Illuminates when a DVD disc is

Illuminates when a title number is displayed.

Illuminates when advanced content is played.

Illuminates when a chapter number is displayed.

Illuminates when a CD is loaded.

Illuminates when a track number is displayed.

: IIluminates when DTS sound is played.

Illuminates when HDMI connection is veriﬁ ed

: Playing

: Pausing : Fast forward playback : Fast reverse playback

Disc indicator

loaded.

TITLE indicator

ADV (Advanced) indicator

CHP (Chapter) indicator

CD indicator

TRK (Track) indicator

Sound format indicator

: Illuminates when Dolby Digital sound is

played.

HDMI Indicator

between the player and another device.

1110

12 151413

TOTAL indicator

Illuminates when the total playing time of the

disc is displayed.

REMAIN (Remaining) indicator

Illuminates when a remaining playback time

is displayed.

2ch indicator

Illuminates when 2 channel (L/R) sound is

output.

MULTI indicator

Illuminates when 5.1 channel sound is

output.

Repeat mode indicator

Illuminates when playing in repeat mode.

Angle icon indicator

Illuminates when playing a scene recorded

with multi angles.

Multi display

Displays the total playing time of the disc,

elapsed time, remaining time, title number, chapter number or message, etc.

Video output format indicator

Displays the video output format currently

selected. 480 480 720 1080

: 480 interlace, 576 interlace : 480 progressive, 576 progressive : 720 progressive : 1080 interlace

Switching the display

Every time you press DISPLAY button on the remote control, the display changes the contents. The display may not change, depending on the disc conditions.

Dimming the display

Pressing DIMMER button on the remote control changes the brightness of the display.

À> i`

"vv

• Turning off the power resets this setting.

Introduction Connections

Playback

(Basic)

Playback

(Advanced)

Others

Internet

connection

button page 35

 (PAUSE) button

page 31

OPEN/CLOSE button page 30

ANGLE button page 34

Direction buttons page 32, 50

OK button page 32, 50

(STOP) button page 31

MENU button page 32

SUBTITLE button page 34

AUDIO button page 33

ON/STANDBY button page 30

TV VOL. buttons page 17

T.SEARCH button page 36

CLEAR button page 36

SETUP button page 50

TV/ DVD button page 17

TV CODE button page 17

DIMMER button page 14

REPEAT button page 38

(SKIP) button page 35

TOP MENU button page 32

A, B, C, D button page 32

CURSOR button page 39

SLOW button page 35

(SKIP) button page 35

button page 35

TV button page 17

RETURN button page 50*

RESUME PLAY button page 36

(PLAY) button page 31

TV CH buttons page 17

Number buttons page 36

MAIN/SUB button*

TV MUTE button page 17

DISPLAY button page 41

 button

page 35

Remote control

MAIN/SUB For future functions may become

available by software update.

RETURN

Returns to the previous screen (the

screen may be speciﬁ ed depending on the disc).Refer to the instructions of the disc.

Chapter

Introduction

Preparation of the remote control

Set up the remote control to operate the player and your TV.

Loading batteries

Open the cover.

Insert batteries.

Use 2 batteries (R03 sizes).

Make sure to match the + and – on the

batteries to the marks inside the battery compartment.

Close the cover.

Operating with the remote control

Point the remote control at the remote sensor and press the buttons.

Distance

Angle

: About 7 m from the

front of the remote sensor

: About 30° in each

direction of the front of the remote sensor

Notes

Do not drop or give the remote control a shock. Do not leave the remote control near an extremely hot or humid place. Do not spill water or put anything wet on the remote control. Do not disassemble the remote control. Dispose of batteries in a designated disposal area. Batteries should always be disposed of with the environment in mind. Always dispose of batteries in accordance with applicable laws and regulations. If the remote control does not operate correctly, or if the operating range becomes reduced, replace all batteries with new

ones.

When necessary to replace batteries in the remote control, always replace all batteries with new ones. Never mix battery types

or use new and used batteries in combination. Be sure to use R03 size batteries. Always remove batteries from remote control if they are dead or if the remote control is not be used for an extended period of

time. This will prevent battery acid from leaking into the battery compartment.

Caution

Never throw batteries into a ﬁ re.

Introduction Connections

Playback

(Basic)

Playback

(Advanced)

Others

Internet

connection

TV :

To turn on and off the TV

TV/DVD : To change the video input

TV CH : To select the TV channel

TV MUTE : To mute the TV

TV VOL. : To adjust the volume

Programming for TV control

While holding , press the

number buttons to enter a corresponding brand code (see below) of your TV.

e.g. To enter 2581

Hold down.

Some brands have several codes. Try one by

•

one until the remote control can operate your TV.

Release .

The brand code is memorized.

Note

When replacing the batteries of the remote control, re-enter

the brand code of your TV.

Operating your TV with the remote control

Point the remote control to your TV after you have entered the brand code. Operate your TV with the buttons below.

Notes

For some TVs, pressing the volume button once may

change the volume by more than one level.

Even after the player's remote control is programmed, it

may not operate some or all of the features on your other device.

If this happens and you wish to use those features, you will

need to use the device's original remote control.

Brand code table

Brand name

Toshiba 2581 2601 3281 3491 3771 4291

Aiwa 3241 Akai 2671 Bang & Olufsen 2621 Beko 2941 3331 4471 Blaupunkt 2711 2801 Brionvega 2621 Bush 2541 2681 2691 2751 2781 2851

Crown 2541 2871 2921 Daewoo 2541 2881 3221 3271 Decca 2611 Ferguson 2761 2841 3351 Finlux 2601 2611 2621 Fisher 2671 2981

Brand code

4301 4311 4321 4671

2861 2881 3291 4261 4481

Brand name

Funai 2731 2781 GEC 2591 2611 Goodmans 2611 2691 2861 2881 3221 3841 Granada 2611 2671 Grundig 2601 2701 3151 3441 4491 Hinari 2541 2681 2691 2901 Hitachi 2591 3301 3471 3501 3511 3701

3671 4501 Inno Hit 2611 JVC 2861 3361 3591 4511 LG Goldstar 2491 Loewe 2621 2771 2961 3311 Luxor 2701 Marantz 2991 Matsui 2541 2581 2611 2651 2671 2691

2781 2851 2861 3151 Metz 2621

Brand code

(Continued)

Chapter

Introduction

Preparation of the remote control (Continued)

Brand name

Mitsubishi 2621 2701 2961 3371 4521 National 2701 Orion 2691 2781 2851 3381 Panasonic 2701 2711 2741 3001 3251 3531

3551 3761 3911 3951 Philco 2621 Philips 2561 2571 2591 2621 2811 2821

2881 2991 3461 3581 3731 3881

3981 4531 4541 4551 Pioneer 2761 3481 3681 3921 3931 3941 Saba 2621 2761 2841 3321 Saisho 2541 2651 2691 2731 Samsung 2541 2631 2731 2991 3161 3231

3521 3541 3711 3721 3901 3961

4271 4561 Sanyo 2611 2671 3391 Schneider 2571 2681 2811 2861 3991 4571

4581 4591 4601 4611

Brand code

Hint on reading this manual

Brand name

SEG 2731 3051 Seleco 2661 2721 Sharp 2641 3401 3611 3631 3781 3791

3801 3811 3821 3831 3971 Singer 2621 Sinudyne 2551 2621 2651 2691 3011 3051 Sony 2551 2951 3621 3641 3651 3871

3891 4281 4621 Tatung 2611 Technics 2711 3001 Telefunken 2841 3421 Tensai 2681 2781 Thomson 6641 2701 2761 2831 3431 3601

4631 4641 4651 4661 Thorn 2581 2611 2951 2961 3221 Universum 2731 Zanussi 2661

Brand code

Instructions and actual buttonsIcons for function applicability

The following icons are used in this manual to indicate features and/or functions that are applicable to various types of discs. (For disc compatibility information, see page 28.)

Icon Disc Icon Disc

HD DVD

DVD-Video

DVD-RW

DVD-R

HD DVD video disc

DVD video disc

DVD-RW

DVD-R

CD-RW

(CD-DA)

CD-R

(CD-DA)

Audio CD

CD-RW (CD-DA format)

CD-R (CD-DA format)

Most instructions are based on remote control operation, unless otherwise noted. You can use the buttons on the remote control and those on the main unit as well when they have the same function. Some functions are available only from the remote control.

Introduction Connections

Playback

(Basic)

(Advanced)

Playback

Connections

Connect your player to your A/V system.

Connecting to a TV

Connecting to an audio system

connection

Internet

Others

Chapter

HDMI INPUT

Most recommended*

HDMI input

Viewable. 21

Down converted.

(Some discs may require

HDMI connection.)

Viewable.

(Some discs may be down

converted or require

HDMI connection.)

Component video

input

S-VIDEO or VIDEO (yellow) input

TV input

High definition video Page

Connections

Connecting to a TV

Step

To view 480p, 576p, 720p or 1080i output, use the HDMI OUTPUT jack or the COMPONENT OUTPUT jacks to connect to a TV. Some discs may require use of the HDMI OUTPUT jack for viewing of high resolution material.

Check the type of video input on your TV.

*Why HDMI connection is most recommended?

HD DVD and DVD video disc creators have the option to include copy protection instructions in their discs that prohibit the output of some standard video or high deﬁ nition video (original 720p or 1080i or up-converted 480i/576i or 480p/576p) from the COMPONENT OUTPUT jacks. If such instructions are present in the disc you are playing, you must use the HDMI OUTPUT jack to view the disc in a high deﬁ nition format and the COMPONENT OUTPUT jacks, if activated, will output video only in 480i/576i or 480p/576p resolution.

Caution on connection

• Do not power this player using any power cord other than the one supplied with this player.

• Do not use the supplied power cord with any device other than this player.

Notes on connection

• When you connect the player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections.

• Connect the player directly to your TV. If you connect the player to a VTR, TV/VTR combination, video selector or AV ampliﬁer, the playback picture may be distorted due to copy protection.

Chapter

HDMI INPUT

Depending on the equipment connected to this player, such as a TV or a projector, no sound may be output by the display. In this case, set “Digital Output HDMI” ( page 53) to “PCM”. If sound still is not heard, use analog output.

HDMI cable (not supplied)

Finally connect the supplied power cord to a wall outlet.

To HDMI OUTPUT

Connections

Introduction Connections

Step

Connect the player to your TV.

Via HDMI input

HDMI stands for High Deﬁnition Multimedia Interface. HDMI transfers digital audio and uncompressed digital video on a single cable. As a result, audio cables and video cables don’t need to be connected separately to a device.

Playback

(Basic)

(Advanced)

Playback

connection

Internet

This player supports simultaneous output of video on its HDMI and component video ports. However, some discs may restrict output of video on the component video ports when viewing high deﬁ nition content or up-converted DVD content. The resolution on the HDMI output will be the same as the resolution output on the component video output. Thus, because the HDMI output can change automatically to match the maximum available resolution of your display, if you connect both the HDMI output and component output, the resolution on the component output will change if the HDMI output Auto-adjusts.

Notes

• Refer to the owner’s manual for the TV to be connected to this player for more information concerning HDMI connections.

• When the HDMI connection is not veriﬁed, an error message appears on the front panel display. In this case, disconnect the HDMI cable then connect it again, or turn off the connected HDMI device then turn it on.

• HDMI output is digital only, DVI analog is not supported.

• HDMI is an evolving technology, so it is possible that some devices may not operate properly with this player.

• To get the most possible beneﬁ t from Dolby Digital Plus, you should connect your HD DVD player to your AV receiver using either its HDMI audio capable input. If your AV receiver has this type of input(s), make sure one of them is connected to your HD DVD player and that the input is set to use audio from HDMI (and not the SPDIF coaxial or optical input). If your AV receiver does not have an HDMI input, but it can decode DTS, then the next best choice is to use the SPDIF (coaxial or optical) input on your AV receiver. While this connection does not have enough bandwidth to transport the full, high-quality Dolby Digital Plus signal, it will support DTS – the highest bandwidth commonly available encoding method that does work over SPDIF. If your receiver does not support DTS, you may be able to obtain a two channel digital by setting the player to output PCM. If your receiver does not have either HDMI or an optical digital input, use the two channel analog outputs.

• If you use the SPDIF optical output or analog outputs to connect your audio system and have the “Digital Output HDMI” ( page 53) set to “Auto” or “PCM”, the audio output level from these jacks will be reduced when listening to a multi-channel disc. To restore the audio output level, set “Digital Output HDMI” to “Downmixed PCM”.

HDMI, the HDMI logo and High-Deﬁnition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

After completing the connection, proceed to page 23 to make the setting.

Others

Chapter

Connections

Connecting to an TV

(Continued)

Via component video input

Composite video cables (not supplied)

To COMPONENT OUTPUT

To use the optical digital output, use an optical cable to connect this jack to an optical audio input on a device capable of processing a DTS bitstream or PCM audio.

To use the analog sound output, connect these jacks to audio input jacks on your TV using the audio cable. For digital sound output, see “Connecting to an audio system” ( page 24).

Finally connect the supplied power cord to a wall outlet.

After completing the connection, proceed to page 23 to make the setting.

Via S-VIDEO or VIDEO (yellow) input

To use the analog sound output, connect these jacks to audio input jacks on your TV using the audio cable. For digital sound output, see “Connecting to an audio system” ( page 24).

Connect either.

To VIDEO

To S-VIDEO

S-VIDEO cable (not supplied)

Finally connect the supplied power cord to a wall outlet.

Audio/video cable (supplied)

To use the optical digital output,

use an optical cable to connect this jack to an optical audio input on a device capable of processing a DTS bitstream or PCM audio.

480i/576i output only regardless of the resolution settings or the connections of other output jack.

After completing the connection, proceed to page 23 to make the setting.

+ 50 hidden pages
