Toshiba C-DR0101 User Manual

Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference.

1CH DIGITAL VIDEO RECORDER

(

NTSC SYSTEM

)

C-DR0100 C-DR0101 C-DR0105

INSTRUCTION MANUAL

DIGITAL

VIDEO RECORDER

DISK FULL/ FAILURE

ALARM RESET

BUZZER STOP

SELECT

BLOCK

PLAY STOP

PLAY

PAUSE

REVERSE

PLAY

REC

TIMER

FRAME

OUTPUT

VIDEO AUDIO

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ............................................................................... 5

2. GENERAL DESCRIPTION ............................................................................. 6

3. FEATURES .......................................................................................................... 6

4. HANDLING PRECAUTIONS .......................................................................... 7

5. NOMENCLATURE AND FUNCTIONS

Front Panel ................................................................................................................ 8

Rear Panel .............................................................................................................. 10

6. SETTING ITEM CHART AND SETTING PROCEDURES

6.1. Basic Setting Procedures ................................................................................. 11

6.2. Setting Item Chart ............................................................................................ 12

7. INDIVIDUAL ITEM SETTINGS

7.1. Main Menu Screen ........................................................................................... 13

7.2. Playback Settings ............................................................................................ 13

7.3. Clock Settings .................................................................................................. 14

7.3.1. Summer Time (Daylight Saving Time) Settings ..................................... 15

7.4. Disk Settings .................................................................................................... 15

7.5. Recording Settings ........................................................................................... 16

7.5.1. General Recording Settings ................................................................... 17

7.5.2. Internal Timer Recording Settings ......................................................... 17

7.5.3. Alarm Recording Settings ...................................................................... 19

7.5.4. About the Alarm Input Mode .................................................................. 20

7.6. Screen Display Settings ................................................................................... 21

7.7. Key Lock .......................................................................................................... 22

7.7.1. Key Lock Release .................................................................................. 22

7.8. Communication Settings .................................................................................. 23

7.8.1. Network Settings .................................................................................... 23

7.9. Log Display ...................................................................................................... 24

7.9.1. General/Timer Recording Logs .............................................................. 24

7.9.2. Alarm Recording Logs ........................................................................... 24

7.9.3. Failure Logs ........................................................................................... 25

7.10. System Maintenance ..................................................................................... 25

7.10.1. Menu Default Settings .......................................................................... 25

7.10.2. Disk Formatting .................................................................................... 26

SETTING BASICS

SUMMARY

8. DIGITAL VIDEO RECORDER ACTIVATION AND TERMINATION

8.1. Recorder’s Activation ....................................................................................... 27

8.2. When the Failure Screen Is Displayed ............................................................. 28

8.3. Recorder’s Termination .................................................................................... 28

9. OPERATION AFTER POWER FAILURE RESTORATION

9.1. When the Power Fails during Recording ......................................................... 28

10. RECORDING

10.1. Type of Recording .......................................................................................... 29

10.1.1. Recording Priorities ............................................................................ 29

10.2. Screen Display During Recording .................................................................. 29

10.3. The Keys to Be Used in Recording ................................................................ 31

10.4. Performing General Recording ...................................................................... 31

10.5. Performing Internal Timer Recording ............................................................. 31

10.6. Performing Alarm Recording .......................................................................... 32

11. PLAYBACK

11.1. Type of Playback ........................................................................................... 33

11.2. Screen Display During Playback .................................................................... 33

11.3. The Keys to Be Used in Playback .................................................................. 34

11.4. Performing Playback ...................................................................................... 34

11.5. Performing Various Playback Functions

11.5.1. Reverse Playback .............................................................................. 34

11.5.2. Fast Forward Playback And Fast Reverse Playback ......................... 34

11.5.3. Playback Pause (Still Picture) ............................................................ 34

11.5.4. Forward Frame Playback And Reverse Frame Playback .................. 35

11.5.5. Forward Block Playback And Reverse Block Playback ..................... 35

11.6. About the Playback Start Position .................................................................. 36

12. SEARCH FUNCTIONS

12.1. The Keys to Be Used in Searching ................................................................ 37

12.2. Date/Time and Block Searches ..................................................................... 37

12.2.1. Basic Date/Time and Block Search Operations ................................. 37

12.2.2. Date/Time Search Operation ............................................................. 37

12.2.3. Block Search Operation ..................................................................... 38

12.3. Time Shift Search .......................................................................................... 39

13. CONNECTIONS

13.1. Preparations for Connections ........................................................................ 40

13.1.1. Control Input/Output Terminal Connections ....................................... 40

13.2. When Using the 24 V AC or 12 V DC or AC Mains Camera .......................... 40

13.3. Connection to The Monitor TV ....................................................................... 40

13.4. Combination With The Digital Video Recorder/Multi-switchers

(C-MS91D, C-MS161D) ................................................................................. 41

13.4.1. Basic System ..................................................................................... 41

13.4.2. Expansion System (Series Recording) .............................................. 41

CONNECTIONS

FUNCTIONS

OPERATION

14. CONNECTION EXAMPLES

14.1. Connection to the 24 V AC or 12 V DC or AC Mains Camera ....................... 42

14.2. Connection to the Multi-switcher

14.2.1. Basic System

(Combined Example with the C-MS91D, Multi-switcher) ................... 43

14.2.2. Expansion System

(Combined Example with the C-MS91D, Multi-switcher) ................... 44

15. RECORDING TIME TABLE

15.1. Recording Picture Quality Setting .................................................................. 45

15.2. When using the C-DR0100 ............................................................................ 45

15.3. When using the C-DR0101 ............................................................................ 45

15.4. When using the C-DR0105 ............................................................................ 46

16. EXTERNAL TERMINAL SPECIFICATIONS

16.1. RS-232C Communication Specifications ....................................................... 47

16.1.1. The Rules of Overall Communications .............................................. 47

16.1.2. Communication Protocol .................................................................... 47

16.1.3. RS-232C Connector Pin Assignment ................................................. 47

16.1.4. RS-232C Communication Format

(Controller to Digital Video Recorder) ................................................ 48

16.1.5. RS-232C Communication Command

(Controller to Digital Video Recorder) ................................................ 48

16.1.6. RS-232C Communication Format

(Digital Video Recorder to Controller) ................................................ 51

16.1.7. RS-232C Communication Command

(Digital Video Recorder to Controller) ................................................ 51

16.2. About the Ethernet Terminal .......................................................................... 53

17. RACK MOUNTING ........................................................................................... 54

18. IF YOU THINK THERE IS A FAILURE: (TROUBLESHOOTING) .... 55

19. SPECIFICATIONS ........................................................................................... 56

WHEN YOU NEED HELP

ADDITIONAL INFORMATION

Note

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Modifications

Any modifications made to this device that are not approved by TOA Corporation may void the authority granted to the user by the FCC to operate this equipment.

NTSC version complies with Part 15 of the FCC Rules.

1. SAFETY PRECAUTIONS

• Be sure to read this safety instructions in this section carefully in prior to use.

• Make sure to observe the instructions in this manual as the conventions of safety symbols and messages regarded as very important precautions are included.

• Keep this instructions handy for future reference.

Safety Symbol and Message Conventions

Safety messages described below are used to prevent bodily injury and property damage that could result from mishandling. Before operating your product, read this manual first and understand messages so you are thoroughly aware of the potential safety hazards.

When installing the Recorder

• This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

• Do not expose the unit to rain or an environment where it may be splashed by water or other liquids, as doing so may result in fire or electric shock.

• Use the unit only with the voltage specified on the unit. Using a voltage higher than specified one may result in fire or electric shock.

• Do not damage, modify nor put the power supply cord in close to heaters. Never place heavy objects on the power supply cord, as doing so may result in fire or electric shock.

• Do not install nor place the unit in unstable locations, such as on a rickety table or a slanted surface. Doing so may result in the unit falling down or dropping and causing personal injury.

When Using the Recorder

• Should the following irregularity be found during use, immediately switch off the main power, disconnect the power supply plug from the AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the unit in this condition as this may cause fire or electric shock.

• If you detect smoke or a strange smell coming form the unit

• If water or any metallic object gets into the unit

• If the unit falls or the unit case breaks

• If the power supply cord is damaged (exposure of the core, disconnection, etc.)

• When the Screen is not Displayed

• Do not open the unit case nor modify the unit. As doing so may result in fire or electric shock as there are high voltage components inside the unit. Refer any needed servicing to authorized TOA dealers.

• Do not put containers of liquid or metallic objects on top of the unit. If they accidentally spill into the unit, this may cause a fire or electric shock.

• Do not insert nor drop metallic objects or flammable materials from ventilation slots of the unit, as this may result in fire or electric shock.

• Do not touch power supply plug during thunder and lightning, as this may result in electric shock.

Indicates a potentially hazardous situation which could result in death or serious personal injury if ignored or mishandled.

WARNING

Indicates a potentially hazardous situation which could result in moderate or minor personal injury, and/or property damage if ignored or mishandled.

CAUTION

When installing the Recorder

• Do not plug in nor remove the power supply plug with wet hands, as doing so may cause electric shock.

• When unplugging the power supply cord, be sure to grasp the power supply plug; never pull the cord itself, as doing so may result in damage the cord, causing fire or electric shock.

• Moving the unit with the power supply cord connected to the wall outlet may cause damage to the power supply cord, resulting in fire or electric shock.

• Do not block the ventilation slots as this may cause inside of the unit filled with heat, as doing so may result in fire.

• Do not install the unit in humid or dusty locations, in locations exposed to the direct sunlight, near the heaters, nor in locations generating soot or steam as doing so may result in fire or electric shock.

3. FEATURES

High Picture Quality

Digital compression system ensures high-quality picture, audio recording, and playback.

Extended-Time Recording

Built-in 120 GB (C-DR0100), 240 GB (C-DR0101) and 500 GB (C-DR0105) large-capacity hard disks permit extended-time recording.

Can Be Used In Conjunction With Switchers

Can be connected to TOA’s switcher system and used in place of analog time-lapse VCRs. In systems that use a Multi-switcher (C-MS91D and C-MS161D), the Series Recording function that permits continuous recording with the connection of two Digital Video Recorders can be enabled, and the switcher’s motion detection function can be used as an alarm input to provide efficient surveillance by means of Alarm Recording.

Simultaneous Recording/Playback

Recorded images can be played back without interrupting recording.

Pre-Alarm Recording

Pre-Alarm function performs retroactive recording to a maximum of 5 minutes before alarm activation.

Search Function

Three search functions Date/Time Search, Block Search, and Time Shift Search permit desired scenes to be quickly found and viewed.

Mirroring Recording (C-DR0101, C-DR0105)

The C-DR0101 and C-DR0105 has two built-in hard disk drives. Mirroring refers to the simultaneous recording of data onto the two hard disks. Even if one of the disks fails, recording and playback can still be performed using the other disk. The possibility of data loss due to hard disk failure is greatly reduced, increasing reliability.

Networking Function

An RS-232C interface and a 100BASE-TX Ethernet port are standard.

Note: The RS-232C control software is not standard.

Indicates a potentially hazardous situation which could result in moderate or minor personal injury, and/or property damage if ignored or mishandled.

CAUTION

When Using the Recorder

• Do not place heavy objects on the unit. Such object may fall or the unit may tip over, possibly resulting in personal injury.

• Clean the unit periodically. Contact your TOA dealer regarding the cleaning. If dust is allowed to accumulate in the unit over a long period of time, a fire may result.

• Clean the power supply plug and wall AC outlet periodically. If dust accumulates on them, a fire may result. Insert the power supply plug into the AC outlet securely.

• Switch off the main power and unplug the power supply plug from the AC outlet for the safety purposes when cleaning or leaving the unit unused for long periods of time. Doing otherwise could cause fire or electric shock.

2. GENERAL DESCRIPTION

The TOA C-DR0100 (C-DR0101, C-DR0105) is a single-channel Digital Video Recorder with 1 channel of video input, and permits connected camera images to be recorded onto its large-capacity internal hard disks using a digital compression system. It can simultaneously play back recorded camera images while continuing to record images onto the hard disk. The Digital Video Recorder can also be easily connected to an existing switcher system, replacing previously installed analog time-lapse VCRs. Mounting in EIA-Standard equipment racks can also be easily performed with the addition of optional rack mounting brackets.

4. HANDLING PRECAUTIONS

• Use the Digital Video Recorder in locations with ambient temperature of between +5°C and +40°C, and humidity levels of less than 80% to ensure that no condensation is formed.

• When moving the Recorder, first switch off the main power and then wait at least 30 seconds before moving.

• Avoid moving the Recorder suddenly from a cold location to a warm location, or installing it in close proximity to an air-conditioner outlet, as internal condensation could result. When condensation occurs, do not switch on the power until the Recorder has sufficiently dried.

• Avoid installing the Recorder in humid or dusty locations, or in locations exposed to direct sunlight, sooty smoke or steam. Note that even in locations which are not particularly dusty, dust may accumulate at the Recorder’s ventilation slots. Because this could cause an extreme rise in temperature inside the Recorder, be sure to clean the ventilation slots periodically after switching off the main power and disconnecting the power supply cord from the AC outlet. It is highly recommended that the ventilation slots be cleaned once a year.

• The socket-outlet shall be installed near the equipment and the plug (disconnecting device) shall be easily accessible.

• To clean, be sure to first switch off the main power and then wipe with a dry cloth. If the Recorder is particularly dirty, use a cloth damped in a neutral detergent. Never use benzene, thinner or chemicallyimpregnated towels, which may damage the Recorder’s surface.

• Do not block the ventilation slots or cooling fan, which could cause the temperature inside the Recorder to rise, possibly resulting in unit failure. Install the Recorder at least 100 mm away from the nearest wall surface.

• Since the Recorder is equipped with a cooling fan, a motor sound is generated.

• Do not install the Recorder in locations influenced by strong electrical or magnetic fields, as monitor screen pictures may become distorted or the Recorder could fail.

• Avoid jarring or striking the Recorder. The Recorder is a piece of precision equipment and accidentally dropping it or subjecting it to strong impacts could cause its failure. When transporting the Recorder, carefully pack it in the supplied carton to protect it from shock.

• Do not use the Recorder in locations exposed to vibration to avoid failure. Avoid installing the Recorder vertically or tilting it at extreme angles, since it is designed to be used in a horizontal position only.

• About the hard disks Hard disks other than those specified by TOA cannot be used. Since the hard disks are pieces of precision equipment, take special care in handling not to accidentally drop, bump or jar them, lest they should fail. If a hard disk on which condensation is formed is used, it could fail. Therefore, when brought into a warm room from the cold outdoors, be sure to leave it unused for at least half a day before using it. If the hard disk fails, recorded data cannot be restored.

• TOA takes no responsibility for any incidental damage, such as loss of sales opportunities, that may result from the Digital Video Recorder’s failure.

• The standby function is used to enable transportation of the unit from one place to another when circumstances do not permit its main power supply to be turned off. While in standby mode, power continues to be supplied to the unit, but its hard disk and fan are stopped. If the unit is left in standby mode for long periods of time, heat can build-up inside the unit, potentially shortening its operating life. To avoid this, be sure to turn off the main power supply when the unit is not in use.

Underwriters Laboratories Inc. (UL) has not tested the performance or reliability of the security aspects of this product. UL has only tested for fire, shock or casualties as outlined in UL's Standard(s) for Safety. UL Certification does not cover the performance or reliability of the security hardware and security operating software. UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY RELATED FUNCTIONS OF THIS PRODUCT.

5. NOMENCLATURE AND FUNCTIONS

[Front Panel]

Standby Key [ ]

Pressing this switch while the main power is supplied initiates a system check (the switch flashes green) and activates the Digital Video Recorder (the switch lights green). Holding down this switch for 1 second or more places the Recorder in standby mode, indicated by the switch flashing every 5 seconds.

Note

Some time is required before the Recorder is placed in standby mode after the main power has been switched on. Ensure that the Recorder is in standby mode before operating the standby key.

Timer Key

This key lights green when pressed, indicating that the Recorder is in Internal Timer Recording standby mode, which permits Internal Timer Recording to be performed at preset times. To cancel Internal Timer Recording, hold down the Timer key for at least 1 second until its light extinguishes.

Recording [

] Key

This key lights red when pressed, indicating that camera recording is in progress. To stop the recording, hold down the Recording key for at least 1 second until its light extinguishes.

Reverse Playback [ ] Key

Plays back recorded images in the reverse direction. This key continuously lights green during reverse playback. The playback speed cycles through x1, x2, x4, and x8 with each depression of this key.

Frame Reverse [ ] Key

Pressing this key while the Recorder is in Playback Pause mode initiates a frame-by-frame reverse playback of the recorded image. Holding down this key performs a continuous frame-byframe playback in the reverse direction.

Pause [ ] Key

Temporary stops playback. This key continuously lights green while in Playback Pause mode. If pressed again, images are played back in the same direction as before. (Playback speed reverts to normal x1 speed.) When the Pause key flashes green, this indicates that the Recorder is in Time Shift Search mode.

Playback [ ] Key

Plays back recorded images in the forward direction, and continuously lights green during playback. The playback speed cycles through x1, x2, x4, and x8 with each depression of the Playback key.

Frame Advance [ ] Key

Pressing this key while the Recorder is in Playback Pause mode initiates a frame-by-frame playback of the recorded image. Holding down this key performs a continuous frame-by-frame playback in the forward direction.

Playback Stop [ ] Key

Stops playback operation.

Note

Current recording in progress does not stop even if this key is pressed.

[ + ] and [ – ] Set Keys

Used to change setting values on the menu or search screen.

Block Shift Key

Pressing the (+) key during playback shifts the recorded image block to the next block in the forward direction, while the (–) key shifts to the preceding block.

Up [ ] and Down [ ] Shift Keys

Used to move the cursor on the menu or search screen.

Select Key

Selects items or choices on the menu or search screen.

Menu Key

Hold down this key for 1 second or more to display the main menu screen on the monitor. Pressing this key during playback stops playback operation to display the main menu screen. The main menu screen can also be displayed even while recording is in progress, however some items cannot be set during recording. If this key is pressed during item selection, the displayed setting contents are set and confirmed, returning the display to the previous screen.

REC

OUTPUT

VIDEO AUDIO

TIMER

REVERSE

PLAY

FRAME

5 6

PLAY

PAUS E

STOP

FRAME

7 8

BUZZER

SELECT

BLOCK

11 12

STOP

ALARM RESET

1415

DISK FULL/ FAILURE

DIGITAL VIDEO RECORDER

12 3 4

Search Key

Displays the search screen on the monitor. Pressing this key during playback stops playback operation to display the search screen. If pressed while in Playback Pause mode, the Time Shift Search screen is displayed. To exit the search screen, press this key again.

Buzzer Stop Key

This key flashes red when an alarm is activated, and the Recorder’s built-in buzzer is sounded to provide both visual and audio alarm warnings. After Alarm Recording completion, the key changes to steady ON (red). Press this key to stop the buzzer. The buzzer can be disabled by selecting "OFF" for Buzzer in the Alarm Recording Settings. (Refer to p. 19.)

Alarm Reset Key

Hold down this key for 1 second or more to reset alarm operation and stop Alarm Recoding.

Disk Full/Failure Indicator Disk Full Indicator

When the Recording mode is set to "STOP" or "SERIES" in the Disk Setting, the indicator flashes whenever less than 1 hour of available hard disk time remains, and changes to steady ON if no available time remains.

Failure Indicator

This indicator lights red when the Recorder fails, and extinguishes when the cause of the failure is removed. This failure indication takes precedence over the Disk Full indication, should both be enabled at the same time. Possible Failure Causes: Hard disk failure, fan failure, and video loss.

Note

If the Recorder should indicate a failure, first check for the cause by switching the power OFF, then contact your TOA dealer if unable to solve the problem.

Video Output Terminal

Used for dubbing recorded video images. This terminal is the same as the Video Output Terminal located on the rear panel.

Audio Output Terminal

Used for dubbing recorded audio signals. This terminal is the same as the Audio Output Terminal located on the rear panel.

141312

AC Inlet

Connect the supplied power cord to this socket.

Main Power Switch

Power switch for the Digital Video Recorder.

Video Input Terminal

Receives video signals. Connect the Multiswitcher’s VCR output to this terminal when connecting the Multi-switcher.

Video Output Terminal

Sends out video signals. Connect this terminal to the Multi-switcher’s VCR input when connecting the Multi-switcher. If the Multi-switcher is not used, connect this terminal to the monitor to transmit video signals to the monitor.

Switcher Video Input Terminal

Connect the Multi-Switcher’s monitor output to this terminal. This terminal is not used if the Multiswitcher is not connected.

Switcher Video Output Terminal

In the system in which the Multi-switcher is connected, connect this terminal to the monitor to transmit video signals to the monitor. Do not use this terminal if the Multi-switcher is not connected.

Audio Input Terminal

Receives audio signals from the drive unit, etc.

Audio Output Terminal

Sends out audio signals to the monitor, etc.

Control Input/Output Terminal Alarm Reset Output Terminal

Shorts to the ground terminal when the Recorder’s alarm is reset.

Alarm Input Terminal

Activates an alarm by way of external sensors. Alarm Input mode can be changed by the Recording Setting’s Alarm Recording Setting.

Ground Terminal

Switcher Control Output Terminal

Connect this terminal to the Multi-switcher’s switcher control input terminal.

100BASE-TX Terminal

RJ-45 terminal for Ethernet.

Control Input/Output Terminal Alarm Reset Input Terminal

Used to permit external equipment to reset the Recorder’s alarm operation. This terminal provides the same operation as the front panelmounted Alarm Reset key.

Recording Start Input Terminal

Used to permit external equipment to initiate recording. When the Disk Setting’s Disk Mode is set to "SERIES," even if the Recorder’s disk is full, the Disk Full status is reset and recording is started.

Recording Stop Input Terminal

Used to stop recording at external equipment. This terminal provides the same operation as the front panel-mounted Recording key.

Time Sync Input/Output Terminals

Synchronize multiple Digital Video Recorders with that of a specified recorder (master unit) when two or more recorders are used. Connect the master unit’s output to the slave unit’s input.

Alarm Output Terminal

Shorts to the ground terminal when an alarm is activated.

System Failure Output Terminal

Shorts to the ground terminal when the hard disk or fan failure or Video Loss occurs.

Disk Full Output Terminal

Shorts to the ground terminal when no available hard disk time remains.

RS-232C Terminal

Connect this terminal to a computer’s RS-232C terminal when controlling the Recorder at the computer. Connect this terminal to the Multiswitcher’s RS-232C terminal to synchronize the Recorder with the Multi-switcher. (This terminal can be connected to any of the C-MS91D, CMS161D Multi-switchers.)

*Ratings and serial numbers are indicated on the

bottom surface.

252423

201918

[Rear Panel]

VIDEO SW VIDEO

OUT

AUDIO

OUT

AC MAINS

MAIN POWER

OFF

ALARM RESET OUT

ALARM IN SW CTRL OUT

OUT

GND GND

100BASE–TX

TIME SYNC IN

REC STOP IN

REC START IN

ALARM RESET IN

25 26

TIME SYNC OUT

ALARM OUT

FAILURE OUT

DISK FULL OUT

RS–232C

ALARM REC SETTING

ALARM SETTING

[ VALID] ALARM IN MODE [ EDGE] PRE–ALARM [20SEC] ALARM PERIOD [10SEC] POST–ALARM [10SEC] PICTURE [LEVEL3] AUDIO [ ON] REC INTERVAL [1/30SEC] BUZZER [ ON] ALARM OUT [DURING REC]

MAIN MENU

•

PLAY SETTING CLOCK SETTING DISK SETTING REC SETTING ON–SCREEN DISP SETTING KEY LOCK COMMUNICATION SETTING LOG DISPLAY SYSTEM MAINTENANCE

MAIN MENU

PLAY SETTING CLOCK SETTING

DISK SETTING

•

REC SETTING ON–SCREEN DISP SETTING KEY LOCK COMMUNICATION SETTING LOG DISPLAY SYSTEM MAINTENANCE

REC SETTING

•

GENERAL REC SETTING TIMER REC SETTING ALARM REC SETTING

REC SETTING

GENERAL REC SETTING TIMER REC SETTING

•

ALARM REC SETTING

REC SETTING

•

GENERAL REC SETTING

TIMER REC SETTING ALARM REC SETTING

MAIN MENU

•

PLAY SETTING CLOCK SETTING

DISK SETTING REC SETTING ON–SCREEN DISP SETTING KEY LOCK COMMUNICATION SETTING LOG DISPLAY SYSTEM MAINTENANCE

2. Enter the setting screen.

3. Select the setting value.

4. Confirm the selected setting value and return to the camera display screen.

Camera Display Screen Main Menu Screen

Setting screen

Camera Display Screen

ALARM REC SETTING

ALARM SETTING

[ VALID] ALARM IN MODE [ EDGE] PRE–ALARM [20SEC] ALARM PERIOD [10SEC] POST–ALARM [10SEC] PICTURE [LEVEL1] AUDIO [ ON] REC INTERVAL [1/30SEC] BUZZER [ ON] ALARM OUT [DURING REC]

Press key for 1

second or more

key

SELECT

key

THU JAN/01/04 00:00:00

THU JAN/ 01/ 04 00:00:00

key

ALARM REC SETTING

ALARM SETTING

[ VALID] ALARM IN MODE [ EDGE] PRE–ALARM [20SEC] ALARM PERIOD [10SEC] POST–ALARM [10SEC] PICTURE [LEVEL3] AUDIO [ ON] REC INTERVAL [1/30SEC] BUZZER [ ON] ALARM OUT [DURING REC]

6. SETTING ITEM CHART AND SETTING PROCEDURES

6.1. Basic Setting Procedures

• The shaded item in the figure refers to the cursor position.

1. Enter the main menu screen.

SELECT

key

6.2. Setting Item Chart

* This setting item is applicable to the C-DR0101 and C-DR0105 Recorder, and not displayed on the screen

when the C-DR0100 Recorder is used.

Main Menu Item Menu Item Setting Item

Main Menu

Playback Settings (p. 13)

Clock Settings (p. 14)

Disk Settings (p. 15)

Recording Settings (p. 16)

Screen Display Settings (p. 21)

Key Lock (p. 22)

Communication Settings (p. 23)

Log Display (p. 24)

System Maintenance (p. 25)

General Recording Settings (p. 17)

Internal Timer Recording Settings (p. 17)

Timer Setting List

Timer Setting 01–10

Alarm Recording Settings (p. 19)

General/Timer Recording Log

Alarm Recording Log

Failure Log

Menu Default Settings

Disk Formatting

Playback Mode

Simultaneous Recording/Playback

Year/Month/Day

Time Synchronization

Synchronization Time

Summer Time

Disk Mode

Recording Mode

Picture Quality

Audio

Recording Intervals

Switcher Control Period

Recoding Start Date

Preset Time

Picture Quality

Audio

Recording Intervals

Recording Pattern

Motion Detection Pattern

Alarm Settings

Alarm Input Mode

Pre-Alarm Recording Periods

Alarm Recording Periods

Post-Alarm Recording Periods

Picture Quality

Audio

Recording Intervals

Buzzer Sound

Alarm Output Time

Picture Quality Indication

Audio ON/OFF Indication

Recording Mode Indication

Recording Indication

Playback Indication

Remaining Time Indication

Date Indication

Time Indication

Date/Time Display Position

Disk Mode Indication

RS232C Baud Rate

RS232C Flow Control

Network Settings

IP Address

Subnet Mask

Default Gateway

Switcher Synchronization

Disk Selection

Setting Value

ContentsSetting Item

7.2. Playback Settings

Playback mode settings are only available to the C-DR0101 and C-DR0105, and not displayed when the CDR0100 is used.

PLAY MODE : Sets the hard disk to be used for playback and search functions. SIMUL REC/PLAY : Selects "ALLOW" or "DISALLOW" for simultaneous recording and playback operations.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (

–) or (+) key.

• Confirm the setting with the Menu key, and return to the previous screen.

• Each setting item and its setting value and contents are as shown in the table below.

PLAY MODE

(Playback Mode)

(C-DR0101, DR0105)

SIMUL REC/PLAY

(Playback during

Recording)

ALL : All set hard disks are used for playback.

HDD-A : Hard disk drive A is used for playback.

HDD-B : Hard disk drive B is used for playback.

ALLOW : Allows playback while recording.

DISALLOW : Disallows playback while recording.

ALL / HDD-A / HDD-B

ALLOW / DISALLOW

PLAY SETTING

PLAY MODE [ ALL] SIMUL REC/ PLAY

[ ALLOW]

* The underlined contents are factory-preset values.

• Select the desired item from 9 main menu items on the main menu screen.

• Move the cursor with the ( ) or ( ) key, and display each setting screen with the Select key.

MAIN MENU

•

PLAY SETTING

CLOCK SETTING

DISK SETTING REC SETTING ON–SCREEN DISP SETTING KEY LOCK COMMUNICATION SETTING LOG DISPLAY SYSTEM MAINTENANCE

Refer to P.13 Refer to P.14 Refer to P.15 Refer to P.16 Refer to P.21 Refer to P.22 Refer to P.23 Refer to P.24 Refer to P.25

Note

Be sure to first perform Clock Settings (Refer to p. 14) before performing each setting.

7. INDIVIDUAL ITEM SETTINGS

7.1. Main Menu Screen

Hold down the Menu key for 1 second or more on the screen displaying the camera to display the Main Menu screen.

CLOCK SETTING

THU JAN / 01 / 04 00:00:00 TIME SETTING : SELECT KEY

TIME SYNC [ SLAVE] SYNC TIME [00H] SUMMER TIME SETTING

THU JAN / 01 / 04 00:00:00

7.3. Clock Settings

Set the date and time. Perform this setting when the Recorder is used for the first time or when the date and time indication has been deleted because the power was switched off for a long period of time.

Note

• Previously logged data times are not updated even if the Clock Settings are changed during use.

• The data times will be lost if the power was switched off for 30 days or more. Set the date and time again. Memory backup: 720 hours (fully charged)

TIME SYNC : Synchronizes the times of other Recorders (slave units) with that of a specified Recorder

(master unit) when multiple Recorders are used.

SYNC TIME : Sets the synchronization time.

Note

The Time Sync function cannot be operated during recording.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (

–) or (+) key.

• After completing the settings of time (hour, minute, second), confirm the time with the Select key.

• The indication "Clock Setting Completed" is displayed on the screen after setting completion.

• Current time is displayed in the lowest part of the screen.

• Confirm the setting with the Menu key, and return to the previous screen.

• Each setting item and its setting value and contents are as shown in the table below.

Setting Value

Contents

Setting Item

TIME SYNC

(Time

Synchronization)

SYNC TIME (Synch-

ronization Time)

MASTER: Designates the master unit.

SLAVE: Designates the slave unit.

Select and set the synchronization time.

MASTER / SLAVE

00H

/ 01H / 02H / 03H / 04H /

...

up to 23H

* The underlined contents are factory-preset values.

Note

Setting the Time Sync settings to "SLAVE," and the Disk Setting’s Disk Mode to "SERIES" places the Recorder in Disk Full mode, causing the Disk Full indicator to light. Perform this setting when using Series Recording. Refer to p. 41; Expansion System (Series Recording).

Setting Value

Contents

Setting Item

7.4. Disk Settings

Disk Mode Settings are only available to the C-DR0101, and not displayed when the C-DR0100 is used.

DISK MODE : Sets the hard disk recording method. REC MODE : Selects "RE-REC","STOP," or "SERIES" for hard disks.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (

–) or (+) key.

• Confirm the setting with the Menu key, and return to the previous screen.

• Each setting item and its setting value and contents are as shown in the table below.

DISK MODE

(C-DR0101, C-DR0105)

NORMAL : Records continuously on each hard disk.

MIRRORING: Recording is performed simultaneously on the 2 hard disks.

NORMAL

MIRRORING

DISK SETTING

DISK MODE [ NORMAL] REC MODE [ STOP]

PLAY CHANGED TO " ALL "

7.3.1. Summer Time (Daylight Saving Time) Setting

Summer Time Setting screen is displayed if Summer Time Setting is selected on the Clock Setting screen.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (–) or (+) key.

• Confirm the setting with the Menu key, and return to the previous screen.

• Each setting item and its setting value and contents are as shown in the table below.

Setting Value

Contents

Setting Item

SUMMER TIME

SETTING

SUMMER TIME

FIRST DAY

SUMMER TIME

LAST DAY

ON : Displays the current date and time by automatically shifting the time

from standard local time to summer time and from summer to

standard time.

OFF : Displays the current date and time having nothing to do with the

summer time.

Sets the time to shift to the summer time.

Select the "Month" and "Which Sunday" and "What time"

Sets the time to shift back to the standard local time.

Select the "Month" and "Which Sunday" and "What time"

ON / OFF

Month :

JAN / FEB / MAR / APR / MAY /

JUN / JUL / AUG / SEP / OCT /

NOV / DEC

Which Sunday :

FIRST / SECOND / THIRD /

FOURTH / LAST

What time :

00H / 01H / 02H / 03H / 04H /

...

up to 23H

Month :

JAN / FEB / MAR / APR / MAY /

JUN / JUL / AUG / SEP / OCT /

NOV / DEC

Which Sunday :

FIRST / SECOND / THIRD /

FOURTH / LAST

What time :

00H / 01H / 02H / 03H / 04H /

...

up to 23H

*The underlined contents are factory-preset values.

Example

(1) If the FIRST DAY time is set to "02H", then at 2:00 AM on the first day of summer time the clock will be

advanced one hour to 3:00 AM.

(2) If the LAST DAY time is set to "02H", then at 2:00 AM on the first day of summer time the clock will be

setback one hour to 1:00 AM.

Note

• Avoid mixing both Normal Recordings and Mirroring Recordings on the hard disk. If mixed, block advance during playback or search operations cannot be correctly performed during playback. Be sure to re-format the disk when changing the Disk Mode Setting. Note that all recording data are deleted when formatted. (Refer to p. 26; "Disk Formatting.")

• Setting the Clock Setting’s Time Sync to "SLAVE" and the Recording Mode to "SERIES" places the Recorder in Disk Full mode and causes the Disk Full indicator to light. Perform this setting when using the Series Recording function. (Refer to p. 41; "Expansion System (Series Recording).")

• When the Recording mode is set to "SERIES," timer program cannot be perfomed.

• If the Disk Mode is changed, the Playback Mode changes as follows and the screen indicates that the Playback Mode has changed. (C-DR0101, C-DR0105)

DISK MODE

NORMAL

MIRRORING

PLAY MODE

ALL

HDD-A

The disk to be used is set to HDD-B if "HDD-B" is selected in the Playback Mode settings. To set to the "HDD-A" disk again, set the Disk mode to "MIRRORING."

• About Mirroring Recording. (C-DR0101, C-DR0105) Setting the Disk Mode to "MIRRORING" permits the same recording to be performed simultaneously on the two built-in hard disks. Should one of the two disks fail, the other disk will continue recording or playing back to ensure automatic backup. Be sure to first format both disks before performing Mirroring Recording to make their available recording times equal. When a difference in available recording time between the two disk drives exists, recording can continue if one of the two disks becomes full, provided recording time remains available on the other disk. However, this will no longer be Mirroring Recording. The maximum available Mirroring Recording time can be checked by setting the remaining time display to "MIN."

7.5. Recording Settings

Set individual recording conditions for General Recording, Internal Timer Recording, and Alarm Recording.

• Move the cursor with the ( ) or ( ) key, and display the selected setting screen with the Select key.

• Confirm the selected setting with the Menu key, and return to the previous screen.

REC SETTING

•

GENERAL REC SETTING TIMER REC SETTING ALARM REC SETTING

Setting Value

Contents

Setting Item

REC MODE

(Recording Mode)

RE-REC: Automatically deletes old recordings in chronological order to

overwrite the hard disk.

STOP: Performs no further recording to save previously recorded data

if no available hard disk time remains.

The Disk Full indicator flashes red whenever less than 1 hour of

available hard disk time remains, and changes to steady ON

(Indecator lights red) if no available time remains.

Selecting "RE-REC" in the menu resets the Disk Full mode and

causes the Disk Full indicator to extinguish.

SERIES: The Recorder stops and sends out a signal from its rear panel-

mounted Disk Full Output terminal if no available hard disk time

remains. If the Recorder receives a signal at its Recording Start

input terminal when it is in Disk Full mode, the Disk Full mode is

reset, causing the Disk Full indicator to extinguish.

RE-REC / STOP

/ SERIES

* The underlined contents are factory-preset values.

• Move the cursor with the ( ) or ( ) key, and press the Select Key. The Timer Schedule Screen is displayed.

• Confirm the setting with the Menu key, and return to the previous screen.

7.5.2. Internal Timer Recording Settings

If Internal Timer Recording Settings is selected, the Timer Setting List screen is displayed. Up to 10 timer programs can be set individually. Move the cursor to the desired program and press the Select key. The Timer Schedule screen is then displayed.

* The underlined contents are factory-preset values.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (–) or (+) key.

• Confirm the setting with the Menu key, and return to the previous screen.

• Each setting item and its setting value and contents are as shown in the table below.

7.5.1. General Recording Settings

Set the recording conditions for General Recording.

GENERAL REC SETTING

PICTURE QUALITY [LEVEL3] AUDIO [ ON] REC INTERVAL [1/30SEC] SW CTRL PERIOD [01]

Setting Value

Contents

Setting Item

PICTURE QUALITY

AUDIO

REC INTERVAL

(Recording Intervals)

SW CTRL PERIOD

(Used for switching

cameras by means

of the sequential

switcher, etc.)

LEVEL1 : Angle of view 720 x 240 file size : 64KB (High Picture Quality )

LEVEL2 : Angle of view 720 x 240 file size : 40KB

LEVEL3 : Angle of view 720 x 240 file size : 32KB

LEVEL4 : Angle of view 720 x 240 file size : 24KB

LEVEL5 : Angle of view 720 x 240 file size : 16KB

(Standard Picture Quality)

ON: Records audio sound simultaneously during recording.

OFF: Records no audio sound during recording.

Sets recording intervals.

Setting the Disk Setting’s Disk Mode to "MIRRORING" limits the

maximum recording interval to 1/30 second. Even if set to "1/60 SEC," the

actual recording interval is 1/30 second, and the "1/30 SEC" indication is

displayed on the screen. (C-DR0101, C-DR0105)

Set the camera switching signal period.

The camera switching signal is provided from the Switcher Control Output

at time intervals of recording interval x switching period to switch

cameras. This setting is common to all Recording Modes of General

Recording, Internal Timer Recording, and Alarm Recording.

LEVEL1 / LEVEL2 / LEVEL3

LEVEL4 / LEVEL5

/ OFF

1/60SEC / 1/30SEC / 1/15SEC /

1/10SEC / 1/5SEC / 1/3SEC /

1/2SEC / 1SEC / 2SEC / 3SEC /

5SEC /10SEC / 20SEC / 30SEC /

60SEC

01 / 02 / 03 / 04 / 05 / 10 / 15 / 20/

30 / 60

TIMER SETTING LIST

START – END

•

JAN / 01 / 04 00 : 00 ~ 10 : 00 SM – W – F – 12 : 34 ~ 23 : 45 ––– / –– / –– –– : –– ~ –– : –– ––– / –– / –– –– : –– ~ –– : –– ––– / –– / –– –– : –– ~ –– : –– ––– / –– / –– –– : –– ~ –– : –– ––– / –– / –– –– : –– ~ –– : –– ––– / –– / –– –– : –– ~ –– : –– ––– / –– / –– –– : –– ~ –– : –– ––– / –– / –– –– : –– ~ –– : ––

* The underlined contents are factory-preset values.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (–) or (+) key.

• Confirm the setting with the Menu key, and return to the previous screen.

• Each setting item and its setting value and contents are as shown in the table below.

Setting Value

Contents

Setting Item

DATE

(Recording Start

Date)

TIME

(Preset Times)

PICTURE QUALITY

AUDIO

REC INTERVAL

(Recording Intervals)

REC PATTERN

(Recording Pattern)

MOTION DETECT

PTN (Motion

Detection Pattern)

DAILY : Designates the Internal Timer Recording date. Timer

schedules can be set for any time between the current time to

one year ahead. The day of the week is automatically

displayed. Programs are automatically deleted after their

preset times are reached.

WEEKLY: Designates two or more days of the week. If all days from

Sunday to Saturday are designated, recording is performed

every day.

CANCEL : Cancels preprogrammed settings.

Designates the timer operating period in minutes. If the same timer preset

time is duplicated, the "TIME SETTING ERROR" indication is displayed

on the screen to the right side of the program number, invalidating the

date setting. In such cases, correctly reset the time. Note that the timer

operating period cannot be set unless the complete time (hour and

minute) is entered.

LEVEL1 : Angle of view 720 x 240 file size : 64KB (High Picture Quality)

LEVEL2 : Angle of view 720 x 240 file size : 40KB

LEVEL3 : Angle of view 720 x 240 file size : 32KB

LEVEL4 : Angle of view 720 x 240 file size : 24KB

LEVEL5 : Angle of view 720 x 240 file size : 16KB

(Standard Picture Quality)

ON: Records audio sound simultaneously during recording.

OFF: Records no audio sound during recording.

Designates the Recording intervals.

Setting the Disk Setting’s Disk Mode to "MIRRORING" limits the

maximum recording interval to 1/30 second. Even if set to "1/60 SEC," the

actual recording interval is 1/30 second, and the "1/30 SEC" indication is

displayed on the screen (C-DR0101, C-DR0105)

Transmits a Pattern Selection command from the RS-232C connector

when the preset timer operating time is reached.

Transmits a Pattern Selection command from the RS-232C connector

when the preset timer operating time is reached.

DAILY

/ WEEKLY / CANCEL

LEVEL1 / LEVEL2 / LEVEL3

LEVEL4 / LEVEL5

/ OFF

1/60SEC / 1/30SEC

/ 1/15SEC /

1/10SEC / 1/5SEC / 1/3SEC /

1/2SEC / 1SEC / 2SEC / 3SEC /

5SEC /10SEC / 20SEC / 30SEC /

60SEC

/ 2

1 / 2

TIMER SETTING 01

DATE

[DAILY] THU JAN / 01 / 04 TIME 00 : 00 – 10 : 00 PICTURE QUALITY [LEVEL3] AUDIO [ON] REC INTERVAL [1/30SEC] REC PATTERN [1] MOTION DETECT PTN [1]

Timer Schedule Screen Settings

Note

Pattern 1 command of both the Recording Pattern and Motion Detection Pattern is transmitted from the RS232C connector at times other than timer set times such as power-on, after Internal Timer Recording completion, and during General Recording. Recording Pattern and Motion Detection Pattern are functions available to the Multi-switcher (C-MS91D, CMS161D). For more information on these functions, refer to the instruction manual for the Multi-switcher.

Program No

ALARM REC SETTING

ALARM SETTING [ VALID] ALARM IN MODE [LEVEL]

PRE–ALARM [00SEC]

ALARM PERIOD [ 1MIN] POST–ALARM [00SEC] PICTURE QUALITY [LEVEL3] AUDIO [ ON] REC INTERVAL [1/30SEC] BUZZER [ ON] ALARM OUT [DURING REC]

Setting Value

Contents

Setting Item

ALARM SETTING

ALARM IN MODE

(Alarm Input Mode)

PRE-ALARM

ALARM PERIOD

POST-ALARM

PICTURE QUALITY

AUDIO

REC INTERVAL

(Recording Interval)

BUZZER

ALARM OUT (Alarm

Output Periods )

VALID : Validates alarm settings. (Alarm standby mode)

VAL REC : Validates alarm settings only during recording.

INVALID : Invalidates alarm settings. (Rejects alarm inputs.)

EDGE : Performs recording during preset Pre-alarm and Alarm

Recording periods

LEVEL : Performs recording during preset Pre-alarm Recording, Alarm

input, and Post-alarm Recording periods.

Performs retroactive recording to a preset time period before alarm

activation.

Performs recording during a preset alarm input period following alarm

activation when the Alarm Input Mode is set to EDGE. (Refer to p. 20;

"About the Alarm Input Mode")

Performs recording during a preset Post-alarm recording period following

the end of alarm activation when the alarm input mode is set to "LEVEL."

LEVEL1 : Angle of view 720 x 240; file size : 64KB (High Picture Quality)

LEVEL2 : Angle of view 720 x 240; file size : 40KB

LEVEL3 : Angle of view 720 x 240; file size : 32KB

LEVEL4 : Angle of view 720 x 240; file size : 24KB

LEVEL5 : Angle of view 720 x 240; file size : 16KB

(Standard Picture Quality)

ON: Records audio sound simultaneously during recording.

OFF: Records no audio sound during recording.

Sets the Recording intervals.

Setting the Disk Mode of Disk Settings to "MIRRORING" limits the

maximum recording interval to 1/30 second. Even if set to "1/60 SEC", the

actual recording interval is 1/30 second, and the "1/30 SEC "indication is

displayed on the screen (C-DR0101, C-DR0105)

ON: Sounds a buzzer when an alarm is activated. Pressing the Buzzer

Reset key stops buzzer operation.

OFF: Sounds no buzzer during alarm activation.

The Alarm Output terminal shorts to ground during a set period of time

following alarm activation.

VALID

/ VAL REC / INVALID

EDGE / LEVEL

00SEC

/ 10SEC/ 15SEC/ 20SEC /

30SEC/ 1MIN/ 2MIN/ 5MIN

10SEC/ 15SEC/ 20SEC/ 30SEC/

1MIN/ 2MIN/ 3MIN/ 4MIN/ 5MIN/

10MIN

00SEC

/ 10SEC/ 15SEC/ 20SEC/

30SEC/ 1MIN/ 2MIN/ 5MIN

LEVEL1 / LEVEL2 / LEVEL3 /

LEVEL4 / LEVEL5

ON / OFF

1/60SEC / 1/30SEC / 1/15SEC /

1/10SEC / 1/5SEC / 1/3SEC /

1/2SEC / 1SEC /

/ OFF

DURING REC / 1SEC

• Move the cursor with the ( ) or ( ) key, and change setting values

with the (–) or (+) key.

• Confirm the setting with the Menu key, and return to the previous screen.

• Each setting item and its setting value and contents are as shown in the table below.

7.5.3. Alarm Recording Settings

Alarm Recording has two Alarm Input modes "EDGE" and "LEVEL" and valid setting items differ depending on each mode.

Alarm Mode set to "EDGE" : Alarm recording time settings are valid.

Post-alarm time settings are invalid.

Alarm Mode set to "LEVEL" : Alarm recording time settings are invalid.

Post-alarm time settings are valid.

(For more information, Refer to p. 20; "About the Alarm Input Mode.")

* The underlined contents are factory-preset values.

7.5.4. About the Alarm Input Mode

The Alarm Input mode for Alarm Recording can be set to "EDGE" or "LEVEL." Each input mode operates as follows:

[Recording period when input mode is set to "EDGE"]

Performs continuous recording during Pre-alarm Recording and Alarm Recording Periods.

[Recording period when input mode is set to "LEVEL"]

Provides continuous recording during periods of time of Pre-alarm Recording, alarm activation, and Postalarm Recording.

Note

Pre-alarm recording is operated by the Alarm Recording Setting. It does not operate even if an alarm is activated during General Recording or Internal Timer Recording since they are operated by their own settings.

Alarm Input

Recording Status

Pre-alarm Period

Recording

Alarm Recording Period

Alarm Output

1 Sec

When an alarm output duration is set to 1 second:

Alarm Input

Recording Status

Pre-alarm Period

Recording

Recording Period Post-alarm Period

Alarm Output

When an alarm output is provided durin

alarm recording:

7.6. Screen Display Settings

The Disk Mode Display item is displayed when the C-DR0101 and C-DR0105 is used. Set whether to display or hide on-screen characters during playback or recording.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (

–) or (+) key.

• Confirm the setting with the Menu key, and return to the previous screen.

• Each setting item and its setting value and contents are as shown in the table below.

ON–SCREEN DISP SETTING

PICTURE QUALITY [DISP] AUDIO [DISP]

REC MODE [DISP]

RECORDING [DISP] PLAYING [DISP] REMAINING TIME [ DISP] DATE [DISP] TIME [DISP] TIME DISP POS [UPPER L] DISK MODE [DISP]

Setting Value

ContentsSetting Item

PICTURE QUALITY

AUDIO

REC MODE

(Recording Mode)

RECORDING

(Recording Display)

PLAYING (Playing

back Display)

REMAINING TIME

(Remaining Time

Display)

DATE

(Date Display)

TIME

(Time Display)

TIME DISP POS

(Date/Time Display

Position)

DISK MODE

(Disk Mode Display)

Displays or hides the picture quality indicator during recording or

playback.

Displays or hides the audio indicator when Audio is set to ON during

recording.

Displays or hides the overwrite recording setting status indicator during

recording.

Displays or hides the recording mode status indicator during recording.

Displays or hides the playback speed, playback direction, and pause

status during playback.

Displays or hides Digital Video Recorder's remaining time. The remaining

hard disk time is calculated from the currently recorded picture quality and

recording interval when the Disk Settings Recording Mode is set to

"STOP" or "SERIES."

Displays or hides Digital Video Recorder's remaining time. The remaining

hard disk time designated is calculated from the currently recorded picture

quality and recording interval when the Disk Settings Recording Mode is

set to "STOP" or "SERIES." (C-DR0101, C-DR0105)

Displays or hides the current date during recording, and the recorded date

during playback.

Displays or hides the current time during recording, and the recorded time

during playback.

Sets the date/time display position. Other display positions also change

depending on the date/time display position.

Displays or hides the disk connection status indicator. (C-DR0101, C-

DR0105)

DISP

/ HIDE

DISP / HIDE

Disk Mode set to "NORMAL":

DISP / HIDE

Disk Mode set to "MIRRORING":

MAX / MIN / HDD-A /

HDD-B / HIDE

DISP / HIDE

UPPER L/ UPPER C/ UPPER R/

LOWER L/ LOWER C/ LOWER R

DISP / HIDE

* The underlined contents are factory-preset values.

• Pressing the Menu key returns the display to the normal operation screen if the password is entered correctly. If the wrong password is entered, the display returns to the Main Menu screen. In such cases, perform the settings again.

• Entering the password correctly displays the following screen and validates key locking.

KEY LOCK

KEY LOCK VALIDATED.

• The following screen is displayed if the wrong password is entered.

KEY LOCK

INVALID PASSWORD

7.7.1 Key Lock Release

• Hold down the Menu key for at least 1 second on the normal operation screen.

• The Key Lock Release screen is displayed.

KEY LOCK RELEASE

ENTER A PASSWORD.

[

]

• Entering the password correctly returns the display to the Main Menu screen.

• If the wrong password is entered, the "INVALID PASSWORD" indication is displayed as in the case of the Key Lock setting. Since the display returns to the normal screen if the Menu key is pressed, perform release operation.

MAIN MENU

•

PLAY SETTING

CLOCK SETTING

DISK SETTING REC SETTING ON–SCREEN DISP SETTING KEY LOCK COMMUNICATION SETTING LOG DISPLAY SYSTEM MAINTENANCE

7.7. Key Lock

This function validates key locking. If validated, any key other than the Menu key is not accepted. Pressing keys other than the Menu key sounds a warning tone.

KEY LOCK

ENTER A PASSWORD.

[

]

• The password input screen is displayed if Key Lock is selected on the main menu screen. Press the (–), (+), ( ), and ( ) keys (in that order) as a password. The " " indication is displayed on the screen to confirm each key entry as the keys are pressed.

Note

The password and the key entry order cannot be changed.

NETWORK SETTING

IP ADDRESS

192. 168. 000. 001

SUBNET MASK

255. 255. 255. 000

DEFAULT GATEWAY

000. 000. 000. 000

COMMUNICATION SETTING

RS232C BAUD RATE [38400] RS232C FLOW CTRL [OFF]

NETWORK SETTING

SWITCHER SYNC

[ OFF]

• Pressing the Menu key after the setting displays the confirmation message in the lower part of the screen if the entered IP address is different from the current IP address.

• Holding down the Select key for at least 1 second on the confirmation message display screen displays the setting save screen.

• Press the Menu key if performing no setting. The display returns to the normal communication setting screen.

NETWORK SETTING

IP ADDRESS

192. 168. 000. 001

SUBNET MASK

255. 255. 255. 000

DEFAULT GATEWAY

000. 000. 000. 000

SET THIS SETTING. OK? YES : SELECT KEY 1SEC

NO : MENU KEY

NETWORK SETTING

SAVING SET DATA NOW.

PLEASE WAIT FOR A WHILE.

Setting Value

Contents

Setting Item

RS232C BAUD

RATE

RS232C FLOW

CTRL

SWITCHER SYNC

(Switcher

Synchronization)

Sets the transmission rate.

Sets Flow Control RTS or CTS

ON : Controls the switcher through the RS-232C interface.

OFF : Controls no switcher

TIME SYNC : Only Time Synchronization can be controlled through the

RS-232C interface.

9600 / 19200 / 38400

(bps)

ON / OFF

ON / OFF / TIME SYNC

7.8.1. Network Settings

The Network Setting screen is displayed if Network Settings is selected on the communication setting screen. Perform settings that are appropriate for the network.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (

–) or (+) key.

* The underlined contents are factory-preset values.

7.8. Communication Settings

Set the transmission rate and whether or not to use flow control in RS-232C communications. Also set the IP address, etc. to be used in the Ethernet network.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (

–) or (+) key.

• Confirm the setting with the Menu key, and return to the previous screen.

Note

*1Recording Pattern, Motion Detection Pattern, Camera/ VCR mode selection, and Time Synchronization

switcher functions can all be controlled by the Digital Video Recorder. However, when syncronizing the switcher's clock from the Recorder, set the Recorder's clock Time Synchronization setting to "MASTER." Time synhronization cannot be performed if set to "SLAVE."

7.9.2 Alarm Recording Logs (Alarm Rec Log)

Logs Alarm Recording start and end times, and displays from the latest log. Up to 500 logs are saved and old logs are deleted in chronological order when this limit is exceeded.

• The display scrolls in page units (1 screen units) as the ( ) or ( ) key is pressed.

• Return to the previous screen with the Menu key.

ALARM REC LOG

JAN/ 02/ 04 07: 00: 00

END

JAN/ 02/ 04 00: 00: 00

START

JAN/ 01/ 04 18: 00: 00

END

JAN/ 01/ 04 09: 00: 00

START

JAN/ 01/ 04 07: 00: 00

END

7.9. Log Display

Log indications include General Recording Log, Alarm Recording Log, and Failure Log.

• Move the cursor with the ( ) or ( ) key, and display Log Screen with the Select key.

• Return to the previous screen with the Menu key.

7.9.1. General/ Timer Recording Logs (General/ Timer Rec Log)

Logs start and end times of both General and Internal Timer Recordings, and displays from the latest log. Up to 100 logs are saved, and old logs are deleted in chronological order when this limit is exceeded.

• The display scrolls in page units (1 screen units) as the ( ) or ( ) key is pressed.

• Return to the previous screen with the Menu key.

LOG DISPLAY

•

GENERAL/ TIMER REC LOG ALARM REC LOG FAILURE LOG

GENERAL/ TIMER REC LOG

JAN/ 02/ 04 07: 00: 00

TIMER REC END

JAN/ 02/ 04 00: 00: 00

TIMER REC START

JAN/ 01/ 04 18: 00: 00

REC END

JAN/ 01/ 04 09: 00: 00

REC START

JAN/ 01/ 04 07: 00: 00

TIMER REC END

• The figure at right is displayed after saving completion.

• Pressing the Menu key returns the display to the communication setting menu screen.

• Switch the power OFF and back ON again to validate the network setting. (Turn off and on the rear-panel mounted Main Power switch.)

Note

Network camera’s settings are not enabled at the front-mounted Standby Key operation.

NETWORK SETTING

NETWORK SETTING CHANGED. TURN POWER OFF AND ON TO VALIDATE THE SETTING.

PRESS MENU KEY TO RETURN.

7.10.1. Menu Default Settings

• Holding down the Select key for at least 1 second clears saved menu setting contents and log information, initializing settings to factorypreset status. However, clock settings and network settings are retained.

• Return to the previous screen with the Menu key.

MENU DEFAULT SETTING

SET TO DEFAULT?

YES : SELECT KEY 1SEC

NO : MENU KEY

7.9.3. Failure Logs

Logs detection times and contents for the various different failure modes that can occur in the Digital Video Recorder, and displays from the latest log. Up to 100 logs are saved and old logs are deleted in chronological order when this limit is exceeded.

• The display scrolls in page units (1 screen units) as the ( ) or ( ) key is pressed.

• Return to the previous screen with the Menu key.

Note

The current log display does not change even if a new log is added during display. To confirm the added log, change the page or return to the log item selection screen to display the log again. All logs are deleted if Menu Default Settings of System Maintenance is performed.

7.10. System Maintenance

Performs menu default settings or format the hard disk.

• Move the cursor with the ( ) or ( ) key, and confirm the Item with the Select key.

• Return to the previous screen with the Menu key.

FAILURE LOG

JAN/ 02/ 04 07: 00: 00

VIDEO FAILURE

JAN/ 02/ 04 00: 00: 00

DISK FAILURE

JAN/ 01/ 04 18: 00: 00

VIDEO FAILURE

JAN/ 01/ 04 09: 00: 00

FAN FAILURE

JAN/ 01/ 04 07: 00: 00

DISK FAILURE

SYSTEM MAINTENANCE

•

MENU DEFAULT SETTING

DISK FORMATTING

ContentsDisplay Item

VIDEO FAILURE

DISK FAILURE

FAN FAILURE

Displays this indication when a video signal cutoff (Video Loss) is

detected during recording.

Displays this indication when a disk error is detected.

Displays this indication when fan operation stops.

7.10.2. Disk Formatting

This function initializes the hard disk. If initialized, all previously recorded contents are deleted. However, setting contents and logs are retained. Hard disks to be formatted can be selected when the C-DR0101 and C-DR0105 is used.

• Move the cursor with the ( ) or ( ) key, and change setting values with the (

–) or (+) key.

• Hold down the Select key for at least 1 second to start formatting.

• Return to the previous screen with the Menu key.

Formatting is started by holding down the Select key for at least 1 second again after the reconfirmation message is displayed. Pressing the Menu key returns the display to the system maintenance screen without formatting.

The disk error message is displayed if a disk error occurs during formatting.

DISK FORMATTING

DISK FORMATTING [ ALL]

FORMAT DISKS?

YES : SELECT KEY 1SEC

NO : MENU KEY

DISK FORMATTING

ARE YOU SURE?

YES : SELECT KEY 1SEC

NO : MENU KEY

(C-DR0101, C-DR0105)

ContentsSetting Items

HDD-A

HDD-B

ALL

Formats Hard Disk A

Formats Hard Disk B

Formats all set hard disks.

After system check completion, the Standby key changes from flashing to steady ON, allowing camera images to be displayed.

Note

When the Recorder is used for the first time or when the power was switched off for a long period of time, the date and time could not be correctly displayed. Perform the clock setting before use. (Refer to p. 14; "Clock Settings.")

8. DIGITAL VIDEO RECORDER ACTIVATION AND TERMINATION

8.1. Recorder's Activation

The switch and key shown in the following figures are used in operation.

1. Connect each component correctly. (Refer to p. 40; "Connections.")

2. Set the rear-panel mounted Main Power switch to the ON position.

The Standby key flashes green for 5 seconds while settings are initialized. Thereafter, the Recorder is placed in standby mode. The Standby key flashes every 5 seconds while in standby mode.

Note

Do not turn off the Main Power switch while the Standby key is flashing. Ensure that the Recorder is in the standby mode when turning off the Main Power switch. Logged data could be damaged or lost if the main power is switched off during initialization (while accessing the hard disk).

3. Press the Standby key while the Recorder is in standby mode.

The screen automatically changes as shown below. The Standby key flashes green during a system check.

Main Power Switch

AC MAINS

MAIN POWER

OUTPUT

VIDEO AUDIO

OFF

VIDEO SW VIDEO

OUT

TIMER

OUT

REVERSE

REC

PLAY

FRAME

ALARM RESET OUT

ALARM IN SW CTRL OUT

OUT

AUDIO

GND GND

100BASE–TX

PLAY

PAUSE

STOP

FRAME

REC START IN

ALARM RESET IN

BLOCK

TIME SYNC IN

REC STOP IN

TIME SYNC OUT

ALARM OUT

FAILURE OUT

DISK FULL OUT

SELECT

RS–232C

BUZZER STOP

ALARM RESET

DISK FULL/ FAILURE

DIGITAL VIDEO RECORDER

Standby Key

V e r .

SYSTEM CHECK IN PROGRESS

PLEASE WAIT

SYSTEM CHECK COMPLETED

8.2. When the Failure Screen Is Displayed:

Note

• Avoid operating any key during a system check after the Standby key has been pressed. The failure indication shown in the figure at right could be displayed. In such cases, switch the power OFF and back ON again.

• If the failure indication is still displayed even though the power is reactivated, format the hard disk. (Refer to p. 26; "Disk Formatting.")

• If the failure indication does not disappear even though the disk is formatted, the disk ‘s failure may be the cause. Please contact your TOA dealer.

DISKS MAY HAVE FAILED.

PLEASE TURN POWER SWITCH OFF AND ON AGAIN.

8.3. Recorder’s Termination

1. Hold down the Standby key for at least 1 second.

All operations stop, placing the Recorder in standby mode.

Note

The Recorder’s operation can be terminated by holding down the Standby key for at least 1 second even while in General Recording mode. However, when the Recorder is next reactivated, the previous recording is not retained and the Recorder is put into Pause mode. Preprogrammed timer times are set revised even if the Recorder is terminated during the timer setting and activated again.

2. Set the Main Power switch to the OFF position.

The Recorder’s power is switched off.

9. OPERATION AFTER POWER FAILURE RESTORATION

The Recorder’s set contents are never reset by power failures. However, since the date and time are backed up by the built-in battery, if no power is supplied for a long period of time (1 month), they are reset. In such cases, perform the clock setting again.

9.1. When the Power Fails during Recording;

• During General Recording Recording is restarted when the power is restored.

• During Alarm Recording If an alarm input still continues when the power is restored, it is recognized as a new alarm input and recording is restarted. However, if no alarm exists, recording is not performed. Also, even if the power is restored within the set Alarm Recording time period or Post-alarm time period, recording is not restarted because there is no alarm signal.

• During Internal Timer Recording Timer operation is restarted if the power is restored within the set time period. If restored during Internal Timer Recording, the recording is restarted.

10. RECORDING

10.1. Type of Recording

Recording modes include General Recording, Internal Timer Recording, and Alarm Recording. Each recording mode permits the picture quality and recording interval to be set individually. (Refer to p. 17; "General Recording Settings.") In the Digital Video Recorder, recorded data from the start to the end of each recording is handled as a single recorded block.

10.1.1. Recording Priorities

The order of Recording Priority is as shown below.

10.2. Screen Display during Recording

The screen display setting is factory-preset to "DISP." (Refer to p. 21; "Screen Display Settings".)

* C-DR0101, C-DR0105

High Low

Order of Priority

Type of Recording

General Recoding Alarm Recoding

Internal Timer Recording

Lower-priority recording stops whenever higher-priority recording is commenced. The following figure shows an example of recording operation that varies whenever recording of different priority levels is commenced.

Note

Internal Timer Recording does not operate even if the Timer key is pressed during General or Alarm recording. Pressing the Recording (

) key during a timer setting cancels the timer setting. To resume the

timer setting, first stop recording and press the Timer key.

Indicates the recording status. (Refer to p. 17; "General Recording Settings".)

•

REC: Represents General Recording is in progress.

•

TIMER: Represents Internal Timer Recording is in progress.

•

ALARM: Represents Alarm Recording is in progress.

Indicates the recording picture quality. Can be set to Levels 1 – 5. LEVEL 1 provides the highest resolution display.

General Recording

Alarm Recording

Internal Timer Recording

Alarm Input

Alarm End

Alarm Input

Rec. key pressed

Alarm Input

Alarm End

Recording End

Timer Key pressed

THU JAN / 01 / 04

00 : 00 : 00

REC

•

LEVEL3

1 / 60

2 3 4 5

00 : 00 : 00

M AB F

Indicates the recording interval. General Recording and Internal Timer Recording : 1/60 – 60 seconds Alarm Recording : 1/60 – 1 seconds

Note

• Even if the Recording Setting’s Recording Interval is set to "1/60 SEC," Mirroring Recording is performed at the recording interval of 1/30 second. (The on-screen interval indication is also "1/30 SEC" in Mirroring Recording.) (Refer to p. 17; "General Recording Settings.")

• The higher the picture quality (resolution) and the shorter the recording interval, the shorter the possible recording time. Conversely, the lower the picture quality and the longer the recording interval, the longer the possible recording time. (Refer to p. 45; "Recording Time Table.")

Indicates whether or not to use the Audio recording function.

: Audio recording ON (enabled)

No indication : Audio recording OFF (disabled)

Indicates the hard disk Recording Mode. (Refer to p. 15; "Disk Settings.")

Re-Rec Mode Stop Mode Series Mode

• Re-Rec Mode : Overwrites old hard disk recordings in chronological order even when no available hard disk

time remains.

• Stop Mode : Stops video recording when no available hard disk time remains.

• Series Mode : Stops video recording when no available hard disk time remains, and sends out a signal

from the Control Terminal’s Disk Full output, allowing other series-connected Digital Video Recorder to start recording. The slave Digital Video Recorder starts recording when it receives a signal at its Recording Start input terminal even if its hard disk becomes full. (Refer to p. 41; "Expansion System (Series Recording).")

Indicates the Disk Mode. (C-DR0101, C-DR0105) (Refer to p. 15, "Disk Settings".)

No indication : Normal Recording M : Mirroring Recording

• About Normal and Mirroring recordings The C-DR0101 and C-DR0105 has two built-in hard disks. Setting the Disk Mode to "NORMAL" permits camera images to be recorded on the second hard disk when the first hard disk becomes full. Setting the Disk Mode to "MIRRORING" permits the same recording to be simultaneously performed on the two hard disks. Even if one of the two disks fails, recording and playback can still be performed using the other disk.

Indicates the hard disk recognition status. (C-DR0101, C-DR0105) Characters are reversed for the hard disk in recording mode. The "X" indication is displayed when the hard disk fails.

Note

Even if the Screen Display Setting’s Disk Mode Indication is set to "HIDE," the "X" indication is displayed when the hard disk fails.

Indicates the remaining hard disk recording time calculated from the picture quality and recording interval of current recording. If the Disk Setting’s Recording Mode is set to "RE-REC", the remaining hard disk recording time is not displayed.(Refer to p. 15; "Disk Settings".)

Indicates the current date and time.

The "F" indication flashes when the fan fails. Cannot be set to "HIDE" in Screen Display Settings.

987

543

10.5. Performing Internal Timer Recording (Refer to p. 17; "Internal Timer Recording Settings)

Note

Be sure to perform date and time settings before recording. (Refer to p. 14; "Clock Settings".)

1. Press the Timer key. The Digital Video Recorder is placed in Internal Timer Recording standby mode, and the Timer key lights green.

2. When the preset time is reached or if the key is pressed within the preset period, the Recording key lights red and recording is started. If "DISP" has been selected in Screen Display Settings, setting data is displayed on the monitor, and the "TIMER" indication is displayed for recording status.

10.4. Performing General Recording (Refer to p. 17; "General Recording Settings)

Note

Be sure to perform time and date settings before recording. (Refer to p. 14; "Clock Settings")

1. Press the Recording key (

) to start General Recording. When recording is started, the Recording key lights red. If "DISP" has been selected in Screen Display Settings, setting data is displayed on the monitor and the Recording indication is displayed for recording status.

Note

When the Disk Setting Recording Mode has been set to "STOP" or "SERIES," the Disk Full indicator flashes if less than 1 hour of available hard disk time remains. If no available hard disk time remains, the Disk Full indicator changes to steady ON and recording stops.

2. Hold down the Recording key (

) for at least 1 second to stop recording.

The illuminated Recording key extinguishes.

Note

If an alarm is activated during General Recording performance while in alarm standby mode, the General Recording is interrupted and switched over to Alarm Recording. The General Recording is automatically restored after Alarm Recording completion.

THU JAN/ 01/ 04 00 : 00 : 00

•

REC

LEVEL3 1/60 M : AB F

THU JAN/ 01/ 04 00 : 00 : 00

•

TIMER

LEVEL3 1/60 M : AB F

10.3. The Keys to Be Used in Recording

The following keys are used in recording:

REVERSE

REC

OUTPUT

VIDEO AUDIO

TIMER

PLAY

FRAME

Timer Key Recording Key

PAUS E

PLAY

FRAME

PLAY STOP

SELECT

BLOCK

Buzzer Stop Key

BUZZER STOP

ALARM RESET

DISK FULL/ FAILURE

DIGITAL VIDEO RECORDER

10.6. Performing Alarm Recording (Refer to p. 19; "Alarm Recording Settings)

Note

• Be sure to perform date and time settings before recording. (Refer to p. 14; "Clock Settings".)

• Be sure to set the Alarm Recording Setting’s Alarm Setting to "VALID" when performing Alarm Recording. This places the Digital Video Recorder in alarm standby mode.

• The setting is factory-preset to "VALID."

1. A buzzer is sounded and the Buzzer stop key flashes red when an alarm signal is received. At the same

time, the Recording key lights red and recording is started. The Buzzer stop key continues flashing red during Alarm Recording.

• If "DISP" has been selected in Screen Display Settings, setting data is displayed on the monitor, and the "ALARM" indication is displayed for recording status.

• Pressing the Buzzer stop key during buzzer output stops the buzzer. Whether or not to sound a buzzer can be set by selecting ON or OFF in Alarm Recording Settings.

• Alarm Recording provides an open collector signal from the Alarm Output Terminal. An alarm output duration can be set to "1 SEC" or "DURING REC" in Alarm Recording Settings.

2. Recording stops when the end of the Preset Alarm Recording Period is reached. The illuminated Recording

key extinguishes, however the Alarm Reset key remains lit. To reset Alarm Recording before the Preset Alarm Dcording Period is started, hold down the Alarm Reset key for at least 1 second.

Note

• Pressing the Recording key (

) during Alarm Recording resets Alarm Recording, and switches it over to General Recording. However, the Alarm Reset key continuously lights red to indicate that an alarm has been activated.

• To extinguish the illuminated Alarm Reset key, hold down the Alarm Reset key for at least 1 second.

• If the Alarm Recording’s Alarm Settings is set to "VAL REC," alarm signals are only accepted while recording is in progress. Alarm inputs can be only accepted during the necessary surveillance period by combining both Alarm and Internal Timer recordings.

• If the Alarm Recording’s Alarm Settings is set to "INVALID," any alarm input is not accepted.

• If other alarms are activated during Alarm Recording, the preset alarm time is initialized to make the recording period longer. In this case, the number of recorded blocks is one.

THU JAN/ 01/ 04 00 : 00 : 00

•

ALARM

LEVEL3 1/60 M : AB F

3. Recording stops when the end of the preset recording period is reached.

The illuminated Recording key extinguishes.

Note

• When the Disk Setting Recording Mode is set to "STOP," recording stops if no available hard disk time remains.

• When the Recording mode is set to "SERIES," timer program cannot be perfomed.

• When an alarm is activated during Internal Timer Recording, the Internal Timer Recording is interrupted, and automatically restored after Alarm Recording completion.

• Pressing the Recording key (

) during Internal Timer Recording resets Internal Timer Recording, and

switches it over to General Recording.

4. To cancel Internal Timer Recording, hold down the Timer key for at least 1 second. The illuminated Timer

key extinguishes.

11. PLAYBACK

11.1. Type of Playback

The Digital Video Recorder features the simultaneous recording/playback function that permits recorded images to be played back without stopping recording. The types of playback include Playback, Reverse Playback, Fast Forward Playback, Fast Reverse Playback, Forward Frame Playback, and Reverse Frame Playback.

Note

• When the Playback Setting’s Simultaneous Recording/Playback is set to "DISALLOW," playback cannot be performed during recording. Only recording or playback can be performed.

• Playback performance could be degraded during simultaneous recording/playback operation.

Indicates playback mode.

: Fast Reverse Playback : Fast Forward Playback : Reverse Playback : Playback : Pause

• Pressing the Playback key ( ) during playback (or the Reverse Playback key ( ) during Reverse playback) changes the mode to Fast Forward playback (Fast Reverse playback during Reverse playback). The "x2", "x4" or "x8" indication is displayed on the screen to indicate the playback speed.

• Pressing the Playback key ( ) or the Reverse Playback key ( ) during still picture playback (while in pause mode) changes the mode to Forward or Reverse Frame playback. Holding down the key performs a continuous frame-by-frame playback of the recorded image.

Indicates the recording picture quality. Can be set to Levels 1 – 5. Quality increases as the number decreases. Indicates the recording interval. General Recording, Internal Timer Recording : 1/60 – 60 seconds Alarm Recording : 1/60 – 1 seconds Indicates an attribute of Mirroring Recording. (C-DR0101, C-DR0105) No indication : Data other than Mirroring Recording data M : Mirroring Recording data Indicates the currently-used hard disk. (C-DR0101, C-DR0105) A : Playback of Hard disk A B : Playback of Hard disk B Indicates recording dates and times. The ( ) indication is displayed when recording is also performed simultaneously with playback. The "F" indication flashes when the fan fails. This indication cannot be set to "HIDE" in Screen Display Settings.

11.2. Screen Display during Playback

Screen Display Settings is factory-preset to "DISP." (Refer to p. 21; "Screen Display Settings.")

* C-DR0101, C-DR0105

THU JAN / 01 / 04

00 : 00 : 00

x 2

•

1 / 60

M A F

3 4

LEVEL3

6 7

11.4. Performing Playback

1. Press the Playback key ( ) to start playback.

The Playback key lights green when playback is started. If Screen Display Settings has been set to "DISP," setting data is displayed on the monitor, and the "Playback" indication is displayed for playback status.

2. Press the Playback Stop key ()to stop playback. The illuminated Playback key extinguishes.

11.5. Performing Various Playback Fanctions

11.5.1. Reverse Playback

Press the Reverse Playback key ( ) to perform playback in the reverse direction. The Reverse Playback key lights green when Reverse playback is started. If Screen Display Settings has been set to "DISP," setting data is displayed on the monitor, and the "Reverse Playback" indication is displayed for playback status.

11.5.2. Fast Forward Playback and Fast Reverse Playback

Pressing the Playback key ( ) during playback (or the Reverse Playback key ( ) during Reverse playback) changes the playback mode to Fast Forward (or to Fast Reverse playback if pressed during Reverse playback). The playback speed changes as the key is pressed.

Playback speed: Original speed Twofold speed (x2) Fourfold speed (x4) Eightfold speed (x8)

Note

Playback may not be performed at the indicated speed depending on the hard disk performance, such as access times.

11.5.3. Playback Pause (Still Picture)

1. Pressing the Pause key ( ) during playback or Reverse playback suspends playback operation, causing

the Pause key to light green. If Screen Display Settings has been set to "DISP," setting data is displayed on the monitor, and the "Pause" indication is displayed while in pause mode.

11.3. The Keys to Be Used in Playback

The following keys are used in playback. Reverse Playback key, Pause key, Playback key, Playback Stop key, Block Shift key

OUTPUT

VIDEO AUDIO

TIMER

REVERSE

REC

PLAY

FRAME

PAUSE

PLAY

FRAME

PLAY STOP

BLOCK

SELECT

BUZZER STOP

ALARM RESET

DISK FULL/ FAILURE

DIGITAL VIDEO RECORDER

Block Shift key

Reverse Playback key

Pause key

Playback Stop key

Playback key

2. Pressing the Pause key ( ) again returns the Digital Video Recorder to the playback mode it was last in

before playback was suspended. The illuminated Pause key extinguishes and the Playback key lights.

11.5.4. Forward Frame Playback and Reverse Frame Playback

If the Playback key ( ) or Reverse Playback key ( ) is pressed while in Playback Pause mode, Forward or Reverse Frame playback can be performed.

Pressing the key once performs a single-frame playback per screen, while holding down the key provides a continuous frame-by-frame playback.

11.5.5. Forward Block Playback and Reverse Block Playback

In the Digital Video Recorder, recorded data from the start to the end of each recording is handled as a single recorded block. Since both the Forward Block Playback and Reverse Block Playback functions shift playback images on a block basis, desired scenes can be searched while viewing playback images.

Pressing the (+) Block Shift key during playback shifts the recorded image to the head of the next block, temporarily stopping playback for 1 second before it is restarted. If the (+) Block Shift key is pressed again while in Playback Pause mode, the recorded image is shifted to the next block, providing the same operation.

Pressing the (–) Block Shift key during playback shifts the recorded image to the head of the block currently played back, temporarily stopping playback for 1 second before it is restarted. If the (–) Block Shift key is pressed again while in Playback Pause mode, the recorded image is shifted to the head of the preceding block and then it is played back.

Block shift is also possible during Reverse Playback operation, however playback resumes in the forward direction after the recorded image has been shifted to the head of the desired block.

Press +

Block Block Block Block

Press + Press +

Playback

Press - while in Playback Pause mode.

Press

Block Block

Playback direction

11.6. About the Playback Start Position

• If playback is initiated from the camera display screen, the playback begins from the position at which it was last stopped. When the power is switched on or when the position previously played back has been overwritten, playback is started from the oldest recorded image. During recording, playback is started from the most recent data in the currently recorded block.

• Pressing the Playback key ( ) (or the Reverse Playback key ( )) while holding down the Playback Stop key ()while in Stop or Playback mode shifts the recorded image to the following position for playback.

• Pressing the Playback key ( ) (or the Reverse Playback key ( )) while holding down the Playback Stop key ()during recording causes playback to be started from the following position.

Note

When playing back in the forward direction, if the Pre-alarm time has been set to 10 second or more and the Digital Video Recorder is in alarm standby mode, playback is started from 10 minutes before the most recent block is played back.

Current position

Press

Oldest block

Block

Playback direction

Current position (recording is in progress)

Block

Press +

Most recent block

Press +

(playback from the most recent data)

Note

• When no recording exists at the designated time, the first image of the recorded block following the designated time is displayed.

• Attempting to perform searches beyond the current time results in a display of the "INVALID SEARCH" indication on the Date/Time Search screen.

12. SEARCH FUNCTIONS

The following three methods are available to search recorded data (images):

1. Date/Time Search : Playback can be initiated by designating the date and time.

2. Block Search : Playback can be initiated by selecting the recorded block.

3. Time Shift Search : Playback can be initiated by increasing or decreasing times from the designated time.

The Digital Video Recorder handles recorded data from the start to the end of each recording as a single recorded block.

The above three search methods differ in operation.

DATE / TIME SEARCH

JAN / 01 / 04 00 : 00

12.2. Date/Time and Block Searches

12.2.1. Basic Date/Time Search and Block Search Operations

1. Press the Search key.

The Search menu screen is displayed. Playback stops if the key is pressed during playback. Pressing the Search key again returns the display to the camera image screen.

2. Move the cursor to select the desired search function with the ( ) or

( ) key, then confirm the selection with the Select key.

Setting Value ContentsSetting Items

DATE/ TIME SEARCH

BLOCK SEARCH

Recorded images are searched by directly entering the date and time

Recorded images are searched by selecting the recorded block.

Date/ time data entry

–

•

DATE / TIME SEARCH

BLOCK SEARCH

12.2.2. Date/Time Search Operation

• Move the cursor with the ( ) or ( ) key, and change setting values with the (

–) or (+) key.

• Executing searches with the Select key displays the image of the designated time on the still picture mode screen. The Pause key lights green.

• Playback begins if the Pause key ( ) is pressed.

12.1. The Keys to Be Used in Searching

The following keys are used in search operation:

Select key

Search key

OUTPUT

VIDEO AUDIO

TIMER

REVERSE

REC

PLAY

FRAME

PAUSE

PLAY

FRAME

PLAY STOP

BLOCK

Pause key

Playback key

Playback Stop key

Up Shift key

Block Shift key

SELECT

STOP

ALARM RESET

BUZZER

Down Shift key

DISK FULL/ FAILURE

DIGITAL VIDEO RECORDER

BLOCK SEARCH

N JAN / 01 / 04 21 : 35 : 27 AMJAN / 01 / 04 21 : 35 : 27 ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : –– ––––– / –– / –– –– : –– : ––

[Recorded block types]

Recorded block types are classified by characters "N," "T," and "A."

ContentsItem

General Recording block

Internal Timer Recording block

Alarm Recording block

[Recorded block attribute]

Character M represents data attribute types.

[Hard disk types]

Characters A and B represent built-in hard disk drives.

ContentsItem

Data contained in Hard Disk A

Data contained in Hard Disk B

12.2.3. Block Search Operation

• Using the ( ) or ( ) key, move the cursor to scroll the screen and

select the desired block. The ( ) indication is displayed when data exists before the currently displayed search screen, while the ( ) indication is displayed when data exists after the currently-displayed search screen.

• Executing searches with the Select key displays the first image of the block on the still picture screen. The image is played back if the Pause key is pressed. Pressing the (+) or (–) key while in the Pause mode displays the first image of the block, performing playback from one block to another. After the block has switched over to another block, playback can be performed even without pressing the Pause key.

• "Loop" playback is performed for all playback operations after Block Shift search.

Note

• "Loop" playback: Repeats playback of each recorded block.

• Pressing the Playback Stop key ( ) and the Playback key ( ) again during "Loop" playback resets the "Loop" playback, causing playback to be performed on a time basis.

Note

The Alarm Recording block time represents the time that an alarm was received. If the Pre-alarm function has been set, Alarm Recording begins from the image recorded before the indicated alarm time.

Note

Avoid mixing both Normal Recordings and Mirroring Recordings on the hard disk. If mixed, block shift or search operations cannot be correctly performed during playback. (Refer to p. 15; "Disk Settings.")

ContentsItem

No IndicationMNormal Recordung data

Mirroring Recording data

2 3

Head of the selected block

Press

Block

“Loop” playback

Block Block

“Loop” playback

Note

• Continuous or normal forward/reverse frame playback can also be performed even when the Time Shift Search screen is displayed (even while the Pause key is flashing).

• If Time Shift Search operation exceeds the range of "Loop" playback during "Loop" playback, the "Loop" playback is reset, reverting to normal playback.

12.3. Time Shift Search

1. Press the Pause key on the playback screen to suspend playback.

2. Press the Search key.

The Time Shift Search screen is displayed, and the Pause key flashes.Pressing the Search key again returns the display to the playback pause screen.

3. Using the ( ) or ( ) key, change the time period to be shifted.The

shift time period increases as the ( ) key is pressed, and decreases as the ( ) key is pressed. It can be set to a variable period of 1 – 60 minutes.

4. Press the (+) or (–) key.

The (+) key advances the shift time period by the designated length of time, while the (–) key reverses the time period by the same designated length of time. If no image exists at the designated time, pressing the (+) key displays the image following the designated time, while the image preceding the designated time is displayed if the (–) key is pressed.

5. Press the Search key to reset the Time Shift Search.

The display is temporarily stopped at the searched Time Shift screen.

6. Press the Pause key to begin playback of the searched image.

THU JAN / 01 / 04 00 : 00 : 00

SHIFT TIME CHANGE : / SHIFTING : – / + CANCEL : SEARCH

SHIFT: 10MIN

LEVEL3 1/60 A

When the Time Shift Search function is operated within the "Loop" playback range:

When the Time Shift Search function is operated beyond the "Loop" playback range:

Time Shift

Block

Pause

Block

Time Shift

Block

“Loop” playback

Time Shift

Pause

Time Shift

Block

Playback operation on a time basis

Block

13. CONNECTIONS

13.1. Preparations for Connections

Switch off the power to the Digital Video Recorder and all connected equipment before performing connections. The Digital Video Recorder has built-in hard disks. To avoid damage to them, when moving the Digital Video Recorder, be sure to leave the Recorder’s Main Power switch turned off for at least 30 seconds before moving.

13.1.1. Control Input/Output Terminal Connections

Applicable cables are as follows:

• Solid cable : AWG28 (ø 0.32mm) – AWG22(ø 0.65mm)

• Twisted cable: AWG28 (0.08mm2) – AWG22(0.32mm2)

To connect, remove the cable sheath 10 mm from the cable end, and then insert the cable into the terminal pressing on the tab on the terminal using a screwdriver.

13.2. When Using the 24V AC or 12V DC or AC Mains Camera:

Connect the Digital Video Recorder’s Video Input terminal to the camera’s video output terminal.

13.3. Connections to the Monitor TV

The Digital Video Recorder’s terminals to be connected to the monitor differ depending on the type of connected equipment.

• When the Digital Video Recorder is not connected to the Multi-switcher: Connect the Recorder’s Video Output terminal to the monitor’s video input terminal, and the Recorder’s Audio Output terminal to the monitor’s audio input terminal.

• When the Digital Video Recorder is connected to the Multi-switcher: Connect the Recorder’s Switcher Video Output terminal to the monitor’s video input terminal, and the Recorder’s Audio Output terminal to the monitor’s audio input terminal.

13.4. Combination With The Digital Video Recorder/ Multi-switchers (C-MS91D and C-MS161D)

The Digital Video Recorder has been designed with an emphasis on the synchronization with the TOA Multiswitchers (C-MS91D, C-MS161D). By synchronizing the Digital Video Recorder with the Multi-switcher, the following advantages – unavailable to conventional systems using analog time-lapse VCRs – can be realized.

1. The Multi-switcher does not need to be operated when operating the Digital Video Recorder.

2. The Digital Video Recorder’s main menu screen or search screen can be easily displayed, facilitating

settings and search operations. The combined Digital Video Recorder/Multi-switcher system is called a basic system in this manual. Since the Multi-switcher has 2 VCR output terminals, hard disk space can be doubled by connecting two Digital Video Recorders. This system is called an expansion system. The expansion system does not permit the synchronization between the Digital Video Recorder and the Multi-switcher.

13.4.1. Basic System

Perform connections as shown in connection examples. (Refer to p. 43) Set the Multi-switcher (C-MS91D and C-MS161D) and the Digital Video Recorder as follows:

13.4.2. Expansion System (Series Recording)

Perform connections as shown in connection examples. (Refer to p. 44) The Digital Video Recorder settings are as follows:

• Operation If the first Digital Video Recorder’s hard disk space becomes full, a signal is provided from the Disk Full Output terminal. When the signal is received at the second Digital Video Recorder’s Recording Start Input terminal, its Disk Full mode is reset, allowing recording to be started in the second unit.

Note

• Recording operation and Internal Timer Recording cannot be performed at the front panel of the Digital

Video Recorder set to Disk Full mode.

• Multi-switcher can be synchronized from the unit set to master through the RS-232C interface.Set

Communication Setting’s Switcher Synchronization to “TIME SYNC.”

• Multi-switcher settings Perform remote and recording settings as follows:

• Digital Video Recorder settings Perform communication settings as follows:

ContentsSetting Items

Remote

Settings

RS-232C

38.4kbps (Default)

1 (Default)

OFF*

Recording Pattern

Operation

Motion Detection

Pattern Operation

RS-232C

RS-232C Protocol

Recording Device

Date/Time (VCR)

ContentsSetting Items

Communication

Settings

38400bps (Default)

OFF (Default)

RS-232C

Transmission Rate

RS-232C Flow Control

Switcher

Synchronization*

Recording Pattern

Motion Detection

Pattern

Recording

Settings

Buzzer/

Character

Display Settings

When perform-

ing Internal

Timer Recording

settings

Match the Recorder’s

settings to those of the

Multi-switcher

Note

*1Use the Digital Video Recorder’s date/time display function for date/time display. If set at both the Multi-

switcher and Digital Video Recorder, characters overlap and cannot be seen clearly. *2Recording Pattern, Motion Detection Pattern, Camera/ VCR mode selection, and Time Synchronization

switcher functions can all be controlled by the Digital Video Recorder. However, when syncronizing the

switcher's clock from the Recorder, set the Recorder's clock Time Synchronization setting to "MASTER."

Time synhronization cannot be performed if set to "SLAVE."

When only performing time synchronization, set the communication swither synchronization setting to

"TIME SYNC." Please note that in this mode Recording Pattern,Motion Detection Pattern, and Camera/

VCR mode selection functions cannot be controlled.

• For more information on the Multi-switcher’s settings, refer to the instruction manual for the Multi-switcher.

First Digital Video Recorder

Setting Items

Recording Mode

Time Synchronization

Disk Full indicator status

SERIES

MASTER

OFF

Second Digital Video Recorder

SERIES

SLAVE

14. CONNECTION EXAMPLES

14.1. Connection to the 24V AC or 12V DC or AC Mains Camera.

Note

Power Sync cameras cannot be used.

Camera

ALARM RESET OUT

ALARM IN

VIDEO OUT

SW CTRL OUT

Sensor etc.

AC MAINS

Monitor TV

MAIN POWER

Video Input

GND

Video Input

OFF

VIDEO SW VIDEO

OUT

ALARM RESET OUT

ALARM IN

SW CTRL OUT

OUT

AUDIO

GND GND

100BASE–TX

REC START IN

ALARM RESET IN

TIME SYNC IN

REC STOP IN

TIME SYNC OUT

ALARM OUT

FAILURE OUT

DISK FULL OUT

RS–232C

1CH Digital Video Recorder

Video Output

14.2. Connection to the Multi-switcher

14.2.1. Basic System (Combined with the C-MS91D Multi-switcher)

Note

Power Sync cameras cannot be used.

Camera

Monitor Output1

VCR Input1

VCR Output1

Video Input 1 – 9

VTR1

GND

Alarm Output

ALARM RESET OUT

ALARM IN

SW CTRL OUT

GND

Sensor etc.

Multi-switcher (C-MS91D)

Alarm Input/Output

RS-232CRS-232C

Switcher Control Input

AC MAINS

Monitor TV

MAIN POWER

Video Input

Switcher Video Input

AUDIO

OUT

ALARM RESET OUT

ALARM IN

SW CTRL OUT

OUT

GND GND

100BASE–TX

TIME SYNC IN

REC STOP IN

REC START IN

ALARM RESET IN

TIME SYNC OUT

ALARM OUT

FAILURE OUT

DISK FULL OUT

Video Input

Video Output

OFF

VIDEO SW VIDEO

OUT

D-Sub9 Pin

RS–232C

1CH Digital Video Recorder

Switcher

Video Output

14.2.2. Expansion System (Combined with the C-MS91D Multi-switcher)

Note

Power Sync cameras cannot be used.

Camera

AC MAINS

MAIN POWER

OFF

Camera

VCR Input 1

VCR Input 2

Video Input

VIDEO SW VIDEO

VCR Output 2

VCR Output 1

Monitor Output 1

Video Output

OUT

Switcher Video

OUT

Video Input 1 – 9

Input

OUT

AUDIO

GND GND

Alarm Output

Switcher Control

ALARM RESET OUT

ALARM IN SW CTRL OUT

100BASE–TX

GND

Switcher Control Input

Alarm Input

Output

TIME SYNC OUT

TIME SYNC IN

REC STOP IN

REC START IN

ALARM RESET IN

Multi-switcher (C-MS91D)

VTR1 VTR2

GND

Alarm Output

Switcher Control Input

1CH Digital Video Recorder (1)

ALARM OUT

FAILURE OUT

DISK FULL OUT

RS–232C

Sensor etc.

Monitor TV

Video Input

Master

AC MAINS

MAIN POWER

GND

Diskfull Output

Switcher

Video Output

GND

Time Sync

Output

Recording Start

Input

Switcher Video Output

Video Input

Switcher Video

Input

Video Output

Recording Start

Input

Alarm Input

OFF

VIDEO SW VIDEO

OUT

ALARM RESET OUT

ALARM IN

SW CTRL OUT

OUT

AUDIO

GND GND

100BASE–TX

REC START IN

ALARM RESET IN

TIME SYNC IN

REC STOP IN

TIME SYNC OUT

Diskfull Output

GND

Time Sync Input

ALARM OUT

FAILURE OUT

DISK FULL OUT

RS–232C

Slave

GND

Switcher Control Output

1CH Digital Video Recorder (2)

15.2. When using the C-DR0100

Disk Mode : NORMAL Audio Record : ON

1/60

8 13 17 22 32

1/30

17 26 33 43 62

1/15

33 52 64 84

120

1/10

50 78

95 124 176

1/5

97 150 183 234 325

1/3 158 239 289 364 494

1/2 227 337 402 498 654

1 409 580 674 804 996

2 681 901

1011 1150 1334

878 1112 1220 1352 1516

5 1134 1356 1450 1558 1684

10 1460 1631 1697 1769 1848

20 1704 1815 1855 1898 1942

30 1803 1884 1913 1943 1973

60 1916 1961 1976 1992 2008

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

Disk Mode : NORMAL Audio Record : OFF

1/60

9 14 17 22 33

1/30

17 27 34 44 65

1/15

34 54 67 89

131

1/10

81 101 133 196

1/5 103 163 202 267 392

1/3 171 271 337 445 654

1/2 257 407 505 667 981

1 513 813

1011 1334 1962

2 1026 1627 2021 2668 3924

3 1539 2440 3032 4002 5885

5 2565 4067 5053 6670 9809

10 5131 8134

10106 13340 19618

20 10262 16268 20212 26680 39236

30 15392 24403 30318 40020 58853

60 30785 48805 60637 80041 117707

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

15. RECORDING TIME TABLE

15.1. Recording Picture Quality Setting

The Digital Video Recorder is designed to be used as a hard disk recorder for surveillance applications, and its picture quality can be set to Levels 1 – 5. Whether emphasis is placed on picture quality or on recording interval can be selected depending on surveillance conditions. When setting the picture quality, carefully consider recording times, recording intervals, recording types and other surveillance conditions, and be sure to carry out test recordings in advance to ensure that the required picture quality is maintained.

Note: Recording time is given as a guideline reference.

Disk Mode : NORMAL Audio Record : ON

1/60

17 27 33 44 64

1/30

34 53 65 86

124

1/15

67 105 129 168 240

1/10

100 155 191 247 351

1/5 195 300 365 468 651

1/3 315 478 577 729 988

1/2 454 674 804 996

1308

818 1160 1347 1607 1991

2 1361 1803 2021 2300 2668

3 1755 2223 2440 2704 3032

5 2269 2711 2900 3117 3369

10 2919 3262 3394 3538 3695

20 3407 3630 3711 3795 3884

30 3605 3768 3826 3885 3947

60 3832 3922 3953 3984 4016

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

Disk Mode : NORMAL Audio Record : OFF

1/60

17 27 34 44 65

1/30

34 54 67 89

131

1/15

68 108 135 178 262

1/10

103 163 202 267 392

1/5 205 325 404 534 785

1/3 342 542 674 889

1308

1/2 513 813

1011 1334 1962

1 1026 1627 2021 2668 3924

2 2052 3254 4042 5336 7847

3 3078 4881 6064 8004

11771

5 5131 8134 10106 13340 19618

10 10262 16268 20212 26680 39236

20 20523 32537 40425 53360 78471

30 30785 48805 60637 80041 117707

60 61570 97610 121274 160081 235413

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

15.3. When using the C-DR0101

Disk Mode : MIRRORING Audio Record : ON

1/60

– – – – –

1/30

17 26 33 43 62

1/15

33 52 64 84

120

1/10

50 78

95 124 176

1/5

97 150 183 234 325

1/3 158 239 289 364 494

1/2 227 337 402 498 654

1 409 580 674 804 996

2 681 901

1011 1150 1334

878 1112 1220 1352 1516

5 1134 1356 1450 1558 1684

10 1460 1631 1697 1769 1848

20 1704 1815 1855 1898 1942

30 1803 1884 1913 1943 1973

60 1916 1961 1976 1992 2008

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

Disk Mode : MIRRORING Audio Record : OFF

1/60

– – – – –

1/30

17 27 34 44 65

1/15

34 54 67 89

131

1/10

81 101 133 196

1/5 103 163 202 267 392

1/3 171 271 337 445 654

1/2 257 407 505 667 981

1 513 813

1011 1334 1962

2 1026 1627 2021 2668 3924

3 1539 2440 3032 4002 5885

5 2565 4067 5053 6670 9809

10 5131 8134

10106 13340 19618

20 10262 16268 20212 26680 39236

30 15392 24403 30318 40020 58853

60 30785 48805 60637 80041 117707

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

Note

Setting the Disk Setting’s Disk Mode to "MIRRORING" limits the maximum recording interval to 1/30 second. (Refer to p. 15;"Disk Setting.")

15.4. When using the C-DR0105

Disk Mode : NORMAL Audio Record : ON

1/60

34 54 67 89

129

1/30

68 108 133 174 252

1/15

136 213 263 342 490

1/10

203 316 389 504 716

1/5 397 612 746 955

1328

1/3 643 976

1179 1488 2017

1/2

926 1375 1640 2032 2670

1 1670 2368 2751 3281 4064

2 2779 3680 4126 4695 5447

3 3583 4539 4982 5520 6189

5 4631 5535 5920 6363 6877

10 5959 6658 6930 7224 7544

20 6956 7410 7575 7748 7928

30 7360 7693 7811 7932 8057

60 7822 8006 8069 8133 8199

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

Disk Mode : NORMAL Audio Record : OFF

1/60

34 55 68 90

133

1/30

69 110 137 181 267

1/15

139 221 275 363 534

1/10

209 332 412 544 801

1/5 419 664 825

1089 1602

1/3

698 1107 1375 1815 2670

1/2 1047 1660 2063 2723 4005

1 2095 3321 4126 5447 8010

2 4190 6642 8253

10894 16020

3 6285 9964

12379 16341 24031

5 10475 16606 20632 27235 40051

10 20950 33213 41265 55470 80103

20 41900 66427 82531 108941 160207

30 62850 99641 123796 163411 240311

60 125701 199282 247593 326823 480622

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

Disk Mode : MIRRORING Audio Record : ON

1/60

– – – – –

1/30

34 54 66 87

126

1/15

68 106 131 171 245

1/10

101 158 194 252 358

1/5 198 306 373 477 664

1/3 321 488 589 744

1008

1/2 463 687 820

1016 1335

835 1184 1375 1640 2032

2 1389 1840 2063 2347 2723

3 1791 2269 2491 2760 3094

5 2315 2767 2960 3181 3438

10 2979 3329 3465 3612 3772

20 3478 3705 3787 3874 3964

30 3680 3846 3905 3966 4028

60 3911 4003 4034 4066 4099

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

Disk Mode : MIRRORING Audio Record : OFF

1/60

– – – – –

1/30

34 55 68 90

133

1/15

69 110 137 181 267

1/10

104 166 206 272 400

1/5 209 332 412 544 801

1/3 349 553 687 907

1335

1/2 523 830

1031 1361 2002

1 1047 1660 2063 2723 4005

2 2095 3321 4126 5447 8010

3 3142 4982 6189 8170

12015

5 5237 8303

10316 13617 20025

10 10475 16606 20632 27235 40051

20 20950 33213 41265 54470 80103

30 31425 49820 61898 81705 120155

60 62850 99641 123796 163411 240311

Level 1 Level 2 Level 3 Lebel 4 Level 5


quality

64KB 40KB 32KB 24KB 16KB

File

Size

Recording Time Intervals (Sec), Recording Time Period

16. EXTERNAL TERMINAL SPECIFICATIONS

16.1. RS-232C Communication Specifications

The Digital Video Recorder’s RS-232C interface permits remote control using a connected PC.

Note

• Control software is not supplied as standard.

• Communication specifications are those set when the Switcher Synchronization selection on the Communication Setting Screen is set to "OFF."

• TOA takes no responsibility for any inconvenience or damage to customer hardware or software which may result from the use of control software based on the specifications described in this section.

16.1.1. The Rules of Overall Communications

1. All communications are established by means of a command from the controller.

2. Responses are always present in mutual communications.

3. The response timeout period is 1 second, and the timeout period between continuous data is 100

milliseconds. When the timeout occurs, the corresponding communications are regarded as failed.

4. Data is only updated when a communication setting content update command is received while in Standby

mode or in Idle and Recording Pause mode. No setting content update commands are accepted during system activation, error message indication, menu screen display, search screen display, playback, recording (Include Alarm Recording Setting’s Alarm is set to “VALID.”) or while in timer mode (DEL is returned).

5. When command operation cannot be performed, received data is discarded and any commands are

regarded as invalid.

16.1.2. Communication Protocol

Transfer System : Start/stop system (asynchronous system), duplex Parity Bit : Even Transfer Rate : 9,600, 19,200, 38,400 bps Code : Binary code Bit Length : 8 bits Flow Control : CTS/RTS handshaking, none Stop Bit : 1 Error Control : None

16.1.3. RS-232C Connector Pin Arrangement

The following table shows the signal name of each pin of the RS-232C D-sub 9P connector.

Signal Name

Pin No.

Unconnected

RXD (Received Data)

TXD (Transmitted Data)

Unconnected

GND

Unconnected

RTS (Request to send)

CTS (Clear to send)

Unconnected

Note: The plug for the RS-232C connector is not supplied with the Digital Video Recorder.

Use a cross cable for the RS-232C interface connection.

STX LEN COMMAND PARA DATA ETX

Item

1 1 2 2 Variable 1No. of Byte

STX : Fixed to A0H. LEN : The number of bytes from command to DATA COMMAND : BT, MS, MV, LG, SE*

PARA : Parameter*

DATA : DATA section (variable depending on a command and parameter) ETX : Fixed to AFH.

*1If communication data is transmitted, an ACK, NAK, or DEL signal is returned immediately after the data is

received. ACK (06H) : Correct reception NAK (15H) : Reception error DEL (7FH) : Invalid operation

16.1.5. RS-232C Communication Command (Controller Digital Recorder)

Commands are 2 bytes in length. Parameters (PARA) are also 2 bytes. They are followed by the multi-byte DATA section. If DATA LEN is "0," no DATA section follows.

Key's Commands

Command

PARA

ST RV PS RD DC

MN ON

PF SC QT

AL RS KH UP

LF RT

DATA LEN

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Operation Playback Key Playback Stop Key Reverse Playback Key Pause Key Recording Key Buzzer Stop Key Menu Key (Press Menu Key for 1 second or more) Start Internal Timer Recording (Press Timer key for 1 second or more) Standby Key ON Standby Key OFF Search Key Periodical Status Inquiry (Response returned) Alarm Operation Recording Stop Key (Press Recording Key for 1 second or more) Recording Start Operation Up Shift Key Down Shift Key – Key + Key Select Key

16.1.4. RS-232C Communication Format (Controller Digital Recorder)

Operation

0 – 4 (Level 5 – Level 1)

0 : OFF, 1 : ON 0:1/60, 1:1/30, 2:1/15, 3:1/10, 4:1/5, 5:1/3, 6:1/2, 7:1, 8:2, 9:3, A:5, B:10, C:20, D:30, E:60 0 – 9 (1,2,3,4,5,10,15,20,30,60) 0 – 9: Setting No.01 – 10 0:Cancel, 1:Daily, 2:Weekly First byte MM:1 – C, Second byte DD:1 – 1F BIT0:Sun, BIT1:Mon, BIT2:Tue, BIT3:Wed, BIT4:Thu, BIT5:Fri, BIT6:Sat First byte HH:0 – 17, Second byte MM:0 – 3B First byte HH:0 – 17, Second byte MM:0 – 3B 0 – 4 (Level 5 – Level 1)

0:OFF, 1:ON

0:1/60, 1:1/30, 2:1/15, 3:1/10, 4:1/5, 5:1/3, 6:1/2, 7:1, 8:2, 9:3, A:5, B:10, C:20, D:30, E:60 0:1, 1:2 0:1, 1:2 0: Invalid, 1:Valid, 2:Valid during recording (Val Rec) 0:Edge, 1:Level 0 – 7 (0Sec, 10Sec, 15Sec, 20Sec, 30Sec, 1Min, 2Min, 5Min) 0 – 9 (10Sec, 15Sec, 20Sec, 30Sec, 1Min, 2Min,, 3Min, 4Min, 5Min, 10Min) 0 – 7 (0Sec, 10Sec, 15Sec, 20Sec, 30Sec, 1Min, 2Min, 5Min) 0 – 4 (Level 5 – Level 1) 0:OFF, 1:ON 0:1/60, 1:1/30, 2:1/15, 3:1/10, 4:1/5, 5:1/3, 6:1/2, 7:1 0:OFF, 1:ON 0:During Alarm Recording, 1:1Second 0:Nomal, 1:Mirroring 0:Stop, 1:Re-Rec, 2:Series YYYY:7D0 – 833 (2000 – 2099 Year) MM: 1 – C (Jan – Dec Month) DD: 1 – 1F (1 – 31 Date) HH: 0 – 17 (00:00 – 23:00 Hour) MM: 0 – 3B (0 – 59 Minute) SS: 0 – 3B (0 – 59 Second) 0: Hide, 1:Display 0: Hide, 1:Display 0: Hide, 1:Display 0: Hide, 1:Display 0: Hide, 1:Display Disk Mode set to Nomal : 0:Hide, 1:Display Disk Mode set to Mirroring: 0:Hide, 1:Max, 2:Min, 3:HDD-A, 4:HDD-B 0: Hide, 1:Display 0: Hide, 1:Display 0:Upper Left, 1: Upper Center, 2:Upper Right, 3: Lower Left, 4: Lower Center, 5: Lower Right 0: Hide, 1:Display

0: 9600, 1: 19200, 2: 38400 bps 0:OFF, 1:ON 0:Master, 1:Slave 0 – 23 0:OFF, 1:ON, 2:Time Sync 0:All, 1:HDD-A, 2:HDD-B 0:Disallow, 1:Allow 0:OFF, 1:ON 1 – C:Jan – Dec Month 1:Fast, 2:Second, 3:Third, 4:Fourth, 5:Last 0 – 17:00 – 23 Hour 1 – C:Jan – Dec Month 1:Fast, 2:Second, 3:Third, 4:Fourth, 5:Last 0 – 17:00 – 23 Hour

Command

PARA

RC TM

AS AN AP AT

AF AQ AD

AI AB AO

WD WM

VQ VD

VR VP VG

VH VT VC

PR SU

SM SW

EM EW

DATA LEN

1 1

1 1 1 2 1

2 2 1

1 1 1 1 1 2

2 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1

1 1 1

1 1 1 1 1 1 1 1 1 1 1 1 1 1

Contents General Recording Setting Picture Quality General Recording Setting Audio General Recording Setting Recording Interval Switcher Control Period Setting Frame No. Timer Setting Mode Date Day of the week

Timer Start Time Timer End Time Internal Timer Recording Setting Picture Quality Internal Timer Recording Setting Audio Internal Timer Recording Setting Recording Interval Recording Pattern Motion Detection Pattern Alarm Setting Alarm Input Mode Pre-Alarm Period Alarm Recording Period

Post-Alarm Period Alarm Recording Picture Quality Alarm Recording Audio Alarm Recording Recording Interval Buzzer Sound Output Alarm Output Period Disk Mode (C-DR0101, C-DR0105) Recording Mode Date/Time Setting Year Date/Time Setting Month Date/Time Setting Date Date/Time Setting Hour Date/Time Setting Minute Date/Time Setting Sec Picture Quality Display Audio ON/OFF Display Re-Recording Mode Recording Mode Display Playback Display Remaining Time Display

Date Display Time Display Date/Time Display Position

Disk Mode Indication (C-DR0101, C-DR0105) Communication Rate Flow Control Time Synchronization Synchronized Time Switcher Synchronization Playback Mode Simultaneous Recording/Playback Summer Time Setting Summer Time First day Month Summer Time First day Sunday Summer Time First day Time Summer Time Last day Month Summer Time Last day Sunday Summer Time Last day Time

Menu Setting Commands

Note: Date/Time search is performed using setting data.

Operation

Request to send setting contents

Request to send setting contents Request to send setting contents

Request to send setting contents 0 – 9: Setting No., Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents (current time) Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents Request to send setting contents

Command

PARA

RC TM AS AN AP AT AF AQ AD

AI AB AO

WD WM

DT VQ VD

VR VP VG VH VT VC

PR SU

SM SW

EM EW

DATA LEN

0 0

0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Contents General Recording Setting Picture Quality General Recording Setting Audio General Recoding Setting Recording Interval Switcher Control Period Timer Setting Data Alarm Setting Alarm Input Mode Pre-Alarm Period Alarm Recording Period Post-Alarm Period Alarm Recording Picture Quality Alarm Recording Audio Alarm Recording Recording Interval Buzzer Sound Output Alarm Output Period Disk Mode (C-DR0101, C-DR0105) Recording Mode Clock Setting Data Picture Quality Display Audio Display Recording Mode Display Recording Display Playback Display Remaining Time Display Daily Display Time Display Date/Time Display Position Disk Mode Indication (C-DR0101,C-DR0105) Transmission Rate Flow Control Time Synchronization Synchronized Time Switcher Synchronization Playback Mode Playback during Recording Summer Time Setting Summer Time First day Month Summer Time First day Sunday Summer Time First day Time Summer Time Last day Month Summer Time Last day Sunday Summer Time Last day Time

Menu Setting Content Request Command

Operation Request for sending from the head of the most recent data Request for continued data Request for sending from the head of the most recent data Request for continued data Request for sending from the head of the most recent data Request for continued data

Command

PARA

AL AQ TR TQ

DATA LEN

0 0 0 0 0 0

Contents Request for Recording Log Next Request for Recording Log Request for Alarm Recording Log Next Request for Alarm Recording Log Request for Failure Logs Next Request for Failure Logs

Log Request Command

Operation

YYYY: 7D0 – 833

(2000 – 2099 Year) MM: 1 – C (Jan – Dec Month) DD: 1 – 1F (1 – 31 Date) HH: 0 – 17 (00:00 – 23:00 Hour) MM: 0 – 3B (0 – 59 Minute)

Command

PARA

DATA LEN

2 1 1 1 1

Contents Date/Time Search Year Date/Time Search Month Date/Time Search Date Date/Time Search Hour Date/Time Search Minute

Search Menu Execution Command

Command

16.1.7. RS-232C Communication Command (Digital Recorder Controller)

Commands are 2 bytes in length. Parameters (PARA) are also 2 bytes. They are followed by the multi-byte DATA section.

Key response command

Operation 0:Power OFF, 1:Power ON 0:Standby or Stop 1:Pause 2:Playback 3:Fast Forward Playback 4 Reverse Playback 5:Rewind

6.Menu or Search Screen Display 7:Disk Error or disk operation such as disk recognition 0:Standby or Stop 1:Recording 2:Alarm Recording 3:Internal Timer Recording 0: No failure 1: Hard disk failure 2: Video loss failure 3: Fan failure

PARA

DATA LEN

1 1

Contents Operation Status Status

Recording Status

Failure

16.1.6. RS-232C Communication Format (Digital Recorder Controller)

STX : Fixed to A0H. LEN : The number of bytes from command to DATA COMMAND : BT, MV, LG PARA : Parameter DATA : DATA section (variable depending on a command and parameter) ETX : Fixed to AFH.

STX LEN

COMMAND PARA DATA ETX

Item

1 1 2 2 Variable 1No. of Byte

Menu Setting Content Response Command

Operation

0 – 4 (Level 5 – Level 1)

0:OFF, 1:ON

Command

PARA

RC TM

AS AN AP AT

AF AQ AD

AI AB AO

WD WM

VQ VD

VR VP VG

VH VT VC

PR SU

SM SW

EM EW

DATA LEN

1 1

1 1 1 2 1

2 2 1

1 1 1 1 1 2

2 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1

1 1 1

1 1 1 1 1 1 1 1 1 1 1 1 1 1

Date Display Time Display Date/Time Display Position

Unit Host

Request for recording log

Transmission of recording log (DATA follows)

Request for next recording log

Transmission of next recording log (DATA follows)

Request for next recording log

Transmission of next recording log (No DATA follows)

Contents Data valid/invalid Year Month Date Time Minute Second Detailed Code

Continuation sign

Log Content Response Command

Shown below are log information DATA section (13 bytes) formats.

DATA LEN

1 2 1 1 1 1 1 4

Description of Data 0: Invalid, 1: Valid YYYY: 7D0 – 833 (2000 – 2099 Year) MM: 1 – C (Jan – Dec Month) DD: 1 – 1F (1 – 31 Date) HH: 0 – 17 (00:00 – 23:00 Hour) MM: 0 – 3B (0 – 59 Minute) SS: 0 – 3B (0 – 59 Second) RD/RQ mode: 0: Recording Start, 1:Recording End, 2:Internal Timer Recording Start,

3: Internal Timer Recording End AL/AQ mode: 0: Alarm Recording Start, 1: Alarm Recording End TR/TQ mode: 65 – C8 Video Failure, C9 – 12C: HDD Failure, 12D: Fan Failure FE:DATA follows, FF: No DATA follows

When transmitting log data, DATA contained in LEN (up to 255 bytes) is set in 13-byte units. If DATA’s 13th byte is a continuation sign (0xFE), DATA follows. If last DATA is a continuation sign, a continued log acquisition command becomes valid. Transmission format and transmitting/receiving sequence are as follows:

STX LEN COMMAND PARA DATA DATA

...........

ETXItem

112213 1

DATA

13No. of Byte

Operation 0 : No corresponding Data is present. 1 : Corresponding Data is present.

Command

PARASDDATA LEN

Contents Time Search Execution Result

Search menu result command

Note

This response is transmitted to a controller when an ACK signal has been returned in response to a SE command.

16.2. About the Ethernet Terminal

The Digital Video Recorder is equipped the Ethernet terminal (100BASE-TX). Use the LAN (crossing) cable to connect the Ethernet terminal to the PC.

Command

PARA

AL AQ TR TQ

DATA LEN

13 13 13 13 13 13

Contents Request for Recording Log Next Request for Recording Log Request for Alarm Recording Log Next Request for Alarm Recording Log Request for Failure Logs Next Request for Failure Logs

17. RACK MOUNTING

Use the optional MB-15B Rack Mounting Bracket when mounting the Digital Video Recorder in an equipment rack. Remove 4 rubber feet on the bottom surface by loosening their respective fixing screws with a standard screwdriver.

Note

• Use the Digital Video Recorder in locations with ambient temperature of between +5°C and +40°C

• Be sure to mount the Digital Video Recorder below the heat generating components, and mount the perforated panel between the Recorder and such a heat generating component as required.

• The Digital Video Recorder has a built-in cooling fan. Never block the Recorder’s ventilation slot.

• Avoid installing the Digital Video Recorder in locations exposed to vibration.

I D

A U

V E

A U

S E

P L

Y S T

R A

L E

C T

A R

R S T

I S

L I L

E L A

I G

E C

5 x 12 mm rack mounting screw (supplied with the MB-15B)

3 x 14 mm tapping screw (supplied with the MB-15B)

MB-15B (optional)

M5 fiber washer (supplied with the MB-15B)

Symptom

Cannot switch on the power.

Cannot operate the front panelmounted keys.

No picture is displayed.

The Recorder is not activated even if the Standby key is pressed.

The Recorder is not terminated even if the Standby key is pressed.

Cannot record.

Cannot stop recording.

Cannot perform Internal Timer recording.

Cannot perform Alarm recording.

No voice or sound recorded.

Cannot perform search and playback.

No screen indication displayed.

On-screen time is not accurate.

System failure indicator does not extinguish.

The indication "Disk may have failed" is displayed on the screen.

Possible Cause

• The supplied power cord is not connected to the Digital Video Recorder’s Power inlet and wall AC outlet.

• Keys are locked.

• Power is not switched on.

• Cables are not correctly connected.

• Main power is not switched on.

• The Standby key is not continuously pressed for 1 second or more.

• Recording mode is set to "STOP" and no available hard disk time remains.

• Key Lock is set to ON.

• The Recorder is in General recording mode.

• Incorrect timer setting.

• Recording mode is set to "SERIES."

• Alarm input cord not correctly connected.

• Alarm not set to "VALID."

• Each Recording Mode Audio Setting selection not set to ON.

• Hard disk is initialized.

• Not recorded on the hard disk.

• Playback during Recording is set to "OFF."

• Display setting set to "HIDE."

• Time not adjusted.

• Power was switched off for a long period of time.

• Check to confirm the contents of failure log (refer to p. 25).

• Hard disk format data may have been damaged.

• Hard disk may have failed. Referring to p. 28; "When the Failure Screen is displayed," check the symptom.

• Connect the power cord.

• Release Key Lock.

• Switch on the power.

• Connect the cable correctly.

• Switch on the main power.

• Hold down the Standby key for 1 second or more.

• Change the Overwrite Recording setting to "RE-REC" or "SERIES."

• Reset Key Lock

• Stop General recording and press the Timer key.

• Set timer operating times correctly.

• Change the Recording mode to "STOP" or "RE-REC."

• Connect cords correctly.

• Set the Alarm setting to "VALID."

• Set Audio setting to "ON."

• Search and playback cannot be performed without recording data. Perform recording.

• Playback cannot be performed during recording. Set the Playback during Recording selection to "ON"

• Set Display setting to "DISP."

• Adjust times.

• If no main power is supplied continuously for 30 days or more, clock data will be lost. In such cases, update times again.

• Remove the cause of the failure.

• If the situation cannot be improved, contact your TOA dealer.

Remedy

18. IF YOU THINK THERE IS A FAILURE: (TROUBLESHOOTING)

Model Power Source Power Consumption Image Compression System Recording Medium

Video Input Video Output

Switcher Video Input Switcher Video Output Audio Recording System Audio Input Audio Output

Frequency Response Alarm Input

Alarm Output

Picture Quality

Pixels Recording Intervals Pre-Alarm Recording Alarm Recording Post Alarm Recording Date/Time

Internal Timer Recording Search Function System Failure Output

Control Input Terminal

Control Output Terminal

Communication Function Memory Backup Operating Temperature Operating Humidity Finish

Dimensions Weight Accessories Optional Equipment

C-DR0100 C-DR0101 C-DR0105

110 – 120 V AC 50/60 Hz

24 W (450 mA) 35 W (640 mA) 37 W (670 mA)

Motion JPEG

E-IDE Hard Disk E-IDE Hard Disk E-IDE Hard Disk

120 GB (120 GB x 1)

240 GB (120 GB x 2) 500 GB (250 GB x 2)

1 Input VBS1.0 V(p-p), 75Ω, BNC Front: 1 Output VBS1.0V(p-p), 75Ω, RCA pin jack Rear: 1 Output VBS1.0V(p-p), 75Ω, BNC 1 Input VBS1.0V(p-p), 75Ω, BNC 1 Output VBS1.0V(p-p), 75Ω, BNC 8 bits, Linear PCM, sampling frequency: 16 KHz

1 Input, –10 dB*, 10 kΩ, RCA pin jack Front: 1 Output, –10 dB*, 600 Ω, RCA pin jack Rear: 1 Output, –10 dB*, 600 Ω, RCA pin jack 300 – 6,000 Hz 1 Input (EDGE, LEVEL), no-voltage make contact input, open voltage: 2 VDC, short-circuit current: 0.5 mA, loop resistance: under 100Ω, screwless connector 1 output, open collector output, withstand voltage: 30 VDC, control current : 20 mA, screwless connector Changeable in 5 steps, File size: 64 KB (LEVEL1), 40 KB (LEVEL2), 32 KB (LEVEL3), 24 KB (LEVEL4), 16 KB (LEVEL5) 720 x 240 (fixed) 15 steps (1/60, 1/30, 1/15, 1/10, 1/5, 1/3, 1/2, 1, 2, 3, 5, 10, 20, 30, 60 sec) 0 sec, 10 sec, 15 sec, 20 sec, 30 sec, 1 min, 2 min, 5 min 10 sec, 15 sec, 20 sec, 30 sec, 1 min, 2 min, 3 min, 4 min, 5 min, 10 min (Edge mode) 0 sec, 10 sec, 15 sec, 20 sec, 30 sec, 1 min, 2 min, 5 min (Level mode)

Year/ month/ date/ hour/ minute/ sec, 24-hours format display, monthly deviation of within ±30 seconds (25°C), can be operated until the leap year 2099, summer time settings 10 independent programs (date, daily, weekly, designated day-of-the-week) recording interval, start and end times, picture quality, and audio on-off can be set. Date/Time search, Block search, Time Shift search 1 output (HDD failure, Video loss, Fan failure) open collector output withstand voltage: 30 VDC, control current: 20 mA, screwless connector alarm reset, recording start, recording stop, clock synchronization no-voltage make contact input, open voltage: 2 VDC, short-circuit current: 0.5 mA, loop resistance: under 100 Ω, screwless connector alarm reset, clock synchronization, disk full : open collector output, withstand voltage: 30 VDC, control current: 20 mA, screwless connector switcher control: TTL level negative logic pulse, pulse width over 17 ms, screwless connector RS-232C (External control function) D-sub connector (9 pin, male) 100 BASE-TX Ethernet terminal 720 hours (fully charged), clock data retention +5°C to +40°C Under 80% RH (no dew condensation) Panel: Aluminum extrusion, black, 30% gloss Case: Surface treated steel plate, black, 30% gloss 420 (W) x 53.8 (H) x 331 (D) mm

4.5 kg 5.3 kg 5.3 kg Power supply cord (2 m) … 1 Rack mounting bracket: MB-15B

Note: The Digital Video Recorder’s specifications and external designs are subject to change without notice.

* 0dB = 1V

19. SPECIFICATIONS

Printed in Japan 133-12-914-0B

Toshiba C-DR0101 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
