BSI(Service Note) TOSHIBA
TOSHIBA TEC CORPORATION
2-4-1, Shibakoen, Minato-ku, TOKYO, 105-8524 JAPAN
BSI No
F98D283
SUBJECT
Correction of Error in Service Manual
MODEL
CATEGORY
Correction of Service Manual
----------
CONTENT
There is an error in the Service Manual (page 66) in the adjustment section.
FC70
FIELD APPLICATION
Others
FACTORY APPLICATION
Date
UNIT
Documents
98/05/13
----
PC drum charge corona wire installation position
Hook the end onto the cutout.
Fit the wire into the cu
tout
BSI No. F98D283 Page 2
Front
Fit the wire into the shaded area
PC drum charge corona wire installation position
Fit the wire into the cu
Front
tout
Rear
Rear
WRITING ERROR
Hook the end onto the cutout.
Fit the wire into the shaded area
CORRECTION
Supplementary explanation:
Set the wire in the corner of the cutout as shown in the corrected illustration. To make sure that the
wire contacts the corner naturally, set the wire cutout and then the setting can be effected as shown
in Fig. 1 easily.
