Toshiba BDX2000KU User Manual

Blu-ray Disc Player

BDX2000KU

OWNER’S MANUAL

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Owner’s Record

The model number and serial number are on the back of this unit. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this unit.

Model number: Serial number :

Safety Instructions

INTRODUCTION

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sucient magnitude to constitute a risk of electric shock to persons.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note is located on the rear or bottom of the cabinet.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

The symbol for CLASS ll (Double Insulation)

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Additional Safety Instructions

15. Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a risk of re or

electric shock.

16. Apparatus shall not be exposed to dripping or splashing and no objects lled with liquids, such as vases, shall be placed on the apparatus.

17. Keep your ngers well clear of the disc tray as it is closing. Neglecting to do so may cause serious personal injury.

18. Do not place a heavy object on or step on the apparatus. The object may fall, causing serious personal injury and

serious damage to the apparatus.

19. Do not use a cracked , deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and apparatus malfunction.

20. If the apparatus should smoke or smell, immediately disconnect the power cord from the wall outlet. Wait until the smoke or smell stops, then ask your dealer for a check and repair. Neglecting to do so may cause re.

21. While it is thundering, do not touch the connecting cables or the apparatus.

22. Warning: To prevent the spread of re, keep candles or other open ames away from this product at all times.

23. Disconnect the mains plug to shut o when nd trouble or not in use. The mains plug shall remain readily operable.

2EN

INTRODUCTION

FCC WARNING

This equipment may generate or use radio frequency energy. Changes or modications to this equipment may cause harmful interference unless the modications are expressly approved in the manual. The user could lose the authority to operate this equipment if an unauthorized change or modication is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

ALWAYS plug the product into an outlet that is located in such a manner that it can be easily unplugged in case the product requires service.

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. WARNING:

Batteries (Battery pack or battery installed) shall not be exposed to excessive heat such as sunshine, re, or the like.

INTRODUCTION C

ONNECTIONS

LAYBACK

UNCTION

LASER SAFETY

This apparatus employs a laser. Only a qualied service person should remove the cover or attempt to service this apparatus, due to possible eye injury.

CAUTION: Use of controls or adjustments or performance of procedures other than those specied herein may

result in hazardous radiation exposure.

CAUTION: Visible and invisible laser radiation when open and interlocks defeated. Do not stare into beam.

LOCATION:

Inside, near the deck mechanism.

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling unit can cause serious injury or even death.

To Avoid the Hazards of Electrical Shock and Fire

Do not handle the AC power cord with wet hands.

• Do not pull on the AC power cord when disconnecting it from an AC outlet. Grasp it by the plug.

• Do not put your ngers or objects into the unit.

•

Location and Handling

•

Do not install the unit in direct sunlight, near strong magnetic elds, or in a place subject to dust or strong vibration.

•

Avoid a place with drastic temperature changes.

•

Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit. Depending on your external devices, noise or disturbance of the picture and/or sound may be generated if the unit is placed too close to them. In this case, please ensure enough space between the external devices and the unit.

•

Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.

•

Be sure to remove the disc and unplug the AC power cord from the outlet before carrying the unit.

SETUP

THERS

Dew Condensation Warning

Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for a few

• hours until its inside gets dry.

- The unit is moved from a cold place to a warm place.

- Under conditions of high humidity.

- After heating a cold room.

3EN

INTRODUCTION

Note about Recycling

This unit’s packaging materials are recyclable and can be reused. Please dispose of any materials in

•

accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local

•

regulations concerning chemical wastes.

Notice for Progressive Scan Output

Consumers should note that not all high denition television sets are fully compatible with this product and may

•

cause artifacts to be displayed in the picture. In case of picture problems with 525(480) progressive scan output, it is recommended that the user switch the connection to the ‘standard denition’ output. If there are questions regarding your TV set compatibility with this 525p(480p) BD/DVD player, please contact Toshiba Customer Service.

Products that earn the ENERGY STAR® prevent greenhouse gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and the U.S. Department of Energy. ENERGY STAR and the ENERGY STAR mark are registered U.S.marks.

MPEG Layer - 3 audio coding technology licensed from Fraunhofer IIS and Thomson.

Because of problems and errors that can occur during the creation of DVD and CD software and / or the manufacture of DVD and CD discs, Toshiba cannot assure that this Blu-ray Disc Player will successfully play every disc bearing the DVD and CD logos. If you happen to experience any difficulty playing a DVD and / or CD disc on this Blu-ray Disc Player, please contact Toshiba Customer Service.

Supplied Accessories

remote control with batteries (AAx2)

OWNER’S MANUAL

owner’s manual (EN/ES) quick start guide (EN/ES)

composite audio / video cables

Symbols Used in this Manual

To specify for which media type each function is, we put the following symbols at the beginning of each item to operate.

Symbol Description

Description refers to BD-video and BD-RE (ver.2.1) / BD-R (ver.1.1/1.2/1.3) recorded in BDMV format

Description refers to DVD-video

Description refers to audio CD / DTS-CD

Description refers to DVD-RW/-R and SD Memory Card with AVCHD files

Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD Memory Card with MP3 files

Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD Memory Card with Windows Media™ Audio files

Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD Memory Card with JPEG files

If you do not find any of the symbols listed above under the function heading, the operation is applicable to all media.

4EN

Trademark Information

INTRODUCTION

INTRODUCTION C

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929; 7,212,872 & other U.S. and worldwide patents issued & pending. DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio | Essential are trademarks of DTS, Inc. ©1996-2008 DTS, Inc. All Rights Reserved.

“x.v.Color” and “x.v.Color” logo are trademarks of Sony Corporation.

“BD-LIVE” logo is trademark of Blu-ray Disc Association.

Java and all other Java trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and/or other countries.

Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

is trademark of Eastman Kodak Company.

ONNECTIONS

LAYBACK

UNCTION

SETUP

THERS

“Blu-ray Disc” and are trademarks.

is a trademark of DVD Format/Logo Licensing

Corporation.

“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

“BONUSVIEW” is trademark of Blu-ray Disc Association.

5EN

Content

INTRODUCTION

Safety Instructions ........................................................................2

Supplied Accessories ...................................................................4

Symbols Used in this Manual....................................................4

Trademark Information...............................................................5

Features ............................................................................................7

Front Panel.......................................................................................8

Rear Panel.........................................................................................8

Remote Control..............................................................................9

Front Panel Display....................................................................11

CONNECTIONS

Connection to the TV................................................................ 12

Connection to an Audio System ........................................... 14

Network Connection with LAN .............................................15

Finding the Video Channel on Your TV.............................. 16

PLAYBACK

Information on Playback.......................................................... 17

How to Insert a Disc................................................................... 20

Reading an SD Memory Card................................................. 20

Selecting the Media................................................................... 21

Playing Back (BD, DVD or a Disc with AVCHD files)........ 22

Playing Back (Audio CD or a Disc with MP3/

Windows Media™ Audio/JPEG Files) ................................23

Kodak Picture CD........................................................................24

Fast Forward / Fast Reverse.................................................... 25

Slow Motion Playback ..............................................................25

Step by Step Playback ..............................................................26

Repeat Playback.......................................................................... 26

A-B Repeat ....................................................................................26

Program Playback ......................................................................26

Random Playback....................................................................... 27

Rapid Playback ............................................................................28

Adjusting the Picture ................................................................28

Virtual Surround.......................................................................... 28

PIP (BONUSVIEW) Setting........................................................ 29

Camera Angle ..............................................................................29

Enjoying BD-Live Discs with Online Content ...................29

Search............................................................................................. 30

Switching Subtitles.................................................................... 31

Switching Audio Soundtrack .................................................31

Setting the BD Audio Mode.................................................... 32

FUNCTION SETUP

Using the Setup Menu ..............................................................33

Quick.........................................................................................33

Custom ....................................................................................34

Language ............................................................................35

Video ....................................................................................36

Audio ....................................................................................38

Parental ...............................................................................43

Others ...................................................................................44

Network Connection .................................................................46

Connection Test ....................................................................46

Enable(Easy)............................................................................46

Enable(Custom).....................................................................46

Disable ......................................................................................49

Software Update .........................................................................49

Current Version......................................................................49

Disc Update.............................................................................49

Initialize ....................................................................................50

OTHERS

Troubleshooting..........................................................................51

Glossary ..........................................................................................53

Language Code List....................................................................55

Specifications ...............................................................................56

Maintenance.................................................................................57

LIMITED WARRANTY ..................................................................58

6EN

INTRODUCTION

Features

Blu-ray Disc

You can enjoy Blu-ray Disc which is capable of storing five times more data than a conventional DVD.

BD-Java

With some BDs which support Java applications, you can enjoy the interactive functions such as games or interactive menus.

BD-Live

BD-Live (BD-ROM version 2 Profile 2.0) that allows interactive functions to be used when this unit is connected to the Internet in addition to the BONUSVIEW function. The various functions differ depending on the disc.

Full high-definition video playback

Watch movies in the highest picture quality available for your HDTV. This unit offers full high-definition video playback up to 1080p resolution for an amazing viewing experience. A highly detailed picture and increased sharpness delivers a more trueto-life picture.

DVD Upconversion for enhanced picture quality

Your current DVD will look even better than before thanks to video upconversion. Upconversion will increase the resolution of standard definition DVD to high definition up to 1080p over an HDMI connection. The picture will be less jagged and more realistic for a near high-definition experience.

Enjoy your content on different kinds of media

Full backwards compatibility with BD, DVD, CD and SD card ensures that you can continue to enjoy your current audiovideo collection. Additionally, you can view JPEG digital pictures or listen to MP3 or Windows Media™ Audio music files.

Experience rich multi-channel surround sound

Multi-channel surround sound, which recognizes real-to-life sound and makes you feel like you are really there.

PIP (BONUSVIEW)

Some BD-videos have the PIP function which enables you to display the secondary video in the primary video. You can call up the secondary video by pressing [PIP] whenever the scene contains the secondary video.

Pop-up menu

Some BD-video have pop-up menu which is a navigation menu that can be called up and be operated on the TV screen without interrupting the playback. You can call up the pop-up menu by pressing [POP MENU / MENU]. Contents in the pop-up menu vary depending on the disc.

Rapid playback

Playback in slightly faster speed while keeping the sound output. Rapid playback is available only on discs recorded in the Dolby Digital format.

Playing back

This unit supports playback of AVCHD format files (new format for high definition video camcorders) recorded on disc/SD card. Your high definition personal archive is playable in HD quality.

x.v.Color

This unit supports playback of video contents on discs recorded with “x.v.Color” technology. To watch this video content with the “x.v.Color”, a TV or other display device supporting both video image reproduction using the “x.v.Color” standard and capable of manually switching it’s color setting is required. Please refer to the owner’s manual of your display device for further information.

AVCHD files

Easy and simple connection to your HDTV via HDMI

Connect this unit to your HDTV with one single HDMI (HighDefinition Multimedia Interface) cable. It is recommended to use a High Speed HDMI Cable for better compatibility. The high definition video output signal will be transferred to your HDTV without conversion to analog signals, so you will get excellent picture and sound quality, completely free from noise. Thanks to other multiple outputs, you can also easily connect to your home theater system or amplifier.

HDMI Deep Color

Deep Color reduces the posterization effect of the playback image. Refer to “HDMI Deep Color” in “FUNCTION SETUP” on page 36.

HDMI CEC (Consumer Electronics Control)

This unit supports HDMI CEC, which allows integrated system control over HDMI and is part of the HDMI standard. This function may not work properly on some devices.

HDMI 1080p24 output (BD only)

This unit is equipped with a feature which can provide the smooth movement in the playback of film originated material with the frame rate of 24 frames per second with progressive scan. (Available only when the TV is connected by an HDMI cable and compatible with 1080p24 frame input.) Refer to “HDMI Video Resolution” in “FUNCTION SETUP” on page 36.

To play back the digital video images of a BD / DVD via an HDMI connection, it is necessary that both the unit and the TV (or an AV amplifier) support a copyright protection system called HDCP (high-bandwidth digital content protection system). HDCP is copy protection technology that comprises data encryption and authentication of the connected AV device. This unit supports HDCP. Please read the operating instructions of your TV (or AV amplifier) for more information.

INTRODUCTION C

ONNECTIONS

LAYBACK

UNCTION

SETUP

THERS

Playback of Content from an SD Memory Card

You can play back AVCHD / MP3 / WMA / JPEGs stored in an SD Memory Card. You can store picture-in-picture commentary, subtitles or other extras for BD-ROM ver. 2 (Profile 2.0 / Profile 1.1) files in an SD Memory Card and play back with the BD-video.

7EN

Front Panel

INTRODUCTION

ON/STANDBY

(*) The unit can also be turned on by pressing these buttons.

4 5* 7 8 96*

PAUSE STOP PLAY

OPEN/CLOSE

1. ON/STANDBY Q button

• Press to turn on the unit, or to turn the unit into the standby mode. (To completely turn off the unit, you must unplug the AC power cord.)

2. ON/STANDBY Q indicator

3. PAUSE F button

4. STOP C button

Rear Panel

5. PLAY B button*

6. OPEN/CLOSE A button*

7. Disc tray

8. Display

• Refer to “Front Panel Display” on page 11.

9. Infrared sensor window

10. SD card slot

PR/C

PB/C

COMPONENT

VIDEO OUT

COAXIALOPTICAL

AUDIO

HDMI

LAN

DIGITAL OUT

OUT

PCM/BITSTREAM

VIDEO

OUT

1. LAN terminal

• Use to connect a network equipment with LAN cable.

2. HDMI OUT jack

• Use to connect a TV with an HDMI compatible port using an HDMI cable.

3. AUDIO OUT jacks

• Use to connect a TV, an AV receiver / amplifier or other device with a composite audio cable.

4. COMPONENT VIDEO OUT jacks

• Use to connect a TV with component video inputs with a component video cable.

5. AC power cord

• Connect to a standard AC outlet to supply power to this unit.

• Unplug this cord from the AC outlet to completely turn off the unit.

6. DIGITAL OUT (OPTICAL / COAXIAL) jacks

• Use to connect an AV receiver / amplifier, Dolby Digital / DTS decoder or other device with a digital audio optical / coaxial input jack with a digital audio optical / coaxial cable.

7. VIDEO OUT jack

• Use to connect a TV, an AV receiver or other device with a composite video cable.

Note

• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

8EN

INTRODUCTION

Remote Control

8 9

11*

(*) The unit can also be turned on by pressing these buttons.

1. HDMI button

• Press to set the HDMI output mode.

2. OPEN/CLOSE A button*

• Press to open or close the disc tray.

3. Number buttons

• Press to enter the title, chapter, track or file number.

• Press to enter values in the input field.

4. SEARCH button

• Press to display the search menu.

5. RED / GREEN / BLUE / YELLOW button

• Press to select items on some BD contents.

• When file list / thumbnail list is shown, press to switch between pages.

6. TOP MENU button

• Press to display the top menu.

7. K / L / s / B buttons

• Press to select items or settings.

8. SETUP button

• Press to display the setup menu.

9. REV E button

• During playback, press to fast reverse the playback.

10. SKIP H button

• During playback, press once to return to the beginning of the current title, chapter, track or file.

• During playback, press twice to return to the previous title, chapter, track or file.

• During the JPEG playback, press to return to the previous file.

11. PLAY B button*

• Press to start playback or resume playback.

19 20

23 24

26 27

12. MODE button

• During BD, DVD or AVCHD playback, press to display the setting for the rapid playback and the picture adjustment.

• During BD, DVD, CD, AVCHD, MP3 and WMA playback, press to display the setting for the virtual surround.

• During BD playback, press to turn the picture-inpicture feature on or off (only applicable to BD-video which supports the PIP function).

• During the JPEG playback, press to display menus for changing the visual effect for switching the image or changing the size of the image.

• In stop mode with BD inserted, press to display a menu for setting the BD audio mode.

• In stop mode with audio CD or MP3 / WMA / JPEG files inserted, press to display menus for program and random playback.

13. REPEAT button

• Press to toggle between various repeat modes.

14. PIP button

• Press to switch picture-in-picture feature on or off (only applicable to BD-video which supports the PIP function).

15. ON/STANDBY Q button

• Press to turn on the unit, or to turn the unit into the standby mode. (To completely turn off the unit, you must unplug the AC power cord.)

16. ANGLE button

• Press to access various camera angles on the disc.

• Press to rotate the JPEG files clockwise by 90 degrees.

17. AUDIO button

• Press to display the audio menu.

18. SUBTITLE button

• Press to display the subtitle menu.

19. DISPLAY button

• Press to display the on-screen display menu.

20. CLEAR button

• Press to clear the information once entered or to cancel the programming for audio CD, etc.

21. POP MENU / MENU button

• Press to display the pop-up menu / disc menu.

22. ENTER button

• Press to confirm or select menu items.

23. RETURN button

• Press to return to the previously displayed menu screen.

24. FWD D button

• During playback, press to fast forward the playback.

• In pause mode, press to slow motion the playback.

25. SKIP G button

• During playback, press to skip to the next title, chapter, track or file.

26. STOP C button

• Press to stop playback.

27. PAUSE F button

• Press to pause playback.

• When playback is in pause mode, press repeatedly to forward the playback step by step.

28. A-B button

• Press to play back a defined section between point A and B repeatedly.

INTRODUCTION C

ONNECTIONS

LAYBACK

UNCTION

SETUP

THERS

9EN

INTRODUCTION

Installing the Batteries in the Remote Control

Install the batteries (AAx2) matching the polarity indicated inside battery compartment of the remote control.

1) Open the cover.

2) Insert batteries.

Using a Remote Control

Keep in mind the following when using the remote control:

• Make sure that there are no obstacles between the remote control and the infrared sensor window on the unit.

• Remote operation may become unreliable if strong sunlight or fluorescent light is shining on the infrared sensor window of the unit.

• Remote control for different devices can interfere with each other. Avoid using remote control for other device located close to the unit.

• Replace the batteries when you notice a fall off in the operating range of the remote control.

• The maximum operable ranges from the unit are as follows.

- Line of sight: approx. 23 feet (7 m)

Either side of the center:

- Above: approx. 16 feet (5 m) within 15°

- Below: approx. 10 feet (3 m) within 30°

PAUSE STOP PLAY

OPEN/CLOSE

ON/STANDBY

approx. 16 feet (5 m) within 30°

30˚30˚

16 feet (5 m)

23 feet (7 m)

16 feet (5 m)

Make sure to match + and - on the batteries to the marks indicated in the battery compartment.

3) Close the cover.

Note

Incorrect use of batteries can result in hazards such as leakage and bursting. Please observe the following:

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together. Although they may look similar, different batteries may have different voltages.

• Make sure that the + and - ends of each battery match the indications in the battery compartment.

• Remove batteries from battery compartment that are not going to be used for a month or more.

• When disposing of used batteries, please comply with governmental regulations or environmental public rules that apply in your country or area. (Refer to page 4.)

• Do not recharge, short-circuit, heat, burn or disassemble batteries.

10 EN

Front Panel Display

1 2

INTRODUCTION

INTRODUCTION C

ONNECTIONS

* Brightness of the display can be adjusted. Refer to “Panel Display” in “FUNCTION SETUP” on page 44.

1. Displays repeat icon. (Appears during repeat playback.)

2. Displays media icon (disc mode or SD card mode).

3. Displays playback status icon. Refer to the table below.

4. Displays various kinds of information such as title number, elapsed playing time, repeat type, menu type, etc.

Playback status icon Mode

Playback is in progress

Stop mode

Pause mode

Fast forward mode

Fast reverse mode

Slow motion mode

LAYBACK

UNCTION

SETUP

THERS

Example of Display Message

Title is being played back. Indicating the current title number and the elapsed time.

Current chapter is in chapter repeat mode.

Loading a disc.

Dolby Digital audio is being played back.

DTS audio is being played back.

11EN

Connection to the TV

Choose the appropriate connection, then proceed to the corresponding

instruction (A, B or C) on the next page.

CONNECTIONS

Best

No analog audio connection required.

HDMI Cable NOT INCLUDED High Speed HDMI Cable (also known as HDMI category 2 cable) is recommended for better compatibility.

Better

(Supports up to 1080i / 1080p, 1080p24 resolution.)

Video Audio

HDMI cable

HDMI IN

(Supports up to 1080i resolution.)

Video

component video cable

COMPONENT

VIDEO IN

PB/CB

PR/CR

Your TV

High

Definition

Your TV

High

Definition

Go To

Line Eithe Abo Belo

Audio

Component Video Cables NOT INCLUDED

Basic

Video

Audio

• Connect this unit directly to the TV. If the composite audio / video cables are connected to a VCR, pictures may be distorted due to the copy right protection system.

Composite Audio / Video Cables included

composite audio cable

(Supports only 480i resolution.)

composite video cable

composite audio cable

AUDIO IN

VIDEO IN

AUDIO IN

Your TV

Standard

Definition

Go To

12 EN

CONNECTIONS

Connect the cables by following the descriptions below.

NTRODUCTION

HDMI Video / Audio Connection

Your TV

02#

0#-")4342%!-

0"#

#/!8)!,/04)#!,

!5$)/

6)$%/

#/-0/.%.4

$)')4!,/54

/54

6)$%//54

HDMI cable

HDMI IN

($-)

/54

($-)

,!.

/54

Note

• Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the

connector are matched.

• When using non-HDCP compatible TV, the image will not display properly.

Component Video + Standard Audio Connection

02#

0"#

#/!8)!,/04)#!,

!5$)/

6)$%/

($-)

,!.

/54

0#-")4342%!-

#/-0/.%.4

$)')4!,/54

/54

6)$%//54

Your TV

CONNECTIONS P

LAYBACK

UNCTION

SETUP

THERS

02#

!5$)/

/54

0"#

#/-0/.%.4

6)$%//54

composite audio cable

Standard Video + Standard Audio Connection

($-)

,!.

/54

0#-")4342%!-

02#

0"#

#/!8)!,/04)#!,

!5$)/

6)$%/

#/-0/.%.4

$)')4!,/54

/54

6)$%//54

composite video cable

!5$)/

/54

6)$%/

composite audio cable

component video cable

COMPONENT

VIDEO IN

PR/CR

PB/CB

VIDEO IN

AUDIO IN

Your TV

AUDIO IN

13EN

CONNECTIONS

Connection to an Audio System

• When you change the connections, all devices should be turned off.

• Refer to the manual accompanying external devices for more information.

2-Channel Analog Audio Connection Digital Audio Connection

stereo system

Analog audio input jacks

PR/C

PB/C

COAXIALOPTICAL

AUDIO

DIGITAL OUT

PCM/BITSTREAM

VIDEO

COMPONENT

OUT

VIDEO OUT

HDMI

LAN

OUT

AUDIO OUT

HDMI Audio Connection

audio

HDMI IN

AUDIO IN

audio

composite

audio cable

this unit

HDMI

LAN

OUT

AUDIO

OUT

AV receiver / amplifier with an HDMI input jack

HDMI cable

AV receiver / amplifier

DIGITAL AUDIO INPUT

OPTICAL

DIGITAL AUDIO INPUT

COAXIAL

digital audio optical / coaxial input jack

DIGITAL OUT

PCM/BITSTREAM

COAXIALOPTICAL

AUDIO

digital audio optical cable

PR/C

PB/C

VIDEO

COMPONENT

OUT

VIDEO OUT

DIGITAL OUT

PCM/ BITSTREAM

COAXIALOPTICAL

digital audio coaxial cable

DIGITAL OUT (OPTICAL / COAXIAL)

To set up “Digital Out”, refer to page 40.

this unit

PR/C

PB/C

COAXIALOPTICAL

AUDIO

DIGITAL OUT

PCM/BITSTREAM

VIDEO

COMPONENT

OUT

VIDEO OUT

HDMI

LAN

OUT

To set up “HDMI Audio Out”, refer to pages 38 and 39.

Digital Audio Optical / Coaxial Cable and HDMI Cable NOT INCLUDED

HDMI

OUT

14 EN

CONNECTIONS

Network Connection with LAN

• You can use a disc which offers BD-Live function by connecting the unit to the Internet. (For BD-Live information, please refer to page 29.)

NTRODUCTION

Networking equipment

(modem, etc.)

Hub or broadband router

LAN

LAN cable

WAN LAN

12345

LAN cable

Internet

this unit

LAN

PR/C

PB/C

COAXIALOPTICAL

AUDIO

DIGITAL OUT

PCM/BITSTREAM

VIDEO

COMPONENT

OUT

VIDEO OUT

HDMI

LAN

OUT

Networking Equipment, Hub or Broadband Router and Cables NOT INCLUDED

Note

• After connecting a LAN cable, set up necessary network settings.

• Do not insert any cable other than a LAN cable to the LAN terminal to avoid damaging the unit.

• If your network equipment (modem, etc.) does not have broadband router functions, connect a broadband router.

• If your network equipment (modem, etc.) has broadband router functions but there is no vacant port, use a hub.

• For a broadband router, use a router which supports 10BASE-T/100BASE-TX.

• Do not connect your PC directly to the LAN terminal of this unit.

• For the network setup, refer to “Network Connection” on pages 46-49.

CONNECTIONS P

LAYBACK

UNCTION

SETUP

THERS

15EN

CONNECTIONS

After you have completed all the connections, you must find the correct video channel (external input channel) on your TV.

Finding the Video Channel on Your TV

After you have made all the necessary connections, press [ON/STANDBY Q] to turn

on the unit.

Turn on your TV.

Press the button on the TV’s remote control that accesses the external input

channel. It may be labeled “SOURCE”, “AV” or “INPUT” (refer to your TV’s user manual).

Note

• If the TV is connected by an HDMI cable, please allow a few moments for the opening screen to display.

16 EN

PLAYBACK

Information on Playback

Before you start playing back a disc, read the following information.

Playable Discs and Files

This unit is compatible to play back the following discs / files. To play back a disc / file, make sure that it meets the requirements for region codes and color systems as described below. You can play back discs that have the following logos. Other disc types are not guaranteed to play back.

Playable discs Logos

Blu-ray Disc

- BD-video (single / dual layer)

- BD-RE ver. 2.1 (single / dual layer) (Recorded in BDMV format)

- BD-R ver. 1.1 / 1.2 / 1.3 (single / dual layer) (Recorded in BDMV format) (Unclosed discs may not be played back.)

DVD-video

DVD-RW

DVD-R

CD-DA (audio CD)

CD-RW

• This unit cannot play back the disc contents protected by Windows Media™ Digital Rights Management (DRM).

SD Memory Card (8 MB - 2 GB) AVCHD, MP3, Windows SDHC Memory Card (4 GB - 8 GB) miniSD Card (8 MB - 2 GB)

microSD Card (8 MB - 2 GB)

Note for SD Memory Cards

• This unit supports SD Memory Card with FAT12/

FAT16 file system, and SDHC Memory Card with FAT32 file system.

• This unit does not support NTFS file system.

• This unit may not read the SD Memory Cards

formatted on a computer. If that is the case, please reformat the SD Memory Cards in this unit and try again.

• This unit does not support miniSDHC and microSDHC

Memory Card.

• For miniSD Card and microSD Card, the adapter is

necessary.

• Portions of this product are protected under

• Please keep the SD Memory Cards in their cases when

you are not using them.

• Do not try to open or modify the card.

• Do not touch the terminal surface with your fingers or

any metals.

• Do not attach additional labels or stickers to cards.

• Do not remove the label of the SD Memory Cards.

• This unit recognizes up to 8 characters of file name in

the SD Memory Card. Characters after 8th will not be displayed.

Readable cards Playable files / data

Media™ Audio, JPEG, picture-in-picture commentary, subtitles or other extras for BD-ROM Profile 1 ver.1.1

miniSD Card adapter

miniSD Card

microSD Card adapter

microSD Card

NTRODUCTION

ONNECTIONS

PLAYBACK F

UNCTION

SETUP

THERS

CD-R

Kodak Picture CD

DTS-CD

Playable files Media

AVCHD

MP3

Windows Media™ Audio

JPEG

DVD-RW/-R, SD Memory Card (including SDHC), miniSD Card, microSD Card

BD-RE/-R, DVD-RW/-R, CD-RW/-R, SD Memory Card (including SDHC), miniSD Card, microSD Card

Unplayable Discs and Files

The following discs will not be played back in this unit.

• CD-ROM • CD-I (compact disc-interactive)

• DVD-RAM • VSD (video single disc)

• DVD-audio • Video CD

• HD DVD • SVCD

• Unfinalized disc

• BD-RE (ver.1.0)

• BD-RE (ver.2.1) (Recorded in BDAV format)

• BD / DVD / SD Memory Card contains DivX

files.

• BD / DVD hybrid disc (played back as a BD-video only)

• BD that contains AVCHD files

• BD-R (ver.1.1 / 1.2 / 1.3) (Recorded in BDAV format)

• DVD-RW/-R recorded in non compatible recording format.

• Super Audio CD - Only the sound on the CD layer can be heard. The sound on the high-density Super Audio CD layer cannot be heard.

• Playability of dual discs are not guaranteed.

17EN

PLAYBACK

Color Systems

BD-video and DVD-video are recorded in different color systems throughout the world. The most common color system is NTSC (which is used primarily in the United States and Canada). This unit employs NTSC color system, so the disc you play back must be recorded in the NTSC system. You cannot play back the disc recorded in other color systems.

Region Codes

This unit has been designed to play back BD-video with region “A” and DVD-video with region “1” or “ALL”. You cannot play back BD-video or DVD-video that are labeled for other regions. Look for the symbols on the right on your BD-video or DVD-video. If these region symbols do not appear on your BD-video or DVD-video, you cannot play back the disc in this unit. The letter or number inside the globe refers to region of the world. A BD-video or DVD-video labeled for a specific region can only be played back in the unit with the same region code.

BD-video

DVD-video

Structure of Disc / SD Memory Card Contents

The contents of BD / DVD / AVCHD are generally divided into titles. Titles may be further subdivided into chapters.

BD / DVD / AVCHD

title 1 title 2

chapter 1

chapter 2 chapter 2chapter 1 chapter 3

On-Screen Display

You can check information about the current disc by pressing [DISPLAY].

To call the on-screen display menu, press [DISPLAY] during playback. Every time you press [DISPLAY], the information changes. Depending on the media, available information varies.

off A Title / Chapter information

A Title information (elapsed time) A Title information (remaining time) A Decoding format information A off

off A Chapter information (elapsed time) A Chapter information (remaining time) A Title information (elapsed time) A Title information (remaining time) A Decoding format information A off

Track information (elapsed time)

A Track information (remaining time) A Disc information* (elapsed time) A Disc information* (remaining time) A Track information (elapsed time)

(* not available during program / random playback)

off (File information (elapsed time))

A File name information A off (File information (elapsed time))

Audio CD is divided into tracks.

track 1 track 2 track 3 track 4 track 5

Data discs or SD Memory Cards containing MP3 / WMA / JPEG are divided into folders, and the folders are subdivided into files.

folder (group) 1

file 1

file 2 file 3 file 4 file 5

audio CD

MP3 / WMA / JPEG

folder (group) 2

off (File information (elapsed time))

A File name information A Tag information (title name) A Tag information (artist name) A off (File information (elapsed time))

off A File information A File name information A off

18 EN

S Chapter information

1 32

1 1/10

4 5

PLAYBACK

S File name information

File_name_001

Media icon and file name

NTRODUCTION

2 6

3 / 5 0 : 01 : 02

Current title number Current chapter number / Total number of chapters Current repeat setting (Only when repeat setting is

active) (C: Chapter repeat, T: Title repeat, AB: A-B repeat)

Indicates that the multi camera angle images are available on the scene

Current playback status

Elapsed time (or remaining time) of the current chapter

S Title information

1 2

3 / 5 0 : 01 : 02

Current title number / Total number of titles

Elapsed time (or remaining time) of the current title

: MP3 files

: WMA files

: JPEG files

S Tag information

TITLE

ARTIST NAME

Title name based on tag information of current Windows Media™ Audio file

Artist name based on tag information of current Windows Media™ Audio file

ONNECTIONS

PLAYBACK F

UNCTION

SETUP

THERS

S Track / File information

1 3 42

SD1 / 14 0 : 00: 51

Current track (file) number / Total number of track (file)

Elapsed time (or remaining time) of the current track / file (except for JPEG files)

Indication of SD Memory Card playback

Current repeat setting (Only when repeat setting is active) (T: Track repeat, G: Group repeat, A: All repeat, AB: A-B repeat)

S Disc information

1 2

1 / 14 0 : 00: 51

Current track number / Total number of tracks

Elapsed time (or remaining time) of the current disc

S Decoding format information

Dolby Digital

Decoding format

19EN

PLAYBACK

How to Insert a Disc

Press [OPEN/CLOSE A] to open the

1 2

• Make sure the disc is compatible with this unit. (Refer to page 17 for the list of compatible discs.)

disc tray.

Place the disc on the disc tray with its label side facing up.

Align the disc to the disc tray guide.

Press [OPEN/CLOSE A] to close the

To eject the disc:

Press [OPEN/CLOSE A] to open the disc tray. Remove the disc. Press [OPEN/CLOSE A] to close the disc tray.

disc tray.

Please allow time for the disc to load.

Reading an SD Memory Card

Use [K / L] to select “SD Card”, then press [ENTER].

Media Select

Disc

SD Card

• Media filter screen will appear.

• When the SD Memory Card contains only one type of file, skip to step 4.

Select the type of the file you want to play back in the media filter screen. Then press [ENTER] to display the file list.

Please select the media to play back.

Video

Audio


• Playback of AVCHD files will start right after

you choose “Video”. (The file list is not available for AVCHD files.)

Use [K / L] to select a desired track, folder or file, then press [ENTER]. Use [s / B] to go back and forward between the hierarchies.

•If you press [ENTER] on the desired file,

playback will start.

You can play back the AVCHD / MP3 / WMA / JPEG files in an SD Memory Card. With the SD Memory Card, you can also enjoy the following functions.

- Special additional contents for BD-ROM Profile 1 ver.1.1. (For more information about the special additional contents, refer to the instruction book that came with the disc.)

- BD-Live function (BD-ROM ver. 2 Profile 2.0). (For more information about BD-Live, refer to page 29.)

Insert an SD Memory Card, with the

label side facing up, into the SD card slot until it clicks.

If no disc is in operation, “Media Select” screen will appear on the TV screen.

PAUSE STOP PLAY

OPEN/CLOSE

SD Memory Card

ON/STANDBY

To remove the SD Memory Card:

In stop mode, gently push in the SD Memory Card, then pull it out slowly.

Note

• The “Media Select” screen will disappear under the conditions listed below:

- when the screen saver is activated.

- when [RETURN] is pressed.

- when the setup menu is called up.

• If the “Media Select” screen disappears before you make the selection, refer to “Selecting the Media” on page 21.

• Do not remove the SD Memory Card or turn the unit to the standby mode while the contents of the card are in playback. It may result in malfunction or loss of the card’s data.

• Do not delete the folders or files in the SD Memory Card with your computer. This unit may not read the SD Memory Cards formatted on a computer.

• If a folder or file name includes one of the following unrecognizable characters, the folder or file name may not be displayed correctly.

- Unrecognizable characters :

. , " = + [ ] ; / \ : | ¥

20 EN

e hen

PLAYBACK

Selecting the Media

For the playback media to be read by this unit, the correct media should be selected. You can switch the media by following the steps below. “Media Select” is available only when an SD Memory Card is inserted.

In stop mode, press [SETUP].

Use [K / L] to select , then press

[ENTER] .

NTRODUCTION

ONNECTIONS

Quick

Media Select

HDMI Audio Out

HDMI Video Resolution

Component Output

Player Menu

Disc

HDMI Multi(Normal)

Auto

480i

English

Use [K/L] to select “Media Select”.

Quick

Media Select

HDMI Audio Out

HDMI Video Resolution

Component Output

Player Menu

Disc

HDMI Multi(Normal)

Auto

480i

English

PLAYBACK F

UNCTION

SETUP

THERS

Press [ENTER] repeatedly to select

the desired media.

Press [SETUP] to exit.

Even if you turn the unit to the standby mode in “SD Card” mode, it will be in “Disc” mode the next time you turn it on.

21EN

+ 46 hidden pages
