Blu-ray Disc Player

BDX2000KB

OWNER’S MANUAL

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Owner’s Record

The model number and serial number are on the back of this unit. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this unit.

Model number:

Serial number :

E5RJ0BD_EN.book Page 2 Tuesday, October 20, 2009 3:53 PM

INTRODUCTION

Safety Instructions

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note is located on the rear or bottom of the cabinet.

Caution

1. Do not attempt to open the cabinet. There are no parts inside you can service. Refer all servicing to qualified service personnel.

2. Slots and openings in the cabinet at the sides and underneath are provided for ventilation. To ensure reliable operation and to protect the unit from overheating, these openings must not be blocked or covered. Avoid installation in enclosed spaces such as bookcases unless suitable ventilation is provided.

3. Keep the unit away from radiators and other heat sources.

4. Avoid use near strong magnetic fields.

5. Do not push objects of any kind into the unit through the cabinet slots or openings as they could touch electrically live parts or short circuit parts resulting in a fire or electric shock.

6. To prevent fire or shock hazard, do not expose this apparatus to dripping or splashing, no objects filled with liquids, such as vases, should be placed on the apparatus.

7. Do not stand the unit vertically. Use the unit in a horizontal (flat) position only.

8. This product is in Stand-by mode when turned off while the mains cable is connected.

9. Do not place a flaming object such as a burning candle on the apparatus.

10. Before moving the unit, be sure to remove any media and unplug the mains cable from the AC outlet.

11. Disconnect the mains plug to shut off the unit, if you suspect a fault has developed, or if it will not be used for an extended period.

12. The mains plug shall remain readily operable and accessible.

13. Read both instruction manuals to ensure correct and safe installation and interconnection of the unit in multimedia systems.

14. Keep a distance of 20 cm around the ventilation openings of the apparatus.

15. Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sucient magnitude to constitute a risk of elec tric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

The symbol for CLASS ll (Double Insulation)

16. Do not use a cracked , deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and apparatus malfunction.

17. If the apparatus should smoke or smell, immediately disconnect the power cord from the wall outlet.Wait until the smoke or smell stops, then ask your dealer for a check and repair. Neglecting to do so may cause fire.

18. While it is thundering, do not touch the connecting cables or the apparatus.

Laser Safety

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: CLASS 2 LASER RADIATION WHEN OPEN DO NOT STARE INTO THE BEAM

LOCATION:

• INSIDE, NEAR THE BD

MECHANISM

Avoid the Hazards of Electrical Shock and Fire

• Do not handle the mains cable with wet hands.

• Do not pull on the mains cable to disconnect it from AC outlet.

Grasp it by the plug.

• If, by accident, water is spilled on the unit, unplug the mains

cable immediately and take the unit to an authorised service centre for servicing.

Moisture Condensation Warning

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, after heating a cold room, or under conditions of high humidity. Do not use the unit for at least 2 hours to allow the inside to dry.

2EN

E5RJ0BD_EN.book Page 3 Tuesday, October 20, 2009 3:53 PM

INTRODUCTION

Connection to Power

Before Switching on make sure that the voltage of your electricity supply is the same as that indicated on the rating plate.

Power Supply

The power supply is connected and the unit is live when the mains cable is plugged into a 220 - 240 V~, 50 Hz AC outlet. To operate the unit, press [ON/STANDBY Q].

WARNING: LIVE PARTS INSIDE.

DO NOT REMOVE ANY SCREWS.

Mains Cord

This apparatus may be fitted with a non-rewireable plug. If it is necessary to change the fuse in a nonrewireable plug the fuse cover must be refitted. If the fuse cover is lost or damaged, the plug must not be used until a replacement available from the apparatus manufacturer is obtained. It is important that the colour of the replacement fuse cover corresponds with the rating marking on the base of the plug. If the plug has to be changed because it is not suitable for your socket, or becomes damaged, it should be cut off and an appropriate plug fitted following the wiring instructions below. The plug removed must be disposed of safely as insertion into a 13A socket is likely to cause an electrical hazard. For your own safety read the following instructions carefully before attempting to connect this unit to mains. The wires in this mains lead are coloured in accordance with the following code: BLUE=NEUTRAL, BROWN=LIVE

FUSE

BROWN

BLUE

(Neutral)

OUTER SHEATH OF THE WIRE

(Live)

CORD GRIP

Installation Location

For safety and optimum performance of this unit:

• Install the unit in a horizontal and stable position.

• Keep the unit away from electronic equipment such as an

amplifier, TV, etc. to prevent warping, damage, fire and malfunction.

• Do not place anything directly on top of the unit.

• Shield the unit from direct sunlight and keep away from sources

of intense heat. Avoid dusty or humid locations. Avoid locations with insufficient ventilation for suitable heat dissipation. Do not block the ventilation holes on the sides of the unit. Avoid locations subject to strong vibration or strong magnetic fields.

• Do not locate near water.

Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling unit can cause serious injury or even death.

EU Conformity Statement

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Important

As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. No connection is to be made to the earth terminal of the plug. If a 13 Amp (BS 1363) Plug is used, a 5 Amp Fuse must be fitted, or if any other type of Plug is used a 3 or 5 Amp Fuse must be fitted, either in the Plug or Adaptor, or on the Distribution Board.

Mains Supply: 220 - 240 V~ 50 Hz - AC only Do not make any connection to the larger pin marked with the

letter “E” or by the symbol or coloured green or green and yellow.

Other Precautions

About Recycle

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

This product consists of materials which can be recycled and reused if disassembled by a specialised company.

Following information is only for EU-member states:

The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

“This product is marked with “CE” and complies therefore with the applicable harmonised European standards listed under the Low Voltage Directive 2006/95/EC and the EMC Directive 2004/108/EC.”

Responsible for CE-marking is TOSHIBA INFORMATION SYSTEMS (U.K.) LTD, Toshiba Court, Weybridge Business Park, Addlestone Road, Weybridge, Surrey, KT15 2UL, United Kingdom

Following information is only valid EU-member States: Disposal of batteries and/or accumulators

The crossed out wheeled dust bin symbol indicates that batteries and/or accumulators must be collected and disposed of separately from household waste. If the battery or accumulator contains more than the specified values of lead (Pb), mercury (Hg), and/or cadmium (Cd) defined in the Battery Directive (2006/66/EC), then the chemical symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd) will appear below the crossed out wheeled dust bin symbol. By participating in separate collection of batteries, you will help to assure the proper disposal of products and batteries and thus help to prevent potential negative consequences for the environment and human health. For more detailed information about the collection and recycling programmes available in your country, please contact your local city office or the shop where you purchased the product.

Make your contribution to the environment!!!

• Exhausted batteries do not belong in the dustbin.

• You can dispose of them at a collection point for

exhausted batteries or special waste.

• Contact your council for details.

Pb, Hg, Cd

3EN

E5RJ0BD_EN.book Page 4 Tuesday, October 20, 2009 3:53 PM

INTRODUCTION

About Copyright

Unauthorised copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by U.S. patents

and other intellectual property rights. Use of this copyright protection technology must be authorised by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorised by Macrovision. Reverse engineering or disassembly is prohibited.

About Maintenance

Cleaning the Unit

Use a soft cloth slightly moistened with a mild detergent solution. Do not use solutions containing alcohol, spirits, ammonia or abrasive.

Cleaning Discs

If a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the centre out. Do not wipe in a circular motion. Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analogue records.

Disc Handling

Handle the discs so that fingerprints and dust do not adhere to the disc surfaces. Always store the disc in its protective case when it is not in use.

Servicing

If the unit becomes inoperative, do not try to correct the problem by yourself. There are no user serviceable parts inside. Turn the unit off, unplug the mains cable, and consult your dealer or an authorised service centre.

Cleaning the Disc Lens

If the unit does not perform correctly even though you have referred to “Troubleshooting” and the relevant sections in the Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an authorised service centre for inspection and cleaning of the laser optical pickup unit.

IR Signal Check

• If the remote control is not working properly, you can use a digital camera (including a cellular phone with built-in camera) to see if it is sending out an infrared signal.

With a digital camera (including built-in cell phone cameras):

Point a digital camera towards the remote control. Push any button on the remote control and look through the digital camera. If the infrared light appears through the camera, the remote control is working.

About Remote Control

Installing the Batteries in the Remote Control

Install 2 R6 (1.5V) batteries matching the polarity indicated inside battery compartment of the remote control.

2)1) 3)2)1) 3)

Make sure to match + and - on the batteries to the marks indicated in the battery compartment.

Caution

Incorrect use of batteries can result in hazards such as leakage and bursting. Please observe the following:

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together. Although they may look similar, different batteries may have different voltages.

• Make sure that the + and - ends of each battery match the indications in the battery compartment.

• Remove batteries from battery compartment that are not going to be used for a month or more.

• When disposing of used batteries, please comply with governmental regulations or environmental public rules that apply in your country or area. (Refer to page 3.)

• Do not recharge, short-circuit, heat, burn or disassemble batteries.

Using a Remote Control

Keep in mind the following when using the remote control:

• Make sure that there are no obstacles between the remote control and the infrared sensor window on the unit.

• Remote operation may become unreliable if strong sunlight or fluorescent light is shining on the infrared sensor window of the unit.

• Remote control for different devices can interfere with each other. Avoid using remote control for other device located close to the unit.

• Replace the batteries when you notice a fall off in the operating range of the remote control.

• The maximum operable ranges from the unit are as follows.

- Line of sight: approx. 7 m

- Either side of the centre: approx. 5 m within 30°

- Above: approx. 5 m within 15°

- Below: approx. 3 m within 30°

PAUSE STOP PLAY

OPEN/CLOSE

ON/STANDBY

Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot

5 m 7 m 5 m

30˚30˚

assure that this Blu-ray Disc Player will successfully play every disc or every feature of every disc bearing the DVD logo and/or every CD bearing the CD logo. As one of the creators of DVD technology, Toshiba DVD players are manufactured using the highest standards of quality, and as a result, such incompatibilities are rare.

4EN

E5RJ0BD_EN.book Page 5 Tuesday, October 20, 2009 3:53 PM

INTRODUCTION

Supplied Accessories

• Remote control with R6 (1.5V) battery x 2

• HDMI cable (High Speed HDMI Cable)

•Owner’s manual

Content

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

•Quick start guide

• Helpline sheet

INTRODUCTION

Safety Instructions ........................................................................2

Caution........................................................................................2

Laser Safety................................................................................2

Avoid the Hazards of Electrical Shock and Fire ............2

Moisture Condensation Warning ......................................2

Connection to Power.............................................................3

Installation Location...............................................................3

EU Conformity Statement ....................................................3

Other Precautions .........................................................................3

About Recycle...........................................................................3

About Copyright......................................................................4

About Maintenance................................................................4

About Remote Control..........................................................4

Supplied Accessories ...................................................................5

Trademark Information...............................................................6

Features ............................................................................................7

Functional Overview ....................................................................8

Front Panel.................................................................................8

Rear Panel ..................................................................................8

Remote Control........................................................................8

Front Panel Display.................................................................9

Symbols Used in this Manual..............................................9

CONNECTIONS

Connection to the TV................................................................ 10

Connection to an Audio System ...........................................12

Network Connection with LAN .............................................12

Finding the Video Channel on Your TV.............................. 12

PLAYBACK

Information on Playback.......................................................... 13

Playable Media...................................................................... 13

Unplayable Media ................................................................ 14

Colour Systems...................................................................... 14

Region Codes......................................................................... 14

Structure of Media Contents............................................14

On-Screen Display................................................................ 14

Preparing to Play Back..............................................................16

How to Insert a Disc............................................................. 16

How to Insert an SD Card ..................................................16

Selecting the Media............................................................. 16

Basic playback .............................................................................16

Playing Back (BD, DVD or a Disc with

AVCHD files) ...........................................................................16

Playing Back (Audio CD or a Media with

DivX®/MP3/Windows Media™ Audio/JPEG Files)...... 17

Reading an SD Card............................................................. 18

Kodak Picture CD.................................................................. 18

Special Playback..........................................................................19

About DivX® and DivX® VOD.............................................19

Playing Back a DivX® with DivX® External

Subtitle .....................................................................................19

Fast Forward / Fast Reverse...............................................20

Slow Motion Playback.........................................................20

Step by Step Playback.........................................................20

Repeat Playback ....................................................................20

A-B Repeat...............................................................................21

Programme Playback ..........................................................21

Random Playback .................................................................22

Rapid Playback.......................................................................22

Useful Function............................................................................22

Noise Reduction ....................................................................22

Virtual Surround....................................................................23

PIP (BONUSVIEW) Setting...................................................23

Camera Angle.........................................................................23

Enjoying BD-Live Discs with Online Content..............23

Search........................................................................................24

Switching Subtitles ..............................................................25

Switching Audio Soundtrack............................................25

Setting the BD Audio Mode ..............................................26

FUNCTION SETUP

How to Navigate through the Setup Menus.....................27

List of Setup Menus....................................................................27

TV Aspect .......................................................................................32

HDMI Audio Out..........................................................................33

Digital Out .....................................................................................34

Parental...........................................................................................35

HDMI CEC (REGZA - LINK).........................................................35

One Touch Play......................................................................35

Standby ....................................................................................35

System Information..............................................................35

Network Connection .................................................................36

Connection Test ....................................................................36

Enable(Easy)............................................................................36

Enable(Custom).....................................................................36

Disable ......................................................................................38

Software Update .........................................................................39

Current Version......................................................................39

Disc Update.............................................................................39

Initialise...........................................................................................39

OTHERS

Language Code List....................................................................40

Troubleshooting..........................................................................41

Specifications ...............................................................................42

5EN

E5RJ0BD_EN.book Page 6 Tuesday, October 20, 2009 3:53 PM

INTRODUCTION

Trademark Information

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929; 7,212,872 & other U.S. and worldwide patents issued & pending. DTS is a registered trademark and the DTS logos, Symbol, DTSHD and DTS-HD Master Audio | Essential are trademarks of DTS, Inc. ©1996-2008 DTS, Inc. All Rights Reserved.

“x.v.Color” and “x.v.Color” logo are trademarks of Sony Corporation.

“Blu-ray Disc” and are trademarks.

is a trademark of DVD Format/Logo Licensing

Corporation.

“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

“BONUSVIEW” is trademark of Blu-ray Disc Association.

“BD-LIVE” logo is trademark of Blu-ray Disc Association.

Java and all other Java trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and/or other countries.

DivX

, DivX Certified®, and associated logos are trademarks of DivX, Inc. and are used under license.

Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

is trademark of Eastman Kodak Company.

THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO

MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA, L. L. C. SEE HTTP://WWW.MPEGLA.COM

6EN

E5RJ0BD_EN.book Page 7 Tuesday, October 20, 2009 3:53 PM

INTRODUCTION

Features

BD-Java

With some BDs which support Java applications, you can enjoy the interactive functions such as games or interactive menus.

BD-Live

BD-Live (BD-ROM version 2 Profile 2.0) that allows interactive functions to be used when this unit is connected to the Internet in addition to the BONUSVIEW function. The various functions differ depending on the disc.

Full High-Definition Video Playback

Watch movies in the highest picture quality available for your HDTV. This unit offers full high-definition video playback up to 1080p resolution for an amazing viewing experience. A highly detailed picture and increased sharpness delivers a more trueto-life picture.

DVD Upconversion for Enhanced Picture Quality

Your current DVD will look even better than before thanks to video upconversion. Upconversion will increase the resolution of standard definition DVD to high definition up to 1080p over an HDMI connection. The picture will be less jagged and more realistic for a near high-definition experience.

Enjoy Your Content on Different Kinds of Media

Full backwards compatibility with BD, DVD, CD and SD card ensures that you can continue to enjoy your current audiovideo collection. Additionally, you can enjoy AVCHD/DivX MP3/WMA/JPEG files.

Experience Rich Multi-Channel Surround Sound

Multi-channel surround sound, which recognises real-to-life sound and makes you feel like you are really there.

PIP (BONUSVIEW)

Some BD-video have the PIP function which enables you to display the secondary video in the primary video. You can call up the secondary video by pressing [PIP] whenever the scene contains the secondary video.

Pop-up Menu

Some BD-videos have pop-up menu which is a navigation menu that can be called up and be operated on the TV screen without interrupting the playback. You can call up the pop-up menu by pressing [POP MENU / MENU]. Contents in the pop-up menu vary depending on the disc.

x.v.Color

This unit supports playback of video contents on discs recorded with “x.v.Color” technology. To watch this video content with the “x.v.Color”, a TV or other display device supporting both video image reproduction using the “x.v.Color” standard and capable of manually switching it’s colour setting is required. Please refer to the owner’s manual of your display device for further information.

Easy and Simple Connection to Your HDTV via HDMI

You can connect this unit to your HDTV with one single HDMI (High-Definition Multimedia Interface) cable. It is recommended to use a High Speed HDMI Cable for optimal compatibility. The high definition video output signal will be transferred to your HDTV without conversion to analogue signals, so you will get excellent picture and sound quality, completely free from noise.

HDMI Deep Colour

Deep Colour reduces the posterisation effect of the playback image. Refer to “HDMI Deep Color” in “FUNCTION SETUP” on page 28.

HDMI CEC (Consumer Electronics Control) (REGZA - LINK)

This unit supports HDMI CEC, which allows integrated system control over HDMI and is part of the HDMI standard. This function may not work properly on some devices.

HDMI 1080p24 Output (BD Only)

This unit is equipped with a feature which can provide the

smooth movement in the playback of film originated material with the frame rate of 24 frames per second with progressive scan. (Available only when the TV is connected by an HDMI cable and compatible with 1080p24 frame input.) Refer to “HDMI Video Resolution” in “FUNCTION SETUP” on page 28.

HDCP Compatible

To play back the digital video images of a BD / DVD via an HDMI connection, it is necessary that both the unit and the TV (or an AV amplifier) support a copyright protection system called HDCP (high-bandwidth digital content protection system). HDCP is copy protection technology that comprises data encryption and authentication of the connected AV device. This unit supports HDCP. Please read the operating instructions of your TV (or AV amplifier) for more information.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Rapid Playback

Playback in slightly faster speed while keeping the sound output. Rapid playback is available only on discs recorded in the Dolby Digital format.

Playback of Content from an SD Card

You can play back AVCHD/MP3/WMA/JPEG stored in an SD card. You can store picture-in-picture commentary, subtitles or other extras for BD-ROM ver. 2 (Profile 2.0 / Profile 1.1) files in an SD card and play them back with the BD-video.

Playing Back AVCHD Files

This unit supports playback of AVCHD format files (new format for high definition video camcorders) recorded on disc/SD card. Your high definition personal archive is playable in HD quality.

7EN

E5RJ0BD_EN.book Page 8 Tuesday, October 20, 2009 3:53 PM

INTRODUCTION

Functional Overview

Front Panel

ON/STANDBY

(*) The unit can also be turned on by pressing these buttons.

1. ON/STANDBY Q button

• Press to turn on the unit, or to turn the unit into the standby mode. (To completely turn off the unit, you must unplug the mains cable.)

4 5* 7 8 96*

PAUSE STOP PLAY

OPEN/CLOSE

2. ON/STANDBY Q indicator

3. PAUSE F button

4. STOP C button

5. PLAY B button*

6. OPEN/CLOSE A button*

Rear Panel

DIGITAL OUT

PCM/BITSTREAM

PR/C

PB/C

COAXIALOPTICAL

AUDIO

OUT

VIDEO

COMPONENT

VIDEO OUT

6. DIGITAL OUT (OPTICAL /

7. VIDEO OUT jack

HDMI

LAN

OUT

1. LAN terminal

2. HDMI OUT jack

3. AUDIO OUT jacks

4. COMPONENT VIDEO OUT jacks

5. Mains cable

COAXIAL) jacks

7. Disc tray

8. Display

9. Infrared sensor window

10. SD card slot

Caution

• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

Remote Control

8 9

11*

19 20

23 24

26 27

(*) The unit can also be turned on by pressing these buttons.

1. HDMI button

2. OPEN/CLOSE A button*

3. Number buttons

4. SEARCH button

5. Red / Green / Yellow / Blue buttons

6. TOP MENU button

7. K / L / s / B buttons

8. SETUP button

9. REV E button

10. SKIP H button

11. PLAY B button*

12. MODE button

13. REPEAT button

14. PIP button

15. ON/STANDBY Q button

• Press to turn on the unit, or to

turn the unit into the standby mode. (To completely turn off the unit, you must unplug the mains cable.)

16. ANGLE button

17. AUDIO button

18. SUBTITLE button

19. DISPLAY button

20. CLEAR button

21. POP MENU / MENU button

22. ENTER button

23. RETURN button

24. FWD D button

25. SKIP G button

26. STOP C button

27. PAUSE F button

28. A-B button

8EN

E5RJ0BD_EN.book Page 9 Tuesday, October 20, 2009 3:53 PM

INTRODUCTION

Front Panel Display

1 2

* Brightness of the display can be adjusted. Refer to “Panel Display” in “FUNCTION SETUP” on page 30.

1. Displays repeat icon. (Appears during repeat playback.)

2. Displays media icon (disc mode or SD card mode).

3. Displays playback status icon. Refer to the table below.

4. Displays various kinds of information such as title number, elapsed playing time, repeat type, menu type, etc.

Playback status icon Mode

Playback is in progress

Stop mode

Pause mode

Symbols Used in this Manual

To specify for which media type each function is, we put the following symbols at the beginning of each item to operate.

Symbol Description

Description refers to BD-video and BD-RE (ver.2.1) / BD-R (ver.1.1/1.2/1.3) recorded in BDMV format

Description refers to DVD-video

Description refers to audio CD / DTS-CD

Description refers to DVD-RW/-R and SD card with AVCHD files

Description refers to BD-RE/-R, DVD-RW/-R and CD-RW/-R with DivX

Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD card with MP3 files

Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD card with Windows Media™ Audio files

Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD card with JPEG files

If you do not find any of the symbols listed above under the function heading, the operation is applicable to all media.

files

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Fast forward mode

Fast reverse mode

Slow motion mode

Example of Display Message

Title is being played back. Indicating the current title number and the elapsed time.

Current chapter is in chapter repeat mode.

Loading a disc.

Dolby Digital audio is being played back.

DTS audio is being played back.

9EN

E5RJ0BD_EN.book Page 10 Tuesday, October 20, 2009 3:53 PM

CONNECTIONS

• When you change the connections, all devices should be turned off.

• Refer also to the manual of the devices to be connected.

Connection to the TV

1 Choose the appropriate connection, then proceed to the corresponding instruction (A, B

or C) on the next page.

Best

No analogue audio connection required.

High Speed HDMI Cable (also known as HDMI category 2 cable) included

Better

(Supports up to 1080i / 1080p, 1080p24 resolution.)

Video Audio

HDMI cable

HDMI IN

(Supports up to 1080i resolution.)

Video

component video cable

COMPONENT

VIDEO IN

PB/CB

PR/CR

Audio

composite audio cable

AUDIO IN

Your TV

High

Definition

Your TV

High

Definition

Go To

Component video cable and composite audio cable NOT INCLUDED

Basic

Video

Audio

• Connect this unit directly to the TV. If the composite audio / video cables are connected to a VCR, pictures may be

distorted due to the copy right protection system.

Composite audio / video cables NOT INCLUDED

(Supports only 480i/576i resolution.)

composite video cable

composite audio cable

VIDEO IN

AUDIO IN

Your TV

Standard

Definition

Go To

10 EN

E5RJ0BD_EN.book Page 11 Tuesday, October 20, 2009 3:53 PM

CONNECTIONS

2 Connect the cables by following the descriptions below.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

HDMI Video / Audio Connection

02#

($-)

/54

,!.

0"#

#/!8)!,/04)#!,

!5$)/

6)$%/

($-) /54

0#-")4342%!-

#/-0/.%.4

$)')4!,/54

/54

6)$%//54

HDMI cable

Your TV

HDMI IN

Note

• Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the connector are matched.

• When using non-HDCP compatible TV, the image may not be displayed properly.

Component Video + Standard Audio Connection

02#

0"#

#/!8)!,/04)#!,

!5$)/

6)$%/

($-)

,!.

/54

0#-")4342%!-

#/-0/.%.4

$)')4!,/54

/54

6)$%//54

component video cable

COMPONENT

VIDEO IN

Your TV

02#

!5$)/

/54

0"#

#/-0/.%.4

6)$%//54

Standard Video + Standard Audio Connection

($-)

,!.

/54

0#-")4342%!-

02#

0"#

#/!8)!,/04)#!,

!5$)/

6)$%/

#/-0/.%.4

$)')4!,/54

/54

6)$%//54

composite video cable

!5$)/

/54

6)$%/

composite audio cable

PR/CR

PB/CB

VIDEO IN

AUDIO IN

Your TV

AUDIO IN

11EN

E5RJ0BD_EN.book Page 12 Tuesday, October 20, 2009 3:53 PM

CONNECTIONS

Connection to an Audio System

2-Channel Analogue Audio

Digital Audio Connection HDMI Audio Connection

Connection

Stereo system

AUDIO IN

composite audio cable

PR/C

PB/C

COAXIALOPTICAL

AUDIO

VIDEO

HDMI

COMPONENT

DIGITAL OUT

OUT

LAN

OUT

PCM/BITSTREAM

VIDEO OUT

AUDIO

OUT

Digital audio optical / coaxial cable and composite audio cable NOT INCLUDED

High Speed HDMI Cable (also known as HDMI category 2 cable) included

Network Connection with LAN

• You can use a disc which offers BD-Live function by connecting the unit to the Internet. (For BD-Live information, please refer to page 23.)

Networking equipment

(modem, etc.)

AV receiver / amplifier

DIGITAL AUDIO INPUT

OPTICAL

COAXIAL

digital audio optical cable

PR/C

PB/C

COAXIALOPTICAL

AUDIO

VIDEO

HDMI

COMPONENT

DIGITAL OUT

OUT

LAN

PCM/BITSTREAM

OUT

VIDEO OUT

COAXIALOPTICAL

DIGITAL OUT

PCM/BITSTREAM

digital audio coaxial cable

• Refer to page 34 for digital audio setting. • Refer to page 33 for HDMI audio setting.

Finding the Video Channel on Your TV

After you have completed all the connections, you must find the correct video channel (external input channel) on your TV.

Hub or broadband router

1 After you have made all the necessary

connections, turn on the unit and your TV.

AV receiver / amplifier with an HDMI input jack

HDMI IN

HDMI cable

PR/C

PB/C

COAXIALOPTICAL

AUDIO

VIDEO

HDMI

COMPONENT

DIGITAL OUT

OUT

LAN

OUT

PCM/BITSTREAM

VIDEO OUT

HDMI OUT

LAN

LAN cable

WAN LAN

LAN cable

Internet

LAN

PR/C

PB/C

COAXIALOPTICAL

AUDIO

VIDEO

HDMI

COMPONENT

DIGITAL OUT

OUT

LAN

OUT

PCM/BITSTREAM

VIDEO OUT

Networking equipment, hub or broadband router and cables NOT INCLUDED

Caution

• Do not insert any cable other than a LAN cable to the

LAN terminal to avoid damaging the unit.

Note

• After connecting a LAN cable, set up necessary

network settings.

• If your network equipment (modem, etc.) does not

have broadband router functions, connect a broadband router.

• If your network equipment (modem, etc.) has

broadband router functions but there is no vacant port, use a hub.

• For a broadband router, use a router which supports

10BASE-T/100BASE-TX.

• Do not connect your PC directly to the LAN terminal

of this unit.

• For the network setup, refer to “Network Connection”

on pages 36-38.

2 Press the button on the TV’s remote

12345

control that accesses the external input channel repeatedly until you see the opening screen. It may be labelled “F (for TOSHIBA TV)”, “SOURCE”, “AV” or “INPUT” (refer to your TV’s user manual).

Note

• If the TV is connected by an HDMI cable, please allow a few minutes for the opening screen to display.

12 EN

E5RJ0BD_EN.book Page 13 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Information on Playback

Before you start playing back a disc, read the following information.

Playable Media

This unit is compatible to play back the following discs / files. To play back a disc / file, make sure that it meets the requirements for region codes and colour systems as described below. You can play back discs that have the following logos. Other disc types are not guaranteed to play back.

Playable discs Logos

Blu-ray Disc

- BD-video (single / dual layer)

- BD-RE ver. 2.1 (single / dual layer) (Recorded in BDMV format)

- BD-R ver. 1.1 / 1.2 / 1.3 (single / dual layer) (Recorded in BDMV format) (Unclosed discs may not be played back.)

DVD-video

DVD-RW

DVD-R

CD-DA (audio CD)

CD-RW

CD-R

• ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video.

• ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified device must be registered in order to play DivX Video-onDemand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD.

• Official DivX DivX of DivX

• Discs containing the DivX (Global Motion Compensation) playback feature, which is DivX this unit.

It is recommended that files to be played back in this unit are recorded under the following specifications:

DivX

Official DivX Certified® product

• Playable codec of AVI files :

• Maximum size of a video : 720 x 480 @30 fps

• Sampling frequency of audio

• Audio type : MPEG1 audio layer 3

MP3/Windows Media™ Audio

• Sampling frequency : 32 kHz, 44.1 kHz or 48 kHz

• Constant bit rate : 112 kbps - 320 kbps (MP3),

JPEG

• Upper limit : 2,560 x 1,900 dots (sub

• Lower limit : 32 x 32 dots

• File size of image maximum

Certified product; Plays all versions of

video (including DivX®6) with standard playback

media files.

files with the DivX® GMC

supplemental function, cannot be played back on

DivX

3.x, DivX®4.x,

5.x, DivX®6.x

DivX

720x576@25fps

: 16 kHz - 48 kHz

(MP3), MPEG1 audio layer 2, Dolby Digital

48 kbps - 192 kbps (Windows Media™ Audio)

sampling is 4:4:4) 5,120 x 3,840 dots (sub sampling is up to 4:2:2)

:12 MB

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Kodak Picture CD

DTS-CD

Playable files Media

AVCHD

DivX

MP3

Windows Media™ Audio

JPEG

DVD-RW/-R, SD Memory Card (including SDHC), miniSD Card, microSD Card

BD-RE/-R, DVD-RW/-R, CD-RW/-R

BD-RE/-R, DVD-RW/-R, CD-RW/-R, SD Memory Card (including SDHC), miniSD Card, microSD Card

Readable cards Playable files / data

SD Memory Card (8 MB - 2 GB) AVCHD, MP3, Windows SDHC Memory Card (4 GB - 8 GB)

miniSD Card (8 MB - 2 GB)

microSD Card (8 MB - 2 GB)

Media™ Audio, JPEG, picture-in-picture commentary, subtitles or other extras for BD-ROM ver. 2 (Profile 2.0 / Profile 1.1)

13EN

E5RJ0BD_EN.book Page 14 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Note for SD cards

• This unit supports SD Memory Card with FAT12/ FAT16 file system, and SDHC Memory Card with FAT32 file system.

• This unit does not support NTFS file system.

• This unit may not read the SD cards formatted on a computer. If that is the case, please reformat the SD cards in this unit and try again.

• This unit does not support miniSDHC and microSDHC Memory Card.

• For miniSD Card and microSD Card, the adapter is necessary.

miniSD Card adapter

miniSD Card

• Portions of this unit are protected under copyright law and are provided under license by ARIS / SOLANA / 4C.

• Please keep the SD cards in their cases when you are not using them.

• Do not try to open or modify the card.

• Do not touch the terminal surface with your fingers or any metals.

• Do not attach additional labels or stickers to cards.

• Do not remove the label of the SD cards.

• This unit recognises up to 8 characters of file name in the SD card. Characters after 8th will not be displayed.

Unplayable Media

The following discs will not be played back in this unit.

• CD-ROM • CD-I (compact disc-interactive)

•DVD-RAM •VSD (video single disc)

•DVD-audio •Video CD

• HD DVD • SVCD

• Unfinalised disc

• BD-RE (ver.1.0)

• BD-RE (ver.2.1) (Recorded in BDAV format)

•SD card contains DivX

files.

• BD / DVD hybrid disc (played back as a BD-video only)

• BD that contains AVCHD files

• BD-R (ver.1.1 / 1.2 / 1.3) (Recorded in BDAV format)

• DVD-RW/-R recorded in non compatible recording format.

• Super Audio CD - Only the sound on the CD layer can be heard. The sound on the high-density Super Audio CD layer cannot be heard.

• Playability of dual discs are not guaranteed.

• This unit cannot play back the disc contents protected by Windows Media™ Digital Rights Management (DRM).

Colour Systems

BD and DVD are recorded in different colour systems throughout the world. The most common colour system, used primarily in the U.K. and other EU countries, is PAL. This unit uses the PAL system. However, it is also possible to play back BD and DVD using other colour systems, such as NTSC.

microSD Card adapter

microSD Card

Region Codes

This unit has been designed to play back BD-video with region “B” and DVD-video with region “2” or “ALL”. You cannot play back BD-video or DVD-video that are labelled for other regions. Look for the symbols on the right on your BD-video or DVD-video. If these region symbols do not appear on your BD-video or DVDvideo, you cannot play back the disc in this unit. The letter or number inside the globe refers to region of the world. A BDvideo or DVD-video labelled for a specific region can only play back on the unit with the same region code.

BD-video

DVD-video

Structure of Media Contents

The contents of BD / DVD / AVCHD are generally divided into titles. Titles may be further subdivided into chapters.

BD / DVD / AVCHD

title 1 title 2

chapter 1

chapter 2 chapter 2chapter 1 chapter 3

Audio CD is divided into tracks.

audio CD

track 1 track 2 track 3 track 4 track 5

Data discs or SD cards containing DivX

/ MP3 / WMA / JPEG are divided into folders, and the folders are subdivided into files.

DivX® / MP3 / WMA / JPEG

folder (group) 1

file 1

file 2 file 3 file 4 file 5

folder (group) 2

On-Screen Display

You can check information about the current disc by pressing [DISPLAY].

To call the on-screen display menu, press [DISPLAY] during playback. Every time you press [DISPLAY], the information changes. Depending on the media, available information varies.

OFF A Title / Chapter information

A Title information (elapsed time) A Title information (remaining time) A Decoding format information A OFF

14 EN

E5RJ0BD_EN.book Page 15 Tuesday, October 20, 2009 3:53 PM

OFF A Chapter information (elapsed time) A Chapter information (remaining time) A Title information (elapsed time) A Title information (remaining time) A Decoding format information A OFF

OFF (Track information(elapsed time))

A Track information (remaining time) A Disc information* (elapsed time) A Disc information* (remaining time) A OFF (Track information(elapsed time))

(* not available during programme / random playback)

PLAYBACK

1. Current track (file) number / Total number of track

(file)

2. Elapsed time (or Remaining time) of the current

track / file (except for JPEG files)

3. Indication of SD card playback

4. Current repeat setting

(Only when repeat setting is active) (T: Track repeat, G: Group repeat, A: All repeat, AB: A-B repeat)

1342

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

SD1 / 14 0 : 00: 51

OFF A File information (elapsed time) A File information (remaining time) A File name information A OFF

OFF (File information (elapsed time))

A File name information A OFF (File information (elapsed time))

OFF (File information (elapsed time))

A File name information A Tag information (title name) A Tag information (artist name) A OFF (File information (elapsed time))

OFF A File information A File name information A OFF

1 1/10

132 45

1 / 10 0 : 01 : 02

1. Current title number

2. Current chapter number / Total number of chapters

3. Current repeat setting (Only when repeat setting is active) (C:Chapter repeat,T:Title repeat,AB:A-B repeat)

4. Indicates that the multi camera angle images are available on the scene

5. Current playback status

6. Elapsed time (or Remaining time) of the current chapter

3 / 5 0 : 01 : 02

1 / 14 0 : 00: 51

1. Current track number / Total number of tracks

2. Elapsed time (or Remaining time) of the current disc

File_name_001

1. Media icon and file name

: DivX® files : MP3 files

: WMA files : JPEG files

Title name information

TITLE

Artist name information

ARTIST NAME

1. Title name based on tag information of current Windows Media™ Audio file

2. Artist name based on tag information of current Windows Media™ Audio file

Dolby Digital

1. Decoding format

1. Current title number / Total number of titles

2. Elapsed time (or Remaining time) of the current title

15EN

E5RJ0BD_EN.book Page 16 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Preparing to Play Back

How to Insert a Disc

1 Press [OPEN/CLOSE A] to open the disc

tray.

2 Place the disc on the disc tray with its

label side facing up.

Align the disc to the disc tray guide.

• Make sure the disc is compatible with this unit. (Refer to page 13 for the list of compatible discs.)

3 Press [OPEN/CLOSE A] to close the disc

tray.

Please allow time for the disc to load.

To eject the disc: Press [OPEN/CLOSE A].

How to Insert an SD Card

1 Gently push in the SD card, with its label

side facing up, into the SD card slot until it clicks.

PAUSE STOP PLAY

OPEN/CLOSE

SD card

ON/STANDBY

To remove the SD card:

In stop mode, gently push in the SD card, then pull it out slowly.

Selecting the Media

When an SD card is inserted, the correct media should be selected in advance. You can switch the media by following the steps below. “Media Select” is available

only when an SD card is inserted.

1 In stop mode, press [SETUP]. 2 Use [K / L] to select , then press

[ENTER] .

Basic playback

Playing Back (BD, DVD or a Disc with AVCHD files)

1 Insert a disc. 2 Playback may start automatically.

If not, press [PLAY B].

• Some discs may show a title or a disc menu. In such case, refer to “Using the Title / Disc / Pop-up Menu” on page 17.

To pause playback: Press [PAUSE F].

To return to the normal playback: Press [PLAY B].

To stop playback:

Press [STOP C]. Playback will be in Resume-On-Stop mode.

Resume-On-Stop mode

If a playback is in Resume-On-Stop mode, when you press [PLAY B] next time, the playback will start from the point where it has been stopped.

Note

• Resume playback may not be available for the BD that supports Java applications (BD-Java).

• In “Disc” mode, the resume information will be cleared when;

- [STOP C] is pressed while in the Resume-On-Stop

mode.

- the parental level is changed.

- the disc tray is opened.

• In “SD Card” mode, the resume information will be cleared when;

- [STOP C] is pressed while in the Resume-On-Stop

mode.

- the SD card is removed.

- the unit is turned into the standby mode.

Note

• may appear at the top-right on the TV screen when the operation is prohibited by the disc or this unit.

• During the playback of 2-layered disc, pictures may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

• The operation may vary when you play back BDvideo and DVD-video with disc menu. Refer to the manual accompanying the disc for details.

• Set “Still Mode” setting to “Field” in “Video” menu if pictures in the pause mode are blurred. Refer to “Still Mode” on page 28.

3 Use [K / L] to select “Media Select”. 4 Press [ENTER] repeatedly to select the

desired media.

5 Press [SETUP] to exit.

Even if you turn the unit to the standby mode in “SD Card” mode, it will be in “Disc” mode the next time you turn it on.

16 EN

E5RJ0BD_EN.book Page 17 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Using the Title / Disc / Pop-up Menu

Many of BD-video and DVD-video discs contain title menu (BD-video / DVD-video / AVCHD), disc menu (DVD-video) or pop-up menu (BD-video) which guides you through the available functions in the disc. The contents of the menus may differ depending on the discs.

Title menu (BD-video / DVD-video / AVCHD)

1 Press [TOP MENU]. 2 Use [K / L / s / B] to select an item, then press

[ENTER].

3 Press [TOP MENU] to exit.

Disc menu (DVD-video)

1 Press [POP MENU / MENU]. 2 Use [K / L / s / B] to select an item, then press

[ENTER].

3 Press [POP MENU / MENU] to exit.

Pop-up menu (BD-video)

• This is a special feature available for some BD-videos. When you press [POP MENU / MENU], a menu pops out on the TV screen during the playback.

1 During the playback of BD-video, press

[POP MENU / MENU].

2 Use [K / L / s / B] to select an item, then press

[ENTER].

3 Press [POP MENU / MENU] to exit.

Note

• Contents of menus and corresponding menu operations may vary among discs. Refer to the manual accompanying the disc for details.

• Title menu is also available for SD card with AVCHD files.

Playing Back (Audio CD or a Media with DivX®/ MP3/Windows Media™ Audio/JPEG Files)

3 Use [K / L] to select a desired track, folder

or file, then press [ENTER]. Use [s / B] to go in and out of folders. (only for DivX

•If you press [ENTER] on the desired track / file, playback will start.

e.g.) JPEG

- - / 20

File List

JPEG_DISC

Folder_1

Folder_2

Folder_3

JPEG_A JPEG_B JPEG_C JPEG_D

Page Up Page Down Media Mode

1. Audio CD

Track information

/ MP3 / WMA / JPEG

DivX

File information

2. Audio CD

“CD-DA” will be displayed

DivX® / MP3 / WMA / JPEG

Current Disc, SD card, or folder name will be displayed

3. Audio CD

List of the track number and time

DivX® / MP3 / WMA / JPEG

List of the folder or file names in the current disc or folder

4. Operation guide

Press [Red] to go to the previous page Press [Green] to go to the next page Press [Yellow] to call up the subtitle list Press [Blue] to select “Media Mode”

5. Current page / Total page number

6. Playback status

7. Media icon

/ MP3 / WMA / JPEG files).

562

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

1 Insert an audio CD or a media with DivX

(not available for SD card), MP3, WMA or JPEG files.

• Media filter screen will appear.

• For audio CD and a disc contains only one type of file, skip to step 3.

2 Select the type of the file you want to play

back in the media filter screen. Then press [ENTER] to display the file list.

: Folder : audio CD tracks

: WMA files : JPEG files

To stop playback:

Press [STOP C].

DivX

files

: MP3 files

17EN

Video

㪉㩷㩷㪆㩷㩷㪊

T R

--/16

Pictures

E5RJ0BD_EN.book Page 18 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Note

• Unrecognisable characters will be replaced with asterisks.

• Some unplayable folders or files may be listed due to the recording status.

• High-resolution JPEG files take longer to be displayed.

• Progressive JPEG files (JPEG files saved in progressive format) cannot be played back in this unit.

• The system can recognise up to 255 folders / 999 files for CD, 999 folders / 9,999 files for BD, DVD and SD card.

• The 9th and deeper hierarchies cannot be displayed for CD. The 10th and deeper hierarchies cannot be displayed for DVD and SD card.

• For the SD card playback, refer to “Reading an SD Card” on page 18.

• Extensions other than listed below cannot be recognised.

: .avi / .AVI / .divx / .DivX

-DivX

-MP3 : .mp3

-WMA:.wma

- JPEG : . jpg / jpeg* * The extension “.jpeg” is not available for SD card.

• If a disc contains AVCHD files, the playback of other files which are in the same disc is not available.

• With regard to the multi-border BD-RE/-R, additionally recorded sections cannot be recognised.

• With regard to the multi-border DVD-RW/-R, additionally recorded sections may not be recognised.

4 Use [K / L] to select a desired folder or

file, then press [ENTER]. Use [s / B] to go in and out of folders.

• If you press [ENTER] on the desired file, playback will start.

Caution

• Do not remove the SD card or turn the unit to the standby mode while the contents of the card are in playback. It may result in malfunction or loss of the card’s data.

Note

• “Media Select” screen will disappear under the conditions listed below:

- when the screen saver is activated.

- when [RETURN] is pressed.

- when the setup menu is called up.

• If “Media Select” screen disappears before you make the selection, refer to “Selecting the Media” on page

16.

• Do not delete the folders or files in the SD card with your computer. This unit may not read the SD cards formatted on a computer.

• If a folder or file name includes one of the following unrecognisable characters, the folder or file name may not be displayed correctly.

- Unrecognisable characters :

. , " = + [ ] ; / \ : | ¥

Reading an SD Card

With SD card, you can enjoy the following functions in addition to playing back AVCHD / MP3 / WMA / JPEG files stored in the card.

- Special additional contents for BD-ROM Profile 1 ver.1.1. (For more information about the special additional contents, refer to the instruction book that came with the disc.)

- BD-Live function (BD-ROM ver. 2 Profile 2.0). (For more information about BD-Live, refer to page 23.)

1 Insert an SD card (refer to page 16 on how

to insert a disc).

If no disc is in operation, “Media Select” screen will appear on the TV screen.

Kodak Picture CD

This unit can also run JPEG files stored on Kodak Picture CD. You can enjoy picture images on the TV set by playing back the Kodak Picture CD. This unit conforms to ver.7.0 of Kodak Picture CD. For details of Kodak Picture CD, contact a shop that provides developing service of Kodak Inc.

1 Insert a Kodak Picture CD. Kodak Picture

CD menu will appear automatically on the TV screen.

Thumbnail

2 Use [K / L] to select “SD Card”, then press

[ENTER].

• When the SD card contains only one type of file, skip to step 4.

3 Select the type of the file you want to play

back. Then press [ENTER] to display the file list.

Please select the media to play back.

Audio


• For AVCHD files, the playback will start right after you select “Video”. (The file list is not available for AVCHD files.)

1. File information

2. Current page / Total page number

3. Operation guide

Press [Yellow] to go to the previous page Press [Blue] to go to the next page

4. Playback status

Page Prev Page Next

18 EN

E5RJ0BD_EN.book Page 19 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

2 Use [K / L / s / B] to select a desired file

to be played back, then press [PLAY B] or [ENTER].

• An image will be played back from the selected file and go to the next one in turn.

To stop playback: Press [STOP C].

To return to the first item: Press [TOP MENU].

To return to the file played back last: Press [POP MENU / MENU].

Tips for JPEG / Kodak Picture CD Playback

•Every press on [ANGLE] will turn the image clockwise by 90 degrees when an image is displayed.

• To change the visual effect for switching the playback image, press [MODE] once, then use [s / B] or [ENTER] to switch between “Cut In/Out” and “Fade In/Out”.

• During JPEG / Kodak Picture CD playback, press [MODE] twice to change the size of the playback image, then use [s / B] or [ENTER] to switch between “Normal” (100 %) and “Small” (95 %). The size change may have no effect on some files (e.g. files with a small picture size).

Note

• A file with an extension of “.avi” and “.DivX” is called as a DivX recognised as MPEG4.

• For CD-RW/-R, maximum of 255 group (folder) or 999 files may be recognised.

• For BD-RE/-R and DVD-RW/-R, maximum of 999 group (folder) or 9,999 files may be recognised.

• The 10th and deeper hierarchies cannot be displayed.

• Unrecognisable characters will be replaced with “*”.

• When playing back the files recorded in high bit rates, the images can be interrupted in some occasions.

• Although DivX it may not be able to play back some data, depending on the characteristics, bit rates, or audio format settings, etc.

• If a large-sized DivX time for the file to start the playback (over 20 seconds sometimes).

•If DivX back, rewrite them on a BD-RE/-R or DVD-RW/-R, and try playing it back again.

• For more information for DivX http://www.divx.com.

file. All files with “.avi” extension are

logo has been obtained for this unit,

file is selected, please allow

files written on a CD-RW/-R cannot be played

, please visit

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Special Playback

About DivX® and DivX® VOD

Hint for the purchased or rented official DivX product

• When you purchase or rent a DivX® file through the official site of DivX

video which is called DivX® Video OnDemand (VOD) services, a registration code is required every time you get the new file from the DivX services. Refer to “DivX

VOD” in “FUNCTION SETUP” on

page 30.

Possible Errors “This rental has c views left. Do you want to use one of

your c views now?”

Some DivX

VOD files are restricted with the limited playable times. You cannot play them back beyond the limit.

“This player is not authorized to play this video.”

You cannot play back the DivX

VOD files obtained with

different registration codes on this unit.

“This rental is expired.”

You cannot play back the DivX

VOD files with the expired

rental period.

“This player does not support this video format.”

You cannot play back the DivX

files whose image size

exceeds 720 x 576.

“This player does not support this audio format.”

For DivX

files with audio format other than MPEG1 audio layer 3 (MP3), MPEG1 audio layer 2 and Dolby Digital, audio will not be output and only the video will be output.

“This player does not support this video frame rate.”

You cannot play back the DivX

files whose frame rate

exceeds 30 fps.

Certified

VOD

Playing Back a DivX® with DivX® External Subtitle

Subtitles created by the user can be displayed during

DivX

playback.

1 Follow steps 1 to 3 in “Playing Back (Audio CD

or a Media with DivX®/MP3/Windows Media™ Audio/JPEG Files)” on page 17.

2 Select a file you want to play back, then press

[Yellow].

Subtitle list will appear.

T R

- / 9

Subtitle List

DivX_File

[Off]

[ASS]

[SMI] [SRT] [SSA] [SUB] [TXT]

File List

• “DivX Subtitle” appears next to “Yellow” icon only when DivX® subtitle is available for the selected file.

•If you press [PLAY B] or [ENTER] instead of [Yellow], playback without subtitle will start.

3 Select the desired subtitle file, then press

[PLAY B] or [ENTER].

Playback of the DivX® file with DivX® subtitle will start.

19EN

E5RJ0BD_EN.book Page 20 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Note

• To utilise this function, the following conditions must meet.

- Playback file and the subtitle file must have the

same name.

- Playback file and the subtitle file must locate in the

same folder.

- Only the subtitle files with the following extensions

are supported; .smi (.SMI), .srt (.SRT), .sub (.SUB), .ass (.ASS), .ssa (.SSA), .txt (.TXT). (.sub (.SUB) and .txt (.TXT) may not be recognised.)

- The subtitles that exceeds the playback time of the

DivX

file will not be displayed.

Fast Forward / Fast Reverse

1 During playback, press [FWD D] repeatedly

for fast forward.

During playback, press [REV E] repeatedly for fast reverse. Every time you press [FWD D] or [REV E], the playback speed will change.

2 Press [PLAY B] to return to normal playback.

Note

• For BD, DVD and AVCHD, speed changes in 5 different levels.

• For audio CD, DivX Audio, speed changes in 3 different levels.

• For audio CD, fast forward / fast reverse search between different tracks are not available during programme and random playback.

•For DivX forward / fast reverse search between different files are not available.

•For some DivX not function.

, MP3 and Windows Media™ Audio, fast

Slow Motion Playback

, MP3 and Windows Media™

files, fast forward/fast reverse may

Step by Step Playback

1 In pause mode, press [PAUSE F] repeatedly.

Every time you press [PAUSE F], playback will advance one step at a time.

2 Press [PLAY B] to return to normal playback.

Note

• Only step by step forward is available.

• Set “Still Mode” setting to “Field” in “Video” menu if pictures in step by step playback mode are blurred. Refer to “Still Mode” on page 28.

Repeat Playback

Available repeat functions vary depending the discs.

1 During playback, press [REPEAT] repeatedly to

select the desired repeat mode.

Repeat mode Available media

Chapter repeat

The current chapter will be played back repeatedly.

Title repeat

The current title will be played back repeatedly.

Track repeat

The current track will be played back repeatedly.

Group repeat

The current folder will be played back repeatedly.

All repeat

All tracks or files in the media will be played back repeatedly.

1 During playback, press [PAUSE F], then press

[FWD D].

Every time you press [FWD D], playback speed will change.

2 Press [PLAY B] to return to normal playback.

Note

• Slow motion speed changes in 3 different levels.

• Only slow forward is available.

• Set “Still Mode” setting to “Field” in “Video” menu if pictures in the slow motion playback mode are blurred. Refer to “Still Mode” on page 28.

•For some DivX

files, slow forward may not function.

Note

• The repeat setting will be cancelled when you stop playback.

• The chapter, title, track or group repeat will be cleared when moving to another chapter, title, track / file or folder.

• Repeat playback does not function during A-B repeat playback.

• Chapter and title repeat are not available with some scenes.

• When the repeat setting is set for a MP3 or WMA folder (file), the repeat setting will be cancelled if you select other MP3 or WMA folder (file) to play back.

20 EN

E5RJ0BD_EN.book Page 21 Tuesday, October 20, 2009 3:53 PM

A-B Repeat

Before you begin

You can play back the specific part (between point A and point B) repeatedly.

1 During playback, press [A-B] at the desired

starting point A.

2 During playback, press [A-B] at the desired

ending point B.

As soon as you set the point B, the part between point A and point B will start playback repeatedly.

• To cancel the A-B repeat, press [A-B] again.

Note

• Point B should be set within the same title or track as point A.

• A-B repeat is not available with some scenes.

• To cancel the A point which was set, press [CLEAR].

• A-B repeat does not function during repeat playback.

•For some DivX function.

Programme Playback

files, A-B repeat playback may not

PLAYBACK

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

6. Playback status

7. Current page / Total page number

8. Operation guide

Press [Red] to go to the previous page in the track / folder / file list Press [Green] to go to the next page in the track / folder / file list Press [Yellow] to go to the previous page in the programmed list Press [Blue] to go to the next page in the programmed list

•For DivX®, MP3, WMA or JPEG files, use [K / L] to select a folder, then press [ENTER] first, and then use [K / L] to select a file, then press [ENTER].

•Press [CLEAR] to erase the last file of the programme.

•Use [K / L] to select “All Clear” at the bottom of the list to erase all the tracks / files in the programme.

•Use [s / B] to go back / forward between the hierarchy of folders.

3 Press [PLAY B] to start programme playback.

• The programme playback will start.

To exit from the programme playback mode:

•Press [RETURN] in stop mode.

You can play back the disc/card in your desired order.

1 In stop mode, press [MODE]. 2 Use [K / L] to select a track / folder / file, then

press [ENTER].

e.g.) audio CD

1623 4

- - / 16

Program CD-DA

0:36

1:14

0:45

0:50

0:53

0:20

0:54



Page Up Page Down Page Prev Page Next

1. Audio CD

Track information

DivX

/ MP3 / WMA / JPEG

File information

2. Audio CD

“CD-DA” will be displayed

DivX® / MP3 / WMA / JPEG

Current disc, SD card, or folder name will be displayed

3. Track / Folder / File list

Track / Folder / File list in the original order

4. Programmed list

Track / File list in the programmed order

5. Cumulative playback time of all tracks in the programmed list (audio CD only)

Total

11 12 14

0 : 26 : 24

1:14 0:50

1:14

0:50 0:53 0:54 0:36



7 8

Note

• During programme playback, press [STOP C] once to set the resume point, and then press [PLAY B] to resume programme playback from where [STOP C] was pressed (audio CD) or from beginning of the file where [STOP C] was pressed (MP3 / WMA / JPEG).

• During programme playback, press [STOP C] twice to display the programme screen. To go back to the normal programme playback, press [RETURN] to exit from the programme screen, then press [PLAY B].

• Up to 99 tracks / files can be entered.

• To repeat the current track / file in the programme, press [REPEAT] repeatedly until “ Track” appears during playback. To repeat the entire

programme, press [REPEAT] repeatedly until “ All” appears during playback.

• Playback from a desired track / file and random playback are not available during programme playback.

• Press

[MODE]

• The programme will be cleared when;

- the unit is turned into the standby mode.

- the media is switched.

- the disc / card is removed (as for “Disc” mode, just

opening the disc tray will clear the programme info).

to switch to the random playback mode.

21EN

E5RJ0BD_EN.book Page 22 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Random Playback

This function shuffles the playback order of tracks / files.

1 In stop mode, press [MODE] twice.

e.g.) audio CD

1623 4 5

- - / 16

Random CD-DA

1 0:36 2 3 4 5 6 7

1:14 0:45 0:50 0:53 0:20 0:54

Page Down

Total

1 : 13 : 29



1. Audio CD

Track information

MP3 / WMA / JPEG

File information

2. Audio CD

“CD-DA” will be displayed

MP3 / WMA / JPEG

Current disc, SD card, or folder name will be displayed

3. Track / File list

Track / File list in the original order will be displayed

4. Operation guide

Press [Red] to go to the previous page in the track / file list Press [Green] to go to the next page in the track / file list

5. Total playback time of all tracks (audio CD only)

6. Playback status

2 Press [PLAY B] to start random playback.

To exit from the random playback mode:

•Press [MODE] in stop mode.

Note

• During the random playback, press [STOP C] once to set the resume point, and then press [PLAY B] to resume random playback from where [STOP C] was pressed (audio CD) or from beginning of the file where [STOP C] was pressed (MP3 / WMA / JPEG).

• To repeat the current track / file in the random selection, press [REPEAT] repeatedly until

“ Track” appears during playback. To repeat the entire random selection press [REPEAT] repeatedly until “ All” appears during playback.

• Playback from a desired track / file is not available during random playback.

• In stop mode, press [RETURN] to switch to the programme playback mode.

• For a disc containing mixed MP3 and Windows Media™ Audio files, random playback of those files will be performed.

Rapid Playback

This function plays back approximately at 1.3 times the normal playback while keeping the sound output. This function is available only on discs recorded in the Dolby Digital format.

1 During playback, press [MODE] repeatedly

until appears.

2 Press [ENTER] or [s / B] to change the setting.

“Off” : Plays back in normal speed.

: Plays back approximately at 1.3 times of normal

“”

playback.

3 Press [PLAY B] to return to normal playback.

Note

• Picture adjustment and audio language setting cannot be changed during this function.

• Virtual surround does not work during this function.

• This function may not work at some points on a disc.

• During this function, 2ch LPCM will be output from HDMI OUT jack and DIGITAL OUT jack.

Useful Function

Noise Reduction

Reduces the noise of the playback picture.

1 During playback, press [MODE] repeatedly

until appears.

2 Use [s / B] to change the setting.

“Off” : Shows the original picture as recorded. “1” :Executes 3D noise reduction which detects and

deletes the noise by comparing each picture frames.

“2” :Executes MPEG noise reduction which reduces

the block noise and mosquito noise on the subtitles on the movie.

“3” :Executes both MPEG noise reduction and 3D

noise reduction.

3 Press [RETURN] to exit.

Note

• The setting will remain the same even if the unit is turned to the standby mode.

• You cannot adjust the setting during rapid playback.

22 EN

E5RJ0BD_EN.book Page 23 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Virtual Surround

You can enjoy stereophonic virtual space through your existing 2-channel stereo system.

1 During playback, press [MODE] repeatedly

until appears.

2 Use [K / L] to change the setting.

“Off” : No surround effect “1” :Natural surround effect “2” :Stronger surround effect

3 Press [RETURN] to exit.

Note

• Set the virtual surround setting to “Off” or lower the volume if the sound is distorted.

• Virtual surround does not function during rapid playback.

• For virtual surround, audio signal will always be 2-channel LPCM.

PIP (BONUSVIEW) Setting

Some BD-videos have the PIP function which enables you to display the secondary video in the primary video. You can call up the secondary video by pressing [PIP] whenever the scene contains the secondary video.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Camera Angle

Some BD-videos and DVD-videos contain scenes which have been shot simultaneously from various angles. You

can change the camera angle when appears on the TV screen.

1 During playback, press [ANGLE]. 2 Use [K / L] to select your desired angle.

1 / 3

3 Press [RETURN] to exit.

Note

• If “Angle Icon” setting is “Off” in “Others” menu, will not appear. Refer to page 30.

Enjoying BD-Live Discs with Online Content

You can enjoy the BD-Live functions which enable you to use the interactive functions when the unit is connected to the Internet. (For the Network connection, refer to page 36.) Examples for BD-Live interactive functions:

• Download the additional contents such as the movie’s trailer, subtitles and BD-Java, etc.

• While downloading, special video data may be played back.

Service and functions differ depending on the disc. Follow the instructions given by the disc when using the BD-Live function.

primary

video

secondary

video

1 During playback, press [PIP]. 2 Use [K / L] to select the secondary video you

want.

3 / 32

3 Press [RETURN] or [PIP] to remove the PIP

information.

Note

• The secondary audio will not be output when the secondary audio is set to “Off ” or when “BD Audio Mode” is set to “HD Audio Output”. Refer to “Switching Audio Soundtrack” on page 25 and “Setting the BD Audio Mode” on page 26.

Note

• You must connect the unit to the Internet and set up necessary settings in order to use the BD-Live function.

• For certain discs, setting for “BD-Live Setting” may need to be changed.

• Depending on your connection environment, it may take time to connect to the Internet or the Internet may not be connected.

• When BD-Live functions are used and the unit is connected to the Internet, you may be charged for this communication.

• While connecting to BD-Live, sometimes it can take awhile before the next page is downloaded or refreshed.

• You must insert an SD card when using the BD-Live function. (SD card of 1GB is recommended.)

• Do not remove the SD card when using the BD-Live function.

Note for AACS Online

• The player or disc IDs may be sent to the content provider when playing back a disc with BD-Live function.

• If you save your viewing history on the server by using these IDs, you will be introduced to other similar movies.

• You can save game score histories.

23EN

E5RJ0BD_EN.book Page 24 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Using [SKIP H / G]

1 During playback, press [SKIP G] to move to

the next track / title / chapter / file. Press it repeatedly to skip to subsequent tracks. Press [SKIP H] once to go back to the beginning of the current track. Press it repeatedly to go to the previous tracks.

• For JPEG files, press [SKIP H] to go back to the previous file.

Note

• If title contains no chapters, [SKIP H / G] changes the title.

• For JPEG files, [s / B] is also available.

Using [SEARCH]

By using [SEARCH], you can select the following search modes.

Search mode Available media

Chapter / Title search

Track search

Using [Number buttons] (Direct Search)

Title Search

In stop mode, enter the title number you want to search using [Number buttons].

Playback of the title will start in a few seconds.

Chapter Search

During playback of a title, enter the chapter number you want to search using [Number buttons].

Playback of the chapter will start in a few seconds.

Track / File Search

Enter the track / file number you want to search using [Number buttons].

Playback of the track / file will start in a few seconds.

Note

• As for the BD-video, how it performs will be strongly determined by the disc, and may not perform as described here.

Time search

1 During playback, press [SEARCH] repeatedly

until your desired search mode appears.

2 Enter the desired chapter, title, track, file

number or time to search for using [Number buttons].

• Chapter, title, track or time search will start.

•Press [CLEAR] to erase an incorrect input.

Note

• During programme and random playback, search functions are not available except the search using [SKIP H / G].

• Time search is available only in the same track, file or title.

• For BD and AVCHD, chapter and time search are available only during playback.

•For some DivX

files, time search may not function.

24 EN

E5RJ0BD_EN.book Page 25 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

You can select the format of audio and video as you prefer depending on the contents of the disc you are playing back.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Switching Subtitles

Some BD, DVD and AVCHD materials may have subtitles in 1 or more languages. For commercially available discs, the supported languages can be found on the disc case. Follow the steps below to switch the subtitle languages during playback.

1 During playback, press [SUBTITLE]. 2 Use [K / L] to select the desired item to set,

then press [ENTER].

“Primary Subtitle” : Sets the subtitle for the

primary video.

“Secondary Subtitle” : Sets the subtitle for the

“Subtitle Style” : Sets style of the subtitle.

secondary video.

3 Use [K / L] to select your desired subtitle or

style.

•Use [s / B] to switch between current subtitle

setting and “Off”.

4 Press [SUBTITLE] to exit.

1 During playback, press [SUBTITLE]. 2 Use [K / L] to select your desired subtitle.

1 / 4

•Use [s / B] to switch between current subtitle

setting and “Off”.

3 Press [SUBTITLE] to exit.

Note

• Some discs will only allow you to change the subtitles from the disc menu or pop-up menu. Press [TOP MENU] or [POP MENU / MENU] to display the disc menu or pop-up menu.

• If 4-digit-language code appears in the subtitle menu, refer to “Language Code List” on page 40.

• If the disc has no subtitle language or subtitle style, “Not Available” will be displayed on the TV screen.

• During playback of the secondary video, the primary subtitle setting is not available except when there is no subtitle for the secondary video.

• If you select a language that has a 3-letter-language code, the code will be displayed every time you change the subtitle language setting. If you select any other languages, “---” will be displayed instead. (Refer to page 40.)

•For DivX DivX® with DivX® External Subtitle” on page 19.

external subtitle, refer to “Playing Back a

Switching Audio Soundtrack

Some BD, DVD, audio CD and AVCHD materials contain multiple audio streams. Those are often in different audio languages or audio formats. For BD, available audio varies depending on “BD Audio Mode” setting. Refer to page 28 for more information.

1 During playback, press [AUDIO]. 2 Use [K / L] to select the desired item to set,

then press [ENTER].

“Primary” : Sets the audio for the primary video. “Secondary” : Sets the audio for the secondary video.

3 Use [K / L] to select your desired audio stream

channel.

• For “Secondary”, use [s / B] to switch between current audio setting and “Off”.

4 Press [AUDIO] to exit.

1 During playback, press [AUDIO]. 2 Use [K / L] to select your desired audio stream

channel.

e.g.) DVD-video

Dolby D

ENG

• For audio CD, you can select following options.

“Stereo” : Both right and left channels are active

(stereo).

“L-ch” : Only left channel is active. “R-ch” : Only right channel is active.

3/2.1ch

/ 31 48k

3 Press [AUDIO] to exit.

• For DTS-CD (5.1 music disc), “DTS” will be displayed. (Selecting audio streams or channels is not available.)

25EN

E5RJ0BD_EN.book Page 26 Tuesday, October 20, 2009 3:53 PM

PLAYBACK

Note

• The secondary audio will not be output when the secondary video is not displayed or when “BD Audio Mode” is set to “HD Audio Output”. (For some BDs, secondary audio will be output even when secondary video is off.)

• The sound mode cannot be changed during playback of discs not recorded in multiple audio.

• Some discs allow changing the audio language setting on the disc menu. (Operation varies depending on the discs. Refer to the manual accompanying the disc.)

• [AUDIO] may not work on some discs with multiple audio streams or channels (e.g. DVDs that allow changing audio setting on the disc menu).

• If you select a language that has a 3-letter-language code, the code will be displayed every time you change the audio language setting. If you select any other languages, “---” will be displayed instead. (Refer to page 40.)

• Audio Language selection cannot be made during rapid playback. (Refer to page 22.)

• If 4-digit-language code appears in the audio menu, refer to page 40.

• If the disc has no audio language, “Not Available” will be displayed on the TV screen.

Setting the BD Audio Mode

There are 2 options for “BD Audio Mode” setting; either by setting the output to the secondary and interactive audio accompanied by the primary audio or by setting only the primary audio. (Refer to pages 33-34 for more information.)

1 In stop mode, press [MODE] repeatedly until

appears .

2 Use [K / L] to change the setting.

“Mix Audio Output”:

If it is available, BD-video’s secondary and interactive audio will be output with the primary audio.

• The secondary audio is the audio for the secondary video (Director’s commentary, etc.) and the interactive audio is the audio for the interactive application (Button click sounds etc.).

“HD Audio Output”:

Only the primary audio will be output. Set this mode in order to output , Dolby Digital Plus, Dolby TrueHD, or DTS-HD audio of BD through HDMI connection.

3 Press [RETURN] to exit.

Note

• You can also set “BD Audio Mode” from the setup menu. Refer to page 28.

• Refer to “Audio signals output from HDMI OUT jack” on page 33 and “Audio signals output from DIGITAL OUT (OPTICAL / COAXIAL) jack” on page 34 for how BD Audio will be output.

• In “Mix Audio Output” mode, if there is no secondary and interactive audio, the audio will be output as “HD Audio Output” mode.

26 EN

E5RJ0BD_EN.book Page 27 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

In the setup menu screen, you can access various kinds of menus, and customise them as you prefer. To call up the setup menu screen, press [SETUP]. Then follow the instructions below to navigate through the screen.

< Setup menu screen >

1. Quick menu

Quic

Media Select

HDMI Audio Out

HDMI Video Resolution

Component Output

Disc

HDMI Multi(Normal)

Auto

480i/576i

How to Navigate through the Setup Menus

•Use [K / L] to move the highlight up and down.

•Press [ENTER] to access the options of an item, to switch settings, or to confirm the selection.

•Use [s / B] to switch settings in some menus.

•Press [RETURN] to go back to the previous screen.

•Press [SETUP] to exit.

List of Setup Menus

Items with (*) can be accessed from “Quick” menu also. The items highlighted in grey are the default setting.

Category Menus / Options Description

Language Audio Original Chinese

English German French Italian Spanish Dutch Swedish Russian

Off Chinese English

German French Italian Spanish Dutch Swedish Russian

English Japanese German

French Italian Spanish Dutch Swedish Russian Chinese

English Portuguese German

French Italian Spanish Dutch Swedish Russian1 Russian2

Custom

Subtitle

Disc Menu

DivX Subtitle

Japanese Korean Danish Finnish Norwegian Icelandic Hungarian Romanian

Korean Danish Finnish Norwegian Icelandic Hungarian Romanian Turkish

Polish

Contains only the frequently used menus.

2. Custom menu

Contains all the available setup menus.

3. Initialise menu

Contains the menus that relates to the initialisation of the unit or the SD card.

4. Menu window

Displays the available items for the selected menu.

Turkish Greek Irish Portuguese Polish Czech Slovak Bulgarian Other

Greek Irish Portuguese Polish Czech Slovak Bulgarian Other

Sets the audio language for BD-video, DVD-video or AVCHD file playback.

“Original”:

Activates the disc’s original language.

“Other”:

If you select “Other”, enter 4-digit-code for the desired language (refer to page 40).

Sets the subtitle language for BD-video, DVD-video or AVCHD file playback.

“Other”:

If you select “Other”, enter 4-digit-code for the desired language (refer to page 40).

Sets the language for disc menu.

“Other”:

If you select “Other”, enter 4-digit-code for the desired language (refer to page 40).

Sets the language for DivX® subtitle. If the DivX® subtitle file contains more than one subtitle language, you can toggle those by pressing [SUBTITLE] repeatedly.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

27EN

E5RJ0BD_EN.book Page 28 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

Category Menus / Options Description

Video TV Aspect

Custom

Audio BD Audio Mode

• Refer to page 32 for more information.

HDMI Video Resolution*

•This feature is available only when the display device is connected by an HDMI cable.

• Refer to page 32 for more information.

HDMI Deep Color

•This feature is available only when the display device is connected by an HDMI cable, and when it supports Deep Colour feature.

Component Output*

Progressive Mode

Still Mode

16:9 Wide Sets the aspect ratio of the playback image to fit your 4:3 Pan & Scan

4:3 Letter Box 16:9 Squeeze

Auto Sets the resolution of the video signal being output 480p/576p

720p 1080i 1080p 1080p24

Auto Reduces the posterisation effect of the playback Off

480i/576i Sets the resolution for the component output picture. 480p/576p

720p 1080i

Auto “Auto”: Video

Auto Adjusts picture resolution and quality in still mode. Field

Frame

Mix Audio Output For BD, selects whether to output the secondary and HD Audio Output

TV.

from the HDMI OUT jack.

picture.

“Auto”:

Reduces the posterisation effect by automatically outputting up to 12 bit colour whenever the unit recognises the connected display device supports Deep Colour feature.

“Off”:

Outputs the standard 8 bit colour.

The progressive mode will detect 24-frame film material (movies) and automatically select appropriate progressive mode.

“Video”:

Suited for playing back video material discs (TV shows or animation).

“Auto”:

Automatically selects the best resolution setting (“Frame” or “Field”) based on the data characteristics of the pictures.

“Field”:

Stabilises the pictures, although the picture quality may become coarse due to the limited amount of data. Select “Field” when the pictures are still unstable even if “Auto” is selected.

“Frame”:

Displays relatively motionless pictures in higher resolution. “Frame” improves the picture quality, although it may unstabilise the pictures due to alternate output of 2-field data.

• An individual picture on the TV screen is called “Frame”, which consists of two separate images called “Field”. Some pictures may be blurred at the auto setting in “Still Mode” setting due to their data characteristics.

interactive audio with primary audio if it is available or only the primary audio. Refer to “Setting the BD Audio Mode” on page 26.

“Mix Audio Output”:

The audio for the secondary video and the interactive application will be output together with the audio for the primary video.

“HD Audio Output”:

Outputs only the primary audio. Set this mode in order to output Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD audio of BD through HDMI connection.

28 EN

E5RJ0BD_EN.book Page 29 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

Category

Audio HDMI Audio Out*

Custom

•This feature is available only when the display device is connected by an HDMI cable.

• Refer to page 33 for more information.

Menus / Options Description

HDMI Multi (Normal)

HDMI Multi (LPCM)

Audio Mute

• Refer to “Digital Out” setting on page 34 for setting options.

Outputs the multi-channel audio signals from HDMI OUT jack with bitstream or LPCM.

Speaker

Front Large Sets the speaker

Size

Center Small Subwoofer Surround Surround

Back Default

Channel

Test Tone Off Outputs the test tone from

Level

Front Lch -12 to Center Subwoofer Front Rch Surround

Rch Surround

Back Rch Surround

Back Lch Surround

Lch Default Distance Feet Sets the desired measure

Delay Time

Front Center

Surround Surround

Back Default Bitstream “Bitstream”:

Digital Out

LPCM

configuration to suite the size/number of your

speakers.

Large

Press [ENTER] to change

Small

the setting.

each speaker.

Manual

Use [s / B] to switch

Auto

options, then press [ENTER] to confirm.

•Test tone will be output automatically.

• To stop the test tone, press [RETURN].

“Manual”:

Allows you to manually select the speaker to test. Use [K / L] to select the speaker. Use [s / B] to adjust the volume.

“Auto”:

Automatically tests all speakers. Use [s / B] to adjust the volume.

Sets the volume level for

0dB

each speaker to get the

(Default

ideal audio balance.

0dB)

Use [s / B] to change the setting.

system. This measure

Meters

system will be used for “Delay Time” setting. Use [s / B] to change the setting.

0 to 18m

Sets the distance from the

(Default

listening point to the

3.6m)

speaker to get the ideal delay time.

0 to 18m

Use [s / B] to change the

(Default

setting.

3.0m)

When playing back discs recorded in Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD, the corresponding core stream (Dolby Digital or DTS) are output. “LPCM”: LPCM signal will be output from DIGITAL OUT jack.

Sets the audio format for the sound output from the HDMI OUT jack.

• For “Speaker Size” and “Delay Time”, if you change the setting of one speaker, the rest of the speakers will be set automatically. For “Delay Time”, difference of the values among “Front”, “Surround” and “Surround Back” cannot exceed 4.5m (15 ft), and between “Front” and “Center” it cannot exceed

1.5m (5 ft).

• For “Delay Time”, the value of “Center”, “Surround” and “Surround Back” cannot exceed the value of “Front”.

Sets the audio format output from DIGITAL OUT jack.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

29EN

E5RJ0BD_EN.book Page 30 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

Category Menus / Options Description

Audio Down Sampling On Sets the digital audio output when playing back BD or

Off

DRC

Auto Sets whether to compress the range of sound volume On Off

Parental

• Refer to page 35 for more information.

Password input field BD Rating

Level DVD Rating

Level

All Sets the rating level for the disc playback. Age Setting All Sets the rating level for the disc playback. 8

to 1

Password

Password input field Sets the new password for “Parental” setting.

Change

Others Angle Icon

On Sets whether to display the angle icon on the TV when Off

Auto Power Off

On Sets whether to turn off the unit (to the standby mode) Off

Panel Display

Auto Sets the brightness of the front panel display. Bright

Custom

DivX

VOD

Dimmer Registration

Code

Your registration code is :

cccccccccc

To learn more visit www.divx.com/vod

Deactivation Code

Your deactivation code is :

cccccccc

To learn more visit www.divx.com/vod

Deactivation

No This menu deactivates the DivX® VOD files and Yes

HDMI CEC

•This feature is available only when the display device is connected with an HDMI cable, and when it supports HDMI CEC feature.

• Refer to page 35 for more information.

Media Select*

On Sets whether to utilise the HDMI CEC function. Off

Disc Select the media to play back. SD Card

DVD recorded in LPCM.

“On”:

LPCM signals are converted to 48 kHz for output. Set to “On” when using digital connections to an AV amplifier that is not compatible with sampling frequencies of 96 kHz.

“Off”:

For BD and DVD recorded in LPCM without copyright protection, 2-channel audio signals up to 192 kHz are output as LPCM signals with no conversion.

(dynamic range control) when Dolby Digital, Dolby Digital Plus or Dolby TrueHD audio is played back.

playing back the scene with various angles.

automatically after 30 minutes of no action.

When “Auto” is selected, the front panel display automatically goes dim during playback.

This menu item provides you with the DivX® VOD registration code. The DivX

registration code is required when downloading the DivX the Internet. To learn more about DivX www.divx.com/vod.

This menu item provides you with the DivX deactivation code. The DivX

deactivation code is required when re-downloading the DivX from the Internet after deactivating. To learn more about DivX

VOD, visit www.divx.com/vod.

provides you with new registration code and deactivation code in order to download the DivX files from the Internet.

VOD files from

VOD, visit

VOD

VOD files

VOD

30 EN

E5RJ0BD_EN.book Page 31 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

Category Menus / Options Description

Others Network

Custom

Connection

• Refer to pages 3638 for more information.

Connection Test

Enable (Easy)

Enable (Custom)

Disable Deactivates the network connection.

IP Address Setting

IP Address Input field Allows you to set “IP Address”, “Subnet Mask” and Subnet

Mask Default

Gateway DNS

Setting

Primary DNS

Secondary DNS

Proxy Setting

Proxy Address

Proxy Port

Connection Speed

BD-Live Setting

MAC Address You can check the MAC Address.

Auto (DHCP) Sets the IP Address. Manual

Auto (DHCP) Sets the DNS Setting. Manual

Input field Allows you to set “Primary DNS” and “Secondary DNS”

Do Not Use Sets the proxy server. Use

Input field Allows you to set “Proxy Address” and “Proxy Port”

Auto Sets the connection speed. 10BASE Half 10BASE Full 100BASE Half 100BASE Full Allow You can restrict Internet access when BD-Live Limited

Allow Prohibit

Performs the network connection test. After you change the IP Address or DNS Setting, always perform this test.

If you select “Enable(Easy)”, Connection test will automatically start.

In most cases, you can connect to the Internet without making any changes to the default setting.

“Default Gateway” manually.

• Available only when “Manual” is selected in “IP Address Setting”.

In most cases, you can connect to the Internet without making any changes to the default setting.

manually.

• Available only when “Manual” is selected in “DNS Setting”.

In most cases, you can connect to the Internet without using proxy server.

manually.

• Available only when “Use” is selected in “Proxy Setting”.

In most cases, you can connect to the Internet without making any changes to the default setting.

functions are used.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Setup No

Format SD Card

Erase Saved BD-ROM Data (Player)

Erase Saved

Initialize

BD-ROM Data (SD Card)

Network Settings

Software Update

• Refer to page 39 for more information.

Yes No Re-formats SD card. Yes No Re-formats local storage (Player) used for BD-Java. Yes

No Re-formats local storage (SD card) used for BD-Java. Yes

No Initialises network settings. Yes

Current Version

Disc Update

• Refer to page 39 for more information.

No Allows you to update this unit’s firmware using a disc. Yes

Indicates the current firmware version.

Resets all the settings, except for “Parental” and “Network Connection” to the factory default.

31EN

E5RJ0BD_EN.book Page 32 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

TV Aspect

[Setup] A “Custom” A “Video” A “TV Aspect”

Use this feature to adjust the aspect ratio of the video source which is different from your TV’s ratio to fit your TV monitor without distorting the picture. Descriptions of each setting are as follows:

Video source Your TV Option Description

4:3 Letter Box To enjoy 16:9 picture on 4:3 monitor:

16:9 picture is scaled down until both sides of the picture fits the 4:3 TV.

4:3

16:9

4:3

4:3 Pan & Scan To enjoy 16:9 picture on 4:3 monitor:

Both sides of the picture are trimmed to fit the 4:3 TV without distorting the aspect ratio of the picture.

16:9 Wide To enjoy 16:9 picture on 16:9 monitor:

Select this setting when you want to enjoy 16:9 picture on the 16:9 TV.

16:9 Squeeze To enjoy 4:3 picture on 16:9 monitor:

Use this setting to display 4:3 picture on the 16:9 TV without distorting the aspect ratio of the picture.

Note for “HDMI Video Resolution” and “Component Output”

• The selected resolution must also be supported by your display device.

• Even if you set “HDMI Video Resolution” setting to “Auto”, when this unit is connected to a DVI compatible display devices with an HDMI-DVI cable, 480p/576p signal will be output.

• Video and audio signals may be distorted temporarily when switching to / from the HDMI output mode.

• You cannot change the video resolution during playback of BDs or AVCHD files. To change the resolution, stop playback.

• In order to get natural and high quality film reproduction of 24-frame film material, use an HDMI cable (High Speed HDMI Cable is recommended) and select “Auto” if the connected TV is compatible with 1080p24 frame input.

• For AVCHD / DivX frame will be output even if the connected TV is compatible with 1080p24 frame input and you set “HDMI Video Resolution” setting to “Auto” or “1080p24”.

•Pressing [PLAY B] on the front panel for 5 seconds changes the setting back to its default.

• When you change the resolution, the TV monitor temporarily goes blank and then comes back again. This is not a malfunction.

• If you have selected the resolution not supported by your TV by mistake and the picture gets disturbed or goes blank and does not come back, press and hold [PLAY B] on the front panel for 5 seconds to change the setting back to its default.

• When HDMI cable is connected, only “480i/576i” and the resolution selected in “HDMI Video Resolution” will be available for “Component Output”.

• If the video resolution for the component output and HDMI video resolution do not match, the video resolution for the component output will be switched to “480i/576i”.

• If you play back copy-protected DVD-video, 480p/576p signal will be output from COMPONENT VIDEO OUT jacks, even when “Component Output” setting is set to “720p” or “1080i”.

• With some copy-protected BD-video, the video image may only be output from HDMI OUT jack.

• Refer also to your TV’s manual.

files, and for discs with the contents which are not compatible with 1080p24 frame, 1080p60

32 EN

E5RJ0BD_EN.book Page 33 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

HDMI Audio Out

[Setup] A “Quick” A “HDMI Audio Out”

Device to be connected “HDMI Audio Out” setting Output HDMI audio signal

Device compatible with Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD decoding

Device compatible with 3 or more channels of audio inputs (not Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD compatible)

HDMI connection to a TV and digital audio connection (optical / coaxial) to an AV amplifier

Audio signals output from HDMI OUT jack

Media Recording format

Dolby Digital Dolby Digital Dolby Digital Multi LPCM Multi LPCM

Dolby Digital Plus Dolby Digital Plus Dolby Digital

BD-video

DVD-video

AVCHD

DivX

audio CD / MP3 / Windows Media™ Audio

DTS-CD DTS Multi LPCM

*1) Full decoded. *2) Only the independent substream is decoded. *3) Dolby TrueHD stream is decoded. *4) Only the Dolby Digital substream is decoded. *5) Only the core substream is decoded. *6) When audio source is Multi-channel, decoded as 7.1ch. However, number of the output audio channel will depend

on the number of the connected speakers.

• If the connected device is not compatible with the HDMI BITSTREAM, audio will be output as multi LPCM or 2-channel down-mixed LPCM depending on the capability of the connected device even if you select “HDMI Multi(Normal)” in “HDMI Audio Out” setting.

• When playing back a BD-video which only contains the primary audio, the audio output will be the same case as the “HD Audio Output” even if the “BD Audio Mode” is set to “Mix Audio Output”.

Dolby TrueHD Dolby TrueHD Dolby Digital

DTS DTS DTS Multi LPCM

DTS-HD DTS-HD DTS

LPCM Multi LPCM Multi LPCM Multi LPCM Multi LPCM

Dolby Digital Dolby Digital Multi LPCM

DTS DTS Multi LPCM

LPCM 2ch LPCM 2ch LPCM

MPEG MPEG Multi LPCM

Dolby Digital Dolby Digital Multi LPCM

LPCM 2ch LPCM Multi LPCM

Dolby Digital Dolby Digital Multi LPCM

MP3 / MP2 2ch LPCM 2ch LPCM

HDMI Multi(Normal) Dolby Digital, Dolby Digital Plus, Dolby TrueHD,

HDMI Multi(LPCM) Multi-channel audio signals are output from

Audio Mute HDMI audio will be mute, and Dolby Digital / DTS

“HDMI Audio Out” setting

HDMI Multi(Normal) HDMI Multi(LPCM)

When “BD Audio Mode” is set to “HD Audio Output”

2ch LPCM 2ch LPCM

When “BD Audio Mode” is set to “Mix Audio Output”

DTS, or DTS-HD bitstream are output from HDMI OUT jack. Make the speaker settings on the connected AV amplifier, etc.

HDMI OUT jack. Make the speaker settings with the speaker setting items appear after you select “HDMI Multi(LPCM)”. Refer to page 29.

bitstream or LPCM will be output from DIGITAL OUT jack depending on “Digital Out” setting. Refer to page 34.

When “BD Audio Mode” is set to “HD Audio Output”

Multi LPCM

*1, *6

When “BD Audio Mode” is set to “Mix Audio Output”

Multi LPCM

*5, *6

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Note

• The audio signals from HDMI OUT jack (including the sampling frequency, the number of channels and bit length)

maybe limited by the device that is connected.

• Among the devices that support HDMI, some do not support audio output (e.g. projectors). In connections with

device such as this unit, audio signals are not output from HDMI OUT jack.

• Video and audio signals may be distorted temporarily when switching to / from the HDMI output mode.

33EN

E5RJ0BD_EN.book Page 34 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

Digital Out

[Setup] A “Quick” A “HDMI Audio Out” A “Audio Mute” A “Digital Out”

When “Audio Mute” is selected in “HDMI Audio Out” setting, HDMI audio signal will be mute and the audio signals output from DIGITAL OUT jack changes depending on “Digital Out” setting.

Audio signals output from DIGITAL OUT (OPTICAL / COAXIAL) jack

“Digital Out” setting

Bitstream LPCM

Media Recording format

Dolby Digital Dolby Digital Dolby Digital 2ch Downmix LPCM 2ch Downmix LPCM

Dolby Digital Plus Dolby Digital Dolby Digital 2ch Downmix LPCM 2ch Downmix LPCM

BD-video

DVD-video

AVCHD

DivX

audio CD / MP3 / Windows Media™ Audio

DTS-CD DTS 2ch Downmix LPCM

Dolby TrueHD Dolby Digital Dolby Digital 2ch Downmix LPCM 2ch Downmix LPCM

DTS DTS DTS 2ch Downmix LPCM 2ch Downmix LPCM

DTS-HD DTS DTS 2ch Downmix LPCM 2ch Downmix LPCM

LPCM 2ch Downmix LPCM 2ch Downmix LPCM 2ch Downmix LPCM 2ch Downmix LPCM

Dolby Digital Dolby Digital 2ch Downmix LPCM

DTS DTS 2ch Downmix LPCM

LPCM 2ch LPCM 2ch LPCM

MPEG MPEG Multi LPCM

Dolby Digital Dolby Digital 2ch Downmix LPCM

LPCM 2ch Downmix LPCM 2ch Downmix LPCM

Dolby Digital Dolby Digital 2ch Downmix LPCM

MP3 / MP2 2ch LPCM 2ch LPCM

When “BD Audio Mode” is set to “HD Audio Output”

2ch LPCM

When “BD Audio Mode” is set to “Mix Audio Output”

When “BD Audio Mode” is set to “HD Audio Output”

2ch LPCM

When “BD Audio Mode” is set to “Mix Audio Output”

Note

• In order to output LPCM signal from DIGITAL OUT jack while outputting the HDMI audio signal, set “HDMI Audio

Out” setting to “HDMI Multi(LPCM)”.

34 EN

E5RJ0BD_EN.book Page 35 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Parental

[Setup] A “Custom” A “Parental”

Some BD-videos or DVD-videos feature a parental lock level. Playback will stop if the ratings exceed the levels you set, it will require you to enter a password before the disc will play back. This feature prevents your children from viewing inappropriate material.

1. With “ ” selected press [ENTER].

Password input field appears.

2. If a password has not been set, follow A).

If a password has already been set, follow B). If you want to change the password, follow B) and C). If you forget the password, follow D).

A) Enter 4 digit password using [Number buttons].

• “4737” cannot be used. B) Enter 4 digit password C) Select “Password Change”, then press [ENTER].

Enter the new password.

D) Enter “4737”. Current password and “Parental”

settings are now cleared. Enter a new password.

3. Select the desired item to set the rating level for, then press [ENTER].

4. Select the desired rating level, then press [ENTER].

All Sets no limit. Age Setting Allows you to enter the age to limit, and

prohibits the playback of a disc whose rating level exceeds the age setting entered here.

• Enter the age as a 3-digit-number. (e.g., For age 15, enter [0], [1], [5].)

All Parental control is inactive; all discs can be

played back.

8 DVD software of any grades (adult /

general / children) can be played back. 7 [NC-17] No one under 17 admitted. 6 [R] Restricted; under 17 requires

accompanying parent or adult guardian. 5 [PGR] Parental Guidance Recommended. 4 [PG13] Unsuitable for children under 13. 3 [PG] Parental Guidance suggested. 2 [G] General audience. 1 Suitable for children.

HDMI CEC (REGZA - LINK)

[Setup] A “Custom” A “Others” A “HDMI CEC”

You can control all HDMI CEC compatible components connected via an HDMI cable by simple button operations of the remote control of this unit. In order to enable the function, you need to set “HDMI CEC” to “On”.

One Touch Play

When the operations with following buttons of the remote control of this unit are performed, the TV will automatically be turned on and switched to the appropriate input channel.

Buttons for one touch play:

- [PLAY B]

- [TOP MENU], or [POP MENU / MENU] (when a disc is inserted in the unit)

Standby

When you press and hold [ON/STANDBY Q] for 2 seconds, it turns off the power of the TV first and then turns off the power of this unit. When the connected HDMI CEC compatible display device is turned off, this unit may also turn off together.

System Information

Receiving Operational Signal from TV’s Remote Control

You can operate this unit with TV’s remote control. Check your TV owner’s manual for details.

• This function may not work properly depending on the

connected TV.

• The available operation may differ depending on the TV’s

remote control you use.

• Other components must be compatible with HDMI CEC

in order to use this function.

To Cancel Parental Lock Temporarily

Some discs allow you to cancel the parental lock temporarily. With those discs, the message below will appear when you try to play them back. “Enter current password.” Follow the instruction which appears on the TV screen to cancel the parental lock.

35EN

E5RJ0BD_EN.book Page 36 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

Network Connection

Set up the network connection settings in order to use the BD-Live function with a BD-Live disc.

Connection Test

[Setup] A “Custom” A “Others” A

“Network

Connection”

After you made IP address/DNS settings or when a LAN cable is connected, always perform the connection test to check if the connection is correctly made.

“Connection

Test”

1 In stop mode, press [SETUP].

2 Use [K / L] to select , then press [ENTER]. 3 Use [K / L] to select “Others”, then press

[ENTER].

4 Use [K / L] to select “Network Connection”,

then press [ENTER].

5 Use [K / L] to select “Connection Test”, then

press [ENTER].

Connection test will start automatically and the test result will appear right after the connection test finishes.

• “Testing...” : The test is in progress.

• “Pass” : Connection test is successfully

• “Fail” : Connection test failed.

Press [ENTER] to go to the list of network status confirmation screen.

completed.

Check the connection settings.

Others Connection Test

Enable(Easy)

[Setup] A “Custom” A “Others” A

“Network

Connection”

Network settings are set to the following settings initially. (In most cases, you can connect to the Internet without making any changes to the default settings.)

- IP Address Setting Auto(DHCP)

- DNS Setting Auto(DHCP)

- Proxy Setting Do Not Use

- Connection Speed Auto

- BD-Live Setting Allow

If you want to set the network settings back to the default settings as above (except “BD-Live Setting”), follow the procedure below.

“Enable

(Easy)”

1 Follow steps 1 to 4 in “Connection Test” on

page 36.

2 Use [K / L] to select “Enable(Easy)”, then press

[ENTER].

• The unit will start the connection test automatically and the test result will appear right after the test finishes.

• After the connection test finishes, press [ENTER] to go to network status confirmation screen.

3 Press [ENTER] to activate the network settings

and set the network connection automatically. Press [SETUP] to exit.

Note

• The setting of “BD-Live Setting” will not be set back to the default, even if you follow the procedure.

IP Address Subnet Mas Default Gateway Primary DNS Secondary DNS then press ‘ENTER’.

xxx.xxx.xxx.xxx xxx.xxx.xxx.xxx xxx.xxx.xxx.xxx xxx.xxx.xxx.xxx xxx.xxx.xxx.xxx

6 Press [ENTER] to go back to the previous

screen, or press [SETUP] to exit.

Note

• If the connection test passes, you can enjoy the BD-Live functions using the Internet without making any extra settings.

• If the connection test fails, you may need to change the MAC address settings of your router. You can check the MAC address of this unit on “Enable(Custom)” screen.

• “Connection Test” is not available when “Disable” is selected in “Network Connection”.

Enable(Custom)

[Setup] A “Custom” A “Others” A

“Network

Connection”

In following cases, select “Enable(Custom)” to set each setting as necessary.

- When connection test failed with the setting of “Enable(Easy)”.

- When instructed by your Internet service provider to make specific settings in accordance with your network environment.

IP Address Setting / DNS Setting

“Enable

(Custom)”

1 Follow steps 1 to 4 in “Connection Test” on

page 36.

2 Use [K / L] to select “Enable(Custom)”, then

press [ENTER].

3 Use [K / L] to select “IP Address Setting”, then

press [ENTER] repeatedly to select the desired setting.

“Auto(DHCP)” : If your router has DHCP server

function, select “Auto(DHCP)”.

“Manual” : If your router does not have DHCP

server function, select “Manual”.

36 EN

E5RJ0BD_EN.book Page 37 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

If you select “Manual”, follow the following instruction to set the IP address and DNS.

1) Use [K / L] to select “IP Address”, “Subnet Mask” or “Default Gateway”, then press [ENTER]. IP address setting screen will appear. Enter IP address, subnet mask and default gateway with cursor buttons and number buttons.

Proxy Setting

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

1 Follow steps 1 to 4 in “Connection Test” on

page 36.

2 Use [K / L] to select “Enable(Custom)”, then

press [ENTER].

Others IP Address Setting

IP Address

Subnet Mas

Default Gateway

then press ‘ENTER’.

xxx . xxx . xxx . xxx

• Enter the IP address number after checking the

specifications of your router.

• If the IP address number is unknown, check the

IP address number of other devices (e.g. PC connected via LAN cable) and assign a different number from those of other devices.

2) After you enter all correctly, press [ENTER].

• Confirmation message will appear. Select “Yes”

to complete the settings.

3) Use [K / L] to select “Primary DNS” or “Secondary DNS”, then press [ENTER]. DNS setting screen will appear. Enter primary DNS and secondary DNS with cursor buttons and number buttons.

• Enter the numbers instructed by your Internet

provider.

• If the number is unknown, check the number of

other devices (e.g. PC connected via LAN cable) and assign the same number.

4) After you enter all correctly, press [ENTER].

• Confirmation message will appear. Select “Yes”

to complete the settings.

4 Press [RETURN] to go back to the previous

screen, or press [SETUP] to exit.

Note

• The range of input number is between 0 and 255.

• If you enter a number larger than 255, the number will automatically be 255.

• The manually entered number will be saved even if you change the setting to “Auto(DHCP)”.

• When you enter a wrong number, press [CLEAR] to cancel. (The number will be back to “0”.)

• If you want to enter 1 or 2 digit number in one cell, press [B] to move on to the next cell.

• If the entered IP address or the default gateway or primary DNS number is same as the default setting, IP address setting will be set to “Auto(DHCP)”. (The manually entered number will be saved.)

• When IP address setting is set to “Manual”, the setting of DNS setting will automatically be “Manual” and when IP address setting is set to “Auto(DHCP)”, you can set either “Auto(DHCP)” or “Manual” for DNS setting.

3 Use [K / L] to select “Proxy Setting”, then

press [ENTER] repeatedly to select the desired setting.

• For default settings, select “Do Not Use”.

• If you need to change the proxy setting as instructed by your Internet service provider to set the designated proxy address and port, select “Use”.

If you select “Use”, follow the following instructions to set the proxy address and proxy port.

1) Use [K / L] to select “Proxy Address”, then press [ENTER]. Proxy address setting screen will appear.

Enter proxy address.

• The keyboard screen will appear.

[K / L / s / B] : Move the highlight.

[Number buttons] :Enter number.

[ENTER] : Enter the highlighted number/word.

[Red] : Clear the entered number or word.

[Green] : Clear all the entered numbers or words.

[Yellow] : Switch between abc ? ABC ? @!?

[Blue] : Set the entered number or word.

2) After you enter proxy address correctly, press [Blue].

• Confirmation message will appear. Select “Yes”

to complete the settings.

3) Use [K / L] to select “Proxy Port” , then press [ENTER]. Proxy port setting screen will appear. Enter proxy port number with number buttons.

4) After you enter proxy port correctly, press [ENTER].

4 Press [RETURN] to go back to the previous

screen, or press [SETUP] to exit.

Note

• The range of input number for the port number is between 0 and 65535. (If you enter a number larger than 65535, it will be regarded as 65535.)

• For proxy port, the selected ports may be blocked and not be able to use depending on your network environment.

37EN

E5RJ0BD_EN.book Page 38 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

Connection Speed

You can set connection speed as your preference. (The default setting is “Auto”.)

1 Follow steps 1 to 4 in “Connection Test” on

page 36.

2 Use [K / L] to select “Enable(Custom)”, then

press [ENTER].

3 Use [K / L] to select “Connection Speed”, then

press [ENTER].

4 Use [K / L] to select the desired setting, then

press [ENTER].

“Auto”:

Set the appropriate connection speed automatically, in accordance with your network environment.

“10BASE Half” : Set the connection speed to

“10BASE Half”.

“10BASE Full” : Set the connection speed to

“10BASE Full”.

“100BASE Half” : Set the connection speed to

“100BASE Half”.

“100BASE Full” : Set the connection speed to

“100BASE Full”.

5 Press [RETURN] to go back to the previous

screen, or press [SETUP] to exit.

Note

• Choose a connection speed in accordance with your network environment.

• The network connection may be disabled depending on the device, when the settings are changed.

BD-Live Setting

You can limit the Internet access from the BD-Live functions. (The default setting is “Allow”.)

1 Follow steps 1 to 4 in “Connection Test” on

page 36.

2 Use [K / L] to select “Enable(Custom)”, then

press [ENTER].

3 Use [K / L] to select “BD-Live Setting”, then

press [ENTER].

4 Use [K / L] to select the desired setting, then

press [ENTER].

“Allow”:

Internet access is permitted from all BD-Live contents.

“Limited Allow”:

Internet access is permitted only for BD-Live contents which have content owner certificates. Internet access without the certificates are prohibited.

“Prohibit”:

Internet access is prohibited from all BD-Live contents.

5 Press [RETURN] to go back to the previous

screen, or press [SETUP] to exit.

Disable

Deactivate all the network connection and settings.

1 Follow steps 1 to 4 in “Connection Test” on

page 36.

2 Use [K / L] to select “Disable”, then press

[ENTER].

3 Press [RETURN] to go back to the previous

screen, or press [SETUP] to exit.

Note

• The network connection can be reactivated by setting the network connection to “Enable(Easy)” or “Enable(Custom)”.

38 EN

E5RJ0BD_EN.book Page 39 Tuesday, October 20, 2009 3:53 PM

FUNCTION SETUP

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Software Update

Current Version

You can confirm the current software version.

1 Follow steps 1 to 3 in “Connection Test” on

page 36.

2 Use [K / L] to select “Software Update”, then

press [ENTER].

3 Use [K / L] to select “Current Version”, then

press [ENTER].

4 Press [ENTER] or [RETURN] to exit.

Note

• Please visit http://www.toshiba-om.net to download the latest firmware version.

Disc Update

You can upgrade the software by using disc.

1 Follow steps 1 to 3 in “Connection Test” on

page 36.

2 Use [K / L] to select “Software Update”, then

press [ENTER].

3 Use [K / L] to select “Disc Update”, then press

[ENTER].

4 Use [K / L] to select “Yes”, then press [ENTER]. 5 Disc tray will open automatically.

• Insert the disc for software update and then press

[OPEN/CLOSE A].

6 After completing loading disc, confirmation

message will appear. Select “Yes” and press [ENTER] to start upgrading.

• It may take awhile to complete the updating. (Please

wait until “100%” appears on the front panel display.)

7 After the disc upgrade finishes, this unit will

restart and eject the disc.

Initialise

Initialise the setting or SD card.

1 In stop mode, press [SETUP]. 2 Use [K / L] to select , then press

[ENTER].

3 Use [K / L] to select a desired option, then

press [ENTER].

• Confirmation message will appear.

“Setup”:

Resets the setup menu to the default. The setting for “Parental”, “Network Connection” and “Media Select” will not be reset.

“Format SD Card” (Available only when an SD card is inserted.):

Initialises the SD card.

“Erase Saved BD-ROM Data (Player)”:

Clears the data saved for the BD-ROM contents, such as BD-ROM game scores, from this player.

“Erase Saved BD-ROM Data (SD Card)” (Available only when an SD card is inserted.):

Clears the supplemental data for the BD-ROM playback, such as subtitle data, from the SD card.

“Network Settings”:

Resets the Network Settings menu to the default.

4 Select “Yes”, then press [ENTER].

•Press [ENTER] again to complete the settings.

5 Press [SETUP] to exit.

Caution

• Do not remove the SD card while executing “Format SD Card” or “Erase Saved BD-ROM Data (SD Card)”. It damages the card.

Note

• You can check the current firmware version in “Current Version” in “Software Update” menu.

• Please do not unplug the mains cable while executing “Disc Update”.

• All settings will remain the same even if you update the firmware version.

39EN

E5RJ0BD_EN.book Page 40 Tuesday, October 20, 2009 3:53 PM

Language Code List

OTHERS

Language Code

A-B

Abkhazian 4748 Afar 4747 Afrikaans 4752 Albanian 6563 Amharic 4759 Arabic 4764 Armenian 5471 Assamese 4765 Aymara 4771 Azerbaijani 4772 Bashkir 4847 Basque 5167 Bengali;Bangla 4860 Bhutani 5072 Bihari 4854 Bislama 4855 Breton 4864 Bulgarian [BUL] 4853 Burmese 5971 Byelorussian 4851

C-E

Cambodian 5759 Catalan 4947 Chinese [CHI] 7254 Corsican 4961 Croatian 5464 Czech [CZE] 4965 Danish [DAN] 5047 Dutch [DUT] 6058 English [ENG] 5160 Esperanto 5161 Estonian 5166

F-H

Faroese 5261 Fiji 5256 Finnish [FIN] 5255

Language Code

French [FRE] 5264 Frisian 5271 Galician 5358 Georgian 5747 German [GER] 5051 Greek [GRE] 5158 Greenlandic 5758 Guarani 5360 Gujarati 5367 Hausa 5447 Hebrew 5569 Hindi 5455 Hungarian [HUN]

I-K

Icelandic [ICE] 5565 Indonesian 5560 Interlingua 5547 Interlingue 5551 Inupiak 5557 Irish [IRI] 5347 Italian [ITA] 5566 Japanese [JPN] 5647 Javanese 5669 Kannada 5760 Kashmiri 5765 Kazakh 5757 Kinyarwanda 6469 Kirghiz 5771 Kirundi 6460 Korean [KOR] 5761 Kurdish 5767

L-N

Laothian 5861 Latin 5847 Latvian;Lettish 5868 Lingala 5860 Lithuanian 5866

5467

Language Code

Macedonian 5957 Malagasy 5953 Malay 5965 Malayalam 5958 Maltese 5966 Maori 5955 Marathi 5964 Moldavian 5961 Mongolian 5960 Nauru 6047 Nepali 6051 Norwegian [NOR]

O-R

Occitan 6149 Oriya 6164 Oromo (Afan) 6159 Panjabi 6247 Pashto;Pushto 6265 Persian 5247 Polish [POL] 6258 Portuguese

[POR] Quechua 6367 Rhaeto-

Romance Romanian

[RUM] Russian [RUS] 6467

Samoan 6559 Sangho 6553 Sanskrit 6547 Scots Gaelic 5350 Serbian 6564 Serbo-Croatian 6554 Sesotho 6566 Setswana 6660 Shona 6560 Sindhi 6550 Singhalese 6555

6061

6266

6459

6461

Language Code

Siswat 6565 Slovak [SLO] 6557 Slovenian 6558 Somali 6561 Spanish [SPA] 5165 Sundanese 6567 Swahili 6569 Swedish [SWE] 6568

Tagalog 6658 Tajik 6653 Tamil 6647 Tatar 6666 Telugu 6651 Thai 6654 Tibetan 4861 Tigrinya 6655 Tonga 6661 Tsonga 6665 Turkish [TUR] 6664 Turkmen 6657 Twi 6669

U-Z

Ukrainian 6757 Urdu 6764 Uzbek 6772 Vietnamese 6855 Volapuk 6861 Welsh 4971 Wolof 6961 Xhosa 7054 Yiddish 5655 Yoruba 7161 Zulu 7267

Note

• If you choose a language that has a 3-letter-language code (written in bracket), the code will be displayed every time you change the audio or subtitle language setting on page 25. If you choose any other languages, “---” will be displayed instead.

40 EN

E5RJ0BD_EN.book Page 41 Tuesday, October 20, 2009 3:53 PM

OTHERS

Troubleshooting

If the unit does not perform properly when operated as instructed in this manual, check the unit, consulting the following checklist.

Problem Solution

No power - Check if the mains cable is properly connected.

- Unplug the mains cable once, and wait for 5-10 seconds and then plug it in again.

No sound or picture - Check if the connected TV is turned on.

- Check if the connections are made securely and correctly.

- Check whether the connected TV or other device supports HDCP. (This unit will not output a video signal unless the other device supports HDCP.)

- Check whether the output format of this unit (HDMI FORMAT) matches the supported input format of other connected device.

Distorted picture - Sometimes a small amount of picture distortion may appear.

This is not a malfunction.

- Connect this unit directly to the TV. If the composite audio / video cables are connected to a VCR, pictures may be distorted due to the copy right protection system.

Completely distorted picture or black / white picture with BD / DVD

No sound or distorted sound - Adjust the volume.

Picture freezes momentarily during playback

Disc cannot be played back - Clean the disc.

SD card cannot be read - The format of the card does not match that accepted by this unit or the card is not

No return to start-up screen when disc is removed

The unit does not respond to the remote control

Buttons do not work or the unit stops responding

The unit does not respond to some operating commands during playback

The unit cannot read BD / DVD/ CD

Angle does not switch - The angle cannot be switched for BD / DVD which do not contain multiple angles.

Playback does not start when the title is selected

The password for rating level has been forgotten

- Make sure the disc is compatible with this unit.

- Check if speakers are connected correctly.

- Check the HDMI connections.

- Check the settings in “Audio” menu.

- Check the disc for fingerprints / scratches and clean with a soft cloth wiping from centre to edge.

-Clean the disc.

- Ensure the disc label is facing up.

- Check if the disc is defective by trying another disc.

- Cancel the ratings control or change the control level.

- Insert a correct disc that can be played back on this unit.

compatible.

- Reset this unit by turning it off, then on again.

- Aim the remote control directly at infrared sensor window on the front panel.

- Reduce the distance to infrared sensor window.

- Replace the batteries in the remote control.

- Re-insert the batteries with their polarities (+ / - signs) as indicated.

- To completely reset the unit, press and hold [ON/STANDBY Q] on the front panel for 10 seconds to shut down the unit or unplug the mains cable from the AC outlet for 5-10 seconds.

- Operations may not be permitted by the disc. Refer to the instructions of the disc.

- Dew condensation may form inside the unit. Do not use this unit for at least a few hours until its inside gets dry.

- You are attempting to play back a disc other than one with one of the logos on page 13.

- Wipe the dirt off the disc or replace the disc.

In some cases multiple angles are only recorded for specific scenes.

- Check the settings in “Parental” menu.

- Enter the default password “4737”, then your forgotten password will be cleared.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

41EN

E5RJ0BD_EN.book Page 42 Tuesday, October 20, 2009 3:53 PM

OTHERS

Problem Solution

Cannot connect to the network

Cannot connect to the network while my PC is connected to the network

Cannot use the BD-Live function

The playback of BD-video or download of data does not perform properly

Note

• Some functions are not available in specific modes, but this is not a malfunction. Read the description in this manual for details on correct operations.

• Some functions are prohibited on some discs.

- Check if the LAN cable connection is properly made.

- Turn on the modem or broadband router.

- Check the network setting.

- Check if the broadband router and/or modem is correctly connected.

- Check “BD-Live Setting”.

- Check the content of your Internet service contract to see if your Internet service provider prevents multiple terminals connecting at the same time.

- Use an SD card with enough space.

- Check if an SD card is correctly inserted. Do not remove the card during playback as some BD-videos require an SD card for playback.

Specifications

General

Signal system NTSC/PAL colour Power requirements 220-240 V AC, 50 Hz Power consumption 22 W (standby: 0.5 W) Dimensions (width x height x depth) 435 x 56 x 218 mm Weight 2.4 kg Operating temperature 5°C to 35°C Operating humidity Less than 80 % (no condensation)

Terminals

Video output

RCA jack x 1 1 Vp-p (75Ω)

Component video output

RCA jack x 3 Y: 1 Vp-p (75Ω) P

HDMI output

HDMI jack x 1 Video: 480p/576p, 720p, 1080i, 1080p, 1080p24 / Audio

Audio output (Analogue)

Rear

RCA jack x 2 L/R: 2 Vrms (output impedance: more than 1kΩ)

Audio output (Digital)

RCA jack x 1 Optical jack x 1

LAN terminal 10BASE-T/100BASE-TX

500 mVp-p (75Ω) Digital connector

Note

• The specifications and design of this unit are subject to change without notice.

B/CB: 700 mVp-p (75Ω) PR/CR: 700 mVp-p (75Ω)

42 EN

E5RJ0BD_EN.book Page 43 Tuesday, October 20, 2009 3:53 PM

OTHERS

License Information on the Software Used in This Product

This document is statement purpose only. Not concerned with operation of this product.

The software pre-installed in this product consists of multiple, independent software components. Each software component is copyrighted by a third party. This product uses software components that are distributed as freeware under a third-party end-user license agreement or copyright notice (hereinafter referred to as a “EULA”).

TOSHIBA provides a warranty for this product you have purchased under conditions set forth by TOSHIBA. However, some of the software components distributed under an EULA are made available for use by the user on the assumption that they are not copyrighted or warranted by a third party. These software components are licensed to the user free of charge and therefore not covered by any warranty within the scope of the applicable laws. These software components are not subject to any copyrights or other third-party rights and are provided in “as is” condition without any warranty, whether express or implied. “Warranty” here includes, but not limited to, an implied warranty for marketability or tness for specic uses. All risks associated with the quality or performance of these software components are assumed by the user. TOSHIBA shall not be liable whatsoever for any cost of repair or correction or other incidental expense incurred in connection with a defect found in any of these software components. Unless specied under the applicable laws or in a written agreement, a party who changes or redistributes the software with consent from the copyright holders or based on the aforementioned licenses shall not be held liable whatsoever for any loss arising from the use of or inability to use such software components. The same applies even when the copyright holders or relevant third parties have been informed of the possibility of such loss. “Loss” here includes normal, special, incidental and indirect loss (including, but not limited to, the loss of data or its accuracy; loss incurred by the user or any third party; and interface incompatibility with other software). Please read each EULA for details on the use conditions and items that must be observed regarding these software components.

The table below lists the software components pre-installed in this product, which are subject to EULAs. The user should read the applicable EULAs carefully before using these software components. The EULAs are exhibited in their original text (English) as exactly written by the respective parties.

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS

Program name EULA

e2fsprogs linux module-init-tools mount netkit nettools sash util-linux
