Toshiba DYNABOOK QOSMIO F40 Schematics

http://laptopblue.vnhttp://laptopblue.vn

Honolulu

DATE CHANGE NO. REV

Pre-MP BUILD

2007 0413

DRAWER
DESIGN
CHECK
RESPONSIBLE

SIZE = 3

http://hobi-elektronika.net

FILE NAME : XXXX-XXXXXX-XX

P/N XXXXXXXXXXXX

VER :

DATEDATEEE POWER

INVENTEC

TITLE

HONOLULU

SIZE CODE DOC. NUMBER REV

A3

CS

SHEET OF

Model_No A02

781

http://laptopblue.vnhttp://laptopblue.vn

TABLE OF CONTENTS

PAGE

1.COVER PAGE

2.INDEX

3.BLOCK DIAGRAM

4.POWER SEQUENCE BLOCK
5-12.SYSTEM POWER

13.CLOCK GENERATOR

14.CPU Merom1

15.CPU Merom2

16.CPU Merom3

17.CPU Merom4

18.FAN & THERMAL CONTROLLER

19.N/B Crestline 1

20.N/B Crestline 2

21.N/B Crestline 2.1

22.N/B Crestline 3

23.N/B Crestline 4

24.N/B Crescline 5

25.N/B Crestline 6

26.N/B Crestline 7

27.DDR2 DIMM0

28.DDR2 DIMM1

29.DDR DAMPING

30.MXM(GM NA)

31.CRT CONN

PAGE

32.S-VIDEO CONN

33.LCM CONN

34. HDMI TRANSMITTER-1

35. HDMI TRANSMITTER-2

36.S/B ICH8 1

37.S/B ICH8 2

38.S/B ICH8 3

39.S/B ICH8 4

40.S/B ICH8 5

41.CARDBUS CONTROLLER

42.PCMCIA CONN

43.5 IN 1 CARD SLOT

44.1394 CONTROLLER

45.EXPRESS CARD CONN

46.TV TUNNER-MASTER

47.TV TUNNER-SLAVE

48.BCAS CARD-1

49.BCAS CARD-2

50.LAN CONTROLLER

51.LAN POWER

52.RJ45 & TRANSFORMER

53.ROBSON & WLAN

54.SATA HDD1 & SATA HDD2 CONN

PAGE

55.FILICA & CAMERA CONN

56.ODD CONN

57.USB CONN

58.BLUE TOOTH CONN

59.MINI CARD

60.KBC

61.IR BLASTER

62.K/B CONN

63.HDMI CONN

64.AZALIA CODEC

65.AUDIO AMP & H/LPF

66.MDC 1.5 CONN

67.PW SWITCH

68.DB CONN

69.SCREW

70.EMI

71.FINGER PRINTER

72.TOUCH PAD

73.HOT KEY BOARD

74.5 WAY+BACK

75.AUDIO BOARD

76.LED & CIR BOARD

77.VOL_VR BOARD

78.CONFIGURATION

http://hobi-elektronika.net

CHANGE by

CHANGE by

TIGER 13-Apr-2007TIGER

INVENTEC

INVENTEC

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

SIZE

CODE

DOC. NUMBERCODESIZE

A3

A3

13-Apr-2007TIGER

A3

DOC. NUMBER

Model_No A02

CS

CS

CS

SHEET

SHEET

278

278

REV

REV

A02Model_No

A02Model_No

OF

OF

782

HDMI CONN

HDMI_GM

SDVO

HDMI Transmitter

SIL1392

http://laptopblue.vnhttp://laptopblue.vn

HDMI_PM

Merom

(uFCPGA)

SLG8SP510

Clock generator

CONN

CONN

USB0

USB1

CONN

USB2

BATTERY

System Charger &

DC/DC System power

(IMVP-6

VR)

S-video_GM

LCM_GM

CRT_GM

CONN

USB3

S-video

LCM
CRT

HDD
HDD

ODD

USB4

Express Card

S-video_PM

USB6

USB5

Mini CARD

MDC / Modem

Module 56K

RJ11

HP JACK+SPDIF

LCM_PM

CRT_PM

SATA_0

SATA_1

Primary_IDE

USB7

Bluetooth

MXM

CAMERA

MIC

JACK

LINE-IN

PCIEX16

USB8

USB9

FINGER PRINT

3.3V, AZALIA

Realtek

ALC888/S

FILICA

FSB, 667/800 MHz

Crestline

1299 PCBGA

DMI x4

ICH8-M

676 BGA

3.3V, LPC_Interface,33MHz

WINBOND

W8769L

BIOS

SPI EEROM

1.8V, DDR2 Interface, 533/667 MHz

1.8V, DDR2 Interface, 533/667 MHz

PCI_EXPRESS

REALTEK

10/100 8101E

RJ45

MINI CARD

Wireless LAN

ANT

IR_Blaster
IR_Blaster

L-CIR

CIR

KB/TP

DDR2_SODIMM0

3.3V, PCI_Interface,33MHz

NEWCARD

ANT

DDR2_SODIMM1

BCAS Card

MINI PCI

MINI CARD

ROBSON

Cardbus

SLOT A

MINI PCI

MINI CARD

CARD BUS & 1394

TI 8412

CO-LAYOUT

Card reader

CONN

TI 8402

1394

CONN

SPEAKER

AMP

HPF

LPF

AMP

Subwoofer

http://hobi-elektronika.net

CHANGE by

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

SIZE

A3

CODE

CS

SHEET

DOC. NUMBER

378

REV

A02Model_No

OF

http://laptopblue.vnhttp://laptopblue.vn

+VADPTR

SCL

SDA

ACOK

+VPACK

+VBAT

ENBL1
ENBL2

EN_PSV

EN_PSV

VO2

VO1

+V3LA

+V5A

+V1.8

VO

+V3A

+V5S

+V1.5S

+V3S

+V0.9S

+V1.8S

+V1.25S

VO

+VCCP

+VGFX_CORE

http://hobi-elektronika.net

CHANGE by

+VCC_CORE

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

SIZE

A3

DOC. NUMBER

CODE

Model_No A02

CS

SHEET

REV

OF

784

CN803

1

1

2

2

3

3

4

4

5

5

6

6

ACES_87343_064N_6P

http://laptopblue.vnhttp://laptopblue.vn

+VADPTR

FUSE1

12

LITTLEFUSE_R451012_12A_65V

C177

1
2

10pF_50v

5-

1
2

C176

0.1uF_25v

+VADPTR

5-

NFM60R30T222

NFM60R30T222

L21

12

L19

12

D11

ROHM_RLZ24 2

34

34

DTA143EKA

2

1

+VBATA

5-

+VBAT +VPACK

Q36
1
2

G2

8

G1

3

12

1
2

D2

S2_D1

AO4916

1uF_25v

C504

56pF_50v

5-,6-,7-,8-,9-,10-,11-,30-,70-

C528

68uF_25v

5
6

1

7

R449

4

S1

OPEN

2

C496

OPEN12

1

R454

10K_5%

2

C505

1
2

1500pF_50v

C476

0.01uF_50v

1

2

PCMB063T_100MS

L43

12

1
2

C495

1

10uF_25v_K_X5R

2

1
2

Q34

1

S

2
3
4

G

AM4825P_AP

R445

12

0.01_1%_1W

C482

12

0.1uF_25v

NEAR IC

C481

0.1uF_25v

8

D

7
6
5

1
2

Q30

1
2

R413

12

10_5%

D30

30-,60-

AM4825P_AP

1

D

S

2
3

G

5-,6-,7-,8-,9-,10-,11-,30-,70-

2

3

1

1

R456

47K_5%

2

C506

1uF_10v

1

R459

100K_5%

2

+V5LA

8
7
6
54

0.1uF_25v

2.2uF_25v

NEAR IC

1

2

5-,6-,7-,12-,18-,68-

C477

C508

+V5LA

1

1

2
1

2
1

2

R453

100K_5%

C503

1
2

1

2

5-,6-,7-,12-,18-,68-

R432

8.06K_1%

R455

39.2K_1%

60-

BATT_IN

R460

22.6K_1%

2

200K_5%

R425

12

0.01_1%_1W

12

0.1uF_25v

NEAR IC

6-

1

R451

2

1
2

THRM1

C478

0.1uF_25v

C498

1
2

10uF_25v_K_X5R

U30

12

VCC

3

ACN

4

ACP

6

BYPASS#

5

ACDET

11

VREF5

10

AGND

15

TS

1

CHGEN#

14

SCL

13

SDA

25

ALARM#

17

IOUT

TI_BQ24721_QFN_32P

ACDRV#

BATDRV#

PVCC

HIDRV

BTST

REGN

LODRV

PGND
SYNP
SYNN

ISYNSET

C497

1
2

0.1uF_25v

2

23

SYS

24

32

30

29

PH

31

28

27
26
22
21
20

SRP

19

SRN

18

BAT

7

EAO

8

EAI

9

FBO

16
33

TML

C499

1
2

10uF_25v_K_X5R

C501

1

2.2uF_25v

2

NEAR IC

R450

12

10_5%

1

D29

BAT54C_30V_0.2A

1

R431

100K_5%

2

C500

3

1

R457

200K_5%

2

12

2

0.1uF_25v

1

R458

18K_5%

2

C507

1
2

100pF_50v

C502

D9

1

3

2

PDS1040S

C178

15uF_25v

1

R429

1

432K_1%

Q11

3

2

DTC124EK

2

Q9

3

C

B

E

1

B

E

C

C444

0.01uF_50v

1

2

+VBATA +VBAT

5-

R412

12

4.7K_5%

R411

12

4.7K_5%

BAT54S_30V_0.2A

1

R430

30.9K_1%

2

ACPRES

60-

CHG_EN

C494

1

10uF_25v_K_X5R

2

C483

1
2

0.1uF_25v

6-

C484

0.1uF_25v

EC_CLK

EC_DATA

30-,60-

30-,60-

http://hobi-elektronika.net

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

DC &BATTERY CHANGER

CODESIZE DOC. NUMBER

A3

CS

578

REV

A02Model_No

OFSHEET

http://laptopblue.vnhttp://laptopblue.vn

BAT_ID

THRM1

BATT_DATA

BATT_CLK

+VBAT

5-,7-,8-,9-,10-,11-,30-,70-

1
R427

1M_5%

2

1
R428

56.2K_1%

2

1
R426

180K_1%

2

CHENMKO_BAT54_3P

60-

5­18-,60­18-,60-

C479

1

OPEN

2

+V3LA

7-,12-,18-,36-,56-,60-,68-

1

R446

47K_5%

2

12

1

D32

EZJZ0V120JA

2

+VPACK

ES

D1005

1

3

1K_5%R448

1

D33

EZJZ0V120JA

2

U29

3

LTH

2

GND

1

HTH

GMT_G680LT1_SOT23_5P

RESET#

VCC

4
5

5-

LITTLEFUSE_R451015_15A_65V

FUSE4

12

C493

1
2

1000pF_50v

7-,60-

+V5AUXON

1
2

CN819

1

BATT+

2

BATT+

3

ID

4

B-I

5

TS

6

SMD

7

SMC

8

GND

9

GND

SYN_200045MR009G152ZL_9P

1

R447

OPEN

2

+V5LA

5-,7-,12-,18-,68-

C480

1
2

0.1uF_10v

C1500

0.1uF_50v

MP

G1

G

G2

G

G3

G

G4

G

http://hobi-elektronika.net

CHANGE by

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

BATTERY CONN

DOC. NUMBER

CODE REV

SIZE

A3

CS

SHEET

678

A02Model_No

OF

+V5AUXON

THRM_SHUTDWN#

EC_PW_ON

SLP_S3#_3R

R1148

12

6-,60-

10K_5%

18-,30-,60-

3

CHENMKO_BAT54_3P

R1151

60-

12

10K_5%

8-,9-,11-,12-,30-,37-,42-,60-,64-

+VBAT

5-,6-,7-,8-,9-,10-,11-,30-,70-

2

R1150

100K_5%

1

D833
1

R1145

0_5%

12

TPS51020

R1140

12

10K_1%

C1094

0.01uF_16v

1

2

C1099

12

C1100

0.01uF_16v

2

1

R1149

12

1M_5%

R1146

2

1

10K_1%

2

R1143

50K_1%

1

CS

http://laptopblue.vnhttp://laptopblue.vn

POWERPAD_2_0610

Q825

1

D1

2

S1_D2

G1

8

3

G2

S2

FDS6900AS

+VBAT

5-,6-,7-,8-,9-,10-,11-,30-,70-

PAD10

POWERPAD_2_0610

C468

1
2

4.7uF_25v

CYNTEC_PCMC063_4R7

PAD804

5
6
7

4

L42

12

CYNTEC_PCMC063_4R7

1

R1138

29.4K_1%

2

C1095

12

0.033uF_16v

0.1uF_16v

12

C1098

3900pF_16v

R1141

2.7K_5%

R1147

2

1.8K_5%

1

R1144

220_5%

2

1
2

1

C1093

4700pF_50v

2

1

R1139

330_5%

2

12

1

C1097

6800pF_25v

U28

1

INV1

2

COMP1

3

SSTRT1

4

SKIP#

5

VO1_VDDQ

6

DDR#

7

GND

8

REF_X

9

ENBL1

10

ENBL2

11

VO2

12

PGOOD

13

SSTRT2

14

COMP2

15

INV2

TI_TPS51020DBT_TSSOP_30P

VBST1

OUT1_U

OUT1_D

OUTGND1

TRIP1

TRIP2

VREG5

REG5_IN

OUTGND2

OUT2_D

OUT2_U

VBST2

30
29
28

LL1

27
26
25
24

VIN

23
22
21
20
19
18

LL2

17
16

R1142

12

4.7_5%

1
2

C1096

4.7uF_25v

R442

20K_5%

12

R444

12

2.2_5%

C1092

1
2

2.2uF_25v

R443

18K_5%

12

C489

12

0.1uF_25v

C467

R423

12

2.2_5%

0.1uF_25v

12

C1088

1
2

10uF_25v_K_X5R

+V5LA

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

765

8

D

Q31

G

FDS8884

S

4

123

8765

D

Q32

G

FDS6690AS

S

23

41

C1087

1
2

4.7uF_25v

5-,6-,7-,12-,18-,68-

C488

1

1uF_6.3v

2

+V5A

C469

1
2

10uF_25v_K_X5R

+VBAT

5-,6-,7-,8-,9-,10-,11-,30-,70-

L38

12

1

C490

2

330uF_6.3v

1
2

1

C435

2

330uF_6.3v

C491

1uF_10v

PAD9

1

POWERPAD_2_0610

C436

1
2

1uF_10v

PAD11

POWERPAD_2_0610

+V3LA

2

+V5A

6-,7-,12-,18-,36-,56-,60-,68-

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

+V5LA

5-,6-,7-,12-,18-,68-

1

2

R368

10K_5%

2N7002W

2N7002W

+V3LA

6-,7-,12-,18-,36-,56-,60-,68-

Q24

4

D

C375

0.1uF_10v

S

AO6409

G

CHENMKO_BAT54_3P D28

2

S

G

1

D

3

Q25
Q23

3

D

1

G

S

2

13

R367

12

100K_5%

1
2

http://hobi-elektronika.net

+V3A

37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

1
2
5
63

1

R362

200_5%

2

INVENTEC

TITLE

HONOLULU

SYSTEM POWER(3V/5V)

DOC. NUMBER

CODE

CHANGE by OF

TIGER 13-Apr-2007

A3

Model_No A02

CS

SHEET

REVSIZE

787

SLP_S5#_3R

8-,12-,37-,60-

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

R390

12

0_5%

C416

1
2

OPEN

C418

1uF_6.3v

+V5A

1

2

R393

10_5%

1
2

http://laptopblue.vnhttp://laptopblue.vn

15

14

16

17

U27

1

VOUT

2

VCCA

3

FB ILIM

4

PGD

TML-PAD

NC

5

NC

TON

EN_PSV

VSSA

PGND

6

7

R388

2.2_5%

12

11

10

9

C356

1
2

1uF_6.3v

+V5A

1

3

D26

R389

12

0_5%

R329

12

33.2K_1%

C414

0.1uF_25v

12

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

BAT54_30V_0.2A

12

13

BST

DH

LX

VDDP

DL

8

SEMTECH_SC411MLTRT_MLPQ_16P

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

+V5A

909K_1%

C417

1
2

1000pF_50v

R391

12

5

76

8

D

G

S

123

4

8765

D

G

S

23

41

Q29

FDS6690AS

Q28

FDS8884

1

R325

OPEN

2

C355

1

OPEN

2

+VBAT

5-,6-,7-,9-,10-,11-,30-,70-

PAD8

POWERPAD_2_0610

C4131

2

10uF_25v_K_X5R

C415

1
2

4.7uF_25v

L35

12

MPLC0730_4R7

R345

10K_1%

1

R392

1

OPEN

26.1K_1%

C361

2

2

1

2

C412

220uF_2v_15mR_Panasonic

8-,12-,19-,24-,25-,27-,28-,70-

+V1.8

PAD7

POWERPAD_2_0610

1

2

1

10uF_6.3v

2

C352

9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

+V5S

C237

1

1uF_6.3v

2

1

R202

SLP_S3#_3R

OPEN

R203

10K_5%

7-,8-,9-,11-,12-,30-,37-,42-,60-,64-

2

1

2

U10

6

VCNTL

7

POK

8

EN

VIN

GND

9

1

C238

1
2

OPEN

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

C224

1
2

22uF_6.3v

5

VOUT
VOUT

VIN

3
4

2

FB

1
2

39pF_50v

ANPEC_APL5913_KAC_TRL_SOP_8P

C221

SLP_S3_5R

1

R199

9.1K_1%

2

1

R200

10K_1%

2

9-,12-

C222

1
2

22uF_6.3v

+V1.5S

16-,25-,36-,37-,39-,45-,53-,59-

PAD3

POWERPAD_2_0610

C223

1

1uF_6.3v

2

2N7002W

1

R198

200_5%

2

Q14

3

D

1

G

S

2

SLP_S5#_3R
SLP_S3#_3R

M_VREF

http://hobi-elektronika.net

8-,12-,37-,60-

7-,8-,9-,11-,12-,30-,37-,42-,60-,64-

19-,27-,28-

1
2

C283

0.1uF_10v

+V5A

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

U15

TML11VDDQSNS

10 2

VIN

VLDOIN

9

S5
GND8PGND

7

S3

VTTSNS

6

VTTREF

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

1

3

VTT

4
5

GMT_G2997F6U_MSOP10_10P

C305

1
2

1uF_10v

CHANGE by SHEET

TIGER 13-Apr-2007

C306

1

22uF_6.3v

2

1
2

PAD6

POWERPAD_2_0610

C284

22uF_6.3v

INVENTEC

TITLE

HONOLULU

SYSTEM POWER (+V1.8/+V1.5S/+V0.9S)

SIZE

A3

CS

+V0.9S

29-,70-

DOC. NUMBER REVCODE

Model_No A02

OF

788

+V5A

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

R824

12

SLP_S3#_5R

12-,64-

0_5%

C811

0.1uF_10v_OPEN

8-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1

R830

1

10_5%

2

2

C814

1
2

1uF_6.3v

+V3S

+V5S

10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

http://laptopblue.vnhttp://laptopblue.vn

+VBAT

5-,6-,7-,8-,10-,11-,30-,70-

R825

2.2_5%

12

11

9

C813

1
2

+V5A

D809

1uF_6.3v

1

3

C809

0.1uF_25v

12

R829

12

19.1K_1%

12

909K_1%

C810

1
2

1000pF_50v

+V5A

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

R826

8

765

D

G

S

123

4

8765

D

G

S

23

41

Q801

FDS6690AS

Q800

FDS8884

1

R800

OPEN

2

C802

1
2

OPEN

PAD800

POWERPAD_2_0610

1

C801

2

10uF_25v_K_X5R

MPLC0730_3R3_5.7A

C800

1
2

4.7uF_25v

L6

12

R827

15K_1%

R828

10K_1%

+V1.25S

9-,19-,25-,39-

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

BAT54_30V_0.2A

12

17

U800

1

VOUT

2

VCCA

310

FB

4

PGD

5

13

16

15

14

NC

BST

TON

TML-PAD

NC

DH

EN_PSV

LX

ILIM

VDDP

VSSA

DL

PGND

8

6

7

SEMTECH_SC411MLTRT_MLPQ_16P

1

1

OPEN

C812

2

2

1

220uF_2v_15mR_Panasonic

2

+V1.25S

9-,19-,25-,39-

PAD1

POWERPAD_2_0610

1

C1

2

1

10uF_6.3v

2

C13

SLP_S3#_3R

R802

10K_5%

R801

1

7-,8-,11-,12-,30-,37-,42-,60-,64-

0_5%

1

C803

1

1uF_6.3v

2

2

6

U801

VCNTL

7

POK

2

8

EN FB

VIN
9

5

VIN

3

VOUT

4

VOUT

2

GND
1

ANPEC_APL5912_KAC_TRL_SOP_8P

11-,30-

VCCP_PG

C818

1
2

22uF_6.3v

1
2

39pF_50v

C815

SLP_S3_5R

1

R832

3.3K_1%

2

1

R831

10K_1%

2

8-,12-

C817

1
2

22uF_6.3v

PAD801

POWERPAD_2_0610

C816

1

1uF_6.3v

2

2N7002W

+VCCP

13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

1

R833

200_5%

2

Q804

3

D

1

G

S

2

INVENTEC

TITLE

HONOLULU

SYSTEM POWER (+V1.25S/+VCCP)

http://hobi-elektronika.net

SIZE CODE

CHANGE by SHEET OF

TIGER 13-Apr-2007

A3

DOC. NUMBER REV

Model_No A02

CS

789

http://laptopblue.vnhttp://laptopblue.vn

1
2

ADP3209AGND

+VBAT

C861

1

220pF_25v

2

19-

19-

19-

19-

1

1K_5%

R931

VGFX_PG

DFGT_VID_3

DFGT_VID_2

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R909

22K_5%

2

R907

DFGT_VR_EN

19-

12

OPEN

C860

470pF_50v

1
2

C1002

OPEN

1

R908

100K_5%

2

12

12

R900

1K_1%

12

470pF_50v

C864

R903

20K_1%

12

2

R904

33.2K_1%

1

C863

1
2

22pF_50v

DFGT_VID_1

DFGT_VID_0

C862

0.012uF_16v

5-,6-,7-,8-,9-,10-,11-,30-,70-

100pF_50v

R957

12

0_5%

ADP3209AGND

1

R902

76.8K_1%

2

2

C902

ADP3209AGND

1
2

R937

12

22K_5%

R941

12

22K_5%

R940

12

22K_5%

R938

2

1

22K_5%

R939

12

22K_5%

30

31

29

EN

VID028VID1

PGDLY

PWRGD

1

FBRTN

2

FB

3

COMP

4

SS

5

ST

6

PMON

7

PMONFS

8

CLIM

CSREF12CSSLIM

LLINE

CSCOMP

932

10

11

R933

12

180K_1%

1

1000pF_50v

2

+V3S

U803

26

25

VID227VID3

VID4

24

VCC

23

BST

22

DRVH

21

SW

20

PVCC

19

DRVL

18

PGND

17

GND

33

TML

RAMP

RPM

RT

VRPM

ADI_ADP3209_LFCSP_32P

13

15

16

14

12

383K_1%

1

R934

412K_1%

2

C904

1000pF_50v

C905

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V5S

8-,9-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

R936

12

10_5%

C907

1
2

1uF_6.3v

POWERPAD_2_0610

C944

1
2

10uF_25v_K_X5R

L814

12

PCMC063T_2R2MN

1

R930

95.3K_1%

2

R932

1

ADP3209AGND

R935

12

2.2_5%

2

ADP3209AGND

0.1uF_25v

C903

1
2

0.0015uF_50v

C943

1

3

2

2

1

D814

BAT54C_30V_0.2A

1
2

C906

1uF_6.3v

765

G

3

4

765

G

4

R901

12

76.8K_1%

8

D

Q815

FDS8884

S

12

8

D

S

123

Q814

FDS6690AS

1

2

1
2

R998

OPEN

C974

OPEN

C945

1
2

4.7uF_25v

PAD803

220uF_2v_15mR_Panasonic

+VBAT

5-,6-,7-,8-,9-,10-,11-,30-,70-

1

C941

2

C942

1
2

10uF_6.3v

+VGFX_CORE

PAD802

POWERPAD_2_0610

R899

100_5%

12

24-

C865

1
2

1000pF_50v

ADP3209AGND

http://hobi-elektronika.net

12

R905

100_5%

INVENTEC

TITLE

HONOLULU

SYSTEM POWER (+VGFX_CORE)

SIZE CODEESDOC. NUMBER REV

A3

CHANGE by SHEET OF

13-Apr-2007TIGER

CS

10 78

A02Model_No

http://laptopblue.vnhttp://laptopblue.vn

VR_PWRGD

IMVP_CKEN#

C171

1
2

1000pF_50v

VCOREGND

+V3S

SLP_S3#_3R

VCCP_PG

7-,8-,9-,11-,12-,30-,37-,42-,60-,64-

9-,30-

H_VID6
H_VID5
H_VID4
H_VID3
H_VID2
H_VID1

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

H_VID0

PSI#

H_DPRSTP#

PM_DPRSLPVR

1

CHENMKO_BAT54_3P

R142

10K_5%

1

R140

10K_5%

2

2

VCORE_EN

11-,18-,37-

12

C120

330pF_50v

12

R144

1.65K_1%

R145

432K_1%

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

R108

12

0_5%

R109

12

0_5%

R120

12

0_5%

C175

220pF_25v

2

1

1

2

2

VCOREGND

CSREF

11-,60-

1

R139

12

61.9K_1%

C173

0.012uF_16v

11-

16-

VCCSENSE

16-

VSSSENSE

R1085

12

604K_1%

ES

16­16­16­16­16­16­16-

15-

15-,19-,36-

19-,37-

VCOREGND

R141

12

0_5%

4700pF_25v

1

C174

18pF_50v

2

1

C118

2

680pF_50v

R119

12

100K_5%

1

R118

OPEN

1

2

2

VCOREGND

C172

1

R117

OPEN

2

C119

D820
13

OPEN

C1051

1
2

0.22uF_6.3v

12

C117

1000pF_50v

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

5

U815

2

4

PHP_74LVC1G17_SOT753_5P

3

48

47

49

TML

1

EN

DPRSLP

2

PWRGD

3

PGDELAY

4

CLKEN

5

FBRTN

6

FB

7

COMP

U4

8

SS

ADI_ADP3208_LFCSP_48P

9

ST

10

VARFREQ

11

VRTT

12

TTSEN

PMON

13

14

R143

115K_1%

1

R116

OPEN

VCOREGND

2

1
2

VCOREGND

DPRSTP

PMONFS

1

R1065

10K_5%

2

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

46

45

44

43

41

40

39

PSI

VID0

VID1

VID242VID3

VID4

VID5

VID6

LLINE

RPM23RT SP

RAMP

CLIM

CSCOMP

CSFEF18CSSUM

VRPM

22

20

19

15

17

16

21

2

R111

80.6K_1%

1

2

1

R113

274K_1%

1

2

1
2

1000pF_50v

VCOREGND

1

C115

1000pF_50v

2

11-,60-

38

37

VCC

BST1

DRVH1

SW1
PVCC1
DRVL1
PGND1
PGND2
DRVL2
PVCC2

SW2
DRVH2

BST2

GND

24

R110

237K_1%

12

12

C113

1000pF_50v

R112

12

10K_5%

C114

1
2

VCORE_EN

C205

1

2.2uF_6.3v

2

VCOREGND

36
35
34
33
32
31
30
29
28
27
26
25

VCOREGND

R168

12

105K_1%

R136

2

1

105K_1%

12

115K_1%

C116

1000pF_50v

+V5S

R171

12

10_5%

D10

BAT54A_30V_0.2A

3

2

1

R169

12

2.2_5%

R137

12

2.2_5%

+VBAT_CPU

C202

12

0.1uF_25v

C206

1

2.2uF_6.3v

2

C170
12

0.1uF_25v

11-

R114

R115

1

R135

220K_5%

2

NTC NEAR CHOCK

2

76.8K_1%

1

http://hobi-elektronika.net

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

12

C1030

0.1uF_16v

U812

4

PHP_74LVC1G17_SOT753_5P

+VBAT

5-,6-,7-,8-,9-,10-,30-,70-

1

L25

4

NFM60R30T222

3

2

SLP_S3#_3R

7-,8-,9-,11-,12-,30-,37-,42-,60-,64-

VR_PWRGD

11-,18-,37-

+VBAT_CPU

11-

CHENMKO_BAT54_3P

D819

13

R1033

12

604K_1%

1

ES

2

C1006

0.22uF_10v

5

2

3

10uF_25v_K_X5R

+V3S

C201

C111

1
2

1

2

2

0.01uF_50v

C204

1

89

567

Q10

SI7686DP_T1_E3

4G321

R170 2.2_5%

12

MP

G

4S1

23

Q12

FDS6676AS

Q13

8765

D

FDS6676AS

765

8

D

G

41S23

R984

OPEN

C959

OPEN

1

1

2

D815

2

1
2

SSM34_3A40V_OPEN

1

MPC1040LR36

CSREF

10uF_25v_K_X5R

C203

1
2

C110

1
2

2.2_5%R138

12

MP

C112

1
2

0.01uF_50v

6

5

G

4

Q6

FDS6676AS

56789

G

Q5

SI7686DP_T1_E3

4321

Q4

8

7

D

S

123

FDS6676AS

8D765

G

S

4

123

R863

OPEN

C827

OPEN

1

1

2

D813

2

1
2

SSM34_3A40V_OPEN

TITLE

SIZE CODE DOC. NUMBER REV

CHANGE by SHEET OF

13-Apr-2007TIGER

A3

19-,37-

PM_PWROK

+VCC_CORE

L811

2

2
R925

10_1%

1

11-

2
R926

10_1%

1

L807

1

2

MPC1040LR36

INVENTEC

HONOLULU

SYSTEM POWER (+VCC_CORE)

CS

11 78

16-

A02Model_No

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

+V5S

1

R1086

200_5%

2

SLP_S3#_5R

CHENMKO_BAT54_3P

9-,12-,64-

5-,6-,7-,12-,18-,68-

1

3

D821

+V5LA +V5LA

66-,68-

C324

47uF_4v

CHENMKO_BAT54_3P

SLP_S5#_5R

5-,6-,7-,12-,18-,68-

74ACT14MTC

ES

http://laptopblue.vnhttp://laptopblue.vn

+V3S

+V3

U817-A

1

2

200_5%

2

R303

D22

5-,6-,7-,12-,18-,68-

+V5LA

Q19

1

S

D

2
5
63

G

AO6409

1

CHENMKO_BAT54_3P

1

3

2

3

1

+V5LA

1

2

U817-B

74ACT14MTC

ES

14

1

7

ES

5-,6-,7-,12-,18-,68-

4

C323

680pF_50v

D21

ES

14

34

7

+V3LA

6-,7-,18-,36-,56-,60-,68-

1

R363

220K_5%

2

ES

7-,8-,9-,11-,30-,37-,42-,60-,64-

SLP_S3#_3R

4

S

3

AO6409

4

S

AO6409

5-,6-,7-,12-,18-,68-

Q20

G

Q21

G

1

D

2
5
6

1

D

2
5
63

C325

1
2

680pF_50v

+V5LA

14

U817-D

98

74ACT14MTC

7

SLP_S5_3R

9-,10-,11-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

8-,19-,24-,25-,27-,28-,70-

2

R304

1

2

C326

47uF_4v

1

3

D

S

2

200_5%

G

1

Q22

2N7002W

SLP_S3#_5R

+V1.8 +V1.8S

Q809

1

8

S

D

2

7

3

6
54

G

AO4406

R873

12

9-,12-,64-

220K_5%

+V5A +V5S_TV

7-,8-,9-,39-,57-,60-,64-,65-,68-

D23

R301

220K_5%

R302

220K_5%

2

2

3

1

1

2

1

R275

200_5%

2

C322

1

0.01uF_16v

2

1

BAT54A_30V_0.2A

4

S

4

S

3

4

S

C492

1

680pF_50v

AO6409

AO6409

AO6409

2

30-,35-

C844

12

680pF_50v

Q55

1

D

2
5
63

G

2N7002W

46-,47-

Q810
1

1

R874

200_5%

2

3

D

G

S

2

MP

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

Q33

1

D

2
5
6

G

Q35

1

D

2
5
63

G

8-,9-

SLP_S3_5R

U817-F

74ACT14MTC

14

1312

74ACT14MTC

7

U817-E

14

1110

7

C1052

12

0.1uF_10v

U817-C

6

74ACT14MTC

14

5

8-,37-,60-

SLP_S5#_3R

7

INVENTEC

TITLE

HONOLULU

POWER(SLEEP)

http://hobi-elektronika.net

CHANGE by

TIGER 13-Apr-2007

SIZE

DOC. NUMBER

CODE

A3

Model_No A02

CS

SHEET

REV

OF

7812

http://laptopblue.vnhttp://laptopblue.vn

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

ICH_NEWCARD_CLKEN

+VCCP

45-

2N7002W

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

MP

CPU_BSEL1

FSA

15-,19-

37-

1K_5%

R1092

FSB

1

1

1

0

FSC

R1093

2

1

FSB CLOCK
FREQUENCY

0
0

CPU_BSEL2

CLK_R3S_ICH14

*CLKREQ# pin controls SRC Table.

Byte5: bit6 =0(PWD)

SRC0

CR#_A

Byte5: bit7=0, disable CR#_A; 1,enable CR#_A

Byte5: bit2 =0(PWD)

SRC0

CR#_C

Byte5: bit3=0, disable CR#_C; 1,enable CR#_C

L815

BLM11A121S

1

Q818

D

1

G

S

MP

12

667
800

Layout note: All decoupling 0.1uF disperse closed to pin

2

C1032

1

10uF_10v

2

13-

3

2

CLKREQ_R_NEWCARD#

WS

C260

1

11

0.1uF_16v

0.1uF_16v

2

2

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

CPU_BSEL0

+VCCP

15-,19-

12

R1790

33_5%

CLK_PWRGD

HOST CLOCK
FREQUENCY

2

1

10K_5%

37-

1K_5%

R1091

X33TU2-P3P

WS

X33TU1-P3P

X33TU3-P3P
CLK_R3S_KBPCI
CLK_R3S_CBPCI

X33TU4-P3P

12

R1090

CLK_R3S_CARD48

CLK_R3S_ICH48

0_5%

C1060

33pF_50v

Please place close to CLKGEN within 500mils

166
200

Byte5: bit6 =1

SRC2

Byte5: bit2 =1

SRC2

CR#_B

CR#_D

Byte5: bit4 =0(PWD)

SRC1

Byte5: bit5=0, disable CR#_B; 1,enable CR#_B

Byte5: bit0 =0(PWD)

SRC1

Byte5: bit1=0, disable CR#_D; 1,enable CR#_D

C1057

46­46­47­60­41­47-

15-,19-

WS

R1046

1K_5%

1

0.1uF_16v

2

1
2

C262

+VCCP

14.31818MHZ

C1056

0.1uF_16v

2

1

2

R1047

12

2.2K_5%

R1048

41-

R1049 22_1%

R1054
R1050

ICH_3S_SMCLK

ICH_3S_SMDATA

X803

12

1

30PPM

2

C263

1

0.1uF_16v

2

12

22_1%

1

2

12

22_5%R1057

12

R1058 22_5%

12

22_5%R1055

12

33_5%

12

33_5%

1

2

R1056 22_5%

R1053

1

OPEN

27-,28-,37­27-,28-,37-

C1059

33pF_50v

Byte5: bit4 =1

SRC4

Byte5: bit0 =1

SRC4

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

Layout note: All decoupling 0.1uF disperse closed to pin

C297

1

0.1uF_16v

2

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V3S

2

10K_5%

R1076

1

2

L817

BLM11A121S

1

CLK_3S_ICH48

CPU_BSEL2_D

CLK_3S_TV1PCI

CLK_3S_TV2PCI
CLK_3S_KBPCI
CLK_3S_CBPCI

2

U813

26

VDDSRC_IO

45

VDDSRC_IO

36

VDDSRC_IO

12

VDD96_IO

39

VDDSRC_IO

61

VDDREF

20

VDDPLL3_IO

49

VDDCPU_IO

9

VDD48

2

VDDPCI

55

VDDCPU

16

VDD

10

SUB_48MHZ_FSLA

57

FSLB_TEST_MODE

62

REF0_FSLC_TEST_SEL

1

PCI0_CR#_A

3

PCI1_CR#_B

4

PCI2_TME

5

PCI3

56

CK_PWRGD_PD#

64

SCLK

63

SDTAT

60

X1

59

X2

8

GNDPCI

11

GND48

15

GND

19

GND

23

GNDSRC

29

GNDSRC

42

GNDSRC

58

GNDREF

52

GNDCPU

ICS_ICS9LPRS365_TSSOP_64P

C1033

1
2

10uF_10v

27MHz_NonSS_SRCT1_SE1

C296

1
2

0.1uF_16v

PCI_STOP#

CPU_STOP#

CPUT2_ITP_SRCT8

CPUC2_ITP_SRCC8

SRCT11_CR#_H

SRCC11_CR#_G

SRCT7_CR#_F

SRCC7_CR#_E

PCI4_27_Select
PCI_F5_ITP_EN

SRCT3_CR#_C

SRCC3_CR#_D

SRCT2_SATAT

SRCC2_SATAC

27MHz_SS_SRCC1_SE2

SRCC0_DOTT_96
SRCT0_DOTC_96

C1061

1
2

0.1uF_16v

CPUT1_F
CPUC1_F

CPUT0

CPUC0

SRCT10

SRCC10

SRCT9

SRCC9

SRCT6

SRCC6

SRCT4

SRCC4

48

NC

38
37

51
50

54
53

47
46

33
32

34
35

30
31

44
43

41
40

6
7

27
28

24
25

21
22

17
18

13
14

C259

1

1
2

2

0.1uF_16v

CLK_R_MCHBCLK
CLK_R_MCHBCLK#

CLK_R_CPUBCLK
CLK_R_CPUBCLK#

CLK_R_PCIE_MINI1
CLK_R_PCIE_MINI1#

CLK_R_PCIE_CARD
CLK_R_PCIE_CARD#

CLK_R_PCIE_MINI2
CLK_R_PCIE_MINI2#

CLK_R_PCIE_ICH
CLK_R_PCIE_ICH#

CLK_3S_MINICARD2
CLK_3S_ICHPCI

CLK_R_PEG_MCH
CLK_R_PEG_MCH#

CLK_R_SATA1
CLK_R_SATA1#

SSCLK1_DREF
SSCLK1_DREF#

CLK_DREF
CLK_DREF#

ES

C261

0.1uF_16v

MP

Byte6: bit7=0, disable CR#_E; 1,enable CR#_E

CR#_E

SRC6

Byte6: bit6=0, disable CR#_F; 1,enable CR#_F

CR#_F

SRC8

Byte6: bit5=0, disable CR#_G; 1,enable CR#_G

CR#_G

SRC9

Byte6: bit4=0, disable CR#_H; 1,enable CR#_H

CR#_H

http://hobi-elektronika.net

SRC10

1
2

C258

0.1uF_16v

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V3S

C1058

1
2

0.1uF_16v

1

1

R1088

R1089

OPEN

2

2

12

12

R1068 475_1%

1

OPEN

R1067

10K_5%

2

12

R10870_5%

475_1%R1069

12

33_5%

12

33_5%

2

R1040 475_1%_OPEN
R1037

475_1%

2

12

0_5%_OPEN

0_5%

12

0_5%_OPEN

0_5%

12

0_5%

12

0_5%_OPEN

PM:OPEN change to ON

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

R1073

2

1

10K_5%

CHANGE by

R1051

2

OPEN

R1052

10K_5%

+V3S

1

12

13-Apr-2007TIGER

+V3S

WS

1

2

2

R1039

R1066

10K_5%

1

1

2

OPEN

R1075
R1074

1

475_1%

12

R10341

R1042
R10710_5% 12
R107012

R1041

12

R1044
R10450_5%_OPEN

12

R1072

R1043

1:SRC_0/SRC_0#&27M&27MSS
0:DOT_96/DOT_96#&LCDCLK/LCDCLK#

1

R1038

R1036

2

10K_5%

OPEN

37-

PCISTOP#_3

37-

CPUSTOP#_3

22-

CLK_R_MCHBCLK

22-

CLK_R_MCHBCLK#

14-

CLK_R_CPUBCLK

14-

CLK_R_CPUBCLK#

53-

CLK_R_PCIE_MINI1

53-

CLK_R_PCIE_MINI1#

13-

CLKREQ_R_NEWCARD#

59-

CLK_R_PCIE_MINI3

59-

CLK_R_PCIE_MINI3#

53-

CLKREQ_R_MINI2#

45-

CLK_R_PCIE_CARD

45-37-

CLK_R_PCIE_CARD#

53-

CLK_R_PCIE_MINI2

53-

CLK_R_PCIE_MINI2#

50-

CLK_R_PCIE_LAN

50-

CLK_R_PCIE_LAN#

37-

CLK_R_PCIE_ICH

37-

CLK_R_PCIE_ICH#

53-

CLK_R3S_MINICARD2

38-

CLK_R3S_ICHPCI

19-

CLK_R_PEG_MCH

19-

CLK_R_PEG_MCH#

CLKREQ_R_GPU#

37-

CLKREQ_R_SATA#

19-

CLKREQ_R_MCH#

36-

CLK_R_SATA1

36-

CLK_R_SATA1#

30-

27M_NONSS

19-

SSCLK1_R_DREF

19-

SSCLK1_R_DREF#

30-

27M_SS

19-

CLK_R_DREF

30-

CLK_R_PEG_REF

19-

CLK_R_DREF#

30-

1

R1035

10K_5%

2

TITLE

SIZE

A3

CLK_R_PEG_REF#

WS

INVENTEC

HONOLULU

CLOCK_GENERATOR

CODE

DOC. NUMBER

CS

SHEET

13 78

OF

WS

WS

WS

REV

A02Model_No

http://laptopblue.vnhttp://laptopblue.vn

H_A#(35:3)

H_ADSTB#1

H_STPCLK#

H_A20M#
H_FERR#

H_IGNNE#

H_INTR

H_NMI

H_SMI#

22-

H_A#(3)
H_A#(4)
H_A#(5)
H_A#(6)
H_A#(7)
H_A#(8)
H_A#(9)
H_A#(10)
H_A#(11)
H_A#(12)
H_A#(13)
H_A#(14)
H_A#(15)
H_A#(16)

H_REQ#(4:0) H_RS#(0:2)

H_A#(17)
H_A#(18)
H_A#(19)
H_A#(20)
H_A#(21)
H_A#(22)
H_A#(23)
H_A#(24)
H_A#(25)
H_A#(26)
H_A#(27)
H_A#(28)
H_A#(29)
H_A#(30)
H_A#(31)
H_A#(32)
H_A#(33)
H_A#(34)
H_A#(35)

22-

36­36­36-

36­36­36­36-

22-

H_REQ#(0)
H_REQ#(1)
H_REQ#(2)
H_REQ#(3)
H_REQ#(4)

H_ADSTB#0

22-

CN805-1

J4

A3#

L5

A4#

L4

A5#

K5

A6#

M3

A7#

N2

A8#

J1

A9#

N3

A10#

P5

A11#

P2

A12#

L2

A13#

P4

A14#

P1

A15#

R1

A16#

M1

ADSTB0#

K3

REQ0#

H2

REQ1#

K2

REQ2#

J3

REQ3#

L1

REQ4#

Y2

A17#

U5

A18#

R3

A19#

W6

A20#

U4

A21#

Y5

A22#

U1

A23#

R4

A24#

T5

A25#

T3

A26#

W2

A27#

W5

A28#

Y4

A29#

U2

A30#

V4

A31#

W3

A32#

AA4

A33#

AB2

A34#

AA3

A35#

V1

ADSTB1#

A6

A20M#

A5

FERR#

C4

IGNNE#

D5

STPCLK#

C6

LINT0

B4

LINT1

A3

SMI#

M4

RSVD01

N5

RSVD02

T2

RSVD03

V3

RSVD04

B2

RSVD05

C3

RSVD06

D2

RSVD07

D22

RSVD08

D3

RSVD09

F6

RSVD010

FOX_PZ4782K_274M_41_478P

GMCH

CPU ICH8

ADS#
BNR#

BPRI#

DEFER#

DRDY#
DBSY#

BR0#

IERR#

ADDR GROUP 0

INIT#

CONTROL

LOCK#

RESET#

RS0#
RS1#
RS2#

TRDY#

HIT#

HITM#

BPM0#
BPM1#
BPM2#
BPM3#
PRDY#
PREQ#

ADDR GROUP 1

XDP/ITP SIGNALS

TRST#

DBR#

THERMAL

PROCHOT#

THERMDA
THERMDC

THERMTRIP#

ICH

H CLK

BCLK0
BCLK1

RESERVED

H1
E2
G5

H5
F21
E1

F1

D20
B3

H4

C1
F3
F4
G3
G2

G6
E4

AD4
AD3
AD1
AC4
AC2
AC1
AC5

TCK

AA6

TDI

AB3

TDO

AB5

TMS

AB6
C20

R166

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

2

56_5%

D21
A24
B25

C7

A22
A21

1

+VCCP

10mils/10mils

+VCCP

22-

H_ADS#

22-

H_BNR#

22-

H_BPRI#

22-

H_DEFER#

22-

H_DRDY#

22-

H_DBSY#

22-

H_BREQ#0

36-

H_INIT#

22-

H_LOCK#

22-

H_CPURST#

22-

H_TRDY#

22-

H_HIT#

22-

H_HITM#

14-

H_BPM5_PREQ#

14-

H_TCK

14-

TDI_FLEX

14-

H_TMS

37-

XDP_DBRESET#

18-

H_THERMDA

18-

H_THERMDC

18-,19-,36-

PM_THRMTRIP#

13-

CLK_R_CPUBCLK

13-

CLK_R_CPUBCLK#

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

H_RS#(0)
H_RS#(1)
H_RS#(2)

R64

12

54.9_1%

R61

12

150_5%

R62

12

39_5%

R65

12

27_5%

TP37

22-

14-

14-

14-

14-

+VCCP

CLOSED TO CPU

H_BPM5_PREQ#

TDI_FLEX

H_TMS

H_TCK

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

1

R167

56_5%

2

H_TRST#

1

R63

619_1%

2

PM_THRMTRIP# should be T at CPU

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

Merom-1

SIZE

CODE DOC. NUMBER

A3

CHANGE by SHEET OF

13-Apr-2007TIGER

CS

14 78

REV

A02Model_No

http://laptopblue.vnhttp://laptopblue.vn

H_D#(63:0)

H_DSTBN#0
H_DSTBP#0

H_DINV#0

H_D#(63:0)

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

1

R1022

1K_1%

2

1

2

R985

2K_1%

GTLREF

Layout note: Zo=55 ohm,

0.5" max for GTLREF.

15-,22-

22­22­22-

15-,22-

H_DSTBN#1

H_DSTBP#1

H_DINV#1

CPU_BSEL0
CPU_BSEL1
CPU_BSEL2

MP

CN805-2

H_D#(0)
H_D#(1)
H_D#(2)
H_D#(3)
H_D#(4)
H_D#(5)
H_D#(6)
H_D#(7)
H_D#(8)
H_D#(9)
H_D#(10)
H_D#(11)
H_D#(12)
H_D#(13)
H_D#(14)
H_D#(15)

H_D#(16)
H_D#(17)
H_D#(18)
H_D#(19)
H_D#(20)
H_D#(21)
H_D#(22)
H_D#(23)
H_D#(24)
H_D#(25)
H_D#(26)
H_D#(27)
H_D#(28)
H_D#(29)
H_D#(30)
H_D#(31)

22­22-

13-,19­13-,19­13-,19-

1

R953

OPEN

2

1

2

R1023

OPEN

C960

1

OPEN

2

Place C5134 close to the TEST4 pin.
Make sure TEST4 routing is reference
to GND and away from other noisy signals.

E22

D0#

F24

D1#

E26

D2#

G22

D3#

F23

D4#

G25

D5#

E25

D6#

E23

D7#

K24

D8#

G24

DATA GRP 0

D9#

J24

D10#

J23

D11#

H22

D12#

F26

D13#

K22

D14#

H23

D15#

J26

DSTBN0#

H26

DSTBP0#

H25

DINV0#

N22

D16#

K25

D17#

P26

D18#

R23

D19#

L23

D20#

M24

D21#

L22

D22#

M23

D23#

P25

D24#

P23

D25#

P22

DATA GRP 1

D26#

T24

D27#

R24

D28#

L25

D29#

T25

D30#

N25

D31#

L26

DSTBN1#

M26

DSTBP1#

N24

DINV1#

AD26

GTLREF

C23

TEST1

D25

TEST2

C24

TEST3

AF26

MISC

TEST4

AF1

TEST5

A26

TEST6

B22

BSEL0

B23

BSEL1

C21

BSEL2

FOX_PZ4782K_274M_41_478P

D32#
D33#
D34#
D35#
D36#
D37#
D38#
D39#
D40#

DATA GRP 2DATA GRP 3

D41#
D42#
D43#
D44#
D45#
D46#

D47#
DSTBN2#
DSTBP2#

DINV2#

D48#

D49#

D50#

D51#

D52#

D53#

D54#

D55#

D56#

D57#

D58#

D59#

D60#

D61#

D62#

D63#
DSTBN3#
DSTBP3#

DINV3#

COMP0
COMP1
COMP2
COMP3

DPRSTP#

DPSLP#

DPWR#

PWRGOOD

SLP#

PSI#

Y22
AB24
V24
V26
V23
T22
U25
U23
Y25
W22
Y23
W24
W25
AA23
AA24
AB25
Y26
AA26
U22

AE24
AD24
AA21
AB22
AB21
AC26
AD20
AE22
AF23
AC25
AE21
AD21
AC22
AD23
AF22
AC23
AE25
AF24
AC20

R26
U26
AA1
Y1

E5
B5
D24
D6
D7
AE6

1

2

R106

OPEN

1

2

R133

OPEN

H_D#(32)
H_D#(33)
H_D#(34)
H_D#(35)
H_D#(36)
H_D#(37)
H_D#(38)
H_D#(39)
H_D#(40)
H_D#(41)
H_D#(42)
H_D#(43)
H_D#(44)
H_D#(45)
H_D#(46)
H_D#(47)

H_D#(48)
H_D#(49)
H_D#(50)
H_D#(51)
H_D#(52)
H_D#(53)
H_D#(54)
H_D#(55)
H_D#(56)
H_D#(57)
H_D#(58)
H_D#(59)
H_D#(60)
H_D#(61)
H_D#(62)
H_D#(63)

12

R987 27.4_1%

12

R986 54.9_1%

12

27.4_1%R60

12

R59 54.9_1%

11-,19-,36-

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

22­22­22-22-

CLOSED TO CPU

36-

H_DPSLP#

22-

H_DPWR#

36-

H_PWRGD

22-

H_CPUSLP#

11-

PSI#

H_DSTBN#3
H_DSTBP#3
H_DINV#3

H_DPRSTP#

15-,22-

15-,22-

22­22­22-

H_D#(63:0)

H_DSTBN#2
H_DSTBP#2
H_DINV#2

H_D#(63:0)

http://hobi-elektronika.net

CHANGE by

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

Merom-2

CODE

SIZE DOC. NUMBER

A3

Model_No A02

CS

SHEET

OF

REV

7815

http://laptopblue.vnhttp://laptopblue.vn

1

C168

2

330uF_2v_6mR_OPEN

1

C199

2

330uF_2v_6mR_OPEN

1

C167

2

330uF_2v_6mR_OPEN

1

C109

2

330uF_2v_6mR_OPEN

+VCC_CORE

11-,16-

12

3

1200uF_2.5v

C169

CN805-3

A7

VCC001

A9

VCC002

A10

VCC003

A12

VCC004

A13

VCC005

A15

VCC006

A17

VCC007

A18

VCC008

A20

VCC009

B7

VCC010

B9

VCC011

B10

VCC012

B12

VCC013

B14

VCC014

B15

VCC015

B17

VCC016

B18

VCC017

B20

VCC018

C9

VCC019

C10

VCC020

C12

VCC021

C13

VCC022

C15

VCC023

C17

VCC024

C18

VCC025

D9

VCC026

D10

VCC027

D12

VCC028

D14

VCC029

D15

VCC030

D17

VCC031

D18

VCC032

E7

VCC033

E9

VCC034

E10

VCC035

E12

VCC036

E13

VCC037

E15

VCC038

E17

VCC039

E18

VCC040

E20

VCC041

F7

VCC042

F9

VCC043

F10

VCC044

F12

VCC045

F14

VCC046

F15

VCC047

F17

VCC048

F18

VCC049

F20

VCC050

AA7

VCC051

AA9

VCC052

AA10

VCC053

AA12

VCC054

AA13

VCC055

AA15

VCC056

AA17

VCC057

AA18

VCC058

AA20

VCC059

AB9

VCC060

AC10

VCC061

AB10

VCC062

AB12

VCC063

AB14

VCC064

AB15

VCC065

AB17

VCC066

AB18

VCC067

FOX_PZ4782K_274M_41_478P

VCC068
VCC069
VCC070
VCC071
VCC072
VCC073
VCC074
VCC075
VCC076
VCC077
VCC078
VCC079
VCC080
VCC081
VCC082
VCC083
VCC084
VCC085
VCC086
VCC087
VCC088
VCC089
VCC090
VCC091
VCC092
VCC093
VCC094
VCC095
VCC096
VCC097
VCC098
VCC099

VCC0100

VCCP01
VCCP02
VCCP03
VCCP04
VCCP05
VCCP06
VCCP07
VCCP08
VCCP09
VCCP10
VCCP11
VCCP12
VCCP13
VCCP14
VCCP15
VCCP16

VCCA01
VCCA02

VCCSENSE

VSSSENSE

+VCC_CORE

11-,16-

AB20
AB7
AC7
AC9
AC12
AC13
AC15
AC17
AC18
AD7
AD9
AD10
AD12
AD14
AD15
AD17
AD18
AE9
AE10
AE12
AE13
AE15
AE17
AE18
AE20
AF9
AF10
AF12
AF14
AF15
AF17
AF18
AF20

G21
V6
J6
K6
M6
J21
K21
M21
N21
N6
R21
R6
T21
T6
V21
W21

B26
C26

AD6

VID0

AF5

VID1

AE5

VID2

AF4

VID3

AE3

VID4

AF3

VID5

AE2

VID6

AF7

AE7

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

1

2

220uF_2v_15mR_Panasonic

11-

H_VID0

11-

H_VID1

11-

H_VID2

11-

H_VID3

11-

H_VID4

11-

H_VID5

11-

H_VID6

C881

+VCC_CORE

11-,16-

1

R107

100_1%

2

1

R134

100_1%

2

11-

11-

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

C878

1
2

0.1uF_16v

VCCSENSE

VSSSENSE

C880

1
2

0.1uF_16v

LAYOUT NOTE:
PLACE C2461 NEAR PIN B26

PLACE THESE INSIDE SOCKET

CAVITY ON L8 (NORTH SIDE

SECONDARY)

C932

C934

1

1

2

2

0.1uF_16v

0.1uF_16v

8-,25-,36-,37-,39-,45-,53-,59-

0.01uF_16v

C985

1
2

+V1.5S

C879

0.1uF_16v

1
2

C933

1
2

0.1uF_16v

1

C986

10uF_6.3v

2

http://hobi-elektronika.net

LAYOUT NOTE:
ROUTE VCCSENSE AND VSSSENSE TRACE AT

24.7 OHM WITH 50 MIL SPACEING
PLACE PU AND PD WITHIN I INCH OF CPU

CHANGE by

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

Merom-3

SIZE

A3

DOC. NUMBER

Model_No A02

CS

SHEET

REVCODE

OF

7816

http://laptopblue.vnhttp://laptopblue.vn

CN805-4

A4

VSS001

A8

VSS002

A11

VSS003

A14

VSS004

A16

VSS005

A19

VSS006

A23

VSS007

AF2

VSS008

B6

VSS009

B8

VSS010

B11

VSS011

B13

VSS012

B16

VSS013

B19

VSS014

B21

VSS015

B24

VSS016

C5

VSS017

C8

VSS018

C11

VSS019

C14

VSS020

C16

VSS021

C19

VSS022

C2

VSS023

C22

VSS024

C25

VSS025

D1

VSS026

D4

VSS027

D8

VSS028

D11

VSS029

D13

VSS030

D16

VSS031

D19

VSS032

D23

VSS033

D26

VSS034

E3

VSS035

E6

VSS036

E8

VSS037

E11

VSS038

E14

VSS039

E16

VSS040

E19

VSS041

E21

VSS042

E24

VSS043

F5

VSS044

F8

VSS045

F11

VSS046

F13

VSS047

F16

VSS048

F19

VSS049

F2

VSS050

F22

VSS051

F25

VSS052

G4

VSS053

G1

VSS054

G23

VSS055

G26

VSS056

H3

VSS057

H6

VSS058

H21

VSS059

H24

VSS060

J2

VSS061

J5

VSS062

J22

VSS063

J25

VSS064

K1

VSS065

K4

VSS066

K23

VSS067

K26

VSS068

L3

VSS069

L6

VSS070

L21

VSS071

L24

VSS072

M2

VSS073

M5

VSS074

M22

VSS075

M25

VSS076

N1

VSS077

N4

VSS078

N23

VSS079

N26

VSS080

P3

VSS081

FOX_PZ4782K_274M_41_478P

VSS082
VSS083
VSS084
VSS085
VSS086
VSS087
VSS088
VSS089
VSS090
VSS091
VSS092
VSS093
VSS094
VSS095
VSS096
VSS097
VSS098
VSS099
VSS100
VSS101
VSS102
VSS103
VSS104
VSS105
VSS106
VSS107
VSS108
VSS109
VSS110
VSS111
VSS112
VSS113
VSS114
VSS115
VSS116
VSS117
VSS118
VSS119
VSS120
VSS121
VSS122
VSS123
VSS124
VSS125
VSS126
VSS127
VSS128
VSS129
VSS130
VSS131
VSS132
VSS133
VSS134
VSS135
VSS136
VSS137
VSS138
VSS139
VSS140
VSS141
VSS142
VSS143
VSS144
VSS145
VSS146
VSS147
VSS148
VSS149
VSS150
VSS151
VSS152
VSS153
VSS154
VSS155
VSS156
VSS157
VSS158
VSS159
VSS160
VSS161
VSS162
VSS163

P6
P21
P24
R2
R5
R22
R25
T1
T4
T23
T26
U3
U6
U21
U24
V2
V5
V22
V25
W1
W4
W23
W26
Y3
Y6
Y21
Y24
AA2
AA5
AA8
AA11
AA14
AA16
AA19
AA22
AA25
AB1
AB4
AB8
AB11
AB13
AB16
AB19
AB23
AB26
AC3
AC6
AC8
AC11
AC14
AC16
AC19
AC21
AC24
AD2
AD5
AD8
AD11
AD13
AD16
AD19
AD22
AD25
AE1
AE4
AE8
AE11
AE14
AE16
AE19
AE23
AE26
A2
AF6
AF8
AF11
AF13
AF16
AF19
AF21
A25
AF25

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

Merom-4

SIZE CODE DOC. NUMBER REV

CHANGE by SHEET OF

TIGER 13-Apr-2007

A3

Model_No A02

CS

7817

FAN1_DAC0_3

+V5LA

60-

5-,6-,7-,12-,68-

12

150_5%

0.1uF_10v

R1083

C1050

1
2

C1029

2.2uF_10v

C1005

1
2

http://laptopblue.vnhttp://laptopblue.vn

+V5S

8-,9-,10-,11-,12-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1
2

2.2uF_10v

GMT_G708T1U_SOT23_5P

U810

2

3

4

GMT_G995P1U_SOP8_8P

CN807
1
2
3

MLX_53398_0371_3P

FAN CN

U811

5

SETVCC

GND

43

HYST

81

FON

GND

7

VIN

GND

6

VO

GND

5

VSET

GND

9-,10-,11-,12-,13-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V3S

VCC

G1

GND
REFENCE

OT

WS

R1084

12

1

23.2K_1%

2

CS

G

G2

G

7-,18-,30-,60-

1

R1032

10K_5%

2

1

C1004

2

0.01uF_50v

THRM_SHUTDWN#

60-

FAN_TACH1

PM_THRMTRIP#

14-,19-,36-

VR_PWRGD

R990

12

330_5%

11-,37-

Q813

2

2SC2411K

1

R991

2M_5%

2

3

C

B

E

1

7-,18-,30-,60-

Q812

D

G

1

S

2N7002W

C963

1
2

OPEN

THRM_SHUTDWN#

3

2

THRM_SHUTDWN#

7-,18-,30-,60-

R988

12

0_5%

+V3LA

6-,7-,12-,36-,56-,60-,68-

1

C962

2

0.1uF_16v

U807

1

VCC

2

DXP

3

DXN

4

THERM#

GMT_G784_MSOP_8P

H_THERMDA
H_THERMDC

1

R989

OPEN

C961

14-

2200pF_50v

14-

2

12

Thermal Sensor For CPU

http://hobi-elektronika.net

SMBCLK

SMBDATA

ALERT#

6-,60-

8
7
6
5

GND

6-,60-

BATT_CLK
BATT_DATA

INVENTEC

TITLE

HONOLULU

THERMAL&FAN CONTROLLER

CHANGE by

TIGER

13-Apr-2007

DOC. NUMBERSIZE CODE

A3

Model_No A02

CS

SHEET

REV

OF

7818

http://laptopblue.vnhttp://laptopblue.vn

MCH_CFG(5)

MCH_CFG(13:12)

XOR/ALLZ

NOTE: CFG[2:0] STRP : 010 : 800 MHz

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

1

2

1

2

LOW=DMIx2

HIGH=DMIx4

00=PARTIAL CLOCK GATING DISABLE
01=XOR MODE ENABLE
10=ALL-Z MODE ENABLE
11=NORMAL OPERATION

011 : 667 MHz

R993

20_1%

R992

20_1%

19-

19-

MCH_CFG(7)

(CPU Strap)

SM_RCOMP

SM_RCOMP#

LOW=RSVD
HIGH=Mobile CPU

MCH_CFG(16)
(FSB Dynamic
ODT)

MCH_CFG(9)
PCIE Graphics
Lane

LOW=Dynamic ODT

Disable

HIGH=Dynamic ODT

Enable

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

12

12

R77 10K_5%

19-,27-

10K_5%R79

19-,28-

CPU_BSEL2
PM_EXTTS#0
PM_EXTTS#1

CPU_BSEL1

13-,15-

MP

MCH_CFG(17:3)

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

MCH_CFG(18)
MCH_CFG(19)
MCH_CFG(20)

MCH_CFG(8)

MCH_CFG(18)

VCC SELECT

MCH_CFG(20)
(PCIE BACKWARD
INTERPOERABILITY

MODE

+V3S

1

R83

OPEN

2

19-

19-

19-

19-

LOW=1.05V
HIGH=1.5V

LOW=ONLY SDVO OR PCIE X1 IS

OPERATIONAL

HIGH=SDVO AND PCIE X1 ARE

OPERATING SIMULTANEOUSLY
VIA THE PEG PORT

1

R82

OPEN

2

MCH_CFG(19)
(DMI LANE
REVERSAL)

1

1

R58

R80

OPEN

OPEN

2

2

LOW=NORMAL
HIGH=LANES REVERSED

MCH_CFG(18)
MCH_CFG(19)
MCH_CFG(20)

BM_BUSY#

H_DPRSTP#
PM_EXTTS#0
PM_EXTTS#1

PM_PWROK

PLT_RST#

PM_THRMTRIP#

PM_DPRSLPVR

LOW=Reverse Lane
HIGH=Normal operation

MCH_CFG(11)
PSB 4X CLK
ENABLE

CPU_BSEL0

13-,15-

R100

1K_5%

19-

19­19­19-

37­11-,15-,36­19-,27­19-,28­11-,19-,37­38-,60­14-,18-,36­11-,37-

MA_A(14)
MB_A(14)

13-,15-

1

2

R75
R76

R163
R165
R105

1

2

27-,29­28-,29-

R90

1K_5%

MCH_CFG(3)
MCH_CFG(4)
MCH_CFG(5)
MCH_CFG(6)
MCH_CFG(7)
MCH_CFG(8)
MCH_CFG(9)
MCH_CFG(10)
MCH_CFG(11)
MCH_CFG(12)
MCH_CFG(13)
MCH_CFG(14)
MCH_CFG(15)
MCH_CFG(16)
MCH_CFG(17)

12
12

12
12
1

LOW=CALISTOGA
HIGH=RESERVED

U802-2

P36

RSVD1

P37

RSVD2

R35

RSVD3

N35

RSVD4

AR12

RSVD5

AR13

RSVD6

AM12

RSVD7

AN13

RSVD8

J12

RSVD9

AR37

RSVD10

AM36

RSVD11

AL36

RSVD12

AM37

RSVD13

D20

RSVD14

DDR MUXING

H10

RSVD20

B51

RSVD21

BJ20

RSVD22

BK22

RSVD23

BF19

RSVD24

BH20

RSVD25

BK18

RSVD26

BJ18

RSVD

RSVD27

BF23

RSVD28

1

R102

1K_5%

2

2

0_5%
0_5%

100_5%

0_5%

0_5%

BG23

RSVD29

BC23

RSVD30

BD24

RSVD31

BJ29

RSVD32

BE24

RSVD33

BH39

RSVD34

AW20

RSVD35

BK20

RSVD36

C48

RSVD37

D47

RSVD38

B44

RSVD39

C44

RSVD40

A35

RSVD41

B37

RSVD42

B36

RSVD43

B34

RSVD44

C34

RSVD45

P27

CFG_0

N27

CFG_1

N24

CFG_2

C21

CFG_3

C23

CFG_4

F23

CFG_5

N23

CFG_6

G23

CFG_7

J20

CFG_8

C20

CFG_9

R24

CFG_10

L23

CFG_11

J23

CFG_12

E23

CFG_13

E20

CFG_14

K23

CFG_15

M20

CFG_16

M24

CFG_17

L32

CFG_18

N33

CFG_19

L35

CFG_20

G41

PM_BM_BUSY#

L39

PM_DPRSTP#

L36

PM_EXT_TS#_0

J36

PM_EXT_TS#_1

AW49

PWROK

AV20

RSTIN#

N20

THRMTRIP#

G36

DPRSLPVR

BJ51

NC1

BK51

NC2

BK50

NC3

BL50

NC4

BL49

NC5

BL3

NC6

BL2

NC7

BK1

NC8

BJ1

NC9

E1

NC10

A5

NC11

C51

NC12

B50

NC13

A50

NC14

A49

NC15

BK2

NC16

ITL_CRESTLINE_FCBGA_TSB_1299P

CFG

NC

PM

SM_RCOMP_VOH
SM_RCOMP_VOL

DPLL_REF_CLK
DPLLREF_CLK#

DPLL_REF_SSCLK

DPLL_REF_SSCLK#

CLK

DMI

GRAPHICS VID

ME

SDVO_CTRL_CLK

SDVO_CTRL_DATA

MISC

http://hobi-elektronika.net

SM_CK_0
SM_CK_1
SM_CK_3
SM_CK_4

SM_CK#_0
SM_CK#_1
SM_CK#_3
SM_CK#_4

SM_CKE_0
SM_CKE_1
SM_CKE_3
SM_CKE_4

SM_CS#_0
SM_CS#_1
SM_CS#_2
SM_CS#_3

SM_ODT_0
SM_ODT_1
SM_ODT_2
SM_ODT_3

SM_RCOMP

SM_RCOMP#

SM_VREF_0
SM_VREF_1

PEG_CLK

PEG_CLK#

DMI_RXN_0
DMI_RXN_1
DMI_RXN_2
DMI_RXN_3

DMI_RXP_0
DMI_RXP_1
DMI_RXP_2
DMI_RXP_3

DMI_TXN_0
DMI_TXN_1
DMI_TXN_2
DMI_TXN_3

DMI_TXP_0

DMI_TXP_1
DMI_TXP_2
DMI_TXP_3

GFX_VID_0
GFX_VID_1
GFX_VID_2
GFX_VID_3

DFGT_VR_EN

CL_CLK

CL_DATA

CL_PWROK

CL_RST#

CL_VREF

CLK_REQ#

ICH_SYNC#

TEST_1
TEST_2

MCH_CFG(12)
MCH_CFG(13)
MCH_CFG(16)

MCH_CFG(9)
MCH_CFG(7)
MCH_CFG(5)

MCH_CFG(11)

AV29
BB23
BA25
AV23

AW30
BA23
AW25
AW23

BE29
AY32
BD39
BG37

BG20
BK16
BG16
BE13

BH18
BJ15
BJ14
BE16

BL15
BK14

BK31
BL31

AR49
AW4

B42
C42
H48
H47

K44
K45

AN47
AJ38
AN42
AN46

AM47
AJ39
AN41
AN45

AJ46
AJ41
AM40
AM44

AJ47
AJ42
AM39
AM43

E35
A39
C38
B39
E36

AM49
AK50
AT43
AN49
AM50

H35
K36
G39
G40

A37
R32

19­19­19­19­19­19­19-

12

0_5%

R164

R78

12

20K_5%

R101

OPEN

C937

0.1uF_16v

C966

1
2

0.01uF_16v

C967

1
2

0.01uF_16v

+V1.25S

1

R98

OPEN

2

9-,25-,39-

1

R955

1K_1%

2

1

R954

392_1%

2

1
2

1
2

1

R103

10K_5%

2

WS

C992

2.2uF_10v

C993

2.2uF_10v

TITLE

1

2

27-

M_CLK_DDR0

27-

M_CLK_DDR1

28-

M_CLK_DDR2

28-

M_CLK_DDR3

27-

M_CLK_DDR0#

27-

M_CLK_DDR1#

28-

M_CLK_DDR2#

28-

M_CLK_DDR3#

27-,29-

M_CKE0

27-,29-

M_CKE1

28-,29-

M_CKE2

28-,29-

M_CKE3

27-,29-

M_CS0#

27-,29-

M_CS1#

28-,29-

M_CS2#

28-,29-

M_CS3#

27-,29-

M_ODT0

27-,29-

M_ODT1

28-,29-

M_ODT2

28-,29-

M_ODT3

19-

SM_RCOMP

19-

SM_RCOMP#

19-

SM_RCOMP_VOH

19-

SM_RCOMP_VOL

8-,27-,28-

M_VREF

13-

CLK_R_PEG_MCH

13-

CLK_R_PEG_MCH#

37-

1

2

R869

0_5%

10­10­10­10­10-

37­37-

37-

34­34­13­37-

DMI_TXN(3:0)

8-,12-,19-,24-,25-,27-,28-,70-

37-

DMI_TXP(3:0)

37-

DMI_RXN(3:0)

37-

DMI_RXP(3:0)

DFGT_VID_0
DFGT_VID_1
DFGT_VID_2
DFGT_VID_3
DFGT_VR_EN

CL_CLK0

CL_DATA0
PM_PWROK
CL_RST#0

SDVO_CLK
SDVO_DATA
CLKREQ_R_MCH#
MCH_ICH_SYNC#

DMI_TXN(0)
DMI_TXN(1)
DMI_TXN(2)
DMI_TXN(3)

DMI_TXP(0)
DMI_TXP(1)
DMI_TXP(2)
DMI_TXP(3)

DMI_RXN(0)
DMI_RXN(1)
DMI_RXN(2)
DMI_RXN(3)

DMI_RXP(0)
DMI_RXP(1)
DMI_RXP(2)
DMI_RXP(3)

11-,19-,37-

CHANGE by SHEET OF

1

R96

OPEN

2

+V1.8

1

R995

1K_0.5%

2

1

R996

3K_1%

2

1

R997

1K_0.5%

2

1
2

TIGER 13-Apr-2007

1

1

R104

R95

OPEN

OPEN

2

2

13-

CLK_R_DREF

13-

CLK_R_DREF#

13-

SSCLK1_R_DREF

13-

SSCLK1_R_DREF#

19-

SM_RCOMP_VOH

19-

SM_RCOMP_VOL

INVENTEC

HONOLULU

Crestline-1

SIZE

CODE DOC. NUMBER

A3

Model_No A02

CS

1

2

7819

R99

OPEN

REV

LCM_BKLTEN_GMCH

R93

12

20-,32-

120_1%

R92

12

20-,32-

120_1%

R88

12

20-,31-

120_1%

R84

12

20-,31-

120_1%

R85

12

20-,31-

120_1%

CLOSE TO CALISTOGA

http://laptopblue.vnhttp://laptopblue.vn

+V3S

9-,10-,11-,12-,13-,18-,19-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

1

R50

10K_5%

2

2

U802-3

J40

L_BKLT_CTRL

H39

L_BKLT_EN

E39

L_CTRL_CLK

E40

L_CTRL_DATA

C37

L_DDC_CLK

D35

L_DDC_DATA

K40

L_VDD_EN

L41

LVDS_IBG

L43

LVDS_VBG

N41

LVDS_VREFH

N40

LVDS_VREFL

33-

D46

LVDSA_CLK#

33-

C45

LVDSA_CLK

33-

D44

LVDSB_CLK#

33-

E42

LVDSB_CLK

33-

G51

LVDSA_DATA#_0

33-

E51

LVDSA_DATA#_1

33-

F49

LVDSA_DATA#_2

33-

G50

LVDSA_DATA_0

33-

E50

LVDSA_DATA_1

33-

F48

LVDSA_DATA_2

33-

G44

LVDSB_DATA#_0

33-

B47

LVDSB_DATA#_1

33-

B45

LVDSB_DATA#_2

33-

E44

LVDSB_DATA_0

33-

A47

LVDSB_DATA_1

33-

A45

LVDSB_DATA_2

E27

TVA_DAC

G27

TVB_DAC

K27

TVC_DAC

F27

TVA_RTN

J27

TVB_RTN

L27

TVC_RTN

M35

TV_DCONSEL0

P33

TV_DCONSEL1

H32

CRT_BLUE

G32

CRT_BLUE#

K29

CRT_GREEN

J29

CRT_GREEN#

F29

CRT_RED

E29

CRT_RED#

K33

CRT_DDC_CLK

G35

CRT_DDC_DATA

F33

CRT_HSYNC

C32

CRT_TVO_IREF

E33

CRT_VSYNC

ITL_CRESTLINE_FCBGA_TSB_1299P

N43

PEG_COMPI

M43

PEG_COMPO

J51

PEG_RX#_0

L51

PEG_RX#_1

N47

PEG_RX#_2

T45

PEG_RX#_3

T50

PEG_RX#_4

U40

PEG_RX#_5

Y44

PEG_RX#_6

Y40

PEG_RX#_7

AB51

PEG_RX#_8

W49

PEG_RX#_9

AD44

PEG_RX#_10

AD40

PEG_RX#_11

LVDS

TV

VGA

AG46

PEG_RX#_12

AH49

PEG_RX#_13

AG45

PEG_RX#_14

AG41

PEG_RX#_15

J50

PEG_RX_0

L50

PEG_RX_1

M47

PEG_RX_2

U44

PEG_RX_3

T49

PEG_RX_4

T41

PEG_RX_5

W45

PEG_RX_6

W41

PEG_RX_7

AB50

PEG_RX_8

Y48

PEG_RX_9

AC45

PEG_RX_10

AC41

PEG_RX_11

AH47

PEG_RX_12

AG49

PEG_RX_13

AH45

PEG_RX_14

AG42

PEG_RX_15

N45

PEG_TX#_0

U39

PEG_TX#_1

U47

PEG_TX#_2

N51

PEG_TX#_3

R50

PEG_TX#_4

PCI-EXPRESS GRAPHICS

T42

PEG_TX#_5

Y43

PEG_TX#_6

W46

PEG_TX#_7

W38

PEG_TX#_8

AD39

PEG_TX#_9

AC46

PEG_TX#_10

AC49

PEG_TX#_11

AC42

PEG_TX#_12

AH39

PEG_TX#_13

AE49

PEG_TX#_14

AH44

PEG_TX#_15

M45

PEG_TX_0

T38

PEG_TX_1

T46

PEG_TX_2

N50

PEG_TX_3

R51

PEG_TX_4

U43

PEG_TX_5

W42

PEG_TX_6

Y47

PEG_TX_7

Y39

PEG_TX_8

AC38

PEG_TX_9

AD47

PEG_TX_10

AC50

PEG_TX_11

AD43

PEG_TX_12

AG39

PEG_TX_13

AE50

PEG_TX_14

AH43

PEG_TX_15

R72

12

24.9_1%

30-

PEG_C_RXN(15)

30-

PEG_C_RXN(14)

30-

PEG_C_RXN(13)

30-

PEG_C_RXN(12)

30-

PEG_C_RXN(11)

30-

PEG_C_RXN(10)

30-

PEG_C_RXN(9)

30-

PEG_C_RXN(8)

30-

PEG_C_RXN(7)

30-

PEG_C_RXN(6)

30-

PEG_C_RXN(5)

30-

PEG_C_RXN(4)

30-

PEG_C_RXN(3)

30-

PEG_C_RXN(2)

21-

PEG_RXN(1)

30-

PEG_C_RXN(0)

30-

PEG_C_RXP(15)

30-

PEG_C_RXP(14)

30-

PEG_C_RXP(13)

30-

PEG_C_RXP(12)

30-

PEG_C_RXP(11)

30-

PEG_C_RXP(10)

30-

PEG_C_RXP(9)

30-

PEG_C_RXP(8)

30-

PEG_C_RXP(7)

30-

PEG_C_RXP(6)

30-

PEG_C_RXP(5)

30-

PEG_C_RXP(4)

30-

PEG_C_RXP(3)

30-

PEG_C_RXP(2)

21-

PEG_RXP(1)

30-

PEG_C_RXP(0)

21-

PEG_C_TXN(15)

21-

PEG_C_TXN(14)

21-

PEG_C_TXN(13)

21-

PEG_C_TXN(12)

21-

PEG_C_TXN(11)

21-

PEG_C_TXN(10)

21-

PEG_C_TXN(9)

21-

PEG_C_TXN(8)

21-

PEG_C_TXN(7)

21-

PEG_C_TXN(6)

21-

PEG_C_TXN(5)

21-

PEG_C_TXN(4)

21-

PEG_C_TXN(3)

21-

PEG_C_TXN(2)

21-

PEG_C_TXN(1)

21-

PEG_C_TXN(0)

21-

PEG_C_TXP(15)

21-

PEG_C_TXP(14)

21-

PEG_C_TXP(13)

21-

PEG_C_TXP(12)

21-

PEG_C_TXP(11)

21-

PEG_C_TXP(10)

21-

PEG_C_TXP(9)

21-

PEG_C_TXP(8)

21-

PEG_C_TXP(7)

21-

PEG_C_TXP(6)

21-

PEG_C_TXP(5)

21-

PEG_C_TXP(4)

21-

PEG_C_TXP(3)

21-

PEG_C_TXP(2)

21-

PEG_C_TXP(1)

21-

PEG_C_TXP(0)

33-

R74

LCM_DDCPDATA_GMCH

100K_1%

LCM_3S_VDDEN_GMCH

SVID_LUMA_GMCH

SVID_CHROMA_GMCH

CRT_R_GMCH

CRT_G_GMCH

CRT_B_GMCH

2

1.3K_0.5%

1

R55

1

LCM_DDCPCLK_GMCH

2

SVID_LUMA_GMCH

SVID_CHROMA_GMCH

CRT_B_GMCH

CRT_G_GMCH

CRT_R_GMCH

R86

12

0_5%

CRT_DDCCLK_GMCH

CRT_DDCDATA_GMCH

CRT_HSYNC_GMCH

CRT_VSYNC_GMCH

INV_PWM_3

33­33-

33-

R73

100K_1%

20-,32­20-,32-

20-,31-

20-,31-

20-,31-

31­31­31-

31-

30-,33-,60-

1

2

12

R52

1

R53

R49

10K_5%

R51

12

OPEN

1
R71

2.4K_1%

LVDS_TXCL-_GMCH

2

LVDS_TXCL+_GMCH
LVDS_TXCU-_GMCH

LVDS_TXCU+_GMCH

LVDS_TXDL0-_GMCH
LVDS_TXDL1-_GMCH
LVDS_TXDL2-_GMCH

LVDS_TXDL0+_GMCH
LVDS_TXDL1+_GMCH
LVDS_TXDL2+_GMCH

LVDS_TXDU0-_GMCH
LVDS_TXDU1-_GMCH
LVDS_TXDU2-_GMCH

LVDS_TXDU0+_GMCH
LVDS_TXDU1+_GMCH
LVDS_TXDU2+_GMCH

R89 1

2

75_1%

R91

12

0_5%

30_5%

2

30_5%

+V1.25S_PEG

25-

WS

http://hobi-elektronika.net

CHANGE by

INVENTEC

TITLE

HONOLULU

Crestline-2

SIZE

13-Apr-2007TIGER

A3

CODE

CS

SHEET

DOC. NUMBER

OF

20 78

REV

A02Model_No

http://laptopblue.vnhttp://laptopblue.vn

C891

PEG_RXN(1) PEG_C_RXN(1)_GMCH

PEG_RXP(1) PEG_C_RXP(1)_GMCH

20-

20-

PEG_C_TXN(0)

PEG_C_TXN(1)

PEG_C_TXN(2)

PEG_C_TXN(3)

PEG_C_TXN(4)
PEG_C_TXN(5)
PEG_C_TXN(6)
PEG_C_TXN(7)
PEG_C_TXN(8)

PEG_C_TXN(9)
PEG_C_TXN(10)
PEG_C_TXN(11)
PEG_C_TXN(12)
PEG_C_TXN(13)
PEG_C_TXN(14)
PEG_C_TXN(15)

C145

20-

C897

C148

20-

C899

C147

20-

C896

C93

20-

C859

C893

20-

C152

20-

C146

20-

C99

20-

C154

20-

C100

20-

C96

20-

C853

20-

C856

20-

C91

20-

C92

20-

C101

20-

R130

C890

R131

0.1uF_10v

12

12

0_5%_OPEN

0.1uF_10v

12

0_5%_OPEN

12

12

0.1uF_10v_OPEN

2

1

12

0.1uF_10v_OPEN

2

1

12

0.1uF_10v_OPEN

2

1

12

0.1uF_10v_OPEN

2

1

2

1

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

2

1

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

12

0.1uF_10v_OPEN

0.1uF_10v

0.1uF_10v

0.1uF_10v

0.1uF_10v

34-

30-

PEG_C_RXN(1)

34-

30-

PEG_C_RXP(1)

30-

PEG_TXN(0)

34-

PEG_TXN(0)_GMCH

30-

PEG_TXN(1)

34-

PEG_TXN(1)_GMCH

30-

PEG_TXN(2)

34-

PEG_TXN(2)_GMCH

30-

PEG_TXN(3)

34-

PEG_TXN(3)_GMCH

30-

PEG_TXN(4)

30-

PEG_TXN(5)

30-

PEG_TXN(6)

30-

PEG_TXN(7)

30-

PEG_TXN(8)

30-

PEG_TXN(9)

30-

PEG_TXN(10)

30-

PEG_TXN(11)

30-

PEG_TXN(12)

30-

PEG_TXN(13)

30-

PEG_TXN(14)

30-

PEG_TXN(15)

PEG_C_TXP(0)

PEG_C_TXP(1)

PEG_C_TXP(2)

PEG_C_TXP(3)

PEG_C_TXP(4)
PEG_C_TXP(5)
PEG_C_TXP(6)
PEG_C_TXP(7)
PEG_C_TXP(8)

PEG_C_TXP(9)
PEG_C_TXP(10)
PEG_C_TXP(11)
PEG_C_TXP(12)
PEG_C_TXP(13)
PEG_C_TXP(14)
PEG_C_TXP(15)

12

C151

20-

C898

C149

20-

C900

C90

20-

C857

C88

20-

C858

C892

20-

C153

20-

C150

20-

C97

20-

C155

20-

C95

20-

C102

20-

C855

20-

C854

20-

C89

20-

C94

20-

C98

20-

1

1

1

1

12

12

12

12
1
12
12
12
12
12
12
1
1
1
12

2

2

2

2

2

2
2
2

0.1uF_10v_OPEN

0.1uF_10v

0.1uF_10v_OPEN

0.1uF_10v

0.1uF_10v_OPEN

0.1uF_10v

0.1uF_10v_OPEN

0.1uF_10v

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

0.1uF_10v_OPEN

30-

PEG_TXP(0)

34-

PEG_TXP(0)_GMCH

30-

PEG_TXP(1)

34-

PEG_TXP(1)_GMCH

30-

PEG_TXP(2)

34-

PEG_TXP(2)_GMCH

30-

PEG_TXP(3)

34-

PEG_TXP(3)_GMCH

30-

PEG_TXP(4)

30-

PEG_TXP(5)

30-

PEG_TXP(6)

30-

PEG_TXP(7)

30-

PEG_TXP(8)

30-

PEG_TXP(9)

30-

PEG_TXP(10)

30-

PEG_TXP(11)

30-

PEG_TXP(12)

30-

PEG_TXP(13)

30-

PEG_TXP(14)

30-

PEG_TXP(15)

close to GMCH

PM: OPEN change to ON

ON change to OPEN

WS

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

Crestline-2.1

SIZE CODE DOC. NUMBER REV

A3

CHANGE by SHEET OF

13-Apr-2007TIGER

CS

21 78

A02Model_No

MCH_HSWING

MCH_HRCOMP

MCH_HSCOMP

MCH_HSCOMP#

+VCCP

22-

12

22-

R927 54.9_1%

12

22-

12

R928

22-

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

1

R864

221_1%

2

1

R866

C830

1

100_1%

2

0.1uF_16v

2

24.9_1%R865

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

+VCCP

54.9_1%

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

MCH_HSCOMP#

http://laptopblue.vnhttp://laptopblue.vn

H_D#(63:0)

MCH_HSWING
MCH_HRCOMP

MCH_HSCOMP

H_CPURST#
H_CPUSLP#

Layout notes:
Trace need be 10 mils

22­22-

22­22-

14­15-

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

1

R868

1K_1%

2

1

R867

2K_1%

2

H_D#(0)
H_D#(1)
H_D#(2)
H_D#(3)
H_D#(4)
H_D#(5)
H_D#(6)
H_D#(7)
H_D#(8)
H_D#(9)
H_D#(10)
H_D#(11)
H_D#(12)
H_D#(13)
H_D#(14)
H_D#(15)
H_D#(16)
H_D#(17)
H_D#(18)
H_D#(19)
H_D#(20)
H_D#(21)
H_D#(22)
H_D#(23)
H_D#(24)
H_D#(25)
H_D#(26)
H_D#(27)
H_D#(28)
H_D#(29)
H_D#(30)
H_D#(31)
H_D#(32)
H_D#(33)
H_D#(34)
H_D#(35)
H_D#(36)
H_D#(37)
H_D#(38)
H_D#(39)
H_D#(40)
H_D#(41)
H_D#(42)
H_D#(43)
H_D#(44)
H_D#(45)
H_D#(46)
H_D#(47)
H_D#(48)
H_D#(49)
H_D#(50)
H_D#(51)
H_D#(52)
H_D#(53)
H_D#(54)
H_D#(55)
H_D#(56)
H_D#(57)
H_D#(58)
H_D#(59)
H_D#(60)
H_D#(61)
H_D#(62)
H_D#(63)

1
2

C832

0.1uF_16v

U802-1

E2

H_D#_0

G2

H_D#_1

G7

H_D#_2

M6

H_D#_3

H7

H_D#_4

H3

H_D#_5

G4

H_D#_6

F3

H_D#_7

N8

H_D#_8

H2

H_D#_9

M10

H_D#_10

N12

H_D#_11

N9

H_D#_12

H5

H_D#_13

P13

H_D#_14

K9

H_D#_15

M2

H_D#_16

W10

H_D#_17

Y8

H_D#_18

V4

H_D#_19

M3

H_D#_20

J1

H_D#_21

N5

H_D#_22

N3

H_D#_23

W6

H_D#_24

W9

H_D#_25

N2

H_D#_26

Y7

H_D#_27

Y9

H_D#_28

P4

H_D#_29

W3

H_D#_30

N1

H_D#_31

AD12

H_D#_32

AE3

H_D#_33

AD9

H_D#_34

AC9

H_D#_35

AC7

H_D#_36

AC14

H_D#_37

AD11

H_D#_38

AC11

H_D#_39

AB2

H_D#_40

AD7

H_D#_41

AB1

H_D#_42

Y3

H_D#_43

AC6

H_D#_44

AE2

H_D#_45

AC5

H_D#_46

AG3

H_D#_47

AJ9

H_D#_48

AH8

H_D#_49

AJ14

H_D#_50

AE9

H_D#_51

AE11

H_D#_52

AH12

H_D#_53

AJ5

H_D#_54

AH5

H_D#_55

AJ6

H_D#_56

AE7

H_D#_57

AJ7

H_D#_58

AJ2

H_D#_59

AE5

H_D#_60

AJ3

H_D#_61

AH2

H_D#_62

AH13

H_D#_63

B3

H_SWING

C2

H_RCOMP

W1

H_SCOMP

W2

H_SCOMP#

B6

H_CPURST#

E5

H_CPUSLP#

B9

H_AVREF

A9

H_DVREF

ITL_CRESTLINE_FCBGA_TSB_1299P

H_A#_3
H_A#_4
H_A#_5
H_A#_6
H_A#_7
H_A#_8

H_A#_9
H_A#_10
H_A#_11
H_A#_12
H_A#_13
H_A#_14
H_A#_15
H_A#_16
H_A#_17
H_A#_18
H_A#_19
H_A#_20
H_A#_21
H_A#_22
H_A#_23
H_A#_24
H_A#_25
H_A#_26
H_A#_27
H_A#_28
H_A#_29
H_A#_30

HOST

H_A#_31
H_A#_32
H_A#_33
H_A#_34
H_A#_35

H_ADS#
H_ADSTB#_0
H_ADSTB#_1

H_BNR#

H_BPRI#

H_BREQ#

H_DEFER#

H_DBSY#

HPLL_CLK

HPLL_CLK#

H_DPWR#

H_DRDY#

H_HIT#

H_HITM#
H_LOCK#
H_TRDY#

H_DINV#_0
H_DINV#_1
H_DINV#_2
H_DINV#_3

H_DSTBN#_0
H_DSTBN#_1
H_DSTBN#_2
H_DSTBN#_3

H_DSTBP#_0
H_DSTBP#_1
H_DSTBP#_2
H_DSTBP#_3

H_REQ#_0
H_REQ#_1
H_REQ#_2
H_REQ#_3
H_REQ#_4

H_RS#_0
H_RS#_1
H_RS#_2

J13
B11
C11
M11
C15
F16
L13
G17
C14
K16
B13
L16
J17
B14
K19
P15
R17
B16
H20
L19
D17
M17
N16
J19
B18
E19
B17
B15
E17
C18
A19
B19
N19

G12
H17
G20
C8
E8
F12
D6
C10
AM5
AM7
H8
K7
E4
C6
G10
B7

K5
L2
AD13
AE13

M7
K3
AD2
AH11

L7
K2
AC2
AJ10

M14
E13
A11
H13
B12

E12
D7
D8

15­15­15­15-

15­15­15­15-

15­15­15­15-

H_DINV#0
H_DINV#1
H_DINV#2
H_DINV#3

H_DSTBN#0
H_DSTBN#1
H_DSTBN#2
H_DSTBN#3

H_DSTBP#0
H_DSTBP#1
H_DSTBP#2
H_DSTBP#3

H_A#(3)
H_A#(4)
H_A#(5)
H_A#(6)
H_A#(7)
H_A#(8)
H_A#(9)
H_A#(10)
H_A#(11)
H_A#(12)
H_A#(13)
H_A#(14)
H_A#(15)
H_A#(16)
H_A#(17)
H_A#(18)
H_A#(19)
H_A#(20)
H_A#(21)
H_A#(22)
H_A#(23)
H_A#(24)
H_A#(25)
H_A#(26)
H_A#(27)
H_A#(28)
H_A#(29)
H_A#(30)
H_A#(31)
H_A#(32)
H_A#(33)
H_A#(34)
H_A#(35)

14-

H_ADS#

14-

H_ADSTB#0

14-

H_ADSTB#1

14-

H_BNR#

14-

H_BPRI#

14-

H_BREQ#0

14-

H_DEFER#

14-

H_DBSY#

13-

CLK_R_MCHBCLK

13-

CLK_R_MCHBCLK#

15-

H_DPWR#

14-

H_DRDY#

14-

H_HIT#

14-

H_HITM#

14-

H_LOCK#

14-

H_TRDY#

14-15-

H_REQ#(0)
H_REQ#(1)
H_REQ#(2)
H_REQ#(3)
H_REQ#(4)

H_A#(35:3)

H_RS#(0)
H_RS#(1)
H_RS#(2)

14-

H_REQ#(4:0)

14-

H_RS#(2:0)

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

Crestline-3

SIZE CODE DOC. NUMBER

CHANGE by SHEET OF

TIGER 13-Apr-2007

A3

Model_No A02

CS

REV

7822

http://laptopblue.vnhttp://laptopblue.vn

MA_DATA(63:0)

MA_DM(7:0)

MA_DQS(7:0)

MA_DQS#(7:0)

MA_A(13:0)

28-

U802-5

AP49

SB_DQ0

AR51

SB_DQ1

AW50

SB_DQ2

AW51

SB_DQ3

AN51

SB_DQ4

AN50

SB_DQ5

AV50

SB_DQ6

AV49

SB_DQ7

BA50

SB_DQ8

BB50

SB_DQ9

BA49

SB_DQ10

BE50

SB_DQ11

BA51

SB_DQ12

AY49

SB_DQ13

BF50

SB_DQ14

BF49

SB_DQ15

BJ50

SB_DQ16

BJ44

SB_DQ17

BJ43

SB_DQ18

BL43

SB_DQ19

BK47

SB_DQ20

BK49

SB_DQ21

BK43

SB_DQ22

BK42

SB_DQ23

BJ41

SB_DQ24

BL41

SB_DQ25

BJ37

SB_DQ26

BJ36

SB_DQ27

BK41

SB_DQ28

BJ40

SB_DQ29

BL35

SB_DQ30

BK37

SB_DQ31

BK13

SB_DQ32

BE11

SB_DQ33

BK11

SB_DQ34

BC11

SB_DQ35

BC13

SB_DQ36

BE12

SB_DQ37

BC12

SB_DQ38

BG12

SB_DQ39

BJ10

SB_DQ40

BL9

SB_DQ41

BK5

SB_DQ42

BL5

SB_DQ43

BK9

SB_DQ44

BK10

SB_DQ45

BJ8

SB_DQ46

BJ6

SB_DQ47

BF4

SB_DQ48

BH5

SB_DQ49

BG1

SB_DQ50

BC2

SB_DQ51

BK3

SB_DQ52

BE4

SB_DQ53

BD3

SB_DQ54

BJ2

SB_DQ55

BA3

SB_DQ56

BB3

SB_DQ57

AR1

SB_DQ58

AT3

SB_DQ59

AY2

SB_DQ60

AY3

SB_DQ61

AU2

SB_DQ62

AT2

SB_DQ63

ITL_CRESTLINE_FCBGA_TSB_1299P

SB_BS_0
SB_BS_1
SB_BS_2

SB_CAS#

SB_DM_0
SB_DM_1
SB_DM_2
SB_DM_3
SB_DM_4
SB_DM_5
SB_DM_6
SB_DM_7

SB_DQS_0
SB_DQS_1
SB_DQS_2
SB_DQS_3
SB_DQS_4
SB_DQS_5
SB_DQS_6

SB_DQS_7
SB_DQS#_0
SB_DQS#_1
SB_DQS#_2
SB_DQS#_3
SB_DQS#_4
SB_DQS#_5
SB_DQS#_6
SB_DQS#_7

SB_MA_0
SB_MA_1
SB_MA_2
SB_MA_3
SB_MA_4
SB_MA_5
SB_MA_6
SB_MA_7

DDR SYSTEM MEMORY B

SB_MA_8

SB_MA_9
SB_MA_10
SB_MA_11
SB_MA_12
SB_MA_13

SB_RAS#

SB_RCVEN#

SB_WE#

AY17
BG18
BG36

BE17

AR50
BD49
BK45
BL39
BH12
BJ7
BF3
AW2

AT50
BD50
BK46
BK39
BJ12
BL7
BE2
AV2
AU50
BC50
BL45
BK38
BK12
BK7
BF2
AV3

BC18
BG28
BG25
AW17
BF25
BE25
BA29
BC28
AY28
BD37
BG17
BE37
BA39
BG13

AV16
AY18

BC17

TP36

MB_A(0)
MB_A(1)
MB_A(2)
MB_A(3)
MB_A(4)
MB_A(5)
MB_A(6)
MB_A(7)
MB_A(8)

MB_A(9)
MB_A(10)
MB_A(11)
MB_A(12)
MB_A(13)

28-,29-

28-,29-

28-,29-

28-,29-

28-,29-

28-

28-

28-

28-,29-

MB_RAS#

MB_WE#

MB_BS0#
MB_BS1#
MB_BS2#

MB_CAS#
MB_DM(7:0)

MB_DQS(7:0)

MB_DQS#(7:0)

MB_A(13:0)

27-,29­27-,29­27-,29-

27-,29-

27-,29-

27-,29-

MB_DATA(63:0)

MA_BS0#
MA_BS1#
MA_BS2#

MA_CAS#

27-

27-

27-

27-,29-

MA_RAS#

MA_WE#

27-

U802-4

AR43

SA_DQ0

AW44

SA_DQ1

BA45

SA_DQ2

AY46

SA_DQ3

AR41

SA_DQ4

AR45

SA_DQ5

AT42

SA_DQ6

AW47

SA_DQ7

BB45

SA_DQ8

BF48

SA_DQ9

BG47

SA_DQ10

BJ45

SA_DQ11

BB47

SA_DQ12

BG50

SA_DQ13

BH49

SA_DQ14

BE45

SA_DQ15

AW43

SA_DQ16

BE44

SA_DQ17

BG42

SA_DQ18

BE40

SA_DQ19

BF44

SA_DQ20

BH45

SA_DQ21

BG40

SA_DQ22

BF40

SA_DQ23

AR40

SA_DQ24

AW40

SA_DQ25

AT39

SA_DQ26

AW36

SA_DQ27

AW41

SA_DQ28

AY41

SA_DQ29

AV38

SA_DQ30

AT38

SA_DQ31

AV13

SA_DQ32

AT13

SA_DQ33

AW11

SA_DQ34

AV11

SA_DQ35

AU15

SA_DQ36

AT11

SA_DQ37

BA13

SA_DQ38

BA11

SA_DQ39

BE10

SA_DQ40

BD10

SA_DQ41

BD8

SA_DQ42

AY9

SA_DQ43

BG10

SA_DQ44

AW9

SA_DQ45

BD7

SA_DQ46

BB9

SA_DQ47

BB5

SA_DQ48

AY7

SA_DQ49

AT5

SA_DQ50

AT7

SA_DQ51

AY6

SA_DQ52

BB7

SA_DQ53

AR5

SA_DQ54

AR8

SA_DQ55

AR9

SA_DQ56

AN3

SA_DQ57

AM8

SA_DQ58

AN10

SA_DQ59

AT9

SA_DQ60

AN9

SA_DQ61

AM9

SA_DQ62

AN11

SA_DQ63

ITL_CRESTLINE_FCBGA_TSB_1299P

BB19 28-,29-

SA_BS_0

BK19

SA_BS_1

BF29

SA_BS_2

BL17

SA_CAS#

AT45

SA_DM_0

BD44

SA_DM_1

BD42

SA_DM_2

AW38

SA_DM_3

AW13

SA_DM_4

BG8

SA_DM_5

AY5

SA_DM_6

AN6

SA_DM_7

AT46

SA_DQS_0

BE48

SA_DQS_1

BB43

SA_DQS_2

BC37

SA_DQS_3

BB16

SA_DQS_4

BH6

SA_DQS_5

BB2

SA_DQS_6

AP3

SA_DQS_7

AT47

SA_DQS#_0

BD47

SA_DQS#_1

BC41

SA_DQS#_2

BA37

SA_DQS#_3

BA16

SA_DQS#_4

BH7

SA_DQS#_5

BC1

SA_DQS#_6

AP2

SA_DQS#_7

BJ19

SA_MA_0

BD20

SA_MA_1

BK27

SA_MA_2

BH28

SA_MA_3

BL24

SA_MA_4

BK28

SA_MA_5

BJ27

SA_MA_6

BJ25

SA_MA_7

BL28

DDR SYSTEM MEMORY A

SA_MA_8

BA28

SA_MA_9

BC19

SA_MA_10

BE28

SA_MA_11

BG30

SA_MA_12

BJ16

SA_MA_13

BE18

SA_RAS#

AY20

SA_RCVEN#

SA_WE#

TP35

BA19

MA_DM(0)
MA_DM(1)
MA_DM(2)
MA_DM(3)
MA_DM(4)
MA_DM(5)
MA_DM(6)
MA_DM(7)

MA_DQS(0)
MA_DQS(1)
MA_DQS(2)
MA_DQS(3)
MA_DQS(4)
MA_DQS(5)
MA_DQS(6)

MA_DQS(7)
MA_DQS#(0)
MA_DQS#(1)
MA_DQS#(2)
MA_DQS#(3)
MA_DQS#(4)
MA_DQS#(5)
MA_DQS#(6)
MA_DQS#(7)

MA_A(0)
MA_A(1)
MA_A(2)
MA_A(3)
MA_A(4)
MA_A(5)
MA_A(6)
MA_A(7)
MA_A(8)

MA_A(9)
MA_A(10)
MA_A(11)
MA_A(12)
MA_A(13)

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

Crestline-4

SIZE CODE DOC. NUMBER REV

CHANGE by SHEET OF

TIGER 13-Apr-2007

A3

Model_No A02

CS

7823

http://laptopblue.vnhttp://laptopblue.vn

1
2

C197

0.1uF_16v

+VGFX_CORE

10-,24-

C196

1
2

C198

1
2

0.22uF_6.3v

+VCCP

220uF_2v_15mR_Panasonic

C828

1
2

22uF_6.3v

C195

1
2

0.22uF_6.3v

C183

1
2

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

PLACE THE EDGE

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

R132

12

0_5%

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

+VGFX_CORE +VCCP

10-,24- 9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

AW33
AW35

AT35
AT34
AH28
AC32
AC31
AK32
AJ31
AJ28
AH32
AH31
AH29
AF32

AU32
AU33
AU35
AV33

AY35
BA32
BA33
BA35
BB33
BC32
BC33
BC35
BD32
BD35
BE32
BE33
BE35
BF33
BF34
BG32
BG33
BG35
BH32
BH34
BH35
BJ32
BJ33
BJ34
BK32
BK33
BK34
BK35
BL33
AU30

AA20
AA23
AA26
AA28
AB21
AB24
AB29
AC20
AC21
AC23
AC24
AC26
AC28
AC29
AD20
AD23
AD24
AD28
AF21
AF26
AA31
AH20
AH21
AH23
AH24
AH26
AD31
AJ20
AN14

R30

R20

T14
W13
W14

Y12

U802-7

VCC_1
VCC_2
VCC_3
VCC_4
VCC_5
VCC_6
VCC_7
VCC_8
VCC_9
VCC_10
VCC_11
VCC_12

VCC_13

VCC_SM_1
VCC_SM_2
VCC_SM_3
VCC_SM_4
VCC_SM_5
VCC_SM_6
VCC_SM_7
VCC_SM_8
VCC_SM_9
VCC_SM_10
VCC_SM_11
VCC_SM_12
VCC_SM_13
VCC_SM_14
VCC_SM_15
VCC_SM_16
VCC_SM_17
VCC_SM_18
VCC_SM_19
VCC_SM_20
VCC_SM_21
VCC_SM_22
VCC_SM_23
VCC_SM_24
VCC_SM_25
VCC_SM_26
VCC_SM_27
VCC_SM_28
VCC_SM_29
VCC_SM_30
VCC_SM_31
VCC_SM_32
VCC_SM_33
VCC_SM_34
VCC_SM_35
VCC_SM_36

VCC_AXG_1
VCC_AXG_2
VCC_AXG_3
VCC_AXG_4
VCC_AXG_5
VCC_AXG_6
VCC_AXG_7
VCC_AXG_8
VCC_AXG_9
VCC_AXG_10
VCC_AXG_11
VCC_AXG_12
VCC_AXG_13
VCC_AXG_14
VCC_AXG_15
VCC_AXG_16
VCC_AXG_17
VCC_AXG_18
VCC_AXG_19
VCC_AXG_20
VCC_AXG_21
VCC_AXG_22
VCC_AXG_23
VCC_AXG_24
VCC_AXG_25
VCC_AXG_26
VCC_AXG_27
VCC_AXG_28
VCC_AXG_29
VCC_AXG_30
VCC_AXG_31
VCC_AXG_32
VCC_AXG_33
VCC_AXG_34

VCC_AXG_NCTF_1
VCC_AXG_NCTF_2
VCC_AXG_NCTF_3
VCC_AXG_NCTF_4
VCC_AXG_NCTF_5
VCC_AXG_NCTF_6
VCC_AXG_NCTF_7
VCC_AXG_NCTF_8

VCC_AXG_NCTF_9
VCC_AXG_NCTF_10
VCC_AXG_NCTF_11
VCC_AXG_NCTF_12
VCC_AXG_NCTF_13
VCC_AXG_NCTF_14
VCC_AXG_NCTF_15
VCC_AXG_NCTF_16
VCC_AXG_NCTF_17
VCC_AXG_NCTF_18
VCC_AXG_NCTF_19
VCC_AXG_NCTF_20
VCC_AXG_NCTF_21
VCC_AXG_NCTF_22
VCC_AXG_NCTF_23
VCC_AXG_NCTF_24
VCC_AXG_NCTF_25
VCC_AXG_NCTF_26

POWER

VCC_AXG_NCTF_27
VCC_AXG_NCTF_28
VCC_AXG_NCTF_29
VCC_AXG_NCTF_30
VCC_AXG_NCTF_31
VCC_AXG_NCTF_32
VCC_AXG_NCTF_33
VCC_AXG_NCTF_34
VCC_AXG_NCTF_35
VCC_AXG_NCTF_36
VCC_AXG_NCTF_37
VCC_AXG_NCTF_38
VCC_AXG_NCTF_39
VCC_AXG_NCTF_40
VCC_AXG_NCTF_41
VCC_AXG_NCTF_42
VCC_AXG_NCTF_43
VCC_AXG_NCTF_44
VCC_AXG_NCTF_45
VCC_AXG_NCTF_46
VCC_AXG_NCTF_47
VCC_AXG_NCTF_48
VCC_AXG_NCTF_49
VCC_AXG_NCTF_50
VCC_AXG_NCTF_51
VCC_AXG_NCTF_52
VCC_AXG_NCTF_53
VCC_AXG_NCTF_54
VCC_AXG_NCTF_55
VCC_AXG_NCTF_56
VCC_AXG_NCTF_57
VCC_AXG_NCTF_58
VCC_AXG_NCTF_59
VCC_AXG_NCTF_60
VCC_AXG_NCTF_61
VCC_AXG_NCTF_62
VCC_AXG_NCTF_63
VCC_AXG_NCTF_64
VCC_AXG_NCTF_65
VCC_AXG_NCTF_66
VCC_AXG_NCTF_67
VCC_AXG_NCTF_68
VCC_AXG_NCTF_69
VCC_AXG_NCTF_70
VCC_AXG_NCTF_71
VCC_AXG_NCTF_72
VCC_AXG_NCTF_73
VCC_AXG_NCTF_74
VCC_AXG_NCTF_75
VCC_AXG_NCTF_76
VCC_AXG_NCTF_77
VCC_AXG_NCTF_78
VCC_AXG_NCTF_79
VCC_AXG_NCTF_80
VCC_AXG_NCTF_81
VCC_AXG_NCTF_82
VCC_AXG_NCTF_83

VCC_SM_LF1
VCC_SM_LF2
VCC_SM_LF3
VCC_SM_LF4
VCC_SM_LF5
VCC_SM_LF6
VCC_SM_LF7

T17
T18
T19
T21
T22
T23
T25
U15
U16
U17
U19
U20
U21
U23
U26
V16
V17
V19
V20
V21
V23
V24
Y15
Y16
Y17
Y19
Y20
Y21
Y23
Y24
Y26
Y28
Y29
AA16
AA17
AB16
AB19
AC16
AC17
AC19
AD15
AD16
AD17
AF16
AF19
AH15
AH16
AH17
AH19
AJ16
AJ17
AJ19
AK16
AK19
AL16
AL17
AL19
AL20
AL21
AL23
AM15
AM16
AM19
AM20
AM21
AM23
AP15
AP16
AP17
AP19
AP20
AP21
AP23
AP24
AR20
AR21
AR23
AR24
AR26
V26
V28
V29
Y31

AW45
BC39
BE39
BD17
BD4
AW8
AT6

ITL_CRESTLINE_FCBGA_TSB_1299P

http://hobi-elektronika.net

1

C850

2

308 mils from
the Edge

+VGFX_CORE

1
2

10-,24-

C159

0.47uF_6.3v

C833

1
2

22uF_6.3v

Cavity Capacitors

C163

11

1

2

2

1uF_10v

Cavity Capacitors

C848 C161

1
2

0.22uF_6.3v

C184

1
2

1uF_10v0.1uF_16v

C829

1
2

0.22uF_6.3v

C182

1
2

1uF_10v0.47uF_6.3v

Place C2046 where LVDS and DDR2 taps.

1
2

C186

0.1uF_16v

1
2

C165

0.1uF_16v

1
2

C158

0.1uF_16v

C157

0.1uF_16v

C160

1
2

0.22uF_6.3v

C166

22uF_6.3v

1
2

C164

2

0.1uF_16v

C834

1
2

0.22uF_6.3v

0.1uF_16v

1
2

Cavity Capacitors

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

1

C212

11
2

0.1uF_16v

C998

2

150uF_4v_R35

2

C973

22uF_6.3v

CHANGE by SHEET OF

U802-6

AB33

VCC_NCTF_1

AB36

VCC_NCTF_2

AB37

VCC_NCTF_3

AC33

VCC_NCTF_4

AC35

VCC_NCTF_5

AC36

VCC_NCTF_6

AD35

VCC_NCTF_7

AD36

VCC_NCTF_8

AF33

VCC_NCTF_9

AF36

VCC_NCTF_10

AH33

VCC_NCTF_11

AH35

VCC_NCTF_12

AH36

VCC_NCTF_13

AH37

VCC_NCTF_14

AJ33

VCC_NCTF_15

AJ35

VCC_NCTF_16

AK33

VCC_NCTF_17

AK35

VCC_NCTF_18

AK36

VCC_NCTF_19

AK37

VCC_NCTF_20

AD33

VCC_NCTF_21

AJ36

VCC_NCTF_22

AM35

VCC_NCTF_23

AL33

VCC_NCTF_24

AL35

VCC_NCTF_25

AA33

VCC_NCTF_26

AA35

VCC_NCTF_27

AA36

VCC_NCTF_28

AP35

VCC_NCTF_29

AP36

VCC_NCTF_30

AR35

VCC_NCTF_31

AR36

VCC_NCTF_32

Y32

VCC_NCTF_33

Y33

VCC_NCTF_34

Y35

VCC_NCTF_35

Y36

VCC_NCTF_36

Y37

VCC_NCTF_37

T30

VCC_NCTF_38

T34

VCC_NCTF_39

T35

VCC_NCTF_40

U29

VCC_NCTF_41

U31

VCC_NCTF_42

U32

VCC_NCTF_43

U33

VCC_NCTF_44

U35

VCC_NCTF_45

U36

VCC_NCTF_46

V32

VCC_NCTF_47

V33

VCC_NCTF_48

V36

VCC_NCTF_49

V37

VCC_NCTF_50

AL24

VCC_AXM_NCTF_1

AL26

VCC_AXM_NCTF_2

AL28

VCC_AXM_NCTF_3

AM26

VCC_AXM_NCTF_4

AM28

VCC_AXM_NCTF_5

AM29

VCC_AXM_NCTF_6

AM31

VCC_AXM_NCTF_7

AM32

VCC_AXM_NCTF_8

AM33

VCC_AXM_NCTF_9

AP29

VCC_AXM_NCTF_10

AP31

VCC_AXM_NCTF_11

AP32

VCC_AXM_NCTF_12

AP33

VCC_AXM_NCTF_13

AL29

VCC_AXM_NCTF_14

AL31

VCC_AXM_NCTF_15

AL32

VCC_AXM_NCTF_16

AR31

VCC_AXM_NCTF_17

AR32

VCC_AXM_NCTF_18

AR33

VCC_AXM_NCTF_19

ITL_CRESTLINE_FCBGA_TSB_1299P

C972

1
2

22uF_6.3v

TIGER 13-Apr-2007

T27

VSS_NCTF_1

T37

VSS_NCTF_2

U24

VSS_NCTF_3

U28

VSS_NCTF_4

V31

VSS_NCTF_5

V35

VSS_NCTF_6

AA19

VSS_NCTF_7

AB17

VSS_NCTF_8

AB35

VSS_NCTF_9

AD19

VSS_NCTF_10

AD37

VSS_NCTF_11

AF17

VSS_NCTF_12

AF35

VSS_NCTF_13

AK17

VSS_NCTF_14

AM17

VSS_NCTF_15

AM24

VSS_NCTF_16

AP26

VSS_NCTF_17

AP28

VSS_NCTF_18

AR15

VSS_NCTF_19

AR19

VSS_NCTF_20

AR28

VSS_NCTF_21

A3

VSS_SCB1

B2

VSS_SCB2

C1

VSS_SCB3

BL1

VSS_SCB4

BL51

VSS_SCB5

POWER

A51

VSS_SCB6

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

AT33

VCC_AXM_1

AT31

VCC_AXM_2

AK29

VCC_AXM_3

AK24

VCC_AXM_4

AK23

VCC_AXM_5

AJ26

VCC_AXM_6

AJ23

VCC_AXM_7

INVENTEC

TITLE

HONOLULU

Crestline-5

SIZE CODE DOC. NUMBER REV

A3

Model_No A02

CS

+VCCP

7824

+V1.25S

+V1.25S

1

2

9-,19-,25-,39-

9-,19-,25-,39-

C835

+V1.5S

+V1.25S

9-,19-,25-,39-

L11

12

BLM11A121S

L12

1

BLM11A121S

L809

12

BLM11A121S

L812

12

BLM11A121S

+V1.25S

9-,19-,25-,39-

L810

12

BLM11B121SB

C65

1
2

47uF_4v

1uF_6.3v

8-,16-,36-,37-,39-,45-,53-,59-

C61

1
2

0.1uF_16v

12

BLM18PG181SN1J

+VCCA_DPLLA

+VCCA_DPLLB

2

1
2

L13

http://laptopblue.vnhttp://laptopblue.vn

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+VCCA_TVDAC

1

2

1

2

1

2

1

2

1
2

C192

1uF_6.3v

1
2

1
2

C59

47uF_4v

C54

33uF_2.5v

C883

22uF_4v

C882

22uF_4v

C852

0.1uF_16v

1
2

C107

+VCCD_QDAC

0.1uF_16v

C108

0.1uF_16v

1
2

1
2

1
2

+V1.25S

1

2

C64

22uF_6.3v

+V1.25S_PEGPLL

C58

C57

1
2

0.1uF_16v

0.1uF_16v

1

C55

33uF_2.5v

2

C888

0.1uF_16v

C887

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

0.1uF_16v

9-,19-,25-,39-

C940

47uF_4v

C190

1
2

0.1uF_16v

C56

1

1

2

2

0.1uF_16v

C885

1
2

1
2

1
2

+V3S

BLM18PG181SN1J

+V1.25M_MPLL

0.1uF_16v

C884

0.1uF_16v
+V1.25S_PEGPLL

25-

C938

22uF_6.3v

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

12

L804

C188

1
2

4.7uF_6.3v

+VCCA_TVDAC

1
2

+V1.25S

9-,19-,25-,39-

C189

1
2

0.1uF_16v

25-

C889

1
2

0.1uF_16v

25-

C837

1
2

0.1uF_16v

C103

0.1uF_16v

+V3S

25-

C836

10uF_6.3v

1
2

1
2

C104

0.1uF_16v

1
2

+V3S

BLM18PG181SN1J

+V1.25M_HPLL

C106

1000pF_50v

C939

22uF_6.3v

C63

0.1uF_16v

12

+VCCA_CRT_DAC

12

L805

+V1.8_LVDS

25-

1
2

C187

1
2

1uF_6.3v

C838

1
2

0.1uF_16v

0_5%R56

+V1.8_LVDS

25-

C105

1
2

0.1uF_16v

1
2

1
2

C62

0.1uF_16v

R57

+VCCD_CRT

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R54

0_5%

2

C60

1

C839

2

0.1uF_16v

0.1uF_16v

100mA

1

1
2

C841

10uF_6.3v

U802-8

J32

VCCSYNC

A33

VCCA_CRT_DAC_1

B33

VCCA_CRT_DAC_2

A30

VCCA_DAC_BG

B32

VSSA_DAC_BG

B49

VCCA_DPLLA

H49

VCCA_DPLLB

AL2

VCCA_HPLL

AM2

VCCA_MPLL

A41

VCCA_LVDS

B41

VSSA_LVDS

K50

VCCA_PEG_BG

K49

VSSA_PEG_BG

U51

VCCA_PEG_PLL

AW18

VCCA_SM_1

AV19

VCCA_SM_2

AU19

VCCA_SM_3

AU18

VCCA_SM_4

AU17

VCCA_SM_5

AT22

VCCA_SM_7

AT21

VCCA_SM_8

AT19

VCCA_SM_9

AT18

VCCA_SM_10

AT17

VCCA_SM_11

AR17

VCCA_SM_NCTF_1

AR16

VCCA_SM_NCTF_2

BC29

VCCA_SM_CK_1

BB29

VCCA_SM_CK_2

C25

VCCA_TVA_DAC_1

B25

VCCA_TVA_DAC_2

C27

VCCA_TVB_DAC_1

B27

VCCA_TVB_DAC_2

B28

VCCA_TVC_DAC_1

A28

VCCA_TVC_DAC_2

2

OPEN

M32

VCCD_CRT

L29

VCCD_TVDAC

N28

VCCD_QDAC

AN2

VCCD_HPLL

U48

VCCD_PEG_PLL

J41

VCCD_LVDS_1

H42

VCCD_LVDS_2

ITL_CRESTLINE_FCBGA_TSB_1299P

VTT_1
VTT_2
VTT_3
VTT_4
VTT_5
VTT_6
VTT_7
VTT_8

VTT_9
VTT_10
VTT_11
VTT_12
VTT_13
VTT_14
VTT_15
VTT_16
VTT_17
VTT_18
VTT_19
VTT_20
VTT_21
VTT_22

VCC_AXD_1
VCC_AXD_2
VCC_AXD_3
VCC_AXD_4
VCC_AXD_5
VCC_AXD_6

VCC_AXD_NCTF

VCC_AXF_1
VCC_AXF_2
VCC_AXF_3

VCC_DMI

POWER

VCC_SM_CK_1
VCC_SM_CK_2
VCC_SM_CK_3
VCC_SM_CK_4

VCC_TX_LVDS

VCC_HV_1
VCC_HV_2

VCC_PEG_1
VCC_PEG_2
VCC_PEG_3
VCC_PEG_4
VCC_PEG_5

VCC_RXR_DMI_1
VCC_RXR_DMI_2

VTTLF1
VTTLF2
VTTLF3

U13
U12
U11
U9
U8
U7
U5
U3
U2
U1
T13
T11
T10
T9
T7
T6
T5
T3
T2
R3
R2
R1

AT23
AU28
AU24
AT29
AT25
AT30
AR29

B23
B21
A21

AJ50

BK24
BK23
BJ24
BJ23

A43

C40
B40

AD51
W50
W51
V49
V50

AH50
AH51

A7
F2
AH1

0.47uF_6.3v

850mA

200mA

350mA

120mA

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

100mA

1

C886

2

1
2

1
2

0.47uF_6.3v

C840

0.1uF_16v

+VCC_RXR_DMI

C851

C831

1
2

0.47uF_6.3v

R870

12

0_5%

C935

1
2

1uF_10v

C193

1
2

1uF_10v

+V3S

R871

2

10_1%

+V1.25S_PEG

20-

R929

12

0_5%

C162

1
2

4.7uF_6.3v

1
2

Place on the Edge

C936

1
2

22uF_6.3v

C191

1
2

10uF_6.3v

+VCCP

D811

13

CHENMKO_BAT54_3P

1

1

2

C894

1
2

10uF_6.3v

C156

2.2uF_6.3v

+V1.25S

+V1.25S

+VCC_SM_CK

R872

OPEN

1
2

9-,19-,25-,39-

9-,19-,25-,39-

C965

1
2

C842

1
2

1000pF_50v

1

C895

2

C185

0.47uF_6.3v

1

C849

2

220uF_2v_15mR_Panasonic

+V1.25S

9-,19-,25-,39-

C194

1
2

0.1uF_16v

R994

12

0_5%

C964

1
2

0.1uF_16v

22uF_6.3v

+V1.8_LVDS +V1.8

25-

L806

12

BLM18PG181SN1J

1

C901

150uF_4v_R35

47uF_4v

1

2

12

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

8-,12-,19-,24-,25-,27-,28-,70-

1

C843

2

150uF_4v_R35

+V1.25S

R956

2

OPEN

L813

BLM18PG181SN1J

9-,19-,25-,39-

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

Crestline-6

SIZE CODE DOC. NUMBER REV

CHANGE by SHEET OF

TIGER 13-Apr-2007

A3

Model_No A02

CS

7825

U802-9

A13

VSS_1

A15

VSS_2

A17

VSS_3

A24

VSS_4

AA21

VSS_5

AA24

VSS_6

AA29

VSS_7

AB20

VSS_8

AB23

VSS_9

AB26

VSS_10

AB28

VSS_11

AB31

VSS_12

AC10

VSS_13

AC13

VSS_14

AC3

VSS_15

AC39

VSS_16

AC43

VSS_17

AC47

VSS_18

AD1

VSS_19

AD21

VSS_20

AD26

VSS_21

AD29

VSS_22

AD3

VSS_23

AD41

VSS_24

AD45

VSS_25

AD49

VSS_26

AD5

VSS_27

AD50

VSS_28

AD8

VSS_29

AE10

VSS_30

AE14

VSS_31

AE6

VSS_32

AF20

VSS_33

AF23

VSS_34

AF24

VSS_35

AF31

VSS_36

AG2

VSS_37

AG38

VSS_38

AG43

VSS_39

AG47

VSS_40

AG50

VSS_41

AH3

VSS_42

AH40

VSS_43

AH41

VSS_44

AH7

VSS_45

AH9

VSS_46

AJ11

VSS_47

AJ13

VSS_48

AJ21

VSS_49

AJ24

VSS_50

AJ29

VSS_51

AJ32

VSS_52

AJ43

VSS_53

AJ45

VSS_54

AJ49

VSS_55

AK20

VSS_56

AK21

VSS_57

AK26

VSS_58

AK28

VSS_59

AK31

VSS_60

AK51

VSS_61

AL1

VSS_62

AM11

VSS_63

AM13

VSS_64

AM3

VSS_65

AM4

VSS_66

AM41

VSS_67

AM45

VSS_68

AN1

VSS_69

AN38

VSS_70

AN39

VSS_71

AN43

VSS_72

AN5

VSS_73

AN7

VSS_74

AP4

VSS_75

AP48

VSS_76

AP50

VSS_77

AR11

VSS_78

AR2

VSS_79

AR39

VSS_80

AR44

VSS_81

AR47

VSS_82

AR7

VSS_83

AT10

VSS_84

AT14

VSS_85

AT41

VSS_86

AT49

VSS_87

AU1

VSS_88

AU23

VSS_89

AU29

VSS_90

AU3

VSS_91

AU36

VSS_92

AU49

VSS_93

AU51

VSS_94

AV39

VSS_95

AV48

VSS_96

AW1

VSS_97

AW12

VSS_98

AW16

VSS_99

ITL_CRESTLINE_FCBGA_TSB_1299P

VSS_100
VSS_101
VSS_102
VSS_103
VSS_104
VSS_105
VSS_106
VSS_107
VSS_108
VSS_109
VSS_110
VSS_111
VSS_112
VSS_113
VSS_114
VSS_115
VSS_116
VSS_117
VSS_118
VSS_119
VSS_120
VSS_121
VSS_122
VSS_123
VSS_124
VSS_125
VSS_126
VSS_127
VSS_128
VSS_129
VSS_130

VSS

VSS_131
VSS_132
VSS_133
VSS_134
VSS_135
VSS_136
VSS_137
VSS_138
VSS_139
VSS_140
VSS_141
VSS_142
VSS_143
VSS_144
VSS_145
VSS_146
VSS_147
VSS_148
VSS_149
VSS_150
VSS_151
VSS_152
VSS_153
VSS_154
VSS_155
VSS_156
VSS_157
VSS_158
VSS_159
VSS_160
VSS_161
VSS_162
VSS_163
VSS_164
VSS_165
VSS_166
VSS_167
VSS_168
VSS_169
VSS_170
VSS_171
VSS_172
VSS_173
VSS_174
VSS_175
VSS_176
VSS_177
VSS_178
VSS_179
VSS_180
VSS_181
VSS_182
VSS_183
VSS_184
VSS_185
VSS_186
VSS_187
VSS_188
VSS_189
VSS_190
VSS_191
VSS_192
VSS_193
VSS_194
VSS_195
VSS_196
VSS_197
VSS_198

AW24
AW29
AW32
AW5
AW7
AY10
AY24
AY37
AY42
AY43
AY45
AY47
AY50
B10
B20
B24
B29
B30
B35
B38
B43
B46
B5
B8
BA1
BA17
BA18
BA2
BA24
BB12
BB25
BB40
BB44
BB49
BB8
BC16
BC24
BC25
BC36
BC40
BC51
BD13
BD2
BD28
BD45
BD48
BD5
BE1
BE19
BE23
BE30
BE42
BE51
BE8
BF12
BF16
BF36
BG19
BG2
BG24
BG29
BG39
BG48
BG5
BG51
BH17
BH30
BH44
BH46
BH8
BJ11
BJ13
BJ38
BJ4
BJ42
BJ46
BK15
BK17
BK25
BK29
BK36
BK40
BK44
BK6
BK8
BL11
BL13
BL19
BL22
BL37
BL47
C12
C16
C19
C28
C29
C33
C36
C41

http://laptopblue.vnhttp://laptopblue.vn

C46
C50

D13
D24

D32
D39
D45
D49
E10
E16
E24
E28
E32
E47

G13
G16
G19
G24
G28
G29
G33
G42
G45
G48

H24
H28

H45

K12
K47

M28
M42
M46
M49

M50

N11
N14
N17
N29
N32
N36
N39
N44
N49

P19

P23

P50
R49

U41
U45
U50

ITL_CRESTLINE_FCBGA_TSB_1299P

http://hobi-elektronika.net

C7

D3

F19
F36

F4
F40
F50

G1

G8

H4

J11
J16

J2
J24
J28
J33
J35
J39

K8

L1
L17
L20
L24
L28

L3
L33
L49

M5

M9

N7

P2

P3

T39
T43
T47

V2
V3

U802-10

VSS_199
VSS_200
VSS_201
VSS_202
VSS_203
VSS_204
VSS_205
VSS_206
VSS_207
VSS_208
VSS_209
VSS_210
VSS_211
VSS_212
VSS_213
VSS_214
VSS_215
VSS_216
VSS_217
VSS_218
VSS_219
VSS_220
VSS_221
VSS_222
VSS_223
VSS_224
VSS_225
VSS_226
VSS_227
VSS_228
VSS_229
VSS_230
VSS_231
VSS_232
VSS_233
VSS_234
VSS_235
VSS_236
VSS_237
VSS_238
VSS_239
VSS_240
VSS_241
VSS_242
VSS_243

VSS_245
VSS_246
VSS_247
VSS_248
VSS_249
VSS_250
VSS_251
VSS_252
VSS_253
VSS_254
VSS_255
VSS_256
VSS_257
VSS_258
VSS_259
VSS_260
VSS_261
VSS_262
VSS_263
VSS_264
VSS_265
VSS_266
VSS_267
VSS_268
VSS_269
VSS_270
VSS_271
VSS_272
VSS_273
VSS_274
VSS_275
VSS_276
VSS_277
VSS_278
VSS_279
VSS_280
VSS_281
VSS_282
VSS_283
VSS_284
VSS_285
VSS_286

W11

VSS_287

W39

VSS_288

W43

VSS_289

W47

VSS_290

W5

VSS_291

W7

VSS_292

Y13

VSS_293

Y2

VSS_294

Y41

VSS_295

Y45

VSS_296

Y49

VSS_297

Y5

VSS_298

Y50

VSS_299

Y11

VSS_300

P29

VSS_301
VSS_302
VSS_303
VSS_304
VSS_305

VSS_306
VSS_307
VSS_308
VSS_309
VSS_310
VSS_311
VSS_312
VSS_313

12

R94

T29

12

R87 0_5%

T31

12

R81

T33

12

R97

R28

AA32
AB32
AD32
AF28
AF29
AT27
AV25
H50

0_5%
0_5%

0_5%

VSS

CHANGE by SHEET OF

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

Crestline-7

SIZE CODE

A3

DOC. NUMBER REV

Model_No A02

CS

7826

http://laptopblue.vnhttp://laptopblue.vn

R231

10K_5%

MA_A(14:0)

1

1

R232

10K_5%

2

2

MA_DQS#(7:0)

MA_DM(7:0)

MA_DQS(7:0)

23-

19-,23-,29-

MA_BS2#
MA_BS0#

MA_BS1#

M_CS0#
M_CS1#

M_CLK_DDR0
M_CLK_DDR0#
M_CLK_DDR1
M_CLK_DDR1#

M_CKE0

M_CKE1
MA_CAS#
MA_RAS#

MA_WE#

23-

23-

MA_A(14)

23-,29-

23-,29­23-,29­19-,29­19-,29­19­19­19­19­19-,29­19-,29­23-,29­23-,29­23-,29-

ICH_3S_SMCLK

ICH_3S_SMDATA

M_ODT0
M_ODT1

13-,28-,37­13-,28-,37-

CN808-1

102

A0

101

A1

100

A2

99

A3

98

A4

97

A5

94

A6

92

A7

93

A8

91

A9

105

A10_AP

90

A11

89

A12

116

A13

86

A14

84

A15

85

A16_BA2

107

BA0

106

BA1

110

S0#

115

S1#

30

CK0

32

CK0#

164

CK1

166

CK1#

79

CKE0

80

CKE1

113

CAS#

108

RAS#

109

WE#

198

SA0

200

SA1

197

SCL

195

19-,29­19-,29-

SDA

114

ODT0

119

ODT1

10

DM0

26

DM1

52

DM2

67

DM3

130

DM4

147

DM5

170

DM6

185

DM7

13

DQS0

31

DQS1

51

DQS2

70

DQS3

131

DQS4

148

DQS5

169

DQS6

188

DQS7

11

DQS#0

29

DQS#1

49

DQS#2

68

DQS#3

129

DQS#4

146

DQS#5

167

DQS#6

186

DQS#7

FOX_AS0A421_NFST_7F_200P

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

23-

MA_DATA(63:0)

5

DQ0

7

DQ1

17

DQ2

19

DQ3

4

DQ4

6

DQ5

14

DQ6

16

DQ7

23

DQ8

25

DQ9

35
37
20
22
36
38
43
45
55
57
44
46
56
58
61
63
73
75
62
64
74
76
123
125
135
137
124
126
134
136
141
143
151
153
140
142
152
154
157
159
173
175
158
160
174
176
179
181
189
191
180
182
192
194

+V1.8

8-,12-,19-,24-,25-,28-,70-

Layout notes: Place these Caps closed So-Dimm0

1
2

C989

0.1uF_16v

1
2

C988

0.1uF_16v

1
2

C995

0.1uF_16v

1
2

+V3S

1

C1010

0.1uF_16v

1

2

2

CN808-2

112

VDD1

111

VDD2

117

VDD3

C991

1

2.2uF_16v

2

C1011

0.1uF_16v

1
2

1
2

C996

2.2uF_16v

1

2.2uF_16v

2

M_VREF

8-,19-,28-

1
2

C1012

2.2uF_16v

1
2

C997

2.2uF_16v

1
2

C994

2.2uF_16v

PM_EXTTS#0

19-

C987

0.1uF_16v

9-,10-,11-,12-,13-,18-,19-,20-,25-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C1009

2.2uF_16v

C990

96

VDD4

95

VDD5

118

VDD6

81

VDD7

82

VDD8

87

VDD9

103

VDD10

88

VDD11

104

VDD12

199

VDDSPD

83

NC1

120

NC2

50

NC3

69

NC4

163

NCTEST

1

VREF

G1

GND0

G2

GND1

47

VSS1

133

VSS2

183

VSS3

77

VSS4

12

VSS5

48

VSS6

184

VSS7

78

VSS8

71

VSS9

72

VSS10

121

VSS11

122

VSS12

196

VSS13

193

VSS14

8

VSS15

FOX_AS0A421_NFST_7F_200P

VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57

18
24
41
53
42
54
59
65
60
66
127
139
128
145
165
171
172
177
187
178
190
9
21
33
155
34
132
144
156
168
2
3
15
27
39
149
161
28
40
138
150
162

SO DIMM0

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

DDR-2-DIMM-0

SIZE CODE DOC. NUMBER REV

CHANGE by SHEET OF

TIGER 13-Apr-2007

A3

Model_No A02

CS

7827

9

http://laptopblue.vnhttp://laptopblue.vn

23-

MB_DATA(63:0)

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

Layout note: Place these Caps closed So-Dimm1

C317

C315

C312

1
2

C310

0.1uF_16v

C309

1
2

0.1uF_16v

C1035

0.1uF_16v

C316

1
2

0.1uF_16v

C311

1
2

0.1uF_16v

1
2

2.2uF_16v

1
2

2.2uF_16v

1
2

2.2uF_16v

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C1034

1

1
2

2

2.2uF_16v

0.1uF_16v

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

C1036

M_VREF

8-,19-,27-

1

1

22

1
2

C1013

2.2uF_16v

C313

2.2uF_16v

C314

1
2

2.2uF_16v

PM_EXTTS#1

CN811-2

112

VDD1

111

VDD2

117

VDD3

96

VDD4

95

VDD5

118

VDD6

81

VDD7

82

VDD8

87

VDD9

103

VDD10

88

VDD11

104

VDD12

199

VDDSPD

83

NC1

120

19-

NC2

50

NC3

69

NC4

163

NCTEST

1

VREF

G1

GND

G2

GND

47

VSS1

133

VSS2

183

VSS3

77

VSS4

12

VSS5

48

VSS6

184

VSS7

78

VSS8

71

VSS9

72

VSS10

121

VSS11

122

VSS12

196

VSS13

193

VSS14

8

VSS15

FOX_AS0A421N2SN7F_DIMM_200P

VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57

18
24
41
53
42
54
59
65
60
66
127
139
128
145
165
171
172
177
187
178
190
9
21
33
155
34
132
144
156
168
2
3
15
27
39
149
161
28
40
138
150
162

MB_DM(7:0)

MB_DQS(7:0)

23-

19-,23-,29-

23-

23-

MB_A(14)

MB_BS2#
MB_BS0#

MB_BS1#

M_CS2#
M_CS3#

M_CLK_DDR2
M_CLK_DDR2#
M_CLK_DDR3
M_CLK_DDR3#

M_CKE2

M_CKE3
MB_CAS#
MB_RAS#

MB_WE#

ICH_3S_SMCLK

ICH_3S_SMDATA

M_ODT2

M_ODT3

23-,29-

23-,29­23-,29­19-,29­19-,29­19­19­19­19­19-,29­19-,29­23-,29­23-,29­23-,29-

13-,27-,37­13-,27-,37-

19-,29­19-,29-

CN811-1

102

A0

101

A1

100

A2

99

A3

98

A4

97

A5

94

A6

92

A7

93

A8

91

A9

105

A10_AP

90

A11

89

A12

116

A13

86

A14

84

A15

85

A16_BA2

107

BA0

106

BA1

110

S0#

115

S1#

30

CK0

32

CK0#

164

CK1

166

CK1#

79

CKE0

80

CKE1

113

CAS#

108

RAS#

109

WE#

198

SA0

200

SA1

197

SCL

195

SDA

114

ODT0

119

ODT1

10

DM0

26

DM1

52

DM2

67

DM3

130

DM4

147

DM5

170

DM6

185

DM7

13

DQS0

31

DQS1

51

DQS2

70

DQS3

131

DQS4

148

DQS5

169

DQS6

188

DQS7

11

DQS#0

29

DQS#1

49

DQS#2

68

DQS#3

129

DQS#4

146

DQS#5

167

DQS#6

186

DQS#7

FOX_AS0A421N2SN7F_DIMM_200P

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

5

DQ0

7

DQ1

17

DQ2

19

DQ3

4

DQ4

6

DQ5

14

DQ6

16

DQ7

23

DQ8

25

DQ9

35
37
20
22
36
38
43
45
55
57
44
46
56
58
61
63
73
75
62
64
74
76
123
125
135
137
124
126
134
136
141
143
151
153
140
142
152
154
157
159
173
175
158
160
174
176
179
181
189
191
180
182
192
194

MB_A(14:0)

-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V3S

1

R274

10K_5%

2

1

R273

10K_5%

2

MB_DQS#(7:0)

SO DIMM1

http://hobi-elektronika.net

1
2

C970

0.1uF_16v

1
2

0.1uF_16v

1
2

0.1uF_16v

1
2

0.1uF_16v

C971

C969

C968

Layout note: Place these Hi_Feq & Resistors closed GMCH

CHANGE by SHEET

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

DDR2-DIMM-1

SIZE REV

A3

DOC. NUMBERCODE

Model_No A02

CS

28

OF

78

+V0.9S

http://laptopblue.vnhttp://laptopblue.vn

8-,29-,70-

+V0.9S

8-,29-,70-

R205

R226
R230 56_5%
R271 56_5%
R247 56_5%

R223

R207

R224
R227
R222 56_5%

R225
R229 56_5%
R270 56_5%
R246 56_5%

R219

R214
R215 56_5%
R213 56_5%
R210 56_5%
R212

R209
R228 56_5%

C252

1

2

0.1uF_16v

C251

1

2

0.1uF_16v

12

12

12

12

12

12

12

12

12

12

12

12

12

12

12

12

12

12

12

1

12

12

12

12

12

12

12

12

12

12

12

12

12

1
2

1
2

C229

0.1uF_16v

C288

0.1uF_16v

1
2

1
2

C247

0.1uF_16v

C294

0.1uF_16v

C289

1
2

C245

1
2

0.1uF_16v

0.1uF_16v

1
2

1
2

C286

0.1uF_16v

C250

0.1uF_16v

C227

1
2

0.1uF_16v

C290

1
2

0.1uF_16v

1
2

1
2

C249

0.1uF_16v

C287

0.1uF_16v

1
2

1
2

C228

0.1uF_16v

C253

0.1uF_16v

1
2

1
2

C292

0.1uF_16v

C230

0.1uF_16v

1
2

1
2

C231

0.1uF_16v

C226

0.1uF_16v

1
2

1
2

LAYOUT NOTES : PLACE ONE CAP CLOSE TO EVERY 2 PULL UP RESISTOR TERMINATED TO +V0.9S

2

56_5%
56_5%R204

56_5%R234
56_5%R260

56_5%

56_5%
56_5%R220
56_5%

56_5%
56_5%

56_5%

56_5%
56_5%R218

56_5%R217
56_5%R216
56_5%

56_5%
56_5%R211

56_5%R221
56_5%R208
56_5%

56_5%R206

MA_A(0)
MA_A(1)
MA_A(2)
MA_A(3)
MA_A(4)
MA_A(5)
MA_A(6)
MA_A(7)
MA_A(8)

MA_A(9)
MA_A(10)
MA_A(11)
MA_A(12)
MA_A(13)
MA_A(14)

19-,27-

19-,27-

19-,28-

19-,28-

19-,27-

19-,27-

19-,28-

19-,28-

23-,27-

23-,27-

23-,27-

23-,27-

23-,27-

23-,27-

19-,27-

19-,27-

19-,28-

19-,28-

19-,23-,27-

M_CKE0
M_CKE1
M_CKE2
M_CKE3

M_ODT0
M_ODT1
M_ODT2
M_ODT3

MA_BS0#
MA_BS1#
MA_BS2#

MA_WE#
MA_CAS#
MA_RAS#

M_CS0#
M_CS1#
M_CS2#
M_CS3#

MA_A(14:0)

+V0.9S

8-,29-,70-

R243

R268

R235

R244
R245
R269

R267
R241
R266
R240
R265
R239
R264
R263
R238
R237
R242
R262
R236
R272
R261

12

12

12

12

12

12

2

1

2

1

12

12

12

12

12

12

12

12

12

12

12

12

12

http://hobi-elektronika.net

1
2

1
2

C291

0.1uF_16v

C246

0.1uF_16v

MB_A(0)
MB_A(1)
MB_A(2)
MB_A(3)
MB_A(4)
MB_A(5)
MB_A(6)
MB_A(7)
MB_A(8)

MB_A(9)
MB_A(10)
MB_A(11)
MB_A(12)
MB_A(13)
MB_A(14)

1
2

1
2

C248

0.1uF_16v

C285

0.1uF_16v

23-,28-

23-,28-

23-,28-

23-,28-

23-,28-

23-,28-

19-,23-,28-

MB_BS0#

MB_BS1#

MB_BS2#

MB_WE#
MB_CAS#
MB_RAS#

MB_A(14:0)

C244

0.1uF_16v

C293

0.1uF_16v

56_5%

56_5%

56_5%

56_5%
56_5%

56_5%

56_5%
56_5%
56_5%
56_5%
56_5%
56_5%
56_5%
56_5%
56_5%
56_5%

56_5%
56_5%
56_5%
56_5%
56_5%

INVENTEC

TITLE

CHANGE by SHEET

TIGER

13-Apr-2007

A3

HONOLULU

DDR2-DAMPING

DOC. NUMBER REVSIZE CODE

CS

29 78

A02Model_No

OF

INV_PWM_3

LCM_BKLTEN

20-,33-,60-

WS

LVDS_TXCU+

LVDS_TXCU-

LVDS_TXDU2+

LVDS_TXDU2-

LVDS_TXDU0+

LVDS_TXDU0-

LVDS_TXDU1+

LVDS_TXDU1-

SVID_LUMA

SVID_CHROMA

CRT_VSYNC
CRT_HSYNC

CRT_DDCCLK

CRT_DDCDATA

PEG_TXP(0)
PEG_TXN(0)

PEG_TXP(1)
PEG_TXN(1)

PEG_TXP(2)
PEG_TXN(2)

R4

CRT_R
CRT_G
CRT_B

+VBAT

5-,6-,7-,8-,9-,10-,11-,70-

CN804-1

1
3
5
7
9

11

CS

13 14
15 16
17 18
19
21 22
23 24

37 38
39

33-

0_5%_OPEN12

41 42
43 44
45 46

33-

47 48

33-

49
51 52

33-

53 54

33-

55 56
57 58

33-

59

33-

61 62

33-

63 64
65 66

33-

67 68
69

32-

71 72

32-

73 74
75 76
77 78

31-

79
81 82

31-

83 84
85 86

31-

87 88
89

31-

91 92

31­31-

93 94

31-

95 96
97 98

99
101 102
103 104

21-

105 106

21-

107 108
109

21-

111 112

21-

113 114
115 116

21-

117 118

21-

119

ACES_88880_2D08_230P_OPEN

2
4
6
8
10
12

7-,8-,9-,11-,12-,37-,42-,60-,64-

20

9-,11-

40

50

60

70

80

90

100

110

120

http://laptopblue.vnhttp://laptopblue.vn

CN804-2

CS

SLP_S3#_3R

WS

VCCP_PG

CS

33-

LCM_3S_VDDEN

33-

LCM_DDCPCLK

33-

LCM_DDCPDATA

33-

LVDS_TXDL1+

33-

LVDS_TXDL1-

33-

LVDS_TXDL0+
LVDS_TXDL0-

33-

LVDS_TXDL2+

33-

LVDS_TXDL2-

33-

LVDS_TXCL+

33-

LVDS_TXCL-

63-

TMDS_TX2-

63-

TMDS_TX2+

63-

TMDS_TX1-

63-

TMDS_TX1+

63-

TMDS_TX0-

63-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

63­63-

63­34­34­64-

20­20-

21­21-

20­20-

TMDS_TX0+
TMDS_TXC-

TMDS_TXC+

HDMI_HPD
TMDS_DDCCLK
TMDS_DDCDATA
SPDIF_MXM

PEG_C_RXP(0)
PEG_C_RXN(0)

PEG_C_RXP(1)
PEG_C_RXN(1)

PEG_C_RXP(2)
PEG_C_RXN(2)

0.1uF_10v_OPEN

+V3S

1

1
2

C12

2

0.1uF_10v_OPEN

47uF_4v_OPEN

C804

+V1.8S

1

2

12-,35-

C11

PEG_TXN(3)
PEG_TXP(3)

PEG_TXN(4)
PEG_TXP(4)

PEG_TXN(5)
PEG_TXP(5)

PEG_TXP(6)
PEG_TXN(6)

PEG_TXP(7)
PEG_TXN(7)

PEG_TXP(8)
PEG_TXN(8)

PEG_TXP(9)
PEG_TXN(9)

PEG_TXP(10)

PEG_TXN(10)

PEG_TXP(11)

PEG_TXN(11)

PEG_TXP(12)

PEG_TXN(12)

PEG_TXP(13)

PEG_TXN(13)

PEG_TXP(14)

PEG_TXN(14)

PEG_TXP(15)

PEG_TXN(15)

BUF_PLT_RST#

THRM_SHUTDWN#

EC_DATA

EC_CLK

ACPRES

27M_NONSS

27M_SS

C806

1
2

1uF_6.3v_OPEN

21­21-

21­21-

21­21-

21­21-

21­21-

21­21-

21­21-

21­21-

21­21-33-

21­21-

21­21-

21­21-

21­21-

37-,38-,53-,59-

7-,18-,60­5-,60­5-,60-

5-,60-

13-

13-

1

C805

2

0.1uF_10v_OPEN

121 122
123 124
125 126
127 128
129
131 132
133 134
135 136
137 138
139 140
141 142
143 144
145 146
147 148
149 150
151
153 154
155 156
157 158
159 160
161 162
163 164
165 166
167 168
169 170
171 172
173
175 176
177 178
179 180
181 182
183
185 186
187 188
189 190
191 192
193 194
195 196
197 198
199 200
201 202
203 204
205 206
207 208
209 210
211 212
213 214
215
217 218
219 220
221 222
223 224
225 226
227 228
229 230
231 232
233 234
235 236
237 238
239 240
241 242
G1 G2

ACES_88880_2D08_230P_OPEN

20-

PEG_C_RXP(3)

20-

130

152

174

184

216

PEG_C_RXN(3)

20-

PEG_C_RXP(4)

20-

PEG_C_RXN(4)

20-

PEG_C_RXP(5)

20-

PEG_C_RXN(5)

20-

PEG_C_RXP(6)

20-

PEG_C_RXN(6)

20-

PEG_C_RXP(7)

20-

PEG_C_RXN(7)

20-

PEG_C_RXP(8)

20-

PEG_C_RXN(8)

20-

PEG_C_RXP(9)

20-

PEG_C_RXN(9)

20-

PEG_C_RXP(10)

20-

PEG_C_RXN(10)

20-

PEG_C_RXP(11)

20-

PEG_C_RXN(11)

20-

PEG_C_RXP(12)

20-

PEG_C_RXN(12)

20-

PEG_C_RXP(13)

20-

PEG_C_RXN(13)

20-

PEG_C_RXP(14)

20-

PEG_C_RXN(14)

20-

PEG_C_RXP(15)

20-

PEG_C_RXN(15)

13-

CLK_R_PEG_REF

13-

CLK_R_PEG_REF#

+V5S

8-,9-,10-,11-,12-,18-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1

C31

2

0.1uF_10v_OPEN

http://hobi-elektronika.net

WS

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

MXM CONN

DOC. NUMBER

CODESIZE

Model_No A02

A3

CS

SHEET

OFCHANGE by

REV

7830

http://laptopblue.vnhttp://laptopblue.vn

0_5%_OPEN

30-

CRT_B

30-

CRT_G

30-

CRT_R

CRT_R_GMCH

CRT_G_GMCH

CRT_B_GMCH

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

20-

20-

20-

CRT_DDCDATA_GMCH

CRT_DDCCLK_GMCH

12

R18
R14

R11

12

R16

12

R20

1

PM:OPEN change to ON

12

12

R9

2

0_5%

0_5%

0_5%

0_5%_OPEN
0_5%_OPEN

WS

L3

12

FBM_11_160808_280T

FBM_11_160808_280T

1

1

R15

R10

200_1%

200_1%

2

2

CRT_R_L

L4

12

ON change to OPEN

30-

R809

30-

R803

R811

12

R804

12

CRT_DDCDATA

20-

CRT_DDCCLK

20-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

12

WS

0_5%

0_5%

0_5%_OPEN

2

0_5%_OPEN

+V3S

PM:OPEN change to ON

ON change to OPEN

CRT_G_L

L5

12

FBM_11_160808_280T

1

MP

R19

200_1%

2

CHENMKO_BAT54_3P D804

+V3S

1

1

2.2K_5%

R805

R810

2.2K_5%

2

2

2N7002W

R12

12

0_5%

R13

1

2

0_5%

CRT_B_L

12

C10

1
2

15pF_50V

R17

0_5%

1
2

C9

15pF_50V

1
2

C8

15pF_50V

MP

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

13

C807

1
2

1uF_10v

Q803

Q802

3

3

2

S

D

D

G

G

1

1

2

S

2N7002W

+V5S_SYNC

1

R813

2.2K_5%

2

1

R806

2.2K_5%

2

R812

12

100_5%

R807

12

100_5%

+V5S

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

SSM34_3A40V 2

1

D802

1

D800

EZJZ0V120JA

2

1

D7

EZJZ0V500AA

2

1

D803

EZJZ0V120JA

2

1

D8

EZJZ0V500AA

2

HSYNC
VSYNC

1

D6

EZJZ0V500AA

2

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1A_32V_0603SFF100F

FUSE800

12

31­31-

SYN_070549FR015S209CX_15P

10
11
12
13
14
15

1
2
3
4
5
6
7
8
9

CN801

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

G1

G

G2

G

(20/5)

CRT_HSYNC

CRT_HSYNC_GMCH

30-

20-

WS

PM:OPEN change to ON

ON change to OPEN

R815

R814

VSYNC

0_5%_OPEN

12

0_5%

12

31-

D801

VARISTOR_OPEN

D150

21

1N4148

1

1

2

12

3

R808

4

30_5%

1

PHP_SN74LVC2G125DCUR_VSSOP_8P

2

U1

8

1OE#

VCC

7

1A

2OE#

6

1Y

2Y

5

2A

GND

CS

2

R8

30_5%

12

http://hobi-elektronika.net

C7

1uF_10v

0_5%_OPEN

31-

1

D5

VARISTOR_OPEN

2

2

HSYNC

1

30-

R816

R817

0_5%

12

WS

PM:OPEN change to ON

CHANGE by

CRT_VSYNC

20-

CRT_VSYNC_GMCH

ON change to OPEN

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

RGB CONNECTOR

SIZE

A3

DOC. NUMBER

CODE

Model_No A02

CS

SHEET

REV

OF

7831

SVID_LUMA

SVID_LUMA_GMCH

SVID_CHROMA

SVID_CHROMA_GMCH

http://laptopblue.vnhttp://laptopblue.vn

R3

30-

20- 32-

30-

20-

PM:OPEN change to ON

12

0_5%_OPEN

R2

12

0_5%

R6

2

1

0_5%_OPEN

R7

12

0_5%

ON change to OPEN

1

R1

200_1%

2

1

R5

200_1%

2

C4

1
2

82pF_50v

C6

1
2

82pF_50v

L1

12

LS_1MH_1.8U

L2

12

LS_1MH_1.8U

1
2

1
2

C3

82pF_50v

C5

82pF_50v

1

D4

EZJZ0V270EA

2

1

D3

EZJZ0V270EA

2

SVID_L_LUMA

32-

SVID_L_CHROMA

SVID_L_LUMA

SVID_L_CHROMA

CN800

1

GND

2

32­32-

GND

G1

3

G

Y

G2

4

G

C

SYN_030008FR004T102ZL_4P

http://hobi-elektronika.net

SVIDEO CN

INVENTEC

TITLE

HONOLULU

S-Video CONN

SIZE

CODE DOC. NUMBER REV

A3

CHANGE by SHEET OF

13-Apr-2007TIGER

CS

32 78

A02Model_No

http://laptopblue.vnhttp://laptopblue.vn

LVDS_TXDL0-

LVDS_TXDL0-_GMCH

LVDS_TXDL1-

LVDS_TXDL1-_GMCH

LVDS_TXDL0+

LVDS_TXDL0+_GMCH

LVDS_TXDL1+

LVDS_TXDL1+_GMCH

LVDS_TXDL2-

LVDS_TXDL2-_GMCH

LVDS_TXCL-

LVDS_TXCL-_GMCH

LVDS_TXDL2+

LVDS_TXDL2+_GMCH

LVDS_TXCL+

LVDS_TXCL+_GMCH

LCM_DDCPCLK LCM_DDCPDATA

30­20-

30­20-

30­20-

30­20-

30­20-

30­20-

30­20-

30­20-

30­20-

12

0_5%

R922

0_5%_OPEN

12

R861

12

0_5%

R898

0_5%_OPEN

12

R896

12

0_5%

R921

0_5%_OPEN

12

R859

12

0_5%

R895

0_5%_OPEN

12

R893

12

0_5%

R920

12

R857

R892

R855

R880

0_5%_OPEN

12

0_5%

R894

12

0_5%_OPEN

12

R919 0_5%

0_5%_OPEN

12
12

0_5%R891

12

0_5%_OPEN

1

2

R878 0_5%

0_5%_OPEN

12

R897

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R32

47K_5%

2

LCM_3S_VDDEN

LCM_3S_VDDEN_GMCH

PM:OPEN change to ON

30-

20-

close to connector

0_5%_OPEN

12

R68

12

R67 0_5%

WS

2N7002W

2N7002W

12

2

S

G

1

Q3

Q2

1

G

470K_5%

D

3

3

D

S

2

ON change to OPEN

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

12

LCM_BKLTEN

LCM_BKLTEN_GMCH

30-

20-

close to connector

100_5%_OPENR875

12

R876 100_5%

WS

EC_BKLTEN

1
2

60-

PM:OPEN change to ON

ON change to OPEN

33-

LVDS_TXDL0-_I

33-

LVDS_TXDL1-_I

33-

LVDS_TXDL0+_I

33-

LVDS_TXDL1+_I

33-

LVDS_TXDL2-_I

33-

LVDS_TXCL-_I

33-

LVDS_TXDL2+_I

33-

LVDS_TXCL+_I

33- 33-

LCM_DDCPCLK_I

close to connector

+V3S

C35

R33

CS

0.01uF_16v

C36

1
2

0.01uF_16v

8-,9-,10-,11-,12-,18-,30-,31-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

2

1

CS

Q1

S

4

SI3433BDV

G

63
5
2

D

1

+V5S

+V3S

1

2

U1000

5

4

TSB_TC7SZ08F_SSOP_5P

3

INV_PWM_3

20-,30-,60-

ES

http://hobi-elektronika.net

LVDS_TXDU0+_GMCH

LVDS_TXDU1+_GMCH

LVDS_TXDU2+_GMCH

(20/5)

1

R31

100_5%

2

PAD2

POWERPAD_2_0610

C77

47uF_6.3v

C846

1
2

OPEN

LVDS_TXDU0-

LVDS_TXDU0-_GMCH

LVDS_TXDU1-

LVDS_TXDU1-_GMCH

LVDS_TXDU0+

LVDS_TXDU1+

LVDS_TXDU2-

LVDS_TXDU2-_GMCH

LVDS_TXCU-

LVDS_TXCU-_GMCH

LVDS_TXDU2+

LVDS_TXCU+

LVDS_TXCU+_GMCH

WS

PM:OPEN change to ON

ON change to OPEN

Place as passible as close to connector

C845

1
2

1000pF_50v

C37

1
2

0.1uF_16v

1
2

1
2

C38

10uF_6.3v

30­20-

30­20-

30­20-

30­20-

30­20-

30­20-

30­20-

30­20-

30­20-

LVDS_TXDL0+_I
LVDS_TXDL1+_I

LVDS_TXDL2+_I

LVDS_TXDU0+_I
LVDS_TXDU1+_I

LVDS_TXDU2+_I

LCM_DDCPCLK_I

LCM_DDCPDATA_I

C72

0.1uF_16v

R890

R918

R854

R889

R888

R917

R853

R887

R886

R916

R852

R885

R884

R914 0_5%

R851

R879

LVDS_TXDL0-_I
LVDS_TXDL1-_I

LVDS_TXDL2-_I

LVDS_TXCL-_I

LVDS_TXCL+_I

LVDS_TXDU0-_I
LVDS_TXDU1-_I

LVDS_TXDU2-_I

LVDS_TXCU-_I

LVDS_TXCU+_I

0_5%_OPEN

2

1
12

0_5%
0_5%_OPEN

12
12

0_5%
0_5%_OPEN

2

1
12

0_5%
0_5%_OPEN

12
1

2

0_5%
0_5%_OPEN

12
12

0_5%
0_5%_OPEN

12
12

0_5%
0_5%_OPEN

1

2

12

0_5%_OPEN

2

1
12

0_5%R883

12

0_5%_OPEN

12

0_5%R877

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

33­33­33­33­33-

33-

33-

33-

33­33­33­33­33­33­33­33-

33­33-

+V3S

33-

33-

33-

33-

33-

33-

33-

33-

1

R882

10K_5%

2

LVDS_TXDU0-_I

LVDS_TXDU1-_I

LVDS_TXDU0+_I

LVDS_TXDU1+_I

LVDS_TXDU2-_I

LVDS_TXCU-_I

LVDS_TXDU2+_I

LVDS_TXCU+_I

LCM_DDCPDATA_ILCM_DDCPCLK_GMCH LCM_DDCPDATA_GMCH

1

R881

10K_5%

2

1

C847

0.1uF_16v

2

CN1

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

16

16

17

17

18

18

19

19

20

20

21

21

22

22

23

23

24

24

25

25

26

26

27

27

28

28

29

29

30

30

31

31

32

32

33

33

34

34

35

35

36

36

37

G

41

37

38

G

42

38

39

39

40

40

IPEX_20265_040E_00E

ES

INVENTEC

TITLE

HONOLULU

HONOLULU

HONOLULU

LCM

SIZE

CODE

A3

A3

A3

CS

CS

CHANGE by

TIGER 27-Sep-2003

TIGER 27-Sep-2003

TIGER 27-Sep-2003

CS

SHEET

DOC. NUMBER

Model_No A02

Model_No A02

Model_No A02

REV

OF

7833

7833

7833

http://laptopblue.vnhttp://laptopblue.vn

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

63-

HPDET

PEG_C_RXP(1)_GMCH

PEG_C_RXN(1)_GMCH

PEG_TXP(0)_GMCH
PEG_TXN(0)_GMCH

PEG_TXP(1)_GMCH
PEG_TXN(1)_GMCH

PEG_TXP(2)_GMCH
PEG_TXN(2)_GMCH

PEG_TXP(3)_GMCH
PEG_TXN(3)_GMCH

21-

21-

21­21-

21­21-

21­21-

21­21-

+V3S_SPVCC

+V3S +V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R43

5.23K_1%

2

38-,41-,42-,45-,46-,56-

19­19-

34-,63­34-,63-

1

R1900

16.5K_1%

2

ES

PCI_3S_RST#

SDVO_DATA

SDVO_CLK

HDMI_SCLDDC

HDMI_SDADDC

WS

ES

35-

1

R44

5.23K_1%

2

1

R1901

16.5K_1%

2

HD97_3S_SDOUT

HD97_3S_RST#

AC97_3S_SDIN2

HD97_3S_BITCLK

HD97_3S_SYNC

R35

12

1K_5%

+V1.8S_SVCC

35-

+V3S_OVCC

+V3S

R70

R41
R40

R37
R39

12

35-

R38

12

4.7K_5%

12

12
12

12
12

36­36­36­36­36-

R691K_5%

12

R3433_5%

+V1.8S_VCC

34-,35-

44

65

48

TML-PAD
49
50

SVCC

51

SDR+

52

SDR-

53

SGND

54

SDG+

55

SDG-

56

SVCC

57

SDB+

58

SDB-

59

SGND

60

SDC+

61

SDC-

62

SPVCC

63

SPGND

64

OVCC PVCC1

1

41

43

45

46

47

42

SDI-

VCC

VCC

GND

SDI+

TEST

HTPLG

U3

SIL_SIL1392CNU_QFN_64P

SDSCL6SDSDA

RESET#

LSCL

LSDA

GND

VCC

7

8

4

3

5

2

R36

0_5%

0_5%

0_5%

0_5%
0_5%

1K_5%

GND

A1

9

1

2

+V3S

39

HDABCLK

HDASYNC

VCC

GND

11

10

37

VCC

HDAVCC

SCLDDC

SDADDC

12

364038

HDASDI

SDAROM

13

MP

35

HDARST#

SCLROM

14

34

33

OTPVCC

AVCC3.3EXT_RES

PVCC2

SPDIF_HDASDO

AGND

AVCC1.8

AGND

AVCC1.8

AGND

LINT#

EXT_SWING

15

16

1

R29

634_1%

2

+V3S_AVCC

TX2+

TX2-

TX1+

TX1-

TX0+

TX0-

TXC+

TXC-

35-

+V1.8S_AVCC

32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17

34-,35-

+V1.8S_PVCC1

+V1.8S_VCC

34-,35-

+V1.8S_AVCC

34-,35-

+V1.8S_PVCC2

35-

300_5% R840

300_5% R838

CLOSE TO TRANSMITTER

TMDS_DDCCLK

TMDS_DDCDATA

35-

12

R841300_5%

12

12

R839300_5%

12

CS

63-

C822

0.1uF_10v

1

2

C821

0.1uF_10v

12

C820

0.1uF_10v

12

C819

0.1uF_10v

12

30­30-

HDMI_TX2+

63-

HDMI_TX2-

63-

HDMI_TX1+

63-

HDMI_TX1-

63-

HDMI_TX0+

63-

HDMI_TX0-

63-

HDMI_TXC+

63-

HDMI_TXC-

12

R46
R45

PM:OPEN change to ON

0_5%_OPEN

12

0_5%_OPEN

WS

34-,63­34-,63-

HDMI_SCLDDC
HDMI_SDADDC

ON change to OPEN

http://hobi-elektronika.net

CHANGE by

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

HDMI Transmitter-1

CODE DOC. NUMBER

SIZE REV

A3

Model_No A02

CS

SHEET

OF

7834

http://laptopblue.vnhttp://laptopblue.vn

+V1.8S

12-,30-,35-

+V1.8S_VCC

L18

12

BLM11A121S

34-

0.1uF_10v

0.1uF_10v

Pin 31

C18

1
2

1000pF_50v

C16

1
2

1000pF_50v

Pin 43

C23

1
2

1uF_6.3v

C48

1
2

100pF_50v

+V3S

C17

1
2

1000pF_50v

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

12

BLM11A121S

C14

1
2

0.1uF_10v

C49

+V1.8S

1
2

12-,30-,35-

12

BLM11A121S

C19

0.1uF_10v

C39

1
2

Pin 2

L8

+V3S_AVCC

1
2

1000pF_50v

L7

C40 C86

C41

1
2

0.1uF_10v

Pin 38

PLACED NEAR TRANSMITTER

C22

C21

1
2

C20

1
2

1000pF_50v

0.1uF_10v

+V1.8S_PVCC2

34-

C15

1
2

10uF_6.3v

1
2

34-

1
2

1000pF_50v

C42

1
2

1000pF_50v

Pin 48Pin 9

1
2

+V1.8S

+V1.8S

12-,30-,35- 9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,7

C47

10uF_6.3v

L15

12

BLM11A121S

+V1.8S_SVCC

12-,30-,35-

+V1.8S_AVCC

L9

12

BLM11A121S

34-

C43

1
2

0.1uF_10v

Pin 50

C27

1
2

0.1uF_10v

C45

1
2

1000pF_50v

Pin 56Pin 17

Pin 21

C26

1
2

1000pF_50v

Pin 27

C82

1
2

10uF_6.3v

C24

1
2

10uF_6.3v

C44

1
2

1000pF_50v

C25

1
2

1000pF_50v

C46

1
2

100pF_50v

+V3S

L16

1

BLM11A121S

+V3S_SPVCC

2

1
2

Pin 62

34-

C84

1000pF_50v

1
2

C87

10uF_6.3v

1
2

100pF_50v

0-34-

+V1.8S

12-,30-,35-

12

BLM11A121S

L10

+V1.8S_PVCC1

34-

C30

1
2

1000pF_50v

Pin 17

1
2

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

L17

12

C29

0.1uF_10v

Pin 31

1
2

C28

1uF_6.3v

BLM11A121S

1
2

http://hobi-elektronika.net

C85

10uF_6.3v

+V3S_OVCC

34-

C83

1
2

1uF_6.3v

CHANGE by

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

HDMI Transmitter-2

SIZE

A3

DOC. NUMBER

CODE

Model_No A02

CS

SHEET

REV

OF

7835

CHENMKO_BAT54_3P

RTC BATTERY

U9

1

+

2

-

MAXELL_ML1220_T10_2P

HDD_LED#

http://laptopblue.vnhttp://laptopblue.vn

+V_RTC

+V3LA

6-,7-,12-,18-,56-,60-,68-

1
2

36-,39-

C923

10uF_6.3v

13

D12

1

R187

665_1%

2

1

R188

665_1%

2

+V_RTC

R161

12

100_5%

36-,39-

R122

330K_5%

C1800

+V_RTC

OPEN

HD97_3S_RST#

HD97_3S_SYNC
HD97_3S_BITCLK
MC97_3S_BITCLK
AC97_3S_BITCLK

+V5S

WS

68-

1

R1005

10K_5%

2

AC97_3S_SYNC

MC97_3S_SYNC

AC97_3S_RST#

MC97_3S_RST#
AC97_3S_SDIN0
AC97_3S_SDIN1
AC97_3S_SDIN2

MC97_3S_SDOUT
AC97_3S_SDOUT
HD97_3S_SDOUT

SATA_C_RXN0
SATA_C_RXP0
SATA_C_TXN0
SATA_C_TXP0

SATA_C_RXN1
SATA_C_RXP1
SATA_C_TXN1
SATA_C_TXP1

CLK_R_SATA1#
CLK_R_SATA1

34­34­34­66­64­64­66­64­66­64­66­34-

66­64­34-

54­54­54­54-

54­54­54­54-

13­13-

12

1

R950

1M_5%

2

36-,39-

1

2

1

+V_RTC

R66

OPEN

2

1
2

MP

CLOSE TO ICH8

CLOSE TO ICH8

1

R197

24.9_1%

2

R949

20K_1%

C877

1uF_6.3v

1
2

36-,39-

1

R158

332K_1%

2

MP

C921

1

2

15pF_50V

X801

32.768KHZ

C947

12

15pF_50V

12

33_5%

33_5%
33_5%
33_5%
33_5%
33_5% 12

33_5%
33_5% R184

12
12

12

12
12

12
12
12

3300pF_50vC220

12

C219

3300pF_50v

C236

12

C235

R1000

R18033_5%
R16033_5%

L180FBM_11_100505_121_T
R18212
R181
R183
R99912

R1001

R18533_5%
R186

12

1

12

24.9_1%

3300pF_50v

3300pF_50v

2

R974

34

+V1.5S

8-,16-,25-,37-,39-,45-,53-,59-

1

2

SATA_TXN0

SATA_TXN1

1

R964

10M_5%

2

R154

12

10K_5%

TP32
TP33

SATA_TXP0

SATA_TXP1

U7-1

AG25

RXTC1

AF24

RXTC2

AF23

RTCRST#

AD22

INTRUDER#

AF25

INTVRMEN

AD21

LAN100_SLP

B24

GLAN_CLK

D22

LAN_RSTSYNC

C21

LAN_RXD0

B21

LAN_RXD1

C22

LAN_RXD2

D21

LAN_TXD0

E20

LAN_TXD1

C20

LAN_TXD2

AH21

GLAN_DOCK#_GPIO13

D25

GLAN_COMPI

C25

GLAN_COMPO

AJ16

HDA_BIT_CLK

AJ15

HDA_SYNC

AE14

HDA_RST#

AJ17

HDA_SDIN0

AH17

HDA_SDIN1

AH15

HDA_SDIN2

AD13

HDA_SDIN3

AE13

HDA_SDOUT

AE10

HDA_DOCK_EN#_GPIO33

AG14

HDA_DOCK_RST#_GPIO34

AF10

SATALED#

AF6

SATA0RXN

AF5

SATA0RXP

AH5

SATA0TXN

AH6

SATA0TXP

AG3

SATA1RXN

AG4

SATA1RXP

AJ4

SATA1TXN

AJ3

SATA1TXP

AF2

SATA2RXN

AF1

SATA2RXP

AE4

SATA2TXN

AE3

SATA2TXP

AB7

SATA_CLKN

AC6

SATA_CLKP

AG1

SATARBIAS#

AG2

SATARBIAS

ITL_ICH8M_BGA_TSB_676P

RTC

CPUPWRGD_GPIO49

LAN / GLAN

IHDA

SATA

FWH0_LAD0
FWH1_LAD1
FWH2_LAD2
FWH3_LAD3

LPC

FWH4_LFRAME#

LDRQ0#

LDRQ1#_GPIO23

A20GATE

A20M#

DPRSTP#

DPSLP#

FERR#

IGNNE#

INIT#

INTR

CPU

RCIN#

SMI#

STPCLK#

THRMTRIP#

DD10
DD11
DD12
DD13
DD14

IDE

DD15

DCS1#
DCS3#

DIOR#
DIOW#

DDACK#

IDEIRQ

IORDY

DDREQ

12

R947 0_5%

53-,60-

LPC_3S_AD(0)

53-,60-

LPC_3S_AD(1)

53-,60-

LPC_3S_AD(2)

53-,60-

LPC_3S_AD(3)

53-,60-

LPC_3S_FRAME#

Close to ICH8

11-,15-,19-

H_DPRSTP#

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V3S

R174

12

10K_5%

60-

PM_3S_KBCCPURST#

R948

12

24.9_1%

Close to ICH8

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

1

R924

56_5%

2

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

+VCCP

1

2

C876

OPEN

12

56­56­56­56­56­56­56­56­56­56­56­56­56­56­56­56-

56-

PIDE_3S_A(0)

56-

PIDE_3S_A(1)

56-

PIDE_3S_A(2)

56-

PIDE_3S_CS#(0)

56-

PIDE_3S_CS#(1)

56­56-

PIDE_3S_DACK#

56­56-

PIDE_3S_IORDY

56-

PIDE_3S_DREQ

56-

14-

H_FERR#

R923

56_5%

14-,18-,19-

PM_THRMTRIP#

PIDE_3S_D(0)
PIDE_3S_D(1)
PIDE_3S_D(2)
PIDE_3S_D(3)
PIDE_3S_D(4)
PIDE_3S_D(5)
PIDE_3S_D(6)
PIDE_3S_D(7)
PIDE_3S_D(8)
PIDE_3S_D(9)
PIDE_3S_D(10)
PIDE_3S_D(11)
PIDE_3S_D(12)
PIDE_3S_D(13)
PIDE_3S_D(14)
PIDE_3S_D(15)

PIDE_3S_IOR#

PIDE_3S_IOW#

PIDE_3S_IRQ

E5
F5
G8
F6

C4

G9
E6

60-

AF13
AG26

AF26
AE26

AD24

AG29

AF27

AE24
AC20
AH14

AD23

NMI

AG28

AA24

AE27

AA23

TP8

V1

DD0

U2

DD1

V3

DD2

T1

DD3

V4

DD4

T5

DD5

AB2

DD6

T6

DD7

T3

DD8

R2

DD9

T4
V6
V5
U1
V2
U6

AA4

DA0

AA1

DA1

AB3

DA2

Y6
Y5

W4
W3
Y2
Y3
Y1
W5

EC_3S_A20GATE

14-

H_A20M#

15-

H_DPSLP#

12

0_5%R123

TP34

15-

14-

14­14-

14­14-

14-

H_PWRGD
H_IGNNE#
H_INIT#

H_INTR

H_NMI
H_SMI#

H_STPCLK#

http://hobi-elektronika.net

CHANGE by

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

ICH8-1

CODE

SIZE

A3

DOC. NUMBER

Model_No A02

CS

SHEET

REV

OF

7836

http://laptopblue.vnhttp://laptopblue.vn

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

ICH_3A_SMCLK

ICH_3S_SMCLK

ICH_3A_SMDATA

ICH_3S_SMDATA

MACHINE_ID0
MACHINE_ID1
MACHINE_ID2
MACHINE_ID3
MACHINE_ID4
MACHINE_ID5
MACHINE_ID6

CS

SMB_ALERT#

PM_RI#

SMB_ALERT#

CL_RST#1
ICH_3A_ALERT_CLK
ICH_3A_ALERT_DAT

PCIE_WAKE#

RSC_0402

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

PCI_3S_CLKRUN#

PCI_3S_SERIRQ

MACHINE_ID0
MACHINE_ID1
MACHINE_ID2
MACHINE_ID3
MACHINE_ID4
MACHINE_ID5
MACHINE_ID6

CS

MACHINE_ID1_DB
MACHINE_ID0_DB

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

CL_VREF0 CL_VREF1

37-

+V3S

1

R944

2.2K_5%

2

37-

13-,27-,28-

37-

13-,27-,28-

R970

12

37-

R126

12

37-

R1009

12

37-

R1010

12

37-

12

37-

R1800

MP

12

37-

12

37-

1122

37-

PASSWORD_0805

ERASE PASSWORD

37­37­37­37-,45-,53-,59­37-,45-,53-,59­37-,45-,50-,53-,59-

37-,41-,46-,47-,60­37-,41-,60-

12

37-

R127 10K_5%

12

37-

R1013 10K_5%

12

37-

12

37-

R1004 10K_5%

12

37-

R1802

1

37-

R1803 10K_5%

12

37-

R1011 10K_5%

12

37-,68-

12

37-,68-

+V3S

C958

1
2

0.1uF_16v

1

R943

2.2K_5%

2

12

R125

12

R946

0_5%_OPEN
0_5%_OPEN
0_5%_OPEN
0_5%_OPEN

0_5%_OPENR1003

10K_5%

0_5%_OPENR1801

CS

B500

R177

R1006

10K_5%R971

10K_5%R1008

0_5%_OPEN

2

10K_5%R960

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

1

R979

3.24K_1%

2

1

R978

453_1%

2

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

2

1

R124

10K_5%

33_5%

33_5%

10K_5%

R945

1

+V5S

2

Q8

3

D

G

1

S

2

2N7002W

Q7

3

D

G

1

S

2

2N7002W

LAN

WLAN

ROBSON

MINI CARD

NEW CARD

+V3A

MACHINE_ID5

1

R179

10K_5%

2

MACHINE_ID4
MACHINE_ID3

MACHINE_ID2
MACHINE_ID0_DB
MACHINE_ID1_DB

MACHINE_ID6

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

10K_5%

12

R968

12

R959
R965
R969
R966

R1002

10K_5%

12

10K_5%

12

10K_5%

12

10K_5%

1

2

1K_5%

8.2K_5%

12
1

8.2K_5%

2

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

MP

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

ICH_NEWCARD_OC#

+V3S

R972

10K_5%

12

ICH_3A_SMCLK

ICH_3A_SMDATA

CL_RST#1
ICH_3A_ALERT_CLK
ICH_3A_ALERT_DAT

PM_RI#

SUS_STAT#_3

XDP_DBRESET#

BM_BUSY#

SMB_ALERT#

PCISTOP#_3

CPUSTOP#_3

PCI_3S_CLKRUN#

PCIE_WAKE#

PCI_3S_SERIRQ

VRHOT#

VR_PWRGD

BT_RESET#

RUNSCI0#_3

CPPE#

WAKEUP0#_3

WS

+V3A

R155

3.24K_1%

37-

C181

1
2

0.1uF_16v

CAMERA_OFF#

MACHINE_ID1
MACHINE_ID0

1

CLKREQ_R_SATA#

2

ICH_NEWCARD_OC#

PCSPKR_ICH_3

1

R150

453_1%

MCH_ICH_SYNC#

2

FILI_PRES#

PCIE_C_RXN1
PCIE_C_RXP1
PCIE_C_TXN1

PCIE_C_TXP1

PCIE_C_RXN2
PCIE_C_RXP2
PCIE_C_TXN2

PCIE_C_TXP2

PCIE_C_RXN3
PCIE_C_RXP3
PCIE_C_TXN3

PCIE_C_TXP3

PCIE_C_RXN4
PCIE_C_RXP4
PCIE_C_TXN4

PCIE_C_TXP4

PCIE_C_RXN5
PCIE_C_RXP5
PCIE_C_TXN5

PCIE_C_TXP5

CS

50­50­50-

C132

0.1uF_16v

50-

12

53­53­53-

C130

0.1uF_16v

53-

12

53­53­53-

C128

0.1uF_16v

53-

12

59­59­59-

C126

0.1uF_16v

59-

2

1

45­45­45-

C124

0.1uF_16v

45-

2

1

37­37­37­37­37-,68­37-,68- M1
37-

CS

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

R1007

12

37-,45-

100K_5%

37­37­37­37-,45-,53-,59­37-,45-,53-,59-

37-

45­14-

19-

37-

13­13-

37-,41-,46-,47-,60-

37-,45-,50-,53-,59­37-,41-,60­38-

11-,18-

58-

38-,60­45-,60­60-

55-

37­37­13-

55­37-,45-

64-

19-

12

R178

0_5%

R153

12

0_5%

TP16

TP17
TP18
TP19
TP20

TP21

TP22

0.1uF_16v

C133

12

0.1uF_16v

C131

2

1

0.1uF_16v

C129

12

0.1uF_16v

C127

12

0.1uF_16v

C125

12

U7-3

AJ26

SMBLCK

AD19

SMBDATA

AG21

LINKALERT#

AC17

SMLINK0

AE19

SMLINK1

AF17

RI#

SUS_STAT#_LPCPD#

AD15

SYS_RESET#

AG12

BMBUSY#_GPIO0

AG22

SMBALERT#_GPIO11

AE20

STP_PCI#_GPIO15

AG18

STP_CPU#_GPIO25

AH11

CLKRUN#_GPIO32

AE17

WAKE#

AF12

SERIRQ

AC13

THRM#

AJ20

VRMPWRGD

AJ22

TP7

AJ8

TACH1_GPIO1

AJ9

TACH2_GPIO6

AH9

TACH3_GPIO7

AE16

GPIO8

AC19

GPIO12

AG8

TACH0_GPIO17

AH12

GPIO18

AE11

GPIO20

AG10

SCLOCK_GPIO22

AH25

QRT_SATAE0_GPIO27

AD16

QRT_SATA1_GPIO28

AG13

SATACLKREQ#_GPIO35

AF9

SLOAD_GPIO38

AJ11

SDATAOUT0_GPIO39

AD10

SDATAOUT1_GPIO48

AD9

SPKR

AJ13

MCH_SYNC#

AJ21

TP3

ITL_ICH8M_BGA_TSB_676P

PCIE_TXN1
PCIE_TXP1

PCIE_TXN2
PCIE_TXP2

PCIE_TXN3
PCIE_TXP3

PCIE_TXN4
PCIE_TXP4

PCIE_TXN5
PCIE_TXP5

TP23
TP24
TP25

TP26
TP27

AJ19
AG16
AG15
AE15
AF15
AG17
AD12

AJ18
AD14
AH18

SATA

SMB

S4_STATE#_GPIO26

SYS GPIO

GPIO

ME_EC_ALERT_GPIO10
EC_ME_ALERT_GPIO14

MISC

P27
P26
N29
N28

M27
M26

L29
L28

K27
K26

J29
J28

H27
H26
G29
G28

F27

F26
E29
E28

D27
D26
C29
C28

C23
B23
E22

D23

F21

SATA0GP_GPIO21
SATA1GP_GPIO19
SATA2GP_GPIO36

GPIO

SATA3GP_GPIO37

DPRSLPVR_GPIO16

Power MGT

Controller Link

MEM_LED_GPIO24

U7-4

PERN1
PERP1
PETN1
PETP1

PERN2
PERP2
PETN2
PETP2

PERN3
PERP3
PETN3
PETP3

PERN4
PERP4
PETN4
PETP4

PERN5
PERP5
PETN5
PETP5

PERN6_GLAN_RXN
PERP6_CLAN_RXP
PETN6_GLAN_TXN
PETP6_GLAN_TXP

SPI_CLK
SPI_CS0#
SPI_CS1#

SPI_MOSI
SPI_MISO

OC0#
OC1#_GPIO40
OC2#_GPIO41
OC3#_GPIO42
OC4#_GPIO43
OC5#_GPIO29
OC6#_GPIO30
OC7#_GPIO31
OC8#
OC9#

ITL_ICH8M_BGA_TSB_676P

CLK14
CLK48

Clocks

SUSCLK

SLP_S3#
SLP_S4#
SLP_S5#

PWROK

BATLOW#

PWRBTN#

LAN_RST#

RSMRST#

CK_PWRGD

CLPWROK

SLP_M#

CL_CLK0
CL_CLK1

CL_DATA0
CL_DATA1

CL_VREF0
CL_VREF1

CL_RST#

WOL_EN_GPIO9

http://hobi-elektronika.net

DMI0RXN
DMI0RXP
DMI0TXN

DMI0TXP

DMI1RXN
DMI1RXP
DMI1TXN

DMI1TXP

DMI2RXN
DMI2RXP
DMI2TXN

DMI2TXP

DMI3RXN
DMI3RXP

PCI-Express

DMI3TXN

Direct Media Interface

DMI3TXP

DMI_CLKN
DMI_CLKP

DMI_ZCOMP

DMI_IRCOMP

SPI

USB

USBRBIAS#

USBRBIAS

TP871

AJ12
AJ10
AF11

TP3

AG11

AG9
G5

D3F4

AG23
AF21
AD18

TP852

AH27

AE23

AJ14

AE21

C2

AH20

AG27

E1

E3

TP28

AJ25

F23

TP29

AE18

F22

TP30

AF19

D24
AH23

AJ23

TP31

AJ27
AJ24
AF22
AG19

USBP0N
USBP0P
USBP1N
USBP1P
USBP2N
USBP2P
USBP3N
USBP3P
USBP4N
USBP4P
USBP5N
USBP5P
USBP6N
USBP6P
USBP7N
USBP7P
USBP8N
USBP8P
USBP9N
USBP9P

100K_5%

V27
V26
U29
U28

Y27
Y26
W29
W28

AB26
AB25
AA29
AA28

AD27
AD26
AC29
AC28

T26
T25

Y23
Y24

G3
G2
H5
H4
H2
H1
J3
J2
K5
K4
K2
K1
L3
L2
M5
M4
M2

N3
N2

F2

USB_RBIAS_PN

F3

Place within 500 mils of ICH

MP

R1026

12

12

R963

1

R156

12

R157

0_5%

12

12

OPEN

0_5%

2

OPEN

0_5%

12

12

0_5%

12

R148

12

R151OPEN

R149OPEN

0_5% R1025

12

R152

R967

R1024

MP

12

21_1%

ES

7-,8-,9-,11-,12-,30-,42-,60-,64-

8-,12-,60-

0_5%R961

11-,19-

11-,19-

30-,38-,53-,59-

50-,60-

11-,19-

19­19­19­19-

19­19­19­19-

19­19­19­19-

19­19­19­19-

13­13-

57-

USB_P0-

57-

USB_P0+

57-

USB_P1-

57-

USB_P1+

57-

USB_P2-

57-

USB_P2+

57-

USB_P3-

57-

USB_P3+

45-

USB_P4-

45-

USB_P4+

59-

USB_P5-

59-

USB_P5+

58-

USB_P6-

58-

USB_P6+

55-

USB_P7-

55-

USB_P7+

68-

USB_P8-

68-

USB_P8+

55-

USB_P9-

55-

USB_P9+

58-

BT_ON#

58-

BTMDL#

55-

FELICA_ON#

13-

CLK_R3S_ICH14

13-

CLK_R3S_ICH48

R1031

10K_5%

SLP_S3#_3R
SLP_S5#_3R

PM_DPRSLPVR

60-

13-

CLK_PWRGD

PM_PWROK

BUF_PLT_RST#
LAN_RST#

RSMRST#

R962 10K_5%

PM_PWROK

19-

CL_CLK0

19-

CL_DATA0

37-

CL_VREF0

37-

CL_VREF1

19-

CL_RST#0

60-

EC_SMI

45-

ICH_NEWCARD_SD#

TIGER 13-Apr-2007

DMI_RXN(0)

DMI_RXP(0)
DMI_TXN(0)
DMI_TXP(0)

DMI_RXN(1)

DMI_RXP(1)
DMI_TXN(1)
DMI_TXP(1)

DMI_RXN(2)

DMI_RXP(2)
DMI_TXN(2)
DMI_TXP(2)

DMI_RXN(3)

DMI_RXP(3)
DMI_TXN(3)
DMI_TXP(3)

CLK_R_PCIE_ICH#

CLK_R_PCIE_ICH

DMI_IRCOMP_R

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

1

U809

5

2

12

1

4

2

3

TSB_TC7SZ08F_SSOP_5P_OPEN

1

R175

2

100K_5%_OPEN

ES

13

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

ISOLATION

R958

12

8.2K_5%

TITLE

SIZE

A3

+V1.5S

8-,16-,25-,36-,39-,45-,53-,59-

1

R973

24.9_1%

2

Close to ICH8

D1001

1

3

CHENMKO_BAT54_3P

60-

EC_PWRSW#

60-,67-

PWR_SWIN#_3

ES

PULL-DOWN FOR GMCH A0
OPEN FOR GMCH A1

D816CHENMKO_BAT54_3P

60-

LOW_BAT#_3

+V3A

INVENTEC

HONOLULU

ICH8-2

CODE

DOC. NUMBER

Model_No A02

CS

SHEET

OFCHANGE by

7837

REV

PCI_3S_AD(31:0)

PCI_3S_INTA#
PCI_3S_INTB#
PCI_3S_INTC#
PCI_3S_INTD#

41-,46-,47-

38-,41­38-,41­38-,41­38-,46-

http://laptopblue.vnhttp://laptopblue.vn

U7-2

D20

AD0

E19

AD1

D19

AD2

A20

AD3

D17

AD4

A21

AD5

A19

AD6

C19

AD7

A18

AD8

B16 C17

AD9

A12

AD10

E16

AD11

A14

AD12

G16

AD13

A15

AD14

B6

AD15

C11

AD16

A9

AD17

D11

AD18

B12

AD19

C12

AD20

D10

AD21

C7

AD22

F13

AD23

E11

AD24

E13

AD25

E12

AD26

D8

AD27

A6

AD28

E8

AD29

D6

AD30

A3

AD31

F9

PIRQA#

B5

PIRQB#

C5

PIRQC#

A10

PIRQD#

ITL_ICH8M_BGA_TSB_676P

REQ1#_GPIO50

GNT1#_GPIO51

REQ2#_GPIO52

GNT2#_GPIO53

REQ3#_GPIO54

GNT3#_GPIO55

PCI

Interrupt I/F

PIRQE#_GPIO2
PIRQF#_GPIO3
PIRQG#_GPIO4
PIRQH#_GPIO5

REQ0#
GNT0#

C_BE0#
C_BE1#
C_BE2#
C_BE3#

IRDY#

PCIRST#

DEVSEL#

PERR#

PLOCK#

SERR#
STOP#
TRDY#

FRAME#

PLTRST#

PCICLK

PME#

PAR

A4
D7
E18
C18
B19
F18
A11
C10

E15
F16
E17

C8
D9
G6
D16
A7
B7
F10
C16
C9
A17

AG24
B10
G7

F8
G11
F12
B3

TP1

TP851

TP2

12

8.2K_5%

R192

38-,46-,47-

41-,46-,47­41-,46-,47­41-,46-,47­41-,46-,47-

38-,41-,46-,47-

41-,46-,47-

38-,41-,46-,47­38-,41-,46-,47-

38-,41-,46-,47­38-,41-,46-,47­38-,41-,46-,47­38-,41-,46-,47-

38-,46-

46-,47­38-,41-

38-,47-

38-

13-

46-

41-

47-

PCI_3S_REQ#(0)
PCI_3S_GNT#(0)
PCI_3S_REQ#(1)
PCI_3S_GNT#(1)
PCI_3S_REQ#(2)
PCI_3S_GNT#(2)
PCI_3S_REQ#(3)
PCI_3S_GNT#(3)

PCI_3S_CBE#(0)
PCI_3S_CBE#(1)
PCI_3S_CBE#(2)
PCI_3S_CBE#(3)

PCI_3S_IRDY#
PCI_3S_PAR

PCI_3S_DEVSEL#
PCI_3S_PERR#
PCI_3S_LOCK#
PCI_3S_SERR#
PCI_3S_STOP#
PCI_3S_TRDY#
PCI_3S_FRAME#

WS

PCI_RST#

CLK_R3S_ICHPCI

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

38-,46-,47-

PCI_3S_INTE#

38-,47-

PCI_3S_INTF#

38-

PCI_3S_INTG#

1

R1016

OPEN

2

+V3S

Q816
1

G

2N7002W

R1030

12

47K_5%

INTG --- MACHINE_ID7

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

1

R1021

OPEN

2

3

D

S

2

41-

+V3A

U808

5

1

4

2

TSB_TC7SZ08F_SSOP_5P

3

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

U5

5

1

4

2

TSB_TC7SZ08F_SSOP_5P

3

PCI_3S_PME#

Boot BIOS from SPI

GNT0# = 0
SPI_CS1# = 1

34-,41-,42-,45-,46-,56-

19-,60-

30-,37-,53-,59-

PCI_3S_RST#

PLT_RST#

BUF_PLT_RST#

PCI_3S_FRAME#

PCI_3S_IRDY#
PCI_3S_TRDY#
PCI_3S_STOP#

PCI_3S_SERR#

PCI_3S_DEVSEL#

PCI_3S_PERR#

PCI_3S_LOCK#
PCI_3S_REQ#(0)
PCI_3S_REQ#(1)
PCI_3S_REQ#(2)
PCI_3S_REQ#(3)

PCI_3S_INTA#
PCI_3S_INTB#
PCI_3S_INTC#
PCI_3S_INTD#
PCI_3S_INTE#

PCI_3S_INTF#

PCI_3S_INTG#

RUNSCI0#_3

VRHOT#

38-,41-,46-,47-

38-,41-,46-,47-

38-,41-,46-,47-

38-,41-,46-,47-

38-,41-,46-,47-

38-,41-,46-,47-

38-,41-,46-,47-

38-

38-,46-

38-,46-,47-

38-,41-

38-,47-

38-,41-

38-,41-

38-,41-

38-,46-

38-,46-,47-

38-,47-

38-

37-,60-

37-

R147

R1027

R1018

R976

R1017

R977

R194

R195

R193

R975

R146

R173

R1020

R196

R1028

R172

R1019

R1014

R1015

R176

R1012

8.2K_5%

12

8.2K_5%

12

8.2K_5%12

8.2K_5%12

12

8.2K_5%

8.2K_5%12

8.2K_5%12

12

8.2K_5%

8.2K_5%12

8.2K_5%

12

8.2K_5%12

1

2

8.2K_5%

8.2K_5%12

8.2K_5%

12

8.2K_5%12

8.2K_5%

12

8.2K_5%

12

8.2K_5%1

2

1

8.2K_5%

2

8.2K_5%1

2

8.2K_5%

12

http://hobi-elektronika.net

WS

CHANGE by

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

INVENTEC

TITLE

HONOLULU

ICH8-3

CODESIZE

A3

CS

13-Apr-2007TIGER

SHEET

DOC. NUMBER

Model_No

38 78

REV

A02

OF

http://laptopblue.vnhttp://laptopblue.vn

+V_RTC

36-

1

C138

0.1uF_16v

2

7-,8-,9-,12-,57-,60-,64-,65-,68-

8-,16-,25-,36-,37-,39-,45-,53-,59-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C137

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

+V3S

+V5S

CHENMKO_BAT54_3P

13

D817

R1029

12

10_1%

C1003

0.1uF_16v

CHENMKO_BAT54_3P D818

1
2

+V3A

+V5A

1
2

0.1uF_16v

+V1.5S

1

C136

220uF_2.5v

2

+V1.5S

8-,16-,25-,36-,37-,39-,45-,53-,59-

L26

12

BLM11A121S

+V1.5S

8-,16-,25-,36-,37-,39-,45-,53-,59-

+V1.5S

8-,16-,25-,36-,37-,39-,45-,53-,59-

8-,16-,25-,36-,37-,39-,45-,53-,59-

+V1.5S

8-,16-,25-,36-,37-,39-,45-,53-,59-

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C956

0.1uF_16v

+V1.5S

1
2

8-,16-,25-,36-,37-,39-,45-,53-,59-

12

10_5%

C953

1
2

0.1uF_16v

10uF_6.3v

C981

0.1uF_16v

L24

12

BLM11A121S

1

3

R1059

ES

0.1uF_16v

C954

1
2

0.1uF_16v

1

C209

2

+V1.5S

+V1.5S

8-,16-,25-,36-,37-,39-,45-,53-,59-

1
2

C1014

1uF_6.3v

1
2

1
2

1
2

VCCSATAPLL

1

C218

2

1
2

1uF_6.3v

1

1uF_6.3v

2

L27

12

BLM11A121S

VCCGLANPLL

C179

10uF_6.3v

C955

0.1uF_16v

C999

C1001

0.1uF_16v

C180

1
2

2.2uF_6.3v

C216

+V3A

1
2

1
2

1
2

1
2

1
2

C949

0.1uF_16v

C140

0.1uF_16v

C979

0.1uF_16v

C207

0.1uF_16v

C950

0.1uF_16v

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

C952

1

0.1uF_16v

2

VCCDMPLL

C134

1
2

0.01uF_16v

+VCCP

C948

1
2

0.1uF_16v

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C1000

1
2

0.1uF_16v

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

12

1

C135

2

10uF_6.3v

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

C951

1
2

4.7uF_6.3v

+V3S

+V3S

+V3S

C976

1
2

0.1uF_16v

R121

0_5%

+V3A

1
2

+V1.5S

8-,16-,25-,36-,37-,39-,45-,53-,59-

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

C975

0.1uF_16v

+V3A

C980

1
2

4.7uF_6.3v

INVENTEC

TITLE

HONOLULU

ICH8-4

SIZE REV

TIGER

13-Apr-2007

CODE DOC. NUMBER

A3

CS

SHEETCHANGE by

39 78

A02Model_No

OF

U7-6

AD25

VCCRTC

A16

V5REF1

T7

V5REF2

G4

V5REF_SUS

AA25

VCC1_5_B1

AA26

VCC1_5_B2

AA27

VCC1_5_B3

AB27

VCC1_5_B4

AB28

VCC1_5_B5

AB29

VCC1_5_B6

D28

VCC1_5_B7

D29

VCC1_5_B8

E25

VCC1_5_B9

E26

VCC1_5_B10

E27

VCC1_5_B11

F24

VCC1_5_B12

F25

VCC1_5_B13

G24

VCC1_5_B14

H23

VCC1_5_B15

H24

VCC1_5_B16

J23

VCC1_5_B17

J24

VCC1_5_B18

K24

VCC1_5_B19

K25

VCC1_5_B20

L23

VCC1_5_B21

L24

VCC1_5_B22

L25

VCC1_5_B23

M24

VCC1_5_B24

M25

VCC1_5_B25

N23

VCC1_5_B26

N24
N25
P24
P25
R24
R25
R26
R27
T23
T24
T27
T28
T29
U24
U25
V23
V24
V25

W25

Y25

AJ6

AE7

AF7
AG7
AH7

AJ7

AC1
AC2
AC3
AC4
AC5

AC10

AC9

AA5
AA6

G12

G17

TP853

TP854

H7

AC7
AD7

D1

F1
L6
L7
M6
M7

W23

F17

G18

F19

G20

A24

A26

A27

B26

B27

B28

B25

1
2

VCCA3GP

VCC1_5_B27
VCC1_5_B28
VCC1_5_B29
VCC1_5_B30
VCC1_5_B31
VCC1_5_B32
VCC1_5_B33
VCC1_5_B34
VCC1_5_B35
VCC1_5_B36
VCC1_5_B37
VCC1_5_B38
VCC1_5_B39
VCC1_5_B40
VCC1_5_B41
VCC1_5_B42
VCC1_5_B43
VCC1_5_B44
VCC1_5_B45
VCC1_5_B46

VCCSATAPLL

VCC1_5_A1
VCC1_5_A2
VCC1_5_A3
VCC1_5_A4
VCC1_5_A5

VCC1_5_A6
VCC1_5_A7
VCC1_5_A8
VCC1_5_A9
VCC1_5_A10

VCC1_5_A11
VCC1_5_A12

VCC1_5_A13
VCC1_5_A14

VCC1_5_A15
VCC1_5_A16
VCC1_5_A17

VCC1_5_A18
VCC1_5_A19

VCCUSBPLL

VCC1_5_A20
VCC1_5_A21
VCC1_5_A22
VCC1_5_A23
VCC1_5_A24

VCC1_5_A25

VCCLAN1_05_1
VCCLAN1_05_2

VCCLAN3_03_1
VCCLAN3_03_2

VCCGLANPLL

VCCGLAN1_5_1
VCCGLAN1_5_2
VCCGLAN1_5_3
VCCGLAN1_5_4
VCCGLAN1_5_5

VCCGLAN3_3

ITL_ICH8M_BGA_TSB_676P

http://hobi-elektronika.net

VCCP

ARXATX

VCCPSUS

USB_CORE

VCCPUSB

GLAN POWER

VCC1_05_1
VCC1_05_2
VCC1_05_3
VCC1_05_4
VCC1_05_5
VCC1_05_6
VCC1_05_7
VCC1_05_8

VCC1_05_9
VCC1_05_10
VCC1_05_11
VCC1_05_12
VCC1_05_13
VCC1_05_14
VCC1_05_15

CORE

VCC1_05_16
VCC1_05_17
VCC1_05_18
VCC1_05_19
VCC1_05_20
VCC1_05_21
VCC1_05_22
VCC1_05_23
VCC1_05_24
VCC1_05_25
VCC1_05_26
VCC1_05_27
VCC1_05_28

VCCDMIPLL

VCC_DMI_1

VCC_DMI_2

V_CPU_IO_1
V_CPU_IO_2

VCC3_3_1

VCC3_3_2

VCC3_3_3
VCC3_3_4
VCC3_3_5

CORE

VCC3_3_6

VCC3_3_7
VCC3_3_8
VCC3_3_9

VCC3_3_10

IDE

VCC3_3_11

VCC3_3_12

VCC3_3_13

VCC3_3_14

VCC3_3_15

VCC3_3_16

VCC3_3_17

VCC3_3_18

VCC3_3_19

PCI

VCC3_3_20

VCC3_3_21

VCC3_3_22

VCC3_3_23

VCC3_3_24

VCCHDA

VCCSUSHDA

VCCSUS1_05_1
VCCSUS1_05_2

VCCSUS1_5_1

VCCSUS1_5_2

VCCSUS3_3_1

VCCSUS3_3_2
VCCSUS3_3_3
VCCSUS3_3_4
VCCSUS3_3_5
VCCSUS3_3_6

VCCSUS3_3_7
VCCSUS3_3_8

VCCSUS3_3_9
VCCSUS3_3_10
VCCSUS3_3_11
VCCSUS3_3_12
VCCSUS3_3_13
VCCSUS3_3_14
VCCSUS3_3_15
VCCSUS3_3_16
VCCSUS3_3_17
VCCSUS3_3_18
VCCSUS3_3_19

VCCCL1_05

VCCCL1_5

VCCCL3_3_1
VCCCL3_3_2

A13
B13
C13
C14
D14
E14
F14
G14
L11
L12
L14
L16
L17
L18
M11
M18
P11
P18
T11
T18
U11
U18
V11
V12
V14
V16
V17
V18

R29

AE28
AE29

AC23
AC24

AF29

AD2

AC8
AD8
AE8
AF8

AA3
U7
V7
W1
W6
W7
Y7

A8
B15
B18
B4
B9
C15
D13
D5
E10
E7
F11

AC12

AD11

J6
AF20

AC16

J7

C3

AC18
AC21
AC22
AG20
AH28

P6
P7
C1
N7
P1
P2
P3
P4
P5
R1
R3
R5
R6

G22

A22

F20
G21

1
2

C978

1
2

0.1uF_16v

+V1.25S

9-,19-,25-

C139

1
2

22uF_6.3v

C957

C983

1

0.1uF_16v

2

0.1uF_16v

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

1

C922

2

0.1uF_16v

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

http://laptopblue.vnhttp://laptopblue.vn

U7-5

A23

VSS001

A5

VSS002

AA2

VSS003

AA7

VSS004

A25

VSS005

AB1

VSS006

AB24

VSS007

AC11

VSS008

AC14

VSS009

AC25

VSS010

AC26

VSS011

AC27

VSS012

AD17

VSS013

AD20

VSS014

AD28

VSS015

AD29

VSS016

AD3

VSS017

AD4

VSS018

AD6

VSS019

AE1

VSS020

AE12

VSS021

AE2

VSS022

AE22

VSS023

AD1

VSS024

AE25

VSS025

AE5

VSS026

AE6

VSS027

AE9

VSS028

AF14

VSS029

AF16

VSS030

AF18

VSS031

AF3

VSS032

AF4

VSS033

AG5

VSS034

AG6

VSS035

AH10

VSS036

AH13

VSS037

AH16

VSS038

AH19

VSS039

AH2

VSS040

AF28

VSS041

AH22

VSS042

AH24

VSS043

AH26

VSS044

AH3

VSS045

AH4

VSS046

AH8

VSS047

AJ5

VSS048

B11

VSS049

B14

VSS050

B17

VSS051

B2

VSS052

B20

VSS053

B22

VSS054

B8

VSS055

C24

VSS056

C26

VSS057

C27

VSS058

C6

VSS059

D12

VSS060

D15

VSS061

D18

VSS062

D2

VSS063

D4

VSS064

E21

VSS065

E24

VSS066

E4

VSS067

E9

VSS068

F15

VSS069

E23

VSS070

F28

VSS071

F29

VSS072

F7

VSS073

G1

VSS074

E2

VSS075

G10

VSS076

G13

VSS077

G19

VSS078

G23

VSS079

G25

VSS080

G26

VSS081

G27

VSS082

H25

VSS083

H28

VSS084

H29

VSS085

H3

VSS086

H6

VSS087

J1

VSS088

J25

VSS089

J26

VSS090

J27

VSS091

J4

VSS092

J5

VSS093

K23

VSS094

K28

VSS095

K29

VSS096

K3

VSS097

K6

VSS098

ITL_ICH8M_BGA_TSB_676P

VSS099
VSS100
VSS101
VSS102
VSS103
VSS104
VSS105
VSS106
VSS107
VSS108
VSS109
VSS110
VSS111
VSS112
VSS113
VSS114
VSS115
VSS116
VSS117
VSS118
VSS119
VSS120
VSS121
VSS122
VSS123
VSS124
VSS125
VSS126
VSS127
VSS128
VSS129
VSS130
VSS131
VSS132
VSS133
VSS134
VSS135
VSS136
VSS137
VSS138
VSS139
VSS140
VSS141
VSS142
VSS143
VSS144
VSS145
VSS146
VSS147
VSS148
VSS149
VSS150
VSS151
VSS152
VSS153
VSS154
VSS155
VSS156
VSS157
VSS158
VSS159
VSS160
VSS161
VSS162
VSS163
VSS164
VSS165
VSS166
VSS167
VSS168
VSS169
VSS170
VSS171
VSS172
VSS173
VSS174
VSS175
VSS176
VSS177
VSS178
VSS179
VSS180
VSS181
VSS182
VSS183

VSS184
VSS_NCTF_01
VSS_NCTF_02
VSS_NCTF_03
VSS_NCTF_04
VSS_NCTF_05
VSS_NCTF_06
VSS_NCTF_07
VSS_NCTF_08
VSS_NCTF_09

VSS_NCTF_010
VSS_NCTF_011
VSS_NCTF_012

K7
L1
L13
L15
L26
L27
L4
L5
M12
M13
M14
M15
M16
M17
M23
M28
M29
M3
N1
N11
N12
N13
N14
N15
N16
N17
N18
N26
N27
N4
N5
N6
P12
P13
P14
P15
P16
P17
P23
P28
P29
R11
R12
R13
R14
R15
R16
R17
R18
R28
R4
T12
T13
T14
T15
T16
T17
T2
U12
U13
U14
U15
U16
U17
U23
U26
U27
U3
U5
V13
V15
V28
V29
W2
W26
W27
Y28
Y29
Y4
AB4
AB23
AB5
AB6
AD5
U4
W24
A1
A2
A28
A29
AH1
AH29
AJ1
AJ2
AJ28
AJ29
B1
B29

http://hobi-elektronika.net

CHANGE by

INVENTEC

TITLE

HONOLULU

ICH8-5

CODESIZE

CS

SHEET

DOC. NUMBER

40 78

13-Apr-2007TIGER

A3

REV

A02Model_No

OF

http://laptopblue.vnhttp://laptopblue.vn

PCI_3S_RST#

34-,38-,42-,45-,46-,56-

R1112

12

60-

OPEN

R1111

12

0_5%

GRST#

PCI_3S_AD(31:0)

PCI_3S_CBE#(3)
PCI_3S_CBE#(2)
PCI_3S_CBE#(1)
PCI_3S_CBE#(0)

PCI_3S_PAR

PCI_3S_FRAME#

PCI_3S_TRDY#

PCI_3S_IRDY#

PCI_3S_STOP#

PCI_3S_DEVSEL#

PCI_3S_AD(22)
PCI_3S_PERR#

PCI_3S_SERR#

PCI_3S_REQ#(2)

PCI_3S_GNT#(2)

CLK_R3S_CBPCI

PCI_3S_PME#

38-,41-,46-,47-

38-,46-,47­38-,46-,47­38-,46-,47­38-,46-,47-

38-,46-,47-

38-,46-,47­38-,46-,47­38-,46-,47­38-,46-,47­38-,46-,47­38-,41-,46-,47-

R1113

38-,46-,47­38-,46-,47-

38­38-

13-

38-

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

R1094

PCI_3S_AD(31)
PCI_3S_AD(30)
PCI_3S_AD(29)
PCI_3S_AD(28)
PCI_3S_AD(27)
PCI_3S_AD(26)
PCI_3S_AD(25)
PCI_3S_AD(24)
PCI_3S_AD(23)
PCI_3S_AD(22)
PCI_3S_AD(21)
PCI_3S_AD(20)
PCI_3S_AD(19)
PCI_3S_AD(18)
PCI_3S_AD(17)
PCI_3S_AD(16)
PCI_3S_AD(15)
PCI_3S_AD(14)
PCI_3S_AD(13)
PCI_3S_AD(12)
PCI_3S_AD(11)
PCI_3S_AD(10)
PCI_3S_AD(9)
PCI_3S_AD(8)
PCI_3S_AD(7)
PCI_3S_AD(6)
PCI_3S_AD(5)
PCI_3S_AD(4)
PCI_3S_AD(3)
PCI_3S_AD(2)
PCI_3S_AD(1)
PCI_3S_AD(0)

12

10K_5%

12

U25-1

W8

VCCP

P1

VCCP

DATA_VD2_VPPDI

M1

CLOCK_VD1_VCCD0#

AD31

M2

AD30

LATCH_VD3_VPPD0

M3

AD29

M6

AD28

M5

AD27

N1

AD26

N2

AD25

N3

AD24

P3

AD23

R1

AD22

R2

AD21

P5

AD20

R3

AD19

T1

AD18

T2 42-

AD17

W4

AD16

W7

AD15

R8

AD14

U8

AD13

V8

AD12

W9

AD11

V9

AD10

U9

AD9

R9

AD8

V10

AD7

U10

AD6

R10

AD5

W11

AD4

V11

AD3

U11

AD2

P11

AD1

R11

AD0

P2

C_BE3#

U5

C_BE2#

V7

C_BE1#

W10

C_BE0#

U7

PAR

R6

FRAME#

W5

TRDY#

V5

IRDY#

V6

STOP#

U6

DEVSEL#

N5

100_5%

IDSEL

R7

PERR#

W6

SERR#

L3

REQ#

L2

GNT#

L1

PCLK

K3

RSVD_VD0_VCCD1#

PRST#

K5

GRST#

L5

RI_OUT#_PME#

TI_PCI8412_PBGA_216P

SUSPEND#

SPKOUT

MFUNC0
MFUNC1
MFUNC2
MFUNC3
MFUNC4
MFUNC5
MFUNC6

CLK_48

USB_EN#

VR_PORT
VR_PORT

VR_EN#

RSVD

RSVD
RSVD

RSVD

RSVD

RSVD
RSVD
RSVD

TEST0

RSVD_D14
RSVD_A18

RSVD_D2

SCL
SDA

VCC

J5

B9
A9
C9

H3

G1
H5
H2
H1
J1
J2
J3

F1

E10

G2
G3

K19
K1
K2

F3

E2
E1

E3

G5

F2
D1
F5

G6

P12

M19
H17
C4
B10

R1097

150_5%

12

12

R1109

R1108

220_5%

220_5%

12

12

0.1uF_10v

C1072

12

0.1uF_10v

TP5

Used for xx11 MLS

43-

R1098

12

220_5%

42­42-

12

R1104

43K_5%

42-

R1096

C1016

42­42-

42-

64-

A_3S_PCSPKR

38­38­38-

37-,60-

10K_5%

68-

37-,46-,47-,60-

13-

12

SC_RFU_SM_RBZ

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

ACARD_3S_D(14)_RFU
ACARD_3S_A18_RFU

ACARD_3S_D(2)_RFU

S_DATA

S_CLOCK

S_LATCH

PCI_3S_INTC#
PCI_3S_INTB#
PCI_3S_INTA#
PCI_3S_SERIRQ

LED_6IN1

PCI_3S_CLKRUN#
CLK_R3S_CARD48

1

R1110

0_5%

2

+V3S

+V3S

+V3S

1
2

C1037

1
2

0.1uF_16v

C1062

0.1uF_16v

C1073

1
2

0.1uF_16v

1
2

C1063

0.1uF_16v

C1015

1
2

0.1uF_16v

1
2

C1064

0.1uF_16v

C1038

1
2

0.1uF_16v

U25-2

CC_BE3#_REG#

CC_BE0#_CE1#

P6

VCC

P8

P10

L6

L14

J6

J14

F6

F9
F12
F14

P7

P9

N6

M14

K6

K14

H6

G14

F7
F10
F13

CDEVSEL#_A21

VCC
VCC
VCC
VCC

CSERR#_WAIT#

VCC
VCC

CREQ#_INPACK#

VCC
VCC
VCC

CSTSCHG_BVD1

VCC

CCLKRUN#_WP
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND

TI_PCI8412_PBGA_216P

VCCB
VCCB

CAD31_D10

CAD30_D9
CAD29_D1
CAD28_D8
CAD27_D0
CAD26_A0
CAD25_A1
CAD24_A2
CAD23_A3
CAD22_A4
CAD21_A5
CAD20_A6

CAD19_A25

CAD18_A7
CAD17_A24
CAD16_A17

CAD15_IOWR#

CAD14_A9

CAD13_IORD#

CAD12_A11

CAD11_OE#

CAD10_CE2#

CAD9_A10

CAD8_D15

CAD7_D7

CAD6_D13

CAD5_D6

CAD4_D12

CAD3_D5

CAD2_D11

CAD1_D4
CAD0_D3

CC_BE2#_A12

CC_BE1#_A8

CPAR_A13

CFRAME#_A23

CTRDY#_A22

CIRDY#_A15

CSTOP#_A20

CBLOCK#_A19

CPERR#_A14

CGNT#_WE#

CCLK_A16

CINT#_READY

CRST#_RESET

CAUDIO_BVD2

CCD1#_CD1#
CCD2#_CD2#

CVS1_VS1#
CVS2_VS2#

ACARDVCC

42-

A15
J19

C10
A10
F11
E11
C11
B13
C13
A14
B14
B15
E14
A16
D19
E17
F15
H19
J17
J15
J18
K15
K17
K18
L15
L18
L19
M17
M18
N19
M15
N17
N18
P19

E13
E18
H18
L17

H14

E19
G15
F17
G18
F19
H15

G19
C12

C14
G17

A12
A11
F18

E12

C15

B12

N15
B11
A13
B16

42-

ACARD_3S_AD31

42-

ACARD_3S_AD30

42-

ACARD_3S_AD29

42-

ACARD_3S_AD28

42-

ACARD_3S_AD27

42-

ACARD_3S_AD26

42-

ACARD_3S_AD25

42-

ACARD_3S_AD24

42-

ACARD_3S_AD23

42-

ACARD_3S_AD22

42-

ACARD_3S_AD21

42-

ACARD_3S_AD20

42-

ACARD_3S_AD19

42-

ACARD_3S_AD18

42-

ACARD_3S_AD17

42-

ACARD_3S_AD16

42-

ACARD_3S_AD15

42-

ACARD_3S_AD14

42-

ACARD_3S_AD13
ACARD_3S_AD12

42-

ACARD_3S_AD11

42-

ACARD_3S_AD10

42-

ACARD_3S_AD9

42-

ACARD_3S_AD8

42-

ACARD_3S_AD7

42-

ACARD_3S_AD6

42-

ACARD_3S_AD5

42-

ACARD_3S_AD4

42-

ACARD_3S_AD3

42-

ACARD_3S_AD2

42-

ACARD_3S_AD1

42-

ACARD_3S_AD0

42-

ACARD_3S_CBE3#

42-

ACARD_3S_CBE2#

42-

ACARD_3S_CBE1#

42-

ACARD_3S_CBE0#

42-

ACARD_3S_PAR

42-

ACARD_3S_FRAME#

42-

ACARD_3S_TRDY#

42-

ACARD_3S_IRDY#

42-

ACARD_3S_STOP#

42-

ACARD_3S_DEVSEL#

42-

ACARD_3S_BLOCK#

42-

ACARD_3S_PERR#

42-

ACARD_3S_SERR#

42-

ACARD_3S_REQ#

42-

ACARD_3S_GNT#

42-

ACARD_3S_STSCHG

42-

ACARD_3S_CLKRUN#

42-

ACARD_3S_CLK

42-

ACARD_3S_INT#

42-

ACARD_3S_RST#

42-

ACARD_3S_AUDIO

42-

ACARD_3S_CD1#

42-

ACARD_3S_CD2#

42-

ACARD_3S_VS1#

42-

ACARD_3S_VS2#

http://hobi-elektronika.net

CHANGE by

INVENTEC

TITLE

HONOLULU

CARDBUS CONTROLLER

CODE

SIZE

13-Apr-2007TIGER

A3

CS

SHEET

DOC. NUMBER

OF

41 78

REV

A02Model_No

ACARDVCC

C1065

1
2

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

ACARDVCC ACARDVPP

41-,42-

0.1uF_16v

1
2

42-

C1067

0.1uF_16v

S_DATA
S_CLOCK
S_LATCH

41-,42-

C1075

1
2

4.7uF_6.3v

41­41-

41-

PCI_3S_RST#

+V5S

34-,38-,41-,45-,46-,56-

http://laptopblue.vnhttp://laptopblue.vn

41­41­41­41­41­41­41­41­41­41­41­41­41­41­41-

41­41­41­41­41­41­41­41­41­41­41­41­41-

41­41­41­41­41­41­41­41­41­41­41­41­41­41­41-

41­41­41­41­41­41­41­41­41­41­41­41­41­41­41-

FOX_WZ21131_G2_8F_68P

C1069

1
2

0.1uF_16v

U816

1
2
3
4
5
6
7
8

9
10
11
12

NC

5V

NC

5V
DATA

NC

SHDN

CLOCK
LATCH

NC
NC

NC

NC

12V
AVPP

NC

AVCC

NC

OC

AVCC
GND

NC

RESET

3.3V

GND

25

TI_TPS2220BPWPR_HTSSOP_24P

ACARDVPP

C1068

1

1

2

2

0.1uF_16v

24
23
22

7-,8-,9-,11-,12-,30-,37-,60-,64-

21
20
19
18
17
16
15
14
13

42-

C1066

4.7uF_6.3v

ACARD_3S_CLK

SLP_S3#_3R

+V3S

R1060

12

41-

33_5%

ACARD_3S_CLKRUN#

ACARDVPP

42-

ACARDVCCACARDVPP

41-,42-42-

R1100

12

OPEN

41-

ACARD_3S_AD0
ACARD_3S_AD1
ACARD_3S_AD3
ACARD_3S_AD5
ACARD_3S_AD7

ACARD_3S_CBE0#

ACARD_3S_AD9
ACARD_3S_AD11
ACARD_3S_AD12
ACARD_3S_AD14

ACARD_3S_CBE1#

ACARD_3S_PAR

ACARD_3S_PERR#

ACARD_3S_GNT#

ACARD_3S_INT#

ACARD_3S_IRDY#

ACARD_3S_CBE2#

ACARD_3S_AD18
ACARD_3S_AD20
ACARD_3S_AD21
ACARD_3S_AD22
ACARD_3S_AD23
ACARD_3S_AD24
ACARD_3S_AD25
ACARD_3S_AD26
ACARD_3S_AD27
ACARD_3S_AD29

ACARD_3S_D(2)_RFU

ACARD_3S_CD1#

ACARD_3S_AD2

ACARD_3S_AD4

ACARD_3S_AD6

ACARD_3S_D(14)_RFU

ACARD_3S_AD8
ACARD_3S_AD10
ACARD_3S_VS1#
ACARD_3S_AD13
ACARD_3S_AD15
ACARD_3S_AD16

ACARD_3S_A18_RFU

ACARD_3S_BLOCK#

ACARD_3S_STOP#

ACARD_3S_DEVSEL#

ACARD_3S_TRDY#

ACARD_3S_FRAME#

ACARD_3S_AD17
ACARD_3S_AD19
ACARD_3S_VS2#
ACARD_3S_RST#

ACARD_3S_SERR#

ACARD_3S_REQ#
ACARD_3S_CBE3#
ACARD_3S_AUDIO

ACARD_3S_STSCHG

ACARD_3S_AD28
ACARD_3S_AD30
ACARD_3S_AD31
ACARD_3S_CD2#

10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68

1
2
3
4
5
6
7
8
9

CN810

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68

G1

G

G2

G

G3

G

G4

G

G5

G

G6

G

G7

G

G8

G

G9

G

G10

G

G11

G

G12

G

G13

G

G14

G

G15

G

G16

G

G17

G

G18

G

G19

G

G20

G

http://hobi-elektronika.net

CHANGE by

TIGER 13-Apr-2007

INVENTEC

TITLE

HONOLULU

PCMCIA

CODECSDOC. NUMBER REV

SIZE

A3

Model_No A02

CS

SHEET

OF

7842

http://laptopblue.vnhttp://laptopblue.vn

MS_CLK_SD_CLK_SM_ELWPZ

MC_3S_PWREN#

C1501

68pF_50v

43-

1
2

R1095

33_5%

12

PWR_CTRL_SM_RBZ

MS_BS_SD_CMD_SM_WEZ

MS_DATA3_SD_DAT3_SM_D3
MS_DATA2_SD_DAT2_SM_D2
MS_DATA1_SD_DAT1_SM_D1
MS_DATA0_SD_DAT0_SM_D0

MC_3S_PWREN#

43-

MP

1

R1114

OPEN

2

VCC_MC

+V3S

1
2

C1078

22uF_6.3v

U818

1

2

4

GMT_G545B2P8U_MSOP_8P

GND

IN

IN3OUT

EN#

8

OUT

7

OUT

6

5

OC#

1

C1076

0.1uF_10v

2

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R1115

47K_5%

2

43-

U25-3

C8

MC_PWR_CTRL0

43-

MS_CDZ

F8

MC_PWR_CTRL1

43-

A8

MS_CD#

A7

MS_CLK_SD_CLK_SM_EL_WP#

43-

E8

MS_BS_SD_CMD_SM_WE#

43-

B6

MS_DATA3_SD_DAT3_SM_D3

43-

A6

MS_DATA2_SD_DAT2_SM_D2

43-

C7

MS_DATA1_SD_DAT1_SM_D1

43-

B7

MS_SDIO_SD_DAT0_SM_D0

SD_CLK_SM_RE#_SC_GPIO1
SD_CMD_SM_ALE_SC_GPIO2

TI_PCI8412_PBGA_216P

VCC_MC

43-

12

R1107

22K_5%

12

SC_RFU_SM_RBZ

PWR_CTRL_SM_RBZ SM_RBZ

43-

C1077

1
2

22uF_6.3v

41-

R1105

OPEN

12

43-

R1106

0_5%

MS_BS_SD_CMD_SM_WEZ
MS_DATA1_SD_DAT1_SM_D1
MS_DATA0_SD_DAT0_SM_D0
MS_DATA2_SD_DAT2_SM_D2

MS_DATA3_SD_DAT3_SM_D3

MS_CLK_SD_CLK_SM_ELWPZ

MS_DATA2_SD_DAT2_SM_D2
MS_DATA3_SD_DAT3_SM_D3

MS_BS_SD_CMD_SM_WEZ

MS_CLK_SD_CLK_SM_ELWPZ

MS_DATA0_SD_DAT0_SM_D0
MS_DATA1_SD_DAT1_SM_D1

http://hobi-elektronika.net

SD_CD#

SD_DAT0_SM_D4_SC_GPIO6
SD_DAT1_SM_D5_SC_GPIO5
SD_DAT2_SM_D6_SC_GPIO4
SD_DAT3_SM_D7_SC_GPIO3

SD_WP_SM_CE#

SM_CD#

SM_CLE_SC_GPIO0

XD_CD#_SM_PHYS_WP#

43-

MS_CDZ

SD_CDZ

SD_WP_SM_CEZ

E9
A4
C5

C6
A5
B5
E6
E7

TP4

B8

B4
A3

43­43­43­43­43­43­43-

43­43­43-

43-

43­43­43-

43-

43-

SD_CDZ

43-

SM_REZ

43-

SM_ALE

43-

SM_D4

43-

SM_D5

43-

SM_D6

43-

SM_D7

43-

SD_WP_SM_CEZ

43-

SM_CLE

43-

XD_CDZ

VCC_MC

43-

2

R252

R251

R292

R293

12

1

100K_5%

MP

CN8

1

MS-GND

2

MS-BS

3

MS-DATA1

4

MS-DATA0

5

MS-DATA2

6

MS-INS

7

MS-DATA3

8

MS-SCLK

9

MS-VCC

10

MS-GND

18

NC

42

NC

11

SD-DAT2

12

SD-DAT3

13

SD-CMD

14

SD-GND

15

SD-VCC

16

SD-CLK

17

SD-GND

19

SD-DAT0

20

SD-DAT1

21

SD-CD-SW

22

SD_COM

43

SD-WP-SW

44

SD_COM

TAI_R012_213_LR_44P

R1062

12

33_5%

CHANGE by SHEET OF

OPEN

12

12

100K_5%

100K_5%

43-

XD_CDZ
MS_BS_SD_CMD_SM_WEZ

43­43-

SM_REZ

43-

SD_WP_SM_CEZ

VCC_MC

43-

C233

1
2

1uF_6.3v

R253

12

OPEN

23

xD-CD

24

xD-GND

25

xD-R_B

26

xD-RE

27

xD-CE

28

xD-CLE

29

xD-ALE

30

xD-WE

31

xD-WP

32

xD-GND

33

xD-D0

34

xD-D1

35

xD-D2

36

xD-D3

37

xD-D4

38

xD-D5

39

xD-D6

40

xD-D7

41

xD-VCC

G1

GND

G2

GND

TIGER 13-Apr-2007

C234

C1074

1

1

2

2

1uF_6.3v

1uF_6.3v

43-

XD_CDZ

43-

SM_RBZ

43-

SM_REZ

43-

SD_WP_SM_CEZ

43-

SM_CLE

43-

SM_ALE

43-

MS_BS_SD_CMD_SM_WEZ

43-

MS_DATA0_SD_DAT0_SM_D0

43-

MS_DATA1_SD_DAT1_SM_D1

43-

MS_DATA2_SD_DAT2_SM_D2

43-

MS_DATA3_SD_DAT3_SM_D3

43-

SM_D4

43-

SM_D5

43-

SM_D6

43-

SM_D7

TITLE

INVENTEC

HONOLULU

MEMORY CARD CONN

SIZE CODE DOC. NUMBER REV

A3

Model_No A02

CS

7843

http://laptopblue.vnhttp://laptopblue.vn

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

12

18pF_50v

C1017

12

18pF_50v

C1018

24.576MHZ

+V3S

R1099

12

1K_5%

1

X802

2

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C1020

1

C1019

0.1uF_16v

2

10uF_6.3v

U25-4

R12

CPS

R18

XO

R19

XI

R14

AGND

U13

AGND

U14

AGND

W17

RSVD

V16

RSVD

W16

RSVD

V15

RSVD

W15

RSVD

TI_PCI8412_PBGA_216P

AVDD_33
AVDD_33
AVDD_33

VDDPLL_33

VDDPLL_15

VSSPLL

TPBIAS0

TPA0+

TPA0-

TPB0+

TPB0-

PHY_TEST_MA

R0

R1

P13
P14
U15

U19

P15
R17

T18

T19

R13

V14
W14

V13
W13

P17

R1061

12

6.34K_1%

R1063

12

4.7K_5%

44-

44­44-

44­44-

1394_TPBIAS0
1394_TPA0P

1394_TPA0N
1394_TPB0P

1394_TPB0N

+V3S

L816

12

BLM21A121S

1
2

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C1021

1
2

0.1uF_10v

1
2

C1022

1uF_6.3v

C1039

1
2

0.01uF_16v

L818

12

BLM21A121S

1

C1023

2

10uF_6.3v

+V3S

CN817

1

G1

GND

1

2

G2

GND

2

3

3

4

SYN_020015FR004S517ZL_4P

4

44­44­44­44-

1394_L_TPB0N
1394_L_TPB0P
1394_L_TPA0N
1394_L_TPA0P

1394_L_TPB0P
1394_L_TPB0N
1394_L_TPA0P
1394_L_TPA0N

C1040

1uF_6.3v

R1077

12

56.2_1%

R1078

12

56.2_1%

1

2

1

L31

3

2

44­44­44­44-

WCM_2012_900T

3

2

4

1

L30

4

1

2

WCM_2012_900T

NEAR TO CN

http://hobi-elektronika.net

1

R1080

56.2_1%

2

C1041

NEAR TO IC

CHANGE by

R1079

56.2_1%

R1081

12

5.1K_5%

12

220pF_25v

44­44­44­44­44-

1394_TPBIAS0
1394_TPB0P
1394_TPB0N
1394_TPA0P
1394_TPA0N

INVENTEC

TITLE

HONOLULU

1394

SIZE

13-Apr-2007TIGER

A3

CODE

CS

DOC. NUMBER

44 78

REV

A02Model_No

OFSHEET

http://laptopblue.vnhttp://laptopblue.vn

+V3AUX_EXP

C1049

45-

+V3_EXP

45-

1
2

C1025

1
2

0.1uF_16v_OPEN

26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10

9
8
7
6
5
4
3
2
1

FOX_1CH4312C_TB_26P_OPEN

CN809

GND
PETp0
PETn0
GND
PERp0
PERn0
GND
REFLCK+
REFLCK­CPPE#
CLKREQ#

+V3.3V
+V3.3V
PERST#
+3.3VAux
WAKE#
+1.5V
+1.5V
SMBDATA
SMBCLK
RESERVED
RESERVED
CPUSB#
USBD+
USBD­GND

CS

G1

G

G2

G

PCIE_C_TXP5

PCIE_C_TXN5

PCIE_C_RXP5
PCIE_C_RXN5

CLK_R_PCIE_CARD

CLK_R_PCIE_CARD#

EXPRESS_CLKREQ#

CPPE#

PERST#

PCIE_WAKE#

ICH_3A_ALERT_DAT
ICH_3A_ALERT_CLK

CPUSB#

USB_P4+

USB_P4-

+V3AUX_EXP

37­37-

37­37­13­13-

37-,45-,60­45-

45-

37-,50-,53-,59-

37-,53-,59­37-,53-,59-

45-

37­37-

45-

1

R1082

10K_5%_OPEN

2

C1042

0.1uF_16v_OPEN

0.1uF_16v_OPEN

+V1.5_EXP

45-

1
2

+V3_EXP

45-

1
2

0.1uF_16v_OPEN

C1026

C1024

1
2

10uF_6.3v_OPEN

+V3S

1

R1064

OPEN

2

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V3S

U814

C1027

1
2

0.1uF_16v_OPEN

C1028

1
2

10uF_6.3v_OPEN

SUS_STAT#_3

PCI_3S_RST#

PERST#
CPUSB#

CPPE#

37-

1

STBY#

2

3.3VIN

3

3.3VOUT

4

NC

5

NC

10

6
7
8
9

SYSRST#
GND
PERST#
CPUSB#
CPPE#

34-,38-,41-,42-,46-,56-

45­45­37-,45-,60-

TI_TPS2231RGPR_QFN_20P_OPEN

SHDN#

RCLKEN

AUXIN

AUXOUT

1.5VIN

1.5VOUT

20
19

OC#

18
17
16

NC

15
14

NC

13

NC

12
11
21

TML

Q817

3

D

1

G

S

2

2N7002W_OPEN

WS

C1043

1
2

0.1uF_16v_OPEN

http://hobi-elektronika.net

+V3A

1
2

ICH_NEWCARD_SD#

37-

ICH_NEWCARD_OC#

37-

ICH_NEWCARD_CLKEN

13-

EXPRESS_CLKREQ#

45-

+V1.5_EXP

45-

C1044

1
2

10uF_6.3v_OPEN

7-,37-,38-,39-,51-,53-,59-,60-,67-,68-

C1048

0.1uF_16v_OPEN

+V3AUX_EXP

45-

C1047

1
2

0.1uF_16v_OPEN

+V1.5S

8-,16-,25-,36-,37-,39-,53-,59-

C1045

1
2

0.1uF_16v_OPEN

C1046

1
2

10uF_6.3v_OPEN

INVENTEC

TITLE

HONOLULU

Express Card

SIZE

CODE

CHANGE by SHEET OF

13-Apr-2007TIGER

A3

DOC. NUMBER REV

CS

45 78

A02Model_No

TM-P3V

46-

http://laptopblue.vnhttp://laptopblue.vn

46-

+V5S_TVTMA-P5V

12-,46-,47-

MP

PCI_3S_AD[31:0]

38-,41-,46-,47-

PCI_3S_INTE#

X33TU2-P3P
X33TU1-P3P

PCI_3S_REQ#(0)

PCI_3S_CBE#(3)

PCI_3S_REQ#(1)

PCI_3S_CBE#(2)

PCI_3S_IRDY#

PCI_3S_CLKRUN#

PCI_3S_SERR#

PCI_3S_CBE#(1)

PCI_3S_PERR#

BCRSTM-P3N

BCIO-P5P
CPGP2M-P3P
CPGP1M-P3P
CPGP0M-P3P
BCCDET-P3N

XBCLKM-P3P

BCPWON-P3P

CN2003

1

TIP

3

8PMJ-3

5

8PMJ-6

7

8PMJ-7

9

8PMJ-8

11

LED1_GRNP

13

LED1_GRNN

15

CHSGND

38-,47-

13-

13­38­38-,41-,47-

PCI_3S_AD(31)
PCI_3S_AD(29)

PCI_3S_AD(27)
PCI_3S_AD(25)

38-,47-

PCI_3S_AD(23)
PCI_3S_AD(21) PCI_3S_AD(22)

PCI_3S_AD(19) PCI_3S_AD(20)
PCI_3S_AD(17)

38-,41-,47­38-,41-,47-

37-,41-,47-,60-

38-,41-,47­38-,41-,47-

PCI_3S_AD(14) PCI_3S_AD(15)

PCI_3S_AD(10)
PCI_3S_AD(8)

PCI_3S_AD(7)
PCI_3S_AD(5)
PCI_3S_AD(3)
PCI_3S_AD(1)

48­47-,48-,49­47­47-,48­47-,48­49-

48-

48-

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

17

INTB#

19

3.3V_0

21

RESERVED1 RESERVED2

23

GROUND_0

25

CLK

27

GROUND_1

29

REQ#

31

3.3V_2

33

AD31

35

AD29

37

GROUND_3

39

AD27

41

AD25

43

RESERVED4

45

C_BE3#

47

AD23
GROUND_5

51

AD21 AD22

53

AD19 AD20

55

GROUND_6

57

AD17 AD18

59

C_BE2#

61

IRDY#

63

3.3V_4

65

CLKRUN#

67

SERR# STOP#

69

GROUND_8

71

PERR#

73

C_BE1#

75

AD14

77

GROUND_10

79

AD12

81

AD10

83

GROUND_12

85

AD08

87

AD07

89

3.3V_7
AD05

93

RESERVED5

95

AD03

97

5V_1

99

AD01

101
103

AC_SYNC

105

AC_SDATA_IN AC_SDATA_OUT

107

AC_BIT_CLK

109

AC_CODEC_ID1#

111

MOD_AUDIO_MON

113

AUDIO_GND

115

SYS_AUDIO_OUT

117

SYS_AUDIO_OUT_GND

119
121

RESERVED7

123

VCC5VA

G1 G2

G

G3

GG

RESERVED_WIP_0
RESERVED_WIP_1

AC_CODEC_ID0#

SYS_AUDIO_IN_GND

RING
8PMJ-1
8PMJ-2
8PMJ-4
8PMJ-5

LED2_YELP
LED2_YELN

RESERVED0

INTA#

3.3VAUX_0
RST#

3.3V_1
GNT#

GROUND_2

PME#

RESERVED3

AD30

3.3V_3

AD28
AD26
AD24

IDSEL

GROUND_4

AD16

GROUND_7

FRAME#

TRDY#

3.3V_5

DEVSEL#

GROUND_9

AD15
AD13
AD11

GROUND_11

AD09

C_BE0#

3.3V_6

AD06
AD04
AD02
AD00

GROUND_13GROUND_14

M66EN

AC_RESET#
RESERVED6
GROUND_15

SYS_AUDIO_IN

AUDIO_GND_0AUDIO_GND_1

MPCIACT#

3.3VAUX_1

2
4
6
8
10
12
14
16
18

5V_0

20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
5049
52
54
56

PAR

58
60
62
64
66
68
70
72
74
76
78
80
82
84
86
88
90
9291
94
96
98
100
102
104
106
108
110
112
114
116
118
120
122
124

G

G4

FOX_AS0B126_S80S_7F_124P

PCI_3S_AD(30)
PCI_3S_AD(28)

PCI_3S_AD(26)
PCI_3S_AD(24)

PCI_3S_AD(18)
PCI_3S_AD(16)

PCI_3S_AD(13)
PCI_3S_AD(11)PCI_3S_AD(12)

PCI_3S_AD(9)

PCI_3S_AD(6)
PCI_3S_AD(4)
PCI_3S_AD(2)
PCI_3S_AD(0)

KBC_AGND

R364 100_5%12

38-,47-

38-,41-,47­38-,41-,47­38-,41-,47­38-,41-,47-38-,41-,47-

38-,41-,47-

38-,41-,47-

47-,60-

47-,48-

38-

PCI_3S_INTD#

38-,41-,46-,47-

38-

PCI_3S_GNT#(0)
PCI_3S_GNT#(1)

R361

12

38-,41-,46-,47-

100_5%

PCI_3S_PAR
PCI_3S_FRAME#
PCI_3S_TRDY#
PCI_3S_STOP#

PCI_3S_DEVSEL#

PCI_3S_CBE#(0)

48-

CPDETM-P3N

60-

TV1-TPM0

60-

TV1-TPM1
TV1-TPM2

CPGP3M-P3P

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C372

1
2

PCI_RST_TVS

PCI_3S_AD(26)

R365

12

220_5%

47-

0.1uF_16v

VCC

4

Y

ON_NL17SZ17DFT2_SC-70_5P

U21

15

NC

2

A

3

GND

34-,38-,41-,42-,45-,56-

PCI_3S_AD(25)

MP

+V5S_TV

12-,46-,47-

FUSE2

12

3A_32V_466003

ES

BLM31PG121SN1

1
12

R407

L33

12

ES

2

0_5%R366
0_5%

1
2

C376

22uF_6.3v

1
2

C377

22uF_6.3v

ES ES

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

L32

12

BLM31PG121SN1

ES

1
2

C426

22uF_6.3v

1
2

C368

22uF_6.3v

1
2

C430

0.1uF_16v

1
2

C432

0.1uF_16v

1
2

1
2

PCI_3S_RST#

C373

0.1uF_16v

C431

0.1uF_16v

1
2

1
2

C374

0.1uF_16v

C369

0.1uF_16v

1
2

1
2

C434

0.1uF_16v

C427

0.1uF_16v

TMA-P5V

C433

1
2

TM-P3V

1
2

46-

0.1uF_16v

TMA_GND

46-

C429

0.1uF_16v

TMA_GND

TMA_GND

WS

http://hobi-elektronika.net

INVENTECINVENTEC

INVENTEC

INVENTEC

INVENTEC

INVENTEC

TITLE

TITLE

TITLE

TITLE

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

HONOLULU

HONOLULU

HONOLULU

HONOLULU

HONOLULU

HONOLULU

HONOLULU

HONOLULU

HONOLULU

TV Tuner-Master

TV Tuner-Master

TV Tuner-Master

TV Tuner-Master

TV Tuner-Master

TV Tuner-Master

TV Tuner-Master

TV Tuner-Master

TV Tuner-Master

TV Tuner-Master TV Tuner-Master

TV Tuner-Master

SIZE

SIZE

SIZE DOC. NUMBERSIZE

SIZE

A3

A3

A3

A3

A3

A3

A3

A3

A3

A3

CHANGE by SHEETSHEET

CHANGE by SHEET

CHANGE byCHANGE by OF

CHANGE by OF

CHANGE by

TIGER 13-Apr-200713-Apr-2007TIGER

TIGER 13-Apr-2007

TIGER 13-Apr-2007

TIGER 13-Apr-2007

TIGER 13-Apr-2007

TIGER 13-Apr-2007

TIGER 13-Apr-2007

TIGER

13-Apr-2007TIGER

13-Apr-2007TIGER

A3

DOC. NUMBERCODE

DOC. NUMBER

DOC. NUMBER REV

CODE DOC. NUMBER REVCODE

CODECODE

Model_No A02

Model_No A02

Model_No A02

Model_NoA3

Model_No A02

Model_No A02

Model_No A02

Model_No A02

CS

CS

CS

CS

CS

CS

CS

CS

CS

CS

CS

CS

SHEET

SHEET

SHEET

46 78

46 78

46 78

46

46 78

REVSIZE

REVCODE DOC. NUMBER

REV

REV

A02

A02Model_No

A02Model_No

A02Model_No

A02Model_No

OF

OFOF

OF

7846

7846

7846

7846

7846

7846

7813-Apr-200713-Apr-2007TIGER

7846

TS-P3V

47-

TSA-P5V

47-

http://laptopblue.vnhttp://laptopblue.vn

+V5S_TV

12-,46-,47-

MP

PCI_3S_AD[31:0]

PCI_3S_INTE#

38-,41-,46-,47-

ES

R409

12

38-,46-

+V3S

0_5%

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

12

R408 8.2K_5%_OPEN

X33TU4-P3P

WS

X33TU3-P3P

PCI_3S_REQ#(3)

PCI_3S_CBE#(3)

PCI_3S_REQ#(1)

WS

PCI_3S_CBE#(2)

PCI_3S_IRDY#

PCI_3S_CLKRUN#

PCI_3S_SERR#

PCI_3S_CBE#(1)

PCI_3S_PERR#

BCRSTS-P3P

BCIO-P5P
CPGP3M-P3P
CPGP1M-P3P
CPGP0M-P3P
BCDETS-P3N

XBCLKS-P3P

BCPWONS-P3P

WS

WS

13-

13­38­38-,41-,46-

PCI_3S_AD(31)
PCI_3S_AD(29)

PCI_3S_AD(27)
PCI_3S_AD(25)

38-,46-

PCI_3S_AD(23)
PCI_3S_AD(21)

PCI_3S_AD(19)
PCI_3S_AD(17)

38-,41-,46­38-,41-,46-

37-,41-,46-,60­38-,41-,46­38-,41-,46­38-,41-,46-

PCI_3S_AD(14)
PCI_3S_AD(12)

PCI_3S_AD(10)
PCI_3S_AD(8)

PCI_3S_AD(7)
PCI_3S_AD(5)
PCI_3S_AD(3)
PCI_3S_AD(1)

48­46-,48-,49­46-,48­46-,48­46-,48­48-,49-

48-

48-

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

CN2009

1

TIP

3

8PMJ-3

5

8PMJ-6

7

8PMJ-7

9

8PMJ-8

11

LED1_GRNP

13

LED1_GRNN

15

CHSGND

17

INTB#

19

3.3V_0

21

RESERVED_2

23

GROUND_0

25

CLK

27

GROUND_1

29

REQ#

31

3.3V_2

33

AD31

35

AD29

37

GROUND_3

39

AD27

41

AD25

43

RESERVED_4

45

C_BE3#

47

AD23

49

GROUND_5

51

AD21

53 54

AD19

55

GROUND_6

57 58

AD17

59

C_BE2#

61

IRDY#

63

3.3V_4

65

CLKRUN#

67 68

SERR#

69

GROUND_8

71

PERR#

73

C_BE1#

75 76

AD14

77

GROUND_10

79

AD12

81

AD10

83

GROUND_12

85

AD08

87

AD07

89

3.3V_7

91

AD05

93

RESERVED_5

95

AD03

97

5V_1

99

AD01
GROUND_14

103

AC_SYNC

105 106

AC_SDATA_IN

107

AC_BIT_CLK

109

AC_CODEC_ID1#

111

MOD_AUDIO_MON

113

AUDIO_GND

115

SYS_AUDIO_OUT

117

SYS_AUDIO_OUT_GND
AUDIO_GND_1

121

RESERVED_7

123

VCC5VA

G1

G1

G3

G3

RESERVED_0

RESERVED_1

RESERVED_3

RESERVED_WIP5_0
RESERVED_WIP5_1

AC_SDATA_OUT
AC_CODEC_ID0#

RESERVED_6

SYS_AUDIO_IN

SYS_AUDIO_IN_GND

AUDIO_GND_0

FOX_AS0B126_S52S_7F_124P

RING

8PMJ-1
8PMJ-2
8PMJ-4

8PMJ-5
LED2_YELP
LED2_YELN

5V_0

INTA#

3.3VAUX_0
RST#

3.3V_1
GNT#

GROUND_2

PME#

AD30

3.3V_3

AD28
AD26
AD24

IDSEL

GROUND_4

AD22
AD20

AD18
AD16

GROUND_7

FRAME#

TRDY#
STOP#

3.3V_5

DEVSEL#

GROUND_9

AD15
AD13
AD11

GROUND_11

AD09

C_BE0#

3.3V_6

AD06
AD04
AD02
AD00

GROUND_13

M66EN

AC_RESET#

GROUND_15

MPCIACT#

3.3VAUX_1

R370

2

4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52

56

PAR

60
62
64
66

70
72
74

78
80
82
84
86
88
90
92
94
96
98
100
102101
104

108
110
112
114
116
118
120119
122
124

G2

G2

G4

G4

PCI_3S_AD(30)
PCI_3S_AD(28)

PCI_3S_AD(26)
PCI_3S_AD(24)

PCI_3S_AD(22)
PCI_3S_AD(20)

PCI_3S_AD(18)
PCI_3S_AD(16)

PCI_3S_AD(15)
PCI_3S_AD(13)
PCI_3S_AD(11)

PCI_3S_AD(9)

PCI_3S_AD(6)
PCI_3S_AD(4)
PCI_3S_AD(2)
PCI_3S_AD(0)

KBC_AGND

38-,41-,46­38-,41-,46­38-,41-,46­38-,41-,46-

38-,41-,46-

38-,41-,46-

TV2-TPM2

38-

PCI_3S_INTF#

38-

R371

12

100_5%

48-

60­60-

46-

R305

12

0_5%

WS

R373

PCI_3S_GNT#(3)

38-,41-,46-,47-

PCI_3S_PAR
PCI_3S_FRAME#
PCI_3S_TRDY#
PCI_3S_STOP#

PCI_3S_DEVSEL#

PCI_3S_CBE#(0)

CPDETS-P3N
TV2-TPM0

TV2-TPM1

CPGP2M-P3P

46-,60-

TV1-TPM2

12

100_5%

1

R369

8.2K_5%_OPEN

2

38-,41-,46-,47-

PCI_3S_AD(29)

ES

12

220_5%

R372

ES

PCI_3S_AD(28)

46-

8.2K_5%_OPEN

12

R374

12

0_5%

+V5S_TV

12-,46-,47-

PCI_RST_TVS

FUSE3

12

3A_32V_466003

ES

R410 0_5%

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

38-,46-

PCI_3S_GNT#(1)

WS

L39

12

BLM31PG121SN1

ES

2

1
12

C470

1

1

2

2

22uF_6.3v

0_5%R424

22uF_6.3v

1
2

C474

0.1uF_16v

ES

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

L34

12

BLM31PG121SN1

ES

1
2

C331

22uF_6.3v

1
2

C330

22uF_6.3v

1
2

C332

0.1uF_16v

1
2

C333

0.1uF_16v

1
2

C383

0.1uF_16v

1
2

C472

0.1uF_16v

C382

1
2

0.1uF_16v

1
2

1
2

C471C438

0.1uF_16v

ES

C384

0.1uF_16v

TSA-P5V

C473

1
2

TS-P3V

1
2

47-

0.1uF_16v

TSA_GND

47-

C334

0.1uF_16v

TSA_GND

TSA_GND

WS

http://hobi-elektronika.net

INVENTEC

INVENTEC

INVENTEC

TITLE

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

TV Tuner-Slave

TV Tuner-Slave

TV Tuner-Slave

CODE

SIZE

CODE

A3

A3

A3

CS

CS

CHANGE by

CHANGE by SHEET

CHANGE by

13-Apr-2007TIGER

13-Apr-2007TIGER

13-Apr-2007TIGER

CS

SHEET

SHEET

DOC. NUMBERCODE

DOC. NUMBER

OF

OF

OF

47 78

47 78

47

REVDOC. NUMBER

REV

REVSIZEMPSIZE

A02Model_No

A02Model_No

A02Model_No

78

http://laptopblue.vnhttp://laptopblue.vn

BCRSTM-P3N

BCRSTS-P3P

CPDETM-P3N

CPDETS-P3N

+V5S+V5S

BCAS-P5V

48-,49-

R1121

12

XBCLKS-P3P

WS

XBCLKM-P3P

WS

47-

46-

47-

47-

0_5%_OPEN

R1120

12

46-

0_5%

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R1126

10K_5%

2

R1124

2

1

46-

0_5%

1

R1125

0_5%_OPEN

2

Q819

3

C

B

2

E

1

DTC143ZUA

1

R1127

10K_5%

2

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

1

R1117

R1116

47K_5%

47K_5%

2

2

2

DTC143ZUA

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

5

U819

1

4

2

SN74AHC1G02DBVR

3

Q821

B

ES

5

1
2

3

BCAS-P5V

48-,49-

5

1
2

3

3

C

E

1

U821

4

TC7SET08F

ES

U820

4

TC7SET08F

ES

R1119

1

2.2K_5%

R1123

12

100_5%

R1122

1

2

100_5%

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R1118

2.2K_5%_OPEN

2

2

ws

46-,47-

49-

49-

47-,49-

ES

XBCCLK-P5P

BCRST-P5N

BCDETS-P3N

CPGP3M-P3P

BCPWON-P3P

BCPWONS-P3P

CPGP1M-P3P
CPGP0M-P3P

WS

L821

46-

12

BLM11A221S

12

47-

BLM11A221S_OPEN

46-,47­46-,47-

L820

1

R406

10K_5%

2

BCAS-P5V

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1

R1133

10K_5%

2

Q822

3

C

B

2

E

1

DTC143ZUA

48-,49-

R1131

1

2

10K_5%

2

1

R1136

DTC143ZUA

10K_5%

2

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

02

Q820

1

4

S

D

2
5

3

6

G

TPC6104

R1134

1

C1086

12

0.047uF_10v

2

10K_5%

Q823

2

E

1

B

C

3

2SA1586

1

R1135

1.5K_5%

2

WS

R1130

12

33K_5%

Q824

3

C

B

E

1

1

R1129

2.2K_5%

2

BCAS-P5V

48-,49-

1

2

R1132

10K_5%

BCAS-P5V

48-,49-

C1085

1
2

4.7uF_6.3v

46-,47-,49-

BCIO-P5P

WS

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

BCAS Card-1

SIZE CODE DOC. NUMBER REV

A3

CHANGE by SHEET OF

13-Apr-2007TIGER

CS

48 78

A02Model_No

http://laptopblue.vnhttp://laptopblue.vn

1
2

C1084

1uF_6.3v

BCASF-P5V

C1083

1
2

C1090

1
2

1uF_6.3v

ACES_88141_10141_10P

1uF_6.3v

1
2

BCAS-P5V

48-

BLM18BA220SN1

L819

BCIO-P5P

47-,48-

12

48­48-

46-,47-,48-

46-

470_5%_OPEN

BLM11A121S

BCRST-P5N

XBCCLK-P5P

BCCDET-P3N

BCDETS-P3N

+V5S DISTF-P5V

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,54-,55-,56-,60-,61-,63-,64-,68-,70-

L822

R1137

12

470_5%

R1128

12

C1091

1
2

10uF_6.3v

12

CN814

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

CN816

1

1

2

G

G1

2

3

G

G2

3

ACES_87213_0300G_3P

C1089

0.1uF_16v

MP

WS

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

BCAS Card-2

SIZE

CODE DOC. NUMBERWSREV

A3

CHANGE by OFSHEET

TIGER 13-Apr-2007

CS

Model_No A02

7849

+V3_LAN

50-,51-,52-

DVDD15

50-,51-

AVDD18

51-,52-

AVDD33

51-

DVDD15

http://laptopblue.vnhttp://laptopblue.vn

X800

12

25MHZ

C875

1

1

2

2

27pF_50v

C920

50-,51-

EVDD18

51-

CTRL15

CTRL18
TRD0P

TRD0N
TRD1P

TRD1N

27pF_50v

52-

LED_LANRXACT#

52-

LED_LANLINK#

52-

50-,51-,52-

NC
NC
NC
NC
NC

NC
NC
NC

LED_LANTXACT#

DVDD15

+V3_LAN

50-,51-,52-

48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33

10/100M: RTL8101E

50-,51-

DVDD15

50-,51-

51-

51-

52­52-

52­52-

R915

1

2K_1%

2

64

65

RSET

TML-PAD

1

VCTRL18

2

AVDD33

3

MDIP0

4

MDIN0

5

AVDD18

6

MDIP1

7

U804

MDIN1

8

REA_RTL8101E_GR_QFN_64P

AVDD18

9

NC

10

NC

11

NC

12

NC

13

NC

14

NC

15

VDD15

16

VDD33

NC

NC

17

18

62

63

61

NC

CKTAL2

VCTRL15

VDD15

LANWAKEB

PERSTB

21

19

20

58

59

60

NC

VDD15

CKTAL1

EVDD1825EGND

HSIN23HSIP

22

24

EGND

57

56

LED0

26

55

54

LED1

LED2

LED3

EVDD1828EGND

REFCLK_N

REFCLK_P

27

53

29

52

VDD33

EGND

HSON30HSOP

31

+V3_LAN

49

50

NC

NC51NC

VDD15
EESK

EEDI_AUX

VDD33

EEDO
EECS

VDD15

VDD33

ISOLATEB

NC

32

R162

12

3.6K_5%

U806

3

DI

2

SK

1

CS

GND

6

NC

ATM_AT93C46_10SI_2.7_SOP_8P

+V3_LAN

50-,51-,52-

+V3_LAN

50-,51-,52-

4

DO

8

VCC

5
7

NC

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R942

10K_5%

2

60-

C210

1
2

0.1uF_10v

LAN_DISABLE#

PCIE_WAKE#

LAN_RST#

PCIE_C_TXP1
PCIE_C_TXN1

CLK_R_PCIE_LAN

CLK_R_PCIE_LAN#

PCIE_C_RXP1
PCIE_C_RXN1

37-,45-,53-,59­37-,60-

37­37-

13­13-

37­37-

C908

1

2

0.1uF_16v

C909

0.1uF_16v

PCIE_RXP1

12

PCIE_RXN1

WS

http://hobi-elektronika.net

THERMAL PAD: 9 VIAS TO GND
TWO EGND PINS: PUT A LARGE PLANE TO THERMAL PAD

CHANGE by OF

INVENTEC

TITLE

HONOLULU

LAN INTERFACE

SIZE CODE

13-Apr-2007TIGER

A3

CS

SHEET

DOC. NUMBER

50 78

REV

A02Model_No

WOL_AUX_ON#

http://laptopblue.vnhttp://laptopblue.vn

R2200

12

200_5%

Q500

3

D

G

1

S

2

2N7002W

60-

MP

7-,37-,38-,39-,45-,53-,59-,60-,67-,68-

+V3A

R906

1

2

220K_5%

4

Q811

S

FDC638P

+V3_LAN

1

D

2
5
63

G

50-,52-

1

C870

2

22uF_6.3v

1
2

C866

0.1uF_16v

1
2

Pin 16

C142

0.1uF_16v

1
2

Pin 37

C143

0.1uF_16v

1
2

Pin 46

C867

0.1uF_16v

1
2

Pin 53

C141

0.1uF_16v

CTRL18: 20mils

CTRL18

AVDD18

L14

50-

12

BLM21B121SD

1

C71

2

22uF_6.3v

(1.8V output:40mils)

C76

1
2

0.1uF_16v

C74

12

10uF_6.3v

CTRL15: 20mils

CTRL15

50-,52-

C73

0.1uF_16v

Pin 5

C79

1
2

0.1uF_16v

Pin 8

1
2

0.1uF_16v

Pin 11

C75

1
2

0.1uF_16v

Pin 14

1
2

Placed near LAN Controller

EVDD18

50-

R128

12

0_5%

4.7uF_6.3v

50-

C144

Placed near LAN Controller

1
2

BLM21B121SD

1

C70

2

22uF_6.3v

0.1uF_16v

Pin 22

L20

12

C911

1
2

C81

1
2

0.1uF_16v

0.1uF_16v

Pin 28

22uF_6.3v

C910

DVDD15

C914

12

1
2

EGND

50-

(1.5V output:40mils)

C912

0.1uF_16v

Pin 15

1

L808

BLM21B121SD

2C78

1
2

Pin 2

C874

0.1uF_16v

1
2

Pin 59

C873

0.1uF_16v

AVDD33

50-

Placed near LAN Controller

R129

12

0_5%

EGND

C868

C918

Pin 21

1
2

0.1uF_16v

Pin 32

1
2

C80

1
2

0.1uF_16v0.1uF_16v

Pin 33 Pin 38

1
2

0.1uF_16v

C919

ws

1
2

C916

0.1uF_16v

Pin 41

1
2

C913

0.1uF_16v

Pin 43

1
2

0.1uF_16v

Pin 49

C915

1
2

0.1uF_16v

Pin 52

C917

1
2

0.1uF_16v

Pin 58

C869

1
2

Placed near LAN Controller

Placed near LAN Controller

WS

http://hobi-elektronika.net

INVENTEC

INVENTEC

TITLE

TITLE

HONOLULU

HONOLULU

LAN POWER

LAN POWER

SIZE

SIZE

A3

CHANGE by

CHANGE by SHEET OF

TIGER 13-Apr-2007

TIGER 13-Apr-2007

A3

DOC. NUMBER

DOC. NUMBER REV

CODECODE

Model_No A02

Model_No A02

CS

CS

SHEET

REV

OF

7851

7851

http://laptopblue.vnhttp://laptopblue.vn

+V3_LAN

50-,51-

1

1

WS

R823

330_5%

2

2

TD+

TD-

RD+

LAN_45

RD-

LAN_78

JACK802

G19

52-

1

TX+

52-

2

TX-

52-

3

RX+

52-

4

P4

5

P5

52-

6

RX-

52-

7

P7

8

P8

11 Y1

FOX_JM36113_L1R8_4F_RJ45_12P

G2

10

G1

G

G2

G

12Y2

50-

LED_LANLINK#

50-

LED_LANTXACT#

1

D810

3

BAT54A

2

50-

LED_LANRXACT#

WS

SWAP YELLOW AND GREEN

AVDD18

50-,51-

R850

330_5%

TRD0P
TRD0N

TRD1P
TRD1N

50­50-

50­50-

U2

1

RD+

2

RD-

3

CT1

4

NC1
NC25NC3

6

CT211CT3

7

TD+

8

TD-

BH_NS0013

CS

MP

1

R910

49.9_1%

2

C871

12

0.01uF_16v

R911

1

49.9_1%

2

R912

49.9_1%

2

C872

12

0.01uF_16v

R913

121

49.9_1%

WS

1
2

C825

C824

12

0.01uF_16v

0.01uF_16v

LAYOUT NOTE : Place termination resistors and caps as close to LAN controller as possible

WS

http://hobi-elektronika.net

RX+
CT4

NC4

RX-

TX+

16
15
14
13
12

10
9

TX-

1

1

1

1

R860

75_5%

2

R858

75_5%

2

1
2

R856

75_5%

2

C826

100pF_3000v

R862

75_5%

2

52-

RD+

52-

RD-

52-

TD+

52-

TD-

LAN_45

52-

LAN_78

52-

INVENTEC

TITLE

HONOLULU

CHANGE by

TIGER 13-Apr-2007

LAN RJ45 CONN

SIZE

CODE

A3

CS

SHEET

DOC. NUMBER

Model_No A02

REV

OF

7852

http://laptopblue.vnhttp://laptopblue.vn

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V1.5S

8-,16-,25-,36-,37-,39-,45-,53-,59-

1

CLK_R_PCIE_MINI1#

CLK_R_PCIE_MINI1

PCIE_C_RXN3
PCIE_C_RXP3

PCIE_C_TXN3

PCIE_C_TXP3

C1054

22uF_6.3v

2

CN7

1

WAKE#

3

Reserved

5

Reserved

7

CLKREQ#

9

13­13-

37­37-

37­37-

GND

11

REFCLK-

13

REFCLK+

15

GND Reserved

17

Reserved

19

Reserved

21

GND

23

PERn0

25

PERp0

27

GND

29

GND

31

PETn0

33

PETp0

35

GND

37

Reserved

39

Reserved

41

Reserved

43

Reserved

45

Reserved

47

Reserved

49

Reserved

51

Reserved 3.3V

G1 G2

G

FOX_AS0B226_S40N_7F_TSB_52P

C1055

1
2

0.1uF_10v

Reserved
Reserved
Reserved
Reserved

Reserved

PERST#

+3.3Vaux

SMB_CLK

SMB_DATA

USB_D-

USB_D+

LED_WWAN#

LED_WLAN#
LED_WPAN#

Wireless & Debug card

1

C381

22uF_6.3v

2

PCIE_WAKE#

CH_DATA

CH_CLK

CLKREQ_R_MINI2#

CLK_R_PCIE_MINI2#

CLK_R_PCIE_MINI2

BUF_PLT_RST#

CLK_R3S_MINICARD2

PCIE_C_RXN2
PCIE_C_RXP2

PCIE_C_TXN2

PCIE_C_TXP2

37-,45-,50-,59­58­58­13-

13­13-

30-,37-,38-,53-,59­13-

37­37-

37­37-

CN18

1

WAKE#

3

Reserved

5

Reserved

7

CLKREQ#

9

GND

11

REFCLK-

13

REFCLK+

15 16

GND

17

Reserved

19

Reserved

21

GND

23

PERn0

25

PERp0

27

GND

29

GND

31

PETn0

33

PETp0

35

GND

37

Reserved

39

Reserved

41

Reserved

43

Reserved

45

Reserved

47

Reserved

49

Reserved

51 52

Reserved

G1

GG

FOX_AS0B226_S40N_7F_TSB_52P

3.3V
GND

1.5V

GND

GND

1.5V

GND

GND

1.5V
GND

G

1
2

2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52

C441

1
2

0.1uF_10v

GND

Reserved
Reserved
Reserved
Reserved
Reserved

GND

Reserved

PERST#

+3.3Vaux

GND

SMB_CLK

SMB_DATA

GND

USB_D-

USB_D+

GND

LED_WWAN#

LED_WLAN#

LED_WPAN#

GND

C1008

0.1uF_10v

2

3.3V
4

6

1.5V
8

10
12
14

18
20
22
24
26
28

1.5V
30

32
34
36
38
40
42
44
46
48

1.5V
50

3.3V
G2

1

2

C1031

22uF_6.3v

C1007

1
2

0.1uF_10v

30-,37-,38-,53-,59-

C1053

1

0.1uF_10v

2

BUF_PLT_RST#

Robson

WXMIT_OFF#

+V1.5S

8-,16-,25-,36-,37-,39-,45-,53-,59-

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C440

1
2

0.1uF_10v

C442

1
2

0.1uF_10v

36-,60­36-,60­36-,60­36-,60­36-,60-

30-,37-,38-,53-,59-

37-,45-,59­37-,45-,59-

TP863

53-

1

C443

1
2

0.1uF_10v

2

LPC_3S_FRAME#
LPC_3S_AD(3)
LPC_3S_AD(2)
LPC_3S_AD(1)
LPC_3S_AD(0)

WXMIT_OFF#

BUF_PLT_RST#

ICH_3A_ALERT_CLK
ICH_3A_ALERT_DAT

WLAN_LED#

WS

C437

22uF_6.3v

C439

1
2

0.1uF_10v

+V3A_WLAN

53-

C475

1
2

22uF_6.3v

53-

+V3A_WLAN

53-

Q26

3

D

S

2

2N7002W

1
2
5
6

G

1

Q27

D

G

SI3433BDV

4

S

3

WLON_LED#

+V3A

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

5

U22

1

4

58-,60-,68-

TC7SET32FU

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

2

3

60-

60-,68-

WOWLAN#

WLON#

KILL_SWCH#

http://hobi-elektronika.net

CHANGE by

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

Robson & WLAN

SIZE

A3

DOC. NUMBERCODE

Model_No A02

CS

SHEET

REV

OF

7853

http://laptopblue.vnhttp://laptopblue.vn

CN812

1

SATA_C_TXP1
SATA_C_TXN1

SATA_C_RXN1

SATA_C_RXP1

ES

36­36-

36­36-

C379

3300pF_50v_OPEN

C378

CLOSE TO SATA CONN

CS

12

12

3300pF_50v_OPEN

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

47uF_6.3v_OPEN

C380

+V5S

1

2

SATA_RXN1
SATA_RXP1

ES

C329

1
2

0.1uF_16v_OPEN

CS

GND

2

A+

3

A-

4

GND

5

B-

6

B+

7

GND

8

V3.3

9

V3.3

10

V3.3

11

GND

12

GND

13

GND

14

V5

15

V5

16

V5

17

GND

18

RESERVED

19

GND

20

V12

21
22

SYN_061107_TF023_22P_OPEN

G1

G1

V12

G2

G2

V12

SATA HDD02

ES

ES

36­36-

36­36-

3300pF_50v

C423

C424

CLOSE TO SATA CONN

CS

12

3300pF_50v

2

1

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

C425

47uF_6.3v

SATA_C_TXP0
SATA_C_TXN0

SATA_C_RXN0

SATA_C_RXP0

CS

http://hobi-elektronika.net

+V5S

1

2

SATA_RXN0
SATA_RXP0

ES

C428

1
2

0.1uF_16v

CN818

1

GND

2

A+

3

A-

4

GND

5

B-

6

B+

7

GND

8

V3.3

9

V3.3

10

V3.3

11

GND

12

GND

13

GND

14

V5

15

V5

16

V5

17

GND

18

RESERVED

19

GND

20

V12

21
22

SYN_127043FR022G256ZR_22P

G1

V12

G

G2

V12

G

ES

SATA HDD01

CHANGE by

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

SATA HDD CONN

SIZE

A3

DOC. NUMBERCODE

Model_No A02

CS

SHEET

REV

OF

7854

http://laptopblue.vnhttp://laptopblue.vn

ES

FILICA

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,56-,58-,59-,60-,62-,63-,64-,68-,70-

37-

USB_P9-

37-

USB_P9+

FILI_PRES#

37-

CAMERA

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

+V5S_FELICA

1

R1955

10K_5%

2

10K_5%

1

R294

CN11

1

1

2

2

3

3

4

4

5

2

5

6

6

ACES_88706_0601_6P

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

G

G1

G

G2

CS

R233

10K_5%_OPEN

+V5S

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1

2

CS

Q1000

1

4

D

S

2
5
63

G

SI3433BDV

TC7SET32FU

PAD4

POWERPAD_2_0610

4

S

3

G

SI3433BDV_OPEN

U1002

Q15

D

ES

+V5S

+V5S

5

4

3

37-

1
2

FELICA_ON#

CS

+V5S_CAMERA

1
2

55-

C241

1uF_6.3v

1
2
5
6

CAMERA_OFF#

Q16

3

1

G

USB_P7+

D

S

2

USB_P7-

EZJZ0V500AA

MP

+V5S_CAMERA

55-

37­37-

1

1

D50

D51

EZJZ0V500AA

2

2

CS

37-

2N7002W_OPEN

http://hobi-elektronika.net

CN5

1

1

2

2

3

G

G1

3

4

G2

G

4

5

5

ACES_87213_0500N_5P

CHANGE by

CHANGE by

TIGER

13-Apr-2007TIGER

13-Apr-2007

13-Apr-2007TIGER

INVENTEC

INVENTEC

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

Filica & Camera

Filica & Camera

SIZE

CODESIZE DOC. NUMBER REVESREVDOC. NUMBER

CODE

A3

A3

A3

CS

CS

CS

SHEET

SHEET

55 78

55 78

55 78

A02Model_No

A02Model_No

A02Model_No

OF

OF

http://laptopblue.vnhttp://laptopblue.vn

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

PIDE_3S_D(15:0)

C1954

0.1uF_16v

36-,56-

PIDE_3S_IORDY

C1955

1
2

0.1uF_16v

PIDE_3S_IRQ

PIDE_3S_DREQ

PIDE_3S_A(2:0)

CS

1
2

+V3S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

R322

12

8.2K_5%

R320

OPEN

2

1

36-,56-

36-

+V3S

1

C349

2

47uF_6.3v

36-

R321

12

4.7K_5%

36-

CS

1
2

DISK_IN

PCI_3S_RST#

PIDE_3S_DREQ

PIDE_3S_IOR#

PIDE_3S_IOW#

PIDE_3S_DACK#

PIDE_3S_IRQ

PIDE_3S_A(1)
PIDE_3S_A(0)

PIDE_3S_A(2)
PIDE_3S_CS#(0)

PIDE_3S_CS#(1)

ODD_LED#+V5S

WS

C347

0.1uF_10v

+V3LA

R1555

100K_5%

60-

C348

1
2

0.1uF_10v

1

2

1

2

34-,38-,41-,42-,45-,46-

PIDE_3S_D(8)
PIDE_3S_D(7)
PIDE_3S_D(9)
PIDE_3S_D(6)
PIDE_3S_D(10)
PIDE_3S_D(5)
PIDE_3S_D(11)
PIDE_3S_D(4)
PIDE_3S_D(12)
PIDE_3S_D(3)
PIDE_3S_D(13)
PIDE_3S_D(2)
PIDE_3S_D(14)
PIDE_3S_D(1)
PIDE_3S_D(15)
PIDE_3S_D(0)

36-,56-

36-

36-,56-

68-

+V5S

C1956

1
2

0.1uF_16v

CS

D24

EZJZ0V270EA

36­36-

36­36-

R323

OPEN

12

12

R324

330_5%

1
2
3

R319

2

4

1

5

33_5%

6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50

CN815

FOX_QT8H0506_25T1R_7F_50P

C1950

11

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41

MP

42
43
44
45
46

G

47

G1

G

48

G2

49
50

2

0.1uF_16v

1
2

C1951

0.1uF_16v

1
2

CS

C1952

0.1uF_16v

2

C1953

0.1uF_16v

ES

http://hobi-elektronika.net

CHANGE by

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

ODD

CODESIZE

CS

SHEET

DOC. NUMBER

56 78

A3

REV

A02Model_No

OF

SB_USB_0

http://laptopblue.vnhttp://laptopblue.vn

+V5A

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

1

C927

2

47uF_6.3v

R951

60-

12

0_5%

C928

1
2

0.01uF_50v

C929

1
2

0.1uF_16v

U805

1

2

3

4

GMT_G545B1P8U_MSOP_8P

8

GND

OUT

7

OUT

IN

6

IN

OUT

5

EN

OC#

1

2

C930

100uF_6.3v

1
2

C931

0.1uF_16v

USBVCC1

57-

1

2

SB_USB_1

R952

OPEN

+V5A

7-,8-,9-,12-,39-,57-,60-,64-,65-,68-

1

C511

2

47uF_6.3v

R441

60-

12

0_5%

C510

1
2

0.01uF_50v

C487

1
2

0.1uF_16v

U31

1

2

3

4

GMT_G545B1P8U_MSOP_8P

GND

IN

IN6OUT

EN

8

OUT

7

OUT

5

OC#

1

2

C486

100uF_6.3v

1
2

C509

0.1uF_16v

USB_VCC2

57-

1

2

R461

OPEN

USB_P0-

USB_P0+

USB_P1-

USB_P1+

L22

37-

37-

2

14

3

QUIETEK_QTC24CG900U_4P

L23

37-

37-

2

14

3

QUIETEK_QTC24CG900U_4P

MP

USB CONN

USBVCC1

57-

CN806

1

USB_L_P1­USB_L_P1+

USB_L_P0-

USB_L_P0+

57­57-

57­57-

1

2

2

3

3

4

4

G1

5

G

5

6

G2

G

6

7

G3

G

7

8

G4

G

8

SYN_020122MR008S579ZL_8P

ES

57-

USB_L_P0-

57-

USB_L_P0+

USB_P2-

USB_P2+

57-

USB_L_P1-

57-

USB_L_P1+

USB_P3-

USB_P3+

37-

37-

37-

37-

CS

L40

1

4

23

QUIETEK_QTC24CG900U_4P

L41

2

3

14

QUIETEK_QTC24CG900U_4P

MP

57-

USB_L_P2-

57-

USB_L_P2+

57-

USB_L_P3-

57-

USB_L_P3+

USB_VCC2

CN20

1

1

USB_L_P2-

USB_L_P2+

USB_L_P3-

USB_L_P3+

57­57-

57­57-

2

2

3

3

4

4

5

5

6

G1

6

G

7

G2

G

7

8

8

ACES_87213_0800N_8P

INVENTEC

TITLE

HONOLULU

http://hobi-elektronika.net

CHANGE by

TIGER 13-Apr-2007

USB CONN

A3

CS

SHEET OF

Model_No A02

REVDOC. NUMBERCODESIZE

7857

http://laptopblue.vnhttp://laptopblue.vn

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

37-

BT_ON#

+V3S

1

R258

OPEN

2

BTIFON#

KILL_SWCH#

+V3S

1
2

C279

22uF_6.3v

60-,68-

53-,60-,68-

+V3S

1
2

5

U14

TC7SET32FU

3

PAD5

POWERPAD_2_0610

4

S

3

SI3433BDV_OPEN

1

R259

OPEN

2

4

1
2

C280

0.1uF_16v

BTRF-E3V

BTRF-E3V

58-

1

R297

100K_5%

2

58-

1
2

C282

10uF_6.3v

1

R298

100K_5%

2

0_5%

12
12

0_5%

10K_5%

R300

R299

BTRF-E3V

R296

1

R295

100K_5%

2

1

2

R1782

BTRF-E3V

1
2

USB_R_P6+
USB_R_P6-

12

ES

58-58-

C304

0.1uF_16v

ACES_87213_1000N_10P

10

10

9

9

8

8

7

7

6

0_5%

6

5

5

4

4

3

3

2

2

1

1

CN15

G

G2
G1

G

Q18

1

D

2
5

C281

6

1

G

2

OPEN

37-

USB_P6+

37-

USB_P6-

53-

CH_CLK

37-

BTMDL#

BT_RESET#

CH_DATA

37­53-

http://hobi-elektronika.net

CHANGE by

INVENTEC

TITLE

HONOLULU

BLUETOOTH

CODE

SIZE DOC. NUMBER

A3

CS

13-Apr-2007TIGER

SHEET

58 78

REV

A02Model_No

OF

http://laptopblue.vnhttp://laptopblue.vn

PCIE_WAKE#

CLK_R_PCIE_MINI3#

CLK_R_PCIE_MINI3

PCIE_C_RXN4

PCIE_C_RXP4

PCIE_C_TXN4
PCIE_C_TXP4

37-,45-,50-,53-

13­13-

37­37-

37­37-

+V3S

C371

1
2

22uF_6.3v_OPEN

CN813

1

WAKE#

3

CH_DATA

5

CH_CLK

7

CLKREQ#

9

GND

11

REFCLK-

13

REFCLK+

15

GND

17

LPC_DEBUG_RST#

19

LPC_PCI_CLK

21

GND

23

PERn0

25

PERp0

27

GND

29

GND

31

PETn0

33

PETp0

35

GND

37

Reserved

39

Reserved

41

Reserved

43

Reserved

45

+V3AL

47

PWR_LED#

49

NUM_LED#

51

CAPS_LED#

G1 G2

G

FOX_AS0B226_S68N_7N_52P_OPEN

C370

1
2

0.1uF_10v_OPEN

2

3.3V
4

GND

6

1.5V
8

LPC_FRAME#

10

LPC_AD3

12

LPC_AD2

14

LPC_AD1

16

LPC_AD0

18

GND

20

W_DISABLE#

22

PERST#

24

+3.3Vaux

26

GND

28

1.5V
30

SMB_CLK

32

SMB_DATA

34

GND

36

USB_D-

38

USB_D+

40

GND

42

LED_WWAN#

44

LED_WLAN#

46

LED_WPAN#

48

1.5V
50

GND

52

3.3V

G

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,60-,62-,63-,64-,68-,70-

C1082

1
2

0.1uF_10v_OPEN

8-,16-,25-,36-,37-,39-,45-,53-

C1079

1
2

0.1uF_10v_OPEN

C1081

1

1

2

2

0.1uF_10v_OPEN

22uF_6.3v_OPEN

C1071

+V3A

7-,37-,38-,39-,45-,51-,53-,60-,67-,68-

+V1.5S

USB_P5­USB_P5+

30-,37-,38-,53-

37-,45-,53­37-,45-,53-

BUF_PLT_RST#

ICH_3A_ALERT_CLK
ICH_3A_ALERT_DAT

37-

USB_P5-

37-

USB_P5+

C1080

1
2

0.1uF_10v_OPEN

C1070

1
2

22uF_6.3v_OPEN

http://hobi-elektronika.net

CHANGE by

CHANGE by

TIGER

TIGER 13-Apr-2007

13-Apr-2007

INVENTEC

INVENTEC

TITLETITLE

HONOLULU

HONOLULU

Mini Card

Mini Card

SIZE

SIZE

CODE

CODE DOC. NUMBER

A3

A3

Model_No A02

CS

CS

SHEET

SHEET OF

59 78

REV

REVDOC. NUMBER

A02Model_No

OF

7859

http://laptopblue.vnhttp://laptopblue.vn

+V3LA

6-,7-,12-,18-,36-,56-,60-,68-

C363

C362

1

1

10uF_6.3v

AVCC +V3LA

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

60-

1

C420

0.1uF_16v

2

KBC_AGND

KBC_AGND

0.1uF_16v

2

1

R354

100K_5%

2

C357

10pF_50v

C358

10pF_50v

1
2

12

12

2

0.1uF_16v

L36

12

BLM11A121S

C419

10uF_6.3v

CLOSE WPC8769L PIN

20-,30-,33-,60-

37-,60-

1

R358

47K_5%

2

X1

32.768KHZ

CLOSE WPC8769L PIN

C421

1

2

0.1uF_16v

0.1uF_16v

6-,7-,12-,18-,36-,56-,60-,68-

INV_PWM_3
RSMRST#

12

34

R335

12

33K_5%

C422

1

2

0.1uF_16v

1
2

C366

THRM_SHUTDWN#

C359

1

2

+V5AUXON

+V3S

C367

1

C365

1

0.1uF_16v

2

1

R341

10M_5%

2

1

2

6-,7-,12-,18-,36-,56-,60-,68-

60-

R342

10M_5%

60-

2

32K_X1

32K_X2

10uF_6.3v

EC_PW_ON

+V3LA

AVCC

KBC_AGND

PWR_OLED#

PWR_SWIN#_3

7-

1

R340

100K_5%

2

60-

WS

SPI_CE#

SPI_SO

BATT_DATA

BATT_CLK

+V3LA

6-,7-,12-,18-,36-,56-,60-,68-

10K_5%

60-

60-

+V3LA

6-,7-,12-,18-,36-,56-,60-,68-

R343

1

1

R346

4.7K_5%

6-,18­6-,18-

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,61-,63-,64-,68-,70-

R327

12

1

2

3

4

WINB_25X80VSSIG_SOIC_8P

U19

4.7K_5%

2

2

EC_DATA

EC_CLK

6-,7-,12-,18-,36-,56-,60-,68-

8

CS#

VCC

R330

12

7

DO

HOLD#

3.3K_5%

6

CLK

WP#

5

GND

DIO

+V3LA

6-,7-,12-,18-,36-,56-,60-,68-

R348

1

R347

4.7K_5%

5-,30­5-,30-

1

4.7K_5%

2

2

+V5S

IM_DAT_5
IM_CLK_5

1
2

C354

0.1uF_10v

47K_5% R333

+V3LA

60-

SPI_CLK

60-

SPI_SI

+V3LA

+V3LA

6-,7-,12-,18-,36-,56-,60-,68-

R396

R397

1

1

2

2

10K_5%

12

1

BATT_IN

FAN1_DAC0_3

LED_DIMM

PWR_BLED#

EC_BKLTEN

ACPRES

60­60-

60­58-,68­60-

37-,45­57-

1

R328

100K_5%

2

C353

1
2

0.1uF_10v_OPEN

CS

R400

4.7K_5%

R399 0_5%_OPEN

2

MP

100_5%

5-

18-

60-

33-

R350 0_5%

12

5-,30-

12

12

10K_5% R404

12

OPEN

12

0_5%

R1880

CS

R332

R331

CS

0_5%

R326

12

7-,18-,30-

0_5%

D25

6-,7-

WS

TV1-TPM0
TV1-TPM1
TV1-TPM2
TV2-TPM0
TV2-TPM1

67-

12

R349

10K_5%

37-,67-

WS

IRTX2-DET#

LID_SW#_3 LOW_BAT#_3
VCORE_EN

CAPS_LED#_3

BAT0_OLED#
BAT0_BLED#

HP_VOL#

IRTX1-DET#

CIR_LED#

IRTX-2

WS

32K_X1
32K_X2

DISK_IN

ES

SB_USB_1

DCIN_BLED#

INV_PWM_3

FAN_TACH1

LAN_DISABLE#

WLON#

SCROLL_LED#_3

NUM_LED#_3

1

2

R33747K_5%

2

1

68­68-

13

CHENMKO_BAT54_3P

AVCC

60-

R398

R344

R401

1

1

1

2

2

2

10K_5%

10K_5%

10K_5%

10K_5%

46­46­46-,47-

WS

47­47-

WS

61-

68­11­62-

68-

68-

64-

61-

61-

60­60-

56-

57­68-

20-,30-,33-,60­18-

50-

53-,68-

62-

62-

SPI_SO

SPI_SI

SPI_CE#
BTIFON#
SPI_CLK

WS

CPPE#

SB_USB_0

http://hobi-elektronika.net

6-,7-,12-,18-,36-,56-,60-,68-

C360

1
2

0.1uF_10v_OPEN

5

2

3

CS

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

2

1

TP867

R33610K_5%

TP869

R402

TP864
TP865

R352

12

0_5%R351

100_5%

12
12

100_5%

12

100_5%

12

R355

C364

1

1uF_6.3v

2

CS

U18

4

PHP_74LVC1G17_SOT753_5P_OPEN

12

0_5%R1903

CS

+V3S

AVCC

+V3LA

6-,7-,12-,18-,36-,56-,60-,68-

60-

19

46

76

88

115

VCC1

VCC2

VCC3

KBC_AGND

103

VCC4

AGND

VCC5

102

AVCC

CLKRUN#_GPIO11_HGPIO02

SOUT_CR_GPIO83_BADDR1

KBSOUT15_GPIO61_XOR_OUT

KBSOUT17_GPIO57_HGPIO03

R394

TP8

TP9

U20

104

97
98

99
100
108

96
101
105
106
107

81

64

95

93

94
119
109
120

84

83

82

112
110

73

6

114

77

79

30

62
118

32

63

31
117

65

66

68

67

69

70

86

87

WS

90

91

92

WS

11

10

71

72

44

VREF

AD0_GPI90
AD1_GPI91
AD2_GPI92
AD3_GPI93
AD4_GPIO05
AD5_GPIO04
DA0_GPI94
DA1_GPI95
DA2_GPI96
DA3_GPI97

SWD_GPIO66

GPIO01
GPIO03
GPIO06_HGPIO06
GPIO07_HGPI07
GPIO23
GPIO30
GPIO31

SPI_DI_GPIO77
SPI_DO_GPIO76_SHBM
SPI_SCK_GPIO75

GPIO84_HGPIO01_BADDR0
GPIO82_HGPIO00_TRIS#
GPIO70
GPIO24_HGPIO01

CIRTX_GPIO16_HGPIO04

32KX1_32KCLKIN
32KX2
CLKOUT_GPIO55

B_PWM0_GPIO13
A_PWM1_GPIO21
A_PWM0
TB1_GPIO14_HGPIO04
TA1_GPIO56
TA2_GPIO20

GPIO32
GPIO33

SDA2
SCL2
SDA1
SCL1

F_SDI
F_SDO

F_CS0#
GPIO81
F_SCK

PSDAT2_GPIO27
PSCLK2_GPIO26
PSDAT1
PSCLK1

VCORF

1

R339

OPEN

2

R334

12

80

4

VDD

LPCPD#_GPIO10_HGPIO00

GPIO63

SIN_CR_CIRRX_GPIO87

GND1

GND2

5

18

45

12

0_5%

VBAT

GPIO34_CIRRX2

LRESET#

LCLK

LFRAME#

LAD0
LAD1
LAD2
LAD3

SERIRQ

KBRST#

CA20

ECSCI#

SMI#

PWUREQ#

GPIO71
GPIO72

GPIO53
GPIO36
GPIO51

GPIO47_JEN0#

PSLCK3_GPIO25
PSDAT3_GPIO12

GPIO45
GPIO40

GPIO42_TCK
GPIO43_TMS

GPIO44_TDI

GPIO46_TRST#

GPIO50_TDO

GPIO52_RDY#

VCC_POR#

KBSIN0
KBSIN1
KBSIN2
KBSIN3
KBSIN4
KBSIN5
KBSIN6

KBSIN7
KBSOUT0
KBSOUT1
KBSOUT2
KBSOUT3
KBSOUT4
KBSOUT5
KBSOUT6
KBSOUT7
KBSOUT8
KBSOUT9

KBSOUT10

KBSOUT11
KBSOUT12_GPIO64
KBSOUT13_GPIO63
KBSOUT14_GPIO62

KBSOUT16_GPIO60

GND4

GND5

GND6

GND3

89

78

WINBOND_WPC8769L_LQFP_128P

116

R338

OPEN

14
124
7
2
3
126
127
128
1
125
8
122
121
29
9
123
74
75
111
28
15
26
24
113

12
13

22
16

17
20
21
23
25
27
85

54
55
56
57
58
59
60
61
53
52
51
50
49
48
47
43
42
41
40
39
38
37
36
35
34
33

60-

VCC_POR#

KBC_AGND

TP10

1

OPEN

TP868

7-,8-,9-,11-,12-,30-,37-,42-,64-

R360

TP12

TP13

CHANGE by

12

0_5%

LED_DIMM

WS

64-

19-,38-

13-

36-,53-

36-,53­36-,53­36-,53­36-,53­37-,41-

37-,41-,46-,47-

36-

37-

61-

68-

2

R403

37-

37-

37-

68-

37-,50-

LAN_RST#

37-,60-

8-,12-,37-

53­51-

68­68-

64-

60-

R395

12

0_5%

TIGER 13-Apr-2007

60-

VOL_EN

PLT_RST#

CLK_R3S_KBPCI
LPC_3S_FRAME#

LPC_3S_AD(0)
LPC_3S_AD(1)
LPC_3S_AD(2)
LPC_3S_AD(3)

PCI_3S_SERIRQ

7-,37-,38-,39-,45-,51-,53-,59-,67-,68-

PCI_3S_CLKRUN#

PM_3S_KBCCPURST#

EC_SMI
IRTX-1

L_CIR_RX1

EC_PWRSW#
WAKEUP0#_3

5-

CHG_EN
CIR_OUT

WS

SLP_S3#_3R

RSMRST#
SLP_S5#_3R

WOWLAN#
WOL_AUX_ON#

6-

BAT_ID
REC_LED
RESERVE_LED#

VOL_VR

VCC_POR#

SCAN_IN(0)
SCAN_IN(1)
SCAN_IN(2)
SCAN_IN(3)
SCAN_IN(4)
SCAN_IN(5)
SCAN_IN(6)
SCAN_IN(7)

KBC_AGND

+V5A

7-,8-,9-,12-,39-,57-,64-,65-,68-

GMT_G995P1U_SOP8_8P

C351

1
2

2.2uF_10v

WS

R359

WS

WS

WS

62-,68-

SCAN_OUT(0)
SCAN_OUT(1)
SCAN_OUT(2)
SCAN_OUT(3)
SCAN_OUT(4)
SCAN_OUT(5)
SCAN_OUT(6)
SCAN_OUT(7)
SCAN_OUT(8)

SCAN_OUT(9)
SCAN_OUT(10)
SCAN_OUT(11)
SCAN_OUT(12)
SCAN_OUT(13)
SCAN_OUT(14)
SCAN_OUT(15)

53-,58-,68-

U17

1

FON

2

VIN

3

VO

4

VSET

36-

10K_5%

12

41-

10K_5%

SCAN_IN(7:0)

+VLED

8

GND

7

GND

6

GND

5

GND

WS

R405

+V3LA

+V3S

12

+V3A

EC_3S_A20GATE

OPEN

1

R357

+V3LA

100K_5%

2

62-,68-

GRST#
KILL_SWCH#

6-,7-,12-,18-,36-,56-,60-,68-

SCAN_OUT(15:0)

INVENTEC

TITLE

HONOLULU

KBC

SIZE CODE

A3

CS

SHEET OF

64-,67-,68-

C350

1
2

2.2uF_10v

6-,7-,12-,18-,36-,56-,60-,68-

1

R463

10K_5%_OPEN

H:NEC(JPN)

2

1

R462

10K_5%

2

L:RC6(WW)

CHENMKO_BAT54_3P

37-,38-

RUNSCI0#_3

13

D27

12

R356

DOC. NUMBER REV

Model_No A02

ES

7860

IRTX-1

http://laptopblue.vnhttp://laptopblue.vn

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1

R837

4.7K_5%

2

BSS84

2

S

G

1

D

3

Q808

2

60-

BSS138

WS

Q807

3

D

G

S

1

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

R836

12

120_5%

IRTX1-DET#

60-

JACK801

G2
G1

1
2
6
3
4

5

FOX_JA6333L_B3S0_7F_6P

WS

IRTX-2

1

R835

4.7K_5%

2

BSS84

2

S

G

1

D

3

Q806

2

60-

BSS138

WS

Q805

3

D

G

S

1

R834

12

120_5%

IRTX2-DET#

WS

60-

http://hobi-elektronika.net

JACK800

G2
G1

1
2
6
3
4

5

FOX_JA6333L_B3S0_7F_6P

WS

INVENTEC

INVENTEC

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

IR Blaster IR Blaster

IR Blaster

CODE REV

SIZE

SIZE

CODE

A3

A3

A3

CS

CS

CHANGE by SHEET

CHANGE by

TIGER 13-Apr-2007

TIGER 13-Apr-2007

13-Apr-2007TIGER

CS

SHEET

DOC. NUMBER REV

DOC. NUMBER

Model_No A02

Model_No A02

61 78

A02Model_No

OF

OF

7861

7861

http://laptopblue.vnhttp://laptopblue.vn

SCAN_OUT(15:0)

60-,68-

ES

SCAN_OUT(4)
SCAN_OUT(2)
SCAN_OUT(13)
SCAN_OUT(15)
SCAN_OUT(1)
SCAN_OUT(0)
SCAN_OUT(11)
SCAN_OUT(9)
SCAN_OUT(5)
SCAN_OUT(6)
SCAN_OUT(10)
SCAN_OUT(14)
SCAN_OUT(8)
SCAN_OUT(12)
SCAN_OUT(7)
SCAN_OUT(3)

ES

CS

CS

2
1

C520

1
2

180pF_50v

C512

180pF_50v

2
1

C521

1
2

C513

180pF_50v

180pF_50v

2
1

C522

1
2

C514

180pF_50v

180pF_50v

2
1

C523

1
2

180pF_50v

C515

180pF_50v

2
1

C524

1
2

180pF_50v

180pF_50v

2

C516

1

1
2

CAPS_LED#_3

SCROLL_LED#_3

NUM_LED#_3

C517

180pF_50v

C525

180pF_50v

2
1

1
2

60­60­60-

C518

180pF_50v

C526

180pF_50v

1

D824

EZJZ0V120JA

2

2

C519

180pF_50v

1

C527

1
2

180pF_50v

R1103

12

200_5%

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,63-,64-,68-,70-

SCAN_IN(7)
SCAN_IN(2)
SCAN_IN(3)
SCAN_IN(4)
SCAN_IN(0)
SCAN_IN(5)
SCAN_IN(6)
SCAN_IN(1)

12

R1101 200_5%

12

1

D823

EZJZ0V120JA

2

1

D822

EZJZ0V120JA

2

+V3S

34

34

33

R353

12

0_5%

60-,62-,68­60-,62-,68­60-,62-,68­60-,62-,68­60-,62-,68­60-,62-,68­60-,62-,68­60-,62-,68-

200_5%R1102

33

32

32

31

31

30

30

29

29

28

28

27

27

26

26

25

25

24

24

23

23

22

22

21

21

20

20

19

19

18

18

17

17

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

CN12

PTWO_AFF340_A2G1V_P_34P

G2

G

G1

G

KEYBOARD

SCAN_IN(2)

SCAN_IN(1)
SCAN_IN(0)

SCAN_IN(3)
SCAN_IN(5)

SCAN_IN(6)
SCAN_IN(4)

SCAN_IN(7)

60-,62-,68-

60-,62-,68-

60-,62-,68-

60-,62-,68-

60-,62-,68-

60-,62-,68-

60-,62-,68-

60-,62-,68-

D831

2

1

EZJZ0V120JA

D825

12

EZJZ0V120JA

D828

12

EZJZ0V120JA

D830

12

EZJZ0V120JA

D827

12

EZJZ0V120JA

D826

12

EZJZ0V120JA

D829

12

EZJZ0V120JA

D832

12

EZJZ0V120JA

http://hobi-elektronika.net

CHANGE by

CHANGE by

TIGER 13-Apr-200713-Apr-2007TIGER

INVENTEC

INVENTEC

INVENTEC

TITLE

TITLETITLE

HONOLULU

HONOLULU

HONOLULU

K/B CONN

K/B CONN

K/B CONN

SIZE

A3

A3

13-Apr-2007TIGER

A3

DOC. NUMBERCODE

Model_No A02

CS

CS

CS

SHEET

SHEET

SHEETCHANGE by OF

62 78

62 78

DOC. NUMBER

CODE

CODESIZE DOC. NUMBER REVREV

SIZE

REV

A02Model_No

A02Model_No

OF

OF

7862

HDMI_TX2+_I

HDMI_TX2-_I

HDMI_TX1+_I

HDMI_TX1-_I

HDMI_TX0+_I

HDMI_TX0-_I

HDMI_TXC+_I

HDMI_TXC-_I

63-

63-

63-

63-

63-

63-

63-

63-

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,64-,68-,70-

R1560

12

30-

HDMI_HPD

WS

1.2K_1%_OPEN
ON_NL17SZ17DFT2_SC-70_5P_OPEN

CS

http://laptopblue.vnhttp://laptopblue.vn

TMDS_TX2+

HDMI_TX2+

TMDS_TX2-

HDMI_TX2-

TMDS_TX1+

HDMI_TX1+

TMDS_TX0+

HDMI_TX0+

TMDS_TX0-

HDMI_TX0-

TMDS_TXC+

HDMI_TXC+
TMDS_TXC-

HDMI_TXC-

TMDS_TX1-

HDMI_TX1-

100pF_50v_OPEN

100pF_50v_OPEN

2

2

1

1

C1554

C1553

C1508

1

1

2

2

100pF_50v_OPEN

100pF_50v_OPEN

CHANGE by

CHANGE by SHEET

QUIETEK_QTC24CG900U_4P

QUIETEK_QTC24CG900U_4P

QUIETEK_QTC24CG900U_4P

QUIETEK_QTC24CG900U_4P

34-

HPDET

CLOSE TO CONNECTOR

U100

NC15VCC

4

GND

Y

CS

MP

CLOSE TO CONNECTOR

L803

1

4

23

L802

1

2

L801

1

23

L800

1

23

+V5S

2

A

3

C823

1
2

100pF_50v

HDMI_L_TX2-

4

3

4

4

HDMI_SCLDDC
HDMI_SDADDC

21

D806

CS

HDMI_L_TX2+

+V5S +V5S

HDMI_L_TX1+

HDMI_L_TX1-

HDMI_L_TXC+

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1

R822

1.8K_5%

2

HDMI_L_TX0+
HDMI_L_TX0-

HDMI_L_TXC-

34­34-

SSM34_3A40V

R820

12

0_5%

1

1

C808

R819

1

D808

OPEN

2

15K_5%

2

2

VARISTOR_OPEN

PM:OPEN change to ON

ON change to OPEN

http://hobi-elektronika.net

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1

R821

1.8K_5%

2

FUSE801

1A_32V_0603SFF100F

12

100pF_50v_OPEN

2
1

C1556

100pF_50v_OPEN

2
1

C1555

+V5S_DDC

1

D807

2

VARISTOR_OPEN

1

D805

2

VARISTOR_OPEN

C1510 C1509

1
2

100pF_50v_OPEN

ES

R21

1

30-

R849

12

34-

12

R22

30-

R848

12

34-

R23

12

30-

R847

12

34-

12

R25

30-

R845

12

34-

R26

12

30-

R844

12

34-

12

R27

30-

R843

12

34-

12

R28

30-

R842

12

34-

12

30-

R846

12

34-

ES

CN802

1

1

2

G1

2

GND

3

G2

3

GND

G3

4

GND

4

G4

5

GND

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

16

16

17

17

18

18

19

19

ALLTOP_C12821_119A5_L_19P

ES

C1507

1
2

100pF_50v_OPEN

TIGER 13-Apr-2007TIGER

2

0_5%_OPEN
0_5%
0_5%_OPEN
0_5%
0_5%_OPEN
0_5%
0_5%_OPEN
0_5%
0_5%_OPEN
0_5%
0_5%_OPEN
0_5%
0_5%_OPEN
0_5%
0_5%_OPENR24
0_5%

WS

close to connector

PM:OPEN change to ON

MP

13-Apr-2007

13-Apr-2007TIGER

63-

HDMI_TX2+_I

63-

HDMI_TX2-_I

63-

HDMI_TX1+_I

63-

HDMI_TX0+_I

63-

HDMI_TX0-_I

63-

HDMI_TXC+_I

63-

HDMI_TXC-_I

63-

HDMI_TX1-_I

ON change to OPEN

INVENTECINVENTEC

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

HDMI CONN

HDMI CONN

HDMI CONN

CODE

SIZE

CODE

SIZE

A3

A3

A3

CS

CS

CS

DOC. NUMBER

DOC. NUMBER

Model_No A02

63 78

63

REV

REV

A02Model_No

A02Model_No

OF

OFSHEET

78

7863

9

http://laptopblue.vnhttp://laptopblue.vn

+V5A

7-,8-,9-,12-,39-,57-,60-,65-,68-

C392

1
2

1uF_10v

SLP_S3#_5R

0_5%

0_5%_OPEN

0.1uF_10v

C387

4.7uF_6.3v

SPDIF_MXM

12

1
2

R416

R415

R417

C337

1
2

10uF_6.3v

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-64-,65-

1

R1660

20K_5%

2

68-

C390

R375

33_5%

SPDIF

MP

1

CS

2

30-

C1901

1
2

1000pF_50v

48

SPDIFO1

1

DVDD

2

SPDIFO2

3

GPIO1

4

DVSS

5

SDATA-OUT

6

BIT-CLK

7

DVSS

REA_ALC888S_LQFP_48P

8

SDATA-IN

9

DVDD-IO

10

SYNC

11

RESET#

12

PCBEEP

SENSE_A

13

ES

45

46

47

43

42

44

LFE

SIDE-L

AVSS2

SIDE-R

CENTER

SPDIFI_EAPD

U23

MIC2-L

MIC2-R

CD-GND

CD-L18CD-R

LINE2-R21MIC1-L

LINE2-L

16

17

19

14

15

41

20

40

SURR-R

JDREF

39

SURR-L

MIC1-R

22

38

23

AVDD2

MIC1-VREFO-R

MIC1-VREFO-L

LINE1-L

C455

12

0.1uF_10v

C456

0.01uF_16v

C457

C458

C454

1uF_6.3v

1uF_6.3v

12

C265

1000pF_50v

12

12

1uF_6.3v

C465

12

0.1uF_10v

+AVCC

1
2

64-,65-

1

2

R418

OPEN

C448

OPEN

12

WS

http://hobi-elektronika.net

C395

12

0.1uF_10v

37

FRONT-R

FRONT-L

PIN37-VREFO

Sense_B

AGPIO

LIN2-VREFO

MIC2-VREFO

LIN1-VREFO

VREF

AVSS1

AVDD1

LINE1-R

24

C460
C459

R434

4.7K_5%

2

1
12

+AVCC

1

10uF_6.3v

2

36
35
34
33
32
31
30
29
28
27
26
25

4.7uF_6.3v

4.7uF_6.3v

WS

C266

C399

4.7uF_6.3v

12

C400

4.7uF_6.3v

12

WS

C396

1

R387

2

2K_5%_OPEN

ES

64-

AREF_R

64-

AREF3

64-

AREF2

64-

AREF_L

64-

AREF_L

64-

AREF_R

1

1

R436

4.7K_5%

2

2

68-

MIC_R

68-

MIC_L

C462

4.7uF_6.3v

12

C461

4.7uF_6.3v

12

WS

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

5

60-

VOL_VR

12

1000pF_50v

4

TI_SN74AUP1G79DCKRE4_SC70_5P

HP_VOL#

+AVCC

64-,65-

1

2

1
2

1
2

BAT54A

1

2

VCC

Q

C336

1000pF_50v

65-

HP_R

65-

HP_L

R386

10_5%

C408

4.7uF_6.3v

C464

0.1uF_10v

3

D31

R438

4.7K_5%

U12

D

CLK

GND

12

1

2

1

2

3

12

WS

60-

64-

R440

4.7K_5%

C410

C405

1
2

60-,64-

AREF2

12

12

C463

0.1uF_10v

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

3

1

S

FDN336P

R250

12

10K_5%

D

KC_FBM_11_160808_101_T_2P

Q17

G

2

C276

1

0.1uF_10v_OPEN

2

L29

12

SLP_S3#_3R

+V3S_HP

65-

R288

7-,8-,9-,11-,12-,30-,37-,42-,60-

1

2

65-

10K_5%

13

D18 CHENMKO_BAT54_3P

4.7uF_6.3v

4.7uF_6.3v

WS

+VREF

65-

C407

12

1uF_6.3v

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

1

R256

47K_5%

2

R254

VOL_EN

68-

68-

VOL_EN

C449

1000pF_50v

LINE_R
LINE_L

12

60-,64-

1
2

CHANGE by

12

C278

0.01uF_16v

+V3S

1

R257

47K_5%

2

C277

1
2

0.01uF_16v

33_5%

R255

12

33_5%

C264

12

1000pF_50v

1

D19

EZJZ0V120JA

2

1

2

D20

EZJZ0V120JA

LED_DIMM#_BUFFER

VOL_A

VOL_B

+VLED

INVENTEC

TITLE

HONOLULU

CODEC

SIZE CODE

A3 CS

13-Apr-2007TIGER

SHEET

HP_SHUTDOWN#

65-

A_RIGHT

65-

A_LEFT

CN9
1
2
3
4
5
6
7
8

ACES_88706_0801_8P

ES

DOC. NUMBER

64 78

1
2
3
4
5

G1

6

G

G2

G

7
8

REV

A02Model_No

OF

C391

1
2

+AVCC

64-,65-

U24

1

VIN

5

VOUT

2

GND

4

C398

0.1uF_16v

C385

1
2

1000pF_50v

CS

AC97_3S_RST#

PCSPKR_ICH_3

A_3S_PCSPKR

C394

1

10uF_6.3v

2

AC97_3S_SDOUT

AC97_3S_BITCLK

AC97_3S_SDIN0

AC97_3S_SYNC

36-

CS

1
2

1
2

37-

41-

1
2

-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

BP

C397

ANPEC_APL5151_SOT23_5P

0.01uF_16v

R376

12

10K_5%

CS

36-

36-

36-

36-

C1900

C388

0.1uF_10v

18pF_50v

C451
12

0.1uF_10v

C450
12

0.1uF_10v

AREF3

65-

MIC_IN

SHDN#

+V3S

3

1

C386

1
2

10uF_6.3v

2

64-

1

R421

4.7K_5%

2

CS

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

68-

MICS

3

D

S

2

LINE_S

C485

12

0.1uF_10v

68-

HPS

C393

12

0.1uF_10v

U900

4

TC7SET04F

C335

0.1uF_10v

Q900
1

G

2N7002W

1

2

5

68-

2

3

100pF_50v

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

1

R378

10K_5%

2

R379

12

9-,12-

0_5%_OPEN

R380

12

R1567

12

ES

+V3S

C389

1

1
2

2

0.1uF_10v

R377

12

10K_5%_OPEN

R420

12

47K_5%

R419

12

47K_5%

C452

1uF_6.3v

C447

0.1uF_10v

12

C453

12

1uF_6.3v

12

R422

1

2

4.7K_5%

12

20K_1%

12

39.2K_1%

12

10K_1%

http://laptopblue.vnhttp://laptopblue.vn

+AVCC+AVCC

64-,65-

64-,65-

A_RIGHT_H

A_RIGHT

AGC_ATTACK

AGC_LV2
AGC_LV1

AGC_ONOFF
AGC_RECOVERY1
AGC_RECOVERY2

SUBWOOFER

65-

64-,65-

65-

C404

2200pF_50v

65­65­65­65­65­65-

C275

C274

C273

C409

12

2200pF_50v

64-,65-

WS

HP_SHUTDOWN#

0.22uF_6.3v

12

1uF_6.3v

12

1uF_6.3v

12

R384

12

CS

+V3S_HP

1

R287

10K_5%_OPEN

2

1

R291

10K_5%

2

R249

12

15K_5%

R248

12

15K_5%

CS

12

150K_5%

12

200K_5%

64-,65-

+VREF

64-,65-

CS

R385

WS

C411

1

0.1uF_10v

2

1

R316

10K_5%_OPEN

2

1

R284

10K_5%

2

WS

U11

1

SHUTDOWN#

27

BYPASS

3

IN+

4

IN-

TI_TPA6211A1DRB_QFN_8P

TLV2462CDGKR_SSOP_8P

1

R317

10K_5%_OPEN

2

1

R318

10K_5%

2

8

VO-

GND

6

VDD

5

VO+

9

TML

U26

1

1OUT

2

1IN-

3

1IN+

4

GND

1

R281

10K_5%_OPEN

2

1

R285

10K_5%

2

+VAUDIO_5S

65-

1
2

VDD+
2OUT

C267

1uF_10v

2IN-

2IN+

HP_L

HP_OUTL

HP_OUTR

HP_R

64-,65-

8
7
6
5

1

R283

10K_5%

2

1

R290

10K_5%_OPEN

2

WS

ES

+VREF

1

2

65-

65-

64-

68-

68-

64-

CS

R381

12

R383

12

200K_5%

C403

WS

0.1uF_10v

1

R280

10K_5%_OPEN

2

1

R282

10K_5%

2

SPK_SUB-

SPK_SUB+

WS

WS

150K_5%

C402

2200pF_50v

12

SPK_SUB+
SPK_SUB-

CS

C401

12

2200pF_50v

65­65-

C121

OPEN

+V5A

7-,8-,9-,12-,39-,57-,60-,64-,68-

L28

12

KC_FBM_11_160808_101_T_2P

+V3S_HP

64-,65-

1
2

R308

12

10K_5%

R311

12

68_5%

R312

12

68_5%

R315

12

10K_5%

1

R309

10K_5%

2

1

R314

10K_5%

2

MP

http://hobi-elektronika.net

121

1
2

C338

1uF_6.3v

65-

64-,65-

C270

0.1uF_10v

SUBWOOFER

A_LEFT

1
2

ACES_87213_0200N_2P

C122

2

OPEN

C269

1

0.1uF_10v

2

HP_SHUTDOWN#

C339

1
2

1uF_6.3v

WS

+VREF

64-,65-

CN2

G

3

1

4

G

2

ES

+VAUDIO_5S

65-

1

C268

2

WS

65-

C343

12

0.022uF_16v

CS

47uF_10v

64-,65-

WS

64-,65-

C340

1
2

22uF_6.3v

MP

R278

12

0_5%

R277

12

0_5%

U13

49

TP870

TML-PAD

37

TEST4

38

VCC_CP

39

C1

40

GND_CP

41

C2

42

VSS_CP

43

VSS

44

HP_INL

45

HP_OUTL

46

GND

47

HP_OUTR

48

HP_INR

+V3S_HP

U16

1

VDD+

1OUT

2

2OUT

1IN-

3

1IN+

4

2IN+

GND

TLV2462CDGKR_SSOP_8P

R313

12

10K_5%

C406

12

0.027uF_10v

CS

ACES_87213_0200N_2P

2

G

4

2

1

3

G

1

CN6

+V3S_HP

64-,65-

C300

1
2

1uF_6.3v

30

298

33

34

31

35

36

HP_STBY2

SP_STBY1

SP_STBY2

HP_STBY1

28

32

27

VCC

GND

TEST3

SP_INL

VREFSP

PREOUT_LPREOUT_R

PAN_AN12948A_QFP_48P

SP_INR

TEST1

VCC_HP

GND

AGC_ATTACK

AGC_LV13AGC_LV2

AGC_ON-OFF

AGC_RECOVERY1

9

5

1

7

4

2

6

10

C344

1
2

1uF_6.3v

CHANGE by

CHANGE by

CHANGE by

8
7
6

2IN-

5

R382

1

10K_5%

1
2

26

25

NC

TEST2

GND_SPL
SP_OUTL+
SP_OUTL+

SP_OUTL­SP_OUTL-

VCC_SPL

VCC_SPR

SP_OUTR-

SP_OUTR­SP_OUTR+
SP_OUTR+

GND_SPR

NC

AGC_RECOVERY2

12

11

ES

CS

R310

12

100K_5%

C342

1

0.1uF_10v

64-

D500

EZJZ0V120JA

2

SPK_OUT_L­SPK_OUT_L+

MIC_IN

SPK_OUT_R­SPK_OUT_R+

2

1

2

MP

MP

R276

12

24.3K_1%

1

R279

C299

10K_5%

820pF_25v

2

WS

C301

1

2

65-

1uF_6.3v

24
23
22
21
20
19
18
17
16
15
14
13

1

C302

820pF_25v

2

65-

AGC_ATTACK

65-

AGC_LV2

65-

AGC_LV1

65-

AGC_ONOFF

65-

AGC_RECOVERY1

65-

AGC_RECOVERY2

TIGER 13-Apr-2007

TIGER 13-Apr-2007

65­65-

C69

OPEN

65­65-

C67

OPEN

C298

1

1uF_6.3v

+VAUDIO_5S

C271

1
2

1uF_6.3v

1

R286

10K_5%

2

ES

13-Apr-2007TIGER

1uF_6.3v

2

100K_5%

C341

100K_5%

12

C68

1

1
2

2

OPEN

C66

1

1

2

2

1
2

65-

C272

1uF_6.3v

OPEN

A_LEFT_H

MP

C303

R289

1

12

24.3K_1%
1uF_6.3v

INVENTEC

INVENTEC

INVENTEC

TITLE

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

AMP&HPF&LPF

AMP&HPF&LPF

AMP&HPF&LPF

CODE

SIZESIZE REVDOC. NUMBER

SIZE

CODE

A3

A3

A3

CS

CS

CS

SHEET

SHEET

R306

12

64-,65-

R307

12

64-,65-

CN3

1

1

2

2

3

3

4

4

ACES_87212_0400N_4P

65-

SPK_OUT_L+

65-

SPK_OUT_L-

65-

SPK_OUT_R-

65-

SPK_OUT_R+

2

65-

A_RIGHT_H

DOC. NUMBERCODE

Model_No A02

Model_No A02

OF

OFSHEET

OF

65 78

A_RIGHT
A_LEFTA_LEFT_H

G
G

G1
G2

REVDOC. NUMBER

REV

A02Model_No

7865

7865

http://laptopblue.vnhttp://laptopblue.vn

+V3

L37

BLM11P600S

12-,68-

12

C445

1
2

0.1uF_16v

CN17

1

MC97_3S_SDOUT

MC97_3S_SYNC
AC97_3S_SDIN1

MC97_3S_RST# MC97_3S_BITCLK

36-

36-

12

36-

R414 33_5%

36- 36-

GND

3

Azalia_SDO

5

GND

7

Azalia_SYNC

9

Azalia_SDI
Azalia_RST#

G1

G

G2

G

G3

G

TYCO_1_1775014_2_12P

REVERSED
REVERSED

3.3Vmain-aux

Azalia_BCLK

2
4
6
8

GND

10

GND

1211
G4

G

G5

G

G6

G

10uF_6.3v

C446

MDC

1
2

http://hobi-elektronika.net

CHANGE by

TIGER

13-Apr-2007

INVENTEC

TITLE

HONOLULU

MDC1.5

SIZE

A3

CODE

CS

DOC. NUMBER

66 78

REV

A02Model_No

OFSHEET

http://laptopblue.vnhttp://laptopblue.vn

POWER SWITCH

SW1

1

PWR_OLED#

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

60-

GMT_G1214T12Uf_SOT23_5P

3

2

DIP_DTSM_61N_S_V_TR_4P

4

+V3A

5

U6

3

+

1

OUT

4

­2

MP

C232

1
2

1000pF_50v

PWR_BUF_OLED#

1

2

68-

D15

D14

1

37-,60-

PWR_SWIN#_3

D17

EZJZ0V120JA

EVL_21SUYC_OPEN

21

EVL_21SUYC_OPEN

2

2

1

270_5%_OPEN

12

270_5%_OPEN

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

R201

R191

CS

+VLED

60-,64-,68-

D16

D13

21

1

2

LED_BLU_19_21_BHC_ZL1M2TY_3T

LED_BLU_19_21_BHC_ZL1M2TY_3T

R190

12

150_5%

R189

12

150_5%

POWER LED

WS

http://hobi-elektronika.net

CS

CHANGE by

INVENTEC

TITLE

HONOLULU

POWER SW

SIZE

13-Apr-2007TIGER

A3

CODE

CS

SHEET

DOC. NUMBER REV

67 78

A02Model_No

OF

http://laptopblue.vnhttp://laptopblue.vn

+V5S

+V3LA

+V3A

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

+V3+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

12-,66-

LED_6IN1

WLON#

BTIFON#

REC_LED

+V5LA

5-,6-,7-,12-,18-

60-

67­60­60­36­56­41­53-,60­58-,60­60-

CIR_OUT

L_CIR_RX1

DCIN_BLED#
PWR_BUF_BLED#
PWR_BUF_OLED#

BAT0_BLED#

BAT0_OLED#

HDD_LED#
ODD_LED#

RESERVE_LED#

+V5A

6-,7-,12-,18-,36-,56-,60-,68-

CS

CS

60-

60-

CS

7-,8-,9-,12-,39-,57-,60-,64-,65-

CN1000

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

16

16

17

17

18

18

19

19

20

20

21

21

22

22

23

23

24

24

25

25

26

26

27

G1

27

G

28

G2

28

fpc_aces_28_050_r_200

G

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

SPDIF

HPS
HP_OUTL
HP_OUTR

MICS

MIC_L

MIC_R

LINE_S

LINE_L

LINE_R

KILL_SWCH#

7-,37-,38-,39-,45-,51-,53-,59-,60-,67-,68-

+V3A

64-

64­65­65-

64­64­64-

64­64­64-

53-,58-,60-

+V5S

CN19

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

16

16

17

G1

G

17

18

G2

G

18

19

19

20

20

ACES_88442_2001_20P

USB_P8+

USB_P8-

IM_CLK_5
IM_DAT_5

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

CN13

1

1

37­37-

60­60-60-

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

G1

15

G

15

G2

16

G

16

ACES_88706_1601_16P

LID_SW#_3

SCAN_OUT(13)

SCAN_IN(7)
SCAN_IN(6)
SCAN_IN(5)
SCAN_IN(3)
SCAN_IN(2)
SCAN_IN(1)

60-

60-,62­60-,62-,68­60-,62­60-,62-,68­60-,62-,68­60-,62­60-,62-,68-

ES

+VLED

60-,64-,67-

+V3LA

6-,7-,12-,18-,36-,56-,60-,68-

CN16

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

G

16

16

G

ACES_88706_1601_16P

TP859

TP858

TP857

SCAN_IN(0)
SCAN_IN(7)
SCAN_IN(3)
SCAN_IN(4)
SCAN_IN(5)
SCAN_IN(1)

DOBLY

TV_OUT

60-,62­60-,62­60-,62­60-,62­60-,62-,68­60-,62-,68­60-,62­60-,62-,68­60-,62-,68-

37­37-

SCAN_OUT(1)
SCAN_OUT(4)
SCAN_OUT(2)

MACHINE_ID0_DB

G1
G2

MACHINE_ID1_DB

WS

http://hobi-elektronika.net

CN4

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

G1

15

G

15

G2

16

G

16

ACES_88706_1601_16P

CHANGE by

INVENTEC

TITLE

HONOLULU

DB CONN

CODE DOC. NUMBER REV

SIZE

A3

CS

13-Apr-2007TIGER

SHEET OF

68 78

A02Model_No

http://laptopblue.vnhttp://laptopblue.vn

FIX4

FIX_MASK

FIX5

FIX6

FIX_MASK

FIX_MASK FIX_MASK

FIX8

FIX_MASK

FIX1 FIX7

FIX2

FIX3

FIX_MASKFIX_MASK

FIX_MASK

S214

SCREW2.8_10_1P

S222 S223

SCREW3.7_8_1P

S217

SCREW3.7_13_1P

S238

SCREW2.8_8_6_1P

S243

SCREW3.7_0_6_1P

S283

SCREW3.2_10_1P

S284

SCREW3.7_0_8_1P

S288

SCREW3.7_6_0_1P

S300

SCREW1.2_6_0_1P

S215

S233

S244

S285

S304

S301

S216 S219

SCREW2.8_10_1P

SCREW3.7_8_1P

SCREW3.7_13_1P

SCREW3.7_0_6_1P

SCREW3.7_0_8_1P SCREW3.7_0_8_1P

SCREW3.7_6_0_1P

SCREW1.2_6_0_1P

SCREW2.8_10_1P

S224

SCREW3.7_8_1P

ES

S245

S286

S302

SCREW1.2_6_0_1P

ES

S225

SCREW3.7_8_1P

SCREW3.7_0_6_1PSCREW3.7_0_6_1P

S287

SCREW3.7_0_8_1P

S303

SCREW1.2_6_0_1P

S218

SCREW2.8_10_1P

S305

SCREW3.7_8_1P

ES

S247S246

SCREW3.7_0_6_1P

SCREW2.8_10_1P

S220

SCREW2.8_10_1P

S221

SCREW2.8_10_1P

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

SCREW

SIZE CODE DOC. NUMBER REV

CHANGE by OF

TIGER 13-Apr-2007

A3

Model_No A02

CS

SHEET

7869

http://laptopblue.vnhttp://laptopblue.vn

8-,12-,19-,24-,25-,27-,28-,70-

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

C240

0.1uF_16v

C255

0.1uF_16v

C318

0.1uF_16v

C307

0.1uF_16v

C243

0.1uF_16v

C308

0.1uF_16v

C211

0.1uF_16v

C225

0.1uF_16v

C321

0.1uF_16v

C256

0.1uF_16v

C257

12

1000pF_50v

+V1.8

8-,12-,19-,24-,25-,27-,28-,70-

12

12

+V0.9S

8-,29-

C254

C239

C295

C242

1000pF_50v

C319

1000pF_50v

C320

1000pF_50v

12

0.1uF_16v

12

0.1uF_16v

12

0.1uF_16v

12

12

12

12

12

12

12

2

1

WS

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

8-,12-,19-,24-,25-,27-,28-,70-

C200

12

1000pF_50v

12

12

1

2

WS

+VCCP+V1.8+V1.8

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

+VBAT

5-,6-,7-,8-,9-,10-,11-,30-

C33

C2

C34

C32

12

1000pF_50v

12

1000pF_50v

12

1000pF_50v

12

1000pF_50v

+VCCP

9-,13-,14-,15-,16-,22-,24-,25-,36-,39-,70-

C984

12

1000pF_50v

+V3S +V5S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C346

1

2

1000pF_50v

C327

12

1000pF_50v

+V5S

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

C345

2

1

1000pF_50v

C328

12

1000pF_50v

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

8-,9-,10-,11-,12-,18-,30-,31-,33-,36-,37-,39-,41-,42-,46-,47-,48-,49-,54-,55-,56-,60-,61-,63-,64-,68-,70-

+V3S

9-,10-,11-,12-,13-,18-,19-,20-,25-,27-,28-,30-,31-,33-,34-,35-,36-,37-,38-,39-,41-,42-,43-,44-,45-,46-,47-,48-,50-,53-,55-,56-,58-,59-,60-,62-,63-,64-,68-,70-

C215

0.1uF_16v

12

C924

0.1uF_16v

12

C925

0.1uF_16v

12

C926

0.1uF_16v

12

C982

0.1uF_16v

12

C977

0.1uF_16v

12

C214

0.1uF_16v

12

C217

0.1uF_16v

12

C123

0.1uF_16v

12

C208

0.1uF_16v

12

WS

FOR EMI

http://hobi-elektronika.net

INVENTEC

TITLE

HONOLULU

EMI

DOC. NUMBER

CODE

A3

CS

13-Apr-2007TIGER

SHEET

70 78

REVSIZE

A02Model_No

OFCHANGE by

http://laptopblue.vnhttp://laptopblue.vn

GPIO13

USB_P8+_FP
USB_P8-_FP

71-

1

R3006

1.5K_1%

2

R3005 27_5%

71­71-

1

R3007

100K_5%

2

GND_TP

NVM_CS

CP_BYPASS

NVM_CS

12
12

GPIO13

27_5%R3008

71-

71-

71-

71-

+V3S_FP

71-

+V3S_FP

71-

GND_TP

U3001

B2

1-PAD_VDD

B1

2-USB_DP

C2

3-USB_DN

D4

4-DIG_VDD

D3

5-DIG_GND

C1

6-U_RX0

D2

7-U_TX0

D1

8-U_EXTCK0

E4

9-U_TX1

E2

10-U_RX1

E1

11-GPIO0

E3

12-GPIO1

F4

13-GPIO2

F2

14-PAD_VDD

F1

15-PAD_GND

F3

16-S_NVM

F5

17-GPIO3

G5

18-GPIO15

G3

19-GPIO14

G1

20-GPIO13

G2

21-GPIO12

G4

22-GPIO11

H1

23-GPIO10

H2

24-GPIO9

J1

25-GPIO8

H3

26-EDATA7

H4

27-PAD_VDD

J2

28-PAD_GND

K1

29-EDATA8

K2

30-EDATA5

L1

31-EDATA4

J3

32-EDATA3

L2

33-EDATA2

K3

34-EDATA1

J4

35-EDATA0

L3

36-ECSON

K4

37-DIG_GND

L4

38-DIG_VDD

H5

39-GPIO7

K5

40-GPIO4_D_NVM

L5

41-PAD_VDD

J5

42-PAD_GND

G6

43-ERDN

H6

44-EWRON0

J6

45-EWRON1

L6

46-EADDR0

K6

47-EADDR1

H7

48-EADDR2

J7

49-EADDR3

L7

50-W_NVM

R3020

12

OPEN

71-

B3

A3

A1

PD0-120A2PD1-119

PAD_GND-121

51-PAD_GND

52-PAD_VDDL853-EADDR4

K8

K7

G7

NVM_CS

+V3S_FP

B4

E5

PD2-118C3PD3-117

PD4-116C4PD5-115

PD6-114D5PD7-113

PDGATE_TC_DREADY-109

54-EADDR5L955-EADDR6

56-EADDR7J857-EADDR8

K9

L10

71-

A4

B5

HOLD_NVM-111

VCC_NVM-112

PDTRIG_TCDATA-108

GPIO6_C_NVM-101
GPIO5_D_NVM-100

58-EADDR9

59-EADDR10

60-EADDR11

61-EADDR12

J9

UPEK_TCD42A1DN0_BGA_121P

L11

K10

PDCLK-110

TC_MCK-107
TC_MISO-106
TC_MOSI-105

PAD_GND-104

PAD_VDD-103

TC_NCS-102

TC_NRESET-99

DIG_GND-98
DIG_VDD-97

DC_BYPASS-96

M3_1-95
M3_0-94

REF_OSC-93

TEST_EN-92

AGND_PLL-91

AVDD_PLL-90

XTALIN-89

XTALOUT-88

SC_PWR-87

SC_PWRIN-86

RESTART-85

NRESET-84

WAKEUP-83

PAD_GND-82

PAD_VDD-81

SENSE-80

TMS-79
TCK-78

TDI-77

TDO-76

SC_DETECT-74

SC_ID-73

SC_RESET-72

SC_CK-71
EADDR17-70
EADDR16-69
EADDR15-68
EADDR14-67
DIG_GND-66
DIG_VDD-65

PAD_VDD-64

PAD_GND-63

EADDR13-62

C5
A5
F6
E6
A6
B6
A7
C6
D6
B7
A8
C7
D7
B8
C8
D8
A9
B9
A10
A11
B10
C9
B11
C10
D9
C11
D10
E7
D11
E10
E9
E8
E11
F10
F11
F9

75

F8
F7
G9
G11
G10
G8
H11
H10
J11
H9
H8
J10
K11

GND_TP

12

C3002

1
2

22pF_50v

USB_P8+_FP

USB_P8-_FP

IM_CLK_5_FP
IM_DAT_5_FP

R3000

X3000

12MHZ

C3000

1
2

0.1uF_16v

71-

DREADY

71-

DDATA

71-

MCLK

71-

MISO

71-

MOSI

71-

MCS

71-

TC_NRESET

71-

M3_0

12

1K_5%

71-

CP_VIN

71-

SENSE

71-

SENSE

C3013

1
2

22pF_50v

GND_TP

71­71-

72­72-

C3003

+V5S_FP

72-

+V3S_FP

71-

ACES_88706_1601_16P

1
2

12

C3001

0.1uF_16v

56pF_50v

GND_TP

CP_PWRIN

CP_VOUT

CN3001

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

16

16

1
2

GND_TP

+V3S_FP

71-

1
2

GND_TP

G1

G

G2

G

C3011

0.1uF_16v

1

R3001

15_5%

2

C3004

0.1uF_16v

71­71-

1
2

1
2

RING

M3_0

1

R3009

33K_5%

2

C3012

1uF_10v

C3006

2.2uF_16v

CP_VOUT

71-

71-

CP_VIN

SENSE

C3019

12

0.01uF_50v

+V3S_FP

1
2

GND_TP

C3007

1
2

0.47uF_6.3v

71-

71-

71-

R3018

12

4.7K_5%

71-

C3014

1uF_10v

1
2

R3010

12

470_5%

CS

CP_VOUT

C3008

0.47uF_6.3v

Q3000

2

E

1

B

C

3

MMBT2907

3

1

R3014

OPEN

2

1

R3012

OPEN

2

GND_TP

CP_VOUT

1
2

GND_TP

12

1

R3013

47K_5%

2

12

D3010

RClamp0502B

71-

GND_TP

C3005

2.2uF_16v

R3011

2_5%

1
2

C3015

1000pF_50v

1

R3016

330K_5%

2

1

R3015

GND_TP

15_5%

2

C3016

1
2

1uF_10v

12

71-

R3003 22K_5%

1

R3004

22K_5%

2

GND_TP

71-

CP_PWRIN

C3018

12

0.1MFD_50v

CP_VOUT

DDATA

DREADY

CP_VOUT

CP_BYPASS

MCLK

TC_NRESET

CP_PWRIN

1
2

GND_TP

+V3S_FP

71-

1

R3019

47K_5%

2

5

D3002

Vp

CH1

CH2

34

Vn

2

CMD_1213_02ST_SOT23_5P

R3017

12

120_5%

71­71-

71­71­71­71-

MOSI

71-

MISO

71­71-

MCS

71-

RING

71-

71-

C3009

1uF_10v

FIX17

FIX_MASK

GND_TP

FIX18

FIX_MASK

71-

M3_0

GND_TP

U3000

A1

RING1

B1

DGND2

C1

GRIDO_SENSE

D1

AVDD

E1

ESD_GND1

F1

ESD_GND2

G1

ESD_GND3

H1

ESD_GND4

J1

DVDD

K1

DATA7DDATASDAT

L1

DGND3

M1

DGND4

A2

REFL

B2

EXTSYSCLKEN

C2

CHARGE

D2

OFFSET

E2

REF_FERQ_MUXOUT

F2

INT

G2

CLOCKTEST

H2

DATA6_SFRAME

J2

DATA5

K2

DATA4

L2

PDCLKDREADYSCK

M2

PAD_VDD

A3

CP_BYPASS

B3

MOSI

C3

MISO

D3

SYS_CLK

E3

MCLK

F3

MCS

G3

DATA3

H3

DATA2

J3

DATA1_MODE1

K3

DATA0_MODE0

L3

CP_VDDPUMP1

M3

CP_VPUMP

A4

RINGO

B4

DGND6

C4

NRESET

D4

SCANMODE

E4

ESD_GND5

F4

ESD_GND6

G4

ESD_GND7

H4

ESD_GND8

J4

CP_CCN

K4

CP_CCP

L4

CP_VDDPUMP2

M4

DGND8

UPEK_TCS3CD6A0_BGA_48P

FIX19

FIX_MASK

FIX20

FIX_MASK

BE1
BE2
BE3
BE4

71-

GND_TP

1
2

RING

C3010

39pF_50v

WS

http://hobi-elektronika.net

GND_TPGND_TP

CHANGE by

CHANGE by

CHANGE by

TIGER 13-Apr-200713-Apr-2007TIGER

TIGER 13-Apr-2007

13-Apr-2007TIGER

INVENTEC

INVENTEC

INVENTEC

TITLE

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

HONOLULU

FINGER PRINTER

FINGER PRINTER FINGER PRINTER

FINGER PRINTER

SIZE

CODE

CODE DOC. NUMBER

CODESIZE DOC. NUMBER

SIZE

A3

A3

A3

A3

DOC. NUMBER

Model_No A02

Model_No A02

Model_No

CS

CS

CS

CS

SHEET

SHEET

SHEET

71 78

71 78

REV

REV

REV

A02Model_No

A02

OF

OF

OF

7871

7871

IM_CLK_5_FP
IM_DAT_5_FP

PHP_PESD5V2S2UT_SOT23_3P

http://laptopblue.vnhttp://laptopblue.vn

+V5S_FP

CN3000

72-

LEFT_TP

72-

RIGHT_TP

71­71-

2

D3006

1

3

PHP_PESD5V2S2UT_SOT23_3P

MP

GND_TP

SW3002

4
5

WS

WS

6

MISAKI_NTC031_EA1G_A106T_6P_OPEN

SW3003

4
5
6

MISAKI_NTC031_EA1G_A106T_6P

SW3000

4
5
6

MISAKI_NTC031_EA1G_A106T_6P

SW3001

4
5
6

MISAKI_NTC031_EA1G_A106T_6P_OPEN

D3005

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

72-

72-

2

3

GND_TP

RIGHT_TP

LEFT_TP

1

R3002

12

OPEN

PAD3000

POWERPAD_2_0610

1

1

2

2

3

3

4

ES

4

5

5

6

6

7

7

8

8

9

G

9

10

G

10

11

11

12

12

KYO_6212_012_340_800_12P

ES

MP

G1
G2

GND_TP

GND_TP

GND_TP

TOUCH PAD BOARD

S296

SCREW3_8_1P

http://hobi-elektronika.net

S297

SCREW3_8_1P

INVENTEC

INVENTEC

INVENTEC

INVENTEC

INVENTEC

TITLE

TITLE

TITLE

TITLE

TITLE

HONOLULU

Touch Pad

SIZE CODE

CODEMPDOC. NUMBER

SIZE CODESIZE

SIZE

CODE REV

CODE

SIZE

A3

CHANGE by

CHANGE by

CHANGE by SHEET OFSHEET

CHANGE by

TIGER 13-Apr-2007

CS

SHEET

SHEET

SHEET

DOC. NUMBER

DOC. NUMBERDOC. NUMBEROFREV

DOC. NUMBER

Model_No A02

REV

REV

REV

OF

OF

OFCHANGE by

7872

http://laptopblue.vnhttp://laptopblue.vn

GROUND_H

SCAN_HK_IN(0)

SCAN_HK_IN(7)
SCAN_HK_IN(3)

SCAN_HK_IN(4)
SCAN_HK_IN(5)

SCAN_HK_IN(1)

SCAN_HK_OUT(2)

SCAN_HK_OUT(4)

SCAN_HK_OUT(1)

TV

S294 S295

SCREW3_6_1P

SCAN_HK_OUT(1)
SCAN_HK_OUT(4)
SCAN_HK_OUT(2)

SCAN_HK_IN(0)
SCAN_HK_IN(7)
SCAN_HK_IN(3)
SCAN_HK_IN(4)
SCAN_HK_IN(5)
SCAN_HK_IN(1)

DOBLY_HK

TV_OUT_HK

MACHINE_ID0_HK
MACHINE_ID1_HK

73-

73-

73-

73-

73-

73-

73-

73-

73-

GROUND_H

73­73­73­73­73­73­73­73­73-

3

3

3

3

3

23

1

CD/DVD

SCREW3_6_1P

1

1

R5001

R5000

OPEN

OPEN

2

2

GROUND_H

GROUND_H

VARISTOR_OPEN

D5002

1

2

PHP_PESD5V2S2UT_SOT23_3P

D5003

1

2

PHP_PESD5V2S2UT_SOT23_3P

D5004

1

2

PHP_PESD5V2S2UT_SOT23_3P

D5005

1

2

PHP_PESD5V2S2UT_SOT23_3P

D5006

1

2

PHP_PESD5V2S2UT_SOT23_3P

MP

CN5000

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

G1

15

G

16

G2

16

G

ACES_88706_1601_16P

1

1

D5001

D5000

VARISTOR_OPEN

2

2

GROUND_H

CS

4

STOP

CS

FIX29

FIX_MASK

GROUND_H

REW(BACK)PLAY/PAUSE

FIX30

FIX_MASK

5

FIX31

FIX_MASK

CS

6

FF(NEXT)

78

REC

BRIGHTNESS(TOGGLE)

SCAN_HK_IN(0)

FIX32

FIX_MASK

SCAN_HK_IN(7)

SCAN_HK_IN(3)

SCAN_HK_IN(4)

SCAN_HK_IN(5)

SCAN_HK_IN(1)

SCAN_HK_IN(0)

SCAN_HK_IN(7)

SCAN_HK_IN(4)

SCAN_HK_IN(1)

SCAN_HK_IN(4)

http://hobi-elektronika.net

9

DIMMER ZOOM(+)/DOLBY

5

73-

MISAKI_NTC031_EA1G_A106T_6P

3

73-

CS

73-

73-

73-

73-

73-

73-

73-

73-

73-

MISAKI_NTC031_EA1G_A106T_6P

4

MISAKI_NTC031_EA1G_A106T_6P

6

MISAKI_NTC031_EA1G_A106T_6P

10

MISAKI_NTC031_EA1G_A106T_6P

11

MISAKI_NTC031_EA1G_A106T_6P

1

MISAKI_NTC031_EA1G_A106T_6P

2

MISAKI_NTC031_EA1G_A106T_6P

7

MISAKI_NTC031_EA1G_A106T_6P

8

MISAKI_NTC031_EA1G_A106T_6P

9

MISAKI_NTC031_EA1G_A106T_6P

GROUND_H GROUND_H

10

11

ZOOM(-)/TV-OUT

SW5008

4
5
6

SW5007

4
5
6

SW5006

4
5
6

SW5005

4
5
6

SW5001

4
5
6

SW5000

4
5
6

SW5010

4
5
6

SW5009

4
5
6

SW5004

4
5
6

SW5003

4
5
6

SW5002

4
5
6

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

1

BCDA

2
3

73-

SCAN_HK_OUT(2)

73-

SCAN_HK_OUT(4)

73-

SCAN_HK_OUT(1)

WS

CHANGE by SHEET

CHANGE by

TIGER 13-Apr-2007

TIGER 13-Apr-2007

TIGER 13-Apr-2007

TIGER

13-Apr-2007

INVENTEC

INVENTEC

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

HONOLULU

Hot Keys Board

Hot Keys Board

Hot Keys Board

SIZE

CODE DOC. NUMBER

SIZE

CODE

DOC. NUMBER

Model_No A02

Model_No A02

Model_No A02

A3

A3

A3

A3

Model_No A02

CS

CS

CS

CS

SHEET

REV

REV

OF

OF

7873

7873

7873

7873

http://laptopblue.vnhttp://laptopblue.vn

LID_SW#_3_5W

SCAN_5W_OUT(13)

SCAN_5W_IN(7)
SCAN_5W_IN(6)
SCAN_5W_IN(5)
SCAN_5W_IN(3)
SCAN_5W_IN(2)
SCAN_5W_IN(1)

74-

74­74­74­74­74­74­74-

LID SWITCH

U8000

3

SAM_HED55XXU12_SOT23_3P

GROUND_5W

SW8000

1

4

BCDA

2

5
6

3

MISAKI_NTC031_EA1G_A106T_6P

SW8002

1

4

BCDA

2

5

3

6

MISAKI_NTC031_EA1G_A106T_6P

SW8004

1

4

BCDA

2

5

3

6

MISAKI_NTC031_EA1G_A106T_6P

SW8005

1

4

BCDA

2

5

3

6

MISAKI_NTC031_EA1G_A106T_6P

SW8003

4

1

BCDA

5

2
3

6

MISAKI_NTC031_EA1G_A106T_6P

SW8001

1

4

BCDA

2

5

3

6

MISAKI_NTC031_EA1G_A106T_6P

GROUND_5W

MP

1

D8010

3

PHP_PESD5V2S2UT_SOT23_3P

2

CS

74-

SCAN_5W_OUT(13)

LEFT

UP

DOWN

RIGHT

OK

BACK

+VLED_5W

+V3LA_5W

74-

74-

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16

CN8000

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16

SCAN_5W_IN(1)

SCAN_5W_IN(2)

SCAN_5W_IN(3)

SCAN_5W_IN(5)

SCAN_5W_IN(6)

SCAN_5W_IN(7)

G1

G

G2

G

74-

PHP_PESD5V2S2UT_SOT23_3P

74-

74-

PHP_PESD5V2S2UT_SOT23_3P

74-

74-

PHP_PESD5V2S2UT_SOT23_3P

74-

D8005

D8007

D8009

MP

1

3

2

1

3

2

1

3

2

CS

ACES_88706_1601_16P

D8000

D8003

D8004

D8001

GROUND_5W

+VLED_5W

74-

R8000

21

GROUND_5W

21

GROUND_5W

21

GROUND_5W

21

GROUND_5W

CHANGE by SHEET OF

12

1

240_5%

D8011

EZJZ0V120JA

2

1

2

1

2

1

2

D8012

EZJZ0V120JA

D8013

EZJZ0V120JA

D8014

EZJZ0V120JA

R8001

12

240_5%

R8002

12

240_5%

R8003

12

240_5%

TIGER 13-Apr-2007

MP

GROUND_5W

13-Apr-2007TIGER

FIX35

FIX_MASK

S292

FIX37 FIX38

FIX36

FIX_MASK

FIX_MASK

SCREW2.3_6_1P

INVENTEC

INVENTEC

TITLE

TITLE

HONOLULU

HONOLULU

5-ways+BACK

5-ways+BACK

CODECODE

SIZE DOC. NUMBER

A3

A3

CS

CS

SHEET

S293

WS

FIX_MASK

SCREW2_6_1P

DOC. NUMBER

Model_No A02

OFCHANGE by

74 78

7874

REVSIZE

REV

A02Model_No

GROUND_5W

GROUND_5W

D8019

EZJZ0V120JA

D8020

EZJZ0V120JA

D8021

EZJZ0V120JA

D8022

EZJZ0V120JA

R8005

12

240_5%

R8006

1

240_5%

R8007

12

240_5%

R8008

12

240_5%

D8015

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

+V3LA_5W

74-

1

R8004

100K_5%

2

Output

GND

1

Vdd

2

1
2

GROUND_5W

C8000

1000pF_50v

1

2

GROUND_5W

74-

D8002

EZJZ0V120JA

LID_SW#_3_5W

LED_BLU_19_21_BHC_ZL1M2TY_3T

LED_BLU_19_21_BHC_ZL1M2TY_3T

GROUND_5W

D8016

LED_BLU_19_21_BHC_ZL1M2TY_3T

D8017

D8018

1

2

GROUND_5W

21

1

2

GROUND_5W

21

1

2

GROUND_5W

21

1

2

GROUND_5W

+VLED_5W

2

GROUND_5W

74-

LED_BLU_19_21_BHC_ZL1M2TY_3T

LED_BLU_19_21_BHC_ZL1M2TY_3T

LED_BLU_19_21_BHC_ZL1M2TY_3T

LED_BLU_19_21_BHC_ZL1M2TY_3T

GROUND_5W

MP

http://hobi-elektronika.net

HP_OUTR_AB

HP_OUTL_AB

LINE_L_AB

LINE_R_AB

75-

75-

FOX_JA6333L_B3S0_7F_6P

75-

75-

MICS_AB

JACK4000

AUDIO_GROUND

MP

LINE_S#_AB

L4006

12

BLM11A121S

L4005

12

BLM11A121S

C4004

1
2

470pF_50v

AGROUND_AUDIO

75-

5
4
3
6
2
1
G1
G2

AGROUND_AUDIO

S298

SCREW4.3_9_1P

L4003 BLM11A121S

12
12

75-

C4003

1
2

470pF_50v

C4010

1
2

470pF_50v

S299

SCREW4.3_9_1P

CS

PHP_PESD5V2S2UT_SOT23_3P

BLM11A121SL4007

C4005

1
2

470pF_50v

AGROUND_AUDIO

http://laptopblue.vnhttp://laptopblue.vn

JACK4001

G2

AGROUND_AUDIO

C4002

1
2

470pF_50v

AGROUND_AUDIO

1

C4012

2

470pF_50v

BLM11A121S
BLM11A121S
BLM11A121S

HPS_AB

G1

1
2
6
3
4
5

L4000

12

L4002

12

L4001

12

D4008

SPDIF_AB

FOX_JA6333L_B3S0_7F_6P

R4000

R4001

AGROUND_AUDIO

MP

2

3

1

AUDIO_GROUND

75-

+V5S_SPDIF_AB

75-

1

2

JACK4003

SINGA_2SJ_D390_001_6P

0_5%

12

12

0_5%

2N7002W

+V5S_AB

75-

1

R4004

10K_5%

2

75-

R4005

C4011

1

2.2K_1%

2

0.1uF_10v

http://hobi-elektronika.net

5
1
2
3
4
6

75-

75-

+V5S_AB

75-

Q4000

3

D

1

G

S

2

AUDIO_GROUND

5
4

2
3

1

7
8

AUDIO_GROUND

1

2

CS

TVGND

MIC_R_AB
MIC_L_AB

+V5S_AB

BSS84

1

Q4001

75-

2

S

G

D

3

R4002

4.7K_5%

JACK4002

VIN
VCC
GND

FOX_2F11381_TJ1_10P

WS

75-

EXCVB1-PXP

1

ES

2

1

ES

2

TVGND

+V5S_SPDIF_AB

75-

1

2

GG1
GG29

ES

AUDIO_GROUND

CS

MP

R4007

33K_5%

R4008

20K_5%_OPEN

R4006

100K_5%

MP

1

R4010

33K_5%

2

1

R4009

20K_5%_OPEN

2

TVGND

ES

ES

EXCVB1-PXP

EXINL-PXP

EXINR-PXP

75-

EXINL-PXP

75-

75-

75-

1

2

AUDIO_GROUND

D4000

EZJZ0V120JA

CHANGE by

75-

EXINR-PXP

CN4000

1
2
3
4
5
6
7
8

ACES_8213_0800N_8P

TVGND

75-

C4008

1
2

1000pF_50v

AUDIO_GROUND

L4004

12

BLM11A221S_OPEN

C4000

12

0.1uF_16v_OPEN

C4001

1

0.1uF_16v_OPEN

TVGND

SPDIF_AB

HPS_AB
HP_OUTL_AB
HP_OUTR_AB

MICS_AB

MIC_L_AB

MIC_R_AB

LINE_S#_AB

LINE_L_AB

LINE_R_AB

KILL_SWCH#_AB

+V3A_AB

75-

G1
G2

AUDIO_GROUND

FIX41

FIX_MASK

KILL SWITCH

KILL_SWCH#_AB

SW4000
4
5
6

DIP_LSS22M_V_B

AUDIO_GROUND

13-Apr-2007TIGER

13-Apr-2007TIGER

2

75-

75­75­75-

75­75­75-

75­75­75-

75-

1
2

CS

3

FIX42

FIX_MASK

+V3A_AB

AUDIO_GROUND

AUDIO_GROUND

+V5S_AB

75-

CN4001

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

16

16

17

G

17

18

G

18

19

19

20

20

ACES_88442_2001_20P

AUDIO_GROUND

AGROUND_AUDIO

FIX43

FIX44

FIX_MASK

FIX_MASK

75-

1

R4011

100K_5%

2

C4009

1
2

0.1uF_16v

INVENTEC

INVENTEC

TITLE

TITLE

HONOLULU

HONOLULU

Audio Board

Audio Board

SIZE DOC. NUMBERCODECODE

SIZE

A3

A3

CS

CS

SHEETCHANGE by

SHEET

G1
G2

DOC. NUMBER

OF

OF

75 78

75 78

REVREV

A02Model_No

A02Model_No

HDD_LED#_DB

DCIN_BLED#_DB

BAT0_BLED#_DB

BAT0_OLED#_DB

FIX47

FIX_MASK

http://laptopblue.vnhttp://laptopblue.vn

+V5S_LB

76-

PWR_BUF_OLED#_DB

76-

D6002

EVL_21SUYC

21

D6001

LED_BLU_19_21_BHC_ZL1M2TY_3T

LED_GROUND

+V5S_LB

76-

5

1

2

3

LED_GROUND

MP

76-

R6006

12

0_5%

U6002

4

TSB_TC7SZ08F_SSOP_5P_OPEN

+V5A_LB

76-

U6000

5

C6000

0.1uF_10v

FIX49

FIX_MASK

12

21

1

2

LED_GROUND

+V5A_LB

1

2

LED_GROUND

FIX50

FIX_MASK

76-

76-

D6003

76-

EVL_21SUYC

FIX48

FIX_MASK

D6000

4

TSB_TC7SZ08F_SSOP_5P

LED_BLU_19_21_BHC_ZL1M2TY_3T

3

76-

U6001

5

4

TSB_TC7SZ08F_SSOP_5P

3

R6004

12

200_5%

21

D6004

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

+V3LA_LB

76-

S290

LED_GROUND

SCREW2.3_6_1P

+V3A_LB

76-

R6001

12

510_5%

12

150_5%

21

R6002

CS

WS

D6005

LED_BLU_19_21_BHC_ZL1M2TY_3T

R6000

12

510_5%

CS

R6003

12

510_5%

CS

BATTERY LED

CIR_OUT_LB

S291

SCREW2.3_6_1P

+V5S_LB

76-

21

+V5A_LB

76-

+V5S_LB

76-

1
2

POWER LED

1

R6005

510_5%

2

CS

LED_6IN1_DB

ODD_LED#_DB

+V5LA_LB

76-

1

R6017

100_5%

VISHAY_TSOP6238_4P

2

4

C6001

4.7uF_6.3v

3
2
1

LED_GROUND

R6012

12

R6014

100K_5%

76-

1

2

LED_GROUND

76-

0_5%

R6011

12

0_5%_OPEN

REC_LED_DB

LED_6IN1_DB

+V3LA_LB

5

RESERVE_LED#_DB

76-

TSB_TC7SZ08F_SSOP_5P

1
2

3

LED_GROUND

+V5S_LB

76-

1

R6015

+V5S_LB

10K_5%

2

Q6000

3

2

+V3S_LB

76-

1

2

1
2

1

2

LED_GROUND

R6018

27K_1%

C6002

330pF_50v

OUT
VS

76-

76-

+V5S_LB

R6013

10K_5%

L_CIR_RX1_LB

76-

1

LED_GROUND

2

1

R6016

10K_5%

2

1

G

2N7002W

76-

D

S

GND
GND

D6010

LED_GROUND

WS

http://hobi-elektronika.net

1
2

LED_GROUND

76-

U6005

D6008

4

76-

U6004

5

4

TSB_TC7SZ08F_SSOP_5P

3

C6003

1
2

0.1uF_10v

LED_GROUND

WS

U6003

5

4

TSB_TC7SZ08F_SSOP_5P3

+V3A_LB

R6009

12

EVL_21SUYC

21

150_5%

LED_BLU_19_21_BHC_ZL1M2TY_3T

WLON#_DB

BTIFON#_DB

76-

76-

TSB_TC7SZ08F_SSOP_5P

+V3S_LB

76-

U6007

OE

VCC

A

4

GND

Y

PHP_74LVC1G125GW_SC88A_5P

ES

16mcd_100D_25mA_SMD_2P

R6008

12

510_5%

CS

ES

76-

GREEN IS 6013A008770K

R6007

12

510_5%

+V3A_LB

5

1
2

3

LED_GROUND

+V5S_LB

76-

R6019

12

100_5%

15

2

3

4.7uF_25v

LED_GROUND

CHANGE by

CHANGE by SHEET

CHANGE by OF

D6007

21

LED_GROUND

+V3S_LB

+V3_LB

76-

DCIN_BLED#_DB

PWR_BUF_BLED#_DB

PWR_BUF_OLED#_DB

BAT0_BLED#_DB
BAT0_OLED#_DB

HDD_LED#_DB

ODD_LED#_DB

LED_6IN1_DB

WLON#_DB

BTIFON#_DB

REC_LED_DB

RESERVE_LED#_DB

+V5LA_LB

+V5S_LB

76-

2

D6006

1

CS

76-

U6006

MP

D6009

4

C6004

LED_GROUND

EVL_21SUYC

21

D6011

1

Vout

2

GND

3

Vcc

VISHAY_TSOP98200_3P

1
2

TIGER 13-Apr-2007

TIGER 13-Apr-200713-Apr-2007TIGER

+V3A_LB

76-

76-

CIR_OUT_LB

L_CIR_RX1_LB

13-Apr-2007TIGER

+V3LA_LB

76-

76­76­76­76­76­76­76­76­76­76-

R6010

200_5%

+V5S_LB

+V5A_LB

76-

76-

fpc_aces_28_050_r_200

76-

76-

ES

+V3A_LB

76-

12

INVENTEC

INVENTEC

INVENTEC

TITLE

TITLE

TITLE

HONOLULU

HONOLULU

HONOLULU

HONOLULU

LED & CIR Board

LED & CIR Board

LED & CIR Board

LED & CIR Board

CODE

SIZE DOC. NUMBER

CODE

CODE

SIZE

SIZE

A3

A3

A3

A3

CS

CS

CS

CS

SHEET

28

28

27

27

26

26

25

25

24

24

23

23

22

22

21

21

20

20

19

19

18

18

17

17

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

CN6003

MP

Model_No A02

Model_No A02

G

G2

G

G1

CS

DOC. NUMBER

DOC. NUMBER

OF

OFSHEET

76 78

76 78

LED_GROUND

7876

7876

REV

REV

REV

A02Model_No

A02Model_No

D7011

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

D7012

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

D7013

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

D7014

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

VL_GROUND

1

2

D7015

EZJZ0V120JA

1

2

D7016

EZJZ0V120JA

http://laptopblue.vnhttp://laptopblue.vn

R7000

12

150_5%

R7001

12

150_5%

R7002

12

150_5%

R7003

12

150_5%

1

D7010

EZJZ0V120JA

2

VL_GROUND

+VLED_VL

77-

MP

1

D7017

EZJZ0V120JA

2

R7004

12

150_5%

R7005

12

150_5%

R7006

12

150_5%

R7007

12

150_5%

1

D7018

EZJZ0V120JA

2

VL_GROUND

+VLED_VL

77-

D7000

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

D7001

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

D7002

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

D7003

21

LED_BLU_19_21_BHC_ZL1M2TY_3T

VL_GROUND

1

2

D7007

EZJZ0V120JA

1

D7008

EZJZ0V120JA

2

1

2

D7009

EZJZ0V120JA

VOL_A_VL
VOL_B_VL

EZJZ0V120JA

ES

MP

VOL_A_VL
VOL_B_VL

77-

77-

D7006

1

2

+VLED_VL

77-

ACES_88706_0801_8P

77-

77-

ES

SW7000

12

VL_GROUNDVL_GROUND

1

D7005

EZJZ0V120JA

2

3

ALPS_EC05E1220401_3P

CS

8
7
6
5
4
3
2
1

8
7
6
5
4
3
2
1

CN7000

G
G

G1G2

G2
G1

VL_GROUND

VL_GROUND

MP

VL_GROUND

S309

SCREW3.5_8_1P

ES

S289

SCREW3.5_8_1P

CS

WS

FIX54

FIX53

FIX_MASK

FIX_MASK

FIX55

FIX_MASK

FIX56

FIX_MASK

http://hobi-elektronika.net

CHANGE by

TIGER 13-Apr-200713-Apr-2007TIGER

INVENTEC

INVENTEC

TITLETITLE

HONOLULU

HONOLULU

VOL_VR Board

VOL_VR Board

SIZE

SIZE CODE

A3

A3

DOC. NUMBERDOC. NUMBER REV

CODE

Model_No A02

CS

CS

SHEET

SHEET OFCHANGE by

77 78

REV

A02Model_No

OF

7877

Honolulu 10 & 10G:

http://laptopblue.vnhttp://laptopblue.vn

HONOLULU Configuration

NB

Graphics

HDMI

CRT

LCM

S-VIDEO

+VGFX-CORE

SPDIF Out

HONOLULU 10 ( UMA )

Crestline-GM Crestline-PM
Crestline-GM

SIL1392

Crestline-GM
Crestline-GM

Crestline-GM

NEED

ALC888 (Single) ALC888S (Both)

HONOLULU 10G ( Discrete )

MXM
MXM
MXM

MXM
MXM

No NEED

TV Tuner, 3’rd mini card & 2’nd HDD Combination:

TV1

Sepia-A
Sepia-A

Sepia-D
Sepia-I

TV2

Not available

Sepia-A
Sepia-D

Not available

BCAS 3’rd mini card

Not support
Not support

Not support

support

Not available
Not available

Not available
Not available

2’nd HDD

Available

Not available
Not available

Available

BTO:

1. HDMI-out

2. Camera with internal microphone

3. Bluetooth

4. MDC/Modem

5. PC Card (type II) or ExpressCard/54

6. BCAS Card

Sepia-I
Sepia-IA

Not available
Not available
Not available

Not available

Sepia-I

Not available

Sepia-A
Sepia-D

Sepia-I

Sepia-IA

support
support

Not support
Not support

support
support

Not available
Not available

HD-DVD accelerator
HD-DVD accelerator
HD-DVD accelerator

HD-DVD accelerator

http://hobi-elektronika.net

Not available

Available

Not available
Not available
Not available

Not available

INVENTEC

TITLE

HONOLULU

CONFIGURATION

SIZE CODE DOC. NUMBER REV

A3

CHANGE by SHEET

TIGER 13-Apr-2007

CS

Model_No A02

OF

7878
