FILE NO. 020-200507

SERVICE MANUAL

Projection Monitor

51HC85 57HC85 65HC15 65HC85

TOSHIBA CORPORATION 2005

Published in Japan Jun. 2005 (YC)

DOCUMENT CREATED IN JAPAN, June, 200

TABLE OF CONTENTS

SAFETY INSTRUCTIONS .............................................................................................................................................. 3

CRT ASSEMBLY REPLACEMENT AND MOUNTING ................................................................................................... 4

PICTURE TUBE COMPONENTS ADJUSTMENT.......................................................................................................... 6

REPLACEMENT OF THE CRT....................................................................................................................................... 9

SERVICE MODE .......................................................................................................................................................... 10

ELECTRICAL ADJUSTMENT ...................................................................................................................................... 12

CONVERGENCE ADJUSTMENT ................................................................................................................................ 15

SCREEN AND MIRROR ALIGNMENTS ...................................................................................................................... 18

CIRCUIT CHECKS ....................................................................................................................................................... 19

SETTING & ADJUSTING DATA .................................................................................................................................... 20

ADDING CHANNELS TO THE TV'S MEMORY ............................................................................................................ 23

MECHANICAL DISASSEMBLY .................................................................................................................................... 24

CHASSIS REPLACEMENT PARTS LIST ..................................................................................................................... 26

PC BOARDS BOTTOM VIEW ...................................................................................................................................... 36

TERMINAL VIEW OF TRANSISTORS ......................................................................................................................... 50

CIRCUIT BLOCK DIAGRAM ........................................................................................................................................ 53

APPENDIX:

CIRCUIT DIAGRAM

SAFETY INSTRUCTIONS

WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-

TION” AND “PRODUCT SAFETY NOTICE” INSTRUCTIONS BELOW.

X-RAY RADIATION PRECAUTION

1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high voltage must not be above the specified limit. The nominal value of the high voltage of this receiver is (A) kV at zero beam current (minimum brightness) under a 120V AC power source. The high voltage must not, under any circumstances, exceed (B) kV.

Refer to table-1 for high voltage (A), (B). (See SETTING & ADJUSTING DATA on page 20)

Each time a receiver requires servicing, the high voltage should be checked following the HIGH VOLTAGE CHECK procedure in this manual. It is recommended that the reading of the high voltage be recorded as a part of the service record. It is important to use an accurate and reliable high voltage meter.

SAFETY PRECAUTION

WARNING : Service should not be attempted by anyone unfamiliar with the necessary precautions on this receiver. The following are the necessary precautions to be observed before servicing this chassis.

1. An isolation Transformer should be connected in the power line between the receiver and the AC line before any service is performed on the receiver.

2. Always discharge the picture tube anode to the CRT conductive coating before handling the picture tube. The picture tube is highly evacuated and if broken, glass fragments will be violently expelled. Use shatter proof goggles and keep picture tube away from the unprotected body while handling.

3. When replacing a chassis in the cabinet, always be certain that all the protective devices are put back in place, such as; non-metallic control knobs, insulating covers, shields, isolation resistor-capacitor network etc.

4. Before returning the set to the customer, always perform an AC leakage current check on the exposed metallic parts of the cabinet, such as antennas, terminals, screwheads, metal overlays, control shafts etc. to be sure the set is safe to operate without danger of electrical shock. Plug the AC line cord directly into a 120V AC outlet (do not use a line isolation transformer during this check). Use an AC voltmeter having 5000 ohms per volt or more sensitivity in the following manner:

PRODUCT SAFETY NOTICE

2. This receiver is equipped with a Fail Safe (FS) circuit which prevents the receiver from producing an excessively high voltage even if the B+ voltage increases abnormally. Each time the receiver is serviced, the FS circuit must be checked to determine that the circuit is properly functioning, following the FS CIRCUIT CHECK procedure in this manual.

3. The only source of X-RAY RADIATION in this TV receiver is the picture tube. For continued X-RAY RADIATION protection, the replacement tube must be exactly the same type tube as specified in the parts list.

4. Some part in this receiver have special safety-related characteristics for X-RAY RADIATION protection. For continued safety, parts replacement should be undertaken only after referring to the PRODUCT SAFETY NOTICE below.

Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15

F, AC type capacitor, between a known good earth ground (water pipe, conduit, etc.) and the exposed metallic parts, one at a time. Measure the AC voltage across the combination of 1500 ohm resistor and 0.15 μF capacitor. Re- verse the AC plug at the AC outlet and repeat AC voltage measurements for each exposed metallic part. Voltage measured must not exceed 0.675 volts rms. This corresponds to 0.45 milliamp. AC. Any value exceeding this limit constitutes a potential shock hazard and must be corrected immediately.

AC VOLTMETER

0.15 μF

Place this probe on Good earth ground such as a water pipe, conduit, etc.

1500 ohm 10 watt

each exposed

metallic part.

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in this manual and its supplements; electrical components having such features are identified by the international hazard symbols on the schematic diagram and the parts list. Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, X-ray radiation or other hazards.

CRT ASSEMBLY REPLACEMENT AND MOUNTING

CAUTION : DO NOT LOOSEN THE HEX HEAD BOLTS WITH SPRINGS (12 PCS), BECAUSE THOSE ARE FOR

SEALING OF CRT COOLANT.

Lens Assembly

Attention Serviceman

The Hex Head Bolts with Springs. (see sketch) used on CRT assembly, are NOT

Adjustment Screws DO NOT LOOSEN-FLUID LEAKAGE WILL OCCUR.

4 Screws

CRT Assembly

S.V.M. Coil

CRT DRIVE Board

Deflection Yoke and Conver Yoke

Lens and Neck Components View

CRT Mounting

TO REMOVE CRT (Same procedure for R, G, B)

1. Remove CRT DRIVE Board, S. V. M. COIL and DEF. YOKE from CRT.

2. Remove Lens Assembly.

3. Detach CRT Anode Cap from CRT.

4. Remove CRT Assembly from CRT Mounting.

CRT REPLACEMENT (Same procedure for R, G, B) Reverse the removal procedures except the followings.

1. Anode Cable should be replaced with new one. See “SERVICING PRECAUTIONS” shown below.

2. Install silicon (T461B) to the CRT, replace the Anode cable and put enough silicon again on around the Anode Cap as illustrated.

Anode Cap

CAUTION: Align the Anode cable as illustrated on page

ADJUSTING PROCEDURE IN REPLACING CRT

1. R.G.B. FOCUS ADJUSTMENT (page 7.)

2. PICTURE TILT ADJUSTMENT (page 7.)

3. USER CONVERGENCE CENTER CHECK (See owner's manual.)

4. CENTERING ADJUSTMENT (page 7.)

5. CONVERGENCE ADJUSTMENT (page 15.)

6. WHITE BALANCE ADJUSTMENT (page 12.)

Adjustments are complete.

Silicon (On shaded area) TSE3843W #23960136

2 ~ 5 mm

15 ~ 25 mm

SERVICING PRECAUTIONS

Do not use a magnetized screw driver for screws of Deflection Yoke and Velocity Modulation Coil to avoid magnetization of electron gun. Magnetization of electron gun will degrade basic function and result in unbalance of right and left shift of user static convergence, and result in no variable quantity.

Screw for D.Y

Screw for SVM coil

When replacing the anode cap assembly (CRT) or anode lead assembly (F.B.T.), remove the anode lead holder from old one and attach the holder again to new anode lead.

Check the point of anode lead in a straight line, if it is winding, please revise it.

Anode lead holder

WARNING : BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.

PICTURE TUBE COMPONENTS ADJUSTMENT

DESCRIPTION OF NECK COMPONENTS



 Deflection yoke and convergence yoke

The position on the neck is required most front (CRT funnel side) and the screw is fastened after rotating yoke adjusting picture tilt.

 Centering magnet

After adjusting picture tilt, picture position is finally fixed by this magnet. In order to get maximum margin of user convergence control for center of screen, this magnet have to be used for center convergence adjustment.



PREPARATION

Operate the receiver for at least 5 minutes.

R, G, B FOCUS ADJUSTMENT

1. Before adjusting the R, G, B FOCUS, remove the 4 screws of Lens Assembly which is fixed on the CRT Assembly. (See page 4.) Then turn around the Lens Assembly by 180 to adjust the fastening screw (Fig. a) and fasten the 4 screws to secure Lens Assembly.

2. Select the adjustment mode. (See page 10.)

3. Press “7” button to display the built-in cross-hatch.

4. Press “0” and “RTN” buttons to make the picture a single Red color.

100 button ................ to erase Red color

0 button .................... to erase Green color

RTN button .............. to erase Blue color.

5. Loosen the fasten screw and adjust Red lens focus to best focusing point of picture center. Then fasten the screw. (See Fig. a.)

Fig. a

6. Adjust FOCUS VR “R” of FOCUS PACK to find best focusing point of picture center.

7. Repeat steps 3 to 5 for Green and Blue colors.

TILT ADJUSTMENT

Rotate R, G, B deflection yoke so that picture becomes horizon, then fasten screw.

CENTERING ADJUSTMENT

1. Stretch a thread between two center of screen edge (top and bottom, left and right).

2. Receive NTSC. Then select SERVICE MODE. (See Page 10.)

3. Select CONVERGENCE ADJUSTING mode, and press "7" button to display the internal net pattern. Move Cursol and recognize horizontal line indicated Y:4. This line is vertical center. Push "9" button to display the vertical stripes, and recognize horizontal center.

4. Perform VCEN adjustment. (See page 16.)

5. Adjust G centering magnet so that the cross-bar pattern center comes to screen center.

6. Perform HEIGHT adjustment .

7. Perform VERT. LINEARITY adjustment.

8. Perform WIDTH adjustment. (See page 16.)

9. Check whole quality of green line.

. Adjust R, B centering magnet so that the cross-bar pat-

tern center comes to screen center.

LOCATION OF SCREEN AND FOCUS VR’S

SCREEN

COVER

Speaker grille

FOCUS

REPLACEMENT OF THE CRT

Service parts are provided for each R, G and B. The contents of the parts are as follows.

RG B

51HC85 23078357 23078358 23078359

57HC85 23447326 23447324 23447327

65HC85 23447328 23447324 23447329

65HC15 23447981 23447982 23447983

REPLACEMENT OF HIGH VOLTAGE CABLE

ANODE LEAD

RUBBER BOOT

LEAD HOLDER

Z450 TPA5011

Fig. a

1. When replacing Anode Lead or Anode Cap with new one, remove Lead Holder from old lead as shown in figure below, and put it on new lead. Do not throw away Lead Holder.

NOTE : THE LEAD HOLDER IS ATTACHED TO TPA5011

(Z450), BUT IS NOT ATTACHED TO ANODE LEAD AND ANODE CAP. RUBBER BOOT IS ATTACHED TO ANODE LEAD AND ANODE CAP.

2. Detaching Lead Holder

RUBBER BOOT

LOCK LEAD HOLDER

Fig. b

Cut here rubber boot and lead together to detach Lead Holder.

OLD ANODE LEAD

ANODE CAP

SERVICE MODE

1. ENTERING TO SERVICE MODE

1) Press MUTE button twice on Remote Control.

MUTE

2. DISPLAYING THE ADJUSTMENT MENU

1) Press MENU button on TV.

Service mode

3. KEY FUNCTION IN THE SERVICE MODE

The following key entry during display of adjustment menu provides special functions.

2) Press MUTE button again to keep pressing.

Adjustment mode

Press

3) While pressing the MUTE button, press MENU button on TV set.

(Service mode display)

Item

Data

Screen adjustment mode ON/OFF: TV (ANT)/VIDEO button (on TV) Selection of the adjustment items : Channel / (on Remote) and / (on TV) Change of the data value : Volume / (on TV or Remote) Adjustment menu mode ON/OFF : MENU button (on TV) Initialization of the memory (QA02) : RECALL + button on TV Initialization of the self diagnostic data: RECALL + button on TV

“RCUT” selection : 1 button “GCUT” selection : 2 button “BCUT” selection : 3 button “SCNT” selection : 4 button “COLC” selection : 5 button Convergence adj : 7 button Self diagnostic display : 9 button

4. SELECTING THE ADJUSTING ITEMS

1) Every pressing of button in the service mode changes the adjustment items in the order of table-2. ( button for reverse order)

Refer to table-2 for preset data of adjustment mode. (See SETTING & ADJUSTING DATA on page 20)

5. ADJUSTING THE DATA

1) Pressing of VOLUME or button will change the value of data in the range from 00H to FFH. The variable range

depends on the adjusting item.

6. EXIT FROM SERVICE MODE

1) Pressing POWER button to turn off the TV once.

INITIALIZATION OF MEMORY DATA OF QA02

After replacing QA02, the following initialization is required.

1. Enter the service mode, then select any register item.

2. Press and hold the RECALL button on the Remote, then press the button on the TV. The initialization of QA02 has been completed.

CAUTION: Never attempt to initialize the data unless QA02 has been replaced.

7. SELF DIAGNOSTIC FUNCTION

1) Press “9” button on Remote Control during display of adjustment menu in the service mode.

The diagnosis will begin to check if interface among IC’s are executed properly.

2) During diagnosis, the following displays are shown.

SELF CHECK NO. 23 * * * * * * POWER : 000 BUS LINE : OK BUS CONT : OK BLOCK : MAIN SUB SET ID : 01 EEP VER : 02 OPT1 : 05 OPT2 : 70 HDMI NO * * * * * * * * ERR CODE :

Part number of microprocessor (QA01)

Operation number of protection circuit (current limiter) . . . . “000” is normal.

BUS line check “OK” ................... Normal

“SCL-GND” or “NG” ........... SCL-GND short circuit

“SDA-GND” or “NG” ........... SDA-GND short circuit

“SCL-SDA” or “NG” ............ SCL-SDA short circuit

BUS line ACK (acknowledge) check

“OK” ..................... Normal

Display of Location Number . . . . NG

(Display example) “QA02 NG”, “Q501 NG” etc. Note: The indication of failure place is only one place though failure places are plural. When

repair of a failure place finishes, the next failure place is indicated. (The order of priority of indication is left side.)

Sync. signal check Green display ..... Normal

Red display ........ NG

MAIN ........ Main sync

SUB .......... Sub sync (when turn on the PIP)

ID code for TV Set Version of "EEP" Data for "OPT" Part number of HDMI microprocessor HDMI error code

ELECTRICAL ADJUSTMENT

ELECTRICAL ADJUSTMENTS

ADJUSTMENT

SPECIFICATION

SIGNAL

10500k+0UV

Same spec is ap-

plied on dark area

and bright area.

White luster signal

(Valuable input level)

on bright

BAR SUNK

5TH

Video input

SUB-BRIGHT SIGNAL

(Pedestal to white peak:

714mV ±30mV Value of

low 10 steps:

200mV ±10mV)

5th bar sunk

PROCESS INSTRUCTIONS

ADJUSTING

1. Heat runnning the set at minimum 15 minutes.

2. Go into screen adjustment mode.

ITEM

SCREEN ADJUST

on dark area, and get 264.3cd/m

Adjust Focus pack Screen VR of Red, Green, and Blue by looking directly into each

CRT and adjusting each screen VR until CRT is just lit on left side of CRT.

area.

2. Using the data up and down keys, cycle through the adjustments for RED DRIVE,

1. Adjust white luster level to get 4.3cd/m

WHITE BALANCE

ADJUSTMENT

BIAS for dark area.

BLUE DRIVE, RED BIAS and BLUE BIAS.

Adjust RED DRIVE, BLUE DRIVE for bright area, and adjust RED BIAS and BLUE

3. Continue to make adjustments color temperature to spec on each area.

1. Receive Sub-Bright pattern on Video input.

2. Go into BRTC of service mode.

3. Press DATA UP/DOWN to adjust Sub-Bright level to spec.

SUB-BRIGHT

ADJUSTMENT

G Dot cross (NTSC)

B Dot cross (NTSC)

Electrical Focus : R Dot cross (NTSC)

• User Adjustment : SPORTS (CONTRAST MAX, BRIGHTNESS CENTER)

• Adjust after Centering Magnet adjusts.

• Signal : Lens Focus : R Dot cross (NTSC)

ADJUSTMENT METHOD

(Condition)

G Dot cross (NTSC)

B Dot cross (NTSC)

1) Rough Adjust the lens focus and electrical focus of each color(R, G, B).

(Adjustment)

1. Common Items

Adjust Green electrical focus VR on focus pack (Z410) for best center focus.

1) Receive green single color by shielding jig.

2) Receive the Dot Cross pattern.

3) Adjust Green electrical focus.

2. Green Adjustment

Red flare width : 1mm

If the focus blur on screen center and circumference, adjust the electrical focus is best point on all of screen.

Receive the Dot Cross pattern. Adjust Green lens for best center focus.

Green lens focus adjustment target

Dot-cross has red flare (red flare width :1mm)

4) Adjust Green lens focus.

5) Repeat (3)~(4),and adjust best focus point.

ITEM

FOCUS ADJUSTMENT (1/2)

Focus Adjustment

Adjust Red electrical focus VR on focus pack (Z410) for best center focus.

Receive the Dot Cross pattern. Adjust Red lens for best center focus.

1) Receive Red single color by shielding jig.

2) Receive the Dot Cross pattern.

3) Adjust Red electrical focus.

4) Adjust Red lens focus.

ADJUSTMENT METHOD

3. Red Adjustment

ITEM

FOCUS ADJUSTMENT (2/2)

Focus Adjustment

5) Repeat (3)~(4),and adjust best focus point.

1) Receive Blue single color by shielding jig.

2) Receive the Dot Cross pattern.

4. Blue Adjustment

3) Adjust Blue electrical focus.

Adjust Blue electrical focus VR on focus pack (Z410) for best center focus.

(The Brightness is minimum point of Blue.)

Receive the Dot Cross pattern. Adjust the Blue lens for best center focus.

After easy lens adjustment, turn to right side lens focus screw,

and so dot-cross has flare.

Next turn left focus screw, so flare disappears in Dot-Cross and Dot-Cross become blur.

This point is blue lens focus adjustment target. (flare disappear and become blur)

4) Adjust Blue lens focus.

CONVERGENCE ADJUSTMENT

1. Receive NTSC signal.

2. Enter to the service mode. (See Page 10.)

RCUT 40H

3. Press "7" button to enter the convergence adjusting mode, and the internal net pattern will be displayed. Then, press "9" button to display veritcal stripes.

4. Select the point and the color by pressing following buttons. (Cursor should be blinking.)

"2", "8", "4", "6" : To select point

"3" : To select color

5. Then press "5" button, and adjust the convergence by pressing following buttons. (Cursor should not be blingking.)

"2", "8", "4", "6" : To adjust convergence

"3" : To select color

6. Repeat from steps 3 to 4 until the convergence and the geometry become fine. (See Page 14.)

7. Press "7" button to memorize the adjusted data.

8. Message of "PLEASE PUSH TOUCH FOCUS" will be dis- played, and press TOUCH FOCUS button which is located on the front panel.

9. TOUCH FOCUS CALIBRATION will start.

10. Soon message of "CALIBRATION FINISHED" will be dis- played, and then a normal picture will be displayed.

11. Then push TOUCH FOCUS button again, and confirm that the convergence does not change.

EXPLANATION OF KEY-FUNCTION IN THE CONVERGENCE ADJUSTMENT MODE

Load BACK UP DATA: 1 button Up : button Selet Green color: Left : button Blinking of cursor ON/OFF: 5 button Right: button Adjust mode ON/OFF: 7 button Down: 8 button Vertical stripe ON/OFF 9 button Erase Green line: 0 button Erase Red line: 100 button Erase Blue line: ENT button

Note: The following message will appear while pressing

"1" button. ENTER: TO LOAD BACKUP DATA MUTE: TO LOAD INITIAL DATA EXIT: TO EXIT

BACKUP DATA sets in factory by performing CALIBRATION. BACKUP DATA updates by performing CALIBRATION again. INITIAL DATA uses the seed data on this model. Thus, it cannot updates. INITIAL DATA is not adjusted. Therefore, convergence data operates incorrectly. Normally, BACKUP DATA operates as base data on this model. If BACKUP DATA is incorrectly operated, INITIAL DATA is operated instead of BACKUP DATA.

2 3

button

Note: If message of "TOUCH FOCUS ERROR" is displayed,

1) Check the connection between four sensors and Convergence Unit.

2) Check the geometry of internal net pattern. (See Page

14.)

If any problem cannnot be found, hardware might have problem.

DEFRECTION and CONVERGENCE

ITEM NAME SETTING

VCEN VERTICAL

Raster centeing Adjustment

CONTRAST :MAX BRIGHTNESS:CNT COLOR :CNT TINT :CNT

INPUT

SIGNAL

Retma Signal

TEST POIN

Between TP-G

to TP-V

MEASURING

INSTRUMENT

Dig

ital Volt

Meter

ADJUSTMENT METHOD ADJUSTMENT SPEC

10 mV

Adjust the voltage between TP-G and TP-V.

DY Tilt

Adjustment

Centering

magnet

Adjustment

WID Horizontal

Adjustment

(FULL)

HIT

(VLIN)

Vertical Adjustment (FULL)

Convergence

CONTRAST: MAX BRIGHTNESS:CNT COLOR :CNT TINT :CNT PIC SIZE :FULL

CONTRAST :MAX BRIGHTNESS:CNT COLOR :CNT TINT :CNT PIC SIZE : FULL C-MUTE :ON

CONTRAST :MAX BRIGHTNESS: CNT COLOR :CNT TINT :CNT PIC SIZE : FULL C-MUTE : ON

D-Cross

Pattern

Retma Signal

Picture Adjustment

After roughly the green centering magnet alignment, adjust the green yoke so that the D-cross is as close as possible to the dummy screen cross. Adjust the Red and Blue in the same manner as Green.

Adjust the green center to the screen center with the centering magnet on Retma signal. And adjust the Red and Blue center to the green center each.

Adjust the Horizontal width by WID on the green raster only. After finishing Convergence adjustment, make sure that the width is the same as the spec.

Adjust the Vertical height by HIT(VLIN) on the green raster only.After finishing Convergence adjustment, make sure that the height is the same as the spec with C-MUTE OFF.

Refer to the following (Convergence Net Geometry)

The dummy screen cross and D-cross Gap

Color gap at the screen center is within

1 bar

In case of C-MUTE OFF is

5mm.

3mm.

the same spec as well.

In case of Convergence mute. Upper left...5 Bottom right...5 In case of C-MUTE OFF. Upper left...4 Bottom right...4

0.5 bar

0.5bar.

CONVERGENCE (Adjust the voltage between TP-G and TP-V.)

Net Pattern Geometry

Model H size H span 51WIDE 1129.0 537.6 448.0 268.8 89.6 0.0 89.6 268.8 448.0 537.6 89.6 57WIDE 1260.0 600.0 500.0 300.0 100.0 0.0 100.0 300.0 500.0 600.0 100.0 65WIDE

1442.0 686.7 572.2 343.3 114.4

0.0

114.4 343.3 572.2 686.7 114.4

Model 57WIDE 65WIDE

51WIDE

V size 708.750

635.085

308.0

231.0

115.5

0.0

115.5

231.0

308.0

V span 43.0

38.5

344.0

258.0

129.0

0.0 0.0

129.0

258.0

344.0

810.00

392.8

294.6

147.3

294.6

392.8

49.1

UNIT: mm

NOTES

In many cases, color misconvergence may be corrected by returning HIT and WID data in main deflection side to initial adjusting values. Following cases will surely require readjustment of convergence.

CRT REPLACEMENT

When CRT is replaced, main deflection readjustment and color matching are required. Perform following procedures.

1. Replace two CRT’s of blue and red.

2. Perform horizontal adjustment for blue and red yokes on base of green CRT data. Mount yoke and velocity mod. coil alignment, pushing towards CRT without gap.

3. Adjust alignment of blue and red. (Refer Alignment adjustment for details.)

4. Rotating centering magnet, adjust CRT centers of red and blue to CRT center of green. (Picture position adjustment)

5. Adjust HIT and WID data of main deflection, and decide data at the most precise screen comparing to green data.

6. Adjust convergence of screen picture for color matching. Do not move green one at this time.

7. After convergence adjustment of screen picture finishes, replace green CRT. For green CRT as well, repeat steps 2 to 5 above on bases of red and blue color matching to adjust convergence.

8. Execute TOUCH FOCUS following instructions displayed on the screen after finishing convergence adjustments of all the colors.

Note: Press button "7" again after "PLEASE PUSH TOUCH FOCUS" has been displayed. Then, TOUCH FOCUS will not be

executed, and the current state of convergence will be displayed.

SCREEN AND MIRROR ALIGNMENTS

ASSEMBLING OF FRONT SCREEN

K503 FRONT PANEL

LENTICULAR

K501

SMOOTH

K502 FRESNAL

BLACK STRIPES

SMOOTH

SPACER

FRONT PANEL LENTICULAR FRESNEL

INSIDE

OUT SIDE

LENS

BLACK STRIPES

0 to 1 mm

MOUNTING OF FRONT SCREEN

SMOOTH

FRESNEL

LENTICULAR

FRONT PANEL

BEZEL

CAUTION : Do not hold the optical system parts (lens and

mirror) with bare hand to avoid finger-prints on the surface of those parts.

HOW TO CLEAN LENS AND MIRROR

1. Be sure to remove sand dust with an air brush, etc.

2. When it is stained slightly, breathe upon it and wipe away with the specified cleaning cloth. For other stains than the above, wipe the stains away with the specified cloth into which a cleaning liquid has been soaked.

Cleaning liquid.................... LENS LUSTER (Manufac-

tured by Edmund Scientific Co.), etc.

HOW TO CLEAN SCREEN

When cleaning the screen, use a soft cloth so as not to damage the screen.

1. Wipe the screen with a dry cloth to remove moisture on the screen.

Note : Absolutely do not use detergent, water, alcohol,

benzine, thinner, etc. for cleaning in order not to wipe away the black print on the surface.

CIRCUIT CHECKS

HIGH VOLTAGE CHECK CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on

this chassis. Checking should be done following the steps below.

1. Connect an accurate high voltage meter to the anode of the picture tube.

2. Turn on the receiver. Set the BRIGHTNESS and CONTRAST to minimum (zero beam current).

3. High voltage must be measured below (B) kV.

Refer to table-1 for high voltage (B). (See SETTING & ADJUSTING DATA on page 20)

4. Vary the BRIGHTNESS to both extremes to be sure the high voltage does not exceed the limit under any conditions.

CAUTION:

When the following parts fail, check the High Voltage after replacing.

Location

No.

T461Z

C440 C443 C444 C467 C468

Name

Flyback Capacitor Capacitor Capacitor Capacitor Capacitor

Descriptions

51", 57", 65"

TFB3094ZD

1000pF, r3% 4700pF, r3% 3600pF, r3% 5600pF, r5% 6800pF, r5%

FS CIRCUIT CHECK

The Fail Safe (FS) circuit check is indispensable for the final check in servicing. Checking should be done following the steps below.

1. Turn the receiver on.

2. Temporarily short TP- (R) and TP- (X) on the DEF/POWER Board with a jumper wire. Raster and sound will disappear.

3. The receiver must remain in this state even after removing the jumper wire. This is the evidence that the FS circuit is functioning properly.

4. To obtain a picture again, temporarily turn the receiver off and allow the FS circuit more than 5 seconds to reset. Then turn the receiver on to produce a normal picture.

ANODE VOLTAGE MEASURING METHOD

CAUTION: Take extra precaution when measuring this high

voltage. High voltages are also present in surrounding circuit boards (CRT DRIVE assembly, DEFLECTION assembly, and POWER SUPPLY assembly).

1. Disconnect the FBT anode cable as outlined below. Measure high voltage at the point where the cable enters the FBT.

2. Holding the rubber cover firmly, turn it counterclockwise and check that the lock has been disengaged. (See Fig. b on page 9.)

3. Determine the extent of the rubber cover before disconnecting the cable.

4. Pull straight up the anode cable to disconnect.

5. When reconnecting the cable, proceed in the reverse order. After reconnecting, tug on the cable to check that it is secure.

SETTING & ADJUSTING DATA

SAFETY INSTRUCTIONS

HIGH VOLTAGE AT ZERO BEAM: MAX HIGH VOLTAGE:

SERVICE MODE

ADJUSTING ITEMS AND DATA IN THE SERVICE MODE:

Table-1

(A)

(B)

51", 57", 65"

32.8 kV

33.9 kV

Item Name of adjustment

RCUT BCUT RDRV BDRV BRTC HIT LIN VSC WID

CIRCUIT CHECKS

R CUT OFF B CUT OFF R DRIVE B DRIVE BRIGHT CENTER PICTURE HIT V LINEARITY V S CORRECTION PICTURE WIDTH

Preset Data

80H 80H 40H 40H 80H 30H 12H 29H 48H

HIGH VOLTAGE DET

Item Name of adjustment Preset Data

COLC VCP PARA CNR HCP VFC VCEN TVOP

Table-2

Q306 # 8 pin-GND

Table-3

COLOR CENTER

V COMPENSATION EW PARABOLA EW M CORRECTION H COMPENSATION V f CORRECTION V CENTERRING TV OPTION

9.0 V

5DH 06H 0FH 10H 00H 00H 7AH 40H

10 screws

4 screws

K501

K502

K503

3 Front Mask Removal

A202

MECHANICAL DISASSEMBLY

A223

6Back Board Removal

4 screws

K601

A160 (CASTER)

A421

(A424)

A001

A102

- -

A201

4 screws

K111

K112

K113

1Speaker Grille Removal 2 Control Panel Removal

4 Shield Plate, Lens Removal 5 Mirror Removal

CHASSIS AND CABINET REPLACEMENT PARTS LIST

WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRE-

CAUTION" AND "PRODUCT SAFETY NOTICE" ON PAGE 3 OF THIS MANUAL.

CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the safety of the receiver through improper servicing.

NOTICE:

The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model number and Description.

The PC board assembly with

Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic

Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film

OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor

(All CD and PF capacitors are

mark is no longer available after the end of the production.

Model : 51HC85/57HC85/65HC15/65HC85

±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)

Location Parts No. Description

No.

#1 : [51HC85] #2 : [57HC85] #3 : [65HC15] #4 : [65HC85]

CAPACITORS

C108 76665221 ELECTROLYTIC, 10V 220UF M 3A C109 76100104 CERAMIC CHIP, 25V F 0.1UF Z C110 76794101 ELECTROLYTIC, 16V 100UF M C221 76503041 PLASTIC FILM , 63V 0.1UF J C301 76503053 PLASTIC FILM, 63V 1UF J C302 76669010 ELECTROLYTIC, 50V 1UF M 3A C303 76503053 PLASTIC FILM, 63V 1UF J C308 76567223 PLASTIC FILM, 50V 0.022UF J C309 76109102 CERAMIC CHIP, 50V B 1000PF K C310 76073053 ELECTROLYTIC, 25V 100UF M 3A C311 76109103 CERAMIC CHIP, 50V B 0.01UF K C312 76109332 CERAMIC CHIP, 50V B 3300PF K C314 76503037 PLASTIC FILM, 63V 0.047UF J C315 76073020 ELECTROLYTIC, 10V 1000UF M 3A C320 76669101 ELECTROLYTIC, 50V 100UF M C321 76669101 ELECTROLYTIC, 50V 100UF M C323 76109473 CERAMIC CHIP, 25V B 0.047UF K C324 76503053 PLASTIC FILM, 63V 1UF J C325 76082057 PLASTIC FILM, 100V 0.22UF J C327 76092730 CERAMIC CHIP, 16V B 0.1UF K C328 76082256 PLASTIC FILM, 100V 2200PF J C330 76073034 ELECTROLYTIC, 16V 10UF M 3A C332 76669101 ELECTROLYTIC, 50V 100UF M C333 76082272 PLASTIC FILM, 100V 0.047UF J C334 76109471 CERAMIC CHIP, 50V B 470PF K C338 76666100 ELECTROLYTIC, 16V 10UF M 3A C340 76073037 ELECTROLYTIC, 16V 47UF M 3A C361 76092730 CERAMIC CHIP, 16V B 0.1UF K C362 76109473 CERAMIC CHIP, 25V B 0.047UF K C370 76669229 ELECTROLYTIC, 50V 2.2UF M 3A C371 76092730 CERAMIC CHIP, 16V B 0.1UF K C401 76214332 CERAMIC DISC, 500V B 3300PF K C402 76214391 CERAMIC DISC, 500V B 390PF K C405 76503041 PLASTIC FILM , 63V 0.1UF J C412 76828124 PLASTIC FILM, 200V 0.12UF J C415 76092484 CERAMIC DISC, 2KV B 1500PF K C416 76676220 ELECTROLYTIC, 100V 22UF M 3A C417 76503334 PLASTIC FILM, 250V 1.5UF J C419 76105331 CERAMIC CHIP, 50V CH 330PF J C420 76503041 PLASTIC FILM , 63V 0.1UF J

Location Parts No. Description

No.

C422 76109102 CERAMIC CHIP, 50V B 1000PF K C423 76503252 PLASTIC FILM, 400V 0.3UF J C425 76503142 PLASTIC FILM, 400V 0.27UF J C426 76211222 CERAMIC DISC, 2KV B 2200PFK C432 76567333 PLASTIC FILM, 50V 0.033UF J C440 76503059 PLASTIC FILM, 1800VH 1000PF H C443 76503099 PLASTIC FILM, 1800VH 4700PF H C444 76503347 PLASTIC FILM, 1800VH 3600PF H C445 76828473 PLASTIC FILM, 200V 0.047UF J C446 76073120 ELECTROLYTIC, 250V 33UF C448 76073118 ELECTROLYTIC, 160V 33UF M C449 76214221 CERAMIC DISC, 500V B 220PF K C450 76073057 ELECTROLYTIC, 25V 1000UF M 3A C460 76678220 ELECTROLYTIC, 200V 22UF M C463 76109682 CERAMIC CHIP, 50V B 6800PF K C464 76503149 PLASTIC FILM, 250V 3.3UF C467 76820562 PLASTIC FILM, 630V 5600PF J C468 76820682 PLASTIC FILM, 630V 6800PF J C473 76092730 CERAMIC CHIP, 16V B 0.1UF K C481 76092784 CERAMIC CHIP, 10V B 0.33UF K C482 76109822 CERAMIC CHIP, 50V B 8200PF K C483 76105470 CERAMIC CHIP, 50V CH 47PF J C490 76073037 ELECTROLYTIC, 16V 47UF M 3A C491 76666100 ELECTROLYTIC, 16V 10UF M 3A C496 76503049 PLASTIC FILM, 63V 0.47UF J C497 76085022 ELECTROLYTIC, NP, 16V 100UF M 3A C499 76666220 ELECTROLYTIC, 16V 22UF M 3A C601 76109681 CERAMIC CHIP, 50V B 680PF K C602 76109681 CERAMIC CHIP, 50V B 680PF K C603 76073084 ELECTROLYTIC, 50V 4.7UF M 3A C604 76073084 ELECTROLYTIC, 50V 4.7UF M 3A C605 76073084 ELECTROLYTIC, 50V 4.7UF M 3A C606 76073084 ELECTROLYTIC, 50V 4.7UF M 3A C607 76073053 ELECTROLYTIC, 25V 100UF M 3A C608 76073086 ELECTROLYTIC, 50V 10UF M 3A C612 76073039 ELECTROLYTIC, 16V 220UF M 3A C661 76073084 ELECTROLYTIC, 50V 4.7UF M 3A C662 76073086 ELECTROLYTIC, 50V 10UF M 3A C663 76073086 ELECTROLYTIC, 50V 10UF M 3A C665 76109103 CERAMIC CHIP, 50V B 0.01UF K C666 76073084 ELECTROLYTIC, 50V 4.7UF M 3A C667 76794100 ELECTROLYTIC, 16V 10UF M C680 76073073 ELECTROLYTIC, 35V 2200UF M 3A C681 76109103 CERAMIC CHIP, 50V B 0.01UF K C682 76073082 ELECTROLYTIC, 50V 2.2UF M 3A C683 76795101 ELECTROLYTIC, 25V 100UF M

– 23 –

Location Parts No. Description

No.

C684 76795470 ELECTROLYTIC, 25V 47UF M C698 76085055 CHEMICON NP 25V 222 25V 2200UF M C699 76085055 CHEMICON NP 25V 222 25V 2200UF M C801 76503004 PLASTIC FILM, AC275V 0.47UF M C805 76092281 CERAMIC DISC, AC250V E 4700PF C809 76086067 CHEMICON 200V 102M LGQ2D102MESHTL C810 76086067 CHEMICON 200V 102M LGQ2D102MESHTL C811 76092595 CERAMIC DISC, AC250V E 2200PF M C812 76092595 CERAMIC DISC, AC250V E 2200PF M C814 76092579 CERAMIC DISC, AC250V B 470PF K C840 76679220 ELECTROLYTIC, 250V 22UF M 3A C841 76073097 ELECTROLYTIC, 10V 2200UF M 3A C842 76503041 PLASTIC FILM , 63V 0.1UF J C843 76092333 CERAMIC DISC, 2KV 100PF K C845 76669229 ELECTROLYTIC, 50V 2.2UF M 3A C849 76073038 ELECTROLYTIC, 16V 100UF M 3A C850 76073187 ELECTROLYTIC, 35V 560UF M 3A C851 76073187 ELECTROLYTIC, 35V 560UF M 3A C852 76073169 ELECTROLYTIC, 25V 470UF M 3A C853 76073169 ELECTROLYTIC, 25V 470UF M 3A C854 76667470 ELECTROLYTIC, 25V 47UF M 3A C860 76214103 CERAMIC DISC, 500V B 0.01UF K C862 76092341 CERAMIC DISC, 2KV R 470PF K C863 76503045 PLASTIC FILM, 63V 0.22UF J C866 76503053 PLASTIC FILM, 63V 1UF J C867 76591472 PLASTIC FILM, 50V 4700PF J C868 76669470 ELECTROLYTIC, 50V 47UF M 3A C869 76678229 ELECTROLYTIC, 200V 2.2UF M 3A C870 76503565 PLASTIC FILM, 800V 0.1UF H C871 76092343 CERAMIC DISC, 2KV 680PF K C873 76503045 PLASTIC FILM, 63V 0.22UF J C874 76092337 CERAMIC DISC, 2KV 220PF K C876 76503049 PLASTIC FILM, 63V 0.47UF J C877 76092344 CERAMIC DISC, 2KV 820PF K C879 76214102 CERAMIC DISC, 500V B 1000PF K C880 76092339 CERAMIC DISC, 2KV 330PF K C881 76092339 CERAMIC DISC, 2KV 330PF K C884 76086916 ELECTROLYTIC, 160V 330UF M 3D C885 76668102 ELECTROLYTIC, 35V 1000UF M 3A C888 76503045 PLASTIC FILM, 63V 0.22UF J C891 76073155 ELECTROLYTIC, 16V 1000UF M 3A C892 76073155 ELECTROLYTIC, 16V 1000UF M 3A C893 76073141 ELECTROLYTIC, 10V 1000UF M 3A C898 76092730 CERAMIC CHIP, 16V B 0.1UF K C901 76211102 CERAMIC DISC, 2KV B 1000PF K C902 76794101 ELECTROLYTIC, 16V 100UF M C903 76232103 CERAMIC DISC, 50V F 0.01UF Z C904 76109471 CERAMIC CHIP, 50V B 470PF K C906 76679220 ELECTROLYTIC, 250V 22UF M 3A C907 76214101 CERAMIC DISC, 500V B 100PF K C911 76211102 CERAMIC DISC, 2KV B 1000PF K C912 76794101 ELECTROLYTIC, 16V 100UF M C913 76232103 CERAMIC DISC, 50V F 0.01UF Z C914 76109471 CERAMIC CHIP, 50V B 470PF K C915 76679220 ELECTROLYTIC, 250V 22UF M 3A C917 76214101 CERAMIC DISC, 500V B 100PF K C921 76211102 CERAMIC DISC, 2KV B 1000PF K C922 76794101 ELECTROLYTIC, 16V 100UF M C923 76109471 CERAMIC CHIP, 50V B 470PF K C924 76232103 CERAMIC DISC, 50V F 0.01UF Z C925 76679220 ELECTROLYTIC, 250V 22UF M 3A C926 76214101 CERAMIC DISC, 500V B 100PF K C934 76092731 CERAMIC CHIP, 16V B 1UF K C944 76092542 CERAMIC CHIP, 16V B 1UF K C954 76092731 CERAMIC CHIP, 16V B 1UF K C961 76763101 ELECTROLYTIC, 16V 100UF M C962 76203100 ELECTORLYTIC, 16V 10UF M 7L 3A C4430 76073034 ELECTROLYTIC, 16V 10UF M 3A C7101 76797470 ELECTROLYTIC, 50V 47UF M C7102 76109103 CERAMIC CHIP, 50V B 0.01UF K C7103 76206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A C7104 76108330 CERAMIC CHIP, 50V SL 33PF J C7105 76092730 CERAMIC CHIP, 16V B 0.1UF K C7106 76797470 ELECTROLYTIC, 50V 47UF M C7107 76790470 ELECTROLYTIC, 160V 47UF M C7108 76214472 CERAMIC DISC, 500V B 4700PF K

Location Parts No. Description

No.

C7109 76214472 CERAMIC DISC, 500V B 4700PF K C7110 76666470 ELECTORLYTIC, 16V 47UF M 3A C7111 76666470 ELECTORLYTIC, 16V 47UF M 3A C7112 76435560 CERAMIC DISC, 500V SL 56PF J C7113 76790100 ELECTROLYTIC, 160V 10UF M C7114 76092730 CERAMIC CHIP, 16V B 0.1UF K C7701 76503047 PLASTIC FILM, 63V 0.33UF J C7704 76073053 ELECTROLYTIC, 25V 100UF M 3A C7705 76073037 ELECTROLYTIC, 16V 47UF M 3A C7706 76503047 PLASTIC FILM, 63V 0.33UF J C7722 76105331 CERAMIC CHIP, 50V CH 330PF J C7724 76073091 ELECTROLYTIC, 50V 220UF M 3A C7725 76073091 ELECTROLYTIC, 50V 220UF M 3A C7727 76105331 CERAMIC CHIP, 50V CH 330PF J C7730 76105331 CERAMIC CHIP, 50V CH 330PF J C7733 76105331 CERAMIC CHIP, 50V CH 330PF J C7735 76073091 ELECTROLYTIC, 50V 220UF M 3A C7736 76073091 ELECTROLYTIC, 50V 220UF M 3A C7738 76105331 CERAMIC CHIP, 50V CH 330PF J C7741 76105331 CERAMIC CHIP, 50V CH 330PF J C7750 76073015 ELECTROLYTIC, 10V 47UF M 3A C7751 76073089 ELECTROLYTIC, 50V 47UF M 3A C7752 76073089 ELECTROLYTIC, 50V 47UF M 3A C7753 76073093 ELECTROLYTIC, 50V 470UF M 3A C7761 76073015 ELECTROLYTIC, 10V 47UF M 3A C7762 76073015 ELECTROLYTIC, 10V 47UF M 3A C7765 76667220 ELECTROLYTIC, 25V 22UF M 3A C7784 76667220 ELECTROLYTIC, 25V 22UF M 3A C7785 76092730 CERAMIC CHIP, 16V B 0.1UF K C7786 76092730 CERAMIC CHIP, 16V B 0.1UF K C7800 76666220 ELECTROLYTIC, 16V 22UF M 3A CB01 24794470 ELECTROLYTIC, 16V 47UF M CB51 24590103 PLASTIC FILM, 50V 0.01UF J CB52 24794470 ELECTROLYTIC, 16V 47UF M CB53 24503041 PLASTIC FILM , 63V 0.1UF J CB54 24436221 CERAMIC DISC, 50V SL 220PF J CB55 24797010 ELECTROLYTIC, 50V 1UF M CB56 24794470 ELECTROLYTIC, 16V 47UF M CB58 24794470 ELECTROLYTIC, 16V 47UF M CB59 24590103 PLASTIC FILM, 50V 0.01UF J CB60 24794100 ELECTROLYTIC, 16V 10UF M CB61 24503041 PLASTIC FILM , 63V 0.1UF J CB504 76794100 ELECTROLYTIC, 16V 10UF M CB505 76590104 CERAMIC DISC, 50V 0.1UF J CV14 76212102 CERAMIC DISC, 50V B 1000PF K CV27 76762471 ELECTROLYTIC, 10V 470UF M CV29 76763101 ELECTROLYTIC, 16V 100UF M CV30 76232103 CERAMIC DISC, 50V F 0.01UF Z CV38 76212102 CERAMIC DISC, 50V B 1000PF K CV39 76212102 CERAMIC DISC, 50V B 1000PF K Z450 76083014 CR-BLOCK, TPA5011AH

RESISTORS

R240 76367153 CARBON FILM, 1/6W 15K OHM G R241 76367183 CARBON FILM, 1/6W 18K OHM G R242 76367183 CARBON FILM, 1/6W 18K OHM G R243 76367273 CARBON FILM, 1/6W 27K OHM G R244 76366124 CARBON FILM, 1/6W 120K OHM J R245 76366472 CARBON FILM, 1/6W 4.7K OHM J R246 76366472 CARBON FILM, 1/6W 4.7K OHM J R247 76366102 CARBON FILM, 1/6W 1K OHM J R249 76366104 CARBON FILM, 1/6W 100K OHM J R264 76366750 CARBON FILM, 1/6W 75 OHM J R265 76366750 CARBON FILM, 1/6W 75 OHM J R266 76366750 CARBON FILM, 1/6W 75 OHM J R286 76366750 CARBON FILM, 1/6W 75 OHM J R287 76366750 CARBON FILM, 1/6W 75 OHM J R288 76366750 CARBON FILM, 1/6W 75 OHM J R302 76366101 CARBON FILM, 1/6W 100 OHM J R305 76322109 OXIDE METAL FILM, 1W 1 OHM J R306 76011822 CHIP, 1/20W 8.2K OHM J R307 76011101 CHIP, 1/20W 100 OHM J R308 76011101 CHIP, 1/20W 100 OHM J R311 76366563 CARBON FILM, 1/6W 56K OHM J R312 76011123 CHIP, 1/20W 12K OHM J R313 76011102 CHIP, 1/20W 1K OHM J

– 24 –

Location Parts No. Description

No.

R314 76011473 CHIP, 1/20W 47K OHM J R315 76011681 CHIP, 1/20W 680 OHM J R321 76011472 CHIP, 1/20W 4.7K OHM J R322 76011101 CHIP, 1/20W 100 OHM J R325 76011472 CHIP, 1/20W 4.7K OHM J R330 76000633 METAL FILM, 1/4W 10K OHM F R331 76000633 METAL FILM, 1/4W 10K OHM F R334 76011102 CHIP, 1/20W 1K OHM J R335 76011102 CHIP, 1/20W 1K OHM J R336 76011102 CHIP, 1/20W 1K OHM J R337 76321129 OXIDE METAL FILM, 1/2W 1.2 OHM J R338 76011153 CHIP, 1/2OW 15K OHM J R340 76366103 CARBON FILM, 1/6W 10K OHM J R341 76011183 CHIP, 1/20W 18K OHM J R343 76011102 CHIP, 1/20W 1K OHM J R344 76382151 OXIDE METAL FILM, 1W 150 OHM J R345 76000445 CHIP JUMPER, 1608TYPE R346 76382391 OXIDE METAL FILM, 1W 390 OHM J R348 76011473 CHIP, 1/20W 47K OHM J R349 76011392 CHIP, 1/20W 3.9K OHM J R350 76011123 CHIP, 1/20W 12K OHM J R355 76366103 CARBON FILM, 1/6W 10K OHM J R360 76011562 CHIP, 1/20W 5.6K OHM J R361 76011104 CHIP, 1/20W 100K OHM J R362 76011473 CHIP, 1/20W 47K OHM J R363 76011103 CHIP, 1/20W 10K OHM J R364 76011331 CHIP, 1/20W 330 OHM J R365 76011682 CHIP, 1/20W 6.8K OHM J R366 76366222 CARBON FILM, 1/6W 2.2K OHM J R367 76011392 CHIP, 1/20W 3.9K OHM J R369 76366103 CARBON FILM, 1/6W 10K OHM J R370 76366102 CARBON FILM, 1/6W 1K OHM J R371 76011823 CHIP, 1/20W 82K OHM J R372 76011332 CHIP, 1/20W 3.3K OHM J R373 76011823 CHIP, 1/20W 82K OHM J R374 76011104 CHIP, 1/20W 100K OHM J R375 76011153 CHIP, 1/2OW 15K OHM J R376 76011333 CHIP, 1/20W 33K OHM J R378 76011103 CHIP, 1/20W 10K OHM J R390 76382561 OXIDE METAL FILM, 1W 560 OHM J R391 76382561 OXIDE METAL FILM, 1W 560 OHM J R392 76382561 OXIDE METAL FILM, 1W 560 OHM J R403 76553101 OXIDE METAL FILM, 1W 100 OHM J R404 76011182 CHIP, 1/20W 1.8K OHM J R405 76366101 CARBON FILM, 1/6W 100 OHM J R406 76382682 OXIDE METAL FILM, 1W 6.8K OHM J R407 76381100 OXIDE METAL FILM, 1/2W 10 OHM J R409 76555220 OXIDE METAL FILM, 3W 22 OHM J R410 76555220 OXIDE METAL FILM, 3W 22 OHM J R411 76323229 OXIDE METAL FILM, 2W 2.2 OHM J R412 76383153 OXIDE METAL FILM, 2W 15K OHM J R413 76366101 CARBON FILM, 1/6W 100 OHM J R414 76019259 FUSIBLE, 1/4W 27 OHM G R415 76011102 CHIP, 1/20W 1K OHM J R416 76383151 OXIDE METAL FILM, 2W 150 OHM J R417 76366222 CARBON FILM, 1/6W 2.2K OHM J R418 76011103 CHIP, 1/20W 10K OHM J R419 76011103 CHIP, 1/20W 10K OHM J R420 76366103 CARBON FILM, 1/6W 10K OHM J R421 76366223 CARBON FILM, 1/6W 22K OHM J R422 76011223 CHIP, 1/20W 22K OHM J R423 76942102 CARBON COMPOSITION, 1/2W 1K OHM J R424 76376104 CARBON FILM, 1/2W 100K OHM J R425 76376104 CARBON FILM, 1/2W 100K OHM J R426 76366101 CARBON FILM, 1/6W 100 OHM J R427 76011101 CHIP, 1/20W 100 OHM J R428 76377224 CARBON FILM, 1W 220K OHM J R429 76942102 CARBON COMPOSITION, 1/2W 1K OHM J R431 76383102 OXIDE METAL FILM, 2W 1K OHM J R432 76376274 CARBON FILM, 1/2W 270K OHM J R433 76376274 CARBON FILM, 1/2W 270K OHM J R434 76376274 CARBON FILM, 1/2W 270K OHM J R435 76366332 CARBON FILM, 1/6W 3.3K OHM J R436 76366473 CARBON FILM, 1/6W 47K OHM J R437 76011223 CHIP, 1/20W 22K OHM J R438 76011102 CHIP, 1/20W 1K OHM J

Location Parts No. Description

No.

R439 76011103 CHIP, 1/20W 10K OHM J R440 76011103 CHIP, 1/20W 10K OHM J R441 76533331 FUSIBLE, 2W 330 OHM J R443 76310109 OXIDE METAL FILM, 1/2W 1 OHM J R444 76322398 OXIDE METAL FILM, 1W 0.39 OHM J R446 76011103 CHIP, 1/20W 10K OHM J R447 76382473 OXIDE METAL FILM, 1W 47K OHM J R448 76366562 CARBON FILM, 1/6W 5.6K OHM J R449 76366152 CARBON FILM, 1/6W 1.5K OHM J R466 76366433 CARBON FILM, 1/6W 43K OHM J R467 76011221 CHIP, 1/20W 220 OHM J R469 76011101 CHIP, 1/20W 100 OHM J R470 76322478 OXIDE METAL FILM, 1W 0.47 OHM J R471 76366224 CARBON FILM, 1/6W 220K OHM J R472 76011101 CHIP, 1/20W 100 OHM J R473 76011223 CHIP, 1/20W 22K OHM J R474 76376393 CARBON FILM, 1/2W 39K OHM J R475 76366101 CARBON FILM, 1/6W 100 OHM J R476 76011471 CHIP, 1/20W 470 OHM J R477 76998331 CHIP, 1/16W 330 OHM D R478 76011102 CHIP, 1/20W 1K OHM J R480 76011473 CHIP, 1/20W 47K OHM J R481 76366103 CARBON FILM, 1/6W 10K OHM J R482 76011103 CHIP, 1/20W 10K OHM J R483 76000445 CHIP JUMPER, 1608TYPE R485 76011681 CHIP, 1/20W 680 OHM J R486 76011472 CHIP, 1/20W 4.7K OHM J R487 76552271 OXIDE METAL FILM, 1/2W 270 OHM J R488 76552151 OXIDE METAL FILM, 1/2W 150 OHM J R489 76011102 CHIP, 1/20W 1K OHM J R490 76552331 OXIDE METAL FILM, 1/2W 330 OHM J R491 76011222 CHIP, 1/20W 2.2K OHM J R492 76998102 CHIP, 1/16W 1K OHM R493 76998391 CHIP, 1/16W 390 OHM R494 76998471 CHIP, 1/16W 470 OHM R495 76011333 CHIP, 1/20W 33K OHM J R496 76011103 CHIP, 1/20W 10K OHM J R497 76011100 CHIP, 1/20W 10 OHM J R498 76011103 CHIP, 1/20W 10K OHM J R499 76011102 CHIP, 1/20W 1K OHM J R513 76366101 CARBON FILM, 1/6W 100 OHM J R515 76366103 CARBON FILM, 1/6W 10K OHM J R601 76011822 CHIP, 1/20W 8.2K OHM J R602 76011822 CHIP, 1/20W 8.2K OHM J R603 76011102 CHIP, 1/20W 1K OHM J R604 76011102 CHIP, 1/20W 1K OHM J R609 76011563 CHIP, 1/20W 56K OHM J R610 76011273 CHIP, 1/20W 27K OHM J R611 76011103 CHIP, 1/20W 10K OHM J R612 76011222 CHIP, 1/20W 2.2K OHM J R613 76011223 CHIP, 1/20W 22K OHM J R614 76011103 CHIP, 1/20W 10K OHM J R615 76011104 CHIP, 1/20W 100K OHM J R616 76011822 CHIP, 1/20W 8.2K OHM J R626 76011223 CHIP, 1/20W 22K OHM J R627 76011223 CHIP, 1/20W 22K OHM J R661 76011102 CHIP, 1/20W 1K OHM J R662 76011333 CHIP, 1/20W 33K OHM J R663 76011822 CHIP, 1/20W 8.2K OHM J R665 76011223 CHIP, 1/20W 22K OHM J R666 76011473 CHIP, 1/20W 47K OHM J R667 76011223 CHIP, 1/20W 22K OHM J R668 76011473 CHIP, 1/20W 47K OHM J R671 76011102 CHIP, 1/20W 1K OHM J R672 76011333 CHIP, 1/20W 33K OHM J R673 76011822 CHIP, 1/20W 8.2K OHM J R674 76011472 CHIP, 1/20W 4.7K OHM J R676 76011104 CHIP, 1/20W 100K OHM J R677 76011104 CHIP, 1/20W 100K OHM J R681 76011222 CHIP, 1/20W 2.2K OHM J R682 76011473 CHIP, 1/20W 47K OHM J R683 76011223 CHIP, 1/20W 22K OHM J R684 76011223 CHIP, 1/20W 22K OHM J R687 76011103 CHIP, 1/20W 10K OHM J R688 76011224 CHIP, 1/20W 220K OHM J R693 76000445 CHIP JUMPER, 1608TYPE

– 25 –

Location Parts No. Description

No.

R697 76553221 OXIDE METAL FILM, 1W 220 OHM J R698 76011103 CHIP, 1/20W 10K OHM J R699 76011103 CHIP, 1/20W 10K OHM J R810 #1 76007061 CERAMIC COVERED, 2W 1.8 OHM K

#2 76120001 CEMENT RES 141C 2.1W 1R8 K #3 76120001 CEMENT RES 141C 2.1W 1R8 K

#4 76120001 CEMENT RES 141C 2.1W 1R8 K R818 76011471 CHIP, 1/20W 470 OHM J R819 76011103 CHIP, 1/20W 10K OHM J R840 76552562 OXIDE METAL FILM, 1/2W 5.6K OHM J R841 76011102 CHIP, 1/20W 1K OHM J R842 76376563 CARB0N FILM, 1/2W 56K OHM J R843 76376563 CARB0N FILM, 1/2W 56K OHM J R844 76011103 CHIP, 1/20W 10K OHM J R845 76366102 CARBON FILM, 1/6W 1K OHM J R849 76011101 CHIP, 1/20W 100 OHM J R854 76381150 OXIDE METAL FILM, 1/2W 15 OHM J R860 76383473 OXIDE METAL FILM, 2W 47K OHM J R862 76321689 OXIDE METAL FILM, 1/2W 6.8 OHM J R864 76552102 OXIDE METAL FILM, 1/2W 1K OHM J R865 76552390 OXIDE METAL FILM, 1/2W 39 OHM J R866 76366472 CARBON FILM, 1/6W 4.7K OHM J R867 76366223 CARBON FILM, 1/6W 22K OHM J R868 76552470 OXIDE METAL FILM, 1/2W 47 OHM J R870 76381151 OXIDE METAL FILM, 1/2W 150 OHM J R871 76382680 OXIDE METAL FILM, 1W 68 OHM J R873 76552100 OXIDE METAL FILM, 1/2W 10 OHM J R874 76366150 CARBON FILM, 1/6W 15 OHM J R881 76011102 CHIP, 1/20W 1K OHM J R883 76381102 OXIDE METAL FILM, 1/2W 1K OHM J R885 76366471 CARBON FILM, 1/6W 470 OHM J R893 76011472 CHIP, 1/20W 4.7K OHM J R894 76011103 CHIP, 1/20W 10K OHM J R899 76010001 CARBON FILM, 1/2W 3.9M OHM J R900 76000892 FUSIBLE, 1W 1.2 OHM J R901 76366331 CARBON FILM, 1/6W 330 OHM J R903 76552101 OXIDE METAL FILM, 1/2W 100 OHM J R905 76872180 CHIP, 1/16W 18 OHM J R906 76872271 CHIP, 1/16W 270 OHM J R908 76872560 CHIP, 1/16W 56 OHM J R909 76872270 CHIP, 1/16W 27 OHM J R910 76322568 OXIDE METAL FILM, 1W 0.56 OHM J R911 76366331 CARBON FILM, 1/6W 330 OHM J R913 76552101 OXIDE METAL FILM, 1/2W 100 OHM J R915 76872270 CHIP, 1/16W 27 OHM J R916 76872271 CHIP, 1/16W 270 OHM J R918 76872560 CHIP, 1/16W 56 OHM J R919 76872180 CHIP, 1/16W 18 OHM J R920 76366222 CARBON FILM, 1/6W 2.2K OHM J R921 76366331 CARBON FILM, 1/6W 330 OHM J R923 76552101 OXIDE METAL FILM, 1/2W 100 OHM J R925 76872330 CHIP, 1/16W 33 OHM J R926 76872271 CHIP, 1/16W 270 OHM J R928 76872680 CHIP, 1/16W 68 OHM J R929 76872180 CHIP, 1/16W 18 OHM J R930 76366222 CARBON FILM, 1/6W 2.2K OHM J R931 76568272 CERAMIC COVERED, 7W 2.7K OHM J R938 76366150 CARBON FILM, 1/6W 15 OHM J R944 76568272 CERAMIC COVERED, 7W 2.7K OHM J R945 76366150 CARBON FILM, 1/6W 15 OHM J R948 76366222 CARBON FILM, 1/6W 2.2K OHM J R950 76366222 CARBON FILM, 1/6W 2.2K OHM J R951 76568272 CERAMIC COVERED, 7W 2.7K OHM J R958 76366150 CARBON FILM, 1/6W 15 OHM J R961 76872182 CHIP, 1/16W 1.8K OHM J R962 76872182 CHIP, 1/16W 1.8K OHM J R963 76872100 CHIP, 1/16W 10 OHM J R964 76872332 CHIP, 1/16W 3.3K OHM J R965 76872101 CHIP, 1/16W 100 OHM J R966 76872122 CHIP, 1/16W 1.2K OHM J R967 76872122 CHIP, 1/16W 1.2K OHM J R968 76366222 CARBON FILM, 1/6W 2.2K OHM J R969 76872122 CHIP, 1/16W 1.2K OHM J R970 76872122 CHIP, 1/16W 1.2K OHM J R971 76872152 CHIP, 1/16W 1.5K OHM J R978 76366222 CARBON FILM, 1/6W 2.2K OHM J

Location Parts No. Description

No.

R987 76872101 CHIP, 1/16W 100 OHM J R988 76366222 CARBON FILM, 1/6W 2.2K OHM J R991 76366222 CARBON FILM, 1/6W 2.2K OHM J R992 76366222 CARBON FILM, 1/6W 2.2K OHM J R4430 76381150 OXIDE METAL FILM, 1/2W 15 OHM J R4431 76366102 CARBON FILM, 1/6W 1K OHM J R7102 76872681 CHIP, 1/16W 680 OHM J R7103 76872102 CHIP, 1/16W 1K OHM J R7104 76872102 CHIP, 1/16W 1K OHM J R7105 76871221 CHIP, 1/8W 220 OHM J R7106 76871221 CHIP, 1/8W 220 OHM J R7107 76872101 CHIP, 1/16W 100 OHM J R7108 76872332 CHIP, 1/16W 3.3K OHM J R7109 76872333 CHIP, 1/16W 33K OHM J R7110 76872273 CHIP, 1/16W 27K OHM J R7111 76872333 CHIP, 1/16W 33K OHM J R7112 76872151 CHIP, 1/16W 150 OHM J R7113 76872751 CHIP, 1/16W 750 OHM J R7114 76872681 CHIP, 1/16W 680 OHM J R7115 76871471 CHIP, 1/8W 470 OHM J R7116 76871471 CHIP, 1/8W 470 OHM J R7117 76872101 CHIP, 1/16W 100 OHM J R7118 76872101 CHIP, 1/16W 100 OHM J R7119 76871100 CHIP, 1/8W 10 OHM J R7120 76871100 CHIP, 1/8W 10 OHM J R7121 76871100 CHIP, 1/8W 10 OHM J R7122 76871100 CHIP, 1/8W 10 OHM J R7123 76871100 CHIP, 1/8W 10 OHM J R7124 76871100 CHIP, 1/8W 10 OHM J R7125 76871100 CHIP, 1/8W 10 OHM J R7126 76871100 CHIP, 1/8W 10 OHM J R7127 76552331 OXIDE METAL FILM, 1/2W 330 OHM J R7128 76872751 CHIP, 1/16W 750 OHM J R7129 76872122 CHIP, 1/16W 1.2K OHM J R7130 76872683 CHIP, 1/16W 68K OHM J R7131 76872683 CHIP, 1/16W 68K OHM J R7132 76872751 CHIP, 1/16W 750 OHM J R7133 76872122 CHIP, 1/16W 1.2K OHM J R7134 76872102 CHIP, 1/16W 1K OHM J R7135 76553100 OXIDE METAL FILM, 1W 10 OHM J R7136 76321229 OXIDE METAL FILM, 1/2W 2.2 OHM J R7137 76553100 OXIDE METAL FILM, 1W 10 OHM J R7138 76322229 OXIDE METAL FILM, 1W 2.2 OHM J R7139 76554221 OXIDE METAL FILM, 2W 220 OHM J R7140 76872220 CHIP, 1/16W 22 OHM J R7141 76872220 CHIP, 1/16W 22 OHM J R7701 76011392 CHIP, 1/20W 3.9K OHM J R7702 76000445 CHIP JUMPER, 1608TYPE R7707 76011472 CHIP, 1/20W 4.7K OHM J R7708 76011472 CHIP, 1/20W 4.7K OHM J R7710 76383221 OXIDE METAL FILM, 2W 220 OHM J R7711 76339189 OXIDE METAL FILM, 2W 1.8 OHM J R7712 76011472 CHIP, 1/20W 4.7K OHM J R7713 76011472 CHIP, 1/20W 4.7K OHM J R7715 76383221 OXIDE METAL FILM, 2W 220 OHM J R7716 76339189 OXIDE METAL FILM, 2W 1.8 OHM J R7717 76011472 CHIP, 1/20W 4.7K OHM J R7718 76011472 CHIP, 1/20W 4.7K OHM J R7720 76383221 OXIDE METAL FILM, 2W 220 OHM J R7721 76339189 OXIDE METAL FILM, 2W 1.8 OHM J R7722 76011472 CHIP, 1/20W 4.7K OHM J R7723 76011472 CHIP, 1/20W 4.7K OHM J R7725 76383221 OXIDE METAL FILM, 2W 220 OHM J R7726 76339189 OXIDE METAL FILM, 2W 1.8 OHM J R7727 76011472 CHIP, 1/20W 4.7K OHM J R7728 76011472 CHIP, 1/20W 4.7K OHM J R7730 76383221 OXIDE METAL FILM, 2W 220 OHM J R7731 76339189 OXIDE METAL FILM, 2W 1.8 OHM J R7732 76011472 CHIP, 1/20W 4.7K OHM J R7733 76011472 CHIP, 1/20W 4.7K OHM J R7735 76383221 OXIDE METAL FILM, 2W 220 OHM J R7736 76339189 OXIDE METAL FILM, 2W 1.8 OHM J R7743 76322338 OXIDE METAL FILM, 1W 0.33 OHM J R7744 76322338 OXIDE METAL FILM, 1W 0.33 OHM J R7745 76011101 CHIP, 1/20W 100 OHM J R7746 76011101 CHIP, 1/20W 100 OHM J

– 26 –

Location Parts No. Description

No.

R7747 76011221 CHIP, 1/20W 220 OHM J R7748 76011221 CHIP, 1/20W 220 OHM J R7749 76011102 CHIP, 1/20W 1K OHM J R7750 76011332 CHIP, 1/20W 3.3K OHM J R7751 76011153 CHIP, 1/2OW 15K OHM J R7752 76011822 CHIP, 1/20W 8.2K OHM J R7753 76011101 CHIP, 1/20W 100 OHM J R7754 76011333 CHIP, 1/20W 33K OHM J R7755 76011153 CHIP, 1/2OW 15K OHM J R7756 76011153 CHIP, 1/2OW 15K OHM J R7757 76011681 CHIP, 1/20W 680 OHM J R7758 76011332 CHIP, 1/20W 3.3K OHM J R7760 76011682 CHIP, 1/20W 6.8K OHM J R7761 76011123 CHIP, 1/20W 12K OHM J R7762 76011682 CHIP, 1/20W 6.8K OHM J R7763 76011123 CHIP, 1/20W 12K OHM J R7765 76011103 CHIP, 1/20W 10K OHM J R7766 76366103 CARBON FILM, 1/6W 10K OHM J R7767 76011103 CHIP, 1/20W 10K OHM J R7768 76011103 CHIP, 1/20W 10K OHM J R7769 76011103 CHIP, 1/20W 10K OHM J R7770 76011103 CHIP, 1/20W 10K OHM J R7771 76011103 CHIP, 1/20W 10K OHM J R7772 76011473 CHIP, 1/20W 47K OHM J R7773 76011103 CHIP, 1/20W 10K OHM J R7774 76011103 CHIP, 1/20W 10K OHM J R7801 76383471 OXIDE METAL FILM, 2W 470 OHM J R7802 76383681 OXIDE METAL FILM, 2W 680 OHM J R7880 76011221 CHIP, 1/20W 220 OHM J R7881 76011472 CHIP, 1/20W 4.7K OHM J R7882 76011103 CHIP, 1/20W 10K OHM J R7883 76011103 CHIP, 1/20W 10K OHM J R7884 76011103 CHIP, 1/20W 10K OHM J R7885 76366472 CARBON FILM, 1/6W 4.7K OHM J R7886 76011104 CHIP, 1/20W 100K OHM J R7887 76366103 CARBON FILM, 1/6W 10K OHM J R7890 76011331 CHIP, 1/20W 330 OHM J R7891 76011331 CHIP, 1/20W 330 OHM J R7892 76366472 CARBON FILM, 1/6W 4.7K OHM J R7893 76011472 CHIP, 1/20W 4.7K OHM J R7910 76011221 CHIP, 1/20W 220 OHM J R7911 76011221 CHIP, 1/20W 220 OHM J R7912 76011101 CHIP, 1/20W 100 OHM J R7913 76011101 CHIP, 1/20W 100 OHM J R7931 76000445 CHIP JUMPER, 1608TYPE R9501 76872101 CHIP, 1/16W 100 OHM J R9503 76872122 CHIP, 1/16W 1.2K OHM J R9504 76872122 CHIP, 1/16W 1.2K OHM J R9607 76872101 CHIP, 1/16W 100 OHM J R9608 76872122 CHIP, 1/16W 1.2K OHM J R9609 76872122 CHIP, 1/16W 1.2K OHM J RA71 76366273 CARBON FILM, 1/6W 27K OHM J RA72 76366153 CARBON FILM, 1/6W 15K OHM J RA73 76366822 CARBON FILM, 1/6W 8.2K OHM J RA76 76366822 CARBON FILM, 1/6W 8.2K OHM J RA77 76366153 CARBON FILM, 1/6W 15K OHM J RA78 76366273 CARBON FILM, 1/6W 27K OHM J RA79 76366823 CARBON FILM, 1/6W 82K OHM J RB01 76366391 CARBON FILM, 1/6W 390 OHM J RB04 76366473 CARBON FILM, 1/6W 47K OHM J RB05 76366102 CARBON FILM, 1/6W 1K OHM J RB15 24366471 CARBON FILM, 1/6W 470 OHM J RB19 24366470 CARBON FILM, 1/6W 47 OHM J RB51 24366224 CARBON FILM, 1/6W 220K OHM J RB52 24366123 CARBON FILM, 1/6W 12K OHM J RB53 24366123 CARBON FILM, 1/6W 12K OHM J RB54 24366123 CARBON FILM, 1/6W 12K OHM J RB55 24366224 CARBON FILM, 1/6W 220K OHM J RB56 24366151 CARBON FILM, 1/6W 150 OHM J RB57 24366103 CARBON FILM, 1/6W 10K OHM J RB58 24366103 CARBON FILM, 1/6W 10K OHM J RB59 24366122 CARBON FILM, 1/6W 1.2K OHM J RB60 24366224 CARBON FILM, 1/6W 220K OHM J RB61 24366100 CARBON FILM, 1/6W 10 OHM J RB62 24366272 CARBON FILM, 1/6W 2.7K OHM J RB63 24366271 CARBON FILM, 1/6W 270 OHM J

Location Parts No. Description

No.

RB67 24366221 CARBON FILM, 1/6W 220 OHM J RB69 24366272 CARBON FILM, 1/6W 2.7K OHM J RB70 24366331 CARBON FILM, 1/6W 330 OHM J RB504 76366104 CARBON FILM, 1/6W 100K OHM J RB505 76366101 CARBON FILM, 1/6W 100 OHM J RB506 76366390 CARBON FILM, 1/6W 39 OHM J RB561 76366101 CARBON FILM, 1/6W 100 OHM J RB562 76366104 CARBON FILM, 1/6W 100K OHM J RB563 76366390 CARBON FILM, 1/6W 39 OHM J RB567 76366223 CARBON FILM, 1/6W 22K OHM J RV20 76366750 CARBON FILM, 1/6W 75 OHM J RV21 76366750 CARBON FILM, 1/6W 75 OHM J RV22 76366750 CARBON FILM, 1/6W 75 OHM J RV23 76366101 CARBON FILM, 1/6W 100 OHM J RV33 76366750 CARBON FILM, 1/6W 75 OHM J RV34 76366750 CARBON FILM, 1/6W 75 OHM J RV35 76366750 CARBON FILM, 1/6W 75 OHM J RV36 76366750 CARBON FILM, 1/6W 75 OHM J RV37 76366750 CARBON FILM, 1/6W 75 OHM J RV40 76366750 CARBON FILM, 1/6W 75 OHM J RV61 76366101 CARBON FILM, 1/6W 100 OHM J RV85 76366471 CARBON FILM, 1/6W 470 OHM J RV86 76366471 CARBON FILM, 1/6W 470 OHM J RV89 76366680 CARBON FILM, 1/6W 68 OHM J GJ102 76000445 CHIP JUMPER, 1608TYPE GJ105 76000445 CHIP JUMPER, 1608TYPE GJ107 76000445 CHIP JUMPER, 1608TYPE GJ911 76000445 CHIP JUMPER, 1608TYPE GR31 76000445 CHIP JUMPER, 1608TYPE GR32 76000445 CHIP JUMPER, 1608TYPE GR103 76000445 CHIP JUMPER, 1608TYPE GR601 76000445 CHIP JUMPER, 1608TYPE

COILS & TRANSFORMERS

L302 23248400 COIL, CHOKE, TLN3299D L303 23248400 COIL, CHOKE, TLN3299D L304 23103302 FERRITE CHOKE, TEM2011AH L305 23103307 FERRITE CHOKE, TEM2014AA L310 23289028 COIL, PEAKING, TRF4101AT L401 23289009 COIL, PEAKING, TRF4560AF L402 23248455 COIL, CHOKE, TLN3534AH L403 23103302 FERRITE CHOKE, TEM2011AH L406 23248413 COIL, CHOKE, TLN3351AD L407 23103307 FERRITE CHOKE, TEM2014AA L408 23103307 FERRITE CHOKE, TEM2014AA L441 23233136 COIL, LINEARITY, TLN2222AH L462 23231431 COIL, DEFLECTION YOKE, TDY707RD L463 23231431 COIL, DEFLECTION YOKE, TDY707RD L464 23231431 COIL, DEFLECTION YOKE, TDY707RD L472 23102564 COIL, CPM29.1VM6T, MAG-1136 L473 23102564 COIL, CPM29.1VM6T, MAG-1136 L474 23102564 COIL, CPM29.1VM6T, MAG-1136 L490 23289981 COIL, PEAKING, TRF4330AZ L840 23289025 COIL, PEAKING, TRF4330AT L841 23103304 FERRITE CHOKE, TEM2011AA L850 23103304 FERRITE CHOKE, TEM2011AA L851 23103304 FERRITE CHOKE, TEM2011AA L852 23103304 FERRITE CHOKE, TEM2011AA L854 23103304 FERRITE CHOKE, TEM2011AA L861 23103304 FERRITE CHOKE, TEM2011AA L862 23103304 FERRITE CHOKE, TEM2011AA L864 23103304 FERRITE CHOKE, TEM2011AA L880 23103304 FERRITE CHOKE, TEM2011AA L881 23103304 FERRITE CHOKE, TEM2011AA L885 23248400 COIL, CHOKE, TLN3299D L886 23103304 FERRITE CHOKE, TEM2011AA L887 23103304 FERRITE CHOKE, TEM2011AA L888 23248446 COIL, CHOKE, TLN3462AH L891 23103304 FERRITE CHOKE, TEM2011AA L892 23103304 FERRITE CHOKE, TEM2011AA L893 23103304 FERRITE CHOKE, TEM2011AA L894 23248432 COIL, CHOKE, TLN3499AH L895 23248432 COIL, CHOKE, TLN3499AH L896 23248432 COIL, CHOKE, TLN3499AH L902 23289993 COIL, PEAKING, TRF41R5AF L904 23289989 COIL, PEAKING, TRF4120AF

– 27 –

Location Parts No. Description

No.

L905 23289014 COIL, PEAKING, TRF46R8AF L911 23289996 COIL, PEAKING, TRF4220AF L913 23289993 COIL, PEAKING, TRF41R5AF L915 23289014 COIL, PEAKING, TRF46R8AF L916 23289989 COIL, PEAKING, TRF4120AF L923 23289993 COIL, PEAKING, TRF41R5AF L924 23289989 COIL, PEAKING, TRF4120AF L925 23289014 COIL, PEAKING, TRF46R8AF L7101 23289022 COIL, PEAKING, TRF4100AT L7102 23103304 FERRITE CHOKE, TEM2011AA L7103 23103304 FERRITE CHOKE, TEM2011AA L7104 23103323 FERRITE CORE, HC5-035 L7710 23248400 COIL, CHOKE, TLN3299D L7711 23248400 COIL, CHOKE, TLN3299D LB51 23237987 COIL, PEAKING, TRF4100AC LV13 23289985 COIL, PEAKING, TRF4100AF LV20 23221156 COIL, PEAKING, TRF4560AJ LV36 23289009 COIL, PEAKING, TRF4560AF LV37 23289009 COIL, PEAKING, TRF4560AF T400 23224401 TRANSFORMER, FOCUS, TLN2220AH T401 23224396 TRANSFORMER, TLN1080AH T461A 23192972 ANODE CAP ASSY, TCC5609AT T461Z 23236941 T801 23211836 COIL, LINE FILTER, TRF3197AH T840 23217790 TRANSFORMER, CONVERTER TPW3425BH T862 23217669 TRANSFORMER, CONVERTER TPW3549AS T865 23224392 TRANSFORMER, PULSE TLN2229AH Z801 23103840 FERRITE CORE, TFE1013 ZV60 23103778 FERRITE CORE, TFE1008

SEMICONDUCTORS

Q241 23205342 TRANSISTOR, 2SC2482(F) Q301 23085526 IC, LA7833-S-E Q302 23085309 IC, TA1317ANG Q305 23205346 TRANSISTOR, KTA2014Y/P Q306 23085872 IC, OPE-AMP 14PIN DIP TA75902PG(5,J) Q370 23205347 TRANSISTOR, KTC4075Y/P Q371 23205346 TRANSISTOR, KTA2014Y/P Q372 23205347 TRANSISTOR, KTC4075Y/P Q400 23205370 TRANSISTOR, 2SC4686A(Q) Q402 23205416 TRANSISTOR, FET, 2SK2962(F) Q404 23205405 TRANSISTOR, 2SC5859(FA,Q) Q405 23205346 TRANSISTOR, KTA2014Y/P Q406 23205347 TRANSISTOR, KTC4075Y/P Q408 23205346 TRANSISTOR, KTA2014Y/P Q409 23205347 TRANSISTOR, KTC4075Y/P Q410 23205347 TRANSISTOR, KTC4075Y/P Q411 23205347 TRANSISTOR, KTC4075Y/P Q420 23205342 TRANSISTOR, 2SC2482(F) Q425 23205350 TRANSISTOR, FET, 2SK2920(Q) Q428 23205347 TRANSISTOR, KTC4075Y/P Q470 23205516 TRANSISTOR, 2SA1320(F) Q471 23205347 TRANSISTOR, KTC4075Y/P Q472 23205347 TRANSISTOR, KTC4075Y/P Q473 23205346 TRANSISTOR, KTA2014Y/P Q601 23009603 IC, AN7580 Q612 23205346 TRANSISTOR, KTA2014Y/P Q613 23205347 TRANSISTOR, KTC4075Y/P Q614 23205327 TRANSISTOR, RN1406(F) Q661 23205424 TRANSISTOR, KTC2875B/P Q662 23205424 TRANSISTOR, KTC2875B/P Q663 23085575 IC, OP AMP, BA4558 Q664 23205325 TRANSISTOR, RN2404(F) Q681 23205424 TRANSISTOR, KTC2875B/P Q682 23205424 TRANSISTOR, KTC2875B/P Q711 23205269 TRANSISTOR, VCBO-160V IC-1.5A 2SA2005 Q712 23205270 TRANSISTOR, VCBO 160V 1.5A 2SC5511 Q751 23135074 IC, STK394-250A Q752 23135074 IC, STK394-250A Q765 23205347 TRANSISTOR, KTC4075Y/P Q766 23205347 TRANSISTOR, KTC4075Y/P Q767 23205347 TRANSISTOR, KTC4075Y/P Q768 23205347 TRANSISTOR, KTC4075Y/P Q769 23085560 IC, TA75S393F(F) Q782 23085531 IC, NJM79M05FA Q784 23085424 IC, KIA7805API-U/P

TRANSFORMER, HORIZ OUTPUT, SERVICE, TFB3094ZD

Location Parts No. Description

No.

Q785 23085596 IC, PST994D Q794 23085560 IC, TA75S393F(F) Q795 23085691 IC, TC4066BP(N,F) Q796 23205347 TRANSISTOR, KTC4075Y/P Q801 23135066 IC, STRZ4479 Q840 23085559 IC, MIP280 Q841 23085431 IC, PHOTO COUPLER, PS2581L1(D) Q842 23085431 IC, PHOTO COUPLER, PS2581L1(D) Q843 23205347 TRANSISTOR, KTC4075Y/P Q844 23205347 TRANSISTOR, KTC4075Y/P Q862 23085431 IC, PHOTO COUPLER, PS2581L1(D) Q881 23085524 IC, SE116N, LF4 Q894 23205347 TRANSISTOR, KTC4075Y/P Q901 23205412 TRANSISTOR, 2SC3942 Q902 23205415 TRANSISTOR, 2SC3950E Q911 23205412 TRANSISTOR, 2SC3942 Q912 23205415 TRANSISTOR, 2SC3950E Q913 23205357 TRANSISTOR, KTA1504S Y/P Q921 23205412 TRANSISTOR, 2SC3942 Q922 23205415 TRANSISTOR, 2SC3950E Q961 23205358 TRANSISTOR, KTC3875S Y/P Q962 23205357 TRANSISTOR, KTA1504S Y/P Q973 23205357 TRANSISTOR, KTA1504S Y/P Q4430 23205444 TRANSISTOR, 2SC2236-Y(F) Q7101 23205358 TRANSISTOR, KTC3875S Y/P Q7102 23205358 TRANSISTOR, KTC3875S Y/P Q7103 23085635 IC, 2SC3437-Y(TE85L,F) Q7104 23205312 TRANSISTOR, 2SC1815-GR(F) Q7105 23205358 TRANSISTOR, KTC3875S Y/P Q7106 23205358 TRANSISTOR, KTC3875S Y/P Q7107 23205357 TRANSISTOR, KTA1504S Y/P Q7108 23205358 TRANSISTOR, KTC3875S Y/P Q7109 23205357 TRANSISTOR, KTA1504S Y/P Q7761 23205346 TRANSISTOR, KTA2014Y/P Q7762 23205347 TRANSISTOR, KTC4075Y/P Q7763 23205347 TRANSISTOR, KTC4075Y/P Q7764 23205346 TRANSISTOR, KTA2014Y/P QB01 23205499 TRANSISTOR, KTC3198 Y/P QB51 23319808 IC, M5218AP QB52 23314965 TRANSISTOR, KTC3198 Y QB53 23314962 TRANSISTOR, KTA1266 Y QB502 23205307 TRANSISTOR, 2SA562TM-Y(F) QB508 23205307 TRANSISTOR, 2SA562TM-Y(F) QB509 23205337 TRANSISTOR, 2SC2878-A(TEM) QV48 23205499 TRANSISTOR, KTC3198 Y/P D301 23357755 DIODE, ZENER, MA8075-H D302 23357366 DIODE, FR105-B5 D303 23357872 DIODE, ZENER, MTZJ15C D304 23357917 DIODE, SC570A D305 23357365 DIODE, 1N4004A-B5 D306 23357365 DIODE, 1N4004A-B5 D327 23357861 DIODE, ZENER, MTZJ11A D333 23357861 DIODE, ZENER, MTZJ11A D334 23357861 DIODE, ZENER, MTZJ11A D336 23357745 DIODE, ZENER, MA8056-M D337 23357745 DIODE, ZENER, MA8056-M D365 23357755 DIODE, ZENER, MA8075-H D370 23357703 DIODE, 1SS355 D401 23357510 DIODE, AG01 D402 23357366 DIODE, FR105-B5 D404 23357705 DIODE, ERC06-15 D406 23357366 DIODE, FR105-B5 D411 23357784 DIODE, ZENER, MA8180-M D412 23357694 DIODE, RP1H D413 23357694 DIODE, RP1H D414 23357366 DIODE, FR105-B5 D415 23357366 DIODE, FR105-B5 D418 23357901 DIODE, ZENER, MTZJ33C D419 23357703 DIODE, 1SS355 D420 23357697 DIODE, 1SS133 D421 23357366 DIODE, FR105-B5 D425 23357366 DIODE, FR105-B5 D426 23357784 DIODE, ZENER, MA8180-M D450 23357365 DIODE, 1N4004A-B5 D461 23357701 DIODE, FMQ-3GU D470 23357770 DIODE, ZENER, MA8120-L

– 28 –

Location Parts No. Description

No.

! D490 23357748 DIODE, ZENER, MA8062-M

D491 23357703 DIODE, 1SS355 D492 23357765 DIODE, ZENER, MA8100-M D505 23357893 DIODE, ZENER, MTZJ27C D601 23357703 DIODE, 1SS355 D602 23357703 DIODE, 1SS355 D603 23357703 DIODE, 1SS355 D604 23357703 DIODE, 1SS355 D605 23357703 DIODE, 1SS355 D606 23357703 DIODE, 1SS355 D607 23357703 DIODE, 1SS355 D608 23357703 DIODE, 1SS355 D609 23357703 DIODE, 1SS355 D611 23357703 DIODE, 1SS355 D612 23357703 DIODE, 1SS355 D613 23357703 DIODE, 1SS355 D614 23357703 DIODE, 1SS355 D615 23357703 DIODE, 1SS355 D616 23357703 DIODE, 1SS355 D617 23357703 DIODE, 1SS355 D628 23357771 DIODE, ZENER, MA8120-M D751 23357104 DIODE, 1SS244 D752 23357104 DIODE, 1SS244 D801 23357712 DIODE, D5SB60, 4009 F05 D840 23362046 DIODE, LN1WBA60 4101 D841 23357746 DIODE, ZENER, MA8056-H D842 23357738 DIODE, ZENER, MA8047-L D843 23357366 DIODE, FR105-B5 D844 23357745 DIODE, ZENER, MA8056-M D845 23357703 DIODE, 1SS355 D846 23357684 DIODE, ZENER, RD3.0ESA B2 D847 23357684 DIODE, ZENER, RD3.0ESA B2 D848 23357703 DIODE, 1SS355 D851 23362051 DIODE, D4SBL20U 4100 D852 23357860 DIODE, RL2Z D853 23357860 DIODE, RL2Z D854 23357366 DIODE, FR105-B5 D862 23357366 DIODE, FR105-B5 D864 23357366 DIODE, FR105-B5 D873 23357893 DIODE, ZENER, MTZJ27C D875 23357852 DIODE, ZENER, MTZJ9.1C D876 23357905 DIODE, ZENER, MTZJ36C D878 23357850 DIODE, ZENER, MTZJ9.1A D879 23357893 DIODE, ZENER, MTZJ27C D880 23357828 DIODE, ZENER, MTZJ4.3B D881 23357703 DIODE, 1SS355 D883 23357105 DIODE, RL2 D884 23357105 DIODE, RL2 D885 23362049 DIODE, D4SBS4 4100 D891 23362136 DIODE, YG801C04RF119 D892 23357408 DIODE, FMX-12S(023-108) D893 23357408 DIODE, FMX-12S(023-108) D894 23357703 DIODE, 1SS355 D895 23357748 DIODE, ZENER, MA8062-M D899 76019485 VARISTOR, TNR10V431K D901 23357697 DIODE, 1SS133 D906 23357104 DIODE, 1SS244 D907 23357104 DIODE, 1SS244 D908 23357104 DIODE, 1SS244 D909 23357104 DIODE, 1SS244 D912 23357697 DIODE, 1SS133 D913 23357496 DIODE, 1S1834(Q) D916 23357104 DIODE, 1SS244 D917 23357104 DIODE, 1SS244 D918 23357104 DIODE, 1SS244 D919 23357104 DIODE, 1SS244 D921 23357697 DIODE, 1SS133 D926 23357104 DIODE, 1SS244 D927 23357104 DIODE, 1SS244 D928 23357104 DIODE, 1SS244 D929 23357104 DIODE, 1SS244 D936 23357496 DIODE, 1S1834(Q) D940 23357697 DIODE, 1SS133 D941 23357697 DIODE, 1SS133 D942 23357697 DIODE, 1SS133 D943 23357697 DIODE, 1SS133

Location Parts No. Description

No.

D944 23357697 DIODE, 1SS133 D945 23357697 DIODE, 1SS133 D962 23357748 DIODE, ZENER, MA8062-M D967 23357496 DIODE, 1S1834(Q) D4430 23357365 DIODE, 1N4004A-B5 D4431 23357767 DIODE, ZENER, MA8110-L D7101 23357697 DIODE, 1SS133 D7102 23357697 DIODE, 1SS133 D7730 23357647 DIODE, ZENER, RD6.2ESA B2 D7731 23357647 DIODE, ZENER, RD6.2ESA B2 D7760 23357703 DIODE, 1SS355 D7761 23357629 DIODE, ZENER, RD8.2ESA B2 D7762 23357629 DIODE, ZENER, RD8.2ESA B2 D7763 23357703 DIODE, 1SS355 D7764 23357703 DIODE, 1SS355 D7766 23357703 DIODE, 1SS355 D7790 23357703 DIODE, 1SS355 D7791 23357703 DIODE, 1SS355 D7792 23357703 DIODE, 1SS355 D7793 23357759 DIODE, ZENER, MA8082-M D7806 23357703 DIODE, 1SS355 DB01 23358606 DIODE, LED RED, SLR-56VC3FPQ DB03 23358522 DIODE, LED, SIR-56SB3F DB51 23358573 PHOTO DIODE, PIN 940NM HPI-2FER4 DB52 23118859 DIODE, 1SS133 DB54 23118859 DIODE, 1SS133 DB55 23118859 DIODE, 1SS133 DB56 23118859 DIODE, 1SS133 DB501 23357697 DIODE, 1SS133 DB504 23357697 DIODE, 1SS133

MISCELLANEOUS

A510 23030815 SCREW, WOOD, PTD #6 X 3/4 B231 23738088 SCREW, BTBW3X12ECO B233 23738085 SCREW, BTB4X12 ECO BB10 23713729 SOCKET, B-B 8P 2.5MM BB11 23713729 SOCKET, B-B 8P 2.5MM BB20 23713729 SOCKET, B-B 8P 2.5MM BB21 23713729 SOCKET, B-B 8P 2.5MM BB51A 23965241 TAPE, CC #12 10MM L30M BB60 23713014 PLUG, B-B 16P 1.5 BB70 23713810 PLUG , TAC-A46P-B1 BB100 23368627 BB200 23368627 F470 23144389 FUSE, AXIAL 125V 1.6A F801 23144319 FUSE, CARTRIDGE, 125V 8A, 5.2X20 F801A 23165433 FUSE HOLDER, 5.2 F801B 23165433 FUSE HOLDER, 5.2 F840 23144704 FUSE, AXIAL 125V 200MA F850 23144712 FUSE, AXIAL 125V 3.0A F851 23144714 FUSE, AXIAL 125V 4.0A F852 23144714 FUSE, AXIAL 125V 4.0A F860 23144392 FUSE, AXIAL 125V 3.15A F885 23144715 FUSE, AXIAL 125V 5.0A F891 23144714 FUSE, AXIAL 125V 4.0A F892 23144710 FUSE, AXIAL 125V 2.0A H002 23148378 IF MODULE, US BUFFER 6M TRAP, MVUS51A MF01 23389291 CABLE, FFC P1.25-16-200 MF03 23389290 CABLE, FFC P1.25-29-70 P101 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 P102 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 P404 23713760 PLUG, NP 2.5MM G, B9B-EH-F1A P710 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 P711 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 P712 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 P800 23713702 PLUG, 2P 11.88MM W VT P801 23372209 POWER CORD, U/C FL 125V7A CMC042P JST P880A 23713759 PLUG, 8P 2.5MM G, B8B-EH-F1-TV4 P880B 23713759 PLUG, 8P 2.5MM G, B8B-EH-F1-TV4 P913 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 P915A 23713760 PLUG, NP 2.5MM G, B9B-EH-F1A P915B 23713760 PLUG, NP 2.5MM G, B9B-EH-F1A P917 23713760 PLUG, NP 2.5MM G, B9B-EH-F1A P918 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 P919 23713754 PLUG, 3P 2.5MM G, B3B-EH-F1-TV4 PB22 23368578 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4

CONNECTOR, BRIDGE B-B 8P 2.5JST 08TM-2.5FJ-E CONNECTOR, BRIDGE B-B 8P 2.5JST 08TM-2.5FJ-E

– 29 –

Location Parts No. Description

No.

PB51 23368577 PLUG, 3P 2.5MM G, B3B-EH-F1-TV4 PB501 23365772 JACK, EARPHONE, HSJ1406-01-020 PB502 23365772 JACK, EARPHONE, HSJ1406-01-020 PB503 23713776 PLUG, 3P 2.5MM W, S3B-EH PV01 23023311 JACK, PIN 2S6P, LAP5030-0111GC PV02 23023205 JACK, PIN 10P SMK KARI2 PV03 23023211 JACK, PIN 7P SMK KARI04 PV05 23023184 JACK, 1S3P, LAP5100-1502F PV60 23713761 PLUG, NP 2.5MM G, B10B-EH-F1A SA01 23344505 SWITCH, PUSH 1C1P SA02 23344505 SWITCH, PUSH 1C1P SA03 23344505 SWITCH, PUSH 1C1P SA04 23344505 SWITCH, PUSH 1C1P SA05 23344505 SWITCH, PUSH 1C1P SA06 23344505 SWITCH, PUSH 1C1P SA07 23344505 SWITCH, PUSH 1C1P SA09 23344505 SWITCH, PUSH 1C1P SR81 23146590 RELAY, DLS5D1-O(M)0.25W SR82 23146584 RELAY, DC12V, TV5, DG-3 V901A 23903180 SOCKET, ISHM62S-WE ICE V901R #1 23078357 OTHER, COUPLING R

#2 23447326 COUPLING, R

#3 23447981 COUPLING, RS

#4 23447328 COUPLING, R V902A 23903180 SOCKET, ISHM62S-WE ICE V902G #1 23078358 OTHER, COUPLING G

#2 23447324 COUPLING, G

#3 23447982 COUPLING, GS

#4 23447324 COUPLING, G V903A 23903180 SOCKET, ISHM62S-WE ICE V903B #1 23078359 OTHER, COUPLING B

#2 23447327 COUPLING, B

#3 23447983 COUPLING, BS

#4 23447329 COUPLING, B W661 23351242 SPEAKER, 160X160 8-OHM 20W SPK-1424AW

W662 23351242 SPEAKER, 160X160 8-OHM 20W SPK-1424AW

Z101 23103840 FERRITE CORE, TFE1013 Z401 23140203 SPARK GAP, 2.0-3.0KV C-010, AG20PC152F-L3N Z410 23110857 FOCUS PACK, TPA6030 Z450A 23507612 CABLE, ANODE, 400LD FBT-C

PC BOARD ASSEMBLIES

E021Z 23764269 PC BOARD ASSY, BACK/AV PU PD1735E1

E022Z 23764270 PC BOARD ASSY, FRONT-CON PU PD1735E2

E023Z 23764271 PC BOARD ASSY, FRONT-IN PU PD1735E3

E024Z 23764272 PC BOARD ASSY, REMOTE PU PD1735E4

E031Z 23764273 PC BOARD ASSY, CRT/SVM/R PU PD1733G1

E032Z 23764274 PC BOARD ASSY, CRT/SVM/G PU PD1733G2

E033Z 23764275 PC BOARD ASSY, CRT/SVM/B PU PD1733G3

E034Z 23764276 PC BOARD ASSY, SVM/DIV PU PD1733G4

E045Z 23788823 PC BOARD ASSY, IR BLASTER PU PD1289

U001 23148433 SCAN CONVERTER MODUL, MHSU12

U401 23764404 PC BOARD ASSY, DEFPOWER PU PD2201A

U601 23764268 PC BOARD ASSY, IF/AUDIO PU PD1731D2

U711 23764267 PC BOARD ASSY, CONVER PU PD1731D1

US01 23764160 PC BOARD ASSY, SPK/CAPA PU PD2065B

UV02 23148418

ACCESSORIES

A701 #1 23067099 CARTON, CARTON

A703 #1 23946479 PACKING, TOP PACKING

A708 #1 23946478 PACKING, BOTTOM PACKING

A709 #1 23946483 PACKING, BOTTOM TRAY

23151232 SPEAKER, SPK1235, 160X160 65HZ 8 OHM

SCAN CONVERTER MODULE, 05HDMI-01A-G MHDM01A

#2 23067100 CARTON, CARTON

#3 23015197 CARTON, CARTON

#4 23064558 CARTON, CARTON

#2 23946481 PACKING, TOP PACKING

#3 23946500 PACKING, TOP

#4 23946500 PACKING, TOP

#2 23946480 PACKING, BOTTOM PACKING

#3 23946499 PACKING, BOTTOM

#4 23946499 PACKING, BOTTOM

#2 23946187 PACKING, BASE TRAY

#3 23946211 PACKING, BASE TRAY

Location Parts No. Description

No.

#4 23946211 PACKING, BASE TRAY K912 23306626 REMOCON HAND UNIT IR, MTVUSA CT-90232 K913 23306614 REMOCON HAND UNIT KB01 23000852 REMOCON RECEIVER, PIC-37043TE2 Y101 #1 23566643 OWNERS MANUAL, ENGLISH/FRENCH

#2 23566643 OWNERS MANUAL, ENGLISH/FRENCH

#3 23566732 OWNERS MANUAL, ENGLISH

#4 23566643 OWNERS MANUAL, ENGLISH/FRENCH

CABINET PARTS

A001 #1 23429055 CABINET, WOOD

#2 23429091 CABINET, WOOD

#3 23429125 CABINET, WOOD CABINET SHIP

#4 23429125 CABINET, WOOD CABINET SHIP A102 #1 23527268 GRILLE, SPEAKER GRILLE 51 REG

#2 23527269 GRILLE, SPEAKER GRILLE 57 REG

#3 23527279 GRILLE, SPK GRILLE ASSY

#4 23527279 GRILLE, SPK GRILLE ASSY A160 23469228 CASTER, TP50H60 A201 #1 23530779 COVER, BEZEL

#2 23532728 COVER, BEZEL ASSEY

#3 23530796 COVER, BEZEL

#4 23530796 COVER, BEZEL A202 23450649 PANEL, CONTROL ASSY A213 23428187 DOOR A215 23929911 PIECE, SNAP-IN GEAR DAMPER CONNON A222 23929910 PIECE, FILTER A223 23445705 BUTTON, POWER BUTTON A268 #1 23530772 COVER, FRONT COVER

#2 23530770 COVER, FRONT COVER

#3 23530770 COVER, FRONT COVER

#4 23530770 COVER, FRONT COVER A329 #1 23433231 DECORATIVE, PIECE

#2 23433230 DECORATIVE, PIECE

#3 23433233 DECORATIVE, PIECE

#4 23433233 DECORATIVE, PIECE A331 #1 23929897 PIECE, POLE BOTTOM LEFT

#2 23929899 PIECE, POLE BOTTOM LEFT

#3 23929899 PIECE, POLE BOTTOM LEFT

#4 23929899 PIECE, POLE BOTTOM LEFT A332 #1 23929898 PIECE, POLE BOTTOM RIGHT

#2 23929900 PIECE, POLE BOTTOM RIGHT

#3 23929900 PIECE, POLE BOTTOM RIGHT

#4 23929900 PIECE, POLE BOTTOM RIGHT A401 #1 23530781 COVER, BACK COVER

#3 23532525 COVER, BACK COVER

#4 23532525 COVER, BACK COVER A411 #2 23532757 COVER, BACK COVER A421 23530812 COVER, REAR BOARD A424 23429059 CABINET, BACK BOARD A721 #1 23943628 PLYETHLENE COVERING

#2 23943628 PLYETHLENE COVERING

#3 23943033 PLYETHLENE COVERING

#4 23943033 PLYETHLENE COVERING E918 #1 23737008 BOLT

#2 23737007 BOLT

#3 23737007 BOLT

#4 23737007 BOLT E929 23969684 E948 #1 23737008 BOLT

#2 23737007 BOLT

#3 23737007 BOLT

#4 23737007 BOLT E959 23969684 E978 #1 23737008 BOLT

#2 23737007 BOLT

#3 23737007 BOLT

#4 23737007 BOLT E989 23969684 K501 #1 23311088 SCREEN, 51KP LENTICULAR SHEET

#2 23311128 SCREEN, 57KQ LENTICULAR SHEET

#3 23311131 SCREEN, 65KQ LENTICULAR SHEET

#4 23311131 SCREEN, 65KQ LENTICULAR SHEET K502 #1 23311016

#2 23311014

#3 23311010

TAPE, GLASS CLOTH, W/ADHESIVE W=90 T=0.18

SCREEN, 51KN FRESNEL SHEET SCREEN51KN-F SCREEN, 57KN FRESNEL SHEET SCREEN57KN-F SCREEN, 65KN FRESNEL SHEET SCREEN65KN-F

– 30 –

Location Parts No. Description

No.

#4 23311010

K503 #1 23311065 SCREEN, PROTECTOR 51KN SCR-PRO51KN

#2 23311038 SCREEN, PROTECTOR 57KN SCR-PRO57KN #3 23311962 SCREEN, PROTECTOR 65KM SCR-PRO65KM #4 23311962 SCREEN, PROTECTOR 65KM SCR-PRO65KM

K601 #1 23405484 MIRROR, 51WQG 993/720*550 T3

#2 23405409 MIRROR, 57WL MIRROR57WL #3 23405415 MIRROR, 65WL MIRROR65WL #4 23405415 MIRROR, 65WL MIRROR65WL

SCREEN, 65KN FRESNEL SHEET SCREEN65KN-F

Location Parts No. Description

No.

– 31 –

BOTTOM (FOIL) SIDE

SCAN CONVERTER MODUL, MHSU12 (U001)

– 32 – – 33 –

TOP (COMPONENT) SIDE

SCAN CONVERTER MODUL, MHSU12 (U001)

– 34 – – 35 –

C879C867

C868

D862

R868

R873

R864

R874

D881

R883

D885

BOTTOM (FOIL) SIDE

P880A

135 2467

DEFPOWER BOARD PD2201A (U401)

C863

R865

D864

Q801

D875

L864

R871

R870

C862

Q862

Q881

C854

R854

L854

D885A

C885

C898

C874

C888

R881

R885

R881

D854

L887

L886

125V 5A

F885

D893A

D893

C893

L893

C892

L892

L888

L895

L896

D4430

10987 5432

P831A

CCP-3400S

C338

TP-G

TP-V

R305

R475

R466

C463

R483

R467

C483

D334

D327

L310

C316

C370

R467

C483

R484

R480

R484

R480

R491

C315

R330

R331

D309

GR31

D309

R322

GR31

GR32

D308

R322

R325

GR32

D308

R370

R367

C302

C314

R367

Q370

R366

R371

Q370

R364

R371

R372

R364

D365

R373

R372

C371

R378

R373

R378

C371

R374

Q372

R375

Q371

R375

Q371

BB11

R374

R376

456

123

C873

R862

12 14

15 17

T865

D892A

D892

R346

Q301A

C481

C482

R482

C482

C312

R321

Q302

C301

B301

D365

D370

Q372

B803

D873

C869

Q801A

D876

L862

C871

T862

125V 2A

F892

D891A

D891

L891

F891

125V 4A

C891

L894

D306

R380

R355

D333

D337

R338

C330

D337

R308

R307

D336

R347

R340

R311

R379

C308

R306

687

D879

C866

D878

C876

C860

R872

L861

R867

R866

C877

B801

D880

L881

610

D883

C809

125V 3.15A

F860

C870

C810

D884

C881

C884

713119

C880

L880

F852

F851

125V 3A

125V 4A

L851

L852

L850

C851

C850

L885

D851A

D851

F850

C852

D852

D853

C853

B802

C420

L303

L302

C321

C332

D305

D302

R335

Q301

R380

R381

Q341

C334

C331

C328

R381

C331

Q305

R334

C334

R334

C323

C327

R348

R345

R306

C303

BB21

R348

Q341

R338

R342

R345

R341

GR30

R362

R302

R314

PF01A

321

Q305

R350

R481

R360

R349

C309 R361 C362

C309

C311

814

D378

R336

C323

R343

R363

R350

R360

R341

Q306

R362

R361

C362

R314

C311

D301

R477

R313

D303

P405

R429

R425

R424

R423

C415

R427

C422

R427

R435

R426

C325

D304

C320

R363

R368

C340

C361

R365

C361

R315

R312

D301 R477

C318

Q409

D371

R434

R428

Q400

C324

R337

L304

C333

D491

R344

D491

C4430

L305

Q4430

R369

R365

D4431

C310

R499

D450

R499

C491

R498

R7932

Q798

Q409

R7932

R7931

D492

R7931

R498

C497

R496

Q798

R496

LIVE AREA

CAUTION

C802

R860

T802

P802

D801A

D801

SR81

D845

R818

Q843

R819

D844

R845

R487

R488

R470

C425

C426

R431

P403

P402

R392

R391

C416

R413

C401

C402

R403

C805

R842

C811

Q844

Q473

R486

R485

R818

R486

Q844

D470

R485

Q473

D470

R473

R472

Q471

R472

Q471

R476

R849

C473

R478

Q472

R849

Q472

C473

R478

R476

C849

R489

Q470

C496

L490

C490

C412

R411

C423

D414

D461

C443

C444

C440

Q404

Q404A

T401

R249

R810

SR82

R893

D895

R893

Q894

R894

D894

R894

Q894

125V 1.6A

F470

R101

P810

Z401

T400

R433

R432

D412

D413

L442

R442

P401

R390

R4430

R4431

C450

R414

Q406

D411

Q408

D411

R415

Q406

R416

R415

D490

Q405

D490

R493

R495

Q408

R492

R494

R492

R495

R494

R497

Q402

Q405

R497

TE481

TE482

D840

R843

D848

C812

C499

R473

R489

D415

T461

D404

C840

Q841

R844

C846

L840

R474

C417

L441

C468

L403

D420

D505

R513

C448

Q410

D401

R515

R404

Q410

R422

R440

R439

R437

R422

R439

R440

D419

C419

C515

R437

D419

C419

R438

R419

R418

Q411

R417

Q411D418

R418

R419

R438

F801

125V 8A

125V 200mA

F840

R469

Q428

R490

Q428

R412

R441

BLK

WHT

P800

C801

D899

T801

Q840

C843

C814

T840

L407

R410

C449

D426

Q425

D426

L408

R471

C432

R446

R448

R449

R446

L402

C467

AA01

R899

P805B

R840

Q842

R841

C842

R841

C845

D841

D842

D847

C841

D843

L841

D846

C460

D425

R409

L406

C464

23547588

P499

R407

C445

R247

R443

R444

R404

R910

Q420

R420

D406

D421

C446

R421

R436

C405

L401

R240

R243

R244

R248

Q241

R246

P404

R245

R406

C221

– 36 – – 37 –

R405

R242

R241 D402

RB61

RB60

CB55

CB59

RB62

CCP-3400

BOTTOM (FOIL) SIDE

RB51

DB51A

DB51

CB60

RB63

RB54

QB51

RB53

CB52

RB55

CB53

CB51

RB56

IR BLASTER BOARD PD1289 (E045Z)

Q601A

Q601

C681

D601

C681

D605

R609

D605

C607

R610

R609

R610

D609

R626

D609

R626

C605

C602

R604

C602

R604

C606

R603

C601

Q681

R601

R602

R601

R602

C663

R668

R666

C662

GJ105

BOTTOM (FOIL) SIDE

IF/AUDIO BOARD PD1731D2 (U601)

GJ106

GJ104

GJ103

GJ104

GJ103

C109

R153

C109

R150

GJ150

Q152

Q151

R151

GJ151

R151

R152

GJ151

Q153

P105

423

C101

R615

R627

R615

R627

Q682

R614

R682

R683

R684

R614

R683

R684

R611

R613

R611

R613

Q614

R672

R673

Q614

R673

R672

R668

C603

C665

Q663

C665

R662

R663

R662

R663

P881B

27 26 25 24 23 22 21 20 19 18 17 16 15

14 13 12 11 10 9 8 7 6 5 4 3 2 1

Q152

R152

R154

P882B

C110

GR103

GJ170

L104

H002

C107

Q151

GR02

Q154

R155

C105

R155

R154

32V

C105

+5V

SDA

G102

SCL

G101

ADR

C103GR02

D102

H001

C103

AGC

D102

DB03A

DB03

87654

C680

D608

C612

D612

R681

D612

Q612

D615

D617

D615

R671

C604

TP12

GJ101

GJ108

HY01

KB01

CB56

LB51

RB67

QB53

D607

R688

R687

R612

R687

Q612

R661

C661

Q664

R675

D614

QY160

LY105

CY105

DY102

P514

DB56

RB19

RB69

RB70

23547370

R697

CCP-3400

D604

D628

C683

C684

R699

R698

R612

GR601

D611

R661

Q661

R676

R674

Q661

C667

R674

R665

Q664

R677

R667

R675

Q662

D613

R693

GR602

D613

R693

GR602

R174

R173

Q172

GR175

RY160

QY160

CY160

GJ107

RB15

DB55

CB01

CB58

GR601

R676

R665

23547589

32 4

1 2 3

PB51

BB10

11 2

3 4

5 6

R7721

R7718

1 2

BB20

C7730

R7720

87654

R7717

C7729

R7912

C7726

R7712

R7910

R7707

R7910

R7707

C7721

R7913

R7760

R7913

R7761

R7760

Q784A

Q784

C7701

– 38 – – 39 –

Q785

R7701

C7784

R7752

Q7762

R7752

R7746

L7711

R7746

C7765

R7751

Q7761

R7749

R7751

R7743

R7745

L7710

R7745

C7761

CCP-3400

R7731

R7726

R7735

R7736

C7738

R7723

R7728

C7733

C7738

C7733

R7723

R7728

R7730

R7725

C7735

C7752

R7763

Q766

D7791

R7763

D7791

Q766

R7762

C7732

R7722

C7732

R7722

Q752A

C7737

R7727

C7740

D7730

R7732

BOTTOM (FOIL) SIDE

CONVER BOARD PD1731D1 (U711)

R7732

R7890

R7891

R7890

R7911

R7891

R7911

C7706

Q782

R7895

R7893

BB60

R7702

P712

RED

432

R7733

C7741

R7802

Q768

OUT

GND

R7884

Q795

R7892

R7886

R7733

R7767

C7704

P711

R7801

R7767

R7768

Q752

R7886

R7896

R7713

R7716

R7766

C7753

R7769

C7724

Q794

R7887

Q796

D7806

R7880

GREEN

134

C7727

R7715

C7725

Q767

R7765

R7774

R7773

R7774

R7769

R7773

Q769

R7772

R7885

C7800

R7882

R7883

R7882

R7881

R7757

R7755

C7785

R7753

Q7763

R7754

C7786

R7756

Q7764

R7754

C7786

R7756

Q7764

P710

BLUE

321

C7722

R7708

C7722

R7708

R7718

C7730

R7711

R7710

Q751

Q751A

Q767

Q765

D7790

Q765

D7790

Q769

R7771

R7770

R7771

D7793

D7792

C7750

D7760

C7751

C7736

D7731

R7883

C7705

R7750

Q7762

R7748

R7744

R7748

C7762

D7762

R7749

D7763

R7747

R7753

D7761

Q7761

D7763

D7764

D7766

D7764

D7766

R7758

23547589

QB52

DB54

RB58

RB59

CB61

RB57

RB52

CB54

DB52

P880B

P106

D603

D602

D606

D603

D602

D604

D606

D608

C608

C682

Q613

R616

D616

D617

R671

C666

PF03A

GJ102

L105

C108

LY103

L103

LY102

C106

D101

CY102

LY101

L101

C102

PV35

PB22

C7114

Q7104

C7114

R7108

Q7103

R7109

R7107

R7109

C7103

C7106

Q7102

R7110

R7101

Q7101

CRT-D/G

R971

C961

R963

D961

CCP-3400S

R963

Q961

R965

Q961

BOTTOM (FOIL) SIDE

L917

R911

D943

CRT/SVM/G BOARD PD1733G2 (E032Z)

Q912

C943

R7114

R7116

C7105

Q7105

R7113

R7117

R7119

R7120

R7119

R7120

R7112

Q7106

R7123

R7112

Q7106

R7124

Q7108

R7105

R7106

Q7102

R7105

C7102

R7103

R7104

R7110

C7102

R7104

Q7101

L7101

R7102

R971

D962

R7102

D962

R961

R962

D961

C962

R964

R965 P919

SCREEN

GREEN

D942

C9100

R9507

C914

R918

C913

R915

R916

R915

R916

R919

R969

R966

Q962

C944

R969 R966

C944

R987

Q962

Q7109

R7115

R7118

R7114

R7118

Q7109

R7113

R7126

R7133

R7126

R7133

R7125

Q7107

R7123

Q7107

R7121

Q712A

R7121

R7124

R7122

C7111

R7106

R7111

R7141

R7111

R7103

R7141

C7104

GJ911

B902

C911

D919

Q915A

D918

R9086

L916

C9100

C914

G944

Q911

R967

R970

Q911A

R967

R970

R987

D912

R914

P911

C7105

R7116 R7115

Q7105

C7101

P705

D7102

R7132

R7139

R7132

L7103

Q712

R7137

R7134

R7138

R7134

C7109

R7131

C935

V902A

R945

R913

R950

G915

R943

R978

G914

G911

C7113

L7104

L7102

R7140

L913

R948

L915

C7107

C7110

R7135

C7112

Q711

R7130

C7108

C917

D913

D917

D916

Q914

P915B

R944

R7136

Q711A

D7101

R7128

R7129

R7127

123

P901

P909

C915

P916A

23547591

C912

BOTTOM (FOIL) SIDE

SVM/DIV BOARD PD1733G4 (E034Z)

23547591

P706

P703A

P705A

321

CCP-3400S

P704A

P103

78654321

23547767

1234

P102

C698

C699

BOTTOM (FOIL) SIDE

P101

1234

SPK/CAPA BOARD PD2065B (US01)

CCP-3400S

C7005

R7016

Q7005

C7001

C7004

Q7004

C7004

R7008

Q7003

R7019

Q7003

R7012

R7009

R7007

R7012

R7007

R7009

Q7006

C7003

Q7008

C7006

Q7002

R7004

R7010

Q7001

R7010

R7004

CRT-D/R

R7001

L7001

Q7001

CCP-3400S

BOTTOM (FOIL) SIDE

CRT/SVM/R BOARD PD1733G1 (E031Z)

23547591

P913

D941

L907

R901

R995

Q902

R908

C933

C903

R906

R909

C934

R7020

Q7006

Q7008

R7005

RED

D940

R906

R7017

C7005

R7013

R7019

R7020

R7023

R7024

R7005

R7006

C7002

R7003

R7002

SCREEN

C967

C904

R909

R905

Q913

C934

Q913

R7015

R7016

R7014

R7015

D7002

R7018

R7014

Q7005

R7018

Q7009

R7017

R7026

R7033

Q7009

R7033

R7026

R7025

R7023

Q7007

R7022

R7024

R7011

C7002

GJ901

R9085

R9501

Q702A

R7021

R7022

C7011

R7006

R7041

R7011

R7003

C7014

GJ901

B901

D909

D908

Q905A

L904

C967

C904

G934

Q901

R9504

R9503

Q901A

R9503

R9504

D901

R904

C7205

R7216

Q7205

C7214

P703

R7032

R7039

R7032

L7003

Q702

R7037

R7034

R7038

R7034

C7009

R7031

C930

V901A

R938

R903

R992

G905

R933

R968

G904

G901

C7013

L7004

R7040

L902

L905

C7007

C7010

R7035

C7012

L7002

R7030

C7008

C907

D967

D907

D906

Q904

R991

R931

R7036

Q701

Q701A

D7001

R7028

R7029

R7027

P906

P907

P908

C906

P915A

2 1

C902

Q7204

R7208

Q7203

R7207

R7209

R7207

R7209

C7203

Q7208

C7206

Q7202

R7210

R7201

CRT-D/B

CCP-3400S

L911

P918

BOTTOM (FOIL) SIDE

432

D945

L927

R921

Q922

R9620

CRT/SVM/B BOARD PD1733G3 (E033Z)

R928

C953

R7215

C7205

R7214

C7201

R7213

R7214

Q7205

R7218

R7213

R7217

Q7209

R7219

R7226

R7219

R7220

R7225

R7220

R7226

R7212

R7225

Q7207

Q7206

R7223

R7212

R7223

Q7207

R7221

R7224

Q7206

R7224

R7222

Q7208

R7222

R7206

R7205

R7211

R7206

R7211

C7202

R7203

R7204

C7202

R7203

C7204

Q7201

C7204

R7204

GJ903

R7202

GJ903

R7202

L7201

Q7201

B903

BLUE

SCREEN

C921

Q925A

D929

R9028

D944

Q92

C9200

R9620

C9200

C923

R928

C923

C924

R925

R926

R925

R926

R929

R9609

R929

R9608

Q973

C954

R9609

R9608

R9607

Q973

R9607

23547591

P704

R7216

R7215

D7202

R7232

R7239

R7233

Q7209

R7233

L7203

Q722

Q722A

R7237

R7221

C7211

C7209

R7241

D928

L924

G954

Q921

D921

R924

R7234

R7238

R7240

R7231

C936

V903A

R923

L923

R930

G925

R953

R988

G924

L925

Q921A

G921

C922

C7213

L7204

R7234

R7240

R958

D936

D927

Q924

R920

C7207

C7210

R7235

R7230

C926

C7208

P920

D926

R951

R7236

Q721

Q721A

D7201

R7228

R7229

R7227

P903

– 40 – – 41 –

P910

C925

P905

R900

P917

P916B

C7212

L7202

R7230

7654213

PB11

RB01

RB05

RB04

QB01

RA78

SA08

FOCUS

TOUCH

RA79

SA07SA09

ANT/VIDEOEXITCH UPCH DNVOL UP

RA77

B1-V-0

23547592

BOTTOM (FOIL) SIDE

FRONT-CON BOARD PD1735E2 (E022Z)

SA01SA02

RA73

RA72

SA03

RA71

SA04SA06

VOL DNMENUPOW

RA76

BOTTOM (FOIL) SIDE

FRONT IN BOARD PD1735E3 (E023Z)

DB01

DB01A

SA05

P701

S701

B1-V-0

23547592

PV60

79108

PV05

1234

RV23

RV20

RV22

LV20

RV21

CV14

BOTTOM (FOIL) SIDE

RB15

RB19

DB03

DB03A

KB01

DB31

DB05

PB22

DB30

CB01

23547592

B1-V-0

REMOTE BOARD PD1735E4 (E024Z)

QB512

RB562

RB561

RB563

RB558

CB504

QB509

QB508

CB505

1 2

PB503

PB501

DB504

DB501

CV38

RV37

LV37

RV33

LV36

RV36

CV39

RB567

QB513

QB511

QB510

RB559

B1-V-0

BOTTOM (FOIL) SIDE

23547592

PS01

BACK/AV BOARD PD1735E1 (E021Z)

RB506

RB504

RB505

QB502

RV189

PB502

RV35

R266

RV34

RV40

PV01

PV02

R265

R264

PV03

RV185

CV127

QV148

CV130

CV129

LV113

RV161

R286

R287

R288

LV13

CV29

CV30

RV86

RV85

QV48

RV89

CV27

BB70

RV61

– 42 – – 43 –

TERMINAL VIEW OF TRANSISTORS

 2SC5144

2SC5859

 RN2203

RN2201 RN2004 RN1203 RN1204 RN2204 RN1205 RN1202 RN1201

 2SC3852

2SD1763A 2SC1569 2SC4544 2SA1788 2SA1306 2SA1186A

 2SD1554

2SD2253 2SD1556 2SD2553 2SC5143

 2SC752GTM

2SC2482 2SC2655 2SC4721P

 ON4409

 2SC752

2SA562TM 2SA1015 2SC1815 2SC2878 2SC1740S 2SC2120 2SA9335

 2SA1788

– 44 –

SCHEMATIC DIAGRAM

MODEL : 51HC85/57HC85/65HC15/65HC85

WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY

PRECAUTION" AND "PRODUCT SAFETY NOTICE" ON THE MANUAL FOR THIS MODEL.

CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE on the MANUAL for this model. Do not degrade the safety of the receiver through improper servicing.

NOTE:

1. RESISTOR Resistance is shown in ohm [K = 1.000, M = 1.000.000]. All resistors are 1/6W and 5% tolerance

2. CAPACITOR Unless otherwise noted in schematic, all capacitor values less than 1 are expressed in F, and

carbon resistor, unless otherwise noted as the following marks. 1/2R = Metal or Metal oxide of 1/2 watt 1/2S = Carbon compsistion of 1/2 watt 1RF = Fuse resistor of 1 watt 10W = Cement of 10 watt

±10% G = ±2% F = ±1%

K =

the values more than 1 in pF. All capacitors are ceramic 50V, unless otherwise noted as the following marks.

Electolytic capacitor Mylar capacitor

3. The parts indicated with "

4. Voltages read with DIGITAL MULTI-METER from point indicated to chassing ground, using a color bar signal with all controls at normal, line voltage at 220 volts.

5. Waveforms are taken receiving color bar signal with enough sensitivity.

6. Voltage reading shown are nominal values and may vary

" have special characteristics, and should be replaced with identical parts only.

±20% except H.V.

– 45 –

SCHEMATIC DIAGRAM STRUCTURE:

– SPK CONNECTOR Circuit .............................................................................................................. 1/62

– DEF POWER Circuit (1/3) [SHEET - 1/3] ................... 2/62

– (2/3) [SHEET - 2/3] ................... 3/62

– (3/3) [SHEET - 3/3] ................... 4/62

– BACK/AV Circuit .............................................................................................................................. 5/62

– CONV/IF/AUDIO (1/3) [SHEET - 1/3] ................... 6/62

– (2/3) [SHEET - 2/3] ................... 7/62

– (3/3) [SHEET - 3/3] ................... 8/62

– CONVER OUT Circuit ...................................................................................................................... 9/62

– FRONT IN/CONT Circuit ............................................................................................................... 10/62

– IR BLASTER Circuit ....................................................................................................................... 11/62

– CRT-D Circuit (1/2) [SHEET - 1/2] ................. 12/62

– (2/2) [SHEET - 2/2] ................. 13/62

– AV Circuit (1/10) [SHEET - 1/10] ............... 14/62

– (2/10) [SHEET - 2/10] ............... 15/62

– (3/10) [SHEET - 3/10] ............... 16/62

– (4/10) [SHEET - 4/10] ............... 17/62

– (5/10) [SHEET - 5/10] ............... 18/62

– (6/10) [SHEET - 6/10] ............... 19/62

– (7/10) [SHEET - 7/10] ............... 20/62

– (8/10) [SHEET - 8/10] ............... 21/62

– (9/10) [SHEET - 9/10] ............... 22/62

– (10/10) [SHEET - 10/10] ............. 23/62

– MICOM Circuit HYPER SIGNAL (1/10) [ SHEET - 1/10] .............. 24/62

– (2/10) [SHEET - 2/10] ............... 25/62

– (3/10) [SHEET - 3/10] ............... 26/62

– (4/10) [SHEET - 4/10] ............... 27/62

– (5/10) [SHEET - 5/10] ............... 28/62

– (6/10) [SHEET - 6/10] ............... 29/62

– (7/10) [SHEET - 7/10] ............... 30/62

– (8/10) [SHEET - 8/10] ............... 31/62

– (9/10) [SHEET - 9/10] ............... 32/62

– (10/10) [SHEET - 10/10] ............. 33/62

– G-HYPER Circuit (1/3) [SHEET - 1/3] ................. 34/62

– (2/3) [SHEET - 2/3] ................. 35/62

– (3/3) [SHEET - 3/3] ................. 36/62

– AD-CONVERTER Circuit (A) [ SHEET - 1/3] ................ 37/62

– (B) [SHEET - 2/3] ................. 38/62

– (C) [SHEET - 3/3] ................. 39/62

– GC-TC90A92A Circuit (1/3) [ SHEET - 1/3] ................ 40/62

– (2/3) [SHEET - 2/3] ................. 41/62

– (3/3) [SHEET - 3/3] ................. 42/62

– GC-REG Circuit .............................................................................. 43/62

– GNESIS Circuit (1/3) [SHEET - 1/3] ................. 44/62

– (2/3) [SHEET - 2/3] ................. 45/62

– (3/3) [SHEET - 3/3] ................. 46/62

– SDRAM Circuit ............................................................................... 47/62

GNESIS OUT Circuit ...................................................................... 48/62

–

– GNESIS REG Circuit ...................................................................... 49/62

– CPU Circuit .................................................................................... 50/62

– DIGITAL CONVER Circuit (1/8) [SHEET - 1/8] ................. 51/62

– (2/8) [SHEET - 2/8] ................. 52/62

– (3/8) [SHEET - 3/8] ................. 53/62

– (4/8) [SHEET - 4/8] ................. 54/62

– (5/8) [SHEET - 5/8] ................. 55/62

– (6/8) [SHEET - 6/8] ................. 56/62

– (7/8) [SHEET - 7/8] ................. 57/62

– (8/8) [SHEET - 8/8] ................. 58/62

– CONVER-REG Circuit (1/4) [SHEET - 1/4] ................. 59/62

– (2/4) [SHEET - 2/4] ................. 60/62

– (3/4) [SHEET - 3/4] ................. 61/62

– (4/4) [SHEET - 4/4] ................. 62/62

– 46 –

CIRCUIT BLOCK DIAGRAM

– 47 – – 48 –

279.4

Toshiba 51HC85, 57HC85, 65HC15, 65HC85 Schematic

Specifications and Main Features

Frequently Asked Questions

User Manual
